4-265-634-45(1)

Digital Still Camera / Instruction Manual GB

DSC-TX100/TX100V

English

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call your Sony dealer regarding this product.

Model No. DSC-TX100/TX100V

Serial No. ______________________________

Model No. AC-UB10/UB10B

Serial No. ______________________________

WARNING

To reduce fire or shock hazard, do not expose the unit to rain or moisture.

IMPORTANT SAFETY INSTRUCTIONS

-SAVE THESE INSTRUCTIONS DANGER TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS

If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the proper configuration for the power outlet.

CAUTION

[ Battery pack

If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical burns. Observe the following cautions.

• Do not disassemble.

• Do not crush and do not expose the battery pack to any shock or force such as hammering, dropping or stepping on it.

• Do not short circuit and do not allow metal objects to come into contact with the battery terminals.

• Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a car parked in the sun.

• Do not incinerate or dispose of in fire.

• Do not handle damaged or leaking lithium ion batteries.

• Be sure to charge the battery pack using a genuine Sony battery charger or a device that

can charge the battery pack.

• Keep the battery pack out of the reach of small children.

• Keep the battery pack dry.

• Replace only with the same or equivalent type recommended by Sony.

• Dispose of used battery packs promptly as described in the instructions.

[ AC Adaptor

Connect the AC Adaptor to the nearest wall outlet (wall socket). If some trouble occurs while using the AC Adaptor, immediately shut off the power by disconnecting the plug from the wall outlet (wall socket).

The power cord (mains lead), if supplied, is designed specifically for use with this camera only, and should not be used with other electrical equipment.

For Customers in the U.S.A. and Canada

[ RECYCLING LITHIUM-ION BATTERIES

Lithium-Ion batteries are recyclable. You can help preserve our environment by returning your used rechargeable batteries to the collection and recycling location nearest you.

For more information regarding recycling of rechargeable batteries, call toll free 1-800-822-8837, or visit http://www.rbrc.org/

Caution: Do not handle damaged or leaking Lithium-Ion batteries.

[ Battery pack

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This Class B digital apparatus complies with Canadian ICES-003.

For Customers in the U.S.A.

UL is an internationally recognized safety organization. The UL Mark on the product means it has been UL Listed.

If you have any questions about this product, you may call:

Sony Customer Information Center 1-800-222-SONY (7669).

The number below is for the FCC related matters only.

[ Regulatory Information

Declaration of Conformity

Trade Name: SONY Model No.: DSC-TX100V Responsible Party: Sony Electronics Inc. Address: 16530 Via Esprillo,

Telephone No.: 858-942-2230

This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

San Diego, CA 92127 U.S.A.

[ CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

[ Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate rad io frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

The supplied interface cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

For Customers in Europe

Hereby, Sony Corporation, declares that this DSC-TX100V Digital Still Camera is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC. For details, please access the following URL: http://www.compliance.sony.de/

[ Notice for the customers in the countries applying EU Directives

The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or guarantee matters please refer to the addresses given in separate service or guarantee documents.

This product has been tested and found compliant with the limits set out in the EMC regulation for using connection cables shorter than 3 meters (9.8 feet).

[ Attention

The electromagnetic fields at the specific frequencies may influence the picture and sound of this unit.

[ Notice

If static electricity or electromagnetism causes data transfer to discontinue midway (fail), restart the application or disconnect and connect the communication cable (USB, etc.) again.

[ Disposal of Old Electrical & Electronic Equipment (Applicable in

the European Union and other European countries with separate collection systems)

please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product,

[ Disposal of waste batteries (applicable in the European Union

and other European countries with separate collection systems)

This symbol on the battery or on the packaging indicates that the battery provided with this product shall not be treated as household waste. On certain batteries this symbol might be used in combination with a chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are added if the battery contains more than 0.0005% mercury or 0.004% lead.

potentially negative consequences for the environment and human health which could otherwise be caused by inappropriate waste handling of the battery. The recycling of the materials will help to conserve natural resources. In case of products that for safety, performance or data integrity reasons require a permanent connection with an incorporated battery, this battery should be replaced by qualified service staff only. To ensure that the battery will be treated properly, hand over the product at end-of-life to the applicable collection point for the recycling of electrical and electronic equipment. For all other batteries, please view the section on how to remove the battery from the product safely. Hand the battery over to the applicable collection point for the recycling of waste batteries. For more detailed information about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

By ensuring these batteries are disposed of correctly, you will help prevent

Notice for customers in the United Kingdom

A moulded plug complying with BS 1363 is fitted to this equipment for your safety and convenience. Should the fuse in the plug supplied need to be replaced, a fuse of the same rating as the supplied one and approved by ASTA or BSI to BS 1362, (i.e., marked with an or mark) must be used. If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.

Refer to “Cyber-shot User Guide” (HTML) on supplied CD-ROM

For details on advanced operations, please read “Cyber-shot User Guide” (HTML) on the CD-ROM (supplied) using a computer.

Insert the CD-ROM into the CD-ROM drive.

For Windows users:

1 Click [User Guide] t [Install]. 2 Start “User Guide” from the shortcut on the desktop.

For Macintosh users:

1 Select the [User Guide] folder and copy [eng] folder stored in [User Guide]

folder to your computer.

2 After copying is complete, double-click “index.html” in [eng] folder.

Checking the supplied items

• Camera (1)

• Rechargeable battery pack NP-BN1 (1)

• Multi-use terminal USB cable (1)

• AC Adaptor AC-UB10/UB10B (1)

• Power cord (mains lead) (not supplied in the USA and Canada) (1)

• Paint pen (1)

• Wrist strap (1)

•CD-ROM (1)

– Cyber-shot application software – “Cyber-shot User Guide”

• Instruction Manual (this manual) (1)

Identifying parts

E Lens F Self-timer lamp/Smile Shutter

lamp/AF illuminator

G Speaker H (Playback) button I Screen/Touch panel J ON/OFF (Power) button K Shutter button L For shooting: W/T (Zoom) lever M Hook for wrist strap N Tripod receptacle

• Use a tripod with a screw less than 5.5 mm (7/32 inches) long. Otherwise, you cannot firmly secure the camera, and damage to the camera may occur.

O Battery eject lever P Battery insertion slot Q (TransferJet™) mark R Battery/memory card cover S Multi connector (Type3b) T Access lamp U Memory card slot V HDMI connector W Connector cover

A Flash B Lens cover C Microphone D GPS sensor (built-in, DSC-

TX100V only)

Inserting the battery pack

Eject lever

Open the cover.

Insert the battery pack.

• While pressing the battery eject lever, insert the battery pack as illustrated. Make sure that the battery eject lever locks after insertion.

Charging the battery pack

For customers in the USA, Canada

Power cord (Mains lead)

For customers in countries/regions other than the USA and Canada

Power/Charge lamp Lit: Charging Off: Charging finished Flash: Charging error

Connect the camera and the AC Adaptor (supplied),

using the multi-use terminal USB cable (supplied).

Connect the AC Adaptor to the wall outlet (wall socket).

The Power/Charge lamp lights orange, and charging starts.

• Turn off the camera while charging the battery.

• You can charge the battery pack even when it is partially charged.

• When the Power/Charge lamp flashes and charging is not finished, remove and re-insert the battery pack.

Notes

• When the Power/Charge lamp on the camera does not lit even if the AC Adaptor is connected to the camera and the wall outlet (wall socket), it indicates that the charging stops temporarily on standby. The charging stops and enters the standby status automatically when the temperature is outside of the recommended operating temperature. When the temperature gets back within the appropriate range, the charging resumes. We recommend charging the battery pack in an ambient temperature of between 10°C to 30°C (50ºF to 86ºF).

• Connect the AC Adaptor (supplied) to the nearest wall outlet (wall socket). If any malfunctions occur while using the AC Adaptor, disconnect the plug from the wall outlet (wall socket) immediately to disconnect the power source.

• When charging is finished, disconnect the AC Adaptor from the wall outlet (wall socket).

• Be sure to use only genuine Sony brand battery packs, multi-use terminal USB cable (supplied) and AC Adaptor (supplied).

Charging by connecting to a computer

The battery pack can be charged by connecting the camera to a computer using a multi-use terminal USB cable.

Note

• Note the following points when charging via a computer:

– If the camera is connected to a laptop computer that is not connected to a power

source, the laptop battery level decreases. Do not charge for an extended period of time.

– Do not turn on/off or restart the computer, or wake the computer resume from

sleep mode when a USB connection has been established between the computer and the camera. The camera may cause a malfunction. Before turning on/off, or restarting the computer or waking the computer from sleep mode, disconnect the camera and the computer.

– No guarantees are made for charging using a custom-built computer or a

modified computer.

Charging time

The charging time is approximately 210 min. using the AC Adaptor (supplied).

Note

• The above charging time applies when charging a fully depleted battery pack at a

temperature of 25°C (77°F). Charging may take longer depending on conditions of use and circumstances.

Battery life and number of still images you can record and view

Battery life Number of images

Shooting (still images) Approx. 110 min. Approx. 220 images

Viewing (still images) Approx. 160 min. Approx. 3200 images

Shooting (movies) Approx. 55 min. —

Notes

• The above number of still images applies when the battery pack is fully charged. The number of still images may decrease depending on the conditions of use.

• The number of still images that can be recorded is for shooting under the following conditions: – Using Sony “Memory Stick PRO Duo” (Mark2) media (sold separately) – The battery pack is used at an ambient temperature of 25°C (77°F). – [GPS setting]: [Off] (DSC-TX100V only)

• The number for “Shooting (still images)” is based on the CIPA standard, and is for shooting under the following conditions: (CIPA: Camera & Imaging Products Association) – [Panel Brightness] is set to [3]. – Shooting once every 30 seconds. – The zoom is switched alternately between the W and T ends. – The flash strobes once every two times. – The power turns on and off once every ten times.

• The battery life for movies applies shooting under the following conditions: – Movie quality: AVCHD HQ – When continuous shooting ends because of set limits (page 22), touch

(Movie button) again and continue shooting. Shooting functions such as the zoom do not operate.

Supplying power

The camera can be supplied with power from the wall outlet (wall socket) by connecting to the AC Adaptor, using the multi-use terminal USB cable (supplied). You can import images to a computer without worrying about wearing down the battery pack by connecting the camera to a computer using the multi-use terminal USB cable.

Notes

• Power cannot be supplied when the battery pack is not inserted in the camera.

• Power supply from the wall outlet (wall socket) is available only when the camera

is in playback mode or when a connection is made between the camera and a computer. If the camera is in shooting mode or while you are changing the settings of the camera, power is not supplied even if you make a USB connection using the multi-use terminal USB cable.

• If you connect the camera and a computer using the multi-use terminal USB cable

when the camera is in playback mode, the display on the camera is changed from the playback screen to the USB connection screen. Press (Playback) button to switch to the playback screen.

Inserting a memory card (sold separately)

Ensure the notched corner faces correctly.

Open the cover.

Insert the memory card (sold separately).

• With the notched corner facing as illustrated, insert the memory card until it clicks into place.

Close the cover.

• Closing the cover with the battery inserted incorrectly may damage the camera.

Memory cards that you can use

Memory card For still images For movies

Memory Stick PRO Duo aa (Mark2 only)

Memory Stick PRO-HG Duo aa

Memory Stick Duo a —

SD memory card aa (Class 4 or faster)

SDHC memory card aa (Class 4 or faster)

SDXC memory card aa (Class 4 or faster)

• In this manual, products in A are collectively referred to as “Memory Stick Duo” media, and products in B are collectively referred to as SD card.

To remove the memory card/battery pack

Memory card: Push the memory card in once. Battery pack: Slide the battery eject lever. Be sure not to drop the battery pack.

Note

• Never remove the memory card/battery pack when the access lamp (page 8) is lit. This may cause damage to data in the memory card/internal memory.

Setting the clock

ON/OFF (Power) button

Lower the lens cover.

The camera is turned on. The power lamp lights up only when the camera starts up.

• You can also turn on the camera by pressing the ON/OFF (Power) button.

• It may take time for the power to turn on and allow operation.

Select a desired language.

Select the desired area following the instructions on the

screen, then touch [NEXT].

Set [Daylight Savings] or [Summer Time], [Date & Time

Format] and [Date & Time], then touch [NEXT].

• Midnight is indicated as 12:00 AM, and noon as 12:00 PM.

Touch [OK].

Select the desired display color and [GPS setting]

(DSC-TX100V), following the instructions on the screen, then touch [OK].

• The battery pack will run out quickly if you set [GPS setting] to [On]. (DSC-TX100V only)

When an [In-Camera Guide] introductory message is

appeared on the screen, touch [OK].

Lens cover

Shooting still images/movies

Movie button

Shutter button

Shooting still images

Press the shutter button halfway down to focus.

When the image is in focus, a beep sounds and the z indicator lights.

Press the shutter button fully down.

Shooting movies

Touch (Movie button) to start recording.

• Use the W/T (zoom) lever to change the zoom scale.

Touch (Movie button) to stop recording.

Note

• Continuous shooting is possible for approximately 29 minutes at one time at the camera’s default settings and when the temperature is approximately 25°C (77°F). When movie recording is finished, you can restart recording by touching (Movie button) again. Recording may stop to protect the camera depending on the ambient temperature.

Viewing images

(Playback)

Press the (Playback) button.

• When images on a memory card recorded with other cameras are played back on this camera, the registration screen for the data file appears.

Selecting next/previous image

Touch (Next)/ (Previous) on the screen.

• To play back movies, touch (Playback) in the center of the screen.

• To zoom in, touch the image being played back.

Deleting an image

1 Touch (Delete) t [This Image].

Returning to shooting images

Touch .

• You can also return to shooting mode by pressing the shutter button halfway down.

In-Camera Guide

This camera contains an internal function guide. This allows you to search the camera’s functions according to your needs.

Touch (In-Camera Guide).

• The mark will appear on the bottom right of the screen while viewing.

Select a search method from [In-Camera Guide].

Shoot/ playback guide: Search for various operation functions in shooting/viewing mode.

Icon guide: Search the function and meaning of displayed icons. Troubleshooting: Search common problems and their solution. Objective guide: Search functions according to your needs. Keyword: Search functions by key words. History: Display the last 10 items displayed in [In-Camera Guide].

Introduction of other functions

Other functions used when shooting or playing back can be operated touching the MENU on the screen. This camera is equipped with a Function Guide that allows you to easily select from the functions. While displaying the guide, try the other functions.

Menu Items

Shooting

Movie shooting scene

Easy Mode Shoot still images using minimal functions.

Movie button Shoot movies from all REC modes quickly.

Flash Sets the flash settings.

Self-Timer Sets the self-timer settings.

Defocus Effect

Still Image Size/ Panorama Image Size/Movie Size/ Movie Quality

Burst Settings Sets the burst shooting settings.

Macro Shoots beautiful close-up images of small subjects.

EV Adjust the exposure manually.

ISO Adjust the luminous sensitivity.

White Balance Adjust color tones of an image.

Focus Select the focus method.

Select movie recording mode.

Set the level of background defocus effect when shooting in Background Defocus mode.

Select the image size and the quality for still images, panoramic images or movie files.

Metering Mode

Select the metering mode that sets which part of the subject to measure to determine the exposure.

Scene Recognition Set to automatically detect shooting conditions.

Soft Skin Effect Set the Soft Skin Effect and the effect level.

Smile Shutter

Smile Detection Sensitivity

Face Detection

Anti Blink

Position Information

Set to automatically release the shutter when a smile is detected.

Set the Smile Shutter function sensitivity for detecting smiles.

Select to detect faces and adjust various settings automatically.

Set to automatically shoot two images and select image in which the eyes are not blinking.

Checking the triangulating status.

In-Camera Guide Search the camera’s functions according to your needs.

DSC-TX100V only

Viewing

Easy Mode Increase the text size on the screen for ease of use.

Date Select Selects the desired image to view by date.

Calendar Selects the date to be played back on Calendar.

Image Index Displays multiple images at the same time.

Slideshow Select a method of continuous playback.

Delete Delete an image.

Send by TransferJet

Transfer data by closely aligning two products equipped with TransferJet.

Paint Paints on a still image and saves it as a new file.

Retouch Retouch an image using various effects.

3D Viewing Set to play back images shot in 3D mode on a 3D TV.

View Mode Select the display format for images.

Display Burst Group

Select to display burst images in groups or display all images during playback.

Protect Protect the images.

Print (DPOF) Add a print order mark to a still image.

Rotate Rotate a still image to the left or right.

Volume Adjusts the volume.

Exposure data

Number of images

Sets whether or not to display the shooting data (Exif data) of the currently displayed file on the screen.

Sets the number of images displayed in the index screen.

in index

In-Camera Guide Search the camera’s functions according to your needs.

Setting items

If you touch the MENU while shooting or during playback, (Settings) is provided as a final selection. You can change the default settings on the

(Settings ) screen.

Shooting Settings

Movie format/AF Illuminator/Grid Line/Digital Zoom/ Wind Noise Reduct./Scene Recog. Guide/Red Eye Reduction/Blink Alert/Write Date

Beep/Panel Brightness/Language Setting/Display color/

Main Settings

Memory Card

Tool

Clock Settings

DSC-TX100V only

If a memory card is not inserted, (Internal Memory Tool) will be displayed

Demo Mode/Initialize/HDMI Resolution/CTRL FOR HDMI/USB Connect Setting/USB Power Supply/LUN Setting/Download Music/Empty Music/GPS setting GPS assist data

/TransferJet/Eye-Fi/Power Save

Format/Create REC.Folder/Change REC.Folder/Delete REC.Folder/Copy/File Number

Area Setting/Date & Time Setting/Auto Clock ADJ Auto Area ADJ

and only [Format] can be selected.

Number of still images and recordable time of movies

The number of still images and recordable time may vary depending on the shooting conditions and the memory card.

Still images

(Units: Images)

Capacity

Size

16M 3 335

VGA 98 9600

16:9(12M) 3 355

Movies

Internal memory Memory card

Approx. 19 MB 2 GB

The table below shows the approximate maximum recording times. These are the total times for all movie files. Continuous shooting is possible for approximately 29 minutes. The maximum size of an MP4-format movie file is up to approximately 2 GB.

(h (hour), m (minute))

Capacity

Size

AVC HD 28M (PS) — 9 m

AVC HD 9M (HQ) — 25 m

MP4 12M — 20 m

MP4 3M — 1 h 10 m

The number in ( ) is the minimum recordable time.

• The recordable time of movies varies because the camera is equipped with VBR (Variable Bit-Rate), which automatically adjusts image quality depending on the shooting scene. When you record a fast-moving subject, the image is clearer but the recordable time is shorter because more memory is required for recording. The recordable time also varies depending on the shooting conditions, the subject or the image quality/size settings.

Internal memory Memory card

Approx. 19 MB 2 GB

(9 m)

(15 m)

Notes on using the camera

Functions built into this camera

• This manual describes the functions of GPS-compatible/incompatible devices,

TransferJet-compatible/incompatible devices, 1080 60p-compatible devices and 1080 50p-compatible devices. To determine whether your camera supports the GPS function, check the model name of your camera. GPS-compatible: DSC-TX100V GPS-incompatible: DSC-TX100 To check if your camera supports the TransferJet function, and whether it is a 1080 60i-compatible device or 1080 50i-compatible device, check for the following marks on the bottom of the camera. TransferJet-compatible device: 1080 60i-compatible device: 60i 1080 50i-compatible device: 50i

• This camera is compatible with 1080 60p movie.

Progressive mode increases resolution over standard interlaced recording mode, resulting in smoother and more realistic images.

• In an airplane, make sure to turn off the camera following cabin announcements.

• Do not watch 3D images shot with this camera for extended periods of time on

3D-compliant monitors.

• When you view 3D images shot with this camera on a 3D-compliant monitors, you

may experience discomfort in the form of eye strain, fatigue, or nausea. To prevent these symptoms, we recommend that you take regular breaks. However, you need to determine for yourself the length and frequency of breaks you require, as they vary according to the individual. If you experience any type of discomfort, stop viewing the 3D images until you feel better, and consult a physician as necessary. Also refer to the operating instructions supplied with the device or software you have connected or are using with this camera. Note that a child's eyesight is still at the development stage (particularly children below the age of 6). Consult a pediatrician or ophthalmologist before letting your child view 3D images, and make sure he/she observes the above precautions when viewing such images.

On GPS-compatible devices (DSC-TX100V only)

• Use GPS in accordance with regulations of countries and regions where you use it.

• If you do not record the direction or location information, set [GPS setting] to

[Off].

On use and care

Avoid rough handling, disassembling, modifying, physical shock, or impact such as hammering, dropping, or stepping on the product. Be particularly careful of the lens.

(TransferJet)

Notes on recording/playback

• Before you start recording, make a trial recording to make sure that the camera is working correctly.

• The camera is neither dust-proof, nor splash-proof, nor water-proof.

• Avoid exposing the camera to water. If water enters inside the camera, a malfunction may occur. In some cases, the camera cannot be repaired.

• Do not aim the camera at the sun or other bright light. It may cause the malfunction of the camera.

• If moisture condensation occurs, remove it before using the camera.

• Do not shake or strike the camera. It may cause a malfunction and you may not be able to record images. Furthermore, the recording media may become unusable or image data may be damaged.

Do not use/store the camera in the following places

• In an extremely hot, cold or humid place In places such as in a car parked in the sun, the camera body may become deformed and this may cause a malfunction.

• Under direct sunlight or near a heater The camera body may become discolored or deformed, and this may cause a malfunction.

• In a location subject to rocking vibration

• Near a location that generates strong radio waves, emits radiation or is strongly magnetic place. Otherwise, the camera may not properly record or play back images.

• In sandy or dusty places Be careful not to let sand or dust get into the camera. This may cause the camera to malfunction, and in some cases this malfunction cannot be repaired.

On carrying

Do not sit down in a chair or other place with the camera in the back pocket of your trousers or skirt, as this may cause malfunction or damage the camera.

Carl Zeiss lens

The camera is equipped with a Carl Zeiss lens which is capable of reproducing sharp images with excellent contrast. The lens for the camera has been produced under a quality assurance system certified by Carl Zeiss in accordance with the quality standards of Carl Zeiss in Germany.

Notes on the screen and lens

• The screen is manufactured using extremely high-precision technology so over

99.99% of the pixels are operational for effective use. However, some tiny black and/or bright dots (white, red, blue or green) may appear on the screen. These dots are a normal result of the manufacturing process, and do not affect the recording.

• The touch panel is less likely to react when gloves are worn.

• If you continue or repeat to display the same image on the screen for a long period

of time, the image may be burned into the screen permanently. In order to prevent an image from being burned into the screen, avoid displaying the same image for a long period of time.

On camera’s temperature

Your camera and battery may get hot due to continuous use, but it is not a malfunction.

On the overheat protection

Depending on the camera and battery temperature, you may be unable to record movies or the power may turn off automatically to protect the camera. A message will be displayed on the screen before the power turns off or you can no longer record movies. In this case, leave the power off and wait until the camera and battery temperature goes down. If you turn on the power without letting the camera and battery cool enough, the power may turn off again or you may be unable to record movies.

On charging the battery

If you charge a battery that has not been used for a long time, you may be unable to charge it to the proper capacity. This is due to the battery characteristics, and is not a malfunction. Charge the battery again.

Warning on copyright

Television programs, films, videotapes, and other materials may be copyrighted. Unauthorized recording of such materials may be contrary to the provisions of the copyright laws.

No compensation for damaged content or recording failure

Sony cannot compensate for failure to record or loss or damage of recorded content due to a malfunction of the camera or recording media, etc.

Cleaning the camera surface

Clean the camera surface with a soft cloth slightly moistened with water, then wipe the surface with a dry cloth. To prevent damage to the finish or casing: – Do not expose the camera to chemical products such as thinner, benzine, alcohol,

disposable cloths, insect repellent, sunscreen or insecticide.

Specifications

Camera

[System]

Image device: 7.77 mm (1/2.3 type)

Exmor R CMOS sensor

Total pixel number of camera:

Approx. 16.8 Megapixels

Effective pixel number of camera:

Approx. 16.2 Megapixels

Lens: Carl Zeiss Vario-Tessar 4× zoom

lens f = 4.43 mm – 17.7 mm (25 mm – 100 mm (35 mm film equivalent)) F3.5 (W) – F4.6 (T) While shooting movies (16:9): 27 mm – 108 mm While shooting movies (4:3):

33 mm – 132 mm SteadyShot: Optical Exposure control: Automatic exposure,

Scene Selection (15 modes) White balance: Automatic, Daylight,

Cloudy, Fluorescent 1/2/3,

Incandescent, Flash, One Push Signal format:

For 1080 50i: PAL color, CCIR

standards HDTV 1080/50i, 1080/

50p specification

For 1080 60i: NTSC color, EIA

standards HDTV 1080/60i, 1080/

60p specification File format:

Still images: JPEG (DCF Ver. 2.0,

Exif Ver. 2.3, MPF Baseline)

compliant, DPOF compatible

3D still images: MPO (MPF

Extended (Disparity Image))

compliant

Movies (AVCHD view): AVCHD

format Ver.2.0 compatible

Video: MPEG-4 AVC/H.264 Audio: Dolby Digital 2ch, equipped with Dolby Digital Stereo Creator

• Manufactured under license from

Dolby Laboratories. Movies (MP4 view): MP4 format Video: MPEG-4 AVC/H.264 Audio: MPEG-4 AAC-LC 2ch

Recording media: Internal Memory

(Approx. 19 MB), “Memory Stick Duo” media, SD cards

Flash: Flash range (ISO sensitivity

(Recommended Exposure Index) set to Auto): Approx. 0.08 m to 5.1 m (3 1/4 inches to 16 feet 8 7/8 inches) (W) Approx. 0.5 m to 4.0 m (1 feet 7 3/4 inches to 13 feet 1 1/2 inches) (T)

[Input and Output connectors]

HDMI connector: HDMI mini jack Multi connector: Type3b

(AV-out/USB/DC-in): Video output Audio output (Stereo) USB communication

USB communication: Hi-Speed USB

(USB 2.0)

[Screen]

OLED:

Wide (16:9), 8.8cm (3.5 type)

Total number of dots:

1 229 760 dots equivalent

[Power, general]

Power: Rechargeable battery pack

NP-BN1, 3.6 V AC Adaptor AC-UB10/UB10B, 5V

Power consumption (during shooting):

1.0 W

Operating temperature: 0 °C to 40 °C

(32 °F to 104 °F)

Storage temperature: –20 °C to +60 °C

(–4 °F to +140 °F)

Dimensions (CIPA compliant):

97.0 mm × 58.5 mm × 17.8 mm (3 7/8 inches × 2 3/8 inches × 23/32 inches) (W/H/D)

Mass (CIPA compliant) (including NP-

BN1 battery pack, “Memory Stick Duo” media):

Approx. 147 g (5.2 oz) Microphone: Stereo Speaker: Monaural Exif Print: Compatible PRINT Image Matching III:

Compatible

AC Adaptor AC-UB10/UB10B

Power requirements: AC 100 V to

240 V, 50 Hz/60 Hz, 70 mA Output voltage: DC 5 V, 0.5 A Operating temperature: 0 °C to 40 °C

(32°F to 104°F) Storage temperature: –20 °C to +60 °C

(–4 °F to +140 °F) Dimensions:

Approx. 50 mm × 22 mm × 54 mm

(2 inches × 7/8 inches ×

2 1/4 inches) (W/H/D) Mass:

For the USA and Canada: Approx.

48 g (1.7 oz)

For countries or regions other than

the USA and Canada: Approx. 43 g

(1.5 oz)

Rechargeable battery pack NP-BN1

Used battery: Lithium-ion battery Maximum voltage: DC 4.2 V Nominal voltage: DC 3.6 V Maximum charge voltage: DC 4.2 V Maximum charge current: 0.9 A Capacity:

typical: 2.3 Wh (630 mAh)

minimum: 2.2 Wh (600 mAh)

Design and specifications are subject to change without notice.

Trademarks

• The following marks are trademarks of Sony Corporation.

, “Cyber-shot,” “Memory Stick PRO Duo,” “Memory Stick PRO-HG Duo,” “Memory Stick Duo”

• Windows is registered trademark of Microsoft Corporation in the United States and/or other countries.

• Macintosh is registered trademark of Apple Inc..

• SDXC logo is a trademark of SD-3C, LLC.

• “ ” and “PlayStation” are registered trademarks of Sony Computer Entertainment Inc.

• In addition, system and product names used in this manual are, in general, trademarks or registered trademarks of their respective developers or manufacturers. However, the ™ or ® marks are not used in all cases in this manual.

• Add further enjoyment with your PlayStation®3 by downloading the application for PlayStation®3 from PlayStation®Store (where available.)

• The application for PlayStation®3 requires PlayStation®Network account and application download. Accessible in areas where the PlayStation®Store is available.

Additional information on this product and answers to frequently asked questions can be found at our Customer Support Website.

Printed on 70% or more recycled paper using VOC (Volatile Organic Compound)-free vegetable oil based ink.

中文（繁體字）

警告

為減少發生火災或電擊的危險，請勿讓本機暴露於雨中或受潮。

重要的安全指示－請保存這些指示危險為了降低火災或電擊的危險，請小心遵守

這些指示

如果插頭的形狀與電源插座不合，請使用適合電源插座的插頭轉接頭。

注意

[ 電池組

如果電池組處理不當，電池組可能會爆炸，造成火災，甚至化學灼傷。請遵循以下注意事項。

• 切勿拆解。

• 切勿擠壓，撞擊電池組或對電池組用力過度，如敲擊，跌落或踩踏在電池

組上。

• 切勿短路或讓金屬物品接觸到電池端子。

• 切勿暴露在超過60℃的高溫下，例如直射陽光下，或停在太陽下的汽車

內。

• 切勿焚化或丟棄在火中。

• 切勿處理損壞或洩漏的鋰離子電池。

• 務必使用Sony原廠的充電器或可對電池組充電的裝置來為電池組充電。

• 電池組應放在幼兒不易觸及的地方。

• 使電池組保持乾燥。

• 請僅使用與Sony建議的相同或相等的電池類型進行更換。

• 請依照說明書中的說明正確丟棄舊電池組。

[ 電源適配器

將電源適配器連接到附近的牆上電源插座。如果使用電源適配器時發生某些問題，請立即中斷插頭與牆上電源插座的連接，以關閉電源。

如果附帶電源線，則該電源線專為本相機設計，不能用於其他電子設備。

注意

本產品已經過測試並確定符合 EMC指示中所提出的使用連接電纜不得超過 3 公尺的限制。

[ 注意

特定頻率的電磁場可能會影響此機的畫面和聲音。

[ 通知

如果靜電或電磁導致資料傳送中斷（失敗），請重新啟動應用程式或斷開連接，並重新連接通信電纜（USB等）。

僅適用於台灣

廢電池請回收

附屬電纜上附有鐵芯時的注意事項：USB電纜或A/V連接電纜或電源適配器之 DC輸出線上的一個鐵芯係抑制電磁波干擾用，請勿任意拆卸。

請參閱附件CD-ROM上的 “Cyber-shot使用者指南” (HTML)

關於進階操作的詳細資訊，請透過電腦閱讀CD-ROM（附件）上的“Cybershot使用者指南”(HTML)。

將CD-ROM插入CD-ROM光碟機中。

對於Windows使用者：

1 按一下[使用者指南] t [安裝]。 2 從桌面上的捷徑啟動 “使用者指南”。

對於Macintosh使用者：

1 選擇[使用者指南]資料夾，將儲存於[使用者指南]資料夾中的[ct]資

料夾複製到電腦。

2 複製完成後，按兩下[ct]資料夾中的 “index.html”。

檢查隨機項目

• 相機（1）

• 充電電池組NP-BN1 (1)

• USB多功能端子線(1)

• 電源適配器AC-UB10/UB10B (1)

• 電源線（美國和加拿大非附件）(1)

• 畫筆(1)

• 腕帶(1)

• CD-ROM (1) – Cyber-shot應用軟體 –“Cyber-shot使用者指南”

• 使用說明書（本手冊）(1)

認識各部件

E 鏡頭 F 自拍定時器指示燈/微笑快門

指示燈/AF照明器

G 揚聲器 H （播放）按鈕 I 螢幕/觸控面板 J ON/OFF （電源）按鈕 K 快門按鈕 L 用來拍攝：W/T （變焦）控制桿 M 腕帶掛鉤 N 三腳架安裝孔

• 請使用螺絲小於5.5 mm長的三腳架。否則，您將無法固定住相機，並有可能損壞相機。

O 電池彈出控制桿 P 電池插入插槽 Q (TransferJet™)標記 R 電池/記憶卡蓋 S 多功能接頭(Type3b) T 存取指示燈 U 記憶卡插槽 V HDMI接頭 W 接頭蓋

A 閃光燈 B 鏡頭蓋 C 麥克風 D GPS感應器（內建，

僅DSC-TX100V）

插入電池組

彈出控制桿

打開電池蓋。

插入電池組。

• 如圖所示按下電池彈出控制桿以插入電池組。插入後確定電池彈出控制桿鎖定。

對電池組充電

對於在美國和加拿大的客戶

電源線

對於在美國和加拿大以外國家/地區的客戶

電源/充電指示燈亮起：正在充電熄滅：充電完成閃爍：充電錯誤

用USB多功能端子線（附件）連接相機和電源適配器（附

件）。

將電源適配器連接到牆上的電源插座。

電源/充電指示燈亮橘燈，並開始充電。

• 為電池充電時，關閉相機。

• 即使電池組已部分充電，仍然可以對電池組充電。

• 當電源 /充電指示燈閃爍並且未完成充電時，請取出電池組並重新

插入。

注意事項

• 將電源適配器連接到相機和牆上的電源插座後，如果電源 / 充電指示燈仍未亮起，表示充電在待機狀態下暫停。當溫度落在建議操作溫度外，會自動停止充電並進入待機狀態。當溫度回到適當的範圍內，將繼續充電。我們建議在10℃至30℃之間的環境溫度下為電池組充電。

• 將電源適配器（附件）連接到最近的牆上電源插座。如果使用電源適配器時發生故障，請立即拔掉牆上電源插座上的插頭，以斷開電源。

• 充電完成後，拔掉牆上電源插座上的電源適配器。

• 務必使用Sony原廠品牌的電池組、USB多功能端子線（附件）及電源適配器

（附件）。

連接至電腦充電

用USB多功能端子線將相機連接到電腦時，可為電池組充電。

注意事項

• 透過電腦充電時，請注意下列事項： – 如果將相機連接到未連接電源的筆記型電腦，筆記型電腦的電池電量會減

少。請勿長時間充電。

– 電腦和相機之間已建立USB連接時，請勿開啟/關閉或重新啟動電腦，或是

從睡眠模式中喚醒電腦。相機可能會導致故障。開啟/關閉或重新啟動電腦，或是從睡眠模式中喚醒電腦前，請斷開相機與電腦的連接。

– 不保證能夠用自行組裝的電腦或改裝的電腦進行充電。

充電時間

使用電源適配器（附件）的充電時間大約為210分鐘。

注意事項

• 以上充電時間適用於在25°C溫度下對用盡的電池組充電。視使用情況和環境而定，充電可能需要更長的時間。

電池壽命與可以記錄和觀看的靜止影像數目

電池壽命影像數目

拍攝（靜止影像）大約110分鐘大約220個影像觀看（靜止影像）大約160分鐘大約3200個影像拍攝（動態影像）大約55分鐘

注意事項

• 以上靜止影像數目適用於充滿電的電池組。視使用情況而定，靜止影像數目

可能減少。

• 可記錄的靜止影像數目是在以下條件拍攝：

– 使用Sony “Memory Stick PRO Duo” (Mark2) （另售） – 在25°C環境溫度下使用電池組。 – [GPS設定]：[關] （僅DSC-TX100V）

• “拍攝（靜止影像）”數目是根據CIPA標準，在以下條件拍攝：

(CIPA: Camera & Imaging Products Association)

– [面板亮度]設定為[3]。 – 每30秒鐘拍一張。 – 變焦在W與T端交替切換。 – 每拍攝兩次閃光燈閃光一次。 – 電源每拍攝十次開啟關閉一次。

• 動態影像的電池壽命適用於在以下條件拍攝：

– 動態影像品質：AVCHD HQ – 因為設定限制而結束連續拍攝時（第19頁），再觸碰一次（動態影像

按鈕）並繼續拍攝。沒有操作變焦等拍攝功能。

—

供電

用USB多功能端子線（附件）連接電源適配器，可以從牆上電源插座為相機供電。用USB多功能端子線將相機連接到電腦時，可以將影像匯入電腦，不需擔心電池電力用盡。

注意事項

• 電池組未裝入相機時，無法供電。

• 只有當相機處於播放模式，或是在相機和電腦之間建立連接時，才能從牆上

電源插座供電。如果相機處於拍攝模式，或者您變更相機設定時，即使使用 USB多功能端子線建立USB連接，也不會供電。

• 當相機處於播放模式時，如果您使用 USB 多功能端子線連接相機和電腦，相機螢幕也會從播放畫面變更為USB連接畫面。按（播放）按鈕切換到播放畫面。

插入記憶卡（另售）

確定斜角插入方向正確。

打開電池蓋。

插入記憶卡（另售）。

• 按照圖示的斜角方向插入記憶卡，直到其發出喀嗒聲。

關閉電池蓋。

• 在未正確插入電池的情況下關閉電池蓋可能會損壞相機。

您可以使用的記憶卡

記憶卡靜止影像動態影像

Memory Stick PRO Duo

Memory Stick PRO-HG Duo Memory Stick Duo SD記憶卡

SDHC記憶卡 SDXC記憶卡

• 在本手冊中，A中的產品泛稱為 “Memory Stick Duo”，B中的產品泛稱為SD

卡。

取出記憶卡/電池組

a —

a （僅Mark2）

a （等級4以上） a （等級4以上） a （等級4以上）

記憶卡：推入記憶卡一次。電池組：滑動電池彈出控制桿。小心不要讓電池組掉落。

注意事項

• 當存取指示燈（第5頁）亮起時，切勿取出記憶卡/電池組。這樣可能會損壞

記憶卡/內部記憶體內的資料。

設定時鐘

ON/OFF（電源）按鈕

降下鏡頭蓋。

相機電源開啟。只有當相機啟動時，電源指示燈才會亮起。

• 按下ON/OFF （電源）按鈕，也可以開啟相機電源。

• 可能需要一些時間，才能開啟電源並進行操作。

選擇想要的語言。

按照畫面上的指示選擇想要的地區，然後觸碰[下頁]。

設定[夏令時間]、[日期時間格式]和[日期時間]，然後觸

碰[下頁]。

• 午夜顯示為12:00 AM，中午顯示為12:00 PM。

觸碰[OK]。

按照畫面上的指示選擇想要的顯示色彩和[GPS設定]

(DSC-TX100V)，然後觸碰[OK]。

• 如果將[GPS設定]設定為[開]，電池組將很快耗盡。 (僅DSC-TX100V）

螢幕上出現[相機指南]介紹訊息時，觸碰[OK]。

鏡頭蓋

拍攝靜止影像/動態影像

快門按鈕

動態影像按鈕

拍攝靜止影像

將快門按鈕按下一半以對焦。

當影像清晰對焦時，發出嗶音，且z指示亮起。

完全按下快門按鈕。

拍攝動態影像

觸碰（動態影像按鈕）開始記錄。

• 用W/T （變焦）控制桿變更變焦比例。

觸碰（動態影像按鈕）停止記錄。

注意事項

• 溫度約25°C時，根據相機預設設定，一次可以連續拍攝大約29分鐘。完成動態影像錄製時，您可以再觸碰一次（動態影像按鈕）以重新開始錄製。視環境溫度而定，可能會停止記錄，以保護相機。

觀看影像

（播放）

按（播放）按鈕。

• 在本相機上播放使用其他相機記錄的記憶卡上的影像時，出現資料檔案的登記畫面。

選擇下一個/上一個影像

觸碰螢幕上的（下一個）/ （上一個）。

• 若要播放動態影像，觸碰螢幕中央的（播放）。

• 若要放大，觸碰播放中的影像。

刪除影像

1 觸碰（刪除） t [這個影像]。

返回拍攝影像

觸碰。

• 將快門按鈕按下一半也可以回到拍攝模式。

相機指南

本相機包含內部功能指南。您可以根據您的需求搜尋相機功能。

觸碰（相機指南）。

• 觀看時螢幕右下角會出現標記。

從[相機指南]選擇搜尋方法。

拍攝/播放指南：搜尋拍攝/觀看模式中的各種操作功能。圖示指南：搜尋所顯示圖示的功能與意義。疑難解答：搜尋常見問題與解決方法。主體指南：根據您的需求搜尋功能。關鍵字：按關鍵字搜尋功能。歷史：顯示在[相機指南]中最後顯示的10個項目。

其他功能簡介

觸碰螢幕上的MENU，可以操作拍攝或播放時使用的其他功能。本相機配備可以輕鬆選擇功能的功能指南。顯示指南時，嘗試其他功能。

功能表項目

拍攝

動態影像拍攝場景選擇動態影像錄製模式。

簡單模式使用最少功能拍攝靜止影像。

動態影像按鈕從所有拍攝模式快速拍攝動態影像。

閃光燈設定閃光燈設定。

自拍定時器設定自拍定時器設定。

散焦效果在背景散焦模式中拍攝時，設定背景散焦效果等級。

靜態影像尺寸/全景影像大小/動態影像尺寸/動畫品質

連拍設定設定連拍設定。

超近拍攝為小的被攝體拍攝美麗的特寫影像。

EV 手動調整曝光。

ISO 調整感光度。

白平衡調整影像色調。

對焦選擇對焦方法。

測光模式

場景辨識設定自動偵測拍攝條件。

柔膚效果設定柔膚效果和效果等級。

選擇靜止影像、全景影像或動態影像檔案的影像尺寸和品質。

選擇設定要根據被攝體的哪個部分決定曝光值的測光模式。

微笑快門設定在偵測到微笑時自動放開快門。

微笑靈敏度設定偵測微笑的微笑快門功能靈敏度。

面孔偵測選擇此項可自動偵測面孔並調整各種設定。

閉眼減弱功能

定位資訊

相機指南根據您的需求搜尋相機功能。

僅DSC-TX100V

設定為自動拍攝兩張影像，然後選擇沒有閉眼的影像。

檢查三角定位狀態。

觀看

簡單模式增加畫面上的文字大小，方便操作。

日期選擇依日期選擇要觀看的影像。

日曆在日曆上選擇要播放的日期。

影像索引同時顯示多個影像。

循環播放選擇連續播放方法。

刪除刪除影像。

以TransferJet傳送

繪製在靜止影像上繪畫，並將其另存為新的檔案。

修飾使用各種效果修整影像。

3D檢視設定在3D電視機上播放以3D模式拍攝的影像。

觀看模式選擇影像的顯示格式。

顯示連拍群組

保護保護影像。

列印(DPOF) 在靜止影像中加上列印指令標記。

轉動向左或向右轉動靜止影像。

音量調節音量。

曝光資料

索引中的影像數目設定在索引畫面中顯示的影像數目。

將配備 TransferJet 的兩個產品靠近對準，可以傳送資料。

選擇此項可以在播放時顯示群組中的連拍影像或顯示所有影像。

設定是否顯示螢幕目前顯示的檔案的拍攝資料（Exif 資料）。

相機指南根據您的需求搜尋相機功能。

設定項目

如果在拍攝或播放時觸碰MENU，（設定）會提供為最終選擇。您可以變更（設定）畫面上的預設設定。

拍攝設定

動態影像格式 /AF 照明器 / 格線 / 數位變焦 / 減少風噪音/場景辨識指引/紅眼減弱/眨眼警告/寫入日期

嗶音 / 面板亮度 /Language Setting/ 顯示顏色 / 演示

主要設定

模式/初始化 /HDMI 解析度 /HDMI 控制 /USB 連接設定 / USB電源供給/LUN設定/下載音樂/清空音樂/

GPS設定

/GPS輔助資料*1/TransferJet/Eye-Fi/

省電

記憶卡工具

時鐘設定

僅DSC-TX100V

如果沒有插入記憶卡，會顯示（內建記憶體工具），且只能選擇

格式化/建立記錄資料夾/ 改變記錄資料夾/ 刪除記錄

資料夾/複製/檔案序號

區域設定/日期時間設定/ 自動調整時鐘

地區

/自動調整

[格式化]。

靜止影像的張數與動態影像的可記錄時間

靜止影像數目和可記錄時間可能視拍攝條件和記憶卡而異。

靜止影像

（單位：影像張數）

容量

尺寸

16M 3 335 VGA 98 9600 16:9(12M) 3 355

動態影像

下表顯示大約的最大記錄時間。這些是所有動態影像檔案的總時間。可以連續拍攝約29分鐘。MP4格式動態影像檔案的最大尺寸約2 GB。

容量

尺寸

AVC HD 28M (PS)

AVC HD 9M (HQ)

MP4 12M MP4 3M

()中的數字表示最短的可錄製時間。

• 因為相機配備的 VBR （可變式位元率）根據拍攝場景自動調整影像品質，所以動態影像可以記錄的時間會不同。記錄一個快速移動的物體時，影像較清晰，但可錄製時間較短，因為進行錄製需要更大的記憶體。可錄製時間也會因拍攝條件、主體或影像品質/尺寸設定而異。

內部記憶體記憶卡

大約19 MB 2 GB

（h （小時），m （分鐘））

內部記憶體記憶卡

大約19 MB 2 GB

—

9 m

(9 m)

25 m

(15 m)

20 m

1 h 10 m

使用本相機的注意事項

本相機內建的功能

• 本手冊說明GPS相容/不相容裝置、TransferJet相容/不相容裝置、1080 60p 相容裝置和1080 50p相容裝置的功能。若要確定相機是否支援GPS功能，請檢查相機的型號名稱。 GPS相容：DSC-TX100V GPS不相容：DSC-TX100 若要檢查相機是否支援 TransferJet 功能，以及是否為 1080 60i 相容裝置或 1080 50i相容裝置，請查看相機底部的以下標誌。 TransferJet相容裝置： (TransferJet) 1080 60i相容裝置：60i 1080 50i相容裝置：50i

• 本相機與1080 60p動態影像相容。逐行模式比標準隔行錄製模式解析度高，從而使影像更順暢更真實。

• 如果搭乘飛機，務必遵照機上廣播關閉相機。

• 不要在3D相容監視器上長時間觀看以本相機拍攝的3D影像。

• 在3D相容監視器上觀看以本相機拍攝的3D影像時，可能會有眼睛疲勞、倦怠

或噁心之類的不適感。為了防止這些症狀，建議您定時休息。不過，您得自行決定休息所需的長度和頻率，因為這些會因人而異。如果您有任何類型的不適，請停止觀看3D影像，直到比較舒服為止，並視需要徵詢醫生意見。另請參考連接本相機或使用於本相機的裝置或軟體所附的使用說明。請注意，孩子的視力還在發育階段（尤其是6歲以下的小孩）。讓小孩觀看3D影像之前，請徵詢小兒科醫生或眼科醫生的意見，並確認孩子在觀看這種影像時有遵守上述注意事項。

關於GPS相容裝置（僅DSC-TX100V）

• 請根據您所在國家和地區的規定使用GPS。

• 如果不要記錄方向或位置資訊，將[GPS設定]設定為[關]。

關於使用和保養

避免粗暴操作、拆卸、改裝、自然撞擊或擊打，如敲擊、跌落或踩踏在產品上。應特別當心鏡頭。

關於記錄/播放的注意事項

• 開始記錄之前，要進行試拍，以確定相機能正確運作。

• 本相機既不防塵也不防濺、不防水。

• 避免將相機暴露在水中。如果有水進入相機內部，可能會發生故障。在某些

情況下，無法修復相機。

• 請勿使相機朝向太陽或其他強光。否則可能會造成相機故障。

• 如果有濕氣凝結，請在使用相機之前將其清除。

• 請勿搖晃或撞擊本相機。否則可能會引起故障，無法記錄影像。此外，記錄

媒體可能會無法使用，影像資料也可能會損壞。

請勿在下列地方使用/存放相機

• 在非常寒冷、炎熱或潮濕的地方

例如，停放在太陽下的車廂中，相機機身可能變形而造成故障。

• 陽光直射或者靠近發熱器的地方

相機機身可能會褪色或變形，而這可能會造成故障。

• 在會受到搖擺振動的地方

• 靠近會產生強烈無線電波、放射輻射線或強烈磁場的地方。否則，相機可能

無法正常記錄或播放影像。

• 在多沙或多塵的地方

小心不要讓沙子或灰塵進入相機中。這樣可能會造成相機故障，有時候這種故障是無法修理的。

關於攜帶

將相機放置於褲子或裙子背後口袋時，請勿坐在椅子上或其他地方，因為這樣可能會造成故障或損壞相機。

Carl Zeiss鏡頭

本相機配備Carl Zeiss鏡頭，這個鏡頭能拍攝出對比度極佳的清晰影像。本相機的鏡頭是根據德國 Carl Zeiss 的品質標準，由經過Carl Zeiss 認證的品質保證系統製作而成。

關於螢幕和鏡頭的注意事項

• 螢幕是採用超高精密技術製造的，其有效像素高達99.99%以上。然而，螢幕

上可能會出現一些微小的黑點和/或亮點（白、紅、藍或綠）。這些點乃製造過程的正常結果，並不會影響記錄。

• 戴手套時，觸控面板反應較不靈敏。

• 如果長時間在螢幕上持續或反覆顯示同一影像，影像可能會永遠燒入螢幕。

為防止影像燒入螢幕，請避免長時間顯示同一影像。

關於相機的溫度

您的相機和電池可能因為持續使用而變熱，但是這並不是故障。

關於過熱保護

視相機和電池溫度而定，您可能無法記錄動態影像，或是電源可能會自動關閉，以保護相機。在電源關閉或無法繼續記錄動態影像前，螢幕上會顯示訊息。在此情況下，保持電源關閉，並等待相機和電池溫度下降。如果您在相機和電池冷卻前打開電源，電源可能會再次關閉，或者您可能無法記錄動態影像。

關於電池的充電

如果您對長時間未使用的電池充電，可能無法將其充電到適當的容量。這是由於電池特性，不是故障。再次為電池充電。

版權警告

電視節目、影片、錄影帶及其他資料可能具有版權。未經許可記錄這些資料可能會違反版權法規定。

內容損壞或記錄失敗均不在賠償範圍內

對於因相機或記錄媒體故障等原因導致記錄失敗或記錄內容遺失或損壞， Sony概不賠償。

清潔相機表面

用沾了一點水的軟布清潔相機表面，然後以乾布擦拭表面。若要預防表層或外殼損壞： – 請勿將相機暴露在化學產品下，如稀釋劑、汽油、酒精、用過即丟的布、驅

蟲劑、防曬油或殺蟲劑等。

規格

相機

[系統]

影像裝置：7.77 mm （1/2.3型）

Exmor R CMOS感應器

相機的總像素數：

大約1680萬像素

相機的有效像素數：

大約1620萬像素

鏡頭：Carl Zeiss Vario-Tessar4倍

變焦鏡頭

f = 4.43 mm – 17.7 mm （25 mm – 100 mm （相當於35 mm底片））

F3.5 (W) – F4.6 (T)

拍攝動態影像時(16:9)：

27 mm – 108 mm

拍攝動態影像時(4:3)：

33 mm – 132 mm

SteadyShot：光學曝光控制：自動曝光、場景選擇

（15模式）

白平衡：自動、日光、多雲、螢光

1/2/3、白熾燈、閃光燈、單按

訊號格式：

1080 50i：PAL彩色，CCIR標準

HDTV 1080/50i規格，1080/50p

規格

1080 60i：NTSC彩色，EIA標準

HDTV 1080/60i規格，1080/60p

規格

檔案格式：

靜止影像：JPEG（DCF Ver.2.0，

Exif Ver. 2.3，MPF基本）相

容，DPOF相容

3D靜止影像：MPO（MPF Extended （視差影像））相容

動態影像（AVCHD 觀看）：AVCHD

格式Ver.2.0相容

視訊：MPEG-4 AVC/H.264

音訊：Dolby Digital 2ch，配備

Dolby Digital Stereo Creator

• 由Dolby Laboratories授權製

造。動態影像（MP4觀看）： MP4格式視訊：MPEG-4 AVC/H.264 音訊：MPEG-4 AAC-LC 2ch

記錄媒體：內部記憶體（大約

19 MB），“Memory Stick Duo”， SD卡

閃光燈：閃光範圍（ISO感光度（建

議曝光指數）設定為自動）：大約0.08 m至5.1 m (W) 大約0.5 m至4.0 m (T)

[輸入與輸出接頭]

HDMI接頭：HDMI迷你插孔多功能接頭：Type3b

（AV輸出/USB/DC輸入）：

視頻輸出音頻輸出（立體聲） USB通訊

USB通訊：Hi-Speed USB (USB 2.0)

[螢幕]

OLED:

寬螢幕(16:9)，8.8cm （3.5型）

總點數：

相當於1 229 760點

[電源，一般]

電源：充電電池組NP-BN1，3.6 V

電源適配器AC-UB10/UB10B，5 V

功率消耗（拍攝時）：1.0 W 操作溫度：0 °C至40 °C 存放溫度：–20 °C至+60 °C 尺寸（CIPA相容）：

97.0 mm × 58.5 mm × 17.8 mm

（寬/高/深）

質量（CIPA相容）（包括NP-BN1電池

組、“Memory Stick Duo”）：

大約147 g 麥克風：立體聲揚聲器：單聲道 Exif Print：相容 PRINT Image Matching III：相容

電源適配器AC-UB10/UB10B

電源要求：AC 100 V至240 V，50 Hz/

60 Hz，70 mA 輸出電壓：DC 5 V，0.5 A 操作溫度：0 °C至40 °C 存放溫度：–20 °C至+60 °C 尺寸：

大約50 mm × 22 mm × 54 mm

（寬/高/深）

質量：

在美國和加拿大：大約48 g

在美國和加拿大以外的國家或地

區：大約43 g

充電電池組NP-BN1

使用的電池：鋰離子電池最大電壓：DC 4.2 V 額定電壓：DC 3.6 V 最大充電電壓：DC 4.2 V 最大充電電流：0.9 A 容量：

典型：2.3 Wh (630 mAh)

最少：2.2 Wh (600 mAh)

設計及規格如有變更，恕不另行通知。

商標

• 以下標誌為Sony Corporation的商標。

, “Cyber-shot”, “Memory Stick PRO Duo”, “Memory Stick PRO-HG Duo”, “Memory Stick Duo”

• Windows是Microsoft Corporation 在美國和/或其他國家的註冊商標。

• Macintosh是Apple Inc.的註冊商標。

• SDXC標誌是SD-3C, LLC的商標。

• “ ”和 “PlayStation”為Sony

Computer Entertainment Inc.的註冊商標。

• 此外，本說明書中使用的系統和產品名稱通常是各自開發商或製造商的商標或註冊商標。但是，本說明書未在各處皆使用™或®標誌。

• 從PlayStation®Store （如果有的話）下載PlayStation®3專用的應用程式，可以為PlayStation®3增加更多娛樂功能。

• 若要使用PlayStation®3專用的應用程式，必須先下載 PlayStation®Network應用程式並且擁有帳號。在有 PlayStation®Store的地區可以取得。

在我們的客戶支援網站可以查到本產品新增的資訊和常見問題的答案

使用基於不含有 VOC （揮發性有機成分）的植物油的油墨在 70％以上再生紙上印刷。

Sony DSC-TX100V Users guide [zh, en]

Specifications and Main Features

Frequently Asked Questions

User Manual

English

Refer to “Cyber-shot User Guide” (HTML) on supplied CD-ROM

Checking the supplied items

Identifying parts

Inserting the battery pack

Charging the battery pack

Inserting a memory card (sold separately)

Setting the clock

Shooting still images/movies

Viewing images

In-Camera Guide

Introduction of other functions

Number of still images and recordable time of movies

Notes on using the camera

Specifications

中文（繁體字）

請參閱附件CD-ROM上的 “Cyber-shot使用者指南” (HTML)

檢查隨機項目

認識各部件

插入電池組

對電池組充電

插入記憶卡（另售）

設定時鐘

拍攝靜止影像/動態影像

觀看影像

相機指南

其他功能簡介

靜止影像的張數與動態影像的可記錄時間

使用本相機的注意事項

Sony DSC-TX100V Users guide [zh, en]

Specifications and Main Features

Frequently Asked Questions

User Manual

English

Refer to “Cyber-shot User Guide” (HTML) on supplied CD-ROM

Checking the supplied items

Identifying parts

Inserting the battery pack

Charging the battery pack

Inserting a memory card (sold separately)

Setting the clock

Shooting still images/movies

Viewing images

In-Camera Guide

Introduction of other functions

Number of still images and recordable time of movies

Notes on using the camera

Specifications

中文 （繁體字）

請參閱附件CD-ROM上的 “Cyber-shot使用者指南” (HTML)

檢查隨機項目

認識各部件

插入電池組

對電池組充電

插入記憶卡 （另售）

設定時鐘

拍攝靜止影像/動態影像

觀看影像

相機指南

其他功能簡介

靜止影像的張數與動態影像的可記錄時間

使用本相機的注意事項

中文（繁體字）

插入記憶卡（另售）
