Sharp LC-13B2M Schematic

SERVICE MANUAL LCD COLOUR TELEVISION MODELS LC-13B2H/M

LC-13B2H/M

SERVICE MANUAL

S91B2LC-13B2H

LCD COLOUR TELEVISION

LC-13B2H

MODELS

In the interests of user-safety (Required by safety regula­tions in some countries) the set should be restored to its
original condition and only parts identical to those specified
be used.

LC-13B2M

CONTENTS

Page

» IMPORTANT SERVICE SAFETY PRECAUTION................................................................................. 2

» SPECIFICATIONS ................................................................................................................................ 3

» OPERATION MANUAL ......................................................................................................................... 4

» DIMENSIONS ....................................................................................................................................... 6

» REMOVING OF MAJOR PARTS .......................................................................................................... 7

» ADJUSTING PROCEDURE OF EACH SECTION ............................................................................. 10

» TROUBLE SHOOTING TABLE ........................................................................................................... 14

» CHASSIS LAYOUT ............................................................................................................................. 18

» BLOCK DIAGRAM.............................................................................................................................. 20

» DESCRIPTION OF SCHEMATIC DIAGRAM ..................................................................................... 22

» SCHEMATIC DIAGRAMS................................................................................................................... 23

» PRINTED WIRING BOARD ASSEMBLIES........................................................................................ 38

» PARTS LIST

Ë

ELECTRICAL PARTS..................................................................................................................... 45

MAIN UNIT ..................................................................................................................................... 45

TERMINAL UNIT............................................................................................................................ 47

OPERATION UNIT ......................................................................................................................... 50

JACK UNIT...................................................................................................................... ............... 51

R/C RECEIVER UNIT .................................................................................................................... 51

Ë

SUPPLIED ACCESSORIES PARTS .............................................................................................. 51

Ë

PACKING PA RTS ........................................................................................................................... 51

Ë

CABINET PARTS LIST................................................................................................................... 52

Ë

CABINET AND MECHANICAL PARTS.......................................................................................... 53

» PACKING OF THE SET ...................................................................................................................... 55

SHARP CORPORATION

1

LC-13B2H/M

2

2

2

Ë

Service work should be perfomed only b y qualified service technicians who are thoroughl y
familiar with all safety checks and the servicing guidelines which follow:

IMPORTANT SERVICE SAFETY PRECAUTION

WARNING

1. For continued safety, no modification of any circuit
should be attempted.

2. Disconnect AC power before ser vicing.

CAUTION: FOR CONTINUED
PROTECTION A GAINST A RISK OF
FIRE REPLACE ONLY WITH SAME
TYPE FUSE. F3701 (1.6A, 250V),
F3703 (2A, 250V) FUSE.

BEFORE RETURNING THE RECEIVER
(Fire & Shock Hazard)

Before returning the receiver to the user, perform
the following safety checks:

1. Inspect all lead dress to make certain that leads are
not pinched, and check that hardware is not lodged
between the chassis and other metal parts in the
receiver.

2. Inspect all protective devices such as non-metallic
control knobs, insulation materials, cabinet backs,
adjustment and compartment covers or shields,
isolation resistor-capacitor networks, mechanical
insulators and etc.

3. To be sure that no shock hazard exists, check for
leakage current in the following manner.

• Plug the AC cord directly into a 110~240 volt A C outlet,
and connect the DC power cable into the receiver's
DC jack. (Do not use an isolation transformer for this
test).

• Using two clip leads, connect a 50k ohm, 10 watt resistor
paralleled by a 0.15µF capacitor in series with all
exposed metal cabinet parts and a known earth ground,
such as electrical conduit or electrical ground connected
to an earth ground.

• Use an AC voltmeter ha ving with 5000 ohm per volt, or
higher, sensitivity or measure the AC voltage drop
across the resisor.

• Connect the resistor connection to all exposed metal
parts having a return to the chassis (antenna, metal
cabinet, screw heads, knobs and control shafts,
escutcheon and etc.) and measure the AC voltage drop
across the resistor.
All checks must be repeated with the AC cord plug
connection reversed. (If necessary, a nonpolarized
adaptor plug must be used only for the purpose of
completing these checks.)
Any reading of 0.75V peak (this corresponds to 0.5
milliamp. peak A C .) or more is e xcessive and indicates
a potential shock hazard which must be corrected
before returning the monitor to the owner .

DVM

AC SCALE

50k ohm

10W

0.15 µF

TEST PROBE

TO EXPOSED
METAL PARTS

CONNECT TO
KNOWN EARTH
GROUND

234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121

234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121

SAFETY NOTICE

Many electrical and mechanical parts in LCD television
have special safety-related characteristics.
These characteristics are often not evident from visual
inspection, nor can protection afforded by them be
necessarily increased by using replacement components
rated for higher voltage, wattage and etc.
Replacement parts which have these special safety
characteristics are identified in this manual; electrical

and shaded areas in the

Schematic Diagrams

For continued protection, replacement parts must be
identical to those used in the original circuit.
The use of a substitute replacement parts which do not
have the same safety characteristics as the factory
recommended replacement parts shown in this service
manual, may create shock, fire or other hazards.

components having such features are identified by “ å”

234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121

2

Replacement Parts Lists

.

and

Specifications

Items ......................................................... 13" LCD COLOUR TV, Model: LC-13B2H/M

LCD panel..................................................................................................13" TFT LCD

Number of dots ..................................................................................921,600 dots VGA

Video colour systems....................................................................... World multi system

TV FUNCTION

TV Standard (CCIR) .................................................................................I/DK/M/BG

TV Turning System ..................................................................... Auto preset turning

STEREO/BILINGUAL ...................................................... NICAM-BG, I, DK/IGR-BG

Universal R/C for TV only .................................................................................... Yes

AUTO PRESET.................................................................................................... Yes

CATV.....................................................................................................~Hyper Band

4-LINE DIGITAL COMB FILTER ............................................................................... Yes

Brightness.......................................................................................................430 cd/m

Lamp life ....................................................................................................60,000 hours

Viewing angles........................................................................................H: 160° V: 160°

Audio output..................................................................................................... 2.1W × 2

Speakers....................................................................................... 4 x 7 cm Oval, 2 pcs.

Terminals

AV1 .......................................................................Composite Video, S-Video, Audio

AV2 IN/OUT ......................................................................... Composite Video/Audio

Component ........................................................................................Y, PB, PR/Audio

Headphone Jack........................................................................... 3.5 mm φ jack (Rear)

OSD LANGUAGE ..................................................................... English/Chinese/Arabic

Power requirement................................................... DC 12V, AC 110 - 240 V, 50/60 Hz

Weight........................................................................................ 3.9 kg w/o accessories

Accessories ......................................................... R/C, Batteries, AC adaptor, AC cord,

Operation manual, Cable clamps,
Antenna cable

LC-13B2H/M

2

Specifications are subject to change without prior notice.

3

LC-13B2H/M

LOCATION OF USERS CONTROL

Main unit (front view)

Speaker

SLEEP indicator

The SLEEP indicator lights up red when

the SLEEP TIMER is set to on.

Speaker

Upper control panel

Remote sensor window

(The actual location is not visible.)

To change the vertical

angle of the LCD TV set,

tilt the screen up to 10

degrees forward or 20

degrees backward. The

TV set can also be

rotated 90 degrees

horizontally. Please adjust

the angle so that the TV

set can be watched most

comfortably.

POWER/STANDBY indicator

A green indicator lights when the power is

on and a red indicator lights when in the

standby mode (the indicator will not light

when the main power is off).

VOL CH MENU TV/VIDEO MAIN POWER

1

2

PRESET

■

TV/VIDEO, CH (

)/( ), and VOL (+)/(–) on the main unit have the same functions as the same buttons on the

remote control. Fundamentally, this operation manual provides a description based on operation with the remote

control.

Note:

VOL (+)/(–)

CH (

)/(

)

MENU

TV/VIDEO

MAIN POWER

Auto Preset Details are

described.

Main unit (rear view)

ANT.

VIDEO

AUDIO

L

Y

P

B

P

R

R

AUDIO

HEAD

PHONE

POWER

INPUT

DC12V

L

R

AV-IN 2/OUT

COMPONENT

VIDEO

S-VIDEO

AUDIO

L

R

AV-IN 1

Antenna terminal

AUDIO (L)

AUDIO (R)

HEADPHONE

POWER INPUT

(DC 12V)

AUDIO (L)

AUDIO (R)

VIDEO

Y

P

RPB

AV-IN 2/OUT

COMPONENT

AUDIO (L)

AUDIO (R)

VIDEO

S-VIDEO

AV-IN 1

Operation Manual

4

LC-13B2H/M

Remote control

CH

VOL

TV/VIDEO

DISPLAY

BRIGHTSLEEP

MENU

POWER

MPX

-/--

MENUSLEEP

MENU cursor

(Right/Left Selection)

VOL (+)/(–)

POWER

TV/VIDEO

MENU cursor

(Upward/Downward Selection)

CHANNEL SELECT

CH ( )/( )

Selects next higher channel

Selects next lower channel

FLASHBACK

Returns to previous channel

DISPLAY

Press....Displays receiving channel for 10 seconds.

Channel indication reduces in size after

about 10 seconds.

Press again...Removes display.

MUTE

Press....Stops sound.

Press again...

Returns sound to previous level.

MPX

Switching Audio mode.

BRIGHT

The brightness can be

switched between 3 levels.

5

LC-13B2H/M

POWER

SLEEP

429

267

264.96

333

264

69

198.72

200.8

Dimensions

55

51

VOL CH MENU

TV/VIDEO

MAIN POWER

PRESET

59.3

271.2

AV-IN 1

92.7

55

148.5 40.5

18 9

177.8

0.5

74.4

229.4102.9

332.3

ANT.

100

VIDEO

AUDIO

S-VIDEO

L

15 15

R

8.4

16

AV-IN 2/OUT

VIDEO

L

AUDIO

R

COMPONENT

Y

PB

P

R

L

AUDIO

R

HEAD

PHONE
POWER

INPUT

DC12V

43

1414

35.4

14141414141314

100

33

(Unit: mm)

6

REMOVING OF MAJOR PARTS

1. Remove the back cover.

2. Remove the table stand fixing screws (4 pcs.).

3. Remove the cabinet B fixing screws (9 pcs.) and detach the cabinet.

4. Release the wire holders at 2 locations and peel off the tape.

5. Detach the connector from each PWB.

LC-13B2H/M

Back cover

2

3

3

Cabinet B

3

1

3

3

Table stand

5

R/C Receiver PWB

Tape

4

P4004

P4004

Terminal PWB

P3501

5

P4005

5

5

P3600

5

P3500

Operation PWB

P3702

5

5

SC2001SC3403

5

7

P2003

P3402

Main PWB

5

P2004

5

Jack PWB

SC5701

5

5

SC1201

P5701

SC1202

5

5

Wire holder

4

LC-13B2H/M

6. Remove the terminal PWB fixing screws (2 pcs.).

7. Remove the jack PWB fixing screw (1 pcs.).

8. Remove the main PWB fixing screws (2 pcs.).

9. Remove the R/C receiver PWB fixing screws (2 pcs.).

10. Remove the operation PWB fixing screws (2pcs.).

11. Remove the PWB frame fixing screws (4 pcs.)

7

6

Terminal PWB

PWB Frame

Jack PWB

8

Main PWB

11

Operation PWB

9

10

R/C Receiver PWB

8

» Precautions in handling the LCD panels

1. Work in a clean room (with humidities below 50%).

2. Be sure to wear an anti-static armband.

3. Handle the panels on an electroconductive mat.

4. Be careful not to fall, shake and shock the panels.

12. Remove the LCD display unit fixing screws (4 pcs.).

13. Detach the two diffusion sheets and reflection/deflection sheet.

14. Detach the four reflection mirrors.

15. Remove the fluorescent lamp.

16. Detach the light guide plate.

17. Detach the two lamp reflection sheets.

14

LC-13B2H/M

Reflection Mirror

12

LCD Display Unit

Fluorescent Lamp
（KLMP-0109CEZZ）

15

12

Light Guide Plate

16

13

Diffusion Sheet

Reflection/deflection Sheet

14

Lamp Reflection Sheet-1

17

（PSHEP0246CEZZ）

Lamp Reflection Sheet-2
（PSHEP0247CEZZ）

Sheilding Plate

Reflection Mirror

9

LC-13B2H/M

ADJUSTING PROCEDURE OF EACH SECTION

Preparation for Adjustments

Use the dedicated AC adaptor or stable DC power supply.
LC13B2 AC adaptor: UADP-0226CEPZ
DC power supply: 12 ± 0.5V, 3.0 (A)

[1] Adjusting procedure

1-1. Checker adjustment

Po wer ON (initialization) → Setting of model and inch siz e → Model data tr ansf er to the setting E2PROM (I2C) →
Adjustment processing mode → Adjustment (+B adjustment)

1-2. Finish processing adjustment

Setup → Power ON → Adjustment processing mode (Remote control) → Opposed bias, TV contrast and white
balance adjustments

[2] Entering the adjustment processing mode

There are the following two methods.

• Setting the 81 pin (KEY4) or 82 pin (KEY5) of IC2001 (microcomputer) to “L”, turn on the power.

• When service is given: A power source SW is made on with pushing an TV/VIDEO key and a MENU key at the
same time.(K of the inspection process mode is displayed by the upper left of the image plane.) → Next, a tuning
DOWN key and a sound volume DOWN key are pushed at the same time.(It becomes the image plane of the

adjustment process mode.).....When it is canceled, it is made to turn it off.(Even off in the po wer source SW, off with

R/C are good.)

[3] Key operation in the adjustment processing

Selection of the receiving channel

• The receiving channel UP/DOWN is performed with the tuning UP/DOWN key.
One push ... The UP/DOWN tuning is performed per channel.
Continuous push ... The UP/DOWN search is performed until a next receivable station is found.

• V arious adjustments
The adjustment is performed for each item by the menu select, tuning UP/DOWN or volume UP/DOWN key (main
body and remote control).

• Adjustment item is chosen with the cursor UP/DOWN key.

• The adjustment item makes a toggle operation with the menu select key input. (Next item)
If the menu select key is input while the bottom item is selected, it moves to the top item on the next page.

[4] Initialization

4-1. Connect the 81 pin and 82 pin of IC2001 (microcomputer) to GND, and turn on the power.
4-2. Select the model name (B2H).
4-3. Select the inch size (13).

10

[5] Adjustment

5-1. +B adjustment...R3760 and a half fixations VOL

1) Receive the colour bar.

2) Adjust the voltage of the 38 pin of SC3403 to 5.00V±0.02V.
Note: Since 5.0V is a reference voltage of all power voltage, adjust it precisely.

5-2. Counter-bias adjustment...Page 2 COM BIAS

Vary the "COM BIAS" setting on Page 2 of the adjustment process so that the contrast be sharpest (black looks
most sinking). The adjustment guideline is around 57 for Model LC-13B2H/M.

5-3. TAMP adjustment

1) Receive the colour bar.

2) When reading value of adjustment process the page 2 "Y" is not within value of the bottom table, the
adjustment of "NTSC TAMP" of the same page is done, and reading value of "Y" is made to be within value of
the bottom table.

Model LC13B2 LC15B2 LC20B2
Setting value B8~C2 B8~C2 BB~CA

3) If the adjustment of “NTSC TAMP” is executed, write its adjustment value to the followings manually.

“PAL TAMP”
“SECAM TAMP”
“PAL-M TAMP”
“PAL-N TAMP”

LC-13B2H/M

(Screen of the page 2 of the adjustment processing menu OSD)

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

0
1
2
3
4
5
6

7
8

9

10
11

12
13

2

COM B I AS 5 7
NTSC TAMP 24

PAL TAMP 24
SECAM TAMP 24

PAL - M TAMP 24
PAL - N TAMP 24
RCU TOF F

GCUTOF F

BCU TOF
G3 B3 R3 00 00 00
G1 B4 Y 0 0 00 BE

TAMP H

TAMP L

F

Y Data

(White 75%)

–

5
0

–3

C2
B8

5-4. White balance adjustment

1) Receive the monoscope pattern.

2) Adjust “RCUTOFF” and “BCUTOFF” on the page 2 of the adjustment processing so as to obtain the colour of
the same level as the standard set.
Caution: For the adjustment processing of “RCUTOFF” and “BCUTOFF”, adjust them in the indication value
range of ... –9, –7, ... –1, +1, ... +7, +9.
When it becomes even-numbered value, side favor noise sometimes occurs in the monochrome signal of the
specific gradation.

11

LC-13B2H/M

[6] Lamp error detection

6-1. Functional description

This LCD color television has a function (lamp error detection) to be turned OFF automatically for safety when
the lamp or lamp circuit is abnormal.
If the lamp or lamp circuit is abnormal, or some other errors happen, and the lamp error detection is
executed, the followings occur.
1 The main unit of television is turned OFF 5 seconds after it is turned ON. (The po w er LED on the front side of

TV turns from green to red.)

2 If the situation 1 happens 5 times sequentially, television can not be turned ON. (The power LED remains

red.)

6-2. Countermeasures
6-2-1. Check when tur ning OFF the lamp error detection

When television is turned OFF by the lamp error detection mentioned above, it enters the adjustment
process with the power LED red. Entering the adjustment process turns OFF the error detection and turns
ON TV.
This enables the operation check to detect errors in the lamp or lamp circuit.
Check whether "ERROR NO RESET" on line 9, page 1 of the adjustment process is 1 or more. If it is 1 or
more, it indicates the lamp error detection was executed.

6-2-2. Resetting of the lamp error count

After confirming that the lamp or lamp circuit is normal, reset the lamp error count. Select "ERROR NO
RESET" on line 9, page 1 of the adjustment process and set the number to 0 using the volume button.

Page 1 of the adjustment process

1

+ B – A D J 160
M O D E L B2H
I NCH S I ZE 13
N T S C P W M F R E Q 0C0
P A L P W M F R E Q 0BD
N T S C P W M D U T Y 0
PAL P W M DUTY 0

T V G A I N OFF

ERROR NO RESET 5
P U B L I C M O D E ON

B 2 H V E R 1 . 0 0

Afterwards, perform the operation check to confirm that the lamp error detection does not function.

Reset 0

12

[7] PUBLIC MODE

• How to enter into PUBLIC MODE

1.Turn off TV by pressing MAIN POWER switch.

2.While pressing at same time VOL(+) key and CH(ù) key, press MAIN POWER switch.
For more than 2 seconds.
TV will turn on, and you will see the screen display a setting of PUBLIC MODE.

• Setting screen of "PUBLIC MODE"

PUBLIC MODE
MAXIMUM VOLUME [ 60]
VOLUME FIXED [VARIABLE]
REMOTE CONTROL [RESPOND]
USER CONTROL [RESPOND]
ON SCREEN DISPLAY [YES ]
AV1 INPUT [NORMAL ]
RESET
ENTER

1 ↔ 2 ··· ↔ 59 ↔ 60
VARIABLE ↔ FIXED
RESPOND ↔ LIMITED
RESPOND ↔ NO RESPOND
YES ↔ NO
NORMAL ↔ START ↔ AV1 FIXED

LC-13B2H/M

Factory setting

Adjust setting

1. You can select each item of functions by pressing cursor UP/DOWN keys on the remote control or CHù/Ù
keys on the LCD TV. The letter of selected item tur ns to yellow colour when you selected it.

2.The setting position of each item of functions are made by pressing cursor RIGHT/LEFT keys on the remote
control or VOL(+)(–) keys on the LCD TV.

3.Select ENTER position after you set all functions, and press cursor RIGHT/LEFT keys on the remote control
or VOL(+)(–) keys on the LCD TV for confirmation.
Unless otherwise you make ENTER confirmation, the settings will not be memorized.

6-functions of Public Mode settings expand for public application.

1. MAXIMUM VOLUME(1--------60)
You can set the maximum volume at your desire level.

2. VOLUME FIXED (VARIABLE/FIXED)
You can fix the sound volume at your desire level.
When you set to "FIXED", the sound volume which you just set is fixed.

3. REMOTE CONTROL (RESPOND/LIMITED)
If you set "LIMITED", remote control keys of POWER, CHù/Ù, VOL(–)(+) and BRIGHT keys are responded, but
other keys are not responded.
This is a position that you can not make MENU adjustments.

4. USER CONTROL (RESPOND/NO RESPOND)
"NO RESPOND" means that the TV does not respond when you press a user control buttons except main power
button on the main unit.

5. ON SCREEN DISPLAY (YES/NO)
If you set "NO" position, OSD will not appear.

6. AV1 INPUT (NORMAL/START/AV1 FIXED)
Some application use DVD or VCR connecting to AV1 input of our monitor and you will not want to change it to
other mode, such as Component or AV2 input.
You can set the position of input "AV1 FIXED".
For other application that you want to start AV1 every time when you press power b utton, and y ou ma y select other
input mode after then, set it at "START" position.

7. RESET
You can cancel all Public Mode settings. (It returns to the factory setting.)

8. ENTER
You make sure after you have specified all functions, then press the enter key. Unless otherwise you press the
enter key, all positions that you have selected will not be set.

13

LC-13B2H/M

No picture

at all

Yes

No

Are inputs

and outputs

of IC801 as

specified?

Check all the settings on the microprocessor’s adjust process menu.

No picture

Check IC801

and its

peripheral

parts.

Yes

No

Are inputs

and outputs

of IC1201 as

specified?

Check

IC1201 and

its peripheral

parts.

Check LCD

panel voltage

and

waveform.

No TV and

VIDEO 1

output

Yes

No

Are inputs

and outputs

of IC402 as

specified?

Check IC402

and its

peripheral

parts.

No

Is input at Pin

(73) of IC801

as specified?

Check IC801,

AV1 line and

their

peripheral

parts.

No TV

output

Yes

No

Are voltages

at Pins (6),

(7) and (9) of

tuner as

specified?

Check the

power line.

Yes

No

Is output at

Pin (19) of

tuner as

specified?

Check the

tuner and its

peripheral

parts.

No

Is input at Pin

(3) of IC402

as specified?

Check the

line in

question.

Yes

Check IC402

and its

peripheral

parts.

Yes

No

Are Pins (2)

and (4) of

IC402 at “H”

and “L”

respectively?

Are Pins (65)

and (66) of

IC2001 at “H”

and “L”

respectively?

No VIDEO

1 or 2

output

Yes

No

Is input at Pin

(1) of IC402

as specified?

Check the

line in

question.

Yes

No

Are Pins (2)

and (4) of

IC402 both at

“L” or Pins (4)

of IC402 at

“H”?

No S

VIDEO

output

No

Are inputs at

Pins (71) and

(72) of IC801

as specified?

Check

SC5001, SY

line, SC line

and

peripheral

parts.

No

COMPONENT

output

No

Is input at

Pins (4), (5),

(6) and (75)

of IC801 as

specified?

Check J3404,

J3405, J3406,

DVD-Y line,

PB line, PR

line and

peripheral

parts.

Are Pins (65)

and (66) of

IC2001 both

at “L”or Pins

(66) of IC1201

at “H”?

Check IC402

and its

peripheral

parts.

Yes

Check the

line in

question.

Yes

Check the

line in

question.

TROUBLE SHOOTING TABLE

14

TROUBLE SHOOTING TABLE (Continued)

No picture and sound

No colour

No TV colour

No S-VIDEO colour

Yes

No

Do F3701 and F3703

function?

Check all the settings on the microprocessor’s adjust process menu.

No

Are secondary outputs

(+34V, +15V, +10V, +5V, -9V)

of T3701 as specified?

Yes

Are the oscillation waveform

at T3701’s primary side as

specified?

Yes

No

Disconnect F3701 and

F3703. Is the load side

short-circuited?

Yes

No

Is any of T3701’s primary

side, Q3700 and S4701 short-

circuited?

Check J3702, its peripheral

parts and connection cable.

Replace F3701 and F3703.

Check S4701 and

connection cable.

Check the secondary-side

load of T3701.

Fluorescent lamp

Yes

No

Does F3703 function?

Yes

No

Is Pin (34) of IC1201 at “H”?

Yes

No

Are the oscillation waveforms

at the primary side of T5701

and T5702 as specified?

Yes

Replace F3703.

No

Is input at Pin (71) of IC801

as specified?

Check SC5001, SC line and

peripheral parts.

Yes

Check the line, IC1201 and

its peripheral parts.

Check Q5701, Q5702,

T5701, T5702, Q5703 and

their peripheral parts.

Replace the fluorescent lamp

and check the oscillation

waveform again.

No VIDEO colour

Check all the settings on the microprocessor’s adjust process menu.

No COMPONENT colour

No

Is input at Pins (4) and (6) of

IC801 as specified?

Check J3405, J3406, PB line,

PR line and peripheral parts.

LC-13B2H/M

15

LC-13B2H/M

No sound

from

speakers

Yes

No

Is Pin (53) of

IC2001 at “L”?

Check all the settings on the microprocessor’s adjust process menu.

No sound

No

Are outputs at

Pins (1) and (7)

of IC3301 as

specified?

Yes

No

Are inputs at

Pins (2) and (4)

as well as

outputs at Pins

(8) and (12), all

of IC3305, as

specified?

Muting effect is

on. Check the

FSMUTE line.

Check IC3301,

IC3302, IC3303

and their

peripheral parts.

Check the line

in question,

IC3305 and its

peripheral

parts.

Yes

Check the

speakers and

their peripheral

parts.

No sound

from

headphone

Yes

No

Is Pin (55) of

IC2001 at “L”?

Check the

headphone and

its peripheral

parts.

Check Q2050,

J3500 and their

peripheral

parts.

No sound

from output

line

Yes

No

Is Pin (58) of

IC2001 at “L”?

No

Are outputs at

Pins (14) and

(15) of IC3501

as specified?

Yes

Check the line

in question.

Check the

LMUTE line.

Check IC3501,

IC3304 and its

peripheral

parts.

TV sound

failure

Yes

No

Is output at Pins

(15) and (16) of

tuner as

specified?

No

Is input at Pin

(67) of IC3304

as specified?

Yes

Check IC3304,

X3301 and

their peripheral

parts.

Check the

tuner and its

peripheral

parts.

Check Q3201,

Q3202 and

their peripheral

parts.

TROUBLE SHOOTING TABLE (Continued)

16

- M E M O -

LC-13B2H/M

17

LC-13B2H/M

CHASSIS LAYOUT

MAIN Unit (Side-A)

J

I

H

G

F

MAIN Unit (Side-B)

E

D

C

B

A

12345678910

18

JACK Unit

J

I

H

LC-13B2H/M

OPERATION Unit

G

F

TERMINAL Unit

E

D

R/C RESEIVER Unit

C

B

A

12345678910

19

LC-13B2H/M

LC-13B2H/M

BLOCK DIAGRAM

J

I2C

TUNER
TU3201

I

AV2

INPUT

OUTPUT

H

COMPONENT

INPUT

G

DC IN

DC12V

F

DC/DC

T3701

IC3701

Q3700
Q3701

E

D

C

Q3702

TV-V

SIF

AUDIO
IN/OUT

SWITCH

IC35 0 1

Q3500

Y, PB, PR

DL, DR

34V

15V

10V

5V

-9V

AUDIO

DECODER

(MSP)

IC3304

I2C

REGULATOR

IC3702

V2/VO

VIDEO

IN/OUT

SWITCH

Q3501-Q3505

FILTER

TERMINAL UNIIT

AUDIO
IC3301

IC3302
IC3303

31V

Q3707

29V

Q3704

14V

Q3705

8V

Q3706

SP-L

V2

VO

LAMP

CHECK

AUDIO

AMPLIFIER

IC3305

HEAD

PHONE

JACK

SP-R

L1, R1

V1

SY, SC

TV-V
V1
V2

IREMI, POWOUT, TIMED

AV1

S-VIDEO

INPUT

VIDEO

SWITCH

IC402

SYNC

SEPARATER.

IC401

CSYNC

KEY1, KEY2

L_ERR

JACK UNIT

INVERTER

Q5701, Q5702

T5701, T5702

V

SY, SC

BUFFER

Q401
Q402

Y, PB, PR

MPU

IC2001

HOT

I2C

VIDEO

DECODER

(VPC)
IC801

3.3V REG.
IC702

CK, VD, HD ,

3 WIRE

BUS-SWITCH

IC2003

LAMPS

OSD-RGB

E2PROM

IC2004

COLD

I2C

FIFO

IC1202

DAC

IC1101

LCD

CONTROLLER

IC1201

GRADUATION

POWER FOR

IC1102-IC1108

COMMON

IC1109

Q1101
Q1102

LCD

IC1110

MAIN UNIT

GATE

CONTROL

IC1203
IC1204
IC1205

LCD

PANEL

5V REG.

B

LED
D4014
D4015

A

1234567891011 12 13 14 15 16 17 18 19 20

R/C

RECEIVER

RMC4002

R/C RECEIVER UNIT

POWER

SWITCH

OPERATION UNIT

CONTROL

KEYS

IC701

RESET
IC2002

20~21

LC-13B2H/M

DESCRIPTION OF SCHEMATIC DIAGRAM

IMPORTANT SAFETY NOTICE:

PARTS MARKED WITH

"å "( )

ARE
INPORTANT FOR MAINTAINING THE SAFETY OF
THE SET.
BE SURE TO REPLACE THESE PARTS WITH
SPECIFIED ONES FORMAINTAINING THE SAFETY
AND PERFORMANCE OF THE SET.

CAUTION:

This circuit diagram is original one, therefore there
may be a slight difference from yours.

1. When the exclusive-use AC adapter is used, the
colour bar signal of colour bar generator for service
is input to get the normal screen. When the audio is
minimized, the voltage value is measured with the
20 kΩ/V tester.

2. When the exclusive-use AC adapter is used, the
colour density, lightness and colour hue are set to
the center position, and the signal of colour bar
generator for service is observed to get waveform.
The wave form test point is indicated with the mark
( ) in the wiring diagram.

[Item]

Resistors

Nonindication Carbon-film resistor

C Solid resistor
S Metal-oxide-film resistor
N Metal-film resistor

W Cement resistor

T Special resistor

Capacitors

Nonndication Ceramic capacitor

ML Mylar capacitor
PF Polypropylene

film capacitor

TA Tantalum capacitor

ST Styrol capacitor

3. Indication of resistors and capacitors
[Resistors]
Unit : Nonindication … Ω, K…kΩ,

M…MΩ

Error : Nonindication … ±5%

F…±1%

D…±0.5%
[Capacitor]
Unit :Nonindication or µ … µF,

P or p … pF

22

SCHEMATIC DIAGRAMS

Ë

OPERATION and R/C RECEIVER Unit

J

OPERATION Unit

I

H

G

LC-13B2H/M

F

R/C RECEIVER Unit

E

D

C

B

A

12345678910

23

LC-13B2H/M

LC-13B2H/M

Ë

MAIN Unit -1/4

J

I

H

G

F

E

D

C

B

A

1234567891011 12 13 14 15 16 17 18 19 20

24~25

LC-13B2H/M

LC-13B2H/M

Ë

MAIN Unit -2/4

J

I

H

G

F

E

D

C

B

A

1234567891011 12 13 14 15 16 17 18 19 20

26~27

LC-13B2H/M

LC-13B2H/M

Ë

MAIN Unit -3/4

J

I

H

G

F

E

D

C

B

A

1234567891011 12 13 14 15 16 17 18 19 20

28~29

LC-13B2H/M

LC-13B2H/M

Ë

MAIN Unit -4/4

J

I

H

G

F

E

D

C

B

A

1234567891011 12 13 14 15 16 17 18 19 20

30~31

LC-13B2H/M

å

å

LC-13B2H/M

Ë

TERMINAL Unit -1/2

J

I

H

å AND SHADED COMPONENTS=SAFETY RELATED PARTS

G

F

E

D

C

B

A

1234567891011 12 13 14 15 16 17 18 19 20

32~33

LC-13B2H/M

LC-13B2H/M

Ë

TERMINAL Unit -2/2

J

I

H

å AND SHADED COMPONENTS=SAFETY RELATED PARTS

G

F

E

å

D

C

B

A

1234567891011 12 13 14 15 16 17 18 19 20

34~35

LC-13B2H/M

LC-13B2H/M

Ë

JACK Unit

J

å AND SHADED COMPONENTS=SAFETY RELATED PARTS

I

H

G

F

å

E

D

C

B

A

1234567891011 12 13 14 15 16 17 18 19 20

36~37

LC-13B2H/M

PRINTED WIRING BOARD ASSEMBLIES

J

I

H

G

F

E

D

C

B

A

Main Unit (Side-A)

12345678910

38

LC-13B2H/M

J

I

H

G

F

E

D

C

B

A

12345678910

Main Unit (Side-B)

39

LC-13B2H/M

J

I

H

G

F

E

D

C

B

A

Terminal Unit (Side-A)

12345678910

40

LC-13B2H/M

J

I

H

G

F

E

D

C

B

A

12345678910

Terminal Unit (Side-B)

41

LC-13B2H/M

J

I

H

G

R/C Receiver Unit (Side-A)

F

E

D

C

B

Operation Unit (Side-A)

A

Jack Unit (Side-A)

12345678910

42

LC-13B2H/M

J

I

R/C Receiver Unit (Side-B)

H

G

F

E

D

C

B

Operation Unit (Side-B)

A

Jack Unit (Side-B)

12345678910

43

LC-13B2H/M

- M E M O -

44

LC-13B2H/M

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

Replacement parts which have these special safety character­istics identified in this manual: electrical components having
such features are identified by
Replacement Parts Lists and schematic diagrams.
The use of a substitute replacement part which does not have
the same safety characteristics as the factory recommended
replacement parts shown in this service manual may create
shock, fire or other hazards.

“

HOW TO ORDER REPLACEMENT PARTS

To have your order filled promptly and correctly, please furnish
the following informations.

1. MODEL NUMBER 2. REF. NO.

3. PART NO. 4. DESCRIPTION

Ref. No. Part No. ★ Description Code

RLCDT0065CEZZ J LCD Unit CX

å KLMP-0109CEZZ J Fluorescent Lamp AZ

PARTS LIST

PARTS REPLACEMENT

“å”

and shaded area in the

MARK★: SPARE PARTS-DELIVERY SECTION

LCD UNIT

LAMP UNIT

DUNTKA562FE04

MAIN PWB UNIT

INTEGRATED CIRCUITS

IC401 VHiBA7046F/-1 J BA7046F AF
IC402 VHiNJM2235M-1 J NJM2235M AE
IC701 VHiAN8005M/-1 J AN8005M, +5V REG AD
IC702 VHiBA033FP/-1 J BA033FP AG
IC801 VHiVPC3230D1EQ J VPC3230D BD
IC1101 VHiMB8346BV-1 J MB8346BV AN
IC1102 VHiNJM4565V-1 J NJM4565V AF
IC1103 VHiNJM4565V-1 J NJM4565V AF
IC1104 VHiNJM4565V-1 J NJM4565V AF

”

IC1105 VHiBU4053V/-1 J BU4053V AE
IC1106 VHiNJM4580V-1 J NJM4580V AE
IC1107 VHiNJM4580V-1 J NJM4580V AE
IC1108 VHiNJM4580V-1 J NJM4580V AE
IC1109 VHiNJM353M/-1 J NJM353M AG
IC1110 VHiBU4053V/-1 J BU4053V AE
IC1201 RH-iX3378CEZZ J IX3378CE AY
IC1202 VHiPD485505-2 J PD485505 AY
IC1203 VHiTC4W53U/-1 J TC4W53U AF
IC1204 VHiTC4024BF-1 J TC4024BF, Binary Counter AG
IC1205 VHiTC4052BF1E J TC4052BF, 4ch Multiplexer AF
IC2001 RH-iXA003WJZZQ J IXA003WJ BA
IC2002 VHiPST529DM-1 J PST529DM AE
IC2003 VHiTC4W66F/-1 J TC4W66F AE
IC2004 VHiBR2416E2-1 J BR2416E2 AK

TRANSISTORS

Q401 VS2SC2712Y/-1 J 2SC2712Y AB
Q402 VS2SA1037KQ-1 J 2SA1037KQ AA
Q701 VS2SA1162Y/-1 J 2SA1162Y AB
Q702 VSDTC144EE/-1 J DTC144EE AA
Q703 VS2SA1162Y/-1 J 2SA1162Y AB
Q1101 VS2SA1729//-1 J 2SA1729 AF
Q1102 VS2SC4520//-1 J 2SC4520 AE
Q1201 VSDTC144EE/-1 J DTC144EE AA
Q1202 VSDTC144EE/-1 J DTC144EE AA
Q2004 VSDTC144EE/-1 J DTC144EE AA
Q2050 VSDTC144EE/-1 J DTC144EE AA

DIODES

D1101 VHD1SS250//1E J 1SS250 AB
D1102 VHDDAN222//-1 J DAN222 AA
D1201 VHDDAN222//-1 J DAN222 AA
D2001 VHDDAN222//-1 J DAN222 AA

PRINTED WIRING BOARD ASSEMBLIES

(NOT REPLACEMENT ITEM)

DUNTKA562FE04 – MAIN PWB Unit —
DUNTKB001DE01 – TERMINAL PWB Unit —
DUNTKB002DE01 – OPERATION PWB Unit —
DUNTKB003DE01 – JACK PWB Unit —
DUNTKB004DE01 – R/C RECEIVER PWB Unit —

X801 RCRSC0012CEZZ J Crystal, CRSC0012CE AH

PACKAGED CIRCUIT

FILTER

X2002 RFiLZ0169TAZZY J Filter, FiLZ0169TA AD

COILS

L401 VP-9N4R7KR56N J Peaking, 4.7µHAC
L402 VP-9N4R7KR56N J Peaking, 4.7µHAC
L801 VP-9N3R3KR46N J Peaking, 3.3µHAC
L802 VP-9N3R3KR46N J Peaking, 3.3µHAC
L803 VP-9N3R3KR46N J Peaking, 3.3µHAC
L804 RCiLC0055CEZZ J Coil, CiLC0055CE AD
L805 RCiLC0055CEZZ J Coil, CiLC0055CE AD
L1201 VP-1M470J5R4N J Peaking, 47µHAC
L1202 VP-1M100J1R6N J Peaking, 10µHAC
L1203 VP-1M220J2R9N J Peaking, 22µHAC
L1204 VP-1M220J2R9N J Peaking, 22µHAC
L1205 VP-1M220J2R9N J Peaking, 22µHAC

CAPACITORS

C401 VCKYTV1AB105K J 1 10V Ceramic AD
C402 VCKYCY1HB102K J 1000p 50V Ceramic AA
C403 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C404 VCEAPF1AW476M J 47 10V Electrolytic AB
C405 VCKYCY1HB222K J 2200p 50V Ceramic AA

45

LC-13B2H/M

Ref. No. Part No. ★ Description Code

DUNTKA562FE04

MAIN PWB UNIT(Continued)

C406 VCKYTV1AB105K J 1 10V Ceramic AD
C407 VCCCCY1HH101J J 100p 50V Ceramic AA
C408 VCKYTV1AB105K J 1 10V Ceramic AD
C409 VCKYTV1AB105K J 1 10V Ceramic AD
C410 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C411 VCKYTV1AB105K J 1 10V Ceramic AD
C412 VCCCCY1HH331J J 330p 50V Ceramic AA
C413 VCCCCY1HH331J J 330p 50V Ceramic AA
C414 VCCCCY1HH331J J 330p 50V Ceramic AA
C701 VCKYTV1CF105Z J 1 16V Ceramic AB
C702 VCEAPF1CN226M J 22 16V Electrolytic AD
C703 VCKYTV1CF105Z J 1 16V Ceramic AB
C705 VCKYCY1CF334Z J 0.33 16V Ceramic AA
C706 VCEAPF0JN226M J 22 6.3V Electrolytic AD
C801 VCEAPF1CN106M J 10 16V Electrolytic AD
C802 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C803 VCCCCY1HH7R0D J 7p 50V Ceramic AA
C804 VCCCCY1HH7R0D J 7p 50V Ceramic AA
C805 RC-KZ1025CEZZ J 1 10V Ceramic AB
C806 RC-KZ1025CEZZ J 1 10V Ceramic AB
C807 VCKYCY1HB331K J 330p 50V Ceramic AA
C808 VCKYCY1HB331K J 330p 50V Ceramic AA
C809 VCEAPK1CN107M J 100 16V Electrolytic AD
C810 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C811 VCKYCY1HB331K J 330p 50V Ceramic AA
C812 RC-KZ1025CEZZ J 1 10V Ceramic AB
C813 RC-KZ1025CEZZ J 1 10V Ceramic AB
C814 VCKYCY1HB102K J 1000p 50V Ceramic AA
C815 VCKYTV1CF105Z J 1 16V Ceramic AB
C816 VCKYTV1CF105Z J 1 16V Ceramic AB
C817 VCKYTV1CF105Z J 1 16V Ceramic AB
C818 RC-KZ1025CEZZ J 1 10V Ceramic AB
C819 RC-KZ1025CEZZ J 1 10V Ceramic AB
C820 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C821 VCEAPW1CN477M J 470 16V Electrolytic AE
C822 RC-KZ1025CEZZ J 1 10V Ceramic AB
C823 RC-KZ1025CEZZ J 1 10V Ceramic AB
C824 VCKYCY1CF224Z J 0.22 16V Ceramic AA
C825 VCKYCY1CF224Z J 0.22 16V Ceramic AA
C826 VCEAPF0GW107M J 100 4V Electrolytic AC
C827 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C829 VCE9PF1CN475M J 4.7 16V Electrolytic AD
C830 VCKYCY1CF224Z J 0.22 16V Ceramic AA
C831 VCKYCY1CF224Z J 0.22 16V Ceramic AA
C832 VCKYCY1CF224Z J 0.22 16V Ceramic AA
C833 VCEAPF0GW107M J 100 4V Electrolytic AC
C834 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C835 VCEAPF0JW107M J 100 6.3V Electrolytic AC
C836 RC-KZ1025CEZZ J 1 10V Ceramic AB
C837 RC-KZ1025CEZZ J 1 10V Ceramic AB
C838 VCEAPF0GW107M J 100 4V Electrolytic AC
C839 RC-KZ1025CEZZ J 1 10V Ceramic AB
C840 VCKYTV1CF105Z J 1 16V Ceramic AB
C1101 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1102 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1103 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1104 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1105 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1106 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1107 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1108 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1109 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1110 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1111 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1112 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1113 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1114 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1115 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1116 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1117 VCCCCY1HH560J J 56p 50V Ceramic AA
C1118 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1119 VCKYTV1CF105Z J 1 16V Ceramic AB

Ref. No. Part No. ★ Description Code

C1120 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1122 VCKYTV1CF105Z J 1 16V Ceramic AB
C1123 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1124 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1125 VCEAPF0JN107M J 100 6.3V Electrolytic AD
C1126 RC-EZ1339CEZZ J 220 16V Electrolytic AD
C1127 VCEAPF1CN107M J 100 16V Electrolytic AD
C1128 VCE9PF1CN106M J 10 16V Electrolytic AD
C1129 RC-EZ1339CEZZ J 220 16V Electrolytic AD
C1202 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1203 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1204 VCCCCY1HH220J J 22p 50V Ceramic AA
C1205 VCCCCY1HH220J J 22p 50V Ceramic AA
C1206 VCEAPF1HN106M J 10 50V Electrolytic AD
C1207 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1208 VCKYTV1HF104Z J 0.1 50V Ceramic AA
C1209 VCEASH0JN227MY J 220 6.3V Electrolytic AC
C1210 VCEAPF0GW107M J 100 4V Electrolytic AC
C1211 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1212 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1213 VCEAPF0JW107M J 100 6.3V Electrolytic AC
C1214 VCEAPF0GW107M J 100 4V Electrolytic AC
C1215 RC-KZ1025CEZZ J 1 10V Ceramic AB
C1216 VCEAPF1VW226M J 22 35V Electrolytic AB
C1218 VCEAPF1CN106M J 10 16V Electrolytic AD
C1219 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1220 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C1222 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C2006 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C2007 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C2009 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C2010 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C2017 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C2018 VCCCCY1HH220J J 22p 50V Ceramic AA
C7104 VCEAPF1CN107M J 100 16V Electrolytic AD
C7105 VCKYCY1EF104Z J 0.1 25V Ceramic AA

RESISTORS

R401 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R402 VRS-CY1JF333J J 33k 1/16W Metal Oxide AA
R403 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R404 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R405 VRS-CY1JF562J J 5.6k 1/16W Metal Oxide AA
R406 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide AA
R407 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R408 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide AA
R409 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R410 VRS-CY1JF474J J 470k 1/16W Metal Oxide AA
R412 VRS-CY1JF562J J 5.6k 1/16W Metal Oxide AA
R414 VRS-CY1JF105J J 1M 1/16W Metal Oxide AA
R415 VRS-CY1JF105J J 1M 1/16W Metal Oxide AA
R416 VRS-CY1JF105J J 1M 1/16W Metal Oxide AA
R417 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R418 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R419 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R701 VRS-CY1JF1R0J J 1 1/16W Metal Oxide AA
R702 VRS-CY1JF154J J 150k 1/16W Metal Oxide AA
R703 VRS-CY1JF274J J 270k 1/16W Metal Oxide AA
R705 VRS-CY1JF1R0J J 1 1/16W Metal Oxide AA
R726 VRS-CY1JF1R0J J 1 1/16W Metal Oxide AA
R727 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R739 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R740 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R801 VRS-CB1JF000J J 0 1/16W Metal Oxide AC
R802 VRS-CB1JF000J J 0 1/16W Metal Oxide AC
R803 VRS-CB1JF000J J 0 1/16W Metal Oxide AC
R804 VRS-CA1JF101J J 100 1/16W Metal Oxide AA
R805 VRS-CY1JF105J J 1M 1/16W Metal Oxide AA
R807 VRS-CY1JF750J J 75 1/16W Metal Oxide AA
R808 VRS-CY1JF750J J 75 1/16W Metal Oxide AA
R809 VRS-CY1JF750J J 75 1/16W Metal Oxide AA
R810 VRS-CB1JF000J J 0 1/16W Metal Oxide AC
R811 VRS-CY1JF222J J 2.2k 1/16W Metal Oxide AA
R812 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R813 VRS-CB1JF000J J 0 1/16W Metal Oxide AC

46

LC-13B2H/M

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

DUNTKA562FE04

MAIN PWB UNIT(Continued)

R814 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide AA
R815 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R816 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R819 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R826 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R831 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R832 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R833 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R834 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R836 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R838 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1101 VRS-CA1JF333J J 33k 1/16W Metal Oxide AA
R1102 VRS-CA1JF103J J 10k 1/16W Metal Oxide AA
R1104 VRS-CA1JF333J J 33k 1/16W Metal Oxide AA
R1105 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R1106 VRS-CA1JF333J J 33k 1/16W Metal Oxide AA
R1107 VRS-CA1JF103J J 10k 1/16W Metal Oxide AA
R1108 VRS-CA1JF103J J 10k 1/16W Metal Oxide AA
R1109 VRS-CA1JF333J J 33k 1/16W Metal Oxide AA
R1110 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R1111 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R1112 VRS-CY1JF103F J 10k 1/16W Metal Oxide AA
R1113 VRS-CA1JF333J J 33k 1/16W Metal Oxide AA
R1114 VRS-CY1JF103F J 10k 1/16W Metal Oxide AA
R1115 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R1116 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R1117 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R1118 VRS-CY1JF823F J 82k 1/16W Metal Oxide AA
R1119 VRS-CY1JF472F J 4.7k 1/16W Metal Oxide AA
R1120 VRS-TX2HF8R2J J 8.2 1/2W Metal Oxide AA
R1121 VRS-CY1JF181J J 180 1/16W Metal Oxide AA
R1123 VRS-CY1JF181J J 180 1/16W Metal Oxide AA
R1124 VRS-CY1JF472F J 4.7k 1/16W Metal Oxide AA
R1125 VRS-TX2HF101J J 100 1/2W Metal Oxide AA
R1126 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1127 VRS-TX2HF1R0J J 1 1/2W Metal Oxide AA
R1128 VRS-CY1JF105J J 1M 1/16W Metal Oxide AA
R1129 VRS-CY1JF563F J 56k 1/16W Metal Oxide AA
R1130 VRS-TX2HF5R6J J 5.6 1/2W Metal Oxide AA
R1131 VRS-CY1JF105J J 1M 1/16W Metal Oxide AA
R1132 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1133 VRS-CY1JF223F J 22k 1/16W Metal Oxide AA
R1134 VRS-CY1JF822F J 8.2k 1/16W Metal Oxide AA
R1135 VRS-CY1JF561J J 560 1/16W Metal Oxide AA
R1136 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1137 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1138 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1143 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R1144 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R1145 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R1146 VRS-CY1JF123J J 12k 1/16W Metal Oxide AA
R1147 VRS-CY1JF100J J 10 1/16W Metal Oxide AA
R1149 VRS-CY1JF563J J 56k 1/16W Metal Oxide AA
R1150 VRS-CY1JF103F J 10k 1/16W Metal Oxide AA
R1151 VRS-CY1JF103F J 10k 1/16W Metal Oxide AA
R1152 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1153 VRS-CY1JF820J J 82 1/16W Metal Oxide AA
R1202 VRS-CB1JF220J J 22 1/16W Metal Oxide AC
R1203 VRS-CA1JF220J J 22 1/16W Metal Oxide AA
R1204 VRS-CB1JF220J J 22 1/16W Metal Oxide AC
R1205 VRS-CA1JF220J J 22 1/16W Metal Oxide AA
R1206 VRS-CB1JF220J J 22 1/16W Metal Oxide AC
R1207 VRS-CA1JF220J J 22 1/16W Metal Oxide AA
R1208 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R1209 VRS-CA1JF220J J 22 1/16W Metal Oxide AA
R1210 VRS-CY1JF220J J 22 1/16W Metal Oxide AA
R1211 VRS-CY1JF221J J 220 1/16W Metal Oxide AA
R1212 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1213 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R1214 VRS-CB1JF101J J 100 1/16W Metal Oxide AA
R1216 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R1217 VRS-CY1JF101J J 100 1/16W Metal Oxide AA

R1218 VRS-CA1JF101J J 100 1/16W Metal Oxide AA
R1219 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1220 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide AA
R1221 VRS-CB1JF332J J 3.3k 1/16W Metal Oxide AC
R1222 VRS-CB1JF000J J 0 1/16W Metal Oxide AC
R1223 VRS-CA1JF101J J 100 1/16W Metal Oxide AA
R1225 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide AA
R1228 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1230 VRS-CY1JF562J J 5.6k 1/16W Metal Oxide AA
R1231 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R1232 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R1233 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R1234 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide AA
R1235 VRS-CB1JF473J J 47k 1/16W Metal Oxide AC
R1236 VRS-CB1JF473J J 47k 1/16W Metal Oxide AC
R1238 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R2002 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R2003 VRS-CA1JF223J J 22k 1/16W Metal Oxide AA
R2007 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R2009 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R2010 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R2011 VRS-CB1JF101J J 100 1/16W Metal Oxide AA
R2012 VRS-CA1JF103J J 10k 1/16W Metal Oxide AA
R2013 VRS-CA1JF223J J 22k 1/16W Metal Oxide AA
R2014 VRS-CA1JF101J J 100 1/16W Metal Oxide AA
R2015 VRS-CB1JF331J J 330 1/16W Metal Oxide AC
R2016 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R2017 VRS-CA1JF102J J 1k 1/16W Metal Oxide AA
R2018 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R2021 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R2022 VRS-CA1JF101J J 100 1/16W Metal Oxide AA
R2025 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R2026 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R2027 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R2029 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R2030 VRS-CA1JF333J J 33k 1/16W Metal Oxide AA
R2033 VRS-CB1JF101J J 100 1/16W Metal Oxide AA
R2036 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R2037 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R2038 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R2041 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R2044 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R2045 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R2050 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R2051 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R2052 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R2053 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R2054 VRS-CY1JF101J J 100 1/16W Metal Oxide AA

BALUNES

FB801 RBLN-0090CEZZ J Balun, BLN-0090CE AD
FB802 RBLN-0090CEZZ J Balun, BLN-0090CE AD
FB1201 RBLN-0090CEZZ J Balun, BLN-0090CE AD
FB1203 RBLN-0076TAZZ J Balun, BLN-0076TA AC

MISCELLANEOUS PARTS

P2001 QPLGN0558REZZ J Plug, 5Pin AE
P2003 QPLGN1058REZZY J Plug, 10Pin AD
P2004 QPLGN0165FJZZ J Plug, 5Pin AD
SC1201 QSOCN0461FJZZ J Socket, 53Pin AH
SC1202 QSOCN0206FJZZ J Socket, 30Pin AF
SC2001 QSOCN0464FJZZ J Socket, 50Pin AH

DUNTKB001DE01

TERMINAL PWB UNIT

TUNER

NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN

ASSEMBLY BUT NOT INDEPENDENTLY.

TU3201 VTUVT2U5CD553 J VHF Tuner BD

47

LC-13B2H/M

Ref. No. Part No. ★ Description Code

DUNTKB001DE01

TERMINAL PWB UNIT(Continued)

INTEGRATED CIRCUITS

IC3301 VHiNJM4560M-1 J NJM4560M AG
IC3302 VHiNJM4560M-1 J NJM4560M, 1.5KHz BEF AG
IC3303 VHiNJM4560M-1 J NJM4560M, 100Hz HPF AG
IC3304 RH-iX3371CEZZ J IX3371CE BD
IC3305 VHiLA4635A+-1S J LA4635A+ AM
IC3501 VHiTC4053BF1E J TC4053BF AF
IC3701 VHiNJM2377M-1 J NJM2377M AK
IC3702 VHiNJM2147M-1 J NJM2147M AF

TRANSISTORS

Q3201 VS2SC2712Y/-1 J 2SC2712Y AB
Q3202 VS2SC2712Y/-1 J 2SC2712Y AB
Q3203 VSDTC144EE/-1 J DTC144EE AA
Q3204 VSDTC144EE/-1 J DTC144EE AA
Q3205 VSDTC144EE/-1 J DTC144EE AA
Q3303 VSDTA144EE/-1 J DTA144EE AA
Q3304 VSDTC314TK/-1 J DTC314TK AC
Q3305 VSDTC314TK/-1 J DTC314TK AC
Q3306 VS2SC2712Y/-1 J 2SC2712Y AB
Q3500 VSUMG4N++++-1Y J UMG4N++++ AB
Q3501 VS2SK1467//-1 J 2SK1467 AE
Q3502 VS2SK1467//-1 J 2SK1467 AE
Q3503 VS2SC3928AR-1 J 2SC3928AR AB
Q3504 VS2SC3928AR-1 J 2SC3928AR AB
Q3505 VSDTC144EE/-1 J DTC144EE AA
Q3510 VSDTC314TK/-1 J DTC314TK AC
Q3511 VSDTC314TK/-1 J DTC314TK AC
Q3512 VS2SA1037KQ-1 J 2SA1037KQ AA
Q3600 VSUPA606T//-1 J UPA606T AD
Q3700 VSFMMT718//-1 J FMMT718 AE
Q3701 VSDTC144EE/-1 J DTC144EE AA
Q3702 VS2SK2503//-1 J 2SK2503 AE
Q3704 VS2SC2712Y/-1 J 2SC2712Y AB
Q3705 VS2SC2712Y/-1 J 2SC2712Y AB
Q3706 VSFMY3/////-1 J FMY3 AB
Q3707 VS2SC2712Y/-1 J 2SC2712Y AB
Q3708 VSDTC114YE/-1 J DTC114YE AB

DIODES

D3301 RH-EX1396CEZZY J Zener Diode, 6.8V AB
D3302 VHDDAN222//-1 J DAN222 AA
D3401 RH-EX1271CEZZ J Zener Diode, 12V AB
D3402 RH-EX1271CEZZ J Zener Diode, 12V AB
D3501 VHDDAN222//-1 J DAN222 AA
D3601 VHDiMN10///-1 J IMN10 AB
D3603 VHDiMN10///-1 J IMN10 AB
D3700 VHDDAN222//-1 J DAN222 AA
D3703 VHDSFPB56//2E J SFPB56 AC
D3704 VHD1SS250//1E J 1SS250 AB
D3705 VHD1SS250//1E J 1SS250 AB
D3706 VHDSFPB74//2E J SFPB74 AD
D3707 VHDSFPB74//2E J SFPB74 AD
D3708 VHDDAN222//-1 J DAN222 AA
D3709 VHDDAN222//-1 J DAN222 AA

PACKAGED CIRCUIT

X3301 RCRSB0307CEZZ+ J Crystal, CRSB0307CE AG

COILS

L3201 VP-1M220J2R9N J Peaking, 22µHAC
L3202 RCiLC0141CEZZ J Coil, CiLC0141CE AF
L3301 VP-1M101J7R7N J Peaking, 100µHAC
L3302 VP-1M4R7J1R2N J Peaking, 4.7 µHAB
L3500 VP-1M101J7R7N J Peaking, 100µHAC
L3700 RCiLC0130CEZZ J Coil, CiLC0130CE AG
L3702 RCiLC0130CEZZ J Coil, CiLC0130CE AG

TRANSFORMER

å T3701 RTRNZ0800CEZZY J Transformer AM

Ref. No. Part No. ★ Description Code

CONTROL

R3760 RVR-M8026TAZZ J Variable Resistor AC

CAPACITORS

C3201 VCKYCY1HB102K J 1000p 50V Ceramic AA
C3202 VCCCCY1HH330J J 33p 50V Ceramic AA
C3203 VCCCCY1HH330J J 33p 50V Ceramic AA
C3204 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3205 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3206 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3208 RC-EZ1351CEZZ J 3300 6.3V Electrolytic AF
C3210 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3308 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3309 VCKYCY1HB153K J 0.015 50V Ceramic AA
C3310 VCKYCY1HB153K J 0.015 50V Ceramic AA
C3311 VCKYCY1CB273K J 0.027 16V Ceramic AA
C3312 VCKYCY1CB273K J 0.027 16V Ceramic AA
C3313 VCKYCY1HB153K J 0.015 50V Ceramic AA
C3314 VCKYCY1HB153K J 0.015 50V Ceramic AA
C3315 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3316 VCKYCY1CB273K J 0.027 16V Ceramic AA
C3317 VCKYCY1CB273K J 0.027 16V Ceramic AA
C3318 VCKYCY1CB273K J 0.027 16V Ceramic AA
C3319 VCKYCY1CB273K J 0.027 16V Ceramic AA
C3320 VCEAPF1CN476M J 47 16V Electrolytic AD
C3321 VCEAPF1HN225M J 2.2 50V Electrolytic AD
C3322 VCEAPF1HN225M J 2.2 50V Electrolytic AD
C3323 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3324 VCEAPF1HN225M J 2.2 50V Electrolytic AD
C3325 VCEAPF1HN225M J 2.2 50V Electrolytic AD
C3328 VCEAPF1HN225M J 2.2 50V Electrolytic AD
C3329 VCEAPF1HN225M J 2.2 50V Electrolytic AD
C3330 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3332 VCEAPF0JN107M J 100 6.3V Electrolytic AD
C3333 VCEAPF1CN107M J 100 16V Electrolytic AD
C3334 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3335 VCKYCY1HB102K J 1000p 50V Ceramic AA
C3336 VCKYCY1HB102K J 1000p 50V Ceramic AA
C3337 VCEAPF1CN106M J 10 16V Electrolytic AD
C3338 VCEAPF1CN106M J 10 16V Electrolytic AD
C3339 VCEAPF1HN335MY J 3.3 50V Electrolytic AD
C3340 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3341 VCCCCY1HH101J J 100p 50V Ceramic AA
C3342 VCCCCY1HH101J J 100p 50V Ceramic AA
C3343 VCCCCY1HH101J J 100p 50V Ceramic AA
C3344 VCCCCY1HH101J J 100p 50V Ceramic AA
C3345 VCCCCY1HH101J J 100p 50V Ceramic AA
C3346 VCCCCY1HH101J J 100p 50V Ceramic AA
C3347 VCEAPF1HW225M J 2.2 50V Electrolytic AB
C3348 VCCCCY1HH101J J 100p 50V Ceramic AA
C3349 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3350 VCEAPF1CN106M J 10 16V Electrolytic AD
C3351 RC-KZ1025CEZZ J 1 10V Ceramic AB
C3352 VCEAPF0JN107M J 100 6.3V Electrolytic AD
C3354 VCCCCY1HH560J J 56p 50V Ceramic AA
C3355 VCCCCY1HH560J J 56p 50V Ceramic AA
C3356 VCCCCY1HH560J J 56p 50V Ceramic AA
C3357 VCCCCY1HH5R0C J 5p 50V Ceramic AA
C3358 VCCCCY1HH5R0C J 5p 50V Ceramic AA
C3359 VCEAPF1CN106M J 10 16V Electrolytic AD
C3360 VCEAPF1CN107M J 100 16V Electrolytic AD
C3361 VCEAPF1HN105M J 1 50V Electrolytic AD
C3362 VCKYCY1HB102K J 1000p 50V Ceramic AA
C3363 VCEAPF1HN225M J 2.2 50V Electrolytic AD
C3364 VCEAPF1HN105M J 1 50V Electrolytic AD
C3365 VCKYCY1HB102K J 1000p 50V Ceramic AA
C3366 VCEAPF1HN225M J 2.2 50V Electrolytic AD
C3367 VCEAPF1CN106M J 10 16V Electrolytic AD
C3368 VCEAPF1CN106M J 10 16V Electrolytic AD
C3369 RC-EZ1274CEZZ J 1000 16V Electrolytic AD
C3370 VCKYTV1CF105Z J 1 16V Ceramic AB
C3371 VCEA4U1CN228M J 2200 16V Electrolytic AE
C3372 RC-EZ1274CEZZ J 1000 16V Electrolytic AD
C3373 VCKYCY1HB102K J 1000p 50V Ceramic AA

48

LC-13B2H/M

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

DUNTKB001DE01

TERMINAL PWB UNIT(Continued)

C3375 VCKYCY1EB223K J 0.022 25V Ceramic AA
C3377 VCKYCY1EB223K J 0.022 25V Ceramic AA
C3380 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3382 RC-KZ1025CEZZ J 1 10V Ceramic AB
C3383 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3385 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3386 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3387 VCKYCY1HB471K J 470p 50V Ceramic AA
C3388 VCKYCY1HB471K J 470p 50V Ceramic AA
C3389 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3401 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3507 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3508 RC-EZ0417CEZZ J 150 16V Electrolytic AD
C3509 VCEAPF1CW107M J 100 16V Electrolytic AD
C3510 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3512 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3513 VCEAPW1CN477M J 470 16V Electrolytic AE
C3514 VCEAPF0JW336M J 33 6.3V Electrolytic AB
C3515 VCEAPF0JW226M J 22 6.3V Electrolytic AB
C3516 RC-KZ1025CEZZ J 1 10V Ceramic AB
C3517 VCKYCY1EB223K J 0.022 25V Ceramic AA
C3518 VCKYCY1EB223K J 0.022 25V Ceramic AA
C3520 VCEAPF1EW475M J 4.7 25V Electrolytic AB
C3521 VCEAPF1EW475M J 4.7 25V Electrolytic AB
C3522 VCEAPF1CW106M J 10 16V Electrolytic AB
C3603 VCKYTQ1EF105Z J 1 25V Ceramic AD
C3604 VCKYTQ1EF105Z J 1 25V Ceramic AD
C3700 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3701 VCEAPF1EW475M J 4.7 25V Electrolytic AB
C3702 RC-KZ1025CEZZ J 1 10V Ceramic AB
C3703 VCEAPT1CN226M J 22 16V Electrolytic AC
C3704 VCCCCY1HH471J J 470p 50V Ceramic AA
C3705 VCKYCY1EB103K J 0.01 25V Ceramic AA
C3710 VCEASH1CN337MYJ 330 16V Electrolytic AE
C3711 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3712 RC-EZ1176CEZZ J 100 16V Electrolytic AK
C3713 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3714 VCEASH1HN476MYJ 47 50V Electrolytic AD
C3715 VCKYTV1HF104Z J 0.1 50V Ceramic AA
C3716 VCEASH1EN227MYJ 220 25V Electrolytic AE
C3717 VCKYTV1CF105Z J 1 16V Ceramic AB
C3718 VCEASH1CN337MYJ 330 16V Electrolytic AE
C3719 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3720 VCCCCY1HH181J J 180p 50V Ceramic AA
C3721 VCKYTV1CF105Z J 1 16V Ceramic AB
C3722 RC-EZ1177CEZZ J 150 6.3V Electrolytic AH
C3724 VCEASH1CN337MYJ 330 16V Electrolytic AE
C3725 VCKYTV1CF105Z J 1 16V Ceramic AB
C3728 VCKYTV1CF105Z J 1 16V Ceramic AB
C3729 RC-EZA018WJZZ J 2200 6.3V Electrolytic AD
C3730 VCKYTV1HF104Z J 0.1 50V Ceramic AA
C3731 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3732 RC-KZ1025CEZZ J 1 10V Ceramic AB
C3733 RC-KZ1025CEZZ J 1 10V Ceramic AB
C3734 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C3735 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3736 VCEA4U1CN228M J 2200 16V Electrolytic AE

RESISTORS

R3201 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3202 VRS-CY1JF153J J 15k 1/16W Metal Oxide AA
R3203 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide AA
R3204 VRS-CY1JF152J J 1.5k 1/16W Metal Oxide AA
R3205 VRS-CY1JF331J J 330 1/16W Metal Oxide AA
R3206 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3207 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3208 VRS-CA1JF561J J 560 1/16W Metal Oxide AA
R3315 VRS-CY1JF433F J 43k 1/16W Metal Oxide AA
R3316 VRS-CY1JF182J J 1.8k 1/16W Metal Oxide AA
R3317 VRS-CY1JF433F J 43k 1/16W Metal Oxide AA
R3318 VRS-CY1JF182J J 1.8k 1/16W Metal Oxide AA
R3319 VRS-CY1JF393F J 39k 1/16W Metal Oxide AA

R3320 VRS-CY1JF393F J 39k 1/16W Metal Oxide AA
R3321 VRS-CY1JF433F J 43k 1/16W Metal Oxide AA
R3322 VRS-CY1JF183J J 18k 1/16W Metal Oxide AA
R3323 VRS-CY1JF433F J 43k 1/16W Metal Oxide AA
R3324 VRS-CY1JF183J J 18k 1/16W Metal Oxide AA
R3325 VRS-CY1JF183F J 18k 1/16W Metal Oxide AA
R3326 VRS-CY1JF183F J 18k 1/16W Metal Oxide AA
R3327 VRS-CY1JF204F J 200k 1/16W Metal Oxide AA
R3328 VRS-CY1JF204F J 200k 1/16W Metal Oxide AA
R3331 VRS-CY1JF473J J 47k 1/16W Metal Oxide AA
R3332 VRS-CY1JF473J J 47k 1/16W Metal Oxide AA
R3333 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R3334 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R3335 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3336 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3337 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R3338 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R3341 VRS-CY1JF221J J 220 1/16W Metal Oxide AA
R3342 VRS-CY1JF221J J 220 1/16W Metal Oxide AA
R3343 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R3344 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R3347 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3348 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R3350 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3351 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R3353 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3354 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3355 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3356 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R3357 VRS-CY1JF105J J 1M 1/16W Metal Oxide AA
R3358 VRS-CY1JF562J J 5.6k 1/16W Metal Oxide AA
R3359 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3360 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3361 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3362 VRS-CY1JF182J J 1.8k 1/16W Metal Oxide AA
R3363 VRS-CY1JF182J J 1.8k 1/16W Metal Oxide AA
R3364 VRS-CY1JF122J J 1.2k 1/16W Metal Oxide AA
R3365 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide AA
R3366 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide AA
R3367 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3368 VRS-CY1JF822J J 8.2k 1/16W Metal Oxide AA
R3369 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3370 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3371 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3372 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3373 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3374 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3375 VRS-CY1JF682J J 6.8k 1/16W Metal Oxide AA
R3376 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3377 VRS-CY1JF682J J 6.8k 1/16W Metal Oxide AA
R3378 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3379 VRS-CY1JF822J J 8.2k 1/16W Metal Oxide AA
R3380 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R3381 VRS-CY1JF562J J 5.6k 1/16W Metal Oxide AA
R3383 VRS-CY1JF153J J 15k 1/16W Metal Oxide AA
R3384 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3386 VRS-CY1JF113F J 11k 1/16W Metal Oxide AA
R3387 VRS-CY1JF113F J 11k 1/16W Metal Oxide AA
R3388 VRS-CY1JF113F J 11k 1/16W Metal Oxide AA
R3389 VRS-CY1JF113F J 11k 1/16W Metal Oxide AA
R3401 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3402 VRS-TQ2BD750J J 75 1/8W Metal Oxide AA
R3409 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3410 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3411 VRS-TQ2BD750J J 75 1/8W Metal Oxide AA
R3412 VRS-TQ2BD750J J 75 1/8W Metal Oxide AA
R3413 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3428 VRS-CY1JF750J J 75 1/16W Metal Oxide AA
R3429 VRS-CY1JF750J J 75 1/16W Metal Oxide AA
R3430 VRS-CY1JF750J J 75 1/16W Metal Oxide AA
R3431 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3432 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3433 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3523 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R3524 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA

49

LC-13B2H/M

Ref. No. Part No. ★ Description Code

DUNTKB001DE01

TERMINAL PWB UNIT(Continued)

R3528 VRS-CY1JF821J J 820 1/16W Metal Oxide AA
R3529 VRS-CY1JF821J J 820 1/16W Metal Oxide AA
R3530 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R3531 VRS-TQ2BD750J J 75 1/8W Metal Oxide AA
R3532 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3533 VRS-CY1JF680J J 68 1/16W Metal Oxide AA
R3534 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R3535 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R3536 VRS-CY1JF562J J 5.6k 1/16W Metal Oxide AA
R3537 VRS-CY1JF272J J 2.7k 1/16W Metal Oxide AA
R3542 VRS-CY1JF680J J 68 1/16W Metal Oxide AA
R3543 VRS-CY1JF562J J 5.6k 1/16W Metal Oxide AA
R3544 VRS-CY1JF104J J 100k 1/16W Metal Oxide AA
R3545 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R3546 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3547 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3550 VRS-TX2HF331J J 330 1/2W Metal Oxide AB
R3551 VRS-TX2HF331J J 330 1/2W Metal Oxide AB
R3552 VRS-CY1JF153J J 15k 1/16W Metal Oxide AA
R3553 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3600 VRS-CA1JF182JY J 1.8k 1/16W Metal Oxide AB
R3604 VRS-CA1JF824JY J 820k 1/16W Metal Oxide AB
R3606 VRS-CA1JF562J J 5.6k 1/16W Metal Oxide AA
R3607 VRS-CY1JF563J J 56k 1/16W Metal Oxide AA
R3700 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide AA
R3701 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3702 VRS-TW2ED102J J 1k 1/4W Metal Oxide AA
R3703 VRS-CY1JF274J J 270k 1/16W Metal Oxide AA
R3704 VRS-CY1JF133F J 13k 1/16W Metal Oxide AA
R3705 VRS-CY1JF184J J 180k 1/16W Metal Oxide AA
R3706 VRS-CY1JF100J J 10 1/16W Metal Oxide AA
R3707 VRS-CY1JF105J J 1M 1/16W Metal Oxide AA
R3708 VRS-CY1JF682J J 6.8k 1/16W Metal Oxide AA
R3710 VRS-CY1JF273F J 27k 1/16W Metal Oxide AA
R3716 VRS-TX2HF000J J 0 1/2W Metal Oxide AA
R3718 VRS-CR3AD821J J 820 1W Metal Oxide AC
R3721 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3722 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3724 VRS-CY1JF1R0J J 1 1/16W Metal Oxide AA
R3725 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3726 VRS-TQ2BD683J J 68k 1/8W Metal Oxide AA
R3727 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3728 VRS-CY1JF393J J 39k 1/16W Metal Oxide AA
R3729 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3730 VRS-CY1JF223J J 22k 1/16W Metal Oxide AA
R3731 VRS-CY1JF222J J 2.2k 1/16W Metal Oxide AA
R3732 VRS-CY1JF000J J 0 1/16W Metal Oxide AA
R3733 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3734 VRS-CY1JF103F J 10k 1/16W Metal Oxide AA
R3735 VRS-CY1JF183F J 18k 1/16W Metal Oxide AA
R3736 VRS-CY1JF183F J 18k 1/16W Metal Oxide AA
R3737 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R3738 VRS-CY1JF103F J 10k 1/16W Metal Oxide AA
R3739 VRS-CY1JF622F J 6.2k 1/16W Metal Oxide AA
R3740 VRS-CY1JF473F J 47k 1/16W Metal Oxide AA
R3741 VRS-CY1JF472F J 4.7k 1/16W Metal Oxide AA
R3742 VRS-CY1JF362F J 3.6k 1/16W Metal Oxide AA
R3743 VRS-CY1JF332F J 3.3k 1/16W Metal Oxide AA
R3744 VRS-CY1JF332F J 3.3k 1/16W Metal Oxide AA
R3745 VRS-CY1JF682F J 6.8k 1/16W Metal Oxide AA
R3746 VRS-CY1JF122F J 1.2k 1/16W Metal Oxide AA
R3747 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3748 VRS-CY1JF153J J 15k 1/16W Metal Oxide AA
R3749 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3750 VRS-CY1JF391J J 390 1/16W Metal Oxide AA
R3751 VRS-TV1JD103J J 10k 1/16W Metal Oxide AA
R3752 VRS-CY1JF102J J 1k 1/16W Metal Oxide AA
R3754 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R3761 VRS-CY1JF272J J 2.7k 1/16W Metal Oxide AA
R3762 VRS-TQ2BD122J J 1.2k 1/8W Metal Oxide AA
R3765 VRS-TW2ED000J J 0 1/4W Metal Oxide AB

Ref. No. Part No. ★ Description Code

R3767 VRS-TW2ED000J J 0 1/4W Metal Oxide AB

BALUNES

FB3301 RBLN-0006TAZZ J Balun, BLN-0006TA AB
FB3302 RBLN-0035TAZZ J Balun, BLN-0035TA AB
FB3700 RBLN-0095CEZZ J Balun, BLN-0095CE AD
FB3701 RBLN-0095CEZZ J Balun, BLN-0095CE AD
FB3704 RBLN-0051TAZZ J Balun, BLN-0051TA AC
FB3705 RBLN-0051TAZZ J Balun, BLN-0051TA AC
FB3706 RBLN-0051TAZZ J Balun, BLN-0051TA AC
FB3707 RBLN-0051TAZZ J Balun, BLN-0051TA AC
FB3708 RBLN-0051TAZZ J Balun, BLN-0051TA AC
FB3709 RBLN-0095CEZZ J Balun, BLN-0095CE AD

MISCELLANEOUS PARTS

QCNW-6053CEZZ J Connecting Cord AC

å FH3701 QFSHD1002CEZZ J Fuse Holder AA
å FH3702 QFSHD1002CEZZ J Fuse Holder AA
å FH3705 QFSHD1002CEZZ J Fuse Holder AA
å FH3706 QFSHD1002CEZZ J Fuse Holder AA
å F3701 QFS-C1622CEZZ J Fuse, 1.6A 250V AD
å F3703 QFS-C2023CEZZ J Fuse, 2A 250V AD

J3301 QJAKE0200CE09 J Jack AE
J3302 QJAKE0200CE02 J Jack AE
J3401 QJAKE0200CE04 J Jack AE
J3402 QJAKE0200CE09 J Jack AE
J3403 QJAKE0200CE02 J Jack AE
J3404 QJAKE0200CE05 J Jack AE
J3405 QJAKE0200CE06 J Jack AE
J3406 QJAKE0200CE02 J Jack AE
J3500 QJAKJ0046CEZZ J Jack AE
J3702 QJAKE0151CEZZ J Jack AE
P3402 QPLGZ1993GEZZ J Plug, 19Pin AE
P3500 QPLGN0174FJZZ J Plug, 2Pin AC
P3501 QPLGN0174FJZZ J Plug, 2Pin AC
P3600 QPLGN0155FJZZ J Plug, 3Pin AE
P3702 QPLGN0578GEZZ J Plug, 5Pin AB
SC3403 QSOCN0464FJZZ J Socket, 50Pin AH

DUNTKB002DE01

OPERATION PWB UNIT

DIODES

D4008 RH-EX0891CEZZ J Zener Diode AC
D4009 RH-EX0879CEZZ J Zener Diode AD
D4010 RH-EX0879CEZZ J Zener Diode AD

RESISTORS

R4005 VRS-CY1JF123J J 12k 1/16W Metal Oxide AA
R4006 VRS-CY1JF822J J 8.2k 1/16W Metal Oxide AA
R4011 VRS-CY1JF123J J 12k 1/16W Metal Oxide AA
R4012 VRS-CY1JF822J J 8.2k 1/16W Metal Oxide AA

SWITCHES

SW4002 QSW-K0108CEZZ J Switch, CH" AD
SW4003 QSW-K0108CEZZ J Switch, CH' AD
SW4004 QSW-K0108CEZZ J Switch, MENU AD
SW4006 QSW-K0108CEZZ J Switch, TV/VIDEO AD
SW4007 QSW-K0108CEZZ J Switch, VOL. (+) AD
SW4008 QSW-K0108CEZZ J Switch, VOL. (–) AD
S4701 QSW-P0035GEZZ J Switch AF

MISCELLANEOUS PART

P4004 QPLGN0564TAZZ J Plug, 5Pin AC

50

LC-13B2H/M

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

DUNTKB003DE01

JACK PWB UNIT

TRANSISTORS

Q5701 VSFZT1053A/-1 J FZT1053A AG
Q5702 VSFZT1053A/-1 J FZT1053A AG
Q5703 VS2SA1162Y/-1 J 2SA1162Y AB

COILS

L5701 RCiLC0107CEZZ J Coil, CiLC0107CE AF
L5702 RCiLC0107CEZZ J Coil, CiLC0107CE AF

TRANSFORMERS

å T5701 RTRNZ0777CEZZ J Transformer AM
å T5702 RTRNZ0777CEZZ J Transformer AM

CAPACITORS

C5701 RC-FZ0174CEZZ J 0.12 100V Mylar AG
C5702 RC-FZ0174CEZZ J 0.12 100V Mylar AG
C5703 VCKYCY1CB333K J 0.033 16V Ceramic AA
C5704 VCKYCY1CB333K J 0.033 16V Ceramic AA
C5707 VCEA4A1CN108M J 1000 16V Electrolytic AD

RESISTORS

R5701 VRS-TW2ED332J J 3.3k 1/4W Metal Oxide AB
R5702 VRS-TW2ED332J J 3.3k 1/4W Metal Oxide AB
R5703 VRS-CY1JF103J J 10k 1/16W Metal Oxide AA
R5704 VRS-CY1JF333J J 33k 1/16W Metal Oxide AA

MISCELLANEOUS PARTS

J5001 QJAKG0068CEZZ J Jack, 6Pin AG
P5701 QPLGN0155FJZZ J Plug, 3Pin AE
SC5001 QSOCD0456CEZZ J Socket, 6pin AE
SC5701 QSOCZ1994GEZZ J Socket, 19Pin AD

SUPPLIED ACCESSORIES

LHLDW0109CESA J Cable Clamp, x2 AD

å QACCB0016TAZZ J AC Cord(LC-13B2H) AV
å QACCK0002TAZZ J AC Cord(LC-13B2M) AM
å QACCL0020TAZZ J AC Cord(LC-13B2M X ) AP

QCNWG0008CEPZ J Antenna Cable AM
RRMCG1663CESA J Remote Control AV
SSAKA0160CEZZ J Operation Manual AB

Polyethylene Bag

TiNS-7507CEZZ J Operation Manual AU

(LC-13B2H)

TiNS-7508CEZZ J Operation Manual AT

(LC-13B2M/M X )

å UADP-0226CEPZ J AC Adaptor BE

PACKING PARTS

(NOT REPLACEMENT ITEM)

SPAKC5600CEZZ – Packing Case(LC-13B2H) —
SPAKC5661CEZZ – Packing Case —

(LC-13B2M/M X )
SPAKP0911CEZZ – Wrapping Paper —
SPAKX2957CEZZ – Buffer Material —
SSAKH0178CEZZ – Polyethylene Bag —
TLABK0001TAZZ – No. Label —

DUNTKB004DE01

R/C RECEIVER PWB UNIT

TRANSISTORS

Q4003 VSDTC144EE/-1 J DTC144EE AA
Q4004 VSDTC144EE/-1 J DTC144EE AA
Q4007 VSUMG4N++++-1Y J UMG4N++++ AB

DIODES AND LED’S

D4012 RH-EX0879CEZZ J Zener Diode AD
D4013 RH-EX0879CEZZ J Zener Diode AD
D4014 RH-PX0421CEZZ J PhotoDiode AD
D4015 RH-PX0421CEZZ J PhotoDiode AD
D4022 RH-EX0879CEZZ J Zener Diode AD

CAPACITOR

C4018 RC-KZ1025CEZZ J 1 10V Ceramic AB

RESISTORS

R4021 VRS-CY1JF101J J 100 1/16W Metal Oxide AA
R4023 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide AA
R4024 VRS-CY1JF471J J 470 1/16W Metal Oxide AA
R4029 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide AA
R4030 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide AA

MISCELLANEOUS PARTS

P4005 QPLGN0564TAZZ J Plug, 5Pin AC
RMC4002

RRMCU0239CEZZ J Remote Receiver AG

51

LC-13B2H/M

Ref. No. Part No. ★ Description Code

CABINET PARTS LIST

1 CCABA2429CE01 J Front Cabinet Ass’y BF
1-1
1-2 GCOVA2004CEZZ J Cover, R/C Receiver/LED AE
1-3 PSPAG0388CEZZ J Spacer, x4 AC
1-4 PSPAG0389CEZZ J Spacer, x4 AB
1-5 PSPAH0605CEZZ J Spacer, x2 AC
1-6 PSPAH0606CEZZ J Spacer, x2 AD
1-7 PSPAH0678CEZZ J Spacer, x2 AA
1-8 QEARZ0051CEZZ J Grounding Part AD
1-9 RSP-Z0131CEZZ J Speaker, Left AR
1-10 RSP-Z0132CEZZ J Speaker, Right AR
1-11 XETSD40P12000 J Screw, x8 AB
1-12 PSPAH0706CEZZ J Spacer, x4 AB
1-13 PSPAH0707CEZZ J Spacer, x4 AB
2 CCABB2316CE02 J Rear Cabinet Ass’y BA

2 CCABB2316CE04 J Rear Cabinet Ass’y BA
2-1

2-2 LANGT9024CEFW J Fixing Metal AL
2-4 HiNDP5861CESA J Model Indicator(LC-13B2H)AG
2-4 HiNDP5863CESA J Model Indicator AG

2-5 XEBSD30P08000 J Screw, x1 AA
3 CDAi-1124CE04 J Stand Ass’y BN
3-1
3-2 GCOVA1945CESA J Cover, Handle AK
3-3 GDAi-1121CESA J Stand, Joint AP
3-4 GDAi-3048CESB J Base, Joint AM
3-5 GLEGG9093CEZZ J Foot, x6 AC
3-6 JHNDP0105CESA J Stand Handle AW
3-7 LANGG0114CEFW J Fixing Metal, x2 AE
3-8 LX-BZ3441CEFN J Screw, x1 AD
3-9 MHNG-3038CEFW J Hinge, Left AV
3-10 MHNG-3039CEFW J Hinge, Right AP
3-11 MHNG-3033CEFW J Hinge, Side AX
3-12 XESSD40P14000 J Screw, x8 AB
3-13 XESSN40P10000 J Screw, x8 AB
3-14 XUSSD40P20000 J Screw, x4 AB
3-15 PSPAZ0415CEZZ J Spacer, x2 AB
3-16 PSPAT0079CEZZ J Spacer AC
4 CCOVA2053CE01 J Button Cover Ass’y AN
4-1
4-2 GCOVA1943CEKA J Button Cover, VOL AD
4-3 GCOVA1943CEKB J Button Cover, CH AD
4-4 JBTN-2072CEKA J Operation Button AE
4-5 XEBSD30P10000 J Screw, x2 AA

å 5 KLMP-0109CEZZ J Fluorescent Lamp AZ

6 LHLDW1025TAZZ J Wire Holder, x1 AB
7 PGiDM0064CEZZ J Light Guide Plate AX
8 PMiR-0287CEFW J Reflection Mirror(L) AG
9 PMiR-0288CEFW J Reflection Mirror(S) AF
10 PSHEP0244CEZZ J Diffusion Sheet, x2 AL
11 PSHEP0245CEZZ J Reflection/deflection Sheet BB
12 PSHEP0246CEZZ J Lamp Reflection Sheet-1 AG
13 PSHEP0247CEZZ J Lamp Reflection Sheet-2 AG
14 PSLDM4660CEFW J Shielding Plate AQ
15 PSPAG2003CEZZ J Spacer, Light Shielding AA
16 PSPAH0607CEZZ J Spacer, x2 AB
17 QCNW-5876CEZZ J Gate FFC AG
18 RLCDT0065CEZZ J LCD Unit CX
19 XBBSD30P05000 J Screw, x4 AA
20 GCOVA2043CEKA J Chassis Frame AM
21 GCOVA2003CEKA J Back Cover AL
22 JBTN-2066CEKA J Button, Power AD
24 QCNW-5908CEZZ J Main-Terminal AE
25 QCNW-5941CEZZ J Source FFC AE
26 QCNW-5973CEZZ J R/C-Main AH
27 QCNW-6007CEN1 J PW 5P 225mm AD
30 LX-BZ3442CEFF J Screw, x4 AB
31 XBBSF30P05000 J Screw, x1 AB
32 XBPSD30P03000 J Screw, x3(PWB-FRAME) AA

Not Available

Not Available

Not Available

Not Available

– Front Cabinet —

(LC-13B2H)
(LC-13B2M/M X )

– Rear Cabinet —

(LC-13B2M/M X )

– Stand, Base —

– Button Cover —

Ref. No. Part No. ★ Description Code

33 XBPSD30P10JS0 J Screw, x4 (Earth) AA
34 XEBSD30P08000 J Screw, x5 (Main Unit/LED) AA
35 XEBSD30P12000 J Screw, x6 (PNL) AA
36 XEBSF30P14000 J Screw, x8 (CAB-A/B) AA
37 PSPAG0408CEZZ J Spacer AB
38 PSPAH0705CEZZ J Spacer, x2 AB
39 TLABN0379CEZZ J No. Label(LC-13B2H) AG
39 TLABN0380CEZZ J No. Label(LC-13B2M) AG
39 TLABN0381CEZZ J No. Label(LC-13B2M X ) AG

52

LC-13B2H/M

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

CABINET AND MECHANICAL PARTS

J

4-1

4-2

4

I

1-11

1-10

1-13

4-3

4-4

4-5

35

H

1-12

1-12

1-13

G

F

1-1

34

22

OPERATION Unit

1-4

1-3

1-4

1-7

1-12

1-13

26

1-13

1-6

1-9

1-5

1-5

1-12

1-11

34

1-6

1-7

19

17

16

16

1-4

1-3

1-4

A

38

18

B

38

A

19

JACK Unit

33

MAIN Unit

32

20

27

33

E

D

1-8

1

1-2

13

7

37

12

R/C RECEIVER
Unit

A

9

6

14

35

25

8

TERMINAL Unit

24

32

15

34

33

B

5

C

8

9

A

B

10

A

11

12345678910

53

LC-13B2H/M

Ref. No. Part No. ★ Description Code

J

I

H

G

Ref. No. Part No. ★ Description Code

3-6

3-2

3

30

F

3-10

3-12

3-7

3-3

3-12

3-4

3-11

3-5

3-16

3-12

3-14

3-16

3-1

3-7

3-9

3-15

E

2

D

2-1

C

2-2

2-5

36

39

2-4

36

36

31

36

21

3-13

3-15

3-8

B

A

12345678910

54

LC-13B2H/M

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code

SSAKA0160CEZZ

(Operation Manual

Polyethylene Bag)

RRMCG1663CESA

(Remote Control)

PACKING OF THE SET

TiNS-7507CEZZ(LC-13B2H)
TiNS-7508CEZZ(LC-13B2M/M X )
(Operation Manual)
LHLDW0109CESA
(Cable Clamp) (2 pcs.)
★ Dry Battery (2 pcs.)

å

å

★ SPAKX2957CEZZ
(Buffer Material)
(Top)

QACCB0016TAZZ(LC-13B2H)
QACCK0002TAZZ(LC-13B2M)
QACCL0020TAZZ(LC-13B2M X )
(AC Cord)
UADP-0226CEPZ
(AC Adaptor)
QCNWG0008CEPZ
(Antenna Cable)

★ SSAKH0178CEZZ
(Polyethylene Bag)

★ TLABK0001TAZZ
(No. Label)

★ SPAKP0911CEZZ
(Wrapping Paper)

★ SPAKX2957CEZZ
(Buffer Material)
(Bottom)

★ SPAKC5600CEZZ(LC-13B2H)
SPAKC5661CEZZ(LC-13B2M/M X )
(Packing Case)

55

★ Not Replacement Item

LC-13B2H/M

Ref. No. Part No. ★ Description Code

Ref. No. Part No. ★ Description Code

COPYRIGHT © 2001 BY SHARP CORPORATION

ALL RIGHTS RESERVED.

No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.

D Japan P Japan TQ1220-S
Oct. 2001 Printed in JAPAN

NA. DS

SHARP CORPORATION
AV Systems Group
Quality & Reliability Control Center
Yaita, Tochigi 329-2193, Japan

56
