Samsung DC43H, DC49H, DC55H, DC43J, DC49J User Guide

User Manual

DCH (DC43H DC49H DC55H) DCJ (DC43J DC49J)

The colour and the appearance may differ depending on the product, and the specications

are subject to change without prior notice to improve the performance. Recommended hours of use per day of this product is under 16 hours. If the product is used for longer than 16 hours a day, the warranty may be void.

Table of contents

Before Using the Product

Safety Precautions 7

Cleaning 7 Storage 8 Electricity and Safety 8 Installation 9 Operation 11

Preparations

Checking the Components 14

Components 14

Parts 15

Control Panel 15 Reverse Side 18 Anti-theft Lock 20 Remote Control 21

Before Installing the Product (Installation Guide) 23

Ventilation 23

Installing the Wall Mount 24

Installing the Wall Mount Kit 24 Wall Mount Kit Specifications (VESA) 24

Remote Control (RS232C) 25

Cable Connection 25 Connection 28

Control Codes 29

Connecting and Using a Source Device

Before Connecting 38

Pre-connection Checkpoints 38

Connecting to a PC 38

Connection using the DVI-RGB Cable 38 Connection using a DVI Cable (Digital type) 39 Connection Using an HDMI-DVI Cable 39 Connection Using an HDMI Cable 40

Connecting to a Video Device 41

Connection Using the AV Cable 41 Connection Using the component Cable 41 Connection Using an HDMI-DVI Cable 42 Connection Using an HDMI Cable 43

Connecting to an Audio System 43

Connecting the LAN Cable 44

Attaching the Network box (Sold separately) 45

Connecting the Network box (Sold separately) 4

MagicInfo 46

Changing the Input source 48

Source 48

Using MDC

MDC Programme Installation/Uninstallation 49

Installation 49 Uninstallation 49

Connecting to MDC 50

Using MDC via Ethernet 50

Screen Adjustment

Picture Mode 51

If the input source is PC, DVI(PC), HDMI(PC) 51 If the input source is AV, Component, DVI(AV),

HDMI(AV

Backlight / Contrast / Brightness / Sharpness / Colour / Tint (G/R)

Gamma 52

Calibrated value 53

Picture Size 54

Picture Size 54 Position 55

Zoom/Position 55 Resolution Select 56

Auto Adjustment 56

PC Screen Adjustment 57

PIP 58

) 51

Table of contents

Advanced Settings 59

Dynamic Contrast 60 Black Tone 60 Flesh Tone 60 RGB Only Mode 60 Colour Space 60 White Balance 61 Motion Lighting 61

Picture Options 62

Colour Tone 63 Colour Temp. 63 Digital Clean View 63 MPEG Noise Filter 63 HDMI Black Level 64 Film Mode 64 Dynamic Backlight 64

Picture Off 65

Reset Picture 65

Sound Adjustment

Speaker Select 69 Auto Volume 69

Reset Sound 70

Network

Network Status 71

Network Settings 71

Network type 71 Network Settings (Wired) 72

AllShare Settings 74

Content Sharing 74

Server Network Settings 74

Connect to server 74 Server Access 74 FTP Mode 74

Device Name 75

USB 77 Network Channel 78

System

Setup 80

Menu Language 81

Multi Control 81

Configuring settings for Multi Control 81

Time 82

Clock Set 82 Sleep Timer 82 On Timer 82 Off Timer 83 Holiday Management 83

Eco Solution 84

Energy Saving 84 Eco Sensor 84 No Signal Power Off 84 Auto Power Off 84

Sound Mode 66

HDMI Sound 67

Sound Effect 68

DTS TruSurround HD 68 DTS TruDialog 68 Equaliser 68

Speaker Settings 69

Applications

Source List 76

Refresh 76 Edit Name 76 Information 76

MagicInfo Lite 77

Playing content from the internal memory or

Auto Protection Time 85

Screen Burn Protection 86

Pixel Shift 86 Timer 87 Immediate display 88 Side Grey 88

Ticker 89

Table of contents

Video Wall 90

Video Wall 90 Format 90 Horizontal 90 Vertical 91 Screen Position 91

Source AutoSwitch Settings 92

Source AutoSwitch 92 Primary Source Recovery 92 Primary Source 92 Secondary Source 93

Change PIN 94

General 95

Max. Power Saving 95 Game Mode 95 Auto Power On 95 Safety Lock 95 Button Lock 96 Standby Control 96 Network Standby 96 Lamp Schedule 97 OSD Display 98 Power On Adjustment 98 Temperature Control 98 Power Button 98

Anynet+ (HDMI-CEC) 99

Anynet+ (HDMI-CEC) 99 Auto Turn Off

100 Troubleshooting for Anynet+ 101

Clone Product 103

DVI Connection 103

Reset System 104

Reset All 104

PC module power 105

Synced power-on 105 Synced power-off 105

Support

Software Update 106

Update now 106

Contact Samsung 106

Playing photos, videos and music (Media Play)

Read the following before using media play with a USB device 107

Using a USB device 109 Menu items in the media content list page 110

Available buttons and features during photo playback 111

Available buttons and features during video playback 112

Available buttons and features during music playback 113

Supported Subtitle and Media play file formats 114

Subtitle 114 Compatible image file format 114 Supported music file formats 115 Supported Video Formats 115

Troubleshooting Guide

Requirements Before Contacting Samsung Customer Service Centre 118

Testing the Product 118 Checking the Resolution and Frequency 118 Check the followings. 119

Q & A 125

Specifications

General 126

Preset Timing Modes 128

Appendix

Responsibility for the Pay Service (Cost to Customers) 130

Table of contents

Not a product defect 130 A Product damage caused by customer's

fault 130 Others 130

Prevention of Afterimage Burn-in 131

What is afterimage burn-in? 131 Recommended prevention practices 131

Licence 132

Terminology 133

Chapter 01

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

• An administration fee may be charged if either – (a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

– (b) you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual).

• The amount of such administration charge will be advised to you before any work or home visit is carried

out.

Safety Precautions

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Cleaning

―

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―

Take the following steps when cleaning.

―

The following images are for reference only. Real-life situations may differ from what is shown in the images.

Power off the product and computer.

Disconnect the power cord from the product.

―

Hold the power cable by the plug and do not touch the cable with wet hands. Otherwise, an electric shock may result.

Wipe the product with a clean, soft and dry cloth.

Instructions marked by this symbol must be followed.

• Do not use detergents that contain alcohol, solvent or surface-active agents.

• Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean

the exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Storage

Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white-coloured stains on the product.

―

Contact Customer Service Centre if the inside of the product needs cleaning (service fee will be charged).

Electricity and Safety

―

The following images are for reference only. Real-life situations may differ from what is shown in the images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

• An electric shock or fire may result.

Do not use multiple products with a single power socket.

• Overheated power sockets may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated devices only).

• An electric shock or injury may result.

Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy object.

• Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

• A fire or electric shock may result.

Clean any dust around the pins of the power plug or the power socket with a dry cloth.

• A fire may result.

Do not touch the power plug with wet hands. Otherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

• An unsecure connection may cause a fire.

Caution

Do not disconnect the power cord while the product is being used.

• The product may become damaged by an electric shock.

Only use the power cord provided with your product by Samsung. Do not use the power cord with other products.

• A fire or electric shock may result.

Keep the power socket where the power cord is connected unobstructed.

• The power cord must be disconnected to cut off power to the product when an issue occurs.

• Note that the product is not completely powered down by using only the power button on the remote.

Hold the plug when disconnecting the power cord from the power socket.

• An electric shock or fire may result.

Installation

Warning

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

• A fire may result.

Have a technician install the wall-mount hanger.

• Installation by an unqualified person can result in an injury.

• Only use approved cabinets.

Do not install the product in poorly ventilated spaces such as a bookcase or closet.

• An increased internal temperature may cause a fire.

Install the product at least 10cm away from the wall to allow ventilation.

• An increased internal temperature may cause a fire.

Keep the plastic packaging out of the reach of children.

• Children may suffocate.

Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.)

• The product may fall and become damaged and/or cause an injury.

Caution

Do not drop the product while moving.

• Product failure or personal injury may result.

• Using the product in an area with excess vibration may damage the product or cause a fire.

Do not install the product in a vehicle or a place exposed to dust, moisture (water drips, etc.), oil, or smoke.

• A fire or electric shock may result.

Do not set down the product on its front.

• The screen may become damaged.

Do not expose the product to direct sunlight, heat, or a hot object such as a stove.

• The product lifespan may be reduced or a fire may result.

Do not install the product within the reach of young children.

• The product may fall and injure children.

• As the front is heavy, install the product on a flat and stable surface.

Edible oil, such as soybean oil, can damage or deform the product. Do not install the product in a kitchen or near a kitchen counter.

When installing the product on a cabinet or shelf, make sure that the bottom edge of the front of the product is not protruding.

• The product may fall and become damaged and/or cause an injury.

• Install the product only on cabinets or shelves of the right size.

Set down the product gently.

• Product failure or personal injury may result.

Installing the product in an unusual place (a place exposed to a lot of fine dust, chemical substances, extreme temperatures or a significant presence of moisture, or a place where the product will operate

SAMSUNG

continuously for an extended period of time) may seriously affect its performance.

• Be sure to consult Samsung Customer Service Centre if you want to install the product at such a place.

Operation

Warning

Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the product.

• The product or heavy objects may fall as children try to reach for the toys or sweets resulting in a serious injury.

There is a high voltage inside the product. Never disassemble, repair or modify the product yourself.

• A fire or electric shock may result.

• Contact Samsung Customer Service Centre for repairs.

Before moving the product, turn off the power switch and disconnect the power cable and all other connected cables.

• Damage to the cord may result in a fire or electric shock.

If the product generates abnormal sounds, a burning smell or smoke, disconnect the power cord immediately and contact Samsung Customer Service Centre.

• An electric shock or fire may result.

Do not let children hang from the product or climb on top of it.

• Children may become injured or seriously harmed.

If the product is dropped or the outer case is damaged, turn off the power switch and disconnect the power cord. Then contact Samsung Customer Service Centre.

• Continued use can result in a fire or electric shock.

GAS

During a lightning or thunderstorm, power off the product and remove the power cable.

• A fire or electric shock may result.

Do not drop objects on the product or apply impact.

• A fire or electric shock may result.

Do not move the product by pulling the power cord or any cable.

• Product failure, an electric shock or fire may result from a damaged cable.

If a gas leakage is found, do not touch the product or power plug. Also, ventilate the area immediately.

• Sparks can cause an explosion or fire.

Do not lift or move the product by pulling the power cord or any cable.

• Product failure, an electric shock or fire may result from a damaged cable.

Do not use or keep combustible spray or an inflammable substance near the product.

• An explosion or fire may result.

Ensure the vents are not blocked by tablecloths or curtains.

• An increased internal temperature may cause a fire.

100

Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn easily (paper, matches, etc) into the product (via the vent or input/output ports, etc).

• Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product. Then contact Samsung Customer Service Centre.

• Product failure, an electric shock or fire may result.

Caution

-_-

Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels.

• Activate power-saving mode or a moving-picture screen saver if you will not be using the product for an extended period of time.

Disconnect the power cord from the power socket if you do not plan on using the product for an extended period of time (vacation, etc).

• Dust accumulation combined with heat can cause a fire, electric shock or electric leakage.

Use the product at the recommended resolution and frequency.

• Your eyesight may deteriorate.

Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the product.

• Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product. Then contact Samsung Customer Service Centre.

• Product failure, an electric shock or fire may result.

Do not hold the product upside-down or move it by holding the stand.

• The product may fall and become damaged or cause an injury.

Looking at the screen too close for an extended period of time can deteriorate your eyesight.

Do not use humidifiers or stoves around the product.

• A fire or electric shock may result.

Rest your eyes for more than 5 minutes for every 1 hour of product use.

• Eye fatigue will be relieved.

Be careful that children do not place the battery in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach.

• If children have had the battery in their mouths, consult your doctor immediately.

Do not touch the screen when the product has been turned on for an extended period of time as it will become hot.

Store small accessories out of the reach of children.

Exercise caution when adjusting the product angle or stand height.

• Your hand or finger may get stuck and injured.

• Tilting the product at an excessive angle may cause the product

to fall and an injury may result.

Do not place heavy objects on the product.

• Product failure or personal injury may result.

When using headphones or earphones, do not turn the volume too high.

• Having the sound too loud may damage your hearing.

When replacing the battery, insert it with the right polarity (+, -).

• Otherwise, the battery may become damaged or it may cause fire, personal injury or damage due to leakage of the internal liquid.

Use only the specified standardised batteries, and do not use a new battery and a used battery at the same time.

• Otherwise, the batteries may be damaged or cause fire, personal injury or damage due to a leakage of the internal liquid.

The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling.

• The customer can return used or rechargeable batteries to a nearby public recycling centre or to a store selling the same type of the battery or rechargeable battery.

Chapter 02

Preparations

Checking the Components

– Contact the vendor where you

purchased the product if any components are missing.

– The pictures may look different from

the actual components.

– A stand is not provided with the

product. To install a stand, you can purchase one separately.

– The RS232C adapter can be used to

connect to another monitor using the D-SUB (9-pin) type RS232C cable.

Components

Quick Setup Guide

Batteries

(Not available in some locations)

Warranty card

(Not available in some locations)

Remote Control RS232C(IN) adapter

Regulatory guide Power cord

Parts

―

The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.

Control Panel

DCH

Speaker

Remote sensor & Panel Key

DCH

Spacer logo

Power on

Power off

Select source

Spacer logo (optional)

Remote sensor

Press and hold for three seconds.

Press the panel key. A popup menu appears.

Make sure Power off is selected and then, press and hold the panel key until the display turns off.

Press the panel key. A popup menu appears.

Press the panel key again to select Source. Then, press and hold the panel key to cycle through the desired source.

Do not pull on the spacer logo using force. The logo may tear or break off.

Press a button on the remote control pointing at the remote sensor on the product to perform the corresponding function.

―

Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.

Use the remote control within 7 m to 10 m from the sensor on the product at an angle of 30° from the left and right.

The product’s screen also works as a remote sensor.

When pointing the remote control at the screen, make sure:

• the remote control is pointing towards the center of the screen.

• to use the remote control 40 cm to 70 cm away from the screen.

―

Store used batteries out of reach of children and recycle.

―

Do not use a new and used battery together. Replace both batteries at the same time.

―

Remove batteries when the remote control is not to be used for an extended period of time.

Remote sensor

• To use the panel key, make sure the sliding panel key is not protruding from the bottom of the product.

• To use remote/eco sensor, make sure the sliding panel key is protruding from the bottom of the product.

Control Panel

―

The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.

DCJ

Speaker

Remote sensor & Panel Key

DCJ

Press a button on the remote control pointing at the bottom of the product face to perform the function. The remote control sensor is located on the bottom of the

Remote sensor

Use the remote control within 7 m to 10 m from the sensor on the product at an angle of 30° from the left and right.

―

Store used batteries out of reach of children and recycle.

―

Do not use a new and used battery together. Replace both batteries at the same time.

―

Remove batteries when the remote control is not to be used for an extended period of time.

product.

―

Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.

Remote sensor

―

The panel key is located on the bottom right front of the product.

―

If you press the P button on the panel key when the product is turned on, the control menu will be displayed.

Control menu

Buttons Description

Power off the product.

Power off

With the control menu screen displayed, briefly press the panel key to move the cursor to Power off

the product.

, and then press and hold the panel key to turn off

Power off

Press: Move

Press & Hold: Select

Select the connected input source.

With the control menu screen displayed, briefly press the panel key to move

Source

―

The panel key can only be used for Power off and Source.

―

To exit from the control menu screen, wait for 3 seconds or more without pressing the panel key.

the cursor to Source input source screen.

With the input source screen displayed, press and hold the panel key to switch to the desired input source.

, and then press and hold the panel key to display the

Reverse Side

Port Description

―

The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.

DCH

AUDIO OUT

RS232C IN

AUDIO IN

HDMI 1, HDMI 2

DVI/PC/MAGICINFO IN

USB ¨ (1.0A)

AV IN / COMPONENT IN

RJ45

Connects to the audio of a source device.

Connects to MDC using an RS232C adapter.

Receives sound from a PC via an audio cable.

Connects to a source device using a HDMI cable or HDMI-DVI cable.

DVI: Connects to a source device using a DVI cable or HDMI-DVI cable. PC: Connects a D-SUB cable (via a DVI-RGB adapter) or a DVI-RGB cable to a PC. MAGICINFO IN: Use the (dedicated) DP-DVI cable when connecting a network box (sold

separately).

Connect to a USB memory device.

―

The USB ports on the product accept a maximum constant current of 1.0A. If the maximum value is exceeded, USB ports may not work.

Connects to a source device using the AV/Component adapter.

Connects to MDC using a LAN cable. (10/100 Mbps)

Reverse Side

Port Description

―

The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.

DCJ

USB ¨(1.0A)

HDMI IN 1

HDMI IN 2

DVI/MAGICINFO IN

RS232C IN

AV/COMPONENT IN

RJ45

DVI/HDMI/AUDIO IN

AUDIO OUT

Connect to a USB memory device.

―

The USB ports on the product accept a maximum constant current of

1.0A. If the maximum value is exceeded, USB ports may not work.

Connects to a source device using a HDMI cable or HDMI-DVI cable.

DVI: Connects to a source device using a DVI cable or HDMI-DVI cable. MAGICINFO IN: To use MagicInfo, make sure to connect the DP-DVI cable.

Connects to MDC using an RS232C adapter.

Connects to a source device using the AV/Component adapter.

Connects to MDC using a LAN cable. (10/100 Mbps)

Receives sound from a PC via an audio cable.

Connects to the audio of a source device.

Anti-theft Lock

―

An anti-theft lock allows you to use the product securely even in public places.

―

The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details.

―

The following images are for reference only. Real-life situations may differ from what is shown in the images.

To lock an anti-theft locking device:

―

Stand: Sold separately

DCH DCJ

Fix the cable of your anti-theft locking device to a heavy object such as a desk.

Put one end of the cable through the loop on the other end.

Insert the locking device into the anti-theft lock slot at the back of the product.

Lock the locking device.

– An anti-theft locking device can be purchased separately. – Refer to the user guide provided with your anti-theft locking device for details. – Anti-theft locking devices can be purchased at electronics retailers or online.

Remote Control

―

Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.

―

A button without a description in the image below is not supported on the product.

Power on the product.

Adjust the volume.

Change the input source.

Display or hide the onscreen display menu, or

return to the previous menu.

Power off the product.

Number buttons

Enter the password in the OSD menu.

– Remote control button functions

may differ for different products.

Mute the sound.

Unmuting the sound: Press MUTE again or press the volume control(+ VOL -) button.

Use this hotkey to directly access MagicInfo

Lite.

This hotkey is available when a network box or PIM (Plug In Module) is connected.

MagicInfo Lite launch Button.

Quickly select frequently used functions.

Display information about the current input source.

Move to the upper, lower, left or right menu, or adjust an option's setting.

Confirm a menu selection.

Return to the previous menu.

It sets safe lock function.

Used in Anynet+ mode and multimedia mode.

To place batteries in the remote control

Exit the current menu.

Manually select a connected input source from PC, DVI, HDMI1, HDMI2.

– Remote control button functions

may differ for different products.

Before Installing the Product (Installation Guide)

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.

• Ensure that an authorized installation company installs the wall mount.

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Ventilation

―

Contact Samsung Customer Service Centre for further details.

Installation on a Perpendicular Wall

A Minimum 40 mm

B Ambient temperature: Under 35 °C

―

When installing the product on a perpendicular wall, allow at least 40 mm of space between the product and wall surface for ventilation and ensure that the ambient A temperature is kept below 35 °C.

Installation on an Indented Wall

A Minimum 40 mm

B Minimum 70 mm

C Minimum 50 mm

D Minimum 50 mm

E Ambient temperature: Under 35 °C

―

When installing the product on an indented wall, allow at least the space specified above between the product and wall for ventilation and ensure that the ambient temperature is kept below 35 °C.

Installing the Wall Mount

Installing the Wall Mount Kit

The wall mount kit (sold separately) allows you to mount the product on the wall.

For detailed information on installing the wall mount, see the instructions provided with the wall mount.

We recommend you contact a technician for assistance when installing the wall mount bracket.

Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own.

Wall Mount Kit Specications (VESA)

―

Install your wall mount on a solid wall perpendicular to the floor. Before attaching the wall mount to surfaces other than plaster board, please contact your nearest dealer for additional information.

If you install the product on a slanted wall, it may fall and result in severe personal injury.

• Samsung wall mount kits contain a detailed installation manual and all parts necessary for assembly are provided.

• Do not use screws that are longer than the standard length or do not comply with the VESA standard screw specifications. Screws that are too long may cause damage to the inside of the product.

• For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ depending on the wall mount specifications.

• Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents.

• Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.

• Always have two people mount the product on a wall.

• Standard dimensions for wall mount kits are shown in the table below.

Model name VESA screw hole specs (A * B)

Standard Screw Quantity

in millimetres (inches)

DC43H / DC43J / DC49J

DC49H / DC55H

―

Do not install your Wall Mount Kit while your product is turned on. It may result in personal injury due to electric shock.

―

If you want to use a wall mount, make sure that it allows you to remove the product from it without using any additional tool. (Supported models: DCJ)

200 x 200 (7,9 x 7,9) M8 4

400 x 400 (15,8 x 15,8)

Remote Control (RS232C)

• Pin assignment

Cable Connection

RS232C Cable

Interface

Bit rate

Data bits

Parity

Stop bit

Flow control

Maximum length

RS232C (9 pins)

TxD (No.2), RxD (No.3), GND (No.5)

9600 bps

8 bit

None

1 bit

None

15 m (only shielded type)

1 2 3 4 5

6 7 8 9

Pin Signal

Detect data carrier

Received data

Transmitted data

Prepare data terminal

Signal ground

5 4 3 2 1

9 8 7 6

Prepare data set

Send request

Clear to send

Ring indicator

• RS232C cable Connector: 9-Pin D-Sub to Stereo Cable

-P1-

-P1- -P1- -P2- -P2-

3 2

-P2-

LAN Cable

• Pin assignment

1 2 3 4 5 6 7 8

Male type Rx

Gnd

----------

Gnd

STEREO

PLUG

(3.5ø)

Pin No Standard Colour Signal

1 White and orange TX+

2 Orange TX-

3 White and green RX+

4 Blue NC

5 White and blue NC

6 Green RX-

7 White and brown NC

8 Brown NC

• Connector : RJ45

Direct LAN cable (PC to HUB)

Cross LAN cable (PC to PC)

HUB

RJ45

Signal

TX+ 1

TX- 2

RX+ 3

RX- 6

P1P2

P1 P2 Signal

↔

1 TX+

2 TX-

3 RX+

6 RX-

RJ45

Signal

TX+ 1

TX- 2

RX+ 3

RX- 6

P1 P2

P1 P2 Signal

↔

3 RX+

6 RX-

1 TX+

2 TX-

Connection

• Connection 1

RJ45 RJ45

• Connection 2

―

Ensure that you connect the RS232C(IN) adapter to the RS232C IN port on the product.

RS232C

Control Codes

No. Command type Command Value range

Viewing control state (Get control command)

Header Command ID Data length Checksum

0xAA Command type 0

Controlling (Set control command)

Header Command ID Data length Data Checksum

0xAA Command type 1 Value

Command

No. Command type Command Value range

Power control 0x11 0~1

Volume control 0x12 0~100

Input source control 0x14 -

• All communications take place in hexadecimals. The checksum is calculated by adding up all values except the header. If a checksum adds up to be more than 2 digits as shown below (11+FF+01+01=112), the first digit is removed.

E.g. Power On & ID=0

Header Command ID Data length Data 1 Checksum

0xAA 0x11 1 "Power"

Header Command ID Data length Data 1 12

0xAA 0x11 1 1

• To control all devices connected by a serial cable simultaneously irrespective of IDs, set the ID as "0xFE" and transmit commands. Commands will be executed by each device but ACK will not respond.

Video Wall On 0x84 0~1

Video Wall User Control 0x89 -

Screen mode control 0x18 -

Screen size control 0x19 0~255

PIP on/off control 0x3C 0~1

Auto adjustment control (PC and BNC only)

Video wall mode control 0x5C 0~1

Safety Lock 0x5D 0~1

0x3D 0

Power control

Volume control

• Function A product can be powered on and off using a PC.

• Viewing power state (Get Power ON / OFF Status)

Header Command ID Data length Checksum

0xAA 0x11 0

• Setting power ON/Off (Set Power ON / OFF)

Header Command ID Data length Data Checksum

0xAA 0x11 1 "Power"

"Power": Power code to be set on a product.

1: Power ON

0: Power OFF

• Ack

Header Command ID Data length Ack/Nak r-CMD Val1 Checksum

0xAA 0xFF 3 'A' 0x11 "Power"

"Power": Power code to be set on a product.

• Nak

Header Command ID Data length Ack/Nak r-CMD Val1 Checksum

• Function The volume of a product can be adjusted using a PC.

• Viewing volume state (Get Volume Status)

Header Command ID Data length Checksum

0xAA 0x12 0

• Setting the volume (Set Volume)

Header Command ID Data length Data Checksum

0xAA 0x12 1 "Volume"

"Volume": Volume value code to be set on a product. (0-100)

• Ack

Header Command ID Data length Ack/Nak r-CMD Val1 Checksum

0xAA 0xFF 3 'A' 0x12 "Volume"

"Volume": Volume value code to be set on a product. (0-100)

• Nak

Header Command ID Data length Ack/Nak r-CMD Val1 Checksum

0xAA 0xFF 3 'N' 0x12 "ERR"

0xAA 0xFF 3 'N' 0x11 "ERR"

"ERR" : A code showing what error has occurred.

+ 103 hidden pages
