4-595-966-41(1)

FM/AM Compact Disc Player

To cancel the demonstration (DEMO) display, see page 10.

To switch the FM/AM tuning step, see page 6. For the connection/installation, see page 20.

데모(DEMO) 표시를 취소하려면 10페이지를 참조하십시오.

FM/AM 튜닝 단위를 전환하려면 6페이지를 참조하십시 오. 연결/설치에 대한내용은 19페이지를 참조 하십시오.

Operating Instructions

사용 설명서

CDX-G1201U/CDX-G1200U

For safety, be sure to install this unit in the dashboard of the car as the rear side of the unit becomes hot during use. For details, see “Connection/Installation” (page 20).

Laser Diode Properties

 Emission Duration: Continuous  Laser Output: Less than 53.3 W

(This output is the value measurement at a distance of 200 mm from the objective lens surface on the Optical Pick-up Block with 7 mm aperture.)

The nameplate indicating operating voltage, etc., is located on the bottom of the chassis.

WARNING: Do not ingest battery, Chemical Burn Hazard.

The remote commander contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.

Note on the lithium battery

Do not expose the battery to excessive heat such as direct sunlight, fire or the like.

Warning if your car’s ignition has no ACC position

Be sure to set the AUTO OFF function (page 10). The unit will shut off completely and automatically in the set time after the unit is turned off, which prevents battery drain. If you do not set the AUTO OFF function, press and hold OFF until the display disappears each time you turn the ignition off.

Disclaimer regarding services offered by third parties

Services offered by third parties may be changed, suspended, or terminated without prior notice. Sony does not bear any responsibility in these sorts of situations.

2GB

Table of Contents

Guide to Parts and Controls. . . . . . . . . . . . . 4

Getting Started

Detaching the Front Panel . . . . . . . . . . . . . . 6

Resetting the Unit . . . . . . . . . . . . . . . . . . . . . 6

Switching the FM/AM Tuning Step . . . . . . . 6

Setting the Clock. . . . . . . . . . . . . . . . . . . . . . 6

Connecting a USB Device . . . . . . . . . . . . . . . 6

Connecting Other Portable Audio

Device . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Listening to the Radio

Listening to the Radio . . . . . . . . . . . . . . . . . 7

Using Radio Data System (RDS). . . . . . . . . . 8

Playback

Playing a Disc . . . . . . . . . . . . . . . . . . . . . . . . 8

Playing a USB Device . . . . . . . . . . . . . . . . . . 8

Searching and Playing Tracks . . . . . . . . . . . 9

Settings

Canceling the DEMO Mode . . . . . . . . . . . . 10

Basic Setting Operation . . . . . . . . . . . . . . . 10

General Setup (GENERAL) . . . . . . . . . . . . . 10

Sound Setup (SOUND) . . . . . . . . . . . . . . . . . 11

Display Setup (DISPLAY). . . . . . . . . . . . . . . 12

Connection/Installation

Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Parts List for Installation . . . . . . . . . . . . . . 20

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Installation . . . . . . . . . . . . . . . . . . . . . . . . . 23

Additional Information

Updating the Firmware . . . . . . . . . . . . . . . 13

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . 13

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 14

Specifications . . . . . . . . . . . . . . . . . . . . . . . 14

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 16

Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3GB

Guide to Parts and Controls

Main unit

 Front panel release button  SRC (source)

Turn o n t he power. Change the source.

OFF

Press and hold for 1 second to turn the source off and display the clock. Press and hold for more than 2 seconds to turn off the power and the display. If the unit is turned off and the display disappears, operation by the remote commander is not available.

 Control dial

Rotate to adjust the volume.

PUSH ENTER

Enter the selected item.

Open the setup menu.

 Disc slot  Display window  / (SEEK –/+)

Tune in radio stations automatically. Press and hold to tune manually.

/ (prev/next) / (fast-reverse/fast-forward)

 (disc eject)

4GB

 PTY (program type)

Select PTY in RDS.

(browse) (page 9)

Enter the browse mode during playback. (Not available when a USB device in Android™ mode is connected.)

 EQ (equalizer)

Select an equalizer curve.

 (back)

Return to the previous display.

MODE (page 7)

 Receptor for the remote commander  Number buttons (1 to 6)

Receive stored radio stations. Press and hold to store stations.

ALBUM /

Skip an album for audio device. Press and hold to skip albums continuously. (Not available when a USB device in Android mode is connected.)

(repeat)

(Not available when a USB device in Android mode is connected.)

(shuffle)

(Not available when a USB device in Android mode is connected.)

 (play/pause)

 EXTRA BASS

Reinforces bass sound in synchronization with the volume level. Press to change the EXTRA BASS setting: [1], [2], [OFF].

 AUX input jack  DSPL (display)

Change display items.

SCRL (scroll)

Press and hold to scroll a display item.

 USB port

RM-X211 Remote commander

The VOL (volume) + button has a tactile dot.

 ATT (attenuate)

Attenuate the sound. Press again to cancel the attenuation.

 SOUND

Open the SOUND menu directly.

Press and hold to open the setup menu.

///

Select a setup item, etc.

ENTER

Enter the selected item.

/ (prev/next) +/– (album +/–)

 VOL (volume) +/–

Remove the insulation film before use.

5GB

Getting Started

Detaching the Front Panel

You can detach the front panel of this unit to prevent theft.

1 Press and hold OFF  until the unit

turns off, press the front panel release button , then pull the panel towards you to remove.

Caution alarm

If you turn the ignition switch to the OFF position without detaching the front panel, the caution alarm will sound for a few seconds. The alarm will only sound if the built-in amplifier is used.

Attaching the front panel

Switching the FM/AM Tuning Step

Set the FM/AM tuning step of your country. This setting appears only while the source

is off and the clock is displayed.

1 Press MENU, rotate the control dial to

select [GENERAL], then press it.

2 Rotate the control dial to select [SET

TUNER-STP], then press it.

3 Rotate the control dial to select from

[SET 50K/9K], [SET 100K/10K] or [SET 200K/10K], then press it.

Setting the Clock

1 Press MENU, rotate the control dial to

select [GENERAL], then press it.

2 Rotate the control dial to select [SET

CLOCK-ADJ], then press it.

The hour indication flashes.

3 Rotate the control dial to set the hour

and minute.

To move the digital indication, press SEEK +/–.

4 After setting the minute, press MENU.

The setup is complete and the clock starts.

To di spl a y the cloc k

Press DSPL.

Resetting the Unit

Before operating the unit for the first time, or after replacing the car battery or changing connections, you must reset the unit.

1 Press DSPL and (back)/MODE for

more than 2 seconds.

Note

Resetting the unit will erase the clock setting and some stored contents.

6GB

Connecting a USB Device

1 Turn down the volume on the unit. 2 Connect the USB device to the unit.

Connecting Other Portable Audio Device

1 Turn off the portable audio device. 2 Turn down the volume on the unit. 3 Connect the portable audio device to

the AUX input jack (stereo mini jack) on the unit with a connecting cord (not supplied)*.

* Be sure to use a straight type plug.

4 Press SRC to select [AUX].

To match the volume level of the connected device to other sources

Start playback of the portable audio device at a moderate volume, and set your usual listening volume on the unit. Press MENU, then select [SOUND]  [SET AUX VOL] (page 12).

Listening to the Radio

Tuning step setting is required (page 6). To listen to the radio, press SRC to select [TUNER].

Storing automatically (BTM)

1 Press MODE to change the b and ( FM1,

FM2, FM3, AM1 or AM2).

2 Press MENU, rotate the control dial to

select [GENERAL], then press it.

3 Rotate the control dial to select [SET

BTM], then press it.

The unit stores stations in order of frequency on the number buttons.

Tuning

1 Press MODE to change the b and ( FM1,

FM2, FM3, AM1 or AM2).

2 Perform tuning.

To tune manually

Press and hold SEEK +/– to locate the approximate frequency, then press SEEK +/– repeatedly to fine adjust to the desired frequency.

To tune automatically

Press SEEK +/–. Scanning stops when the unit receives a station.

Storing manually

1 While receiving the station that you

want to store, press and hold a number button (1 to 6) until [MEM] appears.

Receiving the stored stations

1 Select the band, then press a number

button (1 to 6).

7GB

Using Radio Data System (RDS)

Playback

Selecting program types (PTY)

1 Press PTY during FM reception. 2 Rotate the control dial until the

desired program type appears, then press it.

The unit starts to search for a station broadcasting the selected program type.

Type o f pro grams

NEWS (News), AFFAIRS (Current Affairs), INFO

(Information), SPORT (Spor ts), EDUCATE (Education), DRAMA (Drama), CULTURE (Culture), SCIENCE (Science), VARIE D (Varied),

POP M (Pop Music), ROCK M (Rock Music), EASY M (M.O.R. Music), LIGHT M (Light classical), CLASSICS (Serious classical), OTHER M (Other Music), WEATHER (Weather), FINANCE (Finance), CHILDREN (Children’s program), SOCIAL A (Social Affairs), RELIGION (Religion), PHONE IN (Phone In), TRAVEL (Travel), LEISURE

(Leisure), JAZZ (Jazz Music), COUNT RY (Country Music), NATION M (National Music), OLDIES (Oldies Music), FOLK M (Folk Music), DOCUMENT (Documentary)

Setting clock time (CT)

The CT data from the RDS transmission sets the clock.

1 Set [SET CT-ON] in [GENERAL]

(page 11).

Playing a Disc

1 Insert the disc (label side up).

Playback starts automatically.

Playing a USB Device

AOA (Android Open Accessory) 2.0, MSC (Mass Storage Class) and MTP (Media Transfer Protocol) type USB devices* compliant with the USB standard can be used. Depending on the USB device, the Android mode or MSC/MTP mode can be selected on the unit. Some digital media players or Android smartphones may require setting to MTP mode.

* e.g., a USB flash drive, digital media player,

Android smartphone

Notes

• For details on the compatibility of your USB device, visit the support site on the back cover.

• Smartphones with Android OS 4.1 or higher installed support Android Open Accessory 2.0 (AOA 2.0). However, some smartphones may not fully support AOA 2.0 even if Android OS 4.1 or higher is installed. For details on the compatibility of your Android smartphone, visit the support site on the back cover.

• Playback of the following files is not supported. MP3/WMA/FLAC: – copyright-protected files – DRM (Digital Rights Management) files – Multi-channel audio files MP3/WMA: – lossless compression files

8GB

Before making a connection, select the USB mode (Android mode or MSC/MTP mode) depending on the USB device (page 11).

1 Connect a USB device to the USB port

(page 6).

Playback starts. If a device is already connected, to start playback, press SRC to select [USB].

2 Adjust the volume on this unit.

To stop playback

Press and hold OFF for 1 second.

To remo v e th e dev ice

Stop playback, then remove the device.

Searching and Playing Tracks

Repeat play and shuffle play

Not available when a USB device in Android mode is connected.

1 During playback, press (repeat) or

(shuffle) repeatedly to select the

desired play mode.

Playback in the selected play mode may take time to start.

Available play modes differ depending on the selected sound source.

Searching a track by name (QuickBrowZer™)

Not available when a USB device in Android mode is connected.

1 During CD or USB playback, press

(browse)* to display the list of search categories.

When the track list appears, press (back) repeatedly to display the desired search category.

* During USB playback, press (browse) for

more than 2 seconds to directly return to the beginning of the category list.

2 Rotate the control dial to select the

desired search category, then press it to confirm.

3 Repeat step 2 to search the desired

track.

Playback starts.

To exit the Quick-BrowZer mode

Press (browse).

Searching by skipping items (Jump mode)

Not available when a USB device in Android mode is connected.

1 Press (browse). 2 Press SEEK +. 3 Rotate the control dial to select the

item.

The list is jumped in steps of 10 % of the total number of items.

4 Press ENTER to return to the Quick-

BrowZer mode.

The selected item appears.

5 Rotate the control dial to select the

desired item, then press it.

Playback starts.

9GB

Settings

Canceling the DEMO Mode

You can cancel the demonstration display which appears when the source is off and the clock is displayed.

1 Press MENU, rotate the control dial to

select [GENERAL], then press it.

2 Rotate the control dial to select [SET

DEMO], then press it.

3 Rotate the control dial to select [SET

DEMO-OFF], then press it.

The setting is complete.

4 Press (back) twice.

The display returns to normal reception/ play mode.

Basic Setting Operation

You can set items in the following setup categories: General setup (GENERAL), Sound setup (SOUND), Display setup (DISPLAY)

1 Press MENU. 2 Rotate the control dial to select the

setup category, then press it.

The items that can be set differ depending on the source and settings.

3 Rotate the control dial to select the

options, then press it.

To return to the previous display

Press (back).

General Setup (GENERAL)

DEMO (demonstration)

Activates the demonstration: [ON], [OFF].

CLOCK-ADJ (clock adjust) (page 6)

TUNER-STP (tuner step) (page 6)

(Available only while the source is off and the clock is displayed.)

CAUT ALM (caution alarm)

Activates the caution alarm: [ON], [OFF] (page 6). (Available only while the source is off and the clock is displayed.)

BEEP

Activates the beep sound: [ON], [OFF].

AUTO OFF

Shuts off automatically after a desired time when the unit is turned off: [ON] (30 minutes), [OFF].

STEERING

Registers/resets the setting of the steering wheel remote control. (Available when connected with the connection cable (not supplied).) (Available only while the source is off and the clock is displayed.) STR CONTROL (steering control) Selects the input mode of the connected remote control. To prevent a malfunction, be sure to match the input mode with the connected remote control before use.

CUSTOM

Input mode for the steering wheel remote control

PRESET

Input mode for the wired remote control excluding the steering wheel remote control (automatically selected when [RESET CUSTOM] is performed.)

10GB

EDIT CUSTOM

Registers the functions (SOURCE, ATT, VOL +/–, SEEK +/–) to the steering wheel remote control:  Rotate the control dial to select the

function you want to assign to the steering wheel remote control, then press it.

 While [REGISTER] is blinking, press and

hold the button on the steering wheel remote control you want to assign the function to. When registration is complete, [REGISTERED] is displayed.

 To register other functions, repeat

steps  and .

(Available only when [STR CONTROL] is set to [CUSTOM].)

RESET CUSTOM

Resets the setting of the steering wheel remote control: [YES], [NO]. (Available only when [STR CONTROL] is set to [CUSTOM].)

Notes

• While making settings, only button operation on the unit is available. For safety, park your car before making this setting.

• If an error occurs while reg istering, all the previously-registered information remains. Restart registration from the function where the error occurred.

• This function may not be available on some vehicles. For details on the compatibility of your vehicle, visit the support site on the back cover.

USB MODE

Changes the USB mode: [ANDROID], [MSC/MTP]. (Available only when the USB source is selected.)

CT (clock time)

Activates the CT function: [ON], [OFF].

BTM (best tuning memory) (page 7)

(Available only when the tuner is selected.)

FIRMWARE

(Available only while the source is off and the clock is displayed.) Checks/updates the firmware version. For details, visit the support site on the back cover. FW VERSION (firmware version) Displays current firmware version. FW UPDATE (firmware update) Enters firmware update process: [YES], [NO]. Updating the firmware takes a few minutes to complete. During the update, do not turn the ignition to the OFF position, nor remove the USB device.

Sound Setup (SOUND)

This setup menu can also be opened by pressing SOUND.

EQ10 PRESET

Selects an equalizer curve from 10 equalizer curves or off: [OFF], [R&B], [ROCK], [POP], [HIP-HOP], [ELECTRONICA], [JAZZ], [REGUETON],

[SALSA], [KARAOKE]*, [CUSTOM]. The equalizer curve setting can be memorized for each source.

* [KARAOK E] reduces the vocal s ound but

cannot be fully removed during playback. Also, using a microphone is not supported.

EQ10 CUSTOM

Sets [CUSTOM] of EQ10. Setting the equalizer curve: [BAND1] 32 Hz, [BAND2] 63 Hz, [BAND3] 125 Hz, [BAND4] 250 Hz, [BAND5] 500 Hz, [BAND6] 1 kHz, [BAND7] 2 kHz, [BAND8] 4 kHz, [BAND9] 8 kHz, [BAND10] 16 kHz. The volume level is adjustable in 1 dB steps, from -6 dB to +6 dB.

BALANCE

Adjusts the sound balance: [RIGHT-15] – [CENTER] – [LEFT-15].

11GB

FAD ER

Adjusts the relative level: [FRONT-15] – [CENTER] – [REAR-15].

S.WOOFER (subwoofer)

SW LEVEL (subwoofer level) Adjusts the subwoofer volume level: [+6 dB] – [0 dB] – [-6 dB]. ([ATT] is displayed at the lowest setting.) SW PHASE (subwoofer phase) Selects the subwoofer phase: [NORM], [REV]. LPF FREQ (low pass filter frequency) Selects the subwoofer cut-off frequency: [80Hz], [100Hz], [120Hz].

HPF FREQ (high pass filter frequency)

Selects the front/rear speaker cut-off frequency: [OFF], [80Hz], [100Hz], [120Hz].

AUX VOL (AUX volume level)

Adjusts the volume level for each connected auxiliary device: [+18 dB] – [0 dB] – [-8 dB]. This setting negates the need to adjust the volume level between sources. (Available only when the AUX is selected.)

Display Setup (DISPLAY)

BLK OUT (black out)

Turns off the illumination automatically if no operation is performed for 5 seconds when any source is selected: [ON], [OFF]. To turn the light back on, press any button on the unit or the remote commander.

DIMMER

Changes the display brightness: [ON], [OFF], [CLK]. To set this function to be active only during a fixed period, select [CLK], then set the start and end times. – To set the brightness when the dimmer

function is activated: Set [DIMMER] to [ON], then adjust [BRIGHTNESS].

– To set the brightness when the dimmer

function is deactivated: Set [DIMMER] to [OFF], then adjust

[BRIGHTNESS]. The brightness setting is stored and applied when the dimmer function is activated or deactivated.

BRIGHTNESS

Adjusts the display brightness. The brightness level is adjustable: [1] – [10].

SND SYNC (sound synchronization)

Activates the synchronization of the illumination with the sound: [ON], [OFF].

AUTO SCR (auto scroll)

Scrolls long items automatically: [ON], [OFF]. (Not available when the AUX or tuner is selected.)

12GB

Additional Information

Folder (album)

Audio file (track)

Updating the Firmware

To update the firmware, visit the support site on the back cover, then follow the online instructions.

Notes

• Using a USB device (not supplied) is required for updating the firmware. Store the updater in th e USB device, and connect the device to the USB port, then perform the update operation.

• Updating the firmware takes a few minutes to complete. During the update, do not turn the ignition to the OFF position, nor remove the USB device.

Precautions

• Cool off the unit beforehand if your car has been parked in direct sunlight.

• Do not leave the front panel or audio devices brought in inside the car, or it may cause malfunction due to high temperature in direct sunlight.

• Power antenna (aerial) extends automatically.

Moisture condensation

Should moisture condensation occur inside the unit, remove the disc and wait for about an hour for it to dry out; otherwise the unit will not operate properly.

To maintain high sound quality

Do not splash liquid onto the unit or discs.

• This unit is designed to play discs that conform to the Compact Disc (CD) standard. DualDiscs and some of the music discs encoded with copyright protection technologies do not conform to the Compact Disc (CD) standard, therefore, these discs may not be playable by this unit.

• Discs that this unit CANNOT play – Discs with labels, stickers, or sticky tape

or paper attached. Doing so may cause a malfunction, or may ruin the disc.

– Discs with non-standard shapes (e.g.,

heart, square, star). Attempting to do so may damage the unit.

–8 cm (3

/4 in) discs.

Notes on CD-R/CD-RW discs

• If the multi-session disc begins with a CDDA session, it is recognized as a CD-DA disc, and other sessions are not played.

• Discs that this unit CANNOT play – CD-R/CD-RW of poor recording quality. – CD-R/CD-RW recorded with an

incompatible recording device.

– CD-R/CD-RW which is finalized

incorrectly.

– CD-R/CD-RW other than those recorded

in music CD format or MP3 format conforming to ISO9660 Level 1/Level 2, Joliet/Romeo or multi-session.

Playback order of audio files

Notes on discs

• Do not expose discs to direct sunlight or heat sources such as hot air ducts, nor leave it in a car parked in direct sunlight.

• Before playing, wipe the discs with a cleaning cloth from the center out. Do not use solvents such as benzine, thinner, commercially available cleaners.

If you have any questions or problems concerning your unit that are not covered in this manual, consult your nearest Sony dealer.

13GB

Maintenance

+ side up

Specifications

Replacing the lithium battery of the remote commander

Under normal conditions, the battery will last approximately 1 year. (The service life may be shorter, depending on the conditions of use.) When the battery becomes weak, the range of the remote commander becomes shorter.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent type.

Notes on the lithium battery

• Keep the lithium battery out of the reach of children. Should the battery be swallowed, immediately consult a doctor.

• Wipe the ba ttery with a dr y cloth to ensure a good contact.

• Be sure to obser ve the correct polari ty when installing the battery.

• Do not hold the battery with metallic tweezers, otherwise a short-circuit may occur.

Cleaning the connectors

The unit may not function properly if the connectors between the unit and the front panel are not clean. In order to prevent this, detach the front panel (page 6) and clean the connectors with a cotton swab. Do not apply too much force. Otherwise, the connectors may be damaged.

Notes

• For safety, turn off the ignition before cleaning the connectors, and remove the key from the ignition switch.

• Never touch the connectors directly with your fingers or with any metal device.

Tuner section

Tuning range:

87.5 MHz – 108.0 MHz (at 50 kHz step)

87.5 MHz – 108.0 MHz (at 100 kHz step)

87.5 MHz – 107.9 MHz (at 200 kHz step)

FM tuning step:

50 kHz/100 kHz/200 kHz switchable

Antenna (aerial) terminal:

External antenna (aerial) connector

Intermediate frequency:

FM CCIR: -1,956.5 kHz to -487.3 kHz and

+500.0 kHz to +2,095.4 kHz Usable sensitivity: 7 dBf Selectivity: 75 dB at 400 kHz Signal-to-noise ratio: 73 dB Separation: 50 dB at 1 kHz Frequency response: 20 Hz – 15,000 Hz

Tuning range:

531 kHz – 1,602 kHz (at 9 kHz step) 530 kHz – 1,710 kHz (at 10 kHz step)

AM tuning step:

9 kHz/10 kHz switchable

Antenna (aerial) terminal:

External antenna (aerial) connector

Sensitivity: 26 µV

CD Player section

Signal-to-noise ratio: 95 dB Frequency response: 10 Hz – 20,000 Hz Wow and flutter: Below measurable limit The maximum number of: (CD-R/CD-RW

only)

– folders (albums): 150 (including root

folder)

– files (tracks) and folders: 300 (may less

than 300 if folder/file names contain many characters)

– displayable characters for a folder/file

name: 32 (Joliet)/64 (Romeo)

Corresponding codec: MP3 (.mp3) and WMA

(.wma)

14GB

USB Player section

Interface: USB (Full-speed) Maximum current: 500 mA The maximum number of recognizable

tracks: – folders (albums): 256 – files (tracks) per folder: 256 Compatible Android Open Accessory

protocol (AOA): 2.0 Corresponding codec:

MP3 (.mp3)

Bit rate: 8 kbps – 320 kbps (Supports

VBR (Variable Bit Rate))

Sampling rate: 16 kHz – 48 kHz

WMA (.wma)

Bit rate: 32 kbps – 192 kbps (Supports

VBR (Variable Bit Rate))

Sampling rate: 32 kHz, 44.1 kHz,

48 kHz

FLAC (.flac)

Bit depth: 16 bit, 24 bit Sampling rate: 44.1 kHz, 48 kHz

Power amplifier section

Output: Speaker outputs Speaker impedance: 4  – 8  Maximum power output: 55 W × 4 (at 4 )

General

Outputs:

Audio outputs terminal (REAR, SUB)

Power antenna (aerial)/Power amplifier

control terminal (REM OUT)

Inputs:

Remote controller input terminal

Antenna (aerial) input terminal

AUX input jack (stereo mini jack)

USB port Power requirements: 12 V DC car battery

(negative ground (earth)) Rated current consumption: 10 A Dimensions:

Approx. 178 mm × 50 mm × 177 mm

/8 in × 2 in × 7 in) (w/h/d)

Mounting dimensions:

Approx. 182 mm × 53 mm × 160 mm

/4 in × 2 1/8 in × 6 5/16 in) (w/h/d)

Mass: Approx. 1.2 kg (2 lb 11 oz)

Package contents:

Main unit (1) Remote commander (1): RM-X211 Parts for installation and connections

(1 set)

Your dealer may not handle some of the above listed accessories. Please ask the dealer for detailed information.

Design and specifications are subject to change without notice.

Copyrights

Windows Media is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.

This product is protected by certain intellectual property rights of Microsoft Corporation. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft or an authorized Microsoft subsidiary.

MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.

Android is a trademark of Google Inc.

libFLAC

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

– Redistributions of source code must retain

the above copyright notice, this list of conditions and the following disclaimer.

– Redistributions in binary form must

reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

15GB

+ 33 hidden pages

Sony CDX-G1200U Users guide [ko, en]

Specifications and Main Features

Frequently Asked Questions

User Manual
