Taylor SLUSH 382 User Manual

Model 382 (With RC25)

Slush Freezer

Operator’s Manual

053105-M

10/98

Complete this page for quick reference when service is required:

Taylor Distributor:

Address:

Phone:

Service:

Parts:

Date of Installation:

Information found on the 382 data label:

Model Number:

Serial Number:

Electrical Specs: Voltage Cycle

Phase

Maximum Fuse Size: Amps

Minimum Wire Ampacity: Amps

Part Number:

Information found on RC25 data label:

Model Number:

Serial Number:

Electrical Specs: Voltage Cycle

Phase

Maximum Fuse Size: Amps

Minimum Wire Ampacity: Amps

E October, 1998 T aylor

All rights reserved.

053105--M

The word Taylor and the Crown design
are registered trademarks in the United States
of America and certain other countries.

Taylor Company
750 N. Blackhawk Blvd.
Rockton, IL 61072

Table of Contents

Section 1 To the Installer 1............................................

Installation Instructions 1.................................................

Electrical Connections 1.................................................

Section 2 To the Operator 5...........................................

Compressor Warranty Disclaimer 5.......................................

Section 3 Safety 6....................................................

Section 4 Operator Parts Id en t ificatio n 7...............................

Beater Door Assembly 8.................................................

Accessories 9..........................................................

Section 5 Important: To the Operator 10.................................

Symbol Legend 10.......................................................

Control Switch (Item 1) 10.................................................

Fill Switch (Item 2) 11....................................................

Add Mix Light (Item 3) 11.................................................

Mix Out Light (Item 4) 11..................................................

Viscosity Control (Item 5) 11...............................................

Standby Switch (Optional) 11..............................................

Display Light Switch (Item 6) (Optional) 11..................................

Push-Button Switch 11....................................................

Section 6 Operating Procedures 12.....................................

Assembly 12............................................................

Sanitizing 16............................................................

Priming 17..............................................................

Closing Procedure 18....................................................

Draining Product From T he Freezing Cylinder 18............................

Rinsing 18..............................................................

Cleaning 19.............................................................

Disassembly 20..........................................................

Brush Cleaning 20.......................................................

Table of Contents Models 382RC25

Table of Contents -- Page 2

Section 7 Important: Operator Checklist 21..............................

During Cleaning and Sanitizing 21.........................................

Troubleshooting Bacterial Count 21........................................

Regular Maintenance Checks 21...........................................

Winter Storage 21........................................................

Section 8 Troubleshooting Guide 22....................................

Section 9 Parts Replacement Schedule 25...............................

Section 10 Parts List 26.................................................

Wiring Diagrams 32......................................................

Note: Continuing research results in steady improvements; therefore, information
in this manual is subject to change without notice.

Models 382/RC25 Table of Contents

Section 1 To the Installer

This machine is designed for indoor use only.

DO NOT install the machine in an area where

a water jet could be used to clean or rinse the machine.
Failure to follow this instruction may result in serious
electrical shock.

Installation Instructions

Preparation

Uncrate the condensing and dispensing units. After
inspecting both units for damage, position them in the
desired locations.

Electrical Connections

Individual power supplies are required for each unit.
Check the data label on each unit for fuse, circuit
ampacity, and electrical specifications. For proper
power connections, refer to the wiring diagram
provided inside of the electrical box.

Stationary appliances which are not equipped with a
power cord and a plug or other device to disconnect
the appliance from the power source must have an
all--pole disconnecting device with a contact gap of at
least 3 mm installed in the external installation.

CAUTION: THIS EQUIPMENT MUST BE
PROPERLY GROUNDED! FAILURE TO DO SO
CAN RESULT IN SEVERE PERSONAL INJURY
FROM ELECTRICAL SHOCK!

Beater rotation must be counterclockwise as viewed
looking into the freezing cylinder of the Model 382
dispenser.

NOTE: The following procedures should

be performed by a trained service technician.

To correct rotation on a three-phase unit, exchange
any two incoming power supply lines at the freezer
main terminal block only .

In the United States, this equipment is intended to be
installed in accordance with the National Electrical
Code (NEC), ANSI/NFPA 70--1987. The purpose of
the NEC code is the practical safeguarding of persons
and property from hazards arising from the use of
electricity. This code contains provisions considered
necessary for safety. Compliance therewith and
proper maintenance will result in an installation
essentially free from hazard!

In all other areas of the world, equipment should be
installed in accordance with the existing local codes.
Please contact your local authorities.

To correct rotation on a single-phase unit, exchange
the leads inside the beater motor. (Follow the diagram
printedonthemotor.)

Electrical connections are made directly to the splice
box. The splice box is located behind the back panel.

IMPORTANT

Beater rotation on the 380 Series

differs from other Taylor equipment.

050722

Models 382/RC25 To the Installer

1

Refrigeration Charging and Line
Construction

The dispensing unit is shipped with a refrigerant
holding charge that is sufficient enough to prevent
moisture contamination (8 oz./227 g. HP62). This
holding charge will become part of the total system
charge.

The condensing unit is shipped with the total amount
of refrigerant required for a typical installation of 75 ft.
or less with a single dispenser. For other installation
configurations, use the following chart for line sizing
and for adding required refrigerant.

Note: Maximum line length is 150 ft. (45.7 m).
Note: To meet individual installation requirements,

lines must be purchased and constructed locally .

Line Size

Liquid Line - Single or dual dispensers require 3/8”

refrigerant grade copper tubing (hard or soft).

Note: Insulating the liquid line is recommended if it is
exposed to high ambient conditions. This will reduce
heat accumulation and prevent the formation of flash
gas in the liquid line.

Single Dispensing Installations

Recommended System Refrigerant
Charge

Domestic

Suction Line

Length

Less than 75 ft. Single 10 lb.

More than 75 ft. Single 12 lb. (add 2 lb.)

Less than 75 ft. Dual 13 lb. (add 3 lb.)

More than 75 ft. Dual 15 lb. (add 5 lb.)

International

Suction Line

Length

Less than 22.8 m Single 4.5 kg

More than 22.8 m Single 5.4 kg (add 0.91 kg)

Less than 22.8 m Dual 5.9 kg (add 1.4 kg)

More than 22.8 m Dual 6.8 kg (add 2.3 kg)

Dispenser Required Charge

Dispenser Required Charge

Suction Line - Less than 75 ft. (22.8 m) total line

length requires 5/8” refrigerant grade copper tubing
(hard or soft). Maximum 5/8” tubing length is 75 ft.
(22.8 m).

Note: Suction lines must be insulated.

Suction Line - More than 75 ft. (22.8 m) total line

length requires 3/4” refrigerant grade copper tubing
(hard or soft). Maximum tubing length is 150 ft. (45.7
m).

Dual Dispensing Installations
(One Condenser , Two Dispensers)

Individual Suction Line - Requires 5/8” refrigeration

grade copper tubing (hard or soft) from each dispenser
to the common suction tube.

Common Suction Line - Requires 3/4” refrigeration
grade copper tubing.

Note: Lines must be insulated and requires a 5/8” x
3/4” reducer fitting at the quick disconnect
connections. See Figure 1 below.

Note: Use 5/8” wire to attach the quick disconnects to the other components.

Figure 1

To th e Installer

2

Models 382/RC25

DISPENSER UNIT

382

Condenser

Access Valve

DISPENSER UNIT

382

Note: 5/8” individual line lengths are not to exceed 75 ft. (22.8 m) maximum length each.
Total line length is not to exceed 150 ft. (45.7 m). 5/8” line + 5/8” line + 3/4” line = 150 ft. or less.

Installation

Step 1

Install refrigeration lines from the dispenser to the
condensing unit. Do not create oil traps.

Note: For proper oil return, installation of horizontal
suction lines are to be sloped downward in the
direction of the condensing unit. The slope must be a
minimum 1/4” (6.4 mm) angle per 10 ft. (30.48 mm) of
line length.

FROM
DISPENSER

10'-0"

(3.048 m)

FLOW

¼" (.64 cm)

TO CONDENSER

Compressor

Liquid Refrigerant

Reciever

CONDENSING UNIT

Figure 2

Normally, any straight run of tubing must be supported
near each end of the run. Long runs require additional
supports. As a guide, 3/8” to 3/4” copper should be
supported every 5 ft. (1.5 m). When changing
directions, no corner should be left unsupported.
Supports should be placed a maximum of 2 ft. (.61 m)
in each direction from the corner. If soft copper tube is
used, make sure it is not kinked or flattened. If hard
drawn copper tubing is used, use only long radius
elbows.

Step 2

Braze the supplied quick connect/disconnect
couplings on the dispenser end of the refrigeration
lines. Couplings are supplied with the dispenser.

Step 3

Braze the quick connect/disconnect couplings and
access tees on the condensing unit end of the
refrigeration lines. Couplings and access tees are
supplied with the unit.

Note: Wrap a wetcloth around the brass coupling
bodies to prevent heat damage to the seal.

Step 4

Figure 3

Models 382/RC25 To the Installer

Test the field constructed lines for leaks.

3

Step 5

Evacuate the field constructed refrigerant lines using
the access fittings brazed on the condensing end of the
refrigeration lines.

Step 6

When the evacuation process is complete, relieve the
vacuum with 4 oz. (113 g.) of HP62 refrigerant per line,
for a total of 8 oz. (227 g.) This procedure will prevent
moisture contamination during dispenser and
condensing unit connection and complete the total
charge.

Refrigeration Connections

Connect the refrigerant line quick connect/disconnect
couplings to the mating quick connect/disconnect
couplings on the dispensing and condensing unit.

Step 1

Remove the shipping caps from the quick
connect/disconnect coupling on the dispensing unit.

Step 2

Thoroughly clean and lubricate the mating surfaces of
the quick connect/disconnects.

Note: Use polyolester oil to lubricate the surfaces.

Step 3

Manually thread the coupling halves together to insure
proper mating of the threads.

Step 4

Using proper sized wrenches, tighten the coupling
halves until the round, flat surfaces of inner coupling
bodies completely depress one another.

Step 5

Once the flat surfaces are completely depressed,
tighten the couplings an additional 1/4 turn. This step
is necessary to insure that the knife edge of the seal
seats into the brass seat of the coupling halves,
forming a leak-proof joint (metal seal).

Step 6

Check all connections for leaks.

Step 7

Insulate all exposed suction line tubing and fittings.

Step 8

Set the pump down switch located in the condensing
unit. For indoor condensing unit application:

Set cut in at 30 PSIG (207 kPa).
Set cut out at 5 PSIG (34 kPa).

For outdoor condensing unit application:

Set cut in at 20 PSIG (138 kPa).
Set cut out at 0 PSIG (0 kPa).

Pump down pressure readings are to be taken at the
refrigeration line access fittings at the condensing unit.

Step 9

Allow the dispenser to run until the condensing unit
cycles off. Verify the proper pump down pressure
switch setting. See Step 8 of “Refrigeration
Connections” (page 4).

Note: Pump down pressure readings are to be taken
at the refrigeration line access fittings near the
condensing unit.

Step 10

If necessary, adjust viscosity to produce satisfactory
product. Adjustments are made by turning the
viscosity adjustment screw (located under the control
panel) clockwise for a thicker product or
counterclockwise for a thinner product.

Set Up Procedures

Standard Fill Module

Step 1

Connect the product supply line to the 1/4” barbed
fitting on the fill solenoid. Adjust the fill system
pressure to deliver product to the hopper at
approximately 15 to 20 PSIG (103-138 kPa).

To th e Installer

Figure 4

Step 2

Lubricate, assemble, sanitize and prime the dispenser
as outlined in the Assembly section of this manual.

Step 3

Place the power switch in the “AUTO” position.

Note: The fill switch must be in the “ON” position to
enable refrigeration.

4

Models 382/RC25

Section 2 To the Operator

The freezer you have purchased has been carefully
engineered and manufactured to give you dependable
operation. The Taylor equipment, when properly
operated and cared for, will produce a consistent
quality product. Like all mechanical products, this
machine will require cleaning and maintenance. A
minimum amount of care and attention is necessary if
the operating procedures outlined in this manual are
followed closely.

This Operator’s Manual should be read before
operating or performing any maintenance on your
equipment.

Your Model 382 will NOT eventually compensate and
correct for any errors during the set-up or filling
operations. Thus, the initial assembly and priming
procedures are of extreme importance. It is strongly
recommended that all personnel responsible for the
equipment’s operation thoroughly read this manual.

If you require technical assistance, please contact
your local authorized Taylor Distributor.

If the crossed out wheeled bin symbol is
affixed to this product, it signifies that this product is
compliant with the EU Directive as well as other
similar legislation in effect after August 13, 2005.
Therefore, it must be collected separately after its
use is completed, and cannot be disposed as
unsorted municipal waste.

The user is responsible for returning the product to
the appropriate collection facility, as specified by
your local code.

For additional information regarding applicable local
laws, please contact the municipal facility and/or
local distributor.

Compressor Warranty Disclaimer

The refrigeration compressor(s) on this machine are
warranted for the term indicated on the warranty card
accompanying this machine. However, due to the
Montreal Protocol and the U.S. Clean Air Act
Amendments of 1990, many new refrigerants are
being tested and developed, thus seeking their way
into the service industry. Some of these new
refrigerants are being advertised as drop-in
replacements for numerous applications. It should be
noted that, in the event of ordinary service to this
machine’s refrigeration system, only the refrigerant
specified on the affixed data label should be used.
The unauthorized use of alternate refrigerants will void
your compressor warranty. It will be the owner’s
responsibility to make this fact known to any technician
he employs.

It should also be noted that Taylor does not warrant the
refrigerant used in its equipment. For example, if the
refrigerant is lost during the course of ordinary service
to this machine, Taylor has no obligation to either
supply or provide its replacement either at billable or
unbillable terms. Taylor does have the obligation to
recommend a suitable replacement if the original
refrigerant is banned, obsoleted, or no longer available
during the five year warranty of the compressor.

The Taylor Company will continue to monitor the
industry and test new alternates as they are being
developed. Should a new alternate prove, through our
testing, that it would be accepted as a drop-in
replacement, then the above disclaimer would
become null and void. To find out the current status of
an alternate refrigerant as it relates to your
compressor warranty, call the local Taylor Distributor
or the T aylor Factory. Be prepared to provide the
Model/Serial Number of the unit in question.

050906

Models 382/RC25 To th e Operator

5

Section 3 Safety

We at Taylor Company are concerned about the safety
of the operator when he or she comes in contact with
the freezer and its parts. Taylor has gone to extreme
efforts to design and manufacture built-in safety
features to protect both you and the service technician.
As an example, warning labels have been attached to
the freezer to further point out safety precautions to the
operator.

IMPORTANT -- Failure to adhere to the following
safety precautions may result in severe personal
injury. Failure to comply with these warnings may
damage the machine and its components.
Component damage will result in part
replacement expense and service repair expense.

To Operate Safely:

S DO NOT allow untrained personnel to

operate this machine.

S DO NOT operate the freezer unless all

service panels and access doors are
restrained with screws.

S DO NOT remove the door, beater, scraper

blades, drive shaft, or torque rotor shaft
unless the power switch is in the OFF
position.

S DO NOT put objects or fingers in the door

spout.
Failure to follow these instructions may result in
contaminated product or severe personal injury to
fingers or hands from hazardous moving parts.

DO NOT operate the freezer without reading
this operator’s manual. Failure to follow this instruction
may result in equipment damage, poor freezer
performance, health hazards, or personal injury.

S DO NOT operate the freezer unless it is

properly grounded.

S DO NOT attempt any repairs unless the

main power supply to the freezer has been

disconnected.

S DO NOT operate the freezer with larger

fuses than specified on the freezer data

label.
Failure to follow these instructions may result in
electrocution or damage to the machine. Contact your
local authorized Taylor Distributor for service.

DO NOT use a water jet to clean or rinse the
freezer. Failure to follow this instruction may result in
serious electrical shock.

USE EXTREME CAUTION when removing
the beater assembly. The scraper blades are very
sharp and may cause injury.

This freezer must be placed on a level
surface. Failure to comply may result in personal injury
or equipment damage.

DO NOT obstruct air intake and discharge openings:
6” (152 mm) minimum air space on sides and rear ,
7-1/2” (191 mm) minimum on bottom. Failure to follow
this instruction may cause poor freezer performance
and damage to the machine.

This freezer is designed to operate indoors, under
normal ambient temperatures of 70_-- 7 5 _F
(21_-- 2 4 _C). The freezer has successfully performed
in high ambient temperatures of 104_F(40_C) at
reduced capacities.

NOISE LEVEL: Airborne noise emission does not
exceed 78 dB(A) when measured at a distance of 1.0
meter from the surface of the machine and at a height
of 1.6 meters from the floor.

050722

Safety

6

Models 382/RC25

Section 4 Operator Parts Identification

Item Description Part No.

1 REMOTE CONDENSING UNIT RC 25

2 PANEL--SIDE LEFT 052117

3 COVER--HOPPER--12 QT 045416

4 PANEL A.--REAR X52115

5 PANEL--SIDE RIGHT 051713

6 GASKET--BASE PAN 051868

7 TRAY A.--DRIP X46848

Models 382/RC25 Operator Parts Identification

Item Description Part No.

8 SHIELD--SPLASH 046851

DECAL--DEC--380--FLAVOR SET OF 4 050703

9

DECAL--DEC--TAYLOR 045967

10 PANEL--FRONT 051090

11 STUD--FREEZER DOOR 051950

12 SHELF--DRIP TRAY 052065

7

Beater Door Assembly

Item Description Part No.

1 KNOB--DRAW VALVE--BLACK 047358

2 SCREW--1/4--20X9/16 THUMB--300 047632

3 PLATE--DRAW SPOUT MOUNT 049275

4 SPOUT--DOOR ZERO WASTE 049276--BLA

5 O--RING--2.375 OD X 1/16W 046830

6 SPRING--COMP.845X.055X3.5 047357

7 VA LV E -- D R AW 047353

8 STUD--NUT (HANDSCREW) 045644

9 O--RING--7/8 OD X .103W 014402

10 DOOR A.--PARTIAL X51098

11 O--RING--8--3/8 ODX.105W 027814

12 BEARING--FRONT--TORQUE 052005

Operator Parts Identification

Item Description Part No.

13 ARM --TORQUE 014500

14 O --RING-- .291 ID X .080W 018550

15 TORQUE A. X51081

16 BEARING--GUIDE 014496

17 BEATER A.--TORQUE X51105

18 BLADE--SCRAPER 051088

19 CLIP--SCRAPER BLADE 051978

20 SHAFT--BEATER 049270

21 O --RING-- 7/8 OD X .139W 025307

22 SEAL--DRIVE SHAFT 032560

23 PLUG --PRIME *380/1* 046833

24 O--RING--9/32 OD X 1/16 WALL 029751

8

Models 382/RC25

Accessories

Item Description Part No.

1 BRUSH--MIX PUMP BODY--3”X7” 023316

2 BRUSH--DRAW VALVE 1”X2”X17” 013073

3 BRUSH-- DOUBLE ENDED 013072

4 BRUSH-- REAR BRG 1IN.DX2IN.L 013071

5 LUBRICANT--TAYLOR HI PERF--4 048232

6 SANITIZER KAY--5R (CASE OF 125

PACKETS)

Models 382/RC25 Operator Parts Identification

041082

9

Section 5 Important: To the Operator

5

2

1

ADD MIX

MIX OUT

3

4

Item Description

1 Control Switch
2 Fill Switch
3 Add Mix Light
4 Mix Out Light
5 Viscosity Control
6 Display Light Switch (Optional)

6

Symbol Legend

= The “ON/AUTO” symbol.

= The “OFF” symbol.

= The “WASH” symbol.

= The “ADD MIX” symbol.

= The “MIX OUT” symbol.

Important: To the Operator

Control Switch (Item 1)

The control switch is located on the front of the
machine. The center position is “OFF”. The up position
is the “WASH” mode and activates the beater motor
only. The down position is the “AUTO” mode. The
“AUTO” mode activates the beater motor and enables
refrigeration when the fill switch is in the “ON” position.

10

Models 382/RC25

Fill Switch (Item 2)

Standby Switch (Optional)

The fill switch is located under the control channel. The
“ON” position enables refrigeration when the control
switch is in the “AUTO” position. The “ON” position
enables the fill system to replenish and maintain
product levels in the freezing cylinder and in the
hopper. The “OFF” position terminates the fill function.
The refrigeration system is disabled when the fill
switch is in the “OFF” position.

Add Mix Light (Item 3)

An “ADD MIX” indicating light is located on the front
panel. When the light is lit, it indicates that the mix
supply in the hopper is low and must be replenished.

Mix Out Light (Item 4)

A “MIX OUT” indicating light is located on the front
panel. When the light is lit, it indicates that the hopper
is empty and the mix supply must be replenished.
When the indicator lights, refrigeration is automatically
disabled to prevent component damage. The beater
motor continues to run.

Viscosity Control (Item 5)

The viscosity adjustment screw is located under the
control channel. The viscosity (thickness) of the slush
can be adjusted by turning the adjustment screw
clockwise for a thicker product or counterclockwise for
a thinner product.

The standby switch is located under the control
channel. To maintain a refrigerated product during long
no sale periods, the standby mode will maintain the
product at approximately 38_Fto40_F(3.3_Cto

4.4_C).

To operate the standby mode, place the power switch
in the “AUTO” position. Place the fill switch in the
“FILL” position and the standby switch in the
“STANDBY” position.

To resume normal operation, leave the power switch
in the “AUTO” position and the fill switch in the “FILL”
position. Move the standby switch to the “OFF”
position.

Display Light Switch (Item 6)
(Optional)

The display light switch is located under the control
channel. The left position is “OFF”. The right position
is “ON”, and activates the display light.

Push-Button Switch

If an overload condition occurs, the freezer will
automatically stop operating. To properly reset the
freezer, place the toggle switch in the “OFF” position.
Wait two or three minutes; then press the push-button
switch. Place the power switch in the “WASH” position
and observe the freezer’s performance; place the
power switch in the “AUTO” position.

Note: If the freezer is unplugged from the wall
receptacle, it will be necessary to press the
push-button switch for the freezer to operate once
power is re-established.

Models 382/RC25 Important: To the Operator

11

Section 6 Operating Procedures

We begin our instructions at the point where the parts
are disassembled and laid out to dry from the previous
night’s cleaning.

The following procedures will explain how to assemble
the parts into the freezer, sanitize them, and prime the
freezer with fresh product.

If you are disassembling the machine for the first time
or need information to get to this starting point in our
instructions, turn to “Disassembly” on page 20, and
start there.

Assembly

MAKESURE THE CONTROL SWITCH IS IN

THE “OFF” POSITION. Failure to do so may result in

personal injury or component damage.

Note: When lubricating parts, use an approved food
grade lubricant (example: Taylor Lube HP). Every
three months discard rubber parts and install new
rubber parts.

Step 1
Install the beater drive shaft. Lubricate the groove

and shaft portion that comes in contact with the rear
shell bearing on the beater drive shaft. DO NOT
lubricate the hex end of the drive shaft.

Install the drive shaft into the freezing cylinder, hex end
first. The drive shaft seal must fit securely over the rear
shell bearing. Be certain the drive shaft fits into the
drive coupling without binding.

Figure 6

Step 2
Install the beater assembly. First check scraper

blades for any nicks or signs of wear. If any nicks are
present or if the blades are worn, replace the blades.

Slide the seals over the shaft until they snap into their
grooves. Fill the inside portion of the seal with lubricant
and evenly lubricate the flat side of the seal that fits
onto the rear shell bearing.

Figure 5

Operating Procedures

12

Figure 7

Models 382/RC25

If the blades are in good condition, assemble the clips
on the blades. Install one scraper blade and clip over
the two holding pins on one side of the beater. Holding
the blade and clip on the beater, turn the assembly
over and install the second scraper blade and clip.

Figure 8

Holding the blades in position, insert the beater
assembly into the freezing cylinder, and slide the
assembly into position over the drive shaft. Turn the
beater slightly to be certain that the beater is properly
seated.

Figure 10

Insert the torque rotor (guide bearing end first) into the
pilot hole in the center of the drive shaft. The hole in the
torque rotor shaft should be rotated to the 12 o’clock
position.

Figure 9

When in position, the beater bearing hub will protrude
beyond the front of the freezing cylinder about 1/4 inch
(.635 cm.).

Step 3
Install the torque rotor. Install the plastic guide

bearing on the short end of the torque rotor. Slide the
o-ring into the groove on the long end of the torque
rotor and lubricate the o-ring. Do not lubricate the
guide bearing.

Figure 11

Step 4
Install the freezer door. Slide the draw valve o-ring

into the groove on the draw valve and lubricate the
o-ring.

Figure 12

Models 382/RC25 Operating Procedures

13

Place the draw valve spring over the shaft end on the
draw valve.

Align the draw spout assembly with the door. Place the
draw spout mounting plate over the draw spout
assembly and align the holes.

Figure 13

Insert the draw valve and spring into the door spout
until the threaded end of the shaft passes through the
hole in the end of the door spout. Thread the draw
valve knob onto the end of the draw valve shaft.

Figure 14

Place the door spout seal o-ring into the groove in the
door and lubricate the components.

Figure 16

Using the thumb screws, fasten the draw spout
assembly and draw spout mounting plate to the door .

Figure 17

Slide the o-ring into the groove on the prime plug.
Apply an even coat of lubricant to the o-ring and shaft.

Figure 15

Operating Procedures

Figure 18

Install the prime plug into the bleed port in the top of the
freezer door. Do not over-tighten the prime plug.

14

Models 382/RC25

Figure 19

Place the large o-ring into the groove on the back side
of the door and lubricate the installed o-ring.

Step 6

Install the four handscrews on the studs.
Finger-tighten the screws equally in a crisscross
pattern to insure that the door is snug. Do not
over-tighten the handscrews.

Figure 22

Step 7
Install the torque arm. Position the torque arm by

inserting it through the slot in the torqueswitch arm and
down into the hole in the torque rotor which protrudes
from the door. Verify proper installation by moving the
torque rotor back and forth to be sure it moves freely
and easily.

Figure 20

Place the door bearing into the back side of the door.

Note: Do not lubricate the door bearing.
Step 5

Install the freezer door. Align the torque rotor into the
center of the door and position the door on the four
studs on the front of the freezing cylinder. Firmly push
the door into place.

Figure 21

Figure 23

Models 382/RC25 Operating Procedures

15

Step 8

Install the front drip tray and the splash shield under
the door spout.

Figure 24

Make sure all sanitizer is removed from the fill system.
Place the fill switch in the “OFF” position.

Drain any remaining solution from the freezing
cylinder.

Sanitizing

Step 1
Fill System. Disconnect the product supply lines from

the mix delivery container. Prepare two gallons (7.6
liters) of an approved 100 PPM sanitizing solution
(Example: Kay--5t). USE WARM WATER AND
FOLLOW THE MANUFACTURER’S SPECIFICA­TIONS. Pour the solution into a clean, empty mix
delivery container.

Figure 25

Figure 26

Step 3

While the solution is flowing through the system, brush
clean the mix hopper, the mix inlet hole, and the mix
level sensing probe.

Step 4

Remove the prime plug and allow all of the solution to
flow into the freezing cylinder. Replace the prime plug.

Step 5

Place the control switch in the “WASH” position. This
will cause the sanitizing solution in the freezing
cylinder to be agitated. Allow the solution to agitate for
five minutes.

Step 2

Connect the container to the mix delivery line.

Place the control switch in the “WASH” position. Place
the fill switch in the “ON” position. This will activate the
mix solenoid. The mix solenoid will remain open until
the mix level probe is satisfied. Drain sanitizer from the
freezing cylinder and repeat this procedure until the
solution is dispensed from the mix delivery container.

Operating Procedures

16

Figure 27

Models 382/RC25

Step 6

Place the control switch in the “OFF” position. Place an
empty mix pail beneath the door spout. Open the draw
valve and draw off all of the sanitizing solution. When
the sanitizer stops flowing from the door spout, close
the draw valve.

strength product is flowing from the door spout, close
the draw valve. Allow the mix hopper to fill until the
product rises to the bleed port. Replace the prime plug.

Figure 28

Step 7

Replace the hopper cover.

Figure 29

Priming

Step 1

Connect the mix delivery line to a container filled with
mix.

Figure 30

Step 4

Place the control switch in the “AUTO” position. When
the unit cycles off, the product will be at serving
viscosity. The viscosity (thickness) of the slush can be
adjusted by turning the viscosity adjustment screw
under the control channel. Turn the viscosity
adjustment screw clockwise for a thicker product, or
counterclockwise for a thinner product. After making
an adjustment, allow the refrigeration system to cycle
2 or 3 times to accurately evaluate the viscosity.

Step 2

Remove the prime plug.

Step 3

With a mix pail beneath the door spout, open the draw
valve. Place the fill switch in the “ON” position to allow
fresh product to flow into the freezing cylinder. This will
force out any remaining sanitizing solution. When full

Models 382/RC25 Operating Procedures

Note: In order for the refrigeration system to operate,

the fill switch must be in the “ON” position while the
control switch is in the “AUTO” position.

17

Figure 31

Closing Procedure

To disassemble the units, the following items will be
needed:

S Two cleaning pails

S Necessary brushes provided with freezer

S Cleaner

S Single service towels

Draining Product From The
Freezing Cylinder

Step 2

With a pail beneath the door spout, open the draw
valve. When all of the product has been drained from
the mix hopper and freezing cylinder, close the draw
valve. Make sure the control switch is in the “OFF”
position.

Figure 33

Step 1

Place the fill switch in the “OFF” position. Place the
control switch in the “WASH” position as far ahead of
cleaning time as possible. This will allow frozen
product to soften for easier draining.

Figure 32

Rinsing

Step 1

Remove the hopper cover.

Step 2

Pour cool, clean water into the mix hopper and allow
it to flow into the freezing cylinder. With the brushes
provided, scrub the mix hopper, mix inlet hole, and mix
probes.

Figure 34

Operating Procedures

18

Models 382/RC25

Step 3

Place the control switch in the “WASH” position. With
a mix pail beneath the door spout, open the draw valve.
Drain all the rinse water from the freezing cylinder.
When the rinse water stops flowing from the door
spout, close the draw valve and place the control
switch in the “OFF” position.

Figure 35

Repeat this procedure until the rinse water being
drawn from the freezing cylinder is clear.

Step 3

Brush clean the mix hopper, the mix inlet hole, and the
mix level sensing probes.

Step 4

Place the control switch in the “WASH” position. This
will cause the cleaning solution in the freezing cylinder
to be agitated. Allow the solution to agitate for five
minutes.

Cleaning

Step 1

Prepare two gallons (7.6 liters) of an approved
cleaning solution (Example: Kay-5t). USE WARM
WATER AND FOLLOW THE MANUFACTURER’S
SPECIFICATIONS.

Step 2

Pour the cleaning solution into the hopper and allow it
to flow into the freezing cylinder.

Figure 37

Step 5

Place the control switch in the “OFF” position. Place an
empty mix pail beneath the door spout. Open the draw
valve and draw off all of the cleaning solution. When
the solution stops flowing from the door spout, close
the draw valve.

Figure 36

Models 382/RC25 Operating Procedures

19

Figure 38

Disassembly

BE SURE THE CONTROL SWITCH IS IN

THE “OFF” POSITION.

Step 1

Remove the torque arm, handscrews, freezer door,
beater assembly, scraper blades, torque rotor, and the
drive shaft, and take these parts to the sink for
cleaning.

Note: To remove o-rings, use a single service towel to
grasp the o-ring. Apply pressure in an upward direction
until the o-ring pops out of its groove. With the other
hand, push the top of the o-ring forward and it will roll
out of the groove and can be removed easily .

Step 3

Thoroughly brush clean all disassembled parts in the
cleaning solution making sure all lubricant and mix film
is removed. Place all the cleaned parts on a clean dry
surfacetoairdry.

Step 2

Remove the front drip tray and splash shield and take
them to the sink for cleaning.

Brush Cleaning

Step 1

Prepare a sink with an approved cleaning solution.
USE WARM WATER AND FOLLOW THE
MANUFACTURER’S SPECIFICATIONS. Make sure
all brushes provided with the freezer are available for
brush cleaning.

Step 2

Remove the:

S seals from the drive shaft.
S o-ring and front bearing from the freezer

door.

S door spout from the freezer door.
S draw valve and spring from the door spout.
S o-ring from the draw valve.
S o-ring and guide bearing from the torque

rotor.

S prime plug and prime plug o-ring.

Step 4

Return to the freezer with a small amount of cleaning
solution. Brush clean the rear shell bearing with the
black bristle brush.

Figure 39

Step 5

Wipe clean all exterior surfaces of the freezer.

Operating Procedures

20

Models 382/RC25

Section 7 Important: Operator Checklist

During Cleaning and Sanitizing

ALWAYS FOLLOW LOCAL HEALTH CODES.

Cleaning and sanitizing schedules are governed by
your State or local regulatory agencies and must be
followed accordingly. The following check points
should be stressed during the cleaning and sanitizing
operations.

WE RECOMMEND DAILY CLEANING AND
SANITIZING.

T roubleshooting Bacterial Count

j 1. Thoroughly clean and sanitize the machine

regularly, including complete disassembly and
brush cleaning.

j 2. Use all brushes supplied for thorough cleaning.

The brushes are specially designed to reach all
product passageways.

j 3. Use the white bristle brush to clean the mix inlet

hole which extends from the mix hopper down
to the rear of the freezing cylinder.

Regular Maintenance Checks

j 1. Replace scraper blades that are nicked or

damaged.

j 2. Before installing the beater, be certain that the

scraper blades are properly attached over the
pins.

j 3. Check the rear shell bearing for signs of wear

(excessive product leakage from the rear drip
pans to the front drip tray).

j 4. Dispose of o-rings and seals if they are worn,

torn, or fit too loosely, and replace with new
ones.

j 5. Follow all lubricating procedures as outlined in

“Assembly”.

j 6. If your machine is air cooled, check the

condenser(s) for accumulation of dirt and lint.
Dirty condensers will reduce the efficiency and
capacity of the machine. Condensers should be
cleaned monthly. Use a soft brush to clean
between the fins. Never use screwdrivers or
other metal probes to clean between the fins.

j 4. Use the black bristle brush to thoroughly clean

the rear shell bearing located at the rear of the
freezing cylinder. Be sure to have a generous
amount of cleaning solution on the brush.

j 5. Using a screwdriver and cloth towel, keep the

female hex drive socket and rear shell bearing
clean and free of lubricant and product deposits.

j 6. Properly prepare the cleaning and sanitizing

solutions. Read and follow label directions
carefully. Too strong of a solution may damage
the parts and too weak of a solution will not do
an adequate job of cleaning or sanitizing.

j 7. Clean and sanitize the product lines regularly to

prevent syrup residue build-up that would
restrict the proper flow of syrup.

j 8. On a regular basis, take a brix reading to assure

a consistent, quality product (post mix valve
systems only).

Winter Storage

If the place of business is to be closed during the winter
months, it is important to protect the freezer by
following certain precautions, particularly if the
building is subject to freezing conditions.

Disconnect the freezer from the main power source to
prevent possible electrical damage.

Your local T aylor Distributor can perform this service
for you.

Wrap detachable parts of the freezer such as beater,
blades, drive shaft, and freezer door, and place in a
protected dry place. Rubber trim parts and gaskets
can be protected by wrapping them with
moisture-proof paper. All parts should be thoroughly
cleaned of dried mix or lubrication which attract mice
and other vermin.

Models 382/RC25 Important: Operator Checklist

21

Section 8 Troubleshooting Guide

PROBLEM PROBABLE CAUSE REMEDY PAGE

REF.

1. No product is being
dispensed with the draw
valve open.

a. Product freeze-up due to

improper product mixing.

b. The torque arm is not

installed.

a. Follow directions for

mixing product carefully.

b. Install the torque arm.

-- --

15

c. Bent or improperly

installed torque rotor.

2. The product is too thin. a. Improper mixing of

product.

b. Missing, incorrectly

installed, or worn scraper
blades.

c. The viscosity adjustment

screw needs to be
adjusted.

d. The torque rotor is bound

leaving the torque arm in
the cold position.
Therefore, the compressor
will not run.

3. The product is too stiff. a. The torque rotor bound

leaving the torque arm in
the warm position.
Therefore, the compressor
continually runs.

b. The torque arm is missing

or bent.

c. Replace the bent rotor or

follow proper assembly
procedures.

a. Follow directions for

mixing product carefully.

b. Replace or install the

blades correctly.

c. Adjust the screw

accordingly.

d. Free the torque rotor.

a. Free the torque rotor.

b. Install or replace the

torque arm.

13

-- --

12

4, 10

-- --

-- --

15

Troubleshooting Guide

c. The viscosity adjustment

screw needs to be
adjusted.

d. Improper mixing of

product.

22

c. Adjust the screw

accordingly.

d. Follow directions for

mixing product carefully.

4, 10

-- --

Models 382/RC25

PROBLEM PROBABLE CAUSE REMEDY PAGE

4. The freezing cylinder walls
are scored.

a. Broken beater pins. a. Repair or replace the

beater assembly.

REF.

-- --

5. Unable to remove the
drive shaft.

6. Excessive mix leakage in
the rear drip pan.

7. No freezer operation with
the unit in the “AUTO”
position.

b. The gear unit is out of

alignment.

c. The beater assembly is

bent.

d. The door bearing is

b. Contact a service

technician.

c. Repair or replace the

beater assembly.

d. Install the door bearing.

missing.

a. There is lubrication on the

hex end of the drive shaft.

a. Do not lubricate the hex

end of the drive shaft.
Contact a service
technician for drive shaft
removal.

b. Rounded corners of the

drive shaft, drive coupling
or both components.

a. Improper or inadequate

lubrication on the drive
shaft o-ring or seal.

b. Replace the drive shaft,

drive coupling or both
components.

a. Use the correct lubricant

(Taylor Lube) and follow
proper lubrication
procedures.

b. Worn or missing o-ring or

seal on the drive shaft.

b. Replace rubber parts

every 3 months.

c. Worn rear shell bearing. c. Contact a service

technician for component
replacement.

a. The unit is unplugged. a. Plug the power cord in the

wall receptacle.

b. The beater motor has

tripped the reset
mechanism.

b. Place the toggle switch in

the “OFF” position. Allow
the motor to cool, press
the reset button and
resume normal operation.
Contact a service
technician if the problem
continues.

c. The fill switch is not in the

“ON” position.

c. Place the fill switch in the

“ON” position.

-- --

-- --

15

12

-- --

12

12

-- --

-- --

-- --

4

d. The circuit breaker tripped

or the fuse has blown.

Models 382/RC25 Troubleshooting Guide

23

d. Reset the circuit breaker

or replace the blown fuse.

-- --

PROBLEM PROBABLE CAUSE REMEDY PAGE

8. The unit is not freezing
product when placed in
the “AUTO” mode.

a. The torque rotor is bound,

a. Free the torque rotor.
leaving the torque arm in
the cold position.
Therefore the compressor
will not run.

b. The torque arm is bent. b. Replace the torque arm.

c. The condensers are dirty. c. Clean the condensers

monthly.

d. The fill system switch is

not in the “ON” position.

d. Turn the fill switch to the

“ON” position.

REF.

-- --

-- --

21

4

9. The guide bearing is
missing.

10. There is excessive
leakage from the draw
spout.

1 1. The door is not easily

installed.

e. There is a mix out

condition.

f. The circuit breaker has

tripped or the fuse has
blown on the condensing
unit.

a. The guide bearing is stuck

in the drive shaft.

a. There is improper or

inadequate lubrication on
the draw valve o-rings.

b. Worn or missing draw

valve o-ring.

a. Position of the beater

assembly.

e. Refill the mix system.

f. Reset the circuit breaker

or replace the blown fuse.

a. Remove the guide bearing

from the hole in the drive
shaft.

a. Use the correct lubricant

(Taylor Lube) and follow
proper lubrication
procedures.

b. Replace rubber parts

every 3 months.

a. Position the beater

assembly so that the
blades are in the 12:00
o’clock and 6:00 o’clock
positions.

10

-- --

-- --

13

12

12

Troubleshooting Guide

24

Models 382/RC25

Section 9 Parts Replacement Schedule

PART DESCRIPTION EVERY 3 MONTHS EVERY 6 MONTHS ANNUALLY

Scraper Blade Inspect & Replace if

Necessary

Drive Shaft Seal X

Freezer Door O-Ring X

Door Port O-Ring X

Front Bearing X

Door Spout O-Ring X

Drive Shaft O-Ring X

Torque Arm O-Ring X

Brushes Inspect & Replace if

Necessary

Minimum

Minimum

Models 382/RC25 Parts Replacement Schedule

25

Section 10 Parts List

UPDATE

REMARKS PARTS

CLASS

QTY. WARR.

NUMBER

DESCRIPTION PART

+BLADE--SCRAPER *382* 051088 2 000

ARM--TORQUE 014500 1 103

BEARING--FRONT--TORQUE*382-- 384* 052005 1 000

BEARING--GUIDE 014496 1 000

BEARING--UNIT REAR 025629 1 103

BEATER A.-- TORQUE *382--384* X51105 1 103

+CLIP--SCRAPER BLADE*11--21/32* 051978 2 000

BELT-- POLY V-- 510J10 047049 1 000

BRUSH--DOUBLE ENDED-- PUMP&FEED TUBE 013072 1 000

BRUSH--DRAW VALVE 1”ODX2”X17”L 013073 1 000

BRUSH--MIX PUMP BODY--3”X7”WHITE 023316 1 000

BRUSH--REAR BRG 1IN.DX2IN.LGX14 013071 1 000

CAP--DUST--BULKHEAD COUPLING 048427 2 000

COUPLING--BULKHEAD--3/8OD--COPPER 048425 1 103 QD SOCKET-- MALE (ON DISPENSER)

COUPLING--BULKHEAD--5/8OD COPPER 048423 1 103 QD SOCKET--MALE (ON DISPENSER)

+FLANGE--MOUNTING 048426 2 103 HOLDS COUPLING IN PLACE

+GASKET--INSULATOR--COUPLING 049055 2 000 UNDER FLANGE

COUPLING--TUBING--3/8 OD COPPER 048424 1 103 QD SOCKET-- FEMALE (ON REFIGERANT LINES )

COUPLING--TUBING--5/8 OD COPPER 048422 1 103 QD SOCKET-- FEMALE (ON REFIGERANT LINES )

COVER--HOPPER--12 QT 045416 1 103

DEC A.--PLA TE *382--384* X51131 1 103

DECAL--CLEAN INST.--HOPPER 019029 1 000

DECAL--DEC--380-- FLAVOR SET OF 4 050703 1 000

DECAL-- DEC-- TA YLOR 380*RD30 045967 1 000

DECAL--REFRIGERATION--LIQUID 049205 1 000

DECAL-- REFRIGERATION-- SUCTION 049204 1 000

DECAL--TROUBLESHOOTING 038374 1 000

DIAGRAM-- WIRING *382*C/F* 051061--12 1 000

DOOR A.--PARTIAL *382* X51098 1 103

+O-- RING-- 8-- 3/8 ODX.105W 027814 1 000 GASKET

+KNOB--DRAW VALVE-- BLACK PLASTIC 047358 1 103

+ Available Separately

Parts List Models 382/RC25

26

+PLATE-- DRAW SPOUT MOUNTING 049275 1 103

Model 382

UPDATE

REMARKSWARR.

CLASS

QTY.PART

NUMBER

DESCRIPTION PARTS

+SCREW-- 1/4--20X9/16 THUMB--300 047632 2 103

+O--RING--9/32 OD X 1/16 WALL 029751 1 000

+O-- RING-- 2.375 OD X 1/16W 046830 1 000

+PLUG-- PRIME *380/1* 046833 1 103

+SPOUT--DOOR ZERO WASTE 049276--BLA 1 103

+ Available Separately

Models 382/RC25 Parts List

+SPRING-- COMP.845X.055X3.5--SS 047357 1 103

+VALVE--DRAW *380/1*ZERO WASTE 047353 1 103

+O-- RING--7/8 OD X .103W 014402 1 000

DRYER-- FILTER 3/8 X 3/8SOL HP62 049154 1 000

GASKET--BASE PAN *382--384* 051868 1 000

INDICATOR-- LIQUID-- 3/8 049170 1 103

KIT A.--TUNE UP *382* X51255 1 000

BEARING--FRONT--TORQUE*382-- 384 052005 1 000

BEARING--GUIDE 014496 1 000

O-- RING-- .291 ID X .080W 018550 1 000 TORQUE ASSEMBLY

27

O-- RING-- 2.375 OD X 1/16W 046830 1 000 DOOR SPOUT

O-- RING-- 7/8 OD X .103W 014402 2 000 DRAW VALVE

O-- RING-- 8--3/8 ODX.105W 027814 1 000 DOOR GASKET

O-- RING-- 9/32 OD X 1/16 WALL 029751 1 000 PRIME PLUG

O-- RING-- 7/8 O.D. X .139W 025307 1 000 DRIVE SHAFT

SEAL--DRIVE SHAFT 032560 1 000

LABEL--DOOR CAUTION 032749 1 000

LABEL--SWITCH-- OFF/FILL--INTL SYM 051971-- BLA 1 000

LABEL--SWITCH-- POWER--INT’L SYM 046089--BLA 1 000

LABEL-- WARNING--COVER 051433 6 000

LENS-- LIGHT *382--384* 051129 1 103

+BRACKET-- LIGHT *382--384* 051870 1 103

LIGHT-- AMBER-- RECTANGULAR--250VAC 047141-- 1 103 *ADD MIX*

TERMINALS 026962 2 000

LIGHT--AMBER--RECT-- MIX OUT 050036-- 1 103 *MIX LOW*

LUBRICANT--TAYLOR HI PERF-- 4 OZ 048232 1 000

MAN-- OPER 380/381 047455--M 1 000

MOTOR-- 1/2 HP 024839-- 1 212

Model 382

UPDATE

REMARKSWARR.

CLASS

QTY.PART

NUMBER

DESCRIPTION PARTS

+CLIP--SPRING--SIDE PANEL 050877 2 103

+CLIP--SPRING--SIDE PANEL 050877 2 103

PAN--DRIP *380/1* 046852 1 103

PANEL A.-- FRONT *382* X51097 1 103

PANEL A.-- REAR*382* X52115 1 103 INCLUDES 2--021106 NUTSERTS

PANEL--SIDE *382--3--4*RIGHT 051713 1 103

PAN EL - -SIDE LEF T 052117 1 103

PCB A.--DUAL MIX LVL/CONT. FILL X41420--SER 1 212

PLATE--FILL-- REAR *339/382* 051133 1 103

PROBE A.-- MIX LOW-- HOPPER X51804 1 103

PROBE A.--MIX OUT --SQUARE HOLE X41348 1 103

PULLEY-- 10J-- 1.125PD--5/8BORE 028857 1 103

PULLEY-- 10J-- 11”PD--5/8BORE 025570 1 103

RELAY--DPDT--20 A-- 230 V 026581-- 4 103

RESISTOR A.-- DELAY TIMER*383-- 4* X52008--12 1 103

+ Available Separately

Parts List Models 382/RC25

28

SANITIZER KAY--5 125 PACKETS 041082 1 000

SHAFT--BEATER W/BAFFLE GUIDE 049270 1 103 ADDED GROOVE -- 7/15/98 133

+O-- RING 7/8 O.D. X .139W 025307 1 000 133

+SEAL--DRIVE SHAFT 032560 1 000

SHELF-- DRIP TRAY*382--384* 052065 1 103

SHELL A.-- INS.*383-- 384*TORQUE X5 1112 - -SP 1 512

+STUD-- FREEZER DOOR *383--384* 051950 4 103

SHIELD-- SPLASH *380/1* 046851 1 103

SWITCH A.--TORQUE *382* X51100 1 103

ARM-- SWITCH-- TORQUE *382* 051 101 1 103

BRACKET-- TORQUE CONTROL *382* 051086 1 103

BUSHING A.--TORQUE X50399 1 103

BUSHING-- ARM-- TORQUE 049737 1 103

BUSHING--PIVOT--TORQUE ARM 049739 1 103

SPRING--TORQUE*BLACK* 015007 1 103

SWITCH--LEVER-- SPDT--20A-- 125--48 027026 1 103

SWITCH--PUSHBUTTON--SPST 016530 1 103

SWITCH--TOGGLE--DPST 075772 1 103

Model 382

UPDATE

REMARKSWARR.

CLASS

QTY.PART

NUMBER

DESCRIPTION PARTS

+BOOT--TOGGLE SWITCH 043398 1 000

SWITCH-- TOGGLE--DPDT*ON--OFF-- O N 014464 1 103

+ Available Separately

Models 382/RC25 Parts List

TIMER A.-- DELAY ON MAKE--2 MIN. X49541-- 12 1 103

TORQUE A. *382* X51081 1 103

O--RING--TORQUE 018550 1 000

TRAY A.-- DRIP *380* X46848 1 103

+WASHER-- FILL TUBE .531”IDX7/8OD 043135 1 103

TUBE A.--FILL *340*CONT. FILL X43081 1 103 FRONT PANEL DRAIN

TUBE-- CAPILLARY .021ID X 9 FT 020059 1 103

VALVE A.-- SOLENOID *382* X51398-- 12 1 103 FILL SOLENOID ASSY

ADAPTOR--1/4MPT X 1/4BARB--NYL 021630 1 103

CLAMP-- HOSE-- ADJ 7/16 X 25/32 010031 1 000

ELBOW--1/4MP X 3/8BARB-- PLASTI 016487 1 000

HOSE--BEVERAGE--3/8 ID X 5/8 O 020565-- 30 1 000

VALVE-- SOLENOID SYRUP 051396--12 1 103

VALVE--ACCESS 1/4FL X 1/4SOLD 044404 2 103

VALVE--EPR 1/4S 022665 1 103

VALVE-- EXP--THERMO 051287 1 103

VALVE-- SOLENOID 1/8PORT-- 3/8ODF 051127--12 1 103 FILL SOLENOID

VALVE-- SOLENOID-- REFRIGERATION 048952-- 12 1 103 SUCTION LINE

VARISTOR A.-- 130VAC X49300 1 103

29

Model 382

UPDATE

REMARKS PARTS

WARR.

CLASS

QTY.

RC25

NUMBER

DESCRIPTION PART

BOOT-- ROTOLOCK VALVE 037116 1 000 J7032493/PRIOR (TECUMSEH)

RC25 Condensing Unit

+ Available Separately

BLOCK-- TERMINAL 2P--L1,L2 039422 1 103 J7032493/UP (BRISTOL)

CAP--DUST--BULKHEAD COUPLING 048427 2 000

+CAPACIT OR--RUN 048132 1 103

+CAPACITOR--START 036048 1 103

+RELAY--START-- COMPRESSOR 036047 1 103

+CAPACIT OR--RUN 012906 1 103

+CAPACITOR--START 031790 1 103

+RELAY--START-- COMPRESSOR 038145 1 103

COMPRESSOR 049512--27 1 512 J7032493/PRIOR (TECUMSEH)

COMPRESSOR L63A113BBCA 048259-- 27 1 512 J7032493/UP (BRISTOL)

CONDENSER 049516 1 103 J7032493/PRIOR (TECUMSEH)

CONDENSER 048629 1 103 J7032493/UP (BRISTOL)

CONTROL-- DUAL PRESSURE 049514 1 103 J7032493/PRIOR (TECUMSEH)

CONTROL-- DUAL PRESSURE 050358 1 103 J7032493/UP (BRISTOL)

COUPLING--BULKHEAD--3/8OD--COPPER 048425 1 103 QD SO CKET-- MALE (ON CONDENSER)

COUPLING--BULKHEAD--5/8OD COPPER 048423 1 103 QD SOCKET--MALE (ON CONDENSER)

COUPLING--TUBING--3/8 OD COPPER 048424 1 103 QD SOCKET-- FEMALE (ON REFRIGERANT LINES)

COUPLING--TUBING--5/8 OD COPPER 048422 1 103 QD SOCKET-- FEMALE (ON REFRIGERANT LINES)

DECAL--REFRIGERATION--LIQUID 049205 1 000

DECAL-- REFRIGERATION-- SUCTION 049204 1 000

FLANGE--MOUNTING 048426 2 103 HOLDS QD’S IN PLACE

GASKET--INSULATOR--COUPLING 049055 2 000 UNDER FLANGE

HEATER CRANKCASE 049518 1 103 BRISTOL

INDICATOR-- LIQUID-- 3/8 S 049170 1 103

LEG A.--4”--3/8--16 STUD--W/CAP X43408 4 103

+ L E G -- 4 ” -- 3 / 8 -- 1 6 S T U D 036397 4 103

+CAP--RUBBER 037268 4 000

+BLADE-- FAN 049515 1 103

MOTOR-- FAN 049513-- 27 1 103 J7032493/PRIOR (TECUMSEH)

MOTOR-- FAN 050265-- 27 1 103 J7032493/UP (BRISTOL)

Model RC25

Parts List Models 382/RC25

30

UPDATE

REMARKSWARR.

CLASS

QTY.

RC25

PART

NUMBER

DESCRIPTION PARTS

+BLADE-- FAN 031532 1 103

+CAPACIT OR--RUN 023739 1 103

+CAPACITOR--START 031790 1 103

+RELAY--START-- COMPRESSOR 038146 1 103

PANEL--BACK&SIDE*RC25* 049164 1 103 J7032493/PRIOR (TECUMSEH)

PANEL--BACK&SIDE*RC25* 050162 1 103 J7032493/UP (BRISTOL)

PANEL--CORNER 050160 1 103 J7032493/UP (BRISTOL)

PANEL--FRONT--TOP 050161 1 103 J7032493/UP (BRISTOL)

PANEL--SERVICE-- SIDE 050159 1 103 J7032493/UP (BRISTOL)

PANEL--SIDE *RC25* 049165 1 103 J7032493/PRIOR (TECUMSEH)

PANEL--TOP *RC25* 049166 1 103 J7032493/PRIOR (TECUMSEH)

PANEL--TOP *RC25* 050158 1 103 J7032493/UP (BRISTOL)

RECEIVER--REFRIGERANT 10# 050182 1 103

TEE-- ACCESS 1/2” W/5344 CORE 026688 1 103 J7032493/UP (BRISTOL)

TEE--ACCESS 3/8 026687 1 103

TEE--ACCESS 5/8 026689 1 103

VALVE--ACCESS 1/4FL X 3/8SDR-- 044455 1 103 J7032493/UP (BRISTOL)

VALVE--REG UL ATOR CPR 5/8S 025780 1 103 J7032493/UP (BRISTOL)

50 Hz

BLOCK--TERMINAL 2P--L1,N 039421 1 B J7032493/UP (BRISTOL)

COMPRESSOR 048259--40 1 512 TECUMSEH & BRISTOL

CONDENSER 048629 1 103 J7032493/PRIOR (TECUMSEH)

+BLADE-- FAN 031532 1 103

CONTROL-- DUAL PRESSURE 050358 1 103 J7032493/PRIOR (TECUMSEH)

MOTOR-- FAN 050265-- 40 1 103 TECUMSEH & BRISTOL

PANEL--BACK&SIDE*RC25* 050162 1 103 J7032493/PRIOR (TECUMSEH)

PANEL--CORNER 050160 1 103 J7032493/PRIOR (TECUMSEH)

PANEL--FRONT--TOP 050161 1 103 J7032493/PRIOR (TECUMSEH)

PANEL--SERVICE-- SIDE 050159 1 103 J7032493/PRIOR (TECUMSEH)

PANEL--TOP *RC25* 050158 1 103 J7032493/PRIOR (TECUMSEH)

Model RC25

+ Available Separately

Models 382/RC25 Parts List

31

Model 382
051061--12

Model 382
051061--40
