Owner’s Manual
Instructions For Operation, Safety And Maintenance
Before Use
Please read the following information carefully. It contains important instructions
concerning the operation, safety and maintenance of the heater. Keep these instructions
for future reference.
Safety Instructions
When using an electrical appliance, the following basic safety precautions should always
be followed to reduce the risk of fire, electric shock or personal injury.
This heater is hot when in use. To avoid burns, do not let any part of the body touch hot
surfaces.
Keep combustible material, such as furniture, pillows, bedding, paper, clothes, and
curtains at least 3 feet (0.9m) from the front of the heater and keep them away from the
sides and rear.
Extreme caution is necessary when the heater is used by or near children or
handicapped individuals and whenever any heater is left operating and unattended.
Always unplug heater when not in use.
Do not operate any heater with a damaged cord or plug or after the heater malfunctions,
or has been dropped or damaged in any manner. Return heater to authorized service
facility for examination, electrical or mechanical adjustment, or repair.
The apparatus must not be stored or used outdoors.
This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations. Never locate heater where it may fall into a bathtub or near water.
Do not run cord under carpeting. Do not cover cord with throw rugs or runners.
Arrange cord away from traffic area and where it will not be tripped over.
To disconnect heater, turn controls to “OFF”, then remove plug from outlet.
Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use
on soft surfaces, like a bed, where openings may become blocked.
If the heater is used in a location that is not level, the tip over switch may be activated,
the heater will not operate or may fall over.
Always place the heater on a solid level surface.
A heater has hot sparking parts inside. Do not use it in areas where gasoline, paint, or
flammable liquids are used or stored.
Use this heater only as described in this manual. Any other use is not recommended
by the manufactured and may cause fire, electric shock, or personal injury.
Avoid the use of an extension cord. The extension cord may overheat and cause a fire.
However, if you have to use an extension cord, we recommend No. 14AWG, minimum
size and rated not less than 1875 watts.
2
Page 3
Owner’s Manual
Unpacking And Setup
Carefully remove the heater from the shipping carton and inspect for damage. It is
recommended that you retain the packaging in which the apparatus was delivered as
proper storage for removal purposes.
Main Parts:
1. Thermostat
2. Selection Switch
3. Power light
3
2
1
3
Page 4
Owner’s Manual
Heater Switch Functions
Functions are selected by turning rotary switch to the desired position.
Provides 1500 watts of heat output
Provides 750 watts of heat output operation.
Fan only operation for cooling comfort.
Will power the unit off.
SAVE THESE IMPORTANT INSTRUCTIONS FOR EASY REFERENCE.
Electrical Ratings
This product is rated 12.5 amps (1500W) at 120V, 60Hz.
Operation
• Place the heater on a firm, level surface free from obstructions, and at least 3ft.
(0.9m) away from any wall or combustible material.
• With the selection switch in the position, plug the heater into a polarized
120V outlet.
• Turn the thermostat control fully clockwise to the max setting.
• To turn the heater on, selection switch while turning it clockwise to the desired
position ( for 1500W, or for 750W). The power light will illuminate.
• When the room reaches a comfortable temperature, slowly turn the thermostat
control counter-clockwise until the heater goes off. This is the point at which the
thermostat setting equals the room temperature. At this setting, the thermostat will
automatically turn the heater on and off to maintain this selected temperature.
• Turn the selection switch to and unplug the heater when you are finished using it.
If Your Heater Fails To Operate:
• Be sure it is plugged in and that the electrical outlet is working.
• Check for any obstruction. If you find an obstruction turn the heater unplug the
heater and wait at least ten minutes for it to cool. Carefully remove the plug from the
socket and have the appliance serviced by authorized service personnel only.
• Check that the thermostat is not set too low. With the selection switch set a heat
setting, turn the thermostat up (clockwise) until the heater restarts.
4
Page 5
Owner’s Manual
Cleaning And Storage
We recommend that the heater be cleaned at least once a month and before off season
storage.
• Turn the heater and unplug it. Allow it to cool.
• Use a dry cloth to clean the external surfaces of heater.
DO NOT USE WATER, WAX, POLISH OR ANY CHEMICAL SOLUTION.
• Clean your heater using the above mentioned steps, then pack the heater in its original
container and store it in a cool dry place.
• This heater does not disassemble.
• The motor is factory lubricated for life, and will require no further lubrication.
Limited Warranty
This product is warranted against defects in materials and workmanship for 1 year from
the date of purchase. Within 1-year warranty period the item will be replaced or your
money will be refunded at the place of purchased upon presentation of sales receipt or
other proof of purchase. This warranty does not apply to items subjected to misuse or
accidental damage.
