Sharp XL-DAB9H User Manual

MIKRO KOMPONENTEN SYSTEM MICRO-CHAÎNE SISTEMA MICRO MIKRO KOMPONENT SYSTEM MICRO SISTEMI MICRO SYSTEEM SISTEMA DE MICRO COMPONENTE MICRO COMPONENT SYSTEM

MODELL MODÈLE MODELO MODELL

MODELLO MODEL MODELO MODEL

XL-DAB9H

Mikro Komponenten System XL-DAB9H besteht aus XLDAB9H (Hauptgerät) und CP-DAB9H (Lautsprechersystem).

Micro-chaîne XL-DAB9H composée de XL-DAB9H (appareil principal) et CP-DAB9H (enceinte acoustique).

Sistema micro XL-DAB9H que consta de XL-DAB9H (aparato principal) y CP-DAB9H (sistema de altavoces).

XL-DAB9H mikro komponent system bestående av XL-DAB9H (huvudenhet) och CP-DAB9H (högtalarsystem).

Micro sistemi XL-DAB9H composto da XL-DAB9H (apparecchio principale) e CP-DAB9H (sistema di diffusori).

XL-DAB9H micro systeem bestaande uit XL-DAB9H (hoofdtoestel) en CP-DAB9H (luidsprekersysteem).

XL-DAB9H Sistema de Micro Componente com posto de XLDAB9H (unidade principal) e CP-DAB9H (sist ema de alto-falante).

XL-DAB9H Micro Component System consisting of XL-DAB9H (main unit) and CP-DAB9H (speaker system).

DEUTSCH

Siehe Seiten i bis x und D-1 bis D-38.

FRANÇAIS

Se reporter aux pages i à x et F-1 à F-38.

ESPAÑOL

Consulte las páginas i a x y S-1 a S-38.

SVENSKA

Hänvisa till sidorna i till x och V-1 till V-38.

ITALIANO

Leggere le pagine i a x e I-1 a I-38.

BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUAL DE MANEJO BRUKSANVISNING

MANUALE DI ISTRUZIONI GEBRUIKSAANWIJZING MANUAL DE OPERAÇÃO OPERATION MANUAL

05/7/12 XL-DAB9H(H)_FRONT.fm

NEDERLANDS

Raadpleeg de bladzijden i t/m x en N-1 t/m N-38.

PORTUGUÊS

Consulte as páginas i a x e P-1 a P-38.

ENGLISH

Please refer to pages i to x and E-1 to E-38.

TINSZA071SJZZ

XL-DAB9H

BESONDERE ANMERKUNGEN REMARQUES SPÉCIALES NOTAS ESPECIALES SÄRSKILDA ANMÄRKNINGAR NOTE PARTICOLARI BIJZONDERE OPMERKINGEN NOTAS ESPECIAIS SPECIAL NOTES

● Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG.

● Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/ 68/CEE.

● Este aparato satisface las exigencias de las Directivas 89/336/CEE y 73/23/CEE, modificadas por medio de la 93/ 68/CEE.

● Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/ EEC och 73/23/EEC så som kompletteras av 93/68/EEC.

● Quest’apparecchio è conforme ai requisiti delle direttive 89/ 336/EEC e 73/23/EEC, come emendata dalla direttiva 93/68/ EEC.

● Dichiarazione di conformità

La società SHARP ELECTRONICS EUROPE GmbH dichiara che il prodotto SHARP MINI SISTEMI CD-XP300H è costruito in conformità alle prescrizioni del D.M.n˚548 del 28/8/95, pubblicato sulla G.U.n˚301 del 28/12/95 ed in particolare è conforme a quanto indicato nell’art. 2, comma 1 dello stesso decreto.

● Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/ EEG en 73/23/EEG, gewijzigd door 93/68/EEG.

● Este equipamento obedece às exigências das directivas 89/ 336/CEE e 73/23/CEE, na sua versão corrigida pela directiva 93/68/CEE.

● This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/ EEC.

MICRO SISTEMI XL-DAB9H

● Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med tillaeg nr. 93/68/EEC.

● Dette produktet oppfyller betingelsene i direktivene 89/336/ EEC og 73/23/EEC i endringen 93/68/EEC.

● Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita on muutettu direktiivillä 93/68/EEC.

●

● Bei Einstellung der ON/STAND-BY-Taste auf STAND-BY ist

die Netzspannung immer noch im Gerät vorhanden. Wenn die ON/STAND-BY-Taste auf STAND-BY eingestellt wird, kann das Gerät unter Verwendung der T imer-Betriebsart oder Fernbedienung in Betrieb gesetzt werden.

Warnung:

In diesem Gerät sind keine vom Benutzer wartbaren Teile vorhanden. Niemals Abdeckungen entfernen, außer wenn Sie dafür qualifiziert sind. In diesem Gerät sind gefährliche Spannungen vorhanden. Vor Ausführung von irgendwelchen Kundendienstarbeiten oder bei längerer Nichtverwendung des Gerätes stets den Netzstecker aus der Netzsteckdose ziehen.

● Lorsque la touche ON/STAND-BY est mise en STAND-BY, l’appareil est toujours sous tension. Lorsque la touche ON/STAND-BY se trouve sur la position STAND-BY, l’appareil est prêt à fonctionner par la minuterie ou la télécommande.

Avertissement:

Cet appareil contient des pièces non réparables par l’utilisateur. Personne non qualifiée n’enlèvera jamais les couvercles. L’appareil contenant des organes portés à haute tension, débrancher l’appareil avant toute réparation ou en période de non-utilisation.

0203

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

● Cuando el botón ON/STAND-BY está puesto en la posición STAND-BY, todavía hay tensión dentro del aparato. Cuando el botón ON/STAND-BY está puesto en la posición STAND-BY, el aparato puede ponerse en funcionamiento utilizando el modo del temporizador o el controlador remoto.

Advertencia:

Tenga en cuenta que dentro de este aparato no hay piezas que pueda reparar. No quite nunca las tapas a menos que se esté cualificado para hacerlo. Este aparato tiene en su interior tensiones peligrosas. Desenchufe siempre la clavija de la red del tomacorriente antes de realizar cualquier servicio de mantenimiento y cuando no se use el aparato durante un largo período de tiempo.

● När ON/STAND-BY knappen är i läge STAND-BY, finns nätspänning i apparaten. Med ON/STAND-BY knappen i läge ST AND-BY kan apparaten startas med timerfunktion eller fjärrkontrollen.

Varning:

Apparaten innehåller inga delar som kan åtgärdas av kunden. Höljet får endast öppnas av kvalificerad personal. Apparaten innehåller farliga spänningar. Stickkontakten ska därför dras ut från nätuttaget före reparationsarbeten och bör dras ut om apparaten inte ska användas på mycket länge.

● Quando il tasto ON/STAND-BY si trova in posizione STANDBY, all’interno dell’apparecchio c’è ancora la corrente. Se il tasto ON/STAND-BY si trova nella posizione STANDBY, l’unità può essere accesa con il modo timer o con il telecomando.

Avvertenza:

L’apparecchio non contiene parti riparabili dall’utente. Non togliere mai i coperchi, a meno di non essere qualificati per farlo. All’interno dell’apparecchio ci sono tensioni pericolose, per cui si deve sempre staccare la spina del cavo d’alimentazione dalla presa di corrente prima di qualsiasi intervento di manutenzione e quando non si usa l’apparecchio per un lungo periodo di tempo.

● Wanneer de ON/STAND-BY toets in de STAND-BY stand staat, loopt er nog steeds stroom (netspanning) in het toestel. Wanneer de ON/STAND-BY toets in de STAND-BY stand staat, kan het toestel ingeschakeld worden via de timerfunctie of de afstandsbediening.

Waarschuwing:

Dit toestel bevat geen door de gebruiker te repareren onderdelen. Verwijder de behuizing nooit tenzij u deskundig bent op dit gebied. In het toestel loopt een gevaarlijke spanning; haal de stekker altijd uit het stopcontact alvorens onderhoud uit te voeren of wanneer het toestel voor langere tijd niet gebruikt wordt.

● Quando o botão ON/STAND-BY estiver ajustado na posição STAND-BY, a voltagem de alimentação ainda se encontra presente dentro do aparelho. Quando o botão ON/STAND-BY estiver ajustado na posição STAND-BY, o aparelho pode ser colocado em operação através do modo de programação horária ou pelo controle remoto.

Advertência:

Neste aparelho não há partes que podem ser consertadas pelo usuário. Nunca retire a tampa, a menos que você tenha qualificação para tal. Este aparelho contém voltagens perigosas. Remova sempre o cabo de alimentação da tomada antes de efetuar qualquer conserto ou quando deixar o aparelho muito tempo fora de uso.

● When the ON/STAND-BY button is set at STAND-BY position, mains voltage is still present inside the unit. When the ON/STAND-BY button is set at STAND-BY position, the unit may be brought into operation by the timer mode or remote control.

Warning:

This unit contains no user serviceable parts. Never remove

covers unless qualified to do so. This unit contains dangerous voltages, always remove mains plug from the socket before any service operation and when not in use for a long period.

0203

XL-DAB9H

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

XL-DAB9H

● Når ON/STAND-BY-knappen er sat i STAND-BY positionen, er der stadig netspaending til stede i apparatet. Når ON/STAND-BY-knappen er sat i STAND-BY position, kan apparatet startes v.hj.a. fjernbetjeningen.

Advarsel:

Apparatet indeholder ingen dele, der kan repareres af brugeren selv. Fjern aldrig kabinettet med mindre De er kvalificeret hertil. Apparatet indeholder farlig strømspaending. Traek altid stikket ud af stikkontakten før der foretages reparationer, eller hvis apparatet ikke er i brug i laengere tid.

DENNA APPARAT ÄR ANSLUTEN TILL 230 V VÄXELSTRÖM NÄR STICKPROPPEN ÄR INSKJUTEN I VÄGGUTTAGET. FÖR ATT FULLSTÄNDIGT KOPPLA IFRÅN APPARATEN, V.G. DRAG UT STICKPROPPEN.

● Vorsicht:

Das Gerät weder Tropf- noch Spritzwasser aussetzen. Ansonsten besteht die Gefahr eines Brandes oder elektrischen Schlages. Es dürfen keine mit Flüssigkeiten gefüllten Gegenstände wie Vasen auf dem Gerät abgestellt werden.

● Attention:

Pour éviter un incendie ou une secousse électrique, mettre l’appareil à l’abri de l’eau (éclaboussure, goutte). Ne pas poser sur l’appareil un récipient contenant du liquide.

● Advertencia:

Para evitar incendios y descargas eléctricas, no exponga el aparato a goteo o salpicadura de líquidos. No deberán ponerse encima del aparato objetos que estén llenos de líquido, como por ejemplo un florero.

● Varning:

Utsätt inte enheten för dropp eller stänk för att förhindra brand eller elektriska stötar. Inga vätskefyllda föremål såsom vaser får placeras på enheten.

● Attenzione:

Per prevenire incendi o scosse elettriche, non fare gocciolare nessun liquido sull’apparecchio e non bagnarlo. Non collocarvi sopra nessun oggetto riempito d’acqua, come per esempio vasi.

● Waarschuwing:

Stel het toestel niet bloot aan druipend of spattend water om brand en elektrische schokken te voorkomen. Met vloeistoffen gevulde voorwerpen, zoals vazen, mogen niet op het toestel geplaatst worden.

● Cuidado:

Para evitar incêndio ou choque elétrico, não exponha este aparelho a gotejamento ou salpicamento de água. Não coloque objetos com água como, por exemplo, um vaso de flores, em cima do aparelho.

● Warning:

To prevent fire or shock hazard, do not expose this appliance to dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus.

iii

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

● Advarsel:

Til at forbygge ild og stød risiko, lad vaere med at undsaette denne indretning for drypning eller overstaenkning. Der må ikke anbringes nogen genstande fyldt med vand, som for eksempel vaser, på dette apparat.

● Advarsel:

For å unngå brann eller kortslutning, utsett ikke produktet for vann eller fuktighet. Gjenstander som inneholder vaeske, feks. en blomstervase, må ikke plasseres oppå apparatet.

● Varoitus:

Älä vie laitetta sateeseen tai kosteisiin tiloihin. Jos laite on kostunut, anna sen kuivua ennen kuin käytät sitä verkkovirralla. Nestettä sisältäviä astioita kuten esim. kukkamaljakoita ei saa asettaa laitteen päälle.

Dieses Produkt ist ein Laserprodukt der Klasse 1. Ce produit est classifié comme étant un LASER DE CLASSE 1. Este producto está clasificado como un PRODUCTO LÁSER DE

CLASE 1. Denna produkt klassificeras som KLASS 1 LASERPRODUKT. Questo prodotto è classificato come CLASS 1 LASER PRODUCT. Dit product is geclassificeerd als een KLASSE 1 LASER PRODUCT. Este produto é classificado como PRODUTO LASER DE CLASSE 1. This product is classified as a CLASS 1 LASER PRODUCT.

Dette produktet er klassifisert som et KLASSE 1 LASERPRODUKT. Dette produkt er klassificeret som et KLASSE 1 LASERPRODUKT. Tämä laite on luokiteltu LUOKAN 1 LASERLAITTEEKSI. Denna produkt klassificeras som KLASS 1 LASERAPPARAT.

0402_A5_2

XL-DAB9H

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

XL-DAB9H

● VORSICHT

Verwendung von Regelungen oder Einstellungen bzw. Durchführung von anderen Verfahren als die hierin angegebenen kann zum Aussetzen gefährlicher Strahlung führen.

Da der in diesem Compact Disc Player verwendete Laserstrahl für die Augen schädlich ist, ist das Gehäuse unter keinen Umständen zu zerlegen. Wenden Sie sich für Wartungsarbeiten nur an berechtigten Fachhändler.

● ATTENTION

Respecter les indications données relatives à la manipulation, au réglage et au fonctionnement. En cas de non-respect, on s’exposera à une radiation dangereuse.

Éviter absolument de démonter l’appareil, qui utilise un rayon laser nuisible aux yeux. Pour toute réparation, s’adresser à une personne qualifiée.

● PRECAUCIÓN

El uso de los controles, ajustes o ejecución de procedimientos distintos de los especificados podría causar la exposición a radiación peligrosa.

No intente desmontar la caja ya que el haz de láser usado en este reproductor de discos compactos es perjudicial para los ojos. Para el servicio de reparación, consulte a una persona cualificada.

● OBSERVERA

Användning av reglage eller justeringar eller handhavande på annat sätt än som anges kan leda till farlig bestrålning.

Försök inte ta isär höljet eftersom CD-spelarens laserstråle är skadlig för ögonen. Överlåt service endast till kvalificerad personal.

● ATTENZIONE

L’uso dei comandi e l’effettuazione di regolazioni e procedimenti diversi da quelli specificati nel manuale possono provocare una pericolosa esposizione alle radiazioni.

Poiché il raggio laser usato in questo giradischi può danneggiare gli occhi, non smontare l’apparecchio. Per le riparazioni rivolgersi a personale specializzato.

● LET OP

Gebruik van regelaars, het maken van instellingen, gebruik of handelingen anders dan in deze gebruiksaanwijzing vermeld, kan gevaarlijke straling blootleggen.

De laserstraal in deze CD-speler kan de ogen beschadigen, Probeer derhalve de ombouw niet te verwijderen. Laat reparaties alleen over aan erkend onderhoudspersoneel.

● CUIDADO

O uso de controles, ajustes ou a execução de procedimentos além daqueles especificados aqui pode resultar em perigosa exposição à radiação.

Como os raios laser usados neste player de CD são perigosos para os olhos, não tente desmontar o aparelho. Solicite o conserto somente para pessoas especializadas.

● CAUTION

Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

As the laser beam used in this compact disc player is harmful to the eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only.

0203

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

Eigenschaften der Laserdiode

Material: GaAIAs Wellenlänge: 780 nm Emissionsdauer: kontinuierlich Laser-Ausgang: max. 0,6 mW

Caractéristiques de la diode laser

Matière: GaAIAs Longueur d’onde: 780 nm Durée d’émission: ininterrompue Puissance de sortie laser maximale: 0,6 mW

Características del diodo láser

Material: GaAIAs Longitud de onda: 780 nm Duración de emisión : continua Salida de láser: máx. 0,6 mW

Laserdiodens egenskaper

Material: GaAIAs Våglängd: 780 nm Utstrålningsvaraktighet: kontinuerlig Lasereffekt: max. 0,6 mW

Proprietà del diodo laser

Materiale: GaAIAs Lunghezza d’onda: 780 nm Durata di emissione: continua Uscita massima del laser: 0,6 mW

Laser diode specificaties

Materiaal: GaAIAs Golflengte: 780 nm Stralingsduur: doorlopend Laseruitgang: max. 0,6 mW

Propriedades do diodo laser

Material: GaAlAs Comprimento de onda: 780 nm Duração da emissão: contínua Saída de laser: máx. 0,6 mW

Laser Diode Properties

Material: GaAIAs Wavelength: 780 nm Emission Duration: continuous Laser Output: max. 0.6 mW

XL-DAB9H

ADVARSEL-USYNLIG LASERSTRÅLING VED ÅBNING. SE IKKE IND I STRÅLEN-HELLER IKKE MED OPTISKE INSTRUMENTER.

VARO! AVATTAESSA OLET ALTTIINA NÄKYMÄTÖN LASERSÄTEILYLLE. ÄLÄ TUIJOTA SÄTEESEEN ÄLÄKÄ KATSO SITÄ OPTISEN LAITTEEN LÄPI.

VARNING-OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD. STIRRA EJ IN I STRÅLEN OCH BETRAKTA EJ STRÅLEN GENOM OPTISKT INSTRUMENT.

VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.

VARNING - OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA BRUKSANVISNING SPECIFICERAS. KAN ANVÄNDAREN UTSÄTTAS FÖ R OSYNLIG LASERSTRÅLNING, SOM ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1.

0408_A5 (3A_CD)

0203

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

XL-DAB9H

vii

Entsorgungsinformationen

A. Entsorgungsinformationen für Benutzer aus

Privathaushalten

1. In der Europäischen Union

Achtung: Werfen Sie dieses Gerät zur Entsorgung bitte nicht in den normalen Hausmüll ! Gemäß einer neuen EU-Richtlinie, die die ordnungsgemäße Rücknahme, Behandlung und Verwertung von gebrauchten Elektro- und Elektronikgeräten vorschreibt, müssen elektrische und elektronische Altgeräte getrennt entsorgt werden. Nach der Einführung der Richtlinie in den EU-Mitgliedstaaten

können Privathaushalte ihre gebrauchten Elektro- und Achtung: Ihr Produkt trägt dieses Symbol. Es besagt, dass Elektro- und Elektronikgeräte nicht mit dem Haushaltsmüll entsorgt, sondern einem getrennten Rücknahmesystem zugeführt werden sollten.

Elektronikgeräte nun kostenlos an ausgewiesenen

Rücknahmestellen abgeben*.

In einigen Ländern* können Sie Altgeräte u.U. auch

kostenlos bei Ihrem Fachhändler abgeben, wenn Sie ein

vergleichbares neues Gerät kaufen.

Weitere Einzelheiten erhalten Sie von Ihrer

Gemeindeverwaltung. Wenn Ihre gebrauchten Elektro- und Elektronikgeräte Batterien oder Akkus enthalten, sollten diese vorher entnommen und gemäß örtlich geltenden Regelungen getrennt entsorgt werden. Durch die ordnungsgemäße Entsorgung tragen Sie dazu bei, dass Altgeräte angemessen gesammelt, behandelt und verwendet werden. Dies verhindert mögliche schädliche Auswirkungen auf Umwelt und Gesundheit durch eine unsachgemäße Entsorgung.

2. In anderen Ländern außerhalb der EU

Bitte erkundigen Sie sich bei Ihrer Gemeindeverwaltung nach dem ordnungsgemäßen Verfahren zur Entsorgung dieses Geräts. Für die Schweiz: Gebrauchte Elektro- und Elektronikgeräte können kostenlos beim Händler abgegeben werden, auch wenn Sie kein neues Produkt kaufen. Weitere Rücknahmesysteme finden Sie auf der Homepage von www.swico.ch oder www.sens.ch.

B. Entsorgungsinformationen für gewerbliche

Nutzer

1. In der Europäischen Union

Wenn Sie dieses Produkt für gewerbliche Zwecke genutzt haben und nun entsorgen möchten:

Bitte wenden Sie sich an Ihren SHARP Fachhändler, der Sie über die Rücknahme des Produkts informieren kann. Möglicherweise müssen Sie die Kosten für die Rücknahme und Verwertung tragen. Kleine Produkte (und kleine Mengen) können möglicherweise bei Ihrer örtlichen Rücknahmestelle abgegeben werden. Für Spanien: Bitte wenden Sie sich an das vorhandene Rücknahmesystem oder Ihre Gemeindeverwaltung, wenn Sie Fragen zur Rücknahme Ihrer Altgeräte haben.

2. In anderen Ländern außerhalb der EU

Bitte erkundigen Sie sich bei Ihrer Gemeindeverwaltung nach dem ordnungsgemäßen Verfahren zur Entsorgung dieses Geräts.

WEEE_0502_D

Informations sur la mise au rebut correcte

A. Informations sur la mise au rebut à l'intention

des utilisateurs privés (ménages)

1. Au sein de l'Union européenne

Attention : si vous souhaitez mettre cet appareil au rebut, ne le jetez pas dans une poubelle ordinaire ! Les appareils électriques et électroniques usagés doivent être traités séparément et conformément aux lois en vigueur en matière de traitement, de récupération et de recyclage adéquats de ces appareils. Suite à la mise en oeuvre de ces dispositions dans les Etats membres, les ménages résidant au sein de l'Union européenne peuvent désormais ramener gratuitement*

Attention : votre produit comporte ce symbole. Il signifie que les produits électriques et électroniques usagés ne doivent pas être mélangés avec les déchets ménagers généraux. Un système de collecte séparé est prévu pour ces produits.

leurs appareils électriques et électroniques usagés sur des sites de collecte désignés. Dans certains pays*, votre détaillant reprendra également gratuitement votre ancien produit si vous achetez un produit neuf similaire. *) Veuillez contacter votre administration locale pour plus

de renseignements. Si votre appareil électrique ou électronique usagé comporte des piles ou des accumulateurs, veuillez les mettre séparément et préalablement au rebut conformément à la législation locale en vigueur. En veillant à la mise au rebut correcte de ce produit, vous contribuerez à assurer le traitement, la récupération et le recyclage nécessaires de ces déchets, et préviendrez ainsi les effets néfastes potentiels de leur mauvaise gestion sur l'environnement et la santé humaine.

2. Pays hors de l'Union européenne

Si vous souhaitez mettre ce produit au rebut, veuillez contacter votre administration locale qui vous renseignera sur la méthode d'élimination correcte de cet appareil. Suisse : les équipements électriques ou électroniques usagés peuvent être ramenés gratuitement au détaillant, même si vous n'achetez pas un nouvel appareil. Pour obtenir la liste des autres sites de collecte, veuillez vous reporter à la page d'accueil du site www.swico.ch ou www.sens.ch .

B. Informations sur la mise au rebut à l'intention

des entreprises

1. Au sein de l'Union européenne

Si ce produit est utilisé dans le cadre des activités de votre entreprise et que vous souhaitiez le mettre au rebut : Veuillez contacter votre revendeur SHARP qui vous informera des conditions de reprise du produit. Les frais de reprise et de recyclage pourront vous être facturés. Les produits de petite taille (et en petites quantités) pourront être repris par vos organisations de collecte locales. Espagne : veuillez contacter l'organisation de collecte existante ou votre administration locale pour les modalités de reprise de vos produits usagés.

2. Pays hors de l'Union européenne

Si vous souhaitez mettre ce produit au rebut, veuillez contacter votre administration locale qui vous renseignera sur la méthode d'élimination correcte de cet appareil.

WEEE_0502_F

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

Información sobre la eliminación

A. Información sobre eliminación para usuarios

particulares

1. En la Unión Europea

Atención: si quiere desechar este equipo, ¡por favor no utilice el cubo de la basura habitual! Los equipos eléctricos y electrónicos usados deberían tratarse por separado de acuerdo con la legislación que requiere un tratamiento, una recuperación y un reciclaje adecuados de los equipos eléctricos y electrónicos usados. Tras la puesta en práctica por parte de los estados miembros, los hogares de particulares dentro de los estados de la Unión Europea pueden devolver sus

Atención: su producto está marcado con este símbolo. Significa que los productos eléctricos y electrónicos usados no deberían mezclarse con los residuos domésti- cos generales. Existe un sistema de recogida independiente para estos productos.

equipos eléctricos y electrónicos a los centros de recogida designados sin coste alguno *. En algunos países* es posible que también su vendedor local se lleve su viejo producto sin coste alguno si Ud. compra uno nuevo similar. *) Por favor, póngase en contacto con su autoridad local

para obtener más detalles. Si sus equipos eléctricos o electrónicos usados tienen pilas o acumuladores, por favor deséchelos por separado con antelación según los requisitos locales. Al desechar este producto correctamente, ayudará a asegurar que los residuos reciban el tratamiento, la recuperación y el reciclaje necesarios, previniendo de esta forma posibles efectos negativos en el medio ambiente y la salud humana que de otra forma podrían producirse debido a una manipulación de residuos inapropiada.

2. En otros países fuera de la Unión Europea

Si desea desechar este producto, por favor póngase en contacto con las autoridades locales y pregunte por el método de eliminación correcto. Para Suiza: Los equipos eléctricos o electrónicos pueden devolverse al vendedor sin coste alguno, incluso si no compra ningún nuevo producto. Se puede encontrar una lista de otros centros de recogida en la página principal de www.swico.ch o www.sens.ch.

B. Información sobre Eliminación para

empresas usuarias

1. En la Unión Europea

Si el producto se utiliza en una empresa y quiere desecharlo: Por favor póngase en contacto con su distribuidor SHARP, quien le informará sobre la recogida del producto. Puede ser que le cobren los costes de recogida y reciclaje. Puede ser que los productos de tamaño pequeño (y las cantidades pequeñas) sean recogidos por sus centros de recogida locales. Para España: por favor, póngase en contacto con el sistema de recogida establecido o con las autoridades locales para la recogida de los productos usados.

2. En otros países fuera de la Unión Europea

Si desea desechar este producto, por favor póngase en contacto con sus autoridades locales y pregunte por el método de eliminación correcto.

WEEE_0502_S

Information om återvinning

A. Information om återvinning av elektrisk

utrustning för hushåll

1. EU-länder

OBS! Kasta inte denna produkt i soporna! Förbrukad elektrisk utrustning måste hanteras i enlighet

med gällande miljölagstiftning och återvinningsföreskrifter. I enlighet med gällande EU-regler ska hushåll ha möjlighet att lämna in elektrisk utrustning till återvinningsstationer utan kostnad.* I vissa länder* kan

OBS! Produkten är märkt med symbolen ovan. Denna symbol indikerar att elektroniska produkter inte ska kastas i det vanliga hushållsavfallet ef- tersom det finns ett separat avfallshanteringssystem för dem.

det även hända att man gratis kan lämna in gamla produkter till återförsäljaren när man köper en ny liknande enhet. *) Kontakta kommunen för vidare information.

Om utrustningen innehåller batterier eller ackumulatorer ska dessa först avlägsnas och hanteras separat i enlighet med gällande miljöföreskrifter.

Genom att hantera produkten i enlighet med dessa föreskrifter kommer den att tas om hand och återvinnas på tillämpligt sätt, vilket förhindrar potentiella negativa hälso- och miljöeffekter.

2. Länder utanför EU

Kontakta de lokala myndigheterna och ta reda på gällande sorterings- och återvinningsföreskrifter om du behöver göra dig av med denna produkt.

B. Information om återvinning för företag

1. EU-länder

Gör så här om produkten ska kasseras: Kontakta SHARPs återförsäljare för information om hur

man går till väga för att lämna tillbaka produkten. Det kan hända att en avgift för transport och återvinning tillkommer. Mindre skrymmande produkter (om det rör sig om ett fåtal) kan eventuellt återlämnas till lokala återvinningsstationer.

2. Länder utanför EU

Kontakta de lokala myndigheterna och ta reda på gällande sorterings- och återvinningsföreskrifter om du behöver göra dig av med denna produkt.

WEEE_0502_V

XL-DAB9H

viii

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

XL-DAB9H

Informazioni per un corretto smaltimento

A. Informazioni sullo smaltimento per gli utenti

(privati)

1. Nell'Unione europea

Attenzione: Per smaltire il presente dispositivo, non utilizzare il normale bidone della spazzatura! Le apparecchiature elettriche ed elettroniche usate devono essere gestite a parte e in conformità alla legislazione che richiede il trattamento, il recupero e il riciclaggio adeguato dei suddetti prodotti. In seguito alle disposizioni attuate dagli Stati membri, i privati residenti nella UE possono conferire gratuitamente

Attenzione: Il dispositivo è contrassegnato da questo simbolo, che segnala di non smaltire le apparecchiature elettriche ed elettroniche insieme ai normali rifiuti domestici. Per tali prodotti è previsto un sistema di raccolta a parte.

le apparecchiature elettriche ed elettroniche usate a centri di raccolta designati*. In alcuni paesi*, anche il rivenditore locale può ritirare gratuitamente il vecchio prodotto se l'utente acquista un altro nuovo di tipologia simile. *) Per maggiori informazioni si prega di contattare

l'autorità locale competente. Se le apparecchiature elettriche o elettroniche usate hanno batterie o accumulatori, l'utente dovrà smaltirli a parte preventivamente in conformità alle disposizioni locali. Lo smaltimento corretto del presente prodotto contribuirà a garantire che i rifiuti siano sottoposti al trattamento, al recupero e al riciclaggio necessari prevenendone il potenziale impatto negativo sull'ambiente e sulla salute umana, che potrebbe derivare da un'inadeguata gestione dei rifiuti.

2. In paesi che non fanno parte dell'UE

Se si desidera eliminare il presente prodotto, contattare le autorità locali e informarsi sul metodo di smaltimento corretto. Per la Svizzera: Le apparecchiature elettriche o elettroniche usate possono essere restituite gratuitamente al rivenditore, anche se non si acquista un prodotto nuovo. Altri centri di raccolta sono elencati sulle homepage di www.swico.ch o di www.sens.ch.

B. Informazioni sullo smaltimento per gli utenti

commerciali

1. Nell'Unione europea

Se il prodotto è impiegato a scopi commerciali, procedere come segue per eliminarlo. Contattare il proprio rivenditore SHARP che fornirà informazioni circa il ritiro del prodotto. Potrebbero essere addebitate le spese di ritiro e riciclaggio. Prodotti piccoli (e quantitativi ridotti) potranno essere ritirati anche dai centri di raccolta locali. Per la Spagna: Contattare il sistema di raccolta ufficiale o l'ente locale preposto al ritiro dei prodotti usati.

2. In paesi che non fanno parte dell'UE

Se si desidera eliminare il presente prodotto, contattare le autorità locali e informarsi sul metodo di smaltimento corretto.

WEEE_0502_I

Informatie over verantwoorde verwijdering

A. Informatie over afvalverwijdering voor

gebruikers (particuliere huishoudens)

1. In de Europese Unie

Let op: Deze apparatuur niet samen met het normale huisafval weggooien! Afgedankte elektrische en elektronische apparatuur moet gescheiden worden ingezameld conform de wetgeving inzake de verantwoorde verwerking, terugwinning en recycling van afgedankte elektrische en elektronische apparatuur. Na de invoering van de wet door de lidstaten mogen particuliere huishoudens in de lidstaten van de Europese Unie hun afgedankte elektrische en elektronische

Let op: Uw product is van dit merkteken voorzien. Dit betekent dat afgedankte elektrische en elektronische apparatuur niet samen met het normale huisafval mogen worden weggegooid. Er bestaat een afzonderlijk inzamelingssysteem voor deze producten.

apparatuur kosteloos* naar hiertoe aangewezen inzamelingsinrichtingen brengen*. In sommige landen* kunt u bij de aanschaf van een nieuw apparaat het oude product kosteloos bij uw lokale distributeur inleveren. *) Neem contact op met de plaatselijke autoriteiten voor

verdere informatie. Als uw elektrische of elektronische apparatuur batterijen of accumulatoren bevat dan moet u deze afzonderlijk conform de plaatselijke voorschriften weggooien. Door dit product op een verantwoorde manier weg te gooien, zorgt u ervoor dat het afval de juiste verwerking, terugwinning en recycling ondergaat en potentiële negatieve effecten op het milieu en de menselijke gezondheid worden voorkomen die anders zouden ontstaan door het verkeerd verwerken van het afval.

2. In andere landen buiten de Europese Unie

Als u dit product wilt weggooien, neem dan contact op met de plaatselijke autoriteiten voor informatie omtrent de juiste verwijderingsprocedure. Voor Zwitserland: U kunt afgedankte elektrische en elektronische apparatuur kosteloos bij de distributeur inleveren, zelfs als u geen nieuw product koopt. Aanvullende inzamelingsinrichtingen zijn vermeld op de startpagina van www.swico.ch of www.sens.ch.

B. Informatie over afvalverwijdering voor

bedrijven

1. In de Europese Unie

Als u het product voor zakelijke doeleinden heeft gebruikt en als u dit wilt weggooien: Neem contact op met uw SHARP distributeur die u inlichtingen verschaft over de terugname van het product. Het kan zijn dat u een afvalverwijderingsbijdrage voor de terugname en recycling moet betalen. Kleine producten (en kleine hoeveelheden) kunnen door de lokale inzamelingsinrichtingen worden verwerkt. Voor Spanje: Neem contact op met de inzamelingsinrichting of de lokale autoriteiten voor de terugname van uw afgedankte producten.

2. In andere landen buiten de Europese Unie

Als u dit product wilt weggooien, neem dan contact op met de plaatselijke autoriteiten voor informatie omtrent de juiste verwijderingsprocedure.

WEEE_0502_N

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

Informação sobre Eliminação de Produtos

A. Informações sobre a Eliminação de Produtos

para os Utilizadores (particulares)

1. Na União Europeia

Atenção: Se quiser eliminar este equipamento, não o deve fazer juntamente com o lixo doméstico comum! O equipamento eléctrico e electrónico deve ser tratado separadamente e ao abrigo da legislação aplicável que obriga a um tratamento, recuperação e reciclagem adequados de equipamentos eléctricos e electrónicos usados. Após a implementação desta legislação por parte dos Estados-membros, todos os cidadãos residentes na

União Europeia poderão entregar o seu equipamento Atenção: O seu produto está identificado com este símbolo. Significa que os produtos eléctricos e electrónicos não devem ser misturados com o lixo doméstico comum. Existe um sistema de recolhas específi-

para estes pro-

co dutos.

eléctrico e electrónico usado em estações de recolha

específicas a título gratuito*.

Em alguns países* o seu revendedor local também pode

recolher o seu equipamento usado a título gratuito na

compra de um novo equipamento.

*) Contacte as entidades locais para mais informações.

Se o seu equipamento eléctrico e electrónico usado

funcionar a pilhas ou baterias, deverá eliminá-las em

separado, conforme a legislação local, e antes de

entregar o seu equipamento.

Ao eliminar este produto correctamente estará a contribuir

para que o lixo seja submetido aos processos de tratamento,

recuperação e reciclagem adequados. Desta forma é possível

evitar os efeitos nocivos que o tratamento inadequado do lixo

poderia provocar no ambiente e na saúde.

2. Em outros Países fora da UE

Se quiser eliminar este produto, contacte as entidades

locais e informe-se sobre o método correcto para

proceder à sua eliminação.

Na Suíça: O equipamento eléctrico e electrónico é aceite,

a título gratuito, em qualquer revendedor, mesmo que

não tenha adquirido um novo produto. Poderá encontrar

uma lista das estações de recolha destes equipamentos

na página da Web www.swicho.ch ou www.sens.ch.

B. Informações sobre a Eliminação de Produtos

para Utilizadores-Empresas

1. Na União Europeia

Se o produto for usado para fins comerciais e quiser

eliminá-lo:

Contacte o seu revendedor SHARP que irá informá-lo

sobre a melhor forma de eliminar o produto. Poderá ter de

pagar as despesas resultantes da recolha e reciclagem do

produto. Alguns produtos mais pequenos (e em pequenas

quantidades) poderão ser recolhidos pelas estações locais.

Na Espanha: Contacte o sistema de recolhas público ou

as entidades locais para mais informações sobre a

recolha de produtos usados.

2. Em outros Países fora da UE

Se quiser eliminar este produto, contacte as entidades

locais e informe-se sobre o método correcto para

proceder à sua eliminação.

WEEE_0502_P

Information on Proper Disposal

A. Information on Disposal for Users (private

households)

1. In the European Union

Attention: If you want to dispose of this equipment, please do not use the ordinary dust bin!

Used electrical and electronic equipment must be treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment. Following the implementation by member states, private

households within the EU states may return their used Attention: Y our product is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collection system for these products.

electrical and electronic equipment to designated

collection facilities free of charge*. In some countries*

your local retailer may also take back your old product

free of charge if you purchase a similar new one.

*) Please contact your local authority for further details.

If your used electrical or electronic equipment has

batteries or accumulators, please dispose of these

separately beforehand according to local requirements.

By disposing of this product correctly you will help ensure

that the waste undergoes the necessary treatment,

recovery and recycling and thus prevent potential

negative effects on the environment and human health

which could otherwise arise due to inappropriate waste

handling.

2. In other Countries outside the EU

If you wish to discard this product, please contact your

local authorities and ask for the correct method of

disposal.

For Switzerland: Used electrical or electronic equipment

can be returned free of charge to the dealer, even if you

don't purchase a new product. Further collection facilities

are listed on the homepage of www.swico.ch or

www.sens.ch.

B. Information on Disposal for Business Users

1. In the European Union

If the product is used for business purposes and you

want to discard it:

Please contact your SHARP dealer who will inform you

about the take-back of the product. You might be charged

for the costs arising from take-back and recycling. Small

products (and small amounts) might be taken back by

your local collection facilities.

For Spain: Please contact the established collection

system or your local authority for take-back of your used

products.

2. In other Countries outside the EU

If you wish to discard of this product, please contact your

local authorities and ask for the correct method of

disposal.

WEEE_0502_E

XL-DAB9H

05/7/12 XL-DAB9H(H)_com.fm

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Introduction

ENGLISH

Contents

E-1

Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product.

Special note

Supply of this produc t does not conv ey a license nor imply an y right to di stribute content cr eated with this product in revenue-generatin g broadcast systems (terrestrial, satellite, cable and/or other distribution channels), revenue-generating st reamin g a pplic ation s ( via Inte rnet, intr anet s an d/or othe r networks), other revenue-generating content distribution systems (payaudio or audio-on-demand applications and the like) or on revenue-generating physical media (compact discs, digital versatile discs, semiconductor chips, hard dr ives, memor y cards and the like). An indep endent li cense for such use is required. For details, please vis it http://mp3licens ing.com MPEG Layer-3 audio coding technology licensed from Fr aunhofer IIS and Thomson.

Accessories

Please confirm that the following accessories are included.

General Information

Remote control 1 "AA" size battery (UM/SUM-3,

FM aerial 1 AC power lead 1 Plug adaptor 1

Caution:

Do not use the supplied AC power lead for other equipment. Fire or electric shock may result.

Note:

Only the above accessories are included.

R6, HP-7 or similar) 2

Page

 General Information

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Controls and indica t ors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 5

 Preparation for Use

System connection s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

 Basic Operation

Sound control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

 Disc Playback

CD or MP3/WMA disc playback . . . . . . . . . . . . . . . . . . . . 11 - 13

Advanced disc playback . . . . . . . . . . . . . . . . . . . . . . . . . . 14 - 17

 DAB Operation

Listening to the DAB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 - 21

Listening to the me morised DAB st ati on . . . . . . . . . . . . . . . . . 22

Listening to DAB stations in the time shift mode . . . . . . . 23, 24

Changing the informa t ion display . . . . . . . . . . . . . . . . . . . . . . 25

 FM Operation

Listening to the FM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Listening to the me m o rised FM station . . . . . . . . . . . . . . . . . . 27

 RDS Operation

Using the Radio Da t a Sy s t e m (RDS) . . . . . . . . . . . . . . . . 28 - 32

 Advanced Features

Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . 33, 34

Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

 References

Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36, 37

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

05/7/12 XL-DAB9H(H)E1.fm

TINSZA071SJZZ

Precautions

 General

Please ensure that the equipment is posi tioned in a well venti-

lated area and that there is at least 10 cm of free space along the sides and back. There must also be a minimum of 20 cm of free space on the top of the unit.

10 cm 10 cm

Use the unit on a firm, level surface free from vibration.

Keep the unit away from direct sunl ight, strong magnetic fields,

excessive dust, humidity and electronic/electrical equipment (home computers, facsimiles, etc.) which generate electrical noise. Do not place anything on top of the unit.

Do not expose the unit to moisture, to temperatures higher than

60°C or to extremely low temperatures. If your system does not work proper ly, disconnec t the AC power

lead from the wall socket. Plug the AC power lead back in, and then turn on your system. In case of an electrical storm, unplug the unit for safety.

Hold the AC power plug by the head when removing it from the

wall socket, as pulling the lead can damage internal wires.

Do not remove the outer cover, as this may result in electric

shock. Refer internal service to your local SHARP service facility.

The ventilation should not be impeded by covering the ventilation

openings with items, such as newspapers, tablecloths, curtains, etc. No naked flame sources, such as lighted candles, should be

placed on the apparatus. Attention should be drawn to the environmental aspects of bat-

tery disposal. The apparatus is designed for use in moderate climate.

This unit should only be used within the range of 5°C - 35°C.

20 cm

10 cm

Warning:

The voltage used must be the same as that specified on this unit . Using this product with a higher voltage other than that which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.

 Volume control

The sound level at a given volume setting depends on speaker ef ficiency, location, and various other factors. It is advisable to avoid exposure to high volume levels. Do not turn the volume on to full at switch on and listen to music at moderate levels.

 Care of discs

Compact discs are fairly resistant t o damage, however mistracking can occur due to an accumulation of dirt on the disc surface. Follow the guidelines below for maximum enjoyment from your CD collection and player.

Do not write on either side of the disc, particularl y the non-label

side from which signals are read. Do not mark this surface. Keep your discs away from direct sunlight, heat, and exces sive

moisture. Always hold the CDs by the edges. Fingerprints, dirt, or water on

the CDs can cause noise or mistracking. If a CD is dirty or does not play properly, clean it with a soft, dry cloth, wiping straight out from the centre, along the radius.

YES Correct

XL-DAB9H

ENGLISH

General Information

05/7/12 XL-DAB9H(H)E1.fm

E-2

TINSZA071SJZZ

XL-DAB9H

ENGLISH

General Information

Controls and indicators

1 2 3

4 5

6 7 8

21 22

9 10

11 12 13

14 15 16

17 18

19 20

1.On/Stand-by Butt o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Reference page

2.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.Bass/Treble Selector Button . . . . . . . . . . . . . . . . . . . . . . . . . 9

4.Preset Zone Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.Preset Number Select/Time Shift Mode Buttons . . 22, 23, 24

6.Time Shift Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

7.Volume Up and Down/Track Up and Down/

Preset Up and Down Lever . . . . . . . . . . . . . . . . . . . . 9, 14, 27

8.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 5

9.Disc Stop/Tuning Down Butto n . . . . . . . . . . . . . . . 12, 19, 26

10.Function Selector Button . . . . . . . . . . . . . . . . . 12, 19, 26, 33

11.Disc Eject Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

12.Disc Play or Pause/Tuning Up Butt on . . . . . . . . . . 12, 19, 26

13.MP3/WMA Display Button . . . . . . . . . . . . . . . . . . . . . . . 13 , 14

14.Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

15.Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

16.Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . 17, 19, 27

17.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 27

18.Disc Slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

19.Line Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

20.Line Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

21.DAB Rod Aerial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7

22.AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 7

23.FM 75 Ohm Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

24.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

E-3

05/7/12 XL-DAB9H(H)E1.fm

TINSZA071SJZZ

Reference page

321 5

6 7 8

11 12 13

14 15 16109

1.DAB Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 26

4.Preset Zone Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.Preset Number Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 22

6.Repeat Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

7.Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

8.Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

9.MP3 Track Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

10.WMA Track Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

11.Primary with Secondary Indicator . . . . . . . . . . . . . . . . . . . 19

12.Secondary Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

13.RDS Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

14.Time Shift Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

15.Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

16.Timer Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

17.Tweeter

18.Woofer

19.Bass Reflex Duct

20.Speaker Wire Note:

There is no distinction between the right and the left speakers.

Speaker grilles are removable:

Make sure nothing comes into contact with the speaker diaphragm when you remove the speaker grilles.

XL-DAB9H

ENGLISH

General Information

05/7/12 XL-DAB9H(H)E1.fm

E-4

TINSZA071SJZZ

XL-DAB9H

ENGLISH

General Information

Controls and indicators (continued)

13 18 14 15 16

19 20 21 2217

3029

32 33

3 4

5 6

23 24 25 26 27

10 11

1.Remote Control Trans mitter . . . . . . . . . . . . . . . . . . . . . . . . . 8

Reference page

2.Fast Reverse/Tuning Down Button . . . . . . . . . . . . . 14, 19, 26

3.Track Down/Preset Down Button . . . . . . . . . . . . . . 10, 14, 27

4.Direct Search Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5.Treble Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . 9

6.CD Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

7.Tuner and Band Selector Button . . . . . . . . . . . . . . . . . 18, 26

8.Fast Forward/Tuning Up Butt on . . . . . . . . . . . . . . . 14, 19, 26

9.Track Up/Preset Up Button . . . . . . . . . . . . . . . . . . . 10, 14, 27

10.MP3/WMA Display Button . . . . . . . . . . . . . . . . . . . . . . . 13 , 14

11.Bass Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . 9

12.Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

13.On/Stand-by But t o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

14.Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . 10, 17, 19, 27

15.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 27

16.Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

17.Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

18.RDS Display Mode/Information Select Button . . . . . . . 25, 28

19. RDS Programme Type/

Traffic Infor m a ti on Se a rc h Button . . . . . . . . . . . . . . . . . . . 32

20.RDS ASPM (Auto Station Programme Memory) Button . . 30

21.Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

22.Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

23.Time Shift Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

24.Preset Zone Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . 22

25.Auto Tune Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

26.Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20, 21

27.Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

28.Preset Number Select/Time Shift Mode Buttons . . . . . 22, 23

29.Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

30.Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

31.Disc Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

32.Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

33.Disc Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

E-5

05/7/12 XL-DAB9H(H)E1.fm

TINSZA071SJZZ

System connections

Make sure to unplug the AC power lead before making any connections.

FM aerial

DAB rod aerial

Right speaker

Left speaker

 Speaker connection

Connect the wire with the white line to the minus (-) terminal and the plain wire to the plus (+) terminal.

Caution:

Do not let the bare speaker wires touch each

other.

Use speakers with an impedance of 4 ohms or

more, as lower impedance speakers can damage the unit. Do not mistake the right and the left channels.

The right speaker is the one on the right side when you face the unit.

Do not allow any objects to fall into or to be placed

in the bass reflex ducts.

Incorrect

 FM aerial connection

Supplied FM aerial:

Connect the FM aerial wire to the FM 75 OHMS socket and position the FM aerial wire in the direction where the strongest signal can be received.

External FM aerial:

Use an external FM aerial if you require better recept ion. Consult your dealer.

External FM aerial

XL-DAB9H

ENGLISH

Preparation for Use

Wall socket (AC 230 V, 50 Hz)

White line

Plain

05/7/12 XL-DAB9H(H)E1.fm

E-6

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Preparation for Use

System connections (continued)

 DAB aerial adjustment

Raise and extend the telescopic rod aerial, then adjust the position and length for the best reception.

 AC power connection

After checking all the connecti ons have been made correctly, connect the AC power lead to the AC power input socket, then plug the AC power lead of this unit into the wall socket.

Wall socket (AC 230 V, 50 Hz)

Notes:

Unplug the AC power lead from the wall socket if the unit will not

be in use for a prolonged period of time. Never use a power lead other than the one supplied. Othe rwise,

a malfunction or an accident may occur.

 To turn the power on

Press the ON/STAND-BY button to turn the power on.

After use:

Press the ON/STAND-BY button to enter the power stand-by mode.

E-7

05/7/12 XL-DAB9H(H)E1.fm

TINSZA071SJZZ

Remote control

 Battery installation

Use 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).

1 Remove the battery cover. 2 Insert the batteries according to the direction indicated in

the battery compartment.

When inserting or removing the batteries, push them toward the

battery terminals.

3 Replace the cover.

Precautions for battery use:

Replace all old batteries with new ones at the same time.

Do not mix old and new batteries.

Remove the batteries if the unit is not to be used for long per iod s

of time. This will prevent potential damage due to battery leakage.

Caution:

Do not use rechargeable batteries (nickel-cadmium battery, etc.).

Installing the batteries i ncorrectly may ca use t he unit t o mal func-

tion.

Notes concerning use:

Replace the batteries if the operating distance is reduced or if the

operation becomes erratic. Periodically clean the transmitter on the remote control and the

sensor on the unit with a soft cloth. Exposing the sensor on the unit to strong light may i nterfere with

operation. Change the lighting or the direction of the unit. Keep the remote control away from moisture, heat, shock, and

vibrations.

 Test of the remote control

Check the remote control after checking all the connections. Point the remote control directly at the remote sensor on the unit.

The remote control can be used within the range shown below:

Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy music.

Remote sensor

0.2 m - 6 m

XL-DAB9H

ENGLISH

Preparation for Use

Battery removal:

Remove the battery cover. Push each battery toward the battery terminal and take them out.

05/7/12 XL-DAB9H(H)E1.fm

E-8

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Sound control

 Adjusting the volume

Main unit operation:

Move the operation lever toward VOLUME + or VOLUME - to increase or decrease the volume.

Remote control operation:

Press the VOLUME (- or +) button to increase or decrease the volume.

.....

21 28 29 300

 Adjusting the bass

Main unit operation:

1 Press the BASS/TREBLE button to select "Bass". 2 Within 5 seconds, move the opera tion lever toward VOLUME +

or VOLUME - to adjust the bass.

Remote control operation:

Press the BASS (- or +) button to adjust the bass.

E-9

...

Basic Operation

...

04-3

 Adjusting the treble

Main unit operation:

1 Press the BASS/TREBLE button to select "Treble". 2 Within 5 seconds, move the opera tion lever toward VOLUME +

or VOLUME - to adjust the treble.

Remote control operation:

Press the TREBLE (- or +) button to adjust the treble.

...

05/7/12 XL-DAB9H(H)E1.fm

...

04-3

TINSZA071SJZZ

Setting the clock

In this example, the clock is set for the 24-hour (0:00) display.

Press the CLOCK button and within 8 seconds, press the MEMORY button.

Within 1 minute, press the PRESET ( or ) button to adjust the hour and then press the MEMORY button.

Press the PRESET ( or ) button once to advance the time by 1 hour. Hold it down to advance continuously.

Within 1 minute, press the PRESET ( or ) button to adjust the minutes and then press the MEMORY button.

Press the PRESET ( or ) button once to advance the time by 1 minute. Hold it down to advance continuously.

To confirm the time display:

Press the CLOCK button. The time display will appear for about 8 seconds.

XL-DAB9H

ENGLISH

Within 1 minute, press the PRESET ( or ) button to select 24-hour or 12-hour display and then press the MEMORY button.

"0:00" The 24-hour display will appear. (0:00 - 23:59) "AM12:00" The 12-hour display will appear. (AM12:00 - PM11:59)

Note:

The "0:00" or time will flash when the AC power supply is restored after a power failure or unplugging the unit. Readjust the clock as follows.

To readjust the clock:

Perform "Setting the clock" from the begi nning. If the "0:00" is not flashing in step 1, step 2 (for selecting the 24-hour or 12-hour display) will be skipped.

To change the 24-hour or 12-hour display:

1 Clear all the programmed contents. [Refer to "Clearing all the

memory (reset)" on page 37 for details.]

2 Perform "Setting the clock" from the beginning.

05/7/12 XL-DAB9H(H)E1.fm

TINSZA071SJZZ

Basic Operation

E-10

XL-DAB9H

ENGLISH

Disc Playback

CD or MP3/WMA disc playback

This system can play back a standard CD, CD-R/RW in the CD format and CD-R/RW with MP3 or WMA files, but cannot record o n them. Some audio CD-R and CD-RW discs may not be playable due to the state of the disc or the equipment used for recording.

MP3:

MP3 is a form of compression. It is an acronym which stands for MPEG Audio Layer 3. MP3 is a type of audio code which is pr ocessed by signific ant compression from the original audio source with very little loss in sound quality.

The MP3 track indicator will light up when an MP3 track is read.

This system supports MPEG 1 Layer 3, MPEG 2 Layer 3, and

VBR files. During VBR file playback, time counter in the displ ay may differ

from its actual playback time. Supported bit rates for MP3 files range from 64 kbps to 160 kbps.

WMA:

WMA files are ASF (Advanced Systems Format) audio files which are compressed with Windows Media Audio codec. WMA i s developed by Microsoft as an audio format file for Windows Media Player.

The WMA track indicator will light up when a WMA track is read.

Supported bit rates for WMA files range from 64 kbps to 160

kbps.

E-11

05/7/12 XL-DAB9H(H)E2.fm

TINSZA071SJZZ

Press the ON/STAND-BY button to turn the power on.

Press the FUNCTION button until "CD NO DI SC" appears on the display.

When operating with the remote control, press the CD button.

Insert a disc into the disc slot with the label on the right.

The disc enters automatically.

Notes:

Do not push in the disc. Damage may result.

Load an 8 cm disc gently in the middle of the disc slot (do not

use an adaptor).

Total number of tracks

[MP3]

Disc slot

Label side

[CD]

MP3 track indicator Total number of tracks

[WMA]

Press the button to start playback from track 1.

Disc play indicator

When the last track on the disc has finished playing, the unit will stop automatically.

To interrupt playback: Main unit operation:

Press the button. To resume playback, press the button again.

Remote control operation:

Press the button. To resume playback, press the button.

To stop playback:

Press the button.

To remove the disc:

1 Press the button. 2 Remove the disc.

XL-DAB9H

ENGLISH

Disc Playback

Total number of tracks

Due to the structure of the disc information, it takes longer to

read a CD-R/RW disc recorded in the MP3 or WMA format than a normal CD.

Total playing time

WMA track indicator

05/7/12 XL-DAB9H(H)E2.fm

E-12

TINSZA071SJZZ

XL-DAB9H

ENGLISH

CD or MP3/WMA disc playback (continued)

Caution when inserting disc:

Do not touch the playback side.



Whilst in the stop mode or playback mode, press the CD DISPLAY button. Each time the button is pressed, the display will change as follows.

To change the display (CD-R/RW discs recorded in the MP3 or WMA format only)

Do not insert two or more discs in the disc slot.

Discs with labels, stickers or glue attached

may cause damage to the main unit.

Do not use discs of special shapes (heart,

octagon, etc.) or 8 cm discs with an adaptor. Malfunction may result.

A disc with scratches or fingerprints may not play properly. Refer

to "Care of discs" (page 2) and clean the disc. Insert or remove the disc straight.

Otherwise, damage may result.

Disc Playback

Caution:

Be careful not to damage the disc when inserting or removing it.

A disc does not play if damaged, dirty or loaded upside down.

Make sure to remove the disc before transporting the main unit.

Otherwise the disc inside may cause malfunction.

z Do not let coins, clips, etc. get into the disc slot. Malfunction may

occur.

z Subjecting the unit to shock or vibration may cause mistracki ng. z If TV or radio interference occurs during disc operation, move the

unit away from it.

[When in the stop mode]

Total number of tracks

To check the total number of tracks, press the button.

[When in the playback mode]

Track number

Elapsed playback time

Folder name Track name

1st track

Folder name

Artist name Title nameAlbum name

Track name

E-13

05/7/12 XL-DAB9H(H)E2.fm

TINSZA071SJZZ

Advanced disc playback

To use the operation lever on the unit, move it toward the corresponding directions.



To select the desired folder or track by name (CD-R/RW discs recorded in the MP3 or WMA format only)

Whilst in the stop mode, press the CD DISPLAY button to display the folder

name.

Select the desired folder by pressing the or button.

Press the CD DISPLAY button to display the track name.



To locate the beginning of a track

To move to the beginning of the next track:

Press the button for less than 0.5 seconds during playback.

To restart the track being played:

Press the button for less than 0.5 seconds during playback.

Note:

You can skip to any track by pressing the or button repeatedly until the desired track number appears.



To locate the desired portion

CD sound is heard except for CD-R/RW in the MP3 or WMA format. (Check elapsed time on the display.)

For fast forward:

Press and hold down the button during playback.

For fast reverse:

Press and hold down the button during playback.

Notes:

Normal playback will resume when the or button is

released. When the end of the last track is reached during fast forward,

"END" will appear on the display and disc operation will be paused. When the beginning of the first track is reached during fast reverse, the disc will start playback automatically. You can locate the desired portion by moving the operation lever

toward or .

XL-DAB9H

ENGLISH

Disc Playback

Select the desired track by pressing the or button.

Press the button to begin playback.

05/7/12 XL-DAB9H(H)E2.fm

E-14

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Disc Playback

Advanced disc playback (continued)



Direct search of the track

By using the direct search buttons, the desired tracks can be played.

Whilst in the stop mode, use the direct search buttons on the remote control to select the desired track.

Selected track number

The direct search buttons allow you to select up to number 9.

When selecting number 10 or higher, use the "+10" button.

A. For example, to choose 13

1 Press the "+10" button once. 2 Press the "3" button.

B. For example, to choose 30

1 Press the "+10" button three times. 2 Press the "0" button.

Press the button to start playback.

Playback of the selected track is started. When the last track on the disc has finished playing, the unit will stop automatically.

To stop playback:

Press the button.

Notes:

The selected track can be started simply by pressing the direct

search buttons during playback. (I t is not neces sary to pres s the

button.)

A track number higher than the number of tracks on the disc can-

not be selected. During random play, direct search is not possible.

For CD-R/RW discs recorded in t he MP3 or WMA format, you

can select the track number but cannot select the folder by pressing the direct search buttons.

E-15

05/7/12 XL-DAB9H(H)E2.fm

TINSZA071SJZZ



Repeat play

All tracks or a programmed sequence can be continuously repeated.

To repeat all tracks:

1 Press the REPEAT button. 2 Press the butt on.

To repeat a desired track:

1 Perform steps 1 - 3 in the "Programmed play" section on page

17 and then press the REPEAT button.

2 Press the butt on.

To repeat random play:

Press the REPEAT button during random play.

To cancel repeat play:

Press the REPEAT button again. " " will go out.

Caution:

After performing repeat play, be sure to press the button. Otherwise, the disc will play continuously.



Random play

The tracks can be played in random order automatically.

Whilst in the stop mode, press the RANDOM button and t h e butt o n s equentially to begin random play.

To cancel random play:

Whilst in the stop mode, press the RANDOM button again. "Random" will go out.

Notes:

When you press the RANDOM button during playback, the main

unit switches to random play. Random play will stop automatically when all tracks are played

once. (The same track will not be played back twice.) In random play, the unit will select and play tracks automatically.

(You cannot select the order of the tracks.) If you press the but ton during random play, you can move to

the next track by the random operation. On the other hand, the

button does not allow you to move to the prev ious t rack. The

beginning of the track being played will be located.

XL-DAB9H

ENGLISH

Disc Playback

05/7/12 XL-DAB9H(H)E2.fm

E-16

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Disc Playback

Advanced disc playback (continued)



Programmed play

You can choose up to 32 selections for playback in the order you like.

Whilst in the stop mode, use the direct search buttons to select the desired track.

Selected track number

You can also select a track by pressing the or button.

Press the MEMORY button to save the track number.

Playback order

When the track is memorised, "Memory" will appear.

Repeat steps 1 - 2 for other tracks. Up to 32 tracks can be programmed.

If you make a mistake, the programmed tracks can be cleared by pressing the CLEAR button.

Press the button to start playback.

To clear the programmed selections:

Whilst the "Memory" indicator is lit, set the CD to the stop mode and then press the CLEAR button. Each time the button is pressed, one track will be cleared, beginning with the last track programmed. When all the tracks are cleared, "Memory" will disappear.

Adding tracks to the programme:

If a programme has been previously stored, t he "Memory" indicator will be displayed. Then follow steps 1 - 2 to add track s. The new tracks will be stored after the last track of the original programme.

Notes:

The programmed sequence is cancelled when the disc is

removed. If you press the ON/STAND-BY button to enter the stand-by

mode or change the function from CD to another, the programmed selections will no t be clea r ed . During the programme operation, random play is not possible.

For CD-R/RW discs recorded in t he MP3 or WMA format, you

can select the track number but cannot select the folder by pressing the direct search buttons.

To use the operation lever on the unit, move it toward the corresponding directions.

E-17

05/7/12 XL-DAB9H(H)E2.fm

TINSZA071SJZZ

Listening to the DAB



About DAB (Digital Audio Broadcasting)

Digital Audio Broadcasting is a digital transmission system where audio signals are converted to digital signals for broadcasting. DAB is broadcast as a group of data called multiplex (ensemble) which may contain one or more stations (services). Each station contains a primary service and there may be one or more secondary services. This allows several programmes or serv ices to be transmitted on a single frequency.



Auto tune

When turned on for the first time, the unit scans radio stations automatically to create a station list.

12-digit solid blocks show the progress of scan.

The number of received stations is displayed.

Total received stations

XL-DAB9H

ENGLISH

DAB SIGNAL

MULTIPLEX (ENSEMBLE)

SERVICES

SERVICE COMPONENTS (STATIONS)

After the scan:

The stations will be stored in alphanumeric order and the first station on the list will be selected and you will hear it through the speakers.

To listen to other stations, see "Selecting a station in the station

list" on page 19. You can arrange the ord er of stations in the station list (see page 20).

Notes:

If no station is found, "No station" appears.

Up to 99 appears for total received stations.



Retuning the unit (Auto tune)

You can retune the radio when you move the unit to other areas or add multiplex channels to the station list.

Press the TUNER (BAND) button until "DAB" appears on the display.

Press the AUTO TUNE button.

All frequencies of Band III and L-Band are scanned. This

may take a few minutes. You can cancel the Auto tune by pressing the AUTO TUNE

button again.

After the scan:

The unit will return to the station you were listening to and you will hear it through the speakers. All the stations found are now stored in the unit.

DAB Operation

E-18

05/7/12 XL-DAB9H(H)E2.fm

TINSZA071SJZZ

XL-DAB9H

ENGLISH

DAB Operation

Listening to the DAB (continued)



Selecting a station in the station list

Once a DAB station is received, y ou ca n select stations in t he sta tion lis t.

Press the FUNCTION button until "DAB" appears on the display.

When operating with the remote control, press the TUNER (BAND) button to select "DAB".

Whilst receiving a DAB station, press the TUNING ( or ) button to select the desired station.

The upper part of the display shows the current station

name, and the name of the station being scanned (with "

") appears in the lower part.

The current station name The name of the station being scanned

If a station has one or more secondary

services, " " appears next to the station name. This indicates a secondary service is also available.

Whilst selecti ng a secondar y service, " "

appears before the station name. This indicates a primary service is available.

Within 30 seconds, press the MEMORY/SET button.

E-19

When the current station is pr imary with secondary , "P" lights up.

When the current station is secondary, "S" lights up.

When the current station is primary without other services,

no indicator lights up.

Note:

Inactive stations cannot be received by Auto tune ("Not available" appears). Tune in manually by adjusting the aerial direction.

05/7/12 XL-DAB9H(H)E2.fm

TINSZA071SJZZ



Manual tune

You can manually store stations which Auto tune cannot find. If reception is poor, you can adjust the sensitivity. Manual tune is only available after Auto tune. Perform Auto tune first.

Press the FUNCTION button until "DAB" appears on the display.

When operating with the remote control, press the TUNER (BAND) button to select "DAB".

Press the MENU button on the remote control repeatedly to select "Manual

tune".

Within 30 seconds, press the MEMORY/ SET button.

Within 30 seconds, press the TUNING ( or ) button to tune in to the desired

station.

Within 30 seconds, press the MEMORY/SET button.

Reception sensitivity appears. The

white block indicates the minimum required level and the solid blocks indicate the current level.

If the level is below the white block,

move the rod aerial or unit to improve reception. When the level reaches the white block, a multiplex name appears and the multiplex will be added to the service list.

Exiting Manual tune:

Press the MEMORY/SET button to exit manual tuning.



Changing the station order

You can change the order of stations in the station list.

Press the FUNCTION button until "DAB" appears on the display.

When operating with the remote control, press the TUNER (BAND) button to select "DAB".

Press the MENU button on the remote control repeatedly to select "Station or-

der".

Within 30 seconds, press the MEMORY/ SET button.

Within 30 seconds, press the TUNING ( or ) button to select the desired station order.

Alphanumeric:

All stations are displayed in alphanumeric order. This is the default setting.

Fav. station:

The 10 most recent stations appear as "Fav." and then appear in alphanumeric order.

Active station:

The station list shows receivable stations and then others in alphanumeric order.

Multiplex:

Stations are sorted by frequency, in ascending order.

Trim stn. list:

Delete inactive stations from the list.

Within 30 seconds, press the MEMORY/ SET button.

XL-DAB9H

ENGLISH

DAB Operation

E-20

05/7/12 XL-DAB9H(H)E2.fm

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Listening to the DAB (continued)

 Adjusting the DRC value

When the volume is low, adjust the DRC (Dynamic Range Control) value to make the sound more audible (may not avai lable for some broadcast material).

Press the FUNCTION button until "DAB" appears on the display.

When operating with the remote control, press the TUNER (BAND) button to select "DAB".

Press the MENU button on the remote control repeatedly to select "Set DRC

value".

Within 30 seconds, press the MEMORY/ SET button.

Within 30 seconds, press the TUNING ( or ) button to select the desired

DRC value.

E-21

DAB Operation

DRC 1: Dynamic range is controlled as set for the broad-

DRC 0: DRC is off. DRC 1/2: Dynamic range is controlled half as much as the

Within 30 seconds, press the MEMORY/ SET button.

05/7/12 XL-DAB9H(H)E3.fm

cast. This is the default setting.

level set for the broadcast.

TINSZA071SJZZ

Listening to the memorised DAB station

Hold down the PRESE T button (1 - 5) for 2 seconds or more to store the station in memory.

Repeat steps 1 - 3 to set other stations, or to change a preset station.

When a new station is stored in memory, the station previously memorised will be erased.

Note:

The backup function protects the memorised stations for a few hours should there be a power failure or the AC power lead disc onnection.

 To recall a memorised station

Press the PRESET SELECT button repeatedly to select the

If the "TIME SHIFT" indicator is on the display, press the TIME SHIFT button to turn it off.

 Memorising a station

You can store up to 20 DAB stations (5 stations for each zone A - D) and recall them at the press of a button.

Tune in to the desired station. (See pages 19, 20.)

Press the PRESET SELECT button repeatedly to select the desired preset zone.

Zone A

Zone B

Zone C

Zone D

desired preset zone.

Press the PRESET button (1 - 5) for less than 1 second to recall a station.

Note:

If the selected preset number is empty th e display shows "Preset** empty".

 To erase entire preset memory

Hold down the PRE SET SELECT button for 3 seconds or more.

Within 30 seconds, press the MEMORY/ SET button.

XL-DAB9H

ENGLISH

DAB Operation

E-22

05/7/12 XL-DAB9H(H)E3.fm

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Listening to DAB stations in the time shift mode

Use these functions when you are mis sing your favourite music for answering calls, etc. Received dat a is stored in memory, and you can listen to the music and view t he DLS (Dynamic Label Segment) from the desired position afterwards.

These functions are available only when receiving DAB band broadcasting.

The maximum storage time depends on the bit rate of the data.

At 64 kbps: approx. 16.6 minutes

At 80 kbps: approx. 13.3 minutes

At 128 kbps: approx. 8.3 minutes

At 192 kbps: approx. 5.5 minutes

 Rewind in the time shift mode

Whilst receiving a DAB station, press the TIME SHIFT button to enter the time shift mode.

"TIME SHIFT" appears in the display of the unit.

The memory stores DAB broadcasts.

Time on the display indicates a difference with the actual time. For example, "-02:30" indicates that playback is 2 minutes and 30 seconds behind the actual time.

Press the or button to set to the desired time.

Release the button to start playback.

-2:30 0:00 (Actual time)

E-23

DAB Operation

When you press the button, the white block moves to the left and time goes back further.

To cancel the rewind mode:

Press the TIME SHIFT button. "TIME SHIFT" disappears.

Notes:

The memory is refreshed all the time. If full, the oldest data is

replaced by new one. When recorded data is converted for playback, sound is muted

for a certain time period to prevent noise.

05/7/12 XL-DAB9H(H)E3.fm

When you press the button, the white block moves to the right and time advances to the actual time.

TINSZA071SJZZ

 Pause in the time shift mode

In the time shift mode, you can pause a DAB broadcast and listen to the content from the desired position.

Whilst receiving a DAB station, press the TIME SHIFT button to enter the time shift mode.

Press the button at the desired position.

Sound is not heard in the pause mode.

Elapsed time (shown as "-**:**") increases and the white

block moves to the left. DAB broadcasts are stored until the memory is full.

Press the button to start playback.

Elapsed time remains the same.

To cancel the pause mode:

Press the TIME SHIFT button.

Note:

If the memory becomes full in the pause mode, playback starts automatically from where the button was pressed. The memory is continually refreshed.

 Hold in the time shift mode

When you press the ( hold) but ton in the time shi ft mode, you can repeatedly listen to broadcast content of several minutes before you press it.

Whilst receiving a DAB station, press the TIME SHIFT button to enter the time shift mode.

Press the button.

Sound is not heard in the hold mode.

Data in memory will be retained until the hold mode is can-

celled.

Press the or button to select a playback position.

Release the button to start playback.

White block

ForwardRewind

The white block indicates the current position.

To reverse, move the white block to the left by pressing the

button repeatedly.

To move forward, move the white block to the right by press-

ing the button repeatedly. In the hold mode, you can play stored data as many times as

you want.

To cancel the hold mode:

Press the TIME SHIFT button.

XL-DAB9H

ENGLISH

DAB Operation

E-24

05/7/12 XL-DAB9H(H)E3.fm

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Changing the information display

You can switch information in the lower part of display.

Press the DISPLAY/INFO button.

Each time the button is pressed, the information display changes in the following order. When "Not available" appears, the DISPLAY/INFO button does not allow you to change the display.

[Scrolling text] [Programme type] [Multiplex name] [Channel/Frequency]

E-25

[Sensitivity]

[Scrolling text]

Information scrolls across the displ ay when sent from the station (set by default). You can pause, forward, or reverse scrolling text.

DAB Operation

Pausing text scroll:

Press the MEMORY button.

Forwarding/reversing text scroll:

Whilst text scroll is paused, press the TUNING ( or ) button. Text scrolls by one character. Hold it to scroll t hrough, and release to return to the pause mode.

Resuming text scroll:

Whilst text scroll is paused, press the MEMORY button again.

[Progra m me type]

A description of the type of content being broadcast by the station.

[Signal quality]

[Multiplex name]

The name of the multiplex (ensemble) which provides the current service.

[Channel/Frequency]

The DAB channel and frequency for the station.

[Mode]

The data transfer speed and channel type (stereo or mono) appear.

[Signal quality]

The signal quality is displayed as a number (0 - 100). [85 - 100: Good 70 - 84: Fair 0 - 69: Poor]

[Sensitivity]

Sensitivity of reception. The empty block indicates the minimum required level for reception and the solid blocks indicate the current level.

05/7/12 XL-DAB9H(H)E3.fm

[Mode]

TINSZA071SJZZ

Listening to the FM

You can use buttons on the remote control instead of the operation lever.

Press the ON/STAND-BY button to turn the power on.

Press the FUNCTION button until "FM" appears on the display.

When operating with the remote control, press the TUNER (BAND) button to select "FM".

Press the TUNING ( or ) button to tune in to the desired station.

Manual tuning:

Press the TUNING button as many times as required to tune in to the desired station.

Auto tuning:

When the TUNING button is pressed for more than 0.5 seconds, scanning will start automatically and the tuner will stop at the first receivable broadcast station.

Notes:

When radio interference occurs, auto scan tuning may stop auto-

matically at that point. Auto scan tuning will skip weak signal stations.

To stop the auto tuning, press the TUNING button again.

When an RDS (Radio Data System) sta tion is tuned in, the fre-

quency will be displayed first, and then the RDS indicator will light. Finally, the station name will appear. Full auto tuning can be achieved for RDS stations "ASPM", see

page 30.

To receive an FM stereo transmission:

Press the FUNCTION button to display the "ST" indicator.

" " will appear when an FM broadcast is in stereo.

If the FM reception is weak, press the FUNCTION button to extin-

guish the "ST" indicator. The reception changes to monaural, and the sound becomes clearer.

FM stereo receiving indicator FM stereo mode indicator

XL-DAB9H

ENGLISH

FM Operation

E-26

05/7/12 XL-DAB9H(H)E3.fm

TINSZA071SJZZ

XL-DAB9H

ENGLISH

FM Operation

Listening to the memorised FM station

 Memorising a station

You can store 40 FM stations in memory and recall them at the push of a button. (Preset tuning)

Perform steps 1 - 3 in "Listening to the FM" on page 26.

Press the MEMORY/SET button to enter the preset tuning saving mode.

Within 5 seconds, move the operation lever toward PRESET or PRESET to se-

lect the preset channel number.

Store the stations in memory, in order, starting with preset channel 1.

Within 5 seconds, press the MEMORY/ SET button to store that station in memory.

If the "Memory" and preset number indicators go out before the station is memorised, repeat the operation from step 2.

Repeat steps 1 - 4 to set other stations, or to change a preset station.

When a new station is stored in memory, the station previously memorised will be erased.

Note:

The backup function protects the memorised stations for a few hours should there be a power failure or the AC pow er lead disconnection.

 To recall a memorised station

Move the operation lever toward PRESET or PRESET for less than 0.5 seconds to select the desired station.

To select a preset station with the direct number buttons:

Press the corresponding number ("0" - "+10").

Example:

To select 28, press "+10", "+10" and "8".

 To scan the preset stations

The stations saved in memory can be scanned automati cally. (Preset memory scan)

1 Move the operation lever toward PRESET or PRESET for

more than 0.5 seconds. The preset number will flash and the programmed stations will be

tuned in sequentially, for 5 seconds each.

2 Move the operation lever toward PRESET or PRESET again

when the desired station is located.

 To clear a memorised station

1 Recall the memorised station. 2 Whilst it is displayed, press the MEMORY/SET button. 3 Within 5 seconds, press the CLEAR button.

 To erase entire preset memory

1 Press the ON/STAND-BY button to enter the power stand-by

mode.

2 Whilst pressing down the MEMORY/SET button and move the

operation lever toward PRESET , press the ON/STAND-BY button until "Preset Clear" appears.

E-27

05/7/12 XL-DAB9H(H)E3.fm

TINSZA071SJZZ

Using the Radio Data System (RDS)

RDS is a broadcasting service which a growing number of FM stations provide. These FM stations send additional signals along with their regular programme signals. They send their station names, and information about the type of programme such as sport, music, etc.

When tuned to an RDS station, "RDS" and the station name will be displayed. "TP" (Traffic Programme) will appear on the display when the received broadcast carries traffic information, and "TA" (Traffic Announcement) will appear whilst a traffic information is on air. "PTYI" (Dynamic PTY Indicator) will appear whilst the Dynamic PTY station is received.

You can control the RDS by using the remote control only.

 Information provided by RDS

Each time the DISPLAY/INFO button is pressed, the display will switch as follows:

When you are tuning in to a station other than an RDS station or to an RDS station which sends weak signal, the display will change in the following order:

XL-DAB9H

ENGLISH

Station name (PS) Programme type (PTY)

Frequency

NO PS NO PTY

FM 98.80 MHz

05/7/12 XL-DAB9H(H)E3.fm

RDS Operation

E-28

TINSZA071SJZZ

XL-DAB9H

ENGLISH

RDS Operation

Using the Radio Data System (RDS) (continued)

Descriptions of the PTY (Programme Type) codes, TP (Traffic Programme) and TA (Traffic Announcement).

You can search for and receive the following PTY, TP and TA s ignals.

NEWS Short accounts of facts, events and publicly ex-

pressed views, reportage and actuality.

AFFAIRS Topical programme expanding or enlarging upon

the news, generally in different presentation style or concept, including debate, or analysis.

INFO Programmes whose purpose is to impart advice in

the widest sense.

SPORT Programme concerned with any aspect of sport. EDUCATE Programme intended primarily to educate, of which

the formal element is fundamental.

DRAMA All radio plays and serials. CULTURE Programmes concerned with any aspect of national

or regional culture, including language, theatre, etc.

SCIENCE Programmes about the natural sciences and tech-

nology.

VARIED Used for mainly speech-based programmes usually

of light-entertainment nature, not covered by other categories. Examples include: quizzes, panel games, personality interviews.

POP M Commercial music, which would generally be con-

sidered to be of current popular appeal, often featuring in current or recent record sales charts.

ROCK M Contemporary modern music, usually written and

performed by young musicians.

EASY M Current contemporary mus i c consi dered to be

"easy-listening", as opposed to Pop, Rock or Classical, or one of the specialised music styles, Jazz, Folk or Country. Music in this category is often but not always, vocal, and usually of short duration.

LIGHT M Classical music for general, rather than specialist

CLASSICS Performances of major orchestral works, sympho-

OTHER M Musical styles not fitting into any of the other cate-

WEATHER Weather reports and forecasts and meteorological

FINANCE Stock Market reports, commerce, trading, etc. CHILDREN For programmes targeted at a young audience, pri-

SOCIAL Programmes about people and things that influence

RELIGION Any aspect of beliefs and faiths, involving a God or

PHONE IN Involving members of the public expressing their

TRAVEL Features and programmes concerned with travel to

LEISURE Programmes concerned with recreational activities

JAZZ Polyphonic, syncopated music characterised by im-

appreciation. Examples of music in this category are instrumental music, and vocal or choral works.

nies, chamber music, etc., and including Grand Opera.

gories. Particularly used for specialist music of which Rhythm & Blues and Reggae are examples.

information.

marily for entertainment and interest, rather than where the objective is to educate.

them individually or in groups. Includes: sociology, history, geography, psychology and society.

Gods, the nature of existence and ethics.

views either by phone or at a public forum.

near and far destinations, package tours and travel ideas and opportunities. Not for use for announcements about problems, delays, or roadworks affecting immediate travel where TP/TA should be used.

in which the listener might participate. Examples include, Gardening, Fishing, Antique collecting, Cooking, Food & Wine, etc.

provisation.

E-29

05/7/12 XL-DAB9H(H)E3.fm

TINSZA071SJZZ

COUNTRY Songs which originate from, or continue the musical

tradition of the American Southern States. Characterised by a straightforward melody and narrative story line.

NATION M Current Popular Music of the Nation or Region in

that country's language, as opposed to International 'Pop' which is usually US or UK inspired and in English.

OLDIES Music from the so-called "golden age" of popular

music.

FOLK M Music which has its roots in the musical culture of a

particular nation, usually played on acoustic instruments. The narrative or story may be based on historical events or people.

DOCUMENT Programme concerned with factual matters, pre-

sented in an investigative style.

TEST Broadcast when testing emergency broadcast

equipment or receivers.

ALARM Emergency announcement made under exception-

al circumstances to give warning of events causing danger of a general nature.

TP Broadcasts which carry traffic announcements. TA Traffic announcements are being broadcast.

 Using the Auto Station Programme Memory

(ASPM)

Whilst in the ASPM operation mode, the tuner will automatically search for new RDS stations. Up to 40 stations can be stored. If you have already stored some stations in memory, the number of new stations you can store will be less.

Press the TUNER (BAND) button to select the FM band.

Press and hold down the ASPM button for at least 3 seconds.

1 After "ASPM" has flashed for about 4 seconds, scanning will

start (87.50 - 108.00 MHz).

2 When an RDS station is found, "RDS" will appear first, and

then "Memory" and the preset channel number will flash for 2 seconds. Finally the station will be stored in memory.

XL-DAB9H

ENGLISH

RDS Operation

3 After scanning, "END" will appear for 4 seconds.

05/7/12 XL-DAB9H(H)E3.fm

E-30

TINSZA071SJZZ

XL-DAB9H

ENGLISH

RDS Operation

Using the Radio Data System (RDS) (continued)

To stop the ASPM operation before it is complete:

Press the ASPM button whilst it is scanning for stations. The stations which are already stored in memory will be kept there.

Notes:

If the same station is broadcasting on different f requencies, the

strongest frequency will be stored in memory. Any station which has the same frequency as one stored in mem-

ory will not be stored. If 40 stations have already been stored in memory, the scan will

be aborted. If you want to redo the ASPM operation, erase the preset memory. If no stations have been stored in memory, "END" will appear for

about 4 seconds. If the RDS signals are very weak, station names may not be

stored in memory.

To erase one of the contents of preset memory:

1 Press the PRESET ( or ) button to select the preset channel

number you want to erase. 2 Press the MEMORY button. 3 Within 5 seconds, press the CLEAR button.

To erase all of the contents of preset memory:

1 Press the ON/STAND-BY button to enter the power stand-by

mode. 2 Whilst pressing down the MEMORY/SET button and move the

operation lever toward PRESET , press the ON/STAND-BY

button until "Preset Clear" appears.

After performing this operation, all of the preset memory informa-

tion will be erased.

To store a station name again if the wrong name was stored in memory:

It may be impossible to store st ation names in memory using the ASPM function if there is lots of noise or if the signal is too weak. In this case, perform as fo llows.

1 Press the PRESET ( or ) button to check whether the names

are correct.

2 If you find a wrong name during receiving the station, wait until the

correct name will be displayed. And then press the MEMORY button.

3 Within 5 seconds, press the MEMORY button whilst the preset

channel number is flashing. The new station name has been stored in memory correctly.

Notes:

The same station name can be stored in different channels.

In a certain area or during certain time periods, the station names

may temporarily be different.

 Notes for RDS operation

If any of the following events occur, it does not mean that the unit is faul t y :

"PS", "NO PS" and a station name appear alternately, and the

unit does not operate properly. If a particular station is not broadcast ing properly or a station is

conducting tests, the RD S reception function may not work properly. When you receive an RDS station whose signal is too weak,

information like the station name may not be displayed. "NO PS" or "NO PTY" will flash for about 5 seconds, and then the

frequency will be displayed.

E-31

05/7/12 XL-DAB9H(H)E4.fm

TINSZA071SJZZ

 To recall stations in memory

To specify programme types and select stations (PTY search):

You can search a station by s pecifying th e programme type (news,

sports, traffic programme, etc. .. . see pages 29 - 30) from the sta-

tions in memory.

Press the TUNER (BAND) button to select the FM.

Press the PTY.TI button.

"PTY TI" will flash for about 6 seconds.

Within 6 seconds, press the PRESET ( or ) button to select the programme type.

Each time the button is pressed, the programme type will appear. If the button is held down for more than 0.5 seconds, the programme type will appear continuously.

Whilst the selected programme type is flashing (within 4 seconds), press the PTY.TI button again.

Notes:

If the display has stopped flashin g, st art again f rom s tep 2. If the

unit finds a desired programme type, the corresponding channel number will flash for about 4 seconds, and then the st ation name will flash for 7 seconds, which will remain lit. If you want to listen to another station of that programme type,

press the PTY.TI button whilst the channel number or station name is flashing. The unit will look for the next station of that type. If no station can be found, "NOT FOUND" will appear for 4 sec-

onds.

If you select the traffic programme:

If you select the traffic programme (TP) in step 3, "TP" will appear. (This does not mean that you can listen to the traffic information at that time.) When the traffic information is broadcast, "TA" will appear.

To specify station names and select stations manually:

You can select a station by specifying the name (BBC R1, BBC R2, etc.) from the stations stored in memory. Before starting this operation, you must store one or more station names in memory.

1 Press the TUNER (BAND) button to select the FM band. 2 Press the PRESET ( or ) button to select a desired station.

XL-DAB9H

ENGLISH

RDS Operation

After the selected programme type has been lit for 2 seconds, "SEARCH" will appear, and the search operation will start.

05/7/12 XL-DAB9H(H)E4.fm

E-32

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Advanced Features

Timer and sleep operation

Timer playback:

The unit turns on and plays the desired source (CD, DAB or FM) at a preset time.

Sleep operation:

The radio or disc can be turned off automatically.

Before setting timer:

1 Check that the clock is set to the correct time (refer to page 10). 2 Load a disc to be played.

You can use buttons on the remote control instead of the operation lever.

 Timer playback

Press the ON/STAND-BY button to turn the power on.

Press the FUNCTION button to select the desired so urce (CD, DAB or FM).

Depending on the source, insert a disc or tune in to a station.

Adjust the volume using the volume control.

Do not turn the volume up too high.

Press the TIMER button. Within 8 seconds, press the MEMORY/SET button.

Within 1 minute, move the operation lever toward PRESET

or PRESET to specify the hour to start, then press the

MEMORY/SET button.

Within 1 minute, move the operation lever toward PRESET

or PRESET to specify the minutes to start, then press

the MEMORY/SET button.

The timer playback starting time, function, and volume will be

displayed, and then the unit will enter the stand-by mode automatically.

" " will appear and the current time will be displayed.

E-33

To cancel the timer playback:

Press the ON/STAND-BY button to turn the power on.

05/7/12 XL-DAB9H(H)E4.fm

TINSZA071SJZZ

When the preset time is reached, playback will start.

The volume will increase gradually until it reaches the volume you were listening at before your system enters the timer standby mode.

The unit will enter the stand-by mode one hour after the timer playback starts. However, when disc playback time is

one hour or less, it will enter the stand-by mode after completing playback.

To reset or change the timer setting:

Perform "Timer playback" from the beginning.

Note:

When performing timer playback usi ng another unit connected to the LINE sockets, select "AUX" in step 2. At this time, only this unit will be turned on or enter the power stand-by mode automatically. It will enter the power stand-by mode 1 hour after t he timer playback starts. However, the other unit will not be turned on or off.

 To use timer and sleep operation together

Example: To fall asleep and wake up to the same radio station You can play back the same source only (the function cannot be switched).

Set the sleep time (steps 1 - 2 on the right).

Whilst the sleep timer is set, set the desired playback time (steps 4 - 6, page 33).

Sleep timer setting Timer playback setting

5 minutes - 3 hours

Sleep operation will automatically stop.

Timer playback start time

 Sleep operation

Play back the desired sound source.

Press the SLEEP button.

To change the sleep time:

Time decreases as follows each time they are pressed. The amount of sleep time can also be changed whilst in the

sleep mode.

(Maximum: 3 hours - Minimum: 5 minutes)

3:00 2:00 1:30 1:00

10 15 305off

Your system will enter the power stand-by mode automatically after the preset time has elapsed.

The volume will turn down 30 seconds before the sleep operation finishes.

To cancel the sleep operation:

Press the ON/STAND-BY button whilst "SLEEP" is indicated. To cancel the sleep operation without setting the system to the stand-by mode, press the SLEEP button until "off" appears on the display.

To confirm the remaining sleep time:

Press the SLEEP button once whilst the sleep timer is set. The remaining sleep time is displayed for about 8 seconds.

XL-DAB9H

ENGLISH

Advanced Features

E-34

05/7/12 XL-DAB9H(H)E4.fm

TINSZA071SJZZ

XL-DAB9H

ENGLISH

Enhancing your syst em

Note:

The LINE IN/OUT sockets accept 2.5 mm mini plugs only. Use the supplied 3.5 mm to 2.5 mm plug adaptor. (Only one plug adaptor is supplied with the unit.)

Recording equipment

To audio input sockets (Commercially available)

Source equipment

To audio output socket (Commercially available)

E-35

Turn off all other equipment before making this connection.

Advanced Features

 Headphones

Before plugging in or unplugging the headphones, reduce the

volume. Be sure your headphones have a 3.5 mm diameter plug and

impedance between 16 and 50 ohms. The recommended impedance is 32 ohms. Plugging in the headphones disconnects the speakers automati-

cally. Adjust the volume using the volume control.

 Connecting source equipment

You can listen to sound of source equipment throug h the unit. Set the function to "AUX" beforehand.

 Connecting recording equipment

You can record sound of the unit to recording equipm ent. Use an audio cable for connection.

Notes:

Plug in each cable fully to prevent noise interference.

Refer to the manual for the connected equipment.

Do not connect the input and output sockets to the same external

equipment. Howling may result. To prevent noise interference, plac e the unit away from the tele-

vision.

05/7/12 XL-DAB9H(H)E4.fm

TINSZA071SJZZ

Troubleshooting char t

Many potential problems can be resolved by the owner without calling a service technician. If something is wrong with this product, check the following bef ore calling your authorised SHARP dealer or service centre.

 General

Symptom Possible cause

The clock is not set to the

correct time. When a button is pressed,

the unit does not respond.

No sound is heard.

 CD player

Symptom Possible cause

Playback does not start.

Playback stops in the mid-

dle or is not performed properly.

Playback sounds are

skipped, or stopped in the middle of a track.

Did a power failure occur? Reset

the clock. (Refer to page 10.) Set the unit to the power stand-

by mode and then turn it back on. If the unit still malfunctions, reset

it. (Refer to page 37.) Is the volume level set to "0"?

Are the headphones connected?

Are the speaker wires discon-

nected?

Is the disc loaded upside down?

Does the disc satisfy the stan-

dards? Is the disc distorted or

scratched? Is the unit located near excessive

vibrations? Is the disc very dirty?

Has condensation formed inside

the unit?

 Tuner

Symptom Possible cause

The FM makes unusual

noises continuously.

DAB channels cannot be

received.

Sound from DAB chan-

nels is interrupted or distorted.

Secondary services can-

not be received.

 Remote control

Symptom Possible cause

The remote control does

not operate.

Is the unit placed near the TV or

computer? Is the FM aerial placed properly?

Move the aerial away from the AC power lead if it's located nearby.

Signal reception is poor. Adjust

the aerial direction (see page 7). Move the unit to another room or

near the window, then tune in manually (see page 20).

Is the unit placed near the TV or

computer? Move the unit to another room or

near the window, then tune in manually (see page 20).

Some DAB channels do not offer

secondary services. " " appears next to the station name when secondary services are available (see page 19).

Is the AC power lead of the unit

plugged in? Is the battery polarity correct?

Are the batteries dead?

Is the distance or angle incor-

rect? Does the remote control sensor

receive strong light?

XL-DAB9H

ENGLISH

References

E-36

05/7/12 XL-DAB9H(H)E4.fm

TINSZA071SJZZ

XL-DAB9H

ENGLISH

References

Troubleshooting chart (continued)

 If trouble occurs

When this product is subjected to strong external interference (mechanical shock, excessive static electricity, abnormal supply voltage due to lightning, etc.) or if it is oper ated incorrectly, it may malfunction.

If such a problem occurs, do the following:

1 Set the unit to the stand-by mode and turn the power on again. 2 If the unit is not restored in the previous operation, un plug and

plug in the unit, and then turn the power on.

Note:

If neither operation above restores t he unit, cl ear al l the memory by resetting it.

 Clearing all the memory (reset)

1 Press the ON/STAND-BY button to enter the power stand-by

mode. 2 Whilst pressing down the FUNCTION button and the CLEAR

button, press the ON/STAND-BY button until "Clear All"

appears.

Caution:

This operation will erase all data stored in memory including clock, timer settings, tuner preset, CD programme, station list, etc.

 Condensation

Sudden temperature changes, storage or operation i n an ext remely humid environment may cause condensation inside the cabinet (CD pickup, etc.) or on the transmitter on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc in the unit until normal play back is possible (about 1 hour). Wi pe off any condensation on t he transmitter with a soft cloth before operating the unit.

Maintenance

 Cleaning the cabinet

Periodically wipe the cabinet with a soft cloth and a diluted s oap solution, then with a dry cloth.

Caution:

Do not use chemicals for cleaning (petrol, paint thinner, etc.) . It

may damage the cabinet finish. Do not apply oil to the ins ide of the unit. It may cause m alfunc-

tions.

E-37

05/7/12 XL-DAB9H(H)E4.fm

TINSZA071SJZZ

Specifications

As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

 General

Power source AC 230 V, 50 Hz Power

consumption Dimensions Width: 100 mm

Weight 2.3 kg

 Amplifier

Output power PMPO: 30 W (total)

Output terminals S peakers: 4 ohms

Input terminals Line input: 47 k ohms

 Tuner

Frequency range DAB: 174 - 240 MHz (Band-III)

Power on: 25 W Power stand-by: 0.9 W

Height: 205 mm Depth: 266 mm

MPO: 15 W (7.5 W + 7.5 W) (DIN 45 324) RMS: 10 W (5 W + 5 W) (DIN 45 324)

Headphones: 16 - 50 ohms (recommended: 32 ohms)

Line output: 2 k ohms

1,450 - 1,492 MHz (L-Band)

FM: 87.5 - 108.0 MHz

 CD player

Type Compact disc player Signal readout Non-contact, 3-beam semiconductor laser

D/A converter 1-bit D/A converter Frequency

response Dynamic range 90 dB (1 kHz)

pickup

20 - 20,000 Hz

 Speaker

Type 2-way type speaker system

4 cm tweeter 8 cm woofer

Maximum input power

Rated input power 5 W Impedance 4 ohm s Dimensions Width: 100 mm

Weight 1.2 kg/each

10 W

Height: 205 mm Depth: 193 mm

XL-DAB9H

ENGLISH

References

05/7/12 XL-DAB9H(H)E4.fm

E-38

TINSZA071SJZZ

SHARP CORPORATION

0401_A5

TINSZA071SJZZ 05G N YA 1

05/7/12 XL-DAB9H(H)_BACK.fm

TINSZA071SJZZ

U P

DOWN

XL-DAB9H

MICRO COMPONENT SYSTEM

05/7/12 XL-DAB9H(H)_SP.fm

TINSZA071SJZZ

Sharp XL-DAB9H User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
