Schaerer Coffee Art
Model SCA 1 CT1-1M (coffee, hot water)
Schaerer Ltd.
May 2011
Basic configuration
Spouts: coffee / hot water 1 / 1
Boiler: coffee and hot water (2 kW or 3 kW) 1
Grinders / Inlet for ground coffee 1 / 1
Programmable beverage selection up to 16 different beverage
Connections
Voltage power fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
Water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 38 kg
Output per hour (approximate)
Espresso (cup of 50 – 60ml) 180 (CCC 175)**
Coffee (cup of 120ml) 150 (CCC 130)**
Hot water (litre) 12
Options
Lockable bean containers
Brewing accelerator
Additional steam spout for milk system
External water- and dirty water tank
Waste water monitor
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Cup warmer
Dimensions
** Top quality according Schaerer Coffee Competence Centre
Colours
Illustrations may not reflect actual colour
Costa Rica, silver
Costa Rica, black
* Counter cutout for power, drin k i ng water and was t wa ter / Differences between the offered machine and the picture and configuration are possible.
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
SWISS MADE
SWISS MADE
Schaerer Coffee Art
Model SCA 1 CT1-2M (coffee, hot water)
Schaerer Ltd.
May 2011
Basic configuration
Spouts: coffee / hot water 1 / 1
Boiler: coffee and hot water (2 kW or 3 kW) 1
Grinders / Inlet for ground coffee 2 / 1
Programmable beverage selection up to 16 different beverage
Connections
Voltage power fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
Water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 38 kg
Output per hour (approximate)
Espresso (cup of 50 – 60 ml) 180 (CCC 175)**
Coffee (cup of 120 ml) 150 (CCC 130)**
Hot water (litre) 12
Options
Lockable bean containers
Brewing accelerator
Additional steam spout for milk system
External water- and dirty water tank
Waste water monitor
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Cup warmer
Dimensions
** Top quality according Schaerer Coffee Competence Centre
Colours
Illustrations may not reflect actual colour
* Counter cutout for power, dri nking water and wast water / Differences between the offered machine and the picture and configuration are possible.
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
Costa Rica, silver
Costa Rica, black
Output per hour (approximate)
Schaerer Coffee Art
Model SCA 1 CT1/S-1M/S (coffee, hot water, steam)
Schaerer Ltd.
May 2011
Basic configuration
Spouts: coffee / hot water / steam 1 / 1 / 1
Boiler: coffee and hot water (2 kW or 3 kW) / steam (2 kW or 3 kW) 1 / 1
Grinders / Inlet for ground coffee 1 / 1
Programmable beverage selection up to 16 different beverage
Connections
Voltage power fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
2L, PE: 200-220V 2~ 50/60 Hz 2000-2200 W 2x 15 A
2600-3200 W 2x 15 A
4700-5800 W 30 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
Water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 38 kg
Espresso (cup of 50 – 60 ml) 180 (CCC 175)**
Coffee (cup of 120 ml) 150 (CCC 130)**
Cappuccino (cup of 180 ml) 130 (CCC 120)**
Hot water (litre) 12
** Top quality according Schaerer Coffee Competence Centre
Options
Lockable bean containers
Brewing accelerator
Additional steam spout for milk system
External water- and dirty water tank
Waste water monitor
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Cup warmer
Dimensions
Colours
Illustrations may not reflect actual colour
Costa Rica, silver
Costa Rica, black
* Counter cutout for power, drinking wate r and wast water / Differences between the offered machine and the picture and configuration are possible.
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
SWISS MADE
Output per hour (approximate)
Schaerer Coffee Art
Model SCA 1 CT1/S-2M/S (coffee, hot water, steam)
Schaerer Ltd.
May 2011
Basic configuration
Spouts: coffee / hot water / steam 1 / 1 / 1
Boiler: coffee and hot water (2 kW or 3 kW) / steam (2 kW or 3 kW) 1 / 1
Grinders / Inlet for ground coffee 2 / 1
Programmable beverage selection up to 16 different beverage
Connections
Voltage power fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
2L, PE: 200-220V 2~ 50/60 Hz 2000-2200 W 2x 15 A
2600-3200 W 2x 15 A
4700-5800 W 30 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
Water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 38 kg
Espresso (cup of 50 – 60 ml) 180 (CCC 175)**
Coffee (cup of 120 ml) 150 (CCC 130)**
Cappuccino (cup of 180 ml) 130 (CCC 120)**
Hot water (litre) 12
** Top quality according Schaerer Coffee Competence Centre
Options
Lockable bean containers
Brewing accelerator
Additional steam spout for milk system
External water- and dirty water tank
Waste water monitor
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Cup warmer
Dimensions
Colours
Illustrations may not reflect actual colour
Costa Rica, silver
Costa Rica, black
* Counter cutout for power, drinking water and was t water / Differences between the offered machine and the picture and configuration are possible.
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
SWISS MADE
Output per hour (approximate)
Dimensions
Colours
Schaerer Coffee Art
Model SCA 1 CT1/S-1M/L (coffee, hot water, milk)
Schaerer Ltd.
May 2011
Basic configuration
Spouts: coffee / hot water 1 / 1
Boiler: coffee and hot water (2 kW or 3 kW) / steam (2 kW or 3 kW) 1 / 1
Grinders / Inlet for ground coffee 1 / 1
Programmable beverage selection up to 16 different beverage
Connections
Voltage power fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
2L, PE: 200-220V 2~ 50/60 Hz 2000-2200 W 2x 15 A
2600-3200 W 2x 15 A
4700-5800 W 30 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
Water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 38 kg
Espresso (cup of 50 – 60 ml) 180 (CCC 175)**
Coffee (cup of 120 ml) 150 (CCC 130)**
Cappuccino (cup of 180 ml) 130 (CCC 120)**
Latte Macchiato (cup of 200 ml) 120 (CCC 120)**
Hot water (litre) 12
Hot milk 130
** Top quality according Schaerer Coffee Competence Centre
Options
Lockable bean containers Cup warmer
Brewing accelerator Cup & Cool
Additional steam spout for milk system Additional cooling unit
External water- and dirty water tank
Waste water monitor
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Illustrations may not reflect actual colour
Costa Rica, silver
Costa Rica, black
* Counter cutout for power, dri nking water and wast water / Differences between the offered machine and the picture and configuration are possible.
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
SWISS MADE
Output per hour (approximate)
Dimensions
Colours
Schaerer Coffee Art
Model SCA 1 CT1/S-2M/L (coffee, hot water, milk)
Schaerer Ltd.
May 2011
Basic configuration
Spouts: coffee / hot water 1 / 1
Boiler: coffee and hot water (2 kW or 3 kW) / steam (2 kW or 3 kW) 1 / 1
Grinders / Inlet for ground coffee 2 / 1
Programmable beverage selection up to 16 different beverage
Connections
Voltage power fuse protection
1L, N, PE: 220-240 V~ 50/60 Hz 2000-2400 W 10 A
3000-3600 W 16 A
2L, PE: 200-220V 2~ 50/60 Hz 2000-2200 W 2x 15 A
2600-3200 W 2x 15 A
4700-5800 W 30 A
Water connection G 3/8 “ max 0.6 MPa (6 bar)
Water outlet Ø 36 mm
Water hardness 4°-6° dKH / 8°-10° fKH
Dimensions
Width / depth / height 420 / 538 / 642 mm
Weight about 38 kg
Espresso (cup of 50 – 60 ml) 180 (CCC 175)**
Coffee (cup of 120 ml) 150 (CCC 130)**
Cappuccino (cup of 180 ml) 130 (CCC 120)**
Latte Macchiato (cup of 200 ml) 120 (CCC 120)**
Hot water (litre) 12
Hot milk 130
** Top quality according Schaerer Coffee Competence Centre
Options
Lockable bean containers Cup warmer
Brewing accelerator Cup & Cool
Additional steam spout for milk system Additional cooling unit
External water- and dirty water tank
Waste water monitor
Chute for under-counter grounds disposal
Connection to all commercial invoicing systems
Illustrations may not reflect actual colour
Costa Rica, silver
Costa Rica, black
* Counter cutout for power, drinking water and wast water / Differences between the offered machine and the picture and configuration are possible.
.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
SWISS MADE
Schaerer Coffee Art / Vito
Model Cup & Cool
May 2011
Basic configuration
Combined refrigerator unit and cup warmer
Removable milk tank with approx. 4-litre capacity
3 heatable shelves made of uncoated stainless steel
2 separate on/off switches for cup warmer and accessory refrigerator unit
Suitable for self-service
Connections
Voltage Power Fuse protection
1L, N, PE: 220-240V~ 50/60Hz 180 W 10-16 A
2L, PE: 200-220V 2~ 50/60Hz 180 W 15 A
Dimensions
Width / depth / height 277 / 385 / 524 mm
Weight 26.5 kg
Capacity about 60 cups* / 4 litre
Dimensions
* depending on the size of the cups
Schaerer AG
Postfach
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
Differences between the offered machine and the picture and the configuration are possible.
.
Schaerer Ltd.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
SWISS MADE
Schaerer Coffee Art Plus
Model Powder doser
May 2011
Basic configuration
Choco 1 x 1.0 kg Chocolate powder (1 type)
Topping 1 x 1.0 kg Milk powder (1 type)
Twin Choco 2 x 0.5 kg Chocolate powder (2 types)
Twin Topping 2 x 0.5 kg Milk powder (2 types)
Choco / Topping 2 x 0.5 kg Chocolate- and Milk powder
Connections
This device must always be connected to the adjacent coffee machine
Dimensions
Width / depth / height 140 / 451 / 715 mm
Weight 25 kg
Dimensions
Schaerer AG
Postfach
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
Differences between the offered machine and the picture and the configuration are possible.
.
Schaerer Ltd.
B.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
SWISS MADE
Schaerer Coffee Art / Vito
Model "W" Cup warmer
May 2011
Basic configuration
4 heatable shelves made of perforated, uncoated stainless steel
Freely-adjustable thermostat
On/off switch
Suitable for self-service
Connections
Voltage power fuse protection
1L, N, PE: 220-240V~ 50/60Hz 190-230 W 10-16 A
Dimensions
Width / depth / height 277 / 385 / 524 mm
Weight 18.8 kg
Capacity about 70 - 100 cups*
Dimensions
* depending on the size of the cups
Schaerer AG
Postfach
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
Differences between the offered machine and the picture and the configuration are possible.
.
Schaerer Ltd.
P.O. Box
Allmendweg 8
CH-4528 Zuchwil
T +41 (0)32 681 62 00
F +41 (0)32 681 62 42
info@schaerer.com
www.schaerer.com
SWISS MADE
Loading...
