Sharp MX-M202D User Manual

MX-M202D
PRINT, COPY, SCAN, FAX PAGES PER MINUTE: 20 B/W PAPER CAPACITY: STD 600 MAX 1100 SHEETS FULL COLOUR A3 SCANNING STANDARD DUPLEX AND E-SORT FUNCTION OPTIONAL DOCUMENT FEEDER FOR INCREASED
PRODUCTIVITY OPTIONAL NETWORK PRINTING/SCANNING SCAN TO USB MEMORY
Keep up with today's fast-paced business communications with one easy-to-use, compact solution that has all your basic office needs covered. The MX-M202D is packed with an extensive range of superb performance functions, delivering efficient copying, printing and brilliant colour scanning. Thanks to Sharp Printer Language with Compression (SPLC), print speeds are kept to a maximum even on complex jobs. Copying is just as fast, and handy features such as Electronic Sorting, for creating multiple sets of sorted documents without the need for a bulky page collator, will increase productivity. A Single Pass Feeder (SPF) for single-sided documents or a Reversing Single Pass Feeder (RSPF) for double-sided originals can be specified for easier double­sided scanning and copying. Certified for Energy Star and with Pre-heat and Auto Power Shut off modes proves the MX-M202D is energy efficient and environmentally-friendly. And with options available for powerful network printing/scanning and Super G3 faxing, the MX-M202D even has the functionality to grow with your business.
GENERAL
COPIER
Engine speed B/W ppm (A4): 20 Engine speed B/W ppm (A3): 11 Paper size: Min.-Max.: A6 - A3 Paper weight (g/m2): 56-90 (Bypass 56-200) Paper capacity:Std (sheets): 600 Paper capacity: Max. (sheets): 1,100 Warm Up Time (sec.): 25 Memory general min/max (MB): 128 Memory printer min/max (MB): 128/256 Duplex: STD Power requirements - rated local AC voltage (Hz): 220-240V, 50/60Hz Power consumption (kW): 1,2 Dimensions (mm): 591 x 573 x 595 Weight (Kg): 35
DOCUMENT FEEDER
Original capacity (sheets): 40
PRINTER
Resolution (dpi): 600 x 600 Network Printer (Standard / Option): OPT Interface Std/Opt: STD USB 2.0 OPT 10Base-T/100Base-TX Supported OS Standard:
Windows 2000/XP, Windows Server 2003/2008/2008R2, Windows Vista, Windows 7 Supported OS Options: Mac OS X 10.2.8,10.3.9,10.4.11,10.5 – 10.5.8,10.6 – 10.6.5
Network protocols: TCP/IP Printing protocols: LPR, Raw TCP (port 9100), POP3 (e-mail printing),
HTTP, Novell Printserver application with NDS and Bindery, FTP for downloading print files, EtherTalk printing, IPP PDL Std/Opt: STD SPLC (GDI with JBIG compression) OPT PCL 6, PostScript 3 Available fonts: 80 (PCL), 136 (PS3)
FINISHING
Original paper size (Max.): A3 First copy out time B/W (sec.): 7,2 E-sort Std: Continuous copy (Max. copies): 999 Resolution Scan B/W (dpi): 600 x 600 Resolution Scan Colour (dpi): 600 x 600 Resolution Print (dpi): 600 x 600 Gradation (equivalent levels) - B/W: 2 Gradation (equivalent levels) - Colour: 256 Zoom range (%): 25-400 Preset copy ratios: 10
SCANNER
Network Scanner (Standard / Option): OPT Scan method Push scan and Pull scan: Resolution push scan (dpi): 75,100, 150,200, 300,400, 600 Resolution pull scan (dpi): 75,100, 150,200, 300,400, 600,50-9600 custom File formats: TIFF, PDF, JPEG Scanner utilities: Button Manager, Sharpdesk Scan destinations Desktop: Scan destination FTP, Email: Scan destination USB memory:
FAX
Fax (Standard / Option): OPT Compression method: JBIG/MMR/MR/MH Communication protocol: Super G3/G3 Transmission time (sec): 2 Modem Speed (bps): 33,600 - 2,400 Transmission resolution: STD: 203,2 x 97,8 dpi/Super Fine: 406,4 x 391
dpi
Document Size (Min): A5 Document Size (Max): A3 Memory (MB): 16 (not upgradeable) Grey Scale levels: 256 Dial Registration; rapid/speed dial: 350 Broadcast Transmission (max. destinations): 200
Off-set shifting: STD
