SONY DSC-F77, DSC-FX77 SERVICE MANUAL L2 V1.2

DSC-F77/FX77

SERVICE MANUAL

Ver 1.2 2003. 02

Revision History

Photo: DSC-FX77

Link

SPECIFICATIONS

BLOCK DIAGRAMS

LEVEL 2

AEP Model

UK Model

E Model

Hong Kong Model

Australian Model

Japanese Model

DSC-F77/FX77

Chinese Model

Tourist Model

DSC-F77

PRINTED WIRING BOARDS

SERVICE NOTE

DISASSEMBLY

•For ADJUSTMENTS (SECTION 6), refer to SERVICE MANUAL, ADJ (992999751.pdf).

•For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (992999741.pdf).

• Reference No. search on printed wiring boards is available.

•To repair DSC-FX77, make sure to follow the items of “DISASSEMBLING THE HINGE COVER AT REPAIRING (DSC-FX77)”.

On the SY-81 and BT-14 (FX77) boards

This service manual provides the information that is premised the circuit board replacement service and not intended repair inside the SY-81and BT-14 (FX77) boards. Therefore, schematic diagram, printed wiring board, waveforms, mounted parts location and electrical parts list of the SY-81 and

BT-14 (FX77)

The following pages are not shown.

Schematic diagram ......................Pages 4-9 to 4-36

Printed wiring board.....................Pages 4-47 to 4-52

Waveforms ....................................

boards are not shown.

Pages 4-58 and 4-59

FRAME SCHEMATIC DIAGRAMS

SCHEMATIC DIAGRAMS

Mounted parts location .................

Electrical parts list........................ Pages 5-10, 5-12 to 5-18

REPAIR PARTS LIST

Pages 4-61 and 4-62

DIGITAL STILL CAMERA

DSC-F77/FX77

COVER

SPECIFICATIONS

System

Image device 8.98 mm (1/1.8 type) color

Total pixels number of camera Effective pixels number of camera Lens f=7.65 mm

Exposure control

White balance

File format (DCF compliant)

Recording media Flash Recommended distance

Input/output connectors

Multi connector

LCD screen

LCD panel used Total number of dots

Power, general

Used battery pack Power requirements Power consumption (when shooting)

CCD Primary color filter

Approx. 4 130 000 pixels Approx. 3 950 000 pixels (35 mm camera conversion: 37mm

15

(1

/32 inches))

F2.8 Automatic,

Scene selection (four modes) Automatic, Daylight, Cloudy,

Fluorescent, Incandescent Still images: Exif Ver. 2.2, JPEG

compliant, GIF (for Clip Motion), DPOF compatible Audio with still image: MPEG1 compliant (Monaural) Movies: MPEG1 compliant (Monaural)

“Memory Stick”

0.5 to 1.7 m (1 feet 7

5 feet 7 inches) (when ISO sensitivity is set to Auto)

3.8 cm (1.5 type) TFT drive

123 200 (560×220) dots

NP-FC10

3.6 V

1.9 W

3

/4 inches to

Operating temperature range Storage temperature range Dimensions DSC-F77:

Mass DSC-F77: Approx. 180 g (6.3 oz)

Microphone Electret condenser microphone Speaker Dynamic speaker

Bluetooth function (DSC-FX77)

Communication type Maximum transmission speed Output Bluetooth standards, Power Class 2

Communication distance Compatible Bluetooth profile

Frequency band

1) Maximum data transmission speed based on Bluetooth standards, ver. 1.1. This speed depends on the distance between the devices, obstacles, radio wave conditions, application software, or the OS.

2) This distance depends on the obstacles between the devices, radio wave conditions, application software, or the OS.

3) This specification is in accordance with the intended use between two Bluetooth devices. This is defined by the Bluetooth standards.

UC-FA USB cradle

Input/output connectors

A/V OUT (MONO) jack (Monaural)

0º to +40ºC (32º to +104ºF) –20º to +60ºC (–4º to +140ºF)

92.6 × 71 × 27 mm

3

(3

/4 × 2 7/8 × 1 1/8 inches)

DSC-FX77:

98.1 × 71 × 27 mm

7

(3

/8 × 2 7/8 × 1 1/8 inches)

(W/H/D, protruding portions not included) DSC-FX77: Approx. 185 g (6.5 oz)

(NP-FC10 battery pack, “Memory Stick” and wrist strap included)

Bluetooth standards, ver. 1.1 About 723 Kbps

About 10 m (3.3 feet) without obstacles Basic Imaging Profile (Image Push Initiator,

Image Push Responder, Remote Camera Responder)

2.4 GHz (2.400 to 2.4835 GHz)

Minijack Video: 1 Vp-p, 75 Ω, unbalanced,

1)

2)

3)

sync negative Audio: 327 mV (at a 47 kΩ load)

USB jack mini-B DC IN connector Camera connector

AC-LM5 AC power adaptor

Power requirements Rated output voltage Operating temperature range Storage temperature range Dimensions 47 × 30 × 80 mm (1 Mass Approx. 170 g (6.0 oz)

NP-FC10 battery pack

Used battery Lithium ion battery Maximum voltage

Nominal voltage Capacity 2.4 Wh (675 mAh)

Accessories

• NP-FC10 battery pack (1)

•AC-LM5 AC power adaptor (1)

• UC-FA USB cradle

• USB cable (1)

• A/V connecting cable (1)

•Power cord (mains lead) (1)

• Wrist strap (1)

• “Memory Stick” (16MB) (1)

• CD-ROM (USB driver: SPVD-008) (1)

• Operating Instructions (1) DSC-FX77:

• Bluetooth Function Operating Instructions (1) Design and specifications are subject to change

without notice.

Output impedance 2.2 kΩ

AC 100 to 240 V, 50/60 Hz DC 4.2 V, 1.5 A 0º to +40ºC (32º to +104ºF) –20º to +60ºC (–4º to +140ºF) (W/H/D, protruding parts not included) (adaptor only)

DC 4.2 V DC 3.6 V

7

/8 × 1 3/16 × 3 1/4 inches)

— 2 —

DSC-F77/FX77

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY .

SAFETY CHECK-OUT

After correcting the original service problem, perform the following safety checks before releasing the set to the customer.

1. Check the area of your repair for unsoldered or poorly-soldered connections. Check the entire board surface for solder splashes and bridges.

2. Check the interboard wiring to ensure that no wires are "pinched" or contact high-wattage resistors.

3. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement.

4. Look for parts which, through functioning, show obvious signs of deterioration. Point them out to the customer and recommend their replacement.

5. Check the B+ voltage to see it is at the values specified.

6. Flexible Circuit Board Repairing

•Keep the temperature of the soldering iron around 270˚C during repairing.

• Do not touch the soldering iron on the same conductor of the circuit board (within 3 times).

• Be careful not to apply force on the conductor when soldering or unsoldering.

Unleaded solder

Boards requiring use of unleaded solder are printed with the leadfree mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.)

: LEAD FREE MARK

Unleaded solder has the following characteristics.

• Unleaded solder melts at a temperature about 40°C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350°C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful!

• Strong viscosity Unleaded solder is more viscous (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc.

• Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder.

— 3 —

DSC-F77/FX77

Charging Capacitor (C104) ·············································1-1 1-2-1.Preparing the Short Jig ····················································1-1 1-2-2.Discharging the Capacitor ···············································1-1 1-3. Description on Self-diagnosis Display ····························1-2 1-4. Disassembling the Hing Cover at Repairing

(DSC-FX77) ····································································1-3

2. DISASSEMBLY

2-1. Hinge Cover (DSC-F77)··················································2-2 2-2. Hinge Cover, BT-14 Board (DSC-FX77)························2-2 2-3. Cabinet (Front) ································································2-3 2-4. Inner Cabinet (Front)·······················································2-4 2-5. Lens Block Assembly······················································2-4 2-6. Cabinet (Rear) Block·······················································2-5 2-7. Cabinet (Bottom) Assembly ···········································2-6 2-8. Control Switch Block ······················································2-6 2-9. Inner Cabinet (Rear), KK-29 Board ································2-7 2-10. LCD Module ····································································2-7 2-11. SY-81 Board ····································································2-8 2-12. Lens Block ······································································· 2-9 2-13. CD-415 Board, Optical Filter Block ·······························2-9 2-14. ST-78 Board···································································2-10 2-15. FP-585 Flexible Board Block ········································2-12 2-16. Circuit Boards Location ················································2-13 2-17. Flexible Boards Location ··············································2-14

Section Title Page

5-1-6. BT Block Assembly-1···················································5-7 5-1-7. BT Block Assembly-2···················································5-8 5-2. Electrical Parts List ·······················································5-9

3. BLOCK DIAGRAMS

3-1. Overall Block Diagram (1/2)···········································3-1 3-2 Overall Block Diagram (2/2) ··········································· 3-3 3-3. Power Block Diagram (1/2)·············································3-5 3-4. Power Block Diagram (2/2)·············································3-7

4. PRINTED WIRING BOARDS AND

SCHEMATIC DIAGRAMS

4-1. Frame Schematic Diagram ··············································4-1 4-2. Schematic Diagrams························································4-5

CD-415 (CCD IMAGER)················································4-7

ST-78 (FLASH DRIVE) ················································ 4-37

KK-29 (LENS POSITION) ···········································4-39

CONTROL SWITCH BLOCK (MD51200) ·················4-40

FP-585 FLEXIBLE ·······················································4-41

FP-586 FLEXIBLE ·······················································4-42 4-3. Printed Wiring Boards ···················································4-43

CD-415 ··········································································4-45

ST-78 ·············································································4-53

KK-29 ············································································4-55

FP-586 FLEXIBLE ·······················································4-56 4-4. Waveforms·····································································4-57 4-5. Mounted Parts Location ················································4-60

5. REPAIR PARTS LIST

5-1. Exploded V iews ····························································5-2 5-1-1. Overall Assembly (F77) ················································5-2 5-1-2. Overall Assembly (FX77) ·············································5-3 5-1-3. Cabinet (Upper) Block Assembly ·································5-4 5-1-4. Lens Cabinet Assembly ················································5-5 5-1-5. Cabinet (Rear) Block Assembly ···································5-6

— 4 —

DSC-F77/FX77

When installing a connector, don’t press down at wire of connector. It is possible that a wire is snapped.

COVER

SECTION 1

SERVICE NOTE

1-1. NOTE FOR REPAIR

Make sure that the flat cable and flexible board are not cracked of bent at the terminal. Do not insert the cable insufficiently nor crookedly.

Cut and remove the part of gilt which comes off at the point. (Be careful or some pieces of gilt may be left inside)

When remove a connector, don’t pull at wire of connector. It is possible that a wire is snapped.

1-2. DISCHARGING OF THE ST-78 BOARD’S CHARGING CAPACITOR (C104)

The charging capacitor (C104) of the ST-78 board is charged up to the maximum 300 V potential. There is a danger of electric shock by this high voltage when the battery is handled by hand. The electric shock is caused by the charged voltage which is kept without discharging when the main power of the unit is simply turned off. Therefore, the remaining voltage must be discharged as described below.

1-2-1. Preparing the Short Jig

To preparing the short jig, a small clip is attached to each end of a resistor of 1 kΩ /1 W (1-215-869-11). Wrap insulating tape fully around the leads of the resistor to prevent electrical shock.

1 kΩ/1 W

Wrap insulating tape.

1-2-2. Discharging the Capacitor

Short-circuit between the positive and the negati v e terminals of the changed capacitor with the short jig about 10 seconds.

R:1 kΩ/1 W (Part code: 1-215-869-11)

Capacitor

1-1

DSC-F77/FX77

1-3. DESCRIPTION ON SELF-DIAGNOSIS-DISPLAY

Self-diagnosis display

• C: ss: ss You can reverse the camera malfunction yourself. (However, contact your Sony dealer or local authorized Sony service facility when you cannot recover from the camera malfunction.)

• E: ss: ss Contact your Sony dealer or local authorized Sony service facility.

Display Code

C:32:ss

C:13:ss

E:61:ss

E:91:ss

E:92:ss

Countermeasure

Turn the power off and on again.

Format the “Memory stick”. Insert a new “Memory Stick”.

Checking of lens drive circuit.

Checking of flash unit or replacement of flash unit.

Insert a battery pack correctly. Battery pack is not inserted correctly.

Turn the power off and on again.

Trouble with hardware.

Unformatted memory stick is inserted. Memory stick is broken.

When failed in the focus and zoom initialization.

Abnormality when flash is being charged.

Battery pack was installed or removed when using the AC adaptor.

Cause

Caution Display During Error

SYSTEM ERROR

FORMAT ERROR MEMORY STICK ERROR

—

1-2

1-4. DISASSEMBLING THE HINGE COVER AT REPAIRING (DSC-FX77)

Hinge cover

When two SPECIAL BIT (P2 MAIN) M1.7 are removed or installed, use ANT DRIVER (D5LUOX113A).

ANT DRIVER (J-2507-052-1)

Two BIT screws (DSC-FX77)

Note: Be sure to use SPECIAL BIT (P2 MAIN) M1.7

(3-079-777-010) at service.

DSC-F77/FX77

1-3

1-3E

DSC-F77/FX77

2-3. CABINET (FRONT)

(Page 2-3)

2-1. HINGE COVER

(DSC-F77) (Page 2-2)

2-13. CD-415 BOARD,

OPTICAL FILTER BLOCK (Page 2-9)

2-2. HINGE COVER,

BT-14 BOARD (DSC-FX77) (Page 2-2)

2-6. CABINET (REAR) BLOCK

(Page 2-5)

2-12. LENS BLOCK (Page 2-9)

2-5. LENS BLOCK ASSEMBLY

(Page 2-4)

2-4. INNER CABINET (FRONT)

(Page 2-4)

2-14. ST-78 BOARD

(Page 2-10)

2-15. FP-585 BOARD

(Page 2-12)

DSC-F77/FX77

2-10. LCD MODULE

(Page 2-7)

2-11. SY-81 BOARD

(Page 2-8)

2-9. INNER CABINET (REAR),

KK-29 BOARD (Page 2-7)

2-7. CABINET (BOTTOM)

ASSEMBLY (Page 2-6)

2-8. CONTROL SWITCH

BLOCK (Page 2-6)

SERVICE POSITION : LCD (Page 2-5)

SERVICE POSITION : LENS BLOCK (Page 2-10)

SERVICE POSITION : SY-81 BOARD SIDE A (Page 2-11)

SERVICE POSITION : SY-81 BOARD SIDE B (Page 2-11)

COVER

• This following flow shows the disassembly procedure.

SECTION 2

DISASSEMBLY

2-1

DSC-F77/FX77

Note: Follow the disassembly procedure in the numerical order given.

2-1. HINGE COVER (DSC-F77)

2 Remove the hinge cover (BLT) assembly

in the direction of arrow A, and releace four claws.

3 Hinge cover

A

2-2. HINGE COVER, BT-14 BOARD (DSC-FX77)

5 FP-588 flexible board

(CN1001)

9 BLT frame

7 BT-14 board

8 Screw

(M1.7)

4 BLT sheet

6 Two screws (M1.7)

1 Two screws

(M1.7)

3 Hinge cover (BLT)

assembly

When two SPECIAL BIT (P2 MAIN) M1.7 are removed or installed, use ANT DRIVER

A

(D5LUOX113A).

2 Remove the hinge cover (BLT) assembly

in the direction of arrow A, and releace four claws.

1 Two special BIT screws

ANT DRIVER (J-2507-052-1)

Note: Be sure to use SPECIAL BIT (P2 MAIN) M1.7

(3-079-777-010) at service.

2-2

2-3. CABINET (FRONT)

-Side view-

1 Screw (M1.7)

Rear

DSC-F77/FX77

4 Open the BT lid

in the direction of arrow A.

-Bottom view-

Rib (inner cabinet (rear))

Front Rear

Claw (cabinet (front))

A

2 Screw

-Side view-

(M1.7)

3 Screw (M1.7)

5 Move the lower part of the

cabinet (front) in the direction of arrow B.

Note: Do not move

that part too far.

B

Claw (cabinet (front))

Hole (inner cabinet (rear))

C

Rib (inner cabinet (rear))

D

6 Pressing the rib (inner cabinet (rear)) in the

direction of arrow C, disengage the claw with holding up the cabinet (front) a little in the direction of arrow D.

Note: Be careful not to perform it by force,

or the cabinet (front) may be distorted.

7 Cabinet (front)

2-3

DSC-F77/FX77

2-4. INNER CABINET (FRONT)

Inner cabinet (rear)

Cabinet (front)

Two claws

2-5. LENS BLOCK ASSEMBLY

9 Remove the lens block assembly

from inner cabinet section in the direction of arrow B.

FP-585 flexible board

6 Screw

(DIA. 1.7 × 4)

2 Inner cabinet

(front)

1 Disengage two claws

of the inner cabinet (front) with sticking a flat head driver or something similar.

B

1 Turn the lens block assembly

in the direction of arrow A.

A

0 Lens block assembly

8 Connector (CN151)

4 Cabinet (upper)

2 Pull the cabinet (upper)

5 Screw

(M1.7)

B

in the direction of arrow B.

7 Connector (CN351)

3 Connector (CN402)

2-4

2-6. CABINET (REAR) BLOCK

DSC-F77/FX77

Note: Be careful not to perform it

by force, or the cabinet (front) may be distorted.

4 Pressing the rib (inner cabinet (rear)) in the

direction of arrow B, disengage the claw with holding up the cabinet (rear) a little in the direction of arrow C.

Claw

A

3 Move the lower part of the cabinet (front)

in the direction of arrow A.

Note: Do not move

that part too far.

2 Screw (M1.7)

Rib (inner cabinet (rear))

B

1 Screw (M1.7)

C

[SERVICE POSITION : LCD]

Setting the "Forced Play ON mode"

1) Select page: 0, address: 01, and set data: 01.

2) Select page: D, address: 21, set data: 08, and then press the PAUSE button of adjustment remote commander.

SY-81 board

LCD module

Exiting the "Forced Power ON mode"

1) Select page: 0, address: 01, and set data: 01.

2) Select page: D, address: 21, set data: 00, and then press the PAUSE button of adjustment remote commander.

3) Select page: 0, address: 01, and set data: 00.

to cradle

AC power adaptor

Adjustment remote commander

DC-IN

Cradle with LANC jack (J-6082-548-A)

2-5

DSC-F77/FX77

2-7. CABINET (BOTTOM) ASSEMBLY

2 Cabinet (bottom) assembly

2-8. CONTROL SWITCH BLOCK

4 Control switch block

2

1 Turn the cabinet (bottom) assembly

inthe direction of arrow, and releace two claws.

3 Flexible board (CN853)

1 Screw

(M1.7)

2-6

2-9. INNER CABINET (REAR), KK-29 BOARD

Inner cabinet (rear) block

3 Two screws

(DIA. 1.7 × 4)

DSC-F77/FX77

2 Flexible board (CN851)

5 KK-29 board

4 Inner cabinet

2-10.LCD MODULE

(rear)

A

4 Flexible board

(CN702)

1 Pressing the lower part of the inner

cabinet (rear) block in the direction of arrow A, disengage the claw with rotating it in the direction of arrow B.

6 LCD module

3

1 Two screws

(M1.7)

2 Claw

5 Flexible board

(CN701)

2-7

DSC-F77/FX77

2-11.SY-81 BOARD

8 Screw (M1.7)

qa Main frame

9 Screw (M1.7)

qs Two screws (M1.7)

4

0 Claw

5 Claw

3 LCD frame

7 Screw (M1.7)

6 Connector holder

2 Screw (M1.7)

1 Screw (M1.7)

qf FP-587 board

(CN601)

qh Claw

qg Two bosses

qj

qk SY-81board

qd FP-586 flexible board

(CN401)

2-8

2-12.LENS BLOCK

2 Screw

(M1.7)

DSC-F77/FX77

4 L cabinet (lower)

assembly

Note: High-voltage cautions

5 Screw (M1.7)

(See page 1-1)

7 L cabinet (upper)

assembly

1 Screw

(M1.7)

8 Lens block

3 Three claws

6 Screw (M1.7)

2-13.CD-415 BOARD, OPTICAL FILTER BLOCK

6 Light intercepttion plate

5 Seal rubber (K)

7 Optical filter block

Note: High-voltage cautions

(See page 1-1)

4 CD-415 board

Optical filter block

-side view-

lens block side: bluish

3 Two screws

(M1.7 × 6)

1 Tape (K)

2 FP-585 flexible board

(CN001)

CCD block side: whitish

2-9

DSC-F77/FX77

2-14.ST-78 BOARD

7 Two claws

8 Hinge block

9 ST-78 board

Note: High-voltage cautions

(See page 1-1)

ST-78 board

3

4 Two claws

1 Screw (M1.7)

[SERVICE POSITION : LENS BLOCK]

Setting the "Forced Camera ON mode"

1) Select page: 0, address: 01, and set data: 01.

2) Select page: D, address: 21, set data: 04, and then press the PAUSE button of adjustment remote commander.

6 Connector

(CN101)

2 Lens block assembly

5 L cabinet assembly (front)

Exiting the "Forced Power ON mode"

1) Select page: 0, address: 01, and set data: 01.

2) Select page: D, address: 21, set data: 00, and then press the PAUSE button of adjustment remote commander.

3) Select page: 0, address: 01, and set data: 00.

Hinge block

ST-78 board

SY-81 board

Cradle with LANC jack (J-6082-548-A)

2-10

to cradle

AC power adaptor

DC-IN

Lens block

Adjustment remote commander

[SERVICE POSITION : SY-81 BOARD SIDE A]

: Contacting surface

Lens block

DSC-F77/FX77

Control switch block

DC-IN

AC power adaptor

Memory stick connector

[SERVICE POSITION : SY-81 BOARD SIDE B]

: Contacting surface

LCD module

SY-81 board

LCD module

ST-78 board

Memory stick connector

DC-IN

SY-81 board

Control switch block

AC power adaptor

Lens block

2-11

DSC-F77/FX77

2-15.FP-585 FLEXIBLE BOARD BLOCK

2 FP-585 flexible board

( CN001)

Lens section

1 Tape (K)

Lens section

6 FP-585 flexible board block

3

4 Remove the FP-585 flexible board block

in the direction of arrow.

[INSTALLATION OF FP-585 FLEXIBLE BOARD]

B to B connector side

: Fold mark

Adhesive tape

Fold

FP-585 flexible board

Lens block side

5 Connector

FP-585 flexible board

Lens block side

B to B connector side

2 FP sheet

8

-

7

1

0

3

-

3

-printed side-

1 Fold the FP-585 flexible board.

Adhesive tape

Lens block side

B to B connector side

Adhesive tape

4 FP holder

Lens block side

2 FP sheet

3 Wind the

FP-585 flexible board.

B to B connector side

2-12

2-16.CIRCUIT BOARDS LOCATION

CD-415

ST-78

KK-29

SY-81

BT-14 (DSC-FX77)

ADLEBoard Name Function

CD-415 CCD IMAGER KK-29 LENS POSITION ST-78 FLASH DRIVE SY-81 A/D CONVERTER, TIMING GENERATOR,

CAMERA DSP, SH DSP, VIDEO, CLOCK GENERATOR, LANS DRIVE, HI CONTROL, AUDIO, LCD DRIVE, FLASH CONTROL, CONTROL SWITCH, DC IN, CRADLE TERMINAL, DC/DC CONVERTER, REGULATOR

BT-14 (DSC-FX77) BLUETOOTH

DSC-F77/FX77

2-13

DSC-F77/FX77

2-17.FLEXIBLE BOARDS LOCATION

FP-585

FP-587

FP-586

FP-588 (DSC-FX77)

2-14

2-14E

COVER

3. BLOCK DIAGRAMS

Link

OVERALL BLOCK DIAGRAM (1/2) POWER BLOCK DIAGRAM (1/2)

DSC-F77/FX77

OVERALL BLOCK DIAGRAM (2/2)

POWER BLOCK DIAGRAM (2/2)

DSC-F77/FX77

COVER

SECTION 3

BLOCK DIAGRAMS

3-1. OVERALL BLOCK DIAGRAM (1/2)

LENS BLOCK

LENS

FOCUS

SENSOR

FOCUS

MOTOR

M

IRIS

(SHUTTER)

IRIS

METER

M

LENS TEMP

SENSOR

ST-78 BOARD

FLASH

UNIT

CD-415 BOARD

IC001

CCD

IMAGER

H

TH001

CCD TEMP

SENSOR

D001

(SELF TIMER/REC)

D002

(AE/AF LOCK)

D003

FLASH/CHG

12 15

13 14

8 9

10

4

ı

7

(SELF TIMER/AF ILLUMINATOR)

CHARGING CAPACITOR

CN001

10 29

12

ı

14 19 20

1 ı 6

D102

T101

FP-585 FLEXIBLE BOARD

2

5

ı

7

13

ı

18

11

23

24

25

FOCUS A, A, B, B

CN101

V1A, V1B, V2,

XAE LOCK LED

XFC RST SENS

3

1 2

8

3. BLOCK DIAGRAMS

( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

SY-81 BOARD (1/2)

42 - 47

55 56 74

5

CLOCK

GENERATOR

46

ı

48

1

ı

11

17 59

23 41 58

54

TG CLK

50

IC603

(4/13)

HALL AMP,

HALL CONTROL

(5/13)

4 16 11

IC803IC801

HR EN0, HR DIR0A, HR DIR0B

XFC RST SENS

CA AD00 - AD13

CA HD1

CA FD1

MCK12

MC CLK1

27MHz

USB 48MHz

HALL AD

IRIS COM

IRIS COM 1, 2

HALL OFFSET, HALL REF, HALL GAIN

XMSHUT ON MSHUT EN

STB ON

CAM SO, XCAM SCK, XCAM RESET

IRIS COM 1, 2

HALL OFFSET, HALL REF, HALL GAIN

PRELAMP AF ON

12 - 14

16

18 - 27

8

9

IC651

CAMERA DSP, 128M SDRAM

96

88

246 196

233

ı

235

192 232

248

CAM SO, XCAM SCK, XCAM RESET

1

15

IC602

EVR

4

(D/A CONV.)

ı

(4/13)

6

2

65 - 69 71 - 81

29 - 41 43 - 54

13 14

10

212 207 204

225 229

94

249

215

276 272

227

CAM SO, XCAM SCK

SP VOL

CCD OUT

RG, H1, H2

V3A, V3B, V4

CCD TEMP

XTALLY LED

XCHAGE LED

HALL+, –

BIAS+, –

DRIVE+, –

LENS TEMP

PRELAMP

ST UNREG

STB FULL

CN001

CN151

50

IC802

FOCUS/IRIS

MOTOR DRIVE

(5/13)

Q363

LED

DRIVE

81 84 85

63 - 65

67 68 70

PRELAMP AF ON SELF TIMER LED

40

42

44

29

31

33

ı

36

39

26

23

24

16

17

15

18

5

11

12

14

5

6

8

10

1

11

CN351

3

1 2

8

7 17 19

(MECHA SHUTTER)

2

4 21 23

Q360, 362

IC151

TIMING

GENERATOR

S/H, AGC, A/D CONV.

(1/13)

X501

27MHz

SHUTTER CONTROL

(5/13)

13 15

14 16

9

ı

12

ACV UNREG

STB CHARGE

XSTB FULL

IC804

PANEL R PANEL G PANEL B

HDO PANEL V

XRST SYS

CAM SO, XCAM SCK

EXT STRB ON

50 23 51

LCD DRIVE

48 67

19 45

20

CV OUT

AU AINL

AOUT L SP VOL

SYS V

MC D00 - D15

MC A01 - A25

XAE LOCK LED

CCD TEMP LENS TEMP

IC701

(8/13)

61

7 8

62

13 32

41 - 43

63 64 72 76

77

15

5

VG P SIG

IRISN COM HALL AD

USB 48MHz 27MHz

Q601

LED

DRIVE

P SIG VG

PANEL 2.9V

BACKLIGHT

5 3

232 235

MC CAM,

SH DSP,

32M FLASH

164

39 41 - 45

47 49 51 52

54 56 - 60

62 - 64 66 68 - 70 72

73 75 76 78 79 81

83 - 88 90

92 93 95 97

199 200 220

8

228

184 187

35

230 229

IC702

DRIVE (8/13)

IC601

(3/13)

Q703, 704

PSIG

DRIVE

WIDE, DWN, EN,

VCK, VST, COM

Q706

238 239

216

213

215

202

204

193

196

185 190 191

140 180

CN702

VR VG VB

PSIG

RGT, HCK1, HCK2, HST,

CN701

BL THH

BL L

EXT STRB ON

USB D±

(MS ACCESS)

MS DIO, MS BS, MS SCLK

ı

DO, DI,

SCK

ı

BT RTS, BT CTS,

BT RXDT, BT TXDT

ı

32

FR SI, FR SO, XFR SCK

4 5 3

6

2 7

8 12 13 19

ı

23

6

1

CV OUT

AU AINL

AOUT L SP VOL

D853

IC604

2

EEPROM

ı 4

(4/13)

BT LED ON

LCD901

COLOR

LCD

D901

BACKLIGHT

1

CN601

3 5 7

2

OVERALL (2/2) (PAGE 3-3)

MEMORY

STICK

OVERALL (2/2) (PAGE 3-3)

XRST SYS

SYS V

XTALLY LED

Q102

STB ON

7

A : VIDEO SIGNAL

A : AUDIO SIGNAL

A : VIDEO/AUDIO SIGNAL

05

XCHARGE LED

SELF TIMER LED STB CHARGE XSTB FULL

3-1 3-2

DSC-F77/FX77

COVER

3. BLOCK DIAGRAMS

3-2. OVERALL BLOCK DIAGRAM (2/2)

SY-81 BOARD (2/2)

USB D± USB D±

OVERALL (1/2)

(PAGE 3-2)

MIC901

MICROPHONE

1

FP-586 FLEXIBLE BOARD

SP901

SPEAKER

BT301

LITHIUM

BATTERY

OVERALL (1/2)

(PAGE 3-2)

2

CV OUT

AU AINL AOUT L

SP VOL

CN402

MIC SIG

2

CN401

SP OUT±

5 6

1 2

FR SI, FR SO, XFR SCK

SYS V

XTALLY LED

XCHARGE LED

SELF TIMER LED STB CHARGE XSTB FULL

DSC-FX77

BT RTS, BT CTS, BT RXDT, BT TXDT

BT LED ON

VL 3V

FR 4V

DRIVE

KEY AD2

CN352

Q364

LED

IC301

6 4

VIDEO AMP

(4/13)

19 25

16

IC401

AUDIO AMP

(7/13)

40

1 3

IC203

3

INITIAL RESET,

BACK UP VCC

7

(6/13)

Q205

LED

DRIVE

KEY AD2

13

BT RTS, BT CTS,

9

BT RXDT, BT TXDT

ı

12

XBT LED ON

3

( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

46

11

5

8 6

EVER 3.0V BACKUP VCC

BT-14 BOARD

CN1001

3

4

ı

7

13

EXT STRB ONEXT STRB ON

LANC SIG

BEEP

S101

BLUETOOTH

17

ı

BLUETOOTH

20

V OUT

AU OUT

CP101

MODULE

15

10 12

17

16

6

IC201 LANC

11

DRIVER

(6/13)

Q207

MODULATOR

S851

RESET

FR SI, FR SO, XFR SCK

5

D104

(BLUETOOTH)

(MULTI CONNECTOR)

LANC IN

LANC OUT

XRESET

X201

10MHz

X202

32.768kHz

XRST SYSXRST SYS

SYS V

XTALLY LED

CHARGE ST LED

SELF TIMER LED

STB CHARGE

XSTB FULL

KEY AD2

ANT101

CN503

3910 4012

74

79

73

28

29

51

52

23

ı

25

77 32

15

16

19 46 34

57

IC202

HI CONTROL

(6/13)

1

ı

3

24

11

5 14 13

9

10

11 33

43 42

47 48

8

20 21

1

4 5

2 35 54

17

3

55 56

58

BT901

BATTERY

TERMINAL

ACV UNREG

BATT/XEXT

Q202

Q214

LENS PWR ON

+

S

–

USB JACK IN

XLANC JACK IN

XAV JACK IN

USB JACK IN

XLANC JACK IN

XAV JACK IN

Q208

BATTERY

CHARGE

DETECTOR

KEY AD0 KEY AD1

KEY AD3

BATT UNREG

BATT SIG BATT SIG

Q016, 020

Q204

S855

CONTROL

BATT UNREG

ACV UNREG

S854

S852, 853

DIGITAL ZOOM

XMULTI IN

BATT SIG

INIT CHARGE

FAST CHARGE

BATT/XEXT

UNREG SO, UNREG SCK

XPWR ON

XSHTR ON, XAE LOCK SW

MODE DIAL, XSET UP, XPB ON

S856

DSPL/LCD

ON/OFF

MENU

Q018, 019

INIT CHARGE

FAST CHARGE

45 46

CN853

CN851

BATT/XEXT

IC051

DC CONVERTER

(13/13)

IC052

DC CONVERTER

(13/13)

IC001

DC CONTROL

(12/13)

CONTROL SWITCH BLOCK (MD51200)

XPWR ON

5

XSHTR SW, XAE LOCK SW

15 16

AUTO/NC, XPB ON, XMOVIE, XSET UP,

2

SCN/MODE, PAUTO/NC

3 7

ı

10

XPWR LEDXPWR LED ON

14

KK-29 FLEXIBLE BOARD

P ON

3 4

XHANTEN

1 2

BATT UNREG

ACV UNREG

FR 4V

LANC 5.5V

D 1.5V D 2.9V PANEL 2.9V A 2.9V CAM 3.2V A 4.9V M 5V PANEL 13.5V CAME 15V CAME –7.5V

S004

POWER

S003

SHUTTER

S005

MODE

DIAL

D001

(POWER)

S051

LENS OPEN

S052

LENS REVERSE

A : VIDEO SIGNAL

A : AUDIO SIGNAL

A : VIDEO/AUDIO SIGNAL

05

3-3 3-4

COVER

3. BLOCK DIAGRAMS

DSC-F77/FX77

3-3. POWER BLOCK DIAGRAM (1/2)

SY-81 BOARD (1/2)

BATT UNREG

CN503

23

GND

25 26

ACV

1

UNREG

ı

3

BATT/XEXT

24

LANC DC

4

BT301

LITHIUM

BATTERY

BATT SIG

BATT GND

LF003

LINE

FILTER

Q016, 020

Q018, 019

CHARGE

CONTROL

CN401

1

VL 3V

2

BATT SIG

FAST CHARGE

D007

INIT CHARGE

BATT/XEXT

BT901

BATTERY

TERMINAL

MULTI

CONNECTOR

+

S

–

FP-586 FLEXIBLE BOARD

( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

F051

F003

F002

XLANC ON

D054

D055

IC201

LANC DRIVE

(6/13)

L064L063

D202

L062

Q061

SWITCHING

LANC 5.5V

Q212

INITIAL RESET,

BACK UP VCC

D057

IC203

(6/13)

D052

IC051

DC/DC

CONVERTER

IC052

DC/DC

CONVERTER

Q209

(13/13)

LANC ON DD

L201

L061

L065

EVER 3.0V

FR 4V

EVER 3.0V

BACK UP VCC

D004

D051

41

48 56

47

EVER 3.0V

DD CON SENS

IC001

DC/DC CONTROL

(12/13)

VCC2

OUT 1p OUT 1n

OUT 4p OUT 4n

OUT 5p OUT 5n

LD ON VCC1

OUT 5S

RST

VIN 1–

VCC3 VCC5

VIN 4–

VIN 5–

Q002, 004

SWITCHING

36 37

55

42 20

30 31

53

Q007, 013

L006

SWITCHING

38 39

43 52

L008L001 R063

Q006, 010

L003

SWITCHING

Q015

L004

L010

R068

Q008

SWITCHING

D001 D002

R065

R066

R067

R070

ACV UNREG

Q353, 356

13.5V REG

CAM 15V DD

EVER 3.0V

D 1.5V

D 2.9V

A 2.9V

PANEL 2.9V

A 4.9V

PANEL

13.5V

A

POWER 2

(PAGE 3-7)

ST-78 BOARD

T001

FLASH

UNIT

(SELF TIMER/AF ILLUMINATOR)

D102

CN101

1 2

4

ST UNREG

M 5V

1 2

4

CN351

Q360, 362

L351

STB CHARGE

XLANC ON

FAST CHARGE

INIT CHARGE

BATT/EXT

BATT SIG

Q208

BATTERY CHARGE

DETECTOR

IC202

HI CONTROL

(6/13)

67 BATT SENS

ACV SENS

68

18

XLANC ON

48

FAST CHARGE

47

INIT CHARGE

8

BATT/XEXT

BATT SI

43 42

BATT SO

46 STB CHG

SYS DD ON

XCS DDCON

UNREG SO

UNREG SCK

23

OUT 9

80

IN 9–

SCP 9

1

Q003, 012

L005

SWITCHING

66DD CON SENS

76 22 20 21

SYS DD ON

XCS DDCON

UNREG SO

UNREG SCK

57

CONT

44

XCS

45

DATA

46

CLK

OUT 6p OUT 6n

OUT 6S

VIN 6–

VCC4

OUT 10

AMP IN

AMP OUT

IN 10

SCPIN

OUT 3p

V IN3–

28 29

18 50

19

22

4 5

−

3

10

32

54

Q001

EMERGENCY

DETECT

Q014

Q011

SWITCHING

L002

Q005

SWITCHING

R069

L012

L009

R064

M 5V

CAM –7.5V DD

CAM 3.2V

CAM 3.2V BT

05

3-5 3-6

DSC-F77/FX77

COVER

3. BLOCK DIAGRAMS

3-4. POWER BLOCK DIAGRAM (2/2)

SY-81 BOARD (2/2)

L703

L701

L702

L707 L708 D706

IC701

LCD DRIVE

(8/13)

P OFF E3

EXT DA J7

BACK LIGHT DRIVE

POWER 1

(PAGE 3-6)

PANEL 13.5V

PANEL 2.9V

ACV UNREG

CAM 3.2V BT

CAM 15V DD

CAM −7.5V DD

A

A 4.9V

EVER 3.0V

D 2.9V

M 5V

CAM 3.2V

( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

LCD901

GEN

CN702

D702

CN701

VDD

18

VDDG

16

CRext

9

REF

11

BL THH

6

BL H

3

BL L

1

COLOR

BACKLIGHT

CAM 3.2V BT

CAM 15V DD

CAM −7.5V DD

A 4.9V

EVER 3.0V

D 2.9V

M 5V

CAM 3.2V

LCD

D901

Q057 - 060

CAME 15V DD

CAME −7.5V DD

CAM 3.2V BT

BT WAKEUP

M 5V

FB155

FB157

L152

L153

L154

L151

L801

L803

Q701, 702

Q705

REF VOLTAGE 59 15

Q706

IC702

(8/13)

FB153

FB154

FB156

IC151

TIMING GENERATOR,

S/H, AGC,

A/D CONVERTER

(1/13)

IC803

FOCUS/

IRIS

(MECHA SHUTTER)

DRIVE (5/13)

Q803

CN352

CN151

CAM 3.2V

6

BT WAKEUP

5

M 5V

4

FP-585 FLEXIBLE BOARD

CN001

25

30

21

22

2

DSC-FX77

BT-14 BOARD

CN1001

10

11

12

CAMERA 15V

CAMERA −7.5V

EVER 3.0V

D 2.9V

FC SENS VCC

Q101, 102

FB101

(BLUETOOTH)

CD-415 BOARD

CN001

22

FB001

21

26

27

2

L101

D104

LENS BLOCK

CP101

BLUETOOTH

MODUULE

CCD IMAGER

(FLASH/CHG)

(SELF TIMER/REC)

(AE/AF LOCK)

FOCUS

SENSOR

IC001

D003

D001

D002

IC801

HALL CONTROL

(5/13)

IC803

HALL CONTROL,

HALL AMP

(5/13)

IC804

SHUTTER CONTROL

(5/13)

PWR LED VCC

CN601

VCC

MEMORY

2 6

STICK

CONTROL SWITCH BLOCK (MD51200)

CN853

12

D001

(POWER)

D32/PTA 7

IC501

32M FLASH

(3/13)

L802

30

MS POWER ON

Q603

IC604

EEPROM

(4/13)

L602

D 1.5V

L403

L401

A 2.9V

L301

05

IC301

VIDEO AMP

(4/13)

L402

IC602

EVR

(D/A CONV.)

(4/13)

AUDIO AMP

AU 2.9V

IC401

(7/13)

FB652

FB605

CLOCK GEN.

L651

L652

IC603

(4/13)

D 2.9V

D 1.5V

FB651

FB653

CAM DD ON

IC651

CAMERA DSP, 128M SDRAM

BT WAKEUP

L603

FB601

FB603

FB602

L601

16

TENO/PTO0

198

PTM 6

MC CAM, SH DSP,

D853

(MS ACCESS)

3-7 3-8E

COVER

PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS

4-1. FRAME SCHEMATIC DIAGRAM

1

FRAME SCHEMATIC DIAGRAM

A

352647

CAMERA BLOCK

SECTION 4

4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS

811109121513 14 16 17

DSC-F77/FX77

10P

CN101

ST_UNREG

1 ST_UNREG

2

ST-78

BOARD

3 PRELAMP

4 M_5V

5 REG_GND

6 REG_GND

7 STB_ON

8 STB_FULL

9 ST_GND

15P

10 ST_GND

1 SENS RST

B

C

2 SENS VCC

3 SENS GND

4 FOCUS_A

LENS

BLOCK

5 FOCUS_B-

6 FOUCS_B

7 FOCUS_A-

8 IG_DRIVE+

9 IG_DRIVE-

10 TEMP OUT

11 GND

12 HALL_OUT+

13 HALL_IN-

14 HALL_IN+

CN001

27P

XCHARGE_LED

XAE_LOCK_LED

D_2.9V

EVER 3.0V

15 HALL_OUT-

XTALLY_LED

27

CAMERA_15V

CAMERA_-7.5V

GND

CD-415 BOARD

CCD

V2

V3A

V4

V1A

GND

V3B

KK-29

FLEXIBLE

BOARD

BACK 1.5inch

LIGHT

H1

GND

VSUB_CONT

VSHT

CCD_TEMP

1011121314151617181920212223242526

GND

V1B

GND

RG

CCD_OUT

GND

H2

GND

123456789

LCD901D901

COLOR LCD

D

SS-173 HARNESS

FP-585 FLEXIBLE

1

2

3456789

E

F

G

H

MEMORY

STICK

CONNECTOR

FLEXIBLE

FP-587

MIC901

MICROPHONE

10

2

1

8

7

6

5

4

3

2

1

9

8

7

6

5

4

3

2

1

CN402

CN601

MIC_SIG

MIC_GND

VSS

BS

VCC

DIO

INT

SCLK

VCC

VSS

ST_GND

STB_FULL

STB_ON

REG_GND

M_5V

PRELAMP

ST_UNREG

FOCUS_B

REG_GND

FC_SENS_VCC

2P

8P

10PCN351

XFC_RST_SENS

CN151

50P

1011121314151617181920212223242526272829303132333435363738394041424344454647484950

V3B

FOCUS_A

REG_GND

FOCUS_B

REG_GND

FOCUS_A

DRIVE-

DRIVE+

REG_GND

BIAS-

LENS_TEMP

HALL+

HALL-

BIAS+

GND

D_2.9V

EVER_3.0V

CAMERA_15V

XCHARGE_LED

XAE_LOCK_LED

XTALLY_LED

V1A

GND

CAMERA_-7.5V

V4

V2

V1B

V3A

GND

RG

GND

VSHT

CCD_TEMP

VSUB_CONT

IC651

ZB-007 BOARD

SY-81 BOARD

H2

H1

GND

CCD_OUT

12345

P_ON

XHANTEN

CN851

6P

6

GND

P_ON

12345

N.C.

BL_L

BL_H

6PCN701

BL_THL

6

1234567

B

N.C.

BL_THH

16P

XAE_LOCK_SW

CN853

N.C.

XPWR_LED

XSHTR_SW

RGT

24PCN702

NC

R

NC/D_2.9V

PWR_LED_VCC

G

PAUTO/NC

10111213141516

9

8

10111213141516171819202122

REF

XMOVIE

HST

WIDE

SDUT

CRext

AUTO/NC

XPB_ON

NC

XPWR_ON

PSIG

SCN/MODE

HCK1CSHCK2

XSET_UP

23

24

EN

VSS

VSSG

VDDG

GND

123456789

VST

VCK

VDD

COM

DWN

TEST

I

J

K

L

DSC-FX77

05

BT-14

BOARD

CN1001

15P

15GND

14GND

13XBT_LED_ON

12M_5V

11BT_WAKEUP

10CAM_3.2V

9BT_XSLEEP

8BT_BMCTEST0

7BT_CTS

FLEXIBLE

6BT_RXDT

5BT_TXDT

4BT_RTS

3KEY_AD2

2GND

1GND

FP-588

15PCN352

1 GND

2 GND

3 XBT_LED_ON

4 M_5V

5 BT_WAKEUP

6 CAM_3.2V

7 BT_XSLEEP

8 BT_BMCTEST0

9 BT_CTS

10 BT_RXDT

11 BT_TXDT

12 BT_RTS

13 KEY_AD2

14 GND

15 GND

CN401

6P

GND

SP_OUT-

SP_OUT+

6

FP-586 FLEXIBLE

BT301 LITHIUM BATTERY

VL_3V

VL_3v

12345

SP901

SPEAKER

CN503

1

3

5

7

9

11

13

15

17

19

21

23

25

(MULTI CONNECTOR)

ACV_UNREG

XLANC_JACK_IN

USB_LED

USB_HOST

USB_VBUS

XMULTI_IN

EXT_STRB_ON

V_OUT

V_GND

AUX

ACV_GND

272829

30

CRADLE UNIT

or

AC ADAPTOR

ACV_UNREG

LANC_DC

LANC_SIG

USB/LANC_GND

XAV_JACK_IN

A_OUT_L

A_OUT_R

BATT/XEXT

ACV_GND

A_GND

BT901

BATTERY

TERMINAL

2

4

6

8

10

D+

12

D-

14

16

18

20

22

AUX

24

26

CONTROL

SWITCH

BLOCK

(MD51200)

4-1 4-2

FRAME

4-2. SCHEMATIC DIAGRAMS

COVER

4-2. SCHEMATIC DIAGRAMS

THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS (In addition to this, the necessary note is printed in each block)

DSC-F77/FX77

(For schematic diagrams)

• All capacitors are in µF unless otherwise noted. pF : µ

Link

µF. 50 V or less are not indicated e xcept for electrolytics and tantalums.

• Chip resistors are 1/10 W unless otherwise noted. kΩ=1000 Ω, MΩ=1000 kΩ.

• Caution when replacing chip parts. New parts must be attached after removal of chip. Be careful not to heat the minus side of tantalum capacitor, Because it is damaged by the heat.

• Some chip part will be indicated as follows.

Example C541 L452

22U 10UH TA A 2520

Kinds of capacitor

Case size

External dimensions (mm)

• Constants of resistors, capacitors, ICs and etc with XX indicate that they are not used. In such cases, the unused circuits may be indicated.

• Parts with ★ differ according to the model/destination. Refer to the mount table for each function.

• All variable and adjustable resistors have characteristic curve B, unless otherwise noted.

• Signal name XEDIT→ EDIT PB/XREC → PB/REC

• 2: non flammable resistor

• 5: fusible resistor

• C: panel designation

• A: B+ Line

• B: B– Line

• J : IN/OUT direction of (+,–) B LINE.

• C: adjustment for repair.

• A: VIDEO SIGNAL (ANALOG)

• A: AUDIO SIGNAL (ANALOG)

• A: VIDEO/A UDIO SIGNAL

• A: VIDEO/A UDIO/SER V O SIGNAL

• A: SERVO SIGNAL

• Circled numbers refer to waveforms.

(Measuring conditions voltage and waveform)

• Voltages and waveforms are measured between the measurement points and ground when camera shoots color bar chart of pattern box. They are reference values and reference waveforms. (VOM of DC 10 MΩ input impedance is used)

• Voltage values change depending upon input impedance of VOM used.)

1. Connection

Pattern box

Front of the lens

L

L = About 30 cm

2. Adjust the distance so that the output waveform of Fig. a and the Fig. b can be obtain.

H

Yellow

Cyan

White

Magenta

Green

AABBA=B

Fig. a (Video output terminal output waveform)

Fig.b (Picture on monitor TV)

When indicating parts by reference number, please include the board name.

Red

Blue

Note : The components identified by mark 0 or

dotted line with mark 0 are critical for safety. Replace only with part number specified.

4-5

COVER

Link

DSC-F77/FX77

4-2. SCHEMATIC DIAGRAMS

CD-415 BOARD

ST-78 BOARD

KK-29 BOARD

COMMON NOTE FOR SCHEMATIC DIAGRAMS WAVEFORMS

(CCD IMAGER)

(FLASH DRIVE)

(LENS POSITION)

CONTROL SWITCH BLOCK

FP-585 FLEXIBLE BOARD

FP-586 FLEXIBLE BOARD

COVER

For Schematic Diagram

• Refer to page 4-45 for printed wiring board.

• Refer to page 4-57 for waveform.

4-2. SCHEMATIC DIAGRAMS CD-415 BOARD

DSC-F77/FX77

1

3

CD-415 BOARD

A

CCD IMAGER(CD BLOCK)

XX MARK:NO MOUNT

NO MARK:REC/PB MODE

R:REC MODE P:PB MODE

B

1

C

D

IC001

CCD IMAGER

IC001

ICX406BQC-13

R-7/P0

1

V4

H2

R-7/P0

2

V3A3V3B

R-7/P0

18VL19H120

R-0.3/P0

4V25

16

R-0.3/P0

V1A6V1B

SUB17CSUB

2

C006

0.1u

R12/P0

7

8

9

10

GND

TEST

VOUT

VDD12RG13H214H115GND

11

16V

3

4

C008

10p

R12/P0

Q002

2SC4250(T5LSONY1)

BUFFER

R010

220

R009

1k

CL-196YG-CD-T

D001

CL-196HR-CD-T

(SELF TIMER/REC)

R005

3300

R11.3/P0

R14.8/P0

D002

(AE/AF LOCK)

78

D003

CN001

27

26

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

27P

D_2.9V

EVER 3.0V

XCHARGE_LED

XAE_LOCK_LED

XTALLY_LED

CAMERA_15V

CAMERA_-7.5V

GND

V3B

V2

V1A

V3A

V4

V1B

VSHT

CCD_TEMP

VSUB_CONT

GND

H1

RG

H2

GND

CCD_OUT

GND

FLEXIBLE

LND101-LND127

(PAGE 4-41)

/CHG

220R011

SML-310YTT86D003

TH001

9625

FP-585

R2.2/P0

R2.6/P0

R9.1/P0

R8.7/P0

R2.6/P0

R2.2/P0

R13.1/P0

C003

0.1u 16V

Q001

C005

R14.8/P0

0.1u

C004

10u 16V

16V

R004

C007

0.001u

R006

12

16

10

R007

D004

MA4L11100AS0

4

1

R014 100k

2

3

SIGNAL PATH

Y/CHROMA

VIDEO

SIGNAL

REC

C011

0.22u

FB001

C010

0.22u

Precautions for Replacement of CCD Imager

R-7.4/P0

22R002

E

5

F

05

R9.1/P0

C001

0.1u 16V

R001 2700

R003 220k

C002

2200p

0

DTC144EHT2L

SWITCH

• The CD-415 board mounted as a repair part is not equipped with a CCD imager. When replacing this board, remove the CCD imager from the old one and mount it onto the new one.

• If the CCD imager has been replaced, carry out all the adjustments for the camera section.

• As the CCD imager may be damaged by static electricity from its structure, handle it carefully like for the MOS IC. In addition, ensure that the receiver is not covered with dusts nor exposed to strong light.

4-7 4-8

CD-415

Schematic diagrams of the SY-81and BT-14 (FX77) boards are not shown. Pages from 4-9 to 4-36 are not shown.

DSC-F77/FX77

COVER

For Schematic Diagram

• Refer to page 4-53 for printed wiring board.

4-2. SCHEMATIC DIAGRAMS ST-78 BOARD

1

35269487

ST-78 BOARD

A

FLASH DRIVE(ST BLOCK)

XX MARK:NO MOUNT

NO MARK:REC/PB MODE

T101

DC/DC CONVERTER

D101

MA2S111-(K8).SO

B

Q101 2SB1073-R-TX TRANS DRIVE

C101

10u

R102

0

27k

0

R101

47

C103

1u

R104

270

TRANS

4

3

2

1

5

6

C

C102

0.01u

R103

2700

D103

HAU160C030TP

R108

1.5k

C104

42u

330V

CHARGING

CAPACITOR

LND101

GND

Q102

CY25AAJ-8-T13

FLASH SWITCH

R105

47

R107

1M

R106

1M

LND103

XE_A(H)

L101

C105

0.047u

190

8

7

5

6

1

23

4

0

LND102

TRIGGER

LND104

XE_K(L)

FLASH UNIT

D

E

F

05

SY-81 (9/13)

CN351

THROUGH THE

SS-173 HARNESS

(PAGE 4-26)

CN101

10P

4

6

5

1ST_UNREG

2ST_UNREG

3PRELAMP

4M_5V

5REG_GND

6REG_GND

7STB_ON

8STB_FULL

9ST_GND

10ST_GND

TLOH9202(SONY)

(SELF TIMER/AF ILLUMINATOR)

LND105

ST_GND

23

1

D102

ST-78

4-37

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

4-38

COVER

For Schematic Diagram

• Refer to page 4-55 for printed wiring board.

4-2. SCHEMATIC DIAGRAMS KK-29 BOARD

DSC-F77/FX77

1

A

KK-29 FLEXIBLE BOARD

342

A

LENS POSITION(KK BLOCK)

S051

(LENS OPEN)

B

C

D

S052

(LENS REVERSE)

LND901

XHANTEN

LND902

XHANTEN

LND903

P_ON

LND904

P_ON

LND905

GND

LND906

GND

05

1

SY-81

(10/13)

CN851

(PAGE 4-28)

6

B

C

D

1

CONTROL SWITCH BLOCK(MD51200)

CONTROL SWITCH BLOCK(MD51200) is replased as block, so that PRINTED WIRING BOARD is omitted.

POWER

XPB_ON

AUTO/NC

NC

GND

S004

XPWR_ON

2

SET_UP

MOVIE

(2nd)

D001

(POWER)

NC

XMOVIE

XSET_UP

PAUTO/NC

NC/D_2.9V

SCN/MODE

PWR_LED_VCC

PLAY

NC

3

B

G

6

A

(1st)

XPWR_LED

XSHTR_SW

S005

MODE DIAL

S003

(SHUTTER)

XAE_LOCK_SW

4

SCN

3

P_AUTO

2

AUTO

1

5

LND005

LND004

LND003

LND001

LND002

E

05

116

LND008

LND006

SY-81(10/13)

LND007

CN853

(PAGE 4-28)

LND009

LND010

LND011

LND012

LND013

LND014

LND015

LND016

4-39 4-40

KK-29, CONTROL SWITCH BLOCK

DSC-F77/FX77

COVER

4-2. SCHEMATIC DIAGRAMS FP-586 FLEXIBLE BOARD

For Schematic Diagram

• Refer to page 4-56 for printed wiring board.

1

FP-585 FLEXIBLE BOARD

A

B

C

D

E

F

G

H

FP-585 FLEXIBLE BOARD is replased as block, so that PRINTED WIRING BOARD is omitted.

SY-81 (1/13)

CN151

(PAGE 4-9)

CN001

XFC_RST_SENS

FC_SENS_VCC

REG_GND

FOCUS_B

FOCUS_A

REG_GND

FOCUS_B

REG_GND

FOCUS_A

DRIVE-

DRIVE+

REG_GND

LENS_TEMP

HALL+

EVER_3.0V

D_2.9V

XAE_LOCK_LED

XCHARGE_LED

CAMERA_15V

XTALLY_LED

CAMERA_-7.5V

CCD_TEMP

VSUB_CONT

CCD_OUT

BIAS-

HALL-

BIAS+

VSHT

GND

50P

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

V3B

29

30

V1A

31

32

V3A

33

V2

34

V1B

35

V4

36

37

38

39

40

RG

41

42

H1

43

H2

44

45

46

47

48

49

50

3

4

7

8

9625

A

SENS_RST

SENS_VCC

SENS_GND

FOCUS_A

FOCUS_B-

FOCUS_B

FOCUS_A-

IG_DRIVE+

IG_DRIVE-

TEMP_OUT

GND

HALL_OUT+

HALL_IN-

HALL_IN+

HALL_OUT-

LND001

LND002

LND003

LND004

LND005

LND006

LND007

LND008

LND009

LND010

LND011

LND012

LND013

LND014

LND015

LENS

BLOCK

B

C

1

FP-586 FLEXIBLE BOARD

SPEAKER

SIGNAL PATH

AUDIO

24

LND301

SP_OUT+SP901

SP_OUT-

LND302

BT301

LITHIUM BATTERY

(SECONDARY)

SIGNAL

VL_3V

3

GND

VL_3V

SP_OUT-

SP_OUT+

PB

LND303

LND304

LND305

LND306

LND307

LND308

D2.9

EVER_3.0V

XCHARGE_LED

XAE_LOCK_LED

XTALLY_LED

CAM_15V

CAM_-7.5V

GND

V3B

V2

V1A

V3A

V4

V1B

VSHT

CCD_TEMP

VSUB_CONT

GND

H1

RG

H2

GND

CCD_OUT

GND

LND127

LND126

LND125

LND124

LND123

LND122

LND121

LND120

LND119

LND118

LND117

LND116

LND115

LND114

LND113

LND112

LND111

LND110

LND109

LND108

LND107

LND106

LND105

LND104

LND103

LND102

LND101

27

CD-415

(PAGE 4-8)

1

CN001

D

05

16

SY-81(7/13)

CN401

(PAGE 4-22)

SIGNAL PATH

05

FP-585, FP-586

4-41

REC

VIDEO

SIGNAL

Y/CHROMA

4-42

4-3. PRINTED WIRING BOARDS

COVER

4-3. PRINTED WIRING BOARDS

THIS NOTE IS COMMON FOR WIRING BOARDS (In addition to this, the necessary note is printed in each block)

(For printed wiring boards)

• : Uses unleaded solder.

• : Circuit board

: Flexible board

Pattern from the side which enables seeing.

: pattern of the rear side

(The other layers’ patterns are not indicated)

• Through hole is omitted.

• Circled numbers refer to waveforms.

• There are a few cases that the part printed on diagram isn’t mounted in this model.

• C: panel designation

• Chip parts.

Transistor Diode

C

DSC-F77/FX77

43

12

3

43

12

31

4625

4

3

12

5

654

5246

EB

123

31 21

12

345

534

54

45

21321321

123

312 43

12

21

34

4-43

COVER

Link

DSC-F77/FX77

4-3. PRINTED WIRING BOARDS

CD-415 BOARD

ST-78 BOARD FP-586 FLEXIBLE BOARD

COMMON NOTE FOR PRINTED WIRING BOARDS

MOUNTED PARTS LOCATION

CIRCUIT BOARDS LOCATION

KK-29 BOARD

WAVEFORMS

FLEXIBLE BOARDS LOCATION

DSC-F77/FX77

COVER

CD-415 (CCD IMAGER)

For Printed Wiring Board.

• :Uses unleaded solder.

• CD-415 board is 6-layer print board. However, the pattern

of layer 2 to 5 have not been included in the diagram.

• There are a few cases that the part isn't mounted in this model is printed on this diagram.

• See page 4-60 for printed parts location.

4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS

CD-415 BOARD

D001

SELF TIMER/REC

1 2

3

MOUNTED PARTS LOCATION

A

05

D001

D002

D003

/CHG

R009

R010

AE/AF LOCK

BCE

R001

R011

Q001

TH001

C001

1

C011

R003

R002

20

C002

C010

C003

FB001

IC001

10

C008

C006

R005

E

B

26

27

+

C004

R014

D004

BB

R006

R007

Q002

C005

R004

C

CN001

5

4

11

C007

213

2

1-685-827-

1

11

4-45 4-46

CD-415

Printed wiring boards of the SY-81 and BT-14 (FX77) boards are not shown. Pages from 4-47 to 4-52 are not shown.

DSC-F77/FX77

COVER

ST-78 (FLASH DRIVE)

For Printed Wiring Board.

• :Uses unleaded solder.

• ST-78 board is 8-la yer print board. Ho we ver , the pattern of

layers 2 to 7 have not been included in the diagram.

• There are a few cases that the part isn't mounted in this model is printed on this diagram.

• See page 4-63 for printed parts location.

ST-78 BOARD (SIDE A)

LND105

4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS

ST-78 BOARD (SIDE B)

C104

MOUNTED PARTS LOCATION

A

B

LND103

R107

T101

635

124

L101

R103

C103

R104

LND102

D101

B

Q101

E

R102

C

C102

LND101

R101

LND104

85

Q102

1

1-685-826-

4

R105 R106

11

A

D102

K

10

SELF TIMER/

AF ILLUMINATOR

CN101

A

C101

R108

AA

1

D103

K

B

C105

1-685-826-

11

05

4-53 4-54

213

05

2 13

ST-78

DSC-F77/FX77

COVER

KK-29 (LENS POSITION)

For Printed Wiring Board.

• :Uses unleaded solder.

• KK-29 board is 4-layer print board. Howev er , the pattern of

layers 2 to 3 have not been included in the diagram.

• There are a few cases that the part isn't mounted in this model is printed on this diagram.

KK-29 BOARD (SIDE A)

4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS

KK-29 BOARD (SIDE B)

61

LND905

LND906

LND903

LND904

LND901

LND902

FP-586 FLEXIBLE

For Printed Wiring Board.

• :Uses unleaded solder.

• There are a few cases that the part isn't mounted in this

model is printed on this diagram.

FP-586 FLEXIBLE BOARD

61

LND303

LND304

LND305

LND306

LND307

LND308

MOUNTED PARTS LOCATION

BT301

LITHIUM BATTERY

SECONDARY

+

-

BT301

05

S051

(LENS OPEN)

05

1-685-819-

11

(LENS REVERSE)

05

S052

1-685-819-

11

LND302

LND301

1-685-821-

11

SP901

SPEAKER

KK-29, FP-586

4-55

4-56

COVER

4-4. WA VEFORMS

CD-415 BOARD

1

148 µsec

IC001 1, 2, 3 REC

2

CD-415 BOARD

7.6 Vp-p

DSC-F77/FX77

3

4

148 µsec

IC001 4, 5, 6 REC

1.0 Vp-p

148 µsec

IC001 q; REC

3.6 Vp-p

18 MHz

IC001 qs REC

5

5.1 Vp-p

56 nsec

IC001 qd, qf, ql, w; REC

4-57

CD-415

Waveforms of the SY-81 board are not shown. Pages 4-58 and 4-59 are not shown.

DSC-F77/FX77

COVER

4-3. PRINTED WIRING BOARDS

4-5. MOUNTED PARTS LOCATION

CD-415 BOARD

C001 A-1 C002 A-2 C003 A-2 C004 A-2 C005 A-2 C006 A-2 C007 A-3 C008 A-2 C010 A-2 C011 A-2

CN001 A-3

D001 A-1 D002 A-1 D003 A-1 D004 A-2

FB001 A-2

IC001 A-2

Q001 A-1 Q002 A-2

R001 A-1 R002 A-2 R003 A-2 R004 A-2 R005 A-2 R006 A-2 R007 A-2 R009 A-1 R010 A-1 R011 A-1 R014 A-2

TH001 A-1

no mark : side A * mark : side B

* C101 A-1

C102 B-2

C103 A-1 * C104 A-3 * C105 B-1

* CN101 A-2

D101 B-2 * D102 B-2 * D103 A-1

L101 B-1

Q101 A-2

Q102 B-2

R101 B-2

R102 B-2

R103 A-1

R104 B-1

R105 B-2

R106 B-3

R107 B-1

T101 A-1

CD-415

4-60

Mounted parts location of the SY-81 board are not shown. Pages 4-61 and 4-62 are not shown.

Ver 1.1 2003. 02

COVER

ST-78 BOARD

C102 B-2

C103 A-1 * C104 A-3 * C105 B-1

* CN101 A-2

D101 B-2 * D102 B-2 * D103 A-1

L101 B-1

Q101 A-2

Q102 B-2

R101 B-2

R102 B-2

R103 A-1

R104 B-1

R105 B-2

R106 B-3

R107 B-1 * R108 A-1

T101 A-1

4-3. PRINTED WIRING BOARDS

DSC-F77/FX77

no mark : side A * mark : side B

4-63E

ST-78

DSC-F77/FX77

CABINET (UPPER)

BLOCK ASSEMBLY

CABINET (UPPER)

BLOCK ASSEMBLY

BT BLOCK ASSEMBLY-2

COVER

NOTE

5. REPAIR PARTS LIST

NOTE: Characters A to Z of the electrical parts list indicate location of exploded views in which the desired part is shown.

Link

OVERALL ASSEMBLY

(DSC-F77)

CABINET (REAR)

BLOCK ASSEMBLY

Link

EXPLODED VIEWS

A

OVERALL ASSEMBLY

(DSC-FX77)

BC

BT BLOCK ASSEMBLY-1

ELECTRICAL PARTS LIST

LENS CABINET

ASSEMBLY

ACCESSORIES

KK-29 BOARD

A

B

ST-78 BOARD FP-586 FLEXIBLE BOARDCD-415 BOARD

AC

5. REPAIR PARTS LIST

COVER

NOTE:

• -XX, -X mean standardized parts, so they may have some differences from the original one.

• Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.

•The mechanical parts with no reference number in the exploded views are not supplied.

• Accessories are given in the last of the electrical parts list.

• Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set.

• CAPACITORS: uF: µF

• COILS uH: µH

• RESISTORS All resistors are in ohms. METAL: metal-film resistor METAL OXIDE: Metal Oxide-film resistor F: nonflammable

• SEMICONDUCTORS In each case, u: µ, for example: uA...: µA... , uPA... , µPA... , uPB... , µPB... , uPC... , µPC... , uPD..., µPD...

•Abbreviation

AUS: Australian model CH : Chinese model HK : Hong Kong model JE : Tourist model J: Japanese model

5. REPAIR PARTS LIST

DSC-F77/FX77

When indicating parts by reference number, please include the board name.

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

5-1

DSC-F77/FX77

COVER

5-1. EXPLODED VIEWS

5-1-1. OVERALL ASSEMBLY (DSC-F77)

5. REPAIR PARTS LIST

5

2

Main assembly-1 (See page 5-4)

3

2

1

Ref. No. Part No. Description Ref. No. Part No. Description

1 3-078-103-01 CABINET (FRONT) 2 3-057-082-21 SCREW (M1.7), P2

3 3-078-127-01 COVER, HINGE 5 3-078-104-01 CABINET (FRONT), INNER

5-2

2

5. REPAIR PARTS LIST

51

52

53

54

55

56

57

ns

Main assembly-1 (See page 5-4)

59

COVER

5. REPAIR PARTS LIST

5-1-2. OVERALL ASSEMBLY (DSC-FX77)

ns: not supplied

DSC-F77/FX77

Ref. No. Part No. Description Ref. No. Part No. Description

51 3-078-103-01 CABINET (FRONT) 52 3-057-082-21 SCREW (M1.7), P2 53 X-3952-865-1 COVER (BLT) ASSY, HINGE 54 3-078-684-01 SHEET, PROTECTION, BLT

55 A-7078-501-A BT-14 BOARD, COMPLETE 56 1-685-823-11 FP-588 FLEXIBLE BOARD 57 3-079-777-01 BIT (P2 MAIN) M1.7, SPECIAL 59 3-078-104-01 CABINET (FRONT), INNER

5-3

DSC-F77/FX77

COVER

5-1-3. CABINET (UPPER) BLOCK ASSEMBLY

5. REPAIR PARTS LIST

Lens cabinet assembly (See page 5-5)

Main assembly-2 (See page 5-6)

104

101

105

106

103

MIC901

102

Ref. No. Part No. Description Ref. No. Part No. Description

101 3-075-827-01 COVER, CUSHION MICROPHONE

* 102 3-055-971-01 CUSHION, MICROPHONE

103 3-078-132-01 COVER, MICROPHONE 104 3-078-130-01 CABINET (UPPER)

105 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION 106 3-057-082-21 SCREW (M1.7), P2 MIC901 1-542-446-21 MICROPHONE

5-4

COVER

5. REPAIR PARTS LIST

DSC-F77/FX77

5-1-4. LENS CABINET ASSEMBLY

152

157

156

155

153

154

152

158

171

152

161

(Note 2)

159

IC001 (Note 1)

162

174

160

163

173

160

164

172

165

166

167

170

152

151

152

Ref. No. Part No. Description Ref. No. Part No. Description

151 X-3952-806-1 CABINET (LOWER) ASSY, L 152 3-057-082-21 SCREW (M1.7), P2 153 X-3952-807-1 CABINET (FRONT) ASSY, L 154 3-078-128-01 FRAME, LENS 155 3-078-129-01 HOLDER, FP

156 A-7078-429-A FP-585 FLEXIBLE BOARD, COMPLETE 157 3-078-133-01 SHEET, FP 158 X-3952-805-1 CABINET (UPPER) ASSY, L 159 A-7031-373-A LENS ASSY 160 3-713-791-15 SCREW (M1.7X6), TAPPING, P2

168

(Note 1) Be sure to read “Precuations for Replacement of CCD

Imager” on page 4-8 when changing the CCD imager.

(Note 2) Refer to page 2-9 “CD-415 BOARD, OPTICAL FILTER

BLOCK” to find correct side of optical filter block to install.

164 A-7078-428-A CD-415 BOARD, COMPLETE 165 3-078-746-01 SHEET (CD), LIGHT SHIELDING 166 1-758-804-11 FINDER, OPTICAL (B157A) 167 A-7078-427-A ST-78 BOARD, COMPLETE 168 1-961-972-11 HARNESS (SS-173)

169 3-078-123-01 CASE, HARNESS 170 X-3952-808-1 HINGE ASSY 171 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION 172 3-078-027-01 SHEET, INSULATED 173 CAUTION TAPE (K)

169

161 1-758-805-11 FILTER BLOCK, OPTICAL 162 3-078-029-01 PLATE, LIGHT INTERCEPTION 163 3-054-555-01 RUBBER (K), SEAL

174 3-079-091-01 SHEET, AF IC001 A-7013-047-A CCD BLOCK ASSY

CAUTION :

For the part of 173 : T APE (K) (3-831-441-11), cut WOVEN (T0.25), FABRIC NON (3-076-631-01) into the desired length and use it.

5-5

DSC-F77/FX77

COVER

5-1-5. CABINET (REAR) BLOCK ASSEMBLY

ns: not supplied

5. REPAIR PARTS LIST

208

Ver 1.1 2003. 02

204

203

208

206

202

201

ns

208

207

212

Main assembly-3 (See page 5-7)

209

210

211

Ref. No. Part No. Description Ref. No. Part No. Description

201 X-3952-812-1 CABINET (BOTTOM) ASSY 202 3-078-114-01 CABINET (REAR), INNER 203 A-7078-431-A KK-29 BOARD, COMPLETE 204 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION 206 1-477-510-11 SWITCH BLOCK, CONTROL (MD51200)

207 3-078-112-01 BRACKET, STRAP

208 3-057-082-21 SCREW (M1.7), P2 209 3-078-131-01 WINDOW, LCD 210 3-078-111-01 SHEET (LCD), ADHESIVE 211 X-3952-811-1 CABINET (REAR) ASSY 212 3-989-735-51 SCREW (M1.7), LOCK ACE, P2

5-6

COVER

5-1-6. BT BLOCK ASSEMBLY-1

ns: not supplied

5. REPAIR PARTS LIST

DSC-F77/FX77

252

LCD901

251

BT901

D901

252

253

254

252

Main assembly-4 (See page 5-8)

Ref. No. Part No. Description Ref. No. Part No. Description

251 A-7078-496-A SY-81 BOARD, COMPLETE (SERVICE) (F77) 251 A-7078-541-A SY-81 BOARD, COMPLETE (SERVICE) (FX77) 252 3-057-082-21 SCREW (M1.7), P2 253 3-078-124-01 FRAME, LCD 254 3-078-125-01 FRAME, MAIN

0 D901 1-477-429-11 BLOCK, LIGHT GUIDE PLATE

255

255 3-078-126-01 HOLDER, CONNECTOR BT901 1-694-854-11 BATTERY TERMINAL BOARD

LCD901 8-753-051-66 ACX309AKA-1

252

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

5-7

DSC-F77/FX77

COVER

5-1-7. BT BLOCK ASSEMBLY-2

ns: not supplied

302

ns

5. REPAIR PARTS LIST

304

309

310

303

302

301

!

: BT301 (BATTERY, LITHIUM SECONDARY)

Board on the mount position. (See page 4-56.)

307

ns

304

ns

306

311

302

$

305

Ref. No. Part No. Description Ref. No. Part No. Description

301 1-815-853-13 CONNECTOR, MEMORY STICK 302 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION 303 X-3952-809-1 HOLDER ASSY, BT 304 3-989-735-51 SCREW (M1.7), LOCK ACE, P2 305 A-7078-430-A FP-586 FLEXIBLE BOARD, COMPLETE

306 3-078-122-01 HOLDER, SPEAKER 307 1-685-822-11 FP-587 FLEXIBLE BOARD 309 X-3952-917-1 LID, ASSY (SERVICE), BT 310 3-318-382-01 SCREW (1.7X3), TAPPING 311 3-078-069-01 CUSHION, SP

5-8

5-2. ELECTRICAL PARTS LIST

Ref. No. Part No. Description Ref. No. Part No. Description

Electrical parts list of the BT -14 board (FX77) is not shown. Pages 5-10 is not shown.

DSC-F77/FX77

5-9

Ver 1.1 2003. 02

CD-415 FP-586 KK-29 ST-78

Ref. No. Part No. Description Ref. No. Part No. Description

A-7078-428-A CD-415 BOARD, COMPLETE

**********************

(IC001 is not included in the complete board)

< CAPACITOR >

C001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C002 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V C003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C004 1-135-957-91 TANTAL. CHIP 10uF 20% 16V C005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

S051 1-786-179-11 SWITCH, PUSH (1KEY) (LENS OPEN) S052 1-786-179-11 SWITCH, PUSH (1KEY) (LENS REVERSE)

A-7078-431-A KK-29 BOARD, COMPLETE

**********************

< SWITCH >

A-7078-427-A ST-78 BOARD, COMPLETE

*********************

DSC-F77/FX77

C006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C007 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V C008 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V C010 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V C011 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V

< CONNECTOR >

CN001 1-794-407-21 CONNECTOR, FPC (ZIF) 27P

< DIODE >

D001 8-719-077-09 DIODE CL-196HR-CD-T (SELF TIMER/REC) D002 8-719-063-83 DIODE SML-510MWT86 (AE/AF LOCK) D003 8-719-077-34 DIODE SML-310YTT86 (FLASH/CHG) D004 8-719-077-54 DIODE MA4L11100AS0

< FERRITE BEAD >

FB001 1-469-082-21 FERRITE 0uH

< IC >

IC001 A-7013-047-A CCD BLOCK ASSY (Note)

< TRANSISTOR >

Q001 8-729-052-64 TRANSISTOR DTC144EHT2L Q002 8-729-050-22 TRANSISTOR 2SC4250 (T5LSONY1)

0 1-477-523-11 FLASH UNIT

< CAPACITOR >

C101 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C103 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V

0 C104 1-100-394-11 CAP, ELECT 42uF 330V

C105 1-137-723-21 CERAMIC CHIP 0.047uF 10% 250V

< CONNECTOR >

CN101 1-816-463-11 PIN, CONNECTOR (PC BOARD) 10P

< DIODE >

D101 8-719-056-23 DIODE MA2S111- (K8).SO D102 6-500-432-01 DIODE TLOH9202 (SONY)

(SELF TIMER/AF ILLUMINATOR)

0 D103 6-500-237-01 DIODE HAU160C030TP

< COIL >

0 L101 1-456-193-11 COIL, TRIGGER

< TRANSISTOR >

Q101 8-729-422-87 TRANSISTOR 2SB1073-R

0 Q102 8-729-053-74 TRANSISTOR CY25AAJ-8-T13

< RESISTOR >

R001 1-218-958-11 RES-CHIP 2.7K 5% 1/16W R002 1-208-643-11 RES-CHIP 22 5% 1/16W R003 1-218-981-11 RES-CHIP 220K 5% 1/16W R004 1-208-635-11 RES-CHIP 10 5% 1/16W R005 1-218-959-11 RES-CHIP 3.3K 5% 1/16W

R006 1-220-872-81 METAL CHIP 12 0.5% 1/16W R007 1-220-875-11 METAL CHIP 16 0.5% 1/16W R009 1-218-953-11 RES-CHIP 1K 5% 1/16W R010 1-218-945-11 RES-CHIP 220 5% 1/16W R011 1-218-945-11 RES-CHIP 220 5% 1/16W

R014 1-218-977-11 RES-CHIP 100K 5% 1/16W

< THERMISTOR >

TH001 1-810-816-11 THERMISTOR, NTC (1608)

A-7078-430-A FP-586 FLEXIBLE BOARD, COMPLETE

******************************

< BATTERY >

BT301 1-756-191-21 BATTERY, LITHIUM (SECONDARY)

(Note) Be sure to read “Note on the CCD Imager

Replacement” on page 4-8 when changing the CCD imager.

< RESISTOR >

R101 1-216-805-11 METAL CHIP 47 5% 1/16W R102 1-216-838-11 METAL CHIP 27K 5% 1/16W R103 1-216-826-11 METAL CHIP 2.7K 5% 1/16W R104 1-216-814-11 METAL CHIP 270 5% 1/16W R105 1-218-937-11 RES-CHIP 47 5% 1/16W

R106 1-218-989-11 RES-CHIP 1M 5% 1/16W R107 1-216-270-00 RES-CHIP 1M 5% 1/8W R108 1-218-955-11 RES-CHIP 1.5K 5% 1/16W

< TRANSFORMER >

0 T101 1-435-741-21 TRANSFORMER, DC-DC CONVERTER

Electrical parts list of the SY -81 board is not shown. Pages 5-12 to 5-18 are not shown.

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number

5-11

specified.

Ref. No. Part No. Description Ref. No. Part No. Description

ACCESSORIES

************

1-477-487-11 CRADLE UNIT

0 1-477-488-11 ADAPTOR, AC (EXCEPT CH) 0 1-477-488-12 ADAPTOR, AC (CH) 0 1-569-007-11 ADAPTOR, CONVERSION (F77: E, JE) 0 1-569-008-21 ADAPTOR, CONVERSION 2P (F77: E)

0 1-696-819-21 CORD, POWER (F77: AUS) 0 1-769-608-11 CORD, POWER (F77: AEP, E/FX77: AEP) 0 1-782-476-11 CORD, POWER (F77: CH) 0 1-783-374-11 CORD, POWER (F77: UK, HK/FX77: UK) 0 1-790-732-11 CORD, POWER (F77: JE)

0 1-791-637-11 CORD, POWER (J)

1-823-932-11 CORD, CONNECTION (USB5P) 1-824-111-11 CORD, CONNECTION (AV CONNECTING) 3-065-665-05 MANUAL, INSTRUCTION (JAPANESE) (J) 3-076-646-02 STRAP, HAND

3-077-012-02 SPVD008 (51100) (J) (USB DRIVER) 3-077-023-02 SPVD008 (51100) (EXCEPT J) (USB DRIVER) 3-078-407-01 MANUAL, INSTRUCTION (JAPANESE) (F77: J) 3-078-407-11 MANUAL, INSTRUCTION (ENGLISH)

(F77: AEP, UK, E, HK, AUS, CH, JE)

3-078-407-21 MANUAL, INSTRUCTION (FRENCH, GERMAN)

(F77: AEP)

DSC-F77/FX77

3-078-407-31 MANUAL, INSTRUCTION

3-078-407-41 MANUAL, INSTRUCTION (ITALIAN, DUTCH)

3-078-407-51 MANUAL, INSTRUCTION

3-078-407-61 MANUAL, INSTRUCTION

3-078-407-71 MANUAL, INSTRUCTION (ARABIC) (F77: E)

3-078-408-01 MANUAL, INSTRUCTION (JAPANESE) (F77: J) 3-078-409-01 MANUAL, INSTRUCTION (JAPANESE)

3-078-409-11 MANUAL, INSTRUCTION (ENGLISH)

3-078-409-21 MANUAL, INSTRUCTION (FRENCH, GERMAN)

3-078-409-31 MANUAL, INSTRUCTION (ITALIAN, DUTCH)

3-078-410-01 MANUAL, INSTRUCTION (JAPANESE)

3-079-664-01 MANUAL, INSTRUCTION (BT) (JAPANESE)

3-079-664-11 MANUAL, INSTRUCTION (BT) (ENGLISH)

3-079-664-21 MANUAL, INSTRUCTION (BT)

3-079-664-31 MANUAL, INSTRUCTION (BT)

(SPANISH, PORTUGUESE) (F77: AEP, E, JE)

(F77: AEP)

(TRADITIONAL CHINESE, SIMPLIFIED CHINESE)

(F77: E, HK, CH, JE)

(RUSSIAN, SWEDISH) (F77: AEP)

(FX77: J)

(FX77: AEP, UK)

(FX77: AEP)

(FX77: J)

(FX77: AEP, UK)

(FRENCH, GERMAN) (FX77: AEP)

(ITALIAN, DUTCH) (FX77: AEP)

5-195-19E

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

DSC-F77/FX77

9-929-997-31

Sony EMCS Co.

— 68 —

2003B0500-1

Published by DI Customer Center

DSC-F77/FX77

LEVEL 2

AEP Model

SERVICE MANUAL

Ver 1.1 2003. 02

CORRECTION-1

File this correction with the service manual

• Correction of MOUNTED PARTS LOCATION

• Correction of repair parts

SECTION 4

PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS

UK Model

Japanese Model

DSC-F77/FX77

E Model

Hong Kong Model

Australian Model

Chinese Model

Tourist Model

DSC-F77

& : Points added parts.

4-5. MOUNTED PARTS LOCATION

(Service manual page 4-63)

ST-78 BOARD

C102 B-2

C103 A-1 * C104 A-3 * C105 B-1

* CN101 A-2

D101 B-2 * D102 B-2 * D103 A-1

L101 B-1

Q101 A-2

Q102 B-2

R101 B-2

R102 B-2

R103 A-1

R104 B-1

R105 B-2

R106 B-3

R107 B-1 * R108 A-1

T101 A-1

*

no mark : side A * mark : side B

DSC-F77/FX77

- : Points changed portion.

5-1. EXPLODED VIEWS

5-1-5. CABINET (REAR) BLOCK ASSEMBLY (Service manual page 5-6)

INCORRECT CORRECT

SECTION 5

REPAIR PARTS LIST

Ref. No. Part No. DescriptionRef. No. Part No. Description

212 3-989-735-51 SCREW (M1.7), LOCK ACE, P2

208

207

ns

208

5-2. ELECTRICAL PARTS LIST

(Service manual page 5-11)

211

210

208

ns

208

212

[

207

210

211

5-11

INCORRECT CORRECT

A-7078-428-A CD-415 BOARD, COMPLETE

R006 1-218-990-11 SHORT CHIP 0 R007 1-218-990-11 SHORT CHIP 0

A-7078-427-A ST-78 BOARD, COMPLETE

R108

Ref. No. Part No. DescriptionRef. No. Part No. Description

A-7078-428-A CD-415 BOARD, COMPLETE

R006 1-220-872-81 METAL CHIP 12 0.5% 1/16W R007 1-220-875-11 METAL CHIP 16 0.5% 1/16W

Ref. No. Part No. DescriptionRef. No. Part No. Description

A-7078-427-A ST-78 BOARD, COMPLETE

R108 1-218-955-11 RES-CHIP 1.5K 5% 1/16W

9-929-997-91

Sony EMCS Co.

— 2 —

2003B0500-1

Published by DI Customer Center

DSC-F77/FX77

LEVEL 2

AEP Model

SERVICE MANUAL

Ver 1.2 2003. 02

SUPPLEMENT-1

File this supplement with the service manual.

• Addition of Black Model (F77)

• Addition of E, Hong Kong, Australian Model (FX77)

• Addition and Change of repair parts

UK Model

E Model

Hong Kong Model

Australian Model

Japanese Model

DSC-F77/FX77

Chinese Model

Tourist Model

DSC-F77

(PV02-011)

DSC-F77/FX77

SECTION 5

REPAIR PARTS LIST

Addition of Black Model (F77) 5-1. EXPLODED VIEWS

5-1-1. OVERALL ASSEMBLY (DSC-F77) (BLACK MODEL)

5

Main assembly-1 (See page 5-4)

2

3

2

1

Ref. No. Part No. Description Ref. No. Part No. Description

1 3-078-103-11 CABINET (FRONT) 2 3-057-082-11 SCREW (M1.7), P2

3 3-078-127-11 COVER, HINGE 5 3-078-104-11 CABINET (FRONT), INNER

2

— 2 —

5-1-3. CABINET (UPPER) BLOCK ASSEMBLY (BLACK MODEL)

Main assembly-2 (See page 5-6)

DSC-F77/FX77

Lens cabinet assembly (See page 5-5)

101

105

104

106

103

MIC901

102

Ref. No. Part No. Description Ref. No. Part No. Description

101 3-075-827-01 COVER, CUSHION MICROPHONE

* 102 3-055-971-01 CUSHION, MICROPHONE

103 3-078-132-01 COVER, MICROPHONE 104 3-078-130-11 CABINET (UPPER)

105 3-375-114-01 SCREW (DIA. 1.7X4), PRECISION 106 3-057-082-11 SCREW (M1.7), P2 MIC901 1-542-446-21 MICROPHONE

— 3 —

DSC-F77/FX77

5-1-4. LENS CABINET ASSEMBLY (BLACK MODEL)

157

152

153

156

175

155

154

158

171

152

161

(Note 2)

159

IC001 (Note 1)

162

174

160

163

173

160

164

172

165

166

167

170

152

151

152

Ref. No. Part No. Description Ref. No. Part No. Description

151 X-3953-328-1 CABINET (LOWER) ASSY, L 152 3-057-082-11 SCREW (M1.7), P2 153 X-3953-329-1 CABINET (FRONT) ASSY, L 154 3-078-128-01 FRAME, LENS 155 3-078-129-01 HOLDER, FP

156 A-7078-429-A FP-585 FLEXIBLE BOARD, COMPLETE 157 3-078-133-01 SHEET, FP 158 X-3953-327-1 CABINET (UPPER) ASSY, L 159 A-7031-373-A LENS ASSY 160 3-713-791-15 SCREW (M1.7X6), TAPPING, P2

168

(Note 1) Be sure to read “Precuations for Replacement of CCD

Imager” on page 4-8 when changing the CCD imager.

(Note 2) Refer to page 2-9 “CD-415 BOARD, OPTICAL FILTER

BLOCK” to find correct side of optical filter block to install.

164 A-7078-428-A CD-415 BOARD, COMPLETE 165 3-078-746-01 SHEET (CD), LIGHT SHIELDING 166 1-758-804-11 FINDER, OPTICAL (B157A) 167 A-7078-427-A ST-78 BOARD, COMPLETE 168 1-961-972-11 HARNESS (SS-173)

169 3-078-123-01 CASE, HARNESS 170 X-3953-330-1 HINGE ASSY 171 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION 172 3-078-027-01 SHEET, INSULATED 173 CAUTION TAPE (K)

169

161 1-758-805-11 FILTER BLOCK, OPTICAL 162 3-078-029-01 PLATE, LIGHT INTERCEPTION 163 3-054-555-01 RUBBER (K), SEAL

174 3-079-091-01 SHEET, AF IC001 A-7013-047-A CCD BLOCK ASSY

CAUTION :

For the part of 173 : T APE (K) (3-831-441-11), cut WOVEN (T0.25), FABRIC NON (3-076-631-01) into the desired length and use it.

— 4 —

5-1-5. CABINET (REAR) BLOCK ASSEMBLY (BLACK MODEL)

213

DSC-F77/FX77

204

203

208

206

202

201

ns

213

207

208

Main assembly-3 (See page 5-7)

209

210

211

Ref. No. Part No. Description Ref. No. Part No. Description

201 X-3953-333-1 CABINET (BOTTOM) ASSY 202 3-078-114-11 CABINET (REAR), INNER 203 A-7078-431-A KK-29 BOARD, COMPLETE 204 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION 206 1-477-510-21 SWITCH BLOCK, CONTROL (MD51200)

207 3-078-112-01 BRACKET, STRAP

208 3-057-082-21 SCREW (M1.7), P2 209 3-078-131-01 WINDOW, LCD 210 3-078-111-01 SHEET (LCD), ADHESIVE 211 X-3953-332-1 CABINET (REAR) ASSY 213 3-057-082-11 SCREW (M1.7), P2

— 5 —

DSC-F77/FX77

5-1-7. BT BLOCK ASSEMBLY-2 (BLACK MODEL)

302

ns

309

304

ns

310

303

ns

302

311

301

307

$

305

!

: BT301 (BATTERY, LITHIUM SECONDARY)

Board on the mount position. (See page 4-56.)

Ref. No. Part No. Description Ref. No. Part No. Description

301 1-815-853-13 CONNECTOR, MEMORY STICK 302 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION 303 X-3953-331-1 HOLDER ASSY, BT 304 3-989-735-51 SCREW (M1.7), LOCK ACE, P2 305 A-7078-430-A FP-586 FLEXIBLE BOARD, COMPLETE

306 3-078-122-01 HOLDER, SPEAKER 307 1-685-822-11 FP-587 FLEXIBLE BOARD 309 X-3953-334-1 LID, ASSY (SERVICE), BT 310 3-318-382-01 SCREW (1.7X3), TAPPING 311 3-078-069-01 CUSHION, SP

304

306

302

— 6 —

Addition and Change of repair parts

2

& : Points added parts.

- : Points changed parts.

5-1. EXPLODED VIEWS

5-1-3. CABINET (UPPER) BLOCK ASSEMBLY (Service manual page 5-4)

FORMER NEW

Ref. No. Part No. DescriptionRef. No. Part No. Description

105 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION 105 3-375-114-01 SCREW

Lens cabinet assembly (See page 5-5)

DSC-F77/FX77

[

5-1-4. LENS CABINET ASSEMBLY (Service manual page 5-5)

FORMER NEW

Ref. No. Part No. Description

152

158

152

105

Ref. No. Part No. Description

175 3-080-666-01 SHEET (VH)

152

&

175

)

158

152

156

155

171

161

(Note 2)

— 7 —

156

155

171

161

(Note

DSC-F77/FX77

& : Points added parts.

- : Points changed parts.

5-1-7. BT BLOCK ASSEMBLY-2 (Service manual page 5-8)

FORMER NEW

Ref. No. Part No. DescriptionRef. No. Part No. Description

309 X-3952-917-1 LID, ASSY (SERVICE), BT 309 X-3952-917-1 LID, ASSY (SERVICE), BT

309 X-3952-917-3 LID, ASSY (SERVICE), BT

(WITHOUT MS-PRO logo mark)

)

(WITH MS-PRO logo mark)

[

— 8 —

- : Points changed parts. ! : Points deleted parts.

5-2. ELECTRICAL PARTS LIST

(Service manual page 5-11)

FORMER NEW

Ref. No. Part No. Description

A-7078-428-A CD-415 BOARD, COMPLETE

DSC-F77/FX77

Ref. No. Part No. Description

A-7078-428-A CD-415 BOARD, COMPLETE

5-11

5-19E

CN001 1-794-407-21 CONNECTOR, FPC (ZIF) 27P

R002 1-208-643-11 RES-CHIP 22 5% 1/16W

Ref. No. Part No. Description

A-7078-430-A FP-586 BOARD, COMPLETE

BT301 1-756-191-21 BATTERY, LITHIUM (SECONDARY)

Ref. No. Part No. Description

A-7078-427-A ST-78 BOARD, COMPLETE

0 1-477-523-11 FLASH UNIT

C105 1-137-723-21 CERAMIC CHIP 0.047uF 10% 250V

Ref. No. Part No. Description

ACCESSORIES

************

0 1-477-488-11 ADAPTOR, AC (EXCEPT CH)

0 1-477-488-12 ADAPTOR, AC (CH)

0 1-569-007-11 ADAPTOR, CONVERSION (F77: E, JE)

0 1-696-819-21 CORD, POWER (F77: AUS)

0 1-769-608-11 CORD, POWER (F77: AEP, E/FX77: AEP)

0 1-782-374-11 CORD, POWER (F77: UK, HK/FX77: UK)

CN001 1-817-077-11 CONNECTOR, FPC (ZIF) 27P

R002 1-218-933-11 RES-CHIP 22 5% 1/16W

Ref. No. Part No. Description

A-7078-430-A FP-586 BOARD, COMPLETE

BT301 1-756-191-22 BATTERY, LITHIUM (SECONDARY)

Ref. No. Part No. Description

A-7078-427-A ST-78 BOARD, COMPLETE

0 1-477-523-12 FLASH UNIT

C105 1-100-533-11 CERAMIC CHIP 68000PF 10% 250V

Ref. No. Part No. Description

ACCESSORIES

************

0 1-477-488-12 ADAPTOR, AC

0 1-569-007-11 ADAPTOR, CONVERSION

0 1-696-819-21 CORD, POWER (AUS)

0 1-769-608-11 CORD, POWER (AEP, E)

0 1-783-374-11 CORD, POWER (UK, HK)

@

(F77: E, JE/FX77: E)

[

=

$

— 9 —

[

3-078-407-03 MANUAL, INSTRUCTION (BLACK)

[

3-078-407-12 MANUAL, INSTRUCTION (BLACK)

(ENGLISH) (F77: E, HK, AUS, CH, JE)

[

3-078-407-32 MANUAL, INSTRUCTION (BLACK)

(SPANISH, PORTUGUESE) (F77: E, JE)

[

3-078-407-52 MANUAL, INSTRUCTION (BLACK)

[

3-078-407-72 MANUAL, INSTRUCTION (BLACK)

[

3-078-408-03 MANUAL, INSTRUCTION (BLACK)

[

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

(JAPANESE) (F77: J)

(TRADITIONAL CHINESE,

SIMPLIFIED CHINESE)

(F77: E, HK, CH, JE)

(ARABIC) (F77: E)

(JAPANESE) (F77: J)

DSC-F77/FX77

& : Points added parts.

- : Points changed parts.

Ref. No. Part No. Description

5-19E

FORMER NEW

Ref. No. Part No. Description

3-078-409-02 MANUAL, INSTRUCTION (BLACK)

[

3-078-409-12 MANUAL, INSTRUCTION (ENGLISH)

[

3-078-409-41 MANUAL, INSTRUCTION (TRADITIONAL

3-079-664-11 MANUAL, INSTRUCTION (BT) (ENGLISH)

(JAPANESE) (FX77: J)

(FX77: E, HK, AUS)

)

CHINESE, SIMPLIFIED CHINESE)

(FX77: E, HK)

)

(FX77: E, HK, AUS)

3-079-664-41 MANUAL, INSTRUCTION (BT)

(TRADITIONAL CHINESE, SIMPLIFIED

CHINESE) (FX77: E, HK)

)

9-929-997-81

Sony EMCS Co.

— 10 —

2003B0500-1

Published by DI Customer Center

Reverse

992999733.pdf

Revision History

Ver.

1.0

1.1

1.2

Date

2002.10

2003.02

History

Official Release Correction-1

(C1)

Supplement-1

(S1 PV02-011)

Contents

—

• Correction of MOUNTED PARTS LOCATION

• Correction of repair parts

S.M. correction : Page 4-63, Page 5-6,

Page 5-11

• Addition of Black Model (F77)

•Addition of E, Hong Kong, Australian Model (FX77)

• Addition and Change of repair parts

S.M. Rev.

issued

—

Yes

No

SONY DSC-F77, DSC-FX77 SERVICE MANUAL L2 V1.2

Specifications and Main Features

Frequently Asked Questions

User Manual

SPECIFICATIONS

TABLE OF CONTENTS

SERVICE NOTE

DISASSEMBLY

7 Cabinet (front)

0 Lens block assembly

2 Cabinet (bottom) assembly

4 Control switch block

6 LCD module

qk SY-81board

8 Lens block

ST-78 board

6 FP-585 flexible board block

BLOCK DIAGRAMS

PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS

FRAME SCHEMATIC DIAGRAM

CD-415

ST-78

CD-415

ST-78

CORRECTION-1

PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS

REPAIR PARTS LIST

SUPPLEMENT-1

REPAIR PARTS LIST

Addition and Change of repair parts

Revision History
