2
Breathtaking to Behold – Even Better to Hear.
The concept is simple. Combine the pick of the finest hi-fi separates money
can buy with the convenience of contemporary full-system integration.
Machined from solid aluminum, with stylish brushed fascias, these audio
components can claim to be special on appearance alone. However, look
deeper and you will find the most advanced electronics and technology
available – enough to satisfy the most discerning and demanding audiophile.
It is no surprise, then, that for several decades now, the toughest audio critics
throughout the world have consistently praised TEAC Reference Series systems.
For these are the world’s ultimate mini systems.
4
Reference 600 series
No Limit to Versatility
With a linked iPod docking station, the AG-H 600NT is more than
flexible enough to handle today’s latest portable music players
to playback your playlists on this hi-fi system. More over, w ith
the innovative AG-H600NT, Internet-Radio offers countless music
stations from all over the world – while a new AM/FM tuner delivers
crystal-clear sound.
No matter where you are, over
12,000 Internet-Radio stations
are available – from cool jazz
stat ions in New York City to
meditative beats from Bali.
Imposing Power Supply
Large Toroidal-core power transfor mers o n both the AG-H600NT
and PD-H600 deliv er ample current power to t he heart of th e
amplifier, and to the digital and analog sections of the CD player.
The AG-H600NT carries ELNA electrolytic capacitors and resistors
exc lusi vely desig ned for high
fi de li ty pr od uc ts , w h il e a
Sch ottk y barrie r di ode i n th e
rectifier circuit offers great
adv ant age s in re spo ndi ng to
sudd en musical surge s. There
is an oxygen-free copper coil for the audio filter in the power
amplifier section and, in addition, a Direct FET Power MOSFET is
used to fully maximize the highly efficient Class-D amplifier.
On the PD-H600, thick film resistors used in the signal input
section also contribute to the player’s natural, free-flowing sound.
Furthe rmore, a m aster clock generator, operatin g with a fin ite
low-noise current, is located independently on the circuit closely
adjacent to the D/A converter to avoid jitter noise.
Achieving Seamless Connectivity
OPTIONAL DOCKING STATION FOR iPod: DS-20
This small docking station for iPod keeps your iPod charged while
playing music through the Reference 600 system. S-Video and rear
composite video outp uts allow you to display either a movie or a
slide show on your TV.
Achieving the Ultimate Performance
STEREO RECEIVER WITH iPo d INTERFACE A ND INTER NET-RA DIO: AG-H600NT
When you first listen to TEAC’s h igh end Stereo Receiver, the AG-H600NT, do not be surprised if you experience similar
emotions as the performing musicians. This is not achieved by magic, but through the accumulation of TEAC’s superior
technology skills and experience over almost 60 years.
It is a fact that a clean and stable power supply is critical when striving to achieve the ultimate audio performance.
Any sud den and rapid increase of the signal lev el require d in a musical passage, for exa mple, as in the introduction to the
second m ovement of Beethoven’s Ninth Symphony, requires a measured and controlled power input. That’s why, f rom the
very beginning of its development, TEAC’s engineers carefully designed the power supply section of the AG-H600NT to deliver
pure and unwavering power to every single part of the unit.
4
iPod Docking Station sold separately.
5
AG-H600NT Stereo Receiver with iPod Interface
Output Power: Minimum 75W + 75W (8 ohms, 1kHz, JEITA)
Minimum 90W + 90W (4 ohms, 1kHz, JEITA)
Input Selector: 5 (Phono, Tuner, CD, AUX, iPod)
Tuner: Internet-Radio, AM, FM
Preset Memory: 30 AM, 30 FM
Display: Dimmable Dot-matrix Fluorescent
Tone Control: Bass, Mid, Treble, CD Direct
Dimension, Weight: 11-
7
/16”(W) x 4”(H) x 13-5/16”(D), 15.0 lbs.
TEAC Reference Series 2010
Reference 600 series
Power with Subtlety
A closer look at the electronics reveals that Burr-Brown’s 24-bit/
192kHz Delta-sigma D/A Converters maximize the potential of your
latest compact-disc recordings. In addition, as you would expect
from TEAC, every component – including the ELNA electrolytic
capa cito rs and r esis tors – are carefu lly chosen by experie nced
engineers for true audiophiles.
A shun t regul ator mainta ins the
same level of output current by
adjusting the value of the resistors,
whic h are conn ected in para llel
within the in-flow current section.
Fully Armed
The CD tray is constructed using one of the strongest synthetic
materials available, contributing to the anti-vibration qualities
when the disc is rapidly rotating and ensuring rigidity throughout.
In addition, the CD mechanism is positioned at the precise centre
of the unit, thus optimising the balance-to-weight ratio. Moreover,
construction of the unit has been fully equipped with a robust
chassis with thick aluminium panels for the front, top, and sides.
This concept is also applied to the striking remote controls, which
are finished with aluminium fascia and an engraved logo.
Uncompromising Detail
TEAC has thoughtfully incorporated large speaker cable terminals
for a better connec tion – and included an FL display that can be
turned off to cancel the unwanted effects of high-frequency noise.
Achieving Greater Accuracy
CD PLAYER: PD-H600
Listening to music on TEAC’s PD-H600 CD player, allows you hear subtle details, breathing new life into even the most familiar
recordings. The Compact Disc is still the most popular and widely used digital music source in the world, and its potential is
huge and indispensable. For accurate signal reading from discs, TEAC’s Reference 600 CD Player employs an ultra high precision
CD mechanism incorporated into a rigid body construction, skillfully created, and machined by true craftsmen.
PD-H600 CD Player
Compatible Discs: CD-DA, CD-R/RW, MP3, WMA
D/A Converter: 24bit/192kHz Delta-sigma (PCM1796)
Oversampling: 8-times
Programme Play: 30 Tracks
Repeat Play: 1, ALL
Shuffle Play: Yes
Display: Dimmable Dot-matrix Fluorescent
Dimension, Weight: 11-
7
/16”(W) x 4”(H) x12-1/8”(D), 11.9 lbs.
Optional DS-20 Docking Station for iPod
iPod Dock: 1 (Universal)
Audio Connector: 1 (18-pin)
Video Output: 2 (S-Video, Composite Video)
Dimension, Weight: 4”(W) x 1-
9
/16”(H) x 4”(D), 14.1 oz.
5
6
Reference 500 series
Driving on the Digital Highway
CD RECEIVER WITH INTERNET-RADIO AND USB/iPod DIRECT DIGITAL INTERFACE: CR-H500NT
Since the introduction of the original TEAC Reference 500 series in the mid-1990s, the development of this mini component system has
continued to evolve, expanding the musical experience into the digital era.
Keeping the original concept of a mini hi-fi system with ultra high quality and style, every single part of the all-new Reference 500 series
has been reviewed and refined to achieve the very best sound quality in its class. Digital connection from an iPod via the USB port is an
example, as the music files on your iPod are transmitted digitally and directly into the digital processing section. From there on, a Digitalto-Analog converter on the CR-H500NT draws smooth and flawless audio signals.
The USB port allows you to record and playback music to/from USB memory, as the state-of-the-art Internet-Radio tuner brings countless
numbers of music stations from throughout the world. Enjoy driving on the 21st century digital highway with the TEAC Reference 500!
Solid Build Quality - Pleasure to Behold
As TEA C‘s a udio signal proces sing achieved its nex t generat ion
standard, the enclosure of the unit is designed to help it perform
to its ultimate – whatever the occasion. A robust chassis and thick
aluminium panels on the front and sides help eliminate vibration,
while a centr e-mounted C D m echanism keeps accurat e b alance
when reading hi gh-speed rotation CDs. This is a TEAC tra dition
– to design audio products in a realistic manner that is timeless,
regardless of format, digital or analog.
In addition, the outstanding finish in high quality materials, with an
aesthetic design to match, makes the product a pleasure to behold.
Digital Processing Throughout
A USB interface on the CR-H500NT is not just for recording and
playing back MP3 files to/from USB memory. It also works as
digit al interface between i Pod and t he CR-H500N T. T o secur e
the audio signal transmission,
di gi ta l mu si c fi le s on the
iPod are digi tal ly transf erred
directly into the digi tal sect ion
of the CR- H500N T, and the
Burr- Brown Digit al-to -Anal og
con vert er con ve ys a prec ise
analog audio signal to pass onto the amplifier section.
This process is free from jitter noise that is often present in motor
rotation, such as in CD Players. Once the music is stored onto
a flash memory type iPod* in a lossless** format, this becomes
the ideal process for digital music playback that audiophiles have
demanded since the iPod first appeared.
* Flash memory type iPod: iPod touch and iPod nano, iPod is not included.
** Choose ”AIFF”, ”WAV” or ”Apple Lossless” from the Preference menu of iTunes software.
USB cable is supplied from Apple with iPod.
CR-H500NT CD Receiver with USB/iPod Interface
Output Power: Minimum 40W + 40W (6 ohms, 1kHz, 0.5% THD)
Input Selector: 7 (Phono, CD, Tuner, iPod, USB, AUX1, AUX2)
Tuner: Internet-Radio, AM, FM
Preset Memory: 30 AM, 30 FM
Compatible Discs: CD-DA, CD-R/RW, MP3, WMA
Programme Play: 30 Tracks
Repeat Play: 1, All
Shuffle Play: Yes
Encoding and Decoding: MP3, WMA
Timer Function: Daily (On/Off),
Timer Recording to USB Memory (Once, Daily)
Display: Dimmable Dot-matrix Fluorescent
Dimension, Weight: 11-
7
/16”(W) x 4-7/16”(H) x 13-5/16”(D), 12.4 lbs.
6
7TEAC Reference Series 2010
Internet-Radio
What is Internet-Radio?
Internet-Radio, also known as streaming radio or
web-radio, is an audio bro adcasting service on the
internet. Most of the broadcasters on the internet
are existing broadcasting stations for FM or AM,
and the y are transm itt ing the same pro gram to
the i nterne t simult ane ousl y. H owe ver, the re are
thou sands of interne t-exc lusi ve broadca ster s and
per sonal -ba sed stat ion s a s well . More ove r, the
number of stations has been increasing day by day
and the total number has reached over 12,000.
The most interesting characteristic of Internet-Radio
is that it is ”Borde rless” wh ich no o ther traditional
broadcasting medium is. It is also accessible from
anywhere in the world, whenever you connect to the
internet, via either wire or wireless.
Once you connect to the internet, the InternetRadio tuner displays dozens of the thousands of
station names by genre, or by country. You can then
narrow t he list by s electi ng a sub-g enre and c lick
select to listen to a station that you may want to try.
Digital audio signals from the station travels over
the internet, across city limit, borders, mountains, or
even the Atlantic Ocean.
Internet-Radio turns you into an armchair music
world traveller. Furthermore, Internet-Radio is not
just for music lovers. Almost all interests including,
religion, news, comedy or talk radio stations can all
be heard in your preferred language. Internet-Radio
will forever make a significant difference to your
listening choice and habits.
7
8
Reference 380 series
Impeccable Digital Replay
CD PLAYER WITH USB: PD-H380
An ultra-wide-band, high-through-rate, dual-operation amplifier chipset in the PD-H380
contributes to perfect replay of CD, CD-R/RW or MP3 discs, while a smart front-panel USB
port allows users to play their MP3 files from a suitable portable player.
The PD-H380 also looks the part, with a stylish fascia and glowing blue illuminated display
– a perfect visual statement for contemporary life.
MP3 files
CD, CD-R/RW, MP3 discs
The Complete Stereo Receiver
STEREO RECEIVER WITH USB/iPod DIRECT DIGITAL INTERFACE: AG-H380
This compact, high performance stereo receiver makes listening to music a real pleasure. A USB
interface for iPod connection allows you to deliver the complete digital audio signal directly to
the digital processing section of the AG-H380 – the very heart of any contemporary quality audio
system. A high-performance D/A Converter within the AG-H380, flawlessly converts a pure digital
signal into a sharp and clear analog audio signal.
You can also record several sources – CD, radio programs
on AM/FM, AUX - or vinyl records via the Phono input
– to USB memory devices. In addition, the excellent
AM/FM t uner deliver s both music and spoken word
broadcast stations to your liste ning environment, and
a subwoofer preout allows connection for an optional,
external subwoofer.
Versatile Playback Options
Whatever you have, be it MP3 files on a CD-R/RW
disc, a USB Memory device, or a USB-type Portable
MP3 Player, the USB port on the CD Player directly reads
MP3 files to playback on a true hi-fidelity component system.
USB cable is supplied from Apple with iPod.
AG-H380 Stereo Receiver with USB/iPod Interface
Output Power: Minimum 40W + 40W (6 ohms, 1kHz, 0.5% THD)
Input Selector: 7 (Phono, CD, Tuner, iPod, USB, AUX1, AUX2)
Tuner: AM, FM
Preset Memory: 30 AM, 30 FM
Tone Control: Bass, Treble, CD Direct
MP3/WMA Files: Encoding and Decoding
Timer Function: Daily (On/Off), Sleep Timer,
Timer Recording to USB Memory (Once, Daily)
Display: Dimmable Dot-matrix Fluorescent
Dimension, Weight: 8-
7
/16”(W) x 4-5/16”(H) x 12-5/16”(D), 9.7 lbs.
PD-H380 CD Player with USB
Compatible Discs: CD-DA, CD-R/RW, MP3, WMA
D/A Converter: 1-bit
Oversampling: 8-times
Programme Play: 40 Tracks
Repeat Play: 1, All, A-B
Shuffle Play: Yes
Decoding: MP3, WMA
Display: Dimmable Dot-matrix Fluorescent
Dimension, Weight: 8-
7
/16”(W) x 3-11/16”(H) x 10-13/16”(D), 6.2 lbs.
8
9TEAC Reference Series 2010
Pure Digital Path from the Source
The all ne w CR- H500NT and AG-H380 bring you
a new standard of digital audio application. A USB
port on these units allows you to connect an iPod
via the USB cable which is supplied with your iPod,
directly from digital audio connectors on iPod’s
bottom – (known as 30-pin connector) – to a hi-fi
standard D/A converter on the CR-H500NT or AGH380. This is a pure digital process from the source
to amplifier section, through a USB cable. The pure
digital audio data is proces sed through the hi gh
grade D/A converter on the unit, then delivered to
the amplifier output section.
TEAC’s pure digital path provides much higher
quality digital-to-an alog conversi on as compared
to processing on an iPod, and this process uses
a better D/A converter as an authentic way of
improving the sound.
In addition, digital audi o fil es on flash mem ory –
such as with iPod touch and nano, which employ
silicon memory for music storage, and don’t have
any motor that generate a byproduct jitter noise –
is an ideal source for audiophiles.
When you choose a linear audio format like ”AIFF”,
”WAV” or ”Apple Lossless,” from the preference
menu of iTunes when you rip a CD, t he original
digital data stream on CD will be stored on your
iPod.
In the past, audiophiles would upgrade their phono
cartridge to improve sound, because it wa s at the
very heart of the audio performance from vinyl disc
contac t to the electrical si gnal. Now, choosing a
more a dvanced D/A converter is the modern route
to audio quality perfection.
Digital Connection
9
10
Micro Systems
A Private Concert in Your Own Home
DVD AUDIO VID EO MICRO COMPONENT WITH USB/iPod INTERFACE: DR-H338i
The sound of musical quality from this DVD Mini component can be likened to having your own
private concert at home, whether it is on CD, DVD, Hybrid CD, or DivX disc. Alternatively, you
can hear whatever you choose from the dazzling array of music stations available on AM/FM.
HDMI interface and Dolby Virtual Speaker technology combine to achieve an impressive balance
of digital picture and digital sound, thanks to a massive T oroidal core pow er transform er –
among the best in its class.
The Perfect Fit
CD MICRO COMPONENT WITH USB/SD/iPod INTERFACE: CR-H238i
Now, the latest CD Micro unit from TEAC allows you to playback almost any type of music
media, including CD, CD-R/RW, MP3 disc, SD card or USB Memory with MP3 files, and iPod.
However, versatility is not the only reason to choose TEAC. The excellent AM/ FM stereo tuner
grabs airwave s while the 25W + 25W amplifier delivers spectacular sound quality. Video outputs
in both S-Video and composite video from an optional iPod docking station complete the audiovisu al experie nce. O nce you tune into your favou rite stati on, you
will experience an almost unparalleled clarity and quality of sound,
(enhanced further by the optional system-matched LS-H255 speaker
system.)
iPod Docking Station sold separately. iPod Docking Station sold separately.
CR-H238i CD Micro Component with USB/SD/iPod Interface
Output Power: Minimum 25W + 25W (6 ohms, 1kHz, 0.5% THD)
Input Selector: 7 (CD, Tuner, iPod, USB, SD, AUX1, AUX2)
Tuner: AM, FM
Preset Memory: 30 AM, 30 FM
Compatible Disc: CD-DA, CD-R/RW, MP3, WMA
Programme Play: 32 Tracks
Repeat Play: 1, All, A-B
Shuffle Play: Yes
Decoding: MP3, WMA
Timer Function: Daily (On/Off), Sleep Timer
Display: Dimmable Dot-matrix Fluorescent
Dimension, Weight: 8-
7
/16”(W) x 4-5/16”(H) x 14-1/8”(D), 9.3 lbs.
Optional DS-20 Docking Station for iPod
iPod Dock: 1 (Universal)
Audio Connector: 1 (18-pin)
Video Output: 2 (S-Video, Composite Video)
Dimension, Weight: 4”(W) x 1-
9
/16”(H) x 4”(D), 14.1 oz.
DR-H338i DVD Micro Component with USB/iPod Interface
Output Power: Minimum 50W + 50W (4 ohms, 1kHz)
Input Selector: 6 (DVD/CD, Tuner. iPod, USB, AUX1, AUX2)
Tuner: AM, FM
Preset Memory: 20 AM, 20 FM
Compatible Disc: DVD-Video, DVD+R/+RW, VCD, SVCD,
CD-DA, CD-R/RW, MP3, WMA, JPEG, DivX
Surround: Dolby Digital Virtual Speaker Pro Logic II
Programme Play: 20 Tracks
Repeat Play: 1, All, A-B
Shuffle Play: Yes
Decoding: MP3, WMA, DivX
Timer Function: Daily (On/Off), Sleep Timer
Display: Dimmable Dot-matrix Fluorescent
Dimension, Weight: 8-
7
/16”(W) x 4-5/16”(H) x 14-3/16”(D), 9.1 lbs.
Optional DS-21 Docking Station for iPod
iPod Dock: 1 (Universal)
Audio/Video Connector: 1 (Mini 18-pin)
Dimension, Weight: 3-
3
/4”(W) x 1”(H) x 3-3/4”(D), 7.4 oz.
10
TEAC Reference 2010 Appendix
Appendix
US
PD-H380 CD Player with USB
DR-H338i DVD Receiver
CR-H238i CD Receiver
AG-H380 Stereo Receiver
AG-H600 Internet-Radio AM/FM Stereo Receiver
PD-H600 High Resolution CD Player
CR-H500NT Internet-Radio AM/FM Stereo CD Receiver
DS-20 Docking Station for iPod
DS-21 Docking Station for iPod
11
PD-H380
CD Player with USB
• Total Harmonic Distortion: less than 0.005% (1kHz)
• Frequency Response: 20-20kHz
• Signal-to-Noise Ratio: more than 120dB
• Analog Audio: Out x 1
• Digital Audio: Out x 1 (Optical)
• USB Port: x 1 (MP3/WMA Decoding)
• Dimension: 8-
7
/16”(W) x 3-11/16”(H) x 10-13/16”(D)
215(W) x 93(H) x 275(D) mm
• Weight: 6.2 lbs. 2.8kg
PD-H600
CD Player
• Total Harmonic Distortion: less than 0.003%
• Frequency Response: 20-20kHz
• Signal-to-Noise Ratio: more than 110dB
• High-resolution 24bit/192kHz D/A Converter
• Analog Audio: Out x 1
• Digital Audio: Out x 1 (Coaxial)
• Dimension: 11-
7
/16”(W) x 4”(H) x 12-1/8”(D)
290(W) x 102(H) x 308(D) mm
• Weight: 11.9 lbs. 5.4kg
AG-H600NT
Stereo Receiver with iPod Interface
• Minimum 75W + 75W (8 ohms, 1kHz, JEITA)
• Minimum 90W + 90W (4 ohms, 1kHz, JEITA)
• Total Harmonic Distortion: 0.05% (8 ohms, 1kHz, 40W)
• Frequency Response: 10-65kHz
• Signal-to-Noise Ratio: 70dB (Phono), 100dB (Line),
110dB (CD Direct)
• Internet-Radio/AM/FM Tuner
• Analog Audio: In x 3, Out x 1
• iPod Dock Interface: x 1 (18-pin)
• Ethernet Port: x 1 (10Base-T)
• Wireless LAN (IEEE802.11b/g)
• Binding-post Speaker Terminals
• 1/4” Headphone Jack
• Dimension: 11-
7
/16”(W) x 4”(H) x 13-15/16”(D)
290(W) x 102(H) x 338(D) mm
• Weight: 15.0 lbs. 6.8kg
Optional iPod Dock (DS-20, Sold separately)
CR-H500NT
CD Receiver with USB/iPod Interface
• Minimum 40W + 40W (6 ohms, 1kHz, 0.5%THD)
• Total Harmonic Distortion: 0.03% (6 ohms, 1kHz, 20W)
• Frequency Response: 20-60kHz
• Signal-to-Noise Ratio: 78dB (Phono), 91dB (Line)
• Internet-Radio/AM/FM Tuner
• Analog Audio: In x 3, Out x 1
• Subwoofer Preout: x 1
• USB Port: x 1 (MP3/WMA Encoding/Decoding, iPod
Digital Audio Input)
• Ethernet Port: x 1 (10Base-T)
• Wireless LAN (IEEE802.11b/g)
• Binding-post Speaker Terminals
• 1/8” Headphone Jack
• Dimension: 11-
7
/16”(W) x 4-7/16”(H) x 13-15/16”(D)
290(W) x 113(H) x 338(D) mm
• Weight: 12.4 lbs. 5.6kg
AG-H380
Stereo Receiver with USB/iPod Interface
• Minimum 40W + 40W (6 ohms, 1kHz, 0.5%THD)
• Total Harmonic Distortion: 0.03% (6 ohms, 1kHz, 20W)
• Frequency Response: 20-60kHz
• Signal-to-Noise Ratio: 78dB (Phono), 91dB (Line)
• AM/FM Tuner
• Analog Audio: In x 4, Out x 1
• Subwoofer Preout: x 1
• USB Port: x 1 (MP3/WMA Encoding/Decoding, iPod
Digital Audio Input)
• Binding-post Speaker Terminals
• 1/8” Headphone Jack
• Dimension: 8-
7
/16”(W) x 4-5/16”(H) x 12-5/16”(D)
215(W) x 110(H) x 315(D) mm
• Weight: 9.7 lbs. 4.4kg
RC-1180RC-1225RC-1225RC-1182RC-1181
RC-1240 RC-1240
RC-1226
TEAC Reference Series 2010
Specifications
LS-H265
2-way Speaker System
• 125W (Max Music Power)
• 19mm Dome Tweeter
• 130mm Woofer
• 8 ohms Impedance
• Sensitivity: 88dB
• Frequency Response: 54-40kHz
• Binding-post Speaker Terminals
• Dimension: 7-
1
/16”(W) x 11-1/2”(H) x 10-1/8”(D)
180(W) x 292(H) x 257(D) mm
• Weight: 9.7 lbs. 4.4kg
• Cabinet Finish in Black
LS-H255
2-way Speaker System
• 50W (Max Music Power)
• 25mm Soft Dome Tweeter
• 130mm Woofer
• 6 ohms Impedance
• Sensitivity: 86dB
• Frequency Response: 60-22kHz
• Binding-post Speaker Terminals
• Dimension: 6-
11
/16”(W) x 10-5/8”(H) x 9-1/4”(D)
170(W) x 270(H) x 242(D) mm
• Weight: 8.2 lbs. 3.7kg
• Cabinet Finish in Black Ash
LS-H250
2-way Speaker System
• 50W (Max Music Power)
• 25mm Soft Dome Tweeter
• 130mm Woofer
• 6 ohms Impedance
• Sensitivity: 88dB
• Frequency Response: 50-22kHz
• Binding-post Speaker Terminals
• Dimension: 7-
1
/1”(W) x 11”(H) x 8-1/4”(D)
190(W) x 280(H) x 210(D) mm
• Weight: 9.3 lbs. 4.2kg
• Cabinet Finish in Piano Black
LS-W300
2.1ch Speaker System with Subwoofer
• 50W (Max Music Power)
• Subwoofer Output Power: 100W
• 25mm Soft Dome Tweeter
• 80mm Mid-range
• 200mm Woofer
• 4 ohms Impedance
• Sensitivity: 83dB
• Frequency Response: 120-20kHz (Speaker)
Frequency Response: 45-180Hz (Subwoofer)
• Magnetic Shielded (Speaker)
• Phase Changer 0 or 180
• Subwoofer Level Control
• Binding-post Speaker Terminals
• Analog Audio Input (Subwoofer)
• Dimension: 4-
3
/4”(W) x 8-7/16”(H) x 6-3/16”(D),
120(W) x 215(H) x 157(D) mm (Speaker),
10-
5
/8”(W) x 10-5/8”(H) x 9-13/16”(D),
270(W) x 270(H) x 249(D) mm (Subwoofer)
• Weight: 4.0 lbs. 1.8kg (Speaker),
18.8 lbs. 8.5kg (Subwoofer)
• Cabinet Finish in Mahogany
CR-H238i
CD Receiver with USB/SD/iPod Interface
• Minimum 25W + 25 W (6 ohms, 1kHz, 0.5% THD)
• Total Harmonic Distortion: 0.03% (6 ohms, 1kHz, 19W)
• Frequency Response: 20-30kHz
• Signal-to-Noise Ratio: more than 86dB (CD),
49dB (FM, Mono), 52dB (FM, Stereo)
• AM/FM Tuner
• Analog Audio: In x 2, Out x 1
• Digital Audio: Out x 1 (Optical)
• Subwoofer Preout: x 1
• iPod Dock Interface: x 1 (18-pin)
• USB Port: x 1 (MP3/WMA Decoding)
• SD Slot: x 1 (MP3/WMA Decoding)
• Binding-post Speaker Terminals
• 1/8” Headphone Jack
• Dimension: 8-
7
/16”(W) x 4-5/16”(H) x 14-1/8”(D)
215(W) x 110(H) x 359(D) mm
• Weight: 9.3 lbs. 4.2kg
Optional iPod Dock (DS-20, Sold separately)
DR-H338i
DVD Receiver with USB/iPod Interface
• Minimum 50W + 50W (4 ohms, 1kHz)
• Minimum 36W + 36W (4 ohms, 1kHz, 0.9%THD)
• Total Harmonic Distortion: 0.7% (4 ohms, 1kHz, 5W)
• Frequency Response: 20-20kHz
• Signal-to-Noise Ratio: 90dB
• AM/FM Tuner
• HDMI: Out x 1 (ver.1.2, 1080p)
• Component Video: Out x 1
• Composite Video: Out x 1
• Analog Audio: In x 2, Out x 1
• Digital Audio: Out x 2 (Optical, Coaxial)
• Subwoofer Preout: x 1
• iPod Dock Interface: x 1 (Mini 18-pin)
• USB Port: x 1 (MP3/WMA/DivX Decoding)
• Binding-post Speaker Terminals
• 1/8” Headphone Jack
• Dimension: 8-
7
/16”(W) x 4-5/16”(H) x 14-3/16”(D)
215(W) x 110(H) x 360(D) mm
• Weight: 9.1 lbs. 4.1kg
Optional iPod Dock (DS-21, Sold separately)
* Note: Not all products shown may be available in all countries. For more information contact your local TEAC retailer.
11
TEAC CORPORATION 1-47, Ochiai, Tama-shi, Tokyo 206-8530, Japan
Phone: 042-356-9156 www.teac.co.jp
TEAC AMERICA, INC. 7733 Telegraph Road, Montebello, CA 90640 U.S.A.
Phone: 323-726-0303 www.teac.com/consumer_electronics/reference_series/
TEAC CANADA LIMITED 5939 Wallace Street, Mississauga, Ontario L4Z 1Z8, Canada
Phone: 905-890-8008 www.teac.com/canada
TEAC MEXICO, S.A. de C.V Río Churubusco 364, Colonia Del Carmen, Delegación Coyoacán, CP 04100, México DF, México
Phone: 5255-5010-6000 www.teacmexico.com
TEAC UK LIMITED Suites 19 & 20, Building 6, Hatters Lane, Croxley Green Business Park, Watford, Hertfordshire, WD18 8TE, U.K.
Phone: 0845-130-2511 www.teac.co.uk
TEAC EUROPE GmbH Bahnstrasse 12, 65205 Wiesbaden-Erbenheim, Germany
(Austria, Benelux) Phone: 0611-71580 www.teac.de www.teac.nl
Please note that not all models and colours are available in every country. Design and specifications subject to change without notice. © 2009 TEAC Corporation. All Rights Reserved. All text, images, graphics and other materials on this catalogue are subject to the copyright and other intellectual property rights of
TEAC Corporation. These materials shall not directly or indirectly be published, reproduced, modified or distributed in any medium. is a trademark of DVD Format/Logo Licensing Corporation, registered in the U.S., Japan and other countries. Dolby and the double-D symbol are registered trademarks of Dolby
Laboratories. DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license. HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC. iPod and iTunes are trademarks of Apple Inc., registered in the U.S. and
other countries. ”Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. All other
brand or product names are trademarks or registered trademarks of their respective holders.
Printed in Japan US002A-01
TEAC Reference Series 2010
Loading...
