Page 1
Owner’s Manual
Infrared Quartz Heater
NOTE
For Indoor Use Only
120V AC 15 AMP Dedicated Circuit
SP-HI1200BP
WARNING! To Reduce The Risk Of Injury, User
Must Read And Understand Instruction Manual.
www.steele-products.com
Page 2
Introduction
This heater utilizes the latest infrared heat technology. This
portable heater provides a safe, convenient, clean, and economical
way to distribute heat throughout your home or business without
producing deadly fumes or monoxide gases. Our heating system
produces therapeutic infrared heat that can potentially relieve symptoms of cardiovascular conditions and inflammatory diseases. Infrared heat technology can produce rays that are safe and highly
beneficial to our bodies.
This portable heater is constructed with infrared quartz Bulbs. Each
infrared quartz bulb is rated at 750W. The Infrared quartz bulbs are
constructed with stainless steel thermal conducing housing. An AC
cross flow fan pushes air over these Infrared quartz bulbs. Cross flow
fans create a wide flow of air using a cylindrical-shaped impeller. Air
is drawn inside the portable heater, flows along the circumference of
the chamber and over the infrared quartz bulbs, and is blown out
laterally creating a uniform flow of warm air.
Heater Specifications
Heater Model: SPHI1200BP
Power: 1500W
Voltage:120V/60HZ
Heater Size: 13” x 10” x 18.1”
Page 1
Page 3
USE CAUTION
• Heater must be operated by an adult. Keep heater out of the reach
of children.
• Only operate the heater when it is on the floor.
• Never plug heater cord into a loose fitting or broken receptacle.
• Never alter the heater’s design or operation.
• Do not operate the heater if it has a damaged cord or plug.
• Do not operate the heater if there are signs of malfunction.
• Keep combustible materials such as furniture, pillows and other
bedding materials, papers, clothing, and curtains at least three feet
away from all sides of the heater during operation.
• Always unplug heater when not in use.
• Do not use the heater outdoors.
• Do not run heater cord under carpet.
• Do not use the heater in bathrooms, laundry rooms or similar indoor
locations.
• Turn OFF the heater before unplugging.
• Do not insert any foreign object in the heater.
• Do not locate heater, when in use below a receptacle.
Page 2
Page 4
STARTING YOUR HEATER
1. Open the portable heater package and remove the heater by
sliding it from the box. Make sure there is no obvious damages that
may have occurred during shipment.
2. Plug the power cord directly into a conventional 120V 15 A Outlet.
3. Press the red button on the upper left side of the heater to turn the
heater ON.
4. Give it about 30 seconds before the fan starts working and warm
air starts to flow out.
TURNING OFF YOUR HEATER
1. Press the red button on the upper left side of the heater to turn the
heater OFF.
2. The fan will remain on for 30 seconds then it will turn OFF.
Page 3
Page 5
WARRANTY
Warranty information
Warranty period is 12 months from the purchased date.
This warranty is void if the portable heater has been altered, misused,
or has been repaired by an authorized dealer, or it is not installed
according to stated instructions.
You will be charged a minimum repair cost in the following cases:
When warranty period has expired.
For mishandling the heater.
Not following manual instructions.
Unauthorized repair.
The warranty covers only manufacturing defects and does not cover
any damage resulting from mishandling of the product by the owner.
For warranty info or help please call: 888-896-6881
Page 4
