Tektronix TDS2024, TDS2022, TDS2014, TDS2012, TDS2002 Datasheet

Features & Benefits

60 MHz, 100 MHz and
200 MHz Bandwidths

Sample Rates up to 2 GS/s
2 or 4 Channels
Color or Monochrome

LCD Display
Autoset Menu with Waveform

Selection
Probe Check Wizard To

Ensure Correct Probe Usage
Context-sensitive Help
Dual Time Base
Advanced Triggering
11 Automatic Measurements
Multi-language User Interface
Waveform and Setup

Memories
FFT Standard on All Models
Extended Capabilities Are

Provided with Optional
TDS2CMA Module,
WaveStar

™

Software and

Probes

Applications

Service and Repair
Education and Training
Manufacturing Test and

Quality Control
Design and Debug

Digital Storage Oscilloscopes

TDS1002 • TDS1012 • TDS2002 • TDS2012 • TDS2014 • TDS2022 • TDS2024

TDS1000 and TDS2000 Series Oscilloscopes.
Colorful Performance at a Black and White Price.

The TDS1000 Series and TDS2000 Series
digital storage oscilloscopes deliver an
unbeatable combination of superior perform­ance,unmatched ease-of-use and affordability
in an ultra lightweight, portable package. These
new products extend the performance and
ease-of-use features in the former TDS200
Series, the benchmark for low-cost oscilloscopes.

Affordable Digital
Performance

With up to 200 MHz bandwidth and 2 GS/s
maximum sample rate, no other color digital
storage oscilloscope offers as much band­width and sample rate for the price.The
TDS1000 and TDS2000 Series oscilloscopes

provide accurate real-time acquisition up to
their full bandwidth.These instruments offer
advanced triggering, such as pulse width trig­gering and line-selectable video triggering,
and 11 standard automatic measurements on
all models.The Fast Fourier Transform (FFT)
math function allows the user to analyze,
characterize and troubleshoot circuits by view­ing frequency and signal strength (standard
on all models).

Simple User Interface

The simple user interface makes these instru­ments easy to use, reducing learning time and
increasing efficiency.Classic, analog-style
controls provide instant, front-panel access to

Digital Storage Oscilloscopes • TDS1000 and TDS2000 Series Oscilloscopes • www.tektronix.com/scopes

1

Digital Storage Oscilloscopes

TDS1002 •TDS1012 •TDS2002 • TDS2012 •TDS2014 •TDS2022 •TDS2024

the most frequently used functions.The
autoset function automatically detects sine
waves, square waves and video signals, and
provides readouts of relevant measurements.
This function also allows the user to select
additional views of the signal, such as rising
and falling edges, video lines and fields, and
FFT.The probe check wizard aids the user in
setting the attenuation factor and compensat­ing the probe.The context-sensitive help
menu with indexed and hyper-linked topics
allows the user to selectively learn about the
operation of any oscilloscope function.The
color LCD display on the TDS2000 Series
models dedicates a different color for each
trace and its associated readouts to simplify
viewing complex signals on multiple channels.

Characteristics

Acquisition Modes

Peak Detect – High frequency and random glitch cap­ture. Captures glitches as narrow as 12 ns typical using
acquisition hardware at all time/div settings from
5 µs/div to 50 s/div.

Sample – Sample data only.
Average – Waveform averaged, selectable: 4, 16,

64, 128.
Single Sequence – Use the Single Sequence button

to capture a single triggered acquisition sequence
at a time.

Trigger System (Main Only)

Trigger Modes –Auto,Normal,Single Sequence.

Trigger Types

Edge (rising or falling) – Conventional level-driven
trigger.Positive or negative slope on any channel.
Coupling selections:AC,DC,Noise Reject,HF Reject,
LF Reject.

Video – Trigger on all lines or individual line,
odd/even or all fields from composite video, or
broadcast standards (NTSC, PAL,SECAM).

Pulse Width (or Glitch) – Trigger on a pulse width
less than, greater than, equal to or not equal to a
selectable time limit ranging from 33 ns to 10 sec.

Trigger Source

2-channel models – CH1, CH2, Ext, Ext/5, AC Line.
4-channel models – CH1, CH2, CH3, CH4, Ext,

Ext/5,AC Line.

Trigger View

Displays trigger signal while trigger view button
is depressed.

Digital Storage Oscilloscopes • TDS1000 and TDS2000 Series Oscilloscopes • www.tektronix.com/scopes

2

TDS1000 and TDS2000 Series Electrical Characteristics

TDS1002 TDS1012 TDS2002 TDS2012 TDS2014 TDS2022 TDS2024

Display Mono Mono Color Color Color Color Color
(1/4 VGA LCD)

Bandwidth*

1

60 MHz 100 MHz 60 MHz 100 MHz 100 MHz 200 MHz 200MHz
Channels 2 222424
External Yes on all models

Trigger Input
Sample Rate 1.0 GS/s 1.0 GS/s 1.0 GS/s 1.0GS/s 1.0 GS/s 2.0GS/s 2.0 GS/s

on each channel
Record Length 2.5 K points on all models
Vertical 8-bits

Resolution
Vertical 2 mV to 5 V/div on all models with calibrated fine adjustment

Sensitivity
DC Vertical ±3% on all models

Accuracy
Vertical Zoom Vertically expand or compress a live or stopped waveform
Max Input 300 V

RMS

CATII; derated at 20 dB/decade above 100 kHz to 13 V

p-p

AC at 3 MHz and above

Voltage
Position 2 mV to 200 mV/div ±2 V

Range >200 mV to 5 V/div ±50 V
BW Limit 20 MHz for all models
Input Coupling AC, DC, GND on all models
Input Impedance 1 MΩ in parallel with 20 pF
Time Base 5 ns to 5 ns to 5 ns to 5 ns to 5 ns to 2.5 ns to 2.5 ns to

Range 50 sec/div 50 sec/div 50 sec/div 50 sec/div 50 sec/div 50 sec/div 50 sec/div
Time Base 50 ppm

Accuracy
Horizontal Zoom Horizontally expand or compress a live or stopped waveform

*1Bandwidth is 20 MHz at 2 mV/div,all models.

Digital Storage Oscilloscopes

TDS1002 •TDS1012 •TDS2002 • TDS2012 •TDS2014 •TDS2022 •TDS2024

Trigger Signal
Frequency Readout

Provides a frequency readout of the trigger source.

Cursors

Types– Voltage,Time.
Measurements – [∆]T,1/[∆]T (frequency),[∆]V.

Measurement System

Automatic Waveform Measurements – Period,
Frequency,+Width, –Width, Rise-time, Fall-time,
Max, Min, Peak-to-Peak, Mean, Cycle RMS.

Waveform Processing

Operators – Add, Subtract, FFT.
FFT – Windows: Hanning, Flat Top,Rectangular;

2048 sample points.

Sources –

2-channel models: CH1 - CH2, CH2 - CH1,
CH1 + CH2.
4-channel models: CH1 - CH2, CH2 - CH1,
CH3 - CH4, CH4 - CH3, CH1 + CH2, CH3 + CH4.

Nonvolatile Storage

Waveform Display – Two 2500 point
reference waveforms.

Waveform Storage – 2-channel models: Two 2500
point reference waveforms. 4-channel models:
Four 2500 point reference waveforms.

Setups – 10 front-panel setups.

Display Characteristics

Display –

Monochrome models: 1/4 VGA,backlit passive LCD
with adjustable multi-level contrast and inverse video
selectable from front panel.
Color models: 1/4 VGA,passive color LCD with color on
black background with adjustable multi-level contrast.

Interpolation – Sin(x)/x.
Display Types– Dots, vectors.
Persistence – Off, 1 sec, 2 sec, 5 sec, infinite.
Format – YT and XY.

Autoset Menu

Single-button, automatic setup of all channels
for vertical, horizontal and trigger systems, with
undo autoset.

I/O Interface
TDS2CMA Communications

Extension Module

Printer Port – Centronics-type parallel.
GPIB (IEEE std. 488-1987) Programmability –

Full talk/listen modes. Control of all modes, settings
and measurements. Includes WaveStar

™

software

for oscilloscopes, 30-day product demo.
RS-232 Programmability – Full talk/listen modes.

Control of all modes, settings and measurements.
Baud rate up to 19,200. 9-Pin, DTE.

Printer Capability (Requires
TDS2CMA Module)

Graphics File Formats – TIFF,PCX (PC Paintbrush),
BMP (Microsoft Windows),EPS (Encapsulated
Postscript) and RLE.

Printer Formats – Bubble Jet, DPU-411, DPU-412,
DPU-3445,Thinkjet,Deskjet, LaserJet, and Epson
(9- or 24-Pin).

Layout – Landscape or Portrait.

Environmental and Safety

Temper ature–

Operating: 0°C to +50°C.
Nonoperating: –40°C to +71°C.

Humidity –

Operating and Nonoperating: up to 90% RH
at or below +30°C.
Operating: up to 60% RH up to 50°C.
Nonoperating: up to 60% RH up to 55°C.

Altitude –

Operating and Nonoperating: up to 3,000 m.
Electromagnetic Compatibility – Meets Directive

89/336/EEC, amended by 93/68/EEC, meets or
exceeds EN55011 Class A Radiated and Conducted
Emissions; FCC 47 CFR, Part 15, Subpart B, Class A;
Australian EMC Framework, demonstrated per
Emission Standard AS/NZS 2064; Russian GOST
EMC regulations.

Safety – UL3111-1, CSA1010.1, IEC61010-1,
EN61010-1.

Physical Characteristics

INSTRUMENT
Dimensions mm in.

Width 323.8 12.75
Height 151.4 5.96
Depth 124.5 4.90

Weight kg lbs.

Instrument only 2.0 4.4
with accessories 2.2 4.9

INSTRUMENT SHIPPING
Package Dimensions mm in.

Width 476.2 18.75
Height 266.7 10.50
Depth 228.6 9.00

RM2000 RACKMOUNT
Dimensions mm in.

Width 482.6 19.00
Height 177.8 7.00
Depth 108.0 4.25

Instrument Accessories

TDS2CMA – Communications Extension Module
(Includes user and programmer manuals. Does not
include I/O cable).

AD007 – LAN/WAN GPIB converter.
AC220 – Soft case for carr ying instrument.
HCTDS32 – Hard plastic case for carr ying instrument

(requires AC220).

Digital Storage Oscilloscopes • TDS1000 and TDS2000 Series Oscilloscopes • www.tektronix.com/scopes

3

Autoset Menu for Multiple

Signal Types

Signal Type Autoset Menu

Choices

Square wave Single-cycle

Multi-cycle

Rising or Falling Edge

Sine Wave Single-cycle

Multi-cycle

FFT Spectrum

Video (NTSC, PAL, Field:All, Odd or Even
SECAM) Line: All or Selectable

Line Number

For the most up-to-date product information

visit our web site at

www.tektronix.com

Copyright © 2002, Tektronix, Inc. All rights reserved. Tektronix products are
covered by U.S. and foreign patents, issued and pending.Information in this pub­lication supersedes that in all previously published material.Specification and price
change privileges reserved. TEKTRONIX and TEK are registered trademarks of
Tektronix,Inc.All other trade names referenced are the service marks,trademarks
or registered trademarks of their respective companies.

02/02 HB/PG 40W-15314-0

Digital Storage Oscilloscopes • TDS1000 and TDS2000 Series Oscilloscopes • www.tektronix.com/scopes

4

Digital Storage Oscilloscopes

TDS1002 •TDS1012 •TDS2002 • TDS2012 •TDS2014 •TDS2022 •TDS2024

RM2000 – Rackmount kit.
Service Manual (TDS1000 and TDS2000 Series

Digital Storage Oscilloscopes) – English Only

(071-1076-00).

Programmer Manual (TDS200,TDS1000 and
TDS2000 Series Digital Storage Oscilloscopes) –

English only (071-1075-00).

WaveStar

™

Software for Oscilloscopes (WSTRO) –

Windows 95/98/NT 4.0 application for waveform
capture, analysis, documentation and control from
your PC.

Operator Training Kit – Extensive instructions and
step-by-step lab exercises provide education about
the operation of the TDS1000 and TDS2000 Series
oscilloscopes. Kit includes a self-paced CD-ROM­based manual and signal source board. (TNGTDS01).
Optional hard copy manual is available for
order separately.

Probes

P2200 – 10X – 1X switchable passive probe
(200 MHz when 10X is selected).

P6015A – 1000X high voltage passive probe
(75 MHz).

P5100 – 100X high voltage passive probe
(250 MHz).

P5200 – High voltage active differential probe
(25 MHz).

P6021 – 60 MHz AC current probe.
P6022 – 120 MHz AC current probe.
A621 – 2000 A AC current probe/BNC.
A622 – 100 A AC/DC current probe/BNC.
AM503S – AC/DC current probe system.

Ordering Information

TDS1002, TDS1012, TDS2002,
TDS2012, TDS2014, TDS2022,
TDS2024 Digital Storage
Oscilloscopes

Standard Accessories

Probes – P2200 200-MHz 10X – 1X Switchable
Passive Probes (one per channel).

Documentation – User manual.
Power cord.
NIM/NIST-Traceable Certificate of Calibration.

Warranty Information

Three year warranty covering all labor and parts,
excluding probes.

International Power Plugs

Standard – U.S. 120 V,60 Hz (161-0066-00).
Opt. A1 – Universal Euro 220 V,50 Hz

(161-0066-09).
Opt. A2 – United Kingdom 240 V,50 Hz

(161-0066-10).

Opt. A3 – Australia 240 V,50 Hz (161-0066-11).
Opt. A5 – Switzerland 220 V,50 Hz (161-0154-00).
Opt. AC – China 240 V,50 Hz (161-0304-00).
Opt. 99 – No power cord.

Accessory Cables

GPIB,1 m (3.3 ft.) – Order 012-0991-01.
GPIB,2 m (6.6 ft.) – Order 012-0991-00.
RS-232, 9-Pin female to 25-Pin male,

4.6 m (15 ft.), for Modems – Order 012-1241-00.
RS-232, 9-Pin female to 9-Pin female,null

modem, for computers – Order 012-1379-00.
RS-232, 9-Pin female to 25-Pin female,null

modem, for computers – Order 012-1380-00.
RS-232, 9-Pin female to 25-Pin male,null

modem, for printers – Order 012-1298-00.
Centronics, 25-Pin male to 36-Pin Centronics,

2.4 m (8 ft.), for Parallel Printer Interfaces –

Order 012-1214-00.

International User Manual
(TDS1000 and TDS2000 Series
Digital Storage Oscilloscopes,
includes TDS2CMA user
information)

Standard – English (071-1064-00).
Opt. L1 – French (071-1065-00).
Opt. L2 – Italian (071-1066-00).
Opt. L3 – German (071-1067-00).
Opt. L4 – Spanish (071-1068-00).
Opt. L5 – Japanese (071-1069-00).
Opt. L6 – Portuguese (071-1070-00).
Opt. L7 – Simplified Chinese (071-1071-00).
Opt. L8 – Traditional Chinese (071-1072-00).
Opt. L9 – Korean (071-1073-00).
Opt. LR – Russian (071-1074-00).

Translated front panel overlays included with their
respective user manuals (except Russian).

Contact Tektronix:

ASEAN Countries & Pakistan (65) 6356 3900

Australia & New Zealand (65) 6356 3900

Austria [phone]

Belgium [phone]

Brazil & South America 55 (11) 3741-8360

Canada 1 [phone]

Central Europe & Greece [phone]

Denmark [phone]

Finland [phone]

France & North Africa [phone]

Germany [phone]

Hong Kong (852) 2585-6688

India (91) 80-2275577
Italy [phone]

Japan (Sony/Tektronix Corporation) 81 (3) 3448-3111

Mexico, Central America & Caribbean 52 (55) 56666-333

The Netherlands [phone]

Norway [phone]

People’s Republic of China 86 (10) 6235 1230

Poland [phone]

Republic of Korea 82 (2) 528-5299

Russia, CIS & The Baltics [phone]

South Africa [phone]

Spain [phone]

Sweden [phone]/4

Taiwan886 (2) 2722-9622

United Kingdom & Eire [phone]

USA 1 [phone]

For other areas contact Tektronix, Inc.at:1 [phone]

Updated 8 February 2002
