Page 1
USER MANUAL
FAVORITE
FAVORITE
switch
®
Page 2
FAVORITE Switch - User Manual
MODE
A
B
C
MODE
A
B
C
MIXTIME
REPEATS
fixed
multi
single
BYPASSTAP
®
WOW & FLUTTERTAPE AGE
TAPE HEAD
MODE
A
B
C
dTape Echo
Operation & set-up for products with toggle switches
®
INPUT
EXP
TRS
RIGHT OUTLEFT OUT
®
9VDC
+
or
-
To use a FAVORITE switch with
1.
To use an Expression Pedal with your Strymon
pedal, set both toggles to the up position.
your Strymon pedal, set both
toggles to the middle position.
FAVORITE
Press footswitch to engage
favorite setting. Press and hold
BYPASS on your Strymon pedal to
save a new favorite setting.
2.
Power up holding BOTH footswitches.
pg 2
Page 3
FAVORITE Switch - User Manual
Set up for products without toggle switches
®
2.
• Turn TOPMOST LEFT KNOB full clockwise to use with the FAVORITE switch
• Turn TOPMOST LEFT KNOB full counterclockwise to use with an EXPRESSION pedal
While holding both footswitches:
EXTERNAL
SPEED SWITCH
MIC DISTANCE
EXP
PEDAL
FAST ROTOR
SPEED
FAV
SWITCH
PREAMP
DRIVE
HORN LEVEL
BYPASSSLOW/FAST
rotary
3.
BYPASS LED
will turn on to
indicate that you
have set up your
pedal to use a
FAVORITE switch
1.
®
Power up holding BOTH footswitches
pg 3
Page 4
FAVORITE Switch - User Manual
Specification
Dimensions 4.5” deep x 2.4” wide x 1.75” tall
Cable 1/4” TRS (tip / ring / sleeve)
Strymon Non-Transferrable Limited Warranty
Warranty
Strymon warrants the product to be free from defects in material and workmanship for a period of one (1) year
from the original date of purchase. If the product fails within the warranty period, Strymon will repair or, at our
discretion, replace the product at no cost to the original purchaser.
Exclusions
This warranty covers defects in manufacturing discovered while using this product as recommended by
Strymon. This warranty does not cover loss or theft, nor does the coverage extend to damage caused by
misuse, abuse, unauthorized modification, improper storage, lightning, or natural disasters.
®
Limits of Liability
In the case of malfunction, the purchaser’s sole recourse shall be repair or replacement, as described in the
preceding paragraphs. Strymon will not be held liable to any party for damages that result from the failure of
this product. Damages excluded include, but are not limited to, the following: lost profits, lost savings, damage
to other equipment, and incidental or consequential damages arising from the use, or inability to use this
product. In no event will Strymon be liable for more than the amount of the purchase price, not to exceed the
current retail price of the product. Strymon disclaims any other warranties, express or implied. By using the
product, the user accepts all terms herein.
How to Obtain Service Under this Warranty
For North American customers: Contact Strymon through our website at http://www.strymon.net/support for
Return Authorization and information. Proof of original ownership may be required in the form of a purchase
receipt.
For International Customers: Contact the Strymon dealer from which the product was purchased from in order
to arrange warranty repair service.
Strymon® is a division of Damage Control®, LLC.
REV D
pg 4
