TOURGUIDE 2020D

Information becomes an
experience. Quite simply.

Tourguide 2020-D

Universally convincing

The quick and easy way to a
professional solution for visitor
guidance. Excels with extremely
simple handling, convinces with
professional functionalities: The digital
system Tourguide 2020-D stands
for uncomplicated audio solutions
in visitor guidance, at conferences,
and for assistive listening.

Specifications HDE 2020-D-II

Dimensions 245 x 125 x 20 mm

(9.65“ x 4.92“ x 0.79“)

Weight
incl. battery

Modulation 2 FSK

RF frequency
range

Frequency
response

Sound pressure
level

Typical operating
time

Battery 830 mAh (Li-poly)

73 g (2.58 oz)

863 - 865 MHz
926 - 928 MHz (US-Version)

100 – 7,000 Hz

120 dB SPL at 1 kHz

8 h

Number of
channels

THD at 1 kHz < 1 %

Operating
temperature

Delivery includes HDE 2020-D-II,

Tourguide mode: 6
Conferene mode: 8

0° C – 50° C

Manual

Hassle free
design

Tourguide 2020-D combines the wireless receiver
and headphones in one device. That makes it easy to
handle even for large scale setups with many visitors.
Use the practical charging case (EZL 2020-20L) as a
convenient solution for charging and storing of up to
20 receivers and additional accessories.

Simply
intuitive

Best
flexibility

Full flexibility for diverse application scenarios:
The Tourguide 2020-D is not only fit for guidance
and interpreter applications. For assistive
listening in theaters or opera houses hearing
aids can be easily connected to the system.

License
free ISM band

Stethoset receiver

HDE 2020-D-II

Handheld transmitter

SKM 2020-D

Bodypack transmitter
with headset microphone

SK 2020-D

+ HS 2

Guided tours applications – Tourguide 2020-D compact versatility

Bodypack receiver
with headphones

EK 2020-D-II

+ HP 02

Bodypack receiver with
induction neck loop

EK 2020-D-II

+ EZT 3011

Charging unit for handheld
and bodypack transmitter
and 20 receivers

EZL 2020-20L

The digital Tourguide 2020-D is designed for
ease of use and doesn’t require special technical
knowledge. Its intelligent technology ensures
absolutely simple handling.

The Tourguide 2020-D runs within the license-free
ISM frequency band (which can be operated world
wide) and is therefore extremely quick to set up,
without elaborate frequency planning.

Components

HDE 2020-D-II SR 2020-DEK 2020-D-II

HDE 2020-D-II stethoset Tourguide receiver is
the comfortable to wear receiver of the digital
Tourguide System 2020-D. This truly unique device
integrates both the receiver and headphones and
delivers a number of advantages for you.

Whether conferences, guided tours or
hearing assistance: this extremely sturdy and
versatile bodypack receiver provides excellent
audio and ease of use for your guests. The
EK 2020-D-II can be used with headphones
or an induction neckloop for transmitting the
sound to hearing aids equipped with a T coil.

SR 2020-D, multiply gifted! For each of
your productions, the compact high­tech transmitter SR 2020-D will provide
perfect audio in exactly the right way.

NP 02, HP 02

These robust and lightweight headphones
are the ideal addition to the EK 2020-D-II. For
every occasion, there's a pair of headphones
available for maximum comfort and in
renowned Sennheiser quality.

The SKM 2020-D hand-held microphone
efficiently attenuates unwanted background
noise. The transmitter is easy and comfortable to
operate and highly robust.

The Tourguide transmitter SK 2020-D will allow
you to deliver a highly professional guided tour.
Combining the bodypack transmitter with an
headworn or clip-on microphone, will give you total
freedom of movement during your tour.

The EZL 2020-20L charger case has been
designed to be highly user-friendly. It acts as
both the storage case for all equipment and
charging station for the Tourguide receivers and
transmitters. The L 2021-40 has been specially
designed for stationary applications. It holds up to
40 receivers that will automatically quick-charge.

SL INTERPRETERSKM 2020-D EZL 2020-20L & L 2021-40 SK 2020-D

The SL Interpreter perfectly completes either
the Tourguide 2020 or the Tourguide 1039
portfolio to create a compact, quick to install
and easy to use interpretation setup for
presentation-style conferences or events alike.

Applications

Factory Tours

The production facilities are the heart of every
company and are therefore of particular interest
to customers and journalists. This is where ideas
are turned into product solutions. Also, this
is the place where machines work around the
clock and generate the highest noise level in the
company. With the Tourguide 2020-D, several
groups of visitors can be guided through the plant
simultaneously. So you can ensure that your visitors
understand every single word during the tour.

Exhibitions

Turn every exhibition into a very special
experience with exciting and explanatory audio
accompaniment and make it accessible to a wide
audience. With Sennheiser Tourguide you can
manage even large visitor rushes with ease.

Conferences

'This system

improves guided
tours enormously,

especially in
heavily frequented
cities or museums.'

At conferences, every spoken word counts.
Speech intelligibility is particularly important
here. There is no room for technical failure.
Tourguide 2020-D functions simply and very
reliably in every important conference situation
and is also suitable for interpreting.

'We use the Sennheiser Tourguide System on our 15 riverboats

throughout Europe. All guests of the group hear the comments without

annoying noise. They don't always have to "stick" to the guide but

can also take a photo a little off the beaten track and still hear his

comments. The guests come back enthusiastically from the excursions.'

Marion Hilbrich, Head of Operations, nicko cruises, Germany
