2.0 Your Receiver
2.1 Front Panel
(Please see inside cover Figure 1)
1. Power Button
Turns the receiver ON/OFF.
2. Stand-BY/ ON/ SIGNAL (3 LEDs)
The red LED is the “stand-by” indicator. The green LED is the “Power On” indicator.
The orange LED lights up once you correctly receive a satellite signal (signal locked).
3. UP/DOWN Buttons
Move the cursor UP/DOWN in Menu state. Changes the channels UP/DOWN in no menu state.
4. LED Display
This 4-digit LED panel indicates the time or the program number.
2.2 Rear Panel (Please see inside cover Figure 2)
1. SAT IN (LNB IN)
Connect the I.F. digital signal from your LNB of your satellite dish to this connector.
2. SAT OUT
Gives you the possibility to connect an extra receiver (analogue or digital).
3. AUDIO Right (Red RCA) and Left (White RCA)
These connectors give you the possibility to connect the audio signal to an external amplifier or to the audio input of your TV.
4. VIDEO (Yellow RCA)
This connector has a constant video signal for additional VCR-connections
5. TV Scart Connector
Use this connector to connect your receiver to your TV using a scart cable.
6. VIDEO Scart Connector
Use this connector to connect your receiver to your video recorder using a scart cable. Your video signal will now be looped
through to your TV.
7. IR SENSOR
Use this connector to connect an external remote eye if you wish to store your receiver in a place where the IR on your
receiver cannot communicate with the remote. For example, if you wish to put your receiver in a closed environment such as
a well ventilated closet, then this accessory will be useful because it can allow the remote control to control the receiver
through the remote eye.
8. RS 232 Serial Port
This serial port can be used to connect your PC to your receiver, and enables you to download new versions of software into
your receiver. Detailed information about downloading software into your receiver can be found on our website
(www.strongsat.com).
Note
: It is recommended to ONLY use the original software provided via our website. Loading other versions of software not
adapted to your model number can cause severe damage to your receiver, and will not be covered by the warranty.
9. Input Antenna
RF Modulator (female part). If you have cable TV or if you have an outdoor antenna, then you can connect the RF cable
coming from the antenna or wall connector to this ANT input. If you use a scart cable to connect the receiver to your TV,
the additional antenna can be put directly into your TV.
10. To TV
RF Modulator (male part). If you do not use a scart cable to connect your receiver to your TV, or if you have connected a
cable to the ANT input, you will have to use this connector to connect the receiver to your TV by using a coaxial cable.
11. S/PDIF
Use this coaxial output to connect your receiver to the input of your digital audio amplifier.
12. Power Cord
Your receiver requires a mains voltage supply of 90~240V AC (Auto-selectable), 50~60Hz+/-5%. Make sure to check the
power specification of the wall outlet before connecting your receiver to the main power.
