TEXAS INSTRUMENTS PCI1520 Technical data

l

查询PCI1520供应商

 

  

Data Manua

March 2004 PCIBus Solutions

SCPS065D

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,
enhancements, improvements, and other changes to its products and services at any time and to discontinue
any product or service without notice. Customers should obtain the latest relevant information before placing
orders and should verify that such information is current and complete. All products are sold subject to TI’s terms
and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI
deems necessary to support this warranty . Except where mandated by government requirements, testing of all
parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for
their products and applications using TI components. To minimize the risks associated with customer products
and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right,
copyright, mask work right, or other TI intellectual property right relating to any combination, machine, or process
in which TI products or services are used. Information published by TI regarding third-party products or services
does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.
Use of such information may require a license from a third party under the patents or other intellectual property
of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without
alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction
of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for
such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that
product or service voids all express and any implied warranties for the associated TI product or service and
is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Following are URLs where you can obtain information on other Texas Instruments products and application
solutions:

Products Applications

Amplifiers amplifier.ti.com Audio www.ti.com/audio
Data Converters dataconverter.ti.com Automotive www.ti.com/automotive

DSP dsp.ti.com Broadband www.ti.com/broadband
Interface interface.ti.com Digital Control www.ti.com/digitalcontrol
Logic logic.ti.com Military www.ti.com/military
Power Mgmt power.ti.com Optical Networking www.ti.com/opticalnetwork
Microcontrollers microcontroller.ti.com Security www.ti.com/security

Telephony www.ti.com/telephony
Video & Imaging www.ti.com/video
Wireless www.ti.com/wireless

Mailing Address: Texas Instruments

Post Office Box 655303 Dallas, Texas 75265

Copyright  2004, Texas Instruments Incorporated

Contents

Section Title Page

1 Introduction 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Description 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Features 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Related Documents 1−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Trademarks 1−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.5 Ordering Information 1−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.6 PCI1520 Data Manual Document History 1−3. . . . . . . . . . . . . . . . . . . . . . .

2 Terminal Descriptions 2−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Feature/Protocol Descriptions 3−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Power Supply Sequencing 3−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 I/O Characteristics 3−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Clamping Voltages 3−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Peripheral Component Interconnect (PCI) Interface 3−2. . . . . . . . . . . . . .

3.4.1 PCI GRST

3.4.2 PCI Bus Lock (LOCK

3.4.3 Loading Subsystem Identification 3−3. . . . . . . . . . . . . . . . . . . . .

3.5 PC Card Applications 3−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.1 PC Card Insertion/Removal and Recognition 3−4. . . . . . . . . . .

2

3.5.2 P

3.5.3 Zoomed Video Support 3−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.4 Standardized Zoomed-Video Register Model 3−7. . . . . . . . . . .

3.5.5 Internal Ring Oscillator 3−8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.6 Integrated Pullup Resistors 3−8. . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.7 SPKROUT and CAUDPWM Usage 3−9. . . . . . . . . . . . . . . . . . .

3.5.8 LED Socket Activity Indicators 3−10. . . . . . . . . . . . . . . . . . . . . . . .

3.5.9 CardBus Socket Registers 3−10. . . . . . . . . . . . . . . . . . . . . . . . . . .

3.6 Serial-Bus Interface 3−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.6.1 Serial-Bus Interface Implementation 3−11. . . . . . . . . . . . . . . . . . .

3.6.2 Serial-Bus Interface Protocol 3−11. . . . . . . . . . . . . . . . . . . . . . . . .

3.6.3 Serial-Bus EEPROM Application 3−13. . . . . . . . . . . . . . . . . . . . . .

3.6.4 Accessing Serial-Bus Devices Through Software 3−14. . . . . . .

3.7 Programmable Interrupt Subsystem 3−15. . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.1 PC Card Functional and Card Status Change

3.7.2 Interrupt Masks and Flags 3−17. . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.3 Using Parallel IRQ Interrupts 3−17. . . . . . . . . . . . . . . . . . . . . . . . .

3.7.4 Using Parallel PCI Interrupts 3−18. . . . . . . . . . . . . . . . . . . . . . . . .

C Power-Switch Interface (TPS222X) 3−4. . . . . . . . . . . . . . .

Interrupts 3−15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Signal 3−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

) 3−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

iii

3.7.5 Using Serialized IRQSER Interrupts 3−18. . . . . . . . . . . . . . . . . . .

3.7.6 SMI Support in the PCI1520 3−18. . . . . . . . . . . . . . . . . . . . . . . . . .

3.8 Power Management Overview 3−19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.1 Integrated Low-Dropout Voltage Regulator (LDO-VR) 3−19. . . .

3.8.2 Clock Run Protocol 3−19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.3 CardBus PC Card Power Management 3−20. . . . . . . . . . . . . . . .

3.8.4 16-Bit PC Card Power Management 3−20. . . . . . . . . . . . . . . . . . .

3.8.5 Suspend Mode 3−20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.6 Requirements for Suspend Mode 3−21. . . . . . . . . . . . . . . . . . . . .

3.8.7 Ring Indicate 3−21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.8 PCI Power Management 3−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.9 CardBus Bridge Power Management 3−23. . . . . . . . . . . . . . . . . .

3.8.10 ACPI Support 3−24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.8.11 Master List of PME

Context Bits and Global

Reset-Only Bits 3−25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 PC Card Controller Programming Model 4−1. . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 PCI Configuration Registers (Functions 0 and 1) 4−1. . . . . . . . . . . . . . . . .

4.2 Vendor ID Register 4−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.3 Device ID Register 4−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.4 Command Register 4−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.5 Status Register 4−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.6 Revision ID Register 4−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.7 PCI Class Code Register 4−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.8 Cache Line Size Register 4−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.9 Latency Timer Register 4−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.10 Header Type Register 4−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.11 BIST Register 4−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.12 CardBus Socket/ExCA Base-Address Register 4−7. . . . . . . . . . . . . . . . . .

4.13 Capability Pointer Register 4−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.14 Secondary Status Register 4−8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.15 PCI Bus Number Register 4−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.16 CardBus Bus Number Register 4−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.17 Subordinate Bus Number Register 4−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.18 CardBus Latency Timer Register 4−10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.19 Memory Base Registers 0, 1 4−10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.20 Memory Limit Registers 0, 1 4−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.21 I/O Base Registers 0, 1 4−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.22 I/O Limit Registers 0, 1 4−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.23 Interrupt Line Register 4−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.24 Interrupt Pin Register 4−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.25 Bridge Control Register 4−14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.26 Subsystem Vendor ID Register 4−15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.27 Subsystem ID Register 4−15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.28 PC Card 16-Bit I/F Legacy-Mode Base Address Register 4−15. . . . . . . . .

iv

4.29 System Control Register 4−16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.30 Multifunction Routing Register 4−19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.31 Retry Status Register 4−21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.32 Card Control Register 4−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.33 Device Control Register 4−23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.34 Diagnostic Register 4−24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.35 Capability ID Register 4−25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.36 Next-Item Pointer Register 4−25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.37 Power-Management Capabilities Register 4−26. . . . . . . . . . . . . . . . . . . . . .

4.38 Power-Management Control/Status Register 4−27. . . . . . . . . . . . . . . . . . . .

4.39 Power-Management Control/Status Register Bridge

Support Extensions 4−28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.40 Power-Management Data Register 4−28. . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.41 General-Purpose Event Status Register 4−29. . . . . . . . . . . . . . . . . . . . . . . .

4.42 General-Purpose Event Enable Register 4−30. . . . . . . . . . . . . . . . . . . . . . .

4.43 General-Purpose Input Register 4−31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.44 General-Purpose Output Register 4−32. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.45 Serial-Bus Data Register 4−32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.46 Serial-Bus Index Register 4−33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.47 Serial-Bus Slave Address Register 4−33. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.48 Serial-Bus Control and Status Register 4−34. . . . . . . . . . . . . . . . . . . . . . . . .

5 ExCA Compatibility Registers (Functions 0 and 1) 5−1. . . . . . . . . . . . . . . . . .

5.1 ExCA Identification and Revision Register 5−5. . . . . . . . . . . . . . . . . . . . . .

5.2 ExCA Interface Status Register 5−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.3 ExCA Power Control Register 5−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.4 ExCA Interrupt and General Control Register 5−8. . . . . . . . . . . . . . . . . . .

5.5 ExCA Card Status-Change Register 5−9. . . . . . . . . . . . . . . . . . . . . . . . . . .

5.6 ExCA Card Status-Change Interrupt Configuration Register 5−10. . . . . . .

5.7 ExCA Address Window Enable Register 5−11. . . . . . . . . . . . . . . . . . . . . . . .

5.8 ExCA I/O Window Control Register 5−12. . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.9 ExCA I/O Windows 0 and 1 Start-Address Low-Byte Registers 5−13. . . .

5.10 ExCA I/O Windows 0 and 1 Start-Address High-Byte Registers 5−13. . . .

5.11 ExCA I/O Windows 0 and 1 End-Address Low-Byte Registers 5−14. . . . .

5.12 ExCA I/O Windows 0 and 1 End-Address High-Byte Registers 5−14. . . .

5.13 ExCA Memory Windows 0−4 Start-Address Low-Byte Registers 5−15. . .

5.14 ExCA Memory Windows 0−4 Start-Address High-Byte Registers 5−16. . .

5.15 ExCA Memory Windows 0−4 End-Address Low-Byte Registers 5−17. . . .

5.16 ExCA Memory Windows 0−4 End-Address High-Byte Registers 5−18. . .

5.17 ExCA Memory Windows 0−4 Offset-Address Low-Byte Registers 5−19. .

5.18 ExCA Memory Windows 0−4 Offset-Address High-Byte Registers 5−20.

5.19 ExCA Card Detect and General Control Register 5−21. . . . . . . . . . . . . . . .

5.20 ExCA Global Control Register 5−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.21 ExCA I/O Windows 0 and 1 Offset-Address Low-Byte Registers 5−23. . .

5.22 ExCA I/O Windows 0 and 1 Offset-Address High-Byte Registers 5−23. . .

v

5.23 ExCA Memory Windows 0−4 Page Registers 5−24. . . . . . . . . . . . . . . . . . .

6 CardBus Socket Registers (Functions 0 and 1) 6−1. . . . . . . . . . . . . . . . . . . . . .

6.1 Socket Event Register 6−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.2 Socket Mask Register 6−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.3 Socket Present-State Register 6−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.4 Socket Force Event Register 6−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.5 Socket Control Register 6−8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.6 Socket Power-Management Register 6−9. . . . . . . . . . . . . . . . . . . . . . . . . .

7 Electrical Characteristics 7−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.1 Absolute Maximum Ratings Over Operating Temperature Ranges 7−1.

7.2 Recommended Operating Conditions 7−2. . . . . . . . . . . . . . . . . . . . . . . . . .

7.3 Electrical Characteristics Over Recommended

Operating Conditions 7−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7.4 PCI Clock/Reset Timing Requirements Over Recommended
Ranges of Supply Voltage and Operating Free-Air Temperature 7−3. . .

7.5 PCI Timing Requirements Over Recommended Ranges of

Supply Voltage and Operating Free-Air Temperature 7−4. . . . . . . . . . . . .

8 Mechanical Information 8−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vi

List of Illustrations

Figure Title Page

2−1 PCI1520 GHK-Package Terminal Diagram 2−1. . . . . . . . . . . . . . . . . . . . . . . . . . .

2−2 PCI1520 PDV-Package Terminal Diagram 2−2. . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−1 PCI1520 Simplified Block Diagram 3−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−2 3-State Bidirectional Buffer 3−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−3 TPS222X Typical Application 3−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−4 Zoomed Video Implementation Using the PCI1520 3−6. . . . . . . . . . . . . . . . . . . .

3−5 Zoomed Video Switching Application 3−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−6 Sample Application of SPKROUT and CAUDPWM 3−10. . . . . . . . . . . . . . . . . . . .

3−7 Two Sample LED Circuits 3−10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−8 Serial EEPROM Application 3−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−9 Serial-Bus Start/Stop Conditions and Bit Transfers 3−12. . . . . . . . . . . . . . . . . . . .

3−10 Serial-Bus Protocol Acknowledge 3−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−11 Serial-Bus Protocol − Byte Write 3−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−12 Serial-Bus Protocol − Byte Read 3−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−13 EEPROM Interface Doubleword Data Collection 3−13. . . . . . . . . . . . . . . . . . . . .

3−14 IRQ Implementation 3−18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−15 Signal Diagram of Suspend Function 3−21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−16 RI_OUT

3−17 Block Diagram of a Status/Enable Cell 3−24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−1 ExCA Register Access Through I/O 5−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−2 ExCA Register Access Through Memory 5−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−1 Accessing CardBus Socket Registers Through PCI Memory 6−1. . . . . . . . . . . .

Functional Diagram 3−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vii

List of Tables

Table Title Page

2−1 Signal Names by PDV Terminal Number 2−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−2 Signal Names by GHK Terminal Number 2−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−3 CardBus PC Card Signal Names Sorted Alphabetically 2−7. . . . . . . . . . . . . . . .

2−4 16-Bit PC Card Signal Names Sorted Alphabetically 2−9. . . . . . . . . . . . . . . . . . .

2−5 Power Supply Terminals 2−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−6 PC Card Power Switch Terminals 2−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−7 PCI System Terminals 2−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−8 PCI Address and Data Terminals 2−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−9 PCI Interface Control Terminals 2−14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−10 Multifunction and Miscellaneous Terminals 2−15. . . . . . . . . . . . . . . . . . . . . . . . . .

2−11 16-Bit PC Card Address and Data Terminals (Slots A and B) 2−16. . . . . . . . . .

2−12 16-Bit PC Card Interface Control Terminals (Slots A and B) 2−17. . . . . . . . . . . .

2−13 CardBus PC Card Interface System Terminals (Slots A and B) 2−19. . . . . . . . .

2−14 CardBus PC Card Address and Data Terminals (Slots A and B) 2−20. . . . . . . .

2−15 CardBus PC Card Interface Control Terminals (Slots A and B) 2−21. . . . . . . . .

3−1 PC Card Card-Detect and Voltage-Sense Connections 3−4. . . . . . . . . . . . . . . .

3−2 Power Switch Options 3−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−3 Functionality of the ZV Output Signals 3−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−4 Zoomed-Video Card Interrogation 3−8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−5 Integrated Pullup Resistors 3−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−6 CardBus Socket Registers 3−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−7 Register- and Bit-Loading Map 3−14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−8 PCI1520 Registers Used to Program Serial-Bus Devices 3−15. . . . . . . . . . . . . . .

3−9 Interrupt Mask and Flag Registers 3−16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−10 PC Card Interrupt Events and Description 3−16. . . . . . . . . . . . . . . . . . . . . . . . . . .

3−11 Interrupt Pin Register Cross Reference 3−18. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−12 SMI Control 3−19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−13 Requirements for Internal/External 2.5-V Core Power Supply 3−19. . . . . . . . . .

3−14 Power-Management Registers 3−23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−1 PCI Configuration Registers (Functions 0 and 1) 4−1. . . . . . . . . . . . . . . . . . . . . .

4−2 Bit Field Access Tag Descriptions 4−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−3 Command Register Description 4−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−4 Status Register Description 4−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−5 Secondary Status Register Description 4−8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−6 Interrupt Pin Register Cross-Reference 4−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−7 Bridge Control Register Description 4−14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−8 System Control Register Description 4−17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

viii

4−9 Multifunction Routing Register Description 4−19. . . . . . . . . . . . . . . . . . . . . . . . . . .

4−10 Retry Status Register Description 4−21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−11 Card Control Register Description 4−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−12 Device Control Register Description 4−23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−13 Diagnostic Register Description 4−24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−14 Power-Management Capabilities Register Description 4−26. . . . . . . . . . . . . . . .

4−15 Power-Management Control/Status Register Description 4−27. . . . . . . . . . . . . .

4−16 Power-Management Control/Status Register Bridge Support

Extensions Description 4−28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−17 General-Purpose Event Status Register Description 4−29. . . . . . . . . . . . . . . . . .

4−18 General-Purpose Event Enable Register Description 4−30. . . . . . . . . . . . . . . . .

4−19 General-Purpose Input Register Description 4−31. . . . . . . . . . . . . . . . . . . . . . . . .

4−20 General-Purpose Output Register Description 4−32. . . . . . . . . . . . . . . . . . . . . . .

4−21 Serial-Bus Data Register Description 4−32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−22 Serial-Bus Index Register Description 4−33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−23 Serial-Bus Slave Address Register Description 4−33. . . . . . . . . . . . . . . . . . . . . .

4−24 Serial-Bus Control and Status Register Description 4−34. . . . . . . . . . . . . . . . . . .

5−1 ExCA Registers and Offsets 5−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−2 ExCA Identification and Revision Register Description 5−5. . . . . . . . . . . . . . . . .

5−3 ExCA Interface Status Register Description 5−6. . . . . . . . . . . . . . . . . . . . . . . . . .

5−4 ExCA Power Control Register Description—82365SL Support 5−7. . . . . . . . . .

5−5 ExCA Power Control Register Description—82365SL-DF Support 5−7. . . . . . .

5−6 ExCA Interrupt and General Control Register Description 5−8. . . . . . . . . . . . . .

5−7 ExCA Card Status-Change Register Description 5−9. . . . . . . . . . . . . . . . . . . . . .

5−8 ExCA Card Status-Change Interrupt Configuration

Register Description 5−10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−9 ExCA Address Window Enable Register Description 5−11. . . . . . . . . . . . . . . . . . .

5−10 ExCA I/O Window Control Register Description 5−12. . . . . . . . . . . . . . . . . . . . . .

5−11 ExCA Memory Windows 0−4 Start-Address High-Byte Registers

Description 5−16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−12 ExCA Memory Windows 0−4 End-Address High-Byte Registers

Description 5−18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−13 ExCA Memory Windows 0−4 Offset-Address High-Byte Registers

Description 5−20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−14 ExCA Card Detect and General Control Register Description 5−21. . . . . . . . . .

5−15 ExCA Global Control Register Description 5−22. . . . . . . . . . . . . . . . . . . . . . . . . .

6−1 CardBus Socket Registers 6−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−2 Socket Event Register Description 6−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−3 Socket Mask Register Description 6−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−4 Socket Present-State Register Description 6−4. . . . . . . . . . . . . . . . . . . . . . . . . . .

6−5 Socket Force Event Register Description 6−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−6 Socket Control Register Description 6−8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−7 Socket Power-Management Register Description 6−9. . . . . . . . . . . . . . . . . . . . .

ix

x

1 Introduction

1.1 Description

The Texas Instruments PCI1520, a 208-terminal dual-slot CardBus controller designed to meet the PCI Bus Power
Management Interface Specification for PCI to CardBus Bridges, is an ultralow-power high-performance

PCI-to-CardBus controller that supports two independent card sockets compliant with the PC Card Standard (rev.

7.1). The PCI1520 provides features that make it the best choice for bridging between PCI and PC Cards in both
notebook and desktop computers. The 1997 PC Card Standard retains the 16-bit PC Card specification defined in
PCI Local Bus Specification and defines the new 32-bit PC Card, CardBus, capable of full 32-bit data transfers at
33 MHz. The PCI1520 supports any combination of 16-bit and CardBus PC Cards in the two sockets, powered at
5 V or 3.3 V, as required.

The PCI1520 is compliant with the PCI Local Bus Specification, and its PCI interface can act as either a PCI master
device or a PCI slave device. The PCI bus mastering is initiated during CardBus PC Card bridging transactions. The
PCI1520 is also compliant with PCI Bus Power Management Interface Specification (rev. 1.1).

All card signals are internally buffered to allow hot insertion and removal without external buffering. The PCI1520 is
register-compatible with the Intel 82365SL-DF and 82365SL ExCA controllers. The PCI1520 internal data path logic
allows the host to access 8-, 16-, and 32-bit cards using full 32-bit PCI cycles for maximum performance. Independent
buffering and a pipeline architecture provide an unsurpassed performance level with sustained bursting. The
PCI1520 can also be programmed to accept fast posted writes to improve system-bus utilization.

Multiple system-interrupt signaling options are provided, including parallel PCI, parallel ISA, serialized ISA, and
serialized PCI. Furthermore, general-purpose inputs and outputs are provided for the board designer to implement
sideband functions. Many other features designed into the PCI1520, such as socket activity light-emitting diode (LED)
outputs, are discussed in detail throughout the design specification.

An advanced complementary metal-oxide semiconductor (CMOS) process achieves low system power consumption
while operating at PCI clock rates up to 33 MHz. Several low-power modes enable the host power management
system to further reduce power consumption.

1.2 Features

The PCI1520 supports the following features:

• A 208-terminal low-profile QFP (PDV) or 209-terminal MicroStar BGA ball-grid array (GHK/ZHK) package

• 2.5-V core logic and 3.3-V I/O with universal PCI interfaces compatible with 3.3-V and 5-V PCI signaling

environments

• Integrated low-dropout voltage regulator (LDO-VR) eliminates the need for an external 2.5-V power supply

• Mix-and-match 5-V/3.3-V 16-bit PC Cards and 3.3-V CardBus Cards

• Two PC Card or CardBus slots with hot insertion and removal

• Serial interface to TI TPS222X dual-slot PC Card power switch

• Burst transfers to maximize data throughput with CardBus Cards

• Interrupt configurations: parallel PCI, serialized PCI, parallel ISA, and serialized ISA

• Serial EEPROM interface for loading subsystem ID and subsystem vendor ID

• Pipelined architecture for greater than 130-Mbps throughput from CardBus-to-PCI and from

PCI-to-CardBus

1−1

• Up to five general-purpose I/Os

• Programmable output select for CLKRUN

• Multifunction PCI device with separate configuration space for each socket

• Five PCI memory windows and two I/O windows available for each 16-bit interface

• Two I/O windows and two memory windows available to each CardBus socket

• Exchangeable-card-architecture- (ExCA-) compatible registers are mapped in memory and I/O space

• Intel 82365SL-DF and 82365SL register compatible

• Ring indicate, SUSPEND

, PCI CLKRUN, and CardBus CCLKRUN

• Socket activity LED terminals

• PCI bus lock (LOCK

)

• Advanced quarter-micron, ultralow-power CMOS technology

• Internal ring oscillator

1.3 Related Documents

• Advanced Configuration and Power Interface (ACPI) Specification (revision 1.1)

• PCI Bus Power Management Interface Specification (revision 1.1)

• PCI Bus Power Management Interface Specification for PCI to CardBus Bridges (revision 0.6)

• PCI to PCMCIA CardBus Bridge Register Description (Yenta) (revision 2.1)

• PCI Local Bus Specification (revision 2.2)

• PCI Mobile Design Guide (revision 1.0)

• PC Card Standard (revision 7.1)

• PC 2001

• Serialized IRQ Support for PCI Systems (revision 6)

1.4 Trademarks

Intel is a trademark of Intel Corporation.
TI and MicroStar BGA are trademarks of Texas Instruments.
Other trademarks are the property of their respective owners.

1.5 Ordering Information

ORDERING NUMBER NAME VOLTAGE PACKAGE

PCI1520 PC Card controller 3.3 V, 5-V tolerant I/Os 208-terminal LQFP

209-ball PBGA

PCI1520I PC Card controller,

industrial temperature

1−2

3.3 V, 5-V tolerant I/Os 208-terminal LQFP
209-ball PBGA

1.6 PCI1520 Data Manual Document History

DATE PAGE NUMBER REVISION

01/2003 2−1 Corrected part number typo in the first sentence of the page
01/2003 2−15 Corrected description of EEPROM detection scheme. EEPROM detection happens on

01/2003 3−2 Added new subsection 3.4.1 to describe GRST during power up
12/2003 3−3 Corrected bit description of SUBSYSRW bit in the system control register
01/2003 3−13 Modified byte-read diagram (Figure 3−12) to better reflect a read transaction to the EEPROM
01/2003 3−23 Modified description of power management capabilities register. This register is not a static

01/2003 4−13 Corrected default value for interrupt pin register
01/2003 4−26 Corrected default value for power management capabilities register
01/2003 5−13 Corrected typo on register description for ExCA I/O windows 0 and 1 start-address high-byte

01/2003 5−24 Corrected typo on the bit type for ExCA memory 0−4 page register
01/2003 6−8 Corrected default value for socket control register
01/2003 6−8 Modified description for bit 10 in the socket control register
03/2004 Cover Added ZHK package to document title
03/2004 1−1 Added ZHK package to text
03/2004 2−1 Added ZHK package to text
03/2004 8−1 Added ZHK package to text
03/2004 8−2 Added ZHK mechanical

deassertion of GRST

read-only register.

register

rather than PRST.

1−3

1−4

2 Terminal Descriptions

The PCI1520 is available in three packages, a 208-terminal quad flatpack (PDV) and two 209-terminal MicroStar
BGA packages (GHK/ZHK). The GHK and ZHK packages are mechanically and electrically identical, but the ZHK
is a lead-free (Pb, atomic number 82) design. Throughout the remainder of this manual (except Chapter 8), only the
GHK designator is used for either the GHK or ZHK package. The terminal layout for the GHK package is shown in
Figure 2−1. The terminal layout with signal names for the PDV package is shown in Figure 2−2.

GHK PLASTIC BALL GRID ARRAY (PBGA) PACKAGE

BOTTOM VIEW

W
V
U
T
R
P
N
M
L
K
J
H
G
F
E
D
C
B
A

2

1

75634

18

19171613 14 1511 129810

Figure 2−1. PCI1520 GHK-Package Terminal Diagram

2−1

I)

M

PDV LOW-PROFILE QUAD FLAT PACKAGE

(LQFP)

TOP VIEW

/RI)

)

//A_CD2

156 MFUNC0

155 DATA

154 CLOCK

153 LATCH

152 SPKROUT

151 A_CAD31//A_D10

150 A_RSVD//A_D2

149 A_CAD30//A_D9

148 A_CAD29//A_D1

147 GND

146 A_CAD28//A_D8

145 A_CAD27//A_D0

MFUNC1 157

SUSPEND

MFUNC2 159

MFUNC3/IRQSER 160

MFUNC4 161
MFUNC5 162

FUNC6/CLKRUN 163

RI_OUT

DEVSEL 198

C/BE3 164

/PME 165

GND 166

AD25 167

PRST

GNT

REQ 170
AD31 171
AD30 172
AD11 173

V

CC

AD29 175
AD28 176

GRST

AD27 178
AD26 179
V

CCP

AD24 181

PCLK 182

IDSEL 183

AD23 184

GND 185
AD22 186
AD21 187
AD20 188
AD19 189
AD18 190
AD17 191
AD16 192

C/BE2

FRAME

V

CC

IRDY

TRDY

GND 199

STOP
PERR
SERR

PAR 203

C/BE1

AD15 205
AD14 206
AD13 207
AD12 208

158

168
169

174

177

180

193
194
195
196
197

200
201
202

204

AD9 2

AD10 1

4

AD8 3

AD7 5

AD6 7

AD5 8

GND 6

C/BE0

144 A_CCD2

AD4 9

AD3 10

AD2 11

AD1 12

AD0 13

//A_WAIT

139 A_CSERR

143 VCC142 A_CCLKRUN//A_WP(IOIS16)

141 A_CSTSCHG//A_BVD1(STSCHG

138 A_CINT//A_READY(IREQ)

140 A_CAUDIO//A_BVD2(SPKR

137 A_CVS1//A_VS1

14

CC

V

//B_CD1 15

B_CAD0//B_D3 16

B_CAD3//B_D5 20

B_CAD1//B_D4 18

B_CAD2//B_D11 17

B_CAD4//B_D12 19

B_CCD1

136 A_CAD26//A_A0

135 A_CAD25//A_A1

B_CAD5//B_D6 22

B_CAD6//B_D13 21

134 A_CAD24//A_A2

133 VCC132 A_CC/BE3//A_REG

131 A_CAD23//A_A3

PCI1520

GND 24

B_CAD7//B_D7 25

B_CAD8//B_D15 26

B_RSVD//B_D14 23

//A_INPACK

A_CAD22//A_A4

130 A_CREQ

129

128 VR_PORT

29

VR_EN

//B_CE1 27

B_CAD9//B_A10 28

B_CC/BE0

//A_RESET

125 A_CAD20//A_A6

127 A_CAD21//A_A5

126 A_CRST

30

B_CAD11//B_OE 31

B_CAD12//B_A11 32

B_CAD10//B_CE2

//A_A12

124 A_CVS2//A_VS2

123 A_CAD19//A_A25

122 A_CAD18//A_A7

121 A_CAD17//A_A24

120 A_CC/BE2

33

34

//B_A8 37

B_CAD14//B_A9 35

B_CC/BE1

B_CAD16//B_A17 36

B_CAD13//B_IORD

B_CAD15//B_IOWR

CC

A_CFRAME//A_A23

119

118 V

39

CC

V

B_RSVD//B_A18 38

//A_A22

117 A_CIRDY//A_A15

116 A_CTRDY

//B_A19 41

B_CPAR//B_A13 40

B_CBLOCK

CCA

115 A_CCLK//A_A16

114 V

113 A_CDEVSEL//A_A21

GND 43

//B_A20 44

//B_A14 42

B_CSTOP

B_CPERR

//A_A20

//A_WE

111 A_CSTOP

112 A_CGNT

//B_WE 45

//B_A21 46

B_CGNT

B_CDEVSEL

//A_A14

A_CPERR

110 GND

109

47

CCB

V

B_CCLK//B_A16 48

//A_A19

//A_A8

107 A_CPAR//A_A13

106 A_RSVD//A_A18

105 A_CC/BE1

108 A_CBLOCK

104 A_CAD16//A_A17
103 A_CAD14//A_A9
102 A_CAD15//A_IOWR
101 A_CAD13//A_IORD
100 A_CAD12//A_A11

99 A_CAD11//A_OE
98 A_CAD10//A_CE2
97 A_CAD9//A_A10
96 A_CC/BE0//A_CE1
95 GND
94 A_CAD8//A_D15
93 A_CAD7//A_D7
92 A_RSVD//A_D14
91 V

CC

90 A_CAD5//A_D6
89 A_CAD6//A_D13
88 A_CAD3//A_D5
87 A_CAD4//A_D12
86 A_CAD1//A_D4
85 A_CAD2//A_D11
84 A_CAD0//A_D3
83 A_CCD1
82 B_CAD31//B_D10
81 NC
80 B_RSVD//B_D2
79 B_CAD30//B_D9
78 B_CAD29//B_D1
77

B_CAD28//B_D8
76 B_CAD27//B_D0
75 B_CCD2
74 B_CCLKRUN//B_WP(IOIS16)
73 B_CSTSCHG//B_BVD1(STSCHG
72 B_CAUDIO//B_BVD2(SPKR)
71 B_CSERR
70 V

CC

69 B_CINT
68 B_CVS1//B_VS1
67

B_CAD26//B_A0
66 B_CAD25//B_A1
65 B_CAD24//B_A2
64 B_CC/BE3
63 B_CAD23//B_A3
62 GND
61 B_CREQ
60 B_CAD22//B_A4
59 B_CAD21//B_A5
58 B_CRST

B_CAD20//B_A6

57
56 B_CVS2//B_VS2
55 B_CAD19//B_A25
54 B_CAD18//B_A7
53 B_CAD17//B_A24

//B_A23 51

//B_A12 52

//B_A22 49

B_CIRDY//B_A15 50

B_CTRDY

B_CC/BE2

B_CFRAME

//A_CD1

//B_CD2

/R

//B_WAIT

//B_READY(IREQ)

//B_REG

//B_INPACK

//B_RESET

2−2

Figure 2−2. PCI1520 PDV-Package Terminal Diagram

Table 2−1 and Table 2−2 list the terminal assignments arranged in terminal-number order, with corresponding signal

TERM.

TERM.

TERM.

names for both CardBus and 16-bit PC Cards; Table 2−1 is for terminals on the PDV package and Table 2−2 is for
terminals on the GHK package. Table 2−3 and Table 2−4 list the terminal assignments arranged in alphanumerical
order by signal name, with corresponding terminal numbers for both PDV and GHK packages; Table 2−3 is for
CardBus signal names and Table 2−4 is for 16-bit PC Card signal names.

Terminal E5 on the GHK package is an identification ball used for device orientation; it has no internal connection
within the device.

Table 2−1. Signal Names by PDV Terminal Number

SIGNAL NAME

NO.

10 AD3 AD3 47 V
11 AD2 AD2 48 B_CCLK B_A16 85 A_CAD2 A_D11
12 AD1 AD1 49 B_CTRDY B_A22 86 A_CAD1 A_D4
13 AD0 AD0 50 B_CIRDY B_A15 87 A_CAD4 A_D12
14 V
15 B_CCD1 B_CD1 52 B_CC/BE2 B_A12 89 A_CAD6 A_D13
16 B_CAD0 B_D3 53 B_CAD17 B_A24 90 A_CAD5 A_D6
17 B_CAD2 B_D11 54 B_CAD18 B_A7 91 V
18 B_CAD1 B_D4 55 B_CAD19 B_A25 92 A_RSVD A_D14
19 B_CAD4 B_D12 56 B_CVS2 B_VS2 93 A_CAD7 A_D7
20 B_CAD3 B_D5 57 B_CAD20 B_A6 94 A_CAD8 A_D15
21 B_CAD6 B_D13 58 B_CRST B_RESET 95 GND GND
22 B_CAD5 B_D6 59 B_CAD21 B_A5 96 A_CC/BE0 A_CE1
23 B_RSVD B_D14 60 B_CAD22 B_A4 97 A_CAD9 A_A10
24 GND GND 61 B_CREQ B_INPACK 98 A_CAD10 A_CE2
25 B_CAD7 B_D7 62 GND GND 99 A_CAD11 A_OE
26 B_CAD8 B_D15 63 B_CAD23 B_A3 100 A_CAD12 A_A11
27 B_CC/BE0 B_CE1 64 B_CC/BE3 B_REG 101 A_CAD13 A_IORD
28 B_CAD9 B_A10 65 B_CAD24 B_A2 102 A_CAD15 A_IOWR
29 VR_EN VR_EN 66 B_CAD25 B_A1 103 A_CAD14 A_A9
30 B_CAD10 B_CE2 67 B_CAD26 B_A0 104 A_CAD16 A_A17
31 B_CAD11 B_OE 68 B_CVS1 B_VS1 105 A_CC/BE1 A_A8
32 B_CAD12 B_A11 69 B_CINT B_READY(IREQ) 106 A_RSVD A_A18
33 B_CAD13 B_IORD 70 V
34 B_CAD15 B_IOWR 71 B_CSERR B_WAIT 108 A_CBLOCK A_A19
35 B_CAD14 B_A9 72 B_CAUDIO B_BVD2(SPKR) 109 A_CPERR A_A14
36 B_CAD16 B_A17 73 B_CSTSCHG B_BVD1(STSCHG/RI) 110 GND GND
37 B_CC/BE1 B_A8 74 B_CCLKRUN B_WP(IOIS16) 111 A_CSTOP A_A20

†

Terminal 81 is an NC on the PCI1520 to allow for terminal compatibility with the next generation of devices.

CardBus

PC Card

1 AD10 AD10 38 B_RSVD B_A18 75 B_CCD2 B_CD2
2 AD9 AD9 39 V
3 AD8 AD8 40 B_CPAR B_A13 77 B_CAD28 B_D8
4 C/BE0 C/BE0 41 B_CBLOCK B_A19 78 B_CAD29 B_D1
5 AD7 AD7 42 B_CPERR B_A14 79 B_CAD30 B_D9
6 GND GND 43 GND GND 80 B_RSVD B_D2
7 AD6 AD6 44 B_CSTOP B_A20 81 NC
8 AD5 AD5 45 B_CGNT B_WE 82 B_CAD31 B_D10
9 AD4 AD4 46 B_CDEVSEL B_A21 83 A_CCD1 A_CD1

CC

16-Bit

PC Card

V

CC

NO.

51 B_CFRAME B_A23 88 A_CAD3 A_D5

CardBus

PC Card

SIGNAL NAME

CC

CCB

CC

16-Bit

PC Card

V

CC

V

CCB

V

CC

SIGNAL NAME

NO.

76 B_CAD27 B_D0

84 A_CAD0 A_D3

107 A_CPAR A_A13

CardBus

PC Card

†

CC

16-Bit

PC Card

†

NC

V

CC

2−3

Table 2−1. Signal Names by PDV Terminal Number (Continued)

TERM.

TERM.

TERM.

SIGNAL NAME

NO.

112 A_CGNT A_WE 145 A_CAD27 A_D0 178 AD27 AD27
113 A_CDEVSEL A_A21 146 A_CAD28 A_D8 179 AD26 AD26
114 V
115 A_CCLK A_A16 148 A_CAD29 A_D1 181 AD24 AD24
116 A_CTRDY A_A22 149 A_CAD30 A_D9 182 PCLK PCLK
117 A_CIRDY A_A15 150 A_RSVD A_D2 183 IDSEL IDSEL
118 V
119 A_CFRAME A_A23 152 SPKROUT SPKROUT 185 GND GND
120 A_CC/BE2 A_A12 153 LATCH LATCH 186 AD22 AD22
121 A_CAD17 A_A24 154 CLOCK CLOCK 187 AD21 AD21
122 A_CAD18 A_A7 155 DATA DATA 188 AD20 AD20
123 A_CAD19 A_A25 156 MFUNC0 MFUNC0 189 AD19 AD19
124 A_CVS2 A_VS2 157 MFUNC1 MFUNC1 190 AD18 AD18
125 A_CAD20 A_A6 158 SUSPEND SUSPEND 191 AD17 AD17
126 A_CRST A_RESET 159 MFUNC2 MFUNC2 192 AD16 AD16
127 A_CAD21 A_A5 160 MFUNC3/IRQSER MFUNC3/IRQSER 193 C/BE2 C/BE2
128 VR_PORT VR_PORT 161 MFUNC4 MFUNC4 194 FRAME FRAME
129 A_CAD22 A_A4 162 MFUNC5 MFUNC5 195 V
130 A_CREQ A_INPACK 163 MFUNC6/CLKRUN MFUNC6/CLKRUN 196 IRDY IRDY
131 A_CAD23 A_A3 164 C/BE3 C/BE3 197 TRDY TRDY
132 A_CC/BE3 A_REG 165 RI_OUT/PME RI_OUT/PME 198 DEVSEL DEVSEL
133 V
134 A_CAD24 A_A2 167 AD25 AD25 200 STOP STOP
135 A_CAD25 A_A1 168 PRST PRST 201 PERR PERR
136 A_CAD26 A_A0 169 GNT GNT 202 SERR SERR
137 A_CVS1 A_VS1 170 REQ REQ 203 PAR PAR
138 A_CINT A_READY(IREQ) 171 AD31 AD31 204 C/BE1 C/BE1
139 A_CSERR A_WAIT 172 AD30 AD30 205 AD15 AD15
140 A_CAUDIO A_BVD2(SPKR) 173 AD11 AD11 206 AD14 AD14
141 A_CSTSCHG A_BVD1(STSCHG/

142 A_CCLKRUN A_WP(IOIS16) 175 AD29 AD29 208 AD12 AD12
143 V
144 A_CCD2 A_CD2 177 GRST GRST

CardBus

PC Card

CCA

CC

CC

CC

16-Bit

PC Card

V

CCA

V

CC

V

CC

)

RI

V

CC

NO.

147 GND GND 180 V

151 A_CAD31 A_D10 184 AD23 AD23

166 GND GND 199 GND GND

174 V

176 AD28 AD28

CardBus

PC Card

CC

SIGNAL NAME

16-Bit

PC Card

V

CC

SIGNAL NAME

NO.

207 AD13 AD13

CardBus

PC Card

CCP

CC

16-Bit

PC Card

V

CCP

V

CC

2−4

Table 2−2. Signal Names by GHK Terminal Number

TERM.

TERM.

TERM.

SIGNAL NAME

NO.

A04 AD12 AD12 E07 PERR PERR H06 AD2 AD2
A05 PAR PAR E08 FRAME FRAME H14 A_CSTSCHG A_BVD1(STSCHG/RI)
A06 GND GND E09 AD19 AD19 H15 A_CCLKRUN A_WP(IOIS16)
A07 V
A08 AD18 AD18 E11 AD27 AD27 H18 A_CSERR A_WAIT
A09 GND GND E12 AD31 AD31 H19 A_CINT A_READY(IREQ)
A10 V
A11 AD29 AD29 E14 MFUNC2 MFUNC2 J02 B_CAD3 B_D5
A12 V
A13 REQ REQ E18 LATCH LATCH J05 B_CAD5 B_D6
A14 GND GND E19 A_CAD31 A_D10 J06 B_RSVD B_D14
A15 MFUNC5 MFUNC5 F01 AD3 AD3 J14 A_CAD26 A_A0
A16 MFUNC1 MFUNC1 F02 AD5 AD5 J15 A_CVS1 A_VS1
B05 AD15 AD15 F03 AD6 AD6 J17 A_CAD25 A_A1
B06 STOP STOP F05 AD8 AD8 J18 A_CAD24 A_A2
B07 IRDY IRDY F06 C/BE1 C/BE1 J19 V
B08 AD17 AD17 F07 DEVSEL DEVSEL K01 GND GND
B09 AD22 AD22 F08 C/BE2 C/BE2 K02 B_CAD7 B_D7
B10 AD24 AD24 F09 AD20 AD20 K03 B_CAD8 B_D15
B11 AD28 AD28 F10 AD23 AD23 K05 B_CC/BE0 B_CE1
B12 AD11 AD11 F11 AD26 AD26 K06 B_CAD9 B_A10
B13 GNT GNT F12 AD25 AD25 K14 A_CC/BE3 A_REG
B14 C/BE3 C/BE3 F13 MFUNC3/IRQSER MFUNC3/IRQSER K15 A_CAD23 A_A3
B15 MFUNC4 MFUNC4 F14 SPKROUT SPKROUT K17 A_CREQ A_INPACK
C05 AD13 AD13 F15 CLOCK CLOCK K18 A_CAD22 A_A4
C06 SERR SERR F17 A_RSVD A_D2 K19 VR_PORT VR_PORT
C07 TRDY TRDY F18 A_CAD29 A_D1 L01 VR_EN VR_EN
C08 AD16 AD16 F19 GND GND L02 B_CAD10 B_CE2
C09 AD21 AD21 G01 V
C10 PCLK PCLK G02 AD0 AD0 L05 B_CAD13 B_IORD
C11 GRST GRST G03 AD1 AD1 L06 B_CAD12 B_A11
C12 AD30 AD30 G05 AD4 AD4 L14 A_CAD21 A_A5
C13 PRST PRST G06 C/BE0 C/BE0 L15 A_CRST A_RESET
C14 MFUNC6/

C15 SUSPEND SUSPEND G15 A_CAD30 A_D9 L18 A_CVS2 A_VS2
D01 AD10 AD10 G17 A_CAD27 A_D0 L19 A_CAD19 A_A25
D19 MFUNC0 MFUNC0 G18 A_CCD2 A_CD2 M01 B_CAD15 B_IOWR
E01 GND GND G19 V
E02 AD7 AD7 H01 B_CAD1 B_D4 M03 B_CAD16 B_A17
E03 AD9 AD9 H02 B_CAD2 B_D11 M05 B_RSVD B_A18
E05 NC NC H03 B_CAD0 B_D3 M06 B_CC/BE1 B_A8
E06 AD14 AD14 H05 B_CCD1 B_CD1 M14 A_CCLK A_A16

CardBus
PC Card

CC

CCP

CC

CLKRUN

16-Bit

PC Card

V

CC

V

CCP

V

CC

MFUNC6/

CLKRUN

NO.

E10 IDSEL IDSEL H17 A_CAUDIO A_BVD2(SPKR)

E13 RI_OUT/PME RI_OUT/PME J01 B_CAD4 B_D12

E17 DATA DATA J03 B_CAD6 B_D13

G14 A_CAD28 A_D8 L17 A_CAD20 A_A6

CardBus

PC Card

CC

CC

SIGNAL NAME

16-Bit

PC Card

V

CC

V

CC

SIGNAL NAME

NO.

L03 B_CAD11 B_OE

M02 B_CAD14 B_A9

CardBus

PC Card

CC

16-Bit

PC Card

V

CC

2−5

Table 2−2. Signal Names by GHK Terminal Number (Continued)

TERM.

TERM.

TERM.

SIGNAL NAME

NO.

M15 A_CFRAME A_A23 P17 A_CSTOP A_A20 U13 A_CAD7 A_D7
M17 A_CC/BE2 A_A12 P18 A_CGNT A_WE U14 A_CAD10 A_CE2
M18 A_CAD17 A_A24 P19 V
M19 A_CAD18 A_A7 R01 V
N01 V
N02 B_CPAR B_A13 R03 B_CFRAME B_A23 V07 B_CAD24 B_A2
N03 B_CBLOCK B_A19 R06 B_CAD19 B_A25 V08 B_CINT B_READY(IREQ)
N05 B_CGNT B_WE R07 B_CREQ B_INPACK V09 B_CAUDIO B_BVD2(SPKR)
N06 B_CPERR B_A14 R08 B_CAD26 B_A0 V10 B_CAD28 B_D8
N14 A_CBLOCK A_A19 R09 B_CCLKRUN B_WP(IOIS16) V11 B_CAD31 B_D10
N15 A_CDEVSEL A_A21 R10 B_CAD30 B_D9 V12 A_CAD4 A_D12
N17 A_CTRDY A_A22 R11 A_CAD2 A_D11 V13 A_RSVD A_D14
N18 A_CIRDY A_A15 R12 A_CAD5 A_D6 V14 A_CC/BE0 A_CE1
N19 V
P01 GND GND R14 A_CAD15 A_IOWR W04 B_CAD17 B_A24
P02 B_CSTOP B_A20 R17 A_RSVD A_A18 W05 B_CRST B_RESET
P03 B_CDEVSEL B_A21 R18 A_CPERR A_A14 W06 GND GND
P05 B_CIRDY B_A15 R19 GND GND W07 B_CAD25 B_A1
P06 B_CCLK B_A16 T01 B_CC/BE2 B_A12 W08 V
P07 B_CVS2 B_VS2 T19 A_CC/BE1 A_A8 W09 B_CSERR B_WAIT
P08 B_CAD23 B_A3 U05 B_CAD18 B_A7 W10 B_CAD27 B_D0
P09 B_CCD2 B_CD2 U06 B_CAD21 B_A5 W11 NC
P10 B_RSVD B_D2 U07 B_CC/BE3 B_REG W12 A_CAD1 A_D4
P11 A_CAD0 A_D3 U08 B_CVS1 B_VS1 W13 V
P12 A_CAD6 A_D13 U09 B_CSTSCHG B_BVD1(STSCHG/RI) W14 GND GND
P13 A_CAD8 A_D15 U10 B_CAD29 B_D1 W15 A_CAD11 A_OE
P14 A_CAD12 A_A11 U11 A_CCD1 A_CD1 W16 A_CAD16 A_A17
P15 A_CPAR A_A13 U12 A_CAD3 A_D5

†

Terminal W11 is an NC on the PCI1520 to allow for terminal compatibility with the next generation of devices.

CardBus

PC Card

CC

CC

16-Bit

PC Card

V

CC

V

CC

NO.

R02 B_CTRDY B_A22 V06 B_CAD22 B_A4

R13 A_CAD9 A_A10 V15 A_CAD13 A_IORD

CardBus

PC Card

SIGNAL NAME

CCA
CCB

16-Bit

PC Card

V

CCA

V

CCB

SIGNAL NAME

NO.

U15 A_CAD14 A_A9
V05 B_CAD20 B_A6

CardBus

PC Card

CC

†

CC

16-Bit

PC Card

V

CC

NC

V

CC

†

2−6

Table 2−3. CardBus PC Card Signal Names Sorted Alphabetically

SIGNAL NAME

SIGNAL NAME

SIGNAL NAME

TERM NO.

PDV GHK

A_CAD0 84 P11 A_CDEVSEL 113 N15 AD24 181 B10
A_CAD1 86 W12 A_CFRAME 119 M15 AD25 167 F12
A_CAD2 85 R11 A_CGNT 112 P18 AD26 179 F11
A_CAD3 88 U12 A_CINT 138 H19 AD27 178 E11
A_CAD4 87 V12 A_CIRDY 117 N18 AD28 176 B11
A_CAD5 90 R12 A_CPAR 107 P15 AD29 175 A11
A_CAD6 89 P12 A_CPERR 109 R18 AD30 172 C12
A_CAD7 93 U13 A_CREQ 130 K17 AD31 171 E12
A_CAD8 94 P13 A_CRST 126 L15 B_CAD0 16 H03

A_CAD9 97 R13 A_CSERR 139 H18 B_CAD1 18 H01
A_CAD10 98 U14 A_CSTOP 111 P17 B_CAD2 17 H02
A_CAD11 99 W15 A_CSTSCHG 141 H14 B_CAD3 20 J02
A_CAD12 100 P14 A_CTRDY 116 N17 B_CAD4 19 J01
A_CAD13 101 V15 A_CVS1 137 J15 B_CAD5 22 J05
A_CAD14 103 U15 A_CVS2 124 L18 B_CAD6 21 J03
A_CAD15 102 R14 A_RSVD 106 R17 B_CAD7 25 K02
A_CAD16 104 W16 A_RSVD 92 V13 B_CAD8 26 K03
A_CAD17 121 M18 A_RSVD 150 F17 B_CAD9 28 K06
A_CAD18 122 M19 AD0 13 G02 B_CAD10 30 L02
A_CAD19 123 L19 AD1 12 G03 B_CAD11 31 L03
A_CAD20 125 L17 AD2 11 H06 B_CAD12 32 L06
A_CAD21 127 L14 AD3 10 F01 B_CAD13 33 L05
A_CAD22 129 K18 AD4 9 G05 B_CAD14 35 M02
A_CAD23 131 K15 AD5 8 F02 B_CAD15 34 M01
A_CAD24 134 J18 AD6 7 F03 B_CAD16 36 M03
A_CAD25 135 J17 AD7 5 E02 B_CAD17 53 W04
A_CAD26 136 J14 AD8 3 F05 B_CAD18 54 U05
A_CAD27 145 G17 AD9 2 E03 B_CAD19 55 R06
A_CAD28 146 G14 AD10 1 D01 B_CAD20 57 V05
A_CAD29 148 F18 AD11 173 B12 B_CAD21 59 U06
A_CAD30 149 G15 AD12 208 A04 B_CAD22 60 V06
A_CAD31 151 E19 AD13 207 C05 B_CAD23 63 P08

A_CAUDIO 140 H17 AD14 206 E06 B_CAD24 65 V07

A_CBLOCK 108 N14 AD15 205 B05 B_CAD25 66 W07

A_CC/BE0 96 V14 AD16 192 C08 B_CAD26 67 R08
A_CC/BE1 105 T19 AD17 191 B08 B_CAD27 76 W10
A_CC/BE2 120 M17 AD18 190 A08 B_CAD28 77 V10
A_CC/BE3 132 K14 AD19 189 E09 B_CAD29 78 U10

A_CCD1 83 U11 AD20 188 F09 B_CAD30 79 R10

A_CCD2 144 G18 AD21 187 C09 B_CAD31 82 V11

A_CCLK 115 M14 AD22 186 B09 B_CAUDIO 72 V09

A_CCLKRUN 142 H15 AD23 184 F10 B_CBLOCK 41 N03

TERM. NO.

PDV GHK

TERM. NO.

PDV GHK

2−7

Table 2−3. CardBus PC Card Signal Names Sorted Alphabetically (Continued)

SIGNAL NAME

SIGNAL NAME

SIGNAL NAME

TERM NO.

PDV GHK

B_CC/BE0 27 K05 C/BE2 193 F08 NC — E05
B_CC/BE1 37 M06 C/BE3 164 B14 NC
B_CC/BE2 52 T01 CLOCK 154 F15 PAR 203 A05
B_CC/BE3 64 U07 DATA 155 E17 PCLK 182 C10

B_CCD1 15 H05 DEVSEL 198 F07 PERR 201 E07
B_CCD2 75 P09 FRAME 194 E08 PRST 168 C13

B_CCLK 48 P06 GND 6 A06 REQ 170 A13
B_CCLKRUN 74 R09 GND 24 A09 RI_OUT/PME 165 E13
B_CDEVSEL 46 P03 GND 43 A14 SERR 202 C06

B_CFRAME 51 R03 GND 62 E01 SPKROUT 152 F14

B_CGNT 45 N05 GND 95 K01 STOP 200 B06

B_CINT 69 V08 GND 110 P01 SUSPEND 158 C15

B_CIRDY 50 P05 GND 147 R19 TRDY 197 C07

B_CPAR 40 N02 GND 166 W06 V

B_CPERR 42 N06 GND 185 F19 V

B_CREQ 61 R07 GND 199 W14 V

B_CRST 58 W05 GNT 169 B13 V

B_CSERR 71 W09 GRST 177 C11 V

B_CSTOP 44 P02 IDSEL 183 E10 V

B_CSTSCHG 73 U09 IRDY 196 B07 V

B_CTRDY 49 R02 LATCH 153 E18 V

B_CVS1 68 U08 MFUNC0 156 D19 V

B_CVS2 56 P07 MFUNC1 157 A16 V

B_RSVD 23 J06 MFUNC2 159 E14 V

B_RSVD 38 M05 MFUNC3/IRQSER 160 F13 V

B_RSVD 80 P10 MFUNC4 161 B15 VR_EN 29 L01

C/BE0 4 G06 MFUNC5 162 A15 VR_PORT 128 K19
C/BE1 204 F06 MFUNC6/CLKRUN 163 C14

†

Terminals 81 and W11 are NC on the PCI1520 to allow for terminal compatibility with the next generation of devices.

TERM NO.

PDV GHK

†

CC
CC
CC
CC
CC
CC
CC
CC

CC
CCA
CCB
CCP

TERM NO.

PDV GHK

81 W11

14 A07
39 A12
70 G01

91 G19
118 J19
133 N01
143 N19
174 W08
195 W13
114 P19

47 R01
180 A10

2−8

Table 2−4. 16-Bit PC Card Signal Names Sorted Alphabetically

SIGNAL NAME

SIGNAL NAME

SIGNAL NAME

TERM. NO.

PDV GHK

A_A0 136 J14 A_D10 151 E19 AD24 181 B10
A_A1 135 J17 A_D11 85 R11 AD25 167 F12
A_A2 134 J18 A_D12 87 V12 AD26 179 F11
A_A3 131 K15 A_D13 89 P12 AD27 178 E11
A_A4 129 K18 A_D14 92 V13 AD28 176 B11
A_A5 127 L14 A_D15 94 P13 AD29 175 A11
A_A6 125 L17 A_INPACK 130 K17 AD30 172 C12
A_A7 122 M19 A_IORD 101 V15 AD31 171 E12
A_A8 105 T19 A_IOWR 102 R14 B_A0 67 R08

A_A9 103 U15 A_OE 99 W15 B_A1 66 W07
A_A10 97 R13 A_READY(IREQ) 138 H19 B_A2 65 V07
A_A11 100 P14 A_REG 132 K14 B_A3 63 P08
A_A12 120 M17 A_RESET 126 L15 B_A4 60 V06
A_A13 107 P15 A_VS1 137 J15 B_A5 59 U06
A_A14 109 R18 A_VS2 124 L18 B_A6 57 V05
A_A15 117 N18 A_WAIT 139 H18 B_A7 54 U05
A_A16 115 M14 A_WE 112 P18 B_A8 37 M06
A_A17 104 W16 A_WP(IOIS16) 142 H15 B_A9 35 M02
A_A18 106 R17 AD0 13 G02 B_A10 28 K06
A_A19 108 N14 AD1 12 G03 B_A11 32 L06
A_A20 111 P17 AD2 11 H06 B_A12 52 T01
A_A21 113 N15 AD3 10 F01 B_A13 40 N02
A_A22 116 N17 AD4 9 G05 B_A14 42 N06
A_A23 119 M15 AD5 8 F02 B_A15 50 P05
A_A24 121 M18 AD6 7 F03 B_A16 48 P06
A_A25 123 L19 AD7 5 E02 B_A17 36 M03

A_BVD1(STSCHG/RI) 141 H14 AD8 3 F05 B_A18 38 M05

A_BVD2(SPKR) 140 H17 AD9 2 E03 B_A19 41 N03

A_CD1 83 U11 AD10 1 D01 B_A20 44 P02
A_CD2 144 G18 AD11 173 B12 B_A21 46 P03
A_CE1 96 V14 AD12 208 A04 B_A22 49 R02
A_CE2 98 U14 AD13 207 C05 B_A23 51 R03

A_D0 145 G17 AD14 206 E06 B_A24 53 W04

A_D1 148 F18 AD15 205 B05 B_A25 55 R06

A_D2 150 F17 AD16 192 C08 B_BVD1(STSCHG/RI) 73 U09

A_D3 84 P11 AD17 191 B08 B_BVD2(SPKR) 72 V09

A_D4 86 W12 AD18 190 A08 B_CD1 15 H05

A_D5 88 U12 AD19 189 E09 B_CD2 75 P09

A_D6 90 R12 AD20 188 F09 B_CE1 27 K05

A_D7 93 U13 AD21 187 C09 B_CE2 30 L02

A_D8 146 G14 AD22 186 B09 B_D0 76 W10

A_D9 149 G15 AD23 184 F10 B_D1 78 U10

TERM. NO.

PDV GHK

TERM NO.

PDV GHK

2−9

Table 2−4. 16-Bit PC Card Signal Names Sorted Alphabetically (Continued)

SIGNAL NAME

SIGNAL NAME

SIGNAL NAME

TERM NO.

PDV GHK

B_D2 80 P10 C/BE2 193 F08 NC — E05
B_D3 16 H03 C/BE3 164 B14 NC
B_D4 18 H01 CLOCK 154 F15 PAR 203 A05
B_D5 20 J02 DATA 155 E17 PCLK 182 C10
B_D6 22 J05 DEVSEL 198 F07 PERR 201 E07
B_D7 25 K02 FRAME 194 E08 PRST 168 C13
B_D8 77 V10 GND 6 A06 REQ 170 A13

B_D9 79 R10 GND 24 A09 RI_OUT/PME 165 E13
B_D10 82 V11 GND 43 A14 SERR 202 C06
B_D11 17 H02 GND 62 E01 SPKROUT 152 F14
B_D12 19 J01 GND 95 K01 STOP 200 B06
B_D13 21 J03 GND 110 P01 SUSPEND 158 C15
B_D14 23 J06 GND 147 R19 TRDY 197 C07
B_D15 26 K03 GND 166 W06 V

B_INPACK 61 R07 GND 185 F19 V

B_IORD 33 L05 GND 199 W14 V

B_IOWR 34 M01 GNT 169 B13 V

B_OE 31 L03 GRST 177 C11 V

B_READY(IREQ) 69 V08 IDSEL 183 E10 V

B_REG 64 U07 IRDY 196 B07 V

B_RESET 58 W05 LATCH 153 E18 V

B_VS1 68 U08 MFUNC0 156 D19 V
B_VS2 56 P07 MFUNC1 157 A16 V

B_WAIT 71 W09 MFUNC2 159 E14 V

B_WE 45 N05 MFUNC3/IRQSER 160 F13 V

B_WP(IOIS16) 74 R09 MFUNC4 161 B15 VR_EN 29 L01

C/BE0 4 G06 MFUNC5 162 A15 VR_PORT 128 K19
C/BE1 204 F06 MFUNC6/CLKRUN 163 C14

†

Terminals 81 and W11 are NC on the PCI1520 to allow for terminal compatibility with the next generation of devices.

TERM NO.

PDV GHK

†

CC
CC
CC
CC
CC
CC
CC
CC

CC
CCA
CCB
CCP

TERM NO.

PDV GHK

81 W11

14 A07
39 A12
70 G01

91 G19
118 J19
133 N01
143 N19
174 W08
195 W13
114 P19

47 R01
180 A10

2−10

The terminals are grouped in tables by functionality, such as PCI system function, power-supply function, etc. The

NAME

I/O

DESCRIPTION

NAME

I/O

DESCRIPTION

terminal numbers are also listed for convenient reference.

Table 2−5. Power Supply Terminals

TERMINAL

NO.

PDV GHK

6, 24, 43, 62,

GND

V

CC

V

CCA

V

CCB

V

CCP

VR_EN 29 L01 I Internal voltage regulator enable. Active-low

VR_PORT 128 K19 I/O

95, 110, 147,
166, 185, 199

14, 39, 70, 91,
118, 133, 143,

174, 195

114 P19 −

47 R01 −

180 A10 − Clamp voltage for PCI and miscellaneous I/O, 5 V or 3.3 V

A06, A09, A14,
E01, F19, K01,

P01, R19, W06,

W14

A07, A12, G01,
G19, J19, N01,

N19, W08, W13

I/O DESCRIPTION

Device ground terminals

−

Power supply terminal for I/O and internal voltage regulator

−

Clamp voltage for PC Card A interface. Matches card A signaling environment, 5 V
or 3.3 V

Clamp voltage for PC Card B interface. Matches card B signaling environment, 5 V
or 3.3 V

Internal voltage regulator input/output. When VR_EN is low, the regulator is en­abled and this terminal is an output. An external bypass capacitor is required on this
terminal. When VR_EN is high, the regulator is disabled and this terminal is an input
for an external 2.5-V core power source.

Table 2−6. PC Card Power Switch Terminals

TERMINAL

NO.

PDV GHK

CLOCK 154 F15 I/O

DATA 155 E17 O

LATCH 153 E18 I/O

I/O DESCRIPTION

Power switch clock. Information on the DATA line is sampled at the rising edge of CLOCK. CLOCK defaults to
an input, but can be changed to a PCI1520 output by using bit 27 (P2CCLK) in the system control register
(offset 80h, see Section 4.29). The TPS222X defines the maximum frequency of this signal to be 2 MHz. How­ever, PCI1520 requires a 16-KHz to 100-KHz frequency range. If a system design defines this terminal as an
output, then this terminal requires an external pulldown resistor. The frequency of the PCI1520 output CLOCK
is derived from the internal ring oscillator (16 KHz typical).

Power switch data. DATA is used to communicate socket power control information serially to the power
switch.

Power switch latch. LATCH is asserted by the PCI1520 to indicate to the power switch that the data on the
DATA line is valid. When a pulldown resistor is implemented on this terminal, the MFUNC1 and MFUNC4 ter­minals provide the serial EEPROM SDA and SCL interface.

2−11

TERMINAL

NAME

I/O

DESCRIPTION

NO.

PDV GHK

GRST 177 C11 I

PCLK 182 C10 I

PRST

168 C13 I

Table 2−7. PCI System Terminals

I/O DESCRIPTION

Global reset. When the global reset is asserted, the GRST signal causes the PCI1520 to place all output
buffers in a high-impedance state and reset all internal registers. When GRST
completely in its default state. For systems that require wake-up from D3, GRST
during initial boot. PRST
transition from D3 to D0. For systems that do not require wake-up from D3, GRST
When the SUSPEND
preserved. All outputs are placed in a high-impedance state.

PCI bus clock. PCLK provides timing for all transactions on the PCI bus. All PCI signals are sampled at the
rising edge of PCLK.

PCI reset. When the PCI bus reset is asserted, PRST causes the PCI1520 to place all output buffers in a
high-impedance state and reset internal registers. When PRST
signal only if it is enabled. After PRST is deasserted, the PCI1520 is in a default state.
When the SUSPEND
preserved. All outputs are placed in a high-impedance state.

should be asserted following initial boot so that PME context is retained during the

mode is enabled, the device is protected from GRST, and the internal registers are

is asserted, the device can generate the PME

mode is enabled, the device is protected from PRST, and the internal registers are

is asserted, the device is

normally is asserted only

should be tied to PRST.

2−12

TERMINAL

NAME

I/O

DESCRIPTION

NO.

PDV GHK

AD31
AD30
AD29
AD28
AD27
AD26
AD25
AD24
AD23
AD22
AD21
AD20
AD19
AD18
AD17
AD16
AD15
AD14
AD13
AD12
AD11
AD10

AD9
AD8
AD7
AD6
AD5
AD4
AD3
AD2
AD1
AD0

C/BE3
C/BE2
C/BE1
C/BE0

PAR 203 A05 I/O

171
172
175
176
178
179
167
181
184
186
187
188
189
190
191
192
205
206
207
208
173

1
2
3
5
7
8

9
10
11
12
13

164
193
204

4

E12
C12

A11
B11
E11

F11
F12
B10
F10
B09
C09
F09
E09
A08
B08
C08
B05
E06
C05
A04
B12
D01
E03
F05
E02
F03
F02
G05
F01
H06
G03
G02

B14
F08
F06
G06

Table 2−8. PCI Address and Data T erminals

I/O DESCRIPTION

PCI address/data bus. These signals make up the multiplexed PCI address and data bus on the primary
interface. During the address phase of a primary-bus PCI cycle, AD31−AD0 contain a 32-bit address or

I/O

other destination information. During the data phase, AD31−AD0 contain data.

PCI-bus commands and byte enables. These signals are multiplexed on the same PCI terminals. During
the address phase of a primary-bus PCI cycle, C/BE3
phase, this 4-bit bus is used as byte enables. The byte enables determine which byte paths of the full 32-bit

I/O

data bus carry meaningful data. C/BE0
C/BE2

applies to byte 2 (AD23−AD16), and C/BE3 applies to byte 3 (AD31−AD24).

PCI-bus parity. In all PCI-bus read and write cycles, the PCI1520 calculates even parity across the
AD31−AD0 and C/BE3
indicator with a one-PCLK delay. As a target during PCI cycles, the PCI1520 compares its calculated parity
to the parity indicator of the initiator. A compare error results in the assertion of a parity error (PERR).

−C/BE0 buses. As an initiator during PCI cycles, the PCI1520 outputs this parity

applies to byte 0 (AD7−AD0), C/BE1 applies to byte 1 (AD15−AD8),

−C/BE0 define the bus command. During the data

2−13

TERMINAL

NAME

I/O

DESCRIPTION

NO.

PDV GHK

DEVSEL

FRAME

GNT

IDSEL 183 E10 I

IRDY

PERR

REQ

SERR

STOP

TRDY

198 F07 I/O

194 E08 I/O

169 B13 I

196 B07 I/O

201 E07 I/O
170 A13 O PCI bus request. REQ is asserted by the PCI1520 to request access to the PCI bus as an initiator.

202 C06 O

200 B06 I/O

197 C07 I/O

Table 2−9. PCI Interface Control T erminals

I/O DESCRIPTION

PCI device select. The PCI1520 asserts DEVSEL to claim a PCI cycle as the target device. As a PCI initiator
on the bus, the PCI1520 monitors DEVSEL
occurs, then the PCI1520 terminates the cycle with an initiator abort.

PCI cycle frame. FRAME is driven by the initiator of a bus cycle. FRAME is asserted to indicate that a bus
transaction is beginning, and data transfers continue while this signal is asserted. When FRAME
deasserted, the PCI bus transaction is in the final data phase.

PCI bus grant. GNT is driven by the PCI bus arbiter to grant the PCI1520 access to the PCI bus after the
current data transaction has completed. GNT
bus parking algorithm.

Initialization device select. IDSEL selects the PCI1520 during configuration space accesses. IDSEL can be
connected to one of the upper 24 PCI address lines on the PCI bus.

PCI initiator ready. IRDY indicates the ability of the PCI bus initiator to complete the current data phase of the
transaction. A data phase is completed on a rising edge of PCLK where both IRDY
Until IRDY

PCI parity error indicator. PERR is driven by a PCI device to indicate that calculated parity does not match
PAR when PERR

PCI system error. SERR is an output that is pulsed from the PCI1520 when enabled through bit 8 of the
command register (PCI offset 04h, see Section 4.4) indicating a system error has occurred. The PCI1520
need not be the target of the PCI cycle to assert this signal. When SERR is enabled in the command register,
this signal also pulses, indicating that an address parity error has occurred on a CardBus interface.

PCI cycle stop signal. STOP is driven by a PCI target to request the initiator to stop the current PCI bus
transaction. STOP
support burst data transfers.

PCI target ready. TRDY indicates the ability of the primary bus target to complete the current data phase of
the transaction. A data phase is completed on a rising edge of PCLK when both IRDY
Until both IRDY

and TRDY are both sampled asserted, wait states are inserted.

is enabled through bit 6 of the command register (PCI offset 04h, see Section 4.4).

is used for target disconnects and is commonly asserted by target devices that do not

and TRDY are asserted, wait states are inserted.

until a target responds. If no target responds before timeout

may or may not follow a PCI bus request, depending on the PCI

and TRDY are asserted.

and TRDY are asserted.

is

2−14

TERMINAL

NAME

I/O

DESCRIPTION

NO.

PDV GHK

MFUNC0 156 D19 I/O

MFUNC1 157 A16 I/O

MFUNC2 159 E14 I/O

MFUNC3/

IRQSER

MFUNC4 161 B15 I/O

MFUNC5 162 A15 I/O

MFUNC6/

CLKRUN

NC

RI_OUT/PME 165 E13 O

SPKROUT

SUSPEND 158 C15 I

160 F13 I/O

163 C14 I/O

—81E05

W11

152 F14 O

Table 2−10. Multifunction and Miscellaneous Terminals

I/O DESCRIPTION

Multifunction terminal 0. MFUNC0 can be configured as parallel PCI interrupt INTA, GPI0, GPO0, socket
activity LED output, ZV switching output, CardBus audio PWM, GPE
Section 4.30, Multifunction Routing Register, for configuration details.

Multifunction terminal 1. MFUNC1 can be configured as parallel PCI interrupt INTB, GPI1, GPO1, socket
activity LED output, ZV switching output, CardBus audio PWM, GPE
Section 4.30, Multifunction Routing Register, for configuration details.

Serial data (SDA). When LA TCH is detected low after the deassertion of GRST
provides the SDA signaling for the serial bus interface. The two-terminal serial interface loads the
subsystem identification and other register defaults from an EEPROM after a PCI reset. See
Section 3.6.1, Serial Bus Interface Implementation, for details on other serial bus applications.

Multifunction terminal 2. MFUNC2 can be configured as GPI2, GPO2, socket activity LED output, ZV
switching output, CardBus audio PWM, GPE
Multifunction Routing Register, for configuration details.

Multifunction terminal 3. MFUNC3 can be configured as a parallel IRQ or the serialized interrupt signal
IRQSER. This terminal is IRQSER by default. See Section 4.30, Multifunction Routing Register, for
configuration details.

Multifunction terminal 4. MFUNC4 can be configured as PCI LOCK, GPI3, GPO3, socket activity LED
output, ZV switching output, CardBus audio PWM, GPE
Section 4.30, Multifunction Routing Register, for configuration details.

Serial clock (SCL). When LA TCH is detected low after the deassertion of GRST, the MFUNC4 terminal
provides the SCL signaling for the serial bus interface. The two-terminal serial interface loads the
subsystem identification and other register defaults from an EEPROM after a PCI reset. See
Section 3.6.1, Serial Bus Interface Implementation, for details on other serial bus applications.

Multifunction terminal 5. MFUNC5 can be configured as GPI4, GPO4, socket activity LED output, ZV
switching output, CardBus audio PWM, D3_STAT
Multifunction Routing Register, for configuration details.

Multifunction terminal 6. MFUNC6 can be configured as a PCI CLKRUN or a parallel IRQ. See
Section 4.30, Multifunction Routing Register, for configuration details.

No connect. These terminals have no connection anywhere within the package. Terminal E05 on the
GHK package is used as a key to indicate the location of the A1 corner of the BGA package. Terminals
W11 on the GHK package and 81 on the PDV package will be used as a 48-MHz clock input on
future-generation devices.

Ring indicate out and power management event output. This terminal provides an output for ring-indicate
or PME

signals.

Speaker output. SPKROUT is the output to the host system that can carry SPKR or CAUDIO through
the PCI1520 from the PC Card interface. SPKROUT is driven as the exclusive-OR combination of card
SPKR//CAUDIO inputs.

Suspend. SUSPEND protects the internal registers from clearing when the GRST or PRST signal is
asserted. See Section 3.8.5, Suspend Mode, for details.

, RI_OUT, D3_STAT, or a parallel IRQ. See Section 4.30,

, D3_STAT, RI_OUT, or a parallel IRQ. See

, GPE, or a parallel IRQ. See Section 4.30,

, or a parallel IRQ. See

, or a parallel IRQ. See

, the MFUNC1 terminal

2−15

Table 2−11. 16-Bit PC Card Address and Data Terminals (Slots A and B)

I/O

DESCRIPTION

NAME

TERMINAL

NUMBER

†

NAME

A25
A24
A23
A22
A21
A20
A19
A18
A17
A16
A15
A14
A13
A12

A11

A10

A9
A8
A7
A6
A5
A4
A3
A2
A1
A0

D15
D14
D13
D12

D11

D10

D9
D8
D7
D6
D5
D4
D3
D2
D1
D0

†

Terminal name for slot A is preceded with A_. For example, the full name for terminals 123 and L19 is A_A25.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminals 55 and R06 is B_A25.

SLOT A

PDV

123
121
119
116
113

111
108
106
104
115
117
109
107
120
100

97
103
105
122
125
127
129
131
134
135
136

94

92

89

87

85
151
149
146

93

90

88

86

84
150
148
145

GHK

L19
M18
M15
N17
N15
P17
N14
R17
W16
M14
N18
R18
P15
M17
P14
R13
U15

T19

M19

L17

L14
K18
K15

J18

J17

J14
P13

V13
P12
V12
R11
E19
G15
G14
U13
R12
U12
W12

P11

F17

F18
G17

PDV

55
53
51
49
46
44
41
38
36
48
50
42
40
52
32
28
35
37
54
57
59
60
63
65
66
67

26
23
21
19
17
82
79
77
25
22
20
18
16
80
78
76

SLOT B

‡

GHK

R06

W04

R03
R02
P03
P02

N03
M05
M03

P06

P05

N06

N02

T01

L06

K06
M02
M06

U05

V05

U06

V06

P08

V07
W07

R08

K03

J06
J03

J01
H02
V11
R10
V10
K02

J05

J02
H01
H03
P10
U10

W10

O PC Card address. 16-bit PC Card address lines. A25 is the most significant bit.

I/O PC Card data. 16-bit PC Card data lines. D15 is the most significant bit.

2−16

Table 2−12. 16-Bit PC Card Interface Control Terminals (Slots A and B)

I/O

DESCRIPTION

NAME

TERMINAL

NUMBER
†

NAME

BVD1

(STSCHG

†

Terminal name for slot A is preceded with A_. For example, the full name for terminals 130 and K17 is A_INPACK

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminals 61 and R07 is B_INPACK

/RI)

BVD2

(SPKR

)

CD1
CD2

CE1
CE2

INPACK 130 K17 61 R07 I

IORD

IOWR

SLOT A

PDV GHK PDV GHK

141 H14 73 U09 I

140 H17 72 V09 I

83

U11

144

G181575

9698V14

U142730

101 V15 33 L05 O

102 R14 34 M01 O

SLOT B

‡

H05
P09

K05
L02

Battery voltage detect 1. BVD1 is generated by 16-bit memory PC Cards that
include batteries. BVD1 is used with BVD2 as an indication of the condition of the
batteries on a memory PC Card. Both BVD1 and BVD2 are high when the battery
is good. When BVD2 is low and BVD1 is high, the battery is weak and should be
replaced. When BVD1 is low, the battery is no longer serviceable and the data in
the memory PC Card is lost. See Section 5.6, ExCA Card Status-Change Interrupt

Configuration Register, for enable bits. See Section 5.5, ExCA Card
Status-Change Register, and Section 5.2, ExCA Interface Status Register, for the

status bits for this signal.
Status change. STSCHG

write protect, or battery voltage dead condition of a 16-bit I/O PC Card.
Ring indicate. RI

Battery voltage detect 2. BVD2 is generated by 16-bit memory PC Cards that
include batteries. BVD2 is used with BVD1 as an indication of the condition of the
batteries on a memory PC Card. Both BVD1 and BVD2 are high when the battery
is good. When BVD2 is low and BVD1 is high, the battery is weak and should be
replaced. When BVD1 is low, the battery is no longer serviceable and the data in
the memory PC Card is lost. See Section 5.6, ExCA Card Status-Change Interrupt

Configuration Register, for enable bits. See Section 5.5, ExCA Card
Status-Change Register, and Section 5.2, ExCA Interface Status Register, for the

status bits for this signal.
Speaker. SPKR

socket have been configured for the 16-bit I/O interface. The audio signals from
cards A and B are combined by the PCI1520 and are output on SPKROUT.

Card detect 1 and card detect 2. CD1 and CD2 are internally connected to ground
on the PC Card. When a PC Card is inserted into a socket, CD1

I

low. For signal status, see Section 5.2, ExCA Interface Status Register.
Card enable 1 and card enable 2. CE1 and CE2 enable even- and odd-numbered

address bytes. CE1

O

odd-numbered address bytes.
Input acknowledge. INPACK is asserted by the PC Card when it can respond to an

I/O read cycle at the current address.
I/O read. IORD is asserted by the PCI1520 to enable 16-bit I/O PC Card data output

during host I/O read cycles.
I/O write. IOWR is driven low by the PCI1520 to strobe write data into 16-bit I/O PC

Cards during host I/O write cycles.

is used by 16-bit modem cards to indicate a ring detection.

is an optional binary audio signal available only when the card and

is used to alert the system to a change in the READY,

enables even-numbered address bytes, and CE2 enables

and CD2 are pulled

.

.

2−17

Table 2−12. 16-Bit PC Card Interface Control Terminals (Slots A and B) (Continued)

I/O

DESCRIPTION

NAME

TERMINAL

NUMBER

†

NAME

OE 99 W15 31 L03 O

READY

(IREQ

REG

RESET 126 L15 58 W05 O PC Card reset. RESET forces a hard reset to a 16-bit PC Card.

VS1
VS2

WAIT

WE 112 P18 45 N05 O

WP

(IOIS16

†

Terminal name for slot A is preceded with A_. For example, the full name for terminals 112 and P18 is A_WE

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminals 45 and N05 is B_WE

SLOT A

PDV GHK PDV GHK

138 H19 69 V08 I

)

132 K14 64 U07 O

137

J15

124

L186856

139 H18 71 W09 I

142 H15 74 R09 I

)

SLOT B

‡

U08
P07

Output enable. OE is driven low by the PCI1520 to enable 16-bit memory PC Card data
output during host memory read cycles.

Ready. The ready function is provided by READY when the 16-bit PC Card and the host
socket are configured for the memory-only interface. READY is driven low by 16-bit memory
PC Cards to indicate that the memory card circuits are busy processing a previous write
command. READY is driven high when the 16-bit memory PC Card is ready to accept a new
data transfer command.

Interrupt request. IREQ
device on the 16-bit I/O PC Card requires service by the host software. IREQ
(deasserted) when no interrupt is requested.

Attribute memory select. REG remains high for all common memory accesses. When REG
is asserted, access is limited to attribute memory (OE or WE active) and to the I/O space

or IOWR active). Attribute memory is a separately accessed section of card memory

(IORD
and is generally used to record card capacity and other configuration and attribute
information.

Voltage sense 1 and voltage sense 2. VS1 and VS2, when used in conjunction with each

I/O

other, determine the operating voltage of the PC Card.
Bus cycle wait. WAIT is driven by a 16-bit PC Card to extend the completion of the memory

or I/O cycle in progress.
Write enable. WE is used to strobe memory write data into 16-bit memory PC Cards. WE

is also used for memory PC Cards that employ programmable memory technologies.
Write protect. WP applies to 16-bit memory PC Cards. WP reflects the status of the

write-protect switch on 16-bit memory PC Cards. For 16-bit I/O cards, WP is used for the
16-bit port (IOIS16

I/O is 16 bits. IOIS16
when the address on the bus corresponds to an address to which the 16-bit PC Card
responds, and the I/O port that is addressed is capable of 16-bit accesses.

is asserted by a 16-bit I/O PC Card to indicate to the host that a

) function.

applies to 16-bit I/O PC Cards. IOIS16 is asserted by the 16-bit PC Card

is high

.

.

2−18

Table 2−13. CardBus PC Card Interface System T erminals (Slots A and B)

I/O

DESCRIPTION

NAME

TERMINAL

NUMBER
†

NAME

CCLK 115 M14 48 P06 O

CCLKRUN

CRST

†

Terminal name for slot A is preceded with A_. For example, the full name for terminals 115 and M14 is A_CCLK.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminals 48 and P06 is B_CCLK.

SLOT A

PDV GHK PDV GHK

142 H15 74 R09 I/O

126 L15 58 W05 O

SLOT B

‡

CardBus clock. CCLK provides synchronous timing for all transactions on the
CardBus interface. All signals except CRST

, CCD1, CVS2, and CVS1 are sampled on the rising edge of CCLK, and all

CCD2
timing parameters are defined with the rising edge of this signal. CCLK operates at
the PCI bus clock frequency, but it can be stopped in the low state or slowed down
for power savings.

CardBus clock run. CCLKRUN is used by a CardBus PC Card to request an increase
in the CCLK frequency, and by the PCI1520 to indicate that the CCLK frequency is
going to be decreased.

CardBus reset. CRST brings CardBus PC Card-specific registers, sequencers, and
signals to a known state. When CRST
placed in a high-impedance state, and the PCI1520 drives these signals to a valid
logic level. Assertion can be asynchronous to CCLK, but deassertion must be
synchronous to CCLK.

, CCLKRUN, CINT, CSTSCHG, CAUDIO,

is asserted, all CardBus PC Card signals are

2−19

Table 2−14. CardBus PC Card Address and Data T erminals (Slots A and B)

I/O

DESCRIPTION

NAME

TERMINAL

NUMBER

†

NAME

CAD31
CAD30
CAD29
CAD28
CAD27
CAD26
CAD25
CAD24
CAD23
CAD22
CAD21
CAD20
CAD19
CAD18
CAD17
CAD16
CAD15
CAD14
CAD13
CAD12
CAD11
CAD10

CAD9
CAD8
CAD7
CAD6
CAD5
CAD4
CAD3
CAD2
CAD1
CAD0

CC/BE3
CC/BE2
CC/BE1
CC/BE0

CPAR 107 P15 40 N02 I/O

†

Terminal name for slot A is preceded with A_. For example, the full name for terminals 107 and P15 is A_CPAR.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminals 40 and N02 is B_CPAR.

SLOT A

PDV GHK PDV GHK

151

E19

149

G15

148

F18

146

G14

145

G17
136
135
134
131
129
127
125
123
122
121
104
102
103
101
100

132
120
105

99
98
97
94
93
89
90
87
88
85
86
84

96

J14
J17

J18
K15
K18

L14

L17

L19

M19
M18
W16

R14
U15
V15
P14

W15

U14
R13
P13
U13
P12
R12
V12
U12
R11

W12

P11

K14

M17

T19
V14

SLOT B

82
79
78
77
76
67
66
65
63
60
59
57
55
54
53
36
34
35
33
32
31
30
28
26
25
21
22
19
20
17
18
16

64
52
37
27

‡

V11
R10
U10
V10

W10

R08

W07

V07
P08
V06
U06
V05
R06

U05
W04
M03
M01
M02

L05

L06

L03

L02

K06

K03

K02

J03

J05

J01

J02

H02

H01

H03

U07

T01
M06

K05

CardBus address and data. These signals make up the multiplexed CardBus address
and data bus on the CardBus interface. During the address phase of a CardBus cycle,

I/O

CAD31−CAD0 contain a 32-bit address. During the data phase of a CardBus cycle,
CAD31−CAD0 contain data. CAD31 is the most significant bit.

CardBus bus commands and byte enables. CC/BE3−CC/BE0 are multiplexed on the
same CardBus terminals. During the address phase of a CardBus cycle,
CC/BE3−CC/BE0 define the bus command. During the data phase, this 4-bit bus is used
as byte enables. The byte enables determine which byte paths of the full 32-bit data bus

I/O

carry meaningful data. CC/BE0
byte 1 (CAD15−CAD8), CC/BE2
applies to byte 3 (CAD31−CAD24).

CardBus parity . In all CardBus read and write cycles, the PCI1520 calculates even parity
across the CAD and CC/BE
outputs CPAR with a one-CCLK delay. As a target during CardBus cycles, the PCI1520
compares its calculated parity to the parity indicator of the initiator; a compare error
results in a parity error assertion.

applies to byte 0 (CAD7−CAD0), CC/BE1 applies to

applies to byte 2 (CAD23−CAD16), and CC/BE3

buses. As an initiator during CardBus cycles, the PCI1520

2−20

Table 2−15. CardBus PC Card Interface Control Terminals (Slots A and B)

I/O

DESCRIPTION

NAME

CCD1

83

U1115H05

CCD1

83

U11

H05

with CVS1 and CVS2 to identify card insertion and interrogate cards to determine the

TERMINAL

NUMBER
†

NAME

CAUDIO 140 H17 72 V09 I

CBLOCK

CCD2

CDEVSEL

CFRAME

CGNT

CINT

CIRDY

CPERR

CREQ

CSERR

CSTOP

CSTSCHG

CTRDY

CVS1
CVS2

SLOT A

PDV GHK PDV GHK

108 N14 41 N03 I/O

144

G181575

113 N15 46 P03 I/O

119 M15 51 R03 I/O

112 P18 45 N05 O

138 H19 69 V08 I

117 N18 50 P05 I/O

109 R18 42 N06 I/O

130 K17 61 R07 I

139 H18 71 W09 I

111 P17 44 P02 I/O

141 H14 73 U09 I

116 N17 49 R02 I/O

137
124

J15
L186856

SLOT B

‡

P09

U08
P07

CardBus audio. CAUDIO is a digital input signal from a PC Card to the system
speaker. The PCI1520 supports the binary audio mode and outputs a binary signal
from the card to SPKROUT.

CardBus lock. CBLOCK is used to gain exclusive access to a target.
CardBus detect 1 and CardBus detect 2. CCD1 and CCD2 are used in conjunction

I

operating voltage and card type.
CardBus device select. The PCI1520 asserts CDEVSEL to claim a CardBus cycle as

the target device. As a CardBus initiator on the bus, the PCI1520 monitors CDEVSEL
until a target responds. If no target responds before timeout occurs, then the PCI1520
terminates the cycle with an initiator abort.

CardBus cycle frame. CFRAME is driven by the initiator of a CardBus bus cycle.
CFRAME
transfers continue while this signal is asserted. When CFRAME
CardBus bus transaction is in the final data phase.

CardBus bus grant. CGNT is driven by the PCI1520 to grant a CardBus PC Card
access to the CardBus bus after the current data transaction has been completed.

CardBus interrupt. CINT is asserted low by a CardBus PC Card to request interrupt
servicing from the host.

CardBus initiator ready. CIRDY indicates the ability of the CardBus initiator to
complete the current data phase of the transaction. A data phase is completed on a
rising edge of CCLK when both CIRDY and CTRDY are asserted. Until CIRDY and
CTRDY

CardBus parity error. CPERR reports parity errors during CardBus transactions,
except during special cycles. It is driven low by a target two clocks following the data
cycle during which a parity error is detected.

CardBus request. CREQ indicates to the arbiter that the CardBus PC Card desires
use of the CardBus bus as an initiator.

CardBus system error. CSERR reports address parity errors and other system errors
that could lead to catastrophic results. CSERR
CCLK, but deasserted by a weak pullup; deassertion may take several CCLK periods.
The PCI1520 can report CSERR to the system by assertion of SERR on the PCI
interface.

CardBus stop. CSTOP is driven by a CardBus target to request the initiator to stop
the current CardBus transaction. CSTOP
commonly asserted by target devices that do not support burst data transfers.

CardBus status change. CSTSCHG alerts the system to a change in the card status,
and is used as a wake-up mechanism.

CardBus target ready . CTRDY indicates the ability of the CardBus target to complete
the current data phase of the transaction. A data phase is completed on a rising edge
of CCLK, when both CIRDY and CTRDY are asserted; until this time, wait states are
inserted.

CardBus voltage sense 1 and CardBus voltage sense 2. CVS1 and CVS2 are used

I/O

in conjunction with CCD1
to determine the operating voltage and card type.

is asserted to indicate that a bus transaction is beginning, and data

is deasserted, the

are both sampled asserted, wait states are inserted.

is driven by the card synchronous to

is used for target disconnects, and is

and CCD2 to identify card insertion and interrogate cards

†

Terminal name for slot A is preceded with A_. For example, the full name for terminals 140 and H18 is A_CAUDIO.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminals 72 and V09 is B_CAUDIO.

2−21

2−22

3 Feature/Protocol Descriptions

The following sections give an overview of the PCI1520. Figure 3−1 shows a simplified block diagram of the PCI1520.
The PCI interface includes all address/data and control signals for PCI protocol. The interrupt interface includes
terminals for parallel PCI, parallel ISA, and serialized PCI and ISA signaling. Miscellaneous system interface
terminals include multifunction terminals: SUSPEND
SPKROUT.

, RI_OUT/PME (power management control signal), and

PCI Bus

INTA

Activity LEDs

INTB

Interrupt

Controller

TPS222X

Power Switch

PC Card

Socket A

PC Card

Socket B

External ZV Port

NOTE: The PC Card interface is 68 terminals for CardBus and 16-bit PC Cards. In zoomed video mode 23 terminals are used for routing the

zoomed video signals to the VGA controller and audio subsystem.

3

68

68

PCI1520

68 68

23

23

23

IRQSER

3

Multiplexer

PCI950

IRQSER

Deserializer

Zoomed Video

19

Zoomed Video

4

IRQ2−15

VGA

Controller

Audio

Subsystem

Figure 3−1. PCI1520 Simplified Block Diagram

3.1 Power Supply Sequencing

The PCI1520 contains 3.3-V I/O buffers with 5-V tolerance requiring an I/O power supply and an LDO-VR power
supply for core logic. The core power supply , which is always 2.5 V, can be supplied through the VR_PORT terminal
(when VR_EN
terminals. The clamping voltages (V
following power-up and power-down sequences are recommended.

is high) or from the integrated LDO-VR. The LDO-VR needs a 3.3-V power supply via the V

, V

CCA

CCB

, and V

) can be either 3.3 V or 5 V , depending on the interface. The

CCP

CC

The power-up sequence is:

1. Assert GRST

to the device to disable the outputs during power up. Output drivers must be powered up in
the high-impedance state to prevent high current levels through the clamp diodes to the 5-V clamping rails
(V

CCA

, V

CCB

, and V

2. Apply 3.3-V power to V

3. Apply the clamp voltage.

CCP

CC

).

.

3−1

The power-down sequence is:

1. Assert GRST

to the device to disable the outputs during power down. Output drivers must be powered down
in the high-impedance state to prevent high current levels through the clamp diodes to the 5-V clamping
rails (V

CCA

, V

CCB

, and V

CCP

).

2. Remove the clamp voltage.

3. Remove the 3.3-V power from V

CC

.

NOTE: The clamp voltage can be ramped up or ramped down along with the 3.3-V power. The
voltage difference between V

and the clamp voltage must remain within 3.6 V.

CC

3.2 I/O Characteristics

Figure 3−2 shows a 3-state bidirectional buffer. Section 7.2, Recommended Operating Conditions, provides the
electrical characteristics of the inputs and outputs.

NOTE: The PCI1520 meets the ac specifications of the 1997 PC Card Standard and PCI Local
Bus Specification.

V

Tied for Open Drain

OE

Figure 3−2. 3-State Bidirectional Buffer

CCP

Pad

NOTE: Unused terminals (input or I/O) must be held high or low to prevent them from floating.

3.3 Clamping Voltages

The clamping voltages are set to match whatever external environment the PCI1520 is interfaced with, 3.3 V or 5 V.
The I/O sites can be pulled through a clamping diode to a voltage rail that protects the core from external signals.
The core power supply is always 3.3 V and is independent of the clamping voltages. For example, PCI signaling can
be either 3.3 V or 5 V, and the PCI1520 must reliably accommodate both voltage levels. This is accomplished by using
a 3.3-V I/O buffer that is 5-V tolerant, with the applicable clamping voltage applied. If a system designer desires a
5-V PCI bus, then V

can be connected to a 5-V power supply.

CCP

The PCI1520 requires three separate clamping voltages because it supports a wide range of features. The three
voltages are listed and defined in Section 7.2, Recommended Operating Conditions. GRST

, SUSPEND, PME, and

CSTSCHG are not clamped to any of them.

3.4 Peripheral Component Interconnect (PCI) Interface

The PCI1520 is fully compliant with the PCI Local Bus Specification. The PCI1520 provides all required signals for
PCI master or slave operation, and may operate in either a 5-V or 3.3-V signaling environment by connecting the V
terminal to the desired voltage level. In addition to the mandatory PCI signals, the PCI1520 provides the optional
interrupt signals INTA

and INTB.

3.4.1 PCI GRST Signal

During the power-up sequence, GRST and PRST must be asserted. GRST can only be deasserted 100 µs after PCLK
is stable. PRST

can be deasserted at the same time as GRST or any time thereafter.

CCP

3−2

3.4.2 PCI Bus Lock (LOCK)

The bus-locking protocol defined in the PCI Local Bus Specification is not highly recommended, but is provided on
the PCI1520 as an additional compatibility feature. The PCI LOCK
setting the appropriate values in bits 19−16 of the multifunction routing register. See Section 4.30, Multifunction
Routing Register,

for details. Note that the use of LOCK is only supported by PCI-to-CardBus bridges in the

downstream direction (away from the processor).

signal can be routed to the MFUNC4 terminal by

PCI LOCK

indicates an atomic operation that may require multiple transactions to complete. When LOCK is asserted,
nonexclusive transactions can proceed to an address that is not currently locked. A grant to start a transaction on
the PCI bus does not guarantee control of LOCK
for different initiators to use the PCI bus while a single master retains ownership of LOCK
signal for this protocol is CBLOCK

to avoid confusion with the bus clock.

; control of LOCK is obtained under its own protocol. It is possible

. Note that the CardBus

An agent may need to do an exclusive operation because a critical access to memory might be broken into several
transactions, but the master wants exclusive rights to a region of memory. The granularity of the lock is defined by
PCI to be 16 bytes, aligned. The LOCK

protocol defined by the PCI Local Bus Specification allows a resource lock

without interfering with nonexclusive real-time data transfer, such as video.
The PCI bus arbiter may be designed to support only complete bus locks using the LOCK

the arbiter will not grant the bus to any other agent (other than the LOCK

master) while LOCK is asserted. A complete

protocol. In this scenario,

bus lock may have a significant impact on the performance of the video. The arbiter that supports complete bus lock
must grant the bus to the cache to perform a writeback due to a snoop to a modified line when a locked operation
is in progress.

The PCI1520 supports all LOCK

protocol associated with PCI-to-PCI bridges, as also defined for PCI-to-CardBus
bridges. This includes disabling write posting while a locked operation is in progress, which can solve a potential
deadlock when using devices such as PCI-to-PCI bridges. The potential deadlock can occur if a CardBus target
supports delayed transactions and blocks access to the target until it completes a delayed read. This target
characteristic is prohibited by the PCI Local Bus Specification, and the issue is resolved by the PCI master using
LOCK

.

3.4.3 Loading Subsystem Identification

The subsystem vendor ID register (PCI offset 40h, see Section 4.26) and subsystem ID register (PCI offset 42h, see
Section 4.27) make up a doubleword of PCI configuration space for functions 0 and 1. This doubleword register is
used for system and option card (mobile dock) identification purposes and is required by some operating systems.
Implementation of this unique identifier register is a PC 99/PC 2001 requirement.

The PCI1520 offers two mechanisms to load a read-only value into the subsystem registers. The first mechanism
relies upon the system BIOS providing the subsystem ID value. The default access mode to the subsystem registers
is read-only, but can be made read/write by clearing bit 5 (SUBSYSR W) in the system control register (PCI of fset 80h,
see Section 4.29). Once this bit is cleared, the BIOS can write a subsystem identification value into the registers at
PCI offset 40h. The BIOS must set the SUBSYSRW bit such that the subsystem vendor ID register and subsystem
ID register is limited to read-only access. This approach saves the added cost of implementing the serial electrically
erasable programmable ROM (EEPROM).

In some conditions, such as in a docking environment, the subsystem vendor ID register and subsystem ID register
must be loaded with a unique identifier via a serial EEPROM. The PCI1520 loads the data from the serial EEPROM
after a reset of the primary bus. Note that the SUSPEND
including the serial-bus state machine (see Section 3.8.5, Suspend Mode, for details on using SUSPEND

input gates the PCI reset from the entire PCI1520 core,

).

The PCI1520 provides a two-line serial-bus host controller that can interface to a serial EEPROM. See Section 3.6,
Serial-Bus Interface,

for details on the two-wire serial-bus controller and applications.

3−3

3.5 PC Card Applications

This section describes the PC Card interfaces of the PCI1520.

• Card insertion/removal and recognition

2

C power-switch interface

• P

• Zoomed video support

• Speaker and audio applications

• LED socket activity indicators

• CardBus socket registers

3.5.1 PC Card Insertion/Removal and Recognition

The PC Card Standard (release 7.1) addresses the card-detection and recognition process through an interrogation
procedure that the socket must initiate on card insertion into a cold, nonpowered socket. Through this interrogation,
card voltage requirements and interface (16-bit versus CardBus) are determined.

The scheme uses the card-detect and voltage-sense signals. The configuration of these four terminals identifies the
card type and voltage requirements of the PC Card interface. The encoding scheme is defined in the PC Card
Standard (release 7.1) and in Table 3−1.

Table 3−1. PC Card Card-Detect and Voltage-Sense Connections

CD2//CCD2 CD1//CCD1 VS2//CVS2 VS1//CVS1 KEY INTERFACE VOLTAGE

Ground Ground Open Open 5 V 16-bit PC Card 5 V
Ground Ground Open Ground 5 V 16-bit PC Card 5 V and 3.3 V
Ground Ground Ground Ground 5 V 16-bit PC Card 5 V, 3.3 V, and X.X V
Ground Ground Open Ground LV 16-bit PC Card 3.3 V
Ground Connect to CVS1 Open Connect to CCD1 LV CardBus PC Card 3.3 V

Ground Ground Ground Ground LV 16-bit PC Card 3.3 V and X.X V
Connect to CVS2 Ground Connect to CCD2 Ground LV CardBus PC Card 3.3 V and X.X V
Connect to CVS1 Ground Ground Connect to CCD2 LV CardBus PC Card 3.3 V, X.X V, and Y.Y V

Ground Ground Ground Open LV 16-bit PC Card X.X V
Connect to CVS2 Ground Connect to CCD2 Open LV CardBus PC Card X.X V

Ground Connect to CVS2 Connect to CCD1 Open LV CardBus PC Card X.X V and Y.Y V
Connect to CVS1 Ground Open Connect to CCD2 LV CardBus PC Card Y.Y V

Ground Connect to CVS1 Ground Connect to CCD1 Reserved

Ground Connect to CVS2 Connect to CCD1 Ground Reserved

3.5.2 P2C Power-Switch Interface (TPS222X)

The PCI1520 provides a PCMCIA peripheral control (P2C) interface for control of the PC Card power switch. The
CLOCK, DATA, and LATCH terminals interface with the TI TPS222X dual-slot PC Card power interface switches to
provide power switch support. Figure 3−3 illustrates a typical application where the PCI1520 represents the PCMCIA
controller. Table 3−2 shows the available power switch options compatible with the PCI1520.

3−4

Power Supply

12 V

5 V

3.3 V

Supervisor

12 V
5 V

3.3 V

RESET
RESET

TPS222X

AVPP

AVCC
AVCC
AVCC

V
V
V
V

PP1
PP2
CC
CC

PC Card

A

PCI1520

(PCMCIA

Controller)

CLOCK
DATA
LATCH

BVPP

BVCC
BVCC
BVCC

V
V
V
V

PP1
PP2
CC
CC

PC Card

B

Figure 3−3. TPS222X Typical Application

Table 3−2. Power Switch Options

DEVICE PIN-COMPATIBLE REPLACEMENT(S)

TPS2206
TPS2214(A) TPS2224IDB† – 24-pin SSOP

TPS2216(A) TPS2226IDB† – 30 pin SSOP
TPS2223
TPS2224
TPS2226

†
‡

†‡
†
†

Recommended for new designs
For applications not requiring 12 volts

TPS2226IDB† – 30-pin SSOP
TPS2216ADAP – 32-pin TSSOP

N/A − Check for newer device
N/A − Check for newer device
N/A − Check for newer device

The CLOCK terminal on the PCI1520 can be an input or an output. The PCI1520 defaults the CLOCK terminal as
an input to control the serial interface and the internal state machine. Bit 27 (P2CCLK) in the system control register
(offset 80h, see Section 4.29) can be set by the platform BIOS or the serial EEPROM to enable the PCI1520 to
generate and drive CLOCK internally from the PCI clock. When the system design implements CLOCK as an output
from the PCI1520, an external pulldown resistor is required.

3.5.3 Zoomed Video Support

The PCI1520 allows for the implementation of zoomed video (ZV) for PC Cards. Zoomed video is supported by setting
bit 6 (ZVENABLE) in the card control register (PCI offset 91h, see Section 4.32) on a per-socket function basis.
Setting this bit puts 16-bit PC Card address lines A25−A4 of the PC Card interface in the high-impedance state. These
lines can then transfer video and audio data directly to the appropriate controller. Card address lines A3−A0 can still
access PC Card CIS registers for PC Card configuration. Figure 3−4 illustrates a PCI1520 ZV implementation.

3−5

Audio
Codec

PCM
Audio
Input

Speakers

PC Card

19

PC Card

Interface

CRT

Motherboard

PCI Bus

VGA

Controller

Zoomed Video

Port

19 4

PCI1520

Figure 3−4. Zoomed Video Implementation Using the PCI1520

Video

Audio

4

Not shown in Figure 3−4 is the multiplexing scheme used to route either socket 0 or socket 1 ZV source to the graphics
controller. The PCI1520 provides ZVSTAT, ZVSEL0

, and ZVSEL1 signals on the multifunction terminals to switch
external bus drivers. Figure 3−5 shows an implementation for switching between three ZV streams using external
logic.

2

PCI1520

ZVSTAT
ZVSEL0
ZVSEL1

0 1

Figure 3−5. Zoomed Video Switching Application

Figure 3−5 illustrates an implementation using standard three-state bus drivers with active-low output enables.
ZVSEL0

is an active-low output indicating that the socket 0 ZV mode is enabled, and ZVSEL1 is an active-low output
indicating that socket 1 ZV is enabled. When both sockets have ZV mode enabled, the PCI1520 by defaults indicates
socket 0 enabled through ZVSEL0

; however, bit 5 (POR T_SEL) in the card control register (see Section 4.32) allows

software to select the socket ZV source priority. Table 3−3 illustrates the functionality of the ZV output signals.

3−6

Table 3−3. Functionality of the ZV Output Signals

INPUTS OUTPUTS

PORTSEL SOCKET 0 ENABLE SOCKET 1 ENABLE ZVSEL0 ZVSEL1 ZVSTAT

X 0 0 1 1 0
0 1 X 0 1 1
0 0 1 1 0 1
1 X 1 1 0 1
1 1 0 0 1 1

Also shown in Figure 3−5 is a third ZV input that can be provided from a source such as a high-speed serial bus like
IEEE 1394. The ZVSTAT signal provides a mechanism to switch the third ZV source. ZVSTAT is an active-high output
indicating that one of the PCI1520 sockets is enabled for ZV mode. The implementation shown in Figure 3−5 can be
used if PC Card ZV is prioritized over other sources.

3.5.4 Standardized Zoomed-Video Register Model

The standardized zoomed-video register model is defined for the purpose of standardizing the ZV port control for PC
Card controllers across the industry. The following list summarizes the standardized zoomed-video register model
changes to the existing PC Card register set.

• Socket present state register (CardBus socket address + 08h, see Section 6.3)
Bit 27 (ZVSUPPORT) has been added. The platform BIOS can set this bit via the socket force event register
(CardBus socket address + 0Ch, see Section 6.4) to define whether zoomed video is supported on that
socket by the platform.

• Socket force event register (CardBus socket address + 0Ch, see Section 6.4)
Bit 27 (FZVSUPPORT) has been added. The platform BIOS can use this bit to set the ZVSUPPORT bit in
the socket present state register (CardBus socket address + 08h, see Section 6.3) to define whether
zoomed video is supported on that socket by the platform.

• Socket control register (CardBus socket address +10h, see Section 6.5)
Bit 11 (ZV_ACTIVITY) has been added. This bit is set when zoomed video is enabled for either of the PC
Card sockets.

Bit 10 (STDZVREG) has been added. This bit defines whether the PC Card controller supports the
standardized zoomed-video register model.

Bit 9 (ZVEN) is provided for software to enable or disable zoomed video, per socket.

If the STDZVEN bit (bit 0) in the diagnostic register (PCI offset 93h, see Section 4.34) is 1, then the standardized
zoomed video register model is disabled. For backward compatibility, even if the STDZVEN bit is 0 (enabled), the
PCI1520 allows software to access zoomed video through the legacy address in the card control register (PCI offset
91h, see Section 4.32), or through the new register model in the socket control register (CardBus socket address +
10h, see Section 6.5).

3.5.4.1 Zoomed-Video Card Insertion and Configuration Procedure

1. A zoomed-video PC Card is inserted into an empty slot.

2. The card is detected and interrogated appropriately.

3−7

There are two types of PC Card controllers to consider.

• Legacy controller not using the standardized ZV register model
Software reads bit 10 (STDZVREG) of the socket control register (CardBus socket address + 10h) to
determine if the standardized zoomed-video register model is supported. If the bit returns 0, then software
must use legacy code to enable zoomed video.

• Newer controller that uses the standardized ZV register model
Software reads bit 10 (STDZVREG) of the socket control register (CardBus socket address + 10h) to
determine if the standardized zoomed-video register model is supported. If the bit returns 1, then software
can use the process/register model detailed in Table 3−4 to enable zoomed video.

Table 3−4. Zoomed-Video Card Interrogation

ZVSUPPORT

(this socket)

1 X 0 Set ZVEN to enable zoomed video.
1 X 1

0 0 X

0 1 X

ZVSUPPORT

(other socket)

ZV_ACTIVITY ACTION

Display a user message such as, “The zoomed video protocol required by this PC
Card application is already in use by another card.”

Display a user message such as, “This platform does not support the zoomed-video
protocol required by this PC Card application.”

Display a user message such as, “This platform does not support the zoomed-video
protocol required by this PC Card application in this PC Card socket. Please remove
the card and re-insert in the other PC Card socket.”

3.5.5 Internal Ring Oscillator

The internal ring oscillator provides an internal clock source for the PCI1520 so that neither the PCI clock nor an
external clock is required in order for the PCI1520 to power down a socket or interrogate a PC Card. This internal
oscillator, operating nominally at 16 kHz, can be enabled by setting bit 27 (P2CCLK) of the system control register
(PCI offset 80h, see Section 4.29) to 1. This function is disabled by default.

3.5.6 Integrated Pullup Resistors

The PC Card Standard (release 7.1) requires pullup resistors on various terminals to support both CardBus and 16-bit
card configurations. Unlike the PCI12XX, PCI1450, and PCI4450 which required external pullup resistors, the
PCI1520 has integrated all of these pullup resistors. The I/O buffer on the BVD1(STSCHG
the capability to switch either pullup or pulldown. The pullup resistor is turned on when a 16-bit PC Card is inserted,
and the pulldown resistor is turned on when a CardBus PC Card is inserted. This prevents unexpected CSTSCHG
signal assertion. The integrated pullup resistors are listed in Table 3−5.

)/CSTSCHG terminal has

3−8

Table 3−5. Integrated Pullup Resistors

SIGNAL NAME

A14/CPERR 109 R18 42 N06

A15/CIRDY 117 N18 50 P05

A19/CBLOCK 108 N14 41 N03

A20/CSTOP 111 P17 44 P02

A21/CDEVSEL 113 N15 46 P03

A22/CTRDY 116 N17 49 R02

BVD1(STSCHG)/CSTSCHG 141 H14 73 U09

BVD2(SPKR)/CAUDIO 140 H17 72 V09

CD1/CCD1 83 U11 15 H05
CD2/CCD2 144 G18 75 P09

INPACK/CREQ 130 K17 61 R07

READY/CINT 138 H19 69 V08

RESET/CRST 126 L15 58 W05

VS1/CVS1 137 J15 68 U08
VS2/CVS2 124 L18 56 P07

WAIT/CSERR 139 H18 71 W09

WP(IOIS16)/CCLKRUN 142 H15 74 R09

3.5.7 SPKROUT and CAUDPWM Usage

TERM. NUMBER SOCKET A TERM. NUMBER SOCKET B

PDV GHK PDV GHK

SPKROUT carries the digital audio signal from the PC Card to the system. When a 16-bit PC Card is configured for
I/O mode, the BVD2 terminal becomes SPKR
is referred to as CAUDIO. SPKR

passes a TTL-level digital audio signal to the PCI1520. The CardBus CAUDIO signal

. This terminal is also used in CardBus binary audio applications, and

also can pass a single-amplitude binary waveform. The binary audio signals from the two PC Card sockets are XORed
in the PCI1520 to produce SPKROUT. This output is enabled by bit 1 (SPKROUTEN) in the card control register (PCI
offset 91h, see Section 4.32).

Older controllers support CAUDIO in binary or PWM mode but use the same terminal (SPKROUT). Some audio chips
may not support both modes on one terminal and may have a separate terminal for binary and PWM. The PCI1520
implementation includes a signal for PWM, CAUDPWM, which can be routed to an MFUNC terminal. Bit 2
(AUD2MUX), located in the card control register, is programmed on a per-socket function basis to route a CardBus
CAUDIO PWM terminal to CAUDPWM. If both CardBus functions enable CAUDIO PWM routing to CAUDPWM, then
socket 0 audio takes precedence. See Section 4.30, Multifunction Routing Register, for details on configuring the
MFUNC terminals.

Figure 3−6 provides an illustration of a sample application using SPKROUT and CAUDPWM.

3−9

System

Core Logic

BINARY_SPKR

Speaker

Subsystem

PWM_SPKR

PCI1520

SPKROUT

CAUDPWM

Figure 3−6. Sample Application of SPKROUT and CAUDPWM

3.5.8 LED Socket Activity Indicators

The socket activity LEDs are provided to indicate when a PC Card is being accessed. The LEDA1 and LEDA2 signals
can be routed to the multifunction terminals. When configured for LED outputs, these terminals output an active high
signal to indicate socket activity. LEDA1 indicates socket 0 (card A) activity, and LEDA2 indicates socket 1 (card B)
activity. The LED_SKT output indicates socket activity to either socket 0 or socket 1. See Section 4.30, Multifunction
Routing Register,

The active-high LED signal is driven for 64-ms. When the LED is not being driven high, it is driven to a low state. Either
of the two circuits shown in Figure 3−7 can be implemented to provide LED signaling, and the board designer must
implement the circuit that best fits the application.

The LED activity signals are valid when a card is inserted, powered, and not in reset. For PC Card-16, the LED activity
signals are pulsed when READY/IREQ
IRDY

, or CREQ are active.

for details on configuring the multifunction terminals.

is low. For CardBus cards, the LED activity signals are pulsed if CFRAME,

Current Limiting

R ≈ 500 Ω

PCI1520

PCI1520

Application-

Specific Delay

Current Limiting

R ≈ 500 Ω

LED

LED

Figure 3−7. Two Sample LED Circuits

As indicated, the LED signals are driven for a period of 64 ms by a counter circuit. To avoid the possibility of the LEDs
appearing to be stuck when the PCI clock is stopped, the LED signaling is cut off when the SUSPEND signal is
asserted, when the PCI clock is to be stopped during the clock run protocol, or when in the D2 or D1 power state.

If any additional socket activity occurs during this counter cycle, then the counter is reset and the LED signal remains
driven. If socket activity is frequent (at least once every 64 ms), then the LED signals remain driven.

3.5.9 CardBus Socket Registers

The PCI1520 contains all registers for compatibility with the 1997 PC Card Standard. These registers exist as the
CardBus socket registers and are listed in Table 3−6.

3−10

3.6 Serial-Bus Interface

Table 3−6. CardBus Socket Registers

REGISTER NAME OFFSET

Socket event 00h
Socket mask 04h
Socket present state 08h
Socket force event 0Ch
Socket control 10h
Reserved 14h−1Ch
Socket power management 20h

The PCI1520 provides a serial-bus interface to load subsystem identification information and selected register
defaults from a serial EEPROM, and to provide a PC Card power-switch interface alternative to P
Section 3.5.2, P
with various I

2

C Power-Switch Interface (TPS222X), for details. The PCI1520 serial-bus interface is compatible

2

C and SMBus components.

2

C. See

3.6.1 Serial-Bus Interface Implementation

The PCI1520 defaults to serial bus interface are disabled. To enable the serial interface, a pulldown resistor must
be implemented on the LATCH terminal and the appropriate pullup resistor must be implemented on the SDA and
SCL signals, that is, the MFUNC1 and MFUNC4 terminals. When the interface is detected, bit 3 (SBDETECT) in the
serial bus control and status register (see Section 4.48) is set. The SBDETECT bit is cleared by a writeback of 1.

The PCI1520 implements a two-terminal serial interface with one clock signal (SCL) and one data signal (SDA). When
a pulldown resistor is provided on the LATCH terminal, the SCL signal is mapped to the MFUNC4 terminal and the
SDA signal is mapped to the MFUNC1 terminal. The PCI1520 drives SCL at nearly 100 kHz during data transfers,
which is the maximum specified frequency for standard mode I
A0h. Figure 3−8 illustrates an example application implementing the two-wire serial bus.

V

CC

Serial

EEPROM

A2

SCL

A1

SDA

A0

2

C. The serial EEPROM must be located at address

PCI1520

LATCH

MFUNC4
MFUNC1

Figure 3−8. Serial EEPROM Application

Some serial device applications may include PC Card power switches, ZV source switches, card ejectors, or other
devices that may enhance the user’s PC Card experience. The serial EEPROM device and PC Card power switches
are discussed in the sections that follow.

3.6.2 Serial-Bus Interface Protocol

The SCL and SDA signals are bidirectional, open-drain signals and require pullup resistors as shown in Figure 3−8.
The PCI1520, which supports up to 100-Kb/s data-transfer rate, is compatible with standard mode I
addressing.

All data transfers are initiated by the serial bus master. The beginning of a data transfer is indicated by a start
condition, which is signaled when the SDA line transitions to low state while SCL is in the high state, as illustrated

2

C using 7-bit

3−11

in Figure 3−9. The end of a requested data transfer is indicated by a stop condition, which is signaled by a low-to-high
transition of SDA while SCL is in the high state, as shown in Figure 3−9. Data on SDA must remain stable during the
high state of the SCL signal, as changes on the SDA signal during the high state of SCL are interpreted as control
signals, that is, a start or a stop condition.

SDA

SCL

Start

Condition

Stop

Condition

Change of

Data Allowed

Data Line Stable,

Data Valid

Figure 3−9. Serial-Bus Start/Stop Conditions and Bit Transfers

Data is transferred serially in 8-bit bytes. The number of bytes that may be transmitted during a data transfer is
unlimited; however, each byte must be completed with an acknowledge bit. An acknowledge (ACK) is indicated by
the receiver pulling the SDA signal low, so that it remains low during the high state of the SCL signal. Figure 3−10
illustrates the acknowledge protocol.

SCL From

Master

SDA Output

By Transmitter

SDA Output
By Receiver

123 789

Figure 3−10. Serial-Bus Protocol Acknowledge

The PCI1520 is a serial bus master; all other devices connected to the serial bus external to the PCI1520 are slave
devices. As the bus master, the PCI1520 drives the SCL clock at nearly 100 kHz during bus cycles and places SCL
in a high-impedance state (zero frequency) during idle states.

Typically, the PCI1520 masters byte reads and byte writes under software control. Doubleword reads are performed
by the serial EEPROM initialization circuitry upon a PCI reset and may not be generated under software control. See
Section 3.6.3, Serial-Bus EEPROM Application, for details on how the PCI1520 automatically loads the subsystem
identification and other register defaults through a serial-bus EEPROM.

Figure 3−11 illustrates a byte write. The PCI1520 issues a start condition and sends the 7-bit slave device address
and the command bit zero. A 0 in the R/W

command bit indicates that the data transfer is a write. The slave device
acknowledges if it recognizes the address. If no acknowledgment is received by the PCI1520, then an appropriate
status bit is set in the serial-bus control and status register (PCI offset B3h, see Section 4.48). The word address byte
is then sent by the PCI1520, and another slave acknowledgment is expected. Then the PCI1520 delivers the data
byte MSB first and expects a final acknowledgment before issuing the stop condition.

3−12

Slave Address Word Address

Data Byte

Sb6 b4b5 b3 b2 b1 b0 0 b7 b6 b5 b4 b3 b2 b1 b0AA

R/W

S/P = Start/Stop ConditionA = Slave Acknowledgement

b7 b6 b4b5 b3 b2 b1 b0 A P

Figure 3−11. Serial-Bus Protocol − Byte Write

Figure 3−12 illustrates a byte read. The read protocol is very similar to the write protocol, except the R/W

command
bit must be set to 1 to indicate a read-data transfer. In addition, the PCI1520 master must acknowledge reception
of the read bytes from the slave transmitter. The slave transmitter drives the SDA signal during read data transfers.
The SCL signal remains driven by the PCI1520 master.

Slave Address Word Address

Sb6 b4b5 b3 b2 b1 b0 0 b7 b6 b5 b4 b3 b2 b1 b0AA

Start

A = Slave Acknowledgement

R/W

Sb6 b4b5 b3 b2 b1 b0 1 A

Restart R/W

b7 b6 b4b5 b3 b2 b1 b0 M P

S/P = Start/Stop ConditionM = Master Acknowledgement

Slave Address

Data Byte

Stop

Figure 3−12. Serial-Bus Protocol − Byte Read

Figure 3−13 illustrates EEPROM interface doubleword data collection protocol.

Slave Address Word Address

S1 10 0 0 0 0 0 b7 b6 b5 b4 b3 b2 b1 b0AA

Start

Data Byte 3 M

R/W

Data Byte 2 Data Byte 1 Data Byte 0 M PMM

M = Master Acknowledgement

S1 1000001A

Restart

S/P = Start/Stop ConditionA = Slave Acknowledgement

Slave Address

R/W

Figure 3−13. EEPROM Interface Doubleword Data Collection

3.6.3 Serial-Bus EEPROM Application

When the PCI bus is reset and the serial-bus interface is detected, the PCI1520 attempts to read the subsystem
identification and other register defaults from a serial EEPROM. The registers and corresponding bits that can be
loaded with defaults through the EEPROM are provided in Table 3−7.

3−13

Table 3−7. Register- and Bit-Loading Map

EEPROM

OFFSET

00h Flag 01h: Load / FFh: do not load

01h PCI 04h

02h PCI 40h Subsystem vendor ID bits 7−0 ← bits 7−0
03h PCI 40h Subsystem vendor ID bits 15−8 ← bit 7−0
04h PCI 42h Subsystem ID bits 7−0 ← bits 7−0
05h PCI 42h Subsystem ID bits 15−8 ← bits 7−0
06h PCI 44h PC Card 16-bit I/F legacy-mode base address bits 7−1 ← bits 7−1
07h PCI 44h PC Card 16-bit I/F legacy-mode base address bits 15−8 ← bits 7−0
08h PCI 44h PC Card 16-bit I/F legacy-mode base address bit 23:16 ← bit 7:0
09h PCI 44h PC Card 16-bit I/F legacy-mode base address bits 31−24 ← bits 7−0
0Ah PCI 80h System control bits 7−0 ← bits 7−0
0Bh PCI 80h System control bits 15−8 ← bits 7−0
0Ch PCI 80h System control byte bits 31−24 ← bits 7−0
0Dh PCI 8Ch Multifunction routing bits 7−0 ← bits 7−0
0Eh PCI 8Ch Multifunction routing bits 15−8 ← bits 7−0
0Fh PCI 8Ch Multifunction routing bits 23−16 ← bits 7−0
10h PCI 8Ch Multifunction routing bits 27−24 ← bits 3−0
11h PCI 90h Retry status bits 7, 6 ← bits 7, 6
12h PCI 91h Card control bits 7, 5 ← bits 7, 6
13h PCI 92h Device control bits 6, 3−0 ← bits 6, 3−0
14h PCI 93h Diagnostic bits 7, 4−0 ← bits 7, 4−0
15h PCI A2h Power management capabilities bit 15 ← bit 7
16h ExCA 00h ExCA identification and revision bits 7−0 ← bits 7−0

17h

18h

REGISTER

OFFSET

CB Socket + 0Ch

(function 0)

CB Socket + 0Ch

(function 1)

REGISTER BITS LOADED FROM EEPROM

Command register, bits 8, 6−5, 2−0
Note: bits loaded per following:
b8 ← b7
b6 ← b6
b5 ← b5
b2 ← b2
b1 ← b1
b0 ← b0

Function 0 socket force event, bit 27 ← bit 3
Function 1 socket force event, bit 27 ← bit 3

This format must be followed for the PCI1520 to load initializations from a serial EEPROM. All bit fields must be
considered when programming the EEPROM.

The serial EEPROM is addressed at slave address 1010 000b by the PCI1520. All hardware address bits for the
EEPROM should be tied to the appropriate level to achieve this address. The serial EEPROM chip in the sample
application circuit (Figure 3−8) assumes the 1010b high-address nibble. The lower three address bits are terminal
inputs to the chip, and the sample application shows these terminal inputs tied to GND.

3.6.4 Accessing Serial-Bus Devices Through Software

The PCI1520 provides a programming mechanism to control serial bus devices through software. The programming
is accomplished through a doubleword of PCI configuration space at offset B0h. Table 3−8 lists the registers used
to program a serial-bus device through software.

3−14

Table 3−8. PCI1520 Registers Used to Program Serial-Bus Devices

PCI OFFSET REGISTER NAME DESCRIPTION

B0h Serial-bus data Contains the data byte to send on write commands or the received data byte on read commands.
B1h Serial-bus index

B2h

B3h

Serial-bus slave
address

Serial-bus control
and status

The content of this register is sent as the word address on byte writes or reads. This register is not used
in the quick command protocol.

Write transactions to this register initiate a serial-bus transaction. The slave device address and the

command selector are programmed through this register.

R/W
Read data valid, general busy, and general error status are communicated through this register. In

addition, the protocol-select bit is programmed through this register.

3.7 Programmable Interrupt Subsystem

Interrupts provide a way for I/O devices to let the microprocessor know that they require servicing. The dynamic
nature of PC Cards and the abundance of PC Card I/O applications require substantial interrupt support from the
PCI1520. The PCI1520 provides several interrupt signaling schemes to accommodate the needs of a variety of
platforms. The different mechanisms for dealing with interrupts in this device are based on various specifications and
industry standards. The ExCA register set provides interrupt control for some 16-bit PC Card functions, and the
CardBus socket register set provides interrupt control for the CardBus PC Card functions. The PCI1520 is, therefore,
backward compatible with existing interrupt control register definitions, and new registers have been defined where
required.

The PCI1520 detects PC Card interrupts and events at the PC Card interface and notifies the host controller using
one of several interrupt signaling protocols. T o simplify the discussion of interrupts in the PCI1520, PC Card interrupts
are classified either as card status change (CSC) or as functional interrupts.

The method by which any type of PCI1520 interrupt is communicated to the host interrupt controller varies from
system to system. The PCI1520 offers system designers the choice of using parallel PCI interrupt signaling, parallel
ISA-type IRQ interrupt signaling, or the IRQSER serialized ISA and/or PCI interrupt protocol. It is possible to use the
parallel PCI interrupts in combination with either parallel IRQs or serialized IRQs, as detailed in the sections that
follow. All interrupt signaling is provided through the seven multifunction terminals, MFUNC0−MFUNC6.

3.7.1 PC Card Functional and Card Status Change Interrupts

PC Card functional interrupts are defined as requests from a PC Card application for interrupt service and are
indicated by asserting specially-defined signals on the PC Card interface. Functional interrupts are generated by
16-bit I/O PC Cards and by CardBus PC Cards.

Card status change (CSC)-type interrupts are defined as events at the PC Card interface that are detected by the
PCI1520 and may warrant notification of host card and socket services software for service. CSC events include both
card insertion and removal from PC Card sockets, as well as transitions of certain PC Card signals.

Table 3−9 summarizes the sources of PC Card interrupts and the type of card associated with them. CSC and
functional interrupt sources are dependent on the type of card inserted in the PC Card socket. The three types of cards
that can be inserted into any PC Card socket are:

• 16-bit memory card

• 16-bit I/O card

• CardBus cards

3−15

Table 3−9. Interrupt Mask and Flag Registers

CardBus

Battery conditions

Battery conditions

memory

All PC Cards

All PC Cards

CARD TYPE EVENT MASK FLAG

16-bit memory

16-bit I/O

All 16-bit PC

Cards

Battery conditions (BVD1, BVD2) ExCA offset 05h/45h/805h bits 1 and 0 ExCA offset 04h/44h/804h bits 1 and 0
Wait states (READY) ExCA offset 05h/45h/805h bit 2 ExCA offset 04h/44h/804h bit 2
Change in card status (STSCHG) ExCA offset 05h/45h/805h bit 0 ExCA offset 04h/44h/804h bit 0
Interrupt request (IREQ) Always enabled PCI configuration offset 91h bit 0

Power cycle complete ExCA offset 05h/45h/805h bit 3 ExCA offset 04h/44h/804h bit 3
Change in card status (CSTSCHG) Socket mask bit 0 Socket event bit 0

Interrupt request (CINT) Always enabled PCI configuration offset 91h bit 0
Power cycle complete Socket mask bit 3 Socket event bit 3
Card insertion or removal Socket mask bits 2 and 1 Socket event bits 2 and 1

Functional interrupt events are valid only for 16-bit I/O and CardBus cards; that is, the functional interrupts are not
valid for 16-bit memory cards. Furthermore, card insertion and removal-type CSC interrupts are independent of the
card type.

Table 3−10. PC Card Interrupt Events and Description

CARD TYPE EVENT TYPE SIGNAL DESCRIPTION

A transition on BVD1 indicates a change in the
PC Card battery conditions.

A transition on BVD2 indicates a change in the
PC Card battery conditions.

A transition on READY indicates a change in the
ability of the memory PC Card to accept or provide
data.

The assertion of STSCHG indicates a status change
on the PC Card.

The assertion of IREQ indicates an interrupt request
from the PC Card.

The assertion of CSTSCHG indicates a status
change on the PC Card.

The assertion of CINT indicates an interrupt request
from the PC Card.

A transition on either CD1//CCD1 or CD2//CCD2
indicates an insertion or removal of a 16-bit or
CardBus PC Card.

An interrupt is generated when a PC Card power-up
cycle has completed.

16-bit

16-bit I/O

CardBus

(BVD1, BVD2)

Wait states

(READY)

Change in card

status (STSCHG

Interrupt request

(IREQ

)

Change in card

status (CSTSCHG)

Interrupt request

(CINT

)

Card insertion

or removal

Power cycle

complete

BVD1(STSCHG)//CSTSCHG

CSC

BVD2(SPKR)//CAUDIO

CSC READY(IREQ)//CINT

CSC BVD1(STSCHG)//CSTSCHG

)

Functional READY(IREQ)//CINT

CSC BVD1(STSCHG)//CSTSCHG

Functional READY(IREQ)//CINT

CSC

CSC N/A

CD1//CCD1,

CD2

//CCD2

The naming convention for PC Card signals describes the function for 16-bit memory, I/O cards, and CardBus. For
example, READY(IREQ
CardBus cards. The 16-bit memory card signal name is first, with the I/O card signal name second, enclosed in
parentheses. The CardBus signal name follows after a double slash (//).

The 1997 PC Card Standard describes the power-up sequence that must be followed by the PCI1520 when an
insertion event occurs and the host requests that the socket V
power-up sequence, the PCI1520 interrupt scheme can be used to notify the host system (see Table 3−10), denoted
by the power cycle complete event. This interrupt source is considered a PCI1520 internal event, because it depends
on the completion of applying power to the socket rather than on a signal change at the PC Card interface.

3−16

)//CINT includes READY for 16-bit memory cards, IREQ for 16-bit I/O cards, and CINT for

and VPP be powered. Upon completion of this

CC

3.7.2 Interrupt Masks and Flags

Host software may individually mask (or disable) most of the potential interrupt sources listed in Table 3−10 by setting
the appropriate bits in the PCI1520. By individually masking the interrupt sources listed, software can control those
events that cause a PCI1520 interrupt. Host software has some control over the system interrupt the PCI1520 asserts
by programming the appropriate routing registers. The PCI1520 allows host software to route PC Card CSC and PC
Card functional interrupts to separate system interrupts. Interrupt routing somewhat specific to the interrupt signaling
method used is discussed in more detail in the following sections.

When an interrupt is signaled by the PCI1520, the interrupt service routine must determine which of the events listed
in Table 3−9 caused the interrupt. Internal registers in the PCI1520 provide flags that report the source of an interrupt.
By reading these status bits, the interrupt service routine can determine the action to be taken.

Table 3−9 details the registers and bits associated with masking and reporting potential interrupts. All interrupts can
be masked except the functional PC Card interrupts, and an interrupt status flag is available for all types of interrupts.

Notice that there is not a mask bit to stop the PCI1520 from passing PC Card functional interrupts through to the
appropriate interrupt scheme. These interrupts are not valid until the card is properly powered, and there should never
be a card interrupt that does not require service after proper initialization.

Table 3−9 lists the various methods of clearing the interrupt flag bits. The flag bits in the ExCA registers (16-bit PC
Card-related interrupt flags) can be cleared using two different methods. One method is an explicit write of 1 to the
flag bit to clear and the other is by reading the flag bit register. The selection of flag bit clearing methods is made by
bit 2 (IFCMODE) in the ExCA global control register (ExCA offset 1Eh/5Eh/81Eh, see Section 5.20), and defaults to
the flag-cleared-on-read method.

The CardBus-related interrupt flags can be cleared by an explicit write of 1 to the interrupt flag in the socket event
register (see Section 6.1). Although some of the functionality is shared between the CardBus registers and the ExCA
registers, software should not program the chip through both register sets when a CardBus card is functioning.

3.7.3 Using Parallel IRQ Interrupts

The seven multifunction terminals, MFUNC6−MFUNC0, implemented in the PCI1520 can be routed to obtain a
subset of the ISA IRQs. The IRQ choices provide ultimate flexibility in PC Card host interruptions. To use the parallel
ISA-type IRQ interrupt signaling, software must program the device control register (PCI offset 92h, see
Section 4.33), to select the parallel IRQ signaling scheme. See Section 4.30, Multifunction Routing Register, for
details on configuring the multifunction terminals.

A system using parallel IRQs requires (at a minimum) one PCI terminal, INTA
is dictated by certain card and socket-services software. The INT A
for INTA
a maximum) six different IRQs to support legacy 16-bit PC Card functions.

As an example, suppose the six IRQs used by legacy PC Card applications are IRQ3, IRQ4, IRQ5, IRQ10, IRQ11,
and IRQ15. The multifunction routing register must be programmed to a value of 0FBA 5432h. This value routes the
MFUNC0 terminal to INTA
that INTA
PCI interrupts to the host.

signaling. The INTRTIE bit is used, in this case, to route socket B interrupt events to INTA. This leaves (at

signaling and routes the remaining terminals as illustrated in Figure 3−14. Not shown is

must also be routed to the programmable interrupt controller (PIC), or to some circuitry that provides parallel

requirement calls for routing the MFUNC0 terminal

, to signal CSC events. This requirement

3−17

PCI1520 PIC

INTRTIE BIT

MFUNC1
MFUNC2
MFUNC3
MFUNC4
MFUNC5
MFUNC6

IRQ3
IRQ4
IRQ5
IRQ10
IRQ11
IRQ15

Figure 3−14. IRQ Implementation

Power-on software is responsible for programming the multifunction routing register to reflect the IRQ configuration
of a system implementing the PCI1520. The multifunction routing register is shared between the two PCI1520
functions, and only one write to function 0 or 1 is necessary to configure the MFUNC6−MFUNC0 signals. Writing to
function 0 only is recommended. See Section 4.30, Multifunction Routing Register,

for details on configuring the

multifunction terminals.
The parallel ISA-type IRQ signaling from the MFUNC6−MFUNC0 terminals is compatible with the input signal

requirements of the 8259 PIC. The parallel IRQ option is provided for system designs that require legacy ISA IRQs.
Design constraints may demand more MFUNC6−MFUNC0 IRQ terminals than the PCI1520 makes available.

3.7.4 Using Parallel PCI Interrupts

Parallel PCI interrupts are available when exclusively in parallel PCI interrupt/parallel ISA IRQ signaling mode, and
when only IRQs are serialized with the IRQSER protocol. Both INTA
(MFUNC0 and MFUNC1). However, interrupts of both socket functions can be routed to INTA
(INTRTIE) is set in the system control register (PCI offset 80h, see Section 4.29).

The INTRTIE bit affects the read-only value provided through accesses to the interrupt pin register (PCI offset 3Dh,
see Section 4.24). When the INTRTIE bit is set, both functions return a value of 01h on reads from the interrupt pin
register for both parallel and serial PCI interrupts. Table 3−11 summarizes the interrupt signaling modes.

Table 3−11. Interrupt Pin Register Cross Reference

FUNCTION 0 FUNCTION 1

0 01h 02h
1 01h 01h

and INTB can be routed to MFUNC terminals

(MFUNC0) if bit 29

INTPIN

3.7.5 Using Serialized IRQSER Interrupts

The serialized interrupt protocol implemented in the PCI1520 uses a single terminal to communicate all interrupt
status information to the host controller. The protocol defines a serial packet consisting of a start cycle, multiple
interrupt indication cycles, and a stop cycle. All data in the packet is synchronous with the PCI clock. The packet data
describes 16 parallel ISA IRQ signals and the optional 4 PCI interrupts INTA
the IRQSER protocol, refer to the document Serialized IRQ Support for PCI Systems.

3.7.6 SMI Support in the PCI1520

The PCI1520 provides a mechanism for interrupting the system when power changes have been made to the PC
Card socket interfaces. The interrupt mechanism is designed to fit into a system maintenance interrupt (SMI) scheme.
SMI interrupts are generated by the PCI1520, when enabled, after a write cycle to either the socket control register
(CB offset 10h, see Section 6.5) of the CardBus register set, or the ExCA power control register (ExCA offset
02h/42h/802h, see Section 5.3) causes a power cycle change sequence to be sent on the power switch interface.

The SMI control is programmed through three bits in the system control register (PCI offset 80h, see Section 4.29).
These bits are SMIROUTE (bit 26), SMISTATUS (bit 25), and SMIENB (bit 24). Table 3−12 describes the SMI control
bits function.

3−18

, INTB, INTC, and INTD. For details on

Table 3−12. SMI Control

BIT NAME FUNCTION

SMIROUTE This shared bit controls whether the SMI interrupts are sent as a CSC interrupt or as IRQ2.
SMISTAT This socket dependent bit is set when an SMI interrupt is pending. This status flag is cleared by writing back a 1.
SMIENB When set, SMI interrupt generation is enabled. This bit is shared by functions 0 and 1.

If CSC SMI interrupts are selected, then the SMI interrupt is sent as the CSC on a per-socket basis. The CSC interrupt
can be either level or edge mode, depending upon the CSCMODE bit in the ExCA global control register (ExCA offset
1Eh/5Eh/81Eh, see Section 5.20).

If IRQ2 is selected by SMIROUTE, then the IRQSER signaling protocol supports SMI signaling in the IRQ2 IRQ/Data
slot. In a parallel ISA IRQ system, the support for an active low IRQ2 is provided only if IRQ2 is routed to either
MFUNC3 or MFUNC6 through the multifunction routing register (PCI offset 8Ch, see Section 4.30).

3.8 Power Management Overview

In addition to the low-power CMOS technology process used for the PCI1520, various features are designed into the
device to allow implementation of popular power-saving techniques. These features and techniques are discussed
in this section.

3.8.1 Integrated Low-Dropout Voltage Regulator (LDO-VR)

The PCI1520 requires 2.5-V core voltage. The core power can be supplied by the PCI1520 itself using the internal

LDO-VR. The core power can alternatively be supplied by an external power supply through the VR_PORT terminal.

Table 3−13 lists the requirements for both the internal core power supply and the external core power supply.

Table 3−13. Requirements for Internal/External 2.5-V Core Power Supply

SUPPLY V

Internal 3.3 V GND 2.5-V output Internal 2.5-V LDO-VR is enabled. A 1.0 µF bypass capacitor is required on the VR_PORT

External 3.3 V V

VR_EN VR_PORT NOTE

CC

CC

2.5-V input Internal 2.5-V LDO-VR is disabled. An external 2.5-V power supply, of minimum 50-mA

terminal for decoupling. This output is not for external use.

capacity, is required. A 0.1 µF bypass capacitor on the VR_PORT terminal is required.

3.8.2 Clock Run Protocol

The PCI CLKRUN feature is the primary method of power management on the PCI interface of the PCI1520. CLKRUN
signaling is provided through the MFUNC6 terminal. Since some chip sets do not implement CLKRUN, this is not
always available to the system designer, and alternate power-saving features are provided. For details on the
CLKRUN

The PCI1520 does not permit the central resource to stop the PCI clock under any of the following conditions:

protocol see the PCI Mobile Design Guide.

• Bit 1 (KEEPCLK) in the system control register (PCI offset 80h, see Section 4.29) is set.

• The 16-bit PC Card- resource manager is busy.

• The PCI1520 CardBus master state machine is busy. A cycle may be in progress on CardBus.

• The PCI1520 master is busy. There may be posted data from CardBus to PCI in the PCI1520.

• Interrupts are pending.

• The CardBus CCLK for either socket has not been stopped by the PCI1520 CCLKRUN

manager.

3−19

The PCI1520 restarts the PCI clock using the CLKRUN protocol under any of the following conditions:

• A 16-bit PC Card IREQ

or a CardBus CINT has been asserted by either card.

• A CardBus CBWAKE (CSTSCHG) or 16-bit PC Card STSCHG

• A CardBus attempts to start the CCLK using CCLKRUN

• A CardBus card arbitrates for the CardBus bus using CREQ

/RI event occurs in either socket.

.

.

3.8.3 CardBus PC Card Power Management

The PCI1520 implements its own card power-management engine that can turn off the CCLK to a socket when there
is no activity to the CardBus PC Card. The PCI clock-run protocol is followed on the CardBus CCLKRUN
to control this clock management.

interface

3.8.4 16-Bit PC Card Power Management

The COE bit (bit 7) of the ExCA power control register (ExCA offset 02h/42h/802h, see Section 5.3) and PWRDWN
bit (bit 0) of the ExCA global control register (ExCA offset 1Eh/5Eh/81Eh, see Section 5.20) bits are provided for 16-bit
PC Card power management. The COE bit places the card interface in a high-impedance state to save power. The
power savings when using this feature are minimal. The COE bit resets the PC Card when used, and the PWRDWN
bit does not. Furthermore, the PWRDWN bit is an automatic COE, that is, the PWRDWN performs the COE function
when there is no card activity.

NOTE: The 16-bit PC Card must implement the proper pullup resistors for the COE and
PWRDWN modes.

3.8.5 Suspend Mode

The SUSPEND signal, provided for backward compatibility, gates the PRST (PCI reset) signal and the GRST (global
reset) signal from the PCI1520. Besides gating PRST
in order to minimize power consumption.

and GRST, SUSPEND also gates PCLK inside the PCI1520

Gating PCLK does not create any issues with respect to the power switch interface in the PCI1520. This is because
the PCI1520 does not depend on the PCI clock to clock the power switch interface. There are two methods to clock
the power switch interface in the PCI1520:

• Use an external clock to the PCI1520 CLOCK terminal

• Use the internal oscillator

It should also be noted that asynchronous signals, such as card status change interrupts and RI_OUT
to the host system without a PCI clock. However, if card status change interrupts are routed over the serial interrupt
stream, then the PCI clock must be restarted in order to pass the interrupt, because neither the internal oscillator nor
an external clock is routed to the serial-interrupt state machine. Figure 3−15 is a signal diagram of the suspend
function.

, can be passed

3−20

RESET

GNT

SUSPEND

PCLK

RESETIN

SUSPENDIN

PCLKIN

External Terminals

Internal Signals

Figure 3−15. Signal Diagram of Suspend Function

3.8.6 Requirements for Suspend Mode

The suspend mode prevents the clearing of all register contents on the assertion of reset (PRST or GRST) which
would require the reconfiguration of the PCI1520 by software. Asserting the SUSPEND

signal places the PCI outputs
of the controller in a high-impedance state and gates the PCLK signal internally to the controller unless a PCI
transaction is currently in process (GNT
when SUSPEND

is asserted because the outputs are in a high-impedance state.

The GPIOs, MFUNC signals, and RI_OUT

is asserted). It is important that the PCI bus not be parked on the PCI1520

signal are all active during SUSPEND, unless they are disabled in the

appropriate PCI1520 registers.

3.8.7 Ring Indicate

The RI_OUT output is an important feature in power management, allowing a system to go into a suspended mode
and wake up on modem rings and other card events. TI-designed flexibility permits this signal to fit wide platform
requirements. RI_OUT

• A 16-bit PC Card modem in a powered socket asserts RI
incoming call.

• A powered down CardBus card asserts CSTSCHG (CBWAKE) requesting system and interface wake up.

• A powered CardBus card asserts CSTSCHG from the insertion/removal of cards or change in battery

voltage levels.

on the PCI1520 can be asserted under any of the following conditions:

to indicate to the system the presence of an

Figure 3−16 shows various enable bits for the PCI1520 RI_OUT

function; however, it does not show the masking of

CSC events. See Table 3−9 for a detailed description of CSC interrupt masks and flags.

3−21

RI_OUT Function

CSTSMASK

PC Card
Socket 0

Card

PC Card
Socket 1

Card

I/F

I/F

CSC

RINGEN

RI

CDRESUME

CSC

CSTSMASK

CSC

RINGEN

RI

CDRESUME

CSC

RIENB

RI_OUT

Figure 3−16. RI_OUT Functional Diagram

from the 16-bit PC Card interface is masked by bit 7 (RINGEN) in the ExCA interrupt and general control register

RI
(ExCA of fset 03h/43h/803h, see Section 5.4). This is programmed on a per-socket basis and is only applicable when
a 16-bit card is powered in the socket.

The CBWAKE signaling to RI_OUT

is enabled through the same mask as the CSC event for CSTSCHG. The mask
bit (bit 0, CSTSMASK) is programmed through the socket mask register (CB offset 04h, see Section 6.2) in the
CardBus socket registers.

RI_OUT

can be routed through any of three different pins, RI_OUT/PME, MFUNC2, or MFUNC4. The RI_OUT
function is enabled by setting RIENB in the card control register (PCI offset 91h, see Section 4.32). The PME function
is enabled by setting PMEEN in the power management control/status register (PCI offset A4h, see Section 4.38).
When RIMUX in the system control register (PCI offset 80h, see Section 4.29) is set to 0, both the RI_OUT
and the PME
the RI_OUT
using both the RI_OUT

function are routed to the RI_OUT/PME terminal. If both functions are enabled and RIMUX is set to 0,

/PME terminal becomes RI_OUT only and PME assertions will never be seen. Therefore, in a system

function and the PME function, RIMUX must be set to 1 and RI_OUT must be routed to either

function

MFUNC2 or MFUNC4.

3.8.8 PCI Power Management

The PCI Bus Power Management Interface Specification for PCI to CardBus Bridges establishes the infrastructure
required to let the operating system control the power of PCI functions. This is done by defining a standard PCI
interface and operations to manage the power of PCI functions on the bus. The PCI bus and the PCI functions can
be assigned one of seven power-management states, resulting in varying levels of power savings.

The seven power-management states of PCI functions are:

• D0-uninitialized − Before device configuration, device not fully functional

• D0-active − Fully functional state

• D1 − Low-power state

• D2 − Low-power state

• D3

• D3

• D3

− Low-power state. Transition state before D3

hot

− PME signal-generation capable. Main power is removed and VAUX is available.

cold

− No power and completely nonfunctional

off

cold

3−22

NOTE 1: In the D0-uninitialized state, the PCI1520 does not generate PME

NOTE 2: The PWR_STATE bits (bits 0−1) of the power-management control/status register (PCI offset A4h, see Section 4.38) only code for four

1) of the command register (PCI offset 04h, see Section 4.4) are both set, the PCI1520 switches the state to D0-active. Transition from
D3

to the D0-uninitialized state happens at the deassertion of PRST. The assertion of GRST forces the controller to the

cold

D0-uninitialized state immediately.

power states, D0, D1, D2, and D3
is not accessible in the D3

cold

. The differences between the three D3 states is invisible to the software because the controller

hot

or D3

off

state.

and/or interrupts. When the IO_EN and MEM_EN bits (bits 0 and

Similarly, bus power states of the PCI bus are B0−B3. The bus power states B0−B3 are derived from the device power
state of the originating bridge device.

For the operating system (OS) to manage the device power states on the PCI bus, the PCI function should support
four power-management operations. These operations are:

• Capabilities reporting

• Power status reporting

• Setting the power state

• System wake up

The OS identifies the capabilities of the PCI function by traversing the new capabilities list. The presence of
capabilities in addition to the standard PCI capabilities is indicated by a 1 in bit 4 (CAPLIST) of the status register (PCI
offset 06h, see Section 4.5).

The capabilities pointer provides access to the first item in the linked list of capabilities. For the PCI1520, a CardBus
bridge with PCI configuration space header type 2, the capabilities pointer is mapped to an offset of 14h. The first
byte of each capability register block is required to be a unique ID of that capability. PCI power management has been
assigned an ID o f 01h. The next byte is a pointer to the next pointer item in the list of capabilities. If there are no more
items in the list, then the next item pointer must be set to 0. The registers following the next item pointer are specific
to the capability of the function. The PCI power-management capability implements the register block outlined in
Table 3−14.

Table 3−14. Power-Management Registers

REGISTER NAME OFFSET

Power-management capabilities Next item pointer Capability ID A0h

Power-management control/

Data

status register bridge support
extensions

Power-management control/status (CSR) A4h

The power management capabilities register (PCI offset A2h, see Section 4.37) provides information on the
capabilities of the function related to power management. The power-management control/status register (PCI offset
A4h, see Section 4.38) enables control of power-management states and enables/monitors power-management
events. The data register is an optional register that can provide dynamic data.

For more information on PCI power management, see the PCI Bus Power Management Interface Specification for
PCI to CardBus Bridges.

3.8.9 CardBus Bridge Power Management

The PCI Bus Power Management Interface Specification for PCI to CardBus Bridges was approved by PCMCIA in
December of 1997. This specification follows the device and bus state definitions provided in the PCI Bus Power
Management Interface Specification published by the PCI Special Interest Group (SIG). The main issue addressed
in the PCI Bus Power Management Interface Specification for PCI to CardBus Bridges is wake-up from D3
without losing wake-up context (also called PME context).

hot

or D3

cold

3−23

The specific issues addressed by the PCI Bus Power Management Interface Specification for PCI to CardBus Bridges
for D3 wake up are as follows:

• Preservation of device context. The specification states that a reset must occur during the transition from
D3 to D0. Some method to preserve wake-up context must be implemented so that the reset does not clear
the PME

context registers.

• Power source in D3

if wake-up support is required from this state.

cold

The Texas Instruments PCI1520 addresses these D3 wake-up issues in the following manner:

• Two resets are provided to handle preservation of PME

− Global reset (GRST

) is used only on the initial boot up of the system after power up. It places the

context bits:

PCI1520 in its default state and requires BIOS to configure the device before becoming fully functional.

− PCI reset (PRST

then PME

context is preserved. If PME is not enabled, then PRST acts the same as a normal PCI reset.

Please see the master list of PME

• Power source in D3
auxiliary power source must be supplied to the PCI1520 V

) has dual functionality based on whether PME is enabled or not. If PME is enabled,

context bits in Section 3.8.11.

if wake-up support is required from this state. Since VCC is removed in D3

cold

terminals. Consult the PCI14xx

CC

cold

, an

Implementation Guide for D3 Wake-Up or the PCI Power Management Interface Specification for PCI to
CardBus Bridges for further information.

3.8.10 ACPI Support

The Advanced Configuration and Power Interface (ACPI) Specification provides a mechanism that allows unique
pieces of hardware to be described to the ACPI driver. The PCI1520 of fers a generic interface that is compliant with
ACPI design rules.

Two doublewords of general-purpose ACPI programming bits reside in PCI1520 PCI configuration space at offset
A8h. The programming model is broken into status and control functions. In compliance with ACPI, the top level event
status and enable bits reside in the general-purpose event status register (PCI offset A8h, see Section 4.41) and
general-purpose event enable register (PCI offset AAh, see Section 4.42). The status and enable bits are
implemented as defined by ACPI and illustrated in Figure 3−17.

Status Bit

Event Input

Enable Bit

Event Output

Figure 3−17. Block Diagram of a Status/Enable Cell

The status and enable bits generate an event that allows the ACPI driver to call a control method associated with the
pending status bit. The control method can then control the hardware by manipulating the hardware control bits or
by investigating child status bits and calling their respective control methods. A hierarchical implementation would
be somewhat limiting, however, as upstream devices would have to remain in some level of power state to report
events.

For more information of ACPI, see the Advanced Configuration and Power Interface (ACPI) Specification.

3−24

3.8.11 Master List of PME Context Bits and Global Reset-Only Bits

If the PME enable bit (bit 8) of the power-management control/status register (PCI offset A4h, see section 4.38) is
asserted, then the assertion of PRST
then the PME

context bits are cleared with PRST. The PME context bits are:

• Bridge control register (PCI offset 3Eh): bit 6

• System control register (PCI offset 80h): bits 10, 9, 8

• Power-management control/status register (PCI offset A4h): bits 15, 8

• ExCA power control register (ExCA offset 802h): bits 7, 5

• ExCA interrupt and general control register (ExCA offset 803h): bits 6−5

• ExCA card status change register (ExCA offset 804h): bits 11−8, 3−0

• ExCA card status-change-interrupt configuration register (ExCA offset 805h): bits 3−0

• CardBus socket event register (CardBus offset 00h): bits 3−0

• CardBus socket mask register (CardBus offset 04h): bits 3−0

• CardBus socket present state register (CardBus offset 08h): bits 13−7, 5−1

• CardBus socket control register (CardBus offset 10h): bits 6−4, 2−0

will not clear the following PME context bits. If the PME enable bit is not asserted,

†

, 4−3, 1−0 († 82365SL mode only)

Global reset places all registers in their default state regardless of the state of the PME
is gated only by the SUSPEND
thus preserving all register contents. The registers cleared only by GRST

signal. This means that assertion of SUSPEND blocks the GRST signal internally,

are:

• Status register (PCI offset 06h): bits 15−11, 8

• Secondary status register (PCI offset 16h): bits 15−11, 8

• Interrupt pin register (PCI offset 3Dh): bits 1,0 (function 1 only)

• Subsystem vendor ID register (PCI offset 40h): bits 15–0

• Subsystem ID register (PCI offset 42h): bits 15–0

• PC Card 16-bit legacy mode base address register (PCI offset 44h): bits 31–1

• System control register (PCI offset 80h): bits 31–29, 27–13, 11, 6−0

• Multifunction routing register (PCI offset 8Ch): bits 27−0

• Retry status register (PCI offset 90h): bits 7−5, 3, 1

• Card control register (PCI offset 91h): bits 7−5, 2−0

• Device control register (PCI offset 92h): bits 7−5, 3−0

• Diagnostic register (PCI offset 93h): bits 7−0

• Power management capabilities register (PCI offset A2h): bit 15

• General-purpose event status register (PCI offset A8h): bits 15−14

• General-purpose event enable register (PCI offset AAh): bits 15−14, 11, 8, 4−0

• General-purpose output (PCI offset AEh): bits 4−0

• Serial bus data (PCI offset B0h): bits 7−0

• Serial bus index (PCI offset B1h): bits 7−0

• Serial bus slave address register (PCI offset B2h): bits 7−0

• Serial bus control and status register (PCI offset B3h): bits 7, 5−0

• ExCA identification and revision register (ExCA offset 00h): bits 7−0

• ExCA global control register (ExCA offset 1Eh): bits 2−0

• Socket present state register (CardBus offset 08h): bit 29

• Socket power management register (CardBus offset 20h): bits 25−24

enable bit. The GRST signal

3−25

3−26

4 PC Card Controller Programming Model

This section describes the PCI1520 PCI configuration registers that make up the 256-byte PCI configuration header
for each PCI1520 function. As noted, some bits are global in nature and are accessed only through function 0.

4.1 PCI Configuration Registers (Functions 0 and 1)

The PCI1520 is a multifunction PCI device, and the PC Card controller is integrated as PCI functions 0 and 1. The
configuration header is compliant with the PCI Local Bus Specification as a CardBus bridge header and is PC 99
compliant as well. Table 4−1 shows the PCI configuration header , which includes both the predefined portion of the
configuration space and the user-definable registers.

Table 4−1. PCI Configuration Registers (Functions 0 and 1)

REGISTER NAME OFFSET

Device ID Vendor ID 00h

Status Command 04h

Class code Revision ID 08h

BIST Header type Latency timer Cache line size 0Ch

CardBus socket/ExCA base address 10h

Secondary status Reserved Capability pointer 14h

CardBus latency timer Subordinate bus number CardBus bus number PCI bus number 18h

CardBus Memory base register 0 1Ch

CardBus Memory limit register 0 20h

CardBus Memory base register 1 24h

CardBus Memory limit register 1 28h

CardBus I/O base register 0 2Ch

CardBus I/O limit register 0 30h

CardBus I/O base register 1 34h

CardBus I/O limit register 1 38h
Bridge control Interrupt pin Interrupt line 3Ch
Subsystem ID Subsystem vendor ID 40h

PC Card 16-bit I/F legacy-mode base address 44h

Reserved 48h−7Ch

System control 80h

Reserved 84h−88h

Multifunction routing 8Ch

Diagnostic Device control Card control Retry status 90h

Reserved 94h−9Ch

Power-management capabilities Next-item pointer Capability ID A0h

Power-management

Power-management data

General-purpose event enable General-purpose event status A8h

General-purpose output General-purpose input ACh

Serial bus control/status Serial bus slave address Serial bus index Serial bus data B0h

control/status bridge

support extensions

Power-management control/status A4h

Reserved B4h−FCh

4−1

A bit description table, typically included when a register contains bits of more than one type or purpose, indicates
bit field names, which appear in the signal column; a detailed field description, which appears in the function column;
and field access tags, which appear in the type column of the bit description table. Table 4−2 describes the field
access tags.

Table 4−2. Bit Field Access T ag Descriptions

ACCESS TAG NAME MEANING

R Read Field may be read by software.

W Write Field may be written by software to any value.

S Set Field may be set by a write of 1. Writes of 0 have no effect.
C Clear Field may be cleared by a write of 1. Writes of 0 have no effect.
U Update Field may be autonomously updated by the PCI1520.

4.2 Vendor ID Register

This 16-bit register contains a value allocated by the PCI Special Interest Group (SIG) and identifies the manufacturer
of the PCI device. The vendor ID assigned to TI is 104Ch.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Vendor ID
Type R R R R R R R R R R R R R R R R
Default 0 0 0 1 0 0 0 0 0 1 0 0 1 1 0 0

Register: Vendor ID
Offset: 00h (functions 0, 1)
Type: Read-only
Default: 104Ch

4.3 Device ID Register

This 16-bit register contains a value assigned to the PCI1520 by TI. The device identification for the PCI1520 is
AC55h.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Device ID
Type R R R R R R R R R R R R R R R R
Default 1 0 1 0 1 1 0 0 0 1 0 1 0 1 0 1

Register: Device ID
Offset: 02h (functions 0, 1)
Type: Read-only
Default: AC55h

4−2

4.4 Command Register

The command register provides control over the PCI1520 interface to the PCI bus. All bit functions adhere to the
definitions in PCI Local Bus Specification. None of the bit functions in this register is shared between the two PCI1520
PCI functions. Two command registers exist in the PCI1520, one for each function. Software must manipulate the
two PCI1520 functions as separate entities when enabling functionality through the command register. The
SERR_EN and PERR_EN enable bits in this register are internally wired-OR between the two functions, and these
control bits appear separately according to their software function. See Table 4−3 for a complete description of the
register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Command
Type R R R R R R R RW R RW RW R R RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Command
Offset: 04h
Type: Read-only, Read/Write
Default: 0000h

Table 4−3. Command Register Description

BIT SIGNAL TYPE FUNCTION

15−10 RSVD R Reserved. Bits 15−10 return 0s when read.

9 FBB_EN R

8 SERR_EN RW

7 STEP_EN R

6 PERR_EN RW

5 VGA_EN RW

4 MWI_EN R

3 SPECIAL R

2 MAST_EN RW

1 MEM_EN RW

0 IO_EN RW

Fast back-to-back enable. The PCI1520 does not generate fast back-to-back transactions; therefore, bit 9
returns 0 when read.

System error (SERR) enable. Bit 8 controls the enable for the SERR driver on the PCI interface. SERR can
be asserted after detecting an address parity error on the PCI bus. Both bits 8 and 6 must be set for the
PCI1520 to report address parity errors.

0 = Disable SERR
1 = Enable SERR

Address/data stepping control. The PCI1520 does not support address/data stepping; therefore, bit 7 is
hardwired to 0.

Parity error response enable. Bit 6 controls the PCI1520 response to parity errors through PERR. Data parity
errors are indicated by asserting PERR

0 = PCI1520 ignores detected parity error (default)
1 = PCI1520 responds to detected parity errors

VGA palette snoop. Bit 5 controls how PCI devices handle accesses to video graphics array (VGA) palette
registers.

Memory write-and-invalidate enable. Bit 4 controls whether a PCI initiator device can generate memory
write-and-Invalidate commands. The PCI1520 controller does not support memory write-and-invalidate
commands, but uses memory write commands instead; therefore, this bit is hardwired to 0.

Special cycles. Bit 3 controls whether or not a PCI device ignores PCI special cycles. The PCI1520 does
not respond to special cycle operations; therefore, this bit is hardwired to 0.

Bus master control. Bit 2 controls whether or not the PCI1520 can act as a PCI bus initiator (master). The
PCI1520 can take control of the PCI bus only when this bit is set.

0 = Disables the PCI1520 from generating PCI bus accesses (default)
1 = Enables the PCI1520 to generate PCI bus accesses

Memory space enable. Bit 1 controls whether or not the PCI1520 can claim cycles in PCI memory space.

0 = Disables the PCI1520 from responding to memory space accesses (default)
1 = Enables the PCI1520 to respond to memory space accesses

I/O space control. Bit 0 controls whether or not the PCI1520 can claim cycles in PCI I/O space.

0 = Disables the PCI1520 from responding to I/O space accesses (default)
1 = Enables the PCI1520 to respond to I/O space accesses

output driver (default)

output driver

, whereas address parity errors are indicated by asserting SERR.

4−3

4.5 Status Register

The status register provides device information to the host system. Bits in this register can be read normally. A bit
in the status register is reset when a 1 is written to that bit location; a 0 written to a bit location has no effect. All bit
functions adhere to the definitions in the PCI Local Bus Specification. PCI bus status is shown through each function.
See Table 4−4 for a complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Status
Type RC RC RC RC RC R R RC R R R R R R R R
Default 0 0 0 0 0 0 1 0 0 0 0 1 0 0 0 0

Register: Status
Offset: 06h (functions 0, 1)
Type: Read-only, Read/Clear
Default: 0210h

Table 4−4. Status Register Description

BIT SIGNAL TYPE FUNCTION

15 PAR_ERR RC Detected parity error. Bit 15 is set when a parity error is detected (either address or data).
14 SYS_ERR RC Signaled system error . Bit 14 is set when SERR is enabled and the PCI1520 signals a system error to the host.

13 MABORT RC

12 TABT_REC RC

11 TABT_SIG RC

10−9 PCI_SPEED R

8 DATAPAR RC

7 FBB_CAP R

6 UDF R

5 66MHZ R

4 CAPLIST R

3−0 RSVD R Reserved. Bits 3−0 return 0s when read.

Received master abort. Bit 13 is set when a cycle initiated by the PCI1520 on the PCI bus is terminated by a
master abort.

Received target abort. Bit 12 is set when a cycle initiated by the PCI1520 on the PCI bus is terminated by a target
abort.

Signaled target abort. Bit 11 is set by the PCI1520 when it terminates a transaction on the PCI bus with a target
abort.

DEVSEL timing. These bits encode the timing of DEVSEL and are hardwired 01b, indicating that the PCI1520
asserts PCI_SPEED at a medium speed on nonconfiguration cycle accesses.

Data parity error detected.

0 = The conditions for setting bit 8 have not been met.
1 = A data parity error occurred, and the following conditions were met:

a. PERR
b. The PCI1520 was the bus master during the data parity error.
c. The parity error response bit is set in the command register (PCI offset 04h, see Section 4.4).

Fast back-to-back capable. The PCI1520 cannot accept fast back-to-back transactions; therefore, bit 7 is
hardwired to 0.

User-definable feature support. The PCI1520 does not support the user-definable features; therefore, bit 6 is
hardwired to 0.

66-MHz capable. The PCI1520 operates at a maximum PCLK frequency of 33 MHz; therefore, bit 5 is hardwired
to 0.

Capabilities list. Bit 4 returns 1 when read. This bit indicates that capabilities in addition to standard PCI
capabilities are implemented. The linked list of PCI power-management capabilities is implemented in this
function.

was asserted by any PCI device including the PCI1520.

4−4

4.6 Revision ID Register

The revision ID register indicates the silicon revision of the PCI1520.

Bit 7 6 5 4 3 2 1 0
Name Revision ID
Type R R R R R R R R
Default 0 0 0 0 0 0 0 1

Register: Revision ID
Offset: 08h (functions 0, 1)
Type: Read-only
Default: 01h

4.7 PCI Class Code Register

The class code register recognizes PCI1520 functions 0 and 1 as a bridge device (06h) and a CardBus bridge device
(07h), with a 00h programming interface.

Bit 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name PCI class code

Base class Subclass Programming interface

Type R R R R R R R R R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 1 1 0 0 0 0 0 0 1 1 1 0 0 0 0 0 0 0 0

Register: PCI class code
Offset: 09h (functions 0, 1)
Type: Read-only
Default: 06 0700h

4.8 Cache Line Size Register

The cache line size register is programmed by host software to indicate the system cache line size.

Bit 7 6 5 4 3 2 1 0
Name Cache line size
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: Cache line size
Offset: 0Ch (functions 0, 1)
Type: Read/Write
Default: 00h

4−5

4.9 Latency Timer Register

The latency timer register specifies the latency time for the PCI1520 in units of PCI clock cycles. When the PCI1520
is a PCI bus initiator and asserts FRAME
before the PCI1520 transaction has terminated, then the PCI1520 terminates the transaction when its GNT

, the latency timer begins counting from zero. If the latency timer expires

is
deasserted. This register is separate for each of the two PCI1520 functions. This allows platforms to prioritize use
of the PCI bus by the two PCI1520 functions.

Bit 7 6 5 4 3 2 1 0
Name Latency timer
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: Latency timer
Offset: 0Dh
Type: Read/Write
Default: 00h

4.10 Header Type Register

This register returns 82h when read, indicating that the PCI1520 function 0 and 1 configuration spaces adhere to the
CardBus bridge PCI header. The CardBus bridge PCI header ranges from PCI register 000h to 7Fh, and 80h to FFh
is user-definable extension registers.

Bit 7 6 5 4 3 2 1 0
Name Header type
Type R R R R R R R R
Default 1 0 0 0 0 0 1 0

Register: Header type
Offset: 0Eh (functions 0, 1)
Type: Read/Write
Default: 82h

4.11 BIST Register

Because the PCI1520 does not support a built-in self-test (BIST), this register returns the value of 00h when read.

Bit 7 6 5 4 3 2 1 0
Name BIST
Type R R R R R R R R
Default 0 0 0 0 0 0 0 0

Register: BIST
Offset: 0Fh (functions 0, 1)
Type: Read-only
Default: 00h

4−6

4.12 CardBus Socket/ExCA Base-Address Register

The CardBus socket/ExCA base-address register is programmed with a base address referencing the CardBus
socket registers and the memory-mapped ExCA register set. Bits 31−12 are read/write and allow the base address
to be located anywhere in the 32-bit PCI memory address space on a 4-Kbyte boundary. Bits 11−0 are read-only,
returning 0s when read. When software writes all 1s to this register, the value read back is FFFF F000h, indicating
that at least 4 Kbytes of memory address space are required. The CardBus registers start at offset 000h, and the
memory-mapped ExCA registers begin at offset 800h. Because this register is not shared by functions 0 and 1,
mapping of each socket control is performed separately.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name CardBus socket/ExCA base-address
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name CardBus socket/ExCA base-address
Type RW RW RW RW R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: CardBus socket/ExCA base-address
Offset: 10h
Type: Read-only, Read/Write
Default: 0000 0000h

4.13 Capability Pointer Register

The capability pointer register provides a pointer into the PCI configuration header where the PCI
power-management register block resides. PCI header doublewords at A0h and A4h provide the power-management
(PM) registers. Each socket has its own capability pointer register. This register returns A0h when read.

Bit 7 6 5 4 3 2 1 0
Name Capability pointer
Type R R R R R R R R
Default 1 0 1 0 0 0 0 0

Register: Capability pointer
Offset: 14h
Type: Read-only
Default: A0h

4−7

4.14 Secondary Status Register

The secondary status register is compatible with the PCI-to-PCI bridge secondary status register and indicates
CardBus-related device information to the host system. This register is very similar to the status register (offset 06h,
see Section 4.5); status bits are cleared by writing a 1. See Table 4−5 for a complete description of the register
contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Secondary status
Type RC RC RC RC RC R R RC R R R R R R R R
Default 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0

Register: Secondary status
Offset: 16h
Type: Read-only, Read/Clear
Default: 0200h

Table 4−5. Secondary Status Register Description

BIT SIGNAL TYPE FUNCTION

15 CBPARITY RC Detected parity error. Bit 15 is set when a CardBus parity error is detected (either address or data).
14 CBSERR RC

13 CBMABORT RC

12 REC_CBTA RC

11 SIG_CBTA RC

10−9 CB_SPEED R

8 CB_DPAR RC

7 CBFBB_CAP R

6 CB_UDF R

5 CB66MHZ R

4−0 RSVD R Reserved. Bits 4−0 return 0s when read.

Signaled system error. Bit 14 is set when CSERR is signaled by a CardBus card. The PCI1520 does not
assert CSERR

Received master abort. Bit 13 is set when a cycle initiated by the PCI1520 on the CardBus bus has been
terminated by a master abort.

Received target abort. Bit 12 is set when a cycle initiated by the PCI1520 on the CardBus bus is terminated
by a target abort.

Signaled target abort. Bit 11 is set by the PCI1520 when it terminates a transaction on the CardBus bus
with a target abort.

CDEVSEL timing. These bits encode the timing of CDEVSEL and are hardwired 01b, indicating that the
PCI1520 asserts CB_SPEED at a medium speed.

CardBus data parity error detected.

0 = The conditions for setting bit 8 have not been met.
1 = A data parity error occurred and the following conditions were met:

Fast back-to-back capable. The PCI1520 cannot accept fast back-to-back transactions; therefore, bit 7
is hardwired to 0.

User-definable feature support. The PCI1520 does not support user-definable features; therefore, bit 6
is hardwired to 0.

66-MHz capable. The PCI1520 CardBus interface operates at a maximum CCLK frequency of 33 MHz;
therefore, bit 5 is hardwired to 0.

.

a. CPERR
b. The PCI1520 was the bus master during the data parity error.
c. The parity error response bit is set in the bridge control.

was asserted on the CardBus interface.

4−8

4.15 PCI Bus Number Register

This register is programmed by the host system to indicate the bus number of the PCI bus to which the PCI1520 is
connected. The PCI1520 uses this register in conjunction with the CardBus bus number and subordinate bus number
registers to determine when to forward PCI configuration cycles to its secondary buses.

Bit 7 6 5 4 3 2 1 0
Name PCI bus number
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: PCI bus number
Offset: 18h (functions 0, 1)
Type: Read/Write
Default: 00h

4.16 CardBus Bus Number Register

This register is programmed by the host system to indicate the bus number of the CardBus bus to which the PCI1520
is connected. The PCI1520 uses this register in conjunction with the PCI bus number and subordinate bus number
registers to determine when to forward PCI configuration cycles to its secondary buses. This register is separate for
each PCI1520 controller function.

Bit 7 6 5 4 3 2 1 0
Name CardBus bus number
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: CardBus bus number
Offset: 19h
Type: Read/Write
Default: 00h

4.17 Subordinate Bus Number Register

This register is programmed by the host system to indicate the highest-numbered bus below the CardBus bus. The
PCI1520 uses this register in conjunction with the PCI bus number and CardBus bus number registers to determine
when to forward PCI configuration cycles to its secondary buses. This register is separate for each CardBus controller
function.

Bit 7 6 5 4 3 2 1 0
Name Subordinate bus number
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: Subordinate bus number
Offset: 1Ah
Type: Read/Write
Default: 00h

4−9

4.18 CardBus Latency Timer Register

This register is programmed by the host system to specify the latency timer for the PCI1520 CardBus interface in units
of CCLK cycles. When the PCI1520 is a CardBus initiator and asserts CFRAME

, the CardBus latency timer begins
counting. If the latency timer expires before the PCI1520 transaction has terminated, then the PCI1520 terminates
the transaction at the end of the next data phase. A recommended minimum value for this register is 40h, which allows
most transactions to be completed.

Bit 7 6 5 4 3 2 1 0
Name CardBus latency timer
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: CardBus latency timer
Offset: 1Bh (functions 0, 1)
Type: Read/Write
Default: 00h

4.19 Memory Base Registers 0, 1

The memory base registers indicate the lower address of a PCI memory address range. These registers are used
by the PCI1520 to determine when to forward a memory transaction to the CardBus bus and when to forward a
CardBus cycle to PCI. Bits 31−12 of these registers are read/write and allow the memory base to be located anywhere
in the 32-bit PCI memory space on 4-Kbyte boundaries. Bits 11−0 are read-only and always return 0s. Write
transactions to these bits have no effect. Bits 8 and 9 of the bridge control register specify whether memory windows
0 and 1 are prefetchable or nonprefetchable. The memory base register or the memory limit register must be nonzero
for the PCI1520 to claim any memory transactions through CardBus memory windows (that is, these windows are
not enabled by default to pass the first 4 Kbytes of memory to CardBus).

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name Memory base registers 0, 1
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Memory base registers 0, 1
Type RW RW RW RW R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

4−10

Register: Memory base registers 0, 1
Offset: 1Ch, 24h
Type: Read-only, Read/Write
Default: 0000 0000h

4.20 Memory Limit Registers 0, 1

The memory limit registers indicate the upper address of a PCI memory address range. These registers are used
by the PCI1520 to determine when to forward a memory transaction to the CardBus bus and when to forward a
CardBus cycle to PCI. Bits 31−12 of these registers are read/write and allow the memory base to be located anywhere
in the 32-bit PCI memory space on 4-Kbyte boundaries. Bits 11−0 are read-only and always return 0s. Write
transactions to these bits have no effect. Bits 8 and 9 of the bridge control register specify whether memory windows
0 and 1 are prefetchable or nonprefetchable. The memory base register or the memory limit register must be nonzero
for the PCI1520 to claim any memory transactions through CardBus memory windows; that is, these windows are
not enabled by default to pass the first 4 Kbytes of memory to CardBus.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name Memory limit registers 0, 1
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Memory limit registers 0, 1
Type RW RW RW RW R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Memory limit registers 0, 1
Offset: 20h, 28h
Type: Read-only, Read/Write
Default: 0000 0000h

4.21 I/O Base Registers 0, 1

The I/O base registers indicate the lower address of a PCI I/O address range. These registers are used by the
PCI1520 to determine when to forward an I/O transaction to the CardBus bus and when to forward a CardBus cycle
to the PCI bus. The lower 16 bits of this register locate the bottom of the I/O window within a 64-Kbyte page, and the
upper 16 bits (31−16) are a page register which locates this 64-Kbyte page in 32-bit PCI I/O address space. Bits 31−2
are read/write. Bits 1 and 0 are read-only and always return 0s, forcing I/O windows to be aligned on a natural
doubleword boundary.

NOTE: Either the I/O base register or the I/O limit register must be nonzero to enable any I/O
transactions.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name I/O base registers 0, 1
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name I/O base registers 0, 1
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: I/O base registers 0, 1
Offset: 2Ch, 34h
Type: Read-only, Read/Write
Default: 0000 0000h

4−11

4.22 I/O Limit Registers 0, 1

The I/O limit registers indicate the upper address of a PCI I/O address range. These registers are used by the PCI1520
to determine when to forward an I/O transaction to the CardBus bus and when to forward a CardBus cycle to PCI.
The lower 16 bits of this register locate the top of the I/O window within a 64-Kbyte page, and the upper 16 bits are
a page register that locates this 64-Kbyte page in 32-bit PCI I/O address space. Bits 15−2 are read/write and allow
the I/O limit address to be located anywhere in the 64-Kbyte page (indicated by bits 31−16 of the appropriate I/O base)
on doubleword boundaries.

Bits 31−16 are read-only and always return 0s when read. The page is set in the I/O base register. Bits 1 and 0 are
read-only and always return 0s, forcing I/O windows to be aligned on a natural doubleword boundary. Write
transactions to read-only bits have no effect. The PCI1520 assumes that the lower 2 bits of the limit address are 1s.

NOTE: The I/O base or the I/O limit register must be nonzero to enable an I/O transaction.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name I/O limit registers 0, 1
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name I/O limit registers 0, 1
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: I/O limit registers 0, 1
Offset: 30h, 38h
Type: Read-only, Read/Write
Default: 0000 0000h

4.23 Interrupt Line Register

The interrupt line register communicates interrupt line routing information. Each PCI1520 function has an interrupt
line register.

Bit 7 6 5 4 3 2 1 0
Name Interrupt line
Type RW RW RW RW RW RW RW RW
Default 1 1 1 1 1 1 1 1

Register: Interrupt line
Offset: 3Ch
Type: Read/Write
Default: FFh

4−12

4.24 Interrupt Pin Register

INTRTIE BIT

The value read from the interrupt pin register is function dependent and depends on the interrupt signaling mode,
selected through bits 2−1 (INTMODE field) of the device control register (PCI offset 92h, see Section 4.33) and the
state of bit 29 (INTRTIE) in the system control register (PCI offset 80h, see Section 4.29). When the INTRTIE bit is
set, this register reads 01h (INTA

Bit 7 6 5 4 3 2 1 0
Name Interrupt pin
Type R R R R R R R R
Default 0 0 0 0 0 0 X X

Register: Interrupt pin
Offset: 3Dh
Type: Read-only
Default: 0Xh

) for both functions. See Table 4−6 for a complete description of the register contents.

Table 4−6. Interrupt Pin Register Cross-Reference

INTPIN

FUNCTION 0 FUNCTION 1

0 01h 02h
1 01h 01h

4−13

4.25 Bridge Control Register

The bridge control register provides control over various PCI1520 bridging functions. Some bits in this register are
global and are accessed only through function 0. See Table 4−7 for a complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Bridge control
Type R R R R R RW RW RW RW RW RW R RW RW RW RW
Default 0 0 0 0 0 0 1 1 0 1 0 0 0 0 0 0

Register: Bridge control
Offset: 3Eh (functions 0, 1)
Type: Read-only, Read/Write
Default: 0340h

Table 4−7. Bridge Control Register Description

BIT SIGNAL TYPE FUNCTION

15−11 RSVD R Reserved. Bits 15−11 return 0s when read.

Write posting enable. Enables write posting to and from the CardBus sockets. Write posting enables

10 POSTEN RW

9 PREFETCH1 RW

8 PREFETCH0 RW

7 INTR RW

6 CRST RW

†

5

MABTMODE RW

4 RSVD R Reserved. Bit 4 returns 0 when read.
3 VGAEN RW

2 ISAEN RW

†

1

0

†

This bit is global and is accessed only through function 0.

CSERREN RW

†

CPERREN RW

posting of write data on burst cycles. Operating with write posting disabled inhibits performance on burst
cycles. Note that burst write data can be posted, but various write transactions may not. Bit 10 is socket
dependent and is not shared between functions 0 and 1.

Memory window 1 type. Bit 9 specifies whether or not memory window 1 is prefetchable. This bit is socket
dependent. Bit 9 is encoded as:

0 = Memory window 1 is nonprefetchable.
1 = Memory window 1 is prefetchable (default).

Memory window 0 type. Bit 8 specifies whether or not memory window 0 is prefetchable. This bit is
encoded as:

0 = Memory window 0 is nonprefetchable.
1 = Memory window 0 is prefetchable (default).

PCI interrupt − IREQ routing enable. Bit 7 selects whether PC Card functional interrupts are routed to PCI
interrupts or the IRQ specified in the ExCA registers.

0 = Functional interrupts routed to PCI interrupts (default)
1 = Functional interrupts routed by ExCAs

CardBus reset. When bit 6 is set, CRST is asserted on the CardBus interface. CRST can also be asserted
by passing a PRST

0 = CRST
1 = CRST

Master abort mode. Bit 5 controls how the PCI1520 responds to a master abort when the PCI1520 is an
initiator on the CardBus interface. This bit is common between each socket.

0 = Master aborts not reported (default)
1 = Signal target abort on PCI and SERR

VGA enable. Bit 3 affects how the PCI1520 responds to VGA addresses. When this bit is set, accesses
to VGA addresses are forwarded.

ISA mode enable. Bit 2 affects how the PCI1520 passes I/O cycles within the 64-Kbyte ISA range. This
bit is not common between sockets. When this bit is set, the PCI1520 does not forward the last 768 bytes
of each 1K I/O range to CardBus.

CSERR enable. Bit 1 controls the response of the PCI1520 to CSERR signals on the CardBus bus. This
bit is common between the two sockets.

0 = CSERR is not forwarded to PCI SERR.
1 = CSERR

CardBus parity error response enable. Bit 0 controls the response of the PCI1520 to CardBus parity errors.
This bit is common between the two sockets.

0 = CardBus parity errors are ignored.
1 = CardBus parity errors are reported using CPERR

assertion to CardBus.
deasserted
asserted (default)

(if enabled)

is forwarded to PCI SERR.

.

4−14

4.26 Subsystem Vendor ID Register

The subsystem vendor ID register is used for system and option-card identification purposes and may be required
for certain operating systems. This register is read-only or read/write, depending on the setting of bit 5 (SUBSYSRW)
in the system control register (PCI offset 80h, see Section 4.29).

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Subsystem vendor ID
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Subsystem vendor ID
Offset: 40h (functions 0, 1)
Type: Read-only (Read/Write if enabled by SUBSYSRW)
Default: 0000h

4.27 Subsystem ID Register

The subsystem ID register is used for system and option-card identification purposes and may be required for certain
operating systems. This register is read-only or read/write, depending on the setting of bit 5 (SUBSYSRW) in the
system control register (PCI offset 80h, see Section 4.29).

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Subsystem ID
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Subsystem ID
Offset: 42h (functions 0, 1)
Type: Read-only (Read/Write if enabled by SUBSYSRW)
Default: 0000h

4.28 PC Card 16-Bit I/F Legacy-Mode Base Address Register

The PCI1520 supports the index/data scheme of accessing the ExCA registers, which are mapped by this register.
An address written to this register is the address for the index register and the address + 1 is the data address. Using
this access method, applications requiring index/data ExCA access can be supported. The base address can be
mapped anywhere in 32-bit I/O space on a word boundary; hence, bit 0 is read-only, returning 1 when read. As
specified in the PCI to PCMCIA CardBus Bridge Register Description (Yenta), this register is shared by functions 0
and 1. See Section 5, ExCA Compatibility Registers, for register offsets.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name PC Card 16-bit I/F legacy-mode base address
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name PC Card 16-bit I/F legacy-mode base address
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW R
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1

Register: PC Card 16-bit I/F legacy-mode base address
Offset: 44h (functions 0, 1)
Type: Read-only, Read/Write
Default: 0000 0001h

4−15

4.29 System Control Register

System-level initializations are performed by programming this doubleword register. Some of the bits are global and
are written only through function 0. See Table 4−8 for a complete description of the register contents.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name System control
Type RW RW RW R RW RW RC RW R RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 1 0 0 0 1 0 0

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name System control
Type RW RW R R R R R R R RW RW RW RW RW RW RW
Default 1 0 0 1 0 0 0 0 0 1 1 0 0 0 0 0

Register: System control
Offset: 80h (functions 0, 1)
Type: Read-only, Read/Write, Read/Clear
Default: 0044 9060h

4−16

Table 4−8. System Control Register Description

BIT SIGNAL TYPE FUNCTION

Serialized PCI interrupt routing step. Bits 31 and 30 configure the serialized PCI interrupt stream signaling
and accomplish an even distribution of interrupts signaled on the four PCI interrupt slots. Bits 31 and 30 are

31−30†SER_STEP RW

†

29

28 RSVD R Reserved. Bit 28 returns 0 when read.

27

26 SMIROUTE RW

25 SMISTATUS RC

24

23 RSVD R Reserved. Bit 23 returns 0 when read.

22 CBRSVD RW

21 VCCPROT RW

20 REDUCEZV RW

19−16 RSVD RW Reserved. Do not change the default value.

15

14

13

12 RSVD R Reserved. Bit 12 returns 1 when read.

†

This bit is global and is accessed only through function 0.

INTRTIE RW

†

P2CCLK RW

†

SMIENB RW

MRBURSTD

†

MRBURSTU

†

SOCACTIV

N

P

E

global to all PCI1520 functions.

00 = INTA
01 = INTA
10 = INTA
11 = INTA

Tie internal PCI interrupts. When this bit is set, the INTA and INTB signals are tied together internally and are
signaled as I N TA
functions.
When configuring the PCI1520 functions to share PCI interrupts, multifunction terminal MFUNC3 must be
configured as IRQSER prior to setting the INTRTIE bit.

P2C power switch clock. The PCI1520 CLOCK signal is used to clock the serial interface power switch and
the internal state machine. The default state for bit 27 is 0, requiring an external clock source provided to the
CLOCK terminal (terminal number F15 for the GHK package or terminal number 154 for the PDV package).
Bit 27 can be set to 1, allowing the internal oscillator to provide the clock signal.

0 = CLOCK provided externally, input to PCI1520 (default)
1 = CLOCK generated by internal oscillator and driven by PCI1520.

SMI interrupt routing. Bit 26 is shared between functions 0 and 1, and selects whether IRQ2 or CSC is signaled
when a write occurs to power a PC Card socket.

0 = PC Card power change interrupts routed to IRQ2 (default)
1 = A CSC interrupt is generated on PC Card power changes.

SMI interrupt status. This socket-dependent bit is set when bit 24 (SMIENB) is set and a write occurs to set
the socket power. W riting a 1 to bit 25 clears the status.

0 = SMI interrupt signaled (default)
1 = SMI interrupt not signaled

SMI interrupt mode enable. When bit 24 is set and a write to the socket power control occurs, the SMI interrupt
signaling is enabled and generates an interrupt. This bit is shared and defaults to 0 (disabled).

CardBus reserved terminals signaling. When a CardBus card is inserted and bit 22 is set, the RSVD CardBus
terminals are driven low. When this bit is 0, these terminals are placed in a high-impedance state.

0 = Place CardBus RSVD terminals in a high-impedance state.
1 = Drive Cardbus RSVD terminals low (default).

VCC protection enable. Bit 21 is socket dependent.

0 = VCC protection enabled for 16-bit cards (default)
1 = VCC protection disabled for 16-bit cards

Reduced zoomed video enable. When this bit is enabled, terminals A25−A22 of the card interface for PC
Card-16 cards are placed in the high-impedance state. This bit should not be set for normal ZV operation. This
bit is encoded as:

0 = Reduced zoomed video disabled (default)
1 = Reduced zoomed video enabled

Memory read burst enable downstream. When bit 15 is set, memory read transactions are allowed to burst
downstream.

RW

RW

R

0 = Downstream memory read burst is disabled.
1 = Downstream memory read burst is enabled (default).

Memory read burst enable upstream. When bit 14 is set, the PCI1520 allows memory read transactions to
burst upstream.

0 = Upstream memory read burst is disabled (default).
1 = Upstream memory read burst is enabled.

Socket activity status. When set, bit 13 indicates access has been performed to or from a PC card and is
cleared upon read of this status bit. This bit is socket-dependent.

0 = No socket activity (default)
1 = Socket activity

/INTB signal in INTA/INTB IRQSER slots
/INTB signal in INTB/INTC IRQSER slots
/INTB signal in INTC/INTD IRQSER slots

/INTB signal in INTD/INTA IRQSER slots

. INTA can then be shifted by using bits 31−30 (SER_STEP). This bit is global to all PCI1520

4−17

Table 4−8. System Control Register Description (Continued)

BIT SIGNAL TYPE FUNCTION

Power stream in progress status bit. When set, bit 11 indicates that a power stream to the power switch

†

11

10

†

This bit is global and is accessed only through function 0.

PWRSTREAM R

†

†

9

8 INTERROGATE R

7 RSVD R Reserved. Bit 7 returns 0 when read.
6 PWRSAVINGS RW

†

5

†

4

3 RSVD RW Reserved. Do not change the default value.

2 EXCAPOWER RW

†

1

0 RIMUX RW

DELAYUP R

DELAYDOWN R

SUBSYSRW RW

CB_DPAR RW

KEEPCLK RW

is in progress and a powering change has been requested. This bit is cleared when the power stream is
complete.

0 = Power stream is complete and delay has expired.
1 = Power stream is in progress.

Power-up delay in progress status. When set, bit 10 indicates that a power-up stream has been sent to
the power switch and proper power may not yet be stable. This bit is cleared when the power-up delay has
expired.

Power-down delay in progress status. When set, bit 9 indicates that a power-down stream has been sent
to the power switch and proper power may not yet be stable. This bit is cleared when the power-down delay
has expired.

Interrogation in progress. When set, bit 8 indicates an interrogation is in progress and clears when
interrogation completes. This bit is socket dependent.

0 = Interrogation not in progress (default)
1 = Interrogation in progress

Power savings mode enable. When this bit is set, if a CB card is inserted, idle, and without a CB clock,
then the applicable CB state machine will not be clocked.

Subsystem ID (PCI offset 42h, see Section 4.27), subsystem vendor ID (PCI offset 40H, see
Section 4.26), ExCA identification and revision (ExCA offset 00h/40h/800h, see Section 5.1) registers
read/write enable. Bit 5 is shared by functions 0 and 1.

0 = Subsystem ID, subsystem vendor ID, ExCA identification and revision registers are read/write.
1 = Subsystem ID, subsystem vendor ID, ExCA identification and revision registers are read-only

(default).

CardBus data parity SERR signaling enable

0 = CardBus data parity not signaled on PCI SERR
1 = CardBus data parity signaled on PCI SERR

ExCA power-control bit.

0 = Enables 3.3 V
1 = Enables 5 V

Keep clock. This bit works with PCI and CB CLKRUN protocols.

0 = Allows normal functioning of both CLKRUN
1 = Does not allow CB clock or PCI clock to be stopped using the CLKRUN

RI_OUT/PME multiplex enable.

0 = RI_OUT

at the same time, the terminal becomes RI_OUT

1 = Only PME

and PME are both routed to the RI_OUT/PME terminal. If both functions are are enabled

is routed to the RI_OUT/PME terminal.

protocols (default)

protocols

only and PME assertions are not seen.

4−18

4.30 Multifunction Routing Register

The multifunction routing register is used to configure the MFUNC0−MFUNC6 terminals. These terminals may be
configured for various functions. All multifunction terminals default to the general-purpose input configuration. This
register is intended to be programmed once at power-on initialization. The default value for this register can also be
loaded through a serial bus EEPROM. See Table 4−9 for a complete description of the register contents.

Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Name Multifunction routing
Type R R R R RW RW RW RW RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Multifunction routing
Type RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW RW
Default 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0

Register: Multifunction routing
Offset: 8Ch (functions 0, 1)
Type: Read-only, Read/Write
Default: 0000 1000h

Table 4−9. Multifunction Routing Register Description

BIT SIGNAL TYPE FUNCTION

31−28 RSVD R Bits 31−28 return 0s when read.

Multifunction terminal 6 configuration. These bits control the internal signal mapped to the MFUNC6 terminal

27−24 MFUNC6 RW

23−20 MFUNC5 RW

19−16 MFUNC4 RW

15−12 MFUNC3 RW

11−8 MFUNC2 RW

as follows:

0000 = RSVD
0001 = CLKRUN
0010 = IRQ2 0110 = IRQ6 1010 = IRQ10 1110 = IRQ14
0011 = IRQ3 011 1 = IRQ7 1011 = IRQ11 1111 = IRQ15

Multifunction terminal 5 configuration. These bits control the internal signal mapped to the MFUNC5 terminal
as follows:

0000 = GPI4
0001 = GPO4 0101 = IRQ5 1001 = D3_STAT
0010 = PCGNT
0011 = IRQ3 0111 = ZVSEL1 1011 = IRQ11 1111 = IRQ15

Multifunction terminal 4 configuration. These bits control the internal signal mapped to the MFUNC4 terminal
as follows:

NOTE: When the serial bus mode is implemented by pulling down the LATCH terminal, the MFUNC4 terminal

provides the SCL signaling.

0000 = GPI3
0001 = GPO3 0101 = IRQ5 1001 = IRQ9 1101 = LED_SKT
0010 = LOCK
0011 = IRQ3 0111 = ZVSEL1 1011 = IRQ11 1111 = D3_STAT

Multifunction terminal 3 configuration. These bits control the internal signal mapped to the MFUNC3 terminal
as follows:

0000 = RSVD 0100 = IRQ4 1000 = IRQ8 1100 = IRQ12
0001 = IRQSER
0010 = IRQ2 0110 = IRQ6 1010 = IRQ10 1110 = IRQ14
0011 = IRQ3 011 1 = IRQ7 1011 = IRQ11 1111 = IRQ15

Multifunction terminal 2 configuration. These bits control the internal signal mapped to the MFUNC2 terminal
as follows:

0000 = GPI2
0001 = GPO2 0101 = IRQ5 1001 = IRQ9 1101 = LEDA2
0010 = PCREQ
0011 = IRQ3 0111 = ZVSEL0 1011 = D3_STAT 1111 = IRQ7

†

†

†

PCI 0110 = ZVSTAT 1010 = IRQ10 1110 = GPE

†

0100 = IRQ4 1000 = IRQ8 1100 = IRQ12
0101 = IRQ5 1001 = IRQ9 1101 = IRQ13

0100 = IRQ4 1000 = CAUDPWM 1100 = LEDA1

0110 = ZVSTAT 1010 = IRQ10 1110 = GPE

0100 = IRQ4 1000 = CAUDPWM 1100 = RI_OUT

†

0101 = IRQ5 1001 = IRQ9 1101 = IRQ13

0100 = IRQ4 1000 = CAUDPWM 1100 = RI_OUT

0110 = ZVSTAT 1010 = IRQ10 1110 = GPE

1101 = LED_SKT

4−19

Table 4−9. Multifunction Routing Register Description (Continued)

BIT SIGNAL TYPE FUNCTION

Multifunction terminal 1 configuration. These bits control the internal signal mapped to the MFUNC1 terminal
as follows:

NOTE: When the serial bus mode is implemented by pulling down the LATCH terminal, the MFUNC1 terminal

7−4 MFUNC1 RW

3−0 MFUNC0 RW

†

Default value

provides the SDA signaling.

0000 = GPI1
0001 = GPO1 0101 = IRQ5 1001 = IRQ9 1101 = LEDA2
0010 = INTB
0011 = IRQ3 0111 = ZVSEL0 1011 = IRQ11 1111 = IRQ15

Multifunction terminal 0 configuration. These bits control the internal signal mapped to the MFUNC0 terminal
as follows:

0000 = GPI0
0001 = GPO0 0101 = IRQ5 1001 = IRQ9 1101 = LEDA2
0010 = INTA
0011 = IRQ3 0111 = ZVSEL0 1011 = IRQ11 1111 = IRQ15

†

†

0100 = IRQ4 1000 = CAUDPWM 1100 = LEDA1

0110 = ZVSTAT 1010 = IRQ10 1110 = GPE

0100 = IRQ4 1000 = CAUDPWM 1100 = LEDA1

0110 = ZVSTAT 1010 = IRQ10 1110 = GPE

4−20

4.31 Retry Status Register

The retry status register enables the retry timeout counters and displays the retry expiration status. The flags are set
when the PCI1520 retries a PCI or CardBus master request and the master does not return within 2

15

PCI clock
cycles. The flags are cleared by writing a 1 to the bit. These bits are expected to be incorporated into the PCI
command, PCI status, and bridge control registers by the PCI SIG. Access this register only through function 0. See
Table 4−10 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Retry status
Type RW RW RC R RC R RC R
Default 1 1 0 0 0 0 0 0

Register: Retry status
Offset: 90h (functions 0, 1)
Type: Read-only, Read/Write, Read/Clear
Default: C0h

Table 4−10. Retry Status Register Description

BIT SIGNAL TYPE FUNCTION

PCI retry timeout counter enable. Bit 7 is encoded:

7 PCIRETRY RW

†

6

3

†

This bit is global and is accessed only through function 0.

CBRETRY RW

5 TEXP_CBB RC

4 RSVD R Reserved. Bit 4 returns 0 when read.

†

TEXP_CBA RC

2 RSVD R Reserved. Bit 2 returns 0 when read.

1 TEXP_PCI RC

0 RSVD R Reserved. Bit 0 returns 0 when read.

0 = PCI retry counter disabled
1 = PCI retry counter enabled (default)

CardBus retry timeout counter enable. Bit 6 is encoded:

0 = CardBus retry counter disabled
1 = CardBus retry counter enabled (default)

CardBus target B retry expired. Write a 1 to clear bit 5.

0 = Inactive (default)
1 = Retry has expired

CardBus target A retry expired. Write a 1 to clear bit 3.

0 = Inactive (default)
1 = Retry has expired.

PCI target retry expired. Write a 1 to clear bit 1.

0 = Inactive (default)
1 = Retry has expired.

4−21

4.32 Card Control Register

The card control register is provided for PCI1130 compatibility. RI_OUT is enabled through this register, and the
enable bit is shared between functions 0 and 1. See Table 4−11 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Card control
Type RW RW RW R R RW RW RC
Default 0 0 0 0 0 0 0 0

Register: Card control
Offset: 91h
Type: Read-only, Read/Write, Read/Clear
Default: 00h

Table 4−11. Card Control Register Description

BIT SIGNAL TYPE FUNCTION

Ring indicate output enable.

†

7

6 ZVENABLE RW

5 PORT_SEL RW

4−3 RSVD R Reserved. Bits 4 and 3 return 0 when read.

2 AUD2MUX RW

1 SPKROUTEN RW

0 IFG RC

†

This bit is global and is accessed only through function 0.

RIENB RW

0 = Disables any routing of RI_OUT
1 = Enables RI_OUT

and for routing to MFUNC2 or MFUNC4

Compatibility ZV mode enable. When set, the corresponding PC Card socket interface ZV terminals enter
a high-impedance state. This bit defaults to 0.

Port select. This bit controls the priority for the ZVSEL0 and ZVSEL1 signaling if bit 6 (ZVENABLE) is set
in both functions.

0 = Socket 0 takes priority, as signaled through ZVSEL0, when both sockets are in ZV mode.
1 = Socket 1 takes priority, as signaled through ZVSEL1

CardBus audio-to-IRQMUX. When set, the CAUDIO CardBus signal is routed to the corresponding
multifunction terminal which may be configured for CAUDPWM. When both socket 0 and 1 functions have
AUD2MUX set, socket 0 takes precedence.

Speaker out enable. When bit 1 is set, SPKR on the PC Card is enabled and is routed to SPKROUT. The
SPKR

signal from socket 0 is XORed with the SPKR signal from socket 1 and sent to SPKROUT. The
SPKROUT terminal drives data only when the SPKROUTEN bit of either function is set. This bit is encoded
as:

0 = SPKR
1 = SPKR

Interrupt flag. Bit 0 is the interrupt flag for 16-bit I/O PC Cards and for CardBus cards. Bit 0 is set when a
functional interrupt is signaled from a PC Card interface and is socket dependent (that is, not global). Write
back a 1 to clear this bit.

0 = No PC Card functional interrupt detected (default).
1 = PC Card functional interrupt detected.

to SPKROUT not enabled
to SPKROUT enabled

signal for routing to the RI_OUT/PME terminal, when RIMUX is set to 0,

signal (default)

, when both sockets are in ZV mode.

4−22

4.33 Device Control Register

The device control register is provided for PCI1130 compatibility and contains bits that are shared between functions
0 and 1. The interrupt mode select is programmed through this register which is composed of PCI1520 global bits.
The socket-capable force bits are also programmed through this register. See Table 4−12 for a complete description
of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Device control
Type RW RW RW R RW RW RW RW
Default 0 1 1 0 0 1 1 0

Register: Device control
Offset: 92h (functions 0, 1)
Type: Read-only, Read/Write
Default: 66h

Table 4−12. Device Control Register Description

BIT SIGNAL TYPE FUNCTION

Socket power lock bit. When this bit is set to 1, software cannot power down the PC Card socket while

7 SKTPWR_LOCK RW

†

6

5 IO16V2 RW Diagnostic bit. This bit defaults to 1.
4 RSVD R Reserved. Bit 4 returns 0 when read.

3

2−1 INTMODE RW

0

†

This bit is global and is accessed only through function 0.

3VCAPABLE RW

†

†

TEST RW TI test. Only a 0 should be written to bit 3.

RSVD RW Reserved. Bit 0 is reserved for test purposes. Only 0 should be written to this bit.

in D3. This may be necessary to support wake on LAN or RING if the operating system is programmed
to power down a socket when the CardBus controller is placed in the D3 state.

3-V socket capable force

0 = Not 3-V capable
1 = 3-V capable (default)

Interrupt signaling mode. Bits 2 and 1 select the interrupt signaling mode. The interrupt signaling
mode bits are encoded:

00 = Parallel PCI interrupts only
01 = Parallel IRQ and parallel PCI interrupts
10 = IRQ serialized interrupts and parallel PCI interrupt
11 = IRQ and PCI serialized interrupts (default)

4−23

4.34 Diagnostic Register

The diagnostic register is provided for internal TI test purposes. It is a read/write register, but only 0s should be written
to it. See Table 4−13 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Diagnostic
Type RW R RW RW RW RW RW RW
Default 0 1 1 0 0 0 0 0

Register: Diagnostic
Offset: 93h (functions 0, 1)
Type: Read/Write
Default: 60h

Table 4−13. Diagnostic Register Description

BIT SIGNAL TYPE FUNCTION

†

7

6 RSVD R Reserved. Bit 6 returns 1 when read.

5 CSC RW

4
3
2
1

0 STDZVEN RW

†

This bit is global and is accessed only through function 0.

TRUE_VAL RW

†
†
†
†

DIAG4 RW Diagnostic RETRY_DIS. Delayed transaction disable.
DIAG3 RW Diagnostic RETRY_EXT. Extends the latency from 16 to 64.
DIAG2 RW Diagnostic DISCARD_TIM_SEL_CB. Set = 210, reset = 215.
DIAG1 RW Diagnostic DISCARD_TIM_SEL_PCI. Set = 210, reset = 215.

This bit defaults to 0. This bit is encoded as:

0 = Reads true values in PCI vendor ID and PCI device ID registers (default)
1 = Reads all 1s in reads from the PCI vendor ID and PCI device ID registers

CSC interrupt routing control

0 = CSC interrupts routed to PCI if ExCA 803 bit 4 = 1
1 = CSC interrupts routed to PCI if ExCA 805 bits 7−4 = 0000b (default)
In this case, the setting of ExCA 803 bit 4 is a don’t care.

Standardized zoomed video register model enable.

0 = Enable the standardized zoomed video register model (default).
1 = Disable the standardized zoomed video register model.

4−24

4.35 Capability ID Register

The capability ID register identifies the linked list item as the register for PCI power management. The register returns
01h when read, which is the unique ID assigned by the PCI SIG for the PCI location of the capabilities pointer and
the value.

Bit 7 6 5 4 3 2 1 0
Name Capability ID
Type R R R R R R R R
Default 0 0 0 0 0 0 0 1

Register: Capability ID
Offset: A0h
Type: Read-only
Default: 01h

4.36 Next-Item Pointer Register

The next-item pointer register indicates the next item in the linked list of the PCI power-management capabilities.
Because the PCI1520 functions include only one capabilities item, this register returns 0s when read.

Bit 7 6 5 4 3 2 1 0
Name Next-item pointer
Type R R R R R R R R
Default 0 0 0 0 0 0 0 0

Register: Next-item pointer
Offset: A1h
Type: Read-only
Default: 00h

4−25

4.37 Power-Management Capabilities Register

This register contains information on the capabilities of the PC Card function related to power management. Both
PCI1520 CardBus bridge functions support D0, D1, D2, and D3 power states. See Table 4−14 for a complete
description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Power-management capabilities
Type RW R R R R R R R R R R R R R R R
Default 1 1 1 1 1 1 1 0 0 0 0 1 0 0 1 0

Register: Power-management capabilities
Offset: A2h
Type: Read/Write, Read-only
Default: FE12h

Table 4−14. Power-Management Capabilities Register Description

BIT SIGNAL TYPE FUNCTION

PME support. This 5-bit field indicates the power states from which the PCI1520 device functions may
assert PME
power state. These five bits return 11111b when read. Each of these bits is described below:

15 PME_Support RW Bit 15 defaults to the value 1 indicating the PME signal can be asserted from the D3

14−11 PME_Support R Bit 14 contains the value 1, indicating that the PME signal can be asserted from D3

10 D2_Support R

9 D1_Support R

8−6 RSVD R Reserved. Bits 8−6 return 0s when read.

5 DSI R

4 AUX_PWR R

3 PMECLK R

2−0 VERSION R

R/W because wake-up support from D3
to the VCC terminals. If the system designer chooses not to provide an auxiliary power source to the V
terminals for D3

Bit 13 contains the value 1, indicating that the PME
Bit 12 contains the value 1, indicating that the PME
Bit 11 contains the value 1, indicating that the PME

D2 support. Bit 10 returns a 1 when read, indicating that the CardBus function supports the D2 device
power state.

D1 support. Bit 9 returns a 1 when read, indicating that the CardBus function supports the D1 device
power state.

Device-specific initialization. Bit 5 returns 1 when read, indicating that the CardBus controller function
requires special initialization (beyond the standard PCI configuration header) before the generic-class
device driver is able to use it.

Auxiliary power source. Bit 4 is meaningful only if bit 15 (PME_Support, D3
it indicates that support for PME
proprietary delivery vehicle. When bit 4 is 0, it indicates that the function supplies its own auxiliary power
source.

PME clock. Bit 3 returns 0 when read, indicating that no host bus clock is required for the PCI1520 to
generate PME

Version. Bits 2−0 return 010b when read, indicating that the power-management registers (PCI offsets
A4h−A7h, see Sections 4.38−4.40) are defined in the PCI Bus Power Management Interface Specification
version 1.1.

. A 0 (zero) for any bit indicates that the function cannot assert the PME signal while in that

state. This bit is

is contingent on the system providing an auxiliary power source

cold

wake-up support, then BIOS should write a 0 to this bit.

cold

signal can be asserted from D2 state.
signal can be asserted from D1 state.

signal can be asserted from the D0 state.

in D3

.

requires auxiliary power supplied by the system by way of a

cold

cold

cold

CC

state.

hot

) is set. When bit 4 is set,

4−26

4.38 Power-Management Control/Status Register

The power-management control/status register determines and changes the current power state of the PCI1520
CardBus function. The contents of this register are not affected by the internally-generated reset caused by the
transition from D3
transition. TI-specific registers, PCI power-management registers, and the PC Card 16-bit legacy-mode base
address register (PCI offset 44h, see Section 4.28) are not reset. See Table 4−15 for a complete description of the
register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Power-management control/status
Type RC R R R R R R RW R R R R R R RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: Power-management control/status
Offset: A4h (functions 0, 1)
Type: Read-only, Read/Write, Read/Clear
Default: 0000h

BIT SIGNAL TYPE FUNCTION

15 PMESTAT RC

14−13 DATASCALE R

12−9 DATASEL R

8 PME_EN RW

7−2 RSVD R Reserved. Bits 7−2 return 0s when read.

1−0 PWR_STATE RW

to D0 state. All PCI, ExCA, and CardBus registers are reset as a result of a D3

hot

Table 4−15. Power-Management Control/Status Register Description

PME status. Bit 15 is set when the CardBus function would normally assert PME, independent
of the state of bit 8 (PME_EN). Bit 15 is cleared by a writeback of 1, and this also clears the PME
signal if PME was asserted by this function. Writing a 0 to this bit has no effect.

Data scale. This 2-bit field returns 0s when read. The CardBus function does not return any
dynamic data.

Data select. This 4-bit field returns 0s when read. The CardBus function does not return any
dynamic data.

PME enable. Bit 8 enables the function to assert PME. If this bit is cleared, then assertion of PME
is disabled.

Power state. This 2-bit field is used both to determine the current power state of a function and
to set the function into a new power state. This field is encoded as:

00 = D0
01 = D1
10 = D2
11 = D3

hot

to D0 state

hot

4−27

4.39 Power-Management Control/Status Register Bridge Support Extensions

The power-management control/status register bridge support extensions support PCI bridge specific functionality.
See Table 4−16 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Power-management control/status register bridge support extensions
Type R R R R R R R R
Default 1 1 0 0 0 0 0 0

Register: Power-management control/status register bridge support extensions
Offset: A6h (functions 0, 1)
Type: Read-only
Default: C0h

Table 4−16. Power-Management Control/Status Register Bridge Support Extensions Description

BIT SIGNAL TYPE FUNCTION

BPCC_Enable. Bus power/clock control enable. This bit returns 1 when read.
This bit is encoded as:

0 = Bus power/clock control is disabled.
1 = Bus power/clock control is enabled (default).

7 BPCC_EN R

6 B2_B3 R

5−0 RSVD R Reserved. Bits 5−0 return 0s when read.

A 0 indicates that the bus power/clock control policies defined in the PCI Bus Power Management
Interface Specification are disabled. When the bus power/clock control enable mechanism is disabled,
the bridge power-management control/status register power state field (see Section 4.38, bits 1−0)
cannot be used by the system software to control the power or the clock of the bridge secondary bus. A
1 indicates that the bus power/clock control mechanism is enabled.

B2/B3 support for D3
programming the function to D3
as:

0 = When the bridge is programmed to D3
1 = When the bridge function is programmed to D3

stopped (B2) (default).

. The state of this bit determines the action that is to occur as a direct result of

hot

. This bit is only meaningful if bit 7 (BPCC_EN) is a 1. This bit is encoded

hot

, its secondary bus has its power removed (B3).

hot

, its secondary bus PCI clock is

hot

4.40 Power-Management Data Register

The power-management data register returns 0s when read, because the CardBus functions do not report dynamic
data.

Bit 7 6 5 4 3 2 1 0
Name Power-management data
Type R R R R R R R R
Default 0 0 0 0 0 0 0 0

Register: Power-management data
Offset: A7h (functions 0, 1)
Type: Read-only
Default: 00h

4−28

4.41 General-Purpose Event Status Register

The general-purpose event status register contains status bits that are set when events occur that are controlled by
the general-purpose control register. The bits in this register and the corresponding GPE
to the corresponding bit location. The status bits in this register do not depend upon the states of corresponding bits
in the general-purpose enable register. Access this register only through function 0. See Table 4−17 for a complete
description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name General-purpose event status
Type RC RC R R RC R R RC R R R RC RC RC RC RC
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: General-purpose event status
Offset: A8h (function 0)
Type: Read-only, Read/Clear
Default: 0000h

Table 4−17. General-Purpose Event Status Register Description

BIT SIGNAL TYPE FUNCTION

15 ZV0_STS RC

14 ZV1_STS RC

13−12 RSVD R Reserved. Bits 13 and 12 return 0s when read.

11 PWR_STS RC

10−9 RSVD R Reserved. Bits 10 and 9 return 0s when read.

8 VPP12_STS RC

7−5 RSVD R Reserved. Bits 7−5 return 0s when read.

4 GP4_STS RC GPI4 Status. Bit 4 is set on a change in status of the MFUNC5 terminal input level.
3 GP3_STS RC GPI3 Status. Bit 3 is set on a change in status of the MFUNC4 terminal input level .
2 GP2_STS RC GPI2 Status. Bit 2 is set on a change in status of the MFUNC2 terminal input level.
1 GP1_STS RC GPI1 Status. Bit 1 is set on a change in status of the MFUNC1 terminal input level.
0 GP0_STS RC GPI0 Status. Bit 0 is set on a change in status of the MFUNC0 terminal input level.

PC Card socket 0 ZV status. Bit 15 is set on a change in status of bit 6 (ZVENABLE) in the function 0 card

control register (PCI offset 91h, see Section 4.32).

PC Card socket 1 ZV status. Bit 14 is set on a change in status of bit 6 (ZVENABLE) in the function 1 card

control register (PCI offset 91h, see Section 4.32).

Power-change status. Bit 11 is set when software has changed the power state of either socket. A change

in either VCC or VPP for either socket causes this bit to be set.

12-V VPP request status. Bit 8 is set when software has changed the requested VPP level to or from 12 V

for either of the two PC Card sockets.

are cleared by writing a 1

4−29

4.42 General-Purpose Event Enable Register

The general-purpose event enable register contains bits that are set to enable a GPE signal. The GPE signal is driven
until the corresponding status bit is cleared and the event is serviced. The GPE
multifunction terminals, MFUNC6−MFUNC0, is configured for GPE

signaling. Access this register only through

function 0. See Table 4−18 for a complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name General-purpose event enable
Type RW RW R R RW R R RW R R R RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: General-purpose event enable
Offset: AAh (function 0)
Type: Read-only, Read/Write
Default: 0000h

Table 4−18. General-Purpose Event Enable Register Description

BIT SIGNAL TYPE FUNCTION

15 ZV0_EN RW

14 ZV1_EN RW

13−12 RSVD R Reserved. Bits 13 and 12 return 0s when read.

11 PWR_EN RW

10−9 RSVD R Reserved. Bits 10 and 9 return 0s when read.

8 VPP12_EN RW

7−5 RSVD R Reserved. Bits 7−5 return 0s when read.

4 GP4_EN RW

3 GP3_EN RW

2 GP2_EN RW

1 GP1_EN RW

0 GP0_EN RW

PC Card socket 0 ZV enable. When bit 15 is set, a GPE is signaled on a change in status of bit 6
(ZVENABLE) in the function 0 card control register (PCI offset 91h, see Section 4.32).

PC Card socket 1 ZV enable. When bit 14 is set, a GPE is signaled on a change in status of bit 6
(ZVENABLE) in the function 1 card control register (PCI offset 91h, see Section 4.32).

Power change enable. When bit 11 is set, a GPE is signaled on when software has changed the power
state of either socket.

12-V VPP request enable. When bit 8 is set, a GPE is signaled when software has changed the requested
VPP level to or from 12 V for either card socket.

GPI4 enable. When bit 4 is set, a GPE is signaled when there has been a change in status of the MFUNC5
terminal input level if configured as GPI4.

GPI3 enable. When bit 3 is set, a GPE is signaled when there has been a change in status of the MFUNC4
terminal input level if configured as GPI3.

GPI2 enable. When bit 2 is set, a GPE is signaled when there has been a change in status of the MFUNC2
terminal input if configured as GPI2.

GPI1 enable. When bit 1 is set, a GPE is signaled when there has been a change in status of the MFUNC1
terminal input if configured as GPI1.

GPI0 enable. When bit 0 is set, a GPE is signaled when there has been a change in status of the MFUNC0
terminal input if configured as GPI0.

can only be signaled if one of the

4−30

4.43 General-Purpose Input Register

The general-purpose input register provides the logical value of the data input from the GPI terminals, MFUNC5,
MFUNC4, and MFUNC2−MFUNC0. Access this register only through function 0. See Table 4−19 for a complete
description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name General-purpose input
Type R R R R R R R R R R R R R R R R
Default 0 0 0 0 0 0 0 0 0 0 0 X X X X X

Register: General-purpose input
Offset: ACh (function 0)
Type: Read-only
Default: 00XXh

Table 4−19. General-Purpose Input Register Description

BIT SIGNAL TYPE FUNCTION

15−5 RSVD R Reserved. Bits 15−5 return 0s when read.

4 GPI4_DATA R GPI4 data bit. The value read from bit 4 represents the logical value of the data input from the MFUNC5 terminal.
3 GPI3_DATA R GPI3 data bit. The value read from bit 3 represents the logical value of the data input from the MFUNC4 terminal.
2 GPI2_DATA R GPI2 data bit. The value read from bit 2 represents the logical value of the data input from the MFUNC2 terminal.
1 GPI1_DATA R GPI1 data bit. The value read from bit 1 represents the logical value of the data input from the MFUNC1 terminal.
0 GPI0_DATA R GPI0 data bit. The value read from bit 0 represents the logical value of the data input from the MFUNC0 terminal.

4−31

4.44 General-Purpose Output Register

The general-purpose output register is used for control of the general-purpose outputs. Access this register only
through function 0. See Table 4−20 for a complete description of the register contents.

Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name General-purpose output
Type R R R R R R R R R R R RW RW RW RW RW
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Register: General-purpose output
Offset: AEh (function 0)
Type: Read-only, Read/Write
Default: 0000h

Table 4−20. General-Purpose Output Register Description

BIT SIGNAL TYPE FUNCTION

15−5 RSVD R Reserved. Bits 15−5 return 0s when read.

4 GPO4_DATA RW

3 GPO3_DATA RW

2 GPO2_DATA RW

1 GPO1_DATA RW

0 GPO0_DATA RW

GPO4 data bit. The value written to bit 4 represents the logical value of the data driven to the MFUNC5
terminal if configured as GPO4. Read transactions return the last data value written.

GPIO3 data bit. The value written to bit 3 represents the logical value of the data driven to the MFUNC4
terminal if configured as GPO3. Read transactions return the last data value written.

GPO2 data bit. The value written to bit 2 represents the logical value of the data driven to the MFUNC2
terminal if configured as GPO2. Read transactions return the last data value written.

GPO1 data bit. The value written to bit 1 represents the logical value of the data driven to the MFUNC1
terminal if configured as GPO1. Read transactions return the last data value written.

GPO0 data bit. The value written to bit 0 represents the logical value of the data driven to the MFUNC0
terminal if configured as GPO0. Read transactions return the last data value written.

4.45 Serial-Bus Data Register

The serial-bus data register is for programmable serial-bus byte reads and writes. This register represents the data
when generating cycles on the serial bus interface. To write a byte, this register must be programmed with the data,
the serial bus index register must be programmed with the byte address, the serial-bus slave address must be
programmed with the 7-bit slave address, and the read/write indicator bit must be reset.

On byte reads, the byte address is programmed into the serial-bus index register, the serial bus slave address register
must be programmed with both the 7-bit slave address and the read/write indicator bit, and bit 5 (REQBUSY) in the
serial bus control and status register (PCI offset B3h, see Section 4.48) must be polled until clear. Then the contents
of this register are valid read data from the serial bus interface. See Table 4−21 for a complete description of the
register contents.

Bit 7 6 5 4 3 2 1 0
Name Serial-bus data
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: Serial-bus data
Offset: B0h (function 0)
Type: Read/Write
Default: 00h

Table 4−21. Serial-Bus Data Register Description

BIT SIGNAL TYPE FUNCTION

7−0 SBDATA RW

Serial-bus data. This bit field represents the data byte in a read or write transaction on the serial interface.
On reads, the REQBUSY bit must be polled to verify that the contents of this register are valid.

4−32

4.46 Serial-Bus Index Register

The serial-bus index register is for programmable serial-bus byte reads and writes. This register represents the byte
address when generating cycles on the serial-bus interface. To write a byte, the serial-bus data register must be
programmed with the data, this register must be programmed with the byte address, and the serial-bus slave address
register must be programmed with both the 7-bit slave address and the read/write indicator bit.

On byte reads, the word address is programmed into this register, the serial-bus slave address must be programmed
with both the 7-bit slave address and the read/write indicator bit, and bit 5 (REQBUSY) in the serial-bus control and
status register (see Section 4.48) must be polled until clear. Then the contents of the serial-bus data register are valid
read data from the serial-bus interface. See Table 4−22 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Serial-bus index
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: Serial-bus index
Offset: B1h (function 0)
Type: Read/Write
Default: 00h

Table 4−22. Serial-Bus Index Register Description

BIT SIGNAL TYPE FUNCTION

7−0 SBINDEX RW Serial-bus index. This bit field represents the byte address in a read or write transaction on the serial interface.

4.47 Serial-Bus Slave Address Register

The serial-bus slave address register is for programmable serial-bus byte read and write transactions. To write a byte,
the serial-bus data register must be programmed with the data, the serial-bus index register must be programmed
with the byte address, and this register must be programmed with both the 7-bit slave address and the read/write
indicator bit.

On byte reads, the byte address is programmed into the serial bus index register, this register must be programmed
with both the 7-bit slave address and the read/write indicator bit, and bit 5 (REQBUSY) in the serial-bus control and
status register (PCI offset B3h, see Section 4.48) must be polled until clear. Then the contents of the serial-bus data
register are valid read data from the serial-bus interface. See Table 4−23 for a complete description of the register
contents.

Bit 7 6 5 4 3 2 1 0
Name Serial-bus slave address
Type RW RW RW RW RW RW RW RW
Default 0 0 0 0 0 0 0 0

Register: Serial-bus slave address
Offset: B2h (function 0)
Type: Read/Write
Default: 00h

Table 4−23. Serial-Bus Slave Address Register Description

BIT SIGNAL TYPE FUNCTION

7−1 SLAVADDR RW

0 RWCMD RW

Serial-bus slave address. This bit field represents the slave address of a read or write transaction on the
serial interface.

Read/write command. Bit 0 indicates the read/write command bit presented to the serial bus on byte read
and write accesses.

0 = A byte write access is requested to the serial bus interface.
1 = A byte read access is requested to the serial bus interface.

4−33

4.48 Serial-Bus Control and Status Register

The serial-bus control and status register communicates serial-bus status information and selects the quick
command protocol. Bit 5 (REQBUSY) in this register must be polled during serial-bus byte reads to indicate when
data is valid in the serial-bus data register. See Table 4−24 for a complete description of the register contents.

Bit 7 6 5 4 3 2 1 0
Name Serial-bus control and status
Type RW R R R RC RW RC RC
Default 0 0 0 0 0 0 0 0

Register: Serial-bus control and status
Offset: B3h (function 0)
Type: Read-only, Read/Write, Read/Clear
Default: 00h

Table 4−24. Serial-Bus Control and Status Register Description

BIT SIGNAL TYPE FUNCTION

Protocol select. When bit 7 is set, the send-byte protocol is used on write requests and the receive-byte

7 PROT_SEL RW

6 RSVD R Reserved. Bit 6 returns 0 when read.

5 REQBUSY R

4 ROMBUSY R

3 SBDETECT RC

2 SBTEST RW

1 REQ_ERR RC

0 ROM_ERR RC

protocol is used on read commands. The word-address byte in the serial-bus index register (PCI offset B1h,
see Section 4.46) is not output by the PCI1520 when bit 7 is set.

Requested serial-bus access busy. Bit 5 indicates that a requested serial-bus access (byte read or write)
is in progress. A request is made, and bit 5 is set, by writing to the serial-bus slave address register (PCI
offset B2h, see Section 4.47). Bit 5 must be polled on reads from the serial interface. After the byte read
access has been requested, the read data is valid in the serial-bus data register.

Serial EEPROM busy status. Bit 4 indicates the status of the PCI1520 serial EEPROM circuitry. Bit 4 is set
during the loading of the subsystem ID and other default values from the serial-bus EEPROM.

0 = Serial EEPROM circuitry is not busy
1 = Serial EEPROM circuitry is busy

Serial-bus detect. When bit 3 is set, it indicates that the serial-bus interface is detected. A pulldown resistor
must be implemented on the LATCH terminal for bit 3 to be set. If bit 3 is reset, then the MFUNC4 and
MFUNC1 terminals can be used for alternate functions such as general-purpose inputs and outputs.

0 = Serial-bus interface not detected
1 = Serial-bus interface detected

Serial-bus test. When bit 2 is set, the serial-bus clock frequency is increased for test purposes.

0 = Serial-bus clock at normal operating frequency,  100 kHz (default)
1 = Serial-bus clock frequency increased for test purposes

Requested serial-bus access error. Bit 1 indicates when a data error occurs on the serial interface during
a requested cycle, and can be set due to a missing acknowledge. Bit 1 is cleared by a writeback of 1.

0 = No error detected during user-requested byte read or write cycle
1 = Data error detected during user-requested byte read or write cycle

EEPROM data-error status. Bit 0 indicates when a data error occurs on the serial interface during the
auto-load from the serial-bus EEPROM, and can be set due to a missing acknowledge. Bit 0 is also set on
invalid EEPROM data formats. See Section 3.6.1, Serial Bus Interface Implementation, for details on
EEPROM data format. Bit 0 is cleared by a writeback of 1.

0 = No error detected during auto-load from serial-bus EEPROM
1 = Data error detected during auto-load from serial-bus EEPROM

4−34

5 ExCA Compatibility Registers (Functions 0 and 1)

Host I/O Space

PCI1520 Configuration Registers

The ExCA registers implemented in the PCI1520 are register-compatible with the Intel 82365SL−DF PCMCIA
controller. ExCA registers are identified by an offset value that is compatible with the legacy I/O index/data scheme
used on the Intel 82365 ISA controller. The ExCA registers are accessed through this scheme by writing the register
offset value into the index register (I/O base) and reading or writing the data register (I/O base + 1). The I/O base
address used in the index/data scheme is programmed in the PC Card 16-bit I/F legacy-mode base address register
(PCI offset 44h, see Section 4.28), which is shared by both card sockets. The offsets from this base address run
contiguously from 00h to 3Fh for socket A, and from 40h to 7Fh for socket B. See Figure 5−1 for an ExCA I/O mapping
illustration.

Offset

PC Card A

CardBus Socket/ExCA Base Address

16-Bit Legacy-Mode Base Address

NOTE: The 16-bit legacy mode base address register is shared by functions 0 and 1 as indicated by the shading.

10h

44h

Index

Data

ExCA

Registers

PC Card B

ExCA

Registers

Offset

00h

3Fh
40h

7Fh

Figure 5−1. ExCA Register Access Through I/O

The TI PCI1520 also provides a memory-mapped alias of the ExCA registers by directly mapping them into PCI
memory space. They are located through the CardBus socket/ExCA base-address register (PCI offset 10h, see
Section 4.12) at memory offset 800h. Each socket has a separate base address programmable by function. See
Figure 5−2 for an ExCA memory mapping illustration. Note that memory offsets are 800h−844h for both functions
0 and 1. This illustration also identifies the CardBus socket register mapping, which is mapped into the same 4-K
window at memory offset 00h.

5−1

PCI1520 Configuration Registers

Host

Memory Space

Offset

Host

Memory Space

OffsetOffset

CardBus

Socket A

CardBus Socket/ExCA Base Address

16-Bit Legacy-Mode Base Address

NOTE: The CardBus socket/ExCA base address mode register is separate for functions 0 and 1.

10h

44h

Registers

ExCA

Registers

Card A

00h

20h

800h

844h

CardBus

Socket B

Registers

ExCA

Registers

Card B

00h

20h

800h

844h

Figure 5−2. ExCA Register Access Through Memory

The interrupt registers in the ExCA register set, as defined by the 82365SL−DL specification, control such card
functions as reset, type, interrupt routing, and interrupt enables. Special attention must be paid to the interrupt routing
registers and the host interrupt signaling method selected for the PCI1520 to ensure that all possible PCI1520
interrupts can potentially be routed to the programmable interrupt controller. The ExCA registers that are critical to
the interrupt signaling are the ExCA interrupt and general control register (ExCA offset 03h/43h/803h, see
Section 5.4) and the ExCA card status-change interrupt configuration register (05h/45h/805h, see Section 5.6).

Access to I/O mapped 16-bit PC cards is available to the host system via two ExCA I/O windows. These are regions
of host I/O address space into which the card I/O space is mapped. These windows are defined by start, end, and
offset addresses programmed in the ExCA registers described in this section. I/O windows have byte granularity.

Access to memory mapped 16-bit PC Cards is available to the host system via five ExCA memory windows. These
are regions of host memory space into which the card memory space is mapped. These windows are defined by start,
end, and offset addresses programmed in the ExCA registers described in this section. Table 5−1 identifies each
ExCA register and its respective ExCA offset. Memory windows have 4-Kbyte granularity.

5−2

Table 5−1. ExCA Registers and Offsets

PCI MEMORY ADDRESS

EXCA REGISTER NAME

PCI MEMORY ADDRESS

ExCA OFFSET (HEX)

OFFSET (HEX)

Identification and revision 800 00 40
Interface status 801 01 41
Power control 802 02 42
Interrupt and general control 803 03 43
Card status change 804 04 44
Card status-change interrupt configuration 805 05 45
Address window enable 806 06 46
I /O window control 807 07 47
I /O window 0 start-address low byte 808 08 48
I /O window 0 start-address high byte 809 09 49
I /O window 0 end-address low byte 80A 0A 4A
I /O window 0 end-address high byte 80B 0B 4B
I /O window 1 start-address low byte 80C 0C 4C
I /O window 1 start-address high byte 80D 0D 4D
I /O window 1 end-address low byte 80E 0E 4E
I /O window 1 end-address high byte 80F 0F 4F
Memory window 0 start-address low byte 810 10 50
Memory window 0 start-address high byte 811 11 51
Memory window 0 end-address low byte 812 12 52
Memory window 0 end-address high byte 813 13 53
Memory window 0 offset-address low byte 814 14 54
Memory window 0 offset-address high byte 815 15 55
Card detect and general control 816 16 56
Reserved 817 17 57
Memory window 1 start-address low byte 818 18 58
Memory window 1 start-address high byte 819 19 59
Memory window 1 end-address low byte 81A 1A 5A

Memory window 1 end-address high byte 81B 1B 5B
Memory window 1 offset-address low byte 81C 1C 5C
Memory window 1 offset-address high byte 81D 1D 5D
Global control 81E 1E 5E
Reserved 81F 1F 5F
Memory window 2 start-address low byte 820 20 60
Memory window 2 start-address high byte 821 21 61
Memory window 2 end-address low byte 822 22 62
Memory window 2 end-address high byte 823 23 63
Memory window 2 offset-address low byte 824 24 64
Memory window 2 offset-address high byte 825 25 65
Reserved 826 26 66
Reserved 827 27 67
Memory window 3 start-address low byte 828 28 68
Memory window 3 start-address high byte 829 29 69
Memory window 3 end-address low byte 82A 2A 6A

CARD A CARD B

5−3

Table 5−1. ExCA Registers and Offsets (Continued)

PCI MEMORY ADDRESS

EXCA REGISTER NAME

PCI MEMORY ADDRESS

ExCA OFFSET (HEX)

OFFSET (HEX)

Memory window 3 end-address high byte 82B 2B 6B
Memory window 3 offset-address low byte 82C 2C 6C
Memory window 3 offset-address high byte 82D 2D 6D
Reserved 82E 2E 6E
Reserved 82F 2F 6F
Memory window 4 start-address low byte 830 30 70
Memory window 4 start-address high byte 831 31 71
Memory window 4 end-address low byte 832 32 72
Memory window 4 end-address high byte 833 33 73
Memory window 4 offset-address low byte 834 34 74
Memory window 4 offset-address high byte 835 35 75
I/O window 0 offset-address low byte 836 36 76
I/O window 0 offset-address high byte 837 37 77
I/O window 1 offset-address low byte 838 38 78
I/O window 1 offset-address high byte 839 39 79
Reserved 83A 3A 7A
Reserved 83B 3B 7B
Reserved 83C 3C 7C
Reserved 83D 3D 7D
Reserved 83E 3E 7E
Reserved 83F 3F 7F
Memory window page 0 840 − −
Memory window page 1 841 − −
Memory window page 2 842 − −
Memory window page 3 843 − −
Memory window page 4 844 − −

CARD A CARD B

A bit description table, typically included when a register contains bits of more than one type or purpose, indicates
bit field names, which appear in the signal column; a detailed field description, which appears in the function column;
and field access tags, which appear in the type column of the bit description table. Table 4−2 describes the field
access tags.

5−4
