Read the User Manual before operating the
product, and keep the manual at a convenient
place near the product.
USER MANUAL
3dprinter.sindoh.com
DP201 Series
Directly plug the power cord in the receptacle on the wall. Do not use extension cord.
If the power cable or plug is worn or damaged, pull out the power plug.
The exposure of the interior of the machine can cause electrocution or burns.
Do not remove covers or screws other than specified in this manual.
Please be cautious. In the process of printing, the nozzle will maintain temperatures of over
100 degrees Celsius.
Do not place the machine in a highly moist environment as it may cause deformation and
malfunction of product.
Avoid contact of electrical terminal with metal product such as necklaces, coins, keys, watches, etc.
Do not hold the shaft for lifting or moving of the printer.
For the following situations turn off power and pull out the power plug
-
When in contact with liquid
-
When in need for a service or repair request
-
When the device cover is damaged
Method of disposal contact local service center or discard within befitting location.
Please turn off power when leaving the office after business hours or in circumstances where
machine is unoccupied for long periods of time, may cause abrupt fire accidents.
Protect device from humid or wet conditions eg. rain, snow, etc
Remove power cord from receptacle on the wall before moving device.
Be careful not to damage power cord while device is being translocated.
When removing the power cord, please pull the plug and not the power cable.
Be cautious of clips, staples and any other small metal objects from falling inside the device.
Please be cautious on safety when operating the interior of the machine, eg cleaning the interior.
Do not dispose of device or consumables in location of treating household waste.
In case of disposal, contact our company dealers or discard in fitting location.
Interior of device may be very hot, do not come in contact with the “Caution Hot” label or the
surrounding areas, may cause burns.
Our company’s product meets high quality standards and performance.
It is recommended to use genuine components only, components can be acquired from any
authorized distributors.
Safety Instructions
Warning:
Failure to observe the instructions may lead to death or serious injury.
Caution:
Failure to observe instructions may cause injuries or damages to property.
Be sure to observe the followIng instructions when using the device.
Firstly we at Sindoh truly thank you for your purchase of our product.
In this user manual, there will be detailed descriptions of the correct use of device and the simple
preparations of the device, maintaining the optimal state of the product at all times and contributing
to the rationalization and efficiency of the office work of your company.
Carefully read the user manual before using the device and keep close at hand.
In order to use device correctly and safely, please carefully note the precautions before use.
Before use
Prohibition and limitation on Duplication
1. This User Manual has been created for the convenience of the user, actual product may
differ from image and explanations shown.
2. The details of the user manual can be changed without a prior notice. Our company
is not responsible for the direct and/or indirect loss or damages caused by results of
handling or operating the product in any case and for results occurring from user’s
negligence.
3. The copyrighted literary works can be duplicated and used for personal use or household
use and within the same parameter. In other cases than the aforementioned, it is
prohibited by law.
4. The above details present only a part of the applicable laws and regulations. Details on
these laws/regulations may not be stated as they are. Our company is not responsible
for its correctness and completeness. Please consult a legal advisor to check if the object
you intend to print is legal.
5. User is responsible for all loss derived from modification of the product executed by the
user or third party.
6. Font used in the printer GUI and the user manual is the “NANUM” font provided by NAVER.
Before using the Machine
1. Preface -------------------------------------------------------------------------------------------------------------------------- 1
2. How to Read This Manual ------------------------------------------------------------------------------------------------2
2.1 Symbols ------------------------------------------------------------------------------------------------------------------------ 2
3. Safety Information ----------------------------------------------------------------------------------------------------------3
4. Precautions ------------------------------------------------------------------------------------------------------------------- 5
4-1 Installation ---------------------------------------------------------------------------------------------------------------------- 5
4-2 Moving the Machine ---------------------------------------------------------------------------------------------------------- 6
5. Consumables Handling ---------------------------------------------------------------------------------------------------7
6. Instructions for Use --------------------------------------------------------------------------------------------------------8
7. Ventilation ---------------------------------------------------------------------------------------------------------------------9
8. Notices ----------------------------------------------------------------------------------------------------------------------- 10
9. Disposal of Used Battery ---------------------------------------------------------------------------------------------- 13
10. Wifi Module Notice ------------------------------------------------------------------------------------------------------- 14
11. USB Memory Disclaimer ----------------------------------------------------------------------------------------------- 16
Chapter 1 Preparations for Machine Operation
1. Machine Specifications ------------------------------------------------------------------------------------------------ 1-2
1.1 Printing ----------------------------------------------------------------------------------------------------------------------- 1-2
1.2 Temperature/Speed ------------------------------------------------------------------------------------------------------ 1-2
1.3 Machine ---------------------------------------------------------------------------------------------------------------------- 1-2
1.4 Software/Support --------------------------------------------------------------------------------------------------------- 1-2
1.5 Default Setting of Print layer Width ----------------------------------------------------------------------------------- 1-2
2. Basic Components ------------------------------------------------------------------------------------------------------ 1-3
3. Designation of Parts ---------------------------------------------------------------------------------------------------- 1-4
4. Installation (Product connection, Cartridge Setup and includes Software Installation) -------- 1-6
4.1 Device Connection -------------------------------------------------------------------------------------------------------- 1-6
4.2 Program Installation ------------------------------------------------------------------------------------------------------ 1-6
5. Slicer Program Manual (Usage) ------------------------------------------------------------------------------------- 1-9
5.1 Standard Screen Manual ------------------------------------------------------------------------------------------------ 1-9
5.2 Functions and Information ----------------------------------------------------------------------------------------------1-10
Importing -------------------------------------------------------------------------------------------------------------------1-10
Profile Value Setting -----------------------------------------------------------------------------------------------------1-11
Filament Condition Indicator -------------------------------------------------------------------------------------------1-14
Contents
ⅰ
View Mode Selection Button ------------------------------------------------------------------------------------------1-14
Model Maneuvering ------------------------------------------------------------------------------------------------------1-15
Adjusting Model Size ----------------------------------------------------------------------------------------------------1-16
Model Rotation ------------------------------------------------------------------------------------------------------------1-16
Print ------------------------------------------------------------------------------------------------------------------------1-16
Basic Menu Bar -----------------------------------------------------------------------------------------------------------1-16
5.3 Printing (basic functions) -----------------------------------------------------------------------------------------------1-21
Loading 3D Model Files ------------------------------------------------------------------------------------------------1-21
Basic Parameter Setting ------------------------------------------------------------------------------------------------1-21
Slicing -----------------------------------------------------------------------------------------------------------------------1-22
Print ------------------------------------------------------------------------------------------------------------------------1-23
5.4 Advanced Features ------------------------------------------------------------------------------------------------------1-23
Support Edit Function ---------------------------------------------------------------------------------------------------1-23
3D Model Analysis Function -------------------------------------------------------------------------------------------1-27
Function to Calculate Optimal Printing Direction -----------------------------------------------------------------1-29
Chapter 2 UI Menu Function description
1. UI Menu Function description --------------------------------------------------------------------------------------- 2-2
1.1 CARTRIDGE ---------------------------------------------------------------------------------------------------------------- 2-3
LOAD ------------------------------------------------------------------------------------------------------------------------- 2-4
UNLOAD -------------------------------------------------------------------------------------------------------------------- 2-5
UNLOCK -------------------------------------------------------------------------------------------------------------------- 2-7
1.2 Settings -------------------------------------------------------------------------------------------------------------------2-10
X, Y, Z ----------------------------------------------------------------------------------------------------------------------- 2-11
EXTRUDER ---------------------------------------------------------------------------------------------------------------2-13
BED LEVELING ----------------------------------------------------------------------------------------------------------2-15
Z OFFSET -----------------------------------------------------------------------------------------------------------------2-17
NOZZLE CLEANING ----------------------------------------------------------------------------------------------------2-19
CLEANING CASE --------------------------------------------------------------------------------------------------------2-21
NETWORK ----------------------------------------------------------------------------------------------------------------2-22
LAMP ------------------------------------------------------------------------------------------------------------------------2-26
BED LOWERING ---------------------------------------------------------------------------------------------------------2-28
TEST PRINT ---------------------------------------------------------------------------------------------------------------2-29
POWER SAVING MODE -----------------------------------------------------------------------------------------------2-31
BEEP SOUND ------------------------------------------------------------------------------------------------------------2-32
NOZZLE SETTING ------------------------------------------------------------------------------------------------------2-34
ⅱ
LANGUAGE ---------------------------------------------------------------------------------------------------------------2-36
E-MAIL ----------------------------------------------------------------------------------------------------------------------2-38
UNIT ------------------------------------------------------------------------------------------------------------------------2-42
TIME SETTING -----------------------------------------------------------------------------------------------------------2-43
TIME ZONE ---------------------------------------------------------------------------------------------------------------2-45
WEB ------------------------------------------------------------------------------------------------------------------------2-46
SOFTWARE UPDATE --------------------------------------------------------------------------------------------------2-48
1.3 Information -----------------------------------------------------------------------------------------------------------------2-50
Chapter 3 Printing
1. Printing ---------------------------------------------------------------------------------------------------------------------- 3-2
1.1 Printing with USB Flash Drive ------------------------------------------------------------------------------------------ 3-2
1.2 Printing Via PC ------------------------------------------------------------------------------------------------------------- 3-6
1.3 Next print job -------------------------------------------------------------------------------------------------------------- 3-6
Chapter 4 Printable Verification
1. Printable Verification ---------------------------------------------------------------------------------------------------- 4-2
1.1 Detaching Printable ------------------------------------------------------------------------------------------------------- 4-2
1.2 Improving Printing Quality ---------------------------------------------------------------------------------------------- 4-4
2. Case of Power Outage ------------------------------------------------------------------------------------------------- 4-6
3. If problems persist. ----------------------------------------------------------------------------------------------------- 4-7
Chapter 5 Maintenance
1. Machine Cleaning ------------------------------------------------------------------------------------------------------- 5-2
1.1 Cleaning Case Maintenance ------------------------------------------------------------------------------------------- 5-2
1.2 Printer Interior Maintenance -------------------------------------------------------------------------------------------- 5-2
1.3 Periodical Inspection ----------------------------------------------------------------------------------------------------- 5-2
Oil/Grease Inspection ----------------------------------------------------------------------------------------------------- 5-2
2. Error Message and Solutions --------------------------------------------------------------------------------------- 5-3
3. Problems and Solutions ---------------------------------------------------------------------------------------------- 5-6
3.1 If filament is not excreted from the nozzle (Fix for EC401) ----------------------------------------------------- 5-6
3.2 In Cases where Filament between Extruder and Nozzle is Disconnected --------------------------------- 5-7
3.3 Incases, After Unloading Cartridge and Filament is Sticking Out of the Cartridge ----------------------- 5-7
ⅲ
4. Methods of Exchanging consumables -------------------------------------------------------------------------- 5-8
4.1 Exchanging Bed ----------------------------------------------------------------------------------------------------------- 5-8
Removing Flexible Bed -------------------------------------------------------------------------------------------------- 5-8
Installing Flexible Bed ---------------------------------------------------------------------------------------------------- 5-8
4.2 Exchanging Cartridge --------------------------------------------------------------------------------------------------- 5-8
4.3 Exchanging Nozzle ------------------------------------------------------------------------------------------------------- 5-9
Methods of Detaching Nozzle ------------------------------------------------------------------------------------------ 5-9
Assembling the Nozzle -------------------------------------------------------------------------------------------------5-11
Chapter 6 Appendix
1. Consumables Category (Material, Color) ----------------------------------------------------------------------- 6-2
ⅳ
1
Before using the Machine
1. Preface
This User Manual describes detailed explanations and points to note in connection with operating and using the
machine. Please read the User Manual well enough for users` safety and ease of use before using machine,
and keep it near within your reach to refer to it quickly later.
- The content of the User Manual is subject to change without any prior notification.
Sindoh shall not be responsible for any consequent damages or losses, indirect, special,
contingent handling or operations of the machine in whatsoever.
-
Copyrighted works can be printed and used within the range of equivalent or similar to personal use or
other household use; otherwise it may be prohibited by law.
-
The above details present only a part of the applicable laws and regulations and the details of the law
may not be stated as they are. Our company is not responsible for its correctness and completeness.
Please consult your legal advisor to check if the object you intend to print is legal.
- The User Manual may include a little different descriptions of the machine from the actual one.
Some options may not be usable depending on the countries. Please consult your local sales/distributor
office for the above cases. Some units can be an optional based on in which country you are now.
Please consult your local service/support office.
-
In some countries some specific types may not be used.
Please consult your local sales office.
-
This User Manual uses two measuring units and the metric unit is applicable for this machine.
Before using the Machine
2
2. How to Read This Manual
2.1 Symbols
This manual uses the following symbols and meanings.
- Indicates importance safety notes.
Ignoring these notes could result in serious injury or death.
Be sure to read these notes carefully for your safe operations of the machine.
- Indicates important safety notes.
Ignoring these notes could result in minor injury, or damage to the machine or to property.
Be sure to read these notes for your safe operations of the machine.
- Indicates points to pay attention to when using the machine, and explanations of likely causes of paper
misfeeds, damage to originals, or loss of data.
Be sure to read these explanations
- Indicates supplementary explanations of the machine`s functions, and instructions on resolving user errors.
- This symbol is located at the end of sections. It indicates where you can find further relevant information.
[ ]
Indicates the messages or menus that appear on the machine`s LCD display panel.
Indicates the names of each function key on the machine control panel and the display window.
3
Before using the Machine
3. Safety Information
Plug the power cord into a properly grounded outlet which is near and quickly accessible from the machine.
Do not use or place the machine in wet or humid environment.
Hot Surface
- The inside of the machine may be hot. To reduce the risk of injury from a hot
component, allow the surface to cool before touching it.
(Please be cautious of getting burns during printing as the Nozzle
will maintain a high temperature of over 100 degrees.)
-
Do not put any portion of your body or objects during machine operation,
as the motor can be in very high temperature and can cause burns/injuries. Please be cautious.
-
When the power is on, do not let any of your body touch the machine except the bed.
-
If you have to touch the machine, please do so after the nozzle temperature have been
lowered to room temperature.
Electrocution
- Proceed your work after turning off the machine and unplugging the power cord
from the outlet in case of accessing the system board, or installing hardware or
optional memory devices after having already installed machine. If the machine is
connected with any other device, turn it off and separate the cables from the machine.
-
This product has been designed, tested and approved to meet strict safety requirements
of international safety standard. Some safety features of parts may not clearly work.
The corresponding manufacturer of the machine shall not be responsible for usage of any
other replacement parts.
-
Disconnect the power cord and all the cables connected to the machine to prevent from any
electrical shock when cleaning the outside or inside of the machine.
Injuries
- Do not twist, fold, step or place heavy objects on the powercord.
-
Be careful with the power cord peeled off or overloaded.
-
Do not make the power cord jammed into objects such as furniture or walls.
-
Misusing the cord could result in fire or electrical shock.
-
Check the cord regularly. Unplug the cord from the outlet for inspection.
-
Please consult a licensed electrician for services or repairs not stated in this User Manual.
Before using the Machine
4
Injuries
- To prevent personal injuries or damages to the machine, you need to
follow the below instructions before moving the machine.
Do not open the front and top door during machine operation.
When the power is on, do not let any of your body touch the machine
except the bed.
If you have to touch any parts other than the bed, please do so after turning the
power off, removing the power cord from the plug and after the nozzle
temperature have been lowered to room temperature.
Turn the power switch off, then unplug the power cord from the power outlet.
Unplug and release all the cords and cables before moving the machine.
Only use the power cords provided with this machine or cords that are approved by the manufacturer.
Do not put any portion of your body or objects during machine operation, as the bed, motor, nozzle
will be in operation and moving. Small objects such as neckless, hair, etc may cause personal injuries
or damages to the machine.
If any problems occur(malfunction, body part being caught inside the machine, etc) during machine
operation, quickly press the pause
or stop button located on the top right side of the
machine.
Nozzle
Bed UI
5
Before using the Machine
4. Precautions
Please comply with the following instructions and the “Safety Information” provided with the purchase of this
product.
4.1 Installation
- Install the machine in a well ventilated area.
Odor may be emitted during machine operation. It should not be harmful; however, if the area of
where the machine is located is not ventilated, make sure to ventilate the area appropriately time to time.
- Install the machine with its vents spaced at least 10 cm away from walls and other equipments.
Secure properly sufficient space around the machine for easy ventilation and operation.
Use the machine at temperatures of 16
~ 29 and relative humidity of 20% ~ 70%.
Do not install or use the machine outdoor.
100 mm
100 mm
100 mm
680 mm
100 mm
100 mm
Before using the Machine
6
4.2 Moving the Machine
- Before moving the machine, be sure to unplug the power cord from the outlet.
When moving the printer, it is recommended that two people lift and move the printer for safety.
-
Hold the bottom handles of the machine when moving it.
Bend your knees enough to protect your spine when lifting the machine.
Handle
Handle
7
Before using the Machine
5. Consumables Handling
- Do not burn the Cartridge unit or filament. It may be a cause of big fire or burn by ignition.
- Keep them out of the reach of children.
-
If skin irritation occurs after touching the filament, please see a doctor.
- Do not keep the cartridge unit in a place.
Exposed to fire
Exposed to direct sunlight;
Where temperature or humidity may rise;
Where sharp change of temperature may occur;
Covered with dust;
Cases of storing cartridge in motor vehicle for periods of time.
-
Keep cartridges away from physical impact or vibration.
-
Do not unpack cartridges until you are just ready to use them.
Before using the Machine
8
6. Instructions for Use
- The nozzle inside the machine is very hot during machine operation.
Please be cautious not to touch the nozzle during removal of the printed objected or during
inspection of the machine inside. It may become the cuase of injuries or burns.
-
Never make the Machine operated in the way of not being specified in this USER MANUAL.
Notification for California customers, USA
- This product contains chemicals known to the State of California to cause cancer and birth defects or
other reproductive harm. This appliance and its accessories can cause low-level exposure to chemicals
during operation, which can be reduced by operating the appliance in a well ventilated area, and
low-level exposure to chemicals through other user or handling.
9
Before using the Machine
7. Ventilation
- Use the machine in a place with good ventilation. If the machine is used in a place without good
ventilation, this may be harmful for your health. Ventilate it at regular basis.
-
Do not block vents. Inappropriate cooling may lead to high temperatures inside the machine,
-
In general, a new machine may produce small amount of gaseous components, so provide good
ventilation for the first period of use. If the machine is planned for a long operation time, it is
recommended that users should not be located in the same location as the printer for long periods
of time.
Before using the Machine
10
8. Notices
Noise Emission Level
The following are measured in accordance of ISO 7779 and reported to meet ISO 9296.
Some modes may not be available in your purchased products.
Average Sound Pressure at 1 Meter Away
Printing 53dBA(Normal Print Condition - Printing speed 40 mm/s, Travel speed 150 mm/s)
Standby under 40 dBA
Temperature/Humidity
Operation 16 ℃ ~ 29 ℃ 20%RH~70%RH
Shipping -30 ℃ ~ 50 ℃, 15%RH~95%RH(Must be above 0 ℃ outdoor temp., must not touch the floor)
Storage -30 ℃ ~ 50 ℃, Below 80%RH(Dew condensation must not be formed, must not touch the floor)
Disposal of The Products
Do not dispose the machine and consumables in the same way as normal garbage.
For disposal or recycling, contact your local sales office.
EMI(Electromagnetic Interference) Notice
This machine complies with the limits for Class B.
Class B (Home Device): This device is designated to Class B. This equipment can be used in all areas
including residential area as it has obtained EMC registration for household use.
FCC COMPLIANCE STATEMET
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
Including interference that may cause undesired operation.
INFORMATION TO USER
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one m ore of the following
measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-
Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Any changes or modifications not expressly approved by the manufacturer responsible for compliance could
void the user’s authority to operate the equipment.
DECLARATION OF CONFORMITY (DOC Letter): 12page
11
Before using the Machine
Wireless LAN Specifications
The competent wireless device may be affected by electromagnetic interference so it should
not be used for life saving services.
WLAN Notice
Exposure to radio frequency radiation
The following notice is applicable if your printer has a wireless network card installed.
The radiated output power of this device is far below the FCC radio frequency exposure limits.
A minimum separation of 20 cm (8 inches) must be maintained between the antenna and any persons for
this device to satisfy the RF exposure requirements of the FCC.
Power Consumption
Power Consumption of the Products
The below table shows power consumption.
Mode Description Power Consumption(W)
Printing A device is printing documents from electronic input data. 70W
Standby A device is standing by print jobs. 12W
Power Off A power plug is plugged into the outlet with its switch off . 0.05W
The above power consumption is the hourly average value.
Instant power consumption can be much higher than the average value.
Deactivated Mode
The machine consumes power even in the deactivated mode. Unplug the power cord to stop the power
consumption to the full.
Total Energy Usage
It would be useful to calculate the Total energy usage of the machine.
Since the electricity bill is charged by Watt, you have to multiply time spent in each mode with power
consumption in order to calculate the energy use.
Total energy usage is the sum of energy used in each mode.
Condensation
Dramatic change of the ambient temperature may produces water droplets on the interior and exterior of the
machine. Wipe the water droplets on the outer surface, but for the inside please wait until the dropletss on the
interior dry off by having the front door or upper door open.
Before using the Machine
12
13
Before using the Machine
9. Disposal of Used Battery
Control board consists of Lithium Batteries which are located within the machine.
Please discard used batteries following the environmentally friendly procedure stated on the manufacturer guidelines.
To replace batteries, please contact manufacturer service engineer.
Before using the Machine
14
10. Wifi Module Disclaimer
This Product contains the Wi-Fi module that is only compatible with below Sindoh models
DP201, DP202
Wifi module is
here(inside).
Precautions
This Wifi module can cause radio interference, therefore it should not be used for any purposes related to
human lives.
Do not expose this product to water, humidity or liquid.
Do not expose this product to direct light, hot temperature or fire.
- Changes or modifications that are not specified by manufacturer can void user’s authority to operate
equipment.
- Antenna shall be mounted in such a manner to minimize the potential for human contact during normal
operation. The antenna should not be contacted during operation to avoid the possibility of exceeding
the FCC radio frequency exposure limit.
15
Before using the Machine
Precautions
Frequency
IEEE 802.11b : 2400MHz ~ 2484MHz
IEEE 802.11g : 2400MHz ~ 2484MHz
IEEE 802.11n(20MHz) : 2400MHz ~ 2483MHz
IEEE 802.11n(40MHz) : 2400MHz ~ 2483MHz
Antenna Power Density IEEE 802.11b : 10mW(10dbm)/MHz
IEEE 802.11g : 10mW(10dbm)/MHz
IEEE 802.11n(20MHz) : 10mW(10dbm)/MHz
IEEE 802.11n(40MHz) : 10mW(10dbm)/MHz
No. of Channels IEEE 802.11b : 14
IEEE 802.11g : 14
IEEE 802.11n(20MHz) : 14
IEEE 802.11n(40MHz) : 9
Modulation IEEE 802.11b : DSSS/CCK
IEEE 802.11g : OFDM
IEEE 802.11n(20MHz) : OFDM
IEEE 802.11n(40MHz) : OFDM
Power Consumption 5V 500mA(Maximum)
Dimension 37.0mm X 28.0mm X 3.7 mm
Operation Temperature 0 ~ 60 ℃
Storage Temperature -10 ~ 80 ℃
Before using the Machine
16
11. USB Memory Disclaimer
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
INFORMATION TO USER
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one more of the following measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-
Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Any changes or modifications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
Specification of compatible USB flash drive for 3DWOX
- Please use the enclosed USB flash drive.
-
The enclosed USB flash drive is in FAT32 (File Allocation Tables) format.
The 3DWOX does not support USB flash drives in NTFS (New Technology File System) format.
-
The warranty will not be guaranteed if the enclosed flash drive is not used.
17
Before using the Machine
IC Identification on Class of ITE
CAN ICES-3 (B)/NMB-3 (B)
DECLARATION OF CONFORMITY
Product name : USB Flash Drive
Model name : 8GB-WJ004, 4GB-WJ004
FCC Rules : Tested to comply with FCC Part 15, Class B
Operating Environment : For HOME OR OFFICE USE
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
RESPONSIBLE PARTY
Name : Sindoh America, Ltd.
Address : 6047 Tyvola Glen Circle, Suite #115, Charlotte, NC 28217
Phone No. : 1-704-414-6690
We hereby declare that the above specified equipment with the trade name and model number
was tested conforming to the applicable FCC Rules under the most accurate measurement
standards possible, and that all the necessary steps have been taken and are in force to assure
that production units of the same equipment will continue to comply with the Commission’s requirements.
Manufacturer : Sindoh Co., Ltd.
Address : 3, Seongsuiro24(isipsa)-gil, Seongdong-gu, Seoul, 133-705 REPUBLIC OF KOREA
1
Preparations for
Machine Operation
DP201 Series
USER MANUAL
Preparations for Machine Operation
1-2
1
1. Machine Specifications
1.1 Printing
Printing Method Fused Filament Fabrication
Printable Lengths(mm) W(max):210, D(max):200, H(max):189
Print Layer Thickness Setting 0.05~0.4mm
Basic Nozzle diameter 0.4mm
Filament width 1.75mm
Printable materials PLA
Printable color White, Black, Gray, Red, Yellow, Green, Blue
Bed leveling Auto measuring + Manual leveling
1.2 Temperature/Speed
Continuous Nozzle Usage/ Maximum Temperature 200 ℃ Recommended / 230 ℃ max
Recommended printing speed/maximum speed 40mm/s Recommended / 200mm/s max
* Continuous operation at maximum temperature can cause machine to malfunction, only use when case of nozzle
blockage or any other troubleshoots.
1.3 Machine
Power 70W
Body Dimensions 421 x 433 x 444
Body Weight 15kg
Supported Connection Port USB, Wifi, Ethernet
Cartridge Auto Load / Unload
1.4 Software/Support
Supported Software Sindoh Exclusive Slicer
Supported File Format *.stl, *.ply, *.obj
Supported Operating System Windows 7 or above, Mac OSX 10.10 or above
Recommended Memory Requirements 4GB + DRAM
- Graphic card must support OpenGL 2.0 or above.
1.5 Default Setting of Print layer Width
Nozzle Width 0.4mm
Print Layer Width 0.2mm
1-3
Preparations for Machine Operation
1
2. Basic Components
Please check all basic components are in the box.
- Box is required for making exchanges / A/S. Do not dispose of box.
3D Printer
USB Cable
Cartridge
USB Drive Simple Installation Guide
Power Cable
Ferrite Core
Preparations for Machine Operation
1-4
1
3. Designation of Parts
1
6
7
8
9
10
2
3
4
5
<Front> <Rear>
No. Designation Explanation
1 Front hatch handle Use front door hatch handle to open the front door.
2 USB flash drive port Connect USB flash drive containing printing information and print directly from
USB flash drive.
3 LCD Control panel Screen used to control printer.
-
Usage of printer is recommended after removing the protection film on LCD control panel.
If the printer is used without remvoing the protection film, the touch screen may not work
properly.
4 Power Button Hold button short to turn on printer Hold button long (More than 2 seconds) to turn
off printer.
Power Button
Signals
Light Power Button Power is On.
1 second interval flickering Turning on power is available. (Only power cable
is connected)
-
If in case of not using the printer for long period of
time, please unplug the machine.
-
Removing power cord can cause flickering for a short
period of time.
Off Inactive Mode. (Power cord is unplugged)
5 Top hatch handle Use handle to open top hatch.
6 Exhaust fan Ventilates heat from interior.
7 Lan Port Connect using LAN cables, to connect to network.
8 USB Port Used to connect printer to computer through USB cable.
9 Power port Connect power cord.
10 Carrier Handles Handles to use Incases of moving the machinery.
Loading...
