To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To avoid electrical shock, do not
open the cabinet. Refer servicing to
qualified personnel only.
The mains lead must only be
changed at a qualified service shop.
This appliance is classified as a
CLASS 1 LASER product. The
CLASS 1 LASER PRODUCT
MARKING is located on the rear
exterior.
CAUTION
The use of optical instruments with this
product will increase eye hazard. As
the laser beam used in this VCR-DVD
recorder is harmful to eyes, do not
attempt to disassemble the cabinet.
Refer servicing to qualified personnel
only.
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AVOID DIRECT EXPOSURE TO BEAM
DANGER
CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO THE BEAM.
CAUTION
KLASSE 3B SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG WENN GEÖFFNET. DIREKTEN KONTAKT MIT DEM
VORSICHT
STRAHL VERMEIDEN.
SYNLIG OG USYNLIG LASERSTRÅLING AF KLASSE 3B VED ÅBNING. UNDGÅ DIREKTE UDSÆTTELSE FOR STRÅLING.
ADVARSEL
SYNLIG OG USYNLIG LASERSTRÅLING I KLASSE 3B NÅR DEKSEL ÅPNES. UNNGÅ DIREKTE EKSPONERING FOR STRÅLEN.
ADVARSEL
KLASS 3B SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD. UNDVIK ATT DIREKT EXPONERA DIG
VARNING
FÖR STRÅLNINGEN.
AVATTUNA LUOKAN 3B NÄKYVÄÄ JA NÄKYMÄTÖNTÄ LASERSÄTEILYÄ. VÄLTÄ SUORAA ALTISTUMISTA SÄTEELLE.
VARO!
This label is located on the laser
protective housing inside the
enclosure.
Notice for customers in the
United Kingdom and Republic of
Ireland
A moulded plug complying with
BS1363 is fitted to this equipment for
your safety and convenience.
Should the fuse in the plug supplied
need to be replaced, same rating fuse
approved by ASTA or BSI to BS1362,
(i.e., marked with or mark)
must be used.
If the plug supplied with this
equipment has a detachable fuse cover,
be sure to attach the fuse cover after
you change the fuse. Never use the
plug without the fuse cover. If you
should lose the fuse cover, please
contact your nearest Sony service
station.
Precautions
• This unit operates on 220 – 240 V
AC, 50 Hz. Check that the unit’s
operating voltage is identical with
your local power supply.
• To prevent fire or shock hazard, do
not place objects filled with liquids,
such as vases, on the apparatus.
VIDEO Plus+ and PlusCode are
registered trademarks of Gemstar
Development Corporation.
The VIDEO Plus+ system is
manufactured under license from
Gemstar Development Corporation.
Disposal of Old Electrical &
Electronic Equipment
(Applicable in the European
Union and other European
countries with separate
collection systems)
applicable collection point for the
recycling of electrical and electronic
equipment. By ensuring this product is
disposed of correctly, you will help
prevent potential negative
consequences for the environment and
human health, which could otherwise
be caused by inappropriate waste
handling of this product. The recycling
of materials will help to conserve
natural resources. For more detailed
information about recycling of this
product, please contact your local
Civic Office, your household waste
disposal service or the shop where you
purchased the product.
This symbol on the
product or on its
packaging indicates
that this product shall
not be treated as
household waste.
Instead it shall be
handed over to the
Precautions
On safety
Should any solid object or liquid fall
into the cabinet, unplug the recorder
and have it checked by qualified
personnel before operating it any
further.
On power sources
• The recorder is not disconnected
from the AC power source (m ains)
as long as it is connected to the
wall outlet, even if the recorder
itself has been turned off.
• If you are not going to use the
recorder for a long time, be sure to
disconnect the recorder from the
wall outlet. To disconnect the AC
power cord (mains lead), grasp the
plug itself; never pull the cord.
On placement
• Place the recorder in a location
with adequate ventilation to
prevent heat build-up in the
recorder.
• If the recorder is brought directly
from a cold to a warm location, or
is placed in a very damp room,
moisture may condense on the
lenses inside the recorder and
cause damage to the video head,
tape, and the optical block. Should
this occur, the recorder may not
operate properly. When you first
install the recorder, or when you
move it from a cold to a warm
location, remove the disc and tape
and leave the recorder turned on
for about three hours before
operating the recorder.
• Do not place the recorder on a soft
surface such as a rug that might
block the ventilation holes.
• Do not place the recorder in a
confined space such as a bo okshelf
or similar unit.
• Do not place the recorder in a
location near heat sources, or in a
place subject to direct sunlight,
excessive dust, or mechanical
shock.
• Do not place the recorder in an
inclined position. It is designed to
be operated in a horizontal
position only.
2
• Keep the recorder, discs, and
cassettes away from equipment
with strong magnets, such as
microwave ovens, or large
loudspeakers.
• Do not place heavy objects on the
recorder.
• When you move the recorder, take
out any discs. If you do not, the
disc may be damaged.
On recording
• Contents of the recording cannot
be compensated for if the
recording or playback is not made
due to a malfunction of the
recorder, disc, etc.
• Make trial recordings before
making the actual recording.
Copyrights
• Television programmes, films,
video tapes, discs, and other
materials may be copyrighted.
Unauthorized recording of such
material may be contrary to the
provisions of the copyright laws.
Also, use of this recorder with
cable television transmission may
require authorization from the
cable television transmitter and/or
programme owner.
• This product incorporates
copyright protection technology
that is protected by U.S. patents
and other intellectual property
rights. Use of this copyright
protection technology must be
authorized by Macrovision, and is
intended for home and other
limited viewing uses only unless
otherwise authorized by
Macrovision. Reverse engineeri ng
or disassembly is prohibited.
IMPORTANT NOTICE
Caution: This recorder is capable
of holding a still video image or
on-screen display image on your
television screen indefinitely. If
you leave the still video image or
on-screen display image di splayed
on your TV for an extend ed period
of time you risk permanent
damage to your television screen.
Plasma display panels and
projection televisions are
especially susceptible to this.
If you have any questions or
problems concerning your recorder,
please consult your nearest Sony
dealer.
Copy guard function
Since the recorder has a copy guard
function, programmes received
through an external tuner (not
supplied) may contain copy
protection signals (copy guard
function) and as such may not be
recordable, depending on the type of
signal.
,continued
3
About this manual
• Instructions in this manual describe the controls on the
remote. You can also use the controls on the recorder if
they have the same or similar names as those on the
remote.
• The on-screen display illustrations used in this manual
may not match the graphics displayed on your TV
screen.
• The explanations regarding discs in this manual refer to
discs created on this recorder. The explanations do not
apply to discs that are created on other recorders and
played back on this recorder.
IconMeaning
+
RW
-
RWVR
-
RW
Video
+
R
-
R
DVD
VCD
CD
DATA CD
DATA DVD
Functions available for DVD+RWs
Functions available for DVD-RWs
in VR (Video Recording) mode
Functions available for DVD-RWs
in video mode
Functions available for DVD+Rs
Functions available for DVD-Rs
Functions available for DVD
VIDEOs
Functions available for VIDEO
CDs, Super VCDs or CD-Rs/CDRWs in video CD format or Super
VCD format
Functions available for music CDs
or CD-Rs/CD-RWs in music CD
format
Functions available for DATA CDs
(CD-Rs/CD-RWs containing MP3
audio tracks or JPEG image files)
Functions available for DATA
DVDs (DVD+RWs/DVD-RWs/
DVD+Rs/DVD-Rs containing
This is a DVD recorder with built-in VHS video deck, and allows recording/playback of DVD discs and
VHS tapes. DVD editing is also possible.
Recording and timer recording
Record TV programmes on a DVD or VHS tape,
either manually or using the timer.
Easy selection between DVD and
VCR
Simply press the DVD or VIDEO button to select
the media format you want to use.
Easy dubbing
Dub in either direction between a DVD disc and
VHS tape with the simple press of a button.
VIDEODVD
* Note that copy-protected signals will not be recorded.
Quick access to recorded titles Title List
Display the Title List to view all titles on a disc
and select a title for playback or editing.
DVD
DVD
VIDEO
VIDEO
T
Prog. 1
16.May.2005
08:00
Title List (Original)
1/4
No. TitleLength Edit
01 Prog. 1
02>00:31:23
03>01:59:00
04>00:58:56
Prog. 2
Prog. 4
Prog. 3
10:10
>01:29:03
8
Creating your own programme Playlist
Record a programme on a DVD-RW (VR mode),
then erase, move, or add scenes as you like
without changing the original contents.
Original
Playlist
Operation restrictions
One Touch Dubbing - DV Dubbing
Connect your digital video camera to the DV IN
jack and press the ONE TOUCH DUBBING
button to dub a DV format tape over to a disc.
Control
Dubbing
Possible Simultaneous Operations
Current Operation
Playing a VHS tape
Recording on a VHS tapeNo—YesYes
Playing a DVD
Recording on a DVDYesYes
*1
When DVD is pressed, VCR playback stops.
*2
When VIDEO is pressed, DVD playback stops.
*3
Only the same programme can be recorded on a DVD and a VHS tape.
*1
*2
VCR
Playback
—NoNoYes
NoYes—No
VCR
Recording
*3
DVD
Playback
No—
Recording
DVD
*3
9
How to Use the On-Screen
Menus
The following three displays are mainly used to
operate this recorder. Once you become familiar
with the basic operations, you will find the
recorder easy to use.
SYSTEM
MENU
System Menu
The System Menu appears when you press
SYSTEM MENU, and provides entries to all of
the recorder’s main functions, such as timer
recording and setup.
Select an option by pressing M/m and ENTER.
M/m/</,,
ENTER
TOOLSO RETURN
A “Title List”
Displays the list of the disc contents,
including the recording information and
movie thumbnail image, which allows you to
select a title to play or edit.
T
Prog. 1
02.May.2005
08:00
Title List (Original)
1/4
No. TitleLength Edit
01 Prog. 1
Prog. 2
02>00:31:23
03>01:59:00
Prog. 4
Prog. 3
04>00:58:56
10:10
>01:29:03
B “Timer”
Used to set a new timer recording for a disc or
VHS tape, as well as change or cancel the
timer recordings you set.
C “Edit”
Used to create or edit a Playlist (unfinalized
DVD-RWs (VR mode) only).
D “Dubbing”
Used to dub from a disc to a VHS tape and
vice versa, and also dub from a DV format
tape to a disc.
E “Disc Setting”
Used to rename, format, or finalize a disc.
F “Setup”
Displays the “Setup” display for setting up the
recorder to suit your preferences.
10
Title List (Original)
Title List
Press ENTER :
Timer
Edit
Title Menu for DVD Title List.
Dubbing
Disc Setting
Setup
10:10
Sub-menu
*1
*1
*1*1
*1*1
The sub-menu appears when you select an item
from a list menu (e.g., a title from the Title List
menu), and press ENTER. The sub-menu displays
options applicable only to the selected item. The
displayed options differ depending on the
situation and disc type.
Select an option by pressing M/m and ENTER.
Example: The Title List menu
T
Prog. 1
02.May.2005
08:00
Title List (Original)
1/4
No. TitleLength Edit
01 Prog. 1
Prog. 2
02>00:31:23
03>01:59:00
Prog. 4
Prog. 3
04>00:58:56
Options for the selected item
10:10
Play
Title Erase
Chapter Erase
Protect
Title Name
A·B Erase
Divide Title
>01:29:03
Selectable options
Selectable options on the System Menu differ
depending on the media type, disc condition, and
operating status.
Example: When a disc or a VHS tape is stopped.
TypeSelectable option
+
RW
-
RWVR
-
RW
Video
+
R
-
R
DVD
VCD
CD
TOOLS
The TOOLS menu appears when you press
TOOLS. You can search for a title/chapter/track,
check the playing and remaining time, or change
audio and repeat settings. The displayed options
differ depending on the media type.
Press M/m to select an option, press </, to
select the desired item, and press ENTER.
Example: When you press TOOLS while a
DVD-RW (VR mode) is playing.
1/4
Title
T
1/1
Chapter
C
Time
00:00:25
ENG Dolby 5.1ch (1/3)
Audio
Repeat
Off
00:01:30
Remain
DATA CD
DATA DVD
*2
*1
Unfinalized disc only
*2
With a disc inserted
To return to the previous display
Press O RETURN.
Notes
• The TOOLS menu may not appear during DVD
recording.
• The System Menu does not appear during recording or
dubbing.
• You cannot use the DVD or VIDEO buttons with the
System Menu turned on.
11
Hookups and Settings
Hooking Up the Recorder
Follow steps 1 to 7 to hook up and adjust the
settings of the recorder.
Notes
• Plug cords securely to prevent unwanted noise.
• See the instructions supplied with the components to be
connected.
• You cannot connect this recorder to a TV that does not
have a SCART or video input jack.
• Be sure to disconnect the mains lead of each
component before connecting.
Connect the aerial cable by following the steps below. Do not connect the mains lead until you reach “Step
5: Connecting the Mains Lead” (page 19).
Hookups and Settings
VCR-DVD recorder
TV
: Signal flow
to AERIAL IN
to AERIAL OUT
Aerial cable (supplied)
1 Disconnect the aerial cable from your TV and connect it to AERIAL IN on the rear panel of the
recorder.
2 Connect AERIAL OUT of the recorder to the aerial input of your TV, using the supplied aerial
cable.
13
Step 3: Connecting to Your TV
Connecting to the LINE 2 OUT jacks
Connect the supplied audio/video cord to the LINE 2 OUT (VIDEO/AUDIO L/R) jacks of the recorder.
To enjoy higher quality images, connect an S video cord (not supplied) instead of the yellow (video) plug.
When using this connection, be sure to connect the audio cord to the LINE 2 OUT (AUDIO L/R) jacks.
S video cord
(not supplied)
INPUT
TV or projector
S VIDEO
to S VIDEO OUT
VCR-DVD recorder
INPUT
AUDIO
RLVIDEO
(red)
(white) (yellow)
(yellow)
(white)
(red)
to LINE 2 OUT (VIDEO/AUDIO L/R)
Audio/video cord
(supplied)
: Signal flow
When playing “wide screen” images
Some recorded images may not fit your TV screen. To change the picture size, see page 101.
Notes
• During DVD recording, you cannot watch VHS pictures by pressing VIDEO, as the S VIDEO OUT jack will output
DVD video signals only.
• Do not connect your TV’s audio output jacks to the LINE 2 IN (AUDIO L/R) jacks at the same time. This will cause
unwanted noise to come from your TV’s speakers.
14
Connecting to the SCART jack
Connect to the LINE 1-TV jack using a SCART cord (not supplied). Be sure to make the connections
firmly to avoid hum and noise.
See the operating instructions supplied with the TV to be connected.
When you use this connection, select “Video” or “RGB” for the Line 1 output setting in step 14 of Easy
Setup (page 22).
SCART INPUT
TV or projector
SCART cord
(not supplied)
Hookups and Settings
VCR-DVD recorder
: Signal flow
to i LINE 1-TV
Note
When you connect the recorder to your TV via the SCART jacks, the TV’s input source is set to the recorder
automatically when you turn the recorder on. If necessary, press t TV/VIDEO on the remote to return the input to the
TV.
,continued
15
If your TV has component video input jacks
Connect to the COMPONENT VIDEO OUT jacks using a component video cord (not supplied) or three
video cords (not supplied) of the same kind and length. You will enjoy accurate colour reproduction and
high quality images.
When you use this connection, select “On” for the component out setting in step 10 of Easy Setup
(page 22).
If your TV accepts progressive 525p/625p format signals, you must use this connection and then set
“Progressive” to “On” in the “Video” setup (page 102). The PROGRESSIVE indicator lights up when the
recorder outputs progressive signals.
When using this connection, be sure to connect the audio cord to the LINE 2 OUT (AUDIO L/R) jacks.
COMPONENT VIDEO IN
PB/CBPR/CRY
(green) (blue)(red)
Component video cord
(not supplied)
to COMPONENT VIDEO OUT
TV or projector
(green)
(blue)
(red)
INPUT
AUDIO
LR
(white)(red)
to LINE 2 OUT (AUDIO L/R)
Audio/video cord (supplied)
(white)
(red)
: Signal flow
z Hint
Video signal can also be output from the COMPONENT VIDEO OUT jack when playing a VHS tape.
VCR-DVD recorder
Note
During DVD recording, you cannot watch VHS pictures by pressing VIDEO, as the COMPONENT VIDEO OUT jacks
will output DVD video signals only.
16
Step 4: Connecting to Your AV Amplifier (Receiver)
Select one of the following patterns A or B, according to the input jack on your AV amplifier (receiver).
This will enable you to listen to sound through your AV amplifier (receiver).
When you use this connection, select “Yes” for the component out setting in step 16 of Easy Setup
(page 22).
Hookups and Settings
A
INPUT
AUDIO
AV amplifier
(receiver)
to DIGITAL AUDIO OUT
(OPTICAL)
Optical digital cord (not supplied)
[Speakers]
Rear (L)
(white)
L
(red)
R
to optical
digital input
Audio cord
(not supplied)
to AUDIO OUT L/R
or
(white)
(red)
VCR-DVD recorder
to DIGITAL AUDIO OUT
(COAXIAL)
Coaxial digital cord (not supplied)
to coaxial
digital input
[Speakers]
Rear (R)
B
Front (L)
Centre
: Signal flow
AV amplifier (receiver)
with a decoder
Front (R)
Subwoofer
,continued
17
A Connecting to audio L/R jacks
This connection uses a stereo amplifier’s
(receiver’s) two front speakers for sound.
You can enjoy the surround function that creates
virtual speakers from two stereo speakers. Select
from “Surround1,” “Surround2,” or “Surround3”
of the surround effects (page 35).
Surround 1
Surround 2
Surround 3
*1
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
*2
“DTS” and “DTS Digital Out” are trademarks of
Digital Theater Systems, Inc.
z Hints
• For correct speaker location, see the operating
instructions supplied with the connected components.
• Digital audio signal can also be output when playing a
VHS tape.
Notes
• During DVD recording, you cannot hear VHS sound
by pressing VIDEO, as the DIGITAL AUDIO OUT
jacks will output DVD audio signals only.
• After you have completed the connection, make the
appropriate settings in Easy Setup (page 22). If your
AV amplifier (receiver) has an MPEG audio decoder
function, set “Digital Out” – “MPEG” to “MPEG” in
the “Audio” setup (page 103). Otherwise, no sound or
a loud noise will come from your speakers.
• With a coaxial or optical digita l connection, you cannot
use the virtual surround effects of this recorder.
• This recorder does not support Linear PCM playback
with 3 channels or more.
• When outputting from the DIGITAL AUDIO OUT
jacks, you cannot switch the bilingual sounds on a
DVD-RW (VR mode) by pressing (audio).
Virtual speaker
B Connecting to a digital audio input jack
Use this connection if your AV amplifier
*1
(receiver) has a Dolby
Digital, DTS*2, or MPEG
audio decoder and a digital input jack. You can
enjoy the surround effect of Dolby Digital (5.1ch),
DTS (5.1ch), or MPEG audio (5.1ch).
18
Step 5: Connecting the
Step 6: Preparing the
Mains Lead
Plug the recorder and TV mains leads into the
mains. After you connect the mains lead, you
must wait for a short while before
operating the recorder. You can operate the
recorder only after the front panel display lights up
and the recorder enters standby mode.
If you connect additional equipment to this
recorder (page 26), be sure to connect the mains
lead only after all connections are complete.
to mains
Remote
You can control the recorder using the supplied
remote. Insert two R6 (size AA) batteries by
matching the 3 and # ends on the batteries to the
markings inside the battery compartment. When
using the remote, point it at the remote sensor
on the recorder.
Notes
• If the supplied remote interferes your other Sony DVD
recorder or player, change the command mode number
for this recorder (page 25).
• Use the batteries correctly to avoid possible leakage
and corrosion. Do not touch the liquid with bare hands
should leakage occur. Observe the following:
– Do not use a new battery with an old battery, or
batteries of different manufacturers.
– Do not attempt to recharge the batteries.
– If you do not intend to use the remote for an extended
period of time, remove the batteries.
– If battery leakage occurs, wipe out any liquid inside
the battery compartment, and insert new batteries.
• Do not expose the remote sensor (marked on the
front panel) to strong light, such as direct sunlight or
lighting apparatus. The recorder may not respond to the
remote.
• With normal use, the batteries should last about three to
six months.
• Do not leave the remote in an extremely hot or humid
place.
• Do not drop any foreign object into the remote casing,
particularly when replacing the batteries.
Hookups and Settings
,continued
19
Controlling TVs with the remote
You can adjust the remote control’s signal to
control your TV.
If you connected the recorder to an AV amplifier
(receiver), you can also use the supplied remote to
control the AV amplifier’s (receiver’s) volume.
Notes
• Depending on the connected unit, you may not be able
to control your TV or AV amplifier (receiver) with
some or all of the buttons below.
• If you enter a new code number, the code number
previously entered will be erased.
• When you replace the batteries of the remote, the code
number may be reset to the default setting. Set the
appropriate code number again.
TV/DVD·VIDEO
switch
"/1
Number
buttons,
-/--
PROG +/–
2 +/–
t TV/VIDEO
2 (volume) +/–Adjust the volume of
your TV
PROG +/–Select the programme
position on your TV
t TV/VIDEOSwitch your TV’s input
source
Number buttons, -*Select the programme
position on a Sony TV
(wide mode)Switch to or from the
wide mode of a Sony
wide-screen TV
* If you use the number buttons to select the TV’s
programme position, press -/-- followed by the number
buttons for two-digit numbers.
To operate the t TV/VIDEO button
(for SCART connections only)
The t TV/VIDEO button switches between the
recorder and the last input source selected on the
TV. Point your remote at the recorder when using
this button. The button works even if the TV/
DVD·VIDEO switch is set to DVD·VIDEO.
When you connect the recorder to your TV via the
SCART jacks, the TV’s input source is set to the
recorder automatically when you turn the recorder
on. To watch another source, press the t TV/
VIDEO button to switch the TV’s input source.
“TV” appears in the front panel display.
1 Slide the TV/DVD·VIDEO switch to TV.
2 Hold down "/1.
3 Enter your TV’s manufacturer code (see
below) using the number buttons.
4 Release "/1.
When the TV/DVD·VIDEO switch is set to
TV, the remote performs the following:
PressTo
"/1Turn your TV on or off
20
Code numbers of controllable TVs
If more than one code number is listed, try
entering them one at a time until you find the one
that works with your TV.
If you want to control the TV’s volume even when the
TV/DVD·VIDEO switch is set to DVD·VIDEO, repeat
the steps above and enter the code number 90 (default).
21
Step 7: Easy Setup
Follow the steps below to make the minimum
number of basic adjustments for using the
recorder. If you do not complete Easy Setup, it
will appear each time you turn on your recorder.
Settings are made in the following order.
OSD Language Setup
m
Tuner and Channel Setup
m
Clock Setup
m
TV Type Setup
m
Video Connection Setup
m
Audio Connection Setup
m
Finished!
“Initial setting necessary to operate the DVD
recorder will be made. You can change them
later using setup.” appears.
• If this message does not appear, select “Easy
Setup” in the “Setup” display to run Easy
Setup (page 108).
4 Press ENTER.
The setup display for selecting the language
used in the on-screen display appears.
Easy Setup
No Disc
Select the screen language.
English
Français
Español
Deutsch
Italiano
Nederlands
5 Select a language, and press ENTER.
The Tuner Preset function automatically
starts.
Easy Setup
No Disc
Searching for receivable channels.
Scanning... Please wait.
25%
"/1
M/m/</,,
ENTER
O RETURN
1 Turn on the TV.
2 Press "/1.
The recorder turns on.
3 Switch the input selector on your TV so that
the signal from the recorder appears on
your TV screen.
22
To set the channels manually, see page 98.
6 After the download or search is complete,
the Clock function automatically starts.
Easy Setup
No Disc
Searching for clock data.
Please wait.
If the current date and time is not set, set the
clock manually.
No Disc
Easy Setup
Set the time and date.
Day Month Year
2005
Hour MinAuto Adjust
12 : 00On
12:00
Sat01 01
Press M/m to set the day and press ,. Set the
month, year, hour, minutes in the same way.
Set “Auto Adjust” to “On” to activate the
Auto Clock Set function. The recorder adjusts
the clock automatically whenever the recorder
is turned off.
7 Press ENTER.
The setup display for selecting the picture size
of the connected TV appears.
No Disc
Easy Setup
Select your TV screen type.
16 : 9
4 : 3 Letter Box
4 : 3 Pan Scan
10:10
8 Select the setting that matches your TV
type.
“4:3 Letter Box”: For standard TVs.
Displays “wide screen” pictures with bands
on the upper and lower sections of the screen.
“4:3 Pan Scan”: For standard TVs.
Automatically displays “wide screen”
pictures on the entire screen and cuts off the
sections that do not fit.
“16:9”: For wide-screen TVs or standard TVs
with a wide screen mode.
For details, see “Video Settings (Video)” on
page 101.
9 Press ENTER.
The setup display for the component out jacks
appears.
10Select whether or not to use the
COMPONENT VIDEO OUT jacks.
Select “On” if you are using the
COMPONENT VIDEO OUT jacks.
Otherwise, select “Off.”
11Press ENTER.
The setup display for the i LINE 3/
DECODER jack appears.
12Select whether or not to use the i LINE
3/DECODER jack.
Select “Yes” if you will use the i LINE 3/
DECODER jack.
Otherwise, select “No.”
13Press ENTER.
The setup display for selecting the type of
video signal output from the i LINE 1-TV
jack appears.
No Disc
Easy Setup
Select the Line1 Output Signal.
Video
RGB
10:10
14Select the type of signal you want to output
from the i LINE 1-TV jack.
“Video”: Outputs video signals.
“RGB”: Outputs RGB signals.
Note that if you select “On” in step 10, you
cannot select “RGB.”
15Press ENTER.
The setup display for selecting the type of jack
used to connect to your amplifier (receiver)
appears.
Easy Setup
No Disc
Is this recorder connected to an amplifier (receiver)?
Select the type of jack you are using.
Yes : LINE2 OUT(R-AUDIO-L)
Yes : DIGITAL OUT
No
10:10
Hookups and Settings
,continued
23
16Select the type of jack (if any) you are
using to connect to an amplifier (receiver).
If you did not connect an AV amplifier
(receiver), select “No,” then go to step 21.
If you connected an AV amplifier (receiver)
using an audio cord to the LINE 2 OUT
(AUDIO L/R) or AUDIO OUT L/R jacks,
select “Yes: LINE 2 OUT (R-AUDIO-L),”
then go to step 21.
If you connected an AV amplifier (receiver)
using either a digital optical or coaxial cord,
select “Yes: DIGITAL OUT.”
17Press ENTER.
The setup display for selecting the type of
Dolby Digital signal appears.
No Disc
Easy Setup
10:10
21Press ENTER when “Finish” appears.
Easy Setup is finished. All connections and
setup operations are complete.
Easy Setup
No Disc
Easy Setup is finished.
Finish
To return to the previous display
Press O RETURN.
10:10
Dolby Digital
D-PCM
Dolby Digital
18Select the type of Dolby Digital signal you
want to send to your amplifier (receiver).
If your AV amplifier (receiver) has a Dolby
Digital decoder, select “Dolby Digital.”
Otherwise, select “D-PCM.”
19Press ENTER.
The setup display for the DTS signal appears.
No Disc
Easy Setup
DTS
On
Off
10:10
20Select whether or not you want to send a
DTS signal to your amplifier (receiver),
and press ENTER.
If your AV amplifier (receiver) has a DTS
decoder, select “On.” Otherwise, select “Off.”
z Hints
• If your AV amplifier (receiver) has an MPEG audio
decoder, set “Digital Out” – “MPEG” to “MPEG” in
the “Audio” setup (page 103).
• If you want to run Easy Setup again, select “Easy
Setup” in the “Setup” display (page 108).
Note
To record TV programmes using the timer, you must set
the clock accurately.
24
If you have a Sony DVD player or
more than one Sony DVD recorder
If the supplied remote interferes with your other
Sony DVD recorder or player, set the command
mode number for this recorder and the supplied
remote to one that differs from the other Sony
DVD recorder or player.
The default command mode setting for this
recorder and the supplied remote is DVD 3.
SYSTEM
MENU
O RETURN
M/m/</,,
ENTER
No Disc
Title List
Timer
Edit
Dubbing
Disc Setting
Setup
Options
Language
Parental
Front Display
Command Mode
Factory Setting
10:10
: Auto
: DVD 3
4 Select “Command Mode,” and press
ENTER.
No Disc
Title List
Timer
Edit
Dubbing
Disc Setting
Setup
Options
Language
Parental
Front Display
Command Mode
Factory Setting
: Auto
DVD 1
: DVD1 No
DVD 2
DVD 3
10:10
5 Select the command mode (“DVD 1,”
“DVD 2,” or “DVD 3”), and press ENTER.
6 Slide the COMMAND MODE switch on the
remote so it matches the mode you
selected above.
Hookups and Settings
COMMAND
MODE switch
1 Press SYSTEM MENU.
The System Menu appears.
2 Select “Setup,” and press ENTER.
No Disc
Title List
Timer
Edit
Dubbing
Disc Setting
Setup
Setup
Tuner Preset
Clock Set
Video
Audio
Features
Options
Easy Setup
10:10
3 Select “Options,” and press ENTER.
To return to the previous display
Press O RETURN.
Note
If the command mode does not match, the recorder’s
command mode appears on the front panel display when
you operate the remote. Set the remote’s command mode
to one that matches the recorder’s.
25
Connecting Another VCR or Similar Device
When you connect additional equipment to this recorder, be sure to connect the mains lead only after all
connections are complete (page 19).
See also the instruction manual supplied with the connected equipment.
To record on this recorder, see “Recording From Connected Equipment Without a Timer” on pages 57
and 85.
Note that this recorder has a copy guard function. Pictures containing copy protection signals that prohibit
any copying cannot be recorded. For details, see “Before Recording” on pages 47 and 76.
Connecting to the LINE 2 IN jacks on the front panel
Connect another VCR or similar recording device to the LINE 2 IN jacks of this recorder. If the equipment
has an S video jack, you can use an S video cord (not supplied) instead of the yellow (video) plug of the
audio/video cord. You can connect a second DVD player and record DVDs.
Other VCR, etc.
S VIDEO
OUTPUT
VIDEO
AUDIO
LR
S video cord
(not supplied)
S VIDEO
: Signal flow
LINE 2 IN
Audio/video cord
(not supplied)
DV IN
RL
to LINE 2 IN
VCR-DVD recorder
z Hint
When the connected equipment outputs only monaural sound, connect an audio cord to the LINE 2 IN o (audio) L
(MONO) jack.
Notes
• Do not connect the yellow LINE 2 IN t (video) jack when using an S video cord.
• Turn on the recorder to view pictures from the connected equipment.
26
Connecting to the LINE 3/DECODER jack
Connect another VCR or similar recording device to the LINE 3/DECODER jack using a SCART cord
(not supplied).
When you turn on the connected equipment, the recorder automatically sends the signal from the
equipment to the TV without turning itself on.
TV
VCR
SCART cord
(not supplied)
to SCART input
to i LINE
VCR-DVD recorder
to i LINE1-TV
Notes
• Do not connect the output jack of this recorder to another equipment’s input jack with the other equipment’s output
jack connected to the input jack of this recorder. Noise (feedback) may result.
• If you pass the recorder signals via a VCR, you may not receive a clear image on your TV screen.
3/DECODER
Hookups and Settings
VCRVCR-DVD recorderTV
Be sure to connect your VCR to the VCR-DVD recorder and your TV in the order shown below. To watch video tapes,
watch the tapes through a second line input on your TV.
Line input 1
VCRVCR-DVD recorderTV
Line input 2
27
Connecting to a Satellite or Digital Tuner
Connect a satellite or digital tuner to this recorder using the LINE 3/DECODER jack. Disconnect the
recorder’s mains lead from the mains when connecting the tuner.
When you turn on the tuner, the recorder automatically sends the signal from the tuner to the TV without
turning itself on.
To use the Synchro Rec function, see below.
TV
to SCART input
SCART cord
(not supplied)
Satellite tuner, etc.
VCR-DVD recorder
to i
LINE1-TV
If the satellite tuner can output RGB signals
This recorder accepts RGB signals. If the satellite
tuner can output RGB signals, connect the TV
SCART connector on the satellite tuner to the
LINE 3/DECODER jack.
When you want to use the Synchro Rec function
This connection is necessary to use the
Synchronized Recording function. See
“Recording From Connected Equipment With a
Timer (Synchro Rec)” (pages 54 and 82).
If you are using a B Sky B tuner, be sure to
connect the tuner’s VCR SCART jack to the LINE
3/DECODER jack.
28
to i LINE 3/
DECODER
Notes
• Synchronized Recording does not work with some
tuners. For details, see the tuner’s operating
instructions.
• The recorder cannot record original RGB signals from
the tuner, but records them in the composite video
format.
• When you connect the recorder to your TV via the
SCART jacks, the TV’s input source is set to the
recorder automatically when you turn the recorder on.
29
Quick Guide to Disc Types
Recordable and Playable Discs
Disc Type
DVD+RW
VR
mode
DVDRW
Video
mode
DVD+R
DVD+R DL
DVD-R
Disc
Logo
Icon used
in this
manual
+
RW
-
RWVR
-
RW
Video
+
R
-
R
Formatting
(new discs)
Automatically
formatted
Format in VR mode*2
(page 69)
Format in Video
*2
mode
(page 69)
Automatically
formatted
Automatically
formatted
Compatibility with other
DVD players (finalizing)
Playable on DVD+RW
compatible players
(automatically finalized)
Playable only on VR mode
compatible players (finalization
unnecessary) (page 91)
Playable on most DVD players
(finalization necessary)
(page 91)
Playable on DVD+R compatible
players (finalization necessary)
(page 91)
Playable on most DVD players
(finalization necessary)
(page 91)
Usable disc versions (as of May 2005)
• 4×-speed or slower DVD+RWs
• 2×-speed or slower DVD-RWs (Ver.1.1, Ver.1.1
with CPRM
*1
)
• 4×-speed or slower DVD-RWs (Ver.1.2, Ver.1.2
with CPRM)
• 8×-speed or slower DVD+Rs
• 8×-speed or slower DVD-Rs (Ver.2.0)
• 2.4×-speed DVD+R DL (Double Layer) discs
30
“DVD+RW,” “DVD-RW,” “DVD+R,” “DVD+R DL,”
and “DVD-R” logos are trademarks.
*5
