Overview
SLET1000-H is a search bogey of the single-bus technology is another masterpiece, is a
strong drive capability of the humidity of remote digital acquisition system, according to different
needs, can be connected to 120-240 digital humidity sensor (a total of ten road, each up to
12-24 months) to RS232 mode or RS485 mode Ibid bit machine communication
Technical parameters
Sensors SLHT8
Display temperature
range
Display resolution
Measuring precision 4.5RH%
Temperature rate 4s (one cycle)
Channels 10 channels, each channel can connect up to 12-24 points
Baud Rate 9600 (other baud rate can be customized)
Communication port RS232 (optional CAN, RS485 or Ethernet)
Power supply DC 5V 1A
Power Consumption 5W
Weight 1000 grams
Storage temperature
Operating environment:
Support temperature
cable length
Dimensions 200×70×175mm3
-55℃～+125.0℃
0.1℃
-20 ～80℃
-40℃～+85℃
>350m
Features
1. To provide secondary development of communication protocol, to facilitate the
development of secondary
2. Sensor Collection Bus cabling, wiring simple and flexible.
3. Networking Easy, workstations have their own ID
4. Can be read into the sensor in real time
5. Can be read online a 64-bit unique serial number sensors humidity sensors
6. Measurement points 120-240 support a SLHT8
7. Optional strong drive sensor bus station up to 450 meters
Wiring
1. Power
This equipment uses the power supply DC5V, maximum voltage must not exceed
5.8V, 4.5V minimum voltage of not less than
Random distribution of the power supply DC5V 1A, if the sensors are more and
ShangHai Sonbest Industry Co,.Ltd Website：http://www.sonbest.com Page 2 Total 3
SLET1000-H Temperature Data Acquisition Workstation Operating Manual +086 021 51083595
lead longer, it is recommended to use the DC5V 2A-3A power supply.
Communication port
This machine comes standard communication interface RS232, RS485
communication when required, can be an external RS232/RS485 converter to
extend the communication distance, because equipment has a unique ID, the
machine is 01, an external RS232/RS485 conversion equipment immediately after
networking.
1. Sensor Interface
A three-wire sensor bus. See terminal block, VCC, GND power supply to the sensor.
DQn for the sensor channel number, the device has 10 channels, that is, DQ1,
DQ2, ... DQ10
The most common line is not greater than 300 meters long, if the communication
distance of more than 300 meters, it is recommended to use thicker wire core
twisted pair (signal line and ground on the cutter.)
Ordering and Selection
Product Name Model (order) Help
Universal
Humidity Data Acquisition
Workstation
SLET1000-H/120 Humidity support 120
SLET1000-H/160 Humidity support 180
SLET1000-H/200 Humidity support 200
SLET1000-H/240 Humidity support 240
Random list
No. Name Model Quantity Remarks
Humidity Data Acquisition
1
Workstation
Monolithic Power
2
Serial communication line
3
Data CD
4
Manual
5
SLET1000-H 1
5V 1A 1
1
1
1
