Page 1
Refrigerator
User manual
Free Standing Appliance
Untitled-4 1 2021-05-25 8:13:29
Page 2
Contents
Safety information
What you need to know about the safety instructions 3
Important safety symbols and precautions: 5
Important safety precautions 6
Severe warning signs for transportation and site 9
Contents
Critical installation warnings 10
Installation cautions 14
Critical usage warnings 14
Usage cautions 19
Cleaning cautions 22
Critical disposal warnings 24
Additional tips for proper usage 25
Instructions about the WEEE 27
Installation
Refrigerator at a glance 28
Step-by-step installation 31
Operations
Main panel 47
Setting the desired temperature or function 49
Changing the temperature scale 50
Turning on or off the ice maker 50
Activating or deactivating the Sabbath mode (applicable models only) 50
Special features 51
Maintenance
Handling and care 54
Cleaning 58
Replacement 59
3
28
47
54
Troubleshooting
General 60
Do you hear abnormal sounds from the refrigerator? 64
Appendix
Safety Instruction 66
Install Instruction 66
Temperature Instruction 67
Information for model and ordering spare parts 70
English2
Untitled-4 2 2021-05-25 8:13:29
60
66
Page 3
Safety information
Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure
that you know how to operate the features and functions that your new appliance offers
safely and efciently.
What you need to know about the safety instructions
• Warnings and Important Safety Instructions in this manual
do not cover all possible conditions and situations that
may occur.
It is your responsibility to use common sense, caution,
and care when installing, maintaining, and operating your
appliance.
• Because these following operating instructions cover
various models, the characteristics of your refrigerator
may differ slightly from those described in this manual and
not all warning signs may be applicable. If you have any
questions or concerns, contact your nearest service center
or nd help and information online at www.samsung.com.
• R-600a or R-134a is used as a refrigerant. Check the
compressor label on the rear of the appliance or the rating
label inside the fridge to see which refrigerant is used for
your appliance. When this product contains ammable gas
(Refrigerant R-600a), contact your local authority in regard
to safe disposal of this product.
• In order to avoid the creation of a ammable gas-air
mixture if a leak in the refrigerating circuit occurs, the size
of the room in which the appliance may be sited depends
on the amount of refrigerant used.
Safety information
English 3
Untitled-4 3 2021-05-25 8:13:29
Page 4
Safety information
Safety information
• Never start up an appliance showing any signs of damage.
If in doubt, consult your dealer. The room must be 1 m
in size for every 8 g of R-600a refrigerant inside the
appliance.
The amount of refrigerant in your particular appliance is
shown on the identication plate inside the appliance.
• Refrigerant squirting out of the pipes could ignite or cause
an eye injury. When refrigerant leaks from the pipe, avoid
any naked ames and move anything ammable away
from the product and ventilate the room immediately.
- Failing to do so may result in re or explosion.
• To avoid contamination of food, please respect the
following instructions:
- Opening the door for long periods can cause a
signicant increase of the temperature in the
compartments of the appliance.
- Clean regularly surfaces that can come in contact with
food and accessible drainage systems.
- Clean water tanks if they have not been used for 48 h;
ush the water system connected to a water supply if
water has not been drawn for 5 days.
- Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
- Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making icecream and
making ice cubes.
- One-, two- and three-star compartments are not suitable
for the freezing of fresh food.
3
English4
Untitled-4 4 2021-05-25 8:13:29
Page 5
- If the refrigerating appliance is left empty for long
periods, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.
Important safety symbols and precautions:
Please follow all safety instructions in this manual. This
manual uses the following safety symbols.
WARNING
Hazards or unsafe practices that may result in severe personal
injury, property damage, and/or death.
CAUTION
Hazards or unsafe practices that may result in severe personal
injury and/or property damage.
NOTE
Useful information that helps users understand or benet
from the refrigerator.
These warning signs are here to prevent injury to you and
others.
Please follow them carefully.
Safety information
After reading this section, keep it in a safe place for future
reference.
English 5
Untitled-4 5 2021-05-25 8:13:29
Page 6
Safety information
Important safety precautions
Warning; Risk of re / ammable materials
Safety information
WARNING
• When positioning the appliance, ensure the supply cord is
not trapped or damaged.
• Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
• Fill with potable water only.
• Connect to potable water supply only.
• Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
• Do not use mechanical devices or any other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory, or
mental capabilities, or those who lack experience and
knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person
responsible for their safety.
English6
Untitled-4 6 2021-05-25 8:13:30
Page 7
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision. Children
aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
• The socket must be easily accessible so that the appliance
can be quickly disconnected from the supply in an
emergency.
- It must be outside the area of the rear of the appliance.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
• If the product is equipped with LED lamps, do not
disassemble the Lamp Covers and LED lamps yourself.
- Contact a Samsung service center.
- Use only the LED Lamps provided by the manufacturer
or its service agents.
• New hose-sets supplied with the appliance are to be used
and old hose-sets should not be reused.
• Have the refrigerator’s water supply connected only to a
potable water supply. To operate the ice maker properly,
water pressure of 206-861 kPa (30-125 psi) is required.
Safety information
English 7
Untitled-4 7 2021-05-25 8:13:30
Page 8
Safety information
Safety information
• For the most efcient use of energy, please keep the all
inner ttings such as baskets, drawers, shelves on the
position supplied by manufacturer.
• To get the best energy efciency of this product, please
leave all shelves, drawers and baskets on their original
position.
How to minimize the energy consumption
• Install the appliance in a cool, dry room with adequate
ventilation.
• Ensure that it is not exposed to direct sunlight and never
put it near a direct source of heat (radiator, for example).
- Not to block any vents or grilles is recommended for
energy efciency.
- Allow warm food to cool down before placing it in the
appliance.
- Put frozen food in the refrigerator to thaw. You can
then use the low temperatures of the frozen products to
cool food in the refrigerator.
- Do not keep the door of the appliance open for too long
when putting food in or taking food out.
- The shorter time for which the door is open, the less ice
will form in the freezer.
- Clean the rear of the refrigerator regularly. Dust
increases energy consumption.
- Do not set temperature colder than necessary.
- Ensure sufcient air exhaust at the refrigerator base
and at the back wall of the refrigerator. Do not cover air
vent openings.
English8
Untitled-4 8 2021-05-25 8:13:30
Page 9
- Allow clearance to the right, left, back and top when
installing. This will help reduce power consumption and
keep your energy bills lower.
This appliance is intended to be used in household and similar
applications such as
- staff kitchen areas in shops, ofces and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Severe warning signs for transportation and site
WARNING
• When transporting and installing the appliance, care should
be taken to ensure that no parts of the refrigerating circuit
are damaged.
- Refrigerant leaking from the pipe work could ignite
or cause an eye injury. If a leak is detected, avoid any
naked ames or potential sources of ignition and air
the room in which the appliance is standing for several
minutes.
Safety information
English 9
Untitled-4 9 2021-05-25 8:13:30
Page 10
Safety information
Safety information
- This appliance contains a small amount of isobutane
refrigerant (R-600a), a natural gas with high
environmental compatibility that is, however, also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no parts
of the refrigerating circuit are damaged.
• When transporting and installing the refrigerator, do not
touch the water hose on the back side of the refrigerator.
- This may damage the refrigerator and as a result the
water dispenser can not be used.
Critical installation warnings
WARNING
• Do not install the refrigerator in a damp location or place
where it may come in contact with water.
- Deteriorated insulation on electrical parts may cause an
electric shock or re.
• Do not place this refrigerator in direct sunlight or expose it
to the heat from stoves, room heaters, or other appliances.
• Do not plug several appliances into the same multiple
power strip. The refrigerator should always be plugged
into its own individual electrical outlet which has a voltage
rating that matches the voltage listed on the refrigerator’s
rating plate.
- This provides the best performance and also prevents
overloading of house wiring circuits, which could cause
a re hazard from overheated wires.
English10
Untitled-4 10 2021-05-25 8:13:30
Page 11
• If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of re.
• Do not use a power cord that has cracks or abrasion
damage along its length or at either end.
• Do not bend the power cord excessively or place heavy
objects on it.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a
heavy object on the power cord, insert the power cord
between objects, or push the power cord into the space
behind the appliance.
• When moving the refrigerator, be careful not to roll over or
damage the power cord.
- This may result in an electric shock or re.
• Never unplug your refrigerator by pulling on the power
cord. Always grip the plug rmly and pull straight out from
the outlet.
- Damage to the cord may cause a short-circuit, re, and/
or electric shock.
• Do not use aerosols near the refrigerator.
- Using aerosols near the refrigerator may cause an
explosion or re.
• Do not install this appliance near a heater or inammable
material.
• Do not install this appliance in a location where gas may
leak.
- This may result in an electric shock or re.
Safety information
English 11
Untitled-4 11 2021-05-25 8:13:30
Page 12
Safety information
Safety information
• This refrigerator must be properly located and installed in
accordance with the instructions in this manual before you
use it.
• Connect the power plug in the proper position with the
cord hanging down.
- If you connect the power plug upside down, the wire
can get cut off and cause a re or electric shock.
• Make sure that the power plug is not crushed or damaged
by the back of the refrigerator.
• Keep the packing materials out of reach of children.
- There is a risk of death from suffocation if a child puts
the packing materials on his or her head.
• Do not install this appliance in a humid, oily or dusty
location, in a location exposed to direct sunlight and water
(rain drops).
- Deteriorated insulation of electrical parts may cause an
electric shock or re.
• If any dust or water is in the refrigerator, pull out power
plug and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance.
- This may result in an electric shock, re, problems with
the product, or injury.
• You need to remove all the protective plastic lm before
you initially plug the product in.
English12
Untitled-4 12 2021-05-25 8:13:30
Page 13
• Children should be supervised to ensure that they do not
play with the snap rings used for door adjustment or the
water tube clips.
- There is risk of death by suffocation if a child swallows
a snap ring or water tube clip. Keep the snap rings and
water tube clips out of children’s reach.
• The refrigerator must be safely grounded.
- Always make sure that you have grounded the
refrigerator before attempting to investigate or repair
any part of the appliance. Power leakages can cause
severe electric shock.
• Never use gas pipes, telephone lines, or other potential
lightning attractors as an electrical ground.
- You must ground the refrigerator to prevent any power
leakages or electric shocks caused by current leakage
from the refrigerator.
- This may result in an electric shock, re, explosion, or
problems with the product.
• Plug the power plug into the wall socket rmly. Do not use
a damaged power plug, damaged power cord, or loose wall
socket.
- This may result in an electric shock or re.
• The fuse on the refrigerator must be changed by a
qualied technician or service company.
- Failing to do so may result in an electric shock or
personal injury.
Safety information
English 13
Untitled-4 13 2021-05-25 8:13:30
Page 14
Safety information
Safety information
Installation cautions
CAUTION
• Allow sufcient space around the refrigerator and install it
on a at surface.
- If your refrigerator is not level, cooling efciency and
durability can be declined.
• Allow the appliance to stand for 2-3 hours before loading
foods after installation and turning on.
• We strongly recommend you have a qualied technician or
service company install the refrigerator.
- Failing to do so may result in an electric shock, re,
explosion, problems with the product, or injury.
Critical usage warnings
WARNING
• Do not insert the power plug into a wall socket with wet
hands.
- This may result in an electric shock.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall
and cause personal injury and/or material damage.
• Do not insert hands, feet or metal objects (such as
chopsticks, etc.) into the bottom or the back of the
refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury.
English14
Untitled-4 14 2021-05-25 8:13:30
Page 15
• Do not touch the inside walls of the freezer or products
stored in the freezer with wet hands.
- This may cause frostbite.
• Do not put a container lled with water on the refrigerator.
- If spilled, there is a risk of re or electric shock.
• Do not keep volatile or ammable objects or substances
(benzene, thinner, propane gas, alcohol, ether, LP gas, and
other such products) in the refrigerator.
- This refrigerator is for storing food only.
- This may result in re or explosion.
• Children should be supervised to ensure that they do not
play with the appliance.
- Keep ngers out of “pinch point” areas. Clearances
between the doors and cabinet are necessarily small. Be
careful when you open the doors if children are in the
area.
• Do not put your ngers or children's ngers between the
doors.
- Keep ngers out of the left and right door gaps. Be
careful when you open the doors if your ngers are in
between the doors.
• Do not let children hang on the door or door bins. A
serious injury may occur.
• Do not let children go inside the refrigerator. They could
become trapped.
• Do not insert your hands into the bottom area under the
appliance.
- Any sharp edges may cause personal injury.
Safety information
English 15
Untitled-4 15 2021-05-25 8:13:30
Page 16
Safety information
Safety information
• Do not store pharmaceutical products, scientic materials,
or temperature sensitive products in the refrigerator.
- Products that require strict temperature controls must
not be stored in the refrigerator.
• If you smell pharmaceutical or smoke, pull out power plug
immediately and contact your Samsung Electronics service
center.
• If any dust or water is in Refrigerator, pull out power plug
and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not let children step on a drawer.
- The drawer may break and cause them to slip.
• Do not leave the doors of the refrigerator open while the
refrigerator is unattended and do not let children enter
inside the refrigerator.
• Do not allow babies or children go inside the drawer.
- It can cause death from suffocation by entrapment or
personal injury.
• Do not overll the refrigerator with food.
- When you open the door, an item may fall out and
cause personal injury or material damage.
• Do not spray volatile material such as insecticide onto the
surface of the appliance.
- As well as being harmful to humans, it may also result
in an electric shock, re, or problems with the product.
• Never put ngers or other objects into the water dispenser
hole, ice chute and ice maker bucket.
- It may cause a personal injury or material damage.
English16
Untitled-4 16 2021-05-25 8:13:30
Page 17
• Do not use or place any substances sensitive to
temperature such as ammable sprays, ammable objects,
dry ice, medicine, or chemicals near or inside of the
refrigerator.
• Do not use a hair dryer to dry the inside of the
refrigerator. Do not place a lighted candle in the
refrigerator for removing bad odours.
- This may result in an electric shock or re.
• Fill the water tank, ice tray and water cubes only with
potable water (mineral water or puried water).
- Do not ll the tank with tea, juice or sports drink, this
may damage the refrigerator.
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance. This may
result in an electric shock, re, problems with the product,
or injury. Do not put a container lled with water on the
appliance.
- If spilled, there is a risk of re or electric shock.
• Never stare directly at the UV LED lamp for long periods of
time.
- This may result in eye strain due to the ultraviolet rays.
• Do not put shelf in upside down. Shelf stopper could not
work.
- It may cause a personal injury because of glass shelf
drop.
• Keep ngers out of “pinch point” areas. Clearances
between the doors and cabinet are necessarily small. Be
careful when you open the doors if children are in the area.
Safety information
English 17
Untitled-4 17 2021-05-25 8:13:30
Page 18
Safety information
Safety information
• If a gas leak is detected, avoid any naked ames or
potential sources of ignition, and air the room in which the
appliance is standing for several minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in explosion or re.
• Bottles should be stored tightly together so that they do
not fall out.
• This product is intended only for the storage of food in a
domestic environment.
• Never put ngers or other objects into the water dispenser
hole, ice chute and ice maker bucket.
- It may cause a personal injury or material damage.
• Do not attempt to repair, disassemble, or modify the
refrigerator yourself.
• Do not use any fuse (such as cooper, steel wire, etc.) other
than a standard fuse.
• If your refrigerator needs to be repaired or reinstalled,
contact your nearest service center.
- Failing to do so may result in an electric shock, re,
problems with the product, or injury.
• If the refrigerator emits a burning smell or smoke, unplug
the refrigerator immediately and contact your Samsung
Electronics service center.
- Failing to do so may result in an electric or re hazards.
• Pull the power plug out of the socket before changing the
interior lamps of the refrigerator.
- Otherwise, there is a risk of electric shock.
• If you experience difculty changing a non-LED light,
contact a Samsung service center.
English18
Untitled-4 18 2021-05-25 8:13:30
Page 19
• Plug the power plug into the wall socket rmly.
• Do not use a damaged power plug, damaged power cord or
loose wall socket.
- This may result in an electric shock or re.
Usage cautions
CAUTION
• Do not refreeze thawed food.
- Frozen and thawed food will develop harmful bacteria
faster than fresh.
- The second thaw will break down even more cells,
leaching out moisture and changing the integrity of the
product.
• Do not thaw meat at room temperature.
- Safety will depend on whether the raw product was
handled properly.
• Do not place glass bottles or carbonated beverages into
the freezer.
- The container may freeze and break, and this may
result in injury.
• Use only the ice maker provided with the refrigerator.
• If you will be away from home for a long period of time
(on vacation, for example) and won’t be using the water or
ice dispensers, close the water valve.
- Otherwise, water leakage may occur.
Safety information
English 19
Untitled-4 19 2021-05-25 8:13:30
Page 20
Safety information
Safety information
• If you won’t be using the refrigerator for a very long
period of time, (3 weeks or more) empty the refrigerator
including the ice bucket, unplug it, close the water valve,
wipe excess moisture from the inside walls, and leave the
doors open to prevent odors and mold.
• To get the best performance from the product:
- Do not place food too close to the vents at the rear of
the refrigerator as this can obstruct free air circulation
in the refrigerator compartment.
- Wrap food up properly or place it in airtight containers
before putting it into the refrigerator.
- Please observe maximum storage times and expiration
dates of frozen goods.
- There is no need to disconnect the refrigerator from
the power supply if you will be away for less than
three weeks. However, if you will be away for more
than three weeks, remove all the food and ice in the ice
bucket, unplug the refrigerator, close the water valve,
wipe excess moisture from the inside walls, and leave
the doors open to prevent odors and mold.
• Service Warranty and Modication.
- Any changes or modications performed by a 3rd
party on this nished appliance are not covered
under Samsung warranty service, nor is Samsung
responsible for safety issues that result from 3rd party
modications.
English20
Untitled-4 20 2021-05-25 8:13:30
Page 21
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic
bag, the refrigerator can be over cooled. If a cooling
period lasts too long, the water lter may break and
cause water leakage.
• Use only the ice-maker provided with the refrigerator.
• Wipe excess moisture from the inside and leave the doors
open.
- Otherwise, odor and mold may develop.
• If the refrigerator is disconnected from the power supply,
you should wait for at least ve minutes before plugging it
back in.
• When the refrigerator got wet by water, pull out the power
plug and contact your Samsung Electronics service center.
• Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or
property damage.
• Fill the water tank and ice cube trays with potable water
only (tap water, mineral water, or puried water).
- Do not ll the tank with tea or a sports drink. This may
damage the refrigerator.
• Be careful that your ngers are not caught in.
• If the refrigerator is ooded, make sure to contact your
nearest service center.
- There is a risk of electric shock or re.
Safety information
English 21
Untitled-4 21 2021-05-25 8:13:30
Page 22
Safety information
Safety information
• Do not keep vegetable oil in your refrigerator’s door bins.
The oil can solidify, making it foul-tasting and difcult to
use. In addition, the open container can leak and the leaked
oil can cause the door bin to crack. After opening an oil
container, it is best to keep the container in a cool and
shaded place such as a cupboard or pantry.
- Examples of vegetable oil: olive oil, corn oil, grape-seed
oil, etc.
Cleaning cautions
CAUTION
• Do not spray water directly on the inside or outside the
refrigerator.
- There is a risk of re or electric shock.
• Do not use a hair dryer to dry the inside of the
refrigerator.
• Do not place a lighted candle in the refrigerator to remove
bad odors.
- This may result in an electric shock or re.
• Do not spray cleaning products directly on the display.
- Printed letters on the display may come off.
• If any foreign substance such as water has entered the
appliance, unplug the power plug and contact your nearest
service center.
- Failing to do so may result in an electric shock or re.
English22
Untitled-4 22 2021-05-25 8:13:30
Page 23
• Use a clean, dry cloth to remove any foreign matter or dust
from the power plug blades. Do not use a wet or damp
cloth when cleaning the plug.
- Otherwise, there is a risk of re or electric shock.
• Do not clean the appliance by spraying water directly onto
it.
• Do not use benzene, thinner, or Clorox, Chloride for
cleaning.
- They may damage the surface of the appliance and may
cause a re.
• Never put ngers or other objects into the dispenser hole.
- It may cause a personal injury or material damage.
• Before cleaning or performing maintenance, unplug the
appliance from the wall socket.
- Failing to do so may result in an electric shock or re.
• Use a clean sponge or soft cloth and a mild detergent in
warm water to clean the refrigerator.
• Do not use abrasive or harsh cleansers such as window
sprays, scouring cleansers, ammable uids, muriatic
acid, cleaning waxes, concentrated detergents, bleaches,
or cleansers containing petroleum products on exterior
surfaces (doors and cabinet), plastic parts, door and interior
liners, and gaskets.
- These can scratch or damage the material.
• Do not clean glass shelves or covers with warm water
when they are cold. Glass shelves and covers may break if
exposed to sudden temperature changes or impacts such
as bumping or dropping.
Safety information
English 23
Untitled-4 23 2021-05-25 8:13:30
Page 24
Safety information
Safety information
Critical disposal warnings
WARNING
• Please dispose of the packaging material from this product
in an environmentally friendly manner.
• Ensure that none of the pipes on the back of the
refrigerator are damaged prior to disposal.
• R-600a or R-134a is used as a refrigerant. Check the
compressor label on the rear of the appliance or the rating
label inside the fridge to see which refrigerant is used for
your refrigerator. If this refrigerator contains ammable
gas (Refrigerant R-600a), contact your local authority in
regard to safe disposal of this product.
• When disposing of this refrigerator, remove the door/
door seals and door latch so that small children or
animals cannot become trapped inside. Children should
be supervised to ensure that they do not play with the
appliance. If trapped inside, a child may get hurt or
suffocate to death.
- If trapped inside, the child may become injury and
suffocate to death.
• Cyclopentane is used in the insulation. The gases in the
insulation material require a special disposal procedure.
Please contact your local authorities in regard to the
environmentally safe disposal of this product.
• Keep all packaging materials well out of the reach of
children, as packaging materials can be dangerous to
children.
- If a child places a bag over his or her head, the child
could suffocate.
English24
Untitled-4 24 2021-05-25 8:13:30
Page 25
Additional tips for proper usage
• In the event of a power failure, call the local ofce of your
electric company and ask how long the failure is going to
last.
- Most power failures that are corrected in an hour or two
will not affect your refrigerator temperatures. However,
you should minimize the number of door openings
while the power is off.
- Should the power failure last more than 24 hours,
remove and discard all frozen food.
• The refrigerator might not operate consistently (frozen
contents can thaw or temperatures can become too
warm in the frozen food compartment) if sited for an
extended period of time in a location where ambient air
temperatures are constantly below the temperatures for
which the appliance is designed.
• In case of particular foods, keeping it under refrigeration
can have a bad effect on preservation due to its properties.
• Your appliance is frost free, which means there is no need
to manually defrost your appliance. This will be carried out
automatically.
• Temperature rise during defrosting complies with ISO
requirements. If you want to prevent an undue rise in the
temperature of frozen food while the appliance defrosts,
wrap the frozen food in several layers of newspaper.
• Do not re-freeze frozen foods that have thawed
completely.
Safety information
English 25
Untitled-4 25 2021-05-25 8:13:30
Page 26
Safety information
Safety information
• The temperature of two star section (sections) or
compartment (compartments) which have two star symbol
) is slightly higher than other freezer compartment
(
(compartments).
The two star section (sections) or compartment
(compartments) is (are) based on the instruction and/or the
condition as delivered.
English26
Untitled-4 26 2021-05-25 8:13:30
Page 27
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased
this product, or their local government ofce, for details of where and
how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
For information on Samsung’s environmental commitments
and product regulatory obligations, e.g. REACH, WEEE or
Batteries, visit our sustainability page available via
www.samsung.com
(For products sold in European countries and in the UK only)
Safety information
English 27
Untitled-4 27 2021-05-25 8:13:31
Page 28
01
02
04
03
06
05
Installation
Installation
Follow these instructions carefully to ensure a proper installation of this refrigerator and to
prevent accidents before using it.
WARNING
• Use the refrigerator only for its intended purpose as described in this manual.
• Any servicing must be performed by a qualied technician.
• Dispose of the product packaging material in compliance with the local regulations.
• To prevent electric shock, unplug the power plug before servicing or replacing parts.
Refrigerator at a glance
The actual refrigerator and provided parts of your refrigerator may differ from the
illustrations in this manual, depending on the model and the country.
Type A
English28
Untitled-4 28 2021-05-25 8:13:31
Page 29
Type B
01
02
04
07
03
06
05
Installation
01 Main panel 02 Freezer
03 Door bins 04 Ice Maker
05 Ice bucket 06 Fridge drawers
07 Water Tank *
* applicable models only
NOTE
• For energy efciency, keep all shelves, drawers, and baskets in their original positions.
• When closing the door, make sure the vertical hinged section is in the correct position
to avoid scratching the other door.
• If the vertical hinged section is reversed, put it back into the correct position, and then
close the door.
• Moisture may form at times on the vertical hinged section.
• If you close a door forcefully, the other door may open.
English 29
Untitled-4 29 2021-05-25 8:13:31
Page 30
Installation
Installation
• If the internal or external LED lamp is out of order, contact a local Samsung service
center.
• If the door is left open for too long, the top internal LED will blink. This is normal.
Door bins
Your refrigerator ships with door bins of different types and sizes. If the door bins for your
refrigerator were packaged separately, use the gure below to help you position the bins
properly.
The number of door bins provided may differ with the model.
Type A
Type B
English30
Untitled-4 30 2021-05-25 8:13:31
Page 31
Step-by-step installation
C
D
B
A
STEP 1 Select a site
Select a site that:
• Has a solid, level surface without carpeting or ooring that may obstruct ventilation
• Is away from direct sunlight
• Has adequate room for opening and closing the door
• Is away from any heat sources
• Provides room for maintenance and servicing
• Has a temperature range between 10 °C and 43 °C
Clearance
See the following gures and tables for space requirements for installation.
Model
RF44A*
RF50A*
RF49A*
RF57A*
Installation
Depth “A” 715 mm 765 mm
Width “B” 817 mm 817 mm
Height “C” 1749 mm 1749 mm
Overall
Height “D”
1776 mm 1776 mm
Untitled-4 31 2021-05-25 8:13:31
English 31
Page 32
Installation
01
02 02
04
03
05
07 08
06
Installation
Model
RF44A*
RF50A*
RF49A*
RF57A*
01 50 mm 50 mm
02 135° 135°
03 1393 mm 1393 mm
04 291 mm 291 mm
05 625 mm 675 mm
06 31.5 mm 31.5 mm
07 1056 mm 1101 mm
08 1082 mm 1132 mm
NOTE
The measurements in the table above
may differ slightly from the actual
measurements, depending on the
measuring and rounding method.
Untitled-4 32 2021-05-25 8:13:32
English32
Page 33
STEP 2 Flooring
If the refrigerator cannot pass through the entrance due to its size, see Door removal for
entrance.
NOTE
To prevent oor damage, make sure the
front leveling legs are in the upright
position.
• The surface you install the refrigerator
on must support a fully loaded
refrigerator.
• To protect the oor, put a large piece
of cardboard along the path to the
refrigerator's nal installation location.
• Once the refrigerator is in its nal
position, do not move it unless
necessary to protect the oor. If you
have to move the refrigerator, place
thick paper or cloth such as old carpets
along the path of movement.
Installation
English 33
Untitled-4 33 2021-05-25 8:13:32
Page 34
Installation
Installation
STEP 3 Door removal for entrance
If the refrigerator cannot pass through the entrance to your home or kitchen due to its
size, follow these instructions to remove and then re-install the refrigerator's doors. If you
do not need to remove the doors, go to page 40 to continue the installation procedure.
WARNING
Unplug the power cord of the refrigerator before removing the doors.
Tools required (not provided)
Phillips screwdriver Flat-head screwdriver Socket wrench 10 mm
Pliers Allen wrench 5 mm
English34
Untitled-4 34 2021-05-25 8:13:32
Page 35
Detach the fridge doors
A
B
C
1. Use a Phillips screwdriver to remove the
screws fastening the top cover (A).
2. Disconnect the wires on the top of the
refrigerator.
Installation
3. Use a socket wrench (10 mm) to remove
the screws fastening the top hinge (B).
4. Use a Phillips screwdriver to remove the
screw fastening the ground wire (C).
Untitled-4 35 2021-05-25 8:13:33
English 35
Page 36
Installation
Installation
5. Remove the top hinge from the door.
NOTE
Remove the top hinge carefully. The wires
from the door are arranged through the
hinge shaft.
6. Gently pull up the fridge door to
remove. Do not apply excessive force
to the door. The door may fall, causing
physical injury.
7. Lay the door down on a at surface.
To reattach the fridge doors
After moving the refrigerator to its nal location, reattach the doors by following the
removal instructions in the reversed order.
English36
Untitled-4 36 2021-05-25 8:13:33
Page 37
Detach the freezer drawer
A
1. Fully open the freezer drawer, and then
lift the drawer basket (A) to remove.
2. Use a socket wrench (10 mm) to remove
the 4 screws fastening the door.
Installation
3. Lift the freezer door from the rails to
remove.
English 37
Untitled-4 37 2021-05-25 8:13:33
Page 38
Installation
A
To reattach the freezer drawer
CAUTION
• Be careful not to scratch or dent the rail
assembly.
• Make sure you mount the freezer
baskets in the correct position.
Otherwise, the door will not open or
close properly, which causes frost to
build up.
• Do not store too much food in the
freezer drawer. This prevents the freezer
drawer from closing properly, resulting
in frost buildup.
Installation
1. Fully pull out the freezer drawer rails.
2. Attach the freezer door to the slots (A)
at the side of the rails.
English38
Untitled-4 38 2021-05-25 8:13:34
Page 39
3. Use a socket wrench (10 mm) to fasten
the door to the rail with 4 screws.
4. Insert the freezer basket back into its
position.
Installation
English 39
Untitled-4 39 2021-05-25 8:13:34
Page 40
Installation
Installation
STEP 4 Leveling the refrigerator
CAUTION
• When installed, the refrigerator must be leveled on a at, solid oor. Not leveling the
refrigerator can cause damage to the refrigerator or physical injury.
• Leveling must be performed with the refrigerator empty. Make sure no food items are
inside the refrigerator.
• For safety reasons, adjust the front a little higher than the rear.
Level the refrigerator using the special screws (levelers) on the front legs. Use a at-head
screwdriver to turn the levelers.
• To adjust the height of the left side:
Insert a at-head screwdriver into the
leveler of the left side front leg. Turn the
leveler clockwise to raise the left side or
turn it counterclockwise to lower.
• To adjust the height of the right side:
Insert a at-head screwdriver into the
leveler of the right side front leg. Turn
the leveler clockwise to raise the right
side or turn it counterclockwise to lower.
English40
Untitled-4 40 2021-05-25 8:13:34
Page 41
STEP 5 Align the fridge doors
A
B
C
D
C
• Before aligning the fridge doors, make
sure the refrigerator is level. Refer to
the “Leveling the refrigerator” section
for detailed instruction.
• You can use the adjustment parts (*) at
the bottom of both fridge doors to raise
or lower the door.
Installation
1. Fully open the freezer drawer (A), and
then nd the middle hinge (B).
2. Insert the Allen wrench (C) into the shaft
(D) of the middle hinge.
3. Turn the Allen wrench (C) clockwise or
counterclockwise to raise or lower the
door.
Untitled-4 41 2021-05-25 8:13:34
English 41
Page 42
Installation
C
G
F
E
D
Installation
4. Use the Pliers (D) to insert the provided
snap ring (E) in the gap between the
hinge-grommet (F) and the middle hinge
(G). The number of snap rings depends
on the gap.
NOTE
Two 0.04” snap rings are provided with the
product.
English42
Untitled-4 42 2021-05-25 8:13:34
Page 43
STEP 6 Connect the water dispenser line (applicable models only)
A
B
C
A
B
A water dispenser with a lter is one of the helpful features on your new refrigerator. To
help promote better health, the water lter removes unwanted particles from your water.
However, it does not sterilize or destroy microorganisms. You may need to purchase a
water purifying system to do that.
The water line also connects to the ice maker. For the ice maker to operate properly, water
pressure of 206 to 827 kPa is required.
If the refrigerator is installed in an area with low water pressure (below 30 psi / 206 kPa),
you can install a booster pump to compensate for the low pressure.
After you have connected the water line, make sure the water storage tank inside the
refrigerator is properly lled. To do this, press the water dispenser lever until water runs
from the water outlet.
NOTE
• Water line installation kits are available at extra cost from your retailer. We recommend
using a water line installation kit that contains copper tubing and a 6 mm compression
nut.
1. Shut off the main water source.
2. Insert the pipe clamp (B) and the shutoff
valve (C) into the cold water line (A).
3. Connect the water line installation kit
(A) to the shutoff valve (B).
Installation
Untitled-4 43 2021-05-25 8:13:35
English 43
Page 44
Installation
A
01
02
03 08
04
05
06
07
B
C
Connect the water supply line to the refrigerator
There are several items you must purchase to complete this connection. You may nd these
items sold as a kit at your local hardware store.
Installation
Copper Tubing
Plastic Tubing
• 1/4" copper tubing
• 1/4" compression nut (1 pc)
• Ferrule (2 pc)
• 1/4" plastic tubing Molded end (Bulb)
• 1/4" compression nut (1 pc)
A. Refrigerator
B. Household water supply line
C. Water Line: must be kept straight.
01 Compression Nut (1/4") (Assembled)
02 Ferrule (Not supplied)
03 Copper tubing (Not supplied)
04 Plastic Tubing (Assembled)
05 Compression Fitting (Assembled)
06 Molded end (Bulb)
07 Compression nut (1/4") (Not supplied)
08 Plastic Tubing (Not supplied)
NOTE
If you have to relocate the refrigerator
after connecting the water line (C), make
sure the joined section of the water line is
straight.
Untitled-4 44 2021-05-25 8:13:35
English44
Page 45
CAUTION
Do not mount the water lter on any part
of the refrigerator. This may damage the
refrigerator.
1. Connect the household water line to the assembled compression tting.
- If you are using copper tubing, slip the compression nut (07) (not supplied) and
ferrule (not supplied) on the copper tubing (not supplied) as shown.
- If you are using plastic tubing (08), insert the molded end (Bulb) of the plastic tubing
(08) into the compression tting.
CAUTION
• If you use plastic tubing (08), do not use it without the molded end (Bulb).
• Leaving the water line disconnected may cause the water valve to produce a buzzing
sound over time. If this is the case, make sure that the ice making function is turned
“OFF” and do not attempt to use the water dispenser.
2. Tighten the compression nut (07) onto the compression tting. Do not over-tighten the
compression nut (07).
3. Turn the water on and check for any leakage. If you nd water drops or leakage in
the connection areas, turn off the main water supply. Check the connections and, if
necessary, tighten.
4. Flush 1 gallon of water through the lter before drinking or using the water from the
refrigerator. (Flush approximately 6 minutes.) To ush, press a large glass or cup against
the water dispenser lever. Fill the glass, empty it, and then repeat.
5. After you turn on the refrigerator, let the ice maker make ice for 1 to 2 days. Over that
period of time, throw out the rst 1 or 2 buckets of ice the ice maker makes to ensure
all impurities have been removed from the water line.
NOTE
Only connect the water line to a potable water source.
• If you have to repair or disassemble the water line, cut off 1/4“ of the plastic tubing to
make sure you get a snug, leak-free connection.
• You can test the water line quickly using a paper cup. Under normal conditions, the
water dispenser can ll a 170 cc cup in about 10 seconds.
Installation
English 45
Untitled-4 45 2021-05-25 8:13:35
Page 46
Installation
Installation
STEP 7 Initial settings
By completing the following steps, the refrigerator should be fully functioning.
1. Plug the power cord into the wall socket to turn the refrigerator on.
2. Open the door, and check if the interior light lights up.
3. Set the temperature to the coldest setting, and wait for about an hour. Then, the freezer
will be slightly chilled, and the motor should be running smoothly.
4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready
for use.
STEP 8 Final check
When installation is complete, conrm that:
• The refrigerator is plugged into an electrical outlet and grounded properly.
• The refrigerator is installed on a at, level surface with a reasonable clearance from
walls and cabinets.
• The refrigerator is level and is sitting rmly on the oor.
• The door opens and closes freely, and the interior light turns on automatically when you
open the door.
English46
Untitled-4 46 2021-05-25 8:13:35
Page 47
Operations
Main panel
01
02
03
04
Operations
05
01 Fridge indicator
02 Freezer indicator
03 Door open
indicator
04 Ice Maker indicator
Untitled-4 47 2021-05-25 8:13:36
• Displays the current or desired temperature of the fridge.
• indicates that the Power Cool function is on.
•
indicates that the Vacation function is on.
• Displays the current or desired temperature of the freezer.
•
indicates that the Power Freeze function is on.
• This indicator blinks with an alarm if the door is left open
for more than 2 minutes.
• Displays the status of the ice maker.
• To enable ice making, you must turn on the ice maker.
English 47
Page 48
Operations
Operations
• When the display is off, tap any button to wake up the
display.
05 Buttons
* applicable models only
NOTE
• The control panel is designed to stay off when the refrigerator is not in use. It only
becomes active and lights up when you open the door or tap the buttons.
• If the door is left open for 5 minutes, the internal light will blink for 5 minutes and turn
off to alert deaf and hard of hearing users that a door is open. Note that this function is
normal.
• Tap
• Tap
to select the desired item on the main panel and to
conrm any setting changes.
or to change the settings of the selected item on
the main panel.
English48
Untitled-4 48 2021-05-25 8:13:36
Page 49
Setting the desired temperature or function
Select the fridge or freezer and set the desired temperature or function of your choice.
1. Tap any button ( , , or ) to wake up the display.
- This step may not apply to some models.
2. Tap until the fridge or freezer indicator blinks.
- The selected compartment’s indicator blinks.
3. Tap or to select the desired temperature or function.
- Refer to the table for available selection for each compartment.
• Available selection (Celsius): (Power Cool) 1 °C 2 °C 3 °C
Fridge
Freezer
4 °C 5 °C 6 °C 7 °C
• Power Cool speeds up the cooling process at maximum fan speed.
The fridge keeps running at full speed for two and a half hours and
then returns to the previous temperature.
• Use the Vacation function if you are going on vacation or a business
trip, or if you do not intend to use the fridge for an extended time.
The fridge temperature will be kept under 17 °C, but the freezer
remains active as previously set.
• Available selection (Celsius): (Power Freeze) -23 °C -22 °C
-21 °C -20 °C -19 °C -18 °C -17 °C -16 °C -15 °C
• Power Freeze speeds up the freezing process at maximum fan speed.
• The freezer keeps running at full speed for 50 hours and then
returns to the previous temperature. To freeze large amounts of food,
activate Power Freeze for at least 20 hours before putting food in the
freezer.
NOTE
When you use this function, the energy consumption of the refrigerator
will increase. Remember to turn it off when you do not need it and
return the freezer to your original temperature setting.
(Vacation)
Operations
4. Wait for 5 seconds or tap to conrm your selection.
- The selected compartment’s indicator stops blinking.
NOTE
• Using Power Cool or Power Freeze increases power consumption.
• When you change the temperature on the panel, the panel displays the actual
temperature inside the refrigerator until the temperature matches the temperature you
set. Then, the panel displays the new set temperature. Note that it will take time for the
refrigerator to reach the new temperature. This is normal. During this time, you do not
need to set the temperature again.
• To ensure optimal performance, we recommend setting the temperature to -19 °C for
the freezer, and 3 °C for the fridge.
English 49
Untitled-4 49 2021-05-25 8:13:36
Page 50
Operations
Operations
• The temperature in the refrigerator may rise if you open the door frequently or put
a large amount of food into the refrigerator. If this happens, the temperature display
blinks until the refrigerator returns to the specied temperature settings. If the blinking
continues for an extended time, contact a local Samsung service center for technical
assistance.
Changing the temperature scale
You can switch the temperature scale between Fahrenheit and Celsius.
1. Tap any button ( , , or ) to wake up the display.
- This step may not apply to some models.
2. Tap until the °F and °C symbols on the fridge or freezer blink.
3. Tap or to select the desired temperature scale.
- Tap
- Tap
4. Wait for 5 seconds or tap to conrm your selection.
- The °F and °C symbols stop blinking.
Turning on or off the ice maker
You can turn on or off the auto ice maker in the freezer.
1. Tap any button ( , , or ) to wake up the display.
- This step may not apply to some models.
2. Tap until the Ice Maker indicator blinks.
3. Tap or to turn on or off the ice maker.
- Tap
- Tap
4. Wait for 5 seconds or tap to conrm your selection.
- The Ice Maker indicator stops blinking.
to select Fahrenheit.
to select Celsius.
to turn it on.
to turn it off.
Activating or deactivating the Sabbath mode (applicable models only)
The Sabbath mode stays active for 85 hours once it is activated. After that, it will be
deactivated automatically.
• To activate or deactivate the Sabbath Mode, tap and hold
seconds. Then, when the display blinks, tap
- When the refrigerator is in the Sabbath mode, the buttons, display, and internal
lights do not function. The refrigerator and freezer, however, continue to cool.
NOTE
• If the refrigerator powers off and restarts (for example, if there is a power failure),
the Sabbath mode remains active. To end Sabbath Mode, you must deactivate it as
instructed above.
English50
Untitled-4 50 2021-05-25 8:13:36
.
and simultaneously for 6
Page 51
Special features
A
Ice maker
The refrigerator has a built-in ice maker that automatically dispenses ice so that you can
enjoy ltered water with cubed or crushed ice.
Ice Maker Operation
• The ice maker will produce 8 cubes per
cycle - approximately 100~130 cubes
in a 24-hour period, depending on
freezer compartment temperature, room
temperature, number of door openings,
and other use conditions.
• Throw away the rst few batches of ice
to allow the water line to clear.
• Be sure nothing interferes with the
sweep of the feeler arm. When the bin
lls to the level of the feeler arm, the ice
maker will stop producing ice.
• After the ice maker has been turned on
again, there will be a time delay before
the ice maker resumes operation.
• It is normal for several cubes to be
joined together.
• If ice is not used frequently, old ice
cubes will become cloudy, taste stale,
and shrink. If you do not want to make
ice, turn the ice maker off. (For detailed
instructions on turning the ice maker on
or off, see the “Turning on or off the ice
maker” section on page 50.)
• If the auto ice maker does not make ice,
remove the ice bucket and press Test
Switch (A) to check if the auto ice maker
operates properly.
Operations
NOTE
When the ice maker is on, the temperature of the freezer will be lower than the set
temperature. If you do not need to use the ice maker, turn off the ice maker.
If You Turn the Ice Maker Off
If you turn the ice maker off, make sure to remove all ice cubes from the ice bucket. The
remaining ice cubes may clump together, making it difcult to remove.
English 51
Untitled-4 51 2021-05-25 8:13:37
Page 52
Operations
Operations
Water dispenser (applicable models only)
With the water dispenser, you can dispense water without opening the fridge door. The
water tank must be lled with potable water before use.
To ll the water tank with potable water
Open the door and locate the water tank that is located in the door shelf area.
1. Hold the handgrips on both sides of the
water tank and lift up to remove.
2. Fill the water tank with potable water
up to 4 liters. You can remove either the
top cap or the cover and pour water.
NOTE
For rst-time use, clean inside the water
tank.
3. Reinsert the water tank and close the
door. Make sure the water outlet of the
water tank faces forward.
English52
Untitled-4 52 2021-05-25 8:13:37
Page 53
4. Put a water glass under the water outlet
of the dispenser, and gently push the
dispenser lever to dispense water. Make
sure the water dispenser is unlocked.
CAUTION
• The water dispenser is designed to dispense potable water. Fill the water tank only with
potable water. Do not ll with any other liquids.
• Do not ll the water tank excessively, which causes an overow.
• Do not try to ll the water tank without removing it from the door.
• Make sure that water tank is seated properly.
• Do not use the refrigerator without the water tank. This may reduce performance and
efciency.
• To prevent water bouncing, make sure the glass is in line with the dispenser lever.
NOTE
To secure more room, you can use the water tank to store food. In this case, remove the lid
of the tank.
Operations
English 53
Untitled-4 53 2021-05-25 8:13:37
Page 54
Maintenance
Handling and care
Shelves
CAUTION
• The shelf must be inserted correctly. Do not insert upside down.
• Glass containers may scratch the surface of glass shelves.
Fridge shelves
To remove a shelf, fully open the fridge
door. Hold the front of the shelf and gently
lift up and slide out.
1. Fully open the fridge door.
2. Hold the front of the shelf lift the back
of the shelf to release the hook from the
groove.
3. Pull out to remove.
Maintenance
English54
Untitled-4 54 2021-05-25 8:13:37
Page 55
Vegetable shelves
Door bins
1. Fully open the fridge door.
2. Lift up the front of the shelf and pull it
to release the shelf from the holder at
the rear wall.
3. Pull out to remove.
• To remove the door bin, hold the front
sides of the bin, and then gently lift up
to remove.
• To reinsert, insert the door bin slightly
above its nal location making sure that
the back of the bin is against the door.
Hold the rear of the door bin with both
hands, and then press down so that it
ts snugly.
Maintenance
CAUTION
• Do not remove a bin that is lled with
food. Empty the bin beforehand.
• Use caution when opening the door if
the bottom bin contains larger bottles,
which may fall over.
• Do not allow children to play with the
bins. Sharp corners of the bin may cause
injury.
English 55
Untitled-4 55 2021-05-25 8:13:38
Page 56
Maintenance
Fridge drawers
Vegetable / fruit drawers
Freezer baskets
Gently lift up the front of the drawer and
slide out.
• We recommend that you remove the
door bins before removing the drawer.
This is to prevent damage to the door
bins.
• To reinsert, insert the drawer into the
frame rails and then slide inward.
1. Fully open the freezer drawer.
Maintenance
English56
Untitled-4 56 2021-05-25 8:13:38
2. Lift the ice bucket to remove.
Page 57
Upper basket
• To remove, fully slide open the freezer
drawer. Lift up the front of the upper
basket and pull to remove.
• To reinsert, align the front wheels of the
upper basket with the end of the lower
basket. Slide the upper basket to the
front.
Lower basket
• To remove, rst remove the upper
basket. Then, tilt up the front of the
lower basket to pull out.
• To reinsert, put the basket onto the rail
assembly rear side rst.
CAUTION
• Do not twist the basket when removing or reinserting the basket. The basket can be
scratched.
• To prevent physical injury, property damage, or suffocation, keep children away from
freezer baskets that have been removed.
• Do not remove the divider.
• Put the wheels of the upper basket on the end of the rails of the lower basket. Then,
slide the upper basket all the way to the front. Otherwise, the drawer will not open or
close properly, which will cause frost to build up.
Maintenance
English 57
Untitled-4 57 2021-05-25 8:13:38
Page 58
Maintenance
Cleaning
Interior and exterior
WARNING
• Do not use benzene, thinner, home/car detergent, or Clorox™ to clean the refrigerator.
They may damage the surface of the refrigerator and cause a re.
• Do not spray water onto the refrigerator. This may cause electric shock.
Regularly use a dry cloth to remove all foreign substances such as dust or water from the
power plug terminals and contact points.
1. Unplug the power cord.
2. Use a moistened, soft, lint-free cloth or paper towel to clean the refrigerator’s interior
and exterior.
3. When done, use a dry cloth or paper towel to dry well.
4. Plug in the power cord.
Rubber seals
If the rubber seals of a door become dirty, the door may not close properly and reducing
refrigerator performance and efciency. Use a mild detergent and damp cloth to clean the
rubber seals. Then, dry well with a cloth.
Rear panel
To keep cords and exposed parts of the
rear panel free of dirt, vacuum the panel
once or twice a year.
Maintenance
CAUTION
Do not remove the rear panel cover. Electric shock may occur.
English58
Untitled-4 58 2021-05-25 8:13:39
Page 59
Replacement
LED Lamps
To replace the lamps of the refrigerator, contact a local Samsung service center.
WARNING
• The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can
cause electric shock.
Lamp (Light Source)
This product contains a light source of energy efciency class <G>.
The lamp(s) and/or control gear(s) are not user-serviceable. To replace the lamp(s) and/or
control gear(s) in the product, contact a local Samsung service centre.
For detailed instructions on replacing lamp(s) or control gear(s) in your product, visit the
Samsung website (http://www.samsung.com), go to Support > Support home, and then
enter the model name.
For detailed instructions on dismantling lamp(s) and/or control gear(s), simply follow the
replacement instruction reached as described above.
Maintenance
English 59
Untitled-4 59 2021-05-25 8:13:39
Page 60
Troubleshooting
Troubleshooting
Before calling for service, review the checkpoints below. Any service calls regarding
normal situations (No Defect Cases) will be charged to users.
General
Temperature
Symptom Possible causes Solution
Fridge/freezer
does not operate.
Fridge/freezer
temperature is
warm.
Fridge/freezer is
over-cooling.
Interior wall is hot.
• Power cord is not plugged in
properly.
• Temperature control is not
set correctly.
• Refrigerator is located near a
heat source or direct sunlight.
• Not enough clearance
between refrigerator and
nearby walls or cabinets.
• The refrigerator is
overloaded. Food is blocking
the refrigerator vents.
• Temperature control is not
set correctly.
• Refrigerator has heat-proof
piping in the interior wall.
• Properly plug in the power
cord.
• Set the temperature lower.
• Keep the refrigerator away
from direct sunlight or a heat
source.
• Make sure there is a gap of
at least 2.5 inches (5 cm)
between the refrigerator
back and sides and any
nearby walls or cabinets.
• Do not overload the
refrigerator. Do not allow
food to block vents.
• Set the temperature higher.
• To prevent condensation
from forming, the
refrigerator has heat-proof
piping in the front corners.
If the ambient temperature
rises, this equipment may not
work effectively. This is not a
system failure.
English60
Untitled-4 60 2021-05-25 8:13:39
Page 61
Odors
Symptom Possible causes Solution
• Clean the refrigerator and
remove any spoiled food.
• Make sure strong smelling
food is wrapped airtight.
Refrigerator has
odors.
• Spoiled food.
• Food with strong odors.
Frost
Symptom Possible causes Solution
Frost around the
vents.
Frost on interior
walls.
• Food is blocking the vents.
• Door is not closed properly.
• Make sure no food blocks the
refrigerator vents.
• Make sure food does not
block the door. Clean the
door gasket.
Condensation
Symptom Possible causes Solution
• Remove the moisture and
do not leave a door open for
extended periods of time.
• Make sure food is wrapped
airtight.
Condensation
forms on the
interior walls.
• If door is left open, moisture
enters the refrigerator.
• Food with high moisture
content.
Water/ice (dispenser models only)
Symptom Possible causes Solution
Water ow is
weaker than
normal.
Ice maker makes a
buzzing sound.
Untitled-4 61 2021-05-25 8:13:39
• Water pressure is too low.
• The Ice Maker function is
activated, but the water
supply to the refrigerator has
not been connected.
• Make sure the water pressure
is between 30 to 125 psi
(206 to 861 kPa).
• Press
Ice Maker.
English 61
Troubleshooting
Page 62
Troubleshooting
Symptom Possible causes Solution
• You must wait for 12 hours
for the refrigerator to make
ice.
• Set the freezer temperature
below 0 °F (-18 °C) or -4 °F
(-20 °C) in warm ambient air.
• Deactivate dispenser panel
Lock.
• If you won't be using the
refrigerator for a long time,
empty the ice bucket and
turn off the ice maker.
• Make sure the ice bucket is
properly inserted.
• Check if the water line is
installed correctly. Check if
the water line stop cock is
closed.
Ice maker does not
make ice.
Ice does not
dispense.
• Ice maker has just been
installed.
• Freezer temperature is too
high.
• Dispenser panel Lock is
activated.
• Ice maker is off. • Turn on the ice maker.
• Ice may jam if the ice
dispenser is not used for a
long time (approx. 3 weeks).
• Ice bucket is not properly
inserted.
• Water line is not connected
properly or water supply is
not on.
Troubleshooting
English62
Untitled-4 62 2021-05-25 8:13:39
Page 63
Symptom Possible causes Solution
• Check if the water line is
installed correctly. Check if
the water line stop cock is
closed.
• Water line is not connected
properly or water supply is
not on.
Water does not
dispense.
• Dispenser panel Lock is
activated.
• Deactivate dispenser panel
Lock.
• Use only Samsung-provided
• A third-party water lter was
installed.
or approved lters.
• Unapproved lters may leak
and damage the refrigerator.
• Water lter indicator turns
on or blinks.
• Replace the water lter. After
replacing, reset the lter
indicator sensor.
English 63
Untitled-4 63 2021-05-25 8:13:39
Troubleshooting
Page 64
Troubleshooting
Clicking!
or Chirping!
Buzzing!
SSSRRR!
Whir!
HiSS!
Do you hear abnormal sounds from the refrigerator?
Before calling for service, review the checkpoints below. Any service calls related to
normal sounds will be charged to the user.
These sounds are normal.
• When starting or ending an operation, the refrigerator may make sounds similar to a
car engine igniting. As the operation stabilizes, the sounds will decrease.
• While the fan is operating, these sounds may occur. When the refrigerator reaches the
set temperature, no fan sound will occur.
Troubleshooting
• During a defrost cycle, water may drip on the defrost heater, causing sizzling sounds.
English64
Untitled-4 64 2021-05-25 8:13:39
Page 65
• As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing
Bubbling!
Cracking!
bubbling sounds.
• As the refrigerator temperature increases or decreases, plastic parts contract and
expand, creating knocking noises. These noises occur during the defrosting cycle or
when electronic parts are working.
• For ice maker models: When the water valve opens to ll the ice maker, buzzing sounds
may occur.
• Due to pressure equalizing when opening and closing the refrigerator door, whooshing
sounds may occur.
Troubleshooting
English 65
Untitled-4 65 2021-05-25 8:13:40
Page 66
Appendix
Safety Instruction
• For the most efcient use of energy, please keep the all inner ttings such as baskets,
drawers, shelves and ice cube tray on the position supplied by manufacturer.
• This refrigerating appliance is not intended to be used as a built-in appliance.
Install Instruction
For refrigerating appliances with climate class
Depending on the climate class, This refrigerating appliance is intended to be used at
ambient temperatures range as specied following table.
The climate class can be found on the rating plate. The product may not operate properly
at temperatures outside of the specic range.
You can nd climate class on label inside of your refrigerator
Effective temperature range
The refrigerator is designed to operate normally in the temperature range specied by its
class rating.
Class Symbol
Extended Temperate SN +10 to +32 +10 to +32
Temperate N +16 to +32 +16 to +32
Subtropical ST +16 to +38 +18 to +38
Tropical T +16 to +43 +18 to +43
NOTE
The cooling performance and power consumption of the refrigerator may be affected by
the ambient temperature, the door-opening frequency, and the location of the refrigerator.
We recommend adjusting the temperature settings as appropriate.
English66
IEC 62552 (ISO 15502) ISO 8561
Ambient Temperature range (°C)
Untitled-4 66 2021-05-25 8:13:40
Page 67
Temperature Instruction
Recommended Temperature
The optimal temperature setting for food storage:
• Fridge: 3 °C
• Freezer: -19 °C
NOTE
The optimal temperature setting of each compartment depends on the ambient
temperature. Above optimal temperature is based on the ambient temperature of 25 °C.
Power Cool
Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running
at full speed for two and a half hours and then returns to the previous temperature.
Power Freeze
Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps
running at full speed for 50 hours and then returns to the previous temperature. To freeze
large amounts of food, activate Power Freeze for at least 20 hours before putting food in
the freezer.
NOTE
When you use this function the energy consumption of the refrigerator will increase.
Remember to turn it off when you don’t need it and return the freezer to your original
temperature setting.
How to store for best preservation (applicable models only)
Cover foods to retain moisture and prevent them from picking up odors from other foods.
A large pot of food like soup or stew should be divided into small portions and put in
shallow containers before being refrigerated. A large cut of meat or whole poultry should
be divided into smaller pieces or placed in shallow containers before refrigerating.
Placement of Foods
Shelves
Specialized compartment
(applicable models only)
Untitled-4 67 2021-05-25 8:13:40
Shelves should be adjustable to accommodate a variety of
packages.
Sealed crisper drawers provide an optimal storage
environment for fruits and vegetables. Vegetables require
higher humidity conditions while fruits require lower
humidity conditions.
Crispers are equipped with controls devices to control
the humidity level. (*Depending on model and options)
An adjustable temperature meat drawer maximizes the
storage time of meats and cheeses.
English 67
Page 68
Appendix
Don’t store perishable foods in the door. Eggs should
Stored on the door
Freezer Compartment
NOTE
Freeze fresh, undamaged food only. Keep food which is to be frozen away from food
which is already frozen. To prevent food from losing its avour or drying out, place in
airtight containers.
Refrigerator & Freezer Storage Chart
The freshness longevity depends on temperature and exposure to moisture. Since product
dates aren't a guide for safe use of a product, consult this chart and follow these tips.
Milk products
Product Refrigerator Freezer
Milk 1 week 1 month
Butter 2 weeks 12 months
Ice cream - 2-3 weeks
Natural cheese 1 month 4-6 months
Cream cheese 2 weeks Not recommended
Yogurt 1 month -
be stored in the carton on a shelf. The temperature of
the storage bins in the door uctuate more than the
temperature in the cabinet. Keep the door closed as much
as possible.
You can store frozen food, make ice cubes and freeze fresh
food in the freezer compartment.
Meat
Product Refrigerator Freezer
Fresh roasts, steaks, chops 3-4 days 2-3 months
Fresh ground meat, stew
meat
Bacon 7 days 1 month
Sausage, Raw from pork,
beef, turkey
English68
Untitled-4 68 2021-05-25 8:13:40
1-2 days 3-4 months
1-2 days 1-2 months
Page 69
Poultry / Eggs
Product Refrigerator Freezer
Fresh poultry 2 days 6-8 months
Poultry salad 1 day -
Eggs, Fresh in shell 2-4 weeks Not recommended
Fish / Seafood
Product Refrigerator Freezer
Fresh sh 1-2 days 3-6 months
Cooked sh 3-4 days 1 month
Fish salad 1 day Not recommended
Dried or pickled sh 3-4 weeks -
Fruits
Product Refrigerator Freezer
Apples 1 month -
Peaches 2-3 weeks -
Pineapple 1 week -
Other fresh fruit 3-5 days 9-12 months
Vegetables
Product Refrigerator Freezer
Asparagus 2-3 days -
Broccoli, Brussels sprouts,
green peas, mushrooms
Cabbage, cauliower, celery,
cucumbers, lettuce
3-5 days -
1 week -
Carrots, beets, radishes 2 weeks -
English 69
Untitled-4 69 2021-05-25 8:13:40
Page 70
Appendix
Information for model and ordering spare parts
Model information
To access the EPREL registration of the model :
1. Go to https://eprel.ec.europa.eu
2. Get the model identier from the energy label of the product and type it in the search
box
3. Energy Labelling information of the model is shown
Part information
• The minimum period during which spare parts, necessary for the repair of the
appliance, are available
- 7 Years thermostats, temperature sensors, printed circuit boards and light sources,
door handles, door hinges, trays, baskets (boxes or drawers)
- 10 Years door gaskets
• The minimum duration of the guarantee of the refrigerating appliance offered by the
manufacturer 24 Months.
• Relevant information for ordering spare parts, directly or through other channels
provided by the manufacturer, importer or authorized representative
• You can nd professional repair information on http://samsung.com/support.
You can nd user servicing manual on http://samsung.com/support.
English70
Untitled-4 70 2021-05-25 8:13:40
Page 71
Memo
Untitled-4 71 2021-05-25 8:13:40
Page 72
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG customer care center.
Country Contact Center Web Site
UK 0333 000 0333 www.samsung.com/uk/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/za/support
DA68-04132L-04
Untitled-4 72 2021-05-25 8:13:40
Loading...
