Strong SRT 8530 User Manual
6
Цифровий ефірний Smart HD
T2
приймач SRT 8530
Каналів
Посібник користувача
Руководство пользователя
./
Списки
обраних
10 Таймерів
1.00 Вт
y Stand-by
Simulacija slike
Телефон служби технічної підтримки
Телефон службы технической поддержки
www.strong.tv
Supplied by STRONG & Co, Japan
Represented by
STRONG Ges.m.b.H.
Franz-Josefs-Kai 1
1010 Vienna
Austria
Email: support_at@strong.tv
10 Nov 2014 15:53
Мал./Рис. 1
Мал./Рис. 2
Мал./Рис. 3
1
3
4
6
7
9
11
12
11
14
16
18
20
21
24
1
2
ВИГОТОВЛЕНО ЗА ЛІЦЕНЗІЄЮ
КОМПАНІЇ DOLBY LABORATORIES.
DOLBY ТА ЕМБЛЕМА З
ПОДВІЙНИМ “D” - ТОРГІВЕЛЬНІ
МАРКИ КОМПАНІЇ
DOLBY LABORATORIES.
USB
5 V 800 mА max.
4 5
3
Цифровий ефірний Smart HD приймач
Made in China
Модель: SRT 8530
Supplied by STRONG & Co, Japan
VIDEO
5 V
50 mА max.
S/PDIF
ANT IN
001
INTERNET
6 7
AUDIO
LR
ON
OFF
12 V 2.0 А max.
3 54 6 7 8 921
2
5
8
10
12
13
15
17
19
22
23
Мал./Рис. 4 Мал./Рис. 5
1.
2.
25
3.
Мал./Рис. 6
Цифровий
підсилювач звукуАнтена ДМХ
Телевізор
ВИГОТОВЛЕНО ЗА ЛІЦЕНЗІЄЮ
КОМПАНІЇ DOLBY LABORATORIES.
DOLBY ТА ЕМБЛЕМА З
ПОДВІЙНИМ “D” - ТОРГІВЕЛЬНІ
МАРКИ КОМПАНІЇ
DOLBY LABORATORIES.
USB
5 V 800 mА max.
ANT IN
001
USB
Пристрій Роутер
Мал./Рис. 7
5 V
50 mА max.
S/PDIF
INTERNET
USB
Пристрій
Цифровий ефірний Smart HD приймач
Модель: SRT 8530
Made in China
Спосіб 1
VIDEO
AUDIO
Supplied by STRONG & Co, Japan
Спосіб 2
OFF
LR
12 V 2.0 А max.
Блок
ON
живлення
ANY USE OF THIS PRODUCT IN ANY MANNER OTHER THAN PERSONAL USE THAT COMPLIES
WITH THE MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR PACKAGED MEDIA
IS EXPRESSLY PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2
Green Circle, Suite 400E, Greenwood Village, Colorado 80111 U.S.A.
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND
NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC
STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.
MPEGLA.COM
This product contains one or more programs protected under international and U.S. copyright laws as
unpublished works. They are confidential and proprietary to Dolby Laboratories. Their reproduction
or disclosure, in whole or in part, or the production of derivative works therefrom without the express
permission of Dolby Laboratories is prohibited. Copyright 2003-2009 by Dolby Laboratories. All rights
reserved.
Content owners use Microsoft PlayReadyTM content access technology to protect their intellectual
property, including copyrighted content. This device uses PlayReady technology to access
PlayReadyprotected content and/or WMDRM-protected content. If the device fails to properly enforce
restrictions on content usage, content owners may require Microsoft to revoke the device’s ability to
consume PlayReady-protected content. Revocation should not affect unprotected content or content
protected by other content access technologies. Content owners may require you to upgrade PlayReady
to access their content. If you decline an upgrade, you will not be able to access content that requires the
upgrade.
PATENT PORTFOLIO, WHICH LICENSE IS AVAILABLE FROM MPEG LA, LLC, 6312 S. Fiddlers
PART 2 • English
TABLE OF CONTENTS
1.0 INTRODUCTION 2
1.1 Storage 2
1.2 Equipment Set-up 2
1.3 Accessories 3
2.0 YOUR RECEIVER 3
2.1 Front panel 3
2.2 Rear panel 3
2.3 Remote control 4
2.4 Installing the batteries 4
2.5 Using the remote control 5
3.0 CONNECTIONS 5
3.1 Connecting to your aerial antenna 5
3.2 Connecting to TV 5
3.3 Connecting to digital audio amplifier 6
3.4 Connecting an external USB drive 6
4.0 FIRST INSTALLATION 6
4.1 Turn on the TV set and the receiver 7
4.2 Activation of the receiver in the digital terrestrial TV operator's network 8
5.0 DAILY OPERATIONS 9
5.1 Switching the receiver on and off 9
5.2 Changing channels 9
5.3 Volume adjustment 10
5.4 Viewing the programme information 10
5.5 Check signal level and quality 11
5.6 Selecting audio language 11
5.7 Selecting subtitle language 11
5.8 Viewing the teletext 12
5.9 Usage of external USB devices 12
6.0 MAIN MENU 13
6.1 Channel Organizer 13
6.2 Settings 16
6.3 Tools 20
6.4 Multimedia 22
6.5 Information 24
7.0 TROUBLESHOOTING 25
8.0 TECHNICAL SPECIFICATION 28
English
STRONG declares that this item complies with the basic requirements and other relevant regulations of directives CE 2004/108/EC
and 73/23/EC, RoHS 2002/95/EC
Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance
of products may change. Irdeto is a registered trademark of Irdeto Access BV. Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are registered trademarks of Dolby Laboratories, HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. All
other product names are trademarks or registered trademarks of their respective owners.
© STRONG 2014. All rights reserved.
03 Nov 2014 12:02
1
PART 3 • English
1.0 INTRODUCTION
1.1 Safety Instructions
DO NOT INSTALL YOUR RECEIVER:
In a closed or poorly ventilated cabinet; directly on top of or under any other equipment; on a
surface which might obstruct the ventilation slots.
DO NOT EXPOSE THE RECEIVER OR ITS ACCESSORIES:
To direct sunlight or any other equipment that generates heat; to rain or intense moisture; to
intense vibration and to any shock which may cause permanent damage to your receiver or to any
magnetic objects, such as loudspeakers, transformers, etc.
Do not use a damaged power cord. It may cause a fire or an electrical shock. Do not touch a power
cord with wet hands. It may cause an electric shock.
When the receiver is not used for a long period of time, you should unplug the power cord from the
wall socket.
Do not use alcohol or ammonia based liquids to clean the receiver. If you wish, you may clean
your receiver with a soft lint-free cloth slightly made damp with a mild soap solution, only after
disconnecting from the mains voltage supply. Make sure no foreign objects fall through the
ventilation slots because this could cause fire or an electric shock.
Do not place any objects on top of the receiver because this might prevent proper cooling of the
components inside.
Safety Precautions
Never open the receiver cover. It is dangerous to touch the inside of the receiver due to high voltage
currents and possible electrical hazards and your warranty will be void. Refer all maintenance or
servicing to suitably qualified personnel.
When you are connecting cables, be sure that the receiver is disconnected from the mains supply
voltage. Wait a few seconds after switching off the receiver before you move the receiver or
disconnect any equipment.
It is a necessity that you only use an approved extension and compatible wiring that is suitable
for the electrical power consumption of the installed equipment. Please ensure that the electrical
power supply corresponds with the voltage on the electrical identification plate at the back of the
receiver.
If the receiver does not operate normally, even after strictly following the instructions in this user manual,
it is recommended to consult your local dealer or contact the appropriate service.
1.1 Storage
Your receiver and its accessories are stored and delivered in a packaging designed to protect against
electric shocks and moisture. When unpacking it, make sure that all the parts are included and keep
the packaging away from children. For transporting the receiver from one place to another or if you are
returning it under warranty conditions, make sure to repack the receiver in its original packaging with its
accessories. Failing to comply with such packaging procedures could void your warranty.
1.2 Equipment Set-up
We recommend you consult a professional installer to set up your equipment. Otherwise, please follow
the instructions below:
Refer to the user manual of your TV and your antenna.
Make sure that the 3RCA/HDMI cable and outdoor components are in a good condition and the
3RCA/HDMI connections are well shielded and of good quality.
This manual provides complete instructions for installing and using this receiver. The following symbols
will serve as follow.
WARNING: Indicates warning information.
NOTE: Indicates any other additional important or helpful information.
2
PART 3 • English
MENU: Represents a button on the remote control or the receiver.
(Bold characters)
Move to: Represents a menu item within a window.
(Italic characters)
1.3 Accessories
Receiver – 1 pc.
User Manual – 1 pc.
Remote control (RCU) – 1 pc.
Power adapter – 1 pc.
Cable type 3RCA-3RCA – 1 pc.
Batteries (AAA type) – 2 pcs.
Warning: The batteries should not be recharged, disassembled, electrically short-
circuited, be mixed or used with other types of batteries.
If you plan to use rechargeable batteries instead of batteries, it is recommended to use NiMH battery
type with low self-discharge for long-term operation of the remote control.
2.0 YOUR RECEIVER
2.1 Front panel
Fig. 1
1. Standby button Switches the receiver between Standby (off) and operating mode.
2. Up/Down buttons Switches channels up and down in view mode, navigation around menu.
3. Digital display Indicates current channel number in operating mode. Indicates current time
in standby mode.
4. Remote sensor Receives signals from RCU.
5. Stand-by indicator RED indicates that the receiver is in standby mode. GREEN indicates that the
receiver is in operating mode.
6. USB port (front) Connector for USB storage device from front side.
7. Slot for smart card (right side panel)
It is intended only for the service functions and is not used during the
operation by user.
2.2 Rear panel
Fig. 2
1. USB port (rear) Connector for USB storage device from rear side.
2. ANT IN connector (input)
To connect to your antenna for reception of broadcasted signals.
3. INTERNET connector (RJ45, TP)
To connect your receiver to internet via cable connection.
4. S/PDIF connector (output, coaxial)
To connect your receiver to a digital home theatre, AV receiver or digital
audio amplifier.
5. HDMI connector To connect your receiver to your TV set using an HDMI cable.
6. VІDEO connector (output, yellow)
To connect your receiver to your TV set using corresponding video input in
your TV.
English
3
PART 3 • English
7. AUDІO L/R connector (output, white/red)
To connect your receiver to your TV set using corresponding right and left
8. Power adapter connector To connect power adaptor supplied with the receiver. Please, use only
9. Power ON/OFF switch Allows mechanically connect and disconnect power source to
channels of audio inputs in your TV or stereo system.
original adapter.
receiver.
2.3 Remote control
1. q Switches the receiver between the working and standby modes.
2. ! Enable/disable the audio output of the receiver.
3. 09 In viewing mode: enters channel number, in menu: enters numeric values.
4. TV/R Switches between TV and radio channels.
55 Switches to internet connection mode.
6. FAV Displays the list of favourite channels.
7.
Switches to the previously viewed channel.
8. AUDIO Selects the menu track audio support.
9. Displays information about the current channel and other information
10. EPG Enters the Electronic Programme Guide.
11. pq In viewing mode: switches to the next/previous channel, in menu mode and
12. tu In viewing mode: decreases/increases the volume, in menu mode: for
13. OK In menu mode: to confirm selection.
14. MENU Switches to menu mode (to access the main menu of the receiver) and back
15. Exits the menu, submenu or cancels actions.
16. VOL +/VOL Increases/decreases the volume level.
17. P+/P In viewing mode: switches to the next/previous channel, in menu mode and
18. LIST In viewing mode: displays the channels list.
19. CH +/CH In viewing mode: switches to the next/previous channel.
20. OPT Changes the output video format and for other options settings.
21. TEXT Switches to Videotext mode.
22. SUB Selects a subtitle language (if subtitles are broadcasted).
555 Displays messages from the operator.
24. MULTIMEDIA BUTTONS
For viewing multimedia files, trick modes, creating and viewing recordings.
25. COLORED BUTTONS
Functions depend on the menu context.
banners.
in channel list: moves cursor up and down.
navigation and changing option settings.
to viewing mode.
during list browsing: scrolls pages up and down.
Fig. 3
2.4 Installing the batteries
Open the cover on the remote control unit (RCU) and insert 2 AAA batteries into the compartment.
Correct position of batteries polar diagram shows inside batteries compartment.
1. Open the cover.
2. Insert the batteries.
3. Close the lid.
4
Fig. 4
PART 3 • English
Warning The batteries should not be recharged, disassembled, electrically short-
circuited, be mixed or used with other types of batteries.
2.5 Using the remote control
Fig. 5
To use the remote control point it towards the front of your receiver. The range of the remote control is
up to 7 meters distance to the receiver at an angle of up to ±30 degrees.
Note: Managing the receiver will be limited or not possible if there are obstacles
between the remote control sensor on the front panel of the receiver and
remote control.
Note: Direct sunlight and very bright light reduces the distance of remote control.
3.0 CONNECTIONS
Warning: Please make sure that any connection devices or equipment are
disconnected from their main power before you make connections
between them and your receiver.
3.1 Connecting to your aerial antenna
To receive digital broadcast signals, your receiver has to be connected to a terrestrial indoor or outdoor
antenna. Use the antenna cable to connect the aerial with the ANT IN connector on the back of your
receiver. Please ensure that a properly shielded antenna cable and suitable connectors are used.
English
Fig.
Note If the signals at your location are too weak to receive proper signals with
an indoor antenna, we recommend using an outdoor antenna which can
be pointed towards the transmission tower. Ask your local dealer for more
information.
3.2 Connecting to TV
This receiver can be connected to a TV in one of two ways.
a: With 3RCA-3RCA cable (included).
connect the cable from one side to the outputs of the receiver and to the input connectors of the TV
set. The connection should be done in accordance with the colour-coded connectors.
Fig. 6
5
PART 3 • English
Note For using the receiver with a TV set with this type of connection please
b: With HDMI cable (not included). We recommend connecting your TV set with the receiver using a
good quality HDMI cable. This connection supports the highest possible quality.
Connect one side of the cable to the connector on the receiver and the other side of the cable to the
suitable connector on the TV.
Note For using the receiver with a TV set with this type of connection please
switch the TV set to video mode. For more details please read chapter 4
First installation.
switch the TV set to HDMI mode. For more details please read chapter 4
First installation.
3.3 Connecting to digital audio amplier
Fig. 6
By connecting your receiver to a digital amplifier or home theatre system, you can enjoy the best
possible sound quality and multi-channel audio (depending on broadcast or multimedia file encoding).
Connect your digital audio amplifier or home theatre system with a suitable cable to the S/PDIF
connector on the back of the receiver.
3.4 Connecting an external USB drive
Fig. 7
Make sure the plug-in USB drive consumes less than 500 mA. If your hard drive consumes more than this
value, use an external power supply for the USB drive. If you use a USB flash drive with an external power
source, you must first connect a USB storage device to a power source, then connect the drive to the
receiver.
Note It is recommended to use USB 2.0 storage devices or higher for recording
and play back of TV programs or HD movies.
Note Timeshift/recording and playback only works properly when a fast
USB storage device such as a USB2.0 HDD is connected to the receiver.
Timeshift/recording and playback of HD content requires a sufficient read/
write speed of the used USB storage device.
4.0 FIRST INSTALLATION
This procedure will enable you to enjoy digital broadcasts just within a few minutes.
It is recommended to follow the Installation Guide step by step. It will guide you through the basic
installation and channel searching process.
Note Ensure that all connections are setup properly. In case of difficulties or
6
questions, please ask your local dealer or service for assistance.
Loading...
