Sharp LC-15B4U User Manual

LC-15B4U

LIQUID CRYSTAL TELEVISION

ENGLISH

OPERATION MANUAL

ENGLISH

IMPORTANT: To aid reporting in case of loss or theft, please record the TV’s model and serial numbers in the space provided. The numbers are located at the rear of the TV.

Model No.:

Serial No.:

U.S.A. ONLY

IMPORTANT INFORMATION

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO

NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

The lightning flash with arrowhead symbol, within an equilat-

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

eral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

IMPORTANT INFORMATION (Continued)

WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment

not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

U.S.A. ONLY

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF

PLUG TO WIDE SLOT, FULLY INSERT.

“Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”

This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eia.org

DEAR SHARP CUSTOMER

Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years of trouble-free operation of your product, please read the Important Safety Precautions carefully before using this product.

IMPORTANT SAFETY PRECAUTIONS

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your LCD color TV product, please read the following precautions carefully before using the product.

■ Read instructions—All operating instructions must be read and understood before the product is operated.

■ Keep this manual in a safe place—These safety and operating instructions must be kept in a safe place for future reference.

■ Observe warnings—All warnings on the product and in the instructions must be observed closely.

■ Follow instructions—All operating instructions must be followed.

■ Attachments—Do not use attachments not recommended by the manufacturer. Use of inad-

equate attachments can result in accidents.

■ Power source—This product must operate on a power source specified on the specification label. If you are not sure of the type of power supply used in your home, consult your dealer or local power company. For units designed to operate on batteries or another power source, refer to the operating instructions.

■ Power cord protection—The power cords must be routed properly to prevent people from stepping on them or objects from resting on them. Check the cords at the plugs and product.

■ If the AC adapter is misplaced or needs to be replaced, obtain the same type of adapter from a SHARP service center or your dealer.

■ Overloading—Do not overload AC outlets or extension cords. Overloading can cause fire or electric shock.

■ Entering of objects and liquids—Never insert an object into the product through vents or openings. High voltage flows in the product, and inserting an object can cause electric shock and/or short internal parts. For the same reason, do not spill water or liquid on the product.

■ Servicing—Do not attempt to service the product yourself. Removing covers can expose you to high voltage and other dangerous conditions. Request a qualified service person to perform servicing.

■ Repair—If any of the following conditions occurs, unplug the power cord from the AC outlet, and request a qualified service person to perform repairs. a.When the power cord or plug is damaged. b.When a liquid was spilled on the product or when objects have fallen into the product. c. When the product has been exposed to rain or water. d.When the product does not operate properly as described in the operating instructions.

Do not touch the controls other than those described in the operating instructions. Improper

adjustment of controls not described in the instructions can cause damage, which often

requires extensive adjustment work by a qualified technician. e.When the product has been dropped or damaged. f. When the product displays an abnormal condition. Any noticeable abnormality in the product

indicates that the product needs servicing.

■ Replacement parts—In case the product needs replacement parts, make sure that the service person uses replacement parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.

■ Safety checks—Upon completion of service or repair work, request the service technician to perform safety checks to ensure that the product is in proper operating condition.

■ Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product according to the method recommended by the manufacturer.

■ Polarization—This AC adapter may be equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

IMPORTANT SAFETY PRECAUTIONS (Continued)

■ Cleaning—Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners.

■ Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen sink and laundry tub, swimming pool and in a wet basement.

■ Stand—Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.

■ When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops, excessive force and uneven floor surface can cause the product to fall from the cart.

■ Ventilation—The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are followed.

■ The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the Liquid Crystal panel breaks.

■ Heat sources—Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating products (including amplifiers).

■ The Liquid Crystal panel is a very high technology product with 921,600 thin film transistors, giving you fine picture details. Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.

IMPORTANT SAFETY PRECAUTIONS (Continued)

(

)

■ If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA

ELECTRIC SERVICE EQUIPMENT

NEC—NATIONAL ELECTRICAL CODE

GROUND CLAMPS POWER SERVICE GROUNDING

ELECTRODE SYSTEM

NEC ART 250, PART H

DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

■ Lighting – For added protection for this television equipment during a lightning storm, or when it is left unattended and unused for long period of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.

■ Power Lines – An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

■ To prevent fire, never place any type of candle or naked flames on the top or near the TV set.

■ To prevent fire or shock hazard, do not expose this products to dripping or splashing. No objects filled with liquids, such as vases, should be placed on the products.

CONTENTS

IMPORTANT INFORMATION ....................................................................................................... 1, 2

DEAR SHARP CUSTOMER .............................................................................................................3

IMPORTANT SAFETY PRECAUTIONS ....................................................................................... 3-5

CONTENTS ....................................................................................................................................... 6

SUPPLIED ACCESSORIES ............................................................................................................. 7

PREPARATION ............................................................................................................................ 8-10

Using the Remote Control ......................................................................................................... 8

Batteries for the Remote Control .............................................................................................. 8

Antenna Connection .............................................................................................................9, 10

Power Connection .................................................................................................................... 10

DISPLAY AND CONTROL OVERVIEW .................................................................................. 11-13

Removing the Back Cover ....................................................................................................... 13

Listening with Headphones ..................................................................................................... 13

REMOTE CONTROL ...................................................................................................................... 14

EZ SETUP (WITH AUTO CLOCK SETTING) ..........................................................................15, 16

EZ SETUP during the First Power On ..............................................................................15, 16

SETTING THE CLOCK ............................................................................................................. 17-19

AUTO CLOCK Setting .........................................................................................................17, 18

MANUAL CLOCK Setting ......................................................................................................... 19

BASIC OPERATION ................................................................................................................. 20-24

TV signals in your region ........................................................................................................ 20

Turning on POWER................................................................................................................... 21

Standby ...................................................................................................................................... 21

Switching TV/VIDEO [AV1/AV2/COMPONENT/TV] Modes ................................................... 22

Sound Volume ........................................................................................................................... 23

Changing Channels .................................................................................................................. 24

SELECTING MENU ITEMS ............................................................................................................25

Selecting Menu Items .............................................................................................................. 25

ADJUSTMENTS ........................................................................................................................ 26-43

Adjusting SLEEP TIMER Settings ........................................................................................... 26

Adjusting BRIGHTNESS Settings ........................................................................................... 27

Adjusting PICTURE FLIP Settings ..........................................................................................28

Adjusting PRESET Settings .................................................................................................... 29

Adjusting LANGUAGE Settings .............................................................................................. 30

Adjusting VIDEO ADJUST Settings ..................................................................................31, 32

SET UP .................................................................................................................................33, 34

Adjusting BLUE SCREEN Settings ......................................................................................... 35

Adjusting CLOSED CAPTION Settings .................................................................................. 36

Adjusting V-CHIP Settings .................................................................................................. 37-43

CONNECTING EXTERNAL DEVICES ..................................................................................... 44-46

Bundling Cables with Clamps ................................................................................................ 46

TROUBLESHOOTING ..............................................................................................................47, 48

SPECIFICATIONS........................................................................................................................... 49

DIMENSIONAL DRAWINGS .......................................................................................................... 50

CALLING FOR SERVICE ............................................................................................................... 51

LIMITED WARRANTY ..............................................................................................................51, 52

Page

SUPPLIED ACCESSORIES

Make sure the following accessories are provided with the product.

Remote Control

RRMCGA152WJSA (LC-15B4US) RRMCGA152WJSB (LC-15B4UB)

“AAA” size (UM/SUM-4) Dry Battery (×2)

AC CordAntenna Cable

QCNWG0003CEPA

AC Adapter

UADP-0212CEZZ

UADP-A009WJPZ

• AC cord enclosed in this product is an object for 110-125V. In using it on the 125-240V AC, please consult to the following.

SHARP ELECTRONICS CORPORATION 1300 Naperville Drive, Romeoville, Illinois 60446-1091, U.S.A. TEL: 630-226-2400

Operation Manual

UBATU0026GEZZ

TINS-A968WJZZ

QACCD3097CEPA

Cable Clamp (×2)

ENGLISHFRANÇAISESPAÑOLPORTUGUÊS

LHLDWA002WJSA

(LC-15B4US)

LHLDWA002WJSB

(LC-15B4UB)

PREPARATION

POWER SLEEP

Using the Remote Control

■ Use the remote control by pointing it towards the remote

control sensor window on the main unit. Objects between the remote control and sensor window may prevent proper operation.

Cautions regarding use of the remote control

■ Do not expose the remote control to shock.

In addition, do not expose the remote control to liquid, and do not place in an area with high humidity.

■ Do not install or place the remote control under direct

sunlight. The heat may cause deformation of the unit.

■ The remote control may not work properly if the remote

control sensor window of the main unit is under direct sunlight or strong lighting. In such case, change the angle of the lighting or LCD TV set, or operate the remote control closer to the remote control sensor window.

Batteries for the Remote Control

Before using the LCD TV set for the first time, install two (“AAA” size, UM/SUM-4) batteries (supplied). When the batteries become depleted and the remote control fails to operate, replace the batteries with new (“AAA” size, UM/SUM-4) batteries.

SLEEP indicator

POWER indicator

Remote control sensor

1 Open the battery

cover.

■ Slide the cover while pressing the (b) part.

Caution!

2 Insert two (“AAA” size, UM/

SUM-4) batteries.

–

■ Position the positive and negative ends of the batteries as indicated in the compartment.

3 Close the battery

cover.

■ Engage the claw on the cover into the battery housing and slide shut.

Cautions regarding batteries

Improper use of batteries can result in chemical leakage and/or explosion. Be sure to follow the instructions below.

• Place batteries with their terminals corresponding to the (+) and (–) as indicated in the compartment.

• Different types of batteries have different characteristics. Do not mix batteries of different types.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new

battery and/or cause the old battery to leak chemicals.

• Remove batteries when they become weak. Chemicals that leak from batteries can cause a rash. If chemical leakage is found, wipe with a cloth.

• The batteries supplied with the product may have a shorter life expectancy due to storage conditions.

• If the remote control will not be used for an extended period of time, remove the batteries from the

remote control.

PREPARATION (Continued)

Antenna Connection

ANTENNAS

• The antenna requirements for good color television reception are more important than those for black & white television reception. For this reason, a good quality outdoor antenna is strongly recommended. The following is a brief explanation of the type of connections that are provided with the various antenna systems.

1. A 75-ohm system is generally a round cable with F-type

F-type connector

connector that can easily be attached to a terminal without tools (not supplied).

75-ohm coaxial cable (round)

2. A 300-ohm system is a flat “twin-lead” cable that can be attached to a 75-ohm terminal through a 300-75-ohm adapter (not supplied).

300-ohm twin-lead cable (flat)

OUTDOOR ANTENNA CONNECTION

• Use one of the following two diagrams if you connect an outdoor antenna. A: Using a VHF/UHF combination outdoor antenna B: Using separate VHF and/or UHF outdoor antennas

• Connect the outdoor antenna cable lead-in to ANT. (Antenna terminal) on the rear of the TV set.

A. Combination VHF/UHF Antenna

300/75-ohm

adapter

VHF/UHF

antenna

300-ohm twin-lead

(not supplied)

VHF/UHF

antenna

75-ohm

coaxial cable

NOTICE

75-ohm coaxial cable

ANT.

USE THE SUPPLIED AC ADAPTER. (

PART NO. LOCATED ON

THE MODEL LABEL.

)

POWER

INPUT DC12V

F-type connector

Antenna cable (supplied)

B. Separate VHF and/or

UHF Antennas

300-ohm twin-lead

Combiner

ANT. (Antenna terminal)

(not supplied)

OUT IN

300-ohm twin-lead

75-ohm coaxial cable

F-type connector should be finger-tightened only.

When connecting the RF cable to the TV set, do not tighten F-type connector with tools. If tools are used, it may cause damage to your TV set. (The breaking of internal circuit, etc.)

UHF

antenna

VHF

antenna

PREPARATION (Continued)

Antenna Connection (Continued)

CABLE TV (CATV) CONNECTION

• A 75-ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75ohm coaxial cable to the set, screw the 75-ohm cable to the ANT. terminal.

• Some cable TV companies offer “premium pay channels”. Since the signals of these premium pay channels are scrambled, a cable TV converter/descrambler is generally provided to the subscriber by the cable TV company. This converter/descrambler is necessary for normal viewing of the scrambled channels. (Set your TV to channel 3 or 4, typically one of these channels is used. If this is unknown, consult your cable TV company.) For more specific instructions on installing cable TV, consult your cable TV company. One possible method of utilizing the converter/descrambler provided by your cable TV company is explained below.

Please note: An RF switch provided with two inputs (A and B) is required (not supplied).

“A” position on the RF switch (not supplied): You can view all unscrambled channels by using the TV’s

channel keys.

“B” position on the RF switch (not supplied): You can view the scrambled channels via the converter/

descrambler by using the converter’s channel keys.

RF switch (not supplied)

OUT

Cable TV converter/

descrambler

(not supplied)

• Consult your SHARP Dealer or Service Center for the type of splitter, RF switch or combiner that might be

required.

Two-set signal splitter (not supplied)

Cable TV Line

Power Connection

MAIN POWER

ANT.

PLIE

TER

(

T N

. LO

EL LA

)

POW

INPUT DC12V

POWER INPUT terminal (DC12V)

Household power outlet

AC adapter

AC cord

• Use a commercially available AC plug adapter, if necessary, depending on the design of the wall outlet.

• Always turn the MAIN POWER switch of the LCD TV set to off when connecting the AC adapter.

• Unplug the AC adapter from the product and power outlet when not using for a long period of time.

DISPLAY AND CONTROL OVERVIEW

Controls

Upper control panel

VOL (l)/(k) CH ( )/( ) MENU TV/VIDEO MAIN POWER

Speaker (Left)

CHVOL

MAIN POWERTV/VIDEO

Speaker (Right)

To change the vertical angle of the LCD TV set, tilt the screen up to 5 degrees forward or 10 degrees backward. The TV set can also be rotated 25 degrees to right and left. Adjust the angle so that the TV set can be watched most comfortably.

Remote control sensor

POWER indicator

A green indicator lights when the power is on and a red indicator lights when in the standby mode (the indicator will not light when the main power is off).

• TV/VIDEO, CH ( )/( ), VOL (l)/(k), and MENU on the main unit have the same functions as the same buttons

on the remote control. Basically, this operation manual provides a description based on operation with the remote control.

SLEEP indicator

The SLEEP indicator lights up red when the SLEEP TIMER is set.

DISPLAY AND CONTROL OVERVIEW (Continued)

Terminals

VIDEO

AV-IN2/OUT

AUDIO

COMPONENT

AUDIO

VIDEO AUDIO (L) AUDIO (R) Y PB PR AUDIO (L) AUDIO (R)

● Adjusting the screen view angle

AV-IN2/OUT

COMPONENT

Hold the carrying handle and tilt the screen while steadying the stand with your other hand.

Carrying handle

VIDEO

AUDIO (L)

AV-IN1

AUDIO (R)

S-VIDEO

HEADPHONE

ANT. (Antenna terminal)

POWER INPUT

(DC12V)

VIDEO

AUDIO

S-VIDEO

HEAD

PHONE

ANT.

USE THE SUPPLIED AC ADAPTER. (

PART NO. LOCATED ON

THE MODEL LABEL.

POW

INPUT

DC12V

AV-IN1

)

DISPLAY AND CONTROL OVERVIEW (Continued)

Removing the Back Cover

■ Before connecting cables and cords to the rear terminals, remove the back covers. Push in the tabs and pull out the back covers carefully.

■ To mount the cover, insert the 2 hooks on the bottom of the cover into the cabinet and press on the upper part of the back cover until the tab locks in place with a click.

Listening with Headphones

■ Plug the headphone mini-plug into the HEADPHONE jack located on the rear of the TV set.

▼ On-screen display

c Rear terminal

VOLUME

Adjust the sound volume

Headphones

• Headphones are not included in the supplied accessories.

• No sound is heard from the main unit speakers when a headphone mini-plug is connected into the

HEADPHONE jack.

using VOL (e)/(f) on the remote control.

REMOTE CONTROL

2 3

6 7

POWER

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

BACK

CHVOL

1 POWER (p. 21)

Switch the Liquid Crystal Television power on or off.

2 DISPLAY

Display the channel and time information.

3 SLEEP (p. 26)

Set the sleep timer.

4 ENTER

13 14

Execute a command.

5 BRIGHT (p. 27)

Adjust the brightness of the screen.

6 MUTE (p. 23)

Mute the sound.

7 VOL (+)/(–) (p. 23)

Set the volume.

8 CH ( )/( ) (p. 24)

Select channel.

9 MTS (p. 23)

Select audio settings.

10 PIC. FLIP (p. 28)

Set the orientation of the picture.

11 a/b/c/d (Cursor control) (p. 15)

Select a desired item on the screen.

12 TV/VIDEO (p. 22)

Select a Liquid Crystal Television input source.

13 MENU (p. 17)

Display the menu screen.

14 FLASHBACK (p. 24)

Return to the previous channel.

15 Channel Select (p. 24)

Set the channel.

EZ SETUP (WITH AUTO CLOCK SETTING)

EZ SETUP during the First Power On

Control section of main unit

MAIN POWER

TV/VIDEO

CHVOL

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASH-

BACK

ENTER/ a/b/c/d

■ When you turn on the TV for the first time, it will automatically memorize the broadcasting channels and clock. Please perform the following instructions before you press MAIN POWER. (1) Insert the batteries into the remote control. (See page 8.) (2) Connect the antenna cable to the TV set. (See page 9.) (3) Connect the AC adapter to the POWER INPUT terminal of the

product and plug in the AC cord to the wall outlet. (See page 10.)

1 Press MAIN POWER, located on

the upper side of the main unit, to turn on the TV. The SELECT LANGUAGE mode will be dis-

ENGLI SH ESPAÑOL FRANCAI S

SELECT LANGUAGE

played.

2 Press a/b to select “ENGLISH”,

“ESPAÑOL (SPANISH)” or “FRANCAIS (FRENCH)”, and press

ENTER.

3 Press a/b to select ON or OFF.

When you select ON, the TV set will automatically memorize the broadcasting channels.

Press ENTER to access AUTO CLOCK mode.

4 Press a/b to select ON or OFF.

When you select ON, the TV set will automatically search the time signals (EDS signals), provided by some TV stations, to adjust the clock. The AUTO CLOCK setting may take from several minutes to an hour depending on the number of channels to receive and signal status. If you know the channel of the EDS signal carrier (PBS or other) in your area, select OFF and follow the procedure in AUTO CLOCK Setting. (See pages 17,

18)

SELECT : ENTER: EXIT:

CH- SET T ING ON OFF

SELECT : ENTER: EXIT:

AUTO CLOCK ON OFF

SELECT : ENTER: EXIT:

EZ SETUP

ENTER

5 Press ENTER to access start EZ

SETUP mode.

• If you select OFF in “EZ SETUP CH-SETTING”, EZ SETUP will be canceled.

EZ SETUP (WITH AUTO CLOCK SETTING) (Continued)

EZ SETUP during the First Power On (Continued)

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASHBACK

ENTER/ a/b/c/d

6 Press a/ b to select YES, and

press ENTER.

If you want to stop the EZ SETUP process once it has started, press c and it will be canceled. If you want to SET UP again, please refer to pages 33 and 34 on SET UP.

To cancel EZ SETUP

Press c.

The tuner will automatically search for the broadcasting and cable TV channels. (The CH No. will automatically increase when it appears.)

The TV set will automatically search for EDS signals.

CONNECT ANTENNA OR CABL E.

START EZ SETUP?

YES

SELECT : ENTER:

PLEASE WAIT

AUTO PROGRA

STOP:

PLEASE WAIT

SEARCH ING T IME

ING

ENTER

EXIT:

If EDS signals are received, the channel number and time will be displayed, and then the screen shown in step 7 appears.

STOP:

7 Once EZ SETUP is completed, the

lowest channel number memorized will be displayed.

STEREO<ON A I R SAP

ONO

• Do not let the EZ SETUP screen remain unattended for a long time.

• If EZ SETUP does not memorize all the channels in your region, please refer to pages 33 and 34 for more

information on manually memorizing the channels using CHANNEL SETTING.

• It may be difficult to preset when the broadcasting signals are weak, the channel cycle frequency is incorrect or the frequency jamming is occurring around the area. Please refer to pages 33 and 34 for more information on manually memorizing channels using CHANNEL SETTING.

• If there are no channels with EDS signals or the antenna signal is weak, the AUTO CLOCK Setting may not operate. In this case, a “EDS CH IS NOT AVAILABLE” message will display and the mode will change to MANUAL CLOCK Setting. Refer to page 19 to set the clock manually.

11: 53AM

SETTING THE CLOCK

AUTO CLOCK Setting

There are two methods of setting the clock: AUTO CLOCK and MANUAL CLOCK. AUTO CLOCK uses EDS signals, which are provided by some TV stations, to automatically adjust the clock. MANUAL CLOCK set the clock manually in areas where no channel carries EDS signals.

POWER

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASH-

BACK

ENTER/ a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SET UP, and press ENTER.

3 Press a/b to move the cursor to

CLOCK, and press ENTER.

4 Press a/b to move the cursor to

AUTO CLOCK, and press ENTER.

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

ENTER

SELECT : EXIT:

RETURN BLUE SCREEN [OFF]

LANGUAGE CH–SETT I NG CLOCK

SELECT : EXIT:

RETURN AUTO CLOCK M

ANUAL CLOCK

OFF

ENTER:

SET UP

ENTER:

CLOCK

ENTER

SELECT : ENTER: EXIT:

ENTER

• The CLOCK can be stopped completely by setting CLOCK to “OFF”.

Time reset for power outage, AC adapter disconnected

If the TV has a power outage or the AC adapter cord is disconnected, the time display will have to be reset. In that case, refer to SETTING THE CLOCK on pages 17 to 19.

SETTING THE CLOCK (Continued)

AUTO CLOCK Setting (Continued)

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASHBACK

ENTER/ a/b/c/d

5 Press a/b to move the cursor to

EDS CH SET, and press ENTER.

6 Press c/d to select AUTO or

MANUAL.

7 Press a/b to move the cursor to

START, and press ENTER.

● If you do not know the channel that carries EDS signals in your area, select EDS CH SET to AUTO and select START. If you know the channel of the EDS signal carrier in your area, select EDS CH SET to MANUAL. Set the EDS CH and select START.

● When set to “AUTO CLOCK”, the time is acquired automatically when MAIN POWER is turned OFF. (This function will not work when EDS CH is not set.)

RETURN EDS CH SET [ AUTO ]

EDS CH [ –––] START

ADJ UST :

PLEASE WAIT

STOP:

STEREO<ON A I R SAP

ONO

AUTO CLOCK

SEARCH ING T IME

ENTER:

ENTER

EXIT:

11: 53AM

• CLOCK: The AUTO CLOCK setting may take from several minutes to an hour depending on the number of channels to receive and signal status.

• If there are no channels with EDS signals or the antenna signal is weak, the AUTO CLOCK Setting may not operate. In this case, an “EDS CH IS NOT AVAILABLE” message will display, and the MANUAL CLOCK Setting screen appears. Refer to MANUAL CLOCK Setting on page 19 to set the clock manually.

• If you know the Channel of the EDS signal carrier in your area, set EDS CH SET to MANUAL and select START. In case, the message “EDS CH (XXX) EDS DATA IS NOT AVAILABLE” displays, set EDS CH SET to AUTO when the AUTO CLOCK Setting screen appears.

• If broadcasting channels are not memorized, EDS signals cannot be received even when the EDS CH SET is set to AUTO. In this case, try EZ SETUP again. (See page 33.)

SETTING THE CLOCK (Continued)

MANUAL CLOCK Setting

If there are no channels with EDS signals, set the clock manually using MANUAL CLOCK.

WER

BRIGHT

SLEEP PIC. FLIP

ENTER

DISPLAY MENU

AUDIO

MUTE

TV/VIDEO

ONLY

FLASH-

CHVOL

BACK

ENTER/ a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SET UP, and press ENTER.

3 Press a/b to move the cursor to

CLOCK, and press ENTER.

4 Press a/b to move the cursor to

MANUAL CLOCK, and press

ENTER.

5 Press a/b to move the cursor to

TIME, and press ENTER.

6 Press c/d to set the time, and

press ENTER.

12:00AM 11:59AM 11:59PM 12:00PM

• Make sure to press ENTER after adjusting the time. Otherwise, the time will not be set.

• When DST is set to ON, the time entered is forwarded by 1 hour.

7 Press MENU to return to the main

screen.

ENU SLEEP T IMER AV AD JUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

RETURN BLUE SCREEN [OFF]

LANGUAGE CH–SETT I NG CLOCK

RETURN AUTO CLOCK M

ANUAL CLOCK

OFF

SELECT : ENTER: EXIT:

RETURN T IME [ 12 : 00AM] DST [ OFF ]

ADJ UST :

SET UP

CLOCK

ANUAL CLOCK

ENTER:

ENTER

EXIT:

Daylight Saving-Time (DST) Adjustment

The Daylight Saving-Time changes as shown below, set the DST to ON to forward the clock by 1 hour. To rewind the clock by 1 hour, set the DST to OFF.

(Spring)

On the first Sunday in April D.S.T. starts.

1:00AM 2:00AM

Advances 1 hour.

3:00AM 4:00AM

(Autumn)

On the last Sunday in October D.S.T. finishes.

1:00AM 2:00AM

Rewinds 1 hour.

1:00AM 2:00AM

BASIC OPERATION

TV signals in your region

This product is factory set to comply with the TV broadcasting system in the United States. For Brazil, Argentina and Uruguay, set the color system according to the country before using this product by following the table below.

The VIDEO INPUT mode is compatible with color systems worldwide and is automatically set.

The World Multi Auto System

Country

U.S.A.

Canada, Mexico, Color: NTSC NTSC (N358) World Multi Latin America TV ch: US ch US ch Auto System

Brazil

Argentina, Color: PAL-N NTSC (N358) World Multi Set color system to Uruguay TV ch: US ch US ch Auto System PAL-N (see page 32)

TV broadcasting system

Color: NTSC NTSC (N358) World Multi

TV ch: US ch US ch Auto System

Color: PAL-M NTSC (N358) World Multi Set color system to TV ch: US ch US ch Auto System PAL-M (see page 32)

Factory setting of color system User setting

TV Video TV

Not required or N/A

is compatible with all color systems indicated below.

1 N358 2 N443 3 PAL 4 PAL-M 5 PAL-N 6 SECAM 7 PAL-60

BASIC OPERATION (Continued)

Turning on POWER

Control section of main unit

POWER indicator

Standby

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

MAIN POWER

TV/VIDEO

CHVOL

FLASH-

BACK

POWER

1 Press MAIN POWER, located on

the upper side of the main unit, to on.

2 The POWER indicator instantane-

ously changes from red to green and the main unit turns on.

• The On-screen indicator disappears after a few seconds.

Notes:

To turn off the LCD TV

Press POWER on the remote control. The POWER indicator turns red.

To turn the LCD TV back on

Press POWER again. The POWER indicator turns green.

▼ On-screen display

STEREO SAP M

ONO

BASIC OPERATION (Continued)

Switching TV/VIDEO [AV1/AV2/COMPONENT/TV] Modes

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

CHVOL

BACK

TV/VIDEO

1 Turn on the power of the con-

nected video equipment.

2 Press TV/VIDEO and select the

applicable input source. The screen displays AV1, AV2, COMPONENT or TV mode each time TV/VIDEO is pressed.

• The AV input mode indication remains for 3 seconds.

• AV1: Video equipment connected to the

AV-IN1 input terminals. The S-video input terminal is additionally provided for the AVIN1 input. If both the S-video terminal and normal video terminals are connected with cables, the S-video input terminal takes priority.

• AV2: AV2 mode is used to adjust the

preset settings and IN or OUT can be selected. AV2 indication is not displayed when OUT is selected. (For details on setting AV2 IN/OUT, see page 29.)

• COMPONENT:

Video equipment connected to the COMPONENT input terminals. Playback from 480 progressive output equipment is available.

AV1 mode

AV1

AV2 mode

AV2

COMPONENT mode

COMPON ENT

TV mode

STEREO<ON A IR SAP M

ONO

BASIC OPERATION (Continued)

Sound Volume

POWER

POW

SLEEP PIC. FLIP

MUTE

BRIGHT TV/VIDEO MENU

DISPLAY

ENTER

CHVOL

FLASH-

BACK

MUTE

VOL (+)/(–)

MTS

1 Press VOL (+) to increase the sound

volume. The bar indicator shifts right.

VOLUME

2 Press VOL (–) to decrease the sound

volume. The bar indicator shifts left.

VOLUME

To mute the sound

1 Press MUTE to temporarily turn off

the sound. The MUTE mark 4 seconds.

is displayed for

2 Press MUTE or VOL (+)/(–) to turn

the sound back to the previous level. The mute function is automatically turned off when any of the following buttons are pressed: POWER,

VOLUME

VOL (+)/(–) or MTS.

To select MTS (Multichannel TV Sound)

1 Press MTS to display the MTS

screen.

2 Press MTS to select the MTS

settings. STEREO: stereo audio SAP: secondary audio program MONO: monophonic audio

•<ON AIR appears when a STEREO or SAP

broadcast is being aired.

STEREO<ON A I R SAP M

ONO

BASIC OPERATION (Continued)

Changing Channels

Changing channels by using Channel Select on the remote control

• This LCD TV set allows you to select up to 125 channels (1 to 125). To select a channel, enter a 2or 3-digit number.

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

CHVOL

BACK

)/( )

(

FLASHBACK

Channel Select

To select a 1- or 2-digit channel number (e.g., Channel 5):

Complete the following procedure within 4 seconds.

1 Press the button. 2 Press the

• When selecting a 1-digit channel

number, do not fail to press the button first.

To select a 3-digit channel number (e.g., Channel 115):

Complete the following procedure within 4 seconds.

button.

1 Press the button. 2 Press the button. 3 Press the

• The 3-digit channel number can be

selected only when the receiving mode is set to CABLE in CH-SETTING. (For details on setting the receiving mode, see page 33.)

• Press FLASHBACK to show the previous channel.

button.

0 –

1 ––

11–

115

Changing channels with CH ( )/( ) on the remote control

Air Press CH ( ) and the channels change in the order shown below:

2 → 3 → . . . → 68 → 69 → 2 → 3 → . . . Press CH (

) and the channels change in the order shown below:

3 → 2 → 69 → 68 → . . . → 3 → 2 → . . .

Cable Press CH (

) and the channels change in the order shown below:

1 → 2 → 3 → . . . → 125 → 1 → 2 → 3 → . . . Press CH (

) and the channels change in the order shown below:

3 → 2 → 1 → 125 → . . . → 3 → 2 → 1 → . . .

SELECTING MENU ITEMS

Selecting Menu Items

• This LCD TV set allows you to adjust the various settings using the menu screen. Select the desired menu item by following the steps below and then refer to the indicated page for details.

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

BACK

CHVOL

ENTER/ a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to select the desired

menu item, and press ENTER.

3 Press MENU to exit.

ENU SLEEP T IMER VI DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

SELECT : EXIT:

ENTER:

ENTER

• The displayed items differ depending on the setting conditions.

• The selected item changes to yellow.

• Items in magenta cannot be selected.

• TV mode

This product is factory set to comply with the color system in the United States (NTSC-N358). For Brazil (PAL-M), Argentina (PAL-N) and Uruguay (PAL-N), set the color system before using this product.

• To return to the previous screen, select RETURN.

• You can adjust some settings with the special buttons: SLEEP, BRIGHT and PIC. FLIP (see pages 26–28).

(Page 26)

SLEEP T IMER

RETURN

ER [––– REMAIN]

SLEEP T I

SELECT : ENTER: EXIT:

ENTER

(Pages 31 and 32)

V IDEO ADJUST( TV) RETURN PICTURE [ 50] TINT COLOR BLACK LEVEL SHARPNESS RED- BLUE GREEN COLOR SYSTEM RESET

SELECT : ENTER:

[ 0] [ 0] [ 0] [ 0] [ 0] [ 0] [ N358]

ENTER

(Pages 27–29)

ER OFF

PRESET

ENTER:

[OFF ]

AL ]

[NOR [IN ]

ENTER

RETURN BRI GHTNESS [BRI GHT] M

TS [ ST EREO]

AUTO PO

PICTURE FLIP

AV2 IN/OUT

SELECT : EXIT:

(Page 36)

CLOSED CAPT I ON

RETURN

[OFF]

CC/ TEXT

SELECT : EXIT:

ENTER:

ENTER

(Pages 37–43)

EXIT:

* The illustrations and on-screen displays in this operation manual are for

explanation purposes and may vary slightly from the actual operations.

INPUT SECRE T NO.

– – – –

EXIT:

(Pages 17–19, 30 and 33–35)

RETURN BLUE SCREEN [OFF] LANGUAGE CH–SE TT ING CLOCK

SELECT : EXIT:

SET UP

ENTER:

ENTER

ADJUSTMENTS

Adjusting SLEEP TIMER Settings

You can set the SLEEP TIMER to automatically turn off the TV.

Directly setting the SLEEP TIMER

1 Press SLEEP to display the SLEEP

POWER

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASH-

BACK

SLEEP

TIMER screen.

2 Press SLEEP to set the sleep timer

(in minutes).

---

30 60

–– – REMA IN

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

CHVOL

BACK

ENTER/ a/b/c/d

120

(minutes)

The SLEEP TIMER is turned off when --- is displayed.

• The SLEEP TIMER screen automatically disappears in 3 seconds.

Setting the SLEEP TIMER on the MENU screen

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SLEEP TIMER.

3 Press ENTER to display the

SLEEP TIMER screen, and press

ENTER.

4 Press c/d to set the sleep timer

(in minutes), and press ENTER.

The time can be set in increments of 30 minutes and in the range between 30 and 120 minutes.

60 REMAI N

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

SELECT : ENTER: EXIT:

RETURN

SLEEP T I

ENTER

SLEEP T IMER

ER [––– REMAIN]

The SLEEP TIMER is turned off when --- is displayed.

5 Press MENU to return to the main

screen.

SELECT : EXIT:

RETURN

SLEEP T I

• When you set the SLEEP TIMER, the SLEEP indicator lights up red.

• After you set the SLEEP TIMER, pressing MAIN POWER on the TV set or POWER on the remote control will cancel the SLEEP TIMER setting and the SLEEP indicator goes out.

• 5 minutes before the SLEEP TIMER turns off the TV, 5 REMAIN is displayed on the screen for 4 seconds. The SLEEP TIMER counts down and shows a similar 4-second display for each remaining minute until the timer turns off the TV.

ENTER

ENTER:

SLEEP T IMER

ER [–60 REMAIN]

ADJUSTMENTS (Continued)

Adjusting BRIGHTNESS Settings

You can adjust the brightness of the screen.

Directly setting the BRIGHTNESS

1 Press BRIGHT to display the

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASHBACK

BRIGHT

BRIGHTNESS screen.

2 Press BRIGHT to change the

setting.

BRIGHT

DARK

• The BRIGHTNESS screen automatically disappears in 3 seconds.

• [BRIGHT]: maximum brightness [NORMAL]: 60% brightness (Suitable for

viewing in a well-lit area. Saves energy.)

[DARK]: 10% brightness (Sufficiently

bright when viewing in dim areas.)

NORMAL

BRI GHTNESS [BR IGHT ]

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

BACK

CHVOL

ENTER/ a/b/c/d

Setting the BRIGHTNESS on the MENU screen

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

PRESET, and press ENTER.

3 Press a/b to move the cursor to

BRIGHTNESS, and press ENTER.

4 Press c/d to change setting, and

press ENTER.

5 Press MENU to return to the main

screen.

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

ENTER

ER OFF

ENTER:

PRESET

ENTER:

[OFF ] [NOR

AL ]

[IN ]

ENTER

EXIT:

SELECT : EXIT:

RETURN BRIGHTNESS [BR I GHT ] M

TS [STEREO] AUTO PO PICTURE FLIP AV2 IN/OUT

ADJ UST :

ADJUSTMENTS (Continued)

Adjusting PICTURE FLIP Settings

You can set the orientation of the picture.

Directly setting the PICTURE FLIP

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

CHVOL

1 Press PIC. FLIP to display the

PICTURE FLIP screen.

2 Press PIC. FLIP to change the

PIC. FLIP

BACK

setting.

MIRROR ROTATENORMAL

UPSIDE DOWN

• The PICTURE FLIP screen automatically disappears in 3 seconds.

• [NORMAL]: normal image [MIRROR]: mirror image [ROTATE]: rotated image [UPSIDE DOWN]: upside down image

ABC

P I CTURE F LI P [ NORMAL]

ABC

P I CTUR E FL I P [ MI RROR]

P I CTURE F LI P [ ROTA TE ]

ABC

P I CTURE F LI P [ UPS I DE DOWN]

ABC

POWER

SLEEP PIC. FLIP

MUTE

BRIGHT TV/VIDEO MENU

DISPLAY

ENTER

CHVOL

FLASH-

BACK

ENTER/ a/b/c/d

Setting the PICTURE FLIP on the MENU screen

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

PRESET, and press ENTER.

3 Press a/b to move the cursor to

PICTURE FLIP, and press

ENTER.

4 Press c/d to select the desired

picture flip setting, and press

ENTER.

5 Press MENU to return to the main

screen.

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

ENTER

SELECT : EXIT:

RETURN BRIGHTNESS [BR I GHT ] M

TS [STEREO] AUTO PO PICTURE FLIP

AV2 IN/OUT

ADJ UST :

ENTER:

PRESET

ER OFF

[OFF ] [NOR

[IN ]

ENTER

ENTER: EXIT:

AL ]

ADJUSTMENTS (Continued)

Adjusting PRESET Settings

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASHBACK

CHVOL

ENTER/ a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

PRESET, and press ENTER.

3 Press a/b to move the cursor to

the desired item, and press

ENTER.

4 Press c/d to change the setting,

and press ENTER.

5 Press MENU to return to the main

screen.

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

ENTER

ER OFF

ENTER:

PRESET

ENTER:

[OFF ] [NOR

AL ]

[IN ]

ENTER

EXIT:

SELECT : EXIT:

RETURN BRIGHTNESS [ BR I GHT ] M

TS [STEREO] AUTO PO PICTURE FLIP AV2 IN/OUT

ADJ UST :

Selected item Factory setting Setting options

BRIGHTNESS [BRIGHT] Maximum brightness [NORMAL] Brightness 60% → Suitable for viewing in a well-lit area.

[DARK] Brightness 10%

MTS* [STEREO] Stereo audio [SAP] Secondary audio program

[MONO] Monophonic audio

AUTO POWER OFF [OFF] This feature is inactive. [ON] The power of the LCD TV set is turned off when there is (only TV mode) no signal for 5 minutes.

PICTURE FLIP [NORMAL] Normal image [MIRROR] Mirror image → To display mirror images for special uses.

orientation

Saves energy.

→ Sufficiently bright when

viewing in dim areas.

ABC

[ROTATE] Rotated image

ABC

→ To display rotated images for special

uses.

ABC

[UPSIDE DOWN] Upside down image

→ To display images upside

down for special uses.

ABC

AV2 IN/OUT [IN] AV-IN2 terminals selected [OUT ] Line Output is selected, Output volume is fixed, Speaker

* In AV1, AV2 or COMPONENT mode, MTS displayed in magenta cannot be selected.

as input terminals output is available.

[OUT

] Line Output is selected, Output volume is variable,

Speaker output is Mute.

ADJUSTMENTS (Continued)

Adjusting LANGUAGE Settings

The language for the On-Screen Display can be ENGLISH, SPANISH or FRENCH.

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

CHVOL

BACK

ENTER/ a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SET UP, and press ENTER.

3 Press a/b to move the cursor to

LANGUAGE, and press ENTER.

4 Press a/b to select the

language, and press ENTER.

ENU

SLEEP T IMER V I DEO ADJUST PRESET

CLOSED CAPT I ON V–CHI P BLOCK

SET UP

ENTER:

SET UP

ENTER:

LANGUAGE

ENTER

SELECT : ENTER: EXIT:

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

SELECT : EXIT:

RETURN BLUE SCREEN [OFF]

LANGUAGE CH–SETT I NG CLOCK

SELECT : EXIT:

RETURN

ENGLI SH ESPAÑOL

FRANCAI S

SELECT : EXIT:

ENTER:

ENTER

ADJUSTMENTS (Continued)

Adjusting VIDEO ADJUST Settings

Video adjustments have different selection items depending on TV mode or AV mode (signal from an external device). (See page 32.)

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASHBACK

CHVOL

ENTER/ a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

VIDEO ADJUST, and press ENTER.

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

SELECT : ENTER: EXIT:

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

ENTER

3 Press a/b to move the cursor to

the desired item, and press

ENTER.

4 Press c/d to change the setting.

• See page 32 for the settings.

5 Press MENU to return to the main

screen.

SELECT : EXIT:

V I DE O ADJUST ( TV)

RETURN

PICTURE [ 50] TINT COLOR BLACK LEVEL

SHARPNESS RED- BLUE GREEN

COLOR SYSTEM

RESET

SELECT : ENTER: EXIT:

RETURN

P ICTURE

SELECT :

ENTER

ENTER:

[ 0] [ 0] [ 0] [ 0] [ 0] [ 0] [ N358 ]

ENTER

– +

ADJ UST :

EXIT:

ADJUSTMENTS (Continued)

Adjusting VIDEO ADJUST Settings (Continued)

TV mode

Selected item Press c Press d

PICTURE Decrease contrast Increase contrast

TINT Toward purple Toward green

COLOR Lower color intensity Higher color intensity

BLACK LEVEL Less brightness More brightness

SHARPNESS Soft picture Sharp picture

RED-BLUE Stronger red Stronger blue

GREEN Weaker green Stronger green

COLOR SYSTEM

N358 PAL-M PAL-N

AV/COMPONENT mode

Selected item Press c Press d

PICTURE Decrease contrast Increase contrast

TINT Toward purple Toward green

COLOR Lower color intensity Higher color intensity

BLACK LEVEL Less brightness More brightness

SHARPNESS Soft picture Sharp picture

RED-BLUE Stronger red Stronger blue

GREEN Weaker green Stronger green

COLOR SYSTEM* • Press c/d to select the COLOR SYSTEM. (AV1/AV2)

* COMPONENT mode has no COLOR SYSTEM.

• In BLUE SCREEN, VIDEO ADJUST settings displayed in magenta cannot be selected.

• Selecting RESET will return all settings to the factory settings. (See page 31.)

• TV mode

This product is factory set to comply with the color system in the United States (NTSC-N358). For Brazil (PAL-M), Argentina (PAL-N) or Uruguay (PAL-N), adjust the color system before using this product.

• COLOR SYSTEM When you set COLOR SYSTEM to AUTO, the AUTO mode automatically detects the receiving signal system and adjusts the reception system of the TV set. When the picture or sound is not stable, set a specific COLOR SYSTEM (not AUTO). The picture and sound may be improved.

ADJUSTMENTS (Continued)

SET UP

■ EZ SETUP

When you move to an area with different broadcasting signals, the set will automatically memorize the channel number and time. Refer to pages 15 and 16 for more information on EZ SETUP.

■ SETTING THE AIR/CABLE

It is necessary to set the receiving mode to AIR or CABLE channels to receive locally broadcast TV programs.

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

ENTER

SELECT : EXIT:

RETURN BLUE SCREEN [OFF] LANGUAGE CH–SETT I NG CLOCK

ENTER:

SET UP

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

BACK

CHVOL

ENTER/ a/b/c/d

1 Switch the screen to TV mode and

press MENU to Display the MENU screen.

2 Press a/b to move the cursor to

SET UP, and press ENTER.

3 Press a/b to move the cursor to

CH-SETTING, and press ENTER.

• When the screen is not in TV mode, CH-SETTING is displayed in magenta and not available.

4 Press a/b to move the cursor to

5 Press a/b to move the cursor to

6 Press MENU to return to the main

• Receivable channels of your TV set are: AIR channels: CABLE channels: VHF: 2 through 13. 1 (HRC and IRC) UHF: 14 through 69. 2 through 125 (STD, HRC and IRC)

AIR/CABLE, and press ENTER.

the desired mode, and press ENTER.

screen.

SELECT : EXIT:

RETURN EZ SETUP AI R/CABLE CH SEARCH

MEM

ORY

SELECT : ENTER: EXIT:

RETURN AIR CABLE

SELECT :

ENTER

ENTER:

CH–SETT I NG

ENTER

AIR/CABLE

ENTER

ENTER:

EXIT:

ADJUSTMENTS (Continued)

SET UP (Continued)

■ Saving broadcast TV channels in the memory

1 Press MENU to display the MENU

screen, press a/b to move the cursor to SET UP, and press

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

CHVOL

BACK

ENTER/ a/b/c/d

ENTER.

2 Press a/b to move the cursor to

CH-SETTING, and press ENTER.

3 Press a/b to move the cursor to

CH SEARCH, and press ENTER.

4 Press d. The tuner will search

ENU SLEEP T IMER V I DEO ADJUST PRESET CLOSED CAPT I ON V–CHI P BLOCK SET UP

RETURN BLUE SCREEN [OFF]

LANGUAGE CH–SETT I NG CLOCK

RETURN EZ SETUP AI R/CABLE CH SEARCH CH

MEM

SET UP

CH–SETT I NG

ORY

through all available channels in your area and add them to the TV memory.

• To interrupt CH SEARCH, press c.

CH SEARCH will stop at the current channel and will not add any higher channels.

START: EXIT:

CH SEARCH

AIR 2

■ Adding weak or additional channels or erasing unwanted channels from TV memory

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASH-

BACK

ENTER/ a/b/c/d

Channel Select

1 Press MENU to display the MENU

screen, press a/b to move the cursor to SET UP, and press

ENTER.

2 Press a/b to move the cursor to

CH-SETTING, and press ENTER.

3 Press a/b to move the cursor to

CH MEMORY, and press ENTER.

4 Use a/b or Channel Select to

select each desired channel to add or erase.

5 Press d to add the channel to the

TV memory or press c to erase the channel from the TV memory.

6 Press MENU to exit.

• If CH SEARCH is performed again, the previously memorized channels will be lost.

RETURN

EZ SETUP AI R/CABLE CH SEARCH CH

TO ADD: EXIT:

TO ERASE: EXIT:

CH–SETT I NG

MEM

ORY

CH MEMORY

AIR 2

Press

to add channel 2 to the TV memory

CH MEMORY

AIR 2

Press

to erase channel 2 from the TV memory

ADJUSTMENTS (Continued)

Adjusting BLUE SCREEN Settings

■ BLUE SCREEN

Automatically turns the screen blue if no broadcast signal is received.

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASHBACK

ENTER/ a/b/c/d

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

SET UP, and press ENTER.

3 Press a/b to move the cursor

to BLUE SCREEN, and press

ENTER.

4 Press c/d to select ON or OFF,

and press ENTER.

5 Press MENU to return to the main

screen.

ENU SLE EP T IMER V I DEO AD JUST PRES ET CLOSED CAPT I ON V–CH I P BLOCK SET UP

ENTER

SELE CT : EXIT:

RETURN BLUE SCRE EN [OFF ]

LANGUAGE

CH–SETT I NG CLOCK

SELE CT : EXIT:

RETURN BLUE SCREEN [ ON ]

LANGUAGE

CH–SETT I NG CLOCK

ENTER :

SET UP

ENTER :

SET UP

ENTER

ADJ UST :

ENTER :

EXIT:

ENTER

• When received signals are weak or interfered with by some other signals, the BLUE SCREEN function may be activated. To watch the TV under such conditions, set BLUE SCREEN to OFF.

• The BLUE SCREEN function is activated when AV1, AV2 or COMPONENT input mode is selected with no signal being input.

ADJUSTMENTS (Continued)

Adjusting CLOSED CAPTION Settings

■ SETTING CLOSED CAPTION

• This TV set is equipped with an internal Closed Caption decoder. “Closed Caption” is

a system which allows conversations, narration, and sound effects in TV programs and home videos to be viewed as captions on the TV screen (see the illustration).

• Not all programs and videos will offer closed captioning. Please look for the “ ” symbol to ensure that captions will be shown.

• The Closed Caption broadcasts can be viewed in two modes: CAPTION and TEXT. For each mode, two channels are available: CH1 and CH2. The CAPTION mode shows subscripts of dialogs and commentaries of TV dramas and news programs while allowing a clear view of the picture. The TEXT mode displays various information over the picture (such as TV program schedules and weather forecasts, etc.) that is independent of the TV programs.

Setting the CLOSED CAPTION on the MENU screen

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

BACK

CHVOL

ENTER/ a/b/c/d

MUTE

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor to

CLOSED CAPTION, and press

ENTER.

3 Press ENTER to change the

CLOSED CAPTION setting.

ENU SLE EP T IMER V I DEO AD JUST PRES ET CLOSED CAPT I ON V–CH I P BLOCK SET UP

SELE CT : ENTER: EXIT:

CLOSED CAPT I ON

RETURN

[OFF]

CC/TEXT

ENTER

ENTER :

ENTER

4 Press c/d to change the CLOSED

CAPTION setting, and press ENTER.

CC 1 CC 2OFF T1 T2

SELE CT : EXIT:

CLOSED CAPT I ON

RETURN

[CC1]

CC/TEXT

• CC1: CAPTION mode for CH1 data CC2: CAPTION mode for CH2 data T1: TEXT mode for CH1 data T2: TEXT mode for CH2 data

ADJ UST :

ENTER :

ENTER

EXIT:

5 Press MENU to return to the main

screen.

• If a broadcast contains Closed Caption data and MUTE is pressed, the set enters CAPTION mode automatically. Pressing MUTE again will return the set to its previous condition.

• Closed Caption may malfunction (white blocks, strange characters, etc.) if signal conditions are poor or if there are problems at the broadcast source. This does not necessarily indicate a problem with your set.

• If any button is pressed to call up the On-Screen Display while viewing a Closed Caption broadcast, the closed captions will disappear momentarily.

• If no TEXT broadcast is being received while viewing in the TEXT mode, the screen may become dark and blank for some programs. Should this occur, switch the CLOSED CAPTION mode to OFF.

ADJUSTMENTS (Continued)

Adjusting V-CHIP Settings

■ V-CHIP

• This function allows TV programs to be restricted and TV usage to be controlled based on FCC data. It prevents

children from watching violent or sexual scenes that may be harmful.

• Restriction of TV programs includes two ratings that contain information about the program: the MPAA rating and

the TV Parental Guidelines. The MPAA rating is restricted by age. TV Parental Guidelines are restricted by age and content.

• Since a TV program may use either the MPAA rating or the TV Guidelines, both should be adjusted for complete

control.

[1] MPAA RATING

RATING

G GENERAL AUDIENCES. All ages admitted.

PG PARENTAL GUIDANCE SUGGESTED. Some material may not be suitable for children.

PG-13 PARENTS STRONGLY CAUTIONED. Some material may be inappropriate for children under 13.

age

based

MPAA RATING

Example 1:

PG-13 in the age-based rating is blocked, this will also automatically block the higher ratings R, NC-17 and X.

R RESTRICTED. Under 17 requires accompanying parent or adult guardian.

NC-17 NO ONE 17 AND UNDER ADMITTED.

X X is an older rating that is unified with NC-17 but may be encoded in the data of older movies.:

Example 2:

R in the age-based rating is blocked, this will also automatically block the higher ratings NC-17 and X.

ote:

• The MPAA rating is only age-based.

ADJUSTMENTS (Continued)

Adjusting V-CHIP Settings (Continued)

[2] TV PARENTAL GUIDELINES

content based

⇐

RATING

TV-Y (All children)

TV-Y7 (Direct to Older Children) ✕

⇑

TV-G (General Audience) X

age

TV-PG (Parental Guidance

based

Suggested) xxx

⇓

TV-14 (Parents Strongly Cautioned) X

TV-MA (Mature Audience Only) X ✕✕ ✕

: The content rating can be set, but this rating is not normally broadcast by TV stations.

✕ : The content rating can be set.

TV PARENTAL GUIDELINES

Example 1:

When TV-Y7 in the age-based rating is set to BLOCK, this will automatically block the higher ratings: TV-G, TV-PG, TV-14 and TV-MA. In addition, D, L, S, V and FV in CONTENT are automatically blocked unless you manually set BLOCK CONTENT.

FV V S L D

(Fantasy (Violence) (Sexual (Adult (Sexually

Violence) Situation) Language) Suggestive

✕✕ ✕ ✕

⇒

Dialog)

Example 2:

When no item in the age-based rating is blocked, D in the content-based rating will be automatically blocked.

• Age-based ratings can be modified by the content-based ratings, but only in the combinations indicated by an X in

the table above.

• Choosing a lower age-based rating blocks the higher age-based ratings regardless of content rating settings.

• If you set TV-Y and TV-Y7 to BLOCK, CONTENT will display all items.

ADJUSTMENTS (Continued)

Adjusting V-CHIP Settings (Continued)

■ SETTING V-CHIP

[1] MPAA RATING

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASHBACK

ENTER/ a/b/c/d

Channel Select

1 Press MENU to display the MENU

screen.

2 Press a/b to move the cursor

to V-CHIP BLOCK, and press

ENTER.

3 INPUT SECRET NO. will be

displayed. Input the 4-digit secret number by using

Channel Select, and press ENTER.

• When you input the secret number for the first time, press ENTER to register. Otherwise, continue to step 4.

4 Press a/b to move the cursor to

MPAA, and press ENTER.

ENU SLE EP T IMER V I DEO AD JUST PRES ET CLOSED CAPT I ON V–CH I P BLOCK SET UP

INPUT SECRET NO.

– – – –

V–CH I P BLOCK

RETURN

PAA TV GUIDEL INES

STATUS

[OFF]

EXIT:

5 Press a/b to move the cursor

to PG, and press ENTER.

6 Press c/d to select BLOCK,

and press ENTER. If you set PG to BLOCK, PG-13, R, NC-17 and X are automatically blocked.

7 Press MENU to return to the

main screen.

• If you set G to BLOCK, all ratings are automatically blocked.

• If you set X to BLOCK, G, PG, PG-13, R and NC-17 are not blocked.

SELE CT : EXIT:

RETURN G [ –––––] PG [ ––––– ] PG– 13 [––––– ] R [ ––––– ] NC– 17 [ –––––] X [ –––––]

SELE CT :

RETURN G [ –––––] PG [ B L OC K ] PG– 13 [ BLOCK] R [BLOCK] NC– 17 [BLOCK] X [BLOCK]

ADJ UST :

ENTER :

PAA

ENTER :

PAA

ENTER :

ENTER

EXIT:

ADJUSTMENTS (Continued)

Parent Control (V-CHIP Operation Continued)

Adjusting V-CHIP Settings (Continued)

[2] TV GUIDELINES

● Setting TV GUIDELINES

1 Repeat steps 1 to 3 of [1] MPAA

RATING. (See page 39.)

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASH-

BACK

ENTER/ a/b/c/d

2 Press a/b to move the cursor to

TV GUIDELINES, and press

ENTER.

3 Press a/b to move the cursor to

TV-Y7, and press ENTER.

4 Press c/d to select BLOCK, and

press ENTER. If you set TV-Y7 to BLOCK, TV-G, TV-PG, TV-14 and TV-MA are automatically blocked. In addition, D, L, S, V and FV in CONTENT are automatically blocked.

5 Press MENU to return to the main

screen.

V–CH I P BLOCK RETURN M

PAA

TV GUIDEL INES

STATUS

[OFF]

SELE CT : EXIT:

RETURN

TV–Y [ –––––] TV–Y7 [–––––] TV–G [ –––––] TV–PG [ –––––] TV– 14 [ ––––– ] TV–

A [ ––––– ]

BLOCK CONT ENT

[ ]

SELE CT : EXIT:

RETURN

TV–Y [ –––––] TV–Y 7 [BLOCK ] TV–G [ BLOCK ] TV–PG [ BLOCK] TV– 14 [ BLOCK ] TV–

A [BLOCK ]

BLOCK CONT ENT

[ D L S V FV ]

ADJ UST :

ENTER

ENTER :

TV GU I DEL I NES

ENTER

ENTER :

TV GU I DEL I NES

ENTER

ENTER :

EXIT:

ADJUSTMENTS (Continued)

Adjusting V-CHIP Settings (Continued)

■ Setting BLOCK CONTENT

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASHBACK

ENTER/ a/b/c/d

1 Repeat steps 1 to 3 of [1] MPAA

RATING. (See page 39.)

2 Press a/b to move the cursor to

TV GUIDELINES, and press

ENTER.

3 Press a/b to move the cursor to

BLOCK CONTENT, and press

ENTER.

4 Press a/b to move the cursor to

the desired item, and press ENTER.

PAA

[OFF]

TV GU I DEL I NES

A [ ––––– ]

[ ]

BLOCK CONT ENT

V–CH I P BLOCK

ENTER

ENTER :

ENTER

ENTER :

ENTER

ENTER :

RETURN M TV GUIDEL INES

STATUS

SELE CT : EXIT:

RETURN TV–Y [ –––––] TV–Y7 [–––––] TV–G [ –––––] TV–PG [ –––––] TV– 14 [ ––––– ] TV–

BLOCK CONT ENT

SELE CT : EXIT:

RETURN D [ ––––– ] L [ ––––– ] S [ ––––– ] V [ ––––– ] FV [–––––]

SELE CT : EXIT:

5 Press c/d to select BLOCK or

----- (unblock), and press ENTER.

RETURN D [ –––––] L [BLOCK ] S [ ––––– ] V [ ––––– ] FV [–––––]

BLOCK CONT ENT

6 Press MENU to return to the

main screen.

ENTER

ADJ UST :

ENTER :

• If you set TV-14 to BLOCK, TV-MA is automatically blocked. Contents D, L, S and V are automatically blocked by X in the table on page 38.

EXIT:

ADJUSTMENTS (Continued)

Adjusting V-CHIP Settings (Continued)

[3] ACTIVATING V-CHIP BLOCK

● Setting STATUS

You can activate V-CHIP BLOCK after setting [1] MPAA RATING and/ or [2] TV GUIDELINES.

POW

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

CHVOL

FLASH-

BACK

ENTER/ a/b/c/d

1 Repeat steps 1 to 3 of [1] MPAA

RATING. (See page 39.)

2 Press a/b to move the cursor to

STATUS, and press ENTER.

SELE CT : EXIT:

3 Press c/d to set STATUS to ON,

and press ENTER.

V–CH I P BLOCK RETURN M

PAA

TV GUIDEL INES

STATUS

[OFF]

ENTER :

V–CH I P BLOCK RETURN M

PAA

TV GUIDEL INES

STATUS

[ ON ]

ENTER

• If STATUS is set to OFF, V-CHIP BLOCK will not be activated.

4 Press MENU to return to the main

screen.

ADJ UST :

ENTER

ENTER: EXIT:

ENTER :

[4] CANCELING THE V-CHIP BLOCK SCREEN WHILE V-CHIP BLOCK IS ACTIVATED

1 V-CHIP HAS BEEN ACTIVATED

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASH-

BACK

CHVOL

appears if you watch a program with the same Program Rating data you configured.

• V-CHIP HAS BEEN ACTIVATED will not be displayed if STATUS is not configured to ON.

V– CH I P HAS BEEN ACT I VATED

TV–Y

2 Press MENU to display INPUT

SECRET NO.

3 Input the 4-digit secret number by

Channel Select

• If you turn the power on from off, V-CHIP BLOCK will be activated again.

• If you select V-CHIP BLOCK again by using MENU, V-CHIP BLOCK will be turned on again.

using Channel Select; V-CHIP BLOCK is temporarily canceled. If you input an incorrect secret number, SECRET NO. IS INCORRECT is displayed. In this case, input the correct secret number.

INPUT SECRET NO.

– – – –

EXIT:

ADJUSTMENTS (Continued)

VOL

CH MENU

Adjusting V-CHIP Settings (Continued)

[5] CHANGING V-CHIP BLOCK SETTINGS

DISPLAY

SLEEP PIC. FLIP

ENTER

MUTE

BRIGHT TV/VIDEO MENU

FLASHBACK

CHVOL

1 Repeat steps 1 to 2 of [1] MPAA

RATING, then INPUT SECRET

NO. will be displayed.

2 Input the 4-digit secret number by

Channel Select

[6] CHANGING OR CLEARING THE SECRET NUMBER

If you forget the secret number, clear the secret number as follows.

Upper control panel of the main unit

using Channel Select; the V- CHIP select mode will be displayed. Set V-CHIP BLOCK again.

1 Repeat steps 1 to 2 of [1] MPAA

RATING, or 1 to 2 of [4] CANCELING THE V-CHIP BLOCK SCREEN WHILE V-CHIP BLOCK IS ACTIVATED, then

INPUT SECRET NO. will be displayed.

INPUT SECRET NO.

– – – –

INPUT SECRET NO.

* * * *

EXIT:

CH ( )

VOL (+)

2 Press and hold both CH ( ) and

VOL (+) on the TV set simultane-

ously until the message INPUT SECRET NO. blinks.

3 Press MENU to exit.

CONNECTING EXTERNAL DEVICES

You can enjoy picture and sound by connecting a VCR or a home video game system to the terminals located on the rear of the TV set. When connecting an external device, turn off the power of the main unit first to prevent any possible damage.

Example of external devices that can be connected

To AV-IN2 terminal

• VCR

• Laser disc player

To COMPONENT terminal

• DVD Player, etc. Playback from 480 progressive output for DVD and DTV is available.

To AV-IN1 terminal

• Camcorder

• Home video game system

* If your external device has an S-video

terminal, S-VIDEO connection is recommended.

* If your external device has a component

terminal, COMPONENT connection is recommended (you can view high-quality pictures).

• PC connection is not possible.

• For the cable, use a commercially available audio/video cable.

• Only connect audio/video signals to AV-IN1 and 2 terminals. Connecting other signals may result in a malfunction.

• AV-IN1 has 2 video input terminals: VIDEO and S-VIDEO. When you connect external devices to both terminals

(and if you select AV-IN1), you can only view pictures from the S-VIDEO terminal. To view the picture from the VIDEO terminal, do not connect any external device to the S-VIDEO terminal.

• For more information about external device connections, see the manuals of your external devices.

• If HDTV (720P/1080I) signals are input to the COMPONENT terminals, “NOT COMPATIBLE WITH THIS SIGNAL”

will appear and playback cannot be viewed.

CONNECTING EXTERNAL DEVICES (Continued)

Connecting a VCR, DVD player or a video camera (AV-IN1/2/COMPONENT)

VIDEO

AV-IN2/OUT

AUDIO

COMPONENT

AUDIO

To AV-IN2 terminal

Video

Audio (L)

To audio/video output terminal

To COMPONENT input (Video) terminal

Audio (R)

VCR

To COMPONENT output (Video) terminal

To COMPONENT input (Audio) terminal

Audio (L)

Audio (R)

To COMPONENT

VIDEO

AUDIO

S-VIDEO

AV-IN1

output (Audio) terminal

To AV-IN1 terminal

To audio/video output terminal

Video Audio (L)

Audio (R)

DVD Player

HEAD

PHONE

ANT.

E TH

E SU

TER.

(

PART NO. LOCATED ON

THE MODEL LABEL.

POWER

INPUT DC12V

To S-VIDEO input terminal

LIED

)

S-video

Camcorder

VCR

To S-video output terminal

• If your VCR (or other external devices) has an S-video terminal, S-VIDEO connection is recommended. (Use an S-video cable.)

• When you connect external devices to both S-VIDEO and VIDEO terminals (and if you select AV-IN1), you can only view pictures from the S-VIDEO terminal.

• You cannot view multiple or synthesized pictures by connecting two or more external devices. When connecting an external device, use care to connect the video and audio cables to the corresponding terminals.

CONNECTING EXTERNAL DEVICES (Continued)

Outputting video and audio (video output)

You can output video and audio signals from the TV set through the AV output terminals (AV-OUT).

• When using AV2 as an output terminal, select PRESET in the MENU and set AV2 IN/OUT to OUT. (See page 29.)

• The factory setting for AV2 IN/OUT is IN.

VIDEO

AV-IN2/OUT

AUDIO

COMPONENT

Connect to a VCR, audio amplifier, etc.

• AV2 IN/OUT has 2 OUT modes (see page 29).

• When using the S-video input for AV-IN1, or Y, PB and PR input for COMPONENT, no video output will be made to the AV output terminal, but audio output will be made for connection to external audio systems.

Bundling Cables with Clamps

• Secure cables and cords with the supplied cable clamps so that they do not get caught when mounting the covers.

Cable clamps (x2)

TROUBLESHOOTING

■ Before calling for repair services, make the following checks for possible remedies to the encountered symptoms.

TV set

Sound

Problem Check item

• Make sure the AC adapter is properly inserted in the


There is no picture or sound.

There is no picture. There is no picture from AV-IN1/2.

There is no sound.

There is no picture or sound, just noise.

Picture is not clear.

power outlet.

• Reception other than those of broadcasting stations can be considered.

• Make sure the input mode is set to TV.

• Make sure the MAIN POWER switch of the main unit

is on.

• Make sure the BLACK LEVEL is properly adjusted.

• Fluorescent lamp may have reached the end of

service life.

• Make sure the S-VIDEO terminal has nothing connected.

• Make sure the volume is not set to minimum.

• Make sure the sound is not set to mute.

• Make sure that headphones are not connected.

• Make sure the antenna cable is properly connected.

• Bad reception could be the problem.

• Make sure the antenna cable is properly connected.

• Bad reception could be the problem.

Reference

Pages

–

22 21

31, 32

23 23 13

–

Picture is light or improperly tinted.

The picture is too dark.

Remote control does not work.

The clock (AUTO CLOCK) cannot be set.

• Check color adjustment.

• Check COLOR SYSTEM setting.

• Press the BRIGHT button or set the BRIGHTNESS

settings.

• Check PICTURE and BLACK LEVEL adjustment.

• Fluorescent lamp may have reached the end of

service life.

• Check the batteries of the remote control.

• Make sure the remote sensor window is not under

strong lighting.

• The broadcasted EDS signal may be weak. Check the antenna.

• Carry out EZ SETUP, SETTING THE CLOCK again.

• If EDS signal is not sent, set the clock using MANUAL

CLOCK Setting.

31, 32 31, 32

31, 32

8 8

–

17–19, 33

TROUBLESHOOTING (Continued)

Antenna

Problem Check item

• The reception may be weak.

• The quality of the broadcast may also be bad.

The picture is not sharp.

The picture moves.

The picture is doubled or tripled.

The picture is spotted.

• Make sure the antenna is facing the right direction.

• Make sure the outside antenna is connected.

• Make sure the antenna is facing the right direction.

• There may be reflected electric waves from mountains or

buildings.

• There may be interference from automobiles, trains, high voltage lines, neon lights, etc.

• There may be interference between the antenna cable and AC cord. Try positioning them further apart.

• Is the unit receiving interference from other devices?

There are stripes on the screen or colors fade.

Transmission antennas of radio broadcasting stations, transmission antennas of amateur radios and cellular phones may also cause interference.

• Use the unit as far apart as possible from devices that may cause possible interference.

■ Cautions regarding use in high and low temperature environments

• When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns normal.

• Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near a heater, as this may cause the cabinet to deform and the LCD panel to malfunction. Storage temperature: –4°F to +140°F (–20°C to +60°C)

SPECIFICATIONS

Items

LCD panel 15” Advanced Super View & BLACK TFT LCD Number of dots 921,600 dots VGA Video color systems N358, N443, PAL, PAL-M, PAL-N, SECAM, PAL-60

Destination USA/Latin America/Taiwan TV Standard (CCIR) NTSC/PAL-M/PAL-N

TV function TV Tuning System PLL 181 ch.

STEREO MTS+SAP

CATV 125 ch. Y/C FILTER 4-LINE COMB FILTER Brightness 430 cd/m Lamp life (Fluorescent lamp) 60,000 hours Viewing angles H: 170° V: 170° Audio amplifier 2.1 W × 2 Speakers 137/64 × 23/4 in. (4 × 7 cm), 2 pcs.

AV-IN1 AV-IN1, S-VIDEO-IN

AV-IN2 AV-IN2/AV-OUT Terminals COMPONENT COMPONENT-IN, AUDIO-IN

Antenna F-Type

Headphone Mini-jack for stereo (ø3.5 mm) OSD language English/French/Spanish Power supply DC 12V, AC 110-240V, 50/60Hz Weight 11.5 lbs. (5.2 kg), w/o accessories Accessories Remote control, Battery (x2), Antenna cable, AC adapter,

Model

LC-15B4U

AC cord, Cable clamp (x2), Operation manual

As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

DIMENSIONAL DRAWINGS

Unit: inch (mm)

231/

(63.2)

(381.7)

(149.5)6

(153.5)

(78.7)

(303)

(58)

/ 2

(63.2)

MAIN POWER

TV/VIDEO

1211/

(322.2)

193/

(484)

(231)

125/

(307)

(1)

315/

(100)

(38.2)

VIDEO

AV-IN 2/OUT

AUDIO

(366.2)

(198)

(1)

COMPONENT

AUDIO

(100)

S-VIDEO

USE THE SUPPLIED AC ADAPTER. (

PART NO. LOCATED ON THE MODEL LABEL.

VIDEO

AV-IN1

AUDIO

HEAD PHONE

ANT.

)

POWER INPUT DC12V

CALLING FOR SERVICE

For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or customer assistance, please call 1-800-BE-SHARP.

LIMITED WARRANTY

CONSUMER LIMITED WARRANTY

SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.

This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction.

In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer.

The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.

The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Model Specific Section

Your Product Model Number & Description:

Warranty Period for this Product:

Additional Item(s) Excluded from Warranty Coverage (if any):

Where to Obtain Service:

What to do to Obtain Service:

TO OBTAIN PRODUCT INFORMATION, CALL 1-888-LCD-SHARP OR VISIT www.sharpusa.com

LC-15B4U LCD Color Television (Be sure to have this information available when you need service for your Product.)

One (1) year parts and labor from the date of purchase.

Non-rechargeable batteries.

From a Sharp Authorized Servicer located in the United States. To find the location of the nearest Sharp Authorized Servicer, call Sharp toll free at 1-800-BE-SHARP.

Ship prepaid or carry in your Product to a Sharp Authorized Servicer. Be sure to have Proof of Purchase available. If you ship the Product, be sure it is insured and packaged securely.

SHARP ELECTRONICS CORPORATION

Sharp Plaza, Mahwah, New Jersey 07430-2135

SHARP CORPORATION

VALID IN CANADA ONLY

LIMITED WARRANTY

Consumer Electronics Products

Congratulations on your purchase!

Sharp Electronics of Canada Ltd. (hereinafter called “Sharp”) gives the following express warranty to the first consumer purchaser for this Sharp brand product, when shipped in its original container and sold or distributed in Canada by Sharp or by an Authorized Sharp Dealer:

Sharp warrants that this product is free, under normal use and maintenance, from any defects in material and workmanship. If any such defects should be found in this product within the applicable warranty period, Sharp shall, at its option, repair or replace the product as specified herein.

This warranty shall not apply to: (a) Any defects caused or repairs required as a result of abusive operation, negligence, accident, improper installation or inappropriate

use as outlined in the owner’s manual.

(b) Any Sharp product tampered with, modified, adjusted or repaired by any party other than Sharp, Sharp’s Authorized Service Centres

or Sharp’s Authorized Servicing Dealers.

(c) Damage caused or repairs required as a result of the use with items not specified or approved by Sharp, including but not limited to

head cleaning tapes and chemical cleaning agents.

(d) Any replacement of accessories, glassware, consumable or peripheral items required through normal use of the product including but

not limited to earphones, remote controls, AC adapters, batteries, temperature probe, stylus, trays, filters, belts, ribbons, cables and

paper. (e) Any cosmetic damage to the surface or exterior that has been defaced or caused by normal wear and tear. (f) Any damage caused by external or environmental conditions, including but not limited to transmission line/power line voltage or liquid

spillage. (g) Any product received without appropriate model, serial number and CSA/cUL markings. (h) Any products used for rental or commercial purposes. (i) Any installation, setup and/or programming charges.

Should this Sharp product fail to operate during the warranty period, warranty service may be obtained upon delivery of the Sharp product together with proof of purchase and a copy of this LIMITED WARRANTY statement to an Authorized Sharp Service Centre or an Authorized Sharp Servicing Dealer. In home warranty service may be provided at Sharp’s discretion on any Sharp television with the screen size of 27” or larger and on any Sharp Over-the-Range Microwave Oven.

This warranty constitutes the entire express warranty granted by Sharp and no other dealer, service centre or their agent or employee is authorized to extend, enlarge or transfer this warranty on behalf of Sharp. To the extent the law permits, Sharp disclaims any and all liability for direct or indirect damages or losses or for any incidental, special or consequential damages or loss of profits resulting from a defect in material or workmanship relating to the product, including damages for the loss of time or use of this Sharp product or the loss of information. The purchaser will be responsible for any removal, reinstallation, transportation and insurance costs incurred. Correction of defects, in the manner and period of time described herein, constitute complete fulfillment of all obligations and responsibilities of Sharp to the purchaser with respect to the product and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise.

WARRANTY PERIODS: Parts & Labour (exceptions noted)

Audio Products 1 year Camcorder 1 year DVD Products 1 year Projector 1 year (lamp 90 days) LCD & Plasma Display TV 1 year Microwave Oven 1 years (magnetron component-4 additional years) Television Products 1 year (picture tube component-1 additional year) VCR Product 1 year Vacuum Cleaner 1 year

To obtain the name and address of the nearest Authorized Sharp Service Centre or Dealer, please contact:

SHARP ELECTRONICS OF CANADA LTD. 335 Britannia Road East, Mississauga, Ontario L4Z 1W9

For more information on this Warranty, Sharp Extended Warranty

Offers, Sharp Canada Products, Accessory Sales, Dealer or Service

Locations, please call (905) 568-7140

Visit our Web site: www.sharp.ca

Sharp LC-15B4U User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
