Samsung MX-H630-ZA User Manual
MX-H630
MINI-Compact System
MP3-CD/WMA-CD/CD-R/RW Playback
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register
This Nanum Gothic Eco font is provided by NAVER.
English 3
Safety Warnings
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates “dangerous voltage” inside
the product that presents a risk of electric shock
or personal injury.
CAUTION : TO PREVENT ELECTRIC
SHOCK, MATCH THE WIDE BLADE
OF THE PLUG TO THE WIDE SLOT
IN THE WALL OUTLET, AND THEN
FULLY INSERT.
This symbol indicates important
instructions accompanying the product.
WARNING
• T
o reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
CAUTION
• Do not expose this device to dripping or splashing. Do
not place items containing liquids, such as vases, on
this device.
• To turn this device off entirely, you must disconnect its
AC plug from the wall outlet. Consequently, the plug
and AC wall outlet must be readily accessible at all
times.
• Only connect this device to an AC outlet that has a
protective grounding connection.
• To prevent electric shock, match the wide blade of the
plug to the wide slot in the wall outlet. Fully insert the
plug into the wall outlet.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LÁSER CLASE 1
CLASS 1 LASER PRODUCT
This Compact Disc player is classified as a CLASS 1
LASER product.
Use of controls, adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION
• INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED, AVOID EXPOSURE TO BEAM.
This product satisfies FCC regulations when shielded cables and connectors are used to connect the
unit to other equipment. To prevent electromagnetic interference with electric appliances, such as
radios and televisions, use shielded cables and connectors for connections.
FCC NOTE (for U.S.A)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorienting or relocating the receiving antenna.
• Increasing t
• Connecting the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consulting the dealer or an experienced radio/TV technician for help.
CAUTION : FCC regulations state that any unauthorized changes or modifications to this equipment may void
he separation between the equipment and receiver.
the user’s authority to operate it.
2 English
Important Safety Instructions
Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep
these operating instructions handy for future reference.
1.
Read th
ese instructions.
2.
Keep these Instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water.
6.
Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10.
Protect the power cord from being walked on or pinched particularly at plugs, near wall outlets, and the
point where they exit from the apparatus.
11.
Only use attachments and accessories specified by the manufacturer.
12.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13.
Unplug this apparatus during lightning storms or when unused for long periods of time.
14.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Accessories
Check for the supplied accessories below.
TUNER/AUX
FM Antenna
(AH42-00021A)
• Figures and illustrations in this User Manual are provided for reference only and may differ from actual
product appearance.
User's Manual
(AH68-02677D)
Remote Control/Batteries
(AH59-02613B/4301-000116)
English 3
English 5
Precautions
• Ensure that the AC power in your house matches the
requirements listed on the identification sticker located
on the back of your product.
• Do not place the product on amplifiers or other
equipment which may become hot. Make sure the
ventilation slots are not covered.
• Do not stack anything on top of the product.
• Before moving the product, ensure the Disc Insert Slot is
empty.
• To turn off the product completely, disconnect the AC
plug from the wall outlet. Disconnect the AC plug from
the wall outlet if you will leave the device unused
for a long period of time.
• During thunderstorms, disconnect the AC plug from
the wall outlet. Voltage peaks due to lightning could
damage the product.
• Do not expose the product to direct sunlight or other
heat sources. This could cause the product to overheat
and malfunction.
• Protect the product from moisture and excess heat and
equipment creating strong magnetic or electric fields
(i.e. speakers.).
• Disconnect the power cable from the AC wall outlet if
the product malfunctions.
• This product is for personal use only. It is not intended
for industrial use.
• Condensation may occur if your product or a disc has
been stored in cold temperatures. If transporting the
product during the winter, wait approximately 2 hours
until the product has reached room temperature before
using.
• The batteries used with this product contain chemicals
that are harmful to the environment. Do not dispose of
batteries in the general household trash.
• Maintain an open space of approximately 6 inches (15
cm) on the sides and rear of the system, for ventilation
purposes.
• Place the loudspeakers at a reasonable distance on
either side of the system to ensure good stereo sound.
• Direct the loudspeakers towards the listening area.
Cautions on Handling and Storing Discs
Small scratches on the disc may reduce sound and
picture quality or cause skipping.
Be especially careful not to scratch discs when handling
them.
Holding discs
• Do not touch the playback side of the disc.
• Hold the disc by the edges so that fingerprints will not
get on the surface.
• Do not stick paper or tape on the disc.
Disc Storage
• Do not keep in direct sunlight.
• Keep in a cool, ventilated area.
• Keep in a clean, protective jacket.
Store vertically.
• Do not allow the discs to become contaminated with
dirt.
• Do not use cracked or scratched discs.
Handling and Storing Discs
If you get fingerprints or dirt on a disc, clean it with a
mild detergent diluted in water and wipe with a soft
cloth.
• When cleaning, wipe gently from the inside to the
outside of the disc.
• Condensation may form if warm air comes into contact
with cold parts inside the product. When condensation
forms inside the product, it may not operate correctly.
If this occurs, remove the disc and let the product stand
for 1 or 2 hours with the power on.
Disc Types And Disc Format
This product does not support Secure (DRM) Media files.
CD-R Discs
• Some CD-R discs may not be playable depending on
the disc recording device (CD-Recorder or PC) and the
condition of the disc.
• Use 650MB/74 minute CD-R discs.
Do not use CD-R discs over 700MB/80 minutes as they
may not be played back.
• Some CD-RW (Rewritable) media, may not be playable.
• Only CD-Rs that are properly "closed" can be fully
played. If the session is closed but the disc is left open,
you may not be able to play the disc fully.
CD-R MP3 Discs
• Only CD-R discs with MP3 files in ISO 9660 or Joliet
format can be played.
• MP3 file names should contain no blank spaces or
special characters (for example, . = +).
• Use discs recorded with a compression/decompression
data rate greater than 128Kbps.
• Only files with the ".mp3" and ".MP3" extensions can
be played.
• Only consecutively written multisession discs can be
played. If there is a blank segment in a Multisession
disc, the disc can be played only up to the blank
segment.
• If a disc is not closed, it will take longer to begin
playback and not all of the recorded files may be
played.
• For files encoded in Variable Bit Rate (VBR) format,
i.e. files encoded in both low bit rate and high bit rate
(e.g., 32Kbps ~ 320Kbps), the sound may skip during
playback.
• A maximum of 999 tracks can be played per CD.
• Supported audio formats: WMA 56 ~128kbps Bit Rate.
4 English
Contents
Thank you for buying this SAMSUNG mini-compact system.
Please take time to read these instructions.
They will allow you how to operate your system and take full advantage of its features.
Safety Warnings .................................... 2
Important Safety Instructions ................ 3
Accessories ........................................... 3
Precautions ........................................... 4
Cautions on Handling and
Storing Discs .........................................4
Disc Types And Disc Format ................... 4
Contents............................................... 5
Description ...........................................6
Front Panel ...................................... 6
Rear Panel ....................................... 7
Remote Control ............................... 8
Display Function ................................... 8
CD/MP3/WMA-CD Playback ................. 9
Selecting a Track ................................... 9
Searching for a Specific Music
Passage on a CD ................................... 9
Repeat One or All Tracks on a
Compact Disc ....................................... 9
10 Skip Function ................................. 10
CD Programming ................................ 10
Checking or Editing the
Programmed Tracks ............................ 10
Auto Change Function........................ 10
Playing a USB Device ........................... 11
To Select a Track from
a USB Device .................................11
To Search a Folder Quickly .............. 11
To Use High Speed Search .............. 11
To Repeat ...................................... 11
To Delete a File .............................. 11
To Skip 10 Tracks ........................... 11
Using Bluetooth .................................. 12
Setting the Clock ................................ 13
Timer Function .................................... 13
Cancelling the Timer ...........................14
Listening to Radio ............................... 14
Selecting a Stored Station ................... 14
Recording Function............................. 15
Recording Speed ................................15
Selecting EQ Mode .............................16
Selecting LOCAL EQ Mode ................. 16
Using the FOOTBALL MODE ............... 16
GIGA SOUND Function ....................... 16
Connecting a Microphone .................. 16
Troubleshooting ................................. 17
Specifications...................................... 18
Symbols
Important
Note
English 5
English 7
Description
Front Panel
1
2
3
4
5
6
7
8
9
10
11
1.
POWER button
• Press this button to switch your minicompact system on and off.
2.
AUTO CHANGE button
3.
EQ button
4.
Window Display
5.
Search/Skip button
6.
STOP/Tuning Mode button
7.
USB/BLUETOOTH button
8.
MP3/CD button
9.
TUNER/AUX button
10.
MIC jack
11.
Disc Tray
12.
USB jack
13.
USB REC button
14.
DELETE button
15.
OPEN/CLOSE button
16.
PLAY/PAUSE button
17.
Search/Skip button
18.
VOLUME Control
19.
LOCAL EQ button
20.
FOOTBALL MODE button
21.
GIGA SOUND BLAST button
21
20
19
18
17
16
15
14
13
12
6 English
Loading...
