The air purier draws in room air from its air intake, lets the air pass through
an Active Carbon Filter (deodorization lter) and a HEPA Filter (dust collection lter) inside of the unit, then discharges the air from its air outlet. The
air purier unit repeats this process by moving its internal fan.
As air passes through the HEPA lter if removes 99.97% of dust particles (as
small as 0.3 microns.). The Active Carbon Filter gradually absorbs odour elements as they repeatedly pass through the lter.
Some odour ingredients absorbed by the lters may become separated and
may be discharged through the air outlet and result in additional odour. Depending on the usage environment, especially when the product is used in
a condition signicantly more severe than household use, this odour may
become strong in a shorter period than expected.
If the odour persist the lters should be replaced.
Please purchase the optional replacement lter.
NOTE
• The air purier is designed to remove air-suspended dust and odour, but not harmful gases (for
example, carbon monoxide contained in cigarette smoke.) If the odour sources still exist, it cannot
completely remove the odour. (for example, odours from construction materials and pet odours.)
• It is suggested to open the window a bit when you are smoking in order to facilitate ventilation.
ENGLISH
FEATURES
"Plasmacluster" technology
Plasmacluster technology uses plasma discharge to produce and release
the same positive and negative ions
as those found in nature ("Plasma-
cluster ions").
This is a unique air cleaning technology of the SHARP CORPORATION
for breaking down and eliminating
such potential allergens as the fecal
matter or corpses of aerial mites*1,
viruses *2 and mold and bacteria *3
suspended in the air, and has been
substantiated by third-party organiza-
tions both in Japan and overseas.
When there is a high density of Plasmacluster ions in the air, the smell of
cigarette smoke trapped in curtains
or so fas is eliminated in about 80
minutes, and when clothing is hung in
a place exposed to the direct air expelled from the unit generating Plasmacluster ions, the smell of sweat is
reduced to a virtually imperceptible
level in one night (about 6 hours).
Thank you for purchasing the SHARP Air Purier. Please read this manual carefully for the
correct usage information. Before using this
product, be sure to read the section: “Important
Safety Instructions.”
After reading this manual, retain it in a conven-
ient location for future reference.
E-1
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING
• Read all instructions before using the unit.
• Use only a 220-240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet
is loosened.
Periodically remove dust from the power plug.
•
• Do not insert ngers or foreign objects into the intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
Electrical shock and/or re from short circuit may occur as a result.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or replaces.
• Remove the power plug from the wall outlet before cleaning the unit and when not using the
unit.
Electrical shock from bad insulation and/or re from short circuit may occur as a result.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent,
Sharp authorized Service Centre or similarly qualied person in order to avoid a hazard.
Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,
•
sparks from lit cigarettes, chemical fumes in the air or in very high humidity condition, such as a
bathroom.
Be cautious when cleaning the unit. Strong corrosive cleansers may damage the exterior.
•
Only Sharp Authorized Service Centre should service this air purier. Contact the nearest Service
•
Centre for any problems, adjustments, or repairs.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the appliance.
- To reduce the risk of electrical shock, re or injury to persons:
NOTE
If this air purier should cause interference to radio or television reception, try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation distance between the unit and radio/TV receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV technician for help.
- Radio or TV Interference
E-2
IMPORTANT SAFETY INSTRUCTIONS
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may come into
contact with steam.
• Do not lay the unit down when using.
• Always hold the handle on the back of the unit when moving it.
Holding the front panel when carrying may cause it to detach, thus dropping the unit and resulting
in bodily injury.
• Do not operate the unit without the lter.
• Do not wash and reuse HEPA lter .
It not only does not improve lter performance, it may cause electric shock or malfunction.
• Clean the exterior with a soft cloth only.
The unit surface may be damaged or cracked.
In addition, the sensors may malfunction as a result.
INSTALLATION GUIDELINES
• During the operation of the product, please place the unit at least 2 m away from equipment
which are subject to electrical waves such as televisions, radios or wave clocks.
• Avoid a location where the sensor is exposed to direct wind.
The unit may not operate properly.
• Avoid locations where curtains, etc., come into contact with the intake or air outlet.
Curtains, etc., may become dirty or a malfunction may occur.
• Avoid locations where the unit is exposed to condensation, due to drastic temperature
changes.
(Use under appropriate conditions between 0 and 35˚C in the room.)
• Place on a stable surface with sufcient air circulation.
When placing the unit on a heavily carpeted area, it may cause the unit to vibrate slightly.
• Do not install when there is generation of lampblack, such as in a kitchen, etc.
The unit surface may crack or the sensor may malfunction as a result.
• Leave about 60cm of space from the wall.
The wall behind the air outlet may become dirty as time passes. When using the unit for extended
period of time in the same location, use a vinyl sheet, etc., to prevent the wall from becoming dirty.
In addition, periodically clean the wall.
ENGLISH
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the lters.
E-3
Odour SensorDate Label
Main Unit
HEPA Filter
Filter Support
Front Panel
Washable Active
Carbon Filter
PART NAMES
Fan Speed Indicator Lights
Filter Reset Indicator Light
Plasmacluster
ON/OFF Indicator Light
Plasmacluster Ion ON/OFF
Button
Fan Speed Button
ION SHOWER Indicator Light
ION SHOWER Mode Button
Light Control Button
MAIN UNIT DISPLAY
ILLUSTRATIVE DIAGRAM
E-4
Green
CleanSlightly ImpureVery Impure
YellowRed
Air Outlet
Air Inlet
Rating Label
Power Cord
Plug
Handle
Dust Sensor
(FU-W53E only)
Blue : Plasmacluster ON
Plasmacluster Indicator Light(Blue)
CLEAN - SIGN Light
POWER ON/OFF
Button
Light Control Button
Light off : Plasmacluster OFF
The colour changes according to
the air condition.
BACK
ABOUT THE CLEAN-SIGN
• The condition of the CLEAN-SIGN depends on the room air condition detect
ed by the Dust and Odour Sensors when the plug is inserted into the wall outlet.
• It is possible to have a green CLEAN-SIGN with impurities in the air at the time
that the air purier was just introduced to the room environment. After a while,
however, the base impurity rate will be adjusted to detect room air condition
correctly.
INCLUDED
• Operation manual
-
ENGLISH
ENGLISH
(Shape of plug depends on country.)
E-5
PREPARATION
1
FILTER INSTALLATION
To maintain the quality of the lters, they are installed in the main unit and packed in
plastic bags. Be sure to remove the lters from the plastic bags before using the unit.
Be sure to remove the power plug from the wall outlet.
Remove the lters
Remove the Front Panel.
1
Pull the Front Panel on the
lower sides, and lift up.
Remove the Filter Support.
2
Push in the hooks on top, then pull the Filter Support.
Front Panel
Filter Support
Remove the Washabe Active Carbon Filter (Black) and
3
HEPA Filter (White) from the plastic bags.
HEPA Filter
Active Carbon Filter
E-6
Tab
(blue)
2
Install the lters
Place the HEPA Filter into the
1
main unit.
Please make sure that the HEPA
Filter(blue) and the tab is placed
in proper direction.
Do not install the lter backwards or the
unit will not operate properly.
Insert the Filter Support’s 2 bottom
2
tabs (left and right) into the small
holes in the unit, and slide the Active
Carbon Filter between the HEPA Filter
and the Filter Support.
Gently push in the upper tabs (left and
3
right) to lock in place.
Fill in the usage start date on the Date
4
Label.
Use the date as a guide for the Filter Replacement schedule.
HEPA Filter
ENGLISH
Active Carbon Filter
Filter Support
Bottom tabs
Upper tabs
Date Label
Replace the Front Panel.
5
Place the Front Panel from the obliquely upward, then mount the hooks at the bottom.
Front Panel
E-7
OPERATION
Plasmacluster Indicator Light
CLEAN - SIGN Light
Plasmacluster
ON/OFF Button
FAN SPEED Button
ION SHOWER Mode Button
POWER ON/OFF Button
LIGHT CONTROL Button
FAN Speed Indicator Lights
MAIN UNIT OPERATION
Power ON/OFF Button
• Used to start operation (short beep) and
stop operation (long beep)
• Plas mac luster Ind ica tor Light and Fa n
Speed Indicator Light turn on/off.
• Unless the power cord is unplugged, the operation will start in the previous mode.
• When stopping the operation in ION SHOWER mode, the unit will return to the prior
ION SHOWER mode.
FAN SPEED Button
• The operation mode can be switched as below.
AUTO operation
The fan speed is automatically switched
(MEDI UM, LOW) dependi ng on the
amount of impurities in the air. The sensors detect the impurities for efficient
air purication.
POLLEN mode operation
The unit wil l op erat e at HI GH* fan
speed for 10 minutes, then will alternate between MEDIUM and HIGH* for
20 minutes.
10 minutes: HIGH fan speed
20 minutes:
20 minutes: HIGH fan speed
SILENT operation
The unit will operate quietly
using minimal air intake.
MEDIUM operation
The unit will operate at a fan
speed of MEDIUM.
MAX operation
The unit will operate at a fan
speed of MAX.
MEDIUM fan speed
ION SHOWER Mode Button
When pushing the ION SHOWER Mode button, the ION SHOWER operation will be activated. (Direct start is available even when the unit is
not turned on.)
By continuously discharging strong airow for 15 minutes the unit effectively removes airborne dust, pollen, mold and allergens from the air as they are drawn
through the lter system.
•When the operation nishes, the unit will return to the prior operation.
* HIGH fan speed is an inter
mediate speed between MEDIUM and MAX.
* LOW fan speed is an interme-
diate speed between SILENT
and MEDIUM.
-
E-8
Plasmacluster ON/OFF Button
Plasmacluster Indicator Light
CLEAN - SIGN Light
ION SHOWER Mode Button
POWER ON/OFF Button
LIGHT CONTROL Button
The lights are brighter.
The lights are darker.
The lights turn off
「 」
「 」
「 」
CAUTION
Press the Plasmacluster ON/OFF Button to turn Plasmacluster Ion
Mode ON and OFF.
When Plasmacluster is ON, both the Indicator Light and Plasmaclus-
ter Indicator will turn on.
ENGLISH
LIGHTS CONTROL Button
Use w h e n the t h e Pla s m a clust e r
Indicator Light and CLEAN-SIGN Light
are too bright.
Refer to the diagram on the righ t t o
select the d esi red br igh tne ss of the
Plasmaclu s t e r I n dicator Li g h t a n d
CLEAN-SIGN Light.
The lights on the front monitor are always brighter when starting.
ADJUSTMENT OF SENSOR DETECTION SENSITIVITY
Set to “low” if CLEAN-SIGN Light is constantly red to reduce sensitivity, and set to
“high” if CLEAN-SIGN Light is constantly green to increase sensitivity.
With the unit OFF, press the Fan Speed Button for 3 seconds.
1
The Fan Speed Indicator Lights will display the currently set sensor sensitivity level. The
factory setting is Standard, indicated by the MED light.
Press the Fan Speed Button to set
2
the desired sensor sensitivity.
Refer to the diagram on the right to select the
desired sensor sensitivity level.
Press the Power ON/OFF Button.
3
Note that if the Power ON/OFF Button is not pushed within 8 seconds of adjusting sensor sensitivity, the set-
ting will be saved automatically. The sensor sensitivity setting will be saved even if the unit is unplugged
E-9
Fan Speed
Indicator Light
Sensor Detection
sensitivity
High
Standard
Low
.
CARE AND MAINTENANCE
Care Cycle
1 month
Care Cycle
2 months
Care Cycle
2 months
To maintain optimum performance of this air purier, please clean the unit including the sensor and lters periodically. When cleaning the unit, be sure to unplug the power cord, and never handle the plug with wet hands. Electrical shock and/or bodily injury may occur as a result.
FILTER RESET INDICATOR LIGHT
The Filter RESET Indicator Light will illuminate as a reminder to perform maintenance of the Filters and Sensors.The Indicator Light will turn on after approximately
720 hours of use.
After performing maintenance, reset the Filter Reset Indicator. Plug the unit in, turn
power ON, and press the Plasmacluster Ion ON/OFF Button for 3 seconds. The Filter Indicator Light will go off. Even if the Filter Indicator Light is already off, the Plasmacluster Ion ON/OFF Button should be pressed to reset the maintenance timer.
MAIN UNIT
To prevent dirt or stains on the main unit, clean as often as necessary. If stains are allowed to
remain, they may become hard to clean.
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
Do not use volatile uids
Benzene, paint thinner, polishing powder, etc., may damage the surface.
Do not use detergents
Detergent ingredients may damage the unit.
Keep the unit away from water
FILTER
Clean the top surface of the Washable Active
Carbon Filter lightly with a vacuum cleaner.
SENSORS
Remove dust from the surface of the hole of the
sensors using a vacuum cleaner.
Sensor Cover
Hde of Dust Sensor
(DUST SENSOR, ODOUR SENSOR)
Hole of Odour Sensor
<FU-W53E only>
Wa shabl e Act ive
Carbon Filter
SENSOR FILTER CARE
<FU-W53E only>
Detach the sensor lter and tap
it lightly with your hand to re-
move the dust.
If it is very dirty, wash it with water and then allow it to dry thoroughly.
Sensor Cover
Sensor Filter
It d oe s no t have a
front and a back.
E-10
WASHABLE ACTIVE CARBON FILTER CARE
Care Cycle
2 months
CAUTION
CAUTION
HAND WASH ONLY!
DO NOT TUMBLE DRY!
HEPA Filter
Washable Active
Carbon Filter
Rinse dirt from the WASHABLE ACTIVE CARBON
1
FILTER under lukewarm water.
Remove dust on the washable active carbon lter before washing.
ENGLISH
• When washing the lter for the rst time, the rinse water may be
brown. This does not affect deodorization performance.
• Avoid bending or folding the lter when washing.
Drip dry lter to remove excess water.
2
Dry filter completely in a well ventilated area. If
3
possible, dry outdoors.
Dry lter in a sideways position to avoid warping of the lter.
The lter takes about 6 hours to dry out.
• Avoid drying lter outdoors during inclement weather (e.g. rain or cold
temperatures).
• Do not allow lter to freeze.
• If lter is dried indoors, take precautions, such as placing towels, etc
under the lter to prevent water damage to the oor.
Replace the lter in unit. (See E-6).
4
Dry lter completely before replacing to prevent odours.
Do not operate unit without all lters properly installed.
E-11
CARE AND MAINTENANCE
FILTER REPLACEMENT GUIDELINES
The replacement period differs depending on the room environment, the usage hours
and location of the Air Purier.
If dust or odour persist, replace the lters.
(Refer to “Please read before operating your new Air Purier”)
HEPA Filter / Washable Active Carbon Filter
Up to 5 years after opening
Guide for lter replacement timing
• Filter life can be greatly reduced in a poor environment.
The presence of cigarette smoke, pet dander and other concentrations of airborne particles
will cause lters to become clogged in less time. Please check lters regularly and replace
as needed.
Replacement Filters
REPLACING THE FILTERS
1. See page E-6,7 for directions on how to install the lters when replacing.
2. Fill in the usage start date of the lters on the Date Label
Disposal of Filters
Please dispose of replaced lters according to the local disposal laws and regulations.
HEPA Filter Materials:
• Filter: Polypropylene • Frame: Polyester
Active Carbon Filter Materials:
Model • HEPA Filter : 1 unit
FZ-W53SEF • Washable Active Carbon Filter : 1 unit
.
E-12
TROUBLESHOOTING
Before calling for repair, please review the list below, since the problem may not be a unit malfunction.
SYMPTOM
Odours and smoke are not
removed.
The CLEAN-SIGN Light lights
green even when the air is impure.
The CLEAN-SIGN Light lights
yellow or red even when the air
is clean.
A clicking or ticking sound is
heard from the unit.
The discharged air has an aroma
or odour.
The unit does not operate when
cigarette smoke is in the air.
REMEDY (not a malfunction)
• Clean or replace the lters if they appear to be heavily soiled.
(Refer to E-11, E-12)
• The air could be impure at the time the unit was plugged in. (Refer
to E-5) Pull out the plug from the electrical outlet, and insert the
plug one minute later
• The sensitivity of the sensors become unstable when the opening of the odour sensor or dust sensor is dirty or is clogged.
Clean the dust around the sensor opening using a vacuum
cleaner. (Refer to E-10)
• Clicking or ticking sounds may be audible when the unit is gen
erating ions.
• Check to see if the lters are heavily soiled.
Replace the lters.
• Plasmacluster Air Purifiers emit small traces of ozone which
may produce an odour. These ozone emissions are well below
safety levels .
• Is the unit installed in a location that is difcult for the sensor to
detect cigarette smoke?
• Are the dust or odour sensor openings blocked or clogged?
(In this case, clean the openings.) (Refer to E-10)
.
-
ENGLISH
Th e Pla smacluster Ind icator
Light or the CLEAN-SIGN Light
will not activate.
ERROR DISPLAY
LAMP INDICATIONREMEDY
The “Silent” Fan Speed Indica-
tor Light blinks.
• Check to see if the Lights OFF Mode is selected. If so, then
press the Light Control Button to activate the indicator lights.
(Refer to E-9)
Fan motor disconnected or abnormal.
Operation stops.
• Pressing the POWER ON/OFF button will reset the error dis
play, but if error occurs again, contact the Sharp Service Cen-
Bydisposingof thisproduct correctlyyouwillhelpensure that thewaste undergoesthe necessarytreatment, recoveryandrecycling andthus preventpotential negativeeffectsonthe environmentandhumanhealthwhichcouldotherwisearise due toinappropriatewastehandling.
2.InotherCountriesoutsidetheEU
Ifyouwishto discard this product,please contactyourlocalauthoritiesand askforthecorrectmethodof disposal.
ForSwitzerland: Used electricalor electronicequipmentcanbereturned freeofcharge to the dealer,evenifyou don’t purchasea new product. Further collectionfacilitiesarelisted on thehomepageof
Please contactyour SHARP dealerwhowill informyouaboutthetake-back of theproduct.Youmight be charged for thecostsarising fromtake-back andrecycling.Smallproducts(andsmallamounts)mightbetakenbackbyyourlocalcollectionfacilities.
ForSpain:Pleasecontacttheestablishedcollectionsystemoryourlocalauthorityfortake-backofyour used products.
Attention:Your product ismarkedwith thissymbol. Itmeans that usedelectricalandelectronicproductsshould not be mixedwithgeneral householdwaste.There is a separatecollectionsystem for theseproducts.
EN
Model
Power supply
Fan
Speed
Operation
High density Plasmacluster ion applicable oor surface
Fan Speed Adjustment
Rated Power
Fan Speed
Recommended Room Size
Cord Length
Dimensions
Weight
Model
Power supply
Fan
Speed
Operation
Fan Speed Adjustment
Rated Power
Fan Speed
Recommended Room Size
High density Plasmacluster ion applicable oor surface
Cord Length
Dimensions
MAX
42W
318m3/hour
MAX
27W
258m3/hour
Weight
FU-W53E
220-240V 50/60Hz
MED
15W
204m3/hour
2 *2
~40m
2 *3
~20m
3.5W(3.2W)
36m3/hour
2.0m
338mm(W)x207mm(D)x620mm(H)
6.1kg
FU-W43E
220-240V 50/60Hz
MED
15W
180m3/hour
2 *2
~32m
2 *3
~15m
3.5W(3.2W)
36m3/hour
2.0m
314mm(W)x207mm(D)x620mm(H)
6.0kg
SILENT
*1
SILENT
*1
Numbers in parentheses indicate the power consumption when the Plasmacluster indicator light and the
*1
CLEAN-SIGN light are off.
The applicable oor surface area is appropriate for operating the unit of maximum fan speed.
*2
•Applicable oor surface area indicates the space where a certain amount of dust particles can be
removed in 30 minutes.(JEM1467)
*3
Size of a room in which approximately 7000 ions can be measured per cubic centimeter in the
center of the room (at a height of approximately 1.2 meters from the oor) when the product is
placed next to a window and run at the MAX operation position.
Standby Power
In order to operate the electrical circuits while the power plug is inserted in the
wall outlet, this product consumes about 0.8W of standby power.
For energy conservation, unplug the power cord when the unit is not in use.
E-14
A. Information on Disposal for Users (private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use the ordinary dust
bin!
Used electrical and electronic equipment must be treated separately and in
accordance with legislation that requires proper treatment, recovery and recycling of
used electrical and electronic equipment.
Following the implementation by member states, private households within the EU
states may return their used electrical and electronic equipment to designated
collection facilities free of charge*. In some countries* your local retailer may also
take back your old product free of charge if you purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accumulators, please
dispose of these separately beforehand according to local requirements.
By disposing of this product correctly you will help ensure that the waste undergoes
the necessary treatment, recovery and recycling and thus prevent potential negative
effects on the environment and human health which could otherwise arise due to
inappropriate waste handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities and ask for the
correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be returned free of
charge to the dealer, even if you don’t purchase a new product. Further collection
facilities are listed on the homepage of
www.swico.ch or www.sens.ch.
B. Information on Disposal for Business Users.
1. In the European Union
If the product is used for business purposes and you want to discard it:
Please contact your SHARP dealer who will inform you about the take-back of the
product. You might be charged for the costs arising from take-back and recycling.
Small products (and small amounts) might be taken back by your local collection
facilities.
For Spain: Please contact the established collection system or your local authority for
take-back of your used products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local authorities and ask for
the correct method of disposal.
Attention: Your product is
marked with this symbol. It
means that used electrical
and electronic products
should not be mixed with
general household waste.
There is a separate
collection system for these
products.
EN
ENGLISH
Memo
ENGLISH
TINS-A303KKRZ
CN
Printed in China
08L
SHARP CORPORATION
OSAKA, JAPAN
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
