Reference
TDS3000B Series
Digital Phosphor
Oscilloscopes
071-0923-00
*P071092300*
071092300
Contacting Tektronix
Phone 1-800-833-9200*
Address Tektronix, Inc.
Department or name (if known)
14200 SW Karl Braun Drive
P.O. Box 500 Beaverton, OR 97077 USA
Web site www.tektronix.com
Sales support 1-800-833-9200, select option 1*
Service support 1-800-833-9200, select option 2*
Technical
support
Email: techsupport@tektronix.com
1-800-833-9200, select option 3*
1-503-627-2400
6:00 a.m. – 5:00 p.m. Pacific time
* This phone number is toll free in North America. After
office hours, please leave a voice mail message.
Outside North America, contact a Tektronix sales office
or distributor; see the Tektronix web site for a list of
offices.
Tektronix warrants that the products that it manufactures and
sells will be free from defects in materials and workmanship
for a period of one (1) year from the date of shipment from an
authorized Tektronix distributor. If a product proves defective
within the respective period, Tektronix will provide repair or
replacement as described in the complete warranty statement.
To arrange for service or obtain a copy of the complete
warranty statement, please contact your nearest Tektronix sales
and service office.
EXCEPT AS PROVIDED IN THIS SUMMARY OR THE
APPLICABLE WARRANTY STATEMENT, TEKTRONIX
MAKES NO WARRANTY OF ANY KIND, EXPRESS OR
IMPLIED, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT
SHALL TEKTRONIX BE LIABLE FOR INDIRECT,
SPECIAL OR CONSEQUENTIAL DAMAGES.
WARRANTY SUMMARY
2
Safety Summary
To avoid potential hazards, use this product only as
specified in the TDS3000B Series Digital Phosphor
Oscilloscope User Manual which is located on the
TDS3000B Series Digital Phosphor Oscilloscope
Manuals and Application Notes CD. While using this
product, you may need to access other parts of the
system.
Read the General Safety Summary in the user manual
and in other system manuals for warnings and cautions
related to operating the system.
Preventing Electrostatic Damage
CAUTION. Electrostatic discharge (ESD) can
damage components in the oscilloscope and its
accessories. To prevent ESD, observe these
precautions when directed to do so.
Use a Ground Strap. W ear a grounded antistatic wrist strap
to discharge the static voltage from your body while
installing or removing sensitive components.
Contents
Safety Summary 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
TDS3000B Initial Setup 5. . . . . . . . . . . . . . . . . . . . . . .
QuickMenus 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Menus 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Acquire Menu 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
XY Cursor Menu 14. . . . . . . . . . . . . . . . . . . . . . . . . . . .
YT Cursor Menu 15. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Display Menu 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Measure Menu 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Save/Recall Menu 24. . . . . . . . . . . . . . . . . . . . . . . . . . .
Trigger Menus 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Utility Menus 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vertical Menus 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
e*ScopeE Web-based Remote Control 41. . . . . . . . . . . .
Automatic Measurements 44. . . . . . . . . . . . . . . . . . . . .
1
Use a Safe Work Area. Do not use any devices capable of
4
More Information
Refer to the TDS3000B Series Digital Phosphor
Oscilloscope User Manual, which is located on the
TDS3000B Series Digital Phosphor Oscilloscope
Manuals and Application Notes CD, for more
information about using this product.
generating or holding a static charge in the work area
where you install or remove sensitive components.
Avoid handling sensitive components in areas that have a
floor or benchtop surface capable of generating a static
charge.
Handle Components Carefully. Do not slide sensitive
components over any surface. Do not touch exposed
connector pins. Handle sensitive components as little as
possible.
Transport and Store Carefully . Transport and store sensitive
components in a static-protected bag or container.
Manual Storage
The oscilloscope front cover has a convenient place to
store this manual.
3
6
3. Connect the oscilloscope probe
to channel 1. Attach the probe
tip and reference lead to the
PROBE COMP connectors.
4. Push the AUTOSET button.
You should see a square wave
in the display (approximately
5 V at 1 kHz).
Probe Compensation
5. Check the shape of the displayed waveform.
6. Adjust your probe if necessary
to achieve correct compensation.
TDS3000B Initial Setup
The following procedures describe how to quickly verify
that the oscilloscope is powering up and functioning
correctly, compensate passive probes using the built-in
compensation signal, and run the signal path compensation (SPC) routine for maximum signal accuracy.
H You should perform all initial setup procedures the
first time you use the oscilloscope.
H You should perform the probe compensation
procedure whenever you attach a passive probe for
the first time to any input channel.
H You should run the signal path compensation routine
whenever the ambient temperature changes by 10_ C
or more.
Functional Check
PROBE COMP
CH 1
Overcompensated
1. Connect the oscilloscope power cable
2. Turn on the oscilloscope. Wait
for the confirmation that the
oscilloscope has passed all
self-tests.
Undercompensated
Compensated correctly
L
On/Standby
button
5
Signal Path Compensation (SPC)
8
Adjusting Time and Date
To set your oscilloscope to the current date and time, do
the following steps:
1 Push the UTILITY button.
2 Push the System menu button to select Config.
3 Push the Set Date & Time menu button.
4 Use the side menu buttons and general purpose knob
to adjust the date and time values.
5 Push the OK Enter Date/Time menu button to set
the instrument date and time.
User Manual
The TDS3000B Series DPO Oscilloscope Manuals and
Application Notes CD contains the TDS3000B Series
Digital Phosphor Oscilloscope User Manual, translated
into all supported languages. The user manual contains
complete information on how to operate your
TDS3000B Series oscilloscope.
The CD also contains manuals for all TDS3000B Series
accessories, application notes, oscilloscope and probe
fundamentals, and software to install the Adobe Acrobat
Reader, which is required to view the online documents.
The signal path compensation (SPC) routine optimizes
the oscilloscope signal path for maximum measurement
accuracy. You can run the routine anytime but you
should always run the routine if the ambient temperature
changes by 10_ C or more.
To compensate the signal path, do the following steps:
1 Disconnect all probes or cables.
2 Push the UTILITY button.
3 Push the System screen button to select Cal.
4 Push the Signal Path screen button.
5 Push OK Compensate Signal Path.
Setting the User Interface Language
To set the user interface language, do the following
steps:
1 Push the UTILITY button.
2 Push the System screen button to select Config.
3 Push a side menu button to select a language.
7
10
To use a QuickMenu, do these steps
1 Push the QUICKMENU button on the front panel.
2 Push the screen button that corresponds to the control
you need to set. Push the screen button repeatedly to
choose one of the settings. The small arrow icon
indicates that there are additional settings available
that are not shown.
You can use most of the front-panel controls at the same
time you are using a QuickMenu. For example, if you
push a channel button to select a different channel, the
QuickMenu changes to show information about that
channel.
You can still use the regular menus. For example, if you
push the MEASURE button, you can set up and take
automatic waveform measurements in the usual way. If
you return to the QuickMenu, the measurement is still
displayed on the screen.
You may have optional application modules installed
that also have QuickMenu displays. To select the QuickMenu you want to use, push the MENU screen button.
This menu item is shown only if application modules
that contain a QuickMenu are installed.
QuickMenus
The QuickMenu feature simplifies the use of the oscilloscope. When you push the QUICKMENU button, a set
of frequently used menu functions show on the display.
Scope is one type of QuickMenu that you can use to
control the basic oscilloscope functions. You can perform many tasks without using the regular menu system.
9
Menus
12
Bottom DescriptionSide
Normal
Autoset
Executes the autoset function.
(Optional application modules
may add choices to execute
specialized autoset functions.)
Undo Autoset Reverts to the settings before
the last autoset.
Wfm Anomaly
Detection
On Off
Enables or disables the
WaveAlert Waveform Anomaly
Detection function. See page
13.
Sensitivity
nn.n%
Sets the comparison sensitivity.
Use the general purpose knob
to set sensitivity from 0% (least
sensitive) to 100% (most sensitive).
Beep On
Anomaly
On Off
When On, the oscilloscope
beeps if it detects a waveform
anomaly on any active channel.
Stop On
Anomaly
On Off
When On, the oscilloscope
stops waveform acquisition if
there is a waveform anomaly on
any channel. The input waveforms and anomalies remain
displayed on the screen.
The following sections briefly describe each oscilloscope
menu item.
Acquire Menu
Bottom Side Description
Mode
Horizontal
Resolution
Reset Horizontal Delay
Sample Use for normal acquisition.
Peak Detect Detects glitches and reduces
Envelope N Captures variations of a signal
Average N Reduces random or uncorre-
Fast Trigger
(500 points)
Normal
(10k points)
Set to 0 s Resets the horizontal delay to
the possibility of aliasing.
over a period of time. (Adjust N
with the general purpose knob.)
lated noise in the signal display.
(Adjust N with the general
purpose knob.)
Acquires 500 point waveforms
at a fast repetition rate.
Acquires 10,000 point waveforms with more horizontal
detail.
zero.
Autoset
WaveAlert
11
14
XY Cursor Menu
The following cursor menu items are available in the XY
display mode (DISPLAY > XY Display > Triggered
XY). Push the CURSOR button to show the cursor
menu.
Bottom Side Description
Off Turns cursors off.
Waveform Turns waveform cursors on and
displays measurements in
rectangular format (X and Y
values). Use the front-panel
SELECT button to select a
cursor. Use the general purpose
knob to move the active cursor.
Independent Sets cursors to move indepen-
dently.
Tracking Sets cursors to move together
when the reference cursor is
selected.
NOTE. The Advanced Analysis application
module (TDS3AAM) adds more XY cursor
features, including graticule cursors and polar
readouts.
Bottom DescriptionSide
WaveAlert
(cont.)
WaveAlertt Waveform Anomaly Detection. WaveAlert
provides a way to detect when a waveform deviates from
a steady-state condition. WaveAlert monitors the current
waveform acquisition and compares it to the previous
waveform acquisition. If the current acquisition exceeds
the comparison tolerance, the oscilloscope considers the
Hardcopy
On Anomaly
On Off
Wfms To Disk
On Anomaly
On Off
Highlight
Entire Wfm
Highlight
Anomaly
When On, the oscilloscope
sends an image of the screen to
the hard copy device or floppy
file if there is a waveform anomaly on any channel.
When On, the oscilloscope
saves the anomalous waveform(s) data to the floppy disk
drive.
Highlights the entire anomalous
waveform.
Highlights just the anomalous
data in a waveform.
current acquisition as an anomaly and responds by
stopping acquisitions, emitting a beep, saving the
anomalous waveform to a disk file, printing the screen
image to a hard copy device, or any combination of the
above. Refer to the TDS3000B Series Digital Phosphor
Oscilloscope User Manual for more information.
Function
Mode
13
YT Cursor Menu
16
Bottom
Side Description
Sec (s) /
1/sec (Hz)
Sets horizontal units to seconds or frequency (Hz).
Ratio (%) Sets V Bar measurement
units to percent.
Phase (degrees) Sets V Bar measurement
units to degrees.
Use cursor positions as %/°
Sets V Bar measurement
scale so that 0% or 0° is the
current position of left V Bar
cursor and 100% or 360° is
the current position of right V
Bar cursor.
Use 5 divs as
%/°
Sets V Bar measurement
scale so that 5 screen major
divisions is 100% or 360°,
where 0% or 0° is –2.5 divisions and 100% or 360° is
+2.5 divisions from center
graticule.
The following YT cursor menu items are available in the
YT display mode (DISPLAY > XY Display > Off
(YT)). Push the CURSOR button to show the cursor
menu.
Bottom Side Description
Function
Mode
Off Turns cursors off.
H Bars Use to take vertical measure-
V Bars Use to take both vertical and
Bring Selected
Cursor to
Center Screen
Bring Both Cursors On Screen
Independent Sets cursors to move indepen-
Tracking Sets cursors to move together
ments.
horizontal measurements.
Moves the active cursor to center
screen.
Moves any off-screen cursor onto
the screen.
dently.
when cursor 1 is selected.
V Bar Units
15
18
Display Menu
Bottom Side Description
Dots Only Set to on to see dots only. Set
to off to see dots and vectors.
Persist Time Sets persist time.
Set to Auto Sets the WA VEFORM
INTENSITY knob to control the
persistence time.
Clear
Persistence
Clears any displayed persis-
tence.
High Use for bright ambient condi-
tions.
Medium Use for dim ambient conditions.
Low Use to extend battery-operation
time.
Graticule Full, Grid,
Cross Hair,
Frame
Selects the graticule type.
Bottom
H Bar Units
Cursor Movement. Use the general purpose knob to move
the active cursor. Push the SELECT button to change
Side Description
Base Sets the H Bar units to be the
Ratio (%) Sets H Bar measurement units
Use cursor
positions as
100%
Use 5 divs as
100%
same as the selected waveform’s vertical measurement
units (volts, IRE, dB, and so
on).
to percent.
Sets the H Bar measurement
scale so that 0% is the current
position of lowest H Bar cursor
and 100% is the current position of highest H Bar cursor.
Sets H Bar measurement scale
so that 5 screen major divisions
is 100%, where 0% is –2.5
divisions and 100% is +2.5
divisions from center graticule.
which cursor is active.
Faster Cursor Movement. Push COARSE to set the general
purpose knob to make faster cursor movements.
Waveform
Display
Backlight Intensity
17
20
Another channel or reference waveform is displayed in
the vertical axis. Use the Vertical POSITION and
SCALE controls for that channel to adjust the vertical
position and size of the XY waveform.
XY Waveform Triggering. The XY waveform is triggered
so you can synchronize periodic input signals to the XY
waveform. This feature is useful when only one part of
the period contains valid information that you want to
see in the XY format. Set the time base and trigger
location to acquire just that part of the period.
When you want to see the complete period of the signals
regardless of the time base setting, set the trigger source
to an unused channel and the trigger mode to Auto.
Gated XYZ. Displays XY signals only when the Z (gating)
channel is true. Gated XYZ is similar to analog oscilloscope modulated XYZ mode except that the displayed
XY signal is either on or off; there is no intensity modulation. Gated XYZ is useful for displaying constellation
diagrams.
The general purpose knob sets the Z-channel threshold
level.
Bottom DescriptionSide
XY Display
Color Palette
Off (YT) Turns of f an XY display.
Triggered XY Turns on triggered XY display.
Gated XYZ Displays XY signals when
Ch1 (X)
Versus
Ref1 (X)
Versus
Gated By
Normal Selects the color display.
Monochrome Sets all waveforms to high-con-
Z-channel signal is above a set
level. Only available on 4-chan-
nel instruments.
Sets Ch2, Ch3, or Ch4, as Y
versus Ch1 as X.
Sets Ref2, Ref3, or Ref4 as Y
versus Ref1 as X.
Sets Ch2, Ch3, or Ch4 as Z
channel (gate) source, and
gating channel threshold level.
trast black and white.
XY Waveforms. For XY waveforms, channel 1 or Ref 1 is
displayed in the horizontal axis. Use the Vertical POSITION and SCALE controls to adjust the horizontal
position and size of the XY waveform.
19
22
Bottom DescriptionSide
Bring Selected
Cursor to
Center Screen
Moves the active cursor to
center screen.
Bring Both Cursors On Screen
Moves any off-screen cursor
onto the screen.
Auto Select Automatically uses the best
measurement method depend-
ing on the measurement type.
Histogram Use to measure pulses.
Min-Max Use to measure other wave
shapes.
Measure Menu
Bottom Side Description
Select
Measurement
Remove
Measurement
Gating
Measurement
1-4
All
Measurements
Off Use to take measurements on
Screen Use to take measurements on
Cursors Use to take measurements on
Select an automatic measure-
ment for the selected (active)
channel. Y ou can display up to
four measurements at one time.
See page 44.
Removes a specific measure-
ment.
Removes all measurements.
the full waveform record.
the portion of the waveform on
screen.
the portion of the waveform
between the V Bar cursors.
Gating
High-Low
Setup
21
24
Save/Recall Menu
Bottom Side Description
To File Saves a setup to disk.
To Setup 1
...
T o Setup 10
Saves a setup to nonvolatile
memory.
From File Recalls a setup from disk.
Recall Setup 1
...
Recall Setup
10
Recalls a setup from nonvolatile
memory.
Recall Factory
Setup
OK Confirm
Factory Init
Initializes the setup to a known
setup.
To File Shows file-format choices:
Internal, Spreadsheet, or Math-
cad. Saves active waveforms to
disk.
T o Ref1
...
T o Ref4
Saves the selected waveform to
nonvolatile memory.
Recall Wfm From File
Recall Ref1
...
Recall Ref4
Recalls a waveform from disk
and displays it as a reference
waveform.
Bottom DescriptionSide
Reference
Levels
Indicators
Set Levels in %
or units
High
Reference
Mid
Reference
Mid 2 Sets the custom mid reference
Low
Reference
Set to
Defaults
Measurement
1-4
Off Turns measurement indicators
Use to choose custom refer-
ence levels in relative or abso-
lute units.
Sets custom high reference
level.
Sets custom mid reference
level.
level for the Delay and Phase
measurement second wave-
form.
Sets custom low reference
level.
Sets reference levels to default
values.
Selects the measurement for
which to display markers that
show the portion of the wave-
form used to calculate the
measurement value.
off.
Save Current
Setup
Recall Saved
Setup
Save Wfm
23
26
Trigger Menus
Edge Trigger Menu
Bottom Side Description
Ch1
...
Ch4
Sets the trigger source to a
specific channel.
AC Line Selects the AC line trigger source
(for AC line operation only)
Ext
Ext/10
Ext Probe
nnX
Voltage / Current
(4-channel only)
Set this value to match the
attenuation factor and the type of
probe (voltage or current) that is
attached to the external trigger
connector. Push the menu button
to select the probe type. Use the
general purpose knob to set the
attenuation factor. The default
values are 1x and voltage.
File Utilities Menu
Bottom Side Description
File
Utilities
Labels Create/edit labels for reference waveforms and
Delete Deletes a file.
Rename
Copy Copies a file to another directo-
Print Prints a file to a printer con-
Create
Directory
Confirm
Delete
Overwrite
Lock
Format Formats a disk (erases all files).
instrument setups stored in nonvolatile memory.
Names or renames a file.
ry.
nected to one of the hard copy
ports.
Creates a new directory.
Turns On or Off a confirmation
message before files are de-
leted.
Sets file overwrite protection to
On or Off.
Source
Sets the oscilloscope to trigger
on the external trigger source.
Ext/10 attenuates the external
trigger signal by a factor of 10.
25
Bottom DescriptionSide
28
Bottom DescriptionSide
Level Use to set the trigger level with
the general purpose knob.
Set to TTL Sets the trigger level to +1.4 V
for TTL logic.
Set to ECL Sets the trigger level to –1.3 V for
ECL logic (V
ee
= –5.2 V).
Set to 50% Sets the trigger level to the 50%
amplitude level of the signal.
Auto (untriggered
roll)
Enables free-running and rollmode acquisitions.
Normal Triggers only on valid trigger
events.
Holdoff (time) Sets holdoff to a specific time.
Holdoff
(% of record)
Sets holdoff to a percent of the
record duration.
Set to Min Sets holdoff to the minimum
value.
Source
Vert Sets the trigger source to the
Alternating
(all active channels)
Coupling
DC Selects DC coupling.
HF Reject Rejects frequencies above
LF Reject Rejects frequencies below
Noise Reject DC coupling with low sensitivity
Slope
/ (rising edge) Triggers on the rising edge of a
\ (falling edge) Triggers on the falling edge of a
lowest-numbered active channel
in the display.
Sequentially uses each active
channel as a trigger source, from
the lowest-numbered active
channel to the highest-numbered
active channel.
30 kHz in the trigger signal.
80 kHz in the trigger signal.
to reject noise in the trigger
signal.
signal.
signal.
Level
Mode &
Holdoff
27
30
B Trigger Menu
Bottom Side Description
B Trigger After
A Time
Sets the oscilloscope to trigger
on the next B-trigger event that
occurs after a specified period
of time from the A trigger. Use
the general purpose knob to set
the time value.
Set to Delay
Time (B³
▼)
then Set
(B³
▼) to 0s
Sets the B Trigger After A Time
value to the horizontal B³
▼
value, then sets B³▼ to zero
seconds. B³
▼ is the delay
time from the B trigger point to
the expansion point (center
screen).
Set to Min Sets B Trigger After A time to
26.4 ns.
B Events Sets the oscilloscope to trigger
on the nth B-trigger event after
the A trigger. Use the general
purpose knob to set the event
value.
Set to Min Sets the B events count to 1.
Video Trigger Menu
Bottom Side Description
Standard
Source Selects the trigger source. See
Trigger On
NOTE. The Extended Video application module
(TDS3VID) adds more video features including
custom video triggering, video picture,
vectorscope, and analog HDTV triggering.
525/NTSC Triggers on a NTSC signal.
625/PAL Triggers on a P AL signal.
SECAM Triggers on a SECAM signal.
Odd
Even
All Fields Triggers on any field in an
All Lines Triggers on all lines.
Edge Trigger Menu for descriptions of these menu items.
Triggers on odd or even fields in
an interlaced signal.
interlaced or noninterlaced
signal.
B Trigger
After A
29
Bottom DescriptionSide
appears in the language you
32
Bottom DescriptionSide
Display Date/
Time
Use to turn the date/time
display On or Off.
Hour Min Use to set the internal clock
with the current hour and minute.
Month Day Use to set the internal clock
with the current month and day.
Year Use to set the internal clock
with the current year.
OK Enter
Date/Time
Sets the date and time of the
internal clock.
Power Off
Time-Out
Use to set the time before an
automatic shut down.
Backlight
Time-Out
Use to set the time before the
backlight automatically turns off.
T ek Secure
Erase Memory
Erases all nonvolatile waveform
and setup memory.
Version Use to see the firmware ver-
sion.
Source
Coupling
Slope
Level
Utility Menus
Configuration System Menu
Bottom Side Description
Language
English
Français
Deutsch
Italiano
Español
Português
(Russian)
(Japanese)
(Korean)
(Simplified
Chinese)
(Traditional
Chinese)
Sets Source, coupling, slope,
and level for the B trigger.
These settings are independent
of similar settings for the A
trigger. See Edge Trigger Menu
for descriptions of these menu
items.
Use to choose your native
language. Most on-screen text
appears in the language you
choose.
Set Date &
Time
Battery
Time-Outs
31
34
Bottom DescriptionSide
Change
Instrument
Settings
Sets oscilloscope Ethernet
parameters such as the IP
address, instrument name, and
domain name.
DHCP/
BOOTP
Enables or disables DHCP/
BOOTP support.
Debug Enables or disables a debug
message window.
Test
Connection
T ests the connection to your
network.
Add Printer
Rename
Printer
Delete Printer
Confirm
Delete
Enables or disables displaying a
printer name delete confirmation
message.
More Information. Refer to the TDS3000 & TDS3000B
Series Digital Phosphor Oscilloscope Programmer
Manual for more information.
I/O System Menu
Bottom Side Description
GPIB
(TDS3GV)
RS-232
(TDS3GV)
Talk/Listen Address
Hard Copy
(Talk Only)
Off Bus Disables the GPIB port.
Debug Enables and disables a mes-
Baud Rate Sets the baud rate in steps from
Flagging Use to enable hard flagging
EOL Selects end-of-line terminator.
Debug Enables and disables a mes-
Set RS-232
Parameters to
Default Values
Sets the GPIB address.
Sets the GPIB port to talk only
for making hard copies.
sage window to help you debug
GPIB problems.
1200 to 38400.
(RTS/CTS) or turn flagging off.
sage window to help you debug
RS-232 problems.
Sets baud rate = 9600, hard
flagging = on, and EOL = LF.
Ethernet Network Settings
Ethernet Printer Settings
Adds, renames, or deletes an
Ethernet network printer from
the oscilloscope printer list.
33
Hard Copy System Menu (Utility > System: Hard Copy )
36
Calibration System Menu
Bottom Side Description
System Cal
Signal Path Compensates the signal paths
to obtain best measurement
accuracy.
Factory Cal Used to calibrate the oscillo-
scope. This is a service function
only.
Notify After
Hours of Operation
Sets the number of hours of
operation before notifying you
that a calibration is due.
Notify After
Years of
Elapsed Time
Sets the number of years before
notifying you that a calibration is
due.
Signal Path Compensation. You can run the Signal Path
Compensation routine anytime but you should always
run the routine if the ambient temperature changes by
10 °C or more.
Bottom Side Description
Format Choose the correct hard copy
Options
Ink Saver
Port
Clear Spool Stops a hard copy in progress.
Portrait Prints in a portrait orientation.
Landscape Prints in a landscape orienta-
Compression Turn on or off hard copy file .gz
Off Prints the display colors.
On Prints colors optimized for
Preview Shows a preview of the hard
Centronics Uses the parallel printer port.
GPIB Uses the GPIB port.
RS-232 Uses the RS-232 port.
File Saves the hard copy to the
Ethernet Uses the Ethernet LAN port.
format for your printer.
tion.
compression format.
printing on white paper.
copy colors on the display.
floppy disk.
Clears the print spooler.
Cal Due
Control
35
38
Vertical Menus
Channel Menu
Bottom Side Description
DC Sets input coupling to DC.
AC Sets input coupling to AC.
GND Provides a 0 V signal reference.
The input BNC disconnects
from internal circuits.
W Sets input resistance to 50 W
or 1 MW.
Invert Off Use for normal operation.
Invert On Inverts the polarity of the signal
in the display.
Full Bandwidth Sets bandwidth to the full
oscilloscope bandwidth.
150 MHz Sets the bandwidth to 150 MHz
(not available on some models).
20 MHz Sets the bandwidth to 20 MHz.
Fine Scale Enables fine scale adjustment
with the general purpose knob.
Diagnostic System Menu
Bottom Side Description
System Diags
Execute Starts diagnostics.
Loop
Error Log
Once Executes the diagnostic loop
Always Executes the diagnostic loop
Until Fail Executes until a failure occurs.
Page Up Use to see the previous error
Page Down Use to see the next error log
once.
continuously.
log page.
page.
Coupling
Invert
Bandwidth
37
40
Math Menu
Bottom Side Description
Set 1st SourcetoSelects the first source wave-
form.
Set OperatortoSelects the math operator: +, –,
, or B
Set 2nd
Source to
Selects the second source
waveform.
Ref Menu
Bottom Side Description
Save Ch1 to
Ref1
Saves channel 1 to reference
waveform Ref 1.
Save Ch2 to
Ref1
Saves channel 2 to reference
waveform Ref 1.
Save Ch3 to
Ref1
Saves channel 3 to reference
waveform Ref 1.
Save Ch4 to
Ref1
Saves channel 4 to reference
waveform Ref 1.
Save Math to
Ref1
Saves the math waveform to
reference waveform Ref 1.
Ref 2
Ref 3
Ref 4
Identical settings for reference waveforms Ref 2,
Ref 3, and Ref 4.
Bottom DescriptionSide
Position
Offset
Probe Setup
Vertical Position
Set to 0 divs Sets vertical position to center
Vertical Offset Enables vertical offset adjust-
Set to 0 V Sets vertical offset to 0 V .
Voltage Probe
Current Probe
Deskew Use to adjust the time skew
Set to 0 Use to set probe skew correc-
Enables numerical vertical
position adjustment.
screen.
ment with the general purpose
knob.
Use to set probe gain or attenu-
ation for probes that do not
have the TekProbe II interface.
correction for each probe.
tion to zero.
Dual Wfm
Math
Ref 1
39
42
Configuring Your Oscilloscope Ethernet Settings
Before using the e*Scope feature, you must set your
oscilloscope Ethernet network settings. The TDS3000B
Series Digital Phosphor Oscilloscope User Manual,
Appendix G, Ethernet Setup, describes how to enter the
Ethernet network parameters for your oscilloscope.
Accessing e*Scope
After your instrument is set up with the correct ethernet
settings, you are ready to access that instrument over the
Internet. To access you instrument’s e*Scope server, do
the following steps:
1 On a PC or work station, open a network browser
program.
2 In the Location or Address field (where you normally
enter a URL), type in the IP address of the
TDS3000B instrument to which you want to connect.
For example, 188.121.212.107. Do not precede the IP
address with any characters. Then press the Return
key.
3 The browser program loads the instrument’s e*Scope
Web-based Remote Control home page, which is an
image of the screen contents when your browser
accessed the instrument.
e*Scope Web-based Remote Control
e*Scope introduces the next generation of oscilloscope
functionality. W ith e*Scope you can access any Internetconnected TDS3000B Series oscilloscope from a
browser on your work station, PC, or laptop computer.
No matter where you are, your TDS3000B is as close as
the nearest browser!
There are two levels to e*Scope: basic and advanced.
The basic level, which is hosted on the oscilloscope, lets
you view a screen image of the current acquisition, save
or load waveform and setup files, and remotely control
the oscilloscope using the oscilloscope programming
commands.
The advanced level, which is hosted on your system,
provides a graphical user interface to remotely control
the oscilloscope. To obtain the advanced level software,
go to the Tektronix TDS3000B website and download
the web-based remote control software.
NOTE. You can also use e*Scope on TDS3000
Series oscilloscopes that are equipped with a
TDS3EM Ethernet communication module and
are running firmware version 3 or above.
41
Menu Functions
44
Automatic Measurements
Measurement
Definition
Amplitude Measured over the entire waveform.
Amplitude = High (100%) – Low (0%)
Burst
Width
The duration of a burst. Measured over the entire
waveform.
Cycle
Mean
The arithmetic mean over the first cycle in the
waveform.
Cycle
RMS
The true Root Mean Square voltage over the first
cycle in the waveform.
Delay The time between the Mid Reference crossings of
two different waveforms.
Fall Time Time that the falling edge of the first pulse in the
waveform takes to fall from 90% to 10% of its
amplitude.
Frequency Reciprocal of the period of the first cycle in the
waveform. Measured in Hertz (Hz).
High The value used as 100%. Calculated using either the
min/max or the histogram method. Measured over
the entire waveform.
Low The value used as 0%. Calculated using either the
min/max or the histogram method. Measured over
the entire waveform.
The menu at the top of the page provides the following
functions:
H Home displays the oscilloscope screen.
H Applications takes you to the application URL
specified in the Configure tab. The default URL is the
application notes site at www.tektronix.com.
H Configure lets you specify URLs for the advanced
Web-based Control HTML pages (Control),
application notes (Applications), and help files
(Help). The default values are for the Tektronix web
site. However, you can host any of these on your
local Intranet for faster access and better system
security.
H Data lets you upload or download waveform data
files and oscilloscope settings, as well as remotely
control the oscilloscope using oscilloscope
programing commands.
H Status displays the version screen, which shows the
firmware version and lists installed application
modules.
H Control displays the advanced Web-based Control
page that lets you remotely control the oscilloscope.
43
46
Measurement
Definition
Positive
Duty Cycle
Positive Duty Cycle +
Positive Width
Period
100%
Measurement of the first cycle in the waveform.
Positive
Overshoot
Measured over the entire waveform.
Positive Overshoot+
Max–High
Amplitude
100%
Positive
Width
Measurement of the first positive pulse in the
waveform. The time between the 50% amplitude
points.
Rise Time Time that the leading edge of the first pulse in the
waveform takes to rise from 10% to 90% of its
amplitude.
RMS The true Root Mean Square voltage over the entire
waveform.
Snapshot
All Measurements
Displays all measurement values (except two-channel measurements) at the time you pushed the
Snapshot All Measurements button, for the
selected waveform. Push the Snapshot All
Measurements button again to update the list
values. Push the MENU OFF button to clear the list
from the screen.
Measurement
Max The maximum amplitude. The most positive peak
Mean The arithmetic mean over the entire waveform.
Min The minimum amplitude. The most negative peak
Negative
Duty Cycle
Negative
Overshoot
Negative
Pulse
Width
Phase The amount one waveform leads or lags another in
Pk–Pk Measured over the entire waveform.
Period Time it takes for the first complete signal cycle to
Definition
voltage measured over the entire waveform.
voltage measured over the entire waveform.
Measurement of the first cycle in the waveform.
Negative Duty Cycle +
Measured over the entire waveform.
Negative Overshoot +
Measurement of the first negative pulse in the
waveform. The time between the 50% amplitude
points.
time. Expressed in degrees, where 360_ comprise
one waveform cycle.
Peak-to-peak = Max – Min
complete in the waveform. Measured in seconds.
Negative Width
Period
Low–Min
Amplitude
100%
100%
45
Loading...
