Page 1
baseLine
WASHING AND DRYING
Page 2
Washing and drying
A compact professional machine for small commercial use.
The new baseLine machines make laundry care easy – efficient,
fast and user-friendly!
With the baseLine series, Schulthess has developed a range of ma-
chines that are tailored to the needs of small businesses and service
providers. baseLine machines are multi-lingual, robust and powerful,
and are used where home appliances reach their limits.
The first-class quality and long service life as well as simple operation
guarantee a smooth operation.
Customised programmes
In addition to the tried-and-tested washing programmes with practi-
cal programme options (prewash, intensive, express wash, energy
saving, spinning, etc.), Schulthess has expanded its range of
segment-specific programmes. The 35 additional profiClean pro-
grammes are designed to meet the needs of particular branches
of industry, such as schools, childcare centres, hairdressers, doctors’
surgeries, cosmetic studios and commercial cleaners (e.g. mop care)
or small businesses.
35 «profiClean»-programmes
Commercial operations (13):
Including 30 °C capes, 40 °C Express for terry towels,
60 °C working clothes, 90 °C kitchen towels intensive
Building cleaners (13):
Including 60 °C mop (with pre-rinse), 40–85 °C mop disinfection,
60 °C wipes, 70 °C autoClean
Wellness Centre (9):
Including 40 °C Express for terry towels,
60 °C cotton disinfection, 60 °C duvet, pillows
baseLine TC 7730 dryer
The baseLine TC 7730 condensation dryer with its electronically
controlled drying programmes is the ideal complement to the wash-
ing machine:
Cotton Mangle Moist, Iron Damp, Slightly Dry, Cabinet Dry, Extra
Dry, and additional programmes such as Mixed Laundry, Synthetic
Laundry, Fine Laundry and Shirts.
Optionally selectable depending on the programme:
Dry+, Express, Antibac and time preset.
Innovations
The new baseLine machine generation impresses with its 34 profi-
Clean programmes that are exactly tailored to your needs; it also
provides 24 free programme slots. The machines newly feature a
modern interactive 4.3" colour display with profiClean programme
selection button and a new, simple programming software.
Plinth with fluff filter drawer
Heavily soiled mop pads and wipes
are efficiently cleaned with the profi-
Clean programmes for building clean-
ers. In order to prevent the fluff from
clogging the drainpipes, the baseLine
washing machine plinth comes with an integrated lint trap drawer
that is specifically developed to meet the needs of building cleaners.
The optimal height of 40 cm of the chrome steel plinth also offers
an ergonomic advantage when loading and unloading the washing
machine and guarantees smooth water discharge at the wall outlet.
Page 3
TOP STANDARD
Schulthess baseLine 7720
TOP STANDARD
Schulthess baseLine TC 7730
1500
Autoclean
Load capacity: 1 – 7 kg
Spin speed: 1500 – 200 rpm
Equipment
• Large 4.3" colour display
• Drum vanes for 3D-Washing
• LED drum lighting
• Drum capacity: 60 l
• Spin speed: 1500 rpm
• g Factor 605
• Residual moisture 44%
• With drain valve or drain pump
• Language selection button (23 languages)
• profiClean programme button
• Favorites for your 6 favourite programmes
• Programme progress and remaining time display
• Door opening angle 180°
• Door hinge right or left
Programmes
• 35 profiClean programmes for small commercial
businesses, building cleaners and special programmes
• 24 freely programmable slots
40– 85 °C disinfection programmes
• Programme groups Sportswear, Busineswear,
Homecare, Antibac
Safety systems
• Control display for water intake / drainage
• Imbalance sensor / child lock / foam level monitoring
Options
• Hot water connection
• Programme expansion module with PC interface
• Coin box interface
• Machine plinth in chrome steel, H: 35.5 cm
• Machine plinth with fluff filter drawer, H: 40 cm
Load capacity: 1 – 7 kg
Equipment
• Condensation dryer
• Large 4.3" colour display
• Stainless steel drum
• LED drum lighting
• Drum capacity: 118 l
• Electronically and time-controlled drying programmes
• Residual moisture measurement
• Language selection button
• Excellent noise insulation
• Crease protection
• Programme progress and remaining time display
• Door opening angle 180°
• Door hinge right or left
Programmes
Automatic programs with 5 drying levels
•
from mangle moist to extra-dry.
•
Time-controlled drying programmes 10–150 minutes
•
Gentle drying at reduced temperature
•
7 kg of laundry is cabinet dry in 83 min. (cotton, 1600 rpm)
Safety systems
• Temperature monitoring
• Child lock / condensed water drainage monitoring
Options
• Stacking kit for washer-dryer tower
• Coin box interface
• Machine plinth in chrome steel, H: 35,5 cm
Safety as per Machinery Directive 2006 / 42 / EG
Page 4
Company or brand name Schulthess
Type of appliance Washing machine
Type or sales description baseLine 7720
Product number
Model with drain pump (P) 7720.1PU
Model with drain valve (V) 7720.1UV
Application features
Load capacity max. kg 7
Drum capacity l 60
Spinning speed max. rpm 1500
g Factor g 605
Residual moisture
Structural design
Footed appliance with work surface •
Door hinge
1)
% 44
3)
r / l / w
Dimensions
Height cm 85
Width cm 60
Depth including distance from wall cm 67
Depth with door open (front loader) cm 110
Height (adjustable) cm 1
Weight when empty kg 90
Equipment
Detergent tank and drum chrome-nickel steel
Loading opening
cm 34 / 180°
Programme time display •
Load quantity display •
Automatic door opening •
LED drum lighting •
Connecting cable m 1,6
Drain:
– Drain hose with benda, only model (P) m 1,5
– Model with drain pump (P)
– Model with drain valve (V)
mm 21
mm 50
Electric power and water supply
Electrical connection 400 V 2 N~ / 50Hz / 4,6kW / 10A
Voltage / connected loads / fuse 230 V 1 N~ / 50Hz / 2,3kW / 10A
Water connection
– Pressure hose G ¾" with fine filter m 1,5
– Can be connected to cold water / hot water cold water / hot water 70 °C
– Water pressure bar 1–10
Options
– Door hinge left
– Hot water connection
– Drain valve or drain pump
– Connection for 8 liquid
detergents with dosing pump
– Machine plinth
– Machine plinth with
drawer for fluff filter
Safety and service
Conforms to the European Machinery Directive 2006/42/EC
Country of origin Switzerland
Guarantee
Service by Schulthess Maschinen AG
Name and address of supplier Schulthess Maschinen AG,
1 year
CH-8633 Wolfhausen/ZH
Company or brand name Schulthess
Type of appliance Condensation dryer
Type or sales description baseLine TC 7730
Product number 7730.1U
Load capacity max. kg 7
Structural form
Footed appliance with work surface •
Standard unit for wash and dry column •
Door hinge
Dimensions
3)
r / l / w
4)
Height cm 85
Width cm 60
Depth including space from wall cm 64
Height for built-in installation cm 85,5
Depth with door open cm 122
Height adjustable cm 2
Drying control
By time selection
5)
Automatic by electronic moisture detection
•
6)
•
System and equipment
Drying technology Air condensation system
Programme time display •
Load quantity display •
Automatic door opening •
Loading opening cm vorne,
36 / 31 / 180°
LED drum lighting •
Connecting cable m 1,5
Outlet hose m 2 /
22 mm
Condensate drainage in container / Drainage direct •
Exhaust line –
Maximum drainage height m 1
Exhaust hose
Power supply
Electrical connection
100 mm m –
7)
Voltage V 400 V 2N~ / 230 V 1N~
Connected values kW 2,8 / 2,1
Fuse protection AT 10 / 10
Safety and service
Conforms to the European Machinery Directive 2006/42/EC
Country of origin Switzerland
Guarantee 1 year
Service by Schulthess Maschinen AG
Name and address of supplier Schulthess Maschinen AG,
CH-8633 Wolfhausen/ZH
Explanations:
– Available or yes • Not available or no
3) Door hinge: l = left, r = right, w = can be changed
Example: l/w means that the machine is delivered with the door hinge to the left, but the
direction of opening can be changed.
4) The stated dimensions are minimum dimensions for the niche where the machine is built
in. Further dimensions can be found in the dimension sheets.
5) Set the degree of drying according to the laundry items, as shown in the operating
instructions.
6) Degree of drying is maintained automatically.
7) Information on switchover options can be found in the installation instructions,
where required.
Explanations:
– Available or yes • Not available or no
1) Values determined in the 60°C cotton programme.
3) Door hinge: l = left, r = right, w = can be changed
Example: l/w means that the machine is delivered with the door hinge to the left,
but the direction of opening can be changed.
7) Information on switchover options can be found in the installation instructions,
where required.
Note: State of the table details as december 2017, subject to further developments.
Schulthess Maschinen AG
Landstrasse 37, CH-8633 Wolfhausen ZH
Tel. +41 55 253 51 11
[email protected]
www.schulthess.ch
01.19 / e1000 / v.19.1 Printed in Switzerland / Subject to changes
