Safety Guidelines
Caution: Always use a power cable is properly grounded. Please use the AC
cords listed below for each area: |
|
USA...................... |
UL |
Canada................. |
CSA/cUL |
FCC Information
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference will not occur in a particular installation. If this equipment does cause by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio / TV technician for help.
FCC Warning
To assure continued FCC compliance, the user must the provided grounded power supply cord and the provided shielded video interface cables to connect to this equipment. Also, any unauthorized changes or modifications to this equipment would void the user’s authority to operate this device.
Caution (for the product without main power switch)
Since there is not the main power switch used into the product. So it is better to detach the power supply cord from the inlet of the power source while the product is not used for a time. And the main plug of the product is used as the disconnect device, the disconnect device shall remain readily operable.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
Operating Instructions
Important Safeguards
Before using your TV, please read these instructions completely, and keep this manual for future reference.
Carefully observe and comply with all warnings, cautions and instructions placed on the unit or described in the operating instructions or service manual.
The User Manual uses the following symbols, to ensure a safe operation and prevent any damage to operators or properties:
WARNING ----- Ignorance or inappropriate use may cause damage to the product.
ATTENTION --- Ignorance or inappropriate use may cause injury to the user.
Examples:
Prohibition
Warning (Attention) symbol (indicating “Electric
Shock”).
WARNING
Never place TV on an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.
Never overload wall outlets and extension cords. Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.
Keep the product away from moisture:
-Do not expose this appliance to rain or moisture.
-If water penetrates into the product, stop the operation; unplug the connector and contact with your dealer. Continuous use in this case may result in fire or electric shock.
WARNING
Never place item such as vases, aquariums, or candles on top of the TV.
Never use a damaged power cord:
Heavy objects, heat, or tensile force may damage the power cord and cause fire or electric shock.
Never block or cover the slots or openings, in the TV cabinet back, bottom, and sides. Never place the TV:
-on a bed, sofa, rug, or similar surface;
-too close to drapes, curtains, or walls; or
-in a confined space such as bookcase, built-in
cabinet, or any other place with poor ventilation. The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV.
Do not use the product if any abnormality occurs:
If any smoke or odor becomes apparent, unplug the connector and contact the manufacturer immediately. Do not try to repair the product by yourself.
WARNING
Operating Instructions
Avoid using dropped or damaged appliances:
If the product is dropped and the housing is damaged, the internal components may function abnormally. Unplug the connector immediately and contact
the manufacturer for repair. Continuous use of the product may cause fire or electric shock.
WARNING
While it is thundering, do not touch the connecting cables or apparatus.
ATTENTION
Do not install the product close to smoke or moisture: Fire or electric shock may be caused when the product is installed close to smoke or moisture.
Do not installed the product in an area with heavy dust or high humidity:
Fire or electric shock may be caused when the product is installed in a place with heavy dust or high humidity.
Instructions for moving the product:
Ensure that the power connector and any other leads are unplugged before moving the product.
The power cable should be kept away from heat sources:
The heat produced by any heat source may melt the covering of the power cable.
Hold the power connector when removing the power |
Unplug the connector |
cable: |
|
Pulling the power cable itself may damage the vires |
|
inside the cable and cause fire or electric shock. |
|
Do not touch the connector with wet hands:
To avoid risk of electric shock.
ATTENTION
Insert batteries in accordance with instructions: Insert the batteries with correct polarities (positive and negative ).
Incorrect polarities may cause breakage and leakage of the batteries, hurt operators and contaminate the remote controller.
Do not block or cover the vents:
Blocking the vents may cause overheating and fire.
Do not install the product in a place with little or no ventilation. Never cover the vents with towels, blankets or dusters.
Unplug the connector: Unplug the power connector when the product will not
be used for a long time.
Unplug the connector
Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges.(see Section 810 of the National Electric Code.)
Antenna lead-in wire
Antenna discharge unit (NEC Section 810-20)
Ground clamp
Electric service equipment
Ground clamp
Grounding conductors
(NEC Section 810-21)
Power service grounding
electrode system (NEC Art 250 Part H)
Use extreme care to make sure you are never in a position where your body
(or any item your are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits. Never attempt to install any of the following during lightning activity:
a). an antenna system; or b).cables, wires, or any home theater component connected to an antenna or phone system.
Operating Instructions
Notes others
▪Although the LCD screen is made with high-precision technology and has effective pixels of 99.99% or more, black dots may appear or bright points of light (red, blue, or green) may appear constantly on the LCD screen. This is a structural property of the LCD panel and is not a malfunction.
▪LCD (Liquid Crystal Display) may cause interference in image, sound, etc.of the other electronic equipment that is easy to receive electromagnetic waves (i.e. AM radios and video equipment) under certain installed condition. In particular, it may affect electronic equipment beyond the residential until where a LCD TV is used.
▪The screen on this TV is manufactured from glass. To prevent damage, never strike the glass with a sharp or heavy object.
▪Your LCD television contains a small amount of Mercury. When the television is no longer useful, please follow local electronic waste guidelines for proper disposal.
▪If you have the LCD screen facing to the sun, the LCD screen will be damaged. Locate the TV in the place such away from windows side or out side of the rooms with windows.
▪This product is designed for indoor use only. ▪Operating environment:
Temperature: 5°C ~30°C
Humidity: 20% to 85% non-condensing
Precaution
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean only with dry cloth.
7.Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that product heat.
9Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13.Unplug this apparatus during lightning storms or when unused for long periods of time.
14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15.The apparatus shall not be exposed to dripping or splashing and that no objected filled with liquids, such as vase, shall be placed on the apparatus.
Operating Instructions
Contents
Safety Guidelines............................ |
1 |
|
Important Safeguards..................... |
2 |
|
Precaution........................................ |
7 |
|
1. Before use................................... |
9 |
|
1.1 |
Open the Package.......................... |
9 |
1.2 |
Installation....................................... |
9 |
2. Product Features........................ |
10 |
|
3. Supplied Accessories................ |
10 |
|
4. Names and Functions of Parts. 11 |
||
4.1 |
Side View........................................ |
11 |
4.2 |
Front View....................................... |
11 |
4.3 |
Rear View....................................... |
12 |
4.4 |
Remote Control.............................. |
13 |
5. Connect Accessory Devices..... |
16 |
|
6. Basic Operation.......................... |
20 |
|
6.1 |
Power ON/OFF............................... |
20 |
6.2 |
Selection of Input Mode................. |
20 |
6.3 |
Other Function................................ |
21 |
6.4 |
OSD Option Adjustment................. |
22 |
Using the Video Menu................ |
23 |
|
|
■ Adjustment of “Contrast”........... |
23 |
|
■ Adjustment of “Brightness”........ |
23 |
|
■ Adjustment of “Saturation”......... |
23 |
|
■ Adjustment of “Hue”................. |
24 |
|
■ Adjustment of “Sharpness”........ |
24 |
|
■ Selection of “Phase” setting....... |
24 |
|
■ Selection of “Color |
|
|
Temperature”............................ |
25 |
|
■ Selection of “Advance |
|
|
Picture Adjust”........................... |
25 |
Using the Audio Menu................ |
26 |
|
|
■ Adjustment of “Bass”................. |
26 |
|
■ Adjustment of “Treble”............... |
26 |
|
■ Adjustment of “Balance”............ |
27 |
|
■ Selection of “Surround”............. |
27 |
Using the Setup Menu................ |
27 |
■ Selection of “Language”............ |
27 |
■ Setting of “V-Chip”.................... |
28 |
■ Selection of “Closed Caption”.... |
33 |
■ Selection of “Blue Back”............ |
34 |
■ Using “Default”......................... |
34 |
Using the TV Menu(Analog)........ |
35 |
■ Using the “Tuner Mode”............ |
35 |
■ Using the “Searching”............... |
35 |
■ Using the “TV”.......................... |
35 |
■ Using the “Channel Skip”.......... |
36 |
■ Using the “Channel Name”....... |
36 |
■ Selecting Channel..................... |
36 |
■ Channel Preview....................... |
37 |
Using the Geometric Menu......... |
37 |
■ Using “Contrast”....................... |
37 |
■ Using “Brightness”.................... |
37 |
■ Using “Color Temperature”........ |
38 |
■ Using “Auto Setting”.................. |
38 |
■ Using “Phase”........................... |
38 |
■ Using “Manual Clock”.............. |
39 |
■ Using “Display Adjustment”....... |
39 |
Using the DTV Menu(Digital)...... |
40 |
■ Using the “General” Menu........ |
40 |
■ Using the “Caption” Menu......... |
42 |
■ Setting of “Parental”.................. |
44 |
■ EPG(Electronic Program Guide)..45 |
|
■ Selecting Channel..................... |
46 |
■ Channel Preview....................... |
47 |
7. Technical Specification.............. |
48 |
8. Support the Signal Mode........... |
49 |
9. Cleaning Simple |
|
Troubleshooting......................... |
50 |
1. Before use
The product is a 37” WXGA (WXGA resolution) LCD TV Player. It has passed the UL and cUL safety certifications, and is an ideal product for personal and commercial use. The product is a precise electronic product. Users should read the following instructions carefully to maximize the performance and life span of the product:
1.1 Open the Package
-The product is packaged in a carton together with other standard accessories.
Any optional accessories shall be packed separately in another carton.
-Due to the size & weight of the product, it is recommended that it should be moved by a minimum of two people.
-The protective glass and the glass substrate are installed on the front of the product. Since both glasses can be broken and scraped easily, move the product gently. Never place the unit with the glass facing downwards unless it is protected with soft pads.
-When opening the carton, check that the product is in good condition and that all standard accessories and items are included.
-Whenever possible, use the handles on the back of the Display for transport.
1.2 Installation
-Please use caution if wall mounting this product. Follow all directions from the manufacturer of the wall mount and be sure to securely fasten the product to the mount.
While the TV can be wall mounted, improper wall installation may void the warranty.
-Due to the higher power consumption, always use the jack exclusively designed for this product. If an extended line is required, please consult with your service agent.
-The product should be installed on a flat surface to avoid tipping. The distance between the back of the product and the wall should be maintained for proper ventilation.
-Avoid installing the product in the kitchen, bathroom or any other places with higher humidity so as not to shorten the service life of the electronic components.
-Please ensure the product be installed horizontally, any 90 degree clockwise or counterclockwise installation may induce poor ventilation and subsequent component damage.
Operating Instructions
2. Product Features
The 37” LCD TV Player provides quality image displays and is suitable for a variety of multi media applications:
1.Available input signals
-The product provides HDMI input connector.
-The product provides VGA (D-Sub 15 PIN) input connector.
-The product supports PC images resolutions up to (1024 x 768@60Hz) with a vertical frequency of 60Hz.
-The product provides component video (RCA) input connectors. It supports the quality input images of DVD and HDTV (480p/720p/1080i).
-The product provides composite video (RCA) and S-Video (DIN 4 PIN) input connectors.
-The product provides five sets of stereo audio input connectors, one set of audio output connector (RCA) and one set of SPDIF output connector for DTV. Note: The support signal mode, please refer to page 49.
2.Power Management Function
The machine provides an automatic power control function. 3.WXGA LCD TV Panel
The WXGA LCD TV panel provides high resolution and high contrast image.
The number of pixels is 1366 (H) x 768 (V). The contrast is 1000:1. 4.Others
-The LCD TV unit provides cool, middle, warm and user color temperature options. The user may customize their favorite color temperature.
3. Supplied Accessories
Remote control................................................... |
1 |
|
|
Batteries (AAA)................................................... |
2 |
|
|
Owner’s manual (This booklet)........................... |
1 |
|
|
Warranty Card..................................................... |
1 |
|
|
Insertion Card..................................................... |
1 |
|
|
Power Cord......................................................... |
1 |
|
|
* Screws (M5x60)............................................... |
4 |
|
|
* It is used for installation Wall Mount adapter |
|
|
|
brackets on Back Cover. |
Fig.1 |
Screws |
|
When the user buys the Wall Mount from |
|||
|
(M5x60) x 4 |
||
PEERLESS. Please see Fig.1. |
|
||
|
|
10
4. Names and Functions of Parts
4.1 Side View
The functions of the buttons are described as follows:
Sketch map
4.2 Front View
Sketch map
STANDBY: Press
(Standby) to turn on and turn off.
VOL.+/-
A.They are used as / buttons in the OSD Menu screen.
B.Press to adjust the volume.
CH.+/-
A.They are used as / buttons in the OSD Menu screen.
B.Press to scan through channels. To scan quickly through channels, press and hold down either channels.
MENU: Press to display the menu. Press again to exit the menu.
SOURCE: Press to cycle display DTV, TV, AV, S-Video, YPbPr1, YPbPr2, VGA, and HDMI source. When display the OSD-menu, press it to confirm.
(IR) Infrared Receiver: Receives IR signals from the remote control.
(Power on / Standby) LED:
Press
(Power) to turn on and off.
Indicator on (Red) |
Standby mode |
Indicator on (Green) |
Power on mode |
11
Operating Instructions
4.3 Rear View
Sketch map
a
b
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
2 3 4 5 6 7 8 |
9 1 |
||||||||||||||||||
a Use the power cord connect to an earthed 120V, 60Hz AC outlet.
bSignal input and other terminals:
1.ANT1 & ANT2: 75Ω Coaxial connector for Antenna/Cable Network.
Note: ANT 1 is for ATSC(DTV), and ANT 2 is for NTSC(ATV). (Refer to page 19.)
2.OPTICAL OUTPUT: Connect the optical output to the optical input connector of the Amplifier. (Only for DTV)
3.RS-232: The D-SUB 9 Pins terminal is used as a control port for serial communication between PC and Panel. (Only for after-sales service & DTV)
4.Audio Output: Connect audio amplifier or other TV set that with audio input.
5.HDMI INPUT: For high quality picture display purposes. Connects to HDMI or
DVI (with DVI to HDMI Adapter-not provided) digital output connector of the DVD or HDTV Set-top box.
6.D-Sub (VGA) INPUT: For PC display purposes. Connects to the Mini D-Sub 15 Pins analog output connector of the PC display card.
7.VGA/DVI AUDIO INPUT: Connect the audio input terminal to the audio output terminal of DVD or HDTV Set-top box with VGA/DVI output terminal.
8.YPbPr (COMP1) INPUT: Connect the Component video input terminal to the Component output terminal of the video output device.
YPbPr (COMP1) Audio INPUT: Connect the audio input terminal to the audio output terminal of the video output device.
9.YPbPr (COMP2) INPUT: Connect the Component video input terminal to the Component output terminal of the video output device.
YPbPr (COMP2) Audio INPUT: Connect the audio input terminal to the audio output terminal of the video output device.
12
.S-Video INPUT: Connects to the S-Video out jack of your VCR or other video equipment that has S-Video.
S-Video Audio Input: Connect the audio input terminal to the audio output terminal of the S-Video output device.
.Video Input: Connect the component video input terminal to the video output terminal of the video output device.
Video Audio Input: Connect the audio input terminal to the audio output terminal of the Video output device.
4.4Remote Control
1Power (
): Press to turn on and off.
2 Mute ( |
): Press to mute the |
1 |
|
sound. Press again or press |
|||
|
|||
VOL+/- to restore the sound. |
|
||
3 0~9 Number Buttons: In TV |
|
||
mode, press 0~9 to select a |
3 |
||
channel; the channel changes |
|
||
after 2 seconds. |
6 |
||
4 EPG: Press to display EPG |
|||
(Electronic Program Guide) menu. |
8 |
||
5 Source ( |
): Press to select the |
||
|
|||
signal sources. |
|
||
6 DTV: Press to select Digital TV |
|
||
mode. |
|
|
|
7 Dot: Press number buttons with it |
|
||
to select the channels directly in |
|
||
DTV. |
|
|
|
|
|
||
8 VOL +/-: Press to adjust the |
|||
|
|||
volume. |
|
|
|
9 CH +/-: Press to changes channels. |
|
||
|
|||
MTS: Press to repeatedly to cycle |
|
|
through the Multi-channel TV sound |
||
|
||
(MTS) options. Such as Stereo, |
|
|
Mono, or Separate Audio |
|
|
Program (SAP broadcast). |
|
,,,, Enter: Press ,,, to move the on-screen cursor. To select an item, press Enter to confirm.
Exit: Press to return or exit the OSD menu.
Menu: Press to display the OSD menu.
V-Chip: Press to select the child protect mode.
2
4
5
7
9
13
Operating Instructions
CCD: Press to select the Closed
Caption mode.
Freeze: Press to freeze the picture, press again to restore the picture. (This button is not available for VGA mode.)
Display: Press to display the channel information and it disappear after 3 seconds.
Favorite: Press repeatedly to cycle through the favorite channel list.
Add/Erase: Press to add or delete favorite channel.
S.Mode: Adjust the TV sound by selecting one of the preset factory settings, such as Normal, News, Cinema, Concert, or User.
PIC.Size: Press to change the screen size, such as Full, 4:3, Panoramic. (Note: In VGA mode, it can select picture size is Full.
While in DTV mode, it can select picture size is: Full and 4:3. )
1 |
2 |
3 |
|
|
4 |
6 |
5 |
7 |
|
8 |
9 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Recall: Press to return to previous channel.
Sleep: Press to sleep a time for the
TV to turn off automatically, such as
15Min, 30Min, 60Min, 90Min, 120Min and, OFF. To cancel sleep time, press
Sleep repeatedly until sleep OFF appears.
P.Mode: Adjust the TV picture by selecting one of the preset factory settings, such as Hi-Bright, User, Cinema, Normal and Vivid.
System: Press repeatedly to cycle through the system options: AUTO,
NTSC3.58 and PAL.(This button is activate for AV, S-Video input source.)
Color Buttons:
Red: Press this button to access the red item or page. Blue: Press this button to access the blue item or page. Green: Press this button to access the green item or page. Yellow: Press this button to access the yellow item or page.
14
Insertion of Batteries
-Turn the remote control upside down, press and slide off the battery cover.
-Insert two 1.5V (AAA) batteries into the compartment, take care to observe the
and markings indicated inside.
-Replace the cover and slide in reverse until the lock snaps.
Range of Remote Control
-Ensure the remote control is pointed towards the Remote control window on the display unit.
-No obstacles should be placed between the remote control and the remote control window.
-The effective receiving range for the signal is within 5-8 meters from the front of the remote control window, and 30° to the left or right side
and 20° above or below the control window.
Care For Remote Control
Sketch map
20°
20°
30° 30°
-Avoid spilling liquids on the remote.
-Avoid dropping or otherwise jarring the remote.
-Always store the remote control at dry and normal room temperature place.
-If the remote is nor performing satisfactorily, replace the batteries. The batteries should be replaced after one year.
-If the remote control will be idled for a long time (above 1 month) take out the batteries to avoid leakage from the batteries.
-Clean up the entire remote control especially the battery compartment if any leakage found.
-Do not mix using different kind of new and used batteries together to avoid leakage.
15
Loading...
