* Counter cutout for power, drinking water and wast wa ter / Differences between the offered machine and the picture and the configuration are possible.
Basic configuration
Schaerer Coffee Art Pl u s
Model SCA P C/T/S -1M (Coffee, Tea, Powersteam)
Schaerer Ltd.
www.schaerer.com
June 2011
Spouts: coffee / hot water / steam (powersteam) 1 / 1 / 1
Boiler: coffee (3kW) / hot water (3kW) / steam (3kW) 1 / 1 / 1
Grinders / Inlet for ground coffee 1 / 1
Programmable beverage selection up to 36 different beverages
Connections
Voltage Power Fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
5700-6900 W 30 A
3L, N, PE: 380-415 V 3N~ 50/60 Hz 5700-6900 W 3x 16 A
8300-10100 W 3x 16 A
2L, PE: 200-220 V 2~ 50/60 Hz 4700-5900 W 2x 30 A
4700-5900 W 2x 25 A
3L, PE: 200 V 3~ 50/60 Hz 7000 W 3x 20 A
3L, PE: 220 V 3~ 50/60 Hz 6900-8500 W 3x 25 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 40 kg
Output per hour (approximate)
Espresso (cup of 50 – 60 ml) 250 (175 CCC)*
Coffee (cup of 120 ml) 200 (150 CCC)*
Cappuccino (cup of 180 ml) 180 (CCC 150)*
Latte Macchiato (cup of 200 ml) 160 (CCC 140)*
Hot milk with Milk Smart / cold milk with Cold mil k sys tem 160 / 150
Hot water (litre) 20
* Top quality according Schaerer Coffee Competence Centre
Options
Autosteam, Supersteam, Finesteam
Lockable bean containers
Different milk systems usable
External water- and dirty water tank
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Cup warmer
Touchscreen
Dimensions
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
Colours
Illustrations may not reflect actual colour
Costa Rica, silver
Kenya, black
SWISS MADE
* Counter cutout for power, drinking water and wast wa ter / Differences between the offered machine and the picture and the configuration are possible.
Schaerer Coffee Art Pl u s
Model SCA P C/T -1M (Coffee, Tea)
Schaerer Ltd.
www.schaerer.com
June 2011
Basic configuration
Spouts: coffee / hot water 1 / 1
Boiler: coffee (3kW) / hot water (3kW) 1 / 1
Grinders / Inlet for ground coffee 1 / 1
Programmable beverage selection up to 36 different beverages
Connections
Voltage Power Fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
5700-6900 W 30 A
3L, N, PE: 380-415 V 3N~ 50/60 Hz 5700-6900 W 3x 16 A
2L, PE: 200-220 V 2~ 50/60 Hz 4700-5900 W 2x 30 A
4700-5900 W 2x 25 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 40 kg
Output per hour (approximate)
Espresso (cup of 50 – 60 ml) 250 (175 CCC)**
Coffee (cup of 120 ml) 200 (150 CCC)**
Hot water (litre) 20
Options
Lockable bean containers
External water- and dirty water tank
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Cup warmer
Touchscreen
Dimensions
** Top quality according Schaerer Coffee Competence Centre
Colours
Illustrations may not reflect actual colour
Costa Rica, silver
Kenya, black
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
SWISS MADE
* Counter cutout for power, drinking water and wast wa ter / Differences between the offered machine and the picture and the configuration are possible.
Schaerer Coffee Art Pl u s
Model SCA P C/T -2M (Coffee, hot water)
Schaerer Ltd.
www.schaerer.com
June 2011
Basic configuration
Spouts: coffee / hot water 1 / 1
Boiler: coffee (3kW) / hot water (3kW) 1 / 1
Grinders / Inlet for ground coffee 2 / 1
Programmable beverage selection up to 36 different beverages
Connections
Voltage Power Fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
5700-6900 W 30 A
3L, N, PE: 380-415 V 3N~ 50/60 Hz 5700-6900 W 3x 16 A
2L, PE: 200-220 V 2~ 50/60 Hz 4700-5900 W 2x 30 A
4700-5900 W 2x 25 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 40 kg
Output per hour (approximate)
Espresso (cup of 50 – 60 ml) 250 (175 CCC)**
Coffee (cup of 120 ml) 200 (150 CCC)**
Hot water (litre) 20
Options
Lockable bean containers
External water- and dirty water tank
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Cup warmer
Touchscreen
Dimensions
** Top quality according Schaerer Coffee Competence Centre
Colours
Illustrations may not reflect actual colour
Costa Rica, silver
Kenya, black
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
SWISS MADE
