ST STM32F101RF, STM32F101VF, STM32F101ZF, STM32F101RG, STM32F101VG User Manual

...

Download

XL-density access line, ARM-based 32-bit MCU with 768 KB

LQFP144

20 × 2

0 mm

LQFP64

× 10 mm

LQFP100

× 14 mm

to 1 MB Flash, 15 timers, 1 ADC and 10 communication interfaces

Features

■ Core: ARM 32-bit Cortex™-M3 CPU with MPU

– 36 MHz maximum frequency,

1.25 DMIPS/MHz (Dhrystone 2.1) performance

– Single-cycle multiplication and hardware

division

■ Memories

– 768 Kbytes to 1 Mbyte of Flash memory

(dual bank with read-while-write capability) – 80 Kbytes of SRAM – Flexible static memory controller with 4

Chip Select. Supports Compact Flash,

SRAM, PSRAM, NOR and NAND

memories – LCD parallel interface, 8080/6800 modes

■ Clock, reset and supply management

– 2.0 to 3.6 V application supply and I/Os – POR, PDR, and programmable voltage

detector (PVD) – 4-to-16 MHz crystal oscillator – Internal 8 MHz factory-trimmed RC – Internal 40 kHz RC with calibration

capability – 32 kHz oscillator for RTC with calibration

■ Low power

– Sleep, Stop and Standby modes –V

■ 1 x 12-bit, 1 µs A/D converters (up to 16

channels) – Conversion range: 0 to 3.6 V – Temperature sensor

■ 2 × 12-bit D/A converters

■ DMA

– 12-channel DMA controller – Peripherals supported: timers, ADC, DAC,

■ Up to 112 fast I/O ports

supply for RTC and backup registers

BAT

SPIs, I

Cs and USARTs

STM32F101xF

STM32F101xG

Preliminary data

– 51/80/112 I/Os, all mappable on 16

external interrupt vectors and almost all 5 V-tolerant

■ Debug mode

– Serial wire debug (SWD) & JTAG interfaces – Cortex-M3 Embedded Trace Macrocell™

■ Up to 15 timers

– Up to ten 16-bit timers, with up to 4

IC/OC/PWM or pulse counters

– 2 × watchdog timers (Independent and

Window) – SysTick timer: a 24-bit downcounter – 2 × 16-bit basic timers to drive the DAC

■ Up to 10 communication interfaces

– Up to 2 x I – Up to 5 USARTs (ISO 7816 interface, LIN,

IrDA capability, modem control) – Up to 3 SPIs (18 Mbit/s)

■ CRC calculation unit, 96-bit unique ID

■ ECOPACK

Table 1. Device summary

Reference Part number

STM32F101xF

STM32F101xG

C interfaces (SMBus/PMBus)

packages

STM32F101RF STM32F101VF STM32F101ZF

STM32F101RG STM32F101VG STM32F101ZG

November 2010 Doc ID 17143 Rev 2 1/108
