Strong SRT 8114 User Manual

Digital Terrestrial HD Receiver SRT 8114

User Manual

Manuel d’utilisation

Manuale Utente

Manual del usuario

Manual do Utilizador

Instrukcja obsługi

Felhasználói kézikönyv

Ръководство на потребителя

Picture similar

HOTLINE

0820 400 150

AT

[e-mail]

€ 0,12/Min. österr. Festnetz

[phone]

BG

[e-mail]

[phone]

CEE

[e-mail]

0180 501 49 91

DE

[e-mail]

€ 0,14/Min. deutsches Festnetz
€ 0,42/Min. max. Mobilfunknetze

[e-mail]

DK

www.strong.tv

Supplied by STRONG & Co, Japan

Represented by

STRONG Ges.m.b.H.

Franz-Josefs-Kai 1

1010 Vienna

Email: [e-mail]

0826 029 928

FR

[e-mail]

€ 0,15 par mn poste fixe en France

199 404 032

IT

[e-mail]

Da rete fissa 24,8 cent. al min.

12,5 cent. scatto alla risposta
Da rete mobile max 49 cent. al min.

15,6 cent. scatto alla risposta

[e-mail]

NL

801 702 017

PL

[e-mail]

[phone]

UA

[e-mail]

Austria

25 Sep 2014 16:32

PART 1

TABLE OF CONTENT

1.0 INTRODUCTION 2

1.1 Safety Instructions 2

1.2 Storage 2

1.3 Equipment Set-up 3

1.4 Accessories 3

1.5 Usage of external USB devices 3

2.0 YOUR RECEIVER 4

2.1 DEFAULT PIN: 1234 4

2.2 Front Panel 4

2.3 Rear Panel 4

2.4 Remote control 4

2.5 Installing the batteries 5

2.6 Using the remote control 5

3.0 CONNECTION 6

3.1 Connecting to a terrestrial antenna 6

3.2 Connecting to TV with HDMI cable 6

3.3 Connecting to TV with SCART cable 6

3.4 Connecting to a Digital Audio Amplifier
with S / PDIF 6

3.5 Connecting to a digital audio amplifier
and TV using HDMI 6

3.6 Connecting to an analogue Audio
Amplifier 7

3.7 Connecting a USB storage device 7

4.0 STARTING UP FOR THE FIRST TIME 7

5.0 QUICK GUIDE TO USING YOUR RECEIVER 8

6.0 OPERATION 8

6.1 Changing channels 8

6.2 Info Banner 9

6.3 Selection of audio language 9

6.4 Teletext 9

6.5 Subtitles 9

6.6 Timeshift 10

6.7 EPG (Electronic Programme Guide) 10

6.8 Instant Recording 10

7.0 MAIN MENU 10

7.1 Edit Channel 11

7.2 Installation 13

7.3 System Setup 13

7.4 Tools 16

7.5 Games 17

7.6 Media 17

8.0 TROUBLESHOOTING 20

9.0 TECHNICAL SPECIFICATIONS 21

English

STRONG declares that this item complies with the basic requirements and other relevant regulations of directives 2004/108/EC and 73/23/EC,
RoHS 2002/95/EC

Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance of products may
change. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are registered trademarks of Dolby
Laboratories. All other product names are trademarks or registered trademarks of their respective owners.

© STRONG 2014. All rights reserved.

1

PART 1

1.0 INTRODUCTION

1.1 Safety Instructions

DO NOT INSTALL YOUR RECEIVER:

In a closed or poorly ventilated cabinet; directly on top of or under any other equipment; on a surface
which might obstruct the ventilation slots.

DO NOT EXPOSE THE RECEIVER OR ITS ACCESSORIES:

 To direct sunlight or any other equipment that generates heat; to rain or intense moisture; to

intense vibration and to any shock which may cause permanent damage to your receiver or to
any magnetic objects, such as loudspeakers, transformers, etc.

 Do not use a damaged power cord. It may cause a fire or an electric shock. Do not touch a

power cord with wet hands. It may cause an electric shock.

 When the receiver is not used for a long period of time, you should unplug the power cord

from the wall socket.

 Do not use alcohol or ammonia based liquids to clean the receiver. If you wish, you may clean

your receiver with a soft lint-free cloth slightly made damp with a mild soap solution, and only
after disconnecting from the mains voltage supply. Make sure no foreign objects fall through
the ventilation slots because this could cause fire or an electric shock.

 Do not place any objects on top of the receiver because this might prevent proper cooling of

the components inside.

Safety Precautions

 Never try to open the receiver. It is dangerous to touch the inside of the receiver due to high

voltages and possible electrical hazards. Opening the receiver will void the warranty of the
product. Refer all maintenance or servicing to suitably qualified personnel.

 When you are connecting cables, be sure that the receiver is disconnected from the mains

supply voltage. Wait a few seconds after switching off the receiver before you move the
receiver or disconnect any equipment.

 It is a necessity that you only use an approved extension and compatible wiring that is suitable

for the electrical power consumption of the installed equipment. Please ensure that the
electrical power supply corresponds with the voltage on the electrical identification plate at the

back of the receiver.
If the receiver does not operate normally even after strictly following the instructions in the user
manual it is recommended to consult your dealer or the appropriate service for your country.

1.2 Storage

Your receiver and its accessories are stored and delivered in a packaging designed to protect against
electric shocks and moisture. When unpacking it, make sure that all the parts are included and keep
the packaging away from children. When transporting the receiver from one place to another or
if you are returning it under warranty conditions, make sure to repack the receiver in its original
packaging with its accessories. Failing to comply with such packaging procedures could damage the
product and void your warranty.

2

PART 1

1.3 Equipment Set-up

We recommend you consult a professional installer to set up your equipment. Otherwise, please
follow the instructions below:

 Refer to the user manual of your TV and antenna.
 Make sure that the HDMI cable and outdoor components are in a good condition.
 If you use TV SCART connection, use then well shielded SCART cable.

This manual provides complete instructions for installing and using this receiver. The following
symbols will serve as follow.

Warning Indicates warning information.
Tips Indicates any other additional important or helpful information.
MENU Represents a button on the remote control or the receiver. (Bold characters)

Move to Represents a menu item within a window. (Italic characters)

1.4 Accessories

 Quick installation guide
 1 remote control
 2x batteries (AAA type)

WARNING: The batteries should not be recharged, disassembled, electrically short-

1.5 Usage of external USB devices

 It is recommended to use USB 2.0 storage devices or higher. If your device is not compatible

to USB 2.0 specifications, recording, playback and other multimedia functions of the receiver

might not work properly.

 To ensure best performance of your USB storage device please format it via your receiver

(through the menu “Media”) to FAT32 system. Other file systems are not supported by the

receiver. However, it is possible to use already NTFS formatted disks.

 STRONG cannot guarantee compatibility with all types of USB storage devices.
 If you are going to use external USB HDDs (Hard Disk Drives), please consider that power

specifications may exceed the supported output of your receiver (max.5 V/800 mA). If so, please

connect your USB HDD to an according external power adapter.

 It is advised not to store important information on USB storage devices used with the receiver.

Always make backups of data on your USB storage device before using it with this receiver.

STRONG will not take responsibility for any loss of information or circumstances caused by loss

of information.

circuited, be mixed or used with other types of batteries. If rechargeable
accumulators instead of batteries are going to be used (e.g. NiMH), we
recommend using types with low self-discharge to ensure long time
operation of your remote control.

English

3

2.0 YOUR RECEIVER

2.1 DEFAULT PIN: 1234

2.2 Front Panel

1. IR sensor Point your remote control towards this sensor.

2. Mode indicator RED indicates that the receiver is in STANDBY mode.

3. USB Connector for USB storage devices.

2.3 Rear Panel

1. ANT IN To connect to your antenna for reception of broadcasted signals.

2. ANT OUT To connect the terrestrial antenna signal to your TV set. This

3. S / PDIF Coaxial: To connect your receiver to a digital home theatre, AV receiver or

4. HDMI To connect your receiver with your TV set using an HDMI cable.

5. TV SCART To connect your receiver with your TV set using a SCART cable.

6. Audio L/R To connect your receiver to an analogue audio amplifier.

7. Power cord Your receiver requires a supply voltage of 220 – 240 V AC

2.4 Remote control

1. q Switches the receiver On/Standby

2. Mutes all audio outputs of the receiver

3. PG+/PG- Page up/down in all list modes

4. DTV/VCR No function

5. INFO Opens the current channel information; 2x opens the current

6. VOL+/VOL- Increases/decreases the volume level

7. MENU Opens the main menu, in a menu you will get one step back

8. EXIT Exits from the menu or sub-menu

9. pq Menu Off: Change channel to previous/next.

10. tu Menu Off: Increases/decreases the volume level.

GREEN indicates that the receiver is in OPERATING mode.

connection will allow you to watch digital terrestrial programmes
depending on the tuner of your TV and local broadcast
conditions

digital audio amplifier.

(Auto-selectable), 50/60Hz ±5%. Please ensure the local power
specification meets these requirements before connecting your
receiver to the wall outlet.

event information and 3x the signal information

Menu On: Moves the cursor up/down.

Menu On: Change settings for specific menus

PART 1

Fig. 1

Fig. 2

Fig. 3

4
