Sony NWZ-S544, NWZ-S544BLK, NWZ-S544PNK, NWZ-S544RED, NWZ-S544VLT Operating Instruction

...

Table of

Contents

Home

Index

Click! You can directly jump

Transferring Music



Transferring Videos/Photos



Troubleshooting



Operation Guide

NWZ-S544 / S545

4-154-416-12(1)

Table of

Contents

Home

Index

Note

Depending on the country/region in which you have purchased the player, some models



may not be available.

Browsing the Operation Guide

To use the buttons in the Operation Guide

Click the buttons located in the upper right of the pages of this manual to jump to “Table of Contents,” “About the Home Menu” or “Index.”

Jumps to the table of contents

Find what you are looking for from a list of topics in the manual.

Jumps to the [Home] menu list

Find what you are looking for from a list of the option items in the player’s menu.

Jumps to the index

Find what you are looking for from a list of key words mentioned in the manual.

 Hint

You can jump to the indicated page by clicking a page number in the table of contents or



in the index.

ou can jump to the indicated page by clicking a page reference indication (e.g.,  p



on each page.

To search for a reference page by keyword, enter the keyword into the find text field on



the Adobe Reader window.

peration procedures may differ, depending on your Adobe Reader version.



. 5)

To change the page layout

The buttons on the Adobe Reader window enable you to select how pages are displayed.

Text field to find text

Continuous

Pages are displayed as a continuous roll of pages, fitting the page width inside the window. When you scroll, the previous or next pages scroll up

Single Page

Pages are displayed one at a time, fitting the page into the window. When you scroll, the display changes to the previous or next page.

or down continuously.

Table of

Contents

Home

Index

Table of Contents

Basic Operations and Screens

Parts and Controls ...................................5

Switching the output between

the headphones and built-in speakers ........7

Turning the Player On and Off ...............8

About the Home Menu ............................9

How to Use the Home Menu .................12

How to Use the Option Menu ................15

About the Software ................................17

Bundled Software ...........................................17

Compatible Software .....................................17

Preparing the Player

Charging the Battery .............................18

Selecting the Display Language

............20

Setting the Date and Time .....................21

Transferring Music

Selecting the Way to Transfer Music .....22

 Transferring Music Using Windows

Media Player 11 ...................................23

Importing music from CDs ..........................23

Transferring Music ........................................25

 Transferring Music Using Content

Transfer ...............................................27

 Transferring Music Using Windows

Explorer ...............................................29

Transferring Videos/Photos

Selecting the Way to Transfer

Videos/Photos .....................................31

 Transferring Videos/Photos Using

Content Transfer .................................32

 Transferring Videos/Photos Using

Windows Explorer ...............................34

Playing Music

Playing Music [Music] .............................36

Music playback screen ...................................37

Music list screen .............................................38

Searching for Songs ...............................39

Playing a playlist .............................................40

Playing All Songs in Random Order.....41

Deleting Songs .......................................42

Using the Music Option Menu ..............43

Displaying the detailed information screen

[Detailed Information] .......................................45

Displaying the cover art screen

[Cover Art] .......................................................45

Changing the Music Settings .................46

Setting the play mode [Play Mode] ..................46

Setting the sound quality Listening with Clear Stereo Adjusting the volume level

[Dynamic Normalizer] .......................................49

Optimizing the quality of the sound output

from the built-in speakers

[Built-in SP Optimizer] ......................................49

[Equalizer] ..............47

[Clear Stereo] ......48

Watching Videos

Playing a Video [Videos] ..........................50

Video playback screen ...................................51

Deleting Videos .....................................52

Using the Video Option Menu ..............53

Changing the Video Settings .................54

Setting the zoom function [Zoom Settings] ....54

Setting the display of the video screen

[Display] ..........................................................56

Setting the video orientation

[Video Orientation] .......................................................57

Continued



Table of

Contents

Home

Index

Viewing Photos

Viewing Photos [Photos] .........................58

Photo display screen ......................................59

Playing a Slide Show ..............................60

Deleting Photos .....................................61

Using the Photo Option Menu ..............62

Changing the Photo Settings .................63

Photo orientation [Photo Orientation] ..............63

Setting the display of the photo screen

[Display] ..........................................................64

Setting the slide show play mode

[Slide Show Repeat] ...........................................64

Setting the interval of a slide show

[Slide Show Interval] ..........................................65

Listening and Recording FM Radio

Listening to FM Radio ...........................66

FM Radio screen ............................................67

Presetting broadcast stations

automatically

Presetting broadcast stations manually .......69

Deleting preset broadcast stations ...............69

Recording FM Radio .............................70

Playing Back Recorded FM Radio

Programs .............................................72

Deleting Recorded FM Radio

Programs .............................................73

Using the FM Radio Option Menu ........74

Changing the FM Radio Settings ..........76

Setting the reception [Scan Sensitivity] ............76

Setting monaural/stereo

[Auto Preset] ............................68

[Mono/Auto] ............76

Common Settings

Changing the Common Settings ...........87

Displaying the player information

[Unit Information] .............................................87

Limiting the volume Turning off the beep sound Setting a screensaver type Adjusting the brightness of the screen

[Brightness] ......................................................89

Setting the current time Setting the date format

[Date Display Format] ........................................91

Setting the time format

[Time Display Format] .......................................91

Returning to the factory settings

[Reset all Settings] .............................................92

Formatting memory

[AVLS (Volume Limit)] ....88

[Beep Settings] ....88

[Screensaver] .........89

[Set Date-Time] .........90

[Format] .........................92

Selecting the Display Language

[Language Settings] ...................................93

Useful Facts

About Battery Life .................................94

What are Format and Bit Rate? .............95

What is audio format? ...................................95

What is video format? ...................................96

What is photo format? ...................................96

Storing Data ...........................................97

Upgrading the Player’s Firmware .........98

Troubleshooting

Troubleshooting ....................................99

Messages ..............................................111

Recording/Listening Voice

Recording Voice .....................................77

Playing Back Recorded Voice Files .......79

Deleting Recorded Voice Files ..............80

Using the Voice Recording

Option Menu .......................................81

Changing the Recording Settings .........83

Selecting a level of recording quality

[Bit Rate Settings] ..............................................83

Using the Timer

Setting the Timer ...................................84

Setting the alarm [Alarm] ................................85

Setting the sleep timer

[Sleep Timer] ...............86

Additional Information

Precautions ..........................................113

License and Trademark Notice ...........122

Specifications.......................................125

Index ....................................................132

Table of

Contents

Home

Index

Basic Operations and Screens

Parts and Controls

Front

 Built-in speakers

See  p

. 7.

 BACK/HOME button

Press to go up one list screen level, or to return to the previous menu. Press and hold the BACK/HOME button to display the [Home] menu

. 9).

( p

 5-way button*

Starts playback and enables navigation of the player’s on-screen menus ( p

. 12, 15).

 Display

See  p

 VOL +*

Adjusts the volume. You can adjust the volume of sound from the headphones and the builtin speakers respectively ( p

. 9.

/− button

. 7).

 Output switch

Switches the output between the headphones and the built-in speakers of the player ( p

. 7).

 HOLD switch

You can protect the player against accidental operation during transportation by setting the HOLD switch. By sliding the HOLD switch in the direction of the arrow , all operation buttons except the output switch are disabled. If you slide the HOLD switch in the opposite position, the HOLD function is released.

 OPTION/PWR OFF button

Press to display the option menu ( p. 15, 43, 53, 62, 74, 81). If you press and hold the OPTION/ PWR OFF button, the screen turns off and the player enters standby mode ( p

. 8).

*1 There are tactile dots. Use them to help with

button operations.

Continued



Table of

Contents

Home

Index

Basic Operations and Screens

Rear

 RESET button

Press the RESET button with a small pin, etc., to reset the player (

. 99).

 Strap hole

This is used to attach a strap (sold separately).

 Microphone

See  p

. 77.

 Stand hole

This is used to attach the supplied stand.

Note

When standing the player with the



stand, be careful not to press down on or knock the player.

About carrying the supplied stand

Carry so as not to lose the stand as follows. Insert the headphone cord through the hole of the stand, and push the headphone cord into the base of the V-shaped notch to secure the stand to the headphone cord.

 WM-PORT jack

Connect the supplied USB cable, or optional peripheral devices.

 Headphone jack

Insert the headphone plug until it clicks into place. If the headphones are connected improperly, the sound from the headphones will be impaired.

Table of

Contents

Home

Index

Basic Operations and Screens

Switching the output between the headphones and built-in speakers

You can switch the output between the headphones and the built-in speakers by sliding the output switch. You can adjust the volume of sound from the headphones and the built-in speakers respectively.

Output switch

Note

When you switch the output to the built-in speakers, the output sound is not turned up



at once.

o not place credit cards or ATM cards, etc. (magnetic coded cards) near the holes of



built-in speakers, as damage to the magnetic coding on the cards may result.

 Set the output switch to  (speaker) or  (headphones).  Press the VOL +/- button to adjust the volume.

The volume indicator appears on the screen. The  (headphones) or  (speaker) icon (depending on the current setting) is displayed to the left of the volume indicator.

 Hint

You can set [Built-in SP Optimizer] to output sound from the built-in speakers (



. 49).

Table of

Contents

Home

Index

Basic Operations and Screens

Turning the Player On and Off

OPTION/PWR OFF button

To turn on the player

Press any button to turn the player on.

 Hint

If [On hold... Cancel HOLD function to activate controls.] appears on the screen, slide



the HOLD switch on the right of the player in the opposite direction of the arrow  to release the HOLD function.

To turn off the player

Press and hold the OPTION/PWR OFF button. [POWER OFF] appears, then the player enters standby mode, and the screen turns off.

 Hint

Set the date and time on the player before using it ( p



uring pause, if there is no operation for more than 3 minutes, the player automatically



enters standby mode to save battery power, and the screen turns off.

hile the player is in standby mode, if there is no operation for about 4 hours, the player



completely turns off automatically. The batteries are consumed a little in this status.

Note

You cannot operate the player when it is connected to a computer. Disconnect the USB



cable before operating the player.

e player consumes battery power very slightly even when it is in standby mode.



Therefore, the player might turn completely off unexpectedly depending on the power remaining in the battery.

. 21, 90).

Table of

Contents

Home

Index

Basic Operations and Screens

About the Home Menu

The following table shows the items of the [Home] menu. For details on the item list of each menu, see  p For details about each menu item, refer to the specified reference page.

[FM Radio]

. 10.

[Shuffle All]

[Photos]

[Music]

[Settings]

[Shuffle All] Listen to all the songs stored on the player in random

order ( p

[FM Radio] Listen to FM radio broadcasting, and also record the

currently received FM radio program ( p

[Voice Recording]

[Photos]

[Music] Listen to songs transferred to the player. You can also

[Videos]

Record voice using the player’s built-in microphone ( p

. 77).

View photos transferred to the player ( p

listen to voice recorded on the player using [Voice Recording] function, and FM radio programs recorded on the player ( p

Watch videos transferred to the player ( p

. 41).

. 36).

[Voice Recording]

[Videos]

[Now Playing] [Playlists]

Information area

. 66).

. 58).

. 50).

[Settings]

[Playlists]

[Now Playing] Display the playback or display screen of the currently

Set up the player and its applications ( p

Listen to songs in the playlists ( p

playing content.

. 87).

. 40).

Continued



Table of

Contents

Home

Index

Basic Operations and Screens

[Shuffle All] ............................. 41

[FM Radio] ............................... 66

[Voice Recording] ....................... 77

[Photos] ................................. 58

[Music]

[All Songs]...................................39

[Album] .......................................39

[Artist] ......................................... 39

[Genre] ........................................39

[Release Year] .............................39

[Folder] ........................................ 39

[Voice Recording] ................39, 79

[FM Recording] ....................39, 72

[Videos] .................................. 50

[Settings]

[Music Settings]

[Play Mode] ...........................46

[Equalizer].............................. 47

[Clear Stereo] ......................... 48

[Dynamic Normalizer] ......... 49

[Built-in SP Optimizer] ........ 49

[Video Settings]

[Zoom Settings]..................... 54

[Video Orientation] .............. 57

[Display] ................................. 56

[Photo Settings]

[Photo Orientation] .............. 63

[Display] ................................. 64

[Slide Show Repeat] .............. 64

[Slide Show Interval] ............ 65

[FM Radio Settings]

[Scan Sensitivity] ................... 76

[Mono/Auto] .........................76

[Recording Settings]

[Bit Rate Settings] .................83

[Common Settings]

[Unit Information] ................ 87

[AVLS (Volume Limit)] ........ 88

[Beep Settings] ....................... 88

[Screensaver] .........................89

[Brightness] ............................ 89

[Set Date-Time] ............... 21, 90

[Date Display Format] .......... 91

[Time Display Format] ......... 91

[Reset all Settings] ................. 92

[Format] .................................92

[Language Settings] .............20, 93

[Playlists]. ................................ 40

[Now Playing]

Continued



Table of

Contents

Home

Index

Basic Operations and Screens

About the information area

The icons, shown in the table below, appear in the information area. The icons vary according to the playback status, setting or the screen. For details about the icons, see each reference page.

Icons Description

, , , , , ,

, , etc

Playback status ( p

. 37, 51, 59)

, 

, , , , ,

, , etc

, etc

, *

*1 If the optional peripheral device to be able to enable volume adjustment is connected to the WM-

PORT jack of the player,  may be displayed.

Recording status ( p

Song name, artist name, video title, photo title, file name of recorded voice, or file name of recorded FM radio program

FM radio

Play mode ( p

Equalizer ( p

Zoom setting ([Auto] or [Full]) ( p

Sleep timer ( p

Remaining battery power ( p

Headphones or speaker ( p

. 71, 78)

. 46)

. 47)

. 54)

. 86)

. 18)

. 7)

Table of

Contents

Home

Index

Basic Operations and Screens

How to Use the Home Menu

The [Home] menu is the starting point of each application, such as searching for songs, changing settings, etc. You can display the [Home] menu by pressing and holding the BACK/HOME button of the player.

BACK/HOME button

5-way button

From the [Home] menu, you can select the desired item on the screen by using the 5-way button.

Press the /// button to select an item, and then press the * confirm.

*1 There are tactile dots. Use them to help with button operations.

button to

/// button: Selects an item.



 button: Confirms an item.



Continued



Table of

Contents

Home

Index

Basic Operations and Screens

In this manual, operating instructions from the [Home] menu are described as below.

Example:

The actual operations for the example above are shown below.

From the [Home] menu, select album

desired song.



[Music]  [Album]  desired

 Press and hold the BACK/HOME button.

The [Home] menu appears.

BACK/HOME button

 Press the /// button to select

[Music], and then press the  button to confirm.

The search menu appears.

 Press the /// button to select

[Album], and then press the  button to confirm.

The album list appears.

Continued



Table of

Contents

Home

Index

Basic Operations and Screens

 Press the /// button to select an

album, and then press the  button to confirm.

The song list for the selected album appears.

ou can scroll the list by pressing the /



button.

 Press the /// button to select a

song, and then press the  button to confirm.

The music playback screen appears and playback begins.

To return to the [Home] menu during operation

Press and hold the BACK/HOME button.

To return to the previous screen during operation

Press the BACK/HOME button.

Table of

Contents

Home

Index

Basic Operations and Screens

How to Use the Option Menu

The option menu items vary function-to-function, allowing you to change the settings of each application. You can display the option menu by pressing the OPTION/PWR OFF button.

OPTION/PWR OFF button

5-way button

From the option menu, you can select the desired item on the screen by using the 5-way button.

Press the /// button to select an item, and then press the * confirm.

*1 There are tactile dots. Use them to help with button operations.

button to

/// button: Selects an item.



 button: Confirms an item.



For example, the operations for setting [Play Mode] option to [Shuffle] are shown below.

 From the music playback screen, press

the OPTION/PWR OFF button.

The option menu appears.

OPTION/PWR OFF button

Continued



Table of

Contents

Home

Index

Basic Operations and Screens

 Press the /// button to select

[Play Mode], and then press the  button to confirm.

 Press the /// button to select

[Shuffle], and then press the  button to confirm.

The play mode changes to [Shuffle].

The items of the option menu differ, depending on the screen on which you press the OPTION/PWR OFF button. For details, see the following pages.

“Using the Music Option Menu” ( p



“Using the Video Option Menu” ( p



“Using the Photo Option Menu” ( p



“Using the FM Radio Option Menu” ( p



“Using the Voice Recording Option Menu” ( p



. 43) . 53) . 62)

. 74)

. 81)

Table of

Contents

Home

Index

Basic Operations and Screens

About the Software

Bundled Software

Content Transfer

Content Transfer can transfer music, videos or photos from a computer to the player by a simple drag-and-drop operation. You can use Windows Explorer or iTunes, etc., to drag-and-drop data to Content Transfer. Content Transfer can also convert a video file of a format not supported by the player into a playable format. For details on operation, refer to the Help of the software. Transferable files: Music (MP3, WMA, AAC, WAV), Photo (JPEG), Video (MPEG-4 Simple Profile, AVC (H.264/AVC) Baseline Profile, WMV*

*1 Some WMV files cannot be played back after being transferred by Content Transfer. If you

retransfer them using Windows Media Player 11, they may become playable.

 Hint

ATRAC files managed by SonicStage can be transferred to the player after conversion to



MP3 file format. To convert files, download the MP3 Conversion Tool from the customer support Web site ( p

. 121).

)

Compatible Software

Windows Media Player 11

Windows Media Player can import audio data from CDs and transfer data to the player. Transferable files: Music (MP3, WMA), Video (WMV), Photo (JPEG) For details on operation, refer to the Help of the software or visit the following website. http://www.support.microsoft.com/

 Hint

Some computers that already have Windows Media Player 10 installed may encounter



file limitations (AAC, video files, etc.) when transferring by drag-and-drop. If you install Windows Media Player 11 from the Windows Media Player download site, you can solve this problem, allowing you to transfer by drag-and-drop again. Before installing Windows Media Player 11 on your computer, make sure to check whether your software or service corresponds to Windows Media Player 11.

Table of

Contents

Home

Index

Preparing the Player

Charging the Battery

The player’s battery is recharged while the player is connected to a running computer. When you connect the player to your computer, use the supplied USB cable. When the remaining battery indication in the lower right corner of the display shows:

When you use the player for the first time, or if you have not used the player for a long time, recharge it fully (to the display).

About the battery indicator

The battery indicator in the information area shows remaining battery charge.

, charging is completed (charging time is approx. 2.5 hours).

in the remaining battery indication of

As the battery power gets lower, the bars of the icon disappear. If [LOW BATTERY. Please Charge.] appears, you cannot use the player. In this case, charge the battery by connecting to your computer. See  p duration.

. 129 on battery

Continued



Table of

Contents

Home

Index

Preparing the Player

Note

If you charge the player when it has not been used for a long period, your computer may



not recognize the player or nothing may appear on the display. Charge the player for about 5 minutes, and it starts operating properly.

harge the battery in an ambient temperature of between 5 ºC to 35 ºC (41 ºF to 95 ºF).



If you try to charge the battery in an ambient temperature outside this range, the battery indicator may blink, and charging cannot be performed.

e number of times the battery can be recharged before it is used up is approximately



500 times. This number may vary, depending on the conditions under which you use the player.

e battery indicator on the display is only an estimate. For example, one section of



black in the indicator will not always indicate exactly one-fourth of the battery’s charge.

o not disconnect.] appears in the display while the computer accesses the player. Do



not disconnect the supplied USB cable while [Do not disconnect.] appears or data being transferred may be damaged.

e control buttons on the player become inoperative while it is connected to a



computer.

f you do not intend to use the player for over half a year, charge the battery at least once



during this time to maintain battery performance.

ome USB devices connected to the computer may interfere with proper operation of



the player.

e do not guarantee battery recharging using a personally assembled/modified



computer.

f the computer enters a power saving mode, such as the Sleep or Hibernation mode,



while the player is connected via the USB cable, the player’s battery will not be charged. Instead, the player continues to draw power from the battery, discharging it.

o not leave the player connected for extended periods to a laptop computer that is not



connected to AC power, since the player may discharge the computer’s battery.

hile the player is connected to a computer, do not turn on, restart, wake up from sleep



mode, or shut down the computer. These operations may cause the player to malfunction. Disconnect the player from the computer before performing these operations.

eat may build up in the player while charging. This is not malfunction.



Table of

Contents

Home

Index

Preparing the Player

Selecting the Display Language

You can select from a variety of languages for menus and messages.

BACK/HOME button

5-way button

 From the [Home] menu, select [Settings]

desired language setting.



Language Messages and menus are displayed in

[Deutsch] German

[English] English

[Español] Spanish

[Français] French

[Italiano] Italian

[Português] Portuguese

[Русский] Russian

[

]

Korean

Simplified Chinese

[Settings]

[Language Settings]



[

]

Traditional Chinese

Table of

Contents

Home

Index

Preparing the Player

Setting the Date and Time

Some applications of the player do not work correctly until the date and time are set. Set the current date and time before using the player.

BACK/HOME button

5-way button

 From the [Home] menu, select [Settings]

[Set Date-Time].



[Common Settings]



[Settings]

 Press the / button to select a year, and then press the /

button to change the value.

 As in step , adjust the settings for month, date, hour, and

minute.

 Press the  button to confirm.

To display the current time

To display the current time, press the OPTION/PWR OFF button on the [Home] menu or the playback screen, and select [Clock Display] from the option menu.

 Hint

You can select the date format from among [YYYY/MM/DD], [MM/DD/YYYY], and



[DD/MM/YYYY]. Furthermore, you can select the time format from either [12-hour] or [24-hour ]. For details, see “Setting the date format [Date Display Format]” ( p “Setting the time format [Time Display Format]” ( p

Note

If the battery power is used up because, for example, the player has not been used for a



long time, your settings for date and time may be lost and “-” will be displayed instead of the current date and time.

e clock may gain or lose up to 60 seconds per month. In this case, set the clock again.



. 91).

. 91), or

Table of

Contents

Home

Index

Transferring Music

Selecting the Way to Transfer Music

You can import music from audio CDs or from the Internet, etc. To import music into your computer, use appropriate software. You can transfer music to the player in the following three ways.

 Transferring music from CDs using Windows Media Player 11 (

p. 23)

You can import music from your CDs, etc., to your computer, and transfer them to the player using Windows Media Player 11.

 Transferring music from iTunes, etc., using Content Transfer (



p. 27)

If you have already managed music with iTunes, etc., you can transfer them to the player using Content Transfer.

 Transferring music by drag-and-drop using Windows Explorer (

p. 29)



You can directly transfer music stored on your computer by drag-and-drop using Windows Explorer.

 Hint

For detailed information on how to import music, refer to the Help of each software.



or details about supported file formats, see “Supported file format” ( p



e player does not use SonicStage software (SonicStage software, developed by Sony,



manages music on a computer or transfers music to other types of players). For this player, you can transfer music in the above three ways, not using SonicStage. ATRAC files managed by SonicStage can be transferred to the player after conversion to MP3 file format. To convert files, download the MP3 Conversion Tool from the customer support Web site ( p

e maximum number of files per folder in the [MUSIC] folder is 4,000.



. 121).

. 125).

Table of

Contents

Home

Index

Transferring Music



Transferring Music Using Windows Media Player 11

You can import songs from your CDs, etc., to your computer, and transfer them to the player using Windows Media Player 11.

 Hint

For details about usage, or support on Windows Media Player, refer to the Windows



Media Player information from the following web site: http://support.microsoft.com/

Importing music from CDs

You can use Windows Media Player 11 to copy (rip) music from your CDs. Follow these instructions to rip songs from a CD to your computer.

 Insert an audio CD.  Start up Windows Media Player 11, and then click the [Rip] tab at

the top of the window.

When connected to the Internet, Windows Media Player 11 obtains CD information (CD title, song name or artist name, etc.) and displays it in the window.

Continued



Table of

Contents

Home

Index

Transferring Music

 Click [Start Rip].

Windows Media Player 11 begins to import the CD. The imported songs are indicated as [Ripped to library]. Wait until all songs have been imported.

 Hint

Imported songs are stored in the [My Music] folder (Windows XP) or [Music] folder



(Windows Vista) of the computer. Click the [Library] tab of the Windows Media Player 11 window to find them.

indows Media Player 11 obtains the CD information from a database on the Internet.



However, some CDs’ information may not be available in the database. If your CDs’ information is missing, you can add it after importing. For information about adding and editing CD information, refer to the Help of Windows Media Player 11. If you want a song not to be imported, uncheck the checkbox to the left of the song title.

Note

Imported songs are limited to private use only. Use of a song beyond this limitation



requires permission of the copyright holders.

Table of

Contents

Home

Index

Transferring Music

You can use Windows Media Player 11 to transfer music from your computer to the player.

Note

Do not disconnect the USB cable while [Do not disconnect.] appears on the player, as



the data being transferred may be damaged.

f Content Transfer starts automatically after connecting the player to your computer



using the supplied USB cable, close or ignore Content Transfer as Content Transfer need not be used. For details on setting automatic start of Content Transfer, refer to the Help of Content Transfer.

 Start up Windows Media Player 11, and then connect the player to

your computer using the supplied USB cable.

Insert the connector of the USB cable into the player with the mark facing up. The [Device Setup] window appears.

 Click [Cancel].

Close the auto play window, if it appears, by clicking [Cancel] or the Close icon.

f you click [Finish] instead of [Cancel], the entire library data of



Windows Media Player is automatically copied to the player. If the library data size is larger than the available storage space on the player, the copy process will not start.

ou can open the [Device Setup] window at any time. To open it, right-



click [WALKMAN] on the left side of the Windows Media Player window, and then click [Set Up Sync].

Continued



Table of

Contents

Home

Index

Transferring Music

 Click the [Sync] tab on the Windows Media Player 11 window.  Drag-and-drop the desired songs to the Sync List on the right side

of the window.

The songs are added to the Sync List.

 Click [Start Sync] to start synchronization.

When synchronization is complete, a message confirming you can disconnect the player appears on the Sync List. After completion, close Windows Media Player 11, and disconnect the player from the computer.

Table of

Contents

Home

Index

Transferring Music

 Transferring Music Using Content Transfer

If you have already managed music with iTunes, etc., you can transfer them to the player using Content Transfer. You can use iTunes, etc., to drag-and-drop music to Content Transfer.

Note

Do not disconnect the USB cable while [Do not disconnect.] appears on the player, or



the data being transferred may be damaged.

ontent Transfer cannot be used for Windows Media Player contents.



ontents with copyright protection cannot be transferred.



ontent Transfer supports data transfer from iTunes 8.1 to the player. For details on



restrictions on transferring songs from iTunes, visit the customer support Web sites ( p. 121).

 Connect the player to your computer using the supplied USB cable.

Insert the connector of the USB cable into the player with the facing up. Content Transfer starts automatically.

or details on setting automatic start and general operation of Content



Transfer, refer to the Help of Content Transfer.

ou can also click [All programs] in the [start] menu, and then [Content



Transfer] - [Content Transfer] to start the software.

mark

 Start up iTunes, etc.

Continued



Table of

Contents

Home

Index

Transferring Music

 Select the desired songs from iTunes, etc., and drag-and-drop them

to Content Transfer.

Content Transfer recognizes the type of data by filename extension, and sends it to the appropriate folder of the player.

iTunes, etc.

Content Transfer

Table of

Contents

Home

Index

Transferring Music

 Transferring Music Using Windows Explorer

You can directly transfer data by drag-and-drop using Windows Explorer on your computer. Playable data hierarchy has rules. To transfer data properly, see the following instructions.

 Hint

Some computers that already have Windows Media Player 10 installed may encounter a



limitation on the number of files (AAC, video files, etc.) that can be transferred by dragand-drop. If you install Windows Media Player 11 from the Windows Media Player download site, you can solve this problem, allowing you to transfer by drag-and-drop again. Before installing Windows Media Player 11 on your computer, make sure to check whether your software or service corresponds to Windows Media Player 11.

Continued



Table of

Contents

Home

Index

Transferring Music

Note

Data hierarchy may differ, depending on your computer environment.



o not disconnect the USB cable while [Do not disconnect.] appears on the player, as



the data being transferred may be damaged. If the player is disconnected while files are being transferred, unnecessary files may be left in the player. In this case, transfer usable files back to the computer and format the player ( p

o not change folder names or delete the [MUSIC], [MP_ROOT], [MPE_ROOT],



[VIDEO], [PICTURE], [PICTURES], [Record], [Voice] and [FM] folders.

o not change folder or file names directly under the [MP_ROOT] ,[MPE_ROOT] and



[Record] folders. Otherwise, they will not be displayed on the player.

ome files may not be played back on the player due to copyright protection. Although



you can transfer more files or folders to the player, the player cannot display or play any files, folders, or levels that exceed this limit.

f Content Transfer starts automatically after connecting the player to your computer



using the supplied USB cable, close or ignore Content Transfer as Content Transfer need not be used. For details on setting automatic start of Content Transfer, refer to the Help of Content Transfer.

. 92).

 Connect the player to your computer using the supplied USB cable.

Insert the connector of the USB cable into the player with the facing up.

mark

 Click [start] – [My Computer] or [Computer] – [WALKMAN] –

[Storage Media], and then select the [MUSIC] folder.

Data hierarchy may differ, depending on your computer environment.

 Drag-and-drop files or folders into the [MUSIC] folder, or one of its

subfolders.

Accessibility to files and folders beyond the 8th level is not guaranteed.

Music files or folders in your computer

[MUSIC] folder in your player

+ 104 hidden pages
