Sharp XL-60H, XL-70H User Manual

MICRO COMPONENT SYSTEM OPERATION MANUAL

MODEL

XL-60H XL-70H

Thank you for purchasing this SHARP product. To obtain the best performance from this product please read this manual carefully. It will guide you in operating your SHARP product.

XL-60H

XL-60H/XL-70H Micro Component System consisting of XL-60H/XL-70H (main unit) and CP-XL60H/ CP-XL70H (speaker system).

XL-70H

60H/70H(SUK).FRONT 00.1.7, 5:07 PM1

SPECIAL NOTES

NOTE FOR USERS IN THE U.K.

The mains lead of this product is fitted with a nonrewireable (moulded) plug incorporating a 3A fuse. Should the fuse need to be replaced, a BSI or AST A approved BS 1362 fuse marked or and of the same rating as above, which is also indicated on the pin face of the plug must be used.

Always refit the fuse cover after replacing the fuse. Never use the plug without the fuse cover fitted.

Ensure that neither the brown nor the blue wire is connected to the earth terminal in your three pin plug.

Before replacing the plug cover, make sure that:

● If the new fitted plug contains a fuse, its value is the same as that removed from the cut-off plug.

● The cord grip is clamped over the sheath of the mains lead and not simply over the lead wires.

In the unlikely event of the socket outlet in your home not being compatible with the plug supplied, cut-off the mains plug and fit an appropriate type.

DANGER:

The fuse from the cut-off plug should be removed and the cut-off plug destroyed immediately and disposed of in a safe manner. Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket outlet as a serious electric shock may occur. T o fit an appropriate plug to the mains lead, follow the instructions below:

IMPORTANT:

The wires in the mains lead are coloured in accordance with the following code: Blue : Neutral Brown : Live

As the colours of the wires in the mains lead of this product may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:

● The wire which is coloured blue must be connected to the plug terminal which is marked N or coloured black.

● The wire which is coloured brown must be connected to the plug terminal which is marked L or coloured red.

IF YOU HA VE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.

SERVICE INFORMATION

In the unlikely event of your equipment requiring repair, please contact the dealer or supplier from whom it was purchased. Where this is not possible, please contact the telephone number listed below. Y ou will then be given details of how to obtain service.

- 0345-125387 -

Please note; all calls will be charged at local rate. Certain replacement parts and accessories may

be obtained from our main parts distributor.

WILLOW VALE ELECTRONICS LTD.

MANCHESTER 0161-682-1415 READING 01189-876444

In the unlikely event of this equipment requiring repair during the guarantee period, you will need to provide proof of the date of purchase to the repairing company. Please keep your invoice or receipt, which is supplied at the time of purchase.

60H/70H(SUK)01-07 00.1.5, 11:38 AM1

(Continued)

● Recording and playback of any material may require consent, which SHARP is unable to give. Please refer particularly to the provisions of the Copyright Act 1956, the Dramatic and Musical Performers Protection Act 1958, the Performers Protection Acts 1963 and 1972 and to any subsequent statutory enactments and orders.

● This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC.

● When the ON/STAND-BY button is set at STAND-BY position, mains voltage is still present inside the unit. When the ON/STAND-BY button is set at STAND-BY position, the unit may be brought into operation by the timer mode or remote control.

Warning:

● This unit contains no user serviceable parts. Never remove covers unless qualified to do so. This unit contains dangerous voltages, always remove mains plug from the socket before any service operation and when not in use for a long period.

Warning:

● To prevent fire or shock hazard, do not expose this appliance to dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus.

CAUTION

Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

As the laser beam used in this compact disc player is harmful to the eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only.

60H/70H(SUK)01-07 00.1.5, 11:38 AM2

CONTENTS

Page

ACCESSORIES .................................................3

PRECAUTIONS ..............................................4-5

NAMES OF CONTROLS AND INDICATORS .. 5-7

PREPARATION FOR USE ........................... 8-10

SOUND CONTROL .................................... 10-11

SETTING THE CLOCK ................................... 12

COMPACT DISC OPERATION .................. 13-15

CASSETTE OPERATION................................ 16

ACCESSORIES

RADIO OPERATION .................................. 17-18

Page

RDS (Radio Data System) OPERATION..19-26

RECORDING ................................................... 27

HOW TO USE THE BUILT-IN TIMER......... 27-29

USING EXTERNAL UNITS......................... 30-31

RESETTING THE MICROCOMPUTER........... 31

MAINTENANCE .............................................. 31

SPECIFICATIONS ........................................... 32

● Remote control × 1

● AC power lead × 1

● AM loop aerial ×1

Note:

Parts and equipment mentioned in this operation manual other than those in the drawing are not included.

PRECAUTIONS

■ General

● Please ensure that the equipment is positioned

in a well ventilated area and ensure that there is at least 10cm (4”) of free space along the sides and back. There must also be a minimum of 20cm (8”) of free space on the top of the unit.

● Do not use oil, solvents, petrol, paint thinners or

insecticides on the unit.

● Do not expose the unit to moisture, to tempera-

tures higher than 60°C (140°F) or to extreme low temperatures.

● Keep the unit away from direct sunlight, strong

magnetic fields, excessive dust, humidity and electronic/electrical equipment (home computers, facsimiles, etc.) which generate electrical noise.

● Hold the AC power plug by the head when re-

moving it from the AC socket, as pulling the lead can damage internal wires.

● FM aerial × 1

● When cleaning the heads, pinch roller, etc., re-

move the AC power plug from the wall socket as the unit contains high voltages. Do not remove the outer cover, as this may result in electric shock. Refer internal service to your local SHARP service facility .

● Use the unit on a firm, level surface free from vibration, and do not place anything on the top of the unit.

● If an electrical storm is taking place near you, it is suggested that you disconnect the AC power lead from the AC socket for safety.

● The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, tablecloths, curtains, etc.

● No naked flame sources, such as lighted candles, should be placed on the apparatus.

● Attention should be drawn to the environmental aspects of battery disposal.

● The apparatus is designed for use in moderate climate.

60H/70H(SUK)01-07 00.1.5, 11:38 AM3

(Continued)

Warning:

The voltage used must be the same as that specified on this unit. Using this product with a higher voltage than that which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.

■ Volume control

The sound level at a given volume setting depends on a combination of speaker efficiency, location and various other factors. It is advisable to avoid exposure to high volume levels, which occur whilst turning the unit on with the volume control setting up high, or whilst continually listening at high volumes.

Warning:

CD players use a laser pickup which can damage the eyes if viewed directly. Do not look at the pickup, and do not touch the pickup directly.

■ Care of compact discs

Compact discs are fairly resistant to damage, however mistracking can occur due to the accumulation of dirt on the disc surface. Follow the guidelines below for maximum enjoyment from your CD collection and player.

● Do not write on either side of the disc, particularly the non-label side. Signals are read from the non-label side. Do not mark this surface.

● Keep your discs away from direct sunlight, heat, and excessive moisture.

● Always hold the CDs by the edges. Fingerprints, dirt, or water on the CDs can cause noise or mistracking. If a CD is dirty or does not play properly, clean it with a soft, dry cloth, wiping straight out from the centre, along the radius.

■ Cassette tape

● For playback, use normal or low-noise tape for

the best sound. (Metal or CrO2 tape is not recommended.) For recording, use only normal tape.

● Do not use C-120 tapes, tapes with large diameter reels, or poor-quality tapes, as they may cause malfunctions.

● Before loading a tape into the cassette compartment, tighten the slack with a pen or pencil.

● Cassettes have removable tabs which prevent accidental recording or erasing from taking place. Removing the tab will protect the corresponding side from being erased. Cover the tab holes with adhesive tape to erase or record again.

Side A (1)

T ab for side B (2) Tab for side A (1)

■ Condensation

Sudden temperature changes, storage or operation in an extremely humid environment may cause condensation inside the cabinet (CD pickup, tape heads, etc.) or on the transmitter LED on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc (or cassette) in the unit until normal playback is possible (about 1 hour). Wipe off any condensation on the remote control transmitter LED with a soft cloth before operating the unit.

60H/70H(SUK)01-07 00.1.5, 11:38 AM4

YES Correct

NAMES OF CONTROLS AND INDICATORS

■ Front panel

1. Timer Indicator

2. Record Indicator

3. Sleep Indicator

4. (CD) Random Indicator

5. (CD/TUNER) Memory Indicator

6. RDS Indicator

7. Traffic Programme Indicator

8. Traffic Announcement Indicator

9. FM Stereo Mode Indicator

10. FM Stereo Indicator

11. (CD) Play Indicator

12. (CD) Repeat Indicator

13. EON Indicator

14. Programme Type Indicator

15. Traffic Information Indicator

16. Surround Indicator

17. CD Compartment

18. EON Button

19. On/Stand-by Button

20. Programme Type/Traffic Information Search Button

21. Surround Button

22. CD Open/Close Button

23. ASPM Button

24. Remote Control Sensor

25. Display Mode Selector Button

26. Volume Select Button

27. (CD/TAPE) Stop Button (TUNER) Memory Clear Button

28. Record Pause Button

29. Bass/Treble Selector Button

30. Memory/Set Button

31. Clock/Timer/Sleep Button

32. Band Selector Button

33. (CD) Review Button (TAPE) Rewind Button (TUNER) Tuning Down Button

34. Function Selector Button

35. Headphone Socket

36. (CD) Play/Pause Button (TAPE) Play Button

37. Jog Dial

38. (CD) Cue Button (TAPE) Fast Forward Button (TUNER) Tuning Up Button

39. Volume/Jog Dial Selector Button

40. Cassette Compartment

17 18 19

20 21

27 28

29 30

31 32

33 34

10 16

22 23

24 25 26

36 37

38 39

60H/70H(SUK)01-07 00.1.5, 11:38 AM5

(Continued)

■ Rear panel

1. CD Digital Output Socket

2. AC Power Input Socket

3. FM 75 ohms Aerial Socket

4. AM Loop Aerial Input Socket

5. Video/Auxiliary (Audio Signal) Input Sock-

3 4

ets

6. Speaker Terminals

■ Speaker section

CP-XL60H

1. Tweeter

2. Woofer

3. Bass Reflex Duct

4. Speaker Wire

CP-XL70H

1. Tweeter

2. Woofer

3. Bass Reflex Duct

4. Speaker Wire

60H/70H(SUK)01-07 00.1.5, 11:38 AM6

(Continued)

2 4

5 6

11 12

16 17

18 19 20

■ Remote control

1. Remote Control Transmitter LED

● Tuner control section

2. Programme Type/Traffic Information

3 7

8 9

10 13

14 15

21 22

Search Button

3. Preset Up/Down Buttons

● CD control section

4. Clear Button

5. Random/Repeat Button

6. Memory Button

7. Stop Button

8. Play/Pause Button

9. Track Down/Review Button

10. Track Up/Cue Button

● Tape control section

11. Record Pause Button

12. Rewind Button

13. Stop Button

14. Play Button

15. Fast Forward Button

● Common section

16. Surround Button

17. Sleep Button

18. Bass Up/Down Buttons

19. Function Selector Buttons

20. On/Stand-by Button

21. Timer Button

22. Clock Button

23. Treble Up/Down Buttons

24. Volume Up/Down Buttons

60H/70H(SUK)01-07 00.1.5, 11:38 AM7

PREPARATION FOR USE

● Unplug the AC power lead from the AC socket before connecting or disconnecting any component.

■ Speaker connection

Right speaker

Left speaker

White line

■ Removing the speaker grilles

1 Remove the lower part of the speaker grille first. 2 Remove the upper part of the speaker grille.

Caution:

When the speaker grilles are removed, the speaker diaphragms are exposed. Make sure nothing comes into contact with the speaker diaphragms.

■ Mounting the speaker grilles

Fit the four posts on the speaker grille into the mounting holes and push them lightly with the palm of your hand to secure.

Connect each speaker wire to the SPEAKER terminals as shown. Use speakers with an impedance of 4 ohms or more. Use of speakers with an impedance less than 4 ohms may damage your unit.

Notes:

● Connect the wire with the white line to the minus (-) terminal and the plain wire to the plus (+) terminal.

● Do not mix the right channel and left channel wiring when connecting the speakers to the unit.

● Do not let the bare speaker wires touch each other as this may damage the amplifier and/or speakers.

● Do not allow any objects to fall into or to be placed in the bass reflex ducts.

*60H/70H(SUK)08-12 00.1.5, 11:39 AM8

(Continued)

■ Aerial connection

FM aerial

Supplied FM aerial

Connect the FM aerial wire to the FM 75 OHMS socket and position the FM aerial wire in the direction where the strongest signal can be received.

Supplied AM loop aerial

Connect the AM loop aerial wire to the AM LOOP socket. Position the AM loop aerial for optimum reception. Place the AM loop aerial on a shelf, etc., or attach it to a stand or wall with screws (not supplied).

Notes:

● Do not place the aerial on the main unit as it may result in noise pickup from the internal digital electronics. Place the aerial away from the unit for better reception.

● If the AM loop aerial and the FM aerial wire are placed near the AC power lead, it may cause interference in radio reception.

AM loop aerial

External FM aerial

■ Connecting the AC power lead

AC 230 V, 50Hz

T o AC INPUT

To an AC socket

Connect the AC power lead to the AC power input socket, then connect the AC power lead plug to an AC socket.

Notes:

● Unplug the AC power lead from the AC socket if the unit is not to be used for a prolonged period of time.

● Never use a power lead other than the one supplied. Otherwise, a malfunction or an accident may occur.

■ Placing the system

10 cm (4")

20 cm (8")

10 cm (4")

External FM aerial

Use an external FM aerial if you need better reception. Consult your dealer.

*60H/70H(SUK)08-12 00.1.5, 11:39 AM9

● Be sure to keep space between the units for ven-

tilation.

● Keep the top of this unit at least 20 cm (8") away

from the wall, and the back at least 10 cm (4") away.

Note:

● Do not place the system or speakers near the

television set as the magnetic fields produced may cause irregular colours to be displayed.

(Continued)

■ Remote control

● 2 “AA” size batteries (UM/SUM-3, R6, HP-7

or similar)

● Batteries are not included.

0.2m - 6m (8” - 20”)

SOUND CONTROL

● When inserting or removing the batteries, push them towards the ë battery terminals.

● Installing the batteries incorrectly may cause the unit to malfunction.

Precautions for battery use:

● Insert the batteries according to the direction indicated in the battery compartment.

● Replace all old batteries with new ones at the same time.

● Do not mix old and new batteries.

● Remove the batteries if they are weak or if the

unit will not be used for long periods of time. This will prevent potential damage due to battery leakage.

Caution:

Do not use rechargeable batteries (nickel-cadmium battery, etc.).

Notes concerning use:

● Replace the batteries if the operating distance is reduced or if the operation becomes erratic.

● Periodically clean the transmitter LED on the remote control and the sensor on the main unit with a soft cloth.

● Exposing the sensor on the main unit to strong light may interfere with operation. Change the lighting or the direction of the unit.

● Keep the remote control away from moisture, excessive heat, shock, and vibrations.

■ Volume

(Main unit)

MIN 15 MAX

(Main unit operation)

When the VOLUME control is turned clockwise, the volume will increase. When it is turned anti-clockwise, the volume will decrease.

(Remote control operation)

Press the VOLUME button to increase the volume and the VOLUME button to decrease the volume.

*60H/70H(SUK)08-12 00.1.5, 11:39 AM10

(Remote control)

Servo Powered V olume:

● The jog dial automatically comes out when the power is turned on, and goes back when the unit is set to the stand-by mode.

● When the power is turned on, you can put the jog dial in and out by pressing the VOLUME SELECT button.

Note:

Do not push in the jog dial forcibly with your finger.

+ 25 hidden pages
