Limit and Enclosed Switches
Miniature Switch Selection Guide
Standard duty
SL1
Pg. A84
PHYSICAL DESCRIPTION Package size (in.)
Actuators
SPECIAL FEATURES Space-saving size for machine
CHARACTERISTICS Electrical data (maximum available)
Circuitry
1.27H
1.7W .7L
Roller plunger, cross roller plunger, plunger, roller lever, one-way roller lever, roller plunger w/seal boot.
miniaturization. Different contact types and actuation methods available.
5A - 125; 250 VAC; 0.1A - 125 VAC;
0.1A - 30 VDC
SPDT
Miniature size
914CE
Pg. A87
2.1H .6W
1.6L
Side rotary, plunger, roller plunger, adj. plunger, PB, wobble lever.
Gang-mount capability. Factory wired cable. Connector options available.
5A - 125, 250 VAC
SPDT
Plastic enclosed
BF
Pg. A93
2.7H
1.2W
2.9L
Pin plunger, roller levers, one way roller lever, wobble lever.
Rugged plastic enclosure eliminates need for grounding. Large internal cavity for easy wiring. Pressure plate style wire clamps.
.1A to 11A 125 VAC
SPDT
Operating force
Differential travel (max.)
ENVIRONMENT Upper Temperature Range Lower
Sealing†
Housing Material
† For NEMA definitions, see page
E7.
AGENCY LISTING UL/CSA listings available. UL Recognized
TYPICAL APPLICATIONS 1 Robotics
Plunger 1200 grams Lever 400 grams
.004 in. (plunger) .012 in. (lever)
158° F (70° C) 14° F (–10° C) Low temperature versions available
NEMA 3, 4, 13; IP 67
Zinc with plastic terminal cover
1 Light material handling 1 Machine tools 1 Low temperature applications
down to –60°F
Plunger
2.75 lbs.
.004 in.
200° F (93° C)* 10° F (–12° C)*
NEMA 1, 3, 4*, 6*, 6P*, 12*, 13*
Zinc
* Most listings
CSA Certified CE Certified
1 Processing equipment 1 Textile machinery 1 Machine tools 1 Robotics 1 Packaging equipment 1 Farm machinery 1 Commercial laundry equipment 1 Printing trades machinery 1 Vehicles
Wobble stick 7 oz. max
160° F (71° C) –25°F (– 31°C)
NEMA 1, 3, 4, 13
Thermoplastic enclosure
UL Recognized
1 Overhead cranes and hoists 1 Surface transportation equipment 1 Special machinery 1 Agricultural equipment 1 Earth moving equipment
A4Honeywell1 Sensing and Control11-800-537-6945 USA1F1-815-235-6847 International11-800-737-3360 Canada
Limit and Enclosed Switches
General Purpose Switches Selection Guide
Compact
E6/V6
Pg. A96
2.7H
1.0W
3.0L
Plunger, roller lever, rod, manual button, roller plunger, one-way roller lever, wobble lever.
Momentary or maintained contact. Sealed or un­sealed actuators. Internal grounding screw. Side or bottom mounting.
Standard/versatile
OP
Pg. A108
2.6H
3.2W
3.7L
Plunger, roller lever, paddle lever.
Mounts from four sides. Captive cover screws. Internal grounding screw.
Compact ­Double Conduit
BZG/BZH
Pg. A102
2.9H
1.0W
3.4L
Plunger, roller lever, rod lever.
Optional: 2 conduit openings, neon pilot light, side or bottom mount. Internal grounding screw.
High current capacity
BAF1
Pg. A105
3.2H
1.3W
4.0L
Plunger, roller lever, flexible rod, manual button, roller plunger, one way roller lever.
Right or lefthand actuators. Momentary or maint. contacts. Internal grounding screw.
Compact LS
LS
Pg. A70
3.7H
2.3W
1.6L
Side rotary, plunger, roller plunger, wobble lever.
Small size of compact version. Years of field­proven performance.
Limit/Enclosed
15A - 125, 250, 480 VAC
SPDT DPDT
(Sealed plunger) 9-24 oz.
.002 in.
160° F (71° C) –25° F (–32° C)
NEMA 1, 3, 4*, 12*, 13*
Zinc
* Some listings
UL Recognized CSA Certified
1 Packaging equipment 1 Special machinery 1 Textile machinery 1 Conveyors 1 Construction machinery
and equipment
1 Printing trades
machinery
1 Overhead cranes and
hoists
20A-125, 250, 480 VAC
SPDT DPDT 2 CKT DB
(Rotary) .5-2.5 lbs.
.007 in.
160° F (71° C) –25° F (–32° C)
NEMA 1, 3*, 4*, 13*
Al or Iron
* Except Q-plunger
UL Recognized CSA Certified
1 Control valves and
actuators
1 Material handling 1 Conveyors
15A-125, 250, 480 VAC
SPDT
(Sealed plunger) 9-24 oz.
.002 in.
160° F (71° C) –25° F (–32° C)
NEMA 1, 3*, 4*, 13*
Al
* Except Q-plunger
UL Recognized UL Recognized
1 Packaging machinery 1 Conveyors 1 Materials handling 1 Food processing 1 Machine tools
20A-125, 250, 480 VAC
SPDT DPDT
(Plunger)
2.5 lbs. max.
.010 in.
160° F (71° C) –25° F (–32° C)
NEMA 1, 3*, 4*, 13*
Al
* Except BAF1-2RQ9
CSA Certified
1 Packaging equipment 1 Special machinery 1 Farm machinery 1 Conveyors 1 Overhead cranes and hoists
10A-120, 240, 480 VAC
2 CKT DB
(Standard size rotary)
4.5 in. lbs. (Low force types available)
12°
160° F (71° C) –20° F (–29° C)
NEMA 1, 3, 4, 6, 13
Al and Zinc
UL Recognized CSA Certified CE Certified
1 Machine tools 1 Conveyors 1 Material handling 1 Metal fabrication
equipment
1 Lift trucks
Honeywell1 Sensing and Control11-800-537-6945 USA1F1-815-235-6847 International11-800-737-3360 CanadaA5
Limit and Enclosed Switches
Heavy Duty Switch Selection Guide
Global Limit Switch DIN Miniature Global Limit Switch Heavy Duty LS
GLA/B GLC/D GLE HDLS
Pg. A11 Pg. A18 Pg. A30
PHYSICAL DESCRIPTION SPDT DPDT Package size (in.) 4.05 (102,9)H 3.03 (77)H 4.2H 4.7H
Actuators Side rotary, plunger, roller plunger,
SPECIAL FEATURES Designed to newest IEC standard
CHARACTERISTICS Electrical data (maximum available)
Circuitry 2 CKT DB
Operating force Side rotary 9.7 N
Differential travel (max.) 12° 11.5° SPDT: 5°
ENVIRONMENT Upper 85°C85°C 250°F (121°C) Temperature range Lower –25°C –25°C10°F (–12°C) –40° See pg. A42
Sealing† IP 67, NEMA 4 IP 67, NEMA 4 NEMA 1, 3, 4, 4X, 6, 13.
Housing material Metal Metal, thermoplastic Zinc
† For NEMA definitions, see page A114.
AGENCY LISTING EN50041
TYPICAL APPLICATIONS
1.65 (42)W 1.201 (30,5)W 2.4W 2.4W
1.64 (41,6)L 1.132 (28,75)L 1.6L 1.9L
roller arm, wobble levers.
for worldwide acceptance.
IEC 947-5-1 Ith 10A Ui 660 VAC/VDC
4 CKT DB 2 CKT BBM 2 CKT MBB 2 CKT Bifurcated
Plunger 16 N
UL, CSA and CE
1 Machine tool 1 Material handling 1 Packaging machinery 1 Textile machinery 1 Construction machinery and
equipment
1 PLC Interface
Side rotary, plunger, roller plunger, roller arm, wobble levers.
Designed to newest IEC standard for worldwide acceptance. GLE 3 cable entry.
IEC 947-5-1 Ith 10A Ui 660 VAC/VDC
2 CKT DB 4 CKT DB 2 CKT BBM 2 CKT MBB 2 CKT Bifurcated
Side rotary 2.5 N Plunger 12N
EN50047 UL, CSA and CE
1 Machine tool 1 Material handling 1 Packaging machinery 1 Textile machinery 1 Construction machinery and
equipment
1 PLC Interface
Side and top rotary, plunger, adj. plunger, roller plunger, wobble lever.
All-metal drive train. Integral grounding screw. Interchangeable mounting of all switch types. Identical cam tracking for single and double­pole models.
60A make. 6A break — 120 VAC; 10A continuous — 120, 240, 480, 600 VAC.
SPDT, DB DPDT, DB SPDT maintained DPDT maintained Center neutral Solid State, digital output.
(Standard side rotary) 4 in. lbs. (Low force types available)
DPDT: 7°
Refer to page A40 for temperatures.
UL Enclosure Types 1, 3, 4, 4X, 6, 6P, 13.
UL Listed CSA Certified CE Certified
1 Machine tool 1 Material handling 1 Packaging 1 Presses 1 Pulp and paper 1 Welding 1 PLC Interface
A6Honeywell1 Sensing and Control11-800-537-6945 USA1F1-815-235-6847 International11-800-737-3360 Canada
Limit and Enclosed Switches
Harsh Duty Switch Selection Guide
Harsh duty epoxy filled HDLS Corrosion resistant HDLS
HDLS HDLS
Pg. A44 Pg. A47
PHYSICAL DESCRIPTION SPDT DPDT Package size (in.) 4.2H 4.7H 4.2H
Actuators Side and top rotary, plunger, adj. plunger, roller
SPECIAL FEATURES All non plug-in HDLS features. Switch cavity epoxy
CHARACTERISTICS Electrical data (maximum available)
Circuitry SPDT, DB
Operating force (Standard side rotary)
Differential travel (max.) SPDT: 5°
ENVIRONMENT Upper 250°F (121°C) 250°F (121°C) Temperature range Lower 10°F (–12°C) –40° See pg. A42 10°F (– 12°C)
Sealing† NEMA 1, 3, 4, 4X, 6, 6P, 13.
Housing material Zinc Stainless Steel
† For NEMA definitions, see page E7.
AGENCY LISTING UL Listed
TYPICAL APPLICATIONS
2.4W 2.4W 2.4W
1.6L 1.9L 1.9L
plunger, wobble lever.
filled. All fluorocarbon seals. Exceeds NEMA 6P. Preleaded or connector.
60A make. 6A break — 120 VAC; 10A continuous — 120, 240, 480, 600 VAC.
DPDT, DB
4 in. lbs. (Low force types available)
DPDT: 7°
Refer to page A42 for temperatures.
UL Enclosure Types 1, 3, 4, 4X, 6, 6P, 13.
CSA Certified CE Certified
1 Food processing machines and conveying
equipment subject to daily washdown.
1 Automotive machine tools and conveyors subject to
various coolants and cutting fluids.
Side and top rotary, plunger, adj. plunger, roller plunger, wobble lever.
All corrosion resistant type 316 stainless steel construction. All non plug-in HDLS features. All fluorocarbon seals.
60A make. 6A break — 120 VAC; 10A continuous — 120, 240, 480, 600 VAC.
SPDT, DB DPDT, DB
(Standard side rotary) 4 in. lbs. (Low force types available)
SPDT: 5° DPDT: 7°
NEMA 1, 3, 4, 4X, 6, 6P, 13. UL Enclosure Types 1, 3, 4, 6, 6P, 13.
UL Listed CSA Certified
1 Shipboards and dockside 1 Power generating plants 1 Caustic waste handling 1 Mining 1 Undersea transit systems 1 Corrosive valve locations
Limit/Enclosed
Honeywell1Sensing and Control11-800-537-6945 USA1F1-815-235-6847 International11-800-737-3360 CanadaA7
Limit and Enclosed Switches
Explosion Proof Switch Selection Guide
Standard explosion proof Sealed explosion proof Explosion proof LS Momentary explosion
EX CX LSX CLSX
Pg. A121 Pg. A127 Pg. A113 Pg. A119
PHYSICAL DESCRIPTION Package size (in.) 2.6H 4.0H 4.0H 5.8H 5.6H
Actuators Plunger, roller and one-way
SPECIAL FEATURES Single or double conduit
CHARACTERISTICS Electrical data (maximum available)
Circuitry SPDT
Operating force (Rotary)
Differential travel (max.) .007-.109 in. 5-25° SPDT: 5°
ENVIRONMENT Upper 160°F (71°C) 185°F (85°C) 250°F (121°C) 158°F (70°C) Temperature range
Sealing† NEMA 1, 7, 9. NEMA 1, 3, 4, 4X, 7, 9, 13 NEMA 1, 3, 4, 6, 7, 9, 13 NEMA 1, 3, 4, 7, 9, 13
Housing material Al Al or Bronze Al and Zinc Al and Zinc
† For NEMA definitions, see page E7.
AGENCY LISTING UL Listed
Lower –40°F (–40°C) –13°F (–25°C) 10°F (–12°C) 30°F (–1°C)
3.2W 6.6W 4.9W 2.4W 2.9W
3.7L 4.0L 4.0L 3.0L 3.0L
roller lever, rod and roller rod lever, and manual paddle.
connection. Mounts from four sides. Interchangeable with OP. Internal grounding screw.
20A-125, 250, 480 VAC 20A-125, 250, 480 VAC 10A-120, 240, 480, 600
DPDT 2 CKT DB
.5-2.5 lbs.
CSA Certified
Plunger, rotary forms. Same as HDLS. Cable
Sealed for outdoor use. Adjustable P.T., O.T. and operating mode. Mounts from front or four sides. Salt and water resistant marine version.
SPDT DPDT
(Rotary)
11.1 in. lbs.
UL Listed CSA Certified
Sealed and explosion­proof interchangeable with HDLS (w/adapter plate) and ML-E1.
VAC
SPDT DPDT
(Side rotary) 4 in. lbs.
DPDT: 7°
UL Listed CSA Certified
proof cable pull
Explosion proof. Covers cable spans up to 200 ft.
I
= 10A
th
U
= 660 VAC/660 VDC
i
1NC Direct Acting 1NO - 1NC Direct Acting 1NO - 1NC Snap Action
UL Listed CSA Certified
TYPICAL APPLICATIONS
1 Control valves and
actuators
1 Grain handling 1 Conveyors 1 Material handling
1 Control valves and
actuators
1 Petroleum plants 1 Chemical plants 1 Waste treatment 1 Hazardous waste
handling
1 Control valves and
actuators
1 Petroleum plants 1 Chemical plants 1 Waste treatment 1 Hazardous waste
handling
1 Power generating 1 Paint booths
For signaling applications:
1 Petroleum Plants 1 Chemical Plants 1 Mining Conveyors
A8Honeywell1 Sensing and Control11-800-537-6945 USA1F1-815-235-6847 International11-800-737-3360 Canada
Limit and Enclosed Switches
Special Purpose Switch Selection Guide
Impact resistance
Multiplunger
Sealed/Analog output
LN
Pg. A111
SPECIAL FEATURES High impact resistance. Factory wired leads. Can replace several individual switches.
Plunger, roller lever. Roller plunger, chisel plunger. 15A - 125, 250, 480 VAC Zinc housing
TYPICAL APPLICATIONS 1 High shock and vibration applications. 1 Machine tools
360° Maintained
High capacity HDLS
Numerous conduit arrangements available.
0.1A - 125 VAC; 10A - 125, 250, 480 VAC;
0.1A - 30 VDC; 0.5A - 125 VDC; 0.25A ­250 VDC
1 Transfer lines
LD
Pg. A82
Low Torque HDLS
Linear CX
Pg. A128
Sealed for outdoor use. Adjustable P.T., O.T. and operating mode. Mounts from front or four sides. Salt water resistant marine version.
4-20 mA, 12.5 to 40 VDC, Analog output
1 Valve position sensing 1 Flow control
Indicator Light HDLS
Limit/Enclosed
(N.C. Lamp Available, Pg. A34
LSQ300 Pg. A35
SPECIAL FEATURES Fixed and adjustable spoke
levers available.
TYPICAL APPLICATIONS 1 Turnstile counting
1 Random direction counting
COMPLETELY FLUOROCARBON-SEALED SWITCHES Pg. A42
Completely fluorocarbon (FC)-sealed switches have a full FC body gasket covering the switch cavity. Rotary types have an extra FC seal on the operating shaft, while plunger versions have FC boot seals.
Honeywell1 Sensing and Control11-800-537-6945 USA1F1-815-235-6847 International11-800-737-3360 CanadaA9
High DC current ratings. 20 amp rating at 120 VAC
(single pole). Plug in or non-plug in. Positive retention lever arm.
1 Power generating stations 1 Presses and other machinery
that create extreme shock/ vibration
1 High current capacity
applications
They are for use in applications where the environment includes fire-resistant synthetic fluids. In addition to most all fluids, FC-sealed switches may be used with such industrial fluids as Cellulube, Fyrquell, Houghto­Safe, Pydraul, and other special cutting and hydraulic oils.
LSQ
Pg. A43
LSS/LST Pg. A42
LSS1H gravity return side rotary limit switches have no return spring mechanism. The weight of the actuating lever must provide the force to restore it to the free position. 5 in. oz. max.
LST1H extra low torque side rotary limit switches have a low force return spring and a maximum operating torque of 12 in. oz.
1 Monitoring feeder roll take up 1 Fill level sensing 1 360° rotation with no
overtravel stop
LOW TEMPERATURE SWITCHES Pg. A42
All forms of HDLS limit switches are also available in low temperature construction with fluorosilicone dia­phragm, shaft seals, and external boot seal (where applicable) plus a low temperature lubricant.
Assembly Modification #7)
See HDLS Order Guides
24 volt LED and 120 or 240 volt neon indicator versions available.
High efficiency bi-polar LED is not polarity sensitive. Draws less than
1.5mA. Parallel lamp wiring does not require a 3rd wire! Allows upgrading to plug-in lighted version without rewiring base receptacle.
1 Applications with high downtime
cost, requiring fast troubleshooting
Limit and Enclosed Switches
Momentary Cable Pull Switch Selection Guide
Momentary cable pull LS single head Momentary cable pull LS duplex head
CLS 2CLS
Pg. A65 Pg. A65
PHYSICAL DESCRIPTION Package size (in.) 4.0H 4.8H
Actuators Cable Cable
SPECIAL FEATURES Covers cable span up to 200 ft. Four conduit thread
CHARACTERISTICS Electrical data (maximum available)
Circuitry 1NO 1NC Direct Acting
ENVIRONMENT Upper 158°F (70°C) 158°F (70°C) Temperature range Lower 30°F (– 1°C) 30°F (–1°C) Sealing† IP 67, NEMA 1, 3, 4, 13 IP 67, NEMA 1, 3, 4, 13
Housing material Metal Metal
† For NEMA definitions, see page E7.
AGENCY LISTING UL Listed
TYPICAL APPLICATIONS
1.8W 1.8W
1.6L 5.9L
sizes available.
I
10A
th
U
660 VAC/660 VDC
i
1NO 1NC Snap Acting
CSA Certified CE Certified
For signaling applications
1 Conveyors 1 Packaging machinery 1 Assembly lines 1 Process equipment 1 Transfer lines
Covers cable spans up to 400 ft. Optional corner installation. Four conduit thread sizes available.
10A
I
th
U
660 VAC/660 VDC
i
(Primary) 1NO 1NC Direct Acting
(Auxiliary) 1NO 1NC Direct Acting 2NO 2NC Snap Action* 1NO 1NC (SDS)*
*For monitoring only.
UL Listed CSA Certified CE Certified
For signaling applications
1 Conveyors 1 Packaging machinery 1 Assembly lines 1 Process equipment 1 Transfer lines
A10Honeywell1 Sensing and Control11-800-537-6945 USA1F1-815-235-6847 International11-800-737-3360 Canada
Loading...
