Snom D735 Datasheet
Snom D735 IP Phone - White (D735W)
Product Name: Snom D735 IP Phone - White (D735W)
Manufacturer: Snom
Model Number: D735W
Snom D735 IP Phone - White (D735W)
The Snom D735W white IP Phone is on the cutting edge, both technically and in terms of
appearance. The high-resolution 2.7” colour display is surrounded by eight multicoloured
function keys that you can label yourself. In order to constantly show the user all the important
information they could need, the Snom D735W has a built-in motion sensor – the first VoIP
telephone in the world to have such a feature!
Snom D735W Key Features
� High-resolution 2.7” graphical TFT display
� 32 self-labelling function keys (8 physical)
� Sensor technology enables responsive UI
� Wideband hands-free talking (speakerphone)
� Digital Signal Processor (DSP) enhanced audio quality
� 2-port Gigabit Ethernet switch (RJ45)
� Power over Ethernet IEEE 802.3af, Class 2
� USB headset ready
� D7 Expansion Module ready
� Support for USB WiFi stick
� Electronic Hook Switch (EHS) support for wireless headsets
� Dual-angle footstand: 46° and 28°
� Stylish white version
Created on: Wednesday 28 April, 2021
As soon as the user’s hand approaches the display or the function keys, the display
springs to life and automatically shows all the relevant key assignment information. When you
move your hand away again, the display reverts to its normal mode. This smart sensor expands
the functionality of the D735W enormously and supports the user in their day to day activities.
Of course, the Snom D735W also benefits from the tried and tested HD audio quality that has
become standard for our telephones. Thanks to this quality, you would be excused for thinking
that the person you’re talking to was sitting right next to you! This is made possible due to
the integrated ‘Digital Signal Processors’ (DSP), which optimise sound quality in
real time, filter out background noise and do so much more. Three-way conferences are also
possible with next to no effort.
The Snom D735W also has an integrated gigabit switch with Power over Ethernet (PoE)
functionality, as well as a USB port so you can swiftly connect accessories, like USB headsets, to
the device.
The Snom D735W is a compact all-rounder and is perfect for all possible uses thanks to its
modern and smart functions, as well as the timeless design and colour variants. The new
optimised firmware allows each user to forward calls at the touch of a button, initiate conference
calls or mute the telephone temporarily.
Snom D735W - Technical Specifications
Features
� 12 SIP identities / accounts
� XML browser
� Call lists for dialled, received, missed calls
� Local directory with 1000 entries
� Multiple language support
� DTMF in-band / out-of-band / SIP-INFO
� Interoperable with all major IP PBX platforms
www.voipon.co.uk | help@voipon.co.uk | Page 1/4
Snom D735 IP Phone - White (D735W)
Call Features
� Speed dialling
� URL Dialling
� Local dial plan
� Automatic redial on busy
� Call completion (busy/unreachable)(
� Caller identification
� Call waiting
� Call blocking (deny list)
� Auto answer
� Hold
� Music on hold
� Blind and attended transfer
� Call forwarding
� 3-way conferencing on the phone
� Extension monitoring, call pickup
� Call park, call unpark
� Multicast paging
� DND mode (do not disturb)
� Keyboard lock
� Client matter code (CMC)
� Unified Communications ready
Created on: Wednesday 28 April, 2021
Audio
� Codecs:
� G.711 A-law, µ-law
� G.722 (wideband) ·
� G.726, G.729AB, GSM 6.10 (FR)
� Built-in assignable ringtones
� Comfort Noise Generator (CNG)
� Voice Activity Detection (VAD)
Setup
� Configurable through a web interface
� Provisioning: Automatic loading of settings via HTTP/HTTPS/TFTP
� DHCP Options 66/67
� Snom Redirection Service
� Remote management via TR-069 / TR-111
Protocols
� SIP (RFC3261)
� DHCP, NTP
� HTTP / HTTPS / TFTP
� LDAP (Directory
� Dual Stack IPv4 / IPv6
User Interface
www.voipon.co.uk | help@voipon.co.uk | Page 2/4
