Tektronix TDS2024 Data Sheet

Digital Storage Oscilloscopes

TDS1000 Series • TDS2000 Series

TDS1000 and TDS2000 Series Oscilloscopes.
Brilliantly Engineered. Irresistibly Priced.

The TDS1000 Series and TDS2000
Series digital storage oscilloscopes deliver
an unbeatable combination of superior
performance, unmatched ease-of-use
and affordability in an ultra lightweight,
portable package.

Affordable Digital Precision

With up to 200 MHz bandwidth and
2 GS/s maximum sample rate, no other
color digital storage oscilloscope offers
as much bandwidth and sample rate
for the price. The TDS1000 and TDS2000
Series oscilloscopes provide accurate
real-time acquisition up to their full band­width, advanced triggers to isolate signals
of interest and 11 standard automatic
measurements on all models.
Their Fast Fourier Transform (FFT)
math function allows the user to analyze,
characterize, and troubleshoot circuits
by viewing frequency and signal strength
(standard on all models).

Features & Benefits

40 MHz, 60 MHz, 100 MHz
and 200 MHz Bandwidths

Sample Rates up to 2 GS/s

2 or 4 Channels

Color or Monochrome
LCD Display

CompactFlash Mass Storage
Option with TDS2MEM Module

Autoset Menu with
Waveform Selection

Probe Check Wizard To Ensure
Correct Probe Usage

Context-sensitive Help

Dual Time Base

Advanced Triggers, Including
Pulse Width Trigger and Line­Selectable Video Trigger

11 Automatic Measurements

Multi-language User Interface

Waveform and Setup Memories

FFT Standard on All Models

OpenChoice®Solutions Speed
Documentation and Analysis of
Measurement Results

– TDS2CMAX Communication

Module

– TDS2MEM Storage Memory

and Communication Module

– TDSPCS1 OpenChoice PC

Communication Software
– WaveStar™Software
– Integration with Third-party

Software

Applications

Design and Debug

Education and Training

Manufacturing Test and
Quality Control

Service and Repair

Digital Storage Oscilloscopes

TDS1000 Series • TDS2000 Series

Unparalleled measurement accuracy with
up to 200 MHz bandwidth and 2 GS/s
maximum sample rate.

Ultra-fast Setup and Use

The simple user interface with classic,
analog-style controls makes these instru­ments easy to use, reducing learning time
and increasing efficiency. Innovative features
such as the autoset menu, probe check
wizard, context-sensitive help menu and
color LCD display (TDS2000 Series) opti­mize instrument setup and operation.

Pulse-width and field- and line-selectable
video triggers make the oscilloscope ideal
for a wide range of applications.

Simple, Speedy Documentation
and Analysis

OpenChoice

®

solutions deliver simple,
seamless integration between the oscillo­scope and the personal computer, providing
you with multiple choices to easily document
and analyze your measurement results.

Precisely analyze, characterize and trouble­shoot circuits – at the push of a button with
the autoset menu.

Choose from optional communication
modules, CompactFlash mass storage
capability, OpenChoice software or
integration with third-party software.

TDS1000/2000 Series Oscilloscope • www.tektronix.com/tds1000_2000

2

Digital Storage Oscilloscopes

TDS1000 Series • TDS2000 Series

Automatically detects sine waves, square
waves and video signals, with readouts
of relevant measurements and additional

Easily document and analyze measurement
results using OpenChoice

®

software.

user-selectable views of the signal.

Quickly transfer waveforms and measure­ment data to an external PC or between
oscilloscopes.

Characteristics

TDS1000 and TDS2000 Series Electrical Characteristics

TDS1001 TDS1002 TDS1012 TDS2002 TDS2004 TDS2012 TDS2014 TDS2022 TDS2024

Display (1/4 Mono Mono Mono Color Color Color Color Color Color
VGA LCD)

Bandwidth

Channels 222242 424

External Trigger Present on all models
Input

Sample Rate on 1.0 GS/s 1.0 GS/s 1.0 GS/s 1.0 GS/s 1.0 GS/s 1.0 GS/s 1.0 GS/s 2.0 GS/s 2.0 GS/s
Each Channel

Record Length 2.5 K points on all models

Vertical 8-bits
Resolution

Vertical 2 mV to 5 V/div on all models with calibrated fine adjustment
Sensitivity

DC Vertical ±3% on all models
Accuracy

Vertical Zoom Vertically expand or compress a live or stopped waveform

Max Input 300 V
Voltage

Position Range 2 mV to 200 mV/div ±2 V; >200 mV to 5 V/div ±50 V

BW Limit 20 MHz for all models

Input Coupling AC, DC, GND on all models

Input Impedance 1 MΩ in parallel with 20 pF

Time Base 5 ns to 5 ns to 5 ns to 5 ns to 5 ns to 5 ns to 5 ns to 2.5 ns to 2.5 ns to
Range 50 s/div 50 s/div 50 s/div 50 s/div 50 s/div 50 s/div 50 s/div 50 s/div 50 s/div

Time Base
Accuracy 50 ppm

Horizontal Zoom Horizontally expand or compress a live or stopped waveform

*1

*1

40 MHz 60 MHz 100 MHz 60 MHz 60 MHz 100 MHz 100 MHz 200 MHz 200 MHz

Bandwidth is 20 MHz at 2 mV/div, all models.

CAT II; derated at 20 dB/decade above 100 kHz to 13 V

RMS

AC at 3 MHz and above

pk-pk

TDS1000/2000 Series Oscilloscope • www.tektronix.com/tds1000_2000

3

Digital Storage Oscilloscopes

TDS1000 Series • TDS2000 Series

Acquisition Modes

Peak Detect –

High frequency and random glitch capture. Captures
glitches as narrow as 12 ns (typical) using acquisition
hardware at all time/div settings from 5 µs/div to
50 s/div.

Sample – Sample data only.
Average –

Waveform averaged, selectable: 4, 16, 64, 128.

Single Sequence –

Use the Single Sequence button to capture a single
triggered acquisition sequence at a time.

Trigger System (Main Only)

Trigger Modes – Auto, Normal, Single Sequence.

Trigger Types

Edge (rising or falling) –

Conventional level-driven trigger. Positive or negative
slope on any channel. Coupling selections: AC, DC,
Noise Reject, HF Reject, LF Reject.

Video –

Trigger on all lines or individual line, odd/even or all
fields from composite video or broadcast standards
(NTSC, PAL, SECAM).

Pulse Width (or Glitch) –

Trigger on a pulse width less than, greater than,
equal to, or not equal to a selectable time limit
ranging from 33 ns to 10 s.

Trigger Source

2-channel models –

CH1, CH2, Ext, Ext/5, AC Line.

4-channel models –

CH1, CH2, CH3, CH4, Ext, Ext/5, AC Line.

Trigger View

Displays trigger signal while trigger view button
is depressed.

Trigger Signal
Frequency Readout

Provides a frequency readout of the trigger source.

Cursors

Types – Voltage, Time.
Measurements –

[∆]T, 1/[∆]T (frequency), [∆]V.

Measurement System

Automatic Waveform Measurements –

Period, Frequency, +Width, –Width, Rise Time, Fall
Time, Max, Min, Peak-to-Peak, Mean, Cycle RMS.

Waveform Processing

Operators – Add, Subtract, FFT.
FFT –

Windows: Hanning, Flat Top, Rectangular;
2048 sample points.

Sources –

2-channel models: CH1 – CH2, CH2 – CH1,
CH1 + CH2.
4-channel models: CH1 – CH2, CH2 – CH1, CH3
– CH4, CH4 – CH3, CH1 + CH2, CH3 + CH4.

Autoset Menu –

Single-button, automatic setup of all channels
for vertical, horizontal and trigger systems with
undo autoset.

Autoset Menu for Multiple
Signal Types

Signal Type Autoset Menu Choices

Square Wave Single-cycle, Multi-cycle,

Rising or Falling Edge

Sine Wave Single-cycle, Multi-cycle,

FFT Spectrum

Video (NTSC, Field: All, Odd or Even
PAL, SECAM) Line: All or Selectable Line Number

Display Characteristics

Display –

Monochrome models: 1/4 VGA, backlit passive LCD
with adjustable multi-level contrast and inverse video
selectable from front panel.
Color models: 1/4 VGA, passive color LCD with color on
black background with adjustable multi-level contrast.

Interpolation – Sin(x)/x.
Display Types – Dots, vectors.
Persistence – Off, 1 sec, 2 sec, 5 sec, infinite.
Format – YT and XY.

4

TDS1000/2000 Series Oscilloscope • www.tektronix.com/tds1000_2000

Digital Storage Oscilloscopes

TDS1000 Series • TDS2000 Series

I/O Interface

I/O interface TDS2CMAX Communications Module TDS2MEM Storage Memory and

Communication Module

Compatibility TDS200, TDS1000, TDS2000 Series Oscilloscopes TDS1002, TDS1012, TDS2002, TDS2012,

TDS2014, TDS2022, TDS2024 Oscilloscopes

Printer Port Centronics-type parallel

Printer Capability (Requires Module) Graphics File Formats – TIFF, PCX (PC Paint Brush), BMP (Microsoft Windows),

EPS (Encapsulated Postscript) and RLE

Printer Formats – Bubble Jet, DPU-411, DPU-412, DPU-3445, Thinkjet,

Deskjet, Laser Jet, Epson Dot (9- or 24-Pin)
Epson C60*2, Epson C80

Layout – Landscape and portrait

RS-232 Programmability Full talk/listen modes. Control of all modes, settings and measurements.

Baud rate up to 19,200. 9-Pin DTE

RS-232 Cable (012-1651-00) included

GPIB (IEEE std. 488-1987) Programmability Full talk/listen modes. Control of all Not available

modes, settings and measurements

Mass Storage CompactFlash Memory Not available • Type 1 CompactFlash memory

card supplied with Module

• Accepts any Type 1 CompactFlash
card, up to and including 1 GB

• Built-in Clock/Calendar

• Includes CompactFlash to USB Memory Card
Reader for use with personal computer

OpenChoice®PC Communications Software • TDSPCS1 OpenChoice PC Communications Software included with each module

• Seamless connection from oscilloscope to PC through GPIB and RS-232

• Transfer and save settings, waveforms, measurements and screen images

• Includes a Windows desktop data transfer application in addition
to convenient Microsoft Word and Excel toolbar add-ins

*1

Not compatible with TDS1001 or TDS2004.

*2

Requires instrument firmware version 2.12/4.12 or higher to support Epson C60/C80 printer formats.

*3

Supplied Type 1 CompactFlash memory card storage capacity 8 MB or greater.

*2

,

*3

.

*1

TDS1000/2000 Series Oscilloscope • www.tektronix.com/tds1000_2000

5

Digital Storage Oscilloscopes

TDS1000 Series • TDS2000 Series

Nonvolatile Storage

Nonvolatile Storage Standard Optional TDS2MEM Storage

Memory and Communication

Module

*1

Reference Waveform Display Two 2500 point reference waveforms Same as instrument

Waveform Storage 2 Channel Models 4 Channel Models 96 or more reference

Two 2500 point reference waveforms Four 2500 point reference waveforms waveforms per 8 MB

Setups 10 front panel setups 4000 or more front panel

setups per 8 MB

Screen Images N/A 128 or more screen images per 8 MB

(the number of images depends

on file format selected)

Save All N/A 12 or more Save All operations per

8 MB. A single Save All operation

creates 2 to 9 files (setup, image,

plus one file for each displayed

waveform)

*1

Supplied with Type 1 CompactFlash memory card, storage capacity 8 MB or greater.

Environmental and Safety

Temperature –

Operating: 0 ºC to +50 ºC.
Nonoperating: –40 ºC to +71 ºC.

Humidity –

Operating and Nonoperating: Up to 90% RH
at or below +30 ºC.
Operating: Up to 60% RH up to 50 ºC.
Nonoperating: Up to 60% RH up to 55 ºC.

Altitude –

Operating and Nonoperating: Up to 3,000 m.

Electromagnetic Compatibility –

Meets Directive 89/336/EEC, amended by
93/68/EEC, meets or exceeds EN55011 Class A
Radiated and Conducted Emissions; FCC 47 CFR,
Part 15, Subpart B, Class A; Australian EMC
Framework, demonstrated per Emission Standard
AS/NZS 2064; Russian GOST EMC regulations.

Safety –

UL61010-1, CSA61010-1, IEC61010-1, EN61010-1.

Physical Characteristics

INSTRUMENT
Dimensions mm in.

Width 323.8 12.75
Height 151.4 5.96
Depth 124.5 4.90

Weight kg lbs.

Instrument only 2.0 4.4
With accessories 2.2 4.9

INSTRUMENT SHIPPING
Package Dimensions mm in.

Width 476.2 18.75
Height 266.7 10.50
Depth 228.6 9.00

RM2000 RACKMOUNT
Dimensions mm in.

Width 482.6 19.00
Height 177.8 7.00
Depth 108.0 4.25

Ordering Information

TDS1001, TDS1002, TDS1012,
TDS2002, TDS2004, TDS2012,
TDS2014, TDS2022, TDS2024

Standard Accessories

Probes – P2220 200 MHz 10X to 1X Switchable
Passive Probes (one per channel).

Documentation – User manual.

NNIIMM//NNIISSTT TTrraacceeaabbllee CCeerrttiiffiiccaattee ooff CCaalliibbrraattiioonn..

PPoowweerr ccoorrdd..

Please specify the power plug and language
options when ordering.

Recommended Accessories

TDS2CMAX – Communication Module (GPIB,
RS-232, Centronics-type Printer Port) includes:
TDSPCS1 OpenChoice
Software, RS-232 cable (012-1651-00),

®

PC Communication

Programmers manual.

TDS2MEM*2– Storage Memory and Communication
Module (RS-232, Centronics-type Printer Port)
includes: Type 1 CompactFlash memory card
(156-9413-00), CompactFlash to USB Memory
Card Reader (119-6827-00), TDSPCS1 OpenChoice
PC Communication Software, RS-232 cable
(012-1651-00), Programmers manual.

*2

Not compatible with TDS1001 or TDS2004.

6

TDS1000/2000 Series Oscilloscope • www.tektronix.com/tds1000_2000

Digital Storage Oscilloscopes

TDS1000 Series • TDS2000 Series

CompactFlash to USB Memory Card Reader –

(119-6827-00).

®

TDSPCS1 OpenChoice

PC Communication

Software – A collection of programs that enable

fast and easy transfer communication between
MS Windows PCs and TDS3000B,TDS2000,
TDS1000 and TDS200 Series oscilloscopes;
included with TDS2CMAX and TDS2MEM
communication modules.

Minimum System Requirements:

500 MHz Pentium equivalent or greater

128 MB RAM

Microsoft Windows 98SE, XP Professional,
ME or 2000

Microsoft Office 2000 or XP (for TDS toolbars
only) – Excel 2000 or 2002; Word 2000
or 2002

Keyboard and mouse

LAN, GPIB or serial connector

™

WaveStar

Software for Oscilloscopes (WSTRO) –

Windows 98/2000/ME/NT 4.0 application for
waveform capture, analysis, documentation and
control from your PC. Provides enhanced oscillo­scope data measurement, analysis, remote-setup
and charting features. Connects to a wide variety
of Tektronix oscilloscopes over GPIB, RS-232 and
Ethernet connections.

AD007 – LAN/WAN GPIB converter.

AC2100 – Soft case for carrying instrument.

HCTEK321 – Hard plastic case for carrying

instrument (requires AC2100).

RM2000 – Rackmount kit.

Service Manual (TDS1000 and TDS2000
Series Digital Storage Oscilloscopes) –

English only (071-1076-xx).

Programmer Manual (TDS200, TDS1000 and
TDS2000 Series Digital Storage Oscilloscopes) –

English only (071-1075-xx).

Operator Training Kit – Extensive instructions and
step-by-step lab exercises provide education about
the operation of the TDS1000 and TDS2000 Series
oscilloscopes. Kit includes a self-paced CD-ROM­based manual and signal source board (TNGTDS01).
Optional hard copy manual is available for
order separately.

Recommended Probes

P2220 – 200 MHz, 10X to 1X switchable passive
probe (200 MHz when 10X is selected).

P6015A – 1000X high-voltage passive probe
(75 MHz).

P5100 – 100X high-voltage passive probe
(250 MHz).

P5200 – High-voltage active differential probe
(25 MHz).

P6021 – 60 MHz AC current probe.

P6022 – 120 MHz AC current probe.

A621 – 2000 A AC current probe/BNC.

A622 – 100 A AC/DC current probe/BNC.

AM503S – AC/DC current probe system.

Power Plug Options

Opt. A0 – North America power.

Opt. A1 – Universal EURO power.

Opt. A2 – United Kingdom power.

Opt. A3 – Australia power.

Opt. A5 – Switzerland power.

Opt. A99 – No power cord or AC adapter.

Opt. AC – China power.

Accessory Cables

GPIB, 1 m (3.3 ft.) – Order 012-0991-01.

GPIB, 2 m (6.6 ft.) – Order 012-0991-00.

RS-232, 9-Pin female to 25-Pin male,

4.6 m (15 ft.), for Modems – Order 012-1241-00.

RS-232, 9-Pin female to 9-Pin female, null
modem, for computers – Order 012-1651-00.

RS-232, 9-Pin female to 25-Pin female, null
modem, for computers – Order 012-1380-00.

RS-232, 9-Pin female to 25-Pin male, null
modem, for printers – Order 012-1298-00.

Centronics, 25-Pin male to 36-Pin Centronics,

2.4 m (8 ft.), for Parallel Printer Interfaces –

Order 012-1214-00.

International User Manual
(TDS1000 and TDS2000
Series Digital Storage
Oscilloscopes, includes
TDS2CMAX*1user information)

Opt. L0 – English (071-1064-xx).

Opt. L1 – French (071-1065-xx).

Opt. L2 – Italian (071-1066-xx).

Opt. L3 – German (071-1067-xx).

Opt. L4 – Spanish (071-1068-xx).

Opt. L5 – Japanese (071-1069-xx).

Opt. L6 – Portuguese (071-1070-xx).

Opt. L7 – Simplified Chinese (071-1071-xx).

Opt. L8 – Traditional Chinese (071-1072-xx).

Opt. L9 – Korean (071-1073-xx).

Opt. LR – Russian (071-1074-xx).

Translated front panel overlays included with their
respective user manuals.

Warranty Information

Three-year warranty covering all labor and parts,
excluding probes and accessories.

*1

The user information for the TDS2CMA communication
module that appears in this manual also applies to the
TDS2CMAX communication module.

TDS1000/2000 Series Oscilloscope • www.tektronix.com/tds1000_2000

7

Digital Storage Oscilloscopes

TDS1000 Series • TDS2000 Series

Tektronix Support Completes the Solution.

We know you depend on Tektronix instrument
solutions when you make and meet critical
commitments. So we make and meet a support
commitment you can depend on. Anytime you
need support, anywhere in the world, Tektronix
Support gives you the lowest possible exposure to
inconvenience, delay or disruption of operations.

Unsurpassed technical expertise and
experience with 24-hour response to
technical questions

Interactive, online support to request
assistance, check service status or
arrange for training

Industry-leading turn-around service time

Credible, reliable support with demonstrated
on-time delivery

90-day unconditional service warranty

No fine print, no exclusions, no surprises

Global support in more than 50 countries

Depend on Tektronix.
Visit www.tektronix.com/support

ASEAN / Australasia / Pakistan (65) 6356 3900

Contact Tektronix:

Austria [phone]

Balkan, Israel, South Africa and other ISE Countries [phone]

Belgium 07 81 60166

Brazil & South America 55 (11) 3741-8360

Canada 1 [phone]

Central East Europe, Ukraine and the Baltics [phone]

Central Europe & Greece [phone]

Denmark [phone]

Finland [phone]

France & North Africa [phone]

Germany [phone]

Hong Kong (852) 2585-6688

India (91) 80-22275577

Italy [phone]

Japan 81 (3) 6714-3010

Luxembourg [phone]

Mexico, Central America & Caribbean 52 (55) 56666-333

Middle East, Asia and North Africa [phone]

The Netherlands 090 02 021797

Norway 800 16098

People’s Republic of China 86 (10) 6235 1230

Poland [phone]

Portugal 80 08 12370

Republic of Korea 82 (2) 528-5299

Russia & CIS 7 095 775 1064

South Africa [phone]

Spain ([phone]

Sweden 020 08 80371

Switzerland [phone]

Taiwan 886 (2) 2722-9622

United Kingdom & Eire [phone]

USA 1 [phone]

For other areas contact Tektronix, Inc. at: 1 [phone]

Updated 15 June 2005

Our most up-to-date product information is available at:

www.tektronix.com

Product(s) are manufactured

in ISO registered facilities.

Copyright © 2005, Tektronix, Inc. All rights reserved. Tektronix products are
covered by U.S. and foreign patents, issued and pending. Information in this publi­cation supersedes that in all previously published material. Specification and price
change privileges reserved. TEKTRONIX and TEK are registered trademarks of
Tektronix, Inc. All other trade names referenced are the service marks, trade­marks or registered trademarks of their respective companies.

8/05 HB/WOW 3GW-15314-6
