M-crew

Version 1.05E

On-line Manual

4-231-460-12 (1)

PCLK-MN10A

2001 Sony Corporation

• Duplication of any or all of the contents of this software and instruction manual or lending of this software to third parties without the express permission of the copyright holder is strictly prohibited by copyright law.

• Sony cannot be held liable in any way for monetary losses, lost profits or claims from third parties arising from the use of this software.

• Should any manufacturing defects occur, Sony’s responsibility shall be limited solely to replacing said defective merchandise.

• This software is approved for use only with the specified equipment.

• Sony reserves the right to change software specifications without prior notice.

• M-crew, PictureGear and VAIO are the registered trademarks of Sony Corporation.

• Microsoft, MS-DOS and Windows are the registered trademarks of Microsoft Corporation.

• IBM and PC/AT are the registered trademarks of International Business Machines Corporation.

• Macintosh is the registrated trademark of Apple Computer Inc.

• Adobe and Adobe Acrobat Reader are the trademarks of Adobe Systems Incorporated.

• Other companies and product names are the trademarks or the registered trademarks of each company.

Table of contents

Preparation

Functional restrictions that vary with the

connected system stereo component ... 4

Display items and functions ........................... 5

Main bar ................................................... 5

Tool bar .................................................... 7

CD bar ...................................................... 9

CD window ........................................... 10

MD bar ................................................... 13

MD window .......................................... 14

TUNER bar ............................................ 18

TUNER window ................................... 19

OTHERS bar .......................................... 21

OTHERS window ................................. 22

PC-CD bar .............................................. 23

PC-CD window ..................................... 24

AudioFile bar ........................................ 27

File window ........................................... 28

Disc Library window ........................... 32

Rec window ........................................... 34

“Option” dialog box ............................. 38

Timer window.......................................39

Operating the CD player

Listening to a CD ............................................ 40

Listening to a CD using the CD or

PC-CD bar .................................... 40

Listening to a CD using the CD or

PC-CD window ........................... 40

Assigning names to CDs ............................... 42

Assigning track names with text data

from another application ........... 43

Using disc and track name data in

other applications ....................... 44

Adding an image to the CD or PC-CD

Jacket display .............................. 45

Performing MD operations

Listening to an MD ......................................... 46

Listening to an MD using

the MD bar ................................... 46

Listening to an MD using

the MD window .......................... 47

Assigning names to MDs...............................48

Assigning disc or track names ............ 48

Assigning track names with the text

data stored in the Disc

Library .......................................... 49

Assigning track names with text data

from another application ........... 50

Using disc and track name data in

other applications ....................... 52

Adding an image to the MD Jacket

display .......................................... 53

Recording to an MD ....................................... 54

Recording from a CD to an MD..........54

Recording from the tuner to

an MD ........................................... 59

Recording music files from the PC to

an MD ........................................... 60

Recording to an MD from other

audio sources...............................62

Editing recorded MDs....................................64

Moving tracks........................................64

Dividing tracks......................................66

Combining tracks..................................67

Erasing part of a track .......................... 69

Adding the fade-in effect after

recording ...................................... 71

Adding the fade-out effect after

recording ...................................... 73

Changing the recording level ............. 74

Erasing tracks ........................................ 76

Printing MD labels with Label Maker .........78

Launching Label Maker ....................... 78

Creating labels with Label Maker ...... 79

Operating the tuner

Listening to the radio ..................................... 86

Listening to the radio using the

TUNER bar .................................. 86

Listening to the radio using the

TUNER window ......................... 87

Assigning names to radio stations ............... 88

Adding an image to the TUNER Jacket

display .......................................... 89

Editing preset numbers ................................. 90

Operating the computer

Listening to file albums ................................. 92

Registering music files to a file

album ............................................ 92

Listening to file albums using

the AudioFile bar ........................ 93

Listening to file albums using

the File window .......................... 93

Editing a file album ........................................ 94

Creating a new file album or folder ... 94

Moving music files ............................... 95

Erasing file albums or folders ............. 96

Assigning names to file albums..........97

Adding an image to the File Jacket

display .......................................... 98

Using the disc library ..................................... 99

Viewing the disc library.......................99

Searching the disc library ..................100

Recording disc information in the

disc library .................................101

Erasing data in the disc library ......... 102

Setting optional items .................................. 103

Setting the audio input from the

computer .................................... 103

Choosing an Internet search

engine ......................................... 104

Creating an original genre.................105

Using the timers

How to use the timers .................................. 106

Setting the time ................................... 106

Setting the playback timer .................107

Setting the recording timer ............... 109

Enabling the timers ............................ 112

Preparation

Functional restrictions that vary with the connected system stereo component

The functions that can be used and the icons displayed on the M-crew Tool bar depend on the system stereo component connected to your computer. For example, M-crew may not support timer and CD-TEXT information display functions for certain system stereo components, even if those components have timer and CD-TEXT information display functions.

For more information about the system stereo components that are compatible with M-crew and the functions that are supported, please go to the following URL on the World Wide Web.

http://www.sony.co.jp/en/Products/homeaudio/

Notes

• In this manual, the term “system stereo component” refers specifically to component stereo systems (incorporating CD and MD decks) and discrete MD decks that support PC-LINK connections.

• The displays shown in this manual are those for a CMT-PX3 stereo system.

Display items and functions

Main bar

The Main bar is referred to as the CD bar (page 9) when “CD” is selected in “2 Function Name display,” as the MD bar (page 13) when “MD” is selected, as the TUNER bar (page 18) when “TUNER” is selected, and as the OTHERS bar (page 21) when “OTHERS” is selected.

2 3

1 SONY logo

Drag the logo with the left mouse button to move the Main bar up or down. Right-click the logo to display a pop-up menu.

2 Function Name display

Displays the name of the selected function. Click to display and select a function. The selectable functions will depend on the nature of the system stereo components connected to your computer.

Preparation

568

3 URL button

Opens the website for the selected disc or radio station.

Notes

• To view websites, we recommend that you use Microsoft Internet Explorer (Ver.4.0 or higher) or Netscape Navigator (Ver.4.0 or higher) as your Internet browser.

• Internet access is necessary for viewing websites. For details on how to gain access to the Internet, consult the manufacturer of your computer.

4 Volume control (only when connected to certain system stereo

components)

Adjusts the volume.

(continued)

5 Tool bar switch

Click to show or hide the Tool bar (page 7).

6 Help button

Click to open Help (see “Using Help” on page 29 of “Operating Instructions” for M-crew Version 1.05E).

7 Minimize button

Click to reduce the size of the window.

8 Close button

Click to exit M-crew.

Tool bar

Preparation

To view the Tool bar, click the Tool bar switch (page 6) in the Main bar. The icons displayed and their positions depend on the stereo system component connected. When you click a function icon in the Tool bar, the system switches to the selected function and the corresponding window appears. Note that only one window can be opened at a time.

Example 1

Example 2

1 CD icon

Click to display the CD window (page 10).

2 MD icon

Click to display the MD window (page 14).

3 TUNER icon

Click to display the TUNER window (page 19).

4 OTHERS icon

Click to display the OTHERS window (page 22).

5 TIMER icon

Click to display the Timer window (page 39). If the clock has not been set yet, the “Clock Set” dialog box (page 106) will appear. The time must be set before the Timer window can be displayed.

Note

M-crew does not support this function for certain system stereo components, even if those components have a timer function.

(continued)

6 File icon

Click to display the File window (page 28).

7 Disc Library icon

Click to display the Disc Library window (page 32).

8 Rec window icon

Click to display the Rec window (page 34).

9 Option icon

Click to display the “Option” dialog box (page 38).

0 PC-CD icon (only when connected to an MDS-series MD deck)

Click to display the PC-CD window (page 24).

CD bar

Preparation

To view the CD bar, click “CD” in the Function Name display (page 5) in the Main bar. Use this bar during CD player operations (page 40).

1 2 3 4 5

1 Function Name display 2 Disc Information display

Click to select the CD to play. The name of the selected CD appears in the Disc Information display. (CDs other than CD1 are available only when your system stereo component is equipped with a CD changer.)

3 Track Number/Track Name display

Click to select the track to play.

4 Time display

Click to select the time display mode.

Display mode Display contents

Total Time Total playing time of all tracks on the CD Elapsed Time Elapsed playing time of the current track Track Remain Remaining playing time of the current track Disc Remain Remaining playing time of the CD

5 CD operation buttons

: Play button : Pause button : Stop button : AMS* (PREV and NEXT) buttons

* AMS: Automatic Music Sensor. This function searches for the beginning of

a track.

CD window

To view the CD window, click the CD icon in the Tool bar (page 7). Use this window to operate the CD player (page 40).

3 2

6 7 8

1 CD operation panel

: Play button

: Pause button : Stop button : AMS* (PREV and NEXT) buttons : Reverse and fast-forward buttons

* AMS: Automatic Music Sensor. This function searches for the beginning of

a track.

2 EJECT button

3 Reload button

Click to refresh the “qa Track Name display” and “qs Disc Information display.”

4 Jacket display

Displays an image of your choice (bitmapped or JPEG file) (page

45).

Click to select all tracks on the CD.

5 Function Tree display

Click on the icon of the CD to be played. The icon flashes while the selected disc is being loaded. During this time, no M-crew operations can be initiated. You can drag the boundary to resize the display box.

6 Disc property button

Click to enter the properties of the currently selected CD. Artist : Enter the name of the artist. URL : Enter the URL of the website that is displayed when the

URL button in the Main bar is clicked.

Genre : Enter the music genre.

7 Play mode button

(Play mode button appears only when your system stereo component is equipped with a CD changer.)

ALL DISCS : Plays all CDs loaded in the system stereo

component.

1 DISC : Plays a single CD.

Preparation

8 Repeat mode selector

Selects a repeat mode. REPEAT : Plays a single CD repeatedly. REPEAT 1 : Plays a single track repeatedly. REPEAT OFF : Turns off the repeat function.

9 Internet search button

Initiates a search for websites based on keywords entered in the dialog box.

Notes

• To view websites, we recommend that you use Microsoft Internet Explorer (Ver.4.0 or higher) or Netscape Navigator (Ver.4.0 or higher) as your Internet browser.

• Internet access is necessary for viewing websites. For details on how to gain access to the Internet, consult the manufacturer of your computer.

(continued)

0 Time display

Click

to select a time display mode.

Display mode Display contents

qa Track Name display

Displays the track names. Click the track number to select it. Click the track name to modify it (page 42). Right-click the track name to display a pop-up menu, and then select “Save to CSV file” to save the disc and track names to a CSV (Comma Separated Value) formatted file (page 44).

You can also copy and paste text that has already been entered (page 42).

qs Disc Information display

Displays the disc number and disc name. Click the disc name to modify it (page 42). Right-click the disc name to display a pop-up menu, and then select “Save to CSV file” to save the disc name track names to a CSV (Comma Separated Value) formatted file (page 44).

You can also copy and paste text that has already been entered (page 42).

qd Close button

Click to close the CD window.

Note

To deselect the currently selected track, click on an empty area (i.e., a place with no button or function key) in the Time display.

MD bar

Preparation

To view the MD bar, click MD in the Function Name display (page 5) in the Main bar. Use this bar when performing MD operations (page 46).

1 Function Name display 2 Disc Information display

Click to select the MD to play. (MDs other than MD1 are available only when your system stereo component is equipped with an MD changer.)

3 Track Number/Track Name display

Click to select the track to play.

4 Time display

Click to select the time display mode.

Display mode Display contents

Total Time Total playing time of all tracks on the MD Elapsed Time Elapsed playing time of the current track Track Remain Remaining playing time of the current track Disc Remain Remaining playing time of the MD

5 MD operation buttons

: Play button : Pause button : Stop button

3 4

: AMS* (PREV and NEXT) buttons

* AMS: Automatic Music Sensor. This function searches for the beginning of

a track.

MD window

To view the MD window, click the MD icon in the Tool bar (page 7). Use this window to perform MD operations (page 46).

6 7 8

0qa

1 MD operation panel

: Play button : Pause button : Stop button : AMS* (PREV and NEXT) buttons

qd qs

: Reverse and fast-forward buttons

* AMS: Automatic Music Sensor. This function searches for the beginning of

a track.

2 EJECT button

3 Reload button

Click to refresh the “qf Track Name display” and “qg Disc Information display.”

4 Jacket display

Displays an image of your choice (bitmapped or JPEG file) (page

53).

Click to select all tracks on the MD.

5 Function Tree display

Click on the icon of the MD to play. The icon flashes while the selected disc is being loaded. During this time, no M-crew operations can be initiated. You can drag the boundary to resize the display box.

6 Disc property button

Click to enter the properties of the currently selected MD. Artist : Enter the name of the artist. URL : Enter the URL of the website that is displayed when the

URL button in the Main bar is clicked.

Genre : Enter the music genre.

7 Play mode button

(Play mode button appears only when your system stereo component is equipped with an MD changer.)

ALL DISCS : Plays all MDs loaded in the system

stereo component. 1 DISC : Plays a single MD. MD SEAMLESS ON/OFF: Selects seamless play mode or normal

play mode.

Preparation

8 Repeat mode selector

Selects a repeat mode. REPEAT : Plays a single MD repeatedly. REPEAT 1 : Plays a single track repeatedly. REPEAT OFF : Turns the repeat function off.

9 Print button

Click to activate the Label Maker software.

(continued)

0 Internet search button

Initiates a search for websites based on keywords entered in the dialog box.

Notes

• To view websites, we recommend that you use Microsoft Internet Explorer (Ver.4.0 or higher) or Netscape Navigator (Ver.4.0 or higher) as your Internet browser.

• Internet access is necessary for viewing websites. For details on how to gain access to the Internet, consult the manufacturer of your computer.

qa MD edit buttons

: Undo button

Click to cancel the most recent edit action performed (except during a data entry or S.F edit operation).

: MOVE button

Click to open the “Move” dialog box (page 64).

: COMBINE button

Click to open the “Combine” dialog box (page 67).

: A-B ERASE button

Click to open the “A-B Erase” dialog box (page 69).

: DIVIDE button

Click to open the “Divide” dialog box (page 66).

: FADE IN button

Click to open the “Fade in” dialog box (page 71).

: FADE OUT button

Click to open the “Fade out” dialog box (page 73).

: LEVEL SHIFT button

Click to open the “Level Shift” dialog box (page 75).

: ERASE (recycle bin) button

Click to open the “Erase” dialog box (page 76).

qs Disc Capacity display

Preparation

Disc space already used

Disc space to be used

Free space

qd Time display

Click

to select the time display mode.

Display mode Display contents

Remain Time Total remaining recording time of the MD Total Time Total playing time of all tracks on the MD Elapsed Time Elapsed playing time of the current track Track Remain Remaining playing time of the current track Disc Remain Remaining playing time of the MD

qf Track Name display

Displays the track names. Click the track number to select it. Click the track name to modify it (page 48). Right-click the track name to display a pop-up menu, and then select “Save to CSV file” to save the disc name track names to a CSV (Comma Separated Value) formatted file (page 52). You can also copy and paste text that has already been entered (page 48).

qg Disc Information display

Displays the disc number and disc name. Click the disc name to modify it (page 48). Right-click the disc name to display a pop-up menu, and then select “Save to CSV file” to save the disc and track names to a CSV (Comma Separated Value) formatted file (page 52). You can also copy and paste text that has already been entered (page 48).

qh Close button

Click to close the MD window.

Note

To deselect the currently selected track, click on an empty area (i.e., a place with no button or function key) in the Time display.

TUNER bar

To view the TUNER bar, select TUNER on the Function Name display in the Main bar (page 5). Use this bar when operating the tuner (page

86).

3 4

1 Radio Band display

Click to select a band.

2 Preset Number/Broadcasting Station Name display

Click to select a preset station.

3 Frequency display 4 Tuner operation buttons

: BAND button : Preset up button : Preset down button : URL button

Click to open the website set to the current preset number (page 90).

Notes

• To view websites, we recommend that you use Microsoft Internet Explorer (Ver.4.0 or higher) or Netscape Navigator (Ver.4.0 or higher) as your Internet browser.

• Internet access is necessary for viewing websites. For details on how to gain access to the Internet, consult the manufacturer of your computer.

TUNER window

To view the TUNER window, click the TUNER icon in the Tool bar (page 7). Use this window to operate the tuner (page 86).

Preparation

1 Tuner operation buttons

: BAND button

Click to select a band.

: Preset up button

: Preset down button : EDIT button

Click to open the “Edit” dialog box (page 90). Use the “Edit” dialog box to edit the preset station settings.

2 Reload button

Click to refresh the system stereo component preset information displayed in “7 Preset display.”

(continued)

3 Jacket display

Displays an image of your choice (bitmapped or JPEG file) for each preset number (page 89).

4 Function Tree display

Displays the currently selected band. You can drag the boundary to resize the display box.

5 Internet search button

Initiates a search for websites based on keywords entered in the dialog box.

Notes

• To view websites, we recommend that you use Microsoft Internet Explorer (Ver.4.0 or higher) or Netscape Navigator (Ver.4.0 or higher) as your Internet browser.

• Internet access is necessary for viewing websites. For details on how to gain access to the Internet, consult the manufacturer of your computer.

6 URL display

Displays the URL set to the selected preset station.

7 Preset display

Click a preset number to select the preset station. Click the station name to modify it (page 88).

8 Close button

Click to close the TUNER window.

OTHERS bar

To view the OTHERS bar, select OTHERS in the Function Name display (page 5) in the Main bar. Use this bar when operating an external component connected to a system stereo component.

1 Function Name display

Preparation

Displays the name of the external component connected to the system stereo component.

OTHERS window

To view the OTHERS window, click the OTHERS icon in the Tool bar (page 7). Use this window to listen to the audio from external audio components connected to a system stereo component.

1 Function Tree display

Click the external audio component that you want to listen to. You can drag the boundary to resize the display box.

2 External Component display

The currently selected component is enclosed in a yellow box.

3 Close button

Click to close the OTHERS window.

PC-CD bar

Preparation

To view the PC-CD bar, click “PC-CD” in the Function Name display (page 5) in the Main bar. Use this bar to operate a CD in the CD-ROM drive of your computer (page 40).

54321

1 Function Name display 2 Disc Information display

The name of the selected CD appears in the Disc Information display. (CDs other than CD1 are available only when you use multiple CDROM drives on your computer.)

3 Track Number/Track Name display

Click to select the track to play.

4 Time display

Click to select the time display mode.

Display mode Display contents

Total Time Total playing time of all tracks on the CD Elapsed Time Elapsed playing time of the current track Track Remain Remaining playing time of the current track

5 PC-CD operation buttons

: Play button : Pause button : Stop button : AMS* (PREV and NEXT) buttons

* AMS: Automatic Music Sensor. This function searches for the beginning of

a track.

PC-CD window

To view the PC-CD window, click the PC-CD icon in the Tool bar (page

7). Use this window to operate the CD loaded in the CD-ROM drive in your computer (page 40).

3 2

1 CD operation panel

: Play button

: Pause button : Stop button : AMS* (PREV and NEXT) buttons : Reverse and fast-forward buttons

* AMS: Automatic Music Sensor. This function searches for the beginning of

a track.

2 EJECT button 3 Reload button

Click to refresh the “0 Track Name display” and “qa Disc Information display.”

4 Jacket display

Displays an image of your choice (bitmapped or JPEG file) (page

45). Click to select all tracks on the CD.

5 Function Tree display

Click on the icon of the CD to be played. You can drag the boundary to resize the display box.

6 Disc property button

Click to enter the properties of the currently selected CD. Artist : Enter the name of the artist. URL : Enter the URL of the website that is displayed when the

URL button in the Main bar is clicked.

Genre : Enter the music genre.

7 Repeat mode selector

Selects a repeat mode. REPEAT : Plays a single CD repeatedly. REPEAT 1 : Plays a single track repeatedly. REPEAT OFF : Turns off the repeat function.

Preparation

8 Internet search button

Initiates a search for websites based on keywords entered in the dialog box.

Notes

• To view websites, we recommend that you use Microsoft Internet Explorer (Ver.4.0 or higher) or Netscape Navigator (Ver.4.0 or higher) as your Internet browser.

• Internet access is necessary for viewing websites. For details on how to gain access to the Internet, consult the manufacturer of your computer.

(continued)

9 Time display

Click

to select the time display mode.

Display mode Display contents

Total Time Total playing time of all tracks on the CD Elapsed Time Elapsed playing time of the current track Track Remain Remaining playing time of the current track

0 Track Name display

Displays the track name. Click the track number to select it. Click the track name to modify it (page 42). Right-click the track name to display a pop-up menu, and then select “Save to CSV file” to save the disc and track names to a CSV (Comma Separated Value) formatted file (page 44). You can also copy and paste text that has already been entered (page 42).

qa Disc Information display

Displays the disc number and disc name. Click the disc name to modify it (page 42). Right-click the disc name to display a pop-up menu, and then select “Save to CSV file” to save the disc and track names to a CSV (Comma Separated Value) formatted file (page 44). You can also copy and paste text that has already been entered (page 42).

qs Close button

Click to close the PC-CD window.

Note

To deselect the currently selected track, click on an empty area in the Time display.

AudioFile bar

To view the AudioFile bar, click “AudioFile” in the Function Name display (page 5) in the Main bar. Use this bar to operate music files stored on your computer’s hard disk (page 92).

1 File Information display

Click to select the file album to play. The name of the selected file album appears in the File Information display.

2 Track Number/Track Name display

Click to select the track to play.

3 Time display

Click to select the time display mode.

Display mode Display contents

Total Time Total playing time of all tracks in the file album Elapsed Time Elapsed playing time of the current track Track Remain Remaining playing time of the current track

Preparation

4321

4 Music files operation buttons

: Play button : Pause button : Stop button : AMS* (PREV and NEXT) buttons

* AMS: Automatic Music Sensor. This function searches for the beginning of

a track.

File window

To view the File window, click the File icon in the Tool bar (page 7), and then click the file album in the Function Tree display. Use this window to play the music files stored on your computer’s hard disk (page 92).

4 5 6

qs qa 0

1 File album operation panel

: Play button : Pause button : Stop button : AMS* (PREV and NEXT) buttons : Reverse and fast-forward buttons

* AMS: Automatic Music Sensor. This function searches for the beginning of

a track.

2 Jacket display

Displays an image of your choice (bitmapped or JPEG file) (page

98).

Click to select all tracks in a file album.

3 Function Tree display

Click on the icon of the file album to play. You can drag the boundary to resize the display box.

4 Disc property button

Set the properties of the track or file album currently displayed. Click this button with no track name selected to set the properties of the file album. Click this button with a track name selected to set the properties of the track. Track properties can only be set in the File window.

Artist : Enter the name of the artist. URL : Enter the URL of the website that is displayed when the

URL button in the Main bar is clicked.

Genre : Enter the music genre.

5 File edit buttons

: Create new folder button

Click to create a new folder. Multiple File Album can be placed inside a folder.

: Create new file album button

Click to create a new File Album.

Preparation

: File registration button

Click to register a music file.

6 Repeat mode selector

Selects a repeat mode. REPEAT : Plays a single file album repeatedly. REPEAT 1 : Plays a single track repeatedly. REPEAT OFF : Turns the repeat function off.

(continued)

7 Cancellation (eraser) button

Click to display the “Erase” dialog box (page 96).

8 Time display

Click

Display mode Display contents

Total Time Total playing time of all tracks being displayed in

Elapsed Time Elapsed playing time of the current track Track Remain Remaining playing time of the current track

9 Track Name display

Displays the track name. Click the track number to select it. Click the track name to modify it (page 97). Right-click the track name to display a pop-up menu, and then select “Save to CSV file” to save the disc and track names to a CSV (Comma Separated Value) formatted file. You can also copy and paste text that has already been entered (page 97). You can also register a music file by dragging it from Explorer and dropping it into the Track Name display.

0 File Information display

Displays a folder name and an album name. Click the folder name or album name to modity it (page 97). Right-click to display a pop-up menu, and then select “Save to CSV file” to save the file and track names to a CSV (Comma Separated Value) formatted file. You can also copy and paste text that has already been entered (page 97).

to select a time display mode.

the Track Name display.

qa Display mode selector

Click

to select the display mode for file and track names.

Display mode Display contents

Title Name Track name File Name File name Title Name/File Name Track and file names

qs Close button

Click to close the File window.

Notes

• To deselect the currently selected track, click on an empty area (i.e., a place with no button or function key) in the Time display.

• In M-crew, the original music file is registered, not a copy. Therefore, when you delete a registered music file or rename it using Explorer or another file management tool, M-crew will no longer be able to play that music file.

• A dimmed track name indicates that some abnormality has happened to the track and that it cannot be played back by M-crew.

• M-crew identifies and plays back music files according to the file name. This key attribute must therefore never be changed.

Preparation

Disc Library window

To view the Disc Library window, click the Disc Library icon in the Tool bar (page 7). Use this window to view or reuse data on the media that were played at least once before (page 99).

6754

1 Jacket display

Displays the image assigned to the disc.

2 Function Tree display

Selects the medium within the disc library. You can drag the boundary to resize the display box.

3 Disc property button

Click to enter the properties of the currently selected disc library window.

Artist : Enter the name of the artist. URL : Enter the URL of the website that is displayed when the

URL button in the Main bar is clicked.

Genre : Enter the music genre.

4 Print button

Click to activate the Label Maker software for the MD.

5 Internet search button

Initiates a search for websites based on keywords entered in the dialog box.

Notes

• To view websites, we recommend that you use Microsoft Internet Explorer (Ver.4.0 or higher) or Netscape Navigator (Ver.4.0 or higher) as your Internet browser.

• Internet access is necessary for viewing websites. For details on how to gain access to the Internet, consult the manufacturer of your computer.

6 Disc library search button

Click to open the “Disc Library Search” dialog box (page 100).

7 Erase (recycle bin) button

Click to erase discs in the disc library one at a time (page 102).

8 Track Name display

Displays the track name. Click the track number to select it. Right-click the track name to display a pop-up menu, and then select “Save to CSV file” to save the disc and track names to a CSV (Comma Separated Value) formatted file.

9 Disc Library Information display

Displays the disc name and disc properties registered in the disc library. Right-click to display a pop-up menu, and then select “Save to CSV file” to save the disc and track names to a CSV (Comma Separated Value) formatted file.

Preparation

0 Close button

Click to close the Disc Library window.

Rec window

To view the Rec window, click the Rec window icon in the Tool bar (page 7). Use this window to record to an MD from the CD player, tuner, optional external component connected to a system stereo component or other sources (pages 54, 59, 60, 62). The recording destination window on the right is always the MD window. The recording source window on the left can be selected from the Function Tree display. The Rec window has a different appearance in synchro recording mode and in manual recording mode. In synchro recording mode, it is possible to record from a CD, PC-CD, or file album.

Synchro recording mode

2 8

1 REC button

Starts recording the tracks and radio stations that have been entered in the right-side (destination) window.

2 Add button

Adds the tracks that have been selected in the left-side (source) window to the right-side (destination) window.

3 Undo button

Deletes specified tracks from the destination window (before the REC button is clicked).

4 Manual button

Selects manual recording mode.

5 Synchro speed change button

Changes the synchro speed to NORMAL (normal speed) or HIGH (high speed).

6 Recording Mode display

STEREO : Stereo recording MONO : Monaural* recording LP2 : 2 × (2 × normal recording time) stereo recording LP4 : 4 × (4 × normal recording time) stereo recording

* The monaural recording time is about twice that of stereo.

7 Erase (recycle bin) button

Erases a recorded track (This function does not work when the system stereo component is in recording pause mode.).

Deselects a track selected for recording. Drag the track number from the Track Name display in the MD

window and drop it into .

8 Close button

Click to close the Rec window.

Preparation

Note

To deselect currently selected track, click on an empty area (i.e., a place with no button or function key) in the Time display.

(continued)

Manual recording mode

2 9

354

1 REC button

Changes the unit to recording pause mode. Click window to start recording to the MD.

* To start recording immediately, click the Rec button before playing the

source CD or sound file.

2 Fader button

Starts the fade-in/fade-out effect.

3 Synchro button

Activates synchro recording mode.

4 System recording mode button

(The system recording mode button appears only when your system stereo component is equipped with an MD changer.)

ALL DISCS : Recording is performed in sequence to

1 DISC : Recording is performed to a single MD. MD SEAMLESS ON/OFF :Selects MD seamless mode or normal

When ALL DISCS and normal recording mode are selected, playback will continue even while the MD is being changed, resulting in a break in the recorded sound. In MD seamless mode, playback is paused while the MD is changed. Tracks recorded and played back in MD seamless mode will have no break in the recorded sound.

all MDs loaded in the system stereo component.

recording mode.

in the MD

5 Recording level adjustment button

Opens the “Rec Level Adjust” dialog box (pages 56, 60, 61, 63).

6 Set up button

Opens the “Set Up” dialog box for use of the following functions: Smart Space : The gaps between recorded tracks are

trimmed to about 3 seconds.

Track Mark Level Sync : Sets the gap detection level for automatic

track marking.

Fader :Sets the fade-in/fade-out effect.

7 Recording Mode display

STEREO : Stereo recording MONO : Monaural* recording LP2 : 2 × (2 × normal recording time) stereo recording LP4 : 4 × (4 × normal recording time) stereo recording

* The monaural recording time is about twice that of stereo.

8 Erase (recycle bin) button

Erases a recorded track. Drag the track number from the Track Name display in the MD

window and drop it into .

9 Close button

Click to close the Rec window.

Preparation

Note

To deselect currently selected track, click on an empty area (i.e., a place with no button or function key) in the Time display.

“Option” dialog box

To view the “Option” dialog box, click the Option icon in the Tool bar (page 7). Use this dialog box to enter settings for PC Input, search engine, and original genre.

1 2

1 PC Input tab

Click to open the “PC Input” dialog box (page 103).

2 Search Engine tab

Click to open the “Search Engine Default Setting” dialog box (page

104).

3 Original Genre tab

Click to open the “Original Genre Setting” dialog box (page 105).

Timer window

To view the Timer window, click the TIMER icon in the Tool bar (page

7). Use this window to set a timer (pages 107, 109). If the clock has not been set yet, the “Clock Set” dialog box (page 106) will appear. The clock must be set before the Timer window can be displayed.

1 Timer set button

Click to open the “Timer Set” dialog box (pages 107, 109).

2 REC Timer display

Displays the timer settings for recording.

Preparation

3 Play Timer display

Displays the timer setting for playing.

4 Close button

Click to close the Timer window.

Operating the CD player

Listening to a CD

Listening to a CD using the CD or PC-CD bar

1 Display the CD or PC-CD bar (pages 9, 23). 2 Click the Disc Information display in the CD or PC-CD bar.

A list of CDs appears. (A CD list is displayed only when your system stereo component is equipped with a CD changer or you use multiple CD-ROM drives on your computer. Otherwise, proceed to step 4.)

3 Click the CD (in the list) that you want to play.

The selected CD appears in the Disc Information display.

4 Click the Track Number/Track Name display in the CD or PC-CD

bar. A list of tracks appears.

5 Click the track (in the list) that you want to play.

Sequential playback of the tracks starts with the selected track.

Listening to a CD using the CD or PC-CD window

The same basic steps below are used to listen to a CD loaded in the system stereo component and a CD loaded in the CD-ROM drive of your computer.

1 Open the CD window or the PC-CD window (pages 10, 24). 2 Click or double-click the CD (in the Function Tree display) that you

want to play. A list of the tracks on the selected CD appears in the Track Name display.

3 Click the track number of the track (in the Track Name display)

that you want to play. Playback of the track also starts when you double click the track number.

4 Click in the CD window (only if you clicked a track number in

step 3). Sequential playback of the tracks begins with the track selected in step 3.

Note

If you play a CD using the PC-CD window, no audio signal will be output from the PC link kit if the “Enable digital CD audio for this CD-ROM drive.” check box is not selected under the “CD Music” tab in the “Multimedia Properties” dialog box on your computer.

Operating the CD player

Assigning names to CDs

You can assign names to discs and tracks, as well as assign names using text data from another application (page 43) and use disc and track name data in other application (page 44).

1 Open the CD window or the PC-CD window (pages 10, 24). 2 Click the CD (in the Function Tree display) that you want to name,

and then click the Disc Information display. To assign a name to a track, click the track name of the track in the Track Name display. The edit mode for entering the name is activated.

3 Input the name.

Right-clicking in the edit mode opens up a pop-up menu that lets you copy and paste previously entered text data.

4 Press the ENTER key.

The name that you typed in is entered and the system becomes ready for input of the next name.

Notes

• Disc and track names are saved to the hard disk in your computer. Do not delete, move or, modify the folder in which these names are stored.

• Disc and track names are displayed only within M-crew, and not on any of the system stereo components. Names (disc memos) that are saved on a system stereo component appear only on that component and not in M-crew.

• If you name a CD containing CD-text, the CD-text information will no longer be displayed afterwards. If you want to view the CD-text information, click the Reload button in the CD or PC-CD window (page 10,

24). Please note that clicking the Reload button will cause all discs and track names assigned to the CD to be deleted.

Assigning track names with text data from another application

You can use a text editor such as Notepad to enter track names in advance, and then use the data to assign names to all tracks in a single operation.

1 Type in the track names as shown in the example below, using

Notepad or other text editing software. Example Track name of the third track<ENTER>

Track name of the fourth track<ENTER> Track name of the fifth track<ENTER>

Track name of the eighth track<ENTER>

2 Copy the text and paste it to the clipboard using the editing menu

of the text editing software. The copy and paste procedure may vary according to the text editing software. For details, refer to the instructions provided with the text editing software.

3 Click the track name of the track (in the Track Name display) that

you want to name. Following the example text given in step 1, click the third track. The edit mode for entering track names is activated.

4 Right-click to display a pop-up menu, and click “Paste.”

In this example, the track names created and copied through the text editing software are entered as the track names of the third to eighth tracks.

Operating the CD player

Notes

• Disc and track names are saved to the hard disk in your computer. Do not delete, move or, modify the folder in which these names are stored.

24). Please note that clicking the Reload button will cause all discs and track names assigned to the CD to be deleted.

Using disc and track name data in other applications

Saving disc and track names entered in M-crew to a CSV (Comma Separated Value) formatted file allows this data to be used in database software, spreadsheets and other software.

1 Open the CD window or the PC-CD window (pages 10, 24). 2 Right-click the Track Name display.

A pop-up menu appears.

3 Click “Save As CSV File” in the pop-up menu.

A “Save As” dialog box appears.

4 Input a CSV file name and click “Save.”

The CSV file is saved and becomes available for use in database software or spreadsheets.

z Tip

M-crew cannot read CSV files, but it can record disc and track names that have been created by and input from another application (page 43).

Adding an image to the CD or PC-CD Jacket display

You can add one jacket image (bitmapped or JPEG file) for each disc.

1 Open the CD or PC-CD window (page 10, 24). 2 Drag a bitmapped image file from the Explorer and drop it onto the

Jacket display. The bitmapped image will appear in the Jacket display.

z Tips

• The bitmapped image file that is dragged and dropped is copied to the Jacket folder (default location: C:\Program Files\M_crew\Jacket), which is located in the same folder as the M-crew application.

• When the image in the Jacket folder is deleted, the image in the Jacket display will not disappear. To delete the Jacket display image, right-click the Jacket display, and then click “Initialize image.” The image file in the Jacket folder, on the other hand, is not affected when the Jacket display image is deleted.

Operating the CD player

Performing MD operations

Listening to an MD

Listening to an MD using the MD bar

1 Display the MD bar (page 13). 2 Click the Disc Information display on the MD bar.

A list of MDs appears. (An MD list is displayed only when your system stereo component is equipped with an MD changer. Otherwise, proceed to step 4.)

3 Click the MD (in the list) that you want to play.

MD text data are read in.

4 Click the Track Number/Track Name display in the MD bar.

A list of tracks appears.

5 Click the track (in the list) that you want to play.

Sequential playback of the tracks starts with the selected track.

Listening to an MD using the MD window

1 Open the MD window (page 14). 2 Click the MD (in the Function Tree display) that you want to play.

A list of the tracks on the selected MD appears in the Track Name display.

3 Click the track number of the track (in the Track Name display)

that you want to play. Playback of the track also starts when you double click the track number.

4 Click in the MD window (only if you clicked a track number in

step 3). Sequential playback of the tracks begins with the track selected in step 3.

Performing MD operations

Assigning names to MDs

Assigning disc or track names

Before you begin

• Only alphanumeric characters and the symbols listed below can be

used in disc and track names: ! ” # $ % & ’ ( ) * + , – . / : ; < = > ? @ _ ‘ All other characters will not be correctly displayed.

• Disc or track names cannot be recorded or edited on a write-

protected MD. To do so, first slide the write-protect tab on the MD to enable writing.

1 Open the MD window (page 14). 2 Click the MD (in the Function Tree display) that you want to name,

and then click the Disk Information display. To assign a name to a track, click the track name of the track in the Track Name display. The edit mode for entering the name is activated.

3 Input the name.

Right-clicking in the edit mode opens up a pop-up menu that lets you copy and paste previously entered text data.

4 Press the ENTER key.

The name that you typed in is entered and the system becomes ready for input of the next name.

Note

Disc and track names are saved to both the MD and your computer’s hard disk. If you modify the name of a track on the system stereo component, the track name may no longer match the one displayed in M-crew. To correctly display track names that have been modified on the MD, click the Reload button in the MD window (page 15).

Assigning track names with the text data stored in the Disc Library

Track names that have been assigned to a disc and stored in the Disc Library can be reassigned in a single operation to another disc with the same contents.

1 Open the Disc Library window (page 32). 2 Right-click the Track Name display.

A pop-up menu appears.

3 Click “Copy all text information” in the pop-up menu.

The text information is temporarily stored.

Performing MD operations

4 Open the MD window (page 14). 5 Right-click the Track Name display.

A pop-up menu appears.

6 Click “Paste all text information” in the pop-up menu.

Note

Assigning track names with text data from another application

You can use a text editor such as Notepad to enter track names in advance, and then use the data to assign names to all tracks in a single operation.

Before you begin

• Only alphanumeric characters and the symbols listed below can be

used in disc and track names: ! ” # $ % & ’ ( ) * + , – . / : ; < = > ? @ _ ‘ All other characters will not be correctly displayed.

• Disc or track names cannot be recorded or edited on a write-

protected MD. To do so, first slide the write-protect tab on the MD to enable writing.

1 Type in the track names as shown in the example below, using

Notepad or other text editing software. Example Track name of the third track<ENTER>

Track name of the fourth track<ENTER> Track name of the fifth track<ENTER>

Track name of the eighth track<ENTER>

2 Copy the text and paste it to the clipboard using the editing menu

of the text editing software. The copy and paste procedure may vary according to the text editing software. For details, refer to the instructions provided with the text editing software.

3 Click the track name of the track (in the Track Name display) that

you want to name. Following the example text given in step 1, click the third track. The edit mode for entering track names is activated.

4 Right-click to display a pop-up menu, and click “Paste.”

In this example, the track names created and copied through the text editing software are entered as the track names of the third to eighth tracks.

Note

Performing MD operations

Using disc and track name data in other applications

Saving disc and track names entered in M-crew to a CSV (Comma Separated Value) formatted file allows this data to be used in database software, spreadsheets and other software.

1 Open the MD window (page 14). 2 Right-click the Track Name display.

A pop-up menu appears.

3 Click “Save As CSV File” in the pop-up menu.

A “Save As” dialog box appears.

4 Input a CSV file name and click “Save.”

The CSV file is saved and becomes available for use in database software or spreadsheets.

z Tip

M-crew cannot read CSV files, but it can record disc and track names that have been created by and input from another application (page 50).

Adding an image to the MD Jacket display

You can add one jacket image (bitmapped or JPEG file) for each disc.

1 Open the MD window (page 14). 2 Drag a bitmapped image file from the Explorer and drop it onto the

Jacket display. The bitmapped image will appear in the Jacket display.

z Tips

Performing MD operations

Recording to an MD

Recording from a CD to an MD

Before you begin

• You cannot record to a write-protected MD. Slide the write-protect

tab on the MD to enable writing.

• Before you begin the recording, double-click the disc icons of all the

MDs to be recorded to. This will cause the system to upload TOC information necessary for the recording operation.

• Click

recording mode.

z Tip

You can also record from a PC-CD to an MD using the same procedure described below.

Synchro recording from a CD to an MD

1 Open the Rec window (page 34). 2 Click the Synchro button (page 36). 3 (Only for certain system components) Click the Synchro speed

change button (page 35).

on the Recording Mode display (page 35) to select the

4 Click the destination MD in the Function Tree display in the MD

window. The names of the tracks on the MD appear in the Track Name display in the MD window. If the track names do not appear, double-click the destination MD.

5 Click the source CD in the Function Tree display in the CD

window. The names of the tracks on the CD appear in the Track Name display in the CD window. If the track names do not appear, double-click the source CD.

6 Drag the number of the track you want to record from the Track

Name display in the CD window and drop it into the Track Name or Disk Information display in the MD window. The dropped track appears in orange in the Track Name display in the MD window, which indicates that it is a track to be recorded. You can register a track to be recorded by selecting the track and pressing the Add button. Repeat the procedure from step 4 to specify other tracks for recording. Two or more tracks can be selected at the same time by clicking the desired track numbers while holding down the CTRL key. To specify all tracks on a CD, drag and drop the CD disc icon (for example, CD1) from the Disc Information display into the MD window. Repeat the procedure from step 4 to record from more than one CD.

Note

If the tracks that you have dragged and dropped cannot be contained on a single MD, the dragging operation is canceled and the message “Insufficient free recording space” appears.

7 Click the REC button in the Rec window.

Recording from the CD to the MD starts. To stop recording, click

in the MD window.

Performing MD operations

Deselecting tracks that have been selected for recording

To deselect a track that has been selected for recording, drag the track number from the Track Name display in the MD window and drop it into Alternatively, you may click the track, and then click the Undo button to cancel the track selection. To cancel all selected tracks, click

in the MD window.

(continued)

Recording from a CD to an MD manually

1 Open the Rec window (page 34). 2 Click the Manual button (page 35). 3 Click the System recording mode button in the Rec window to make

settings for the MD changer (page 36). (System recording mode button appears only when your system stereo component is equipped with an MD changer. Otherwise, proceed to step 4.)

4 Click the REC button.

The MD recorder changes to record-pause mode.

5 Click

Recording to the MD starts. To start recording with the fade-in effect, click the Fader button.

6 Play the CD in the CD window that you want to record to the MD

(page 40). To stop recording, click If you click the Fader button, the fade-out effect is recorded and the MD recorder changes to record-pause mode.

z Tip

SmartSpace, TrackMarklevelSync, and Fade can be set with the Set up button (page 37).

or the Fader button in the MD window.

in the MD window.

Adjusting the recording level

1 Open the Rec window (page 34). 2 Click the Manual button (page 35). 3 Click in the CD window. 4 Click the REC button.

The newly added track is highlighted in orange in the Track Name display in the MD window and the MD recorder changes to recordpause mode.

5 Click the Recording level adjustment button (page 37).

The “Rec Level Adjust” dialog box appears and a red line points to the peak level. Drag the slider to adjust the recording level.

6 Click

If you want to cancel the setting, click

Making settings for manual recordings

1 Open the Rec window (page 34). 2 Click the Manual button. 3 Click the Set Up button to display the “Set Up” dialog box.

4 Make settings for each items.

1 Make space between each tracks equal

If this function is set to ON during manual recording, any space between tracks that is longer than 30 seconds will be automatically shortened to 3 seconds. Click ON to activate this function or OFF to deactivate it.

2 Assign track numbers to each track automatically

If this function is set to ON, when an input signal level goes below the preset level (track space detecting level) for more than 2 seconds and goes above the preset level again, a track number is assigned to the track. Click ON to activate this function or OFF to deactivate it. Click

to select track space detecting level to assign track number.

Performing MD operations

(continued)

3 Adding the fade-in effect or fade-out effect

The beginning of a track becomes louder gradually, or the end of a track fades away gradually. When

or is clicked once, end point of fade-in or begining point of fade-out moves by 0.1 second. When

is draged to left or right, the begining point or end point

moves as you drag.

5 Click .

Set Up dialog closes. If you want to cancel the setting, click

Notes

• While recording to an MD, do not click any icon other than the TIMER icon in the Tool bar. Recording will halt if you do.

• If the MD runs out of space while tracks are being recorded from a CD, the recording operation is halted. Afterwards, M-crew may not function properly. If this happens, restart M-crew.

• If the number or name of previously recorded tracks are displayed in orange for too long, M-crew may fail to work properly after the recording operation is completed. Be sure to restart M-crew.

• If CD or MD information is not displayed correctly after completing the recording, click the Reload button to refresh the information.

• When all tracks on a CD were selected by dragging the Disc Information display in the CD window to the MD window, the tracks cannot be deselected individually. To deselect the tracks, you must deselect all of them by clicking

in the MD window.

Recording from the tuner to an MD

When you record from the tuner to an MD, M-crew enters the manual recording mode automatically. You cannot select synchro recording mode.

Before you begin

• You cannot record to a write-protected MD. Slide the write-protect tab on the MD to enable writing.

• Before you begin the recording, double-click the disc icons of all the MDs to be recorded to. This will cause the system to upload TOC information necessary for the recording operation.

1 Open the Rec window (page 34). 2 Click TUNER in the Function Tree display on the left. 3 Use the TUNER window to tune in the radio broadcast that you

want to record to the MD. (page 87).

4 Click the destination MD in the Function Tree display in the MD

window.

5 Click the REC button in the Rec window.

The MD enters recording-pause mode.

6 Click in the MD window.

Recording from the tuner to the MD starts. To stop recording, click

Recording by drag-and-drop operation

1 Open the Rec window (page 34). 2 Click TUNER in the Function Tree display. 3 Drag the station name from the TUNER window and drop it onto

the destination MD in the MD window.

4 Click

in the MD window.

Performing MD operations

(continued)

Adjusting the recording level

1 Open the Rec window (page 34). 2 Listen to the source radio in the TUNER window. 3 Click the REC button. 4 Click the Recording level adjustment button (page 37).

The “Rec Level Adjust” dialog box appears and a red line points to the peak level. Drag the slider to adjust the recording level.

Note

While recording to an MD, do not click any icon other than the TIMER icon in the Tool bar. Recording will halt if you do.

Recording music files from the PC to an MD

Before you begin

• You cannot record to a write-protected MD. Slide the write-protect tab on the MD to enable writing.

• Before you begin the recording, double-click the disc icons of all the MDs to be recorded to. This will cause the system to upload TOC information necessary for the recording operation.

1 Open the Rec window (page 34). 2 Click the Synchro button (page 36).

3 Click the source file album in the Function Tree display in the File

window. The tracks registered in the file album are displayed in the Track Name display in the File window. If the files to be recorded are stored in a folder, double-click the folder to open it.

4 Drag the number of the track you want to record from the Track

Name display in the File window and drop it into the Track Name or Disc Information display in the MD window. The dropped track appears in orange in the Track Name display in the MD window, which indicates that it is a track to be recorded. You can register a track to be recorded by selecting the track and clicking the Add button. Repeat the procedure from step 3 to specify other tracks for recording. Two or more tracks can be selected at the same time by clicking the desired track numbers while holding down the CTRL key. To specify all tracks on the file album, drag and drop the file album icon from the File Information display into the MD window. Repeat the procedure from step 3 to record from more than one file album.

Note

If the tracks that you have dragged and dropped cannot be contained on a single MD, the dragging operation is canceled and the message “Insufficient free recording space” appears.

5 Click the REC button in the Rec window.

Recording from the PC to the MD starts. To stop recording, click

Adjusting the recording level

1 Open the Rec window (page 34). 2 Click the Manual button (page 35). 3 Click 4 Click the REC button. 5 Click the Recording level adjustment button (page 37).

The “Rec Level Adjust” dialog box appears and a red line points to the peak level. Drag the slider to adjust the recording level.

Note

While recording to an MD, do not click any icon other than the TIMER icon in the Tool bar. Recording will halt if you do.

in the File window.

in the MD window.

Performing MD operations

Recording to an MD from other audio sources

Before you begin

• You cannot record to a write-protected MD. Slide the write-protect tab on the MD to enable writing.

• Before you begin the recording, double-click the disc icons of all the MDs to be recorded to. This will cause the system to upload TOC information necessary for the recording operation.

1 Open the Rec window (page 34). 2 Click the Manual button (page 35). 3 Click the desired function (audio source) in the Function Tree

display you want to record from.

4 Click the REC button in the Rec window.

MD recorder changes to record-pause mode.

5 Start playing the source you want to record. 6 Click or the Fader button in the MD window.

Recording from the selected source to the MD starts. To start recording with the fade-in effect, click the Fader button. To stop recording, click If you click the Fader button, the fade-out effect is recorded and the MD recorder changes to record-pause mode.

in the MD window.

Adjusting the recording level

1 Open the Rec window (page 34). 2 Click the desired function (audio source) in the Function Tree

display and start playing the source that you want to record.

3 Click the REC button. 4 Click the Recording level adjustment button (page 37).

The “Rec Level Adjust” dialog box appears and a red line points to the peak level. Drag the slider to adjust the recording level.

Note

While recording to an MD, do not click any icon other than the TIMER icon in the Tool bar. Recording will halt if you do.

Performing MD operations

Editing recorded MDs

Moving tracks

You can rearrange the order of tracks on an MD, but you cannot move tracks from one MD to another.

Note

While this dialog box is displayed, the MD cannot be operated by the system stereo component.

1 Open the MD window (page 14). 2 Click the number of the track in the Track Name display in the MD

window that you want to move. The name of the track is highlighted in yellow.

Note

You can move only one track per move operation. If you select more than one track, the move function is disabled.

3 Click the MD edit button .

The “Move” dialog box appears.

To cancel the move, click .

4 Click to select the number to which you want the selected track

moved.

5 Click .

The track that you selected in step 2 moves to the track number specified in step 4.

Moving a track by drag-and-drop operation

1 Open the MD window (page 14). 2 Drag the number of the track in the Track Name display in the MD

window that you want to move and drop it at the desired destination.

Moving a track that is being played

1 Open the MD window (page 14). 2 Play the track that you want to move (page 46). 3 Click the MD edit button

The “Move” dialog box appears. To cancel the move, click

Note

Verify that the track you want to move is indicated in the “Move” dialog box.

4 Select the new number to which you want to move the track. 5 Click

The track being played moves to the track number specified in step

Note

To deselect a track, click in an empty area in the MD window (e.g., the empty area in the Time display).

Performing MD operations

Dividing tracks

You can divide a single track into two tracks.

Note

While this dialog box is displayed, the MD cannot be operated by the system stereo component.

1 Open the MD window (page 14). 2 Play the track you want to divide (page 46).

Note

Only the track being played can be divided.

3 Click the MD edit button where you want to divide the track.

The division point is selected temporarily. The “Divide” dialog box appears and Rehearsal playback starts from the position you clicked.

To cancel the divide, click .

4 Adjust the division point.

Each click on point by 1-frame intervals* (1 frame = 1/86 second) during stereo recording. You can also slide division point. Rehearsal playback starts again from the new division point. * In Monaural and LP2 stereo mode : 2-frame intervals

In LP4 stereo mode : 4-frame intervals

or in the “Divide” dialog box moves the division

to the left or right to adjust the

5 When the adjustment is completed, click .

The track is divided into two.

Combining tracks

You can combine two tracks into one track.

Note

While this dialog box is displayed, the MD cannot be operated by the system stereo component.

1 Open the MD window (page 14). 2 Select two tracks you want to combine from the MD window.

Click the track number of the first track, and then click the track number of the second track while holding down the CTRL key.

Notes

• If you select the first track only, and then proceed to step 3, the system assumes the second track to be that which immediately follows.

• You cannot select and combine three or more tracks.

• You cannot combine tracks recorded in different recording modes.

3 Click the MD edit button .

The “Combine” dialog box appears. Rehearsal playback is performed for about 4 seconds of a segment consisting of the last 2 seconds or so of the first track and the first 2 seconds or so of the second track.

Performing MD operations

To cancel the combination, click .

(continued)

4 To enter the combination sequence of the two tracks shown in the

“Combine” dialog box, click The selected tracks are joined. To reverse the sequence of the tracks in the “Combine” dialog box, click

Combining the track being played with the track that immediately follows

1 Open the MD window (page 14). 2 Play the first track that you want to combine (page 46). 3 Click the MD edit button

4 To enter the combination sequence of the two tracks shown in the

“Combine” dialog box, click The selected tracks are joined. To reverse the sequence of the tracks in the “Combine” dialog box, click

Notes

• To deselect a track, click in an empty area within the MD window, e.g., the empty area within the Time display.

• The track being played can only be combined with the track that immediately follows it.

• If two tracks are selected in the Track Name display, they are combined no matter what track is being played.

Erasing part of a track

You can erase a portion of a track.

Note

While this dialog box is displayed, the MD cannot be operated by the systemstereo component.

1 Open the MD window (page 14). 2 Play the part of the track that you want to erase (page 46).

Note

Erasing part of a track can be done only while the track is playing.

3 Click the MD edit button when the part that you want to erase

begins playing. The starting point (point A) of the erasure is temporarily set. The “A-B Erase” dialog box appears, and Rehearsal playback is performed of a 2-second segment ending at point A.

To cancel the erasure, click .

(continued)

Performing MD operations

4 Adjust the starting point (point A).

Each click of by 1-frame interval* (1 frame = 1/86 second) during stereo recording. You can also slide A. * In Monaural and LP2 stereo mode : 2-frame intervals

In LP4 stereo mode : 4-frame intervals

or in the “A-B Erase” dialog box moves point A

to the left or right to adjust point

5 When adjustment of point A is completed, click .

The track starts playing from point A. Clicking or moves the track position backwards or forwards, allowing you locate the ending point (point B) of the erasure easily.

6 Click when the part of the track that you want to erase

finishes playing. The ending point (point B) is set temporarily. Rehearsal playback is performed for about 4 seconds of a segment that begins about 2 seconds before point A and ends about 2 seconds after point B.

7 Adjust the ending point (point B).

Adjust the location of point B using point A.

and or as you did with

8 When adjustment of point B is completed, click .

The part from point A to point B is erased.

Adding the fade-in effect after recording

You can add a fade-in effect at the beginning of a track. The fade-in can range from 1 second to 15 seconds.

Notes

• The fade-in effect cannot be added to a track that has been recorded in an LP mode (LP2 or LP4).

• While this dialog box is displayed, the MD cannot be operated by the system stereo component.

Before you begin

Please note that it is impossible to undo the results of this MD edit operation.

1 Open the MD window (page 14). 2 Select the track in the Track Name display in the MD window for

which you want to add the fade-in effect.

3 Click the MD edit button .

The “Fade in” dialog box appears, and Rehearsal playback of the track starts.

Performing MD operations

To cancel the fade-in procedure, click .

(continued)

4 Adjust the fade-in starting and ending points in three steps.

1 Drag 2 Drag 3 Click

within a range of 1 to 15 seconds.

in Start Point to roughly locate the starting point.

in Rate to fine-tune the starting point.

or to adjust the position in increments of 0.1-second

5 Set the fade-in curve type.

Select Curve1, Curve2, or Curve3.

6 When the adjustment is completed, click .

Updating of the track begins.

Adding the fade-out effect after recording

You can add a fade-out effect at the end of a track. The fade-out can range from 1 second to 15 seconds.

Notes

• The fade-out effect cannot be added to a track that was recorded in an LP mode (LP2 or LP4).

• While this dialog box is displayed, the MD cannot be operated by the system stereo component.

Before you begin

Please note that it is impossible to undo the results of this MD edit operation.

1 Open the MD window (page 14). 2 Select the track in the Track Name display in the MD window for

which you want to add the fade-out effect.

3 Click the MD edit button .

The “Fade out” dialog box appears, and Rehearsal playback of the track starts.

Performing MD operations

To cancel the fade-out procedure, click .

(continued)

4 Adjust the fade-out starting and ending points in three steps.

1 Drag 2 Drag 3 Click

within a range of 1 to 15 seconds..

in Start Point to roughly locate the starting point.

in Rate to fine-tune the starting point.

or to adjust the position in increments of 0.1-second

5 Set the fade-out curve type.

Select Curve1, Curve2, or Curve3.

6 When the adjustment is completed, click .

Updating of the track begins.

Changing the recording level

You can change the recording level setting of a track.

Notes

• The recording level of a track that was recorded in an LP mode (LP2 or LP4)

cannot be changed.

• While this dialog box is displayed, the MD cannot be operated by the system

stereo component.

Before you begin

Please note that it is impossible to undo the results of this MD edit operation.

1 Open the MD window (page 14). 2 Select the track in the Track Name display in the MD window

whose recording level you want to change.

3 Click the MD edit button .

The “Level Shift” dialog box appears, and Rehearsal playback of the track starts.

A red line points to the peak level. To cancel the recording level change, click

4 Click to change the recording level.

The recording level can be adjusted within a range of -12 dB to +12 dB.

5 When the desired recording level is attained, click .

Updating of the track begins.

Performing MD operations

Erasing tracks

You can erase recorded tracks.

Note

While this dialog box is displayed, the MD cannot be operated by the systemstereo component.

1 Open the MD window (page 14). 2 Select the track in the Track Name display in the MD window that

you want to erase. To erase only one track, click the track number. To erase multiple tracks, click the track numbers in sequence while holding down the CTRL key. To select all the tracks on an MD, click the Jacket display (page 15). To erase the track being played, proceed to step 3 without selecting a track.

3 Click the MD edit button .

The “Erase” dialog box appears.

To cancel the erasure, click .

4 To erase the selected tracks, click .

All the selected tracks are erased. If you did not select a track, the track being played is erased.

Dragging tracks to to erase them

1 Open the MD window (page 14). 2 Select the track in the Track Name display in the MD window that

you want to erase. To erase only one track, click the track number. To erase multiple tracks, click the track numbers in sequence while holding down the CTRL key.

3 Drag the selected tracks and drop them on the MD edit button

All the selected tracks are erased.

Erasing all tracks

You can erase all the tracks recorded on an MD and the all the track and disc names registered for the MD.

1 Open the MD window (page 14). 2 While the MD is stopped and no track has been selected, drag the

Disc Information display of the disc to be erased (page 17) and drop it on the MD edit button

To erase all the tracks on an MD while the MD is stopped and no track has been selected, do the following:

1 Click . 2 A dialog box appears. Follow the instructions that appear.

Note

To deselect the currently selected track, click on an empty area (i.e., a place with no button or function key) in the Time display.

Performing MD operations

Printing MD labels with Label Maker

You can use Label Maker to print out disc and track names to MD labels.

Note

Do not affix labels outside the designated area on the MD, e.g., in the area near the shutter. Be sure to affix the label within the embossed label boundary, which varies in shape from one disc type to another.

Launching Label Maker

1 Open the MD window (page 14). 2 Select the MD (in the Function Tree display) for which you want to

print a label. The names of the tracks on the MD appear in the Track Name display in the MD window. If the track names do not appear, double-click the MD in the Function Tree display.

3 Click in the MD window.

Label Maker is started up. You can now make a label.

Note

is functional only if you have installed the Label Maker software.

z Tip

Alternatively you can double-click “PicLabel” located in the PictureGear folder (default location: C:\Program files\Sony\PictureGear\Goodies) to launch the Label Maker.

Creating labels with Label Maker

You can create labels with graphics or text to print for MDs and other media.

1 Open the MD window (page 14). 2 Click to launch the Label Maker.

A template of an MD label appears in the main display. The disc and track names currently displayed in the MD window appear on the MD label. If you want to print the label as it is shown on the MD label go to step 9.

To adjust the display size

Select the zoom magnification from the drop-down list in the main window.

To select another template

Click “Open Template” in the “File” menu. The “Open Template” dialog box opens. Select the file and click “Open” to display the template in the main window.

The templates available are:

3.5-inch floppy disk, 3.5-inch MO disk, Hi8/8mm video cassette, CD-R, DV, Memory stick, MD, Mini DV, VHS video cassette, and Audio cassette

3 Click “Add Image” in the “File” menu.

The “Add Image” dialog box opens.

(continued)

Performing MD operations

4 Select the file containing the image of your preference, and then

click “Open.” The main window appears again with the image displayed on the image palette located at the right side of the window.

The table below lists the file formats supported by the Label Maker and their file extensions.

File format File extension

Bitmap .BMP JPEG .JPG TIFF .TIF FlashPix .FPX GIF .GIF Mavica .JPG Slipclip .BMP (16-bit colour)

5 Place the image.

Drag the desired image from the image palette onto the label creation area.

To place the images automatically

Select the images and click “Autocopy” in the “Edit” menu. The images are pasted into the template area without changing the aspect ratio.

To make the image round or square

Select the image in the label creation area and click “Round” or “Square” in the “Edit” menu. You can change the size of an image in the label creation area but not in the template area.

To rotate the image 90 degrees

Select the image in the label creation area and click “Rotate” in the “Edit” menu.

To change the size of the image

Select the image and drag the frame. To change the size without changing the aspect ratio, drag the image while holding down the SHIFT key.

To switch the positions of overlapping images or texts

Select the image or text in the label creation area, and then click “Front” or “Back” in the “Overlap” menu to bring the selected image or text to the front or move it to the back.

Performing MD operations

To realign multiple images

Select images while pressing down the SHIFT key, or drag the images you want to realign, and then click “Align,” “Display Evenly,” “Condense,” or “Expand.” If you selected “Align,” click the type of alignment from among “Align to Left,” “Align to Right,” “Align to Top,” “Align to Bottom,” “Align to Center [Vertical],” and “Align to Center [Horizontal].” If you selected “Display Evenly,” “Condense,” or “Expand,” select the orientation by clicking “Vertical” or “Horizontal.”

(continued)

To add colour to the image

Click “Add Color” in the “File” menu to open the “Color” dialog box. Select the desired colour to display it on the image palette. The colour, like other images, can be assigned to a template.

To delete an image

Select the image you want to delete on the image palette, and then click “Delete” in the “Edit” menu.

6 Enter the label text.

Click “Text” in the Edit menu or you want to start the text on the label creation area to open the “Text” dialog box. Click “Properties” to specify the text attributes.

and click at the position where

To change the font

Click “Change Font” to open the “Font” dialog box. Select the font name, style and size of your preference. Then click “OK.”

To change the colour of the text

Click the “Text Color” or “Background” button according to the colour of which you want to change, the text or the background of the text. The “Color” dialog box opens. You can check the “Transparent” to use a transparent background colour.

To change vertical/horizontal text direction

Select “Horizontal” or “Vertical” under the “Line Direction” group box.

To rotate the text

Select the desired angle under the “Rotation” group box.

To change the text alignment position

Select “Left,” “Center,” or “Right” under the “Align” group box.

To change the text spacing

Enter the desired line spacing and character spacing in points under the “Spacing” group box.

(continued)

Performing MD operations

7 Click “OK.”

The “Text” dialog box closes.

To delete the text

Select the text you want to delete in the label creation area, and then click “Delete” in the “Edit” menu.

To rotate the text 90 degrees

Select the text in the label creation area and click “Rotate” in the “Edit” menu.

To move overlapping texts to the front or back

Select the text in the label creation area and click “Front” or “Back” in the “Overlap” menu.

8 Save the label.

Click “Save As” in the “File” menu to open the “Save As” dialog box. Select the folder, input file name, and then click “Save” to save the file. The “Save As” dialog box closes.

9 Print the label.

Click “Page Setup” in the “File” menu to select the page settings. Click “Print” in the “File” menu, and then click “OK.”

10Quit the Label Maker.

Click “Exit” in the “File” menu or click the

Performing MD operations

Operating the tuner

Listening to the radio

Listening to the radio using the TUNER bar

1 Display the TUNER bar (page 18). 2 Click the Radio Band display in the TUNER bar.

A list of the radio bands is displayed.

3 Click to select a band.

The selected band appears in the Radio Band display.

4 Click the Preset Number/Radio Station Name display in the

TUNER bar. If the stations are named (page 88), a list of the station names appears. Otherwise, a preset number list appears.

5 Click the preset number of the station that you want to listen to.

The station assigned to the preset number starts to play.

Listening to the radio using the TUNER window

1 Open the TUNER window (page 19). 2 Select a radio band.

Click

in the TUNER window to change the radio band.

3 Click the preset number in the Preset display of the radio station

you want to listen to. The station assigned to the preset number starts to play.

Operating the tuner

Assigning names to radio stations

1 Open the TUNER window (page 19). 2 Click the radio station name in the Preset display in the TUNER

window that you want to name. The edit mode for entering the name is activated.

3 Input the name.

Right-clicking in the edit mode opens up a pop-up menu that lets you copy and paste previously entered text data.

4 Press the ENTER key.

The name you entered is saved.

Notes

• The names you entered are saved to your computer’s hard disk. Do not delete,

move, or modify the folder in which the names are stored.

• Radio station names are displayed only in M-crew and not on the system

stereo component. Names entered on the system stereo component are displayed only on the component and not in M-crew.

Adding an image to the TUNER Jacket display

You can add one jacket image (bitmapped or JPEG file) for each preset number.

1 Open the TUNER window (page 19). 2 Drag a bitmapped image file from the Explorer and drop it onto the

Jacket display. The bitmapped image will appear in the Jacket display.

z Tips

• The bitmapped image file that is dragged and dropped is copied to the TUNER Jacket folder (default location: C:\Program Files\M_crew\Jacket), which is located in the same folder as the M-crew application.

• When the image in the Jacket folder is deleted, the image in the TUNER Jacket display will not disappear. To delete the TUNER Jacket display image, rightclick the Jacket display, and then click “Initialize image.” The image file in the Jacket folder, on the other hand, is not affected when the TUNER Jacket display image is deleted.

Operating the tuner

Editing preset numbers

1 Open the TUNER window (page 19). 2 Click in the TUNER window.

The “Edit” dialog box appears.

3 Set individual items.

1 Select the radio band.

Click to select a band.

2 Select the preset number to be edited.

Click The frequency, station name, stereo/monaural, and URL for the selected preset number will appear in the respective display fields.

Note

The settings entered in the “Edit” dialog box are saved for the preset number selected in 7, and not for the preset number selected here.

on the right side of the “PRESET No” field.

3 Specify the frequency.

Click on the right side of the “Frequency” field. The “TUNED” indicator will glow when a station is received. Hold down the mouse button for 2 seconds or longer to initiate auto-scanning. Scanning stops when a station is received or when you click in an empty area in the dialog box.

4 Select a reception mode (only if FM was selected in 1).

Click to select STEREO or MONO.

5 Input the radio station name.

Click to enter a new radio station name.

6 Input the URL for the preset number.

Click to enter an URL (website address) that you want to associate with the current preset number.

7 Select the preset memory number to which the settings will be

saved. Select the preset memory number to which settings made in the “Edit” dialog box will be saved.

4 Click .

The frequency 3, reception mode 4 (FM only), radio station name 5, and URL 6 are saved to the preset number selected in 7 for the radio band selected in 1.

5 Click .

The “Edit” dialog box disappears.

Operating the tuner

Operating the computer

Listening to file albums

Music files must be registered to file albums before they can be played by M-crew. M-crew can play the following kinds of music files:

• MP3 files*

• WAVE files

• MIDI files * Certain music files cannot be played back. As a rule, if Windows

Media Player cannot play an MP3 file, M-crew cannot play it either.

Registering music files to a file album

1 Open the File window (page 28).

My Album appears in the Function Tree display.

2 Click the icon of the file album in the Function Tree display to

which you want to register a music file. The File window appears.

3 Click the icon.

The dialog box for registering music files appears.

4 Select a music file and click “Open.”

The track name of the registered music file appears in the Track Name display.

z Tips

• You can also register a music file from the list in Explorer on your computer

by dragging and dropping the track name onto My Album or onto the Track Name display in the File window. At this time, you can drag and drop more than two files at once.

• The location of the actual music files does not change after they have been

registered to a file album.

• To find out where music files are stored, click the Display mode selector (page

31) to change to the File Name display.

Listening to file albums using the AudioFile bar

1 Display the AudioFile bar (page 27). 2 Click the File Information display in the AudioFile bar.

A list of file albums appears.

3 Click the file album (in the list) that you want to play.

The selected file album appears in the File Information display.

4 Click the Track Number/Track Name display in the AudioFile bar.

A list of tracks appears.

5 Click the track (in the list) that you want to play.

Sequential playback of the tracks starts with the selected track.

Listening to file albums using the File window

1 Open the File window (page 28). 2 Click the file album that you want to play in the Function Tree

display. A list of the tracks in the selected file album appears in the Track Name display.

3 Click the track number of the track you want to play in the Track

Name display. Double-clicking the track number starts playback of the track.

4 Click in the File window (only if you clicked a track number in

step 3). Playback starts in sequence with the track you clicked in step 3.

Operating the computer

Editing a file album

Music files registered to My Album can be moved to newly created file albums or folders for easier management of the music files.

Creating a new file album or folder

1 Open the File window (page 28). 2 Click the top of the Function Tree display (“File Album”).

The window for creating a new file album or folder appears.

3 Click or .

A new file album or folder will be created in the Function Tree display.

z Tip

To create a new file album in a folder, open the File window with the folder selected.

Moving music files

1 Open the File window (page 28). 2 Click the file album (in the Function Tree display) with the music

file to be moved.

3 Drag the track number of the track to be moved in the Track Name

display and drop onto the destination file album in the Function Tree display. To select multiple tracks at the same time, click the track numbers while holding down the CTRL key.

z Tips

• Multiple file albums can be placed within a single folder for easier management.

• To add a new file album to a folder, select the folder and click .

• You can also move file albums with the same procedure used to move music files. File albums can be moved to the end of another folder or the Function Tree display.

Notes

• A music file cannot be moved to another file album while it is being played.

• Folders cannot be moved.

• My Album cannot be moved nor erased.

Operating the computer

Erasing file albums or folders

1 Open the File window (page 28). 2 Click the folder containing the file album that you want to erase.

To erase a file album that is not contained in a folder, click “File Album” at the top of the Function Tree display.

3 Select the file album or folder (in the Track Name display) that you

want to erase. Two or more file albums or folders can be selected at the same time by clicking them while holding down the CTRL key.

4 Click .

The “Erase” dialog box appears.

5 Click .

Erasing a music file

To erase a music file, select it in the Track Name display and click the

Notes

• File albums displayed in the Main bar cannot be erased.

• Erasing a folder also erases all file albums contained within it.

Assigning names to file albums

You can assign names to file albums and the tracks contained in them. As in the case of MDs, track names can be entered from another application (page 50) and the completed file album and track name data can be used by other applications (page 52).

1 Open the File window (page 28). 2 Click the file album name (in the Function Tree display) that you

want to name, and then click the File Information display. To assign a name to a track, click the track name of the track in the Track Name display. The edit mode for entering the name is activated.

3 Input a file album name (or track name).

Right-clicking in the edit mode opens up a pop-up menu that lets you copy and paste previously entered text data.

4 Press the ENTER key.

The name that you typed in is entered and the system becomes ready for input of the next name.

z Tip

You can also use the above steps to assign names to folders.

Operating the computer

Adding an image to the File Jacket display

You can add one jacket image (bitmapped or JPEG file) for each file album.

1 Open the File window (page 28). 2 Drag a bitmapped image file from the Explorer and drop it onto the

Jacket display. The bitmapped image will appear in the Jacket display.

z Tips

• The bitmapped image file that is dragged and dropped is copied to the Jacket

folder (default location: C:\Program Files\M_crew\Jacket), which is located in the same folder as the M-crew application.

• When the image in the Jacket folder is deleted, the image in the Jacket display

will not disappear. To delete the Jacket display image, right-click the Jacket display, and then click “Initialize image.” The image file in the Jacket folder, on the other hand, is not affected when the Jacket display image is deleted.

Note

If you add a JPEG image to the Jacket display while playing a file album, the track being played may be interrupted. Do not add a JPEG image to the jacket display, especially when recording to an MD. Doing so will cause distortion in the recorded sound.

Using the disc library

The names of discs and track are saved to the M-crew disc library automatically after they have been recorded or played back. The disc library, like other functions, appears in the Function Tree display.

Viewing the disc library

1 Open the Disc Library window (page 32). 2 Click the icon of the disc library (in the Function Tree display) that

you want to view. A list of the tracks stored in the selected disc library appears in the Track Name display.

Operating the computer

Searching the disc library

You can search through the disc library by specifying the type of a disc library and keyword as search keys.

1 Open the Disc Library window (page 32). 2 Click .

The “Disc Library Search” dialog box appears.

3 Select the medium and the search category (“Item”), and enter the

keyword. Then click The “Search Result Display” dialog box appears.

100

4 Click the field that you wish to view.

The Disc Library window for the selected data opens.

z Tip

The data storage media appear as icons in the “Media” field in the “Search Result Display” dialog box.

Sony PCLK-MN10A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Preparation

Functional restrictions that vary with the connected system stereo component

Display items and functions

Main bar

Tool bar

CD bar

CD window

MD bar

MD window

TUNER bar

TUNER window

OTHERS bar

OTHERS window

PC-CD bar

PC-CD window

AudioFile bar

File window

Disc Library window

Rec window

“Option” dialog box

Timer window

Operating the CD player

Listening to a CD

Listening to a CD using the CD or PC-CD bar

Listening to a CD using the CD or PC-CD window

Assigning names to CDs

Assigning track names with text data from another application

Using disc and track name data in other applications

Adding an image to the CD or PC-CD Jacket display

Performing MD operations

Listening to an MD

Listening to an MD using the MD bar

Listening to an MD using the MD window

Assigning names to MDs

Assigning disc or track names

Assigning track names with the text data stored in the Disc Library

Assigning track names with text data from another application

Using disc and track name data in other applications

Adding an image to the MD Jacket display

Recording to an MD

Recording from a CD to an MD

Recording from the tuner to an MD

Recording music files from the PC to an MD

Recording to an MD from other audio sources

Editing recorded MDs

Moving tracks

Dividing tracks

Combining tracks

Erasing part of a track

Adding the fade-in effect after recording

Adding the fade-out effect after recording

Changing the recording level

Erasing tracks

Printing MD labels with Label Maker

Launching Label Maker

Creating labels with Label Maker

Operating the tuner

Listening to the radio

Listening to the radio using the TUNER bar

Listening to the radio using the TUNER window

Assigning names to radio stations

Adding an image to the TUNER Jacket display

Editing preset numbers

Operating the computer

Listening to file albums

Registering music files to a file album

Listening to file albums using the AudioFile bar

Listening to file albums using the File window

Editing a file album

Creating a new file album or folder

Moving music files

Erasing file albums or folders

Assigning names to file albums

Adding an image to the File Jacket display

Using the disc library

Viewing the disc library
