Strong SRT 8910 User Manual

Picture similar

Digital Terrestrial Receiver with
Embedded Conax SRT 8910

User Manual

PART 2 • English

TABLE OF CONTENTS

1.0 INTRODUCTION 2

1.1 Safety Instructions 2

2. INTRODUCTION 6

2.1 Front Panel 6

2.2 Rear Panel 6

2.3 Remote control 6

3.0 CONNECTION 8

3.1 Connecting to Terrestrial Antenna 8

3.2 Connection to TV with HDMI cable 8

3.3 Connecting to TV with SCART cable 8

3.4 Connecting a Hi-Fi system 8

4.0 GETTING STARTED 9

4.1 Switching On 9

4.2 First Time Installation 9

4.3 Channel Search 9

5.0 MAIN MENU 10

5.1 Channel manager 10

6.0 FUNCTIONS 12

6.1 Standby/Power button 12

6.2 Program Guide 12

6.3 Changing Channels 13

6.4 Volume Control 13

6.5 Audio control 13

6.6 Accessing the favorite channels 13

6.7 Teletext 13

6.8 Subtitle 13

6.9 Show program information 13

6.10 Switching between DTV and Radio mode 14

English

7.0 SPECIFICATION 14

A.1 TROUBLESHOOTING 16

1

PART 2 • English

1.0 INTRODUCTION

1.1 Safety Instructions

TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE.

CAUTION: To reduce the risk of fire and electric shock,

do not remove the cover (or back) of the
unit. No user-serviceable parts inside. Refer
to qualified Service for servicing.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of not insulated dangerous voltage within the inside of the product
that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operation and servicing
instructions in the literature accompanying the appliance.

Read the following instructions carefully

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT

AND FULLY INSERT
The apparatus shall not be exposed to dripping or splashing, and that no objects filled with liquids, such
as vases, shall be place on the apparatus.

IMPORTANT SAFEGUARDS

In addition to the careful attention devoted to quality standards in the manufacture of your product,
safety is a major factor in the design of every instrument. However, safety is your responsibility, too. This
sheet lists important information that will help to assure your enjoyment and proper use of the product
and accessory equipment. Please read them carefully before operation and using your product.

INSTALLATION

1. Read and Follow Instructions - All the safety and operation instructions should be read before
the product is operated. Follow all operating instructions.

2. Save Instructions – Save all safety and operating instructions for future reference.

3. Heed Warnings – Read carefully and follow all warning labels on the product and those
described in the instructions.

4. Grounding, Polarization – If this product is used with a specified AC adapter, the adapter may
be equipped with a polarized alternating current line plug. This product may be equipped
with a polarized alternating -current line plug. This plug will fit into the power outlet, try
reversing the plug. If the plug still fails to fit, contact your electrician to replace your obsolete

2

PART 2 • English

outlet. To prevent electric shock, do not use this polarized plug with an extension cord,
receptacle, or other outlet unless the blades can be fully inserted without blade exposure. If
you need an extension cord, use a polarized cord.

5. Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your home,
consult your video dealer or local power company. For products intended to operate from
battery power, or other sources, refer to the operating instructions.

6. Overloading - Do not overload wall outlets or extension cords as this can result in a risk of
fire or electric shock. Overloaded AC outlets, extension cords, frayed power cords, damaged
or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or fire
hazard. Periodically examine the cord, and if its appearance indicated damage or deteriorated
insulation, have it replaced by your service technician.

7. Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where they exit from the product.

8. Ventilation - Slots and openings in the case are provided for ventilation to ensure reliable
operation of the product and to protect it from overheating. These openings must not the
blocked or covered. The openings should never be blocked by placing the product on a bed,
sofa, rug, or heat register. This product should not be placed in a built-in installation such
as a book case or rack, unless proper ventilation is provided or the product manufacturer’s
instructions have been followed.

9. Attachments - Do not use attachments unless recommended by the product manufacturer as
they may cause hazards.

10. Water and Moisture - do not use this product near water for example, near a bath tub, wash
bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool and the like.
Caution: Maintain electrical safety. Power line operated equipment or accessories connected
to this unit should bear safety certification mark on the accessory itself and should not
be modified so as to defeat the safety features. This will help avoid any and should not be
modified so as to defeat the safety features. This will help avoid any potential hazard from
electrical shock or fire. If in doubt, contact qualified service personnel.

11. Accessories - Do not place this product on an unstable cart, stand, tripod, bracket, or table.
The product may fall, causing serious injury to a child or adult as well as serious damage to
the product. Use this product only with a cart, stand, tripod, bracket, or table recommended
by the manufacturer’ or sold with the product. Any mounting of the product should follow the
manufacturer’s instructions and use of a mounting accessory recommended by the manufacturer.

11a. A product and card combination should be moved with care. Quick stops, excessive

force, and uneven surfaces may cause the product and cart combination to overturn. Note to
CATV system installer. This reminder is provided to call the CATV system installer’s attention
to Section 820-40 of the NEC which provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.

12. Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the
product, be sure the antenna or cable system is grounded so as to provide some protection

English

3

PART 2 • English

against voltage surges and built-up static charges. Section 810 of the National Electrical
Code, ANSI/NFPA No.70-1984 (Section 54 of Canadian Electrical Code, Part1) provides
information with respect to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.

13. Power Lines -An outside antenna system should not be located in the vicinity of overhead
power lines, other electric light or power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system, extreme care should be taken to keep
from touching or approaching such power lines or circuits, as contact with them might be
fatal. Installing an outdoor antenna can be hazardous and should be left to a professional
antenna installer.

Use

14. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.

15. Objects that may touch dangerous voltage points or “short-out” parts could result in a fire or
electric shock. Never spill liquid of any kind on the product.

16. Lightning -For added protection for this product during a lightning storm, or when it is
left unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent damage to the product due to
lightning and power line surges.

Service

17. Servicing - Do not attempt to service this product yourself, as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

18. Conditions Requiring Service - Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:

   n When the power-supply cord or plug is damaged.
   n If liquid has been spilled, or objects have fallen into the product.
   n If the product has been exposed to rain or water.
   n If the video does not operate normally by following the operating instructions. Adjust

only those controls that are covered by operating instructions. Improper adjustment
of other controls may result in damage and will often require extensive work by a
qualified technician to restore the product to its normal operation.

   n If the product has been dropped or cabinet has been damaged.
   n When the product exhibits a distinct change in performance-this indicates a need for service.

19. Replacement Parts - When replacement parts are required, have the service technician verify
that the replacements he uses have the same safety characteristics as the original parts. Use
of replacements specified by the product manufacturer can prevent fire, electric shock, or
other hazards.

20. Safety Check - Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks recommended by the manufacturer to determine that the
product is in safe operating condition.

21. Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.

4

PART 2 • English

22. Heat - The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that products heat.

Safety Warnings

1. The normal operating temperature of the digital receiver is between 0° C and 40° C

2. Please prevent the receiver from operating in dusty conditions.

3. The receiver shall be operated in ventilated environment away from heat sources. No
objects filled with liquids, such as vases, shall be placed on the unit. The receiver shall not
be exposed to dripping or splashing. Should this happen, disconnect your receiver from the
main and consult your dealer.

4. Do not open or disassemble the outer chassis in order to avoid the danger of electric shock
and damaging to the receiver. Opening the chassis will also void the warranty.

5. The antenna connected to the receiver shall be equipped with anti-shock device from
lightning. Where the mains plug or an appliance coupler is used as the disconnected device,
the disconnected device shall remain readily operable.

6. If the receiver is inoperative, please consult the Customer Support.

This receiver has been manufactured to satisfy international safety standards. Please read the following
recommended safety precautions carefully.

MAINS SUPPLY: AC 90 ~ 240 V ~ 50/60 Hz
OVERLOADING: Do not overload wall outlets, extension cords or adapters as this can result in fire or

electrical shock.
LIQUIDS: Keep liquids away from the receiver.
CLEANING: Before cleaning, disconnect the receiver from the wall socket. Use a cloth lightly

dampened with water (no solvents) to clean the exterior.
VENTILATION: Do not block the receiver ventilation holes. Ensure that free airflow is maintained

around the receiver. Never store the receiver where it is exposed to direct sunlight or

near heating equipment e.g. a radiator. Never stack other electronic equipment on top

of the receiver. Place the receiver at least 30 mm from the wall.
ATTACHMENTS: Do not use any attachment that is not recommended by the manufacturer; it may cause

a hazard or damage the equipment.
CONNECTION: Connect all components before plugging any power cords into the wall outlet. Always turn off

the receiver, TV and other components before you connect or disconnect any cables.
SERVICING: Do not attempt to service this product yourself. Any attempt to do so will make the

warranty invalid. Refer all servicing to a qualified service agent.
LIGHTNING: If the receiver is installed in an area subject to intense lightning activity, protection

devices for the receiver mains connector and modem telephone line are essential. The

individual manufacturer’s instruction for safeguarding other equipment, such as TV set,

Hi-Fi, etc., connected to the receiver must also be followed during lightning storms.
GROUNDING: cables must be grounded. The grounding system must comply with SABS 061.

English

NOTE: Dispose the used batteries at designated place for environment protection

5
