Important Safety Instructions
1. Read these instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use the speaker near water.
6. Clean only with dry cloth.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
SPEAKER TO RAIN OR MOISTURE.
To reduce the risk of electrical shock, fire, etc.:
1. Do not place unit near any heat source such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
2. Do not block any ventilation openings of unit.
3. The unit shall not be exposed to dripping or splashing and no objects filled with liquids, such
as vases, shall be placed on the unit.
4. Do not place any heavy loads onto the unit, and do not step on it, the load may fall and cause
serious injury to the unit.
5. Please read Rating Labels at the rear of unit for power input and other safety information.
6. This unit is intended to be used only with the power supply provided.
7. Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at any point where they exit from the unit.
8. Never unplug your unit by pulling on the power cord. Always grasp the plug firmly and pull
straight out from the outlet.
9. Repair or replace all electric service cords that have become frayed or otherwise damaged
immediately. Do not use a cord that shows cracks or abrasion damage along its length, the
plug, or the connector end.
10. To prevent fire or shock hazard, do not use this plug with an extension cord or other outlet
unless the blades can be fully inserted to prevent blade exposure.
11. During lightning or raining days, unplug the unit for additional protection during
thunderstorms or when the unit is not used for prolonged periods. This will prevent damage
to the unit from lightning and power surges.
12. The battery shall not be exposed to excessive heat such as sunshine, fire or the like.
13. Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
14. The built-in battery must be replaced by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
15. Do not attempt to carry out any service work yourself. By opening or removing the cabinet,
you may be exposed to dangerous voltage or other hazards. Any service work should be
carried out by qualified technicians.
16. The normal function of the product may be disturbed by strong Electro-Magnetic Interference.
If so, simply reset the product to resume normal operation by following the instruction manual.
In case the function could not resume, please use the product in other location.
17. The means of disconnecting this apparatus from the mains supply is plug of adaptor. The
disconnect device shall remain readily operable.
18. In the interests of safety and to avoid unnecessary energy consumption, never leave the unit
switched on while unattended for long periods of time, e.g. overnight, while on holiday or
while out of the house. Switch it off and disconnect the mains plug from the mains socket.
Contents
Important Safety Instructions .......................................................................................................... 2!
Contents .......................................................................................................................................... 4!
Your radio ....................................................................................................................................... 5!
Getting Started ................................................................................................................................ 6!
DAB Mode ....................................................................................................................................... 8!
Scanning Stations .................................................................................................................... 8!
Manual Tune ............................................................................................................................ 8!
DRC (Dynamic Range Control) value ...................................................................................... 9!
Selecting another Station ......................................................................................................... 9!
Secondary Service ................................................................................................................... 9!
Prune Invalid ............................................................................................................................ 9!
Viewing Station Information ................................................................................................... 10!
Storing Preset Stations .......................................................................................................... 10!
Recalling a Preset Station ..................................................................................................... 10!
FM Mode ....................................................................................................................................... 11!
Selecting FM Mode ................................................................................................................ 11!
Scan settings ......................................................................................................................... 11!
Audio Settings ........................................................................................................................ 11!
Viewing Station Information ................................................................................................... 12!
Storing Preset Stations .......................................................................................................... 12!
Recalling a Preset Station ..................................................................................................... 12!
Bluetooth Mode ............................................................................................................................. 13!
NFC (Near Field Communication) ................................................................................................. 13!
Aux in Mode .................................................................................................................................. 14!
General Operation ........................................................................................................................ 15!
Setting Sleep ......................................................................................................................... 15!
Setting Alarm ......................................................................................................................... 15!
Setting Equaliser .................................................................................................................... 16!
Setting Time ........................................................................................................................... 16!
Setting Backlight .................................................................................................................... 16!
Setting Language ................................................................................................................... 17!
Factory Reset ........................................................................................................................ 17!
Software Upgrade .................................................................................................................. 17!
Viewing SW Version .............................................................................................................. 17!
Troubleshooting ............................................................................................................................ 18!
Specifications ................................................................................................................................ 19!
Your radio
1. VOLUME/ knob
l Press to switch unit on or standby.
l Turn to adjust volume level.
2. INFO/MENU button
l Press to view station information when a
program is playing.
l Press and hold to display or exit menu screen.
3. MODE button
Press to switch among DAB, FM, Bluetooth and
Aux in mode.
4. PAIR button
l Press to select a paired Bluetooth device from
device list.
l Press and hold to disconnect Bluetooth
connection.
5. Display
6. button
Press and hold to fast reverse current playing track
in Bluetooth mode.
7. /PRESET button
l Press to pause or play current playing track in
Bluetooth mode.
l Press and hold to save preset station.
l Press to recall preset station.
8. button
l Press to skip to next track in Bluetooth mode.
l Press and hold to fast forward current playing
track in Bluetooth mode.
9. SCROLL&SELECT/SNOOZE knob
l Turn to browse options.
l Press to confirm selection.
l Press to activate snooze function when alarm
sounds.
10. Handle
11. NFC sensor
12. UPDATE PORT – For service professional only.
13. Headphones socket
14. AUX IN socket
15. DC IN socket
16. POWER switch
17. DAB/FM antenna
Getting Started
Carefully remove your radio from the box. You may wish to store the packaging for future use.
What you can find inside of your package
n Main unit
n Power adaptor
n Instruction manual
Positioning your Radio
Place your radio on a flat / stable surface that is not subject to vibrations.
Avoid the following locations:
n Where the unit will be exposed to direct sunlight.
n Where the unit will be close to heat radiating sources.
n Where the humidity is high and ventilation is poor.
n Where it is dusty.
n Where it is damp or there is a possibility of water dripping or splashing onto unit.
Adjusting the Antenna
Extend the antenna to ensure you receive the best reception possible in both DAB and FM radio
modes. It may be necessary to adjust the position of the radio and /or antenna to achieve the best
signal.
Turning the Unit On/Off
Connect the plug at the end of power adaptor cable to the DC IN socket at the rear of the unit.
Then insert the power adaptor into the mains socket.
Slide POWER switch to POWER ON side, unit will on and then start battery charging. Keep mains
power connecting and charge the built-in battery for 12 hours before first time use.
Press the VOLUME/ knob to switch unit standby.
To turn off unit completely, slide POWER switch to POWER OFF side and disconnect the power
adaptor from the mains socket, especially you attempt to not use radio for long periods of time.
Caution: the built-in battery must be replaced by the manufacturer, its service agent, or
similarly qualified persons in order to avoid a hazard.
Volume Control
Adjust the radio volume by turning VOLUME/ knob. Turn anti-clockwise to decrease volume
and turn clockwise to increase volume.
