Sharp MX-M350U, MX-M450U, MX-450U, MX-M450N, MX-M350N Owner's Manual

MODEL

MX-M350U MX-M450U MX-M350N MX-M450N

LASER PRINTER

OPERATION MANUAL

(for general information and copier operation)

Page

PART 1: GENERAL INFORMATION

• BEFORE USING THE PRODUCT

•

MANAGING THE MACHINE

• PERIPHERAL DEVICES

PART 2: COPIER OPERATION

• MAKING COPIES

• CONVENIENT COPY

FUNCTIONS

•

MACHINE MAINTENANCE (FOR COPYING)

• DOCUMENT FILING FUNCTION

•

SPECIFICATIONS

1-1 2-1 3-1

4-1

5-1

6-1

7-1 8-1

Be sure to become thoroughly familiar with this manual to gain the maximum benefit from the product.

Before installing this product, be sure to read the installation requirements and cautions sections.

Be sure to keep all operation manuals handy for reference including this manual, the "Operation manual (for general information and copier operation)" and operation manuals for any optional equipment which has been installed.

Each instruction also covers the optional units used with these products.

The power switch positions are marked " I " to indicate power "ON" and " " to indicate stand-by.

Caution:

For complete electrical disconnection, pull out the main plug. The socket-outlet should be installed near the equipment and should be easily accessible.

FOR YOUR RECORDS ...

To protect against loss or theft, record and retain for reference the machine's serial number located on the back of the unit.

Model Number Serial Number Date of Purchase Place of Purchase Authorized Sharp Copier

Service Department Number

For users in the USA

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

WARNING:

FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user's authority to operate this equipment.

Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Shielded interface cables must be used with this equipment to maintain compliance with EMC regulations.

This operation manual is also used for the MX-350 / MX-450 / MX-350 J / MX-450 J / MX-M350U J / MX-M450U J / MX-M350N J / MX-M450N J.

Trademark acknowledgments

The following trademarks and registered trademarks are used in conjunction with the machine and its peripheral devices and accessories.

•Microsoft 2003 and Internet Explorer countries.

• PostScript is a registered trademark of Adobe Systems Incorporated.

• Macintosh, Mac OS, AppleTalk, EtherTalk, LaserWriter, and Safari are registered trademarks or trademarks of Apple Computer, Inc.

• Netscape Navigator is a trademark of Netscape Communications Corporation.

• Adobe, the Adobe logo, Acrobat, the Adobe PDF logo, and Reader are registered trademarks or trademarks of Adobe Systems Incorporated in the United States and other countries.

• PCL is a registered trademark of the Hewlett-Packard Company.

• IBM, PC/AT, and PowerPC are trademarks of International Business Machines Corporation.

• Sharpdesk is a trademark of Sharp Corporation.

• All other trademarks and copyrights are the property of their respective owners.

Candid and Taffy are trademarks of Monotype Imaging, Inc. registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. CG Omega, CG Times, Garamond Antiqua, Garamond Halbfett, Garamond Kursiv, Garamond and Halbfett Kursiv are trademarks of Monotype Imaging, Inc. and may be registered in certain jurisdictions. Albertus, Arial, Coronet, Gill Sans, Joanna and Times New Roman are trademarks of The Monotype Corporation registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. Avant Garde, ITC Bookman, Lubalin Graph, Mona Lisa, Zapf Chancery and Zapf Dingbats are trademarks of International Typeface Corporation registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. Clarendon, Eurostile, Helvetica, Optima, Palatino, Stempel Garamond, Times and Univers are trademarks of Heidelberger Druckmaschinen AG, which may be registered in certain jurisdictions, exclusively licensed through Linotype Library GmbH, a wholly owned subsidiary of Heidelberger Druckmaschinen AG. Apple Chancery, Chicago, Geneva, Monaco and New York are trademarks of Apple Computer Inc. and may be registered in certain jurisdictions. HGGothicB, HGMinchoL, HGPGothicB and HGPMinchoL are trademarks of Ricoh Company, Ltd. and may be registered in some jurisdictions. Wingdings is a registered trademark of Microsoft Corporation in the United States and other countries. Marigold and Oxford are trademarks of Arthur Baker and may be registered in some jurisdictions. Antique Olive is a trademark of Marcel Olive and may be registered in certain jurisdictions. Hoefler Text is a trademark of Johnathan Hoefler and may be registered in some jurisdictions. ITC is a trademark of International Typeface Corporation registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. Agfa is a trademark of the Agfa-Gevaert Group and may be registered in certain jurisdictions. Intellifont, MicroType and UFST are trademarks of Monotype Imaging, Inc. registered in the United States Patent and Trademark Office and may be registered in certain jurisdictions. Macintosh and TrueType are trademarks of Apple Computer Inc. registered in the United States Patent and Trademark Office and other countries. PostScript is a trademark of Adobe Systems Incorporated and may be registered in some jurisdictions. HP, PCL, FontSmart and LaserJet are trademarks of Hewlett-Packard Company and may be registered in some jurisdictions. The Type 1 processor resident in Monotype Imaging's UFST product is under license from Electronics For Imaging, Inc. All other trademarks are the property of their respective owners.

, Windows®, Windows® 98, Windows® Me, Windows NT® 4.0, Windows® 2000, Windows® XP, Windows® Server

are registered trademarks or trademarks of Microsoft Corporation in the U.S.A. and other

Part 1: General Information

NOTES

● Considerable care has been taken in preparing this manual. If you have any comments or concerns about the manual, please contact your nearest SHARP Service Department.

● This product has undergone strict quality control and inspection procedures. In the unlikely event that a defect or other problem is discovered, please contact your dealer or nearest SHARP Service Department.

● Aside from instances provided for by law, SHARP is not responsible for failures occurring during use of the product or its options, or failures due to incorrect operation of the product and its options, or other failures, or for any damage that occurs due to use of the product.

Warranty

While every effort has been made to make this document as accurate and helpful as possible, SHARP Corporation makes no warranty of any kind with regard to its content. All information included herein is subject to change without notice. SHARP is not responsible for any loss or damages, direct or indirect, arising from or related to the use of this operation manual.

The display screens, messages, and key names shown in the manual may differ from those on the actual machine due to product improvements and modifications.

PRODUCT CONFIGURATIONS

This product series consists of the models listed below. The product configuration varies by model. The peripheral devices required to use each of the functions are indicated.

Model Function Required peripheral devices

Copier Standard Printer Standard Network printer Network expansion kit Facsimile Facsimile expansion kit

MX-M350U/ MX-M450U

Network scanner Network expansion kit, network scanner expansion kit

Internet fax

Document filing Network expansion kit (with hard drive)

Metadata send

Copier Standard Printer Standard Network printer Standard

Network expansion kit (with hard drive), network scanner expansion kit, Internet fax expansion kit

Network expansion kit (with hard drive), network scanner expansion kit, application integration module

MX-M350N/ MX-M450N

Facsimile Facsimile expansion kit Network scanner Network scanner expansion kit Internet fax Network scanner expansion kit, Internet fax expansion kit Document filing Standard

Metadata send

Network scanner expansion kit, application integration module

0-1

OPERATION MANUALS

The following operation manuals are provided for the machine. Please read the appropriate manuals as needed for the features you wish to learn about.

● Operation manual (for general information and copier operation) (this manual): The first half of this manual provides general information about the machine, including safety information, loading paper, removing misfeeds, and regular maintenance. The second half of the manual explains how to use the copy and document filing functions.

● Administrator settings guide The administrator settings are used by the administrator of the machine to configure functions to meet the needs of your workplace. This guide explains administrator settings for machine management, copying, and document filing. Administrator settings for the fax, printer, network scanner and Internet fax functions are explained in the manuals for those functions.

● Software setup guide This manual mainly explains how to install and configure the software that allows the machine to be used as a printer.

● Operation manual (for printer)* This manual explains the procedures for using the machine as a printer.

● Operation manual (for image send)* This manual explains the procedures for using the image send feature of the machine, including the network scanner and Internet fax functions.

* The Operation manual (for printer) and the Operation manual (for image send) are provided as PDF files in the

CD-ROM. These manuals are not provided as printed manuals.

0-2

INSTALLATION REQUIREMENTS

Improper installation may damage this product. Please note the following during initial installation and whenever the machine is moved.

1.The machine should be installed near an accessible power outlet for easy connection.

2.Be sure to connect the power cord only to a power outlet that meets the specified voltage and current requirements. Also make certain the outlet is properly grounded.

●For the power supply requirements, see the

name plate on the back of the main unit.

3.Do not install your machine in areas that are:

●damp, humid, or very dusty

●exposed to direct sunlight

●poorly ventilated

●subject to extreme temperature or humidity

changes, e.g., near an air conditioner or heater.

4.Be sure to allow the required space around the machine for servicing and proper ventilation.

31-1/2" (80cm)

11-13/16" (30cm)

23-5/8" (60cm)

23-5/8"(60cm)

A small amount of ozone is produced within the machine during operation. The emission level is insufficient to cause any health hazard.

NOTE:

The present recommended long term exposure limit for ozone is 0.1 ppm (0.2 mg/m weighted average concentration. However, since the small amount that is emitted may have an objectionable odor, it is advisable to place the copier in a ventilated area.

) calculated as an 8 hr. time-

0-3

CAUTIONS

1.Do not touch the photoconductive drum. Scratches or smudges on the drum will cause dirty prints.

2.The fusing unit is extremely hot. Exercise care in this area.

3.Do not look directly at the light source. Doing so may damage your eyes.

4.Five adjusters are provided on all optional stand/paper drawer units. These adjusters should be lowered until they contact the floor. When moving the machine with the optional stand/paper drawer, be sure to raise the adjusters. Also, unlock the two casters at the front of the optional stand/paper drawer. After moving the machine, lower the four adjusters until they reach the floor and lock the two casters.

5.Do not make any modifications to this machine. Doing so may result in personal injury or damage to the machine.

Fusing unit

6.Since this machine is heavy, it is recommended that it be moved by more than one person to prevent injury.

7.When connecting this machine to a computer, be sure to first turn both the computer and the machine off.

8.Do not make copies of anything which is prohibited from copying by law. The following items are normally prohibited from printing by national law. Other items may be prohibited by local law.

●

Money ● Stamps ● Bonds ● Stocks

●

Bank drafts ● Checks ● Passports ● Driver's licenses

The part indicated in the illustration is only to be handled by a service technician. Absolutely do not touch this part.

Some models include the document filing function, which stores document image data on the machine’s hard disk. Stored documents can be called up and printed or transmitted as needed. If a hard disk failure occurs, it will no longer be possible to call up the stored document data. To prevent the loss of important documents in the unlikely event of a hard disk failure, keep the originals of important documents or store the original data elsewhere. With the exception of instances provided for by law, Sharp Corporation bears no responsibility for any damages or loss due to the loss of stored document data.

Adjuster

Lock

Release

"BATTERY DISPOSAL"

THIS PRODUCT CONTAINS A LITHIUM PRIMARY MEMORY BACK-UP BATTERY THAT MUST BE DISPOSED OF PROPERLY. PLEASE CONTACT YOUR LOCAL SHARP DEALER OR AUTHORIZED SERVICE REPRESENTATIVE FOR ASSISTANCE IN DISPOSING OF THIS BATTERY.

This product utilizes tin-lead solder, and a fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronics Industries Alliance: www.eia.org

0-4

Laser Information

Wave length

785 nm

+10 nm

-15 nm

Pulse times North America: 35 cpm model: (4.1 µs ± 4.1 ns)/7 mm

45 cpm model: (5.7 µs ± 5.7 ns)/7 mm

Europe: 35 cpm model: (3.8 µs ± 3.8 ns)/7 mm

45 cpm model: (4.4 µs ± 4.4 ns)/7 mm

Output power 0.2 mW - 0.4 mW

At the production line, the output power of the scanner unit is adjusted to 0.4 MILLIWATT PLUS 8 % and is maintained constant by the operation of the Automatic Power Control (APC).

Caution

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

For North America:

SAFETY PRECAUTIONS

This Digital Equipment is rated Class 1 and complies with 21 CFR 1040.10 and 1040.11 of the CDRH standards. This means that the equipment does not produce hazardous laser radiation. For your safety, observe the precautions below.

● Do not remove the cabinet, operation panel or any other covers.

● The equipment's exterior covers contain several safety interlock switches. Do not bypass any safety interlock by

inserting wedges or other items into switch slots.

This product utilizes a CR coin Lithium battery which contains a Perchlorate material. Special handling for this material may apply, California residents, See www.dtsc.ca.gov/hazardouswaste/perchlorate/

Others, consult local environmental officers.

For Europe:

CLASS 1 LASER PRODUCT

LASER KLASSE 1

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

INVISIBLE LASER RADIATION

CAUTION

WHEN OPEN INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.

VORSICHT

UNSICHTBARE LASERSTRAHLUNG WENN ABDECKUNG GEÖFFNET UND SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT. NICHT DEM STRAHL AUSSETZEN.

ADVARSEL

USYNLIG LASERSTRÅLNING VED ÅBNING, NÅR SIKKERHEDSBRYDERE ER UDE AF FUNKTION. UNDGÅ UDSAETTELSE FOR STRÅLNING.

LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.

OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA BRUKSANVISNING SPECIFICERATS, KAN ANVÄNDAREN UTSÄTTAS FÖR OSYNLIG LASERSTRÅLNING, SOM ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1.

VAROITUS!

VARNING

CLASS 1

LASER PRODUCT

LASER KLASSE 1

Laserstrahl

INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.

CAUTION

UNSICHTBARE LASERSTRAHLUNG WENN ABDECKUNG GEÖFFNET UND SICHERHEITSVERRIEGELUNG ÜBERERÜCKT. NICHT DEM STRAHL AUSSETZEN.

VORSICHT

USYNLIG LASERSTRÅLING VED ÅBNING, NÅR SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÅ UDSAETTELSE FOR STRÅLNING.

ADVARSEL

USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES OG SIKKERHEDSLÅS BRYTES. UNNGÅ EKSPONERING FOR STRÅLEN.

ADVERSEL

OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRRAR ÄR URKOPPLADE. STRÅLEN ÄR FARLIG. BETRAKTA EJ STRÅLEN.

VARNING

AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA NÄKYMÄTÖNTÄ LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.

VAR O!

0-5

Page

PRODUCT CONFIGURATIONS...................................0-1

OPERATION MANUALS ..............................................0-2

INSTALLATION REQUIREMENTS...............................0-3

CAUTIONS...................................................................0-4

● Laser Information..................................................0-5

CONTENTS..................................................................0-6

CHAPTER 1 BEFORE USING THE PRODUCT

INTRODUCTION..........................................................1-2

MAIN FEATURES.........................................................1-3

PART NAMES AND FUNCTIONS ................................1-9

● Exterior .................................................................1-9

● Interior ..................................................................1-10

● Part names and functions of peripheral devices...1-11

● Operation panel ....................................................1-13

● Touch panel..........................................................1-14

TURNING THE POWER ON AND OFF .......................1-17

AUDITING MODE.........................................................1-18

● Using the machine when the auditing mode is

enabled.................................................................1-18

CHAPTER 2 MANAGING THE MACHINE

LOADING PAPER.........................................................2-2

● Loading paper in paper tray 1...............................2-2

● Changing the paper size in paper tray 1...............2-2

● Specifications of paper trays.................................2-3

● Setting the paper type and paper size..................2-5

● Setting the paper size when a special size is

loaded...................................................................2-6

● Programming and editing paper types..................2-7

● Loading paper in the multi purpose drawer ..........2-8

● Specifications (multi purpose drawer) ..................2-10

● Loading paper in the stand/3 x 500 sheet paper

drawer...................................................................2-10

● Specifications (stand/3 x 500 sheet paper

drawer) .................................................................2-10

● Loading paper in the stand/MPD & 2000 sheet

paper drawer ........................................................2-11

● Specifications (stand/MPD & 2000 sheet paper

drawer) .................................................................2-11

SYSTEM SETTINGS....................................................2-12

● General procedure for system settings.................2-12

● About the settings.................................................2-14

REPLACING THE TONER CARTRIDGE.....................2-15

STORAGE OF SUPPLIES............................................2-16

MISFEED REMOVAL ...................................................2-17

● Misfeed removal guidance....................................2-17

● Misfeed in the transport area, fusing area, and

exit area................................................................2-18

● Misfeed in the duplex module...............................2-19

● Misfeed in the paper feed area.............................2-20

REMOVING AN ORIGINAL MISFEED.........................2-22

● Removing a misfed original from the automatic

document feeder...................................................2-22

TROUBLESHOOTING..................................................2-23

CHAPTER 3 PERIPHERAL DEVICES

DUPLEX MODULE ...................................................... 3-2

● Part names........................................................... 3-2

● Specifications....................................................... 3-2

● Loading paper in the bypass tray......................... 3-3

Troubleshooting (concerning the duplex module)

●

MAIL-BIN STACKER.................................................... 3-5

● Part names........................................................... 3-5

● Specifications....................................................... 3-5

● Misfeed in the mail-bin stacker............................. 3-6

FINISHER.................................................................... 3-7

● Part names........................................................... 3-7

● Specifications....................................................... 3-7

● Finisher functions................................................. 3-8

● Using the finisher functions.................................. 3-9

● Staple cartridge replacement............................... 3-10

● Misfeed in the finisher .......................................... 3-12

● Troubleshooting finisher problems ....................... 3-13

SADDLE STITCH FINISHER....................................... 3-14

● Part names........................................................... 3-14

● Specifications....................................................... 3-14

● Saddle stitch finisher functions ............................ 3-15

● Using the saddle stitch finisher............................ 3-18

Staple cartridge replacement and staple jam removal....

●

● Misfeed in the saddle stitch finisher..................... 3-22

Troubleshooting (concerning the saddle stitch finisher) ...

●

SHARP OSA................................................................ 3-25

APPLICATION COMMUNICATION MODULE (MX-AMX2)

● Standard application setup

● Selecting a standard application

● Operation in OSA mode

EXTERNAL ACCOUNT MODULE (MX-AMX3)........... 3-27

● External account application setup

● Operation in external account mode

........................................

..............................

.............................................

..........................

........................

.. 3-4

3-19

3-24

3-25 3-25 3-25 3-26

3-27 3-27

CHAPTER 4 MAKING COPIES

AUTOMATIC DOCUMENT FEEDER........................... 4-2

● Acceptable originals............................................. 4-2

PLACING ORIGINALS................................................. 4-3

CHECKING THE SIZE OF A PLACED ORIGINAL...... 4-5

● Manually setting the scanning size ...................... 4-5

STORING, DELETING, AND USING ORIGINAL SIZES

● Storing or deleting an original size....................... 4-6

NORMAL COPYING.................................................... 4-7

● Making copies with the automatic document

feeder................................................................... 4-7

● Automatic two-sided copying using the automatic

document feeder.................................................. 4-10

● Copying from the document glass ....................... 4-11

● Automatic two-sided copying from the document

glass .................................................................... 4-13

ADJUSTING THE EXPOSURE ................................... 4-14

REDUCTION/ENLARGEMENT/ZOOM ....................... 4-15

● Automatic selection (auto image)......................... 4-15

● Manual selection (preset copy ratios/zoom)......... 4-16

● XY ZOOM ............................................................ 4-18

SPECIAL PAPERS ...................................................... 4-20

4-6

0-6

CONTENTS

CHAPTER 5 CONVENIENT COPY FUNCTIONS

SPECIAL MODES........................................................5-2

● General procedure for using special functions .....5-2

● Margin shift...........................................................5-3

● Erase ....................................................................5-4

● Dual page copy ....................................................5-5

● Pamphlet copy...................................................... 5-6

● Job build...............................................................5-8

● Tandem copy........................................................5-10

● Covers/inserts ......................................................5-12

● Transparency film with insert sheets ....................5-23

● Multi shot ..............................................................5-24

● Book copy.............................................................5-26

● Card shot

● Mirror image ......................................................... 5-29

● B/W reverse..........................................................5-29

● Print menu............................................................5-30

STORING, USING AND DELETING JOB

PROGRAMS ................................................................ 5-42

● Storing a job program........................................... 5-42

● Calling up a job program ......................................5-43

● Deleting a stored job program..............................5-43

INTERRUPTING A COPY RUN ...................................5-44

..................................................................

5-27

CHAPTER 8 SPECIFICATIONS

SPECIFICATIONS ........................................................8-2

LIST OF COMBINATION OF PERIPHERAL DEVICES ...

INDEX...........................................................................8-5

8-4

CHAPTER 6 MACHINE MAINTENANCE (FOR COPYING)

USER MAINTENANCE................................................6-2

● Cleaning the document glass and the automatic

document feeder .................................................. 6-2

● Cleaning the main charger of the

photoconductive drum.......................................... 6-2

TROUBLESHOOTING ................................................. 6-3

CHAPTER 7 DOCUMENT FILING FUNCTION

OVERVIEW .................................................................. 7-2

● Document filing function .......................................7-2

TO USE THE DOCUMENT FILING FUNCTION..........7-4

● A look at the operation panel................................7-4

● Saving files ........................................................... 7-4

● Main screen of document filing ............................ 7-5

● Document filing icons ........................................... 7-5

SAVING A DOCUMENT IMAGE FILE..........................7-6

● Quick File .............................................................7-6

● Filing..................................................................... 7-7

● Print jobs ..............................................................7-9

● Scan Save............................................................7-10

CALLING UP AND USING A FILE............................... 7-13

● Searching for and calling up a saved file

● Calling up and using a saved file.......................... 7-15

● File selection screen ............................................7-16

SYSTEM SETTINGS ...................................................7-24

Creating, editing, and deleting user names and folders....

●

ENTERING CHARACTERS.........................................7-29

TROUBLESHOOTING ................................................. 7-31

...............

7-13

7-24

0-7

CHAPTER 1

BEFORE USING THE

PRODUCT

This chapter contains basic information that should be read before using the product.

Page

INTRODUCTION..................................................................................... 1-2

MAIN FEATURES ................................................................................... 1-3

PART NAMES AND FUNCTIONS........................................................... 1-9

●

Exterior............................................................................................ 1-9

●

Interior............................................................................................. 1-10

●

Part names and functions of peripheral devices............................. 1-11

●

Operation panel............................................................................... 1-13

●

Touch panel..................................................................................... 1-14

TURNING THE POWER ON AND OFF.................................................. 1-17

AUDITING MODE................................................................................... 1-18

●

Using the machine when the auditing mode is enabled.................. 1-18

1-1

INTRODUCTION

Thank you for purchasing a SHARP digital multifunction copier. Please read this manual before using the machine. In particular, be sure to read "INSTALLATION REQUIREMENTS" before using the machine. Please keep this manual close at hand for reference whenever necessary. This manual provides general information on using the machine, such as routine maintenance and how to load paper and remove misfeeds. It also explains how to use the copier and document filing functions. Separate manuals have been provided for the fax function, printer function, and network scanner function.

■ Original and paper sizes

This machine allows use of standard sizes in both the inch and AB systems. These are shown in the tables below.

Sizes in the inch system Sizes in the AB system 11" x 17" (LEDGER) A3 8-1/2" x 14" (LEGAL) B4 8-1/2" x 13" (FOOLSCAP) A4 8-1/2" x 11" (LETTER) B5 7-1/4" x 10-1/2" (EXECUTIVE) A5 5-1/2" x 8-1/2" (INVOICE)

■ The meaning of "R" in original and paper size indications

Some original and paper sizes can be placed in either the portrait or landscape orientations. To differentiate between landscape and portrait, the landscape orientation size indication will contain an "R". These are indicated as 8-1/2" x 11"R, 5-1/2" x 8-1/2"R, A4R, B5R, etc. Sizes that can be placed only in the landscape orientation (11" x 17", 8-1/2" x 14", 8-1/2" x 13", A3, B4) do not contain the "R" in their size indication.

Size indication with "R"

Landscape orientation

Size indication without "R"

Portrait orientation

1-2

MAIN FEATURES

The digital multifunction copier is capable of performing a variety of functions. This page shows features related to the copy function.

● Sort mode See page 1-3

● Group mode See page 1-3

● 2-sided Copy See page 1-3

(When the duplex module is installed.)

● Exposure Adjustments See page 1-3

● Reduction/Enlargement See page 1-4

● XY Zoom See page 1-4

● Margin Shift See page 1-4

● Erase See page 1-4

● Dual Page Copy See page 1-4

● Pamphlet Copy See page 1-4

● Job Build See page 1-5

● Tandem Copy See page 1-5

(MX-M350N/MX-M450N, or when the network function has been added.)

● Covers/inserts See page 1-5

● Transparency Insert See page 1-5

● Multi Shot See page 1-5

● Book Copy See page 1-5

● Card Shot See page 1-6

● Job programs See page 1-6

● Mirror Image See page 1-6

● B/W Reverse See page 1-6

● Date See page 1-6

● Stamp See page 1-6

● Page numbering See page 1-7

● Text See page 1-7

● Interrupting a copy run See page 1-7

● Offset mode See page 1-7

(When the Finisher or Saddle stitch finisher is installed.)

● Staple sort mode See page 1-7 (When the Finisher or Saddle stitch finisher is installed.)

● Saddle stitch See page 1-7 (When the Saddle stitch finisher is installed.)

● Hole punching See page 1-8 (When the Saddle stitch finisher and Punch Module are installed.)

● Document filing function See page 1-8 (MX-M350N/MX-M450N, or when the document filing function has been added.)

Sort mode See page 4-9

Copies can be collated.

Original

Group mode See page 4-9

Copies can be grouped by page.

Copy

2-sided Copy See pages 4-10, 4-13

Copy onto both sides of the paper using the document glass or the automatic document feeder.

Original

* When the duplex module is installed.

Exposure Adjustments See page 4-14

The desired image type for the original can be selected.

Copy

Original Copy

Resolution

Exposure

Text Text/Photo Photo

ABCDE

DarkerLighter

1-3

MAIN FEATURES

Reduction / Enlargement See page 4-15

Copies can be enlarged or reduced to the desired size.

Original

Enlargement Reduction

Copy

XY Zoom See page 4-18

Separate ratio settings can be selected for the length and width of a copy.

Original Copy

Erase See page 5-4

Shadows that appear around the edges of copies of books or thick originals can be erased.

Original

Copy

Edge erase

Center erase

Edge+Center

erase

Dual Page Copy See page 5-5

The left and right pages of a book can be successively copied onto separate sheets.

CopyBook original

Margin Shift See page 5-3

Margins can be added to copies.

One-sided copying Original

Two-sided copying Original

Image shifted to the right

Margin

Image shifted to the right

Margin

Image shifted to the left

Margin

Image shifted to the left

Margin

Pamphlet Copy See page 5-6

One-sided or two-sided pamphlet style copies can be made.

Originals (one-sided)

Originals (two-sided)

Left binding

Right binding

Finished copies are folded in two.

First page

1-4

MAIN FEATURES

Job Build See page 5-8

When you have a very large number of originals, the pages can be scanned in sets.

50 sheets100 sheets 50 sheets

Tandem Copy See page 5-10

Two machines can be used to run a large copy job in parallel.

Transparency Insert See page 5-23

Inserts can be automatically inserted between transparencies.

Originals (1-sided)

Originals (2-sided)

Copy

Insert sheets

Multi Shot See page 5-24

Multiple original pages can be copied onto a single sheet of paper in a uniform layout.

Originals (1-sided)

Originals (2-sided)

Copy

100 sets of

copies

* MX-M350N/MX-M450N, or when

the network function has been added

50 sets of

copies

50 sets of

copies

Covers/inserts See page 5-12

Front covers, back covers, and inserts can be added. These can also be copied on.

Originals

Back cover

Front cover

Insert sheets

Book Copy See page 5-26

Books and other bound originals can be copied pamphlet style.

CopyOriginal

Left binding

First page

Right binding

First page

1-5

MAIN FEATURES

JOB PROGRAMS

PRESS PROGRAM NUMBER.

RECALL

Card Shot See page 5-27

The front and back of a card can be copied onto one sheet of paper. This function is convenient for making copies for certification purposes and helps save paper.

Original

CARD

Front of

card

Back of

card

Example: Portrait 8-1/2" x 11" (A4) size

Copy

CARD

Example: Landscape 8-1/2" x 11"(A4) size

Job programs See page 5-42

Various steps of a copy operation can be stored as a program, and up to 10 programs can be stored. Saving frequently used sets of settings in a program saves you the trouble of selecting those settings each time you wish to use them.

B/W Reverse See page 5-29

White and black can be inverted on a copy to produce a negative image.

Original Copy

Date See page 5-33

The date can be added to copies.

Mirror Image See page 5-29

A mirror image copy can be made.

Original Copy

2010/APR/4

Stamp See page 5-34

Reverse text can be added to copies ("stamp").

CONFIDENTIAL

1-6

MAIN FEATURES

AUTO

ORIGINA

EXPOSUR

INTERRUPT

ORIGINAL

8 x11

1 / 2

Page numbering See page 5-35

Page numbers can be added to copies.

Text See page 5-39

Entered text can be added to copies.

Offset mode See page 3-8

Each set of output can be offset slightly from other sets for easy separation.

Offset mode Non-Offset mode

*When the Finisher or Saddle stitch finisher is

installed.

Staple sort mode See page 3-8, 3-16

Sets of copies can be automatically stapled.

Original

Copy

Meeting

Interrupting a copy run See page 5-44

A copy job in progress can be interrupted for a rush job.

*When the Finisher or Saddle stitch finisher is

installed.

Saddle stitch See page 3-14

When a saddle stitch finisher is installed, copies can be automatically folded in half and stapled at the fold. (Use with the pamphlet function (see page 5-6) or book copy function (see page 5-26).)

Saddle stitch binding

*When the Saddle stitch finisher is installed.

1-7

MAIN FEATURES

Hole punching See page 3-17

Copies can be punched to add holes.

Original Punch positions

* When the saddle stitch finisher and punch

module are installed.

Products that have earned the ENERGY STAR® are designed to protect the environment through superior energy efficiency.

Document filing function See CHAPTER 7

A document image can be stored on the hard disk. A stored file can easily be called up and printed or transmitted.

Printed Document Image

Save to machine's hard disk

* MX-M350N/MX-M450N, or when the document

filing function has been added

HDD

Call up a saved file to reuse

Transmitted

Achieves ENERGY STAR energy savings; product fully qualifies when used with a duplexer.

The Environmental Choice Program guidelines are applied to the products only in Canada. The products that meet the Environmental Choice Program guidelines carry the logo shown to the left. The products without the logo may not meet the Environmental Choice Program guidelines.

Energy saving features

This product has the following two power reducing modes to help conserve natural resources and reduce environmental pollution.

Preheat mode

When the machine remains in the standby state for the amount of time set in the administrator settings, preheat mode automatically reduces the temperature of the fusing unit to save power while the machine is on standby. When a fax or print job is received, or keys are pressed on the operation panel, or an original is placed for a copy, fax, or network scanner job, preheat mode automatically turns off.

Auto power shut-off mode

The auto power shut-off mode is the second level of power reduction. In this mode power is shut off to the fusing unit and the touch panel. In this state more energy is saved than in the preheat mode but the time to recover to the ready condition will be longer. The preset time to enter this mode can be set by a setting.

dministrator

When this product is used as a printer, and either of the above modes is active, the mode will be deactivated automatically by an incoming job and the machine will automatically warm up and start to print when it has reached the ready temperature. When this product is configured for multi-function operation, and either of the above modes is active, the mode will be deactivated as above by an incoming print job. Either mode will also be deactivated by operation of DOCUMENT FILING, IMAGE SEND or COPY mode key.

1-8

PART NAMES AND FUNCTIONS

Exterior

(1) (2) (3) (4) (5) (6) (7) (8) (9) (10)

(11)

(12)

(13)

(1) Bypass tray*

(2) Exit tray*

(3) Automatic document feeder (See page 4-2.)

This automatically feeds and scans multiple sheet originals. Both sides of two-sided originals can be scanned at once.

(4) Duplex module*

Module for two-sided printing

(5) Upper paper output area (Center tray)

Finished sheets are deposited here.

(6) Upper exit tray extension*

Provides support for large size paper.

(7) Operation panel

(8) Front cover

Open to add toner.

(9) Power switch

Press to turn power on and off.

(

)Paper tray 1

(11)

Stand/3 x 500 sheet paper drawer*

(12)

Stand/MPD & 2000 sheet paper drawer* (See page 2-11.)

(13)

Multi purpose drawer* (See page 2-8.)

* (1), (2), (4),

Peripheral devices are basically optional, but some are provided as standard equipment for some models.

(6), (11)

, (12) and

(13)

are peripheral devices. For description of these devices, see page 1-11.

1-9

PART NAMES AND FUNCTIONS

Interior

(14) (15) (16) (17)

(14) Duplex module side cover

Open when a misfeed has occurred in the duplex module.

(

) Side cover latch

Push up to open the side cover when a misfeed has occurred in the main unit.

(

) Fusing unit

Lift up to open the side cover when a misfeed has occurred in the main unit.

CAUTION

The fusing unit is hot. Take care in removing misfed paper.

(18) (19)

(

) Toner cartridge (drum/toner cartridge)

The toner cartridge must be replaced when indicated on the operation panel. (See page 2-15)

(

) Photoconductive drum

Images are formed on the photoconductive drum.

NOTE

Do not touch or damage the photoconductive drum.

(

) Cartridge lock lever

When replacing the drum, toner or developer cartridge, turn down this lever and pull it out.

1-10

PART NAMES AND FUNCTIONS

Part names and functions of peripheral devices

(11)

(10)

(9)

(8)

(7)

(1) Upper exit tray extension (AR-TE4)

Mount this unit to the upper paper exit tray. This extension is needed to support large size paper.

(2) Finisher (AR-FN6)

Output sheets can either be sorted in page order or grouped by page. Sorted sets or groups are offset stacked for easy separation when removed. Sorted sets can be delivered either stapled or unstapled.

(1)

(2)

(3)

(4)

(5)

(6)

(6) Multi purpose drawer (AR-MU2)

) paper.

) paper can be

Up to 500 sheets of 20 lbs. (80 g/m loaded. Also special papers such as envelopes (standard sizes only) and postcards can be set.

(7) Stand/3 x 500 sheet paper drawer (AR-D27)

This paper feed unit contains an upper multipurpose drawer (see item (6)) and two lower drawers each of which can hold a maximum of 500 sheets of 20 lbs. (80 g/m

(3) Right output tray (AR-TE5)

Attaches to the output outlet on the right side of the machine.

(4) Mail-bin stacker (AR-MS1)

This unit is an output sorter that has seven receiving bins. The bin to receive printed output can be selected in the printer driver. Each bin can be assigned to receive printed output by an individual person or by groups of people so that their prints are separated from other users making them easy to retrieve. When this unit is installed, any copies or facsimile prints will be sent to the top tray and not into the mail bins.

(5) Stand/MPD & 2000 sheet paper drawer (AR-D28)

This paper feed unit contains an upper multipurpose drawer (see item (6)) and a lower drawer which can hold a maximum of 2000 sheets of 20 lbs. (80 g/m

) paper.

(8) Saddle stitch finisher (AR-FN7)

The saddle stitch finisher can automatically place two staples for centerline binding of paper and fold them along the centerline. An optional punch module is available for installation into the finisher.

(9) Duplex module (AR-DU3)

An optional duplex module must be installed for automatic two-sided printing.

(

) Duplex module/bypass tray (AR-DU4)

This module is basically the same as (9) above with the addition of a manual bypass paper feed unit.

(

) Exit tray (AR-TE3)

Mounted to the paper output port of a duplex module.

1-11

PART NAMES AND FUNCTIONS

■ Other optional equipment

●Network expansion kit (MX-NBX2)

This is required to add on the network function. When this expansion kit is installed, the machine can be used as a network printer.

●Network expansion kit (MX-NBX3)

Required to add the network function and a hard drive to the machine. Installing this expansion kit allows the machine to be used as a printer and enables use of the document filing function.

●Barcode font kit (AR-PF1)

This kit adds bar code fonts to the machine.

●Data security kit (MX-FRX6, MX-FRX6U, MXFRX7, MX-FRX7U)

The MX-FRX6 and MX-FRX6U are for models that have a hard disk drive, and the MX-FRX7 and MXFRX7U are for models without a hard disk drive. This kit is used to erase electronic data from the hard disk and memory immediately after a document is printed or transmitted.

●Network scanner expansion kit (MX-NSX1)

This kit is required to add the network scanning feature. To add the network scanner function to the MXM350U, or MX-M450U, the network expansion kit is required.

●Internet fax expansion kit (MX-FWX1)

This kit is required to use the Internet fax function. To add on the Internet fax function, the network scanner expansion kit is required. On the MXM350U/MX-M450U, the network expansion kit (with hard drive) is also required.

●Application integration module (MX-AMX1)

The application integration module can be combined with the network scanner function to append a metadata file to a scanned image file.

●

Application communication module (MX-AMX2)

This allows the machine to be linked over a network to an external software application.

●PS3 expansion kit (AR-PK6)

This kit provides compatibility of PostScript level 3 to the printer.

●Facsimile expansion kit (AR-FX12)

This kit is required to add fax function.

●Additional fax memory (8MB) (AR-MM9)

Some peripheral devices cannot be installed together while others may require the installation of one or more others to be functional. See page 8-4, "LIST OF COMBINATION OF PERIPHERAL DEVICES". Peripheral devices are basically optional, but some are provided as standard equipment for some models.

●

External account module (MX-AMX3)

This is required to use an external account application on the machine.

●Flash ROM kit (AR-PF2)

This kit contains download fonts.

1-12

Operation panel

PART NAMES AND FUNCTIONS

(1) (2) (3)

When the document filing function has not been added.

DOCUMENT FILING

IMAGE SEND

COPY

JOB STATUS

(1) Touch panel

The machine status, messages and touch keys are displayed on the panel. The document filing* copy, network scanner*

, fax*3 , and Internet fax* functions are used by switching to the screen for the desired function. See the following page.

(2) Mode select keys and indicators

Use to change modes and the corresponding display on the touch panel.

[DOCUMENT FILING] key

Press to select the document filing mode* page 7-5.) When the document filing function has not been added, this key is the [PRINT] key. This key is pressed to change to the print mode screen.

[IMAGE SEND] key/LINE indicator/DATA indicator

Press to change the display to network scanner

mode*

, fax mode*3 or Internet fax mode*4. (See the "Operation manual (for image send)") and "Operation manual (for facsimile)".)

[COPY] key

Press to select the copy mode.

(3) PRINT mode indicators

READY indicator

Print data can be received when this indicator is lit.

DATA indicator

Lights up or blinks when print data is being received. Also lights up or blinks when printing is being performed.

PRINT READY DATA

LINE DATA

SYSTEM

SETTINGS

LOGOUT

(4) (5) (6) (7) (8) (9)

(4) [JOB STATUS] key

Press to display the current job status. (See page 1-15.)

(5) [SYSTEM SETTINGS] key

This is used to store, edit, and delete user names and folder names for the document filing function* and to configure the administrator settings and printer configuration settings. (See page 7-24)

(6) Numeric keys

Use to enter numeric values for various settings.

(7) [ ] key ([LOGOUT] key)

This key is used in copy mode, document filing

mode* Internet fax mode*

, network scanner mode*2, fax mode*3, and

(8) [#/P] key

This is used as a program key when using the copy function, and to dial when using the fax function*

(9) [C] key (Clear key)

This key is used in copy mode, document filing mode

*1, network scanner mode*2, and fax mode*3.

(10)

[START] key

Use this key to start copying in copy mode, scan a document in network scanner mode* document for transmission in fax mode* fax mode*

(11)

[CA] key (Clear all key)

This key is used in copy mode, document filing mode

*1, network scanner mode*2, fax mode*3, and

Internet fax mode*

. Use the key to cancel settings

and perform an operation from the initial machine

. (See

(10) (11)

, or scan a

or Internet

*1 MX-M350N/MX-M450N, or when the document filing function has been added. *2 When the network scanner option is installed. *3 When the fax option is installed. *4 When the Internet fax option is installed.

1-13

PART NAMES AND FUNCTIONS

JOB QUEUE

COPY

Suzuki

0666211221

003 / 000

010 / 000

SETS / PROG

1/13

COMPLETE

PER.

COVER

SETTING

RIGHT

BINDING

LEFT

BINDING

CANCEL OK

DUAL PAGE

COPY

TANDEM

COPY

8 x14

11x17

8 x11

Touch panel

The touch panel screens shown in this manual are printed images, and may appear different from the actual screens.

■ Using the touch panel

[Example 1]

Items on the touch panel are easily selectable by touching the key associated with the item with a finger. Selection

Beep

tone

Also, the key area for the item will be highlighted for visual confirmation.

* If a grayed out key is touched, double beeps will

sound.

[Example 2]

of an item will be accompanied with a beep tone* to confirm the item was selected.

Keys which are grayed out on any screen are not selectable.

■ Selecting a function

[Example 1]

If a key is highlighted in a setting screen at the time the screen appears, the [OK] key can be pressed to store the selection without further operation.

[Example 2]

A function in the special functions screen is selected by touching the key so that it is highlighted. To cancel the selection, touch the highlighted key once again.

Copier feature

● Dual page copy

● Job build

● Tandem copy

● Mirror image

● B/W Reverse

The confirmation beeps can be disabled using "Keys touch sound" in the administrator setting. (See page 10 of the administrator settings guide.)

[Example 3]

READY TO SCAN FOR COPY.

SPECIAL MODES

2-SIDED COPY

OUTPUT

FILE

QUICK FILE

A corresponding icon representing the feature will appear on the touch panel and on the main screen of the mode selected. If this icon is touched, the setting screen of the function (or

a menu screen) will appear, allowing the settings to be checked or adjusted and the function to be canceled easily.

1-14

PART NAMES AND FUNCTIONS

■ Job status screen (common to print, scan, fax and Internet fax)

This screen is displayed when the [JOB STATUS] key on the operation panel is pressed. This screen can be used to display the "JOB QUEUE" (showing stored jobs and the current job) or the "COMPLETE" job list (showing finished jobs). This screen can be used to check jobs, interrupt a job in progress to perform another job, and cancel a job.

(1)

"JOB QUEUE" screen

(2)

"COMPLETE" job screen

JOB QUEUE

COPY

Suzuki

066211221

PRINT JOB

(3) (4) (5) (6) (7) (8) (9)(10) (11)

SETS / PROGRESS

020 / 001

020 / 000

002 / 000

SCAN TO

(1) Job list

The displayed jobs in the job list are themselves operation keys. To cancel printing or to give a job the highest print priority, touch the relevant job key to select the job and execute the desired operation using the keys described in (8) and (9). This shows the current job and the jobs waiting to be run. The icons to the left of the jobs in the queue show the job mode. The document filing reprint job icon is highlighted. Note that the icon does not become highlighted during retransmission of a fax/image transmission job.

STATUS

COPYING

PAPER EMPTY

WAITING

FAX JOB

JOB QUEUE

COMPLETE

DETAIL

CALL

INTERNET-FAX

1/1

JOB QUEUE

COMPLETE

DETAIL

PRIORITY

STOP/DELETE

INTERNET-FAX

*1 "PAPER EMPTY" in the job status display

When a job status display indicates "PAPER EMPTY", the specified paper size for the job is not loaded in any of the trays. In this case, the job will be suspended until the required paper is loaded. Other stored jobs will be printed (if possible) until the required paper is loaded. (Other jobs will not be printed if the paper runs out during printing.) If you need to change the paper size because the specified paper size is not available, touch the current job key to select it and then touch the [DETAIL] key described in (10).

Print mode Copy mode

SCAN mode

Scan to e-mail job

Scan to FTP job

Scan to Desktop job

Scan to Network folder job

Fax mode

Fax send job Fax reception job

PC-Fax send job

Internet Fax mode

i-Fax send job

i-Fax reception job

PC-Internet Fax send job

(2) Mode select key

This switches the job list display between "JOB QUEUE" and "COMPLETE".

"JOB QUEUE": Shows stored jobs and the job in

progress.

"COMPLETE": Shows finished jobs.

Files saved using the "FILE"*

FILE"*

functions and finished broadcast

and "QUICK

transmission jobs appear as keys in the finished job screen. The "FILE"*

or "QUICK FILE"*2 job keys in the finished job screen can be touched, followed by the [CALL] key*

, to call up a finished job and print or transmit it. A finished broadcast transmission job key can be touched followed by the [DETAIL] key to check the result of the transmission. *2 Can only be used on the MX-M350N/MX-M450N

or when the document filing function has been added.

1-15

PART NAMES AND FUNCTIONS

(3) [PRINT JOB] key

This displays the print job list of print mode (copying, printing, fax reception, Internet fax reception, and self printing).

(4) [SCAN TO] key

This displays the transmission status and finished jobs of scan mode (Scan to e-mail, Scan to FTP, Scan to Desktop, and Scan to Network Folder) when the network scanner option is installed.

(5) [FAX JOB] key

This displays the transmission/reception status and finished jobs of fax mode (fax and PC-Fax) when the fax option is installed.

(6) Display switching keys

Use to switch the page of the displayed job list.

(7) [INTERNET-FAX] key

This displays the transmission/reception status and finished jobs of Internet fax mode and PC Internet fax mode when the Internet fax option is installed.

(8) [STOP/DELETE] key

Use to cancel or delete the current job or delete the stored job. Note that printing of received faxes and received Internet faxes cannot be canceled or deleted.

(9) [PRIORITY] key

Touch this key after selecting a stored job in this [JOB QUEUE] list to print the job ahead of the other jobs. Note that a job in progress cannot be interrupted if it is an interrupt copy job or if it is a list print job.

(10)

[DETAIL] key

This shows detailed information on the selected job.

Files saved using the "FILE"*2 and "QUICK

FILE"* transmission jobs job screen. A Quick File in the finished job screen or the [Filing] key [CALL] key transmit it. A finished broadcast transmission job key can be touched followed by the [DETAIL] key to check the result of the transmission.

(11)

[CALL] key*

When this key is touched after selecting a job in the COMPLETE job status screen (a job stored using the FILE or QUICK FILE keys of the document filing function), the "JOB SETTINGS" menu screen appears to let you resend or reprint the finished job. (See "Document filing function" on page 7-2.)

functions and finished broadcast

appear as keys in the finished

*2 can be touched, followed by the

*2, to call up a finished job and print or

*2 Can only be used on the MX-M350N/MX-M450N, or when the document filing function has been added.

1-16

+ 198 hidden pages
