SafeGuard PortAuditor 3.20
User help
Document date: March 2010
SafeGuard® PortAudtior 3.20, user help
Important Notice
This user help is delivered subject to the following conditions and restrictions:
This user help contains proprietary information belonging to Sophos. Such information is
supplied solely for the purpose of assisting explicitly and properly authorized SafeGuard
PortAuditor users.
No part of its contents may be used for any other purpose, disclosed to any person or firm
or reproduced by any means, electronic or mechanical, without the express prior written
permission of Sophos.
The text and graphics are for the purpose of illustration and reference only.
The specifications on which they are based are subject to change without notice.
The software described in this user help is furnished under a license. The software may be
used or copied only in accordance with the terms of that agreement.
Information in this help is subject to change without notice. Corporate and individual
names and data used in examples herein are fictitious unless otherwise noted.
The information in this document is provided in good faith but without any representation
or warranty whatsoever, whether it is accurate, or complete or otherwise and on express
understanding that Sophos shall have no liability whatsoever to other parties in any way
arising from or relating to the information or its use.
SafeGuard PortProtector and SafeGuard PortAuditor are OEM versions of Safend Protector
and Safend Auditor from Safend. Therefore some screenshots throughout this manual may
still contain the Safend branding but mean the same as within the SafeGuard OEM version.
© Copyright 2010 S
ophos. All rights reserved.
Ot
her company and brand products and service names are trademarks or registered trademarks
of their respective holders.
2
SafeGuard
®
PortAuditor 3.20, user help
About This User Help
This user help is comprised of the following chapters:
Chapter 1, Introducing SafeGuard PortAuditor, page 5, introduces the SafeGuard
PortAuditor solution. It describes its features and benefits, in particular the new features.
Chapter 2, Installing SafeGuard PortAuditor, page 8, describes the system requirements for
installing the product and the installation process.
Chapter 3, Auditing, page 13, describes how to perform audit scans, along with all the filters
and settings available. Also described are the options for viewing scan results and
explanations about the various fields in the reports.
Appendix A, Acquiring a License Key, page 28, describes the steps you need to take in order
to purchase and install an update for the product.
Appendix B, Command Line Automation, page 30, describes how to use command line
switches to automatically configure and run SafeGuard PortAuditor scans.
3
SafeGuard® PortAudtior 3.20, user help
Contents
1 Introducing SafeGuard PortAuditor .......................................................................................... 5
2 Installing SafeGuard PortAuditor .............................................................................................. 8
3 Auditing ...................................................................................................................................... 13
4 Appendix A - Acquiring a License Key ..................................................................................... 28
5 Appendix B - Command Line Automation .............................................................................. 30
4
SafeGuard
®
PortAuditor 3.20, user help
1 Introducing SafeGuard PortAuditor
About This Chapter
This chapter introduces the SafeGuard PortAuditor solution, describes how it works and
outlines the main features of the product. It contains the following sections:
The Current Situation, page 6, describes the threat of information leakage that has left a
gaping hole in the data security of today's organizations.
The SafeGuard PortAuditor Solution, page 6, describes SafeGuard PortAuditor's solution
for providing enterprise-wide visibility on the usage of physical and wireless ports on
endpoints.
Main Features, page 7, describes the product's main features, in particular the new features
added in this version.
5
SafeGuard® PortAudtior 3.20, user help
1.1 The Need
Enterprise networks are currently characterized by a proliferation of easily accessible computer
ports, such as USB, FireWire and PCMCIA. In addition, a variety of communication adapters
(such as Bluetooth, IrDA and WiFi) and device types (such as storage devices, printers, digital
cameras, smart phones and PDAs) all enable effortless access to endpoints using these ports and
devices.
These devices enable optimal accessibility and productivity, but they leave endpoints wide open
to infiltration. With the amount of corporate data residing on endpoints estimated at over 60%,
endpoints may be the most valuable, and vulnerable, part of the enterprise network.
At this moment dozens of devices may be connected to your network. Consider the following
questions:
Do you know what is connected?
Can you identify these devices?
Are they permitted or are they trespassing into your company’s integrity?
Are you equipped to locate the security breach and identify the intruder?
1.2 The SafeGuard PortAuditor Solution
With SafeGuard PortAuditor you can immediately begin capturing critical data that provides
you with instant answers to the 'who and what' regarding USB, FireWire and PCMCIA ports in
your organization. It also helps you recognize which WiFi networks your endpoints have
connected to.
SafeGuard PortAuditor is a non-intrusive, clientless software solution that captures the critical
data that you need from each port. SafeGuard PortAuditor creates reports about devices
currently
convenience, SafeGuard PortAuditor can export these reports to MS Excel files, pre-configured
with the most commonly used queries.
connected to your network, as well as those previously connected. As an added
6
SafeGuard
®
PortAuditor 3.20, user help
1.3 Main Features
SafeGuard PortAuditor includes the following main features:
A Clientless Solution – with no administrative commitment, you can run it now and receive
answers in a matter of minutes.
Run the audit on your entire network or on selected computers or groups only.
Multiple scan protocols allow easy operation in various environments (SetupDI and WMI).
Scan for all types of devices, on both internal and external ports including WiFi networks.
Enables reliable and precise device identification.
Various audit filters allowing better focus on desirable types of activity.
Immediate HTML and MS Excel reports.
Fully complements the Sophos Group policy enforcement product – SafeGuard
PortProtector.
Easy-to-use interface - following installation, auditing your network is only one step away:
just choose the computers to be queried, and start the audit.
7
SafeGuard® PortAudtior 3.20, user help
2 Installing SafeGuard PortAuditor
About This Chapter
This chapter first describes the process of installing the product on your computer:
System Requirements, page 9, describes supported operating systems and installation
prerequisite software.
Installing SafeGuard PortAuditor, page 10, describes the installation process.
Uninstalling SafeGuard PortAuditor, page 12, describes how to remove the product from
your computer.
8
SafeGuard
2.1 System Requirements
Operation requirements:
®
PortAuditor 3.20, user help
Client OS
Windows 2000 Professional (Service Pack 3-4)
Windows 2000 Server (Service Pack 3-4)
Windows 2000 Advanced Server (Service Pack 3-4)
Windows XP Professional (Service Pack 0-2)
Windows 2003 Server (Service Pack 0-1, R2)
Windows Vista
Domain OS
Windows 2000 Server (Service Pack 0-4)
Windows 2000 Advanced Server (Service Pack 0-4)
Windows 2003 Server (Service Pack 0-1, R2)
SafeGuard PortAuditor supports an Active Domain
based scan
Credentials Credentials should allow access to the registry data on all
target computers (typically Domain Administrator
privileges)
Report Viewing Requirements:
Software
Internet Explorer version 6.0 and up
For viewing reports in MS Excel - Microsoft Excel
version 2003 and up
9
SafeGuard® PortAudtior 3.20, user help
2.2 Installing SafeGuard PortAuditor
To install SafeGuard PortAuditor:
1 Locate the ’SafeGuardAuditor.msi’ file on the SafeGuard PortAuditor CD.
2 Double-click it to install the SafeGuard PortAuditor on the local computer. The Welcome
window opens:
3 In the Welcome window, click Next. The License Agreement window opens.
10
SafeGuard
®
PortAuditor 3.20, user help
4 Check the license agreement check box and click Next. The Destination Folder window
appears:
5 If you wish to change the destination folder, click Change and select a folder.
6 Click Next. The Ready to Install window opens:
7 If you wish, check the Create Desktop Icon checkbox.
11
SafeGuard® PortAudtior 3.20, user help
8 Click Install to begin the installation. A progress bar is displayed until the installation
process is completed, at which point the InstallShield Wizard Completed window opens.
9 You may check or uncheck the Launch SafeGuard PortAuditor checkbox, then click Finish
to complete the installation.
2.2.1 Registration
Depending on how you obtained your copy, the Auditor installation is valid for 30 days or 5
uses before registration. After 30 days/5 uses, a registration is required.
To acquire a license key, please contact your local reseller or contact us at
Refer to Appendix A, page 28 to learn about how to acquire a license key.
sales@sophos.com.
2.3 Uninstalling SafeGuard PortAuditor
In order to uninstall SafeGuard PortAuditor, you can either select Uninstall SafeGuard
PortAuditor from your computers Start menu Programs, use Add or Remove Programs in
your Control Panel or double-click the SafeGuardAuditor.msi file on the CD.
To complete the uninstall procedure follow the instructions in the window that opens.
12
