Senco DuraSpin DS300-AC Specifications
Fastening Solutions
The powerful SENCO DS300-AC is designed for
high-volume, high-speed screw applications.
Professional remodelers, contractors and DlYers will
appreciate the convenience of the 3300 rpm collated
screw system, which increases productivity by
eliminating the need for handling loose screws.
The DS300-AC has corded power to drive
11/4" – 3" screws into even the toughest work surfaces.
With the built-in extension you can adjust tool to the
proper height to speed productivity and save your back
and knees.
™
DuraSpin® DS300-AC
Corded Collated Screwdriver
Applications:
Ideal for decking, floor sheathing, underlayment and
cement board.
Features and Benefits:
• 3300 RPM high-torque AC motor drives screws
without bogging down
1
• Drives 1
composites
• Easy depth-of-drive adjustment regulates the precise
amount of countersink
• Fast and simple adjustable height extension
• Ergonomically designed to position hands directly over
screw for precise straight drives
• Comfortable grip for less exertion
• Reverse switch to back out driven screws
• Trigger lock for continuous work
• Patented clutch design means long-lasting durability
• Fast and easy loading of screws
• Easy bit change – from Phillips® to square
• Super-tough drive bits – the longest lasting bits
available
• Corded power for the demanding needs of
professional remodelers and contractors
• High-quality ten-foot cord
• One-year warranty
• Each kit comes complete with tool, spare drive bits,
wrenches, spare non-slip nose pads and rugged
carrying case
/4" – 3" screws, even into hard woods and
Tool Specifications:
Item Code: 1P0001N
Voltage: 120
Current: 5.2 amps
Frequency: 60Hz
RPM: 3300
Weight: 8.7 lbs. (3.9 kg)
Height:
Length: collapsed 31.5" (800 mm),
fully extended 41.5" (1054 mm)
Width: 4" (102 mm)
Fastener Capacity: 50 screws (one strip)
Torque Delivered: 85 in-lbs
Generated Noise: 74 dBA
Vibration: less than 2.5 m/sec
67/8" (175 mm)
2
Fastener Specifications:
Screw Lengths: 11/4" – 3" (32 mm – 75 mm)
Screw Diameters: #6 – #10
(see reverse side for chart)
www.senco.com ©2005 by Senco Products, Inc.
Fastening Solutions
DuraSpin DS300-AC
Corded Collated Screwdriver
™
Adjustable
nose piece
11/4" – 3" screws
Drives
(32 mm – 75 mm)
Adjustable
depth-of-screw drive
Drywall to Wood
Reverse switch, to back
out driven screws
Easy-loading strip guide
Telescoping adjustable-height extension
High-quality 10-foot cord (3 m)
Ergonomic design – drives
screws effortlessly
Trigger lock
For additional information on how SENCO power fastening systems will save you
time, reduce costs and increase quality, call your nearest Authorized SENCO
Dealer or Distributor listed in the Yellow Pages under "Staples," or call our toll-free
Action Line: 1-800-543-4596.
www.senco.com ©2005 by Senco Products, Inc.
