Sharp R-6781J User Manual

ENGLISH
Important
800 W (IEC test procedure)
R-6781J
MICROWAVE OVEN WITH
TOP AND BOTTOM GRILL
OPERATION MANUAL WITH COOKBOOK
This operation manual contains important information which you should read carefully before using
your microwave oven.
IMPORTANT: There may be a serious risk to health if this operation manual is not followed or if the oven
is modified so that it operates with the door open.
R-6781J English 31/08/2004 16:15 Page A
R-6781J English 31/08/2004 16:15 Page B
ENGLISH
VJLTKM R-6781J IFHG cjjndtncndetn nht<jdfzbyv zjhvfnbdzsü ljrevtznjd:
Gj <tpjgfczjcnb UJCN H VÄR 335-2-25-97 UJCN H 51318.44.1-99 UJCN H 51318.14.2-99 Gj ÄVC UJCN 51318.11-99
Dj bcgjkztzbt Cnfnmb 5 Pfrjzf Hjccbqcrjq Atlthfwbb ≤J pfobnt ghfd gjnht<bntktq≥, f nfröt Erfpf Ghfdbntkmcndf Hjccbqcrjq Atlthfwbb @ 720 jn 16 b+zy 1997 u. ecnfzfdkbdftncy chjr ckeö<s lfzzjq vjltkb 7 ktn c vjvtznf ghjbpdjlcndf ghb eckjdbb bcgjkmpjdfzby d cnhjujv cjjndtncndbb c bzcnherwbtq gj ärcgkefnfwbb b ghbvtzytvsvb ntüzbxtcrbvb cnfzlfhnfvb.
Cnhfzf-bpujnjdbntkm: Ghjbpdtltzj d Fzukbb Abhvf-bpujnjdbntkm: IFHG Rjhgjhtqiz *hblbxtcrbq flhtc bpujnjdbntky:
22-22 Zfufqrt-xj, F<tzj-re, Jcfrf 545-8522, Ygjzby
BZAJHVFWBY J CTHNBABRFWBB GHJLERWBB
VBRHJDJKZJDFY GTXM C UHBKTV
VJLTKM R-6781J IFHG
cthnbabwbhjdfzf HJCNTCN—VJCRDF
R-6781J English 31/08/2004 16:15 Page C
ГА РАНТИЙНЫЙ ТАЛОН НА ИЗДЕЛИЕ SHARP
Уважаемый покупатель!
Выражаем Вам признательность за выбор изделия SHARP.
В течение гарантийного срока, начинающегося с даты покупки изделия первым покупателем, гарантия на изделие SHARP предоставляется в отношении любых дефектов, произошедших по вине производителя.
Настоящая гарантия действительна в течение 12 (двенадцати) месяцев (36 (тридцати шести) месяцев на ЖК телевизоры; 36 (тридцати шести) месяцев на компрессоры для холодильников; 24 (двадцати четырех) месяцев на магнетроны для СВЧ печей;) с даты покупки изделия первым покупателем при соблюдении условий, перечисленных ниже, если рекомендованные режимы эксплуатации изделия, изложенные в инструкции по эксплуатации, полностью соблюдены.
Если Ваше изделие SHARP нуждается в гарантийном обслуживании, обращайтесь в один из Специализированных Сервисных Центров, информация о которых приведена на внутренней стороне талона. Настоящая гарантия предусматривает замену дефектных узлов и деталей и выполнение ремонтных работ бесплатно.
Гарантия действительна на территории Российской Федерации при соблюдении следующих условий:
1. Данное изделие должно быть куплено на территории Российской Федерации.
2. Данное изделие должно быть использовано в соответствии с инструкцией по эксплуатации (прилагается к изделию). В случае нарушения правил хранения, транспортировки, установки и эксплуатации, изложенных в инструкции по эксплуатации, гарантия недействительна.
3. Гарантия действительна только при наличии четко, правильно и полностью заполненного настоящего гарантийного талона (с подписью и печатью Продавца). Без предъявления данного талона, в случае отсутствия в нем полной информации или при наличии каких-либо изменений в талоне, претензии к качеству изделия не принимаются, и гарантийный ремонт не производится.
4. Гарантия недействительна: а) если изделие имеет механические повреждения б) если изделие ремонтировалось, или в нем произведены изменения не в авторизованном сервисном
центре в) если использовались ненадлежащие расходные материалы или запасные части г) если неисправность вызвана попаданием внутрь изделия посторонних предметов, веществ,
жидкостей, насекомых и т.п. д) если неисправность вызвана стихийными бедствиями, пожаром, бытовыми и другими факторами,
независящими от SHARP е) если повреждения вызваны несоответствием параметров источников питания и связи
соответствующим государственным стандартам ж) в случае любых изменений в установке, настройке и/или программировании. з) в случае внесения несанкционированных изменений в гарантийный талон (поправок и исправлений) и) если серийный номер или номер модели на изделии изменен, удален, стерт или неразборчивый
5. Гарантия не распространяется на расходные материалы, например: картриджи, лампы, программное обеспечение, фильтры, батареи и т. п. в соответствии с указаниями инструкции по эксплуатации.
6. Гарантия не предусматривает чистку изделия, плановое техническое обслуживание и замену расходных материалов и запчастей, пришедших в негодность ввиду нормального износа и / или ограниченного срока службы.
7. Настоящая гарантия распространяется на официально поставляемые изделия, приобретенные для личного использования, не связанного с извлечением прибыли.
8. Настоящая гарантия применяется дополнительно к обязательным гарантиям, предоставляемым покупателям законом.
Внимание!
Настоящая гарантия осуществляется только при наличии правильно заполненного гарантийного талона и оригинала товарного чека с указанием даты продажи.
Список авторизованных сервис-центров может быть изменен без предварительного уведомления.
SHARP ELECTRONICS (EUROPE) GMBH
R-6781J English 31/08/2004 16:15 Page D
ENGLISH
Город Название Адрес Телефон
Москва КДС-Технический центр 123290, Шелепихинская наб., 18 (095) 797-34-34 Москва Алина-Видеопроф-Сервис 115470, Нагатинская наб., 40/1, стр. 5 (095) 118-01-56, 118-19-90 Москва Алина-Видеопроф-Сервис 109172, ул. Большие Каменщики, 19 (095) 912-90-13, 912-76-23 Москва Алина-Видеопроф-Сервис 109280, Ослябинский пер., 3 (095) 275-78-21, 741-25-44 Москва Алина-Видеопроф-Сервис 109172, Краснохолмская наб., 13/15, стр. 1 (095) 912-99-27, 912-98-75 Москва Алина-Видеопроф-Сервис 109369, Новочеркасский б-р, 13 (095) 357-40-51, 356-61-54 Москва Алина-Видеопроф-Сервис 103064, ул. Казакова, 13 (095) 261-90-12 Москва Алина-Видеопроф-Сервис 103055, ул. Новослободская, 48/2 (095) 973-25-71 Архангельск Архсервис-центр 163046, ул. Воскресенская, 85 (8162) 66-18-66 Астрахань Марктех 414000, ул. Володарского, 12 (8512) 22-36-33, 39-43-92 Белгород Союз-Сервис 308034, пр-т Ватутина, 5a (0722) 25-34-00, 54-20-20 Братск Лексика Электроникс 655708, ул. Пионерская, 23 (3953) 47-69-07, 45-13-67 Владимир Электрон-Сервис 600022, ул. Ново-Ямская, 73 (0922) 24-08-19 Волгоград Планета-Сервис и К 400107, ул. Рионская, 3 (8442) 39-62-38, 39-51-01 Волгоград Радиотехника 400006, ул. Штеменко, 33 (8442) 77-15-12, 72-71-27 Волгоград Мир Видео-1 400005, пр-т Ленина, 58/1 (8442) 34-41-36, 34-05-94 Волжский Мир Видео-1 404127, ул. Дружбы, 21 (8443) 56-60-22 Воронеж Орбита-Сервис 394030, ул. Донбасская, 1 (0732) 77-66-25 Воронеж Радиоимпорт-Сервис 394052, ул. Матросова, 66 (0732) 76-96-00, 36-25-95 Екатеринбург Сентри 620098, пр-т Космонавтов, 45 (3432) 35-86-02 Екатеринбург Норд-Сервис 620057, ул. Донская, 31 (3432) 35-94-43, 34-24-37 Ижевск ДС 426000, ул. Карла Маркса, 393 (3412) 43-16-42, 43-50-64 Иркутск Эверест 664040, 15-й Советский пер., 2 (3952) 45-19-11, 53-12-92 Казань Ай-Ти-Эс 420105, ул. Сакко и Ванцетти, 8 (8432) 92-59-62 Казань Техника 420043, ул. Вишневского, 14 (8432) 38-31-37, 38-31-07 Калининград Вестер-Сервис 236029, ул. Горького, 50 (0112) 27-34-32, 27-31-51 Калуга Мастер-Сервис 248600, ул. Рылеева, 39 корп. 2 (0842) 56-18-21, 56-18-22 Киров Экран-Сервис 610027, ул. Воровского, 43 (8332) 37-20-78, 67-00-98 Королев Паллада 141070, ул. Фрунзе, 17 (095) 511-83-64 Кострома Аксон Сервис 156603, ул. Станкостроительная, 5б (0942) 22-05-12, 22-03-82 Красноярск Интернационал Сервис 660062, ул. Вильского, 3 (3912) 45-33-05 Красноярск Дон-ТВ Сервис 660025, ул. Железнодорожников, 11 (3912) 21-94-82, 36-67-09 Курган ТВ-Сервис 640020, ул. Кирова, 83 (3522) 22-75-42, 22-34-43 Курск Экран Сервис Лимитед 305001, ул. Добролюбова, 17 (0712) 56-00-51, 56-00-53 Липецк СПС-Липецк 398600, Петровский пр-д, 1 (0742) 77-74-56, 77-38-76 Магадан ВидеоСервис 685000, ул. Гагарина, 28в, оф. 64 (41322) 757-06 Нижний Новгород Бытовая Автоматика 603086, б-р Мира, 16 (8312) 77-57-79 Нижний Новгород Электроника 603005, ул. Алексеевская, 9 (8312) 19-41-08, 19-41-10 Нижний Новгород Электроника 603016, ул. Лескова, 8 (8312) 59-46-20, 54-68-18 Новосибирск Сонико-Н 630112, ул. Красина, 51 (3832) 77-76-96, 77-02-64 Новый Уренгой Анкор 629300, ул. 26-го съезда КПСС, 10б (34949) 461-45, 461-56 Ноябрьск ТелеРадиоБытТехника 629807, Тюменская обл., ул. Городилова, 8 (34964) 512-38, 233-94 Обнинск Радиотехника 249037, ул. Треугольная, 1 (08439) 644-14, 613-73 Омск Сибтекс 644077, пр-т Мира, 47 (3812) 26-84-39, 26-84-41 Оренбург КомИнКом 460052, ул. Брестская, 7 (3532) 62-68-88, 62-77-01
Авторизованные сервисные центры
R-6781J English 31/08/2004 16:15 Page E
Информацию об авторизованных сервисных центрах в других регионах и о сервисных центрах наших торговых партнеров, Вы можете узнать у фирмы, продавшей Вам товар, на интернет­странице ht
tp://www.sharp.ru или по бесплатному междугороднему телефону 8-800-200-7427.
Город Название Адрес Телефон
Орск Аста-Сервис 462431, пр-т Ленина, 77 (35372) 173-97, 145-99 Пермь ЛЭБТ 614077, б-р Гагарина, 58а (3422) 90-34-00, 90-34-80 Псков Фронда 180007, ул. Киселева, 16, оф. 21 (8112) 44-31-98, 44-61-98 Ростов-на-Дону Элтех 344079, ул. Ленина, 63 (8632) 47-41-52, 62-52-68 Ростов-на-Дону Софт-Сервис 344011, пер. Островского, 124 (8632) 99-30-60, 32-37-90 Ростов-на-Дону ТВ-Сервис 344018, ул. Мечникова, 73д (8632) 34-51-21 Рыбинск Самсон 152900, ул. Ломоносова, 3 (0855) 20-14-04, 52-81-09 Рязань Фаворит 390000, ул. Астраханская, 21, Дом Быта, комн. 112 ( 091 2) 28-99-22 Рязань Сервисный Центр 390011, Куйбышевское шоссе, 21 (0912) 44-63-17 Санкт-Петербург РемCервис 190068, пр-д Римского-Корсакова, 37/15 (812) 327-05-79, 327-05-80 Санкт-Петербург Сонико 191158, Московское шоссе, 16/1 (812) 126-53-89, 127-21-29 Санкт-Петербург Курсор-Сервис 192283, Загребский б-р, 33/1 (812) 108-20-19, 101-73-97 Самара Энон-Сервис 443090, ул. Советской Армии, 148 (8462) 24-07-40, 24-43-61 Самара Мелодия-Сервис 443110, пр-т Ленина, 3 (8462) 36-90-92 Самара Сервис-Центр 443096, ул. Мичурина, 15 (8462) 34-94-28, 34-94-63 Самара Сервис-Центр 443096, пр-т Ленина, 14 (8462) 34-29-79 Самара Сервис-Центр 443096, ул. Мориса Тереза, 13а (8462) 16-88-54 Саранск Видео-Сервис 430016, ул. Терешковой, 18a (8342) 24-54-85 Саратов Аэлита 410005, ул. Пугачевская, 157 (8452) 51-75-61 Саратов Архипелаг 2002 410600, ул. Московская, 134/146 (8452) 51-66-33, 51-68-06 Сочи Техинсервис 354000, ул. Юных Ленинцев, 1 (8622) 62-02-95 Та г анрог АСЦ Кристи 347900, ул. Фрунзе, 45 (8634) 46-47-54, 38-30-48 Тамбов БВС-2000 392002, ул. Энгельса, 5 (0752) 75-17-18 Тобольск Тюмень Импорт-Сервис 625456, ул. Ремезова, 3 (34511) 589-11 Томск ДС 634034, ул. Учебная, 26 (3822) 42-74-50, 42-74-28 Томск Спектр 634063, ул. С. Лазо, 15 (3822) 67-35-73, 67-33-55 Томск Академия-Сервис 634055, Академический пр., 1, бл. А, оф. 204 (3822) 25-85-80, 25-98-08 Тюмень Тюмень Импорт-Сервис 625026, ул. Мельникайте, 97 (3452) 22-35-31, 31-12-80 Тюмень Аверс-Сервис 625007, ул. Мельникайте, 131a (3452) 39-12-18, 39-12-29 Ульяновск Мастер-Сервис 432017, ул. Минаева, 42 (8422) 32-07-33 Ульяновск Апрель 432600, ул. Л. Толстого, 38 (8422) 32-78-89, 31-83-72 Уссурийск Вега-Гарант 692508, ул. Советская, 29 (42341) 400-39, 210-35 Уфа Альянс-Сервис 450104, ул. Российская, 21 (3472) 31-45-49, 35-58-31 Хабаровск Контур-Сервис 680009, пр-т 60-летия Октября, 210 (4212) 72-85-02 Чебоксары ВТИ-Сервис 428029, пр-т И. Яковлева, 4/2 (8352) 20-65-94, 20-64-64 Челябинск Импорт-Сервис-Челябинск 454080, ул. Энтузиастов, 16 (3512) 34-04-95, 34-05-05 Челябинск Импорт-Сервис-Челябинск 454070, ул. Гагарина, 8 (3512) 52-05-05 Челябинск Импорт-Сервис-Челябинск 454075, ул. Комарова, 114 (3512) 72-66-00 Челябинск Импорт-Сервис-Челябинск 454078, ул. Комаровского, 4 (3512) 61-05-49 Челябинск РемБытТехника 454081, ул. Артиллерийская, 102 (3512) 72-72-28, 72-56-01
Авторизованные сервисные центры
R-6781J English 31/08/2004 16:15 Page F
ENGLISH
Уважаемый Покупатель!
Во избежание лишних проблем просим Вас внимательно ознакомиться с информацией, содержащейся в гарантийном талоне и инструкции по эксплуатации.
Настоящим Я подтверждаю, что приобрел данное изделие Шарп пригодным к эксплуатации, в полном комплекте и с русской инструкцией по эксплуатации.
ФИО покупателя Подпись
Информация о приобретении изделия
Модель
Серийный номер
Дата приобретения
Цена
Подпись Продавца / Печать
Адрес Продавца
Продавец / Компания
Улица
Город
Телефон
Информация о Покупателе
ФИО
Улица
Город
Телефон
Журнал Гарантийных Работ
Дата приема Дата выдачи Тип дефекта, описание, Фамилия и подпись изделия в ремонт изделия ремонтных работ и инженера, печать
использованные запасные сервисного центра части
R-6781J English 31/08/2004 16:15 Page G
R-6781J English 31/08/2004 16:15 Page H
1
CONTENTS
ENGLISH
OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
BEFORE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
SETTING THE CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
ENERGY SAVE MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
USING THE STOP BUTTON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
MICROWAVE POWER LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
MICROWAVE COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
GRILL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 11
HEATING WITHOUT FOOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
DUAL COOKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
OTHER CONVENIENT FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 - 14
AUTOMATIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 - 16
PIZZA CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
AUTO COOK CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
AUTO DEFROST CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
RECIPES FOR AUTOCOOK AC-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
SERVICE CALL CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
COOKBOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 - 45
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
R-6781J English 31/08/2004 16:15 Page 1
2
OVEN AND ACCESSORIES
1. Grill heating element (top grill)
2. Oven lamp
3. Control panel
4. Door opening button
5. Waveguide cover
6. Oven cavity
7. Turntable motor shaft
8. Grill heating element (bottom grill)
9. Door seals and sealing surfaces
10. Ventilation openings
11. Power cord
12. Outer cabinet
ACCESSORIES:
Check to make sure the following accessories are provided:
13. Turntable
14. Rack
Place the turntable over the turntable motor shaft on the floor of the cavity. Before first using the turntable and the rack, clean with mild soapy water. Do not cut or scratch the turntable.
3
4
10
11
13
8
14
NOTE:
When you order accessories, please mention the part name and model name to your dealer or SHARP authorised service agent.
12
56789
12
WARNING: The accessories (e.g. turntable) will become very hot during Grill, Dual and Automatic operation (except Auto Defrost) modes. Always use thick oven gloves when removing the food or turntable from the oven to prevent burns.
R-6781J English 31/08/2004 16:15 Page 2
Operating buttons 7 LESS/MORE buttons 8 PIZZA button 9 AUTO DEFROST button 10 COOKING MODE dial
Rotate the dial so that indicator points to appropriate symbol:
Microwave Microwave and Top Grill Microwave and Bottom Grill Top Grill Bottom Grill Top and Bottom Grills
11 WATT button 12 TIME/WEIGHT dial 13 STOP button 14 (START) +1min button 15 CLOCK button 16 AUTO COOK button
Digital Display and Indicators
1 LESS/MORE indicator 2 AUTO indicator - will light during automatic
operation
3WEIGHT (KG) indicator 4 MICROWAVE (WATT) indicator 5 CLOCK SET/TIMER indicator 6COOKING IN PROGRESS indicator
3
CONTROL PANEL
ENGLISH
8
9
10
11
13
12
14
7
16
15
2
3456
1
R-6781J English 31/08/2004 16:15 Page 3
To avoid the danger of fire
The microwave oven should not be left unattended during operation. Power levels that are too high or cooking times that are too long may overheat foods resulting in a fire.
This oven is not designed to fit into a kitchen unit. The electrical outlet must be readily accessible so that the unit can be unplugged easily in an emergency. The AC power supply must be 230 V, 50 Hz, with a minimum 16 A distribution line fuse, or a minimum 16 A distribution circuit breaker. It is recommended that a separate circuit serving only this appliance be provided. Do not place the oven in areas where heat is generated. For example, close to a conventional oven. Do not install the oven in an area of high humidity or where moisture may collect. Do not store or use the oven outdoors.
If food being heated begins to smoke, DO NOT OPEN THE DOOR. Turn off and unplug the oven and wait until the food has stopped smoking. Opening the door while food is smoking may cause a fire.
Use only microwave-safe containers and utensils. See Page 22 - 23.
Do not leave the oven unattended when using disposable plastic, paper or other combustible food containers.
Clean the waveguide cover, the oven cavity and the turntable after use. After cooking fatty foods without a lid, always clean the cavity and especially the grill heating elements thoroughly. These must be dry and free from grease. Built-up grease may overheat and begin to smoke or catch fire.
Do not place flammable materials near the oven or ventilation openings. Do not block the ventilation openings. Remove all metallic seals, wire twists, etc., from food and food packages. Arcing on metallic surfaces may cause a fire. Do not use the microwave oven to heat oil for deep frying. The temperature cannot be controlled and the oil may catch fire.
4
IMPORTANT SAFETY INSTRUCTIONS
To make popcorn, use only special microwave popcorn makers. Do not store food or any other items inside the oven. Check the settings after you start the oven to ensure the oven is operating as desired. See the corresponding hints in the cookery book section.
To avoid the possibility of injury
WARNING:
Do not operate the oven if it is damaged or malfunctioning. Check the following before use: a)The door; make sure the door closes properly
and ensure it is not misaligned or warped.
b)The hinges and safety door latches; check to
make sure they are not broken or loose.
c)The door seals and sealing surfaces; ensure
that they have not been damaged.
d)Inside the oven cavity or on the door; make
sure there are no dents.
e)The power supply cord and plug; ensure that
they are not damaged.
Never adjust , repair or modify the oven yourself. It is hazardous for anyone other than a competent person to carry out any service or repair operation which involves the removal of a cover which gives protection against exposure to microwave energy.
Do not operate the oven with the door open or alter the door safety latches in any way. Do not operate the oven if there is an object between the door seals and sealing surfaces.
Do not allow grease or dirt to build up on the door seals and adjacent parts. Follow the instructions for “Care and Cleaning” on page 20. Failure to maintain the oven in a clean condition could lead to a deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
Individuals with PACEMAKERS should check with their doctor or the manufacturer of the pacemaker for precautions regarding microwave ovens.
To avoid the possibility of electric shock
Under no circumstances should you remove the outer cabinet.
IMPORTANT SAFETY INSTRUCTIONS: READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
R-6781J English 31/08/2004 16:15 Page 4
5
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
Pierce the skin of such foods as potatoes, sausages and fruit before cooking, or they may explode.
To avoid the possibility of burns
Use pot holders or oven gloves when removing food from the oven to prevent burns. Always open containers, popcorn makers, oven cooking bags, etc., away from the face and hands to avoid steam burns.
To avoid burns, always test food temperature and stir before serving and pay special attention to the temperature of food and drink given to babies, children or the elderly.
Temperature of the container is not a true indication of the temperature of the food or drink; always check the food temperature. Always stand back from the oven door when opening it, to avoid burns from escaping steam and heat. Slice stuffed baked foods after heating to release steam and avoid burns. Keep children away from the door and accessible parts that may become hot when the grill is in use. Children should be kept away to prevent them burning themselves. Do not touch the oven door, outer cabinet, rear cabinet, oven cavity, ventilation openings, bottom grill, accessories and dishes during GRILL, DUAL and AUTOMATIC operation (except AUTO DEFROST) as they will become hot. Before cleaning make sure they are not hot.
To avoid misuse by children
WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.
Do not lean or swing on the oven door. Do not play with the oven or use it as a toy. Children should be taught all important safety instructions: use of pot holders, careful removal of food coverings; paying special attention to packaging (e.g. self-heating materials) designed to make food crisp, as they may be extra hot.
Never spill or insert any objects into the door lock openings or ventilation openings. In the event of a spill, turn off and unplug the oven immediately, and call an authorised SHARP service agent. Do not immerse the power supply cord or plug in water or any other liquid. Do not let the power supply cord hang over the edge of a table or work surface. Keep the power supply cord away from heated surfaces, including the rear of the oven. Do not attempt to replace the oven lamp yourself or allow anyone who is not an electrician authorised by SHARP to do so. If the oven lamp fails, please consult your dealer or an authorised SHARP service agent. If the power supply cord of this appliance is damaged, it must be replaced by an authorised SHARP service agent.
To avoid the possibility of explosion and sudden boiling:
WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
Never use sealed containers. Remove seals and lids before use. Sealed containers can explode due to a build up of pressure even after the oven has been turned off. Take care when microwaving liquids. Use a wide­mouthed container to allow bubbles to escape.
Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when handling the container.
To prevent sudden eruption of boiling liquid and possible scalding:
1. Stir liquid prior to heating/reheating.
2. It is advisable to insert a glass rod or similar
utensil into the liquid whilst reheating.
3. Let liquid stand for at least 20 seconds in the
oven at the end of cooking time to prevent delayed eruptive boiling.
Do not cook eggs in their shells, and whole hard boiled eggs should not be heated in microwave ovens since they may explode even after microwave cooking has ended. To cook or reheat eggs which have not been scrambled or mixed, pierce the yolks and the whites, or the eggs may explode. Shell and slice hard boiled eggs before reheating them in the microwave oven.
R-6781J English 31/08/2004 16:15 Page 5
6
IMPORTANT SAFETY INSTRUCTIONS
Other warnings
Never modify the oven in any way. Do not move the oven while it is in operation. This oven is for home food preparation only and may only be used for cooking food. It is not suitable for commercial or laboratory use.
To promote trouble-free use of your oven and avoid damage.
Never operate the oven when it is empty except where recommended in the operation manual, see Page 11. Doing so may damage the oven. When using a browning dish or self-heating material, always place a heat-resistant insulator such as a porcelain plate under it to prevent damage to the turntable due to heat stress. The preheating time specified in the dish’s instructions must not be exceeded. Do not use metal utensils, which reflect microwaves and may cause electrical arcing. Do not put cans in the oven.
Use only the turntable designed for this oven. Do not place anything on the outer cabinet during operation. Do not use plastic containers for microwaving if the oven is still hot from using the GRILL, DUAL and
AUTOMATIC operation (except AUTO DEFROST), because they may melt. Plastic
containers must not be used during above modes unless the container manufacturer says they are suitable.
NOTE:
If you are unsure how to connect your oven, please consult an authorised, qualified electrician. Neither the manufacturer nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the correct electrical connection procedure. Water vapour or drops may occasionally form on the oven walls or around the door seals and sealing surfaces. This is a normal occurrence and is not an indication of microwave leakage or a malfunction.
INSTALLATION
1. Remove all packing materials from the inside of the
oven cavity. Discard the loose polythene sheet from between the door and cavity. Remove the feature sticker, if attached, from the outside of the door.
2. Check the oven carefully for any signs of damage.
3. Place the oven on a flat, level surface strong
enough to support the oven’s weight plus the heaviest item likely to be cooked.
4. The oven door may become hot during cooking. Place or mount the oven so that the bottom of the oven is 85 cm or more above the floor. Keep children away from the door to prevent them burning themselves.
5. Do not allow the power supply cord to
run over any hot or sharp surfaces, such as the hot air vent area at the top rear of the oven.
6.Ensure there is a minimum of free space above the
oven of 20 cm.
7. Securely connect the plug of the oven to a
standard earthed (grounded) household electrical outlet.
Remove this film
20 cm
R-6781J English 31/08/2004 16:15 Page 6
7
BEFORE OPERATION
SETTING THE CLOCK
ENGLISH
Your oven comes pre-set for Energy Save Mode so when you first plug it in nothing will appear on the digital display.
To operate the oven in Energy Save Mode:
1. Plug in the oven. Nothing will appear on the display at this time.
2. Open the door. The oven display will show “.0”.
3. Close the door.
4. Heat the oven without food (See page 11). NOTE: You can change to Clock Set Mode if you prefer, see below. If you decide to set the clock, Energy
Save Mode does not work.
In Energy Save Mode, if you do not operate the oven for 2 minutes or more (i.e. closing the door, pressing the STOP key, or at the end of cooking), you will not be able to operate the oven until you open and close the oven door.
If this occurs during cooking, the programme will be erased. The time of day will also be erased.
5. When you want to reset the time of day, follow the
above example again.
6. If you do not set the clock, press the STOP button
once. “.0” will appear on the display. When the operation of the oven is finished, “.0” will reappear on the display instead of the time of day.
7. If you set the clock, energy save mode does not work.
There are two setting modes: 12 hour clock and 24 hour clock.
x1
1. To set the 12 hour clock, press the CLOCK button once, as shown:
Example: To set the 24 hour clock to 23:35:
x2
1. Choose the 24 hour clock by
pressing the CLOCK button twice.
2. Set the hours. Rotate the TIME/ WEIGHT dial clockwise until the
correct hour is displayed.
3. Change from hours to
minutes by pressing the
CLOCK button once.
Check the display.
4. Set the minutes.
5. Start the clock.
NOTES:
1. You can rotate the TIME/WEIGHT dial clockwise or
counter clockwise.
2. Press the STOP button if you make a mistake during
programming.
3. If the oven is in cooking mode and you wish to know the time of day, touch the CLOCK button. As long as your finger is touching the button, the time of day will be displayed.
4. If the electrical power supply to your microwave oven is interrupted, plug in the oven again, then open and close the door. The display will show: “.0”.
x2
2. To set the 24 hour clock, press the CLOCK button twice, as shown:
x1
x1
R-6781J English 31/08/2004 16:15 Page 7
ENERGY SAVE MODE
8
USING THE STOP BUTTON
Use the STOP button to:
1. Erase a mistake during programming.
2. Stop the oven temporarily during cooking.
3. Cancel a programme during cooking, press the STOP button twice.
1. Make sure the
correct time appears on the display.
3. Adjust the display
to 0 by rotating the
TIME/WEIGHT
dial.
2. Press the CLOCK
button once.
x1
4. Press (START) +1min
button. The power will be off and the display will show nothing.
Display:
x1
Your oven has two operating modes, Energy Save Mode and Clock Set Mode. The difference between them is that when you are not using the oven, in Energy save Mode nothing will appear on the digital display and in Clock Set Mode the time will be shown.
In Energy Save Mode, if you do not operate the oven for 2 minutes or more (i.e. closing the door, pressing the STOP key, or at the end of cooking), you will not be able to operate the oven. To restore power on, open the door.
If you set the clock, energy save mode will be cancelled.
To start energy save mode manually, follow the instructions below.
Example:
To start the energy save mode, (the current time is 23:35):
R-6781J English 31/08/2004 16:15 Page 8
9
MICROWAVE POWER LEVELS
ENGLISH
Your oven has 5 power levels. To choose the power level for cooking, follow the advice given in the recipe section. Generally the following recommendations apply:
800 WATT (800 P) 100 % used for fast cooking or reheating e.g. soup, casseroles, canned food, hot beverages, vegetables, fish, etc.
560 WATT (560 P) 70 % used for longer cooking of dense foods such as roast joints, meat loaf and plated meals, also for sensitive dishes such as cheese sauce and sponge cakes. At this reduced setting, the sauce will not boil over and food will cook evenly without over cooking at the sides.
P = POWER
400 WATT (400 P) 50 % for dense foods which
require a long cooking time when cooked conventionally, e.g. beef dishes, it is advisable to use this power setting to ensure the meat will be tender.
240 WATT (240 P) 30 % (Defrost setting) to defrost, select this power setting, to ensure that the dish defrosts evenly. This setting is also ideal for simmering rice, pasta, dumplings and cooking egg custard.
80 WATT (80 P) 10 % For gentle defrosting, eg. cream gateaux or pastry.
•To select Microwaving, rotate the COOKING MODE dial to the MICROWAVE setting.
• Select the desired microwave power setting by pressing the WATT button.
• If the WATT button is pressed once, 800P (100 %) will be displayed. If you miss your desired level, continue pressing the WATT button until you reach the level again.
If the level is not selected, the level 800P (100 %) is automatically set.
R-6781J English 31/08/2004 16:15 Page 9
10
MICROWAVE COOKING
Your oven has 2 grill heating elements, and a combination of 3 grill cooking modes. Select the desired grill mode by rotating the COOKING MODE dial to the desired setting.
NOTES:
1. When the door is opened during the cooking
process, the cooking time on the digital display stops automatically. The cooking time starts to count down again when the door is closed and the
(START) +1min button is pressed.
2. If you wish to know the power level during
cooking, press the WATT button.
As long as your finger is pressing the WATT button, the power level will be displayed.
3. You can rotate the TIME/WEIGHT dial clockwise
or counter-clockwise. If you rotate the dial counter­clockwise, the cooking time will decrease from 90 minutes by degrees.
4. If you have not used the oven for over 2 minutes,
open and shut the door before programming.
Example:
Suppose you want to heat soup for 2 minutes and 30 seconds on 560 W microwave power.
3. Enter desired cooking
time by rotating the TIME/WEIGHT dial clockwise.
2. Press the WATT
button twice for 560 W microwave power.
COOKING MODE DIAL
GRILL HEATING ELEMENT IN USE
Top Grill
Bottom Grill
Top and Bottom Grill together
1. Rotate the COOKING MODE dial to the
MICROWAVE setting.
x1
4. Press the (START) +1min button once to
start cooking.
Cooking Time: Increasing unit:
0-5 minutes 10 seconds 5-10 seconds 30 seconds 10-30 minutes 1 minute 30-90 minutes 5 minutes
Your oven can be programmed for up to 90 minutes. (90.00). The input unit of cooking (defrosting) time varies from 10 seconds to five minutes. It depends on the total length of the cooking (defrosting) time as shown on the table opposite:
x2
GRILL COOKING
R-6781J English 31/08/2004 16:15 Page 10
Loading...
+ 39 hidden pages
