Sony SNC-VM630-R User Manual

A-EN2-100-13 (2)

Network Camera

User’s Guide

Before operating the unit, please read this manual thoroughly and retain it for future reference.

Software Version 2.1

SNC-VB635/VB630/VB600/VB600B SNC-VM630/VM600/VM600B/VM631/VM601/VM601B/

VM632R/VM602R SNC-EB630/EB630B/EB600/EB600B/EB632R/EB602R SNC-EM630/EM600/EM631/EM601/EM632R/EM602R SNC-XM637/XM636/XM632 SNC-CX600W/CX600

Table of Contents

Overview

Features .................................................................. 4

How to Use This User’s Guide .............................. 5

System Requirements ............................................ 5

Function Chart ...................................................... 6

Accessing the Camera Using the Web

Browser ................................................................... 7

Basic Configuration by the Administrator ......... 9

Precautions for Preventing Access to the Camera

by an Unintended Third Party ........................... 10

How to set up ................................................... 10

Operating the Camera

Administrator and User ...................................... 11

Logging in to System ........................................... 12

Logging in as a user ......................................... 12

About Viewers .................................................. 12

Configuration of Live Viewer ............................. 13

Main menu ....................................................... 13

Control panel section ....................................... 13

Monitor image .................................................. 15

Plug-in free viewer ........................................... 15

Using Solid PTZ function ................................ 15

Controlling via the control panel (Operation

common to Area zoom mode and Vector

dragging mode) .............................................. 16

Panning and tilting by clicking the monitor image

(Area zoom mode only) ................................. 16

Panning, tilting and zooming by specifying the

area (Area zoom mode only) .......................... 16

Panning and tilting by dragging the screen (Vector

dragging mode only) ...................................... 17

Using pan/tilt/zoom operations with the displayed

control bar (PTZ Control bar only) ................ 17

Switching Transmission Mode ........................... 17

Playback viewer ................................................... 18

Control panel section ....................................... 18

Monitor image .................................................. 20

Administrating the Camera

Basic Operations of the Administrator

Menu ..................................................................... 21

How to set up the Administrator menu ............ 21

Configuration of the Administrator menu ........ 21

Configuring the System — System Menu ......... 22

Information Tab ................................................ 22

Date & time Tab ................................................22

Installation Tab .................................................23

Initialize Tab .....................................................24

System log Tab .................................................25

Access log Tab ..................................................25

Setting the Camera Image and Audio — Video / Audio Menu Setting the Camera Image

— Video Menu ......................................................25

Picture Tab ........................................................26

Focus Tab — Adjusting the Focus ....................27

Focus / Zoom Tab — Adjusting the

focus/zoom ......................................................28

Video codec Tab ...............................................28

Audio Tab .........................................................30

Superimpose Tab ..............................................30

Day/Night Tab ..................................................31

Privacy masking Tab .........................................32

Streaming Tab ...................................................33

Configuring the Network — Network Menu .....35

Network Tab .....................................................35

Wi-Fi Tab ..........................................................37

Wi-Fi network connection check ......................37

Manual setting of a Wi-Fi network ...................37

WPS settings .....................................................38

Connection status ..............................................38

QoS Tab ............................................................39

Setting the Security — Security Menu ...............41

User Tab ............................................................41

Access limit Tab ...............................................41

SSL Tab ............................................................42

How to install the CA certificate ......................45

To remove an installed CA certificate ..............46

802.1X Tab .......................................................47

System configuration of 802.1X network ........48

Referer check tab ..............................................49

Setting the PTZ control — PTZ control

Menu .....................................................................50

Solid PTZ Tab ...................................................50

Serial Tab ..........................................................50

Setting the Sensor input/Camera tampering detection/Motion detection — Action input

Menu .....................................................................51

Event condition Tab ..........................................52

Sensor input Tab — Set the sensor input 1/2 ....52

Camera tampering detection Tab — Set the

camera tampering detection ............................53

Motion detection Tab — Set the motion/VMF

detection ..........................................................53

What is VMF ....................................................53

Setting items for motion detection ....................54

VMF settings ....................................................55

Face detection Tab — Set the face detection ....58

Table of Contents

Network disconnection Tab — Monitoring the

connection of a specified IP address .............. 59

Setting the Action output — Action output

Menu ..................................................................... 59

Execution Condition Tab .................................. 59

Mail Transfer Tab — Setting the e-Mail (SMTP)

Function .......................................................... 60

Alarm output Tab —

output .............................................................. 62

Edge Storage Tab — Setting the Edge Storage

movie and still image function ....................... 62

Voice alert Tab .................................................. 64

HTTP alarm notification Tab ........................... 65

FTP still image sending Tab ............................. 65

White LED tab ................................................. 67

Setting the Schedule — Schedule Menu ............ 68

Schedule Tab .................................................... 68

Setting the CLOUD service — CLOUD

Menu ..................................................................... 69

Setting Tab ........................................................ 69

Setting the Alarm

Others

Glossary ................................................................ 70

Index ..................................................................... 72

Table of Contents

Overview

Features

• High-quality Full HD (1080P) real-time monitoring,

up to 60 fps. (SNC-VB635/VB630/VM630/VM631/ VM632R)

• High-quality Full HD (1080P) real-time monitoring,

up to 30 fps. (SNC-XM637/XM636/XM632)

• High-quality SXGA (1280 × 1024) live images from

camera can be monitored at a maximum frame rate of 60 fps. (SNC-VB635/VB630/VB600/VM630/ VM600/VM631/VM601/VM632R/VM602R)

• High-quality HD (720P) real-time monitoring, up to

30 fps. (SNC-CX600W/CX600)

• Exmor CMOS sensor enables high-quality images for

streaming.

• Wide dynamic range (View-DR) and Visibility

Enhancer enable clearer images for streaming in the high contrast environment.

• NR (XDNR) enables clearer images for streaming in

the low lightness environment.

• Two video compression modes (video codecs) JPEG/

H.264 are supported.

• The maximum triple codec mode is available.

• Easy Focus enables easier focus adjustment when it is

installed. (Except SNC-EB630B/EB600B/XM637/ XM636/XM632/CX600W/CX600)

• “Edge Storage” for recording of video or audio signal

based on alarm detection (such as network block), and same protocol real-time image streaming. (SNCVB635/VB630/VB600/VB600B/VM630/VM600/ VM600B/VM631/VM601/VM632R/VM602R/ XM637/XM636/XM632)

• Motion detection, passive infrared motion sensor

(SNC-CX600W/CX600) and camera tampering detection functions.

• Up to 20 users (SNC-CX600W/CX600: five users)

can view images from one camera at the same time.

• Date/time can be superimposed on the image.

• PoE (Power over Ethernet) compliant. (except SNC-

CX600W)

• The recorded movie in the memory card can be

played, saved, or deleted by using the browser. (SNCVB635/VB630/VB600/VB600B/VM630/VM600/ VM600B/VM631/VM601/VM601B/VM632R/ VM602R/XM637/XM636/XM632/CX600W/ CX600)

• The camera image can be sent by using Wi-Fi. (SNC-

CX600W)

NOTICE TO USERS

© 2012 Sony Corporation. All rights reserved. This manual or the software described herein, in whole or in part, may not be reproduced, translated or reduced to any machine readable form without prior written approval from Sony Corporation.

SONY CORPORATION PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE SOFTWARE OR SUCH OTHER INFORMATION. IN NO EVENT SHALL SONY CORPORATION BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.

Sony Corporation reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement.

• “IPELA” and are trademarks of Sony Corporation.

• is trademark of Sony Corporation.

• “Exmor” and are trademarks of Sony Corporation.

• Microsoft, Windows, Internet Explorer and Microsoft DirectX are registered trademarks of Microsoft Corporation in the United States and/or other countries.

• Java Script is a trademark of Sun Microsystems, Inc. in the United States and other countries.

• Intel Core is a registered trademark of Intel Corporation or its subsidiaries in the United States and other countries.

• Adobe, Adobe Reader and Adobe Flash are trademarks of Adobe Systems Incorporated in the United States and/or other countries.

• SD and microSD are trademarks of SD-3C and LLC.

All other company and product names are trademarks or registered trademarks of the respective companies or their respective makers.

Features

How to Use This User’s

System Requirements

Guide

This User’s Guide explains how to operate the Network Camera from a computer. The User’s Guide is designed to be read on the computer display. This section gives tips on making the most of the User’s Guide. Read it before you operate the camera.

Jumping to a related page

When you read the User’s Guide on the computer display, you can click on a sentence to jump to a related page.

Software display examples

Note that the displays shown in the User’s Guide are explanatory examples. Some displays may be different from the ones that appear in actual use. The illustrations of the camera and menu display in the User’s Guide show the SNC-VB600 as an example.

Printing the User’s Guide

Depending on your system, certain displays or illustrations in the User’s Guide, when printed out, may differ from those that appear on your screen.

Installation Manual (printed matter)

The supplied Installation Manual describes the names and functions of parts and controls of the Network Camera, connection examples, and how to set up the camera. Be sure to read the Installation Manual before hand.

The following computer environment is necessary for the computer to display images and the controls of the camera. (Apr 2014)

Common

Microsoft Windows XP, Windows Vista (32-bit version only), Windows 7 (32-bit version, 64-bit version), Windows 8 Pro (32-bit version, 64-bit version)*, Windows 8.1 Pro (32-bit version, 64-bit version)*

Authorized editions: Windows XP: Professional Windows Vista: Ultimate, Business Windows 7: Ultimate, Professional Windows 8: Pro Windows 8.1: Pro

Microsoft DirectX 9.0c or higher

Web Browser

Windows Internet Explorer Ver. 7.0, Ver. 8.0, Ver. 9.0, Ver. 10.0*, Ver.11.0* Firefox Ver.19.0 Safari Ver.5.1 Google Chrome Ver.25.0

CPU

Intel Core i7, 2.8 GHz or higher Intel Core2 Duo, 2.13 GHz or higher (SNC-CX600W/ CX600)

Memory

2 GB or more

Overview

Display

1600 × 1200 pixels or higher

* In case of Windows 8 or Windows 8.1, use the Internet Explorer desktop user interface (desktop UI) edition.

How to Use This User’s Guide / System Requirements

Function Chart

Overview

Maximum

Model name

SNC-VB635 Full HD z 22zz– z

SNC-VB630 Full HD z 22zz––

SNC-VB600 HD z 22zz––

SNC-VB600B HD – 2 2 zz ––

SNC-VM630 Full HD z 22zz––

SNC-VM600 HD z 22zz––

SNC-VM600B HD – 2 2 zz ––

SNC-VM631 Full HD z 22zz––

SNC-VM601 HD z 22zz––

SNC-VM601B HD – 2 2 zz ––

SNC-VM632R Full HD z 22zzz–

SNC-VM602R HD z 22zzz–

SNC-EB630 Full HD – – – – – – –

SNC-EB630B Full HD – – – – – – –

SNC-EB600 HD – – – – – – –

SNC-EB600B HD – – – – – – –

SNC-EB632R Full HD – – – – – z –

SNC-EB602R HD – – – – – z –

SNC-EM630 Full HD – – – – – – –

SNC-EM600 HD – – – – – – –

SNC-EM631 Full HD – – – – – – –

SNC-EM601 HD – – – – – – –

SNC-EM632R Full HD – – – – – z –

SNC-EM602R HD – – – – – z –

SNC-XM637 Full HD – – – z

SNC-XM636 Full HD – – – z

SNC-XM632 Full HD – – – z

SNC-CX600W/ CX600

image size

(page 29)*

HD – – – zz ––

High

framerate

mode

(page 28)**

Sensor

input

(page 51)

Alarm

output

(page 62)

Edge

Storage

(page 62)

Audio

(page 30)

(only mic)

Illuminator

(page 31)

––

Serial

control I/F

(page 50)

z Usable function

– Not usable function * Maximum image size; HD: 1280 × 1024, Full HD: 1920 × 1080 ** High framerate mode: Monitoring maximum 60 frames

Function Chart

Accessing the Camera Using the Web Browser

The live viewer window appears (in SSL communication).

After the IP address has been assigned to the camera, check that you can actually access the camera using the Web browser installed on your computer.

Start the Web browser on the computer and type the IP address of the camera in the URL address bar.

The live viewer window is displayed.

Display sample

Note

• The maximum number of users on the network who can see a viewer at the same time is 20 users (SNC-CX600W/CX600: five users). However, if the transmission function of the camera is overloaded, access to the camera may not be possible, even if there are fewer than the maximum number of users.

• If monitoring with sound, the maximum number of users is 10.

• When using a Wi-Fi network, it may take longer for the image to be transmitted. (SNC-CX600W)

Overview

When “Allow HTTP connection for some clients” (page 43) is checked

To use HTTP and SSL connections separately to access, enter the following in the address box of the browser.

For HTTP connection

http://192.168.0.100/index.html?lang=en

For SSL connection

https://192.168.0.100/index.html?lang=en

When the live viewer of the camera is displayed for the first time

“Security Warning” is displayed. When you click Ye s , ActiveX control is installed and the live viewer is displayed.

Using the SSL function

Note

The model on sale in China does not support the SSL function.

When Internet Explorer is used

When you enter the camera IP address, “Certificate Error” may appear according to the status of the certificate set on the camera. In this case, click Continue to this website (not recommended). to continue.

Notes

• If Automatic configuration is enabled in the Local

Area Network (LAN) settings of Internet Explorer, the image may not be displayed. In that case, disable Automatic configuration and set the proxy server manually. For the setting of the proxy server, consult your network administrator.

• When you install ActiveX Control, you should be logged in to the computer as Administrator.

Accessing the Camera Using the Web Browser

Tip

The software is optimized for Internet Explorer using medium font.

Overview

To display the viewer correctly

To operate the viewer correctly, set the security level of Internet Explorer to Medium or lower, as follows:

Select Too ls from the menu bar for Internet Explorer, then select Internet Options and click the Security tab.

Click the Internet icon (when using the camera via the Internet), or Local intranet icon (when using the camera via a local network).

Set the slider to Medium or lower. (If the slider is not displayed, click Default Level.)

When using antivirus software, etc., on the computer

• When you use antivirus software, security software, personal firewall or pop-up blocker on your computer, the camera performance may be reduced, for example, the frame rate for displaying the image may be lower.

• The Web page displayed when you log in to the camera uses JavaScript. The display of the Web page may be affected if you use antivirus software or other software described above on your computer.

Accessing the Camera Using the Web Browser

Basic Configuration by the Administrator

You can monitor the camera image by logging in with the initial conditions set for this network camera. You can also set various functions according to the installing position, network conditions or purpose of the camera. We recommend you configure the following items before monitoring images from the camera.

Setting contents Setting menu

Set the format of the image sent from the camera. Video codec Tab (page 28)

Select the White balance mode according to the installation position. White balance (page 27)

Select the brightness of the image sent from the camera. Exposure (page 26)

Brightness (page 27)

Select the quality of the image sent from the camera. Video codec Tab (page 28)

Select the view size of the image. View size (page 13)

Select whether the audio from the external input is sent or not. Audio Tab (page 30)

Synchronize the date and time of the camera with those of the computer. Date & time Tab (page 22)

Make the setting for sending the monitor image attached to an e-mail. Mail Transfer Tab (page 60)

Overview

Set the user access right for the camera. User Tab (page 41)

Use Wi-Fi to make the setting for connecting the camera (SNC-CX600W) Wi-Fi Tab (page 37)

Basic Configuration by the Administrator

Overview

Precautions for Preventing Access to the Camera by an Unintended Third Party

The camera may be accessed by an unintended third party on the network, depending on the usage environment. Changing the user name and password of the camera administrator from the default settings is highly recommended for security reasons. If the camera is accessed by an unintended third party, there may be an undesired effect, such as operations or settings to block monitoring, etc.

Set the user name and password of the administrator of the camera. For details, refer to “Setting the Security — Security Menu” in the Administrator menu on page

41.

Check the Referer check checkbox. For details, refer to “Setting the Security — Security Menu” in the Administrator menu on page

41.

Hereafter, use the camera using the SSL connection. If you use the FTP still image sending function, the SSL function will be disabled, and communication content will not be coded. Do not use the FTP still image sending function if the camera is at risk of unauthorized access.

The camera can be fraudulently accessed in a network environment where a device is connected or connectable to the network without the administrator's permission, or a PC or other network device connected to the network can be used without any permission. Connect to these environments at your own risk. To prevent unauthorized access to the camera, set it according to the following steps.

Do not use the browser you use to set the camera to access other websites while you set or after setting the camera. You will remain logged in to the camera as long as the browser is open, so to prevent an unintended third party's use or execution of malicious programs, close the browser after you finish setting the camera.

How to set up

Set the network address of the camera using SNC toolbox. For details about how to use SNC toolbox, refer to the application guide. After this step, do not use SNC toolbox to change the network settings of the camera. Use SNC toolbox to search for the camera only.

Note

The model on sale in China does not support the SSL function.

Start the web browser and set the SSL function to Enable in the camera settings. For details, refer to “Setting the Security — Security Menu” in the Administrator menu on page

41.

Restart the web browser and access the camera again.

Precautions for Preventing Access to the Camera by an Unintended Third Party

Operating the Camera

Administrator and User

This network camera identifies those who log in as the

This section explains how to monitor the image from the camera using your Web browser.

Administrator or User. The Administrator can use all the functions of this network camera, including camera settings. The User

The functions of the camera should be set by the Administrator. For the setting of the camera, see “Administrating the Camera” on page 21.

can use the functions for monitoring the image and audio from the camera, and control the camera. The Viewer mode setting is used to restrict the user’s access rights. There are five types of users.

Each type of user can use the corresponding functions below.

Function Administrator

Monitor a live image zzzzz

View the date and time zzzzz

Control the frame rate (JPEG mode only) zz–––

Control the image view size zzzz–

Save a still image and movie in the computer zzzz–

Switch the TCP/UDP transmission mode (Available in H.264 mode only)

Perform the pan/tilt/zoom operation zzz––

Receive audio zzzzz

Select the codec mode zzzz–

Control the setting menu z ––––

Play the recorded file in the memory card zz–––

Delete the recorded file in the memory card z ––––

zz–––

Full Pan/Tilt Light View

User

Operating the Camera

z Usable function

– Not usable function

The access rights of the administrator and the user can be set in “Setting the Security — Security Menu” of the Administrator menu on page 41.

Administrator and User

Logging in to System

Plug-in free viewer

This viewer enables a browser other than Internet Explorer to display images.

Logging in as a user

Start the Web browser on your computer and type the IP address of the camera you want to monitor.

Operating the Camera

The live viewer is displayed.

Display sample:

Notes

• If Automatic configuration is enabled in the Local

Area Network (LAN) Settings of Internet Explorer, the camera image may not be displayed. In that case, disable Automatic configuration and set the proxy server manually. For the setting of the proxy server, consult your network administrator.

• When you install ActiveX Control, you should be logged in to the computer as the Administrator.

Tip

Every page of this software is optimized for Internet Explorer in Medium font.

Note

If the live viewer does not start correctly, the security level of the Internet Explorer may be set to higher than Medium. See “To display the viewer correctly” on page 8 and check the security level.

About Viewers

You can use the following viewers.

ActiveX viewer

This viewer can monitor the camera image in any of the JPEG and H.264 video codecs. Two types of ActiveX viewer are available: Live viewer and Playback viewer. You must install this viewer when you access the viewer for the first time.

When you display the viewer of the camera for the first time

When you access the network camera using ActiveX viewer for the first time, the Security Warning appears. Click Ye s and install ActiveX Control. You can use all the functions of the viewer with ActiveX Control.

Logging in to System

Configuration of Live Viewer

This section explains the functions of the parts and controls of the live viewer. For a detailed explanation on each part or control, see the specified pages.

Control panel section

You can drag the panels to the monitor screen and configure them. To return to the control panel, drag the panel and configure the control panel. Click the to hide the detail setting menu or click it again to show the menu.

Live viewer using ActiveX viewer

Main menu

Control panel section

Monitor image section

Main menu

Live viewer

Displays the ActiveX viewer or the Plug-in free viewer.

Information panel

Operating the Camera

Check the date and time here.

View panel

You can change the screen mode, view size of the image, image codec mode and frame rate. Also, still images and movies can be saved (movie saving can also be stopped) from here. Microphone and audio output levels can be adjusted.

Screen mode

Select Window or Full Screen.

Playback viewer

Click to play, save and delete the recorded movie in the memory card. (page 18)

Setting

Click to display the Administrator menu. (page 21) You can operate this function only when logging in as the administrator.

License notice

Displays the software consent agreement, etc.

Language

Set language from pull-down.

View size

Selects the view size to be displayed. Click View size list box to select the view size. Select ×1/4 to display images, reduced to 1/4 of the size set in Image size. Select ×1/2 to display images, reduced to 1/2 of the size set in Image size. Select ×1 to display images set in Image size (page 29) of the Video / Audio menu or Video menu. Select Full to display images according to the view size. Select Fit to display images according to the view size, with fixed aspect ratio.

Image codec

Select Image1, Image2 and Image3 of the video codec.

Frame rate

(Displayed only when the camera image is in JPEG.) Selects the frame rate to transmit images.

Configuration of Live Viewer

Capture

Camera control panel

Click to capture a still image shot by the camera and to store it in the computer. Click to open the folder to be saved.

Note

In the case of Windows VISTA, Windows 7, Windows 8 or Windows 8.1, if “Enable Protected Mode” is checked in Control Panel-Internet Option-Security, still images

Operating the Camera

cannot be shot.

Run/ Stop Save Video

Runs and stops Save Video. Click to open the folder to be saved.

Note

In the case of Windows VISTA, Windows 7, Windows 8 or Windows 8.1, if “Enable Protected Mode” is checked in Control Panel-Internet Option-Security, video content cannot be saved.

Volum e

Displays when Enable in the Audio tab of the Video / Audio menu is checked.

Use the slide bar to adjust the volume for sound output level.

When you click , the icon changes to and the output from the speaker stops. To output sound from the speaker, click again.

Mic volume

Displays when Audio upload (page 30) in the Audio tab of the Video / Audio menu is set to Enable, and a user with audio enabled in the User tab of the Security menu accesses the device.

This panel allows you to control the camera’s pan/tilt/ home position and zoom (page 16).

Image action

Select the mode of operation from Off, Area zoom and Vector dragging.

Pan/Tilt control

Click the arrow button the direction in which you want to move the camera. Keep it pressed to move the camera continuously. To return to the home position, click .

Zoom control

Click to zoom out, and click to zoom in. Zooming continues while the button remains pressed.

Other panel

(The Other panel is displayed in the case of an H.264 image.)

You can switch between TCP and UDP (Unicast/ Multicast).

Use the slide bar to adjust the microphone volume.

When you click , the icon changes to and the microphone input stops. To input the microphone, click

again.

Configuration of Live Viewer

Each click switches the transmission mode of the video/ audio data between TCP mode, Unicast mode, and Multicast mode (page 17).

Monitor image

The image shot by the camera is shown here. There are two modes for on-screen pan/tilt/zoom operation using a mouse: Area zoom mode and Vector dragging mode. In the Area zoom mode, click to adjust the camera direction to the center of the image. The Area zoom will move the camera in the direction that displays the area selected by the operator and zooms in at the same time. The operator can choose a part of the image to view and zoom in by surrounding an area with a frame by dragging the mouse. In the Vector dragging mode, the camera moves to the dragged direction. How long you drag the mouse determines the speed. Releasing the button on the mouse after dragging stops the panning or tilting of the camera. You can also use the camera control panel bar to change the camera direction. The zoom operation using the mouse wheel is available in all modes.

Monitor screen

There are two modes for on-screen pan/tilt/zoom operation using a mouse: Area zoom mode and Vector dragging mode. A control bar is displayed on the screen. In the Area zoom mode, click to adjust the camera direction to the center of the image. The Area zoom will move the camera in the direction that displays the area selected by the operator and zooms in at the same time. The operator can choose a part of the image to view and zoom in by surrounding the area with a frame by dragging the mouse. In the Vector dragging mode, the camera moves to the dragged direction. How long you drag the mouse determines the speed. Releasing the button on the mouse after dragging stops the panning or tilting of the camera. You can also use the tool bar to change the camera direction. The zoom operation using the mouse wheel is available in all modes.

Control bar

The following operation buttons are available.

Setting

You can set the streaming method, image size, frame rate, PTZ operation mode and image codec.

Streaming start button

Starts streaming. (Appears while stops streaming.)

Streaming stop button

Stops streaming. (Appears while streaming.)

Save still image button

Captures still images taken by the camera and saves them to the computer.

Operating the Camera

Plug-in free viewer

Live viewer using Plug-in free viewer

Display sample:

Control bar

Monitor screen

Using Solid PTZ function

You can operate the camera by using the Solid PTZ function, which provides panning, tilting and zooming by adjusting the position and zooming ratio from the maximum image size (1280 × 720*, 1280 × 1024**, 1920 × 1080***), without moving the camera.

* 1280 × 720: SNC-CX600W/CX600 ** 1280 × 1024: SNC-VB600/VB600B/VM600/ VM600B/VM601/VM601B/VM602R/EB600/ EB600B/EB602R/EM600/EM601/EM602R *** 1920 × 1080: SNC-VB635/VB630/VM630/ VM631/VM632R/EB630/EB630B/EB632R/EM630/ EM631/EM632R/XM637/XM636/XM632

There are three modes of camera operation: Area zoom mode, Vector dragging mode and PTZ Control bar. You can control pan/tilt and zoom in either mode.

Configuration of Live Viewer

The available functions for the camera operation modes vary according to the live viewer display. The available functions are as follows.

ActiveX

viewer

Operation from control panel

Area zoom aaa

Operating the Camera

Vector dragging aaa

PTZ control bar

–

Plug-in free viewer

JPEG MJPEG

––

Pan/Tilt control

Click the arrow button in the direction in which you want to move the camera. Keep it pressed to move the camera continuously. To return to the home position, click .

Zoom control

Click to zoom out, and click to zoom in. Zooming continues while the button remains pressed.

Note

The four edges of the image may be dark depending on the zoom position. This is a phenomenon related to the

Notes

structure of the camera, and does not cause a problem.

• Pan/Tilt limitation The solid PTZ function controls streaming by

Panning and tilting by clicking the

cropping or reducing a maximum size image. Thus, the more the camera zooms out, the less area to be panned or tilted, and becomes unavailable at the WIDE end.

• Zoom limitation The solid PTZ function enables you to display an area of 1/16 the maximum image size (Aspect ratio: 1:4),

monitor image (Area zoom mode only)

Click on the monitor image, and the camera moves so that the clicked portion is positioned at the center of the display.

when zoomed in at the TELE end. An image cannot be enlarged beyond this. And the whole area shot in the maximum image size will be displayed if the camera is zoomed out at the WIDE end. The solid PTZ function’s zoom is performed digitally; therefore, some deterioration in image quality may be observed at the TELE end.

• The Plug-in free viewer display method will be selected automatically.

Panning, tilting and zooming by specifying the area (Area zoom

Controlling via the control panel (Operation common to Area zoom mode and Vector dragging mode)

You can operate the camera direction and zoom by using the control panel for the monitor image currently displayed.

mode only)

Click and hold the left button of the mouse on the monitor image, and drag the mouse diagonally to draw a red frame around the portion you want to enlarge. The camera moves so that framed portion is positioned at the center of the display and is zoomed in.

Note

When the specified area is zoomed in, the center may be shifted or some portion of the image may appear out of the monitor image section. In this case, click the point you want to move to the center or click the arrow button on the camera control panel.

Configuration of Live Viewer

Panning and tilting by dragging the screen (Vector dragging mode only)

Switching Transmission Mode

When you click on the starting point on the image and drag to the end point, the camera pans/tilts in the direction of the arrow from the starting point to the end point. The speed of operation is determined by the length of arrow. Releasing the button on the mouse stops the panning/tilting of the camera.

Using pan/tilt/zoom operations with the displayed control bar (PTZ Control bar only)

You can change the transmission mode for video/audio data. This function can be used when the video codec mode is set to H.264 and the ActiveX viewer in the live viewer is used.

Note

The function may not operate correctly if you use personal firewall software or antivirus software on your computer. In that case, disable the software or select the TCP mode.

Select TCP, Unicast or Multicast from the Connection drop-down list in the Other panel.

TCP: This is normally selected.

When TCP is selected, HTTP communication is adopted for video/audio communications. HTTP is the protocol used for reading the usual Web page. In an environment capable of reading Web pages, you can watch or listen to video/audio by selecting the TCP port.

Operating the Camera

Pan/Tilt operations

Click the arrow of the direction you wish to move the camera. Continue pressing on the arrow to keep moving the direction of the camera.

Zoom operation

Click to zoom out, click to zoom in. The zoom operation continues while you are pressing on the button.

Unicast: When Unicast is selected, RTP (Realtime Transport Protocol) is adopted for video/audio communications. Since RTP is the protocol for running video/audio data, the video/audio playback is smoother than when TCP (HTTP) is selected. If a firewall is installed between the camera and the computer, or depending on the network environment, video/audio may not play back properly when Unicast is selected. In this case, select TCP.

Multicast: This protocol is selectable when Multicast streaming in the Streaming tab of the

Video / Audio menu or Video menu is set to Enable. When Multicast is selected as the transmission port, RTP (Real-time Transport Protocol) and UDP multicast techniques are adopted for video/audio transmission. By selecting it, the network transmission load of the camera can be reduced. If a router that does not correspond to a multicast or firewall is installed between the camera and the computer, video/audio may not play back properly. In this case, select TCP or Unicast.

Switching Transmission Mode

Note

When connecting via a proxy server, neither Unicast nor Multicast can be selected.

Playback viewer

You can play, save or delete the movies recorded in the memory card. Supported models: SNC-VB635/VB630/VB600/ VB600B/VM630/VM600/VM600B/VM631/VM601/ VM601B/VM632R/VM602R/XM637/XM636/ XM632/CX600W/CX600 This function is available only in the following users.

Operating the Camera

• Administrator

• When Viewer mode is set to Full

Control panel section

Monitor image section

Control panel section

View panel

You can change the screen mode or view size of the image.

Screen mode

Select Window or Full Screen.

View size

Select the view size to be displayed. Click the View size list box to select the view size. Select ×1/4 to display images, reduced to 1/4 of the size set in Image size. Select ×1/2 to display images, reduced to 1/2 of the size set in Image size. Select ×1 to display images set in Image size (page 29) of the Video / Audio menu. Select Full to display images in full size. Select Fit to display images in full size with fixed aspect ratio.

Playback viewer

Search panel

Specify the search period.

Start

Select the start time for searching.

End

Select the end time for searching.

Maximum search number

You can specify the maximum number of the search results.

Search for recorded movies in the specified period.

Go to the previous search result

Displays the previous search results.

Save recorded movie

Save the selected movie to your computer. Click to open the folder in which the movie is to be saved.

Delete recorded movie

Delete the selected movie(s).

Note

Only the administrator can delete movies. Deleted movies cannot be restored.

Control panel (Basic)

Operating the Camera

Search results list

Displays the search results from the search panel. You can select the movie which you want to play, save or delete. You can select multiple files for deletion by clicking those movies while pressing the control key.

Range of the search results displayed in the list

Indicates the list of the total search results that is currently displayed.

You can play, pause, stop, fast forward or jump the selected movie on the search results list. Also you can specify the start position for playback. If you click the button, the control panel (detail) is displayed.

Control panel (Detail)

Specify the start position for playback

Specify the playback time

You can play, pause, stop, fast forward or jump the selected movie on the search results list. Also you can specify the start position for playback, playback time, save the movie or save the captured still image. If you click the button, the control panel (basic) is displayed.

Specify the start position for playback

Move the start position by dragging the slider.

Time

Go to the next search result

Displays the next search results.

Specify the recorded date and time from which the movie will start playback.

Playback viewer

Previous record

Jump to the previous movie.

Stop button

Click this button to stop a movie playing.

Play button

Play the movie. Click this button to play the movie at the normal speed after pressing the fast forward button.

Operating the Camera

Pause button

Click this button to pause a movie playing.

Fast forward

Click this button to fast forward the moving being played.

Monitor image

Next record

Jump to the next movie.

Still image capture

Save the capture of a recorded movie as a still image file to your computer. Click to open the folder in which the movie is to be saved.

Specify the playback time

Specify the start and end position of the movie by moving the slider. You can save the specified time to your computer. You can also specify the start time to In and end time to Out.

Save selected part of recorded movie

Save the part of movie which is specified by the playback time to your computer. Click to open the folder in which the movie is to be saved.

Play the selected movie from the search results list.

Playback viewer

Administrating the Camera

Example: “Date & time” tab of “System” menu

This section explains how to set the functions of the camera by the Administrator. For details about monitoring the camera image, see “Operating the Camera” on page 11.

This section explains the basic operations and each option of the Administrator menu.

Note on the display of menu options

The setting menus of this unit will clearly display only the setting options that you can currently select. Grayed out options cannot be selected. Only supported functions are displayed.

Basic Operations of the Administrator Menu

You can use the Administrator menu to set all functions to suit the user’s needs. Click Setting in the viewer to display the Administrator menu.

How to set up the Administrator menu

Click Setting on the main menu. The authentication dialog appears. Enter the user name and password for Administrator. The Administrator menu appears. The user name “admin” and password “admin” are set at the factory for the Administrator. For security, be sure to change the password from the factory setting before using the camera.

See page 22 for details of the menu tabs and setting options.

After setting, click OK. The settings you have made become active.

Click Cancel to nullify the set values and return to the previous settings.

Buttons common to every menu

The following buttons are displayed on all the menus.

Click this button to confirm the settings.

Click this button to nullify the set values and return to the previous settings.

General notes on menus

• One-byte katakana character is not valid for any text field, such as User name.

• After changing a setting on a menu, wait at least 30 seconds before turning off the power of the camera. If the power is turned off immediately, the new setting may not be stored correctly.

• If the camera settings are changed while watching the live viewer, some settings cannot be restored. To reflect the change on the opening live viewer, click Refresh on the Web browser.

Configuration of the Administrator menu

System

Displays the System menu. (“Configuring the System — System Menu” on page 22)

Administrating the Camera

Click the menu name (example: System) on the left side of the Administrator menu. The clicked menu appears.

Example: “System” menu

Select the required tab above the menu, and set each setting option in the tab.

Video / Audio

Displays the Video / Audio menu for setting the camera image and audio. (“Setting the Camera Image and Audio — Video / Audio Menu Setting the Camera Image — Video Menu” on page 25)

Video

Displays the Video menu for setting the camera image. (“Setting the Camera Image and Audio — Video / Audio Menu Setting the Camera Image — Video Menu” on page 25)

Basic Operations of the Administrator Menu

Network

Displays the Network menu for setting the network connection. (“Configuring the Network — Network Menu” on page 35)

Configuring the System

— System Menu

Security

Displays the Security menu for setting the login user name and password to specify which computer(s) can connect to the camera. (“Setting the Security — Security Menu” on page 41)

PTZ control

Displays the setting menu for solid PTZ and serial interface. (“Setting the PTZ control — PTZ control Menu” on page 50)

Administrating the Camera

Action input

Displays the setting menu for all built-in detection functions. (“Setting the Sensor input/Camera tampering detection/Motion detection — Action input Menu” on page 51)

Action output

Displays the Action output menu for setting an action of the functions such as e-Mail (SMTP) and Edge Storage. (“Setting the Action output — Action output Menu” on page 59)

Schedule

Displays the Schedule menu for the e-Mail (SMTP) function, Alarm output function, Voice alert function, etc. (“Setting the Schedule — Schedule Menu” on page

68)

When you click in the Administrator menu, the System menu appears. Use this menu to perform the principal settings of the software. The System menu consists of the following tabs:

Information, Date & time, Installation, Initialize, System log and Access log.

Information Tab

Model Name

The model name of the camera is displayed.

Serial number

The serial number of the camera is displayed.

Software version

The software version of the camera is displayed.

Date & time Tab

System

CLOUD

Displays the setting menu for the CLOUD service. (“Setting the CLOUD service — CLOUD Menu” on page 69)

Current date & time

Displays the date and time set on the camera.

Note

After you have purchased the camera, be sure to check the date and time of the camera and set as necessary.

PC clock

Displays the date and time set on your computer.

Date & time format

Select the format of date and time to be displayed in the viewer from the drop-down list.

Configuring the System — System Menu

You can select the format between yyyy-mm-dd hh:mm:ss (year-month-day hour:minutes:seconds), mm-dd-yyyy hh:mm:ss (month-day-year

hour:minutes:seconds), and dd-mm-yyyy hh:mm:ss (day-month-year hour:minutes:seconds).

Time setting

Select how to set the day and time.

Keep current setting: Select if you do not need to set

the date and time.

Synchronize with PC: Select if you want to

synchronize the camera’s date and time with the computer.

Manual setting: Select if you want to set the camera’s

date and time manually. Select the year, month, date, hour, minutes and seconds from each drop-down list.

Synchronize with NTP: Select if you want to

synchronize the camera’s date and time with those of the time server called NTP server (Network Time Protocol). Set the NTP server when Synchronize with NTP is selected.

NTP server

Synchronize with the selected NTP server address.

For example: In case of (UTC-06:00) Central Standard Time (USA and Canada); CentralStandardTime6DaylightTime1,M3.2.0,M11.1.0

The name of the time zone is CentralStandardTime and the time difference is 6 hours. The name of the summer time is DaylightTime, and the summer time offset from the time difference is 1 hour, starting from the second week on Sunday in March until the first week on Sunday in November.

Automatically adjust clock for daylight saving time changes

When selected, the clock is automatically adjusted according to the daylight saving time of the selected time zone.

Note

If the time zone selected in Time zone is different from that set on the computer, the time is adjusted using the time zone difference and set on the camera.

OK/Cancel

See “Buttons common to every menu” on page 21.

Administrating the Camera

Note

When the CLOUD service is activated, you cannot set the time and cannot change the NTP server. If you want to set them, deactivate the CLOUD service.

Time zone

Set the time difference from Greenwich Mean Time in the area where the camera is installed. Select the time zone in the area where the camera is installed from the drop-down list.

Manual time zone

If you select Manual in Time zone, you can set a desired time zone that is not included in the list box. The input format is compliant with IEEE 1003.1 section 8.3 standard.

Format:

stdoffset[dst[offset][,start[/time],end[/time]]]

std: 3 to 100 character strings offset: time difference (displayed in + dst: name of summer time offset: offset of summer time, default time is 1 hour start: start date and time of summer time end: end date and time of summer time

Values in [ ] can be omitted.

Installation Tab

You can perform settings related to installation.

Auto iris responding speed

Supported models: SNC-VB635/VB630/VB600/ VB600B/EB630/EB630B/EB600/EB600B When you use a non-standard lens, adjust the speed according to the lens you use. Select high values to make the iris respond faster, lower values to make the iris respond slower.

Stabilizer

Set the stabilizer function. Select the checkbox to display steadier images when the camera is installed in a place subject to vibration.

Notes

• When the stabilizer function is set, the angle of image taken will be smaller than usual.

• The stabilizer may not respond, depending on the amount of vibration.

• Be sure to set this function during the installation.

• Set the privacy masking position or the motion detection area, before setting the stabilizer.

Configuring the System — System Menu

+ 52 hidden pages
