Sharp AR-5420 User Manual

AR-5420

RUS

Shielded interface cables must be used with this equipment to maintain compliance with EMC regulations.

Do not make copies of anything which is prohibited from copying by law. The following items are normally prohibited from copying by national law. Other items may be prohibited by local law.

Money Stamps Bonds Stocks Bank drafts Checks Passports Driver's licenses

In some areas, the "POWER" switch positions are marked "I" and "O" on the copier instead of "ON" and "OFF". The symbol "O" denotes the copier is not completely de-energized but in a standby condition at this "POWER" switch position. If your copier is so marked, please read "I" for "ON" and "O" for "OFF".

Caution! For a complete electrical disconnection, pull out the main plug. The socket-outlet shall be installed near the equipment and shall be easily accessible.

A. Information on Disposal for Users (private households)

1. In the European Union

Attention: If you want to dispose of this equipment, please do not use the ordinary dust bin! Used electrical and electronic equipment must be treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment. Following the implementation by member states, private households within the EU states may return their used electrical and electronic equipment to designated collection facilities free of charge*. In some countries* your local retailer may also take back your old product free of charge if you purchase a similar new one.

*) Please contact your local authority for further details.

Attention: Your product is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collection system for these products.

If your used electrical or electronic equipment has batteries or accumulators, please dispose of these separately beforehand according to local requirements. By disposing of this product correctly you will help ensure that the waste undergoes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health which could otherwise arise due to inappropriate waste handling.

2. In other Countries outside the EU

If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal. For Switzerland: Used electrical or electronic equipment can be returned free of charge to the dealer, even if you don’t purchase a new product. Further collection facilities are listed on the homepage of

www.swico.ch or www.sens.ch.

. Information on Disposal for Business Users.

1. In the European Union

If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities. For Spain: Please contact the established collection system or your local authority for take-back of your used products.

2. In other Countries outside the EU

If you wish to discard of this product, please contact your local authorities and ask for the correct method of disposal.

CAUTIONS

Cautions on using

Follow the cautions below when using this unit.

Warning:

• The fusing area is hot. Exercise care in this area when removing misfed paper.

• Do not look directly at the light source. Doing so may damage your eyes.

• Do not switch the unit rapidly on and off. After turning the unit off, wait 10 to 15 seconds before turning it back on.

• Unit power must be turned off before installing any supplies.

Caution:

• Place the unit on a firm, level surface.

• Do not install the unit in a humid or dusty location.

• When the unit is not used for a long time, for example for consecutive holidays, turn the power switch off and remove the power cord from the outlet.

• When moving the unit, be sure to turn the power switch off and remove the power cord from the outlet.

• Do not cover the unit with a dust cover, cloth or plastic film while the power is on. Doing so may prevent heat radiation, damaging the unit.

• Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

• The socket-outlet shall be installed near the equipment and shall be easily accessible.

Important points when selecting an installation site

Do not install your unit in areas that are:

• damp, humid, or very dusty

• exposed to direct sunlight

• poorly ventilated

• subject to extreme temperature or humidity changes, e.g., near an air conditioner or heater.

Be sure to connect the power cord only to a power outlet that meets the specified voltage and current requirements. Also make certain the outlet is properly grounded.

Connect the unit to a power outlet which is not used for other electric appliances. If a lighting fixture is connected to the same outlet, the light may flicker.

Be sure to allow the required space around the machine for servicing and proper ventilation.

10 cm

20 cm

10 cm

Cautions on handling

Be careful in handling the unit as follows to maintain the performance of this unit.

Do not drop the unit, subject it to shock or strike it against any object. Store spare toner cartridges in a cool dry place without removing from the

package before use.

• If they are exposed to direct sunlight or excessive heat, poor copies may result.

Do not touch the photoconductive drum (green portion).

• Scratches or smudges on the drum will cause dirty copies.

Proper storage for supplies

Store the supplies (paper and toner cartridges) in a location that is:

• clean and dry

• at a stable temperature

• not exposed to direct sunlight.

Store paper in the wrapper and lying flat.

• Paper stored out of the wrapper or in packages standing on end may curl or get damp, resulting in paper misfeeds.

Trademark acknowledgements

• Microsoft and Windows are trademarks of Microsoft Corporation in the U.S.A. and other countries.

• IBM and PC/AT are trademarks of International Business Machines Corporation.

• Adobe and Acrobat are trademarks of Adobe Systems Incorporated.

• All other trademarks and copyrights are the property of their respective owners.

Products that have earned the ENERGY STAR® are designed to protect the environment through superior energy efficiency.

Laser information

Wave length 780 nm +10 nm

Pulse times (North America) 12.88 µs ±12.88 ns/7 mm Output power Max 0.2 mW (Total Power)

At the production line, the output power of the scanner unit is adjusted to 1.2 MILLIWATT (Total Power) PLUS 5% and is maintained constant by the operation of the Automatic Power Control (APC).

Caution

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

This Digital Equipment is CLASS 1 LASER PRODUCT (IEC 60825-1 Edition 1.2-2001)

A small amount of ozone is produced within the unit during operation. The emission level is insufficient to cause any health hazard.

Note:

The present recommended long term exposure limit for ozone is 0.1 ppm (0.2 mg/m However, since the small amount that is emitted may have an objectionable odor, it is advisable to place the unit in a ventilated area.

-15 nm

) calculated as an 8 hr. time-weighted average concentration.

(Four laser diodes)

CONTENTS

1 INTRODUCTION

USING THE MANUAL ................... 4

PART NAMES ............................... 5

OPERATION PANEL..................... 6

2 LOADING PAPER

PAPER........................................... 7

LOADING THE PAPER TRAY....... 8

BYPASS FEED (including special

paper) .......................................... 10

3 MAKING COPIES

COPY FLOW ...............................12

CONNECTING THE POWER CORD 13

ORIGINAL PLACEMENT............. 15

SET THE COPY QUANTITY ....... 16

EXPOSURE ADJUSTMENT/

PHOTO COPYING ......................16

REDUCTION/ENLARGEMENT/

ZOOM ..........................................18

SELECTING THE PAPER TRAY 18

4 SPECIAL FUNCTIONS

DESCRIPTION OF SPECIAL

FUNCTIONS................................ 19

TONER SAVE MODE..................19

USER PROGRAMS.....................20

DISPLAYING TOTAL NUMBER OF

COPIES .......................................21

5 MAINTENANCE

TONER CARTRIDGE

REPLACEMENT ..........................22

TONER CARTRIDGE LIFE..........24

CLEANING THE UNIT .................25

TROUBLESHOOTING THE UNIT

TROUBLESHOOTING.................27

STATUS INDICATORS................28

MISFEED REMOVAL ..................29

DEVELOPER REQUIRED ...........32

MAINTENANCE REQUIRED.......32

SCAN HEAD LOCKING SWITCH ......32

7 APPENDIX

SPECIFICATIONS .......................33

ABOUT SUPPLIES............................. 34

INDEX.................................................35

1 2 3 4 5 6 7

This chapter provides basic information for using the unit.

INTRODUCTION

USING THE MANUAL

The operation manual contains explanations of how to operate the unit, important considerations, and maintenance procedures. To get the most out of the unit, please read the operation manual. Please keep the operation manuals in a suitable location that will allow for convenient future reference.

Conventions used in the manual

In this manual, the following icons are used to provide the user with information pertinent to the use of the unit.

Warns the user that injury may result if the contents of the warning are not properly followed.

Cautions the user that damage to the unit or one of its components may result if the contents of the caution are not properly followed.

Notes provide information relevant to the unit regarding specifications, functions, performance, operation and such, that may be useful to the user.

Indicates a letter displayed in the display.

PART NAMES

1 2

3 4

Multi-bypass tray

Toner cartridge

Original cover

8 9

10 11

14 15

Photoconductive drum

Original table

Operation panel

Front cover

Paper tray

Bypass paper guides

Side cover

Side cover open button

Paper output tray

Paper output tray extension

Power switch

Handle

Power cord socket

Fusing unit release lever

Transfer charger

Charger cleaner

OPERATION PANEL

141

86 70

Exposure mode selector key and

indicators

Use to sequentially select the exposure modes: AUTO, MANUAL or PHOTO. Selected mode is shown by a lit indicator. (p.16)

Light and dark keys and indicators

Use to adjust the MANUAL or PHOTO exposure level. Selected exposure level is shown by a lit indicator. (p.16) Use to start and terminate user program setting. (p.20)

Alarm indicators

5 6

Developer replacement required indicator (p.32)

Misfeed indicator (p.29)

Toner cartridge replacement required indicator (p.22)

Maintenance indicator (p.32)

Copy ratio selector key and indicators

Use to sequentially select preset reduction/enlargement copy ratios. Selected copy ratio is shown by a lit indicator. (p.18)

Copy ratio display (%) key (p.18) Display

Displays the specified copy quantity, zoom copy ratio, user program code, and error code.

Start key and indicator

• Copying is possible when the indicator is on.

• Press to start copying.

• Use to set a user program. (p.20)

Power save indicator

Lights up when the unit is in a power save mode. (p.19, p.20)

Tray select key

Use to select a paper feed station (paper tray or multi-bypass tray). (p.10)

Paper feed location indicators

1210

Light up to show the selected paper feed station.

ZOOM keys and indicator

1311

Use to select any reduction or enlargement copy ratio from 25% to 400% in 1% increments. (p.18)

Copy quantity keys

1412

• Use to select the desired copy quantity (1 to 99). (p.16)

• Use to make user program entries. (p.20)

Clear key

• Press to clear the display, or press during a copy run to terminate copying. (p.16)

• Press and hold down during standby to display the total number of copies made to date. (p.21)

.Follow the steps below to load paper into the tray.

LOADING PAPER

PAP ER

For best results, use only paper recommended by SHARP.

Type of paper

feeding

Paper tray Standard paper A4

Multi-bypass tray

* Do not use non-standard envelopes, and envelopes that have metal clasps, plastic

snappers, string closures, windows, linings, self-adhesive, patches or synthetic materials. Do not use envelopes that are filled with air or envelopes that have labels or stamps attached. These will cause physical damage to the unit.

** For paper weighing from 105g/m

fed through the multi-bypass tray.

• Special papers such as transparency film, labels and envelope must be fed one sheet at a time through the multi-bypass tray.

Type of media Size Weight

56g/m

Standard paper and thick paper

Special media

Transparency film

Envelope* International DL

A5 B5 Letter Legal Invoice

A4 A5 A6 B5 B6 Letter** Legal Invoice

A4 Letter

International C5 Commercial 10 Monarch

to 128g/m2, A4 is the maximum size that can be

80g/m

56g/m 128g/m2**

2 2

LOADING THE PAPER TRAY

Raise the handle of the paper tray

and pull the paper tray out until it stops.

Adjust the paper guides on the paper tray to the copy paper

width and length. Squeeze the lever of paper guide and slide the guide to match with the width of the paper. Move paper guide to the appropriate slot as marked on the tray.

Paper guide B

Fan the paper and insert it into the tray. Make sure the edges go

under the corner hooks.

Do not load paper above the maximum height line ( ). Exceeding the line will cause a paper misfeed.

Paper guide A

Gently push the paper tray back into the unit.

• After loading paper, to cancel the blinking without restarting copying, press the clear ( ) key. The in the display will go out and the start ( ) indicator will light up. Be sure that paper is free of rips, dust, wrinkles, and curled or bent edges.

•

• Make sure all the paper in the stack is the same size and type.

• When loading paper, ensure there is no space between the paper and

the guide, and check if the guide is not set too narrow causing the paper to bend. Loading paper in these ways will result in document skew or a paper jam.

• When not using the unit for an extended period, remove all paper from the paper tray and store it in a dry place. If paper is left in the unit for an extended period, the paper will absorb moisture from the air, resulting in paper jams. When adding new paper to the paper tray, remove the old paper already

•

contained in the tray. Placing new paper on top of the paper already contained in the tray may result in feeding two sheets at one time.

BYPASS FEED (including special paper)

The multi-bypass tray can be used to feed standard paper, transparency film, labels, envelopes, and other special purpose paper. Paper measuring from A6 to A4 and in the weight range of 56g/m from 105g/m2 to 128g/m2), A4 is the maximum size.)

• The multi-bypass tray can hold maximum of 50 sheets of paper.

(Capacity will vary depending on the type of paper loaded.)

• The original image must be smaller than the paper or media for copying. If the original image is bigger than the paper or media, this may cause smudges on the edges of the copies.

The multi-bypass tray

Open the multi-bypass tray and extend the tray.

to 128g/m2 can be used in this tray. (For paper weighing

To close the multi-bypass tray, perform step and then step

in the illustration and push the round projections at the right

of the tray until they click.

Set the paper guides to the paper width. Insert the paper (print

face down) all the way into the multi-bypass tray.

Print face

• Paper must be fed narrow side into the feed slot. Special papers such as transparency film, labels, and envelopes

•

must be fed one sheet at a time through the multi-bypass tray.

• When copying onto transparency film, remove each copy promptly. Do not let copies stack up. When loading an envelope, make sure that it is straight and flat.

Press the tray select ( ) key to select the multi-bypass tray.

Note for loading envelopes

• Envelopes must be fed narrow side into the feed slot at a time.

• Do not use non-standard envelopes, and envelopes that have metal clasps, plastic snappers, string closures, windows, linings, self-adhesive, patches or synthetic materials. Do not use envelopes that are filled with air or envelopes that have labels or stamps attached.

• Envelopes of which the surface is not flat because of embossing may cause the copies/prints to become smudged.

• Under high humidity and temperature conditions the glue flaps on some envelopes may become sticky and be sealed when copied.

• Use only envelopes which are flat and crisply folded. Curled or poorly formed envelopes may cause misfeeds.

• It is recommended that you perform a test print before performing the actual copy job.

Note for loading thick paper

Copying on thick paper requires higher fusing temperature setting. Set the user program 29 to "2 (High)" when using thick paper. (See page 20 and 21.)

This chapter explains basic and other copying functions. The unit is equipped with a one-page memory buffer. This memory allows the unit to scan an original once only and make up to 99 copies. This feature improves workflow, reduces operation noise from the copier, and provides higher reliability by reducing wear and tear on the scanning mechanism.

If the unit does not function properly during use, or if a function cannot be used, see "TROUBLESHOOTING THE UNIT" (p.27).

MAKING COPIES

COPY FLOW

1 Make sure that paper has been loaded in the paper tray (p.8),

or multi-bypass tray (p.10) and check the paper size (p.7).

If paper is not loaded, see page 8.

2 Turn on the unit (p.13).

3 Place the original.

When using the original table, see "ORIGINAL PLACEMENT" (p.15). When copying onto A4 paper or a large size, pull out the paper output tray extension.

4 Select the copy settings.

If you wish to copy using the initial settings (p.14), proceed to the next step. To set the number of copies, see page 16. To adjust the resolution and contrast settings, see page 16. To enlarge or reduce the copy, see page 18.

To change the tray, see page 18.

5 Start copying.

Press the start ( ) key.

CONNECTING THE POWER CORD

If you use the unit in a country other than the country where the unit was purchased, you will need to make sure that your local power supply is compatible with your model. If you plug the unit into an incompatible power supply, irreparable damage to the unit will result.

Ensure that the power switch of

the unit is in the OFF position. Insert the attached power cord into the power cord socket at the rear of the unit.

Plug the other end of the power cord into the nearest outlet.

Only insert the power cord into a properly grounded wall socket. Do not use extension cords or power strips.

Power on

Ensure that the power switch of the unit is in the OFF position. Plug the other end of the power cord into the nearest outlet. Turn the power switch on the left side of the unit to the "ON" position. The start ( ) indicator will light up and other indicators which show the initial settings of the operation panel will also light up to indicate the ready condition. For the initial settings, see the "Initial settings of operation panel" described on the next page.

• The unit will enter a power save mode once the set time has elapsed

without any unit operation. The settings of the power save modes can be modified. See "USER PROGRAMS" (p.20).

• The unit will return to the initial settings a preset amount of time after the end of copy or scanning job. The preset amount of time (auto clear time) can be changed. See "USER PROGRAMS" (p.20).

About the scan head

The scan head lamp remains on constantly when the unit is in the ready condition (when the start ( ) indicator is illuminated). The unit adjusts the scan head lamp periodically to maintain copying quality. At this time, the scan head moves automatically. This is normal and does not indicate unit trouble.

Initial settings of operation panel

When the unit power is on, the operation panel will revert to the initial settings when the time set with the "Auto clear time" setting (p.19) elapses after a copy is finished, or when the clear ( ) key is pressed twice. The initial settings of the operation panel are shown below.

141

"0" is displayed in the display.

When copying is begun in this state, the settings in the following table are used.

Copy quantity 1 copy

Exposure adjustment AUTO

Zoom 100%

Tray Paper tray

Power off methods

If not used for a certain period of time, the unit will automatically enter auto power shut-off mode (p.20) in order to minimise power consumption. In cases where the machine will not be used for a long time, turn off the power switch and remove the power cord from the outlet.

ORIGINAL PLACEMENT

• The original table can read up to A4 original.

• Image loss 4mm can occur at the leading and trailing edges of the

copies. Also image loss 4.5mm in total can occur along the other edges of the copies.

• When copying a book or an original which has been folded or a crumpled original, press down the original cover lightly. If the original cover is not securely closed, the copies may be striped or blurred.

Open the original cover, and place the original.

Place an original face down on the original table. Align it with

the original scale and the centring ( ) mark. Gently close the original cover.

Original scale

mark

Setting a large original

The original cover can be removed to allow copying of bulky objects.

Simply lift the original cover straight

up.

To reattach the original cover, reverse the above procedure.

SET THE COPY QUANTITY

Set the number of copies using the two copy quantity ( , ) keys when copying from the original table.

• Press the clear ( ) key to clear an entry if a mistake is made.

• A single copy can be made with the initial setting, i.e., when "0" is

displayed.

• Press the right copy quantity key to set the unit digit from 0 to 9. This key will not change the tens digit.

• Press the left copy quantity key to set the tens digit from 1 to 9.

A4 B5

Tens digit Unit digit

EXPOSURE ADJUSTMENT/PHOTO COPYING

Exposure adjustment

Copy density adjustment is not required for most originals in the automatic exposure mode. To adjust the copy density manually or to copy photographs, the exposure level can be adjusted in 2 steps manually.

The copy resolution used for AUTO and MANUAL ( ) mode can be changed. (p.20)

Press the exposure mode selector key to

select the MANUAL ( ) mode or PHOTO ( ) mode.

Use the light ( ) and dark ( ) keys to

adjust the exposure level. If exposure level 2 is selected, the two left-handmost indicators for that level will light up simultaneously. Also, if level 4 is selected, the two right-handmost indicators for that level will light up simultaneously.

Automatic exposure adjustment

This automatic exposure level will remain in effect until you change it again by this procedure.

The automatic exposure level can be adjusted to suit your copying needs.

Press the exposure mode selector key to

select the PHOTO ( ) mode.

Press and hold down the exposure mode

selector key for approximately 5 seconds. The PHOTO ( ) indicator will go out and the AUTO indicator will begin to blink. One or two light and dark indicators corresponding to the automatic exposure level which has been selected will light up.

Press the light ( ) or dark ( ) key to

lighten or darken the automatic exposure level as desired. If exposure level 2 is selected, the two left-handmost indicators for that level will light up simultaneously. Also, if level 4 is selected, the two righthandmost indicators for that level will light up simultaneously.

Press the exposure selector key. The AUTO indicator will stop

blinking and light up steadily.

REDUCTION/ENLARGEMENT/ZOOM

Three preset reduction ratios and two enlargement ratios can be selected. The zoom function enables copy ratio selection from 25% to 400% in 1% increments.

Set the original and check the paper size.

Use the copy ratio selector key and/or ZOOM ( , ) keys to

select the desired copy ratio.

• To verify a zoom setting without changing the zoom ratio, press and hold down the copy ratio display (%) key. When the key is released, the display will return to the copy quantity display.

• To reset the ratio to 100%, press the copy ratio selector key repeatedly until the 100% indicator lights up.

Set the reduction/enlargement ratio.

To decrease or increase the zoom ratio rapidly, press and hold down the ZOOM ( ) or ( ) key. However the value will stop at the preset reduction or enlargement ratios. To move beyond these ratios, release the key and then press and hold it down again.

To select a preset copy ratio:

Preset reduction and enlargement ratios are: 50%, 70%, 86%, 141%, and 200%.

141

To select a zoom ratio:

When a ZOOM (

or ) key is pressed, the

ZOOM indicator will light up and the zoom ratio will be displayed in the display.

SELECTING THE PAPER TRAY

Press the tray select ( ) key.

Each time you press the tray select ( ) key, the location indicated by the paper feed location indicator changes in the following order: paper tray, multi-bypass tray.

B5 A5

200

141

70 50

This chapter describes the special functions of this unit. Use these functions as needed.

SPECIAL FUNCTIONS

DESCRIPTION OF SPECIAL FUNCTIONS

Toner save mode (page 19)

Reduces toner consumption by approximately 10%.

Power save modes (page 20)

The unit has two power save modes of operation: preheat mode and auto power shut-off mode.

Preheat mode

When the unit enters the preheat mode, the power save ( ) indicator will light up and other indicators will remain on or off as before. In this condition, the fuser in the unit is maintained at a lower heat level, thereby saving power. To copy from the preheat mode, make desired copier selections and press the start ( ) key using the normal copying procedure.

Auto power shut-off mode

When the unit enters the auto power shut-off mode, the power save ( ) indicator will light up and other indicators will go out. The auto power shut-off mode saves more power than the preheat mode but requires a longer time before starting copying. To copy from the auto power shut-off mode, press the start ( ) key. Then make desired copier selections and press the start ( ) key using the normal copying procedure.

Auto clear (page 20)

The unit returns to the initial settings a preset amount of time after the end of copy. This preset amount of time (auto clear time) can be changed.

Resolution of AUTO & MANUAL mode (page 20)

You can set the copy resolution used for AUTO and MANUAL ( ) exposure mode.

TONER SAVE MODE

Press the exposure mode selector key

to select the MANUAL ( ) mode.

Press and hold down the exposure mode

selector key for approximately 5 seconds. The MANUAL ( ) indicator will go out and the PHOTO ( ) indicator will begin to blink. The light and dark indicator marked "5" will light up, indicating the standard toner mode is active.

To enter the toner save mode, press the

light ( ) key. The light and dark indicator marked "1" will light up, indicating the toner save mode is selected.

Press the exposure mode selector key. The PHOTO ( )

indicator will stop blinking and will light up steadily. The light and dark indicator marked "3" will light up. The toner save mode is now active.

To return to the standard mode, repeat the procedure but use the dark ( ) key to select exposure level "5" in step 3.

USER PROGRAMS

The user programs allow the parameters of certain functions to be set, changed, or cancelled as desired.

Setting the user programs

Press and hold down the light ( ) key for more than 5

seconds until all the alarm indicators ( , , , ) blink and " " appears in the display.

Use the left copy quantity ( ) key to select a user program

number. The selected number will blink in the left side of the display.

Press the start ( ) key. The entered program number will be

steadily lit and the currently selected parameter number for the program will blink on the right side of the display.

Select the desired parameter using the right copy quantity ( )

key. The entered parameter number will blink on the right of the display.

Program

No.

1 Auto clear time

2 Preheat mode

21 Reset factory 1 YES, *2 NO

* Factory default settings are indicated with an asterisk (*).

Mode Parameters

1 10 sec., 2 30 sec., *3 60 sec., 4 90 sec., 5 120 sec., 6 OFF

*1 30 sec., 2 60 sec., 3 5 min., 4 30 min., 5 60 min., 6 120 min., 7 240 min.

Auto power shut- off mode

Auto power shut- off timer

Resolution of AUTO & MANUAL mode

Copy effective paper width setting function (Bypass tray)

Copy effective paper width setting function (Tray 1)

Selection of copy start state (Polygon rotation on/off)

Fusing temperature setting when the bypass tray is used

*1 ON, 2 OFF

*1 5 min., 2 30min., 3 60 min., 4 120 min., 5 240 min.

*1 300dpi, 2 600dpi

*1 Large (A4 width), 2 Small (B5R width)

*1 ON, 2 OFF

1 Low, *2 High

Press the start ( ) key. The right-hand number in the display

will be steadily lit and the entered value will be stored.

To change the setting or to set another mode, press the clear ( ) key. The unit will return to step 2.

Press the light ( ) to return to the normal copy mode.

DISPLAYING TOTAL NUMBER OF COPIES

Use the following procedure to display the total number of copies.

Press and hold down the clear ( ) key for approximately 5 seconds. The total number of copies will appear in two steps, each with three digits.

Example: Total number of copies is 1,234.

This chapter describes how to replace the toner cartridge and how to clean unit.

Be sure to use only genuine SHARP parts and supplies.

For best copying results, be sure to use only SHARP Genuine Supplies which are designed, engineered, and tested to maximise the life and performance of SHARP copiers. Look for the Genuine Supplies label on the toner package.

MAINTENANCE

TONER CARTRIDGE REPLACEMENT

When the toner cartridge replacement required ( ) indicator lights up, replacement of the toner cartridge will be needed soon. Obtain a new cartridge. When the toner cartridge replacement required ( ) indicator blinks, the toner cartridge must be replaced before copying can be resumed. Replace the toner cartridge by following the procedure below.

During long copy run of a dark original, the start ( ) indicator may blink, the indicator light up, and the unit stop, even though toner is left. The unit will feed toner up to 2 minutes and then the start ( ) indicator will light up. Press the start ( ) key to restart copying.

Open the multi-bypass tray, side cover, and front cover, in that

order.

To open the multi-bypass tray, see "The multi-bypass tray" (p.10).

Push gently on both sides of

the front cover to open the cover.

Gently pull the toner cartridge

out while pressing the lock release lever.

• After removing the toner cartridge, do not shake it or tap on it. Doing so may cause toner to leak from the cartridge. Put the old cartridge immediately in the bag contained in the box of the new cartridge.

• Dispose of the old toner cartridge in accordance with local regulations.

Remove the toner cartridge from the bag. Grasp the cartridge

on both sides and shake it horizontally four or five times. After shaking the cartridge, remove the toner seal.

4 or 5 times

Shutter

Toner cartridge lock release lever

Toner seal

Grasp the toner cartridge as shown in the illustration. Do not hold the cartridge by the shutter. Be sure to only shake the cartridge before the toner seal is removed.

Gently insert the toner cartridge along

the guides until it locks in place while pushing the lock release lever. Remove the tape from the shutter. Pull the shutter out of the toner cartridge as shown in the illustration. Discard the shutter.

Close the front cover and

then the side cover by pressing the round projections near the side cover open button. The indicator ( ) will go out and the start ( ) indicator will light up.

When closing the covers, be sure to close the front cover securely and then close the side cover. If the covers are closed in the wrong order, the covers may be damaged.

Even after a new toner cartridge is installed, the start ( ) indicator may not light up, indicating copying cannot be restarted (toner is not sufficiently fed). In this case, open and close the side cover. The copier will feed toner again approximately 2 minutes and then copying can be restarted.

TONER CARTRIDGE LIFE

To find out the approximate quantity of toner remaining, follow the procedure described below.

Press and hold down the light ( ) key for more than 5

seconds until all the alarm indicators ( , , , ) blink and " " appears in the display.

Press and hold down the copy ratio display (%) key for more

than 5 seconds.

The approximate quantity of toner remaining will be indicated in the display as a percentage ("100", "75", "50", "25" or "10" is displayed). When the percentage is less than 10%,

Press the light ( ) key.

All alarm indicators wil go out.

() will be displayed.

CLEANING THE UNIT

Proper care is essential in order to get clean, sharp copies. Be sure to take a few minutes to regularly clean the unit.

Do not spray flammable cleaner gas. Gas from the spray may come in contact with the internal electrical components or high-temperature parts of the fusing unit, creating a risk of fire or electrical shock.

• Before cleaning, be sure to turn the power switch off and remove the power cord from the outlet.

• Do not use thinner, benzene or other volatile cleaning agents. Doing so may cause deformation, discoloration, deterioration or malfunction.

Cabinet

Wipe the cabinet with a soft, clean cloth.

Original table and the back side of the original cover

Stains on the glass or cover will also be copied. Wipe the glass and cover with a soft, clean cloth. If necessary, dampen the cloth with a glass cleaner.

Original table

Original cover

Transfer charger

If copies start becoming streaky or blotchy, the transfer charger may be dirty. Clean the charger using the following procedure.

Turn the power switch off. (p.14)

Ensure that the multi-bypass tray is open and then open the

side cover while pressing the side cover open button.

Take the charger cleaner out by holding the tab. Set the charger

cleaner onto the right end of the transfer charger, gently slide the cleaner to the left end, and then remove it. Repeat this operation two or three times.

Slide the charger cleaner from the right end to the left end along the groove of the transfer charger. If the cleaner is stopped on the way, smudges on copies may occur.

Return the charger cleaner

to its original position. Close the side cover by pressing the round projections near the side cover open button.

Turn the power switch on. (p.13)

TROUBLESHOOTING THE UNIT

This chapter describes misfeed removal and troubleshooting.

TROUBLESHOOTING

If any problem occurs, check the list below before contacting your authorised service representative.

Problem Possible cause Solution Page

Unit plugged in? Plug the unit into a grounded outlet. 13

Unit does not operate.

Blank copies

Copies are too dark or too light.

Dust, dirt, smudges appear on copies.

Striped copies Is transfer charger clean? Clean the transfer charger. 26

Paper misfeeds frequently.

Images rub off the copy easily.

Printing is not uniform between the edges of the paper and the center.

Power switch on? Turn the power switch on. 13 Side cover closed securely? Gently close the side cover. 24 Front cover closed? Gently close the front cover and then

Is the original placed face down on the original table?

Is the scan head locking switch locked?

Is original image too dark or too light?

Is the unit in the automatic exposure mode?

Is the unit in the photo exposure mode?

Original table or original cover dirty?

Original smudged or blotchy?

Non-standard paper used? Use standard paper. If using special

Paper curled or damp? Store paper flat in the wrapper in a

Pieces of paper inside unit? Remove all pieces of misfed paper. 29 Paper guides in the paper

tray not set properly? Too much paper in the

paper tray or multi-bypass tray?

Is the paper too heavy? Use paper within the specified range. 7

The fusing temperature is not appropriate.

Paper damp? Replace with dry paper. If the unit is

The fusing temperature is not appropriate.

close the side cover. Place the original face down on the

original table.

Unlock the scan head locking switch.

Adjust the exposure manually.

Adjust the automatic exposure level.

Cancel the photo exposure mode.

Clean regularly.

Use a clean original.

papers, feed the paper through the multi-bypass tray.

dry location.

Set the guides properly depending on the paper size.

Remove excessive paper from the tray. 8

In the user programs, set "Fusing temperature setting when the bypass tray is used" (program 29) to "2 (High)".

not used for long time, remove the paper from the paper tray and store it in its wrapper in a dry location.

In the user programs, set "Fusing temperature setting when the bypass tray is used" (program 29) to "1 (Low)".

–

STATUS INDICATORS

When the following indicators light up or blink on the operation panel or the following alphanumeric codes appear in the display, solve the problem immediately referring to both the table below and the relevant page.

Be sure to use only genuine SHARP parts and supplies.

Indication Cause and remedy Page

Developer replacement required indicator

Toner cartridge replacement required indicator

Misfeed indicator Blinking

Maintenance indicator

Power save indicator is steadily lit.

The paper tray indicator is blinking.

"CH" is blinking in the display.

"CH" is steadily lit in the display.

"P" is blinking in the display.

A letter and a number appear alternately.

Steadily lit

Blinking

Steadily lit

Developer is required. contact your authorised service representative.

Replacement of Toner cartridge will be needed soon. Prepare a new cartridge. (AR-208T)

Toner cartridge must be replaced. Replace it with a new one. (AR-208T)

A misfeed has occurred. Remove the misfed paper referring to the description of "MISFEED REMOVAL".

Service by an authorised SHARP service technician is required.

The unit is in the preheat mode. Press any key to cancel the preheat mode.

The unit is in the auto power shut-off mode. Press the start ( ) key to cancel the auto power shut-off mode.

The paper tray is not installed properly. Push the tray into the unit securely.

The toner cartridge is not installed. Check if the cartridge is installed. If "CH" is blinking even if a cartridge is installed properly, contact your SHARP service centre immediately.

Side cover is open. Close the side cover securely by pressing the round projections near the side cover open button.

The paper tray or multi-bypass tray is empty. Load paper.

A misfeed has occurred in the paper tray or in the multi- bypass tray. Remove the misfed paper.

Paper tray is not securely installed. Push the tray in securely.

The scan head locking switch is locked. Unlock the scan head locking switch and turn the power switch off/on.

The unit will not function. Turn the power switch off and then switch it on, and if there is again an error, remove the power cord from the outlet, and contact your authorized service representative.

The unit will not function. Turn the power switch off and then switch it on, or when the side cover is opened and then closed ; and if there is again an error, check whether or not you forgot to remove the bundling tape on the cartridge.

–

8, 10

–

MISFEED REMOVAL

When the misfeed ( ) indicator blinks or blinks in the display, the unit will stop because of a misfeed.

Open the multi-bypass tray, and side cover, in that order.

To open the multi-bypass tray, see "The multi-bypass tray" (p.10). To open the side cover, see "TONER CARTRIDGE REPLACEMENT" (p.22).

Check the misfeed location. Remove the misfed paper

following the instructions for each location in the illustration below. If the misfeed ( ) indicator blinks, proceed to "A: Misfeed in the paper feed area" (p.30).

If the misfed paper is seen from this side, proceed to "C: Misfeed in the transport area". (p.31)

If paper is misfed here, proceed to "B: Misfeed in the fusing area". (p.30)

If paper is misfed here, proceed to "A:

Misfeed in the paper feed area". (p.30)

A: Misfeed in the paper feed area

Gently remove the misfed paper from the paper feed area as

shown in the illustration. When the misfeed ( ) indicator blinks, and the misfed paper is not seen from the paper feed area, pull out the paper tray and remove the misfed paper. If the paper cannot be removed, proceed to "B: Misfeed in the fusing area".

The fusing unit is hot. Do not touch the fusing unit when removing misfed paper. Doing so may cause a burn or other injury.

• Do not touch the photoconductive drum (green portion) when removing the misfed paper. Doing so may cause smudges on copies.

• If the paper has been fed through the multi-bypass tray, do not remove the misfed paper through the multi-bypass tray. Toner on the paper may stain the paper transport area, resulting in smudges on copies.

Close the side cover by pressing the round projections near

the side cover open button. The misfeed ( ) indicator will go out and the start ( ) indicator will light up.

B: Misfeed in the fusing area

Lower the fusing unit release

lever.

Fusing unit release lever

Gently remove the misfed paper

from under the fusing unit as shown in the illustration. If the paper cannot be removed, proceed to "C: Misfeed in the transport area".

The fusing unit is hot. Do not touch the fusing unit when removing misfed paper. Doing so may cause a burn or other injury.

• Do not touch the photoconductive drum (green portion) when removing the misfed paper. Doing so may cause smudges on copies.

• Do not remove the misfed paper from above the fusing unit. Unfixed toner on the paper may stain the paper transport area, resulting in smudges on copies.

Raise the fusing unit release lever and then close the side

cover by pressing the round projections near the side cover open button. The misfeed ( ) indicator will go out and the start ( ) indicator will light up.

C: Misfeed in the transport area

Lower the fusing unit release lever.

See "B: Misfeed in the fusing area" (p.30).

Open the front cover.

To open the front cover, see "TONER CARTRIDGE REPLACEMENT" (p.22).

Rotate the roller rotating

knob in the direction of the arrow and gently remove the misfed paper from the exit area.

Roller rotating knob

Raise the fusing unit release lever, close the front cover and

then close the side cover by pressing the round projections near the side cover open button. The misfeed ( ) indicator will go out and the start ( ) indicator will light up.

When closing the covers, be sure to close the front cover securely and then close the side cover. If the covers are closed in the wrong order, the covers may be damaged.

DEVELOPER REQUIRED

When the developer replacement required ( ) indicator lights up, the developer should be replaced. DEVELOPER REPLACEMENT SHOULD ONLY BE DONE BY AN AUTORIZED SHARP SERVICE TECHNICIAN. Contact your service centre as soon as possible.

MAINTENANCE REQUIRED

When maintenance ( ) indicator lights up, service by an authorised SHARP service technician is required. Contact your service centre as soon as possible.

SCAN HEAD LOCKING SWITCH

The scan head locking switch is under the original table. If the switch is locked ( ), the unit will not operate. Unlock the switch ( ) as shown below.

Grasp here and turn in the direction of the arrow.

Lock Unlock

To lock the scan head locking switch, hold up the catch in illustration turn the center knob counter-clockwise 90 degrees until you hear a click.

and

APPENDIX

SPECIFICATIONS

Model AR-5420

Type Digital laser copier, desk-top type

Copy system Dry, electrostatic transfer

Originals Sheets, bound documents

Paper tray 250 sheets

Multi-bypass tray 50 sheets

Paper output tray 200 sheets

Original sizes Max. A4

Original feed 1 sheet

Copy size A6 to A4 *

Image loss

Copy speed 20 pages/min.

Continuous copying Max. 99 pages subtractive counter

First-copy time (Approximately)

Copy ratio

Exposure system

Fusing system Heat rollers

Development system Magnetic brush development

Light source Cold cathode fluorescent lamp

Resolution

Gradation

Bit depth 1 bit or 8 bit/pixel

Sensor Colour CCD

Scanning speed Max. 2.88ms/line

Memory 8 MB

Power supply

Power consumption 1000 W

Overall dimensions

Weight (Approximately) *

Scan 256 levels

Output 2 levels

Width 607.6mm

Depth 462.5mm

Max. 4mm * Max. 4.5mm *

8.0 seconds (When user program 24 is set to OFF)

10.7 seconds (When user program 24 is set to ON) (paper: A4, exposure mode: AUTO, copy ratio: 100%)

Variable:25% to 400% in 1% increments (total 376 steps) Fixed: 50%, 70% 86%, 100%, 141%, 200%

Moving optical source, slit exposure (stationary platen) with automatic exposure

600 x 300dpi (Auto/Manual mode) 600 x 600dpi (Photo mode)

Local voltage name plate located on the back of the unit)

16kg

±10% (For this copier power supply, see the

Model AR-5420

Width 518mm

Unit dimensions

Operating conditions

Noise level

OptEmission concentration (measurement according to RAL-UZ 62)

*1Feed paper lengthwise only.

Leading and trailing edges.

Along the other edges in totals.

Not includes toner and drum cartridges.

Depth 462.5mm

Height 295.6mm

As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

Temperature: 10°C to 30°C Humidity: 20% to 85%

Sound Power Level L Copying: 6.4 [B] Standby: 3.3 [B] Sound Pressure Level L Copying: 48 [dB (A)] Standby: 17 [dB (A)] Sound Pressure Level L Copying: 52 [dB (A)] Standby: 17 [dB (A)] Noise emission measurement in accordance with ISO 7779.

Ozone: less than 0.02 mg/m Dust: less than 0.075 mg/m Styrene: less than 0.07 mg/m

wA (1B=10dB)

pA (bystander positions)

pA (operator position)

ABOUT SUPPLIES

When ordering supplies, please use the correct part numbers as listed below.

Be sure to use only genuine SHARP parts and supplies.

For best copying results, be sure to use only SHARP Genuine Supplies which are designed, engineered, and tested to maximize the life and performance of SHARP copiers. Look for the Genuine Supplies label on the toner package.

Supply list

Supply Part number Usable life

Toner cartridge AR-208T Approx. 8,000 sheets*

*Based on copying onto A4-type paper at 6% toned area.

INDEX

About supplies...................................34

Alarm indicator

- Developer replacement required

indicator..............................6, 28, 32

- Maintenance indicator ........ 6, 28, 32

- Misfeed indicator ................ 6, 28, 29

- Toner cartridge replacement required

indicator..............................6, 23, 28

Appendix ........................................... 33

Auto clear time ..................................20

Auto power shut-off mode ................. 20

Automatic exposure adjustment ........17

Display................................................. 6

Displaying total number of copies ..... 21

Exposure adjustment......................... 16

Exposure mode indicator............... 6, 16

Exposure mode selector key ......... 6, 16

Front cover ..........................................5

Fusing unit release lever ............... 5, 30

Bypass feed....................................... 10

Bypass paper guides ..................... 5, 10

Cautions

- Handling ......................................... 2

- Laser .............................................. 2

- Using .............................................. 1

Charger cleaner............................. 5, 26

CLEANING ........................................ 25

Cleaning the unit

- Cabinet ......................................... 25

- Original cover ............................... 25

- Original table ................................ 25

- Transfer charger ........................... 26

Clear key ................................. 6, 16, 22

Conventions used in the manual ......... 4

Copy flow...........................................12

Copy quantity .................................... 16

Copy quantity key.................... 6, 16, 20

Copy ratio display key ................... 6, 18

Copy ratio selector indicator.......... 6, 18

Copy ratio selector key.................. 6, 18

Dark key ........................................ 6, 16

Developer replacement required

indicator ..................................6, 28, 32

Developer required............................ 32

Handle ................................................. 5

Initial settings of operation panel....... 14

Introduction..........................................4

Light and dark indicator ................. 6, 16

Light key ........................................ 6, 16

Loading paper ..................................... 7

Loading the paper tray ........................ 8

Maintenance indicator ............. 6, 28, 32

Making copies ................................... 12

Misfeed indicator ..................... 6, 27, 28

Misfeed removal

- Fusing area ..................................30

- Paper feed area............................ 30

- Transport area.............................. 31

Multi-bypass tray ...............................10

Name

- Operation panel.............................. 6

- Part names ..................................... 5

Operation panel...................................5

Original placement ............................15

Original table ....................................... 5

Paper................................................... 7

Paper feed location indicator............... 6

Paper output tray.................................5

Paper output tray extension ................5

Paper tray........................................5, 8

Photo copying.................................... 16

Power cord socket...............................5

Power off ........................................... 14

Power on ........................................... 13

Power save indicator .....................6, 46

Power save mode indicator ............... 20

Power switch ................................. 5, 13

Preheat mode.................................... 20

Proper storage.....................................2

Reduction/enlargement/zoom ........... 18

Side cover ........................................... 5

Side cover open button .......................5

Specifications ....................................33

Start indicator ......................................6

Start key .................................. 6, 12, 21

Status indicators................................28

Toner cartridge .................................. 22

Toner cartridge life ............................ 25

Toner cartridge replacement .............22

Toner cartridge replacement

indicator...................................6, 24, 28

Transfer charger............................ 5, 26

Troubleshooting................................. 27

Troubleshooting the unit.................... 27

ZOOM indicator ............................. 6, 18

ZOOM key ..................................... 6, 18

INDEX BY PURPOSE

Cleaning the unit

- Cabinet ......................................... 25

- Original cover ............................... 25

- Original table ................................ 25

- Transfer changer .......................... 26

Copying ............................................. 12

Displaying total number of copies...... 21

Enlarging/reducing copies ................. 18

Loading paper

- Multi-bypass tray ..........................10

- Paper tray .......................................7

Loading the original ...........................15

Power off ........................................... 14

Power on ........................................... 13

Removing paper jams

- Fusing area ..................................30

- Paper feed area............................ 30

- Transport area.............................. 31

Replacing the toner cartridge ............22

Setting the copy quality

- AUTO ........................................... 16

- MANUAL ...................................... 16

- PHOTO......................................... 17

Setting the copy quantity ................... 16

Setting the toner save mode .............19

Setting the user program................... 20

Storing the unit .................................... 1

CLASS 3B INVISIBLE LASER

CAUTION

RADIATION WHEN OPEN AND INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.

VORSICHT

UNSICHTBARE LASERSTRAHLUNG DER KLASSE 3B, WENN ABDECKUNG GEÖFFNET UND SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT. NICHT DEM STRAHL AUSSETZEN.

ADVARSEL

USYNLIG LASERSTRÅLING AF KLASSE 3B VED ÅBNING, NÅR SIKKERHEDSBRYDERE ER UDE AF FUNKTION. UNDGÅ UDSÆTTELSE FOR STRÅLING.

USYNLIG KLASSE 3B

ADVARSEL

LASERSTRÅLING NÅR DEKSEL ÅPNES OG SIKKERHEDSLÅS BRYTES. UNNGÅ EKSPONERING FOR STRÅLEN.

VARNING

OSYNLIG LASERSTRÅLNING KLASS 3B NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRRAR ÄR URKOPPLADE. UNDVIK EXPONERING FÖR STRÅLEN.

VAR O!

AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA NÄKYMÄTÖNTÄ LUOKAN 3B LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.

CLASS 3B INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED.

CAUTION

AVOID EXPOSURE TO BEAM.

UNSICHTBARE LASERSTRAHLUNG DER KLASSE 3B, WENN ABDECKUNG GEÖFFNET UND

VORSICHT

Laserstrahl

SICHERHEITSVERRIEGELUNG ÜBERERÜCKT. NICHT DEM STRAHL AUSSETZEN.

SYNLIG LASERSTRÅLING AF KLASSE 3B VED ÅBNING, NÅR SIKKERHEDSAFBRYDERE ER

ADVARSEL

UDE AF FUNKTION. UNDGA UDSAETTELSE FOR STRÅLING.

Caution

This product contains a low power laser device. To ensure continued safety do not remove any cover or attempt to gain access to the inside of the product. Refer all servicing to qualified personnel.

USYNLIG KLASSE 3B LASERSTRÅLING NÅR DEKSEL ÅPNES OG SIKKERHEDSLÅS BRYTES. UNNGÅ EKSPONERING FOR STRÅLEN.

ADVERSEL

OSYNLIG LASERSTRÅLNING KLASS 3B NÄR DENNA DEL ÄR ÖPPNAD OCH

VARNING

SPÄRRAR ÄR URKOPPLADE. UNDVIK FÖR STRÅLEN

AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA NÄKYMÄTÖNTÄ

VARO!

LUOKAN 3 B LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.

CLASS 1 LASER PRODUCT

LASER KLASSE 1

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

CLASS 1

LASER PRODUCT

LASER KLASSE 1

SHARP Manufacturing France S.A.

Route de Bollwiller 68360 SOULTZ FRANCE

AR-5420

PRINTED IN FRANCE

TINSX1839TSZZ

Sharp AR-5420 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
