6. Exploded View and Parts List
6-1 Cabinet Assembly - - - - - - - - - - - - - - - - - - - - - - -
6-2 Mechanical Parts (Top Side) - - - - - - - - - - - - - - - -
6-3 Mechanical Parts (Bottom Side) - - - - - - - - - - - - -
6-4 Housing Assembly - - - - - - - - - - - - - - - - - - - - - - -
Page
6-2
6-4
6-6
6-8
Exploded View and Parts List
6-2 Samsung Electronics
6-1 Cabinet Assembly
153
157
S.N.A
155
155
155
108
661
601(S.N.A)
LD601A
PT601A
PT602A
S601A
S602A
SC301
663
670(S.N.A)
157
109
S.N.A : SERVICE NOT AVAILABLE
1
22
21
-
DO NOT ORDER
ASSY-DECK (DX7-R) (S.N.A)
1 AC98-11213S ASSY-PANEL FRONT;SV-A12G/SGE,M/GRAY TSEC LOCAL
21 AC64-50076E DOOR-CASSETTE;-,ABS,94HB,-,-,-,-,SV-A12G/SGE TSEC LOCAL
22 AC61-62003A SPRING;-,SUS304,(GE/RCA),-,-,-,- TSEC LOCAL
108 AC61-12265A CONNECTOR-BOARD(ASSY;HIPS94,HB,-,-,-,-,-,-,SV-11 TSEC LOCAL
109 AC63-30078A COVER-BOTTOM;SECC,-,T0.5,NTR,-,-,SV-160X,- TSEC LOCAL
153 AC60-12126A SCREW-BH;-,BH,-,4*12,FE,FZY,-,-,-
155 AC60-12134A SCREW-TAP BH;-,BH,-,2-4X16,-,FE
157 AC60-10063A SCREW-TAPTITE;BH,+,-,M3,L12,ZPC3,SWRCH18A
158 AC60-10063A SCREW-TAPTITE;BH,+,-,M3,L12,ZPC3,SWRCH18A
601
DO NOT ORDER
ASSY-MAIN (S.N.A)
661 AC39-10019A POWER CORD;KKP-419C,H03VVH2-F,VDE/KEMA-KE TSEC LOCAL
663 3711-002602 CONNECTOR-HEADER;NOWALL,40P,1R,1.5MM,STRAIGHT,SN
670
DO NOT ORDER
ASSY-FUNCTION (S.N.A)
LD601A AC61-22345A HOLDER-LED;POM,-,-,-,-,- TSEC LOCAL
PT601A AC61-22344A HOLDER-PHOTO;POM,-,-,-,-,- TSEC LOCAL
PT602A AC61-22344A HOLDER-PHOTO;POM,-,-,-,-,- TSEC LOCAL
S601A AC61-22321A HOLDER-TR;POM,-,-,-,-,-
S602A AC61-22321A HOLDER-TR;POM,-,-,-,-,-
SC301 AC63-42222A SHIELD-CASE P/AMP(AS;3516ET,T0.3,SIL,SV-80Z,- TSEC LOCAL
Exploded View and Parts List
Samsung Electronics 6-3
Loc. No Part No Description and Specification Remark
Note : Location number 1, 21 are only for model SV-A12G/SGE.
Please, refer to the separate information for the other models combind.
Exploded View and Parts List
6-4 Samsung Electronics
6-2 Mechanical Parts (Top Side)
T220
T216
T201
T207
T300
901
920
T309
904
901
T203
T209
T240
900
T239
T210
956
956
956
T208
T202
T227
T233
957
T234
T228
T230
T229
T231
901
912
T233
T204
T238
T232
T225
T226
952
G
T236
T211
T223
T217
T219
952
T218
T212
T221
T237
G
G
O
G
905
919
T224
T303
T302
DX7-R
DX8-R
DX7-RC
DX8-RC
T222
900 AC60-12091A SCREW-MACHINE;FP,BH,-,M3,L4,SWRCH10A,YEL ROB
901 AC60-10012A SCREW-MACHINE;BH,+,M3,L8,-,FE,-,-,-
904 AC60-12125A SCREW-PH;-,-,-,M3X6 TAP TITE,-,-,-,-,905 AC60-12096A SCREW-MACHINE;FP,PH,-,M2.6,X10,SWRCH1-A,YEL
912 67094-604-710 SCREW-DAMPER;M2.0X7.0 SWCM10(MFZN2-C)
919 AC60-10004A SCREW-MACHINE;BH,+,M3,L8,ZPC,SWRCH18A,-,-,-
920 AC60-10007A SCREW-TAPPING;BH,+,M2.6,L12,-,SWRCH18A,-,-,-
952 AC60-30018A WASHER-PLAIN;PLAIN,M3.2,D6,T0.5,POLYSLIDER,
956 AC60-30007A WASHER-SLIT;PLAIN,ID2.5,OD7,T0.5,SPC1,-,-
957 AC60-30008A WASHER-SLIT;-,ID3.5,OD9,T0.5,SPC1,-,-
T201 AC66-10023A REEL-DISK L ASSY;POM,-,PACKAGE,X-5,- TSEC LOCAL
T202 AC66-10022A REEL-DISK R (ASSY);POM,-,PACKAGE,X-5,- TSEC LOCAL
T203 AC66-30474A BRAKE-SUB L;-,PBT,-,-,-,X-5/IS
T204 AC66-30148A BRAKE SUB R-ASSY;PBT,-,-,-,X5,-
T207 AC66-30475A BRAKE-MAIN L ASS’Y;-,POM+PELT,-,-,-,X-5/IS
T208 AC66-30476A BRAKE-MAIN R ASS’Y;-,POM+PELT,-,-,-,X-5/IS
T209 AC61-60112A SPRING- BRAKE MAIN;ES,SUS304WPB,PI0.35,ID2.8,OD4
T210 AC66-20073A GEAR RELAY S-ASSY;-,PEBAX,M0.5,M48,SP,X5,-
T211 AC66-20037A GEAR- RELAY T;PEBAX7033,X-5,Z39,GEAR-SPUR,D1
T212 AC66-30073A ARM-TENSION ASSY;-,-,-,CKD,DX5-R,-
T216 AC61-60119A SPRING TENSION;ES,SWPB,PI0.35,ID2.1,L33(OD3.8),T217 AC66-30470A LEVER-REC S/W;-,PBT #3300,T4.0,L32,-,(X-5/IS TSEC LOCAL
T218 AC61-62017A SPRING-SUB BRAKE L;ES,SUS304,PI0.23,D3.5,L14.8,T219 AC33-10003P HEAD- MAGNET F/E;MH131S,-,-,-,L51.05XW7.4XH12.3
T220 AC66-82050A SLIDER-G/R ASSY(S);-,-,-,-,X-5
T221 AC66-82059A SLIDER-G/R ASSY T;-,-,-,-,X-7(VW31H)
T222 AC33-10002E HEAD-CLEANER;-,-,-,-,-,X-5 (OPTIONAL) TSEC LOCAL
T223 AC66-20065A RACK-HOUSING;L74.29,POM M90-44,BLK,M1,3.14, TSEC LOCAL
T224 AC33-10215A HEAD-ACE ALL ASSY;-,X-7,-,-,-
T225 AC66-82045A SLIDER-PINCH;POM,T2,-,NAT PACKAGE,-
T226 AC66-30014A LEVER-REVIEW;ZYTEL(70G-43L),T3.8,-,PCD25.6, TSEC LOCAL
T227 AC66-30099A ARM REVIEW CKD;-,-,-,-,DX5-RV,-
T228 AC66-30013A LEVER-PINCH CAM;PBT 6300T,-,L45,W9,X-5,- TSEC LOCAL
T229 AC66-30003A LEVER PINCH COUP;PBT 3300,T7.5,L45.25,-,-,X-5 TSEC LOCAL
T230 AC61-60116A SPRING- PINCH COMP;TS,SWPB,PI1.0,D6,L38(OD8),-,- TSEC LOCAL
T231 AC67-32001A PRISM-LED;PMMA,D5,IF-850,-,-,-
T232 V1643-0025-00 SLIDER-PUSH;LUPOX 2150 T2 NTR LOCAL TSEC LOCAL
T233 AC61-62016A SPRING-SLIDE PUSH;ES,SUS304WPB,PI0.55,D3.55,L24.
T234 AC59-90001B UNIT-PINCH ROLLER;X-5,-,YAMAUCHI
T236 AC66-10010A IDLER-ASSY;PACKAGE,-,X-5,- TSEC LOCAL
T237 V3383-0031-00 STOPPER-TAPE;POM T2 NAT X-5 DECK LOCAL (OPTIONAL) TSEC LOCAL
T238 AC61-60132A SPRING ARM PINCH;CS,SUS304WPB,PI0.4,D7.1,OD7.9,
T239 AC66-30132A LEVER JOG-ASSY;-,-,-,-,X-5,- (OPTIONAL)
T240 AC61-60505A SPRING-REC S/W;-,ES,SUS304 WPB,PI0.29,PI3.5,-
T300 AC96-10011L ASSY-CYLINDER;CX5-S2P/DLC,- TSEC LOCAL
T302 AC31-12001M MOTOR-CYLINDER;E20XL03,-,- TSEC LOCAL
T303 AC33-12004S HEAD-BRUSH(ASSY);SECC20/20+CARBON,-,-,-,- TSEC LOCAL
T309 AC73-12001A RETRINER-RUBBER(ASSY);SECC+SILICON,-,-,- TSEC LOCAL
Exploded View and Parts List
Samsung Electronics 6-5
Loc. No Part No Description and Specification Remark
Exploded View and Parts List
6-6 Samsung Electronics
6-3 Mechanical Parts (Bottom Side)
B257
G
G
G
O
B256
B254
951
951
952
918
B258
B261
B255
B260
B267
B266
B265
956
902
922
B259
B262
B253
B263
B268
B251
958
B252
B264
902 AC60-10051A SCREW-TAPPING;BH,-,-,M3,L8,FZY
918 AC60-10006A SCREW-MACHINE;BH,+I90,M2.6,L7,ZPC,SWRCH18A,-
922 67008-130-171 SCREW PH;+M3X3 FE FZY
951 AC60-30025A WASHER-SLIT;-,ID2.5,OD5.0,T0.5,POLY SLIDE,
952 AC60-30018A WASHER-PLAIN;PLAIN,M3.2,D6,T0.5,POLYSLIDER,
956 AC60-30007A WASHER-SLIT;PLAIN,ID2.5,OD7,T0.5,SPC1,-,-
958 AC60-30028A WASHER-SLIT;-,D2.5,D9.0,T0.5,NUMIRROR,-,-
B251 AC66-82042A SLIDER-MAIN;PBT2002K,T12.4,-,NAT PACKAGE,-
B252 AC66-20019A GEAR-LOADING L ASSY;-,-,-,PACKAGE,-,X-5,- TSEC LOCAL
B253 V1473-0105-00 GEAR-LOADING R ASSY;X-5 LOCAL TSEC LOCAL
B254 AC61-60115A SPRING-BRAKE CAPSTAN;ES,SUS304WPB,PI0.4,D22,L16.
B255 AC66-20003A GEAR-MASTER;LUPOXE G5000H,M 1,Z 60,SP,PACK TSEC LOCAL
B256 AC31-12001L MOTOR-D.D CAPSTAN;F2QTB04,-,-
B257 AC66-62008A BELT-CAPSTAN;-,DLB-601,T2,8,L134.9,BLK,X-5
B258 AC66-20066A CLUTCH-ASSY;-,-,-,-,-,X5,- TSEC LOCAL
B259 V1533-0095-00 LEVER-SLIDER PINCH;PBT T4 NAT LOCAL TSEC LOCAL
B260 AC66-20016A GEAR- WORM WHEEL;POM SW-01,M0.55/M1,Z57/Z10,GEA TSEC LOCAL
B261 AC66-30011A LEVER- SHIFT;PBT2002K,T10.9,L35,-,-,- TSEC LOCAL
B262 AC66-30012A LEVER- IDELR CHANGE;PBT330,T3.3,L50,-,W6.0,- TSEC LOCAL
B263 AC61-60111A SPRING-LEVER SHIFT;TS,SWPB,PI0.7,D5.5,L13.8(OD6. TSEC LOCAL
B264 AC59-90001A UNIT-LOADING ASSY;X-5,-,- TSEC LOCAL
B265 66823-0060-00 MOTOR-LOADING ASSY;POM+RF370C X-5 TSEC LOCAL
B266 AC66-20039A GEAR- WORM LO;PBT 2002K,-,-,-,D4.5,3,- TSEC LOCAL
B267 AC61-20224A HOLDER SHAFT;POM M90-44,T1.25,NAT,PI5XH5.5, TSEC LOCAL
B268 AC66-30149A BRAKE CAPSTAN-ASSY;POM,-,-,-,X5,-
Exploded View and Parts List
Samsung Electronics 6-7
Loc. No Part No Description and Specification Remark
Exploded View and Parts List
6-8 Samsung Electronics
6-4 Housing Assembly
914
902
H510
H550
H500
H520
H522
H524
H526
902
H521
H533
H532
H531
H535
H530
H540
H545
H544
H541
H543
H542
914
914
902 AC60-10051A SCREW-TAPPING;BH,-,-,M3,L8,FZY
914 AC60-10067A SCREW-TAPTITE;PWH,+,-,M3,L8,MFZN2-C,SWCH1018
H500 AC61-82005A HOUSING-ASSY;X5FL2326A,-,X-5,-,- TSEC LOCAL
H510 AC61-10006A CHASSIS- UPPER;SECC 20/20,-,T1.0,BLK,-,X5,- TSEC LOCAL
H520 63322-0317-00 HOLDER-CASSETTE(ASSY);SECC X5FL0810A X-5 TSEC LOCAL
H521 AC61-20083A HOLDER-CASSETTE;SECC 20/20,T1.2,-,-,HRB50,- TSEC LOCAL
H522 AC66-30018A LEVER-LOCK R;SECC 20/20,T1.2,L44,W32,-,- TSEC LOCAL
H524 AC61-60121A SPRING-LEVER LOCK;ES,SUS304 WPB,PI0.2,D2.6,L9.9( TSEC LOCAL
H526 AC66-30019A LEVER-KEY CASSETTE;LUCEL N109-LD,T2.5,L20,W15.2, TSEC LOCAL
H530 62203-0105-00 CHASSIS-SIDE L(ASSY) TSEC LOCAL
H531 AC61-10004A CHASSIS- SIDE L;ABS HF-380,-,T10,BLK,-,X5,BLK TSEC LOCAL
H532 AC66-30004A LEVER- LIGHT SHUTTER;LUCEL N109-LD,T2.5,L61.7,BL TSEC LOCAL
H533 AC61-60142A SPRING- LIGHT;ES,SUS304WPB,PI0.2,L11.4(OD3.7 TSEC LOCAL
H535 AC66-30017A LEVER- DOOR;LUCELN109-LD,T5,L74.3,W21.1,-, TSEC LOCAL
H540 62203-0104-00 CHASSIS-SIDE R(ASSY) TSEC LOCAL
H541 AC61-10003A CHASSIS- SIDE R;ABS HF-380,-,T10,BLK,-,X5,BLK TSEC LOCAL
H542 AC66-80008A SLIDER DAMPER;LUCEL N109-LD,T4,L87,-,-,- TSEC LOCAL
H543 AC61-60120A SPRING-SLIDE DAMPER;ES,SUS 304WPB,PI0.4,D3.8,L25 TSEC LOCAL
H544 AC66-30016A LEVER- LID OPENER;LUCEL N109-LD,T5.0,L34.7,W16.6 TSEC LOCAL
H545 AC61-60123A SPRING-LID OPENER;TS,SWPB,PI0.55,D8.9,L15(OD10), TSEC LOCAL
H550 61403-0073-00 SHAFT-ARM(ASSY);SUM24L X5FL0405A X-5 TSEC LOCAL
Exploded View and Parts List
Samsung Electronics 6-9
Loc. No Part No Description and Specification Old Part No
Exploded View and Parts List
6-10 Samsung Electronics
