Sony HDR-HC9 Operating Guide
3-278-987-12(1)
Digital HD Video Camera Recorder
Operating Guide
HDR-HC9
Enjoying pictures with
high definition quality
Getting Started 12
Recording/
Playback
Using the Menu 39
Dubbing/Editing 64
Using a Computer 73
Troubleshooting 78
Additional Information 90
Quick Reference 103
Spanish Quick Guide/
Guía rápida en español
10
21
115
© 2008 Sony Corporation
WARNING
To reduce fire or shock hazard, do
not expose the unit to rain or
moisture.
This symbol is intended to alert
the user to the presence of
uninsulated “dangerous
voltage” within the product’s
enclosure that may be of
sufficient magnitude to
constitute a risk of electric
shock to persons.
This symbol is intended to alert
the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
IMPORTANT SAFEGUARDS
For your protection, please read these safety
instructions completely before operating
the appliance, and keep this manual for
future reference.
Carefully observe all warnings, precautions
and instructions on the appliance, or the one
described in the operating instructions and
adhere to them.
Use
Power Sources
This set should be operated only from the type of
power source indicated on the marking label. If
you are not sure of the type of electrical power
supplied to your home, consult your dealer or
local power company. For those sets designed to
operate from battery power, or other sources, refer
to the operating instructions.
Polarization
This set may be equipped with a polarized ac
power cord plug (a plug having one blade wider
than the other).
This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit, contact
your electrician to have a suitable outlet installed.
Do not defeat the safety purpose of the polarized
plug by forcing it in.
Overloading
Do not overload wall outlets, extension cords or
convenience receptacles beyond their capacity,
since this can result in fire or electric shock.
Object and Liquid Entry
Never push objects of any kind into the set
through openings as they may touch dangerous
voltage points or short out parts that could result
in a fire or electric shock. Never spill liquid of any
kind on the set.
Attachments
Do not use attachments not recommended by the
manufacturer, as they may cause hazards.
2
Cleaning
Unplug the set from the wall outlet before
cleaning or polishing it. Do not use liquid cleaners
or aerosol cleaners. Use a cloth lightly dampened
with water for cleaning the exterior of the set.
Installation
Water and Moisture
Do not use power-line operated sets near water –
for example, near a bathtub, washbowl, kitchen
sink, or laundry tub, in a wet basement, or near a
swimming pool, etc.
Power-Cord Protection
Route the power cord so that it is not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to the
plugs, receptacles, and the point where the cord
exits from the appliance.
Accessories
Do not place the set on an unstable cart, stand,
tripod, bracket, or table. The set may fall, causing
serious injury to a child or an adult, and serious
damage to the set. Use only a cart, stand, tripod,
bracket, or table recommended by the
manufacturer.
Ventilation
The slots and openings in the cabinet are provided
for necessary ventilation. To ensure reliable
operation of the set, and to protect it from
overheating, these slots and openings must never
be blocked or covered.
– Never cover the slots and openings with a cloth
or other materials.
– Never block the slots and openings by placing
the set on a bed, sofa, rug, or other similar
surface.
– Never place the set in a confined space, such as
a bookcase, or built-in cabinet, unless proper
ventilation is provided.
– Do not place the set near or over a radiator or
heat register, or where it is exposed to direct
sunlight.
Lightning
For added protection for this set during a lightning
storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system.
This will prevent damage to the set due to
lightning and power-line surges.
Service
Damage Requiring Service
Unplug the set from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
– When the power cord or plug is damaged or
frayed.
– If liquid has been spilled or objects have fallen
into the set.
– If the set has been exposed to rain or water.
– If the set has been subject to excessive shock by
being dropped, or the cabinet has been
damaged.
– If the set does not operate normally when
following the operating instructions. Adjust
only those controls that are specified in the
operating instructions. Improper adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the set to normal operation.
– When the set exhibits a distinct change in
performance – this indicates a need for service.
Servicing
Do not attempt to service the set yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
Replacement parts
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer that have the same
characteristics as the original parts.
Unauthorized substitutions may result in fire,
electric shock, or other hazards.
Safety Check
Upon completion of any service or repairs to the
set, ask the service technician to perform routine
safety checks (as specified by the manufacturer)
to determine that the set is in safe operating
condition.
3
Read this first
Before operating the unit, please read this
manual thoroughly, and retain it for future
reference.
WARNING
Do not expose the batteries to
excessive heat such as sunshine,
fire or the like.
Excessive sound pressure from
earphones and headphones can
cause hearing loss.
CAUTION
Replace the battery with the
specified type only. Otherwise, fire
or injury may result.
For customers in the U.S.A. and
CANADA
RECYCLING LITHIUM-ION BATTERIES
Lithium-Ion batteries are recyclable.
You can help preserve our
environment by returning your
used rechargeable batteries to the
collection and recycling location
nearest you.
For more information regarding
recycling of rechargeable batteries, call toll free 1800-822- 8837, or visit http://www.rbrc.org/
Caution: Do not handle damaged or leaking
Lithium-Ion batteries.
Battery pack
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
This Class B digital apparatus complies with
Canadian ICES-003.
Owner’s Record
The model and serial numbers are located on the
bottom. Record the serial number in the space
provided below. Refer to these numbers whenever
you call your Sony dealer regarding this product.
Model No. HDR-HC9
Serial No.
Model No. AC-
Serial No.
For customers in the U.S.A.
If you have any questions about this
product, you may call:
Sony Customer Information Center 1-800-
222-SONY (7669).
The number below is for the FCC related
matters only.
Regulatory Information
Declaration of Conformity
Trade Name: SONY
Model No.: HDR-HC9
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo, San Diego, CA
92127 U.S.A.
Telephone number: 858-942-2230
This device complies with Part 15 of the FCC
Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
Notes
HDR-HC9 is to be used with AC Adaptor Model
AC-L200/L200B.
CAUTION
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
4
Note
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment
and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
– Consult the dealer or an experienced radio/TV
technician for help.
The supplied interface cable must be used with t he
equipment in order to comply with the limits for a
digital device pursuant to Subpart B of Part 15 of
FCC Rules.
For the State of California, USA only
Perchlorate Material - special handling may
apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate
Perchlorate Material: Lithium battery contains
perchlorate.
Notes on use
Your camcorder is supplied with two
kinds of manuals
– “Operating Guide” (This manual)
– “First Step Guide” for using your
camcorder while connected to a computer
(stored on the supplied CD-ROM)
Type of cassette you can use in your
camcorder
You can use mini DV cassettes marked
with . Your camcorder is not
compatible with the Cassette Memory
function (p. 91).
Types of “Memory Stick” you can use
in your camcorder
You can use “Memory Stick” that have the
logo shown below (p. 92).
– (“Memory Stick Duo”)
– (“Memory Stick
PRO Duo”)
– (“Memory Stick
PRO-HG Duo”)
“Memory Stick Duo”
(This size can be used with your
camcorder.)
“Memory Stick”
(You cannot use with your camcorder.)
• You cannot use any type of memory card
except “Memory Stick Duo.”
• “Memory Stick PRO Duo” can be used
only with “Memory Stick PRO”
compatible equipment.
Continued ,
5
Read this first (Continued)
• Do not attach a label or the like on a
“Memory Stick Duo” or a Memory Stick
Duo adaptor.
When using a “Memory Stick Duo”
with “Memory Stick” compatible
equipment
Be sure to insert the “Memory Stick Duo”
into the Memory Stick Duo Adaptor.
Memory Stick Duo Adaptor
Using the camcorder
• Do not hold the camcorder by the
following parts.
LCD panelViewfinder
• The camcorder is not dustproof, dripproof
or waterproof.
See “On using your camcorder” (p. 96).
• When connecting your camcorder to
another device with communication
cables, be sure to insert the connector plug
in the correct way.
Pushing the plug forcibly into the terminal
will damage the terminal and may result
in a malfunction of your camcorder.
About menu items, LCD panel,
viewfinder, and lens
• A menu item that is grayed out is not
available under the current recording or
playback conditions.
• The LCD screen and the viewfinder are
manufactured using extremely highprecision technology, so over 99.99% of
the pixels are operational for effective
use. However, there may be some tiny
6
black points and/or bright points (white,
red, blue, or green in color) that appear
constantly on the LCD screen and the
viewfinder. These points are normal
results of the manufacturing process and
do not affect the recording in any way.
Black point
White, red, blue
or green point
• Exposing the LCD screen, the viewfinder,
or the lens to direct sunlight for long
periods of time may cause malfunctions.
• Do not aim at the sun. Doing so might
cause your camcorder to malfunction.
Take pictures of the sun only in low light
conditions, such as at dusk.
About changing the language setting
The on-screen displays in each local
language are used for illustrating the
operating procedures. Change the screen
language before using your camcorder if
necessary (p. 17).
On recording
• Before starting to record, test the
recording function to make sure the
picture and sound are recorded without
any problems.
• Compensation for the contents of
recordings cannot be provided, even if
recording or playback is not possible due
to a malfunction of the camcorder, storage
media, etc.
• TV color systems differ depending on the
country/region. To view your recordings
on a TV, you need an NTSC system-based
TV.
• Television programs, films, video tapes,
and other materials may be copyrighted.
Unauthorized recording of such materials
may be contrary to the copyright laws.
On playing back HDV tapes on other
devices
You cannot play back a tape recorded in the
HDV format on DV format video cameras
or on mini DV players (The screen appears
blue).
Check the contents of tapes by playing
them back on this camcorder prior to
playing them back on other devices.
About this manual
• The images of the LCD screen and the
viewfinder used in this manual for
illustration purposes are captured using a
digital still camera, and therefore may
appear different.
• Design and specifications of recording
media and other accessories are subject to
change without notice.
About the Carl Zeiss lens
Your camcorder is equipped with a Carl
Zeiss lens, which was developed jointly by
Carl Zeiss, in Germany, and Sony
Corporation, and produces superior images.
It adopts the MTF measurement system for
video cameras and offers a quality typical
of a Carl Zeiss lens. Also, the lens for your
camcorder is T -coated to suppress
unwanted reflections and faithfully
reproduce colors.
MTF= Modulation Transfer Function
The number value indicates the amount of
light from a subject coming into the lens.
7
Table of Contents
IMPORTANT SAFEGUARDS ........ 2
Read this first ................................. 4
Notes on use .................................. 5
Enjoying pictures with
high definition quality
Trying out the HDV format! .......... 10
Viewing video recorded in the HDV
format! ........................................ 11
Getting Started
Step 1: Checking supplied items
.................................................... 12
Step 2: Charging the battery pack
.................................................... 13
Step 3: Turning the power on and
setting the date and time ............ 16
Step 4: Making setting adjustments
before recording .........................18
Step 5: Inserting a tape or a “Memory
Stick Duo” ................................... 19
Recording/Playback
Easy Recording/Playback
(Easy Handycam) ....................... 21
Recording ..................................... 23
Zooming ...................................... 25
Recording high quality still images
during tape recording (Dual Rec)
................................................... 25
Controlling the image settings
manually with the CAM CTRL dial
................................................... 26
Using the flash ............................ 26
Recording in dark places
(NightShot) ................................ 27
Adjusting the exposure for backlit
subjects .................................... 27
Recording in mirror mode ........... 27
8
Note on the icons used in this manual
Features available for the HDV format only
Features available for the DV format only
Playback ....................................... 28
Using PB zoom ............................ 30
Using the guide functions (USAGE
GUIDE) .......................................31
Searching for the starting point ....32
Searching for the last scene of the
most recent recording (END
SEARCH) .................................. 32
Reviewing the most recently
recorded scenes (Rec review)
................................................... 32
Searching quickly for a desired
scene (Zero set memory) .......... 32
Searching for a scene by date of
recording (Date search) ...........33
Playing the picture on a TV .......... 34
Selecting the appropriate
connection method (CNNECT
GUIDE) ...................................... 34
Connecting to a high definition TV
................................................... 35
Connecting to a 16:9 (wide) or 4:3 TV
................................................... 36
Using the Menu
Using the menu items .......... 39
Menu items ...................................40
CAMERA SET menu ..............42
Settings to adjust your camcorder to
the recording conditions
MEMORY SET menu .............49
Settings for the “Memory Stick Duo”
PICT.APPLI. menu ................ 52
Special effects on pictures or
additional functions on recording/
playback
EDIT/PLAY menu .................55
Settings for editing or playing back in
various modes
STANDARD SET menu ........56
Settings while recording on a tape or
other basic settings
TIME/LANGU. menu .............62
Customizing Personal Menu ........ 62
Dubbing/Editing
Quick Reference
Dubbing to VCR or DVD/HDD
recorders .....................................64
Recording pictures from a VCR, etc.
.....................................................67
Dubbing pictures from a tape to a
“Memory Stick Duo” ....................69
Deleting recorded pictures from the
“Memory Stick Duo” ....................69
Marking images on the “Memory Stick
Duo” with specific information (Print
mark/Image protection) ...............70
Printing recorded images (PictBridge
compliant printer) ........................71
Using a Computer
What you can do with Windows
computer .....................................73
Installing the “First Step Guide” and
software ......................................75
Viewing “First Step Guide” ............77
Using a Macintosh computer ........77
Troubleshooting
Troubleshooting ............................78
Warning indicators and messages
.....................................................87
Identifying parts and controls ......103
Indicators displayed during recording/
playback ....................................107
Index ...........................................111
Spanish Quick Guide/
Guía rápida en español 115
Additional Information
Using your camcorder abroad ......90
Maintenance and precautions ......91
Usable cassette tapes ................ 91
About the “Memory Stick” ........... 92
About the “InfoLITHIUM” battery
pack .......................................... 93
About i.LINK ................................ 95
About x.v.Color ........................... 96
On using your camcorder ........... 96
Specifications ...............................99
9
Enjoying pictures with high definition quality
Trying out the HDV format!
Shooting in the HDV format
High image quality
Being HDV format compliant, your camcorder is ready to shoot crystal clear, high-definition
images.
What is the HDV format?
The HDV format is a video format for shooting and playing back high definition images on
popular DV standard cassette tapes.
• Your camcorder adopts the HDV1080i
specification, which utilizes 1,080 effective
scanning lines, within the HDV standards, and
records pictures at the image bit rate of about 25 Mbps.
• These operating instructions refer to the HDV1080i specification as HDV format unless there is a need
to specify.
Why shoot in the HDV format?
With the global standard moving to the digital video format, you can record important
moments in HDV format to keep high quality images for the future.
Your camcorder’s down convert function converts pictures in HDV format to SD (standard
definition) image quality for viewing on older wide TV formats, and on 4:3 aspect ratio TVs
when a high definition TV set is not available. This provides an easy path to HDV format
video.
1,080 effective
scanning lines
• The down convert function converts HDV format video to DV for playback or editing when your
camcorder is connected to a TV or VCR that is not HDV1080i compliant. The resulting image is
displayed in SD (standard definition).
10
Viewing video recorded in the HDV format!
Viewing on a high definition TV (p. 34)
Pictures recorded in the HDV format can be played back as crisp HD (high definition)
pictures on a high definition TV.
• For details on HDV1080i compliant TVs, see page 34.
Viewing on a 16:9 (wide)/4:3 TV (p. 36)
Your camcorder can down convert video recorded in the HDV format to SD (standard
definition) image quality for playback on a conventional TV.
Dubbing to VCR or DVD/HDD recorders (p. 64)
Connecting to an HDV1080i device
A supplied i.LINK cable allows you to copy pictures in HD (high definition) image quality.
Enjoying pictures with high definition quality
Connecting to an HDV1080i non-compliant device
Your camcorder can down convert HDV format video to SD (standard definition) image
quality to enable copying.
Connecting to a computer (p. 73)
Using the supplied software, you can import movies from a tape or still images from a
“Memory Stick Duo” to the computer. You can also edit the imported movies and create a
DVD-video in SD (standard definition) image quality.
11
Getting Started
Step 1: Checking supplied items
Make sure that you have following items
supplied with your camcorder.
The number in the parentheses indicates the
number of that item supplied.
AC Adaptor (1) (p. 13)
Power cord (Mains lead) (1) (p. 13)
Wireless Remote Commander (1)
(p. 106)
A button-type lithium battery is already installed.
A/V connecting cable (1) (p. 34, 64)
USB cable (1) (p. 71)
Rechargeable battery pack NP-FH60 (1)
(p. 13, 93)
Lens hood (1) (p. 105)
Remove the lens hood when you use the
flash, Nightshot or SuperNightshot, or its
shadow will appear in the picture.
CD-ROM “Handycam Application
Software” (1) (p. 75)
Operating Guide (This manual) (1)
Component video cable (1) (p. 34)
i.LINK cable (1) (p. 34, 64, 67, 75)
12
Step 2: Charging the battery pack
2
1
DC IN jack
POWER
switch
Getting Started
3
Battery pack
DC plug
4
To the wall outlet
(wall socket)
You can charge the “InfoLITHIUM”
battery pack (H series) (p. 93) after
attaching it to your camcorder.
b Notes
• You cannot attach any “InfoLITHIUM” battery
pack other than the H series to your camcorder.
Power cord (Mains lead)
AC Adaptor
1 Attach the battery pack to your
camcorder.
Attach the battery pack by sliding it in
the direction of the arrow until it clicks.
2 Slide the POWER switch to OFF
(CHG) (the default setting).
3 Connect the AC Adaptor to the
DC IN jack of your camcorder. Be
sure that the v mark on the DC
plug is facing to the v mark on
your camcorder.
4
/CHG
(charge)
lamp
4 Connect the power cord (mains
lead) to the AC Adaptor and the
wall outlet (wall socket).
The /CHG (charge) lamp lights up and
charging starts. The /CHG (charge)
lamp turns off when the battery is fully
charged.
b Notes
• Disconnect the AC Adaptor from the DC IN
jack holding both the camcorder and the DC
plug.
z Tips
• You can operate your camcorder connected to a
power source such as a wall outlet (wall socket)
as shown in the illustration. The battery pack
will not lose its charge in this case.
Continued ,
13
Step2: Charging the battery pack (Continued)
To remove the battery pack
Slide the POWER switch to OFF (CHG).
Slide the BATT (battery release) lever and
remove the battery pack.
BATT (battery
release) lever
When storing the battery pack
Fully discharge the battery before storing it
for an extended period (p. 94).
To check the remaining battery
(Battery Info)
Set the POWER switch to OFF (CHG), then
press DISPLAY/BATT INFO.
DISPLAY/
BATT INFO
Remaining battery (approx.)
60
65
Recording capacity (approx.)
You can check the remaining battery charge
on the LCD screen.
Indicator Status
Sufficient power remaining
Battery low, recording/
playback will stop soon.
Replace the battery with a
fully charged one, or charge
the battery.
Charging time
Approximate time (min.) required when
you fully charge a fully discharged battery
pack.
Battery pack Charging time
NP-FH50 135
NP-FH60 (supplied) 135
NP-FH70 170
NP-FH100 390
After a while, the approximate recordable
time and battery information appear for
about 7 seconds. You can view the battery
information for up to 20 seconds by
pressing DISPLAY/BATT INFO again
while the information is displayed.
14
Recording time
Approximate time (min.) available when
you use a fully charged battery pack.
Continuous
Battery pack
Recording
Format
NP-FH50 70 70 40 40
recording
time
HDVDVHDVDV
70 75 40 40
75 80 40 45
Typical
recording
time*
Battery pack
Recording
Format
NP-FH60
(supplied)
Continuous
recording
time
HDV DV HDV DV
90 95 50 50
95 100 50 55
Typical
recording
time*
100 105 55 55
NP-FH70 150 155 80 85
155 165 85 90
160 170 85 90
NP-FH100 345 365 185 195
365 385 195 210
375 395 205 215
* Typical recording time shows the time when
you repeat recording start/stop, turning the
power on/off and zooming.
b Notes
• All times measured under the following
conditions:
Top: When the LCD backlight turns on.
Middle: When the LCD backlight turns off.
Bottom: Recording with the viewfinder while
the LCD panel is closed.
Playing time
Approximate time (min.) available when
you use a fully charged battery pack.
Battery pack
Recorded
Format
NP-FH50
NP-FH60
(supplied)
LCD panel
opened*
HDV DV HDV DV
105 115 120 130
140 150 160 170
NP-FH70 230 245 255 280
NP-FH100 525 565 590 635
* When the LCD backlight turns on.
LCD panel
closed
• The /CHG (charge) lamp flashes during
charging, or Battery Info (p. 14) will not be
correctly displayed under the following
conditions.
– The battery pack is not attached correctly.
– The battery pack is damaged.
– The battery pack is worn-out (for Battery Info
only).
• The power will not be supplied from the battery
as long as the AC Adaptor is connected to the
DC IN jack of your camcorder, even when the
power cord (mains lead) is disconnected from
the wall outlet (wall socket).
• When attaching an optional video light, it is
recommended that you use an NP-FH70 or NPFH100 battery pack.
On the charging/recording/playback time
• Times measured with the camcorder at 25 °C
(77 °F) (10 to 30 °C (50 °F to 86 °F) is
recommended).
• The recording and playback time will be shorter
when you use your camcorder in low
temperatures.
• The recording and playback time will be shorter
depending on the conditions under which you
use your camcorder.
On the AC Adaptor
• Use the nearby wall outlet (wall socket) when
using the AC Adaptor. Disconnect the AC
Adaptor from the wall outlet (wall socket)
immediately if any malfunction occurs while
using your camcorder.
• Do not use the AC Adaptor placed in a narrow
space, such as between a wall and furniture.
• Do not short-circuit the DC plug of the AC
Adaptor or battery terminal with any metallic
objects. This may cause a malfunction.
• Even if your camcorder is turned off, AC power
(house current) is still supplied to it while
connected to the wall outlet (wall socket) via the
AC Adaptor.
Getting Started
On the battery pack
• Before changing the battery pack, slide the
POWER switch to OFF (CHG).
15
Step 3: Turning the power on and setting the date and time
Set the date and time when using this
camcorder for the first time. If you do not
set the date and time, the [CLOCK SET]
screen appears every time you turn on your
camcorder or change the POWER switch
position.
Touch the button on
the LCD screen.
1 While pressing the green button,
slide the POWER switch in the
direction of the arrow to turn on
the respective lamp.
CAMERA-TAPE: To record on a tape.
CAMERA-MEMORY: To record on a
“Memory Stick Duo.”
PLAY/EDIT: To play or edit pictures.
The [CLOCK SET] screen appears.
CLOCK SET
2 Set [Y] (year) with / .
You can set any year up to the year
2079.
POWER switch
JAN
2008YM1D12:00
–:––:––
AM
OK
3 Move to [M] (month) with ,
then set with / .
4 Move to [D] (day) with , then
set with / and repeat for the
hour and minute.
For midnight, set it to 12:00 AM.
For midday, set it to 12:00 PM.
5 Make sure the date and time
settings are correct, then touch
.
The clock starts.
To turn off the power
Slide the POWER switch to OFF (CHG).
To reset the date and time
You can set the desired date and time by
touching t / t [CLOCK
SET] (p. 39).
b Notes
• If you do not use your camcorder for about 3
months, the built-in rechargeable battery gets
discharged and the date and time settings may
be cleared from the memory. In that case,
charge the rechargeable battery and then set the
date and time again (p. 99).
• At the time of purchase, the power is set to turn
off automatically if you leave your camcorder
without any operation attempted for
approximately 5 minutes, to save battery power
([A.SHUT OFF], p. 61).
z Tips
• The date and time are not displayed while
recording, but they are automatically recorded
on the tape, and can be displayed during
playback (see page 60 for [DATA CODE]
(During Easy Handycam operation, you can set
only [DATE/TIME])).
16
• The lens cover opens automatically when the
POWER switch is set to CAMERA-TAPE or
CAMERA-MEMORY.
• If the buttons on the touch panel do not work
correctly, adjust the touch panel
(CALIBRATION) (p. 98).
Changing the language setting
You can change the on-screen displays to
show messages in a specified language.
Touch t [MENU] t (TIME/
LANGU.) t [LANGUAGE], then select
the desired language.
Getting Started
17
Step 4: Making setting adjustments before recording
The LCD panel
Open the LCD panel 90 degrees to the
camcorder (1), then rotate it to the best
angle to record or play (2).
180 degrees
(max.)
2
2
90 degrees
(max.)
To turn off the LCD backlight to make
the battery last longer
Press and hold DISPLAY/BATT INFO for
a few seconds until appears.
This setting is practical when you use your
camcorder in bright conditions or where
you want to save battery power. The
recorded picture will not be affected by the
setting. To turn on the LCD backlight, press
and hold DISPLAY/BATT INFO for a few
seconds until disappears.
b Notes
• Do not press the buttons on the LCD panel
accidentally when you open or adjust the LCD
panel.
z Tips
• If you rotate the LCD panel 180 degrees to the
lens side, you can close the LCD panel with the
LCD screen facing out. This is convenient
during playback operations.
• See [LCD/VF SET] - [LCD BRIGHT] (p. 58) to
adjust the brightness of the LCD screen.
• Press DISPLAY/BATT INFO to toggle the
screen indicators (such as Battery Info) on or
off.
DISPLAY/BATT INFO
1
90 degrees to the
camcorder
The viewfinder
You can view pictures using the viewfinder
to avoid wearing down the battery, or when
the picture seen on the LCD screen is poor.
Viewfinder
Viewfinder lens
adjustment lever
Move it until the
picture is clear.
z Tips
• You can adjust the brightness of the viewfinder
backlight by selecting [LCD/VF SET] - [VF
B.LIGHT] (p. 58).
The grip belt
Fasten the grip belt and hold your
camcorder correctly.
18
Step 5: Inserting a tape or a “Memory Stick
{DO NOT PUSH}
Duo”
Cassette tape
You can use mini DV cassettes only
(p. 91).
b Notes
• The recordable time varies depending on [
REC MODE] (p. 57).
1 Slide and hold the OPEN/
EJECT lever in the direction of the
arrow and open the lid.
OPEN/EJECT lever
Lid
The cassette compartment automatically
comes out and opens up.
2 Insert a cassette with its window
facing outwards, then press
.
Push the center of the back
of the cassette lightly.
Cassette
compartment
Window
3 Close the lid.
To eject the cassette
Open the lid following the same procedure
as described in step 1 and remove the
cassette.
b Notes
• Do not force the cassette compartment
closed by pressing the portion marked
may cause a malfunction.
while it is sliding in. It
“Memory Stick Duo”
You can use “Memory Stick” that have the
logo shown below (p. 92).
– (“Memory Stick Duo”)
– (“Memory Stick
PRO Duo”)
– (“Memory Stick
PRO-HG Duo”)
z Tips
• The number and time of recordable pictures
vary depending on the image quality or the
image size. For details, see page 49.
1 Open the LCD panel.
2 Insert the “Memory Stick Duo”
into the Memory Stick Duo slot in
the right direction until it clicks.
Getting Started
The cassette compartment
automatically slides back in.
Continued ,
19
Step 5: Inserting a tape or a “Memory Stick Duo” (Continued)
Access lamp
To eject a “Memory Stick Duo”
Lightly push the “Memory Stick Duo” in
once.
b Notes
• When the access lamp is lit or flashing, your
camcorder is reading/writing data. Do not shake
or knock your camcorder, turn the power off,
eject the “Memory Stick Duo,” or remove the
battery pack. Otherwise, image data may be
damaged.
• If you force the “Memory Stick Duo” into the
slot in the wrong direction, the “Memory Stick
Duo,” the Memory Stick Duo slot, or image data
may be damaged.
• When inserting or ejecting the “Memory Stick
Duo,” be careful that the “Memory Stick Duo”
does not pop out and drop.
20
Recording/Playback
A
60min
11
Easy Recording/Playback (Easy Handycam)
With this Easy Handycam operation, most of the camera settings are automatically optimally
adjusted, which frees you from detailed adjustments. The screen font size increases for easy
viewing.
E
If the POWER switch is set to
OFF (CHG), slide it while
pressing the green button.
D
B
C
Movies
1 Slide the POWER
switch E to turn on
the CAMERA-TAPE
lamp.
2 Press EASY C.
EASY
appears on the screen
A.
3 Press START/STOP F or B to
start recording.
REC
EASY
60min
MENUGUIDE
[STBY] t [REC]
To stop recording, press F or B
again.
F
Still images
1 Slide the POWER
switch E to turn on
the CAMERAMEMORY lamp.
2 Press EASY C.
EASY
appears on the screen
A.
3 Press PHOTO D to record.*
11
60min
60min
101
Flashing t Lit
Press and hold lightly
to adjust the focus.
11
EASY
6.1M
MENUGUIDE
Press fully to record.
Recording/Playback
* Still images are recorded in [FINE] quality on a “Memory Stick Duo.”
Continued ,
21
B
S
Easy Recording/Playback (Easy Handycam) (Continued)
Playing back movies/still images
Slide the POWER switch E to turn on the PLAY/EDIT lamp. Touch the buttons
on the touch panel A as follows.
Movies
Touch to rewind,
then touch to start
playback.
A
A Stop
B Play/Pause toggles
C Rewind/Fast forward
C
x To cancel Easy Handycam operation
Press EASY C again. disappears from the screen.
x Adjustable menu settings during Easy Handycam operation
Touch [MENU] to display adjustable menu settings. See page 39 for details on settings.
• Almost all the settings return to their default settings automatically (p. 40).
• is not displayed during Easy Handycam operation.
• Cancel Easy Handycam operation if you want to add any effects or settings to the images.
till images
Touch t /
to select a picture.
A
GUIDE
C
B
A GUIDE (p. 31)
B Tape playback
C Previous/Next
D Delete (p. 69)
D
MENU
x Unavailable buttons during Easy Handycam
During Easy Handycam operation, the following buttons/dial are unavailable. [Invalid
during Easy Handycam operation] may appear if operations not available during Easy
Handycam are attempted.
• . (back light) button (p. 27)
• Pressing and holding DISPLAY/BATT INFO button (p. 18)
• CAM CTRL dial (p. 26)
• MANUAL button (p. 26)
22
Recording
Lens cover
Opens in accordance with the
setting of the POWER switch.
POWER switch
START/STOP B
START/STOP A
Recording movies
Movies are recorded on a tape.
Slide the POWER switch in the direction of the arrow repeatedly
to turn on the CAMERA-TAPE lamp.
If the POWER switch is set to OFF (CHG), slide it
while pressing the green button.
Recording/Playback
Press START/STOP A (or B
60min
STBY REC
[STBY]
).
60min
P-MENUGUIDE P-MENUGUIDE
60min
[REC]
To stop recording, press START/STOP A (or B) again.
z Tips
• The pictures are recorded in the HDV format in the default setting (p. 57).
To record high quality still images during tape recording (Dual Rec)
See page 25 for details.
60min
Continued ,
23
Recording (Continued)
Recording still images
Still images are recorded on the “Memory Stick Duo.”
Slide the POWER switch in the direction of the arrow repeatedly
to turn on the CAMERA-MEMORY lamp.
If the POWER switch is set to OFF (CHG), slide it
while pressing the green button.
Press and hold PHOTO lightly to adjust the focus, then press it
fully to record.
min min
Beep
A shutter sound is heard. When disappears, the image has been recorded.
6.1M 6.1M
P-MENU P-MENUGUIDE GUIDE
Flashing bLights up
Shutter click
To check the latest recording on a “Memory Stick Duo”
Touch . To delete the picture, touch t [YES].
z Tips
• See page 49 for the image quality, image size and the number of recordable pictures.
24
Zooming
You can magnify images to 10 times the
original size with the power zoom lever or
the zoom buttons on the LCD panel.
Recording high quality still images during tape recording (Dual Rec)
You can record high quality still images on
the “Memory Stick Duo” during tape
recording.
Recording/Playback
Power zoom lever
Wider range of view:
(Wide angle)
Close view: (Telephoto)
Move the power zoom lever slightly for a
slower zoom. Move it further for a faster
zoom.
b Notes
• Be sure to keep your finger on the power zoom
lever. If you move your finger off the power
zoom lever, the operation sound of the power
zoom lever may also be recorded.
• You cannot change the zoom speed with the
zoom buttons on the LCD panel.
• The minimum possible distance between
camcorder and subject while maintaining sharp
focus is about 1 cm (about 13/32 in.) for wide
angle and about 80 cm (about 2 5/8 feet) for
telephoto.
z Tips
• You can set [DIGITAL ZOOM] (p. 48) if you
want to zoom to a level greater than 10 ×.
1 Slide the POWER switch to turn on the
CAMERA-TAPE lamp, then press
START/STOP to start tape recording.
2 Press PHOTO fully.
For each separate time tape recording, up to
3 still images can be recorded.
Orange color
boxes indicate
the number of
recorded
images. When
recording is
finished, the
color changes
to orange.
3 Press START/STOP to stop tape recording.
Stored still images appear one by one, and
the images are stored onto the “Memory
Stick Duo.” When disappears, the
image has been recorded.
b Notes
• Do not eject the “Memory Stick Duo” before
tape recording is finished and the still images
are stored on the “Memory Stick Duo.”
• You cannot use the flash during Dual Rec.
z Tips
• During the standby mode, still images will be
stored in the same way as when the POWER
switch is set to CAMERA-MEMORY. You can
use the flash.
Continued ,
25
Recording (Continued)
• When the POWER switch is set to CAMERATAPE, still images will be recorded at image
size 4.6M in the HDV format, 3.4M (4:3) or
4.6M (16:9) in the DV format.
Controlling the image settings manually with the CAM CTRL dial
It is useful to assign a frequently used menu
item to the CAM CTRL dial.
The following is an example of the
procedure when the [FOCUS] setting is
assigned (the default setting).
MANUAL button
CAM CTRL dial
1 Press the MANUAL button to activate the
manual adjustment mode.
The setting mode switches between
automatic and manual every time you press
the MANUAL button.
2 Rotate the CAM CTRL dial to adjust the
focus manually.
Menu items that can be assigned
– [FOCUS] (p. 45)
– [EXPOSURE] (p. 43)
– [SHUTTR SPEED] (p. 44)
– [AE SHIFT] (p. 45)
– [WB SHIFT] (p. 45)
STBY
DIAL SET
FOCUS
EXPOSURE
SHUTTR SPEED
AE SHIFT
WB SHIFT
RESET
0:00:0060
min
[MANUAL]:EXEC
2 Rotate the CAM CTRL dial and select a
menu item to be assigned.
3 Press the MANUAL button.
b Notes
• The menu item settings done before will be
retained even if you set other menu item settings
after that. If [EXPOSURE] is set after [AE
SHIFT] is set manually, [EXPOSURE] will
override [AE SHIFT].
• If you select [RESET] in step 2, all the settings
set manually return to the default setting.
z Tips
• During playback, you can adjust the volume
using the CAM CTRL dial.
• You can also assign menu items using [DIAL
SET] (p. 49).
Using the flash
Flash
Flash
button
To assign the menu items to the CAM
CTRL dial
1 Press and hold the MANUAL button for
several seconds.
The [DIAL SET] screen appears.
26
Press the (flash) button repeatedly to
select an appropriate setting.
No indication (Auto flash): Automatically
flashes when there is insufficient ambient
light.
r
(Forced flash): Always uses the flash
regardless of the surrounding brightness.
r
(No flash): Records without flash.
b Notes
• Remove the lens hood when you use the flash,
or its shadow will appear in the picture.
• The recommended distance to the subject when
using the built-in flash is 0.3 to 2.5 m (1 to 8
feet).
• Remove any dust from the surface of the flash
lamp before using it. Flash effect may be
impaired if heat discoloration or dust obscures
the lamp.
• The /CHG (charge) lamp flickers when
charging the flash, and remains lit when the
flash charge is ready. (In [STBY] of the
CAMERA-TAPE mode, it takes a while to fully
charge the flash.)
• You cannot use the flash during tape recording.
• If you use the flash in bright places such as
when shooting a backlit subject, the flash may
not be effective.
z Tips
• You can change the brightness of the flash by
setting [FLASH LEVEL], or you can prevent
the redeye by setting [REDEYE REDUC], in
[FLASH SET] (p. 46).
Recording in dark places (NightShot)
• Adjust the focus manually ([FOCUS], p. 45)
when it is hard to focus automatically.
• Do not use these functions in bright places. This
may cause a malfunction.
z Tips
• To record an image brighter, use Super
NightShot function (p. 47). To record an image
more faithful to the original colors, use Color
Slow Shutter function (p. 47).
Adjusting the exposure for backlit subjects
To adjust the exposure for backlit subjects,
press . (back light) to display .. To
cancel the backlight function, press .
(back light) again.
Recording in mirror mode
Recording/Playback
Infrared port
Set the NIGHTSHOT switch to ON (
and [“NIGHTSHOT”] appear).
b Notes
• The NightShot and Super NightShot functions
use infrared light. Therefore, do not cover the
infrared port with your fingers or other objects
and remove the conversion lens (optional) and
the lens hood.
Open the LCD panel 90 degrees to the
camcorder (1), then rotate it 180 degrees
to the lens side (2).
z Tips
• A mirror-image of the subject appears on the
LCD screen, but the picture will be normal
when recorded.
27
Playback
Slide the POWER switch in the direction of the arrow repeatedly to
turn on the PLAY/EDIT lamp.
If the POWER switch is set to OFF (CHG), slide it
while pressing the green button.
Playing movies
Touch to rewind to the desired scene, then touch to start
playback.
Toggles Play or Pause as you touch*
60min
Stop**
* Playback automatically stops if pause is engaged for more than 3 minutes.
** is displayed instead of when a “Memory Stick Duo” with recorded images is inserted and
a tape is not being played.
Rewind/Fast forward
60min
GUIDE
P-MENU
To adjust the sound volume
Rotate the CAM CTRL dial to adjust the volume manually (p. 26).
z Tips
• You can also adjust the volume from the menu (p. 58).
To search for a scene during playback
Touch and hold / during playback (Picture Search), or / while fast
forwarding or rewinding the tape (Skip Scan).
z Tips
• You can play back in various modes ([ VAR.SPD PB], p. 55).
28
Viewing still images
min
MEMORY PLAY
Touch .
The most recently recorded image is displayed.
6060min
60min 10/10
6.1M
MEMORY PLAY
MEMORY PLAY
GUIDE
Switches the
P-MENU
playback media*
Previous/Next
Go to the index screen display
* is displayed on the tape playback screen.
To display pictures on a “Memory Stick Duo” on the Index screen
Touch . Touch one of the pictures to back to the single display mode.
A
A Previous/Next 6 pictures
B The picture displayed before switching to the index screen
To view pictures in other folders, touch t t [PB FOLDER], select a folder with
/ , then touch (p. 51).
B
Recording/Playback
Continued ,
29
Playback (Continued)
Using PB zoom
You can magnify images from about 1.1 to
5 times (from about 1.5 to 5 times in still
images) the original size.
Magnification can be adjusted with the
power zoom lever or the zoom
buttons on the LCD panel.
1 Play back the picture you want to
magnify.
2 Magnify the picture with T (Telephoto).
3 Touch the screen at the point you want
to display in the center of the displayed
frame.
4 Adjust the magnification with W (Wide
angle)/T (Telephoto).
To cancel, touch [END].
30
Loading...
