Quick Selection Guide 2021

Universal Enclosures

se.com/enclosures

Universal Enclosures ranges EMC

Outdoor

Heavy Duty

Electrical

distribution

ATEX

Seismic

Spacial

Boxes…

From 85 x 85 mm

To 400 x 800 mm

Wall-mounting

enclosures

Wall-mounting

enclosures

Floor-standing

enclosures

SBM

boxes

… and HMI

S3D Wall-mounting

enclosures

From 300 x 200 mm

To 1400 x 1000 mm

VDM 19" enclosures S3D 19" enclosures

From 300 x 200 mm

To 1400 x 1000 mm

SM Floor-standing compact enclosures

From 1200 x 800 mm

To 2200 x 1600 mm

Industrial

SDB Junction boxes

S3CM, SD, SDF, SDX Control desks SF, SMX PC racks

S3HD

Wall-mounting Heavy Duty enclosures

S3DB, S3DM

S3HF

Electromagnetic compatibility

S3DEX Explosive atmospheres

S3D6G

mounting enclosure*

Wall-

seismic

Floor-standing

enclosures

From 1200 x 600 mm

To 2200 x 1200 mm

Boxes and

Wall-mounting

From 150 x 80 mm

To 1200 x 1000 mm

Choose your enclosure

Floor-standing

enclosures

From 1400 x 1000 mm

Boxes

From 74 x 74 mm

To 540 x 720 mm

To 2000 x 1600 mm

SF Floor-standing suitable enclosures Electronic applications Automobile applications

SBX Industrial Boxes

SFX Floor-standing suitable

TBS ABS industrial boxes

TBP Polycarbonate industrial boxes

SFM

Motor control

centers*

S3X Wall-mounting enclosures

SMX Floor-standing monobloc

PLS Insulating modular boxes

SFHD Floor-standing Heavy Duty enclosures

SF, SFP

Electrical distribution*

SFHF

Electromagnetic compatibility**

SF 6G, SFP 5G

Seismic applications*

Thalassa

Wall-mounting

Floor-standing

PLM Wall-mounting

enclosures

polyester enclosures

From 310 x 215 mm

To 1056 x 852 mm

PLA Floor-standing enclosures

From 500 x 500 mm

To 1500 x 1250 mm

* For more information, see Universal Enclosures general catalogue. ** On demand.

PLD Floor-standing DIN enclosures

PHD

Floor-standing Heavy Duty enclosures

Thermal management system

ClimaSys CV Ventilation systems

ClimaSys CR PTC resistance heaters

ClimaSys CE Air-air exchangers

ClimaSys CRS Ultra thin resistance heaters

ClimaSys CE Air-water exchangers

ClimaSys CC Thrermal control

Mounting accessories

Mounting plates Chassis Rails

Brackets

Plates Nuts

Modular distribution

ClimaSys CU Cooling units

Uprights

ClimaSys DT Dataloggers

Select the right accessory

Panels Covers Bar supports Chassis

Cable management

Simple Cable Entries Multiple Cable Entries

Transversal accessories

LED lamps Document pockets Earth braids Door switches Door retainers

Enclosure spare parts

Cable gland plate Doors Door accessories Fixing hardware Roof accessories

Software and tools

Spacial.confDigital Rules ProClimaWeb Product Selectors Ef fiClima

Customized solutions

Configured offer Engineered to order (ETO) oer

How to define an enclosure solution?

Invariables

Switchgear and Controlgear are the cornerstone of all electrical systems in every segment, from industry to infrastructure, building, energy, and transport. Selecting the correct enclosure and thermal management is

Dusty

crucial in helping guarantee the target performance.

Hard cleaning process

High temperature

Ice

Heat up

Cooldown

Low maintenance

Certifications

This also safeguards the equipment installed inside thereby helping ensure continuity of service.

Correctly selecting an enclosure and thermal solution

Many influences must be considered when defining an enclosure system. They may be split into three groups:

• Protection (Equipment and people)

• Thermal management

• Solution profitability

Protection

Enclosures help protect the equipment installed inside against the external environment, and help protect people against accidental contact with the electrical equipment it contains.

Protection against the environment

This concept includes the following: Rain / Snow / Ice / Humidity / Pollution / Chemicals / UV Radiation / Low temperatures / High temperatures / Cleaning process / Dust / Salt / Sand storms / Wind / Chemicals / Fauna / Flora / Vandalism / Burglary / …

Helping protect people from electrical accidents

This concept includes the following: Public areas / Non segregated private areas / Segregated private areas / Vandalism / Burglary

Humidity

Active

Life time

Efficiency

No derating

Pollution

Chemicals

Passive

UV radiation

Dry up

Low temperature

Public safety

The environment and the enclosure

The table below is only indicative and not binding. It shows, in a general concept, the optimized performance of the Universal Enclosures ranges according to the environmental conditions, taking into account technical and commercial criteria:

•

Highly recommended

• Recommended

• - Not recommended

Environment Enclosure material

Indoor clean environment (1) Hard cleaning process (2) - Outdoor (no public access) Outdoor (public access) Harsh chemicals Solar radiation Sand storm - Temperature > 40ºC (3) Temperature < 5ºC (3) Salty environment - - Sea water splashes - - Humidity > 70% (3) Impact Vandalism Burglary Heavy pollution • Vibration (Marine application) Seismic Electro Magnetic Interference - - - - - -

(1) Not considering F&B process (2) e.g. F&B process (3) Always using ClimaSys solutions (4) Marine solar plants

Steel Steel

Heavy Duty

- - - - - -

304L stainless steel

316L stainless steel

(4)

Stainless steel Paint

- - -

(4)

Polyester Polyester

Heavy Duty

Thermal management

Thermal management system must help guarantee control of the temperature and humidity inside the enclosure. The correct solution must be based on a robust process starting with the environment diagnostic, then calculating the parameters and defining the best architecture (Enclosures + Equipment installed + Thermal solution). ClimaSys is the definitive solution based on ClimaSys DT / EffiClima / ProClima.

Industry and Infrastructure Offer

A material for every environment

Steel

Robust solution for industrial environments

The industrial environment in mechanical plants is especially demanding as regards the protection of electric and electronic components against dust, oil splashes and impacts. This environment therefore requires a range that is suited to the applications and easy to implement.

● Universal range, for industry.

● Functional enclosure, for the electrical distribution.

● Motor Control Centres - fixed MCC

● Heavy Duty range, for outdoor applications in private locations.

● Seismic and nuclear enclosure.

● E.M.C. range, against electromagnetic disturbances

(treated with Aluzinc).

● Range of ATEX enclosures, for potentially explosive atmospheres.

● Human-machine interface enclosures range.

● Customized solutions, for specific applications.

Solution:

The Spacial range in steel (industrial boxes, wall-mounting, monobloc and floor-standing enclosures).

304L - 316L stainless steel

Demanding industrial environments

Food and beverage, pharmaceutical, petrochemical and infrastructure industries are particularly demanding in terms of hygiene and resistance to corrosion. With two grades of stainless steel:

● 304L stainless steel: resistance to corrosion and cleanability (often

used in food production environments).

● 316L stainless steel, also known as "marine stainless steel":

Very high resistance to corrosion (saline or chlorinated environments).

Insulating polyester and plastic materials (ABS, polycarbonate)

Severe infrastructures and industrial environments

Outdoor infrastructures and electrical installations are exposed to direct sunlight, rain, saline mist, extreme temperatures, oil splashes, chemical and corrosive agents, and are in contact with the public.

● Universal range, for industry and infrastructures.

● Heavy Duty range, for harsh outdoor applications in public areas.

Solution:

The Spacial range in stainless steel (wall-mounting, monobloc and suitable floor-standing enclosures).

Solution:

The Thalassa range (boxes, wall-mounting and floor-standing enclosures).

Stainless steelInsulating materials Steel

Spacial SBM, SDB

Spacial SDB

External dimensions (mm)

H W D References References

85 85 49 NSYDBN88 NSYDB88M -

105 105 49 NSYDBN1010 NSYDB1010M -

Low cover

155 105 61 NSYDBN1510 NSYDB1510M NSYPMD1510 206 156 83 NSYDBN2015 NSYDB2015M NSYPMD2015 256 206 93 NSYDBN2520 - NSYPMD2520 307 257 11 6 NSYDBN3025 - NSYPMD3025

Steel industrial boxes

Metallic junction boxes

IP55 - IK07 - RAL 7035

Models without knock-outs Models with knock-outs

Plain mounting plate

Spacial SBM

External dimensions (mm)

H W D

150 150 80 NSYSBM15158 125 135 NSYMM11SB NSYAMRD15357SB 150 150 120 NSYSBM151512 125 135 NSYMM11SB NSYAMRD15357SB 150 200 80 NSYSBM15208 125 185 NSYMM12SB NSYAMRD20357SB 150 200 120 NSYSBM152012 125 185 NSYMM12SB NSYAMRD20357SB 150 300 80 NSYSBM15308 125 285 NSYMM13SB NSYAMRD30357SB 150 300 120 NSYSBM153012 125 285 NSYMM13SB NSYAMRD30357SB 150 400 80 NSYSBM15408 125 385 NSYMM14SB NSYAMRD40357SB 150 400 120 NSYSBM154012 125 385 NSYMM14SB NSYAMRD40357SB 200 200 80 NSYSBM20208 175 185 NSYMM22SB NSYAMRD20357SB 200 200 120 NSYSBM202012 175 185 NSYMM22SB NSYAMRD20357SB 200 300 80 NSYSBM20308 175 285 NSYMM23SB NSYAMRD30357SB 200 300 120 NSYSBM203012 175 285 NSYMM23SB NSYAMRD30357SB 200 400 80 NSYSBM20408 175 385 NSYMM24SB NSYAMRD40357SB 200 400 120 NSYSBM204012 175 385 NSYMM24SB NSYAMRD40357SB 200 500 80 NSYSBM20508 175 485 NSYMM25SB NSYAMRD50357SB 200 500 120 NSYSBM205012 175 485 NSYMM25SB NSYAMRD50357SB 200 600 80 NSYSBM20608 175 585 NSYMM26SB NSYAMRD60357SB 200 600 120 NSYSBM206012 175 585 NSYMM26SB NSYAMRD60357SB 200 800 120 NSYSBM208012 175 785 NSYMM28SB NSYAMRD80357SB 300 300 120 NSYSBM303012 275 285 NSYMM33SB NSYAMRD30357SB 300 400 120 NSYSBM304012 275 385 NSYMM34SB NSYAMRD40357SB 300 500 120 NSYSBM305012 275 485 NSYMM35SB NSYAMRD50357SB 300 600 120 NSYSBM306012 275 585 NSYMM36SB NSYAMRD60357SB 300 800 120 NSYSBM308012 275 785 NSYMM38SB NSYAMRD80357SB 400 400 120 NSYSBM404012 375 385 NSYMM44SB NSYAMRD40357SB 400 500 120 NSYSBM405012 375 485 NSYMM45SB NSYAMRD50357SB 400 600 120 NSYSBM406012 375 585 NSYMM46SB NSYAMRD60357SB 400 800 120 NSYSBM408012 375 785 NSYMM48SB NSYAMRD80357SB

(1) Not compatible with Bus box.

Steel industrial boxes

RAL 7035

Spacial SBM - Flat box

IP66 - IK10

Mounting Plate

H W References

DIN Rail

Spacial S3CM

Dimensions

H W D

300 300 200 NSYS3CM303020 300 400 200 NSYS3CM304020 400 400 200 NSYS3CM404020 400 600 250 NSYS3CM406025 500 500 250 NSYS3CM505025 600 600 200 NSYS3CM606020 600 800 300 NSYS3CM608030 800 600 300 NSYS3CM806030

* Enclosure equipped with a cable-gland plate.

Spacial S3CM

Control enclosure

IP54 - IK10 - RAL 7035

Spacial SD, SDF, SDX

Human-Machine Interface

Keyboard

Dimensions

H W D

250 600 116 NSYCMT2560110 - -

- 500 200 - Keyboard NSYCMBPT

Spacial S3CM Box-keyboard

IP54 - IK10 - RAL 7040

Spacial S3CM

Support

RAL 7035

Suspension system available in the catalogue

Boxes

and HMi

Spacial SD

Control desk dimensions (mm)

H W D

1000 600 469 NSYSD6 - - - - - - 1000 600 500 - - - - NSYSDX6 - - 1000 800 469 NSYSD8 - - - - - - 1000 800 500 - - - - NSYSDX8 - - 1000 1000 469 - NSYSD10 - - - - - 1000 1200 469 - NSYSD12 - - - - - 1000 600 600 - - NSYSD6R - - - - 1000 800 600 - - NSYSD8R - - - - 1000 1000 500 - - - - - NSYSDX10 - 1000 1000 600 - - - NSYSD10R - - - 1000 1200 500 - - - - - NSYSDX12 - 1000 1200 600 - - - NSYSD12R - - - 1400 800 845 - - - - - - NSYSDF88 1400 1000 845 - - - - - - - NSYSDF108 1400 1200 845 - - - - - - - NSYSDF128 1400 1600 845 - - - - - - - NSYSDF168 1400 800 1045 - - - - - - NSYSDF810 1400 1000 1045 - - - - - - - NSYSDF1010 1400 1200 1045 - - - - - - - NSYSDF1210 1400 1600 1045 - - - - - - - NSYSDF1610

With fixed rear panel With removable rear panel With removable rear panel With rear door 1 door 2 doors 1 door 2 doors 1 door 2 doors 1 door 2 doors

Compact control desk IP55 - IK10 - RAL 7035

Sheet steel

Spacial SDX

Compact control desk

IP55 - IK10

Sheet stainless steel

Spacial SDF

Control desk with console

IP55 - IK10 - RAL 7035

Sheet steel

Spacial SF PC rack, SMX PC rack

Control desk dimensions (mm)

H W D No. of compartments References References

1600 600 600 3 NSYSF16660PC NSYSMX16660PC 1600 600 800 3 NSYSF16680PC - 1800 600 600 4 NSYSF18660PC NSYSMX18660PC 1800 600 800 4 NSYSF18680PC -

* IP40 with hinged keyboard.

Spacial SF PC rack

IP55* - IK10 - RAL 7035

Spacial SMX PC rack

304L Stainless steel

IP55 - IK10

Spacial S3D

Steel wall-mounting enclosures

Specifications

Dimensions

H W D

300 200 150 1 3.02 300 250 150 1 3.48 300 300 150 1 3.90 300 300 200 1 4.50 300 400 150 1 4.82 300 400 200 1 5.60 400 300 150 1 4.90 400 300 200 1 5.00 400 400 200 1 6.50 400 600 200 1 10.50 400 600 250 1 12.00 500 300 200 1 7.50 500 400 200 1 9.30 500 400 250 1 10.20 500 500 200 1 11.18 500 500 250 1 12.06 600 400 200 1 11.00 600 400 250 1 12.00 600 500 250 1 16.20 600 600 200 1 14.00 600 600 250 1 15.00 600 600 300 1 17.00 600 600 400 1 19.00 600 800 300 1 25.50 700 500 250 1 15.00 800 600 200 1 21.00 800 600 250 1 23.00 800 600 300 1 25.00 800 600 400 1 29.00 800 800 250 1 30.00 800 800 300 1 32.00 800 1000 300 1 38.00 800 1000 300 2 43.50

800 1200 300 2 46.00 1000 600 250 1 28.00 1000 600 300 1 30.60 1000 600 400 1 33.00 1000 800 250 1 35.00 1000 800 300 1 38.00 1000 800 400 1 42.00 1000 1000 300 1 46.00 1000 1000 300 2 46.00 1000 1200 300 2 53.00 1000 1200 400 2 60.00 1200 600 300 1 37.00 1200 600 400 1 42.00 1200 800 300 1 45.00 1200 800 400 1 49.00 1200 1000 300 1 53.00 1200 1000 300 2 54.00 1200 1000 400 2 61.00 1200 1200 300 2 64.00 1200 1200 400 2 90.00 1400 1000 300 2 80.00

(1) For other dimensions, see our application offer. (2) Enclosure without mounting plate. (3) Double door: IP55.

(1)

Nº of

Weight

doors

(kg)

(2)

NSYS3D3215P NSYS3D3215 NSYS3D32515P NSYS3D32515 NSYS3D32515T NSYS3D3315P NSYS3D3315 NSYS3D3315T NSYS3D3320P NSYS3D3320 NSYS3D3320T NSYS3D3415P NSYS3D3415 NSYS3D3415T NSYS3D3420P NSYS3D3420 NSYS3D3420T NSYS3D4315P NSYS3D4315 NSYS3D4315T NSYS3D4320P NSYS3D4320 NSYS3D4320T NSYS3D4420P NSYS3D4420 NSYS3D4420T NSYS3D4620P NSYS3D4620 NSYS3D4620T NSYS3D4625P NSYS3D4625 NSYS3D4625T NSYS3D5320P NSYS3D5320 NSYS3D5320T NSYS3D5420P NSYS3D5420 NSYS3D5420T NSYS3D5425P NSYS3D5425 NSYS3D5425T NSYS3D5520P NSYS3D5520 NSYS3D5520T NSYS3D5525P NSYS3D5525 NSYS3D5525T NSYS3D6420P NSYS3D6420 NSYS3D6420T NSYS3D6425P NSYS3D6425 NSYS3D6425T NSYS3D6525P NSYS3D6525 NSYS3D6525T NSYS3D6620P NSYS3D6620 NSYS3D6620T NSYS3D6625P NSYS3D6625 NSYS3D6625T NSYS3D6630P NSYS3D6630 NSYS3D6630T NSYS3D6640P NSYS3D6640 NSYS3D6640T NSYS3D6830P NSYS3D6830 NSYS3D6830T NSYS3D7525P NSYS3D7525 NSYS3D7525T NSYS3D8620P NSYS3D8620 NSYS3D8620T NSYS3D8625P NSYS3D8625 NSYS3D8625T NSYS3D8630P NSYS3D8630 NSYS3D8630T NSYS3D8640P NSYS3D8640 NSYS3D8640T NSYS3D8825P NSYS3D8825 NSYS3D8825T NSYS3D8830P NSYS3D8830 NSYS3D8830T NSYS3D81030P NSYS3D81030 NSYS3D81030DP NSYS3D81030D NSYS3D81230DP NSYS3D81230D NSYS3D10625P NSYS3D10625 NSYS3D10625T NSYS3D10630P NSYS3D10630 NSYS3D10630T NSYS3D10640P NSYS3D10640 NSYS3D10640T NSYS3D10825P NSYS3D10825 NSYS3D10825T NSYS3D10830P NSYS3D10830 NSYS3D10830T NSYS3D10840P NSYS3D10840 NSYS3D10840T NSYS3D101030P NSYS3D101030 NSYS3D101030T NSYS3D101030DP NSYS3D101030D NSYS3D101030DT NSYS3D101230DP NSYS3D101230D NSYS3D101240DP NSYS3D101240D NSYS3D12630P NSYS3D12630 NSYS3D12630T NSYS3D12640P NSYS3D12640 NSYS3D12640T NSYS3D12830P NSYS3D12830 NSYS3D12830T NSYS3D12840P NSYS3D12840 NSYS3D12840T NSYS3D121030P NSYS3D121030 NSYS3D121030T NSYS3D121030DP NSYS3D121030D NSYS3D121030DT NSYS3D121040DP NSYS3D121040D NSYS3D121230DP NSYS3D121230D NSYS3D121240DP NSYS3D121240D NSYS3D141030DP NSYS3D141030D

IP66

Plain door Glazed door Cable-gland plates

With mounting

plate

Spacial S3D

(3)

(4)

- IK10

- RAL 7035

Without

mounting plate

Without

mounting plate

Cable-entry accessories Composition accessories

Standard

steel

Aluminium

NSYTLA NSYTLAU NSYTLA NSYTLAU

Steel with cut-out

for FL membrane

(5)

FlexiCable

NSYTLB NSYTLBU NSYTLBFL - NSYTLC NSYTLCU NSYTLCFL NSYTLCME NSYTLB NSYTLBU NSYTLBFL - NSYTLD NSYTLDU NSYTLDFL NSYTLDME NSYTLB NSYTLBU NSYTLBFL - NSYTLC NSYTLCU NSYTLCFL NSYTLCME NSYTLD NSYTLDU NSYTLDFL NSYTLDME

NSYTLF NSYTLFU NSYTLFFL NSYTLFME NSYTLF NSYTLFU NSYTLFFL NSYTLFME

NSYTLC NSYTLCU NSYTLCFL NSYTLCME NSYTLD NSYTLDU NSYTLDFL NSYTLDME NSYTLD NSYTLDU NSYTLDFL NSYTLDME NSYTLE NSYTLEU NSYTLEFL NSYTLEME NSYTLE NSYTLEU NSYTLEFL NSYTLEME NSYTLD NSYTLDU NSYTLDFL NSYTLDME NSYTLD NSYTLDU NSYTLDFL NSYTLDME NSYTLE NSYTLEU NSYTLEFL NSYTLEME

NSYTLF NSYTLFU NSYTLFFL NSYTLFME NSYTLF NSYTLFU NSYTLFFL NSYTLFME NSYTLG NSYTLGU NSYTLG2FL NSYTLG NSYTLGU NSYTLG2FL

(6)

NSYTLGME NSYTLGME

NSYTLD NSYTLDU NSYTLDFL 2 x NSYTLDME NSYTLE NSYTLEU NSYTLEFL NSYTLEME

NSYTLF NSYTLFU NSYTLFFL NSYTLFME NSYTLF NSYTLFU NSYTLFFL NSYTLFME NSYTLG NSYTLGU NSYTLG2FL NSYTLG NSYTLGU NSYTLG2FL

(6)

NSYTLGME NSYTLGME

NSYTLD NSYTLDU NSYTLDFL 2 x NSYTLDME NSYTLD NSYTLDU NSYTLDFL 2 x NSYTLDME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME

NSYTLF NSYTLFU NSYTLFFL NSYTLFME NSYTLG NSYTLGU NSYTLG2FL NSYTLG NSYTLGU NSYTLG2FL

(6)

NSYTLGME NSYTLGME

NSYTLD NSYTLDU NSYTLDFL 2 x NSYTLDME NSYTLD NSYTLDU NSYTLDFL 2 x NSYTLDME NSYTLD NSYTLDU NSYTLDFL 2 x NSYTLDME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME

NSYTLG NSYTLGU NSYTLG2FL NSYTLG NSYTLGU NSYTLG2FL

(6)

NSYTLGME NSYTLGME

NSYTLD NSYTLDU NSYTLDFL 2 x NSYTLDME NSYTLD NSYTLDU NSYTLDFL 2 x NSYTLDME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME NSYTLE NSYTLEU NSYTLEFL 2 x NSYTLEME

(4) Glazed door: IK08. (5) FL13 for entry type B. FL21 for all other entries. (6) Exists with 1 cut-out NSYTLGFL.

Standard locks

Internal door

- -

NSYPIN43 NSYPIN43

NSYPIN54 NSYPIN54

NSYPIN64 NSYPIN64

NSYPIN75 NSYPIN86 NSYPIN86 NSYPIN86 NSYPIN86

NSYPIN106 NSYPIN106 NSYPIN106 NSYPIN108 NSYPIN108 NSYPIN108

NSYPIN126 NSYPIN126 NSYPIN128 NSYPIN128

(7) To adjust the depth of the internal door, please order the step slides. (8) For the double mounting plates, order also ref. NSYSDRSDCR300 (D300) or NSYSDRSDCR400 (D400).

(7)

Step slides Canopy Fixing on post

NSYTJ2015 NSYTJ2515

NSYSDCR200 NSYTJ3020 NSYSFPSC30 NSYAEFPFS3DW30

NSYSDCR200 NSYTJ4020 NSYSFPSC40 NSYAEFPFS3DW40

NSYSDCR200 NSYTJ3020 NSYSFPSC30 NSYAEFPFS3DW30 NSYSDCR200 NSYTJ4020 NSYSFPSC40 NSYAEFPFS3DW40 NSYSDCR200 NSYTJ6020 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR250 NSYTJ6025 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR200 NSYTJ3020 NSYSFPSC30 NSYAEFPFS3DW30 NSYSDCR200 NSYTJ4020 NSYSFPSC40 NSYAEFPFS3DW40 NSYSDCR250 NSYTJ4025 NSYSFPSC40 NSYAEFPFS3DW40 NSYSDCR200 NSYTJ5020 NSYSFPSC50 NSYAEFPFS3DW50 NSYSDCR250 NSYTJ5025 NSYSFPSC50 NSYAEFPFS3DW50 NSYSDCR200 NSYTJ4020 NSYSFPSC40 NSYAEFPFS3DW40 NSYSDCR250 NSYTJ4025 NSYSFPSC40 NSYAEFPFS3DW40 NSYSDCR250 NSYTJ5025 NSYSFPSC50 NSYAEFPFS3DW50 NSYSDCR200 NSYTJ6020 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR250 NSYTJ6025 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR300 NSYTJ6030 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR400 NSYTJ6040 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR300 NSYTJ8030 NSYSFPSC80 NSYAEFPFS3DW80 NSYSDCR250 NSYTJ5025 NSYSFPSC50 NSYAEFPFS3DW50 NSYSDCR200 NSYTJ6020 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR250 NSYTJ6025 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR300 NSYTJ6030 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR400 NSYTJ6040 NSYSFPSC60 NSYAEFPFS3DW60 NSYSDCR250 NSYTJ8025 NSYSFPSC80 NSYAEFPFS3DW80 NSYSDCR300 NSYTJ8030 NSYSFPSC80 NSYAEFPFS3DW80 NSYSDCR300 NSYTJ10030 NSYSDCR300 NSYTJ10030 NSYSDCR300 NSYSDCR250 NSYTJ6025 NSYSDCR300 NSYTJ6030 NSYSDCR400 NSYTJ6040 NSYSDCR250 NSYTJ8025 NSYSDCR300 NSYTJ8030 NSYSDCR400 NSYTJ8040 NSYSDCR300 NSYTJ10030 NSYSDCR300 NSYTJ10030 NSYSDCR300 NSYSDCR400 NSYSDCR300 NSYTJ6030 NSYSDCR400 NSYTJ6040 NSYSDCR300 NSYTJ8030 NSYSDCR400 NSYTJ8040 NSYSDCR300 NSYTJ10030 NSYSDCR300 NSYTJ10030 NSYSDCR400 NSYTJ10040 NSYSDCR300 NSYSDCR400 NSYSDCR300 NSYTJ10030

NSYTJ3015 NSYSFPSC30 NSYAEFPFS3DW30

NSYTJ4015 NSYSFPSC40 NSYAEFPFS3DW40

NSYTJ3015 NSYSFPSC30 NSYAEFPFS3DW30

(8)

NSYTJ12030

(8)

NSYTJ12030

(8)

NSYTJ12040

(8)

NSYTJ12030

(8)

NSYTJ12040

- -

Full width wall

fixing lugs

NSYAEFPFS3DW20

NSYAEFPFS3DW100 NSYAEFPFS3DW100 NSYAEFPFS3DW120 NSYAEFPFS3DW60 NSYAEFPFS3DW60 NSYAEFPFS3DW60 NSYAEFPFS3DW80 NSYAEFPFS3DW80 NSYAEFPFS3DW80 NSYAEFPFS3DW100 NSYAEFPFS3DW100 NSYAEFPFS3DW120 NSYAEFPFS3DW120 NSYAEFPFS3DW60 NSYAEFPFS3DW60 NSYAEFPFS3DW80 NSYAEFPFS3DW80 NSYAEFPFS3DW100 NSYAEFPFS3DW100 NSYAEFPFS3DW100 NSYAEFPFS3DW120 NSYAEFPFS3DW120 NSYAEFPFS3DW100

NSYTFPCRN4 NSYTFPCRN6 NSYTFPCRN6

NSYTFPCRN4 NSYTFPCRN4 NSYTFPCRN5 NSYTFPCRN5 NSYTFPCRN4 NSYTFPCRN4

NSYTFPCRN6 NSYTFPCRN6 NSYTFPCRN6 NSYTFPCRN6 NSYTFPCRN8 NSYTFPCRN5 NSYTFPCRN6 NSYTFPCRN6 NSYTFPCRN6 NSYTFPCRN6 NSYTFPCRN8 NSYTFPCRN8 NSYTFPCRN10

NSYTFPCRN6 NSYTFPCRN6 NSYTFPCRN6 NSYTFPCRN8 NSYTFPCRN8 NSYTFPCRN8 NSYTFPCRN10

NSYTFPCRN8 NSYTFPCRN8 NSYTFPCRN10

Door cross rails

Description

3 mm double bar NSYAEDLB3S3D CNOMO 6.5 mm triangular NSYAEDLT6S3D 8 mm triangular NSYAEDLT8S3D

* Delivered with 1 plastic key.

References

of form insert*

Standard handles with keys

Description

1242 NSYAEDL1242S3D 405 NSYAEDL405S3D 455 NSYAEDL455S3D 2433A NSYAEDL2433S3D 3524E NSYAEDL3524S3D 3131A NSYAEDL3131AS3D 610 NSYAEDL610S3D

* Delivered with 2 keys.

References of

handle with keys*

Padlock

Description Reference

Padlockable 405

(1) Diameter 8 mm.

(1)

NSYAEDLPADS3D

Wall-fixing lugs

Description References

Passivated zinc-coated steel Stainless-steel 304L NSYAEFPFXSC

NSYAEFPFSC

Full-width wall-fixing lugs

Width (mm) References

200 NSYAEFPFS3DW20 300 NSYAEFPFS3DW30 400 NSYAEFPFS3DW40 500 NSYAEFPFS3DW50 600 NSYAEFPFS3DW60 800 NSYAEFPFS3DW80 1000 NSYAEFPFS3DW100 1200 NSYAEFPFS3DW120

Wall-mounting

enclosures

Spacial S3DB, S3DM, VDM, S3DEX, S3HF, S3HD, S3D 19"

Application steel wall-mounting enclosures

Empty enclosure for electrical distribution

Dimensions

H W D

250 300 150 NSYS3DB25315 250 400 150 NSYS3DB25415 250 500 150 NSYS3DB25515 300 300 150 NSYS3DB3315 300 400 150 NSYS3DB3415 300 500 150 NSYS3DB3515 300 600 150 NSYS3DB3615 400 300 150 NSYS3DB4315 NSYS3DM4315T 400 800 150 NSYS3DB4815 500 400 150 NSYS3DB5415 NSYS3DM5415T 600 400 150 NSYS3DB6415 NSYS3DM6415T 600 600 150 - NSYS3DM6615T 700 500 150 - NSYS3DM7515T

800 600 150 - NSYS3DM8615T 1000 600 150 - NSYS3DM10615T 1000 800 150 - NSYS3DM10815T

(1) Modular chassis to be ordered separately (NSYDLM•••).

S3DB terminal blocks

IP66 - IK10

RAL 7035

S3DM modular enclosures

with glazed door

IP66 - IK08

(1)

Outdoor Heavy Duty enclosures

Dimensions

H W D

343 200 180 NSYS3HD3215 448 300 230 NSYS3HD4320 NSYSFPSC30HD 548 400 230 NSYS3HD5420 NSYSFPSC40HD NSYMM54 653 400 280 NSYS3HD6425 NSYSFPSC40HD NSYMM64 658 600 330 NSYS3HD6630 NSYSFPSC60HD NSYMM66 753 500 280 NSYS3HD7525 NSYSFPSC50HD NSYMM75 858 600 330 NSYS3HD8630 NSYSFPSC60HD NSYMM86*

862 800 430 NSYS3HD8840 NSYSFPSC80HD NSYMM88 NSYS3CVR84HD 1062 600 430 NSYS3HD10640 NSYSFPSC60HD NSYMM106 NSYS3CVR64HD 1062 800 430 NSYS3HD10840 NSYSFPSC80HD NSYMM108* NSYS3CVR84HD

* Plate with reversible dimensions; it can be installed in enclosures with inverted dimensions. Example: Plate ref. NSYMM64 can be used for the following enclosures: H 600 x W 400 mm

or H 400 x W 600 mm. For plain and silkscreened mounting plates: In wall-mounting enclosures with widths of 1000 and 1200 mm, it is possible to install 2 mounting plates at different depths using an additional central step slide NSYSDRSDCR.

S3HD

IP66 - IK10 - RAL 7035

Heavy duty

post-fixing device

Plain mounting plate Roof ventilation module

NSYMM32

- -

VDM 19" enclosures with glazed door

IP66 - IK08 - RAL 7035

Dimensions

H W D

300 600 380 - - - 300 600 400 300 600 480 - - - 400 600 200 - - - - - 400 600 250 - - - - - 400 600 380 - - - 400 600 400 400 600 480 - - - 500 600 380 - - - 500 600 400 500 480 - - - 600 600 200 - - - - - 600 600 250 - - - - - 600 600 300 - - - - - 600 600 400 - - - - - 700 600 380 - - - 700 600 400 700 600 480 - - - 800 800 200 - - - - - 800 800 250 - - - - - 800 600 300 - - - - - 800 600 380 - - - 800 600 400

800 600 480 - - - 1000 600 250 - - - - - 1000 600 300 - - - - - 1000 600 400 - - - - - 1000 800 250 - - - - - 1000 800 300 - - - - - 1000 800 400 - - - - - 1200 800 300 - - - - - 1200 800 400 - - - - - -

(1) Plain door, please consult us. (2) IP55 for the double-door enclosures.

1-body 19"

swing rack

NSYVDM4U4P 4 NSYVDM5U4F 5

NSYVDM7U4P 7 NSYVDM8U4F 8

NSYVDM9U4P 9

NSYVDM13U4P13NSYVDM14U4F14- - - - - - - -

NSYVDM16U4P16NSYVDM17U4F17- -

No.

1-body 19"

of U

fixed rack

NSYVDM10U4F10- - - - - - - -

No.

2-body 19"

of U

fixed rack

NSYVD2M5U4 5

- - - - - - - -

NSYVD2M5U5 5

NSYVD2M8U4 8

- - - - - - - -

NSYVD2M8U5 8 NSYVD2M10U4 10

NSYVD2M10U5 10

NSYVD2M14U4 14

NSYVD2M14U5 14

NSYVD2M17U4 17

NSYVD2M17U5 17

(3) IK08 for the glazed-door enclosures. (4) The racks are to be ordered separately.

Electronic applications

(1)

No.

Glazed door Plain door Fixed rack

of U

- - - - - -

NSYS3D4620T NSYS3D4625T

- - - - - -

- - - - -

- - - - - -

NSYS3D6620T NSYS3D6625T NSYS3D6630T NSYS3D6640T

- - - - - -

NSYS3D8620T NSYS3D8625T NSYS3D8630T

- - - - - -

NSYS3D8640T

- - - - - -

NSYS3D10625T NSYS3D10630T NSYS3D10640T NSYS3D10825T NSYS3D10830T NSYS3D10840T NSYS3D12830T NSYS3D12840T

NSYS3D4620 NSYVDM8UF 8 NSYVDM7UP 7 NSYS3D4625 NSYVDM8UF 8 NSYVDM7UP 7

NSYS3D6620 NSYVDM12UF 12 NSYVDM11UP 11 NSYS3D6625 NSYVDM12UF 12 NSYVDM11UP 11 NSYS3D6630 NSYVDM12UF 12 NSYVDM11UP 11 NSYS3D6640 NSYVDM12UF 12 NSYVDM11UP 11

NSYS3D8620 NSYVDM17UF 17 NSYS3D8625 NSYVDM17UF 17 NSYS3D8630 NSYVDM17UF 17

NSYS3D8640 NSYVDM17UF 17

NSYS3D10625 NSYS3D10630 NSYS3D10640 NSYS3D10825 NSYS3D10830 NSYS3D10840 NSYS3D12830 NSYS3D12840

S3D 19'' enclosure

(2)

IP66

(3)

- IK10

- RAL 7035

No.

(4)

of U

NSYVDM21UF 21

- - - -

NSYVDM21UF 21

- -

Swing rack

NSYVDM16UP NSYVDM16UP NSYVDM16UP

NSYVDM16UP

NSYVDM20UP

NSYVDM20UP NSYVDM20U8P NSYVDM20U8P NSYVDM20U8P NSYVDM25U8P NSYVDM25U8P

(4)

No.

of U

16 16 16

20 20 20 20 25 25

Wall-mounting

enclosures

Enclosures for explosive

atmospheres

Dimensions

H W D

300 200 150

300 300 200

400 300 200

400 400 200

500 400 200

600 400 200 -

600 400 250

600 600 250

700 500 250

800 600 300 1000 800 300

* Delivered with a plain mounting plate.

Fixing lugs, ref. NSYPFCR to be ordered separately (1 set of 4 lugs).

S3DEX (empty enclosure)

IP66 - IK10 - RAL 7035

NSYS3DEX3215 NSYS3DEX3320 NSYS3DEX4320 NSYS3HF4320P NSYS3DEX4420 NSYS3DEX5420

NSYS3DEX6425 NSYS3DEX6625 NSYS3HF6625P NSYS3DEX7525 NSYS3DEX8630 NSYS3HF8630P NSYS3DEX10830 NSYS3HF10830P

Electromagnetic protected

steel enclosures

S3HF*

IP55 - IK10 - RAL 7035

NSYS3HF6420P

Spacial S3D 6G Enclosures for seismic & nuclear

Consult the catalogue

For more information, consult the Universal Enclosures general catalogue

Spacial SM

Steel floor-standing enclosures

Spacial SM compact enclosures

Spacial SM

Nominal dimensions (mm)

H W D

1200 800 300 1 NSYSM12830P NSYSM12830 - NSYSPF8100 NSYSPS3100 NSYSPF8200 NSYSPS3200 - NSYSC830 NSYSMEC83 1200 1000 300 2 NSYSM1210302DP NSYSM1210302D - NSYSPF10100 NSYSPS3100 NSYSPF10200 NSYSPS3200 - NSYSC1030 NSYSMEC103 1200 1200 400 2 NSYSM1212402DP NSYSM1212402D - NSYSPF12100 NSYSPS4100 NSYSPF12200 NSYSPS4200 - NSYSC1240 2 x NSYSMEC64 1400 600 300 1 NSYSM14630P NSYSM14630 - NSYSPF6100 NSYSPS3100 NSYSPF6200 NSYSPS3200 - NSYSC630 NSYSMEC63 1400 600 400 1 NSYSM14640P NSYSM14640 - NSYSPF6100 NSYSPS4100 NSYSPF6200 NSYSPS4200 - NSYSC640 NSYSMEC64 1400 800 300 1 NSYSM14830P NSYSM14830 - NSYSPF8100 NSYSPS3100 NSYSPF8200 NSYSPS3200 - NSYSC830 NSYSMEC83 1400 800 400 1 NSYSM14840P NSYSM14840 NSYSM14840T NSYSPF8100 NSYSPS4100 NSYSPF8200 NSYSPS4200 - NSYSC840 NSYSMEC84 1400 1000 400 2 NSYSM1410402DP NSYSM1410402D - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 - NSYSC1040 NSYSMEC104 1400 1200 400 2 NSYSM1412402DP NSYSM1412402D - NSYSPF12100 NSYSPS4100 NSYSPF12200 NSYSPS4200 - NSYSC1240 2 x NSYSMEC64 1600 600 300 1 NSYSM16630P NSYSM16630 - NSYSPF6100 NSYSPS3100 NSYSPF6200 NSYSPS3200 NSYID166 NSYSC630 NSYSMEC63 1600 600 400 1 NSYSM16640P NSYSM16640 NSYSM16640T NSYSPF6100 NSYSPS4100 NSYSPF6200 NSYSPS4200 NSYID166 NSYSC640 NSYSMEC64 1600 800 300 1 NSYSM16830P NSYSM16830 NSYSM16830T NSYSPF8100 NSYSPS3100 NSYSPF8200 NSYSPS3200 NSYID168 NSYSC830 NSYSMEC83 1600 800 400 1 NSYSM16840P NSYSM16840 NSYSM16840T NSYSPF8100 NSYSPS4100 NSYSPF8200 NSYSPS4200 NSYID168 NSYSC840 NSYSMEC84 1600 1000 300 2 NSYSM1610302DP NSYSM1610302D - NSYSPF10100 NSYSPS3100 NSYSPF10200 NSYSPS3200 - NSYSC1030 NSYSMEC103 1600 1000 400 2 NSYSM1610402DP NSYSM1610402D - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 - NSYSC1040 NSYSMEC104 1600 1200 300 2 NSYSM1612302DP NSYSM1612302D - NSYSPF12100 NSYSPS3100 NSYSPF12200 NSYSPS3200 - NSYSC1230 2 x NSYSMEC63 1600 1200 400 2 NSYSM1612402DP NSYSM1612402D - NSYSPF12100 NSYSPS4100 NSYSPF12200 NSYSPS4200 - NSYSC12400 2 x NSYSMEC64 1800 600 300 1 NSYSM18630P NSYSM18630 - NSYSPF6100 NSYSPS3100 NSYSPF6200 NSYSPS3200 NSYID186 NSYSC630 NSYSMEC63 1800 600 400 1 NSYSM18640P NSYSM18640 NSYSM18640T NSYSPF6100 NSYSPS4100 NSYSPF6200 NSYSPS4200 NSYID186 NSYSC640 NSYSMEC64 1800 600 500 1 NSYSM18650P NSYSM18650 - NSYSPF6100 NSYSPS5100 NSYSPF6200 NSYSPS5200 NSYID186 NSYSC650 NSYSMEC65 1800 600 600 - - - - - - - - - - - 1800 800 300 1 NSYSM18830P NSYSM18830 NSYSM18830T NSYSPF8100 NSYSPS3100 NSYSPF8200 NSYSPS3200 NSYID188 NSYSC830 NSYSMEC83 1800 800 400 1 NSYSM18840P NSYSM18840 NSYSM18840T NSYSPF8100 NSYSPS4100 NSYSPF8200 NSYSPS4200 NSYID188 NSYSC840 NSYSMEC84 1800 800 500 1 NSYSM18850P NSYSM18850 NSYSM18850T NSYSPF8100 NSYSPS5100 NSYSPF8200 NSYSPS5200 NSYID188 NSYSC850 NSYSMEC85 1800 800 600 1 NSYSM18860P NSYSM18860 - NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 NSYID188 NSYSC8600 NSYSMEC86 1800 1000 400 1 NSYSM181040P NSYSM181040 - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 NSYID1810 NSYSC1040 NSYSMEC104 1800 1000 400 2 NSYSM1810402DP NSYSM1810402D - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 NSYID1810 NSYSC1040 NSYSMEC104 1800 1000 500 2 NSYSM1810502DP NSYSM1810502D - NSYSPF10100 NSYSPS5100 NSYSPF10200 NSYSPS5200 NSYID1810 NSYSC1050 NSYSMEC105 1800 1200 400 2 NSYSM1812402DP NSYSM1812402D - NSYSPF12100 NSYSPS4100 NSYSPF12200 NSYSPS4200 - NSYSC1240 2 x NSYSMEC64 1800 1200 500 2 NSYSM1812502DP NSYSM1812502D - NSYSPF12100 NSYSPS5100 NSYSPF12200 NSYSPS5200 - NSYSC1250 2 x NSYSMEC65 1800 1600 400 2 NSYSM1816402DP NSYSM1816402D - NSYSPF16100 NSYSPS4100 NSYSPF16200 NSYSPS4200 - NSYSC1640 - 1800 1600 500 2 NSYSM1816502DP NSYSM1816502D - NSYSPF16100 NSYSPS5100 NSYSPF16200 NSYSPS5200 - NSYSC10650 2 x NSYSMEC85 2000 600 300 1 NSYSM20630P NSYSM20630 - NSYSPF6100 NSYSPS3100 NSYSPF6200 NSYSPS3200 NSYID206 NSYSC630 NSYSMEC63 2000 600 400 1 NSYSM20640P NSYSM20640 NSYSM20640T NSYSPF6100 NSYSPS4100 NSYSPF6200 NSYSPS4200 NSYID206 NSYSC640 NSYSMEC64 2000 600 500 1 NSYSM20650P NSYSM20650 - NSYSPF6100 NSYSPS5100 NSYSPF6200 NSYSPS5200 NSYID206 NSYSC650 NSYSMEC65 2000 800 300 1 NSYSM20830P NSYSM20830 NSYSM20830T NSYSPF8100 NSYSPS3100 NSYSPF8200 NSYSPS3200 NSYID208 NSYSC830 NSYSMEC83 2000 800 400 1 NSYSM20840P NSYSM20840 NSYSM20840T NSYSPF8100 NSYSPS4100 NSYSPF8200 NSYSPS4200 NSYID208 NSYSC840 NSYSMEC84 2000 800 500 1 NSYSM20850P NSYSM20850 NSYSM20850T NSYSPF8100 NSYSPS5100 NSYSPF8200 NSYSPS5200 NSYID208 NSYSC850 NSYSMEC85 2000 800 600 1 NSYSM20860P NSYSM20860 NSYSM20860T NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 NSYID208 NSYSC860 NSYSMEC86 2000 1000 400 2 NSYSM2010402DP NSYSM2010402D - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 NSYID2010 NSYSC1040 NSYSMEC104 2000 1000 500 2 NSYSM2010502DP NSYSM2010502D - NSYSPF10100 NSYSPS5100 NSYSPF10200 NSYSPS5200 NSYID2010 NSYSC1050 NSYSMEC105 2000 1200 400 2 NSYSM2012402DP NSYSM2012402D - NSYSPF12100 NSYSPS4100 NSYSPF12200 NSYSPS4200 - NSYSC1240 2 x NSYSMEC64 2000 1200 500 2 NSYSM2012502DP NSYSM2012502D - NSYSPF12100 NSYSPS5100 NSYSPF12200 NSYSPS5200 - NSYSC1250 2 x NSYSMEC65 2000 1200 600 2 NSYSM2012602DP NSYSM2012602D - NSYSPF12100 NSYSPS6100 NSYSPF12200 NSYSPS6200 - NSYSC1260 2 x NSYSMEC66 2000 1600 400 2 NSYSM2016402DP NSYSM2016402D - NSYSPF16100 NSYSPS4100 NSYSPF16200 NSYSPS4200 - NSYSC1640 - 2000 1600 500 2 NSYSM2016502DP NSYSM2016502D - NSYSPF16100 NSYSPS5100 NSYSPF16200 NSYSPS5200 - NSYSC1650 2 x NSYSMEC85 2000 1600 600 2 NSYSM2016602DP NSYSM2016602D - NSYSPF16100 NSYSPS6100 NSYSPF16200 NSYSPS6200 - NSYSC1660 2 x NSYSMEC66

(1) Transparent doors: IK08.

No. of doors

With mounting

plate

IP55 - IK10

Plain door Transparent door

(1)

- RAL 7035

Without mounting

plate

Without mounting

plate

Height 100 mm Height 200 mm

Front kit (corners +

front panels)

Plinth Plinth

Side panels, 2 u.

Lock systems for SM, SF

Handle for shape inserts and cylindrical barrels

Reference

NSYSFHS1

Front kit (corners

+ front panels)

Side

panels, 4 u.

Inner door Canopy

Plain cable-gland

plate

Shape inserts

Description References

6-mm square insert NSYINS61

6.5-mm triangular insert NSYINT61

Push button

Description Reference

Push button

NSYINPULS1

Cylindrical barrels

Cylindrical barrels References

405E key lock NSYIN405E1 455 key lock NSYIN4551 1242E key lock NSYIN1242E1 2433A key lock NSYIN2433A1 3131A1 key lock NSYIN3131A1 3432E key lock NSYIN3432E1 6101 key lock NSYIN6101 E1 keyless lock NSYINE11

Floor-standing

enclosures

Handle and Inserts type DIN, KABA and ASSA

Description References

Adapter for DIN cylinder NSYINDIN2 Adapter for KABA cylinder Adapter for ASSA cylinder NSYINASSA2 Handle for DIN, KABA, ASSA NSYSFHD2

(1) Adapter for receiving the KABA8, KABA20

and KABA start cylinders.

(1)

NSYINKBA2

Eyebolts

Reference

NSYSMEB

Spacial SF, SFHD

Steel floor-standing enclosures

Spacial SF suitable enclosures

Spacial SF

Nominal

dimensions (mm)

H W D

1200 600 400 1 NSYSF12640P NSYSF12640 - NSY2SP124 NSYEC64 NSYEC641 - NSYSPF6100 NSYSPS4100 NSYSPF6200 NSYSPS4200 1200 600 600 1 NSYSF12660P NSYSF12660 - NSY2SP126 NSYEC66 NSYEC661 NSYEC662 NSYSPF6100 NSYSPS6100 NSYSPF6200 NSYSPS6200 1200 800 400 1 NSYSF12840P NSYSF12840 - NSY2SP124 NSYEC84 NSYEC841 - NSYSPF8100 NSYSPS4100 NSYSPF8200 NSYSPS4200 1200 800 600 1 NSYSF12860P NSYSF12860 - NSY2SP126 NSYEC86 NSYEC861 NSYEC862 NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 1400 600 400 1 NSYSF14640P NSYSF14640 - NSY2SP144 NSYEC64 NSYEC641 - NSYSPF6100 NSYSPS4100 NSYSPF6200 NSYSPS4200 1400 800 400 1 NSYSF14840P NSYSF14840 - NSY2SP144 NSYEC84 NSYEC841 - NSYSPF8100 NSYSPS4100 NSYSPF8200 NSYSPS4200 1600 600 600 1 NSYSF16660P NSYSF16660 - NSY2SP166 NSYEC66 NSYEC661 NSYEC662 NSYSPF6100 NSYSPS6100 NSYSPF6200 NSYSPS6200 1600 600 800 1 NSYSF16680P NSYSF16680 - NSY2SP168 NSYEC68 NSYEC681 NSYEC682 NSYSPF6100 NSYSPS8100 NSYSPF6200 NSYSPS8200 1600 800 600 1 NSYSF16860P NSYSF16860 - NSY2SP166 NSYEC86 NSYEC861 NSYEC862 NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 1600 800 800 1 NSYSF16880P NSYSF16880 - NSY2SP168 NSYEC88 NSYEC881 NSYEC882 NSYSPF8100 NSYSPS8100 NSYSPF8200 NSYSPS8200 1800 400 400 1 - NSYSF18440 - NSY2SP184 NSYEC44 NSYEC441 - NSYSPF4100 NSYSPS4100 NSYSPF4200 NSYSPS4200 1800 400 500 1 - NSYSF18450 - NSY2SP185 NSYEC45 NSYEC451 - NSYSPF4100 NSYSPS5100 NSYSPF4200 NSYSPS5200 1800 400 600 1 - NSYSF18460 - NSY2SP186 - NSYEC461 - NSYSPF4100 NSYSPS6100 NSYSPF4200 NSYSPS6200 1800 600 400 1 NSYSF18640P NSYSF18640 NSYSF18640T NSY2SP184 NSYEC64 NSYEC641 - NSYSPF6100 NSYSPS4100 NSYSPF6200 NSYSPS4200 1800 600 500 1 NSYSF18650P NSYSF18650 NSYSF18650T NSY2SP185 NSYEC65 NSYEC651 - NSYSPF6100 NSYSPS5100 NSYSPF6200 NSYSPS5200 1800 600 600 1 NSYSF18660P NSYSF18660 - NSY2SP186 NSYEC66 NSYEC661 NSYEC662 NSYSPF6100 NSYSPS6100 NSYSPF6200 NSYSPS6200 1800 600 800 1 - - NSYSF18680T NSY2SP188 NSYEC68 NSYEC681 NSYEC682 NSYSPF6100 NSYSPS8100 NSYSPF6200 NSYSPS8200 1800 800 400 1 NSYSF18840P NSYSF18840 NSYSF18840T NSY2SP184 NSYEC84 NSYEC841 - NSYSPF8100 NSYSPS4100 NSYSPF8200 NSYSPS4200 1800 800 500 1 NSYSF18850P NSYSF18850 NSYSF18850T NSY2SP185 NSYEC85 NSYEC851 - NSYSPF8100 NSYSPS5100 NSYSPF8200 NSYSPS5200 1800 800 600 1 NSYSF18860P NSYSF18860 NSYSF18860T NSY2SP186 NSYEC86 NSYEC861 NSYEC862 NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 1800 800 600 2 NSYSF188602DP NSYSF188602D - NSY2SP186 NSYEC86 NSYEC861 NSYEC862 NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 1800 1000 400 1 NSYSF181040P NSYSF181040 - NSY2SP184 NSYEC104 NSYEC1041 - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 1800 1000 400 2 NSYSF1810402DP NSYSF1810402D - NSY2SP184 NSYEC104 NSYEC1041 - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 1800 1000 500 1 NSYSF181050P NSYSF181050 - NSY2SP185 NSYEC105 NSYEC1051 - NSYSPF10100 NSYSPS5100 NSYSPF10200 NSYSPS5200 1800 1000 600 1 NSYSF181060P NSYSF181060 - NSY2SP186 NSYEC106 NSYEC1061 NSYEC1062 NSYSPF10100 NSYSPS6100 NSYSPF10200 NSYSPS6200 1800 1000 600 2 NSYSF1810602DP NSYSF1810602D - NSY2SP186 NSYEC106 NSYEC1061 NSYEC1062 NSYSPF10100 NSYSPS6100 NSYSPF10200 NSYSPS6200 1800 1200 400 2 NSYSF1812402DP NSYSF1812402D - NSY2SP184 NSYEC124 NSYEC1241 - NSYSPF12100 NSYSPS4100 NSYSPF12200 NSYSPS4200 1800 1200 500 2 NSYSF1812502DP NSYSF1812502D - NSY2SP185 NSYEC125 NSYEC1251 - NSYSPF12100 NSYSPS5100 NSYSPF12200 NSYSPS5200 1800 1200 600 2 NSYSF1812602DP NSYSF1812602D - NSY2SP186 NSYEC126 NSYEC1261 NSYEC1262 NSYSPF12100 NSYSPS6100 NSYSPF12200 NSYSPS6200 2000 300 500 1 - NSYSF20350 - NSY2SP205 NSYEC35 NSYEC351 - NSYSPF3100 NSYSPS5100 NSYSPF3200 NSYSPS5200 2000 300 600 1 - NSYSF20360 - NSY2SP206 NSYEC36 NSYEC361 - NSYSPF3100 NSYSPS6100 NSYSPF3200 NSYSPS6200 2000 300 800 1 - NSYSF20380 - NSY2SP208 - NSYEC381 - NSYSPF3100 NSYSPS8100 NSYSPF3200 NSYSPS8200 2000 400 400 1 - NSYSF20440 - NSY2SP204 NSYEC44 NSYEC441 - NSYSPF4100 NSYSPS4100 NSYSPF4200 NSYSPS4200 2000 400 500 1 - NSYSF20450 - NSY2SP205 NSYEC45 NSYEC451 - NSYSPF4100 NSYSPS5100 NSYSPF4200 NSYSPS5200 2000 400 600 1 - NSYSF20460 - NSY2SP206 - NSYEC461 - NSYSPF4100 NSYSPS6100 NSYSPF4200 NSYSPS6200 2000 400 800 1 - NSYSF20480 - NSY2SP208 - NSYEC481 - NSYSPF4100 NSYSPS8100 NSYSPF4200 NSYSPS8200 2000 600 400 1 NSYSF20640P NSYSF20640 NSYSF20640T NSY2SP204 NSYEC64 NSYEC641 - NSYSPF6100 NSYSPS4100 NSYSPF6200 NSYSPS4200 2000 600 500 1 NSYSF20650P NSYSF20650 NSYSF20650T NSY2SP205 NSYEC65 NSYEC651 - NSYSPF6100 NSYSPS5100 NSYSPF6200 NSYSPS5200 2000 600 600 1 NSYSF20660P NSYSF20660 - NSY2SP206 NSYEC66 NSYEC661 NSYEC662 NSYSPF6100 NSYSPS6100 NSYSPF6200 NSYSPS6200 2000 600 800 1 NSYSF20680P NSYSF20680 - NSY2SP208 NSYEC68 NSYEC681 NSYEC682 NSYSPF6100 NSYSPS8100 NSYSPF6200 NSYSPS8200 2000 800 400 1 NSYSF20840P NSYSF20840 NSYSF20840T NSY2SP204 NSYEC84 NSYEC841 - NSYSPF8100 NSYSPS4100 NSYSPF8200 NSYSPS4200 2000 800 500 1 NSYSF20850P NSYSF20850 NSYSF20850T NSY2SP205 NSYEC85 NSYEC851 - NSYSPF8100 NSYSPS5100 NSYSPF8200 NSYSPS5200 2000 800 600 1 NSYSF20860P NSYSF20860 NSYSF20860T NSY2SP206 NSYEC86 NSYEC861 NSYEC862 NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 2000 800 600 2 NSYSF208602DP NSYSF208602D - NSY2SP206 NSYEC86 NSYEC861 NSYEC862 NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 2000 800 800 1 NSYSF20880P NSYSF20880 NSYSF20880T NSY2SP208 NSYEC88 NSYEC881 NSYEC882 NSYSPF8100 NSYSPS8100 NSYSPF8200 NSYSPS8200 2000 1000 400 1 NSYSF201040P NSYSF201040 NSYSF201040T NSY2SP204 NSYEC104 NSYEC1041 - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 2000 1000 400 2 NSYSF2010402DP NSYSF2010402D - NSY2SP204 NSYEC104 NSYEC1041 - NSYSPF10100 NSYSPS4100 NSYSPF10200 NSYSPS4200 2000 1000 500 1 NSYSF201050P NSYSF201050 NSYSF201050T NSY2SP205 NSYEC105 NSYEC1051 - NSYSPF10100 NSYSPS5100 NSYSPF10200 NSYSPS5200 2000 1000 500 2 NSYSF2010502DP NSYSF2010502D - NSY2SP205 NSYEC105 NSYEC1051 - NSYSPF10100 NSYSPS5100 NSYSPF10200 NSYSPS5200 2000 1000 600 1 NSYSF201060P NSYSF201060 NSYSF201060T NSY2SP206 NSYEC106 NSYEC1061 NSYEC1062 NSYSPF10100 NSYSPS6100 NSYSPF10200 NSYSPS6200 2000 1000 600 2 NSYSF2010602DP NSYSF2010602D - NSY2SP206 NSYEC106 NSYEC1061 NSYEC1062 NSYSPF10100 NSYSPS6100 NSYSPF10200 NSYSPS6200 2000 1000 800 1 NSYSF201080P NSYSF201080 - NSY2SP208 NSYEC108 NSYEC1081 NSYEC1082 NSYSPF10100 NSYSPS8100 NSYSPF10200 NSYSPS8200 2000 1200 400 2 NSYSF2012402DP NSYSF2012402D - NSY2SP204 NSYEC124 NSYEC1241 - NSYSPF12100 NSYSPS4100 NSYSPF12200 NSYSPS4200 2000 1200 500 2 NSYSF2012502DP NSYSF2012502D - NSY2SP205 NSYEC125 NSYEC1251 - NSYSPF12100 NSYSPS5100 NSYSPF12200 NSYSPS5200 2000 1200 600 2 NSYSF2012602DP NSYSF2012602D - NSY2SP206 NSYEC126 NSYEC1261 NSYEC1262 NSYSPF12100 NSYSPS6100 NSYSPF12200 NSYSPS6200 2000 1200 800 2 NSYSF2012802DP NSYSF2012802D - NSY2SP208 NSYEC128 NSYEC1281 NSYEC1282 NSYSPF12100 NSYSPS8100 NSYSPF12200 NSYSPS8200 2000 1600 400 2 NSYSF2016402DP NSYSF2016402D - NSY2SP204 NSYEC164 NSYEC1641 - NSYSPF16100 NSYSPS4100 NSYSPF16200 NSYSPS4200 2000 1600 500 2 NSYSF2016502DP NSYSF2016502D - NSY2SP205 NSYEC165 NSYEC1651 - NSYSPF16100 NSYSPS5100 NSYSPF16200 NSYSPS5200 2000 1600 600 2 NSYSF2016602DP NSYSF2016602D - NSY2SP206 NSYEC166 NSYEC1661 NSYEC1662 NSYSPF16100 NSYSPS6100 NSYSPF16200 NSYSPS6200 2200 400 600 1 - NSYSF22460 - NSY2SP226 - NSYEC461 - NSYSPF4100 NSYSPS6100 NSYSPF4200 NSYSPS6200 2200 600 600 1 NSYSF22660P NSYSF22660 - NSY2SP226 NSYEC66 NSYEC661 NSYEC662 NSYSPF6100 NSYSPS6100 NSYSPF6200 NSYSPS6200 2200 600 800 1 NSYSF22680P NSYSF22680 - NSY2SP228 NSYEC68 NSYEC681 NSYEC682 NSYSPF6100 NSYSPS8100 NSYSPF6200 NSYSPS8200 2200 800 600 1 NSYSF22860P NSYSF22860 - NSY2SP226 NSYEC86 NSYEC861 NSYEC862 NSYSPF8100 NSYSPS6100 NSYSPF8200 NSYSPS6200 2200 800 800 1 NSYSF22880P NSYSF22880 NSYSF22880T NSY2SP228 NSYEC88 NSYEC881 NSYEC882 NSYSPF8100 NSYSPS8100 NSYSPF8200 NSYSPS8200 2200 1000 600 1 NSYSF221060P NSYSF221060 - NSY2SP226 NSYEC106 NSYEC1061 NSYEC1062 NSYSPF10100 NSYSPS6100 NSYSPF10200 NSYSPS6200 2200 1200 600 2 NSYSF2212602DP NSYSF2212602D - NSY2SP226 NSYEC126 NSYEC1261 NSYEC1262 NSYSPF12100 NSYSPS6100 NSYSPF12200 NSYSPS6200 2200 1200 800 2 NSYSF2212802DP NSYSF2212802D - NSY2SP228 NSYEC128 NSYEC1281 NSYEC1282 NSYSPF12100 NSYSPS8100 NSYSPF12200 NSYSPS8200

(1) Transparent doors: IK08.

No. of doors

mounting plate

IP55 - IK10

Plain door

With

(1)

- RAL 7035

Without

mounting plate

Transparent

door

Without

mounting plate

Side panels

Cable-entry plate Plinth Plinth

Height 100 mm Height 200 mm

Plain 1 entry 2 entries

Front kit (corners

+ front panels)

Side panels, 2 u.

Outdoor Heavy Duty enclosures

Standard coupling kit

Front kit (corners

+ front panels)

Side panels,4 u.

External

dimensions (mm)

H W D

1262 600 430 NSYSFHD12640 NSY2SPHD124 NSY2SPIHD124 1262 800 430 NSYSFHD12840 NSY2SPHD124 NSY2SPIHD124 1262 1200 430 NSYSFHD1212402D NSY2SPHD124 NSY2SPIHD124 1281 600 630 NSYSFHD12660 NSY2SPHD126 NSY2SPIHD126 1281 800 630 NSYSFHD12860 NSY2SPHD126 NSY2SPIHD126 1281 1200 630 NSYSFHD1212602D NSY2SPHD126 NSY2SPIHD126 1662 800 430 NSYSFHD16840 NSY2SPHD164 NSY2SPIHD164 1662 1200 430 NSYSFHD1612402D NSY2SPHD164 NSY2SPIHD164 1681 600 630 NSYSFHD16660 NSY2SPHD166 NSY2SPIHD166 1681 800 630 NSYSFHD16860 NSY2SPHD166 NSY2SPIHD166 1681 1200 630 NSYSFHD1612602D NSY2SPHD166 NSY2SPIHD166 2062 800 430 NSYSFHD20840 NSY2SPHD204 NSY2SPIHD204

Floor-standing

enclosure

Spacial SFHD

IP55 - IK10 - RAL 7035

External fixing Internal fixing

Side panels

Spacial SFP Electrical distribution

External

dimensions (mm) H W D

2000 300 500 NSYSF20350 Plain door 2000 300 600 NSYSF20360 Plain door 2000 300 800 NSYSF20380 Plain door 2000 700 500 NSYSFP20750 Plain door 2000 700 500 NSYSFP20750T Glass door 2000 700 600 NSYSFP20760 Plain door 2000 700 600 NSYSFP20760T Glass door 2000 700 800 NSYSFP20780 Plain door 2000 700 800 NSYSFP20780T Glass door

Floor standing enclosure* Door

Reference

NSYSFBK

Swing 19" rack coupling kit

Reference

NSYSFBK19

Eyebolts

Reference

NSYSFEB

Floor-standing

enclosures

Spacial SFM Compartimentalised enclosure for Motor Control Centres

External

dimensions (mm) H W D

2000 600 600 NSYSF20660M Without door 2000 600 800 NSYSF20680M Without door 2000 800 600 NSYSF20860M Without door 2000 800 800 NSYSFP20880M Without door

* Partial door and accesories in the General Catalogue.

Floor standing enclosure* Door

Other Spacial SF applicative solutions

Consult the Universal Enclosures general catalog

Solutions for Electrical Distribution, Motor Control Centres, Seismic and Nuclear, Electronic applications, Variable speed drives flush mounting kits, Automobile applications…

IEC 61439-2 (for tested assemblies) for SF and SFP.

Lifting brackets

Reference

NSYSFELB

Reinforced coupling

Reference

NSYSFBKR

Spacial S3X

Stainless steel wall-mounting enclosures

Spacial S3X

(1)

- IK10

(2)

304L stainless steel

canopy

External dimensions (mm)

H W D Plain door Glazed door** Plain door

300 200 150 1 1 NSYS3X3215 - NSYS3X3215H NSYTX2015 -

300 250 150 1 1 NSYS3X302515 - NSYS3X302515H NSYTX2515 -

300 300 150 1 1 NSYS3X3315 - NSYS3X3315H NSYTX3015 -

400 300 150 1 1 NSYS3X4315 - NSYS3X4315H NSYTX3015 NSYPIN43

400 300 200 1 1 NSYS3X4320 NSYS3X4320T NSYS3X4320H NSYTX3020 NSYPIN43

400 400 200 1 1 NSYS3X4420 - NSYS3X4420H NSYTX4020 -

400 600 200 1 1 NSYS3X4620 - NSYS3X4620H NSYTX6020 -

500 400 200 2 1 NSYS3X5420 NSYS3X5420T NSYS3X5420H NSYTX4020 NSYPIN54

600 400 200 2 1 NSYS3X6420 NSYS3X6420T NSYS3X6420H NSYTX4020 NSYPIN64

600 600 250 2 1 NSYS3X6625 - NSYS3X6625H NSYTX6025 -

600 1000 300 * 1 NSYS3X601030 - - - -

600 1200 300 * 1 NSYS3X601230 - - NSYTX12030 -

700 500 250 2 1 NSYS3X7525 NSYS3X7525T NSYS3X7525H NSYTX5025 NSYPIN75

800 600 250 2 1 NSYS3X8625 NSYS3X8625T NSYS3X8625H NSYTX6025 NSYPIN86

800 800 300 2 1 NSYS3X8830 - NSYS3X8830H NSYTX8030 -

800 1000 300 * 1 NSYS3X801030 - - - -

800 1200 300 * 1 NSYS3X801230 - - NSYTX12030 -

1000 800 300 2 1 NSYS3X10830 NSYS3X10830T NSYS3X10830H NSYTX8030 NSYPIN108

1000 1000 300 * 2 NSYS3X101030 - NSYS3X101030H NSYTX10030 -

1200 800 300 2 1 NSYS3X12830 - NSYS3X12830H NSYTX8030 NSYPIN128

1200 1000 300 * 2 NSYS3X121030 - NSYS3X121030H NSYTX10030 -

* Three-point closure system. ** The glazed door has no reinforcement. (1) For the double door: IP55. (2) For the glazed door: IK08.

No. of

locks

No. of

doors

304L stainless steel 316L stainless steel

IP66

Inner door

Spacial SBX

Stainless steel Industrial Boxes

New

External

dimensions (mm)

H W D

150 150 80 NSYSBX15158 NSYMM11SB NSYAMRD15357SB NSYAEFPFSBX* NSYPPSB* 150 300 80 NSYSBX15308 NSYMM13SB NSYAMRD30357SB NSYAEFPFSBX* NSYPPSB* 200 200 80 NSYSBX20208 NSYMM22SB NSYAMRD20357SB NSYAEFPFSBX* NSYPPSB* 200 300 80 NSYSBX20308 NSYMM23SB NSYAMRD30357SB NSYAEFPFSBX* NSYPPSB* 200 400 120 NSYSBX204012 NSYMM24SB NSYAMRD40357SB NSYAEFPFSBX* NSYPPSB* 300 300 120 NSYSBX303012 NSYMM33SB NSYAMRD30357SB NSYAEFPFSBX* NSYPPSB*

* Same reference for all dimensions.

Spacial SBX

IP66 - IK10

Stainless steel Industrial Boxes Mounting plate DIN rail Fixing lugs Sealing kit

Lock systems

New New

NSYSTDCX2H* NSYCBXHCRN*

NSYSTDNCSX NSYCL610CSX

NSYCBXHCRN

Description Material References

Standard 3-mm double-bar lock Chrome-plated zamak NSYSTDNCSX

Round 3-mm double-bar lock (spare) Chrome-plated zamak NSYSTDCSX

Round 3-mm double-bar lock 304L stainless steel NSYSTDCXH

Round lock 316 stainless steel NSYSTDCX2H*

8-mm triangular insert 304L stainless steel NSYTT8CSX

7-mm square insert 304L stainless steel NSYTC7CSX

6-mm square insert 304L stainless steel NSYTC6CSX

Padlock 316 stainless steel NSYCBXHCRN*

1242E handle lock Chrome-plated zamak NSYCL1242ECSX

405 handle lock Polyamide NSYCL405CSX

610 handle lock Polyamide NSYCL610CSX

Screw driver insert for handle lock Zamak NSYTSML

Screw driver insert for handle lock Zamak NSYTSMLS3D

* Consult us for availability.

NSYTC6CSX

NSYTC7CSX

NSYTT8CSX

NSYSTDNCSX

NSYSTDCSX

NSYSTDCXH

NSYCL1242ECSX

NSYCL405CSX

Boxes and

Wall-mounting

Set of four stainless steel wall-fixing lugs

Description References

304L stainless steel NSYPFCX 316L stainless steel NSYPFC2X

Stainless steel eyebolts

Description Reference

304 stainless steel NSYAELYTCRXG8

Spacial SMX, SFX

Stainless steel floor-standing enclosures

Spacial SMX

IP55 - IK10

External

dimensions (mm)

H W D

1400 1000 300 2 NSYSMX141030 - - - 1600 600 600 - - - - - 1600 800 400 1 NSYSMX16840 - - - 1800 600 400 1 NSYSMX18640 - 1 NSYSFX18640 NSY2SPX184 1800 600 600 - - - - - 1800 800 400 1 NSYSMX18840 NSYSMX18840H 1 NSYSFX18840 NSY2SPX184 1800 1200 400 2 NSYSMX181240 NSYSMX181240H 2 NSYSFX181240 NSY2SPX184 1800 1600 400 2 NSYSMX181640 NSYSMX181640H - - 2000 600 500 - - - 1 NSYSFX20650 NSY2SPX205 2000 800 400 - - - 1 NSYSFX20840 NSY2SPX204 2000 800 500 1 NSYSMX20850 - - - 2000 800 600 - - - 1 NSYSFX20860 NSY2SPX206 2000 1000 400 2 NSYSMX201040 NSYSMX201040H - - 2000 1000 600 - - - 2 NSYSFX201060 NSY2SPX206 2000 1200 500 2 NSYSMX201250 NSYSMX201250H - - 2000 1200 600 - - - 2 NSYSFX201260 NSY2SPX206 2000 1600 600 2 NSYSMX201660 NSYSMX201660H - - -

(1) 316L stainless steel enclosures on request. (2) IP55 for double-door enclosures.

Wall-fixing lugs for SMX

Number

of front

doors

Eyebolts

Stainless steel floor-standing monobloc

304L 316L Suitable enclosure Set of 2 side panels

Hygienic feet

Number

of front

doors

Coupling kit

for SMX

Spacial SFX

(2)

IP66

- IK10

304L stainless steel floor-standing suitable

Lifting bracket

(1)

Reference

NSYFCMX

Door switch for SFX

Reference

NSYDCM20

Reference

NSYSMXEB

H (mm) References

140 to 200 NSYPHX200

Closure option

Description Pack. References

Spare handle 1 NSYMCSX 5 mm double-bar insert 1 NSYTDB5ME 6 mm square insert 1 NSYTC6ME 8 mm square insert 1 NSYTC8ME

6.5 mm triangular insert 1 NSYTT6ME 8 mm triangular insert 1 NSYTT8ME Padlocking device 1 NSYBCME Barrel and key 405ME 1 NSYTCL405ME Barrel and key 610 1 NSYTCL610ME Barrel and key 1242E 1 NSYTL1242EME

Reference

NSYSFBK19 + NSYSFXJG

Reference

NSYPUNX

Top-mounting accessories Canopy for SMX and SFX

For enclosures with

dimensions (mm)

W D SMX SFX

600 400 600 500 800 400 800 500

800 600 1000 300 1000 400 1000 600 1200 400 1200 500 1200 600 1600 400 1600 600

* Used when coupling 2 SFX together.

NSYSCMX6040 NSYSCX6040

NSYSCMX8040 NSYSCX8040 NSYSCMX8050

NSYSCMX10030 NSYSCMX10040

NSYSCMX12040 NSYSCX12040 NSYSCMX12050 NSYSCX12050*

NSYSCMX16040 NSYSCX16040* NSYSCMX16060 NSYSCX16060*

References

NSYSCX6050

NSYSCX8060

NSYSCX10060

NSYSCX12060

Plinth height 100 mm

(4 corners + front and back)

External dimensions

(mm)

Plinth height 100 mm Plinth height 200 mm Plinth height 100 mm Plinth height 200 mm

H W D

1400 1000 300 1600 800 400 1800 600 400 1800 800 400 1800 1200 400 1800 1600 400 2000 600 500 2000 800 400 2000 800 500 2000 800 600 2000 1000 400 2000 1000 600 2000 1200 500 2000 1200 600 2000 1600 600

* Only for Spacial SMX. ** References for Spacial SMX. For Spacial SFX, add "SF": NSYSPSX••••SF.

Kit (4 corners +

front and back)

NSYSPFX10100 NSYSPSX3100* NSYSPFX10200 NSYSPSX3200* NSYSPFX10100H NSYSPSX3100H* NSYSPFX10200H NSYSPSX3200H* NSYSPFX8100 NSYSPSX4100** NSYSPFX8200 NSYSPSX4200** NSYSPFX8100H NSYSPSX4100H NSYSPFX8200H NSYSPSX4200H NSYSPFX6100 NSYSPSX4100** NSYSPFX6200 NSYSPSX4200** NSYSPFX8100 NSYSPSX4100** NSYSPFX8200 NSYSPSX4200** NSYSPFX8100H NSYSPSX4100H NSYSPFX8200H NSYSPSX4200H NSYSPFX12100 NSYSPSX4100** NSYSPFX12200 NSYSPSX4200** NSYSPFX12100H NSYSPSX4100H NSYSPFX12200H NSYSPSX4200H NSYSPFX16100* NSYSPSX4100** NSYSPFX16200* NSYSPSX4200** NSYSPFX6100 NSYSPSX5100** NSYSPFX6200 NSYSPSX5200** NSYSPFX8100 NSYSPSX4100** NSYSPFX8200 NSYSPSX4200** NSYSPFX8100H NSYSPSX4100H NSYSPFX8200H NSYSPSX4200H NSYSPFX8100 NSYSPSX5100** NSYSPFX8200 NSYSPSX5200** NSYSPFX8100H NSYSPSX5100H NSYSPFX8200H NSYSPSX5200H NSYSPFX8100 NSYSPSX6100** NSYSPFX8200 NSYSPSX6200** NSYSPFX8100H NSYSPSX6100H NSYSPFX8200H NSYSPSX6200H NSYSPFX10100 NSYSPSX4100** NSYSPFX10200 NSYSPSX4200** NSYSPFX10100H NSYSPSX4100H NSYSPFX10200H NSYSPSX4200H NSYSPFX10100 NSYSPSX6100** NSYSPFX10200 NSYSPSX6200** NSYSPFX10100H NSYSPSX6100H NSYSPFX10200H NSYSPSX6200H NSYSPFX12100 NSYSPSX5100** NSYSPFX12200 NSYSPSX5200** NSYSPFX12100H NSYSPSX5100H NSYSPFX12200H NSYSPSX5200H NSYSPFX12100 NSYSPSX6100** NSYSPFX12200 NSYSPSX6200** NSYSPFX12100H NSYSPSX6100H NSYSPFX12200H NSYSPSX6200H NSYSPFX16100* NSYSPSX6100** NSYSPFX16200* NSYSPSX6200**

Stainless steel plinths

Stainless steel, AISI 304L

Set of 2 side

panels

Plinth height 100 mm (Set of 2 side panels)

Kit (4 corners + front and back)

Set of 2 side

panels (x2)

Plinth height 200 mm

(4 corners + front and back)

Stainless steel plinths

Stainless steel, AISI 316L

Kit (4 corners +

front and back)

NSYSPFX16100H*

Set of 2 side

panels

NSYSPSX4100H

NSYSPSX4100H NSYSPSX5100H

NSYSPSX6100H

Plinth height 200 mm (Set of 2 side panels)

Kit (4 corners +

front and back)

NSYSPFX16200H*

NSYSPSX4200H

NSYSPSX4200H NSYSPSX5200H

NSYSPSX6200H

Set of 2 side

panels (x2)

Spacial SDX,

Stainless steel HMI enclosures

SDCX

Stainless steel control desks

Spacial SDX

IP55 - IK10

Dimensions

(mm)

H W D

1000 600 500 NSYSDX6 1 NSYSPFX6100 NSYSPSX5100 NSYSPFX6200 NSYSPSX5200 400 NSYSDCX42 NSYSDCX43 NSYRPX2 1000 600 500 NSYSDX6 1 NSYSPFX6100 NSYSPSX5100 NSYSPFX6200 NSYSPSX5200 600 NSYSDCX62 NSYSDCX63 - 1000 800 500 NSYSDX8 1 NSYSPFX8100 NSYSPSX5100 NSYSPFX8200 NSYSPSX5200 400 NSYSDCX42 NSYSDCX43 2 x NSYRPX2 1000 800 500 NSYSDX8 1 NSYSPFX8100 NSYSPSX5100 NSYSPFX8200 NSYSPSX5200 400 2 x NSYSDCX42 2 x NSYSDCX43 - 1000 800 500 NSYSDX8 1 NSYSPFX8100 NSYSPSX5100 NSYSPFX8200 NSYSPSX5200 600 NSYSDCX62 NSYSDCX63 NSYRPX2 1000 1000 500 NSYSDX10 2 NSYSPFX10100 NSYSPSX5100 NSYSPFX10200 NSYSPSX5200 400 NSYSDCX42 NSYSDCX43 3 x NSYRPX2 1000 1000 500 NSYSDX10 2 NSYSPFX10100 NSYSPSX5100 NSYSPFX10200 NSYSPSX5200 600 NSYSDCX62 NSYSDCX63 2 x NSYRPX2 1000 1000 500 NSYSDX10 2 NSYSPFX10100 NSYSPSX5100 NSYSPFX10200 NSYSPSX5200 600 NSYSDCX62 NSYSDCX63 2 x NSYRPX2

1000 1000 500 NSYSDX10 2 NSYSPFX10100 NSYSPSX5100 NSYSPFX10200 NSYSPSX5200

1000 1200 500 NSYSDX12 2 NSYSPFX12100 NSYSPSX5100 NSYSPFX12200 NSYSPSX5200 400 NSYSDCX42 NSYSDCX43 4 x NSYRPX2

1000 1200 500 NSYSDX12 2 NSYSPFX12100 NSYSPSX5100 NSYSPFX12200 NSYSPSX5200

1000 1200 500 NSYSDX12 2 NSYSPFX12100 NSYSPSX5100 NSYSPFX12200 NSYSPSX5200 600 NSYSDCX62 NSYSDCX63 3 x NSYRPX2 1000 1200 500 NSYSDX12 2 NSYSPFX12100 NSYSPSX5100 NSYSPFX12200 NSYSPSX5200 600 NSYSDCX62 NSYSDCX63 3 x NSYRPX2 1000 1200 500 NSYSDX12 2 NSYSPFX12100 NSYSPSX5100 NSYSPFX12200 NSYSPSX5200 600 2 x NSYSDCX62 2 x NSYSDCX63 -

Control

desk

references

304L stainless steel plinth,

height 100 mm

No. of

front

doors

Front + corner

Side

304L stainless steel plinth,

height 200 mm

Front +

corner

Side

Spacial SDCX

Modular Console references

Modular Console

Width (mm)

400 + 600

Depth:

200 mm

NSYSDCX42 + NSYSDCX62

Depth:

300 mm

NSYSDCX43 + NSYSDCX63

Blanking

covers

NSYRPX2

Floor-standing

enclosures

Thalassa TBS,

Thermoplastic industrial boxes

TBP, PLS

Thalassa TBS and TBP

Low covers

Overall external

dimensions

(mm)

H W D H W D Opaque Transparent Opaque Transparent

74 74 54 65 65 47 37 10 5 Metal NSYTBS775 - NSYTBP775 - 89 89 54 80 80 47 37 10 5 Metal NSYTBS885 - NSYTBP885 -

116 74 62 105 65 55 45 10 5 Metal NSYTBS1176 - NSYTBP1176 -

116 11 6 62 105 105 55 45 10 5 Plastic NSYTBS11116 - NSYTBP11116 - 138 93 72 125 80 65 45 20 2 Plastic NSYTBS1397 NSYTBS1397T NSYTBP1397 NSYTBP1397T 164 121 87 150 105 80 60 20 2 Plastic NSYTBS16128 NSYTBS16128T NSYTBP16128 NSYTBP16128T 192 121 87 175 105 80 60 20 2 Plastic NSYTBS19128 NSYTBS19128T NSYTBP19128 NSYTBP19128T 192 164 87 175 150 80 60 20 1 Plastic NSYTBS19168 NSYTBS19168T NSYTBP19168 NSYTBP19168T 241 194 87 225 175 80 60 20 1 Plastic NSYTBS24198 NSYTBS24198T NSYTBP24198 NSYTBP24198T 241 194 107 225 175 100 80 20 1 Plastic NSYTBS241910 NSYTBS241910T NSYTBP241910 NSYTBP241910T 291 241 88 275 225 80 60 20 1 Plastic NSYTBS29248 NSYTBS29248T NSYTBP29248 NSYTBP29248T 291 241 128 275 225 120 100 20 1 Plastic NSYTBS292412 NSYTBS292412T NSYTBP292412 NSYTBP292412T 341 291 128 325 275 120 100 20 1 Plastic NSYTBS342912 NSYTBS342912T NSYTBP342912 NSYTBP342912T

Overall internal

dimensions (mm)

Body (mm)

Cover

(mm)

Minor pack.

Cover screw

Thalassa TBS

IP66 - IK07 - RAL 7035

ABS boxes PC-UL boxes

Cover Cover

Thalassa TBP

IP66 - IK08 - RAL 7035

Thalassa PLS

Dimensions (mm)

H W D Transparent cover Opaque cover Polyester cover Transparent Opaque Polyester Transparent Opaque

180 270 180 NSYPLS1827G NSYPLSC1827G NSYPLSP1827G 270 270 180 NSYPLS2727G NSYPLSC2727G NSYPLSP2727G 270 270 230 NSYPLS2727AG NSYPLSC2727AG - 270 360 180 NSYPLS2736G NSYPLSC2736G NSYPLSP2736G 270 360 230 NSYPLS2736AG NSYPLSC2736AG - 270 540 180 NSYPLS2754G NSYPLSC2754G NSYPLSP2754G 270 540 230 NSYPLS2754AG NSYPLSC2754AG - 360 360 180 NSYPLS3636G NSYPLSC3636G NSYPLSP3636G 360 540 180 NSYPLS3654G NSYPLSC3654G NSYPLSP3654G 360 540 230 NSYPLS3654AG NSYPLSC3654AG - 360 720 230 NSYPLS3672AG NSYPLSC3672AG - 540 540 180 NSYPLS5454G NSYPLSC5454G NSYPLSP5454G 540 540 230 NSYPLS5454AG NSYPLSC5454AG - 540 720 230 NSYPLS5472AG NSYPLSC5472AG -

Insulating modular boxes

Thalassa PLS

IP66 - IK09 - RAL 7035

Complete box

External dimensions (mm)

H W D

180 270 180 12 1 1.7 NSYPLS1827DLS12 270 270 180 24 2 2.5 NSYPLS2727DLS24 360 270 180 24 2 2.7 NSYPLS3627DLS24 360 270 180 36 3 2.8 NSYPLS3627DLS36 540 270 180 48 4 3.8 NSYPLS5427DLS48

Thalassa PLS for modular distribution applications - RAL 7035

Number of

18 mm modules

Number of rows

Approximate

weight (kg)

References

High covers

Overall

external

dimensions (mm)

H W D H W D Opaque Transparent Opaque Transparent

116 74 94 105 65 85 45 40 3 Metal NSYTBS1179H - - - 116 11 6 133 105 105 125 45 80 2 Plastic NSYTBS111113H - - - 192 121 105 175 105 100 60 40 2 Plastic NSYTBS191210H NSYTBS191210HT NSYTBP191210H NSYTBP191210HT 192 164 105 175 150 100 60 40 1 Plastic NSYTBS191610H NSYTBS191610HT NSYTBP191610H NSYTBP191610HT 241 194 107 225 175 100 60 40 1 Plastic NSYTBS241910H NSYTBS241910HT NSYTBP241910H NSYTBP241910HT 241 194 127 225 175 120 80 40 1 Plastic NSYTBS241912H NSYTBS241912HT NSYTBP241912H NSYTBP241912HT 291 241 128 275 225 120 60 60 1 Plastic NSYTBS292412H NSYTBS292412HT NSYTBP292412H NSYTBP292412HT 291 241 168 275 225 160 100 60 1 Plastic NSYTBS292416H NSYTBS292416HT NSYTBP292416H NSYTBP292416HT 341 291 168 325 275 160 100 60 1 Plastic NSYTBS342916H NSYTBS342916HT NSYTBP342916H NSYTBP342916HT

Overall internal

dimensions (mm)

Body (mm)

Cover

(mm)

Minor

pack.

Cover screw

Thalassa TBS

IP66 - IK07 - RAL 7035

ABS boxes PC-UL boxes

Cover Cover

Thalassa TBP

IP66 - IK08 - RAL 7035

Rear

135 mm

NSYFPLS1827G NSYTPLS1827 NSYTPLSC1827G NSYTPLSP1827G - NSYFPLS2727G NSYTPLS2727 NSYTPLSC2727G NSYTPLSP2727G - NSYFPLS2727G - - - NSYTPLS2727A NSYTPLSC2727AG NSYFPLS2736G NSYTPLS2736 NSYTPLSC2736G NSYTPLSP2736G - NSYFPLS2736G - - - NSYTPLS2736A NSYTPLSC2736AG NSYFPLS2754G NSYTPLS2754 NSYTPLSC2754G NSYTPLSP2754G - NSYFPLS2754G - - - NSYTPLS2754A NSYTPLSC2754AG NSYFPLS3636G NSYTPLS3636 NSYTPLSC3636G NSYTPLSP3636G - NSYFPLS3654G NSYTPLS3654 NSYTPLSC3654G NSYTPLSP3654G - NSYFPLS3654G - - - NSYTPLS3654A NSYTPLSC3654AG NSYFPLS3672G - - - NSYTPLS3672A NSYTPLSC3672AG NSYFPLS5454G NSYTPLS5454 NSYTPLSC5454G NSYTPLSP5454G - NSYFPLS5454G - - - NSYTPLS5454A NSYTPLSC5454AG NSYFPLS5472G - - - NSYTPLS5472A NSYTPLSC5472AG

Wall-fixing lugs

Name References

Steel mounting lugs NSYPF27N Stainless steel mounting lugs NSYPF27X

Low covers: 45 mm High covers: 95 mm

Coupling frames

Opening

110 NSYUM27180 200 NSYUM27270 NSYUCC270 (1) 290 NSYUM27360 NSYUCC360 (1)

(1) References by unit. Order by multiples

Full-opening

(mm)

of 10 units (10, 20, 30, etc.).

frame

Partial-opening

frame

Side plates

Side plates (mm) References

200 290

NSYTL27270G NSYTL27360G

Boxes

Thalassa PLM

Polyester wall-mounting enclosures

Thalassa PLM

External dimensions

(mm)

H W D Plain door Transp. door Plain door Transp. door

310 215 160

308 255 160

430 330 200

530 430 200

647 436 250

747 536 300

847 636 300

1056 852 350

(1) Transparent doors: IK08.

ABS/PC wall-mounting

enclosures

NSYPLM32G NSYPLM32TG - - - - - - - - - NSYCEPLMAG

- - NSYPLM3025G NSYPLM3025TG - - - - - - NSYPA3025PLMG -

- - NSYPLM43G NSYPLM43TG NSYPLM43VG NSYPLM43TVG NSYDPLM200 NSYKPLM NSYSFP300 - NSYPAP43G NSYCEPLMBG

- - NSYPLM54G NSYPLM54TG NSYPLM54VG NSYPLM54TVG NSYDPLM200 NSYKPLM NSYSFP400 NSYSFSPLMG NSYPAP54G NSYCEPLMBG

- - NSYPLM64G NSYPLM64TG NSYPLM64VG NSYPLM64TVG NSYDPLM250 NSYKPLM NSYSFP400 NSYSFSPLMG NSYPAP64G NSYCEPLMCG

- - NSYPLM75G NSYPLM75TG NSYPLM75VG NSYPLM75TVG NSYDPLM300 NSYKPLM NSYSFP500 - NSYPAP75G NSYCEPLMCG

- - NSYPLM86G NSYPLM86TG NSYPLM86VG NSYPLM86TVG NSYDPLM300 NSYKPLM NSYSFP600 - NSYPAP86G NSYCEPLMCG

- - NSYPLM108G NSYPLM108TG - - NSYDPLM350 NSYBCPL - - NSYPAP108G -

IP66 - IK10

(1)

- RAL 7035

Polyester wall-mounting enclosures

Plain door

3-point closure

Transp. door

3-point closure

Options to transform the locks with double-bar inserts

NSYTC6CRN NSYTC7CRN NSYTC8CRN

NSYTT6CRN NSYTT8CRN

NSYTL405PLM NSYTL220PLM

NSYTHL1242EPLM NSYTHL405PLM NSYTHL421PLM NSYTHL455PLM NSYTHL610PLM NSYTHL2331APLM NSYTHL2433APLM NSYTHL3113APLM NSYTHL3131APLM NSYTHPLM

Name References

6 mm male square NSYTC6CRN 7 mm male square NSYTC7CRN 8 mm male square NSYTC8CRN

6.5 mm male triangle NSYTT6CRN 8 mm male triangle NSYTT8CRN Lock and key 405 NSYTL405PLM Lock and key 220 NSYTL220PLM

NB: Not suitable for PLM108

Type of barrel References

Key 1242 E NSYTHL1242EPLM Key 405 NSYTHL405PLM Key 421 NSYTHL421PLM Key 455 NSYTHL455PLM Key 2331 A NSYTHL2331APLM Key 2433 A NSYTHL2433APLM Key 3113 A NSYTHL3113APLM Key 3131A NSYTHL3131APLM Manual NSYTHPLM

Water drain plug

Name Reference

Water drain plug NSYVEA9

Ventilation louvres

Name Reference

Ventilation louvres NSYCAG35LP

PLM range accessories

Step slides Padlocking

Wall-fixing lugs

Post-fixing

device

Floor-mounting pillar Internal door Blanking plates

ZM plinth for PLM enclosure

NSYPFPLM32 NSYPFXPLM

Polyamide NSYPFPLMG

Stainless steel NSYPFXPLM

(1) Exclusive for enclosures ref. NSYPLM32G and NSYPLM32TG.

NSYPFPLM

Material References

NSYPFPLM32G

(1)

For enclosure

H W D References H W D References W D

747 536 300 NSYPLM75G 200 456 302 NSYZM253G 256 252 847 636 300 NSYPLM86G 200 556 302 NSYZM263G 356 252

1056 852 350 NSYPLM108G 200 772 352 NSYZM283G 572 302

Plinth

RAL 7035

Cable

opening area

Wall-mounting

enclosures

Thalassa PLA,

Polyester floor-standing

PLAT

enclosures

Thalassa PLA(Z)

(1)

IP65

External dimensions (mm)

Completely sealed enclosures

References of enclosures with door

H W D

500 500 320 1 NSYPLA553G NSYPLA553TG NSYPLAZ553G 500 500 420 1 NSYPLA554G NSYPLA554TG NSYPLAZ554G 500 750 320 1 NSYPLA573G NSYPLA573TG NSYPLAZ573G 500 750 420 1 NSYPLA574G NSYPLA574TG NSYPLAZ574G 500 1000 320 2 NSYPLA5103G NSYPLA5103TG NSYPLAZ5103G 500 1000 420 2 NSYPLA5104G NSYPLA5105T NSYPLAZ5104G 500 1250 320 2 NSYPLA5123G NSYPLA5123TG NSYPLAZ5123G 500 1250 420 2 NSYPLA5124G NSYPLA5124TG NSYPLAZ5124G 750 500 320 1 NSYPLA753G NSYPLA753TG NSYPLAZ753G 750 500 420 1 NSYPLA754G NSYPLA754TG NSYPLAZ754G 750 750 320 1 NSYPLA773G NSYPLA773TG NSYPLAZ773G 750 750 420 1 NSYPLA774G NSYPLA774TG NSYPLAZ774G 750 750 620 1 NSYPLA776G NSYPLA776TG NSYPLAZ776G 750 1000 320 2 NSYPLA7103G NSYPLA7103TG NSYPLAZ7103G 750 1000 420 2 NSYPLA7104G NSYPLA7104TG NSYPLAZ7104G 750 1250 320 2 NSYPLA7123G NSYPLA7123TG NSYPLAZ7123G

750 1250 420 2 NSYPLA7124G NSYPLA7124TG NSYPLAZ7124G 1000 500 320 1 NSYPLA1053G NSYPLA1053TG NSYPLAZ1053G 1000 500 420 1 NSYPLA1054G NSYPLA1054TG NSYPLAZ1054G 1000 750 320 1 NSYPLA1073G NSYPLA1073TG NSYPLAZ1073G 1000 750 420 1 NSYPLA1074G NSYPLA1074TG NSYPLAZ1074G 1000 1000 320 2 NSYPLA10103G NSYPLA10103TG NSYPLAZ10103G 1000 1000 420 2 NSYPLA10104G NSYPLA10104TG NSYPLAZ10104G 1000 1250 320 2 NSYPLA10123G NSYPLA10123TG NSYPLAZ10123G 1000 1250 420 2 NSYPLA10124G NSYPLA10124TG NSYPLAZ10124G 1250 500 320 1 NSYPLA1253G NSYPLA1253TG NSYPLAZ1253G 1250 500 420 1 NSYPLA1254G NSYPLA1254TG NSYPLAZ1254G 1250 750 320 1 NSYPLA1273G NSYPLA1273TG NSYPLAZ1273G 1250 750 420 1 NSYPLA1274G NSYPLA1274TG NSYPLAZ1274G 1250 750 620 1 NSYPLA1276G NSYPLA1276TG NSYPLAZ1276G 1250 1000 320 2 NSYPLA12103G NSYPLA12103TG NSYPLAZ12103G 1250 1000 420 2 NSYPLA12104G NSYPLA12104TG NSYPLAZ12104G 1250 1250 320 2 NSYPLA12123G NSYPLA12123TG NSYPLAZ12123G 1250 1250 420 2 NSYPLA12124G NSYPLA12124TG NSYPLAZ12124G 1250 1250 620 2 NSYPLA12126G NSYPLA12126TG NSYPLAZ12126G 1500 500 320 1 NSYPLA1553G NSYPLA1553TG NSYPLAZ1553G 1500 500 420 1 NSYPLA1554G NSYPLA1554TG NSYPLAZ1554G 1500 750 320 1 NSYPLA1573G NSYPLA1573TG NSYPLAZ1573G 1500 750 420 1 NSYPLA1574G NSYPLA1574TG NSYPLAZ1574G 1500 750 620 1 NSYPLA1576G NSYPLA1576TG NSYPLAZ1576G 1500 1000 320 2 NSYPLA15103G NSYPLA15103TG NSYPLAZ15103G 1500 1000 420 2 NSYPLA15104G NSYPLA15104TG NSYPLAZ15104G 1500 1250 320 2 NSYPLA15123G NSYPLA15123TG NSYPLAZ15123G 1500 1250 420 2 NSYPLA15124G NSYPLA15124TG NSYPLAZ15124G 1500 1250 620 2 NSYPLA15126G NSYPLA15126TG NSYPLAZ15126G 2000 750 420 1 NSYPLA2074G NSYPLA2074TG NSYPLAZ2074G

(1) Open bottom: IP54. (2) Glazed door: IK08.

No. of doors

Plain Glazed Plain

(2)

- IK10

- RAL 7035

Enclosures with plinth-type

open bottom part

Canopy

NSYTJPLA53G NSYECPLAZ53G NSYTJPLA54G NSYECPLAZ54G NSYTJPLA73G NSYECPLAZ73G NSYTJPLA74G NSYECPLAZ74G NSYTJPLA103G NSYECPLAZ103G NSYTJPLA104G NSYECPLAZ104G NSYTJPLA123G NSYECPLAZ123G NSYTJPLA124G NSYECPLAZ124G NSYTJPLA53G NSYECPLAZ53G NSYTJPLA54G NSYECPLAZ54G NSYTJPLA73G NSYECPLAZ73G NSYTJPLA74G NSYECPLAZ74G NSYTJPLA76G NSYECPLAZ76G NSYTJPLA103G NSYECPLAZ103G NSYTJPLA104G NSYECPLAZ104G NSYTJPLA123G NSYECPLAZ123G NSYTJPLA124G NSYECPLAZ124G NSYTJPLA53G NSYECPLAZ53G NSYTJPLA54G NSYECPLAZ54G NSYTJPLA73G NSYECPLAZ73G NSYTJPLA74G NSYECPLAZ74G NSYTJPLA103G NSYECPLAZ103G NSYTJPLA104G NSYECPLAZ104G NSYTJPLA123G NSYECPLAZ123G NSYTJPLA124G NSYECPLAZ124G NSYTJPLA53G NSYECPLAZ53G NSYTJPLA54G NSYECPLAZ54G NSYTJPLA73G NSYECPLAZ73G NSYTJPLA74G NSYECPLAZ74G NSYTJPLA76G NSYECPLAZ76G NSYTJPLA103G NSYECPLAZ103G NSYTJPLA104G NSYECPLAZ104G NSYTJPLA123G NSYECPLAZ123G NSYTJPLA124G NSYECPLAZ124G NSYTJPLA126G NSYECPLAZ126G NSYTJPLA53G NSYECPLAZ53G NSYTJPLA54G NSYECPLAZ54G NSYTJPLA73G NSYECPLAZ73G NSYTJPLA74G NSYECPLAZ74G NSYTJPLA76G NSYECPLAZ76G NSYTJPLA103G NSYECPLAZ103G NSYTJPLA104G NSYECPLAZ104G NSYTJPLA123G NSYECPLAZ123G NSYTJPLA124G NSYECPLAZ124G NSYTJPLA126G NSYECPLAZ126G NSYTJPLA74G NSYECPLAZ74G

Cable-entry

plate

Plinths for PLA(T) type enclosures

For enclosure 200 mm ZA plinth - RAL 7035 60 mm N plinth - RAL 7035

W D References References References

500 320 NSYPLA(T) 53G NSYZA253G NSYZNPLA53G NSYMFPLAZ53

750 320 NSYPLA(T) 73G NSYZA273G NSYZNPLA73G NSYMFPLAZ73 1000 320 NSYPLA(T) 103G NSYZA2103G NSYZNPLA103G NSYMFPLAZ103 1250 320 NSYPLA(T) 123G NSYZA2123G NSYZNPLA123G NSYMFPLAZ123

500 420 NSYPLA(T) 54G NSYZA254G NSYZNPLA54G NSYMFPLAZ54 1000 420 NSYPLA(T) 104G NSYZA2104G NSYZNPLA104G NSYMFPLAZ104 1250 420 NSYPLA(T) 124G NSYZA2124G NSYZNPLA124G NSYMFPLAZ124

750 620 NSYPLA(T) 76G NSYZA276G - NSYMFPLAZ76 1250 620 NSYPLA(T) 126G NSYZA2126G - NSYMFPLAZ126

750 420 NSYPLA(T) 74G NSYZA274G NSYZNPLA74G NSYMFPLAZ74

Floor-fixing

frame

Thalassa PLA(Z)T

IP44 - IK10 - RAL 7035

With ventilated

canopy

With plinth-type open bottom

part and ventilated canopy

Horizontal

coupling kits

Inner door

Outdoor Heavy Duty

enclosures

Heavy Duty range

With door With door With door

Plain Plain Anti-posting Plain

NSYPLAT553G NSYPLAZT553G NSYMUPLA53G NSYPAPLA55G NSYPHDT553 NSYPHDT553P NSYPLAT554G NSYPLAZT554G NSYMUPLA54G NSYPAPLA55G - NSYPLAT573G NSYPLAZT573G NSYMUPLA53G NSYPAPLA57G - NSYPLAT574G NSYPLAZT574G NSYMUPLA54G NSYPAPLA57G - NSYPLAT5103G NSYPLAZT5103G NSYMUPLA53G 2 x NSYPAPLA55G - NSYPLAT5104G NSYPLAZT5104G NSYMUPLA54G 2 x NSYPAPLA55G - NSYPLAT5123G NSYPLAZT5123G NSYMUPLA53G NSYPAPLA55G + NSYPAPLA57G - NSYPLAT5124G NSYPLAZT5124G NSYMUPLA54G NSYPAPLA55G + NSYPAPLA57G - NSYPLAT753G NSYPLAZT753G NSYMUPLA73G NSYPAPLA75G NSYPHDT753 NSYPHDT753P NSYPLAT754G NSYPLAZT754G NSYMUPLA74G NSYPAPLA75G - NSYPLAT773G NSYPLAZT773G NSYMUPLA73G NSYPAPLA77G - NSYPLAT774G NSYPLAZT774G NSYMUPLA74G NSYPAPLA77G NSYPHDZT774 NSYPHDZT774P NSYPLAT776G NSYPLAZT776G NSYMUPLA76G NSYPAPLA77G NSYPHDZT776 NSYPHDZT776P NSYPLAT7103G NSYPLAZT7103G NSYMUPLA73G 2 x NSYPAPLA75G - NSYPLAT7104G NSYPLAZT7104G NSYMUPLA74G 2 x NSYPAPLA75G - NSYPLAT7123G NSYPLAZT7123G NSYMUPLA73G NSYPAPLA75G + NSYPAPLA77G - NSYPLAT7124G NSYPLAZT7124G NSYMUPLA74G NSYPAPLA75G + NSYPAPLA77G - NSYPLAT1053G NSYPLAZT1053G NSYMUPLA103G NSYPAPLA105G - NSYPLAT1054G NSYPLAZT1054G NSYMUPLA104G NSYPAPLA105G NSYPHDZT1054 NSYPHDZT1054P NSYPLAT1073G NSYPLAZT1073G NSYMUPLA103G NSYPAPLA107G - NSYPLAT1074G NSYPLAZT1074G NSYMUPLA104G NSYPAPLA107G NSYPHDZT1074 NSYPHDZT1074P NSYPLAT10103G NSYPLAZT10103G NSYMUPLA103G 2 x NSYPAPLA105G - NSYPLAT10104G NSYPLAZT10104G NSYMUPLA104G 2 x NSYPAPLA105G - NSYPLAT10123G NSYPLAZT10123G NSYMUPLA103G NSYPAPLA105 + NSYPAPLA107G - NSYPLAT10124G NSYPLAZT10124G NSYMUPLA104G NSYPAPLA105 + NSYPAPLA107G - NSYPLAT1253G NSYPLAZT1253G NSYMUPLA123G NSYPAPLA125G - NSYPLAT1254G NSYPLAZT1254G NSYMUPLA124G NSYPAPLA125G NSYPHDZT1254 NSYPHDZT1254P NSYPLAT1273G NSYPLAZT1273G NSYMUPLA123G NSYPAPLA127G - NSYPLAT1274G NSYPLAZT1274G NSYMUPLA124G NSYPAPLA127G NSYPHDZT1274 NSYPHDZT1274P NSYPLAT1276G NSYPLAZT1276G NSYMUPLA126G NSYPAPLA127G NSYPHDZT1276 NSYPHDZT1276P NSYPLAT12103G NSYPLAZT12103G NSYMUPLA123G 2 x NSYPAPLA125G - NSYPLAT12104G NSYPLAZT12104G NSYMUPLA124G 2 x NSYPAPLA125G - NSYPLAT12123G NSYPLAZT12123G NSYMUPLA123G NSYPAPLA125G + NSYPAPLA127G - NSYPLAT12124G NSYPLAZT12124G NSYMUPLA124G NSYPAPLA125G + NSYPAPLA127G NSYPLAT12126G NSYPLAZT12126G NSYMUPLA126G NSYPAPLA125G + NSYPAPLA127G NSYPLAT1553G NSYPLAZT1553G NSYMUPLA153G NSYPAPLA155G - NSYPLAT1554G NSYPLAZT1554G NSYMUPLA154G NSYPAPLA155G - NSYPLAT1573G NSYPLAZT1573G NSYMUPLA153G NSYPAPLA157G - NSYPLAT1574G NSYPLAZT1574G NSYMUPLA154G NSYPAPLA157G NSYPHDZT1574 NSYPHDZT1574P NSYPLAT1576G NSYPLAZT1576G NSYMUPLA156G NSYPAPLA157G NSYPHDZT1576 NSYPHDZT1576P NSYPLAT15103G NSYPLAZT15103G NSYMUPLA153G 2 x NSYPAPLA155G - NSYPLAT15104G NSYPLAZT15104G NSYMUPLA154G 2 x NSYPAPLA155G - NSYPLAT15123G NSYPLAZT15123G NSYMUPLA153G NSYPAPLA155G + NSYPAPLA157G - NSYPLAT15124G NSYPLAZT15124G NSYMUPLA154G NSYPAPLA155G + NSYPAPLA157G NSYPLAT15126G NSYPLAZT15126G NSYMUPLA156G NSYPAPLA155G + NSYPAPLA157G NSYPLAT2074G NSYPLAZT2074G

- -

NSYPHDZT12124 NSYPHDZT12126

NSYPHDZT15124 NSYPHDZT15126 NSYPHDZT2074

NSYPHDZT12124P NSYPHDZT12126P

NSYPHDZT15124P NSYPHDZT15126P NSYPHDZT2074P

Ventilated ZZ plinths

200 mm

- -

- NSYZZ274VHD NSYPCVR74HD NSYZZ276VHD NSYPCVR76HD

- -

- NSYZZ254VHD NSYPCVR54HD

- NSYZZ274VHD NSYPCVR74HD

- -

- NSYZZ254VHD NSYPCVR54HD

- NSYZZ274VHD NSYPCVR74HD NSYZZ276VHD NSYPCVR76HD

- -

- NSYZZ2124VHD NSYPCVR124HD NSYZZ2126VHD NSYPCVR126HD

- -

- NSYZZ274VHD NSYPCVR74HD NSYZZ276VHD NSYPCVR76HD

- -

- NSYZZ2124VHD NSYPCVR124HD NSYZZ2126VHD NSYPCVR126HD NSYZZ274VHD NSYPCVR74HD

Roof

ventilation

module

Plinths for PLAZ(T) type enclosures

For enclosure

W D References References References References References

500 320

750 320 1000 320 1250 320

500 420 1000 420 1250 420

750 620 1250 620

750 420

NSYPLAZ(T) 53G NSYPLAZ(T) 73G NSYPLAZ(T) 103G NSYPLAZ(T) 123G NSYPLAZ(T) 54G NSYPLAZ(T) 104G NSYPLAZ(T) 124G NSYPLAZ(T) 76G NSYPLAZ(T) 126G NSYPLAZ(T) 74G

200 mm ZZ plinth - RAL 7035 500 mm ZZ plinth - RAL 7035 900 mm H plinth - RAL 7035

Wall-fixing lugs

NSYZZ253G NSYZZ553G NSYZHPLA53G NSYFMPLA NSYZZ273G NSYZZ573G NSYZHPLA73G NSYFMPLA NSYZZ2103G NSYZZ5103G NSYZHPLA103G NSYFMPLA NSYZZ2123G NSYZZ5123G NSYZHPLA123G NSYFMPLA NSYZZ254G NSYZZ554G NSYZHPLA54G NSYFMPLA NSYZZ2104G NSYZZ5104G NSYZHPLA104G NSYFMPLA NSYZZ2124G NSYZZ5124G NSYZHPLA124G NSYFMPLA NSYZZ276G - - NSYFMPLA NSYZZ2126G - - NSYFMPLA NSYZZ274G NSYZZ574G NSYZHPLA74G NSYFMPLA

Floor-standing

enclosures

Thermal management system

ClimaSys CV: ventilation systems

Thermal

Control

Fan flow rate (m3/h)

Free

With

with

1 outlet

grille

2 outlet

filter

50 Hz 50 Hz 50 Hz IP54 - RAL 7035

38 25 33 230 38 27 35 115 58 39 47 24 DC 44 34 41 48 DC 85 63 71 230 79 65 73 115 80 57 77 24 DC

79 59 68 48 DC 165 153 161 230 164 153 161 11 5 188 171 179 24 DC 193 171 179 48 DC 302 260 268 230 302 263 271 11 5 262 221 229 24 DC 247 210 218 48 DC 562 473 481 230 582 485 494 11 5 838 718 728 230 983 843 854 11 5

931 798 809 400

grilles

Voltage

(V)

Fan with filter Outlet grille Covers

IP54 - RAL 7035

NSYCVF38M230PF NSYCVF38M115PF NSYCVF38M24DPF NSYCVF38M48DPF NSYCVF85M230PF NSYCVF85M115PF NSYCVF85M24DPF NSYCVF85M48DPF NSYCVF165M230PF NSYCVF165M115PF NSYCVF165M24DPF NSYCVF165M48DPF NSYCVF300M230PF NSYCVF300M115PF NSYCVF300M24DPF NSYCVF300M48DPF NSYCVF560M230PF NSYCVF560M115PF NSYCVF850M230PF NSYCVF850M115PF

NSYCVF850M400PF

NSYCAG92LPF - - -

NSYCAG125LPF NSYCAP125LZF NSYCAP125LXF NSYCAP125LE

NSYCAG223LPF NSYCAP223LZF NSYCAP223LXF NSYCAP223LE

NSYCAG291LPF NSYCAP291LZF NSYCAP291LXF NSYCAP291LE

ClimaSys CV Smart Ventilation System

Ingress protection rating: IP54

Color: Smokey black RAL 9005

Flow (m3/h) Voltage (V) Fan references

115

74 115

68 142 151 259 259 502 522 638 783 731

(1) The smart fan must be connected to the Filterstat controller that transmits the information

and alarms. (2) NSYCV•••DG fan supply includes: fan rpm sensor and smart filter with dust sensor. (3) The supply of the NSYCAG•••DG smart grids includes: 1 smart filter G2 and dust sensor.

NSYCVF38M115DG

230

NSYCVF38M230DG

NSYCVF85M115DG

230

NSYCVF85M230DG

115

NSYCVF165M115DG

230

NSYCVF165M230DG

115

NSYCVF300M115DG

230

NSYCVF300M230DG

115

NSYCVF560M115DG

230

NSYCVF560M230DG

115

NSYCVF850M115DG

230

NSYCVF850M230DG

400

NSYCVF850M400DG

(2)

(1)

Grid references

NSYCAG92DG

NSYCAG92DG NSYCAG125DG NSYCAG125DG NSYCAG223DG NSYCAG223DG NSYCAG223DG NSYCAG223DG NSYCAG291DG NSYCAG291DG NSYCAG291DG NSYCAG291DG NSYCAG291DG

Forced ventilation

IP55 Steel

(3)

IP55 Stainless steel

Filterstat communication cable

Black unshielded cable with 2 connectors

on each side (Material: PVC)

IP55 EMC Steel

Length (mm) Cable references

500

1000

1500

2000

3000

4000

5000

NSYCCA50MFST

NSYCCA100MFST NSYCCA150MFST NSYCCA200MFST NSYCCA300MFST NSYCCA400MFST NSYCCA500MFST

ClimaSys Smart Ventilation Controllers

Voltage (V)

30V AC/DC

90-250V AC

No. of ports

Filterstat Controllers

references

NSYCCOFST30V

NSYCCOFST90250V

Thermal hub

references

NSYCCOFSEM8U1 NSYCCOFSEM8U2

IP55 door installation

frame references

NSYCCOFR55

ClimaSys CE: air-air exchangers

Side-mounting models - 230V - IP55

Specific power (W/K) References

NSYCEA22E NSYCEA36 NSYCEA50 NSYCEA80

ClimaSys CE: air-water exchangers

Side-mounting models - IP55

Cooling power

W10A35 (W)

1000 5 bar 1 x 230 NSYCEW1K* NSYCEWX1K* 1750 5 bar 1 x 230 NSYCEW1K8* NSYCEWX1K8* 2500 5 bar 1 x 230 NSYCEW2K5* NSYCEWX2K5* 3500 5 bar 1 x 230 NSYCEW3K5* NSYCEWX3K5* 4500 5 bar 1 x 230 NSYCEW4K5* NSYCEWX4K5* 6000 5 bar 1 x 230 NSYCEW6K* NSYCEWX6K* 6000 8 bar 2 x 400-440 NSYCEW6K2P4 NSYCEWX6K2P4

* For UL version add UL to the end of the reference (example: NSYCEW6KUL).

Hydraulic circuit

maximum pressure

Voltage

(V)

Steel Stainless steel

References

Specific power (W/K)

2500 5 bar 1 x 230

Hydraulic circuit

maximum pressure

ClimaSys Smart Ventilation System

Scan this QR code to see the video of operation

Top-mounting model - IP55

Voltage

(V)

NSYCEW2K5R

References

The most efficient way to monitor thermal management in your installation

Scan this QR code to download the brochure

ClimaSys CU: cooling units

Thermal

Control

Cooling power L35-L35

W (Btu/h)

300 (1024) 230 NSYCU300H* - - 380 (1297) 230 NSYCU400 NSYCUX400* NSYCUHD400 640 (2184) 230 NSYCU600 NSYCUX600 NSYCUHD600

820 (2798) 230 NSYCU800 NSYCUX800 NSYCUHD800 1000 (3412) 230 NSYCU1K NSYCUX1K NSYCUHD1K 1000 (3412) 400 NSYCU1K2P4 NSYCUX1K2P4 NSYCUHD1K2P4 1250 (4265) 230 NSYCU1K2 NSYCUX1K2 - 1600 (5459) 230 NSYCU1K6 NSYCUX1K6 NSYCUHD1K6 1600 (5459) 400 NSYCU1K62P4 NSYCUX1K62P4 NSYCUHD1K62P4 2000 (6824) 230 NSYCU2K NSYCUX2K - 2000 (6824) 400 NSYCU2K3P4 NSYCUX2K3P4 NSYCUHD2K3P4 2900 (9895) 400 NSYCU3K3P4 NSYCUX3K3P4 NSYCUHD3K3P4

3850 (13137) 400 NSYCU4K3P4 NSYCUX4K3P4 NSYCUHD4K3P4

(1) For UL version add UL to the end of the reference (example: NSYCU1KUL).

* No UL version available.

Floor-standing models - IP54

Cooling power L35-L35

W (Btu/h)

5800 W (19790) 3 x 400 NSYCU6K3P4 6050 W (20643) 3 x 460 NSYCU6K3P460

Voltage

(V AC)

Voltage

(V AC)

Side-mounting models - IP55

(1)

Steel

References

Steel

References

Stainless steel

(1)

Outdoor heavy duty

Top-mounting models - IP54

Cooling power

L35-L35

W (Btu/h)

410 (1399) 230 NSYCU400R NSYCUX400R 820 (2798) 230 NSYCU800R NSYCUX800R

1150 (3924) 230 NSYCU1K2R NSYCUX1K2R 1550 (5289) 230 NSYCU1K5R NSYCUX1K5R 2050 (6995) 230 NSYCU2KR* NSYCUX2KR 2050 (6995) 400 NSYCU2K3P4R NSYCUX2K3P4R 2900 (9895) 400 NSYCU3K3P4R NSYCUX3K3P4R

3850 (13137) 400 NSYCU4K3P4R NSYCUX4K3P4R

(1) For UL version add UL to the end of the reference (example: NSYCU1K2RUL).

* No UL version available.

Voltage

(V)

Steel

References

(1)

Stainless steel

Side-mounting SLIM models - IP55

Cooling power

L35-L35

Voltage

W (Btu/h)

1100 (3753) 230 1100 (3753) 400 1500 (5118) 230 1500 (5118) 400 2000 (6824) 230 2000 (6824) 400 2500 (8530) 230

2500 (8530) 400 3200 (10919) 230 3200 (10919) 400

(V)

UL Steel UL Stainless steel

NSYCUS1K1UL NSYCUSX1K1UL NSYCUS1K12P4UL NSYCUSX1K12P4UL NSYCUS1K5UL NSYCUSX1K5UL NSYCUS1K52P4UL NSYCUSX1K52P4UL NSYCUS2KUL NSYCUSX2KUL NSYCUS2K3P460UL NSYCUSX2K3P4UL NSYCUS2K5UL NSYCUSX2K5UL NSYCUS2K53P4UL NSYCUSX2K53P4UL NSYCUS3K2UL NSYCUSX3K2UL NSYCUS3K23P4UL NSYCUSX3K23P4UL

References

ClimaSys CR: insulated resistance heaters

Insulated resistance heaters - 4 poles

Power (W) Voltage (V) Reference

55 110-250 AC NSYCR50WU2C*

Insulated resistance heaters - 2 poles

Power (W) Voltage (V) Reference

10 110-250 AC NSYCR10WU2C* 10 12-24 DC NSYCR10WU1C 20 110-250 AC NSYCR20WU2C* 20 12-24 DC NSYCR20WU1C

Thermal

Control

* Models with UL certification.

Insulated resistance heater with fan

Power (W) Voltage (V) Reference

177 230 AC NSYCR170W230VVC*

55 12-24 DC NSYCR50WU1C

55 270-420 AC NSYCR50WU3C 100 110-250 AC NSYCR100WU2C* 100 12-24 DC NSYCR100WU1C 100 270-420 AC NSYCR100WU3C 147 110-250 AC NSYCR150WU2C* 147 12-24 DC NSYCR150WU1C

Thermofans

Power (W) Voltage (V) References

400/550 120 AC NSYCRP1W120VTVC* 400/550 230 AC NSYCRP1W230VTVC*

ClimaSys CR: aluminium resistance heaters

Aluminium resistance heaters

Power (W) Voltage (V) References

Power cord

10 12-24 DC NSYCR10WU1 10 110-250 AC NSYCR10WU2* 20 12-24 DC NSYCR20WU1 20 110-250 AC NSYCR20WU2*

Terminal block

20 270-420 AC NSYCR20WU3 55 12-24 DC NSYCR55WU1 55 110-250 AC NSYCR55WU2* 55 270-420 AC NSYCR55WU3 90 12-24 DC NSYCR100WU1 90 110-250 AC NSYCR100WU2*

90 270-420 AC NSYCR100WU3 150 12-24 DC NSYCR150WU1 150 110-250 AC NSYCR150WU2* 150 270-420 AC NSYCR150WU3

* Models with UL certification.

ClimaSys CR: ultra thin resistance heaters

Ultra thin resistance heaters*

Power (W) Voltage (V) Inrush current (A) Height (mm) Width (mm) Depth (mm)

10 120 0.08 130 250 1.6

10 240 0.04 130 250 1.6

25 120 0.21 130 250 1.6

25 240 0.10 130 250 1.6

50 120 0.42 200 320 1.6

50 240 0.21 200 320 1.6

100 120 0.83 280 450 1.6

100 240 0.42 280 450 1.6

200 120 1.67 400 650 1.6

200 240 0.83 400 650 1.6

* Ultra thin resistance heaters can be manufactured with different dimensions and power ratings than those indicated above. Please contact us. (1) All Ultra thin resistance heaters are UL certified.

Aluminium resistance heaters with fan

Power (W) Voltage (V) References

250 115 AC NSYCR250W115VV* 250 230 AC NSYCR250W230VV* 400 115 AC NSYCR400W115VV* 400 230 AC NSYCR400W230VV* 200 115 AC NSYCRS200W115V 200 230 AC NSYCRS200W230V

References

NSYCRS10W120V NSYCRS10W240V NSYCRS25W120V NSYCRS25W240V NSYCRS50W120V NSYCRS50W240V NSYCRS100W120V NSYCRS100W240V NSYCRS200W120V NSYCRS200W240V

(1)

ClimaSys CC: thermal control

Mechanical controllers

Control a resistance heater

or an alarm

Setting range References

0...+60 °C NSYCCOTHC

NC thermostat

NO thermostat

Double thermostat

Thermostat with inverse contact

+32...+140 °F NSYCCOTHCF

Control a fan or an alarm

Setting range References

0...+60 °C NSYCCOTHO +32...+140 °F NSYCCOTHOF

Control a resistance heater

Setting range References

0...+60 °C NSYCCOTHD +32...+140 °F NSYCCOTHDF

Setting range References

0...+60 °C NSYCCOTHI +32...+140 °F NSYCCOTHIF

and a fan

Control a resistance heater

or a fan

Electronical controllers

Control a resistance heater or a fan

Setting range Display References

-40 °C… +80 °C

Electronic thermostat

Electronic hygrostat 2 different operating modes.

Electronic hygrotherm

7 different operating modes. Option of installing one or two external sensors.

Setting range Display References

20 %…80 % % RH

Control temperature and relative humidity

Setting range Display References

-40 °C… +80 °C

3 different operating modes. Option of installing an external sensor.

°C or °F

Control relative humidity

°C or °F

Sensors

External temperature sensor (double insulation)

Reference

NSYCCASTE

Temperature sensor

NSYCCOTH30VID NSYCCOTH120VID NSYCCOTH230VID

NSYCCOHY30VID NSYCCOHY120VID NSYCCOHY230VID

NSYCCOHYT30VID NSYCCOHYT120VID NSYCCOHYT230VID

ClimaSys DT: diagnostic tools Thermal accessories for outdoor

Heavy Duty enclosures

Temperature recorder

Temperature Reference Model

-40°C... +80°C

NSYDTEF32T

Capture thermal data to find the right thermal solutions

ClimaSys DT

diagnostic tools

EClima

software

DTT

ProClima

software

Voltage (V) References

24 DC

48 DC 115 AC 230 AC

NSYCAF190

NSYCAG223LFHD

NSYCAF223T

Anti-vandalism kit for HD metal grille

NSYCAAPVHD

Fanbox

NSYCVF550M24FB NSYCVF550M48FB NSYCVF550M115FB NSYCVF550M230FB

Roof filter for fanbox

Reference

IP55 HD Metal Grille

Reference

Filter

Reference

Thalassa PLS, Spacial SBM

Thalassa PLS

For boxes

Mounting

accesories

For installing

in the boxes (mm)

H W D Plain Telequick Polyester Bakelite

180 270 180 NSYPMM1827 NSYPMR1827 NSYPMA1827G NSYPMB1827 270 270 180 NSYPMM2727 NSYPMR2727 NSYPMA2727G NSYPMB2727 270 270 230 NSYPMM2727 NSYPMR2727 NSYPMA2727G NSYPMB2727 270 360 180 NSYPMM2736 NSYPMR2736 NSYPMA2736G NSYPMB2736 270 360 230 NSYPMM2736 NSYPMR2736 NSYPMA2736G NSYPMB2736 270 540 180 NSYPMM2754 NSYPMR2754 NSYPMA2754G NSYPMB2754 270 540 230 NSYPMM2754 NSYPMR2754 NSYPMA2754G NSYPMB2754 360 360 180 NSYPMM3636 - NSYPMA3636G NSYPMB3636 360 540 180 NSYPMM3654 NSYPMR3654 NSYPMA3654G NSYPMB3654 360 540 230 NSYPMM3654 NSYPMR3654 NSYPMA3654G NSYPMB3654 360 720 230 NSYPMM3672 NSYPMR3672 NSYPMA3672G NSYPMB3672 540 540 180 NSYPMM5454 NSYPMR5454 NSYPMA5454G NSYPMB5454 540 540 230 NSYPMM5454 NSYPMR5454 NSYPMA5454G NSYPMB5454 540 720 230 NSYPMM5472 NSYPMR5472 NSYPMA5472G NSYPMB5472

Metallic mounting plates Insulating mounting plates

Spacial SBM

Box external dimensions

H W D

150 150 80 NSYMM11SB NSYAMRD15357SB NSYSFPSC15 150 150 120 NSYMM11SB NSYAMRD15357SB NSYSFPSC15 150 200 80 NSYMM12SB NSYAMRD20357SB NSYSFPSC20 150 200 120 NSYMM12SB NSYAMRD20357SB NSYSFPSC20 150 300 80 NSYMM13SB NSYAMRD30357SB NSYSFPSC30 150 300 120 NSYMM13SB NSYAMRD30357SB NSYSFPSC30 150 400 80 NSYMM14SB NSYAMRD40357SB NSYSFPSC40 150 400 120 NSYMM14SB NSYAMRD40357SB NSYSFPSC40 200 200 80 NSYMM22SB NSYAMRD20357SB NSYSFPSC20 200 200 120 NSYMM22SB NSYAMRD20357SB NSYSFPSC20 200 300 80 NSYMM23SB NSYAMRD30357SB NSYSFPSC30 200 300 120 NSYMM23SB NSYAMRD30357SB NSYSFPSC30 200 400 80 NSYMM24SB NSYAMRD40357SB NSYSFPSC40 200 400 120 NSYMM24SB NSYAMRD40357SB NSYSFPSC40 200 500 80 NSYMM25SB NSYAMRD50357SB NSYSFPSC50 200 500 120 NSYMM25SB NSYAMRD50357SB NSYSFPSC50 200 600 80 NSYMM26SB NSYAMRD60357SB NSYSFPSC60 200 600 120 NSYMM26SB NSYAMRD60357SB NSYSFPSC60 200 800 120 NSYMM28SB NSYAMRD80357SB NSYSFPSC80 300 300 120 NSYMM33SB NSYAMRD30357SB NSYSFPSC30 300 400 120 NSYMM34SB NSYAMRD40357SB NSYSFPSC40 300 500 120 NSYMM35SB NSYAMRD50357SB NSYSFPSC50 300 600 120 NSYMM36SB NSYAMRD60357SB NSYSFPSC60 300 800 120 NSYMM38SB NSYAMRD80357SB NSYSFPSC80 400 400 120 NSYMM44SB NSYAMRD40357SB NSYSFPSC40 400 500 120 NSYMM45SB NSYAMRD50357SB NSYSFPSC50 400 600 120 NSYMM46SB NSYAMRD60357SB NSYSFPSC60 400 800 120 NSYMM48SB NSYAMRD80357SB NSYSFPSC80

Plain mounting plate DIN rail Post fastening

Step slides for Thalassa PLM

For wall-mounting enclosure

Depth (mm)

200 NSYDPLM200 250 NSYDPLM250 300 NSYDPLM300 350 NSYDPLM350

References

Plastic nuts for rail fixing for Thalassa PLM

Description References

Plastic nut with self-tapping screw NSYTCSPLM Plastic nut containing an M6 metal nut NSYTCSM6PLM

Spacial S3D, S3X,

For wall-mounting enclosures

Thalassa PLM

AM1-PA

External

dimensions

(mm)

H W type

60 700 - - - - - - - - - - AM1PA0670 120 700 - - - - - - - - - - AM1PA1270 200 200 NSYMM22 - - - - - - - - - 200 300 NSYMM23 - - - - - - - - - 250 200 NSYMM2520 - - - - - - - - - 250 400 NSYMM2540 - - - - - - - - - 250 500 NSYMM2550 - - - - - - - - - 300 150 - - - - - - - - - - AM1PA3015 300 195 - - - - - - - - - - AM1PA3020 300 200 NSYMM32 - NSYMF32 NSYMB32 NSYMPP32 NSYMR32 - - NSYMDVR3 - 300 250 NSYMM3025 - - NSYMB3025 NSYMPP3025 NSYMR3025 - - NSYMDVR3 - 300 300 NSYMM33 - NSYMF33 NSYMB33 - NSYMR33 NSYMD33 B NSYMDVR3 NSYSDR30B 300 400 NSYMM43 NSYMS43 NSYMF43* NSYMB43 NSYMPP43 NSYMR34 - - NSYMDVR3 NSYSDR40B 300 450 NSYMM3045 - - - - - - - - - 300 500 - - - - - - - - - - AM1PA3050 300 600 NSYMM36 - - - - - - - - - 300 700 - - - - - - - - - - AM1PA3070 400 300 NSYMM43 NSYMS43 - NSYMB43 NSYMPP43 NSYMR43 NSYMD43 B NSYMDVR4 NSYSDR30B 400 400 - - NSYMF44 - - NSYMR44 - - - - 400 600 NSYMM64 NSYMS64 - NSYMB64 NSYMPP64 NSYMR46 - - NSYMDVR4 NSYSDR60A 400 800 NSYMM48 - - - - - - - - - 405 300 - - - - - - - - - - AM1PA4030 500 300 NSYMM35 NSYMS53 NSYMF53 - - NSYMR53 - - NSYMDVR5 NSYSDR30B 500 400 NSYMM54 NSYMS54 NSYMF54 NSYMB54 NSYMPP54 NSYMR54 NSYMD54 B NSYMDVR5 NSYSDR40B 500 500 NSYMM55 NSYMS55 NSYMF55 - - NSYMR55 - - NSYMDVR5 NSYSDR50A 600 400 NSYMM64 NSYMS64 NSYMF64* NSYMB64 NSYMPP64 NSYMR64 NSYMD64 B NSYMDVR6 NSYSDR40B AM1PA6040 600 500 NSYMM65 - NSYMF65 NSYMB65 - NSYMR65 - - NSYMDVR6 NSYSDR50A AM1PA6050 600 600 NSYMM66 NSYMS66 NSYMF66 - - NSYMR66 NSYMD66 A NSYMDVR6 NSYSDR60A AM1PA6060 600 700 - - - - - - - - - - AM1PA6070 600 800 NSYMM86 NSYMS86 - NSYMB86 NSYMPP86 NSYMR68 - - NSYMDVR6 NSYSDR80A 700 500 NSYMM75 NSYMS75 NSYMF75 NSYMB75 NSYMPP75 NSYMR75 NSYMD75 B NSYMDVR7 NSYSDR50A 700 600 - - - - - NSYMR76 - - - - 705 500 - - - - - - - - - - AM1PA7050 795 600 800 600 NSYMM86 NSYMS86 NSYMF86* NSYMB86 NSYMPP86 - NSYMD86 A NSYMDVR8 NSYSDR60A 800 800 NSYMM88 - NSYMF88 - - - - - NSYMDVR8 NSYSDR80A 800 1000 NSYMM108 - - NSYMB108 NSYMPP108 NSYMR810 - - NSYMDVR8 NSYSDR100A 900 500 - - - - - - - - - - AM1PA9050 900 600 - - - - - - - - - - AM1PA9060 900 700 - - - - - - - - - - AM1PA9070

1000 600 NSYMM106 - NSYMF106 NSYMB106 - NSYMR106 - - NSYMDVR10 NSYSDR60A 1000 800 NSYMM108 - NSYMF108* NSYMB108 NSYMPP108 NSYMR108 NSYMD108 A NSYMDVR10 NSYSDR80A 1000 1000 NSYMM1010 - NSYMF1010 - - NSYMR1010 - - NSYMDVR10 NSYSDR100A 1000 1200 NSYMM1210 - - NSYMB1210 - NSYMR1012 - - NSYMDVR10 2 x NSYSDR60A 1200 600 NSYMM126 - NSYMF126 - - NSYMR126 - - NSYMDVR12 NSYSDR60A 1200 800 NSYMM128 - NSYMF128 - - NSYMR128 NSYMD128 A NSYMDVR12 NSYSDR80A 1200 1000 NSYMM1210 - NSYMF1210* NSYMB1210 - NSYMR1210 - - NSYMDVR12 NSYSDR100A 1200 1200 NSYMM1212 - - - - - - - NSYMDVR12 2 x NSYSDR60A 1400 1000 NSYMM1410 - - - NSYMR1410 - - - NSYSDR100A -

* Plate with reversible dimensions; it can be installed in enclosures with inverted dimensions. Example: Plate ref. NSYMM64 can be used for the following enclosures: H 600 x W 400 mm

Plain

mounting

plate

- - - - - - - - - -

Silkscreened

Microperforated

Bakelite Polyester

Telequick mounting

plate

DIN rail

chassis

Aluminum

vertical rails

Symetrical

DIN rail for

aluminum

upright

Joinable

Telequick

mounting plate

AM1PA8060

35 mm symmetrical DIN rails for Thalassa PLM

Rail length (mm)

180 215 NSYCS200PLM 280 330 NSYCS300PLM 380 430 / 436 NSYCS400PLM 480 536 NSYCS500PLM 580 636 NSYCS600PLM 795 852 NSYCS800PLM

For wall-mounting enclosure

Width (mm)

References

Clip-on nuts for Telequick mounting plate

Model References

M3 AF1EA3 M4 AF1EA4 M5 AF1EA5 M6 AF1EA6

Spacial SM, SF

For floor-standing enclosures

Mounting

accesories

Nominal dimensions (mm)

H W D

600 - - - - - - - - - - NSYSDR60 - - - -

800 - - - - - - - - - - NSYSDR80 - - - - 1000 - - - - - - NSYTVR10* - - - NSYSDR100 - - - - 1200 600 400 1 - - - NSYTVR12 1200 600 600 1 - - - NSYTVR12 1200 800 300 1 NSYSMVR12 NSYSMHR8 - NSYTVR12 1200 800 400 1 - - - NSYTVR12 1200 800 600 1 - - - NSYTVR12 1200 1000 300 2 NSYSMVR12 NSYSMHR10 - NSYTVR12 1200 1200 400 2 NSYSMVR12 NSYSMHR12 - NSYTVR12 1400 600 300 1 NSYSMVR14 NSYSMHR6 - NSYTVR14 1400 600 400 1 NSYSMVR14 NSYSMHR6 - NSYTVR14 1400 800 300 1 NSYSMVR14 NSYSMHR8 - NSYTVR14 1400 800 400 1 NSYSMVR14 NSYSMHR8 - NSYTVR14 1400 1000 400 2 NSYSMVR14 NSYSMHR10 - NSYTVR14 1400 1200 400 2 NSYSMVR14 NSYSMHR12 - NSYTVR14 1600 600 300 1 NSYSMVR16 NSYSMHR6 - NSYTVR16 1600 600 400 1 NSYSMVR16 NSYSMHR6 - NSYTVR16 1600 600 600 1 - - - NSYTVR16 1600 600 800 1 - - - NSYTVR16 1600 800 300 1 NSYSMVR16 NSYSMHR8 - NSYTVR16 1600 800 400 1 NSYSMVR16 NSYSMHR8 - NSYTVR16 1600 800 600 1 - - - NSYTVR16 1600 800 800 1 - - - NSYTVR16 1600 1000 300 2 NSYSMVR16 NSYSMHR10 - NSYTVR16 1600 1000 400 2 NSYSMVR16 NSYSMHR10 - NSYTVR16 1600 1200 300 2 NSYSMVR16 NSYSMHR12 - NSYTVR16 1600 1200 400 2 NSYSMVR16 NSYSMHR12 - NSYTVR16 1800 400 400 1 - - NSYVR18 NSYTVR18 - - NSYMP184 - - NSYHLCR40 - NSYSMPS4 1800 400 500 1 - - NSYVR18 NSYTVR18 - - NSYMP184 - - NSYHLCR50 - NSYSMPS5 1800 400 600 1 - - NSYVR18 NSYTVR18 - - NSYMP184 - - NSYHLCR60 - NSYSMPS6 1800 600 300 1 NSYSMVR18 NSYSMHR6 NSYVR18 NSYTVR18 1800 600 400 1 NSYSMVR18 NSYSMHR6 NSYVR18 NSYTVR18 1800 600 500 1 NSYSMVR18 NSYSMHR6 NSYVR18 NSYTVR18 1800 600 600 1 - - NSYVR18 NSYTVR18 1800 600 800 1 - - NSYVR18 NSYTVR18 1800 800 300 1 NSYSMVR18 NSYSMHR8 NSYVR18 NSYTVR18 1800 800 400 1 NSYSMVR18 NSYSMHR8 NSYVR18 NSYTVR18 1800 800 500 1 NSYSMVR18 NSYSMHR8 NSYVR18 NSYTVR18 1800 800 600 1 NSYSMVR18 NSYSMHR8 NSYVR18 NSYTVR18 1800 800 600 2 - - NSYVR18 NSYTVR18 1800 1000 400 1 NSYSMVR18 NSYSMHR10 NSYVR18 NSYTVR18 1800 1000 400 2 NSYSMVR18 NSYSMHR10 NSYVR18 NSYTVR18 1800 1000 500 1 - - NSYVR18 NSYTVR18 1800 1000 500 2 NSYSMVR18 NSYSMHR10 NSYVR18 NSYTVR18 1800 1000 600 1 - - NSYVR18 NSYTVR18 1800 1000 600 2 - - NSYVR18 NSYTVR18 1800 1200 400 2 NSYSMVR18 NSYSMHR12 NSYVR18 NSYTVR18 1800 1200 500 2 NSYSMVR18 NSYSMHR12 NSYVR18 NSYTVR18 1800 1200 600 2 - - NSYVR18 1800 1600 400 2 NSYSMVR18 NSYSMHR16 NSYVR18 NSYTVR18 1800 1600 500 2 NSYSMVR18 NSYSMHR16 NSYVR18 NSYTVR18 2000 300 500 1 - - NSYVR20 NSYTVR20 - - - - NSYHLCR50 - NSYSMPS5 2000 300 600 1 - - NSYVR20 NSYTVR20 - - - - NSYHLCR60 - NSYSMPS6 2000 300 800 1 - - NSYVR20 NSYTVR20 - - - - NSYHLCR80 - NSYSMPS8 2000 400 400 1 - - NSYVR20 NSYTVR20 - NSYMP204 - - NSYHLCR40 - NSYSMPS4 2000 400 500 1 - - NSYVR20 NSYTVR20 - NSYMP204 - - NSYHLCR50 - NSYSMPS5 2000 400 600 1 - - NSYVR20 NSYTVR20 - NSYMP204 - - NSYHLCR60 - NSYSMPS6 2000 400 800 1 - - NSYVR20 NSYTVR20 - NSYMP204 - - NSYHLCR80 - NSYSMPS8 2000 600 300 1 NSYSMVR20 NSYSMHR6 NSYVR20 NSYTVR20 2000 600 400 1 NSYSMVR20 NSYSMHR6 NSYVR20 NSYTVR20 2000 600 500 1 NSYSMVR20 NSYSMHR6 NSYVR20 NSYTVR20 2000 600 600 1 - - NSYVR20 NSYTVR20 2000 600 800 1 - - NSYVR20 NSYTVR20 2000 800 300 1 NSYSMVR20 NSYSMHR8 NSYVR20 NSYTVR20 2000 800 400 1 NSYSMVR20 NSYSMHR8 NSYVR20 NSYTVR20 2000 800 500 1 NSYSMVR20 NSYSMHR8 NSYVR20 NSYTVR20 2000 800 600 1 NSYSMVR20 NSYSMHR8 NSYVR20 NSYTVR20 2000 800 600 2 - - NSYVR20 NSYTVR20 2000 800 800 1 - - NSYVR20 NSYTVR20 2000 1000 400 1 - - NSYVR20 NSYTVR20 2000 1000 400 2 NSYSMVR20 NSYSMHR10 NSYVR20 NSYTVR20 2000 1000 500 1 - - NSYVR20 NSYTVR20 2000 1000 500 2 NSYSMVR20 NSYSMHR10 NSYVR20 NSYTVR20 2000 1000 600 1 - - NSYVR20 NSYTVR20 2000 1000 600 2 - - NSYVR20 NSYTVR20 2000 1000 800 1 - - NSYVR20 NSYTVR20 2000 1200 400 2 NSYSMVR20 NSYSMHR12 NSYVR20 NSYTVR20 2000 1200 500 2 NSYSMVR20 NSYSMHR12 NSYVR20 NSYTVR20 2000 1200 600 2 NSYSMVR20 NSYSMHR12 NSYVR20 NSYTVR20 2000 1200 800 2 - - NSYVR20 NSYTVR20 2000 1600 400 2 NSYSMVR20 NSYSMHR16 NSYVR20 NSYTVR20 2000 1600 500 2 NSYSMVR20 NSYSMHR16 NSYVR20 NSYTVR20 2000 1600 600 2 NSYSMVR20 NSYSMHR16 NSYVR20 NSYTVR20 2200 400 600 1 - - NSYVR22 NSYTVR22 - - NSYMP224 - - NSYHLCR60 - NSYSMPS6 2200 600 600 1 - - NSYVR22 NSYTVR22 2200 600 800 1 - - NSYVR22 NSYTVR22 2200 800 600 1 - - NSYVR22 NSYTVR22 2200 800 800 1 - - NSYVR22 NSYTVR22 2200 1000 600 1 - - NSYVR22 NSYTVR22 2200 1200 600 2 - - NSYVR22 NSYTVR22 2200 1200 800 2 - - NSYVR22 NSYTVR22

No.

doors

Spacial SM Spacial SM and SF Spacial SF

Vertical

adaptation

proles

Horizontal

adaptation

proles

Standard

vertical

uprights

Technical

vertical upright

Perforated

mounting plate

"Telequick"

NSYSTMP2260 NSYSPMP2560 NSYSTMP2260 NSYSPMP2560 NSYSTMP2280 NSYSPMP2580 NSYSTMP2280 NSYSPMP2580 NSYSTMP2280 NSYSPMP2580 NSYSTMP22100 NSYSPMP25100 NSYSTMP22120 NSYSPMP25120 NSYSTMP4560 NSYSPMP2575 NSYSTMP4560 NSYSPMP2575 NSYSTMP4580 NSYSPMP4080 NSYSTMP4580 NSYSPMP4080 NSYSTMP45100 NSYSPMP40100 NSYSTMP45120 NSYSPMP40120 NSYSTMP6060 NSYSPMP4060 NSYSTMP6060 NSYSPMP4060 NSYSTMP6060 NSYSPMP4060 NSYSTMP6060 NSYSPMP4060 NSYSTMP6080 NSYSPMP6080 NSYSTMP6080 NSYSPMP6080 NSYSTMP6080 NSYSPMP6080 NSYSTMP6080 NSYSPMP6080 NSYSTMP60100 NSYSPMP60100 NSYSTMP60100 NSYSPMP60100 NSYSTMP60120 NSYSPMP60120 NSYSTMP60120 NSYSPMP60120

NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8280 NSYSTMP8280 NSYSTMP8280 NSYSTMP8280 NSYSTMP8280 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82120 NSYSTMP82120 NSYSTMP82120

NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8280 NSYSTMP8280 NSYSTMP8280 NSYSTMP8280 NSYSTMP8280 NSYSTMP8280 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82100 NSYSTMP82120 NSYSTMP82120 NSYSTMP82120 NSYSTMP82120 NSYSPMP40160 NSYSPMP40160 NSYSPMP40160

NSYSTMP8260 NSYSPMP6060 NSYSTMP8260 NSYSPMP6060 NSYSTMP8280 NSYSTMP8280 NSYSTMP82100 NSYSTMP82120 NSYSTMP82120

Partial

mounting

plate

- NSYMP188 - NSYMPRK8 - - -

- NSYMP188 - NSYMPRK8 NSYHLCR40 NSYSIMP18 NSYSMPS4

- NSYMP188 - NSYMPRK8 NSYHLCR50 NSYSIMP18 NSYSMPS5

- NSYMP188 - NSYMPRK8 NSYHLCR60 NSYSIMP18 NSYSMPS6

- NSYMP1810 - NSYMPRK10 NSYHLCR40 NSYSIMP18 NSYSMPS4

- NSYMP1810 - NSYMPRK10 NSYHLCR50 NSYSIMP18 NSYSMPS5

- NSYMP1810 - NSYMPRK10 NSYHLCR50 - NSYSMPS5

- NSYMP1810 - NSYMPRK10 NSYHLCR60 NSYSIMP18 NSYSMPS6

- NSYMP1812 - NSYMPRK12 NSYHLCR40 NSYSIMP18 NSYSMPS4

- NSYMP1812 - NSYMPRK12 NSYHLCR50 NSYSIMP18 NSYSMPS5

- NSYMP1812 - NSYMPRK12 NSYHLCR60 NSYSIMP18 NSYSMPS6 NSYSPMP40160 NSYSPMP40160

- NSYMP2010 - NSYMPRK10 NSYHLCR40 NSYSIMP20 NSYSMPS4

- NSYMP2010 - NSYMPRK10 NSYHLCR50 NSYSIMP20 NSYSMPS5

- NSYMP2010 - NSYMPRK10 NSYHLCR60 NSYSIMP20 NSYSMPS6

- NSYMP2010 - NSYMPRK10 NSYHLCR80 NSYSIMP20 NSYSMPS8

- NSYMP2012 - NSYMPRK12 NSYHLCR40 NSYSIMP20 NSYSMPS4

- NSYMP2012 - NSYMPRK12 NSYHLCR50 NSYSIMP20 NSYSMPS5

- NSYMP2012 - NSYMPRK12 NSYHLCR60 NSYSIMP20 NSYSMPS6

- NSYMP2012 - NSYMPRK12 NSYHLCR80 NSYSIMP20 NSYSMPS8

- NSYMP2016 - NSYMPRK16 NSYHLCR40 NSYSIMP20 NSYSMPS4

- NSYMP2016 - NSYMPRK16 NSYHLCR50 NSYSIMP20 NSYSMPS5

- NSYMP2016 - NSYMPRK16 NSYHLCR60 NSYSIMP20 NSYSMPS6

- NSYMP2210 - NSYMPRK10 NSYHLCR60 NSYSIMP22 NSYSMPS6

- NSYMP2212 - NSYMPRK12 NSYHLCR60 NSYSIMP22 NSYSMPS6

- NSYMP2212 - NSYMPRK12 NSYHLCR80 NSYSIMP22 NSYSMPS8

Plain

mounting

plate

NSYMP126 NSYSDR120 - NSYHLCR40 NSYSIMP12 NSYSMPS4 NSYMP126 NSYSDR120 - NSYHLCR60 NSYSIMP12 NSYSMPS6 NSYMP128 NSYSDR120 NSYMPRK8 - - - NSYMP128 NSYSDR120 NSYMPRK8 NSYHLCR40 NSYSIMP12 NSYSMPS4 NSYMP128 NSYSDR120 NSYMPRK8 NSYHLCR60 NSYSIMP12 NSYSMPS6 NSYMP1210 NSYSDR120 NSYMPRK10 - - - NSYMP1212 NSYSDR120 NSYMPRK12 NSYHLCR40 - NSYSMPS4 NSYMP146 - - - - - NSYMP146 - - NSYHLCR40 NSYSIMP14 NSYSMPS4 NSYMP148 - NSYMPRK8 - - - NSYMP148 - NSYMPRK8 NSYHLCR40 NSYSIMP14 NSYSMPS4 NSYMP1410 - NSYMPRK10 NSYHLCR40 - NSYSMPS4 NSYMP1412 - NSYMPRK12 NSYHLCR40 - NSYSMPS4 NSYMP166 - - - - - NSYMP166 - - NSYHLCR40 - NSYSMPS4 NSYMP166 - - NSYHLCR60 NSYSIMP16 NSYSMPS6 NSYMP166 - - NSYHLCR80 NSYSIMP16 NSYSMPS8 NSYMP168 - NSYMPRK8 - - - NSYMP168 - NSYMPRK8 NSYHLCR40 - NSYSMPS4 NSYMP168 - NSYMPRK8 NSYHLCR60 NSYSIMP16 NSYSMPS6 NSYMP168 - NSYMPRK8 NSYHLCR80 NSYSIMP16 NSYSMPS8 NSYMP1610 - NSYMPRK10 - - - NSYMP1610 - NSYMPRK10 NSYHLCR40 - NSYSMPS4 NSYMP1612 - NSYMPRK12 - - - NSYMP1612 - NSYMPRK12 NSYHLCR40 - NSYSMPS4

NSYMP186 - - - - - NSYMP186 - - NSYHLCR40 NSYSIMP18 NSYSMPS4 NSYMP186 - - NSYHLCR50 NSYSIMP18 NSYSMPS5 NSYMP186 - - NSYHLCR60 NSYSIMP18 NSYSMPS6 NSYMP186 - - NSYHLCR80 NSYSIMP18 NSYSMPS8

NSYMP1816 - NSYMPRK16 NSYHLCR40 - NSYSMPS4 NSYMP1816 - NSYMPRK16 NSYHLCR50 - NSYSMPS5

NSYMP206 - - - - - NSYMP206 - - NSYHLCR40 NSYSIMP20 NSYSMPS4 NSYMP206 - - NSYHLCR50 NSYSIMP20 NSYSMPS5 NSYMP206 - - NSYHLCR60 NSYSIMP20 NSYSMPS6 NSYMP206 - - NSYHLCR80 NSYSIMP20 NSYSMPS8 NSYMP208 - NSYMPRK8 - - - NSYMP208 - NSYMPRK8 NSYHLCR40 NSYSIMP20 NSYSMPS4 NSYMP208 - NSYMPRK8 NSYHLCR50 NSYSIMP20 NSYSMPS5 NSYMP208 - NSYMPRK8 NSYHLCR60 NSYSIMP20 NSYSMPS6 NSYMP208 - NSYMPRK8 NSYHLCR60 NSYSIMP20 NSYSMPS6 NSYMP208 - NSYMPRK8 NSYHLCR80 NSYSIMP20 NSYSMPS8

NSYMP226 - - NSYHLCR60 NSYSIMP22 NSYSMPS6 NSYMP226 - - NSYHLCR80 NSYSIMP22 NSYSMPS8 NSYMP228 - NSYMPRK8 NSYHLCR60 NSYSIMP22 NSYSMPS6 NSYMP228 - NSYMPRK8 NSYHLCR80 NSYSIMP22 NSYSMPS8

Symmetric

DIN rails

Reinforcements

for mounting

plates

Rails

for heavy duty

* NSYTVR8 for control desk.

Orthogonal brackets

for Spacial SF

Reference

NSYSMPSB

Bracket for fixing uprights

for Spacial SF

Reference

NSYMFB

Brackets for fixing mounting plates

in back-to-back position for Spacial SF

Reference

NSYSBTB

Thalassa PLA

Intermediate

mounting plate

Mounting plate

sliding rails

Enclosure dimensions (mm)

H W

500 500 1 NSYPMM55 NSYPMR55 NSYPMA55 NSYPMB55 500 750 1 NSYPMM75 NSYPMR57 NSYPMA75 NSYPMB75 500 1000 2 NSYPMM510 2 x NSYPMR55 NSYPMA510 NSYPMB510 500 1250 2 NSYPMM55 + NSYPMM75 NSYPMR55 + NSYPMR57 NSYPMA55 + NSYPMA75 NSYPMB55 + NSYPMB75 750 500 1 NSYPMM75 NSYPMR75 NSYPMA75 NSYPMB75 750 750 1 NSYPMM77 NSYPMR77 NSYPMA77 NSYPMB77 750 1000 2 NSYPMM710 2 x NSYPMR75 NSYPMA710 NSYPMB710

750 1250 2 NSYPMM712 NSYPMR75 + NSYPMR77 NSYPMA712 NSYPMB712 1000 500 1 NSYPMM105 NSYPMR105 NSYPMA105 NSYPMB105 1000 750 1 NSYPMM107 NSYPMR107 NSYPMA107 NSYPMB107 1000 1000 2 NSYPMM1010 2 x NSYPMR105 NSYPMA1010 NSYPMB1010 1000 1250 2 NSYPMM1012 NSYPMR105 + NSYPMR107 NSYPMA1012 NSYPMB1012 1250 500 1 NSYPMM125 NSYPMR125 NSYPMA125 NSYPMB125 1250 750 1 NSYPMM127 NSYPMR127 NSYPMA127 NSYPMB127 1250 1000 2 NSYPMM1210 2 x NSYPMR125 NSYPMA1210 NSYPMB1210 1250 1250 2 NSYPMM1212 NSYPMR125 + NSYPMR127 NSYPMA1212 NSYPMB1212 1500 500 1 NSYPMM155 NSYPMR155 - NSYPMB155 1500 750 1 NSYPMM157 NSYPMR157 - NSYPMB157 1500 1000 2 NSYPMM1510 2 x NSYPMR155 - NSYPMB1510 1500 1250 2 NSYPMM1512 NSYPMR155 + NSYPMR157 - NSYPMB1512 2000 750 2* NSYPMM207 2 x NSYPMR107 2 x NSYPMA107 2 x NSYPMB107

* Two doors in vertical.

No. of doors

Metallic mounting plates Insulating mounting plates

Plain Telequick Polyester Bakelite

Step slides for Thalassa PLA

For enclosure References

Depth (mm)

No. of doors Step slides

320 1 NSYDPLA3 NSYPTZ3 420 1 NSYDPLA4 NSYPTZ4 620 1 NSYDPLA6 NSYPTZ6 320 2 2 x NSYDPLA3 NSYPTZ32P 420 2 2 x NSYDPLA4 NSYPTZ42P 620 2 2 x NSYDPLA6 NSYPTZ62P

Adapter plates

for PLAZ or PLAZT

Cross rails

Dimensions Universal cross rails references Quick-fixing cross rails references Integrated cross-rails

H/W/D (mm)

300

400

500

600

800

1000

1200

1400

1600

1800

2000

2200

40 mm (1 row)

NSYSUCR4030 NSYSUCR6530 NSYSUCR9030 NSYSQCR4040 NSYSQCR6540 NSYSQCR9040 NSYSICR4030 NSYSICR6530 NSYSICR9030 NSYSUCR4040 NSYSUCR6540 NSYSUCR9040 NSYSQCR4050 NSYSQCR6550 NSYSQCR9050 NSYSICR4040 NSYSICR6540 NSYSICR9040 NSYSUCR4050 NSYSUCR6550 NSYSUCR9050 NSYSQCR4060 NSYSQCR6560 NSYSQCR9060 NSYSICR4050 NSYSICR6550 NSYSICR9050 NSYSUCR4060 NSYSUCR6560 NSYSUCR9060 NSYSQCR4080 NSYSQCR6580 NSYSQCR9080 NSYSICR4060 NSYSICR6560 NSYSICR9060 NSYSUCR4080 NSYSUCR6580 NSYSUCR9080 NSYSQCR40100 NSYSQCR65100 NSYSQCR90100 NSYSICR4080 NSYSICR6580 NSYSICR9080 NSYSUCR40100 NSYSUCR65100 NSYSUCR90100 NSYSQCR40120 NSYSQCR65120 NSYSQCR90120 NSYSICR40100 NSYSICR65100 NSYSICR90100 NSYSUCR40120 NSYSUCR65120 NSYSUCR90120 - - - NSYSICR40120 NSYSICR65120 NSYSICR90120 NSYSUCR40140 NSYSUCR65140 NSYSUCR90140 - - - - - NSYSUCR40160 NSYSUCR65160 NSYSUCR90160 - - - - - NSYSUCR40180 NSYSUCR65180 NSYSUCR90180 - - - - - NSYSUCR40200 NSYSUCR65200 NSYSUCR90200 - - - - - NSYSUCR40220 NSYSUCR65220 NSYSUCR90220 - - - - - -

65 mm

(2 rows)

Brackets for fixing intermediate mounting plates

in back-to-back position for Spacial SF

Reference

NSYSIBTB

90 mm

(3 rows)

40 mm

(1 row)

65 mm

(2 rows)

90 mm

(3 rows)

40 mm (1 row)

Mounting plate fixing brackets

for Spacial SF, SM, SFX, SMX

For enclosure References

Spacial SF NSYSFPB Spacial SM, Spacial SFX, Spacial SMX NSYSMPB

65 mm

(2 rows)

90 mm

(3 rows)

Modular Distribution

Electrical

Chassis for Spacial SF, SM

Single-chassis coupling set - RAL 7035

Nominal

dimensions (mm)

H W

1200

1400

1600

1800

2000

Plain cover plates - RAL 7035

Nominal dimensions (mm)

H W

150

200

300

400

distribution

450

600

600 NSYMPC156 NSYMPCH156 800 NSYMPC158 NSYMPCH158 600 NSYMPC206 NSYMPCH206 800 NSYMPC208 NSYMPCH208 600 NSYMPC306 NSYMPCH306 800 NSYMPC308 NSYMPCH308 600 NSYMPC406 NSYMPCH406 800 NSYMPC408 NSYMPCH408 600 NSYMPC456 NSYMPCH456 800 NSYMPC458 NSYMPCH458 600 NSYMPC606 NSYMPCH606 800 NSYMPC608 NSYMPCH608

Maximum no. of 18-mm modules

600 144 NSYCSH126

800 216 NSYCSH128

600 192 NSYCSH146

800 288 NSYCSH148

600 216 NSYCSH166

800 324 NSYCSH168

600 240 NSYCSH186

800 360 NSYCSH188

600 288 NSYCSH206

800 432 NSYCSH208

Screwed-on plain

cover plate references

accessories

Double-chassis coupling set - RAL 7035

References

Cut-out cover plates - RAL 7035

Nominal

dimensions

Hinged plain cover

plate references

H W D E F

150

200

300

400

450

600

Spacial

dimensions

(mm)

H W

1400 1200 600 + 600 384 NSYDCSH1412 1600 1200 600 + 600 432 NSYDCSH1612

1800

2000

(mm)

Dimensions

600 432 800 642 1 36 NSYMUC158 NSYMUCH158

600 432 800 642 1 36 NSYMUC208 NSYMUCH208

600 432 800 642 2 72 NSYMUC308 NSYMUCH308

600 432 800 642 2 72 NSYMUC408 NSYMUCH408

600 432 800 642 3 108 NSYMUC458 NSYMUCH458

600 432 800 642 3 108 NSYMUC608 NSYMUCH608

- -

51.75 150

76.75 200

51.75 150

76.75 200

Set made up

of columns

with

a width

(mm)

1200 600 + 600 480 NSYDCSH1812 1600 800 + 800 720 NSYDCSH1816 1200 600 + 600 576 NSYDCSH2012 1600 800 + 800 864 NSYDCSH2016

No.

Maximum

cut-

outs

1 24 NSYMUC156 NSYMUCH156

1 24 NSYMUC206 NSYMUCH206

2 48 NSYMUC306 NSYMUCH306

2 48 NSYMUC406 NSYMUCH406

3 72 NSYMUC456 NSYMUCH456

3 72 NSYMUC606 NSYMUCH606

no. of

18-mm

modules

Maximum

no. of

18-mm

modules

Screwed-on

cut-out

cover plate

references

References

cover plate

references

Hinged cut-out

Chassis-coupling set with zone for busbars - RAL 7035

Nominal

dimensions (mm)

H W

1400

1600

1800

2000

1000 600 + 400 192 NSYCSHB1410 1200 800 + 400 288 NSYCSHB1412 1000 600 + 400 216 NSYCSHB1610 1200 800 + 400 324 NSYCSHB1612 1000 600 + 400 240 NSYCSHB1810 1200 800 + 400 360 NSYCSHB1812 1000 600 + 400 288 NSYCSHB2010 1200 800 + 400 432 NSYCSHB2012

Set made up of

columns with a

width (mm)

Maximum

no. of 18-mm

modules

References

Fixed supports with no rail

Reference

NSYMFS1

Adjustment cover plates - RAL 7035

Cover plate

dimensions (mm)

H W

Nominal dimensions

(mm)

600 NSYADC16 800 NSYADC18

References

Busbars

Chassis for Spacial S3D, SDX, S3DM

630 A bar support for SF, SM, SFX

Nominal

dimensions

(mm)

Width/Depth

400 NSYBS400 500 NSYBS500 600 NSYBS600 800 NSYBS800

References

Screen for 630 A multi-stage busbar

630 A busbar end cover

Reference

NSYBSC630

630 A multi-stage bar support

Modular chassis

Dimensions

(mm)

Height Width

400 300 24 500 400 48 600 400 48 600 600 84 700 500 66 700 500 88 800 600 84

800 600 112 1000 600 168 1000 800 234

* 1 module = 2 steps = 18 mm

Number of

modules*

Modular

chassis

reference

NSYDLM24 NSYCTL300DLM NSYPMP300DLM NSYDLM48 NSYCTL400DLM NSYPMP400DLM NSYDLM48P NSYCTL400DLM NSYPMP400DLM NSYDLM84P NSYCTL600DLM NSYPMP600DLM NSYDLM66 NSYCTL500DLM NSYPMP500DLM NSYDLM88 NSYCTL500DLM NSYPMP500DLM NSYDLM84 NSYCTL600DLM NSYPMP600DLM NSYDLM112 NSYCTL600DLM NSYPMP600DLM NSYDLM168 NSYCTL600DLM NSYPMP600DLM NSYDLM240 NSYCTL800DLM NSYPMP800DLM

Plain front

reference

Chassis for Thalassa PLA

plate

Plain chassis

reference

04197

Reference

04192

Reference

Chassis for Thalassa PLM, Spacial S3D & S3X

Dinimel DLA modular chassis

Dimensions (mm)

Height Width

400 300 24 500 400 48 600 400 48 700 500 66 700 500 88 800 600 84 800 600 112

1000 800 234

* 1 module = 2 steps = 18 mm

Number of

modules*

Modular chassis reference

NSYDLA24G NSYDLA48G NSYDLA48PG NSYDLA66G NSYDLA88G NSYDLA84G NSYDLA112G NSYDLA234G

Modular distribution chassis

Dimensions (mm)

Height Width

750 500 57 NSYDLP57G 750 500 76 NSYDLP76G 750 750 99 NSYDLP99G

750 750 132 NSYDLP132G 1000 500 95 NSYDLP95G 1000 500 114 NSYDLP114G 1000 750 165 NSYDLP165G 1000 750 198 NSYDLP198G 1250 500 114 NSYDLP114PG 1250 500 133 NSYDLP133G 1250 750 198 NSYDLP198PG 1250 750 231 NSYDLP231G 1500 500 152 NSYDLP152G 1500 500 171 NSYDLP171G 1500 750 264 NSYDLP264G 1500 750 297 NSYDLP297G

* 1 module = 2 steps = 18 mm

Number of

modules*

Modular chassis reference

Cable management

Cable entries

Simple Cable Entries

Characteristics Simple-1 Simple-2 Simple-3 Simple-4 Simple-5

Description Mixed membrane entries for

Material SBS PVC EPDM PVC PA6, neoprene gasket PA6 Polyamide, neoprene gasket AISI 304L or AISI 316L stainless

Color RAL 7035 light grey

Ingress protection rating IP55 IP55 IP67 IP55 IP68 IP68 IP68 IP68 Ingress protection rating Cable retention Low Low Medium Low High High High - Cable retention Cable diameter (mm) From 20 to 40 From 5 to 87 From 12 to 50 From 16 to 44 From 12 to 40 From 16 to 40 From 12 to 40 From 3/6.5 to 19/28 Cable diameter (mm) External dimensions (mm) Ø 23 to 44 Ø 25 to 98 - Ø 25 to 52 Ø 15 to 46 From Ø 22 to 46 From Ø 14 to 43 Ø 12 to 40 External dimensions (mm) References RAL 9003 RAL 7035 NSYECPC3

enclosure thickness 20/10e 32/10emm.

or RAL 9003 white

IMT36130 IMT36131

ISM71071 ISM71072 ISM71073 ISM71074

(1) Cable gland with high resistance to ﬁre.

For details, type the reference in the search engine at se.com/enclosures.

PVC adjustable cone-shaped entries for enclosure thickness 30/10e - 32/10e mm.

- Grey: NCS 5500 - RAL 7035 grey RAL 7035, RAL 7001, RAL 9005.

NSYECPC5 NSYECPC6 NSYECPC9 NSYECPC15

Quick cable entries for enclosure thickness 10/10e - 40/10e mm (5/10e - 20/10e mm for ref. IMT36179).

IMT36179 IMT36180 IMT36181 IMT36182 IMT36183 IMT36184 IMT36185

PVC adjustable cone-shaped entries for PG tubes or for enclosure thickness 12/10e - 15/10e mm.

NSYEC7 ISM71501

Cable

Multiple Cable Entries

Characteristics Flexicable Multi-A Multi-C Multi-R Multi-CS Multi-T Prisma Multi-F Multi-CF Multi-CR Multi-H Characteristics

Description Full membrane

management

Material HCE for membrane

Color Ingress protection rating IP55 IP65 IP65 IP65 IP65 IP66 IP55 IP65 IP65 IP54 IP65 Ingress protection rating Cable retention Low

Cable diameter (mm) Up to 26 From 13 to 30 From 3 to 15.9 From 4.3 to 15.9

External dimensions (mm) 245 x 130 to 545 x 130

References NSYTLCME

New

cable gland plate for wall-mounted enclosures S3D.

- Steel for frame

- RAL 7035 - - Black RAL 7035 RAL 9001 RAL 7035 Black - RAL 7035 Color

or 495 x 220

NSYTLDME NSYTLEME NSYTLFME NSYTLGME

FL13 & FL21 type membranes.

TPE, SBS, SEBS and PP co-polymer Halogen-free

High with cable clamp, (up to 18 daN)

216 x 84 Ø 58

FL13

NSYAECPFLA7 NSYAECPFLA10

FL21 FL21 FL21

NSYAECPFLA25 NSYAECPFLA33

Circular connector-free entries.

Polyamide Polyamide Reinforced

Medium Medium Medium Low Low Low Medium High

Ø 71

NSYTSAM504SE NSYTSAM508SE NSYTSAM638SE NSYTSAM6313SE

Rectangular connector-free entries.

146 x 14 x 58 148 x 58 x 15

NSYTSA2414SE NSYTSA2417SE NSYTSA2422SE NSYTSA2423SE NSYTSA2429SE

Modular entry with room for of up to 48 pre-assembled cables.

polypropylene and TPE. Halogen-free

Up to 22

148 x 58 x 18

NSYDCD2412 NSYDCD244 NSYDCD248 NSYDCD249

FL21-type membranes. FL21-type membranes or

TPE Insulating material Fibreglass-reinforced

From 5 to 60 From 28 to 60 (FL21)

214 x 88 216 x 84 134 x 52

NSYAECPFLBP (2) NSYAECPFLT7 NSYAECPFLT25 NSYAECPFLT35

(2) Metallic plate.

For details, type the reference in the search engine at se.com/enclosures.

NewNew New

Synthetic snap-in

ISO cable gland. Threadless.

ISM71502 ISM71503 ISM71504 ISM71505 ISM71506 IMT36150 (1)

Easy assembly and disassembly. Suitable for walls from 0.5 to 4 mm thick.

Other colors on demand

NSYCGSP16 NSYCGSP20 NSYCGSP25 NSYCGSP32 NSYCGSP40

cable gland

Stainless steel cable gland

with lamellar insert

Lamellar technology provides excellent resistance to traction as well as excellent torsional protection. For outdoor use, or for aggressive environments.

steel, neoprene gasket

- - Color

AISI 304L AISI 316L NSYCGHF12

NSYCGX12 NSYCGX16 NSYCGX20 NSYCGX25 NSYCGX32 NSYCGX40

NSYCGX12H NSYCGX16H NSYCGX20H NSYCGX25H NSYCGX32H NSYCGX40H

EMC cable gland Characteristics

EMC cable gland with contact spring.

Thread type:

b Metric EN 60423 b Other types are available on

request Nickel-plated brass, neoprene

gasket

NSYCGHF16 NSYCGHF20 NSYCGHF25 NSYCGHF32 NSYCGHF40

Description

Material

References

New

rectangular.

From 7 to 72 (rectangular)

FL13 FL13 NSYTLK2414

08898 08899

08881 08892 08895 08897

FL13 & FL21 pre-conﬁgured ﬂanges.

polypropylene and TPE Halogen-free

From 16 to 50 From 9 to 30 From 3 to 31 From 12 to 25 Cable diameter (mm)

214 x 90

NSYAECPKFL11

NSYAECPKFL7A NSYAECPKFL10

Cable entry for protected cables.

Reinforced polypropylene and TPE. Halogen-free

148 x 60 x 10 146 x 58 215 x 85 Exter nal dimensions (mm)

NSYTLK2422 NSYTLK2428 NSYTLK2446 NSYTLK24M

Cable entries with gasket for cables equipped with connectors.

Polyamide Polycarbonate glass-ﬁber

(with fastener)

NSYDCE168 NSYDCE244 NSYDCE2410

FL21 insulated ﬂange with ISO knockouts.

reinforced

High (with cable clamp)

NSYTSAKFL References

Description

Material

Cable retention

Transversal accessories

Lighting and power sockets

Multi-fixing LED lamps

Description Power

With socket 10 W 640 lm 230 V AC Schuko With socket 10 W 640 lm 230 V AC UTE With socket 10 W 640 lm 230 V AC British With socket 10 W 640 lm 120 V AC USA

Without socket 10 W 640 lm 230 V AC -

Without socket and with presence detection 10 W 640 lm 230 V AC -

Without socket 10 W 640 lm 48 V DC -

Cost-effective LED lamps

Power Voltage Frequency

5 W

10 W

5 W

120-230 V AC 120-230 V AC

24-48V DC

50-60 Hz 500 lm 50-60 Hz 1100 lm

Luminous

flux

- 470 lm

311 x 30.5 x 22 12.20 x 1.20 x 0.88 560 x 30.5 x 22 22.05 x 1.20 x 0.88 310 x 30.5 x 22 12.20 x 1.20 x 0.87

Luminous

flux

Dimensions

(mm) (in)

Voltage Socket References

References

NSYLAMT5LD1 NSYLAMT5LD2 NSYLAMT5LD1VDC

NSYLAMLDS IEC NSYLAM3M NSYLAM1M NSYLAMLDF IEC NSYLAM3M NSYLAM1M NSYLAMLDB IEC NSYLAM3M NSYLAM1M NSYLAMLDU UL NSYLAM3MUL NSYLAM1MUL

NSYLAMLD

NSYLAMLDD

NSYLAMLDVDC

Standard Power (3 m) Interconnection (1.5 m)

IEC NSYLAM3M NSYLAM1M UL IEC NSYLAM3M NSYLAM1M UL IEC NSYLAM3MDC - UL

Description Power

With switch 10 W 1100 lm

NSYLAM3MUL NSYLAM1MUL

NSYLAM3MDCUL -

Portable LED lamp

Cables

Luminous

flux

Voltage Reference

230 V AC

NSYLAMPORTLD

Door accessories Spacial Floor-standing

Metal document pocket

Enclo sure dimensions (mm)

600 NSYSDP6M 800 NSYSDP8M

Door stop model For enclosures Limit References

Mechanical

Pneumatic

* Compatible with SF.

References

Door retainer

Spacial SF 90º and 160º NSYSFMDR Spacial SM 90º NSYSMDR Spacial SF 120° NSYSFNDR Spacial SM 90º and 160º NSYSMNDR*

Spaci al dimensions (mm)

Folding support tray

500 NSYSDT5 600 NSYSDT6 800 NSYSDT8

References

Door cross rails

Nomin al dimensions (mm)

400 500 600 800 1000

Door switch for floor-standing enclosures

For ranges References

SF - SFX NSYDCM20 SM NSYMDCM20 PLA NSYSNLPLA

References

NSYSDCR4

NSYSDCR5

NSYSDCR6 NSYSDCR8 NSYSDCR10

Transversal

accesories

Spacial Wall-mounting

Steel door retainer

Description Reference

Steel door retainer for Spacial wall-mounting steel enclosure

NSYAEDRSCST

Polyamide door retainer

Description Reference

Door retainer for Spacial wall-mounting steel enclosure

NSYAEDRS3DPA6

Door switch for

wall-mounting enclosures

For ranges Reference

S3D, S3X NSYINLCRN

Plastic document pocket

Document format References

A5 NSYDPA5 A4 NSYDPA4 A4 NSYDPA44 A3 NSYDPA3

(1) Not compatible with 19" chassis or modular enclosure.

(1)

Earthing accessories

110

Earth braids

Length (mm) Width (mm) Section (mm2) Terminal Ø (mm) References

150 12 6 7 NSYEB156D6 150 17 10 7 NSYEB1510D6 155 17 16 8.5 NSYEB1516D8 200 27 25 8.5 NSYEB2025D8 200 33 50 8.5 NSYEB2050D8

Fixing lugs for

Earthing strip

Reference

NSYECB1M153

Central earthing point

Reference

NSYCEP

the earthing strip

Reference

NSYEDCOS

Floor accessories

Earth cables

Length

Section

(mm2)

Terminal Ø

(mm)

130 6 6.4 NSYEL136D6 160 6 6.4 NSYEL166D6 160 6 8.3 NSYEL166D8 170 10 8.3 NSYEL1710D6 220 6 6.4 NSYEL226D6 220 25 8.3 NSYEL2225D8 250 10 6.4 NSYEL2510D6 350 25 8.3 NSYEL3525D8

References

Transport casters

Reference

NSYSTW*

* Only for Spacial SM, SF and SD.

Enclosure casters

Reference

NSYSW

 80

Fixed feet Adjustable feet

Levelling feet (fixed and adjustable)

Model References

Fixed feet NSYSPSJ

Adjustable feet NSYSPRJ

Hygienic 316L stainless steel feet

Model with height (mm) References

200 NSYPHX200

Enclosure spare parts

Schneider Electric has selected a wide variety of spare parts for your enclosure. Whether your enclosure has been built recently or is several years old, the replacement parts you need are available. Any time there is a mistake in a cut-out, a lost component, a logistics issue or an old product you have to repair, we make it easier for you to fix by providing the right solution.

Cable gland plate Plain doors Transparent door Door accessories Earthing

SBM Bag of accessories

S3D S3D S3DM S3DM S3DC S3DC S3DB S3DB SF Gaskets for

SM SM S3X S3X SMX SMX SFX SFX PLA PLA PLM PLM

SD SD

SDX SDX S3CM S3CM S3HF S3HF S3DEX S3DEX PHD PHD S3HD S3HD SFHD SFHD

References NSYCE●●● NSYD●●●

NSYS●D●●●

NSYD●●●T NSYS●D●●●T

NSYAED●●● NSYDH●●● NSYH●●●

accessories

NSYSWMEL NSYAS●●●

Fixing hardware Locking

NSYCS●●● NSY●●●CG●●●

Spare

Consult the Universal Enclosures general catalogue.

parts

accessories

Panels Installation

acc.

plinth accessories

Roof Roof

accessories

Miscellaneous

SBM

(screws)

NSYAEDL●●● NSYBTA●●● NSYV●●● NSYLCK●●● NSYLS●●●

NSYPA●●● NSYBP●●● NSYSWM●●●

NSYSQCR●●● NSYPC●●●

NSYZZ●●●

NSYRS●●● NSYTJ●●● NSYSC●●●

framework uprights

NSYTRIM●●● - References

A complete offer, easy to request and install:

● Complete and consistent offer of spare parts

● Each fragile component can be ordered

● In most cases, parts can be replaced quickly without changing

the enclosure

● Clear delivery time

● Defined price

● International availability

Check with your local contact.

Web Product Selectors

Online tool

What it does: allows technical data to be

viewed and downloaded and components to added to a cart.

How to get it:

www.se.com

> Products > Industrial automation and control > Enclosures and accessories > Select a range

Available for Universal Enclosures

ranges: Spacial, Thalassa, ClimaSys

Software and tools

Software

and tools

Enclosures selector: Digital Rules

Offline software

What it does: The fast enclosure components

selector. Digital Rules is a software assistant which helps you to define the enclosure range, compatible accessories and thermal management solutions in a matter of minutes!

How to get it: type "digital rules" in the

www.se.com search box.

Available for Universal Enclosures

ranges: Spacial, Thalassa, ClimaSys

Thermal calculation: ProClima & EffiClima

Online tool

ProClima

What it does: Online thermal calculation software. It calculates

and selects the thermal accessories required for enclosures containing electrical and electronic equipment. It helps prevent breakdown issues due to overheating of devices in control panels. It can be displayed on any PC, mobile or tablet, and is now available in any language. Free access with login.

How to get it: type proclima.se.com in your internet browser.

Available for all Universal Enclosures ranges.

Offline software

EffiClima

What it does: Creates a complete and accurate tracking report

of thermal conditions – temperature, humidity, dew point – for your machine or process and environment.

A complete diagnosis in 3 steps: 1• ClimaSys DT dataloggers measure and track thermal data. 2• EffiClima software translates data into a report on temperature,

humidity, and dew point

3• ProClima software proposes the right thermal management

solution based on the data variables.

For more information, contact your Universal Enclosures sales specialist.

Customized services configurator: Spacial.conf

Your order in 5 steps with Spacial.conf:

1 - Select country and language

• 12 countries deployed

• 5 languages available: English, French, Spanish, German, Russian.

• Global international version available.

2 - Select enclosure

• Select product range

• Select material

• Select enclosure type

3 - Select accessories

• Composition accessories

• Mounting accessories

• Thermal accessories

4 - Select services

• Mounting

• Machining

• Painting

• Assembly

5 - Validate and send offer

• Order summary

• Send order to get quotation confirmation from local sales representative

Scan this with your smartphone or tablet

Customized solutions

Configured and Specific customized solutions are developed on the basis of existing ranges from the Universal Enclosures standard offer. Depending on the modifications made to enclosures and/or accessories, the certifications/declarations of conformity applicable to the standard ranges could be affected. Additional certifications and declarations of conformity for customized solutions, must be defined in a prior request as part of the specification stage for the offering.

Configurated To Order (CTO) offer

Main characteristics

Solution made of standard references with the following possible services: colors, machining and assembly of several accessories.

Machining

• Cut-outs made before painting to help ensure optimum corrosion resistance

• Almost any shape of cut-out is possible on the enclosure body, door, gland plate or mounting plate

• Enclosure delivered ready to install

Mounting of standard accessories

• Factory mounting of most of the accessories, such as mounting plates, plinth, canopy, etc.

Enclosure ready to be equipped

Assemble to order

• Change the configuration composition (panels, doors…)

• Merge and assemble several enclosures (applicable to Spacial SF and Thalassa PLA)

Enclosure composition 100%

according to customer needs

Easy process to assemble cubicles

and link them

Spacial.conf configurator

Configure your enclosure specifically to your needs in few minutes with Spacial.conf https://custom-enclosures.se.com/

Painting

• Enclosure paint color selection (choice of 12 RAL colors)

• Choice of different coatings to be adapted to requirements (e.g.: zinc) Epoxy powder polyester painting helps ensure the best protection Totally customized

ADDITIONAL COLORS

3000 7032 6019

7037 6034 7040

7011 9001 7016

9002 7022 9005

Non-contractual colors

Customized

solutions

Engineered to order (ETO) offer

Examples of Specic solution

•Cable entry and door adaptation

• Special door shape

The engineered to order offer allows you to have a tailor-made product

ETO main characteristics

Solutions with:

• Cut-outs, special colors, specific dimensions, welding, special adaptation...

• Packaging and delivery can also be adapted to the project,

• Technical and quantitative limitations and lead times are defined case by case by the P&S quotation team, based on complexity.

• Co-engineer your solution with our design and engineering team (20 experts entirely dedicated to your specific needs).

Time Saving

Delivered with cut-outs & painting: no waste of time

Life Time Increased

Cut-outs made before

•

painting, helps guarantee anti-corrosion performance and safe sealing

Painting service for

•

better protection

Improved quality

Cut-outs before painting

Easier handling

Hoisting

Increased useful life of the equipment

Thermal Management

Logistics

Flexible management

•

of your logistic option

(scheduled delivery service for ongoing orders)

Special packaging

•

Quality Improved

No burrs on edges of

•

cut-outs

Guaranteed machining

•

tolerances

Installation Simplied

Enclosures delivered with cut-outs: no special tools required

Aesthetics

Large choice of colors

•

No scratches in

•

external surfaces

Ergonomic Design

Customized project dedicated to your specific requirements

Time-saving

Factory assembled

E󰀩ciency

Accessories mounted in our factory

Aesthetics

Colors

Safety

Dedicated packaging

E󰀩ciency and ergonomics

Surface finish

Need support for your project?

Our Commercial and Industrial infrastructure dedicated to Universal Enclosures includes:

• 3 Factories: 1 in France, 2 in Spain

• 2 R&D centers

• Sales & Marketing specialist around the world

Contact your Schneider sales representative

Schneider Electric Universal Enclosures Quick Start Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
