BD-HDD Combo

user manual

BD-D8200M BD-D8500M

imagine the possibilities

Thank you for purchasing this Samsung product. To receive a more complete service, please register your product at

www.samsung.com/register

Key features

Blu-ray™ Disc Features

Blu-ray Discs support the highest quality HD video available in the industry - Large capacity means no compromise on video quality.

The following Blu-ray Disc features are disc dependant and will vary. Appearance and navigation of features will also vary from disc to disc. Not all discs will have the features described below.

For High-Definition Playback

To view high-definition contents on a Blu-ray Disc, you need an HDTV (High Definition Television). Some Blu-ray Discs may require you to use the product’s HDMI OUT to view high-definition content. The ability to view high-definition content on Blu-ray Discs may be limited depending on the resolution of your TV.

BD-LIVE

You can use a Blu-ray Disc that supports BD-LIVE to download content provided by the disc manufacturer through a network connection.

BD-HDD Combo Features

This product can play 3D contents through an HDMI cable.

To implement the 3D effect, connect a 3D device (3D-compliant AV receiver, 3D-compliant TV) to the product using an HDMI cable, and play the 3D content while wearing 3D vision glasses.

3D Conversion

When you play 2D contents, you can convert 2D into 3D contents by pressing the 2D3D button on the remote control.

Smart Hub

You can download various for pay or freeof-charge applications through a network connection. These applications provide a range of Internet services and content including news, weather forecasts, stock market quotes, games, movies, and music.

AllShare

You can play videos, music, and photos saved on your devices (such as your PC, mobile phones, or NAS) through a network connection.

Playing multimedia files

You can use the USB connection to play various kinds of multimedia files (MP3, JPEG, DivX, etc.) located from a USB storage device.

Digital TV

• This product have dual DTV Tuner. So user can change DTV Programme during recording a programme. As the benefit of dual tuner eliminates the unconvinience of retaining channel when you want to record it.

• Functionalities related to Digital TV (DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC) digital terrestrial signals are broadcasted or where you are able to access to a compatible DVB-C (MPEG2 and MPEG4 AAC) cable-TV service. Please check with your local dealer the possibility to receive DVB-T or DVB-C signal.

• DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and DVB-C is that for the broadcast transmission of digital TV over cable. However, some differentiated features like EPG (Electric Programme Guide), VOD (Video On Demand) and so on, are not included in this specification. So, they cannot be workable at this moment.

• Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with some cable service providers.

• This product can record TV channel in HDD or external devices.

2 English

Safety Information

Warning

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates “dangerous voltage” inside the product that presents a risk of electric shock or personal injury.

Do not install this equipment in a confined space such as a bookcase or similar unit.

WARNING

To prevent damage which may result in fire or electric shock hazard, do not expose this appliance to rain or moisture.

CAUTION

BD-HDD Combo USES AN INVISIBLE LASER BEAM WHICH CAN CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE BD-HDD Combo CORRECTLY AS INSTRUCTED.

CAUTION

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

This product satisfies CE regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances, such as radios and televisions, use shielded cables and connectors for connections.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates important instructions accompanying the product.

IMPORTANT NOTE

The mains lead on this equipment is supplied with a molded plug incorporating a fuse. The value of the fuse is indicated on the pin face of the plug. If it requires replacing, a fuse approved to BS1362 of the same rating must be used.

Never use the plug with the fuse cover omitted if the cover is detachable. If a replacement fuse cover is required, it must be of the same colour as the pin face of the plug. Replacement covers are available from your dealer.

If the fitted plug is not suitable for the power points in your house or the cable is not long enough to reach a power point, you should obtain a suitable safety approved extension lead or consult your dealer for assistance.

However, if there is no alternative to cutting off the plug, remove the fuse and then safely dispose of the plug. Do not connect the plug to a mains jack, as there is a risk of shock hazard from the bared flexible cord.

To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug shall be readily operable.

The product unit accompanying this user manual is licenced under certain intellectual property rights of certain third parties.

02 Safety Information

English 3

Safety Information

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a CLASS 1 LASER product. Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

CAUTION :

• CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO THE BEAM (IEC 60825-1)

• THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVER AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LÁSER CLASE 1

Precautions

Important Safety Instructions

Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings.

Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such

as radiators, heat registers, stoves, or other apparatus (including AV Receivers) that produce heat.

9. Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on

or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified

by the manufacturer.

12. Use only with the cart,

stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms

or when unused for long periods of time.

14. Refer all servicing to qualified service

personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

4 English

Viewing using 3D function

Disc Storage & Management

02 Safety Information

IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D PICTURES. Read and understand the following safety information before using the 3D function.

• Some viewers may experience discomfort while viewing 3D TV such as dizziness, nausea, and headaches. If you experience any such symptom, stop viewing 3D TV, remove the 3D Active Glasses, and rest.

• Watching 3D images for an extended period of time may cause eye strain. If you feel eye strain, stop viewing 3D TV, remove your 3D Active Glasses, and rest.

• A responsible adult should frequently check on children who are using the 3D function. If there are any reports of tired eyes, headaches, dizziness, or nausea, have the child stop viewing 3D TV and rest.

• Do not use the 3D Active Glasses for other purposes (such as general eyeglasses, sunglasses, protective goggles, etc.)

• Do not use the 3D function or 3D Active Glasses while walking or moving around. Using the 3D function or 3D Active Glasses while moving around may cause you to bump into objects, trip, and/or fall, and cause serious injury.

• When displaying 3D programme with this model, the actual screen may appear as shown below:

Screen Display Description

Side by Side

Top & Bottom

• 3D programme reception, recording and playback of this model may not fully support 3D, due to the 3D broadcast format is not yet standardized worldwide. It is not the product’s malfunction or disorder.

Same screen duplicates horizontally.

Same screen duplicates vertically.

Disc Handling

Disc Shape

• Use discs with regular shapes. If you use an irregular disc (a disc with a special shape), you can damage the product.

Holding discs

• Avoid touching the surface of a disc where data has been recorded.

Blu-ray Discs

• Do not leave a Blu-ray Disc in the product for long periods of time. Remove the Blu-ray Disc from the product and store it in its case.

• Be careful not to scratch or leave fingerprints on the surface of the Blu-ray Disc.

DVD-VIDEO, Audio CD (CD-DA)

• Wipe off dirt or contamination on the disc with a soft cloth.

Disc Storage

Be careful not to damage the disc because the data on these discs is highly vulnerable to the environment.

• Do not keep under direct sunlight.

• Keep in a cool ventilated area.

• Store vertically.

• Keep in a clean protection jacket.

• If you move your product suddenly from a cold

place to a warm place, condensation may occur on the operating parts and lens and cause abnormal disc playback. If this occurs, unplug the product, wait for two hours, and then connect the plug to the power outlet. Then, insert the disc, and try to play back again.

English 5

Safety Information

HDD (Hard Disk Drive)

The hard disk has a high storage density, which enables long recording durations and quick access to written data. However, it can easily be damaged by shock, vibration or dust and should be kept away from magnets. To avoid losing important data, observe the following precautions.

• Do not use the BD-HDD Combo in a place subject to extreme changes in temperature.

• Do not apply a strong shock to the BD-HDD Combo.

• Do not place the BD-HDD Combo in a location subject to mechanical vibrations or in an unstable location.

• Do not place the BD-HDD Combo on top of a heat source.

• Do not disconnect the AC power cord while the power is on.

• Do not attempt to change the hard disk. This may result in a malfunction.

Should the hard disk be damaged, you cannot recover lost data. The hard disk is only a temporary storage space.

Handling Cautions

• Do not write on the printed side with a ball-point pen or pencil.

• Do not use record cleaning sprays or antistatic sprays to clean discs. Also, do not use volatile chemicals, such as benzene or thinner.

• Do not apply labels or stickers to discs. (Do not use discs fixed with exposed tape adhesive or leftover peeled-off stickers.)

• Do not use scratch-proof protectors or covers.

• Do not use discs printed with label printers

available on the market.

• Do not load warped or cracked discs.

• Before connecting other components to this

product, be sure to turn them off.

• Do not move the product while it is playing a disc. The disc can be scratched or damaged and the product’s internal parts can be damaged.

• Do not put a flower vase filled with water or any small metal objects on the product.

• Be careful not to put your hand into the disc slot.

• Do not place anything other than the disc in the disc slot.

• Interference from exterior sources such as lightening and static electricity can affect the normal operation of this product. If this occurs, turn the product off and on again with the POWER button, or disconnect and then reconnect the AC power cord to the AC power outlet. The product will operate normally.

• Be sure to remove the disc and turn off the product after use.

• Disconnect the AC power cord from the AC outlet when you don’t intend to use the product for long periods of time.

• To clean a disc, wipe it in a straight line from the inside to the outside of the disc.

• Do not expose the product to any liquid.

• When the AC plug is connected to a wall outlet, the product will still draw power (standby mode) when it is turned off.

• Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

• The main plug is used as a disconnect device and shall stay readily operable at any time.

• Do not touch the power plug with a wet hand. Otherwise, it can cause an electric shock.

• Do not share one power socket with multiple electric devices. Otherwise, it may cause an overheat, resulting in a fire.

• If you encounter an abnormal noise, burning smell or smoke, turn off the power switch immediately and disconnect the power plug from the wall outlet. Then, contact the nearest customer centre for technical assistance. If you still use the product as it is, this may cause an electric shock or fire.

6 English

Maintenance of Cabinet

Before you clean the Blu-ray Disc’s cabinet, be sure to disconnect the AC power cord from the AC outlet.

• Do not use benzene, thinner, or other solvents for cleaning.

• Wipe the cabinet with a soft cloth.

Restrictions on Playback

• This product may not respond to all operating commands because some Blu-ray Disc, DVD, and CD discs allow specific or limited operation and provide only certain features during playback. Please note that this is not a defect in the product.

• Samsung cannot guarantee that this product will play every disc bearing the Blu-ray Disc, DVD or CD logo because disc formats evolve, and problems and errors may occur during the creation of Blu-ray Disc, DVD, and CD software and/or the manufacture of discs. Please contact the SAMSUNG customer care centre if you have questions or encounter difficulty in playing Blu-ray Disc, DVD, or CD discs in this product. Also, refer to rest of this user manual for additional information on playback restrictions.

02 Safety Information

English 7

Contents

KEY FEATURES

SAFETY INFORMATION

GETTING STARTED

2 Blu-ray™ Disc Features 2 BD-HDD Combo Features

3 Warning 4 Precautions 4 Important Safety Instructions 5 Viewing using 3D function 5 Disc Storage & Management 5 Disc Handling

12 Before using the User Manual 12 Disc Types and Contents your product can play 12 Disc types your product cannot play 13 HDD Recording 13 Disc Types 14 Region Code 15 Supported File Formats 18 Connect a USB device before using the Time shift

and Recorded TV functions 18 Blu-ray Disc Compatibility 18 Copyright 19 Logos of Discs the Product Can Play 19 Accessories 20 Front Panel 21 Rear Panel 22 Remote Control 22 Tour of the Remote Control 23 Setting the Remote Control to Operate Your TV 24 TV Control Codes

8 English

CONNECTIONS

25 Connecting to a TV with an Audio/Video cables

and RF cable

26 Connecting to a TV 26 Case 1 : Connecting to a TV with an HDMI Cable

- Best Quality (Recommended)

27 Case 2 : Connecting to a TV with a Component

Cable - Better Quality 28 Case 3 : Connecting to a TV with an Audio/Video

cable - Good Quality

CONNECTIONS

29 Connecting to an Audio System 29 Case 1 : Connecting to an Audio System

(HDMI supported AV receiver) - Best Quality (Recommended)

30 Case 2 : Connecting to an Audio System

(Stereo Amplifier) - Good Quality

30 Case 3 : Connecting to an Audio System

(AV receiver with Dolby Digital or DTS decoder) Better Quality

31 Connecting to the Network 31 Cable Network 32 Wireless Network

ENGLISH

SETUP

BASIC FUNCTIONS

33 Before Starting (Plug & Play) 33 Accessing the Settings Menu 34 Watch TV 34 Channel List 35 Channel Manager 36 Settings 36 Display 40 Audio 43 Channel 45 Network 49 System 51 Language 51 Security 52 General 52 Support 54 Contact Samsung

54 Playing a Video 54 Playback 54 3D Converter 55 Disc Structure 56 Using the Disc Menu/Title Menu/Popup Menu 56 Using the Disc Menu 56 Using the Title Menu 56 Playing the Title List 56 Using the Popup Menu

English 9

Contents

BASIC FUNCTIONS

56 Using the Search and Skip Functions 56 Searching for a Desired Scene 57 Skipping Chapters 57 Slow Motion Play/Step Motion Play 57 Slow Motion Play 57 Step Motion Play 57 Using the TOOLS button 57 Moving to a Desired Scene Directly 58 Repeating the Title or Chapter 58 Repeating the Title or Chapter 58 Repeating a Section 58 Selecting the Picture Settings 59 Selecting the Audio Language 59 Selecting the Subtitle Language 60 Changing the Camera Angle 60 Selecting the Information 60 Setting BONUSVIEW 60 Listening to Music 60 Playing an Audio CD (CD-DA)/MP3 61 AMG function 61 Repeat an Audio CD (CD-DA)/MP3 61 Playlist 62 Playing back a Pictures 62 Playing JPEG files 62 Using the TOOLS button 63 Media Play

10 English

DTV FUNCTIONS

64 Display Screen 64 Using the TOOLS button 64 Picture Settings 64 Selecting the Audio Language 65 Selecting the Dual I II 65 Lock current channel 65 Switch to Cable 65 Add to Favourites 65 Signal Information

DTV FUNCTIONS

65 Setting Audio Description & Subtitle Language 65 Setting the Audio Description 65 Setting the Subtitle Language 66 Viewing the Guide Screen 66 Schedule Manager 67 To Cancel or Edit Schedule 67 Viewing DTV with the 3D effect 68 Using the Teletext Service

ENGLISH

ADVANCED FUNCTIONS

NETWORK SERVICES

69 Recording 69 Recording the current TV channel you are

watching

70 Watching other channels during Recording a TV

channel 70 Playing a Disc while Recording a TV channel 70 Time Shift function 71 Playing the Recorded Title 72 Edit the Recorded Title 72 Renaming a Recorded Title 72 Splitting a Section of a Title (Divide into two) 72 Splitting a Section of a Title (Partial Delete) 73 Copy 73 Copying Videos, Music or Photos 73 Ripping from a Audio CD (CD-DA)

74 Using Smart Hub 74 Starting Smart Hub for the First Time 77 The Settings Menu - BLUE (D) 79 The Edit Mode Menu - YELLOW (C) 81 The Sort Menu - GREEN (B) 81 Samsung Apps 81 For Pay Apps 83 BD-LIVE™ 83 Using the AllShare Function

APPENDIX

84 Troubleshooting 86 Repairs 87 Index 88 Specifications

English 11

Getting Started

Before using the User Manual

Disc Types and Contents your product can play

Ter m Logo Icon Definition

Indicates a function available on a BD-ROM or BD-RE/-R disc recorded in the BD-RE format.

VIDEO

Indicates a function available on a DVD-VIDEO or recorded DVD+RW/ DVD-RW(V)/DVD-R/+R discs that have been recorded and finalized.

MUSIC


VIDEO MUSIC


NOTE

✎

`The product may not play certain CD-RW/-R and DVD-R because of the disc type or recording conditions.

`If a DVD-RW/-R disc has not been recorded properly in DVD video format, it will not be playable.

`Your product will not play content that has been recorded on a DVD-R at a bit-rate that exceeds 10 Mbps.

`Your product will not play content that has been recorded on a BD-R or USB device at a bit rate that exceeds 30 Mbps.

Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-RE/-R disc or a USB storage media containing DivX, MKV, MP4 contents.

Indicates a function available on an audio CD-RW/-R (CD-DA format).

Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-RE/-R disc or a USB storage media containing MP3 or WMA contents.

Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-RE/-R disc or a USB storage media containing JPEG contents.

Indicates a function available on the HDD.

Disc types your product cannot play

• HD DVD

• DVD-ROM/PD/

MV-Disc, etc

• DVD-RAM

• Super Audio CD

(except CD layer)

12 English

• DVD-RW(VR mode)

•

CVD/CD-ROM/CDV/ CD-G/CD-I/LD (CD-Gs play audio only, not graphics.)

• 3.9 GB DVD-R Disc for Authoring.

NOTE

✎

`Some commercial discs and DVDs purchased

outside your region may not play on this product.

`Playback may not work for some types of discs, or

when you use specific operations, such as angle change and aspect ratio adjustment. Information about the discs is written in detail on the disc box. Please refer to this if necessary.

`Do not allow the disc to become dirty or scratched.

Fingerprints, dirt, dust, scratches or deposits of cigarette smoke on the recording surface may make it impossible to use the disc for playback.

`When you play a BD-J title, loading may take longer

than a normal title or some functions may perform slowly.

`This product may not respond to all operating

commands because some Blu-ray Disc, DVD, and CD discs allow specific or limited operation and provide only certain features during playback. Please note that this is not a defect in the product.

`Samsung cannot guarantee that this product will

play every disc bearing the Blu-ray Disc, DVD or CD logo because disc formats evolve, and problems and errors may occur during the creation of Blu-ray Disc, DVD, and CD software and/or the manufacture of discs. Please contact the SAMSUNG customer care centre if you have questions or encounter difficulty when playing Blu-ray Disc, DVD, or CD discs in this product. Also, refer to rest of this user manual for additional information on playback restrictions.

Disc Types

BD-ROM

Blu-ray ROM discs can only be played back. This product can play back pre-recorded commercial BD-ROM discs.

BD-RE/-R

Blu-ray RE/-R discs can be recorded on and played back. This product can play back a BD-RE/-R disc recorded by other compatible Blu-ray Disc recorders.

DVD-VIDEO

• This product can play back pre-recorded commercial DVDs (DVD-VIDEO discs) with movies.

• When switching from the first layer to the second layer of a dual-layered DVD-VIDEO disc, there may be momentary distortion in the image and sound. This is not a malfunction of the product.

DVD-RW/-R/+R

This product can play back a DVD-RW/-R/+R disc recorded and finalized with a DVD video recorder. The ability to play back may depend on recording conditions.

03 Getting Started

HDD Recording

You can record digital broadcast on the internal HDD as below.

Broadcast

Depending on the bitrate of broadcast programme, available recording time may be decreased or increased.

BD-D8200M (250GB) BD-D8500M (500GB)

Recording

Type

HD 64 Hrs 8 Mbps 130 Hrs 8 Mbps

SD 102 Hrs 5 Mbps 208 Hrs 5 Mbps

Time

Estimated

Bitrate

Recording

Time

Estimated

Bitrate

DVD+RW

• This product can play back a DVD+RW disc recorded with a DVD Video recorder. The ability to play back may depend on recording conditions.

Audio CD (CD-DA)

• This product can play back CD-DA format audio CD-RW/-R discs.

• The product may not be able to play some CD-RW/-R discs due to the condition of the recording.

English 13

Getting Started

CD-RW/-R

• Use a 700MB (80 minute) CD-RW/-R disc. If possible, do not use an 800MB (90 minute) or larger disc, as the disc may not play back.

• If the CD-RW/-R disc was not recorded as a closed session, you may experience delays when playing back the beginning of the disc or all recorded files may not play.

• Some CD-RW/-R discs may not play on this product, depending on the device which was used to burn them. For contents recorded on CD-RW/-R media from CDs for your personal use, playability may vary depending on the contents and discs.

AVCHD (Advanced Video Codec High Definition)

• This product can play back AVCHD format discs. These discs are normally recorded and used in camcorders.

• The AVCHD format is a high definition digital video camera format.

• The MPEG-4 AVC/H.264 format compresses images with greater efficiency than the conventional image compressing format.

• Some AVCHD discs use the “x.v.Colour” format. This product can play back AVCHD discs that use “x.v.Colour” format.

• “x.v.Colour” is a trademark of Sony Corporation.

• “AVCHD” and the AVCHD logo are trademarks

of Matsushita Electronic Industrial Co., Ltd. and Sony Corporation.

NOTE

✎

`Some AVCHD format discs may not play, depending

on the recording condition. AVCHD format discs need to be finalized.

`“x.v.Colour” offers a wider colour range than normal

DVD camcorder discs.

`Some DivX, MKV and MP4 format discs may not

play, depending on the video resolution and frame rate condition.

Region Code

Both products and discs are coded by region. These regional codes must match for a disc to play. If the codes do not match, the disc will not play. The Region Number for this product is displayed on the rear panel of the product.

Disc Type

Blu-ray Disc

DVD-VIDEO

Region

Code

North America, Central America, South America, Korea, Japan,

Taiwan, Hong Kong and South East Asia.

Europe, Greenland, French territories, Middle East, Africa,

Australia and New Zealand.

India, China, Russia, Central

and South Asia.

The U.S., U.S. territories and

Canada

Europe, Japan, the Middle East,

Egypt, South Africa, Greenland

Taiwan, Korea, the Philippines,

Indonesia, Hong Kong

Mexico, South America, Central America, Australia,

New Zealand, Pacific Islands, Caribbean

Russia, Eastern Europe, India, most of Africa, North Korea,

Mongolia

China

Area

14 English

Supported File Formats

Notes on the USB connection

• Supported devices: USB storage media, MP3 product, digital camera, USB card reader

• Does not support if a folder or file name is longer than 128 characters.

• A certain USB/digital camera device may not be compatible with the product.

• Connect directly to the product's USB port. Connecting through another cable may raise problems with USB compatibility.

• Inserting more than one memory device to a multi-card reader may not operate properly.

• Supports the PTP protocol.

• Do not disconnect USB device during a

"loading" process.

• Bigger the image resolution, the longer the delay to displaying.

• DRM applied MP3 files downloaded from a commercial site are not played back.

• If the problem of the unrecognized USB device persists or the internal file list is corrupt or a certain file could not be played, connect the USB device to the PC and format it in a proper file system, then check it again.

• If the file deleted from your PC still appears in Media Play, use “Empty Recycle Bin” on your desktop to delete it completely.

• Some USB devices supporting the power saving mode may switch the saving mode of the BD product to Off automatically when connected with each other.

• Need-to-Know List before using Media Play

- Media Play only supports USB Mass Storage Class (MSC) devices. MSC is a Mass Storage Class Bulk-Only Transport device. Examples of MSC are Thumb drives, Flash Card Readers and USB HDD. (HUB is not supported.)

- MSC supports Music, Photo and Video files, while a PTP device supports Photo files only.

- MTP (Media Transfer Protocol) is not supported.

- The file system supports FAT16, FAT32 and NTFS (read only).

- Before connecting your device to the product, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss.

- Do not disconnect the USB device while it is loading.

- If some devices require excessive power, USB device may be limited by the circuit safety device.

• You must remove the USB storage device safely (by performing the “Safely Remove USB” function) in order to prevent a possible damage to the USB memory. Press the MENU button to move to the home menu, and select the YELLOW (C) button and press the ENTER button.

• If you insert the disc when playing USB storage device, the device mode is changed to “DVD or CD” automatically.

• Audio CD (CD-DA), MP3 and JPEG files cannot be displayed in full screen mode.

• A Certain USB HDD Device may not be compatible with this product.

03 Getting Started

English 15

Getting Started

Video File Support

File

Extention

*.avi

*.mkv

*.asf

*.wmv

*.mp4

*.3gp

*.vro

*.mpg

*.mpeg

*.ts

*.tp

*.trp

Container Video Codec Resolution

DivX 3.11/4.x/5.1/6.0 1920x1080 6 ~ 30

AVI

MKV

ASF

ASF Window Media Video v9 1920x1080 6 ~ 30

MP4

3GPP

VRO VOB

H.264 BP/MP/HP 1920x1080 6 ~ 30

MPEG4 SP/ASP 1920x1080 6 ~ 30

Motion JPEG 1920x1080 6 ~ 30

DivX 3.11/4.x/5.1/6.0 1920x1080 6 ~ 30

H.264 BP/MP/HP 1920x1080 6 ~ 30

MPEG4 SP/ASP 1920x1080 6 ~ 30

Motion JPEG 1920x1080 6 ~ 30

DivX 3.11/4.x/5.1/6.0 1920x1080 6 ~ 30

H.264 BP/MP/HP 1920x1080 6 ~ 30

MPEG4 SP/ASP 1920x1080 6 ~ 30

Motion JPEG 1920x1080 6 ~ 30

H.264 BP/MP/HP 1920x1080 6 ~ 30

MPEG4 SP/ASP 1920x1080 6 ~ 30

H.264 BP/MP/HP 1920x1080 6 ~ 30

MPEG4 SP/ASP 1920x1080 6 ~ 30

MPEG2 1920x1080 24/25/30

MPEG1 352x288 24/25/30

MPEG2 1920x1080 24/25/30

H.264 1920x1080 6 ~ 30

MPEG2 1920x1080 24/25/30

H.264 1920x1080 6 ~ 30

VC1 1920x1080 6 ~ 30

Frame rate

(fps)

Bit rate (Mbsp)

25 WMA 25

Audio Codec

MP3 AC3

LPCM

ADPCM

DTS Core

MP3 AC3

LPCM

ADPCM

DTS Core

MP3 AC3

LPCM

ADPCM

WMA

MP3

ADPCM

AAC

ADPCM

AAC

HE-AAC

AC3 MPEG LPCM

AAC

AC3

AAC

MP3

DD+

HE-AAC

16 English

Limitations

- Even when the file is encoded by a supported codec mentioned above, a file might not be played if its content has a problem.

- Normal playback is not guaranteed if the file's container information is wrong or the file itself is corrupted.

- Files having higher Bit rate/frame rate than standard may stutter with sound/video playback.

- Seek (skip) function is not available if the file's index table is damaged.

- When you playback a file remotely through network connection, video playback may stutter depending on established network speed.

Video decoder

- Supports up to H.264 Level 4.1

- Does not support H.264 FMO/ASO/RS, VC1 SP/MP/AP L4 and AVCHD

- MPEG4 SP, ASP: Below 1280x720: 60 frames max Above 1280x720: 30 frames max

- Does not support GMC 2 or higher

Audio decoder

- Supports WMA 7, 8, 9 and STD

- Does not support WMA 9 PRO multi-channel lossless audio decoding if number of channels is more than 2

- Does not support WMA sampling rate of 22050Hz mono

- Supports DTS Core (5.1 ch, 16 bit, 48kHz) only

- Does not support APDCM MULAW, ALAW

Optical Media

- CD Media Bit Rate : Max 9.6Mbps

- DVD Media Bit Rate : Max 22.16Mbps

Supported DivX subtitle file formats

*.ttxt, *.smi, *.srt, *.sub, *.txt

Music File Support

File

Extension

*.mp3

Container

MP3

Audio

Codec

Support Range

MP3 -

Compliant with WMA version 10

* Sampling rates (in

*.wma

WMA

kHz) - 8, 11, 16, 22, 32, 44.1, 48

* Bit rates - All bit-

rates in the range 5kbps to 384kbps

03 Getting Started

English 17

Getting Started

Connect a USB device before using the Time shift and Recorded TV functions

Do not use a USB memory stick. We do not support a USB memory stick.

We recommend using a USB HDD with at least 5400 rpm, but a USB HDD of RAID type is not supported.

• To use the Time shift mode or the Recorded TV function, a connected USB device must be

execute the Device Format function to proper form for recording.

- During the device formatting, do not disconnect the device while formatting is in progress. If you format the device, all files will be deleted.

- Before formatting your device to this product, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss.

• Recorded videos are DRM (digital rights managements) protected and cannot be played on a PC or other product. Note that files saved on the TV cannot be used after the main board is changed.

• If available storage is left less than 10MB during the recording, recording is finished automatically.

• If the USB device has failed the Device Performance Test, the USB device must go through the Device Format and Device Performance Test again before you record with

the Guide or Channel Manager. If the device has failed the Performance Test, It cannot be used for recording.

• For more information, see your user’s manual.

Blu-ray Disc Compatibility

Blu-ray Disc is a new and evolving format. Accordingly, disc compatibility issues are possible. Not all discs are compatible and not every disc will play back. For additional information, refer to the Compliance and Compatibility Notice section of this user manual.

Copyright

manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd.

18 English

Logos of Discs the Product Can Play

Blu-ray Disc 3D Blu-ray Disc DTS-HD Master Audio DivX

03 Getting Started

BD-LIVE Dolby TrueHD

PAL broadcast System in U.K.,

France, Germany, etc.

Java

Accessories

Check for the supplied accessories below.

POWER

BD-HDD/TV

BD TV

1 2 3

4 5 6

7 8 9

DISC MENU

TITLE MENU

TIME SHIFT

TV MUTE

TV VOL PROG

TV SOURCE

CH LIST

RETURN

A B C D

FULL

SMART

SCREEN

HUB

AD/

REC PAUSEREC

AUDIO

SUBTITLE

0000-000000

Audio/Video cable RF cable for TV Remote Control

Batteries for Remote Control (AAA Size) User Manual Quick Guide

2D3D

TTX/MIX

GUIDEiMENU

...

INFOTOOLS

EXIT

2D3D

English 19

Getting Started

a bc d efgh

REMOTE CONTROL SENSOR Detects signals from the remote control.

POWER BUTTON Turns the product on and off.

DISC SLOT Inserts a disc.

Front Panel

j i

DISPLAY Displays the playing status, time, etc.

STOP BUTTON Stops disc playback.

PLAY/PAUSE BUTTON Plays a disc or pauses playback.

ENTER BUTTON Selects menu items or starts a disc.

EJECT BUTTON Ejects a disc.

COMMON INTERFACE SLOT To watch paid channels, insert the CI CAM with CI or CI+ CARD.

USB HOST It can be used for software upgrades and MP3/JPEG/DivX/MKV/MP4 playback.

NOTE

✎

`When the product displays the Blu-ray Disc menu, you may not start the movie by pressing the Play button on the

product or the remote. To play the movie, you must select Play Movie or Start in the disc menu, and then press the ENTER button.

`You must obtain a “CI CAM with CI or CI+ CARD” from a local cable service provider.

20 English

`When removing the “CI CAM with CI or CI+ CARD”, carefully pull it out with your hands since dropping the “CI CAM

with CI or CI+ CARD” may cause damage to it.

`Insert the “CI CAM with CI or CI+ CARD” in the direction marked on the card.

`The location of the CI card slot may be different depending on the model.

`“CI CAM with CI or CI+ CARD” is not supported in some countries and regions; check with your authorized dealer.

If you have any problems, please contact a service provider.

Rear Panel

03 Getting Started

b c d

g fh

ANT OUT (TO TV) Connects RF cable to TV antenna input.

ANT IN Connects RF cable from antenna.

LAN

COMPONENT OUT Connects to external devices that have Component video input.

DIGITAL AUDIO OUT

(OPTICAL)

VIDEO OUT Connects to the video input of external devices using a video cable.

Use for network based services (See pages 74~83), BD-LIVE, and software upgrades using a network connection.

Connects to an AV receiver.

AUDIO OUT Connects to the audio input of external devices using audio cables.

Using an HDMI cable, connect this HDMI output terminal to the HDMI input terminal on your TV for the best quality picture or to your AV receiver for the best quality sound.

HDMI OUT

English 21

Getting Started

Tour of the Remote Control

Remote Control

Turn the product on and off.

Press this to operate a TV.

Press this to operate BD-HDD Combo.

Press numeric buttons to operate options or

to access channels directly.

Use to enter the disc menu.

Press to skip backwards or forwards.

Stops playback or recording.

Mutes the speakers of your TV.

TV volume adjustment.

Displays channel lists on the screen.

Press to move to the home menu.

Press to use Tools menu.

Use to select menu items and change

menu value.

Return to the previous menu.

Press to search contents.

Press to use Smart Hub.

Press this to set audio description and

subtitle.

Press this to set audio.

POWER

BD-HDD/TV

BD TV

1 2 3

4 5 6

7 8 9

DISC MENU

TIME SHIFT

TV MUTE

TV VOL

TV SOURCE

CH LIST

RETURN

A B C D

SMART

HUB

SUBTITLE

0000-000000

FULL

SCREEN

AD/

AUDIO

POWER

2D3D

TITLE MENU

PROG

GUIDE

INFOTOOLS

EXIT

REC PAUSEREC

TTX/MIX

2D3D

Turn the TV on and off. (To operate your TV, please refer to pages 23~24)

Press to eject a disc.

Alternately selects Teletext, Double or Mix.

Use to enter the popup menu/title menu.

Press to search backwards or forwards.

Press this to pause a playback or pause the Time Shift function.

Press this to play or start the Time Shift function.

Press this to select a TV channel.

After setup, allows you to set the input

...

source on your TV.

Displays the EPG (Electronic Programme

Guide.) Press this to display the playback information during playing a Blu-ray Disc/DVDs or display the information of TV channel.

Press to exit the menu.

These buttons are used both for menus on the product and also several Blu-ray Disc functions.

Press this when you want to use 3D function.

Press this to pause during recording.

Press this to see the full screen on a TV.

Press this to make a recording.

22 English

Setting the Remote Control to Operate Your TV

To determine whether your television is compatible, follow the instructions below.

1. Turn your television on.

2. Point the remote control towards the

television.

3. Press the TV button to set the TV mode.

4. Press and hold the TV POWER button, and

then enter the two-figure code in the table to the right that corresponds to the brand of your television by pressing the appropriate number buttons. If your television is compatible with the remote control, it will Turn off. The remote is now programmed to operate the TV.

NOTE

✎

`If several codes are listed for your television brand,

try each one in turn until you find one that works.

`If you replace the remote control’s batteries, you

must set the brand code again.

You can control certain functions of your TV with this remote control.

Button Function

TV POWER Used to Turn the television on and off.

Number Used to input number directly.

TV VOL +/–

TV MUTE Used to toggle the sound on and off.

PROG (,/.) Used to select the desired channel.

TV SOURCE

Used to adjust the volume of the television.

Used to select an external source connected to the TV.

In case of Samsung TV, below buttons are also compatible with this remote control.

Button Function

MENU Used to move to the TV menu.

TOOLS Used to display Tools menu.

▲▼◄►

ENTER Used to select menu items.

INFO Used to display INFO menu.

RETURN Return to the previous menu.

EXIT Used to exit the menu.

COLOUR (A,B,C,D)

NOTE

✎

`The functions listed above will not necessarily work

on all televisions. If you encounter problems, use the TV remote control.

Used to move the cursor or select an item.

These buttons are used for several functions.

Installing batteries

NOTE

✎

`If the remote does not operate properly:

• Check the polarity +/– of the batteries.

• Check if the batteries are drained.

• Check if the remote sensor is blocked by

obstacles.

• Check if there is any fluorescent lighting nearby.

CAUTION

`Dispose of batteries according to local environmental

regulations. Do not put them in the household trash.

03 Getting Started

English 23

Getting Started

TV Control Codes

Brand Code

SAMSUNG

AIWA TV POWER+82

ANAM

BANG &

OLUFSEN

BLAUPUNKT TV POWER+71

BRANDT TV POWER+73

BRIONVEGA TV POWER+57

CGE TV POWER+52

CONTINENTAL

EDISON

DAEWOO

EMERSON TV POWER+64

FERGUSON TV POWER+73

FINLUX TV POWER+06, +49, +57

FORMENTI TV POWER+57

FUJITSU TV POWER+84

GRADIENTE TV POWER+70

GRUNDIG TV POWER+49, +52, +71

HITACHI TV POWER+60, +72, +73, +75

IMPERIAL TV POWER+52

JVC TV POWER+61, +79

LOEWE TV POWER+06, +69

LOEWE OPTA TV POWER+06, +57

MAGNAVOX TV POWER+40

METZ TV POWER+57

MITSUBISHI TV POWER+06, +48, +62, +65

MIVAR TV POWER+52, +77

NEC TV POWER+83

TV POWER+01, +02, +03, +04, +05, +06, +07, +08, +09

TV POWER+10, +11, +12, +13, +14, +15, +16, +17, +18

TV POWER+57

TV POWER+75

TV POWER+19, +20, +23, +24, +25, +26, +27, +28, +29, +30, +31, +32, +33, +34

TV POWER+06, +19, +20, +21, +22, +78

Brand Code

NEWSAN TV POWER+68

NOBLEX TV POWER+66

NOKIA TV POWER+74

NORDMENDE TV POWER+72, +73, +75

PANASONIC TV POWER+53, +54, +74, +75

PHILIPS TV POWER+06, +55, +56, +57

PHONOLA TV POWER+06, +56, +57

PIONEER TV POWER+58, +59, +73, +74

RADIOLA TV POWER+06, +56

RADIOMARELLI

RCA TV POWER+45, +46

REX TV POWER+74

SABA TV POWER+57, +72, +73, +74, +75

SALORA TV POWER+74

SANYO TV POWER+41, +42, +43, +44, +48

SCHNEIDER TV POWER+06

SELECO TV POWER+74

SHARP TV POWER+36, +37, +38, +39, +48

SIEMENS TV POWER+71

SINGER TV POWER+57

SINUDYNE TV POWER+57

SONY TV POWER+35, +48

TELEAVA TV POWER+73

TELEFUNKEN TV POWER+67, +73, +75, +76

THOMSON TV POWER+72, +73, +75

THOMSON

ASIA

TOSHIBA

WEGA TV POWER+57

YOKO TV POWER+06

ZENITH TV POWER+63

TV POWER+57

TV POWER+80, +81

TV POWER+47, +48, +49, +50, +51, +52

24 English

Connections

Connecting to a TV with an Audio/Video cables and RF cable

1. Connect the RF cable as shown.

2. Using video/audio cables, connect the VIDEO OUT (yellow) / AUDIO OUT (white and red)

terminals on the rear of the product to the VIDEO IN (yellow) / AUDIO IN (white and red) terminals of your TV.

3. Plug in the product and TV.

4. Turn on the product and TV.

To ANT IN

To TV

RF cable

Audio/Video cable

04 Connections

WhiteRed Yellow

To ANT INPUT

NOTE

✎

`The RF cable connection of this product sends only signals of TV. You must connect the Audio/Video cables to watch

output from your product.

`Noise may be generated if the audio cable is placed too close to the power cable.

`If you want to connect to an AV receiver, please refer to the AV receiver connection pages. (See pages 29~30)

`The number and position of terminals may vary depending on your TV set. Please refer to the user manual of your TV.

`If there is only one audio input terminal on the TV, connect it to the AUDIO OUT (right/white) terminal of the product.

English 25

Connections

Connecting to a TV

Case 1 : Connecting to a TV with an HDMI Cable - Best Quality (Recommended)

1. Using an HDMI cable, connect the HDMI OUT terminal on the rear of the product to the HDMI IN

terminal of your TV.

2. Turn on the product and TV.

3. Press the input selector on your TV remote control until the HDMI signal from the product appears on

your TV screen.

• If you have set the remote control to operate your TV (See pages 23~24), press the TV SOURCE

button on the remote control and select HDMI as the external source of the TV.

HDMI cable

(not included)

NOTE

✎

`An HDMI cable outputs digital video/audio, so you don't need to connect an audio cable.

`If the product is connected to your TV in the HDMI 720p, 1080i, or 1080p output mode, you must use a High speed

(category 2) HDMI cable.

`HDMI outputs only a pure digital signal to the TV.

If your TV does not support HDCP (High-bandwidth Digital Content Protection), random noise appears on the screen.

`Depending on your TV, certain HDMI output resolutions may not work. Please refer to the user manual of your TV.

`When you connect the product to the TV using the HDMI cable for the first time or to a new TV, the HDMI output

resolution will be automatically set to the highest supported by the TV.

`You must have an HDMI connection to enjoy videos with 3D technology.

`A long HDMI cable may cause a screen noise. If this occurs, set Deep Colour to Off in the menu.

`If you use HDMI-to-DVI cable to connect to your display device, you must also connect the AV OUT or Digital Audio OUT

to your display device or an audio system to hear audio.

26 English

Case 2 : Connecting to a TV with a Component Cable - Better Quality

- You can connect the product to your TV using Component video cables.

- You will enjoy high quality images with accurate colour reproduction. Component video separates the picture element into black and white (Y), blue (P images. (Audio signals are delivered through the audio output.)

1. Using a Component video cable, connect the COMPONENT OUT terminals on the rear of the product to the COMPONENT IN terminals of your TV.

2. Using audio cables, connect the AUDIO OUT (white and red) terminals on the rear of the product to the AUDIO IN (white and red) terminals of your TV.

3. Turn on the product and TV.

4. Press the input selector on your TV remote control until the “COMPONENT” signal from the product

appears on the TV screen.

• If you have set the remote control to operate your TV (See pages 23~24), press the TV SOURCE

button on the remote control and select COMPONENT as the external source of the TV.

Component cable

(not included)

) and red (PR) signals to present clear and clean

Audio cable

04 Connections

Red

White Red Blue Green

NOTE

✎

`Depending on the manufacturer, the component terminals on your TV may be marked “R-Y, B-Y, Y ” or “Cr, Cb, Y”

instead of “P Please refer to the user manual of your TV.

`You can select from a variety of resolution settings as 1080i, 720p, 576p/480p or 576i/480i, depending on the

contents type. (See pages 37~39)

`The actual resolution may differ from the setting in the setup menu if you have connected both Component and HDMI

cables. The resolution may also be different depending on the contents type. (See pages 37~39)

, PR, Y”. The number and position of terminals may vary depending on the TV set.

English 27

Connections

Case 3 : Connecting to a TV with an Audio/Video cable - Good Quality

1. Using an Audio/Video cable, connect the VIDEO OUT (yellow) / AUDIO OUT (white and red)

terminals on the rear of the product to the VIDEO IN (yellow) / AUDIO IN (white and red) terminals of your TV.

2. Turn on the product and TV.

3. Press the input selector on your TV remote control until the “VIDEO” signal from the product appears

on the TV screen.

• If you have set the product's remote control to operate your TV (See pages 23~24), press the TV SOURCE button on the remote control and select VIDEO as the external source of the TV.

Audio/Video cable

WhiteRed Yellow

NOTE

✎

`Noise may be generated if the audio cable is placed too close to the power cable.

`If you want to connect to an AV receiver, please refer to the AV receiver connection pages. (See pages 29~30)

The number and position of TV.

CAUTION

`Do not connect the product to your TV through a VCR. Video signals fed through VCRs may be affected by copyright

protection systems and the picture will be distorted on the television.

input terminals

may vary depending on your TV set. Please refer to the user manual of your

28 English

Connecting to an Audio System

• Please turn the volume down when you turn on the AV receiver. A sudden loud sound may cause damage to the speakers and your ears.

• Set the audio output format according to the capabilities of your AV receiver. (See pages 40~43)

• The position of HDMI input terminals may vary depending on your AV receiver. Please refer to the

user manual of your AV receiver.

Case 1 : Connecting to an Audio System (HDMI supported AV receiver)

- Best Quality (Recommended)

1. Using an HDMI cable, connect the HDMI OUT terminal on the rear of the product to the HDMI IN

terminal of your AV receiver.

2. Using an HDMI cable, connect the HDMI OUT terminal of the AV receiver to the HDMI IN terminal of

your TV.

3. Turn on the product, TV, and AV receiver.

4. Press the input select button of the AV receiver and TV to select the external input to hear sound

from the player. Refer to your AV receiver’s user manual to set the AV receiver’s audio input.

04 Connections

(not included)

HDMI cable

(not included)

HDMI cable

English 29

Connections

Case 2 : Connecting to an Audio System (Stereo Amplifier)

- Good Quality

1. Using the audio cables, connect the AUDIO OUT (white and red) terminals on the rear of

the product to the AUDIO IN (white and red) terminals of your Stereo Amplifier.

2. Using the video signal cable(s), connect the HDMI, COMPONENT, or VIDEO OUT terminals on the rear of the product to the HDMI, COMPONENT, or VIDEO IN terminal of your TV. (See pages 26~28)

3. Turn on the product, TV, and Stereo Amplifier.

4. Press the input select button of the Stereo

Amplifier to select the external input and hear sound from the product. Refer to your Stereo Amplifier's user manual to set the Stereo Amplifier's audio input.

5. Press the input selector on your TV remote control to select the video source (HDMI, Component or Video.)

Case 3 : Connecting to an Audio System (AV receiver with Dolby Digital or DTS decoder) - Better Quality

1. Using an optical cable, connect the DIGITAL AUDIO OUT (OPTICAL) terminal on the rear of the product to the DIGITAL AUDIO IN (OPTICAL) terminal of your AV receiver.

2. Using the video signal cable(s), connect

the HDMI, COMPONENT, or VIDEO OUT terminals on the rear of the product to the HDMI, COMPONENT, or VIDEO IN terminal of your TV. (See pages 26~28)

3. Turn on the product, TV, and AV receiver.

Press the input select button of the to select the external input in order to hear sound from the product. Refer to your manual to set the

5. Press the input selector on your TV remote control to select the video source (HDMI, Component or Video.)

AV receiver’s

AV receiver

AV receiver’s

audio input.

user

Case 2 : Audio cable

WhiteRed

NOTE

✎

`If you use the Digital Audio connection described in Case 3, you will hear only front two speakers with Digital Output

setting as PCM.

Case 3 : Optical cable

(not included)

30 English

Connecting to the Network

This product lets you use network based services (See pages 74~83) such as Smart Hub and BD-LIVE, and software upgrades when it is connected to a network. We recommend using an AP (Access Point) or IP router for the connection. For more information on router connections, refer to the user manual of the router or contact the router manufacturer for technical assistance.

Cable Network

1. Using the Direct LAN Cable (UTP cable), connect the LAN terminal of the product to the LAN terminal

of your modem or router.

2. To set the network options, see pages 45~49.

Router

04 Connections

Broadband modem

(with integrated router)

Broadband

service

NOTE

✎

`Internet access to Samsung’s software update server may not be allowed, depending on the router you use or

ISP’s policy. For more information, contact your ISP (Internet Service Provider).

`For DSL users, please use a router to make a network connection.

`To use the AllShare function, you must connect your PC to your network as shown in the figure.

The connection can be wired or wireless.

Broadband modem

Networking with PC for AllShare function

Broadband service

your

English 31

Connections

Wireless Network

Your product has built in Wi-Fi capability. You can connect to a network through a Wireless IP sharer (a router or modem). To set the network options, see pages 45~49.

Broadband

service

Networking with PC for AllShare function

NOTE

✎

`To use a wireless network, your product must be connected to a wireless IP sharer (router). If the wireless IP sharer

supports DHCP, your product can use a DHCP or static IP address to connect to the wireless network.

`Select a channel for the wireless IP sharer that is not currently being used. If the channel set for the wireless IP sharer

is currently being used by another device nearby, this will result in interference and communication failure.

`If Pure High-throughput (Greenfield) 802.11n mode is selected and the Encryption type is set to WEP, TKIP or TKIP-

AES (WPS2Mixed) for your AP, this product will not support a connection in compliance with new Wi-Fi certification specifications.

`If your AP supports WPS (Wi-Fi Protected Setup), you can connect to the network via PBC (Push Button Configuration)

or PIN (Personal Identification Number). WPS will automatically configure the SSID and WPA key in either mode.

`You can setup a wireless network three ways:

- Wireless (general)

- Using WPS(PBC)

- One Foot Connection

Wireless (general) includes both Automatic and Manual setup procedures.

`Wireless LAN, by its nature, may cause interference, depending on the operating conditions (AP performance, distance,

obstacles, interference by other radio devices, etc).

`Set the wireless IP sharer to Infrastructure mode. Ad-hoc mode is not supported.

`The product supports only the following wireless security key protocols :

- WEP(OPEN/SHARED), WPA-PSK(TKIP/AES), WPA2-PSK(TKIP/AES).

`To use the AllShare function, you must connect your PC to your network as shown in the figure.

The connection can be wired or wireless.

Wireless IP sharer

32 English

Setup

Before Starting (Plug & Play)

1. Turn on your TV after connecting the product.

When you connect the product to a TV for the first time, product turns on automatically and the Plug & Play screen appears.

Select the OSD Language.

Menu Language : English

2. Press the ►▲▼ buttons to select the desired language, and then press the ENTER button.

3. Press the ►▲▼ buttons to select the desired country, and then press the ENTER button.

4. Press the ►▲▼ buttons to select the desired Clock Mode.

• If you select Auto : Press the ENTER

button.

• If you select Manual : Press the ▲▼◄►

button to set the clock, then press the ENTER button.

Set Auto Tuning search options.

Plug & Play

Air

Cable

a Previous d Skip > Move " Enter

►

" Enter

5. Press the ▲▼ buttons to select the desired Antenna Source, then press the ENTER button.

• If you select Air : Press the ▼ button to

select the Search, then press the ENTER button.

• If you select Cable : Press the ▼ button

to select the Next, then press the ENTER button. Set the Search Mode option, then press the ▼ button to select the Search button.

6. Press the ►▲▼ buttons to select the desired Region, and then press the ENTER button.

7. Press the ◄► buttons to the select the Network Settings or Watch TV, then press

the ENTER button. (For more information about Network settings, please refer to pages 45~49)

NOTE

✎

`When the product is connected to the TV for the

first time, the product turns on automatically. This is normal operation.

`Enter the desired 4-digit password using the number

buttons. * Default password is set to 0000.

Accessing the Settings Menu

1. Press the MENU button. The home menu will be displayed.

Press the ◄► buttons to select the desired home menu, and then press the ENTER button.

3. Press the ▲▼ buttons to select the desired submenu, and then press the ENTER button.

4. Press the ▲▼ buttons to select the desired item, and then press the ENTER button.

5. Press the EXIT button to exit the menu.

05 Setup

English 33

Setup

• Home Menu

Watch TV

Guide

Schedule Manager

Channel List

My Devices Internet Settings

Channel Manager

My Contents

d WPS(PBC)

Selects My Devices.

Selects My Contents.

Selects Watch TV.

Selects Internet.

Selects Settings.

Displays the buttons available.

NOTE

✎

`When the product is connected to a network, select

Smart Hub from the Home menu. Download the desired content from Samsung Apps. (See pages 81~82)

`The access steps may differ depending on the menu

you selected.

`The OSD (On Screen Display) may change in this

product after you upgrade the software version.

`If the product is left in the home menu more than 3

minutes without being used, DTV screen will appear.

`If the product is left in the other menu including

settings more than 5 minutes without being used, a screen saver will appear on your TV.

Watch TV

1. Press the MENU button.

The home menu will be displayed.

Press the ◄► buttons to select the Watch TV.

3. Press the ▲▼ buttons to select the desired submenu, then press the ENTER button.

4. Press the ▲▼ buttons to select the desired item, then press the ENTER button.

5. Press the EXIT button to exit the menu.

Channel List

You can see all channels searched.

1. Press the CH LIST button on the remote

control. The Channel List will be displayed.

Channel List Screen

Channel List

All

BBC World

808

bid-up.tv

809

Boomerang

810

Cartoon Nwk

811

Class News

812

Coming Soon

813

Discovery

814

No Information

a Antenna  Programme View < Ch. Mode " Watch ƒ Page Air

Shows the stored channels.

Navigation Help : Displays remote control buttons available.

• RED (A) : Selects Air or Cable.

• YELLOW (C) : Displays the Programme

information.

• Ch. Mode : Shows the channel mode according to channel type. (All, TV, Radio, Data/Other)

• Watch : Displays the selected channel.

• Page : Moves to next or previous page.

2. Press the ▲▼ buttons to select desired channel, press the ENTER button. The selected channel will be displayed.

NOTE

✎

`By pressing the INFO button, you can watch or

record the selected channel.

34 English

Channel Manager

You can manage the stored channels.

Channel Manager Screen

1 2

Channel Manager | All

800 xxxxxxxx

802 xxxxxxxx

804 xxxxxxxx

806 xxxxxxxx

808 xxxxxxxx

810 xxxxxxxx

812 xxxxxxxx

814 xxxxxxxx

a Antenna d Sorting ƒ Page " Select / Tools ' Return

Air

801 xxxxxxxx

803 xxxxxxxx

805 xxxxxxxx

807 xxxxxxxx

809 xxxxxxxx

811 xxxxxxxx

813 xxxxxxxx

815 xxxxxxxx

Channel number

1/2 Pages

Using the TOOLS button

Press the ▲▼ buttons to select the desired channel, then press the TOOLS button.

Channel Manager | All

801 xxxxxxxx

803 xxxxxxxx

805 xxxxxxxx

807 xxxxxxxx



809 xxxxxxxx

811 xxxxxxxx

813 xxxxxxxx

814 xxxxxxxx

a Antenna d Sorting ƒ Page " Select / Tools ' Return

Air

Watch

Select this to watch the channel.

Selected item: 1

Tools

xxxxxxxx

801

801 xxxxxxxx

Watch

803 xxxxxxxx

xxxxxxxx

803

Add to Favourites Lock

805 xxxxxxxx

xxxxxxxx

805

Edit Channel Number

807 xxxxxxxx

xxxxxxxx

807

Delete

809 xxxxxxxx

xxxxxxxx

809

Deselect All

811 xxxxxxxx

xxxxxxxx

811

Select All

813 xxxxxxxx

xxxxxxxx

813

" Enter ' Return

815 xxxxxxxx

xxxxxxxx

815

1/2 Pages

Channel number

05 Setup

Edited Channels : Press the ◄▲▼ buttons to check edited channels.

• Channels ( according to channel type. (All, TV, Radio, Data/

) : Shows the channel list

Other)

• Favourites (

) : Shows all favourite channel.

(Favourites 1, Favourites 2, Favourites 3......)

Shows the stored channels.

Navigation Help : Displays remote control buttons available.

• RED (A) : Selects Air or Cable.

• BLUE (D) : Sorts the list ordered by channel

number or channel name.

• Page : Moves to next or previous page.

• Select : Selects desired Channel.

• Tools : Displays the Channel Manager option.

• Return : Returns to previous menu.

Channel Status Display Icons

Icons Operations

A channel selected.

A channel set as Favourites.

A locked channel.

Add to Favourites / Edit Favourites

Select this to add the desired favourite channel.

Lock / Unlock

Select this to lock the channel.

Edit Channel Number

Select this to edit the channel number. If the Edit Channel Number option is not displayed

in the Channel Manager, set it to Enable in the channels menu. (See page 44).

This menu will be displayed only when you set the antenna source type and country as below.

Antenna source Country

Air Ireland

Delete

Select this to delete the Channel.

Deselect All

Select this to deselect all channel.

Select All

Select this to select all channel.

NOTE

✎

`For satellite broadcasting, editing the channel

numbers may be possible depending on the specification.

English 35

Setup

Settings

1. Press the MENU button.

The home menu will be displayed.

2. Press the ◄► buttons to select the Settings, then press the ENTER button.

3. Press the ▲▼ buttons to select the desired submenu, then press the ENTER button.

4. Press the ▲▼ buttons to select the desired item, then press the ENTER button.

5. Press the EXIT button to exit the menu.

Display

You can configure various display options such as the TV Aspect Ratio, Resolution, etc.

3D Settings

Select whether to play a Blu-ray Disc with 3D contents in 3D Mode.

Settings

Display

Audio

Channel

Network

System

Language

Security

General

Support

3D Blu-ray Playback Mode

3D Blu-ray Discs are available in two formats : Blu-ray 3D and 3D only. You can choose to watch a Blu-ray 3D disc in 3D or 2D mode before playing the disc.

• Auto : Automatically detect if a connected TV

has 3D capability and play a Blu-ray 3D disc in 3D or 2D accordingly or a 3D only disc in 3D if the TV supports 3D. 3D only discs will not be played if your TV does not support 3D.

• 3D  3D : Play 3D only and Blu-ray 3D discs in

3D mode at all times.

• 3D  2D : Play Blu-ray 3D discs in 2D mode at

all times. 3D only discs will not be played.

3D Settings

3D Blu-ray Playback Mode : Auto

Screen Size :

> Move " Enter ' Return

HDMI Deep Color : Auto

inch

NOTE

✎

`Depending on the content and the position of the

picture on your TV screen, you may see vertical black bars on the left side, right side, or both sides.

Screen Size

Lets you enter the actual screen size of your TV so that the product can adjust the image according to the screen size and display an optimal 3D image. (For 3D displays bigger than 116 inches, simply setting it as 116 is a safe choice.)

CAUTION

`If you want to enjoy 3D content, connect a 3D device

(3D compliant AV receiver or TV) to the product’s HDMI OUT port using a high-speed HDMI cable. Put on 3D glasses before playing the 3D content.

`The product outputs 3D signals only through HDMI

cable connected to the HDMI OUT port.

`As the video resolution in 3D play mode is fixed

according to the resolution of the original 3D video, you can not change the resolution to your preference.

`Some functions such as BD Wise, screen size

adjustment, and resolution adjustment may not operate properly in 3D play mode.

`You must use a high-speed HDMI cable for proper

output of the 3D signal.

`Stay at least three times the width of the screen

from the TV when watching 3D images. For example, if you have a 46 inch screen, stay 138 inches (11.5 feet) from the screen.

- Place the 3D video screen at eye level for the best 3D picture.

`When the product is connected to some 3D devices,

the 3D effect may not function properly.

`“Blu-ray 3D” and “Blu-ray 3D” logo are trademarks

of the Blu-ray Disc Association.

36 English

TV Aspect

Depending on the type of television you have, you may want to adjust the screen size setting.

• 16:9 Original : Select when you connect the

product to a 16:9 TV screen. The product will display all content in its original aspect ratio. Content formatted in 4:3 will be displayed with black bars on the left and right.

• 16:9 Full : Select when you connect the

product to a 16:9 TV screen. All content will fill the full screen. Content formatted in 4:3 will be stretched.

• 4:3 Letter Box : Select when you connect the

product to a 4:3 TV screen. The product will display all content in its original aspect ratio. Content formatted in 16:9 will be displayed with black bars on the top and bottom.

• 4:3 Pan-Scan : Select when you connect the

product to a 4:3 TV screen. 16:9 content will have the extreme left and right portions cut off.

NOTE

✎

`Depending on the disc type, some aspect ratios may

not be available.

`If you select an aspect ratio and option which is

different than the aspect ratio of your TV screen, then the picture might appear to be distorted.

`If you select the 16:9 Original, your TV may display

4:3 Pillarbox (black bars on sides of picture).

Smart Hub Screen Size

Set the Smart Hub Screen to the optimal size.

• Size 1 : Smart Hub screen size will be smaller

than default. You may see some black on sides of screen.

• Size 2 : This is the default setting for Smart

Hub. The product displays the normal Smart Hub screen size.

• Size 3 : This will display a larger Smart Hub

screen size. The image may be too large for your TV screen.

BD Wise (Samsung Products only)

BD Wise is Samsung’s latest inter-connectivity feature.

When you connect a Samsung product and a Samsung TV with BD Wise to each other via HDMI, and BD Wise is on in both the product and TV, the product outputs video at the video resolution and frame rate of the Blu-ray Disc/DVDs.

• Off : The output resolution stays fixed at the

resolution you set previously in the Resolution menu, regardless of the resolution of the disc. See Resolution below.

• On : The product outputs video at the original

resolution and frame rate of the Blu-ray Disc/ DVDs.

NOTE

✎

`When BD Wise is on, the Resolution setting

automatically defaults to BD Wise and BD Wise appears in the Resolution menu.

`If the product is connected to a device that does

not support BD Wise, you can not use the BD Wise function.

`For proper operation of BD Wise, set the BD Wise

menu of both the product and the TV to On.

Resolution

Lets you set the output resolution of the Component and HDMI video signal to Auto, 1080p, 1080i, 720p, 576p/480p, or 576i/480i. The number indicates the number of lines of video per frame. The i and p indicate interlaced and progressive scan, respectively. The more lines, the higher the quality.

• Auto : Automatically sets the output resolution

to the connected TV’s maximum resolution.

• BD Wise : Automatically sets the resolution to

the resolution of the Blu-ray Disc/DVDs if you have connected the product via HDMI to a TV with the BD Wise feature. (The BD Wise menu item appears only if BD Wise is set to On. See BD Wise above.)

• 1080p : Outputs 1080 lines of progressive

video.

• 1080i : Outputs 1080 lines of interlaced video.

• 720p : Outputs 720 lines of progressive video.

• 576p/480p : Outputs 576/480 lines of

progressive video.

• 576i/480i : Outputs 576/480 lines of interlaced

video.

05 Setup

English 37

Setup

Resolution according to the output mode

Blu-ray Disc/E-contents/Digital Contents playback

HDMI / connected HDMI / not connected

Setup

BD Wise

1080p 1080p 1080p 576i/480i - - -

Movie Frame : Auto (24Fs) 1080p@24F 1080p@24F 480i - - -

1080i 1080i 1080i 576i/480i 576i/480i 576p/480p 576i/480i

720p 720p 720p 576i/480i 576i/480i 576p/480p 576i/480i

576p/480p 576p/480p 576p/480p 576i/480i 576i/480i 576p/480p 576i/480i

576i/480i - - - 576i/480i 576i/480i 576i/480i

DVD playback

Setup

BD Wise 576i/480i 576i/480i - -

1080p 1080p 576i/480i - -

1080i 1080i 576i/480i 576p/480p 576i/480i

720p 720p 576i/480i 576p/480p 576i/480i

576p/480p 576p/480p 576i/480i 576p/480p 576i/480i

576i/480i - - 576i/480i 576i/480i

Output

Auto

Output

Auto

HDMI Mode

Blu-ray Disc

Resolution of

Blu-ray Disc

Max.

Resolution of

TV input

Max. Resolution of TV

E-contents/

Digital

contents

1080p 576i/480i - - -

Max.

Resolution of

TV input

HDMI / connected HDMI / not connected

HDMI Mode

input

Component/ VIDEO Mode

576i/480i - - -

Component/VIDEO Mode

576i/480i - -

Component Mode

Blu-ray Disc

Component Mode VIDEO Mode

E-contents/

Digital

contents

VIDEO Mode

38 English

DTV View

Resolution

Auto

Output

BD Wise 1080p 576i/480i - -

DTV Smart Resolution

“Auto”

DTV Smart Resolution

“Off”

1080p 1080p 576i/480i - -

1080i 1080i 576i/480i 576p/480p 576i/480i

720p 720p 576i/480i 576p/480p 576i/480i

576p/480p 576p/480p 576i/480i 576p/480p 576i/480i

576i/480i - - 576i/480i 576i/480i

Broadcast stream

Max Resolution of

HDMI connected HDMI not connected

HDMI Mode

Resolution of

TV input

Component/

VIDEO MODE

576i/480i - -

Component Mode VIDEO Mode

05 Setup

NOTE

✎

`DTV smart resolution is activated only when

resolution option is set to Auto.

`If the TV you connected to the product does not

support Movie Frame or the resolution you selected, the message “If no pictures are shown after selecting ‘Yes’, please wait for 15 seconds to return to the previous resolution. Do you want to change the resolution?” appears. If you select Yes, the TV’s screen will go blank for 15 seconds, and then the resolution will revert to the previous resolution automatically.

If the screen stays blank after you have changed the resolution, remove all discs, and then press and hold the STOP ( more than 5 seconds. All settings are restored to the factory default. Follow the steps on the previous page to access each mode and select the Display Setup that your TV will support.

`When the factory default settings are restored, all

stored user BD data is deleted.

`The Blu-ray Disc must have the 24 frame feature for

the product to use the Movie Frame (24Fs) mode.

`If both HDMI and Component jacks are connected

and you are currently viewing Component output, the resolution is fixed to 576i/480i.

) button on the front of the product for

`For Copy protected DivX content, the ouput resolution

of component Video is forced to 576i/480i.

`When the HDMI cable is not connected and video

output is component mode, DivX contents with copy protection can only be output 576i/480i.

DTV Smart Resolution

Use this function to automatically optimised screen resolution for digital broadcasts.

• Auto : Screen resolution is automatically

optimised for digital broadcast.

• Off : Turn off DTV Smart Resolution.

NOTE

✎

`When you change your TV channel with this function

set to Auto, according your TV, the display time of next channels may take longer than the function set to Off.

HDMI Colour Format

Lets you set the colour space format for HDMI output to match the capabilities of the connected device (TV, monitor, etc).

• Auto : Automatically sets the product to the

optimum format supported by your device.

• YCbCr (4:4:4) : If your TV supports the YCbCr

colour space via HDMI, select this to output the normal YCbCr colour gamut.

English 39

Setup

• RGB (Standard) : Select this to output the

normal RGB colour gamut.

• RGB (Enhanced) : If you have connected

the product to a DVI display device such as a monitor, select this to output the enhanced RGB colour gamut.

Movie Frame (24Fs)

Setting the Movie Frame (24Fs) feature to Auto allows you to adjust the product’s HDMI output to 24 frames per second for improved picture quality. You can enjoy the Movie Frame (24Fs) feature only on a TV supporting this frame rate. You can select Movie Frame only when the product is in the HDMI 1080i or 1080p output resolution modes.

• Auto : Movie Frame (24Fs) functions work.

• Off : Movie Frame (24Fs) functions are off.

HDMI Deep Color

Lets you output video from the HDMI OUT jack with Deep Colour. Deep Colour provides more accurate colour reproduction with greater colour depth.

• Auto : The product outputs video with Deep

Colour to a connected TV which supports HDMI Deep Colour.

• Off : The picture is output without Deep Colour.

Still Mode

Lets you set the type of picture the product displays when you pause DVD playback.

• Auto : Automatically shows the best still picture

depending on the content.

• Frame : Select when pausing a scene with a

little action.

• Field : Select when pausing a scene with a lot

of action.

Progressive Mode

Lets you improve picture quality when viewing DVDs.

• Auto :

Select to have the select the best picture quality for the DVD you’re watching.

• Video : Select for the best picture quality from

concert or TV show DVDs.

product

automatically

Audio

Digital Output

You set the Digital Output to match the capabilities of the AV receiver you’ve connected to the product :

• PCM : Choose if you have connected an HDMI

supported AV receiver.

• Bitstream (Unprocessed) : Select if you have

connected an HDMI supported AV receiver with Dolby TrueHD and DTS-HD Master Audio decoding capabilities.

• Bitstream (Re-encoded DTS) : Choose if you

have connected an AV receiver using a Digital Optical input that can decode DTS.

• Bitstream (Re-encoded Dolby D) : Select if

you don’t have an HDMI supported AV receiver, but have an AV receiver with Dolby Digital decoding capabilities.

Blu-ray Discs may include three audio streams :

- Main Feature Audio : The audio soundtrack of the main feature.

- BONUSVIEW audio : An additional soundtrack such as the director or actor’s commentary.

- Navigation Sound Effects : When you choose some menu navigation, Navigation Sound Effects may sound. Navigation Sound Effects are different on each Blu-ray Disc.

NOTE

✎

`Be sure to select the correct Digital Output or you

will hear no sound or a loud noise.

If the HDMI device (AV receiver, TV) is not compatible with compressed formats (Dolby digital, DTS), the audio signal outputs as PCM.

`Regular DVDs do not have BONUSVIEW audio and

Navigation Sound Effects.

`Some Blu-ray Discs do not have BONUSVIEW audio

and Navigation Sound Effects.

This Digital Output setup does not effect the analogue (L/R) audio or HDMI audio output to your TV. It effects the optical and HDMI audio output when connected to an AV receiver.

40 English

Digital Output Selection

05 Setup

Setup PCM

Connection

Audio Stream

on Blu-ray

Disc

Audio Stream

on DVD

Audio Stream

of Broadcast

Bitstream

(Re-encoded

DTS)

HDMI supported

AV receiver or

Optical

(Re-encoded

HDMI supported

AV receiver or

Dolby Digital *

PCM

Dolby Digital

Plus

Dolby TrueHD

DTS

DTS-HD High

Resolution

Audio

DTS-HD

Master Audio

HDMI

supported

AV receiver

Up to PCM

7.1ch

Up to PCM

7.1ch

Up to PCM

7.1ch

Up to PCM

7.1ch

Up to PCM

6.1ch

Up to PCM

7.1ch

Up to PCM

7.1ch

Bitstream

(Unprocessed)

HDMI

Optical

supported

Optical

AV receiver

PCM 2ch PCM PCM 2ch Re-encoded DTS

PCM 2ch Dolby Digital Dolby Digital Re-encoded DTS

PCM 2ch

Dolby Digital

Plus

Dolby Digital Re-encoded DTS

PCM 2ch Dolby TrueHD Dolby Digital Re-encoded DTS

PCM 2ch DTS DTS Re-encoded DTS

DTS-HD High

PCM 2ch

Resolution

DTS Re-encoded DTS

Audio

PCM 2ch

DTS-HD

Master Audio

DTS Re-encoded DTS

PCM PCM 2ch PCM 2ch PCM 2ch PCM 2ch PCM 2ch PCM 2ch

Dolby Digital

DTS

Dolby Digital

Plus

MPEG1

HE-AAC

Up to PCM

5.1ch

Up to PCM

6.1ch

Up to PCM

5.1ch

Up to PCM

5.1ch

Up to PCM

5.1ch

Up to PCM

5.1ch

PCM 2ch Dolby Digital Dolby Digital Dolby Digital Dolby Digital

PCM 2ch DTS DTS DTS DTS

PCM 2ch Dolby Digital Dolby Digital Re-encoded DTS

PCM 2ch

Dolby Digital

Plus***

PCM

(up to 5.1ch)

Re-encoded

Dolby Digital**

(for Multichannel

Programme)

Dolby Digital Re-encoded DTS

PCM 2ch Re-encoded DTS

Re-encoded

Dolby Digital**

(for Multichannel

Re-encoded DTS

Programme)

Dolby Digital *

Bitstream

Dolby D)

Optical

Re-encoded

English 41

Setup

Decodes

the

Decodes the main

Decodes the main feature

Definition for Blu-ray Disc

* If the Source Stream is 2ch or mono, “Re-encoded Dolby D” Setting are not applied. Output will be PCM 2ch.

** If HE-AAC Source Stream is 2ch or 1ch, Output shall be 2ch PCM.

For Dolby Digital Plus stream on Internet Content, PCM Output via HDMI supported up to 5.1ch.

*** If the Audio Description is set to On and the Number of Audio Channel is more than 2, audio output

will be changed Dolby Digital even if the original broadcast stream is Dolby Digital Plus. But, if the Number of Audio Channel is 2 (stereo) or 1 and Audio Description is set to On, Output format will be PCM.

Any

audio and BONUSVIEW

audio stream together

into PCM audio and adds

Navigation Sound Effects.

Outputs only the main feature audio stream so that your AV receiver can decode

the audio bitstream.

You will not hear

BONUSVIEW audio or

Navigation Sound Effects.

feature audio and

BONUSVIEW audio

stream together

into PCM audio and

adds Navigation

Sound Effects, then

re-encodes the

PCM audio into DTS

bitstream.

feature audio and

BONUSVIEW audio

into PCM audio and

then re-encodes

into Dolby digital

main

stream together

adds

Navigation

Sound Effects,

the PCM audio

bitstream.

PCM Downsampling

Lets you set 48kHz and 96kHz PCM downsampling on or off.

• Off : Select when the AV receiver connected to

the product is 96kHz compatible.

• On : Select when the AV receiver connected to

the product is not 96kHz compatible. 96kHz signals will be down converted to 48kHz.

NOTE

✎

`Even when PCM Downsampling is set to Off, some

discs will only output downsampled audio through the optical digital outputs.

HDMI

• If your TV is not compatible with compressed multi-channel formats (Dolby Digital, DTS), the product may output PCM 2ch downmixed audio even though you set the digital output as Bitstream (unprocessed/Re-encoded DTS/Reencoded Dolby D) on your setup menu.

• If your TV is not compatible with PCM sampling rates over 48kHz, the product may output 48kHz downsampled PCM audio even though you set PCM Downsampling to Off.

Dynamic Range Control

You can listen at low volumes, but still hear dialog clearly. This is only active if your product detects a Dolby Digital, Dolby Digital Plus or Dolby TrueHD signal.

• Auto : The Dynamic Range Control will be set

automatically based on the information provided by the Dolby TrueHD Soundtrack.

• Off : You can enjoy the movie with the standard

Dynamic Range.

• On : When Movie soundtracks are played at low

volume or through smaller speakers, the system can apply appropriate compression to make low-level content more intelligible and prevent dramatic passages from getting too loud.

Downmixing Mode

Lets you select how the product will downmix multi-channel audio into fewer channels.

• Normal Stereo : Downmixes the multi-channel

audio into two channel stereo. Choose when connected to equipment that does not support virtual surround functions such as Dolby Pro Logic.

• Surround Compatible : Downmixes multi-

channel audio into surround compatible stereo. Choose when connected to equipment that supports virtual surround functions such as Dolby Pro Logic.

42 English

DTS Neo:6 Mode

You can enjoy multi-channel sound from an Audio CD (CD-DA).

• Off : Outputs a 2-channel audio signal through

the front speakers only.

• Cinema : Select to play 2-channel movie sound

over multi-channels.

• Music : Select to play 2-channel music over

multi-channels.

NOTE

✎

`If you are using an HDMI supported AV receiver, this

option is available when you set Digital Output setup as PCM.

Audio Sync

In some cases when the product is connected to a digital TV, the audio signal may not synchronize with the video signal. If this occurs, adjust the audio delay time to match the video signal.

• You can set the audio delay time between 0 msec and 200 msec. Adjust it to the optimal setting.

NOTE

✎

`The audio delay time you specify may not be exact

depending on the played content.

Channel

You can configure your TV channels with features such as country and auto tune.

Antenna

Selects an appropriate type of antenna for digital broadcasts. Before your product can begin memorizing the available channels, you must specify the type of signal source that is connected to the this product.

• Air : Select Air for receiving digital broadcasts.

• Cable : Select Cable for receiving digital

broadcasts.

Country

Select this to change the country. Enter the desired 4-digit password using the number buttons.

1. Press the ►▲▼ buttons to select the desired country, then press the ENTER button.

2. Press the RETURN button.

NOTE

✎

`Enter the desired 4-digit password using the number

buttons. * Default password is set to 0000.

Auto Tuning

Scans for all channels with active broadcast stations and stores them. Scans for a channel automatically and stores in the product. Automatically allocated programme numbers may not correspond to actual or desired programme numbers. If a channel is locked using the Child Lock function, the PIN input window appears.

• Air : Press the ▼ button to select the Search,

then press the ENTER button.

• Cable : Press the ▼ button to select the Next,

then press the ENTER button. Set the Search Mode option, then press the ▼ button to select the Search button.

- Search Mode (Full / Network / Quick) : Scans for all channels with active broadcast stations and stores them in the product.

05 Setup

English 43

Setup

NOTE

✎

`If you select Quick, you can set up the Network,

Network ID, Frequency, Modulation and Symbol Rate manually by pressing the button on the remote control.

- Network (Auto / Manual) : Selects the Network ID setting mode either Auto or Manual.

- Network ID : When Network is Manual, you can set up Network ID using the numeric buttons.

- Frequency : Displays the frequency for the channel. (differs in each country)

- Modulation : Displays available modulation values.

- Symbol Rate : Displays available symbol rates.

Manual Tuning

Scans for a channel manually and stores in the product.

- When scanning has finished, channels are updated in the channel list.

NOTE

✎

`When selecting Antenna  Air : Channel, Frequency,

Bandwidth. When selecting Antenna  Cable : Frequency, Modulation, Symbol Rate

Cable Search Option

Sets additional search options such as the frequency and symbol rate for a cable network search.

- Start Frequency/Stop Frequency : Set the start or stop frequency (differs in each country).

- Symbol Rate : Displays available symbol rates.

- Modulation : Displays available modulation values.

Transfer Channel List

This function can import or export the channel map. You should connect a USB storage to use this function. Enter your 4 digit PIN number when the PIN input screen appears.

•

Import from USB : Import channel list from USB.

• Export to USB : Export channel list to USB.

This function is available when USB is connected.

Edit Channel Number

Select this to edit the channel number in the channel manager. (See page 35)

• Disable : Select disable if you do not want to

edit channel number.

• Enable : Select enable if you want to edit

channel number.

This menu will be displayed only when you set the antenna source type and country as below.

Antenna source Country

Air Ireland

Digital Text

If the programme broadcasts with digital text, this feature is enabled.

• Disable : Select disable if you do not want to

use digital text.

• Enable : Select enable if you want to use digital

text.

Common Interface

Show the CI Menu Information screen.

• CI Menu : This enables the user to select from

the CAM provided menu. Select the CI Menu based on the menu PC Card.

• Application Info. : View information on the

CAM(Conditional Access Module) inserted into the CI slot and on the “CI CAM with CI or CI+ CARD” which is inserted into the CAM. You can install the CAM anytime whether the product is on or off.

1. Purchase a CI CAM at your nearest dealer or

by phone.

Firmly insert the “CI CAM with CI or CI+ CARD” into the CAM in the direction of the arrow.

44 English

3. Insert the CAM with the “CI CAM with CI or

CI+ CARD” into the common interface slot, in the direction of the arrow so that it aligns parallel with the slot.

4. Check if you can see a picture on a scrambled

signal channel.

NOTE

✎

`This Device is work with CI and CI+ CAM.

But in case of some local DVB-T association, this device doesn't have perfect compatibility with all kinds of CAM. If there is a problem, pull the CAM CARD out of the Set and insert it into the slot again.

Wired Network

Setting Up a Wired Connection - Auto

1. Press the ▲▼ buttons to select Wired.

Settings

Display

Audio

Channel

Network

System

Language

Security

General

Support

Network Settings

Select a network connection type.

Wired

Wireless

(general)

Connect to the network using a LAN cable. Please

WPS(PBC)

sure that the LAN cable is connected.

One Foot

Connection

> Move " Enter ' Return

make

05 Setup

Network

Before you begin, contact your ISP to find out if your IP address is static or dynamic. If it is dynamic, and you are using a wired or wireless connection, we recommend using the Auto procedures. If you are using a wireless connection and your router has the capability, you can use WPS(PBC) or One Foot Connection.

If your IP address is static, you must use the manual set up procedure for both wired and wireless connections.

Network Settings

To begin setting up the network connection for your product, follow these steps:

1. In the Home menu, press the ◄► buttons to select Settings, and then press the ENTER button.

2. Press the ▲▼ buttons to select Network, and then press the ENTER button.

3. Press the ▲▼ buttons to select Network Settings, and then press the ENTER button.

4. Press the ▲▼ buttons to select Wired, Wireless (general), WPS(PBC) or One Foot Connection, and then press the ENTER

button.

5. If you have a wired network, go to Wired Network below. If you have a wireless network, go to Wireless Network on pages 46~49.

2. Press the ENTER button.

The Network Status screen appears. The product connects to the network after the network connection is verified.

Setting Up a Wired Connection - Manual

If you have a static IP address or the Auto Setting does not work, you’ll need to set the Network Settings values manually.

To view your Network Settings values on most Windows computers, follow these steps:

Windows XP

1. Right click the Network icon on the bottom

right of the Windows desktop.

2. In the pop-up menu, click Status.

3. On the dialog that appears, click the Support

tab.

4. On the Support tab, click the Details button.

The Network settings are displayed.

Windows 7

1. Click the Network icon on the bottom right of

the Windows desktop.

2. In the pop-up menu, click Network and

Sharing Centre.

3. On the dialog that appears, click the Local

Area Connection or Wireless Network Connection depending on your network connection.

4. On the Support tab, click the Details button.

The Network settings are displayed.

English 45

Setup

NOTE

✎

`Depending on your Windows version, the information

may differ.

To enter the Network settings into your product, follow these steps:

1. Press the ▲▼ buttons to select Wired, and then press the ENTER button.

2. Press the ◄► buttons to select IP Settings, and then press the ENTER button.

3. On the Network Status screen, select Cancel, and then press Enter.

Settings

Display

Audio

IP Mode Manual

Channel

Network

System

Language

DNS Mode Manual

Security

General

Support

IP Address

Subnet Mask

Gateway

DNS Server

IP Settings

0.0.0.0

> Move " Enter ' Return

4. Press the ENTER button to select IP Mode.

5. Press the ▲▼ buttons to select Manual, and then press the ENTER button.

6. Press the ▼ button to go to the first entry field

(IP Address).

7. Use the number buttons on your remote to enter numbers.

8. When done with each field, press the ► button to move successively to the next field. You can also use the other arrow buttons to move up, down, and back.

9. Enter the IP Address, Subnet Mask, and Gateway values.

10. Press the ▼ button to go to DNS Mode.

11. Press the ▼ button to go to the first DNS

entry field. Enter the numbers as above.

12. Press the ENTER button to select OK. The Network Status screen appears. The product connects to the network after the network connection is verified.

Wireless Network

You can setup a wireless network three ways:

• Wireless (general)

• Using WPS(PBC)

• One Foot Connection

Wireless (general) includes both Automatic and Manual setup procedures.

Setting Up the Wireless Network Connection

- Auto

Most wireless networks have an optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security Key. The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network. If you use this method of setting up the network connection, and have a Security Key for your wireless network, you will have to enter the Pass Phrase during the Auto setup process.

1. Press the ▲▼ buttons to select Wireless (general).

Settings

Display

Select a network connection type.

Audio

Channel

Network

Wired

System

Wireless (general)

Language

Security

WPS(PBC)

General

One Foot

Connection

Support

Network Settings

Set up a wireless network by selecting your wireless router. You may need to enter a security key depending on the settings of the wireless router.

> Move " Enter ' Return

2. Press the ENTER button. When done, it displays a list of the available networks.

3. Press the ▲▼ buttons to select the desired network, and then press the ENTER button. The Security screen appears.

46 English

On the Security screen, enter your network’s Pass Phrase. Enter numbers directly using your remote control. To select a letter, press the ▲▼◄► buttons to move the cursor, then press the ENTER button.

Settings

✎

Display

Audio

Channel

Network

System

Language

Security

General

Support

NOTE

Network Settings

Enter security key. 0 entered

a b c d e f 1 2 3

g h i j k l 4 5 6

m n o p q r 7 8 9

s t u v w x y z 0

a/A

Delete Space Done

a Previous m Move " Enter ' Return

`You should be able to find the Pass Phrase on one of

the set up screens you used to set up your router or modem.

5. When done, press the GREEN (B) button on

your remote, or press the ▲▼◄► buttons to move the cursor to Done, and then press the ENTER button. The Network Status screen appears. The product connects to the network after the network connection is verified.

Setting Up the Wireless Network Connection

- Manual

If the Auto Setting does not work, you need to enter the Network setting values manually.

To view your Network Settings values on most Windows computers, follow these steps:

Windows XP

1. Right click the Network icon on the bottom

right of the Windows desktop.

2. In the pop-up menu, click Status.

3. On the dialog that appears, click the Support

tab.

4. On the Support tab, click the Details button.

The Network settings are displayed.

Windows 7

1. Click the Network icon on the bottom right of

the Windows desktop.

2. In the pop-up menu, click Network and

Sharing Centre.

3. On the dialog that appears, click the Local

Area Connection or Wireless Network Connection depending on your network connection.

4. On the Support tab, click the Details button.

The Network settings are displayed.

NOTE

✎

`Depending on your Windows version, the information

may differ.

To enter the Network settings into your product, follow these steps:

1. Follow Steps 1 through 4 in the ‘Setting Up

the Wireless Network Connection - Auto’ procedure.

2. When done, press the GREEN (B) button on

your remote, or press the ▲▼◄► buttons to move the cursor to Done, and then press the ENTER button. The Network Status screen appears.

3. On the Network Status screen, select Cancel,

and then press Enter.

4. Press the ◄► buttons to select IP Settings, and then press the ENTER button.

Settings

Display

Audio

IP Mode Manual

Channel

Network

System

Language

DNS Mode Manual

Security

General

Support

IP Address

Subnet Mask

Gateway

DNS Server

IP Settings

0.0.0.0

> Move " Enter ' Return

5. Press the ENTER button to select IP Mode.

6. Press the ▲▼ buttons to select Manual, and then press the ENTER button.

7. Press the ▼ button to go to the first entry field

(IP Address).

8. Use the number buttons to enter numbers.

05 Setup

English 47

Setup

9. When done with each field, press the ►

button to move successively to the next field. You can also use the other arrow buttons to move up, down, and back.

10. Enter the IP Address, Subnet Mask, and Gateway values.

11. Press the ▼ to go to DNS Mode.

12. Press the ▼ button to go to the first DNS

entry field. Enter the numbers as above.

13. Press the OK button.

14. The Network Status screen appears. The

product connects to the network after the network connection is verified.

WPS(PBC)

The easiest way to set up the wireless network connection is using the WPS(PBC) function or the One Foot Connection function.

If your wireless router has a WPS(PBC) button, follow these steps:

1. Press the ▲▼ buttons to select WPS(PBC).

Settings

Display

Select a network connection type.

Audio

Channel

Network

Wired

System

Wireless

(general)

Language

Security

WPS(PBC)

General

One Foot

Connection

Support

Network Settings

Connect to the wireless router easily by pressing the WPS(PBC) button. Choose this if your wireless router supports push button configuration(PBC).

> Move " Enter ' Return

1. Press the ▲▼ buttons to select One Foot Connection.

Settings

Display

Select a network connection type.

Audio

Channel

Network

Wired

System

Wireless (general)

Language

Security

WPS(PBC)

General

One Foot

Connection

Support

Network Settings

Connect to the wireless network automatically if your wireless router supports One Foot Connection. Select this connection type after placing the wireless router within 10 inches (25 cm) of product.

> Move " Enter ' Return

2. Press the ENTER button.

3. Place the Samsung Wireless Router within 25

cm (10 inches) of your product to connect.

4. Wait until the connection is automatically established.

Network Status

Check whether a connection to the network and the Internet have been established.

Settings

Display

Audio

Channel

Network

System

Internet is connected successfully. If you have a problem using any Internet services, contact your Internet service

Language

provider.

Security

General

Support

Network Settings

iptime

Network Status

MAC Address XX:XX:XX:XX:XX:XX IP Address 0.0.0.0 Subnet Mask 0.0.0.0 Gateway 0.0.0.0 DNS Server 0.0.0.0

IP Settings Retry

< Move " Enter ' Return

2. Press the ENTER button.

3. Press the WPS(PBC) button on your

router within two minutes. Your product automatically acquires all the network settings values it needs and connects to your network.

4. The Network Status screen appears. The

player connects to the network after the network connection is verified.

One Foot Connection

You can set up the wireless connection automatically if you have a Samsung Wireless Router which supports One Foot Connection. To connect using the One Foot Connection function, follow these steps:

48 English

SWL(Samsung Wireless Link)

Mobile devices with Samsung Wireless Link capability can be connected to your network via this product.

• Off : Set Samsung Wireless Link off.

• On : Set Samsung Wireless Link On.

1. If you select On, press the ▲▼ buttons to select the Connect SWL, then press the ENTER button. Please follow the instruction on TV Screen.

NOTE

✎

`If this product turned off, the network connection

using SWL will be disconnected.

AllShare Server Management

Manage content sharing function. You can share media contents (videos, music, photos) via the AllShare function.

• AllShare Server : Set the server function.

• Change Server Name : Set the server name.

Enables you to identify the server on a network.

• Device Access Control : Configures access

authorization for individual device.

BD-Live Internet Connection

Set to allow or prohibit an Internet connection when you use the BD-LIVE service.

• Allow (All) : The Internet connection is allowed

for all BD-LIVE contents.

• Allow (Valid Only) : The Internet connection is

allowed only for BD-LIVE contents containing a valid certificate.

• Prohibit : No Internet connection is allowed for

any BD-LIVE content.

NOTE

✎

`What is a valid certificate?

When the product uses BD-LIVE to send the disc data and a request to the server to certify the disc, the server uses the transmitted data to check if the disc is valid and sends the certificate back to the product.

`The Internet connection may be restricted while you

are using BD-LIVE contents.

System

Plug & Play

By using Plug & Play, you can set country, clock mode and Network Settings, etc. For more information about the Plug & Play function, refer to the Plug & Play section of this user manual. (See pages 33~54)

NOTE

✎

`If you want to change plug & play options, you

should enter the password.

Clock

Set time-related functions.

•

Clock Mode : You can set it to Auto or Manual.

• Clock Set : If Clock Mode set to Manual, the

this menu will be activated.

NOTE

✎

`If Timer Viewing and Timer Recording is set using

GUIDE, Channel List, or Info menu, It will work based on the time information of the TV programme. If you set the Clock Mode to Manual and change time manually, Timer Viewing and Timer Recording function can be limited or work abnormally.

Anynet+(HDMI-CEC)

Anynet+ is a convenient function that offers linked operations with other Samsung products that have the Anynet+ feature. To operate this function, connect this product to a Samsung TV with an HDMI cable. With Anynet+ on, you can operate this product using a Samsung TV remote control and start disc playback simply by pressing the PLAY ( ) button on the TV’s remote control. For more information, please see the TV user manual.

• Off : Anynet+ functions will not work.

• On : Anynet+ functions will work.

NOTE

✎

`This function is not available if the HDMI cable does

not support CEC.

`If your Samsung TV has an Anynet+ logo, then it

supports the Anynet+ function.

`Depending on your TV, certain HDMI output

resolutions may not work. Please refer to the user manual of your TV.

`If you press the Play button of TV when product is in

DTV mode, Time Shift function will start.

05 Setup

English 49

Setup

Device Management

Manage internal HDD and external devices. You can manage options such as device format and default recording device.

Settings

Display

Audio

Channel

Network

System

Language

Security

General

Support

• Device Format : Format the device.

• Checking Device : Checks for errors on the

device.

• Device Performance Test : Test the recording

performance of the device.

• Default Recording Device : Select default

recording device.

By HDD

1. Select the Default Recording Device, and then press the ENTER button.

2. Select recording device to HDD. (You can also check available storage in this menu.)

Settings

Display

Audio

Channel

Network

System

Language

Security

General

Support

Plug & Play

Device Management

Device Format

Checking Device

Device Performance Test

Default Recording Device : HDD

HDMI Deep Color : Auto

> Move " Enter ' Return

Plug & Play

Default Recording Device

HDD XXX.XX GB/XXX.XX GB

Select default device for recording.

 HDD Internal storage

abc Recordable



HDMI Deep Color : Auto

> Move " Enter ' Return

By External Device

1. In Stop mode, connect the external storage

device to the USB port on the front panel of the product.

2. Select the Device Format, and then press the ENTER button. Device format will be started.

3. Select the Default Recording Device, and then press the ENTER button.

Settings

Display

Audio

Channel

Network

System

Language

Security

General

Support

Plug & Play

Default Recording Device

HDD XXX.XX GB/XXX.XX GB

Select default device for recording.

 HDD Internal storage

abc Recordable



HDMI Deep Color : Auto

> Move " Enter ' Return

4. Select recording device to connected external device. (You can also check available storage in this menu.)

NOTE

✎

`It may take several times to detect a connected

external device.

`The total size of device must have at least 375MB of

free space to use the time shift function.

`In case of USD HDD is used for recording, Don't

plug-out USB HDD Device during format.

`Recording Function is supported only for DTV.

`Recording Function is not supported for data

channel.

`Maximum length of Recording or Time shift is

affected by available size of storage device and the Video resolution of TV Programme.

50 English

BD Data Management

Enables you to manage the downloaded contents from a Blu-ray Disc that supports the BD-LIVE service.

You can check the device information including the storage size, delete the BD data.

• Current Device : Displays the current device.

• Total Size : Displays the total size of the device.

(Storage)

• Available Size : Displays the available size of

the device. (Storage)

• Delete BD Data : Press this to delete the BD

data.

NOTE

✎

`The total size of BD Data Management may differ,

depending on the conditions.

DivX® Video On Demand

View DivX® VOD Registration Codes to purchase and play DivX® VOD contents.

Security

This function works in conjunction with Blu-ray Disc/DVDs that have been assigned an age rating or numeric rating that indicates the maturity level of the content. These numbers help you control the types of Blu-ray Disc/DVDs that your family can watch.

When you access this function, the security screen appears. Enter the your Security password. (The default password is 0000.)

NOTE

✎

`Enter the desired 4-digit password using the number

buttons. * Default password is set to 0000.

05 Setup

Reset

All settings will revert to the default except for the network and Smart Hub settings.

NOTE

✎

`The default password is 0000.

Language

You can select the language you prefer for the Home menu, disc menu, etc.

• On-Screen Menu : Select the language for the

on-screen displays.

• BD/DVD Disc Menu : Select the language for

the disc menu displays.

• BD/DVD Audio : Select the language for disc

audio language.

• BD/DVD Subtitle : Select the language for disc

subtitle language.

• DTV Primary Audio : Select the language for

DTV primary audio language.

• DTV Secondary Audio : Select the language

for DTV secondary audio language.

• DTV Primary Subtitle : Select the language for

DTV primary subtitle language.

• DTV Secondary Subtitle : Select the language

for DTV secondary subtitle language.

• DTV Primary Teletext : Select the language for

DTV primary teletext language.

• DTV Secondary Teletext : Select the language

for DTV secondary teletext language.

NOTE

✎

`The selected language will only appear if it is

supported on the disc or broadcast channel.

DTV Channel Lock

You can lock some channels using the Channel Lock function so that children cannot watch them.

• Off : DTV Channel Lock will not work.

• On : DTV Channel Lock will work.

DTV Program Rating Lock

This function works in conjunction with DTV that have been assigned a rating, which helps you control the types of DTV that your family watches. Select the rating level you want to set.

BD Parental Rating

Prevent playback of Blu-ray Discs with specific age ratings unless a password is entered.

DVD Parental Rating

Prevent playback of DVDs with specific numerical ratings unless a password is entered. A larger number indicates that the programme is intended for adult use only. For example, if you select up to Level 6, discs that contain Level 7, 8 will not play.

English 51

Setup

Change PIN

Change the 4-digit password used to access security functions.

If you forgot your password

1. Press the MENU button to display home

menu with no disc inserted.

2. Press the STOP (

panel of the product for more than 5 seconds. All settings will revert to the factory settings.

NOTE

✎

`When the factory default settings are restored, all

the user stored BD data will be deleted.

) button on the front

General

Energy Saving

You can reduce power consumption by setting the front panel to turn off automatically when the product is in standby mode.

• Off : Set not to use the energy saving function.

• On : Turn off the front panel automatically when

the product is in standby mode.

Light Effect

You can adjust the light effect on the product.

• Always On : Activate Light Effect at all times.

It is recommended for continuous display for commercial or demonstration use.

• Auto : Activate Light Effect when you turn the

product on or off and when you insert or eject a disc. This is recommended for home use.

• Off : Turn Light off.

Advanced Music Copy

When you copy music files, information can be updated automatically. The copying time may be increased.

• Off : Turn Advanced Music Copy Off.

• On : Turn Advanced Music Copy On.

NOTE

✎

`This feature is available only when the product is

connected to the network.

`This can be used if you copy from an external device

such as USB/ODD/AllShare to the HDD.

`This will not work if you copy from the HDD to an

external device.

Network Remote Control

The Network Remote Control function lets you control your product from a remote device such as a smart phone through a wireless connection to your local area network.

To use the Network Remote Control function, follow these steps:

1. Select On in the Network Remote Control menu.

2. Install the Samsung network remote control application to control your product on your compatible portable device.

3. Make sure your portable device and your product are connected to the same wireless router.

4. Start the application on your portable device. The application should find your product and display it on a list.

5. Select the product.

6. If this is the first time you are using the

function, it will ask you to allow or deny remote control of the product. Select Allow.

7. Follow the instructions that came with the application to control the product.

Support

Software Upgrade

The Software Upgrade menu allows you to upgrade the product’s software for performance improvements or additional services.

By Internet

To upgrade by Internet, follow these steps:

1. Select By Internet, and then press the ENTER button. The Connecting to Server

message appears.

2. If there is a download available, the Download pop-up appears with a progress bar and the download starts.

52 English

3. When the download is complete, the Upgrade

Query window appears with three choices: Upgrade Now, Upgrade Later, or Don’t Upgrade.

4. If you select Upgrade Now, the product

upgrades the software, turns off, and then turns on automatically.

5. If you do not make a selection in one minute

or select Upgrade Later, the product stores the new upgrade software. You can upgrade the software later using the Via Download function.

6. If you select Don’t Upgrade, the product

cancels the upgrade.

NOTE

✎

`Your product must be connected to the Internet to

use the By Internet function.

`The upgrade is complete when the product turns off,

and then turns on again by itself.

`Never turn the product off or back on manually

during the update process.

`Samsung Electronics shall take no legal responsibility

for product malfunction caused by an unstable Internet connection or consumer negligence during a software upgrade.

`If you want to cancel the upgrade while the upgrade

software is downloading, press the ENTER button.

By Channel

Upgrade software using the broadcasting signal.

By USB

To upgrade by USB, follow these steps:

1. Visit www.samsung.com/bluraysupport.

2. Download the latest USB software upgrade

zip archive to your computer.

3. Unzip the zip archive to your computer. You

should have a single folder with the same name as the zip file.

4. Copy the folder to a USB flash drive.

5. No disc should be inserted in the product,

and then insert the USB flash drive into the USB port of the product.

6. In the product’s menu, go to Settings >

Support > Software Upgrade.

7. Select By USB.

NOTE

✎

`No disc should be inserted in the product when you

upgrade the software using the USB Host jack.

`When the software upgrade is done, check the

software details in the Software Upgrade menu.

`Do not turn off the product during the software

upgrade. It may cause the product to malfunction.

`Software upgrades using the USB Host jack must be

performed with a USB memory flash stick only.

By Disc

To upgrade by Disc, follow these steps:

1. Visit www.samsung.com/bluraysupport.

2. Download the latest disc software upgrade

zip archive to your computer.

3. Unzip the zip archive to your computer. You

should have a single folder with the same name as the zip file.

4. Write the folder onto a disc. We recommend a

CD-R or DVD-R.

5. Finalize the disc before you remove it from

your computer.

6. Insert the disc into product.

7. In the product’s menu, go to Settings >

Support > Software Upgrade.

8. Select By Disc.

NOTE

✎

`When the system upgrade is done, check the

software details in the Software Upgrade menu.

`Do not turn off the product during the Software

Upgrade. It may cause the product malfunction.

Via Download

The Via Download option lets you upgrade using a file the product downloaded earlier but you decided not to install immediately or a file downloaded by the product in Standby Mode (See Download in Standby Mode below).

To upgrade Via Download, follow these steps:

1. If upgrade software has been downloaded,

you will see the software version number to the right of Via Download.

2. Select Via Download, and then press the ENTER button.

05 Setup

English 53

Setup

Basic Functions

3. The product displays a message asking if you want to upgrade. Select Yes. The product begins the upgrade.

4. When the update is complete, the product turns off automatically, and then turns on.

NOTE

✎

`When the system upgrade is done, check the

software details in the Software Upgrade menu.

`Do not turn off the product during the Software

Upgrade. It may cause malfunction to the product.

Download in Standby Mode

You can set the Download in Standby Mode function so that the product downloads new upgrade software when it is in Standby mode. In Standby mode, the product is off, but its Internet connection is active. This allows the product to download upgrade software automatically, when you are not using it.

To set Download in Standby Mode, follow these steps:

1. Press the ▲▼ buttons to select Download in Standby Mode, and then press the ENTER

button.

2. Select the desired downloaded time. If you select Off, the product will notify you with a pop up message when new upgrade software is available. If you select the desired downloaded time, the product will automatically download new upgrade software when it is in Standby mode with the power off. If it downloads new upgrade software, the product will ask you if you want to install it when you turn the product on.

NOTE

✎

`To use the Download in Standby Mode function, your

product must be connected to the Internet.

Contact Samsung

Provides contact information for assistance with your product.

Playing a Video

Playback

Push a disc into the product with the disc’s label facing up.

2. Press the PLAY ( ) button.

Playback related buttons

PLAY (

) Starts playback.

Stops playback.

STOP (

PAUSE (

NOTE

✎

`For some discs, pressing the STOP (

once may not memorize the stop position.

`Video files with high bit rates of 20Mbps or more

strain the product’s capabilities and may stop playing during playback.

• If you press the button once : The

)

stop position is memorized.

• If you press the button twice : The stop position is not memorized.

) Pauses playback.

) button

3D Converter

This function can convert the 2D output of 2D contents into 3D.

1. Connect this product to a TV that supports

3D using an HDMI cable.

2. When you play 2D contents, press the 2D3D button on the remote control to

convert 2D into 3D contents.

54 English

3. You can toggle between 2D and 3D by pressing the 2D3D button repeatedly. If you are playing 3D contents in the 3D mode, you cannot use this function.

NOTE

✎

`You can’t convert 2D contents into 3D or use the

2D3D button In the following cases:

- When the product is not connected with an HDMI cable

- When the connected TV does not support 3D

- When you are playing 3D contents (disc, file).

`2D content is converted into the following 3D

formats:

- 1080p 24fps : Output to 1080p 24 fps 3D.

- Others : Output to 720p 3D.

- Photo files : Output to 720p 3D.

`2D content that the product can convert to 3D:

- 2D content that supports 3D conversion

- Smart Hub content, DVD Video, BD-ROM, VCD, Video files, photo files, DTV programme, and recorded DTV programme.

`When you use the 3D converter, the BONUSVIEW

function is not available. (Depending on the disc, a black outline appears.)

`Some viewers may experience discomfort while

viewing 3D contents such as dizziness, nausea, and headaches.

Adjusting the 3D Depth

The 3D Depth function lets you adjust the 3D depth of 2D to 3D conversions. Values range from 1 to 10. The higher the number, the deeper the 3D

depth.

1. When you are viewing converted 3D contents, press the TOOLS button.

2. Press the ▲▼ buttons to select 3D Depth, and then press the ENTER button.

3. Adjust the 3D Depth using the ◄► buttons.

Disc Structure

The content of discs are usually divided as shown below.

• Blu-ray Disc, DVD-VIDEO

title 1 title 2

chapter 1 chapter 2 chapter 1 chapter 2 chapter 3

• Audio CD (CD-DA)

track 1 track 2 track 3 track 4 track 5

• MP3, WMA, DivX, MKV and MP4

folder (group) 1 folder (group) 2

file 1 file 2 file 1 file 2 file 3

NOTE

✎

`Playback during recording converts the media into

profile 1.0, while normal playback only supports profile 2.0. In such cases, the following limitations are applied:

- BONUSVIEW is not available.

- Browsable slideshow audio is not available. (Audio may not be produced in Disc Menu mode for some discs.)

06 Basic Functions

English 55

Basic Functions

Using the Disc Menu/Title Menu/

Popup Menu

Using the Disc Menu

1. During playback, press the DISC MENU button on the remote control.

2. Press the ▲▼◄►

selection, and then press the ENTER button.

NOTE

✎

`Depending on the disc, the menu items may differ

and this menu may not be available.

Using the Title Menu

1. During playback, press the TITLE MENU button on the remote control.

2. Press the ▲▼◄► buttons to make

the desired selection, then press the

ENTER button.

NOTE

✎

`Depending on the disc, the menu items may differ

and this menu may not be available.

Playing the Title List

1. During playback, press the DISC MENU or TITLE MENU button.

2. Press the ▲▼ buttons to select an

entry you want to play from the Title List, and then press the ENTER button.

NOTE

✎

`If your disc has a playlist, press the GREEN (B) button

to go to the playlist.

buttons to make a

Using the Popup Menu

1. During playback, press the POPUP MENU button on the remote control.

2. Press the ▲▼◄► buttons or ENTER

button to select the desired menu.

NOTE

✎

`Depending on the disc, the menu items may differ

and this menu may not be available.

Using the Search and Skip Functions

During play, you can search quickly through a chapter or track, and use the Skip function to jump to the next selection.

Searching for a Desired Scene

ThzZyx

• During playback, press the SEARCH ( )

button. Each time you press the SEARCH ( )

button, the playback speed will change as follows

HDD,

BD-ROM,

BD-RE/-R,

DVD-RW/-R,

DVD+RW/+R,

DVD-VIDEO

DivX, MKV, MP4

• To return to normal speed playback, press the

PLAY (

NOTE

✎

`The product does not play sound in search mode.

) )

( (

) (

) button.

)



)



(



(



)



(



2  ) 3  5  ) 6  ) 7

2  ( 3  5  ( 6  ( 7

2  ) 3 2  ( 3

56 English

Skipping Chapters

ThzZyx

• During playback, press the SKIP ( )

button. If you press the SKIP (

moves to the next chapter. If you press the SKIP (

moves to the beginning of the chapter. One more press makes the disc move to the beginning of the previous chapter.

Slow Motion Play/Step Motion Play

Slow Motion Play

) button, the disc

Using the TOOLS button

During playback, you can operate the disc menu by pressing the TOOLS button.

• Tools Menu Screen

<BD-ROM / DVD>

Tools

Title Search 1/2

Chapter Search : 1/20

Time Search : 00:00:13/01:34:37

Repeat Mode : 0ff

Picture Settings : Normal

Audio : 1/1 JPN 2CH

Subtitle : 0/2 Off

Angle : 1/1

BONUSVIEW Video : Off

BONUSVIEW Audio : 0/1 Off

< Change " Enter ' Return

06 Basic Functions

ThzZyx

• In pause mode, press the SEARCH ( )

button. Each time you press the SEARCH (

) button,

the playback speed will change as follows:

1/8 * 1/4 * 1/2

• To return to normal speed playback, press the

PLAY (

✎

NOTE

) button.

`The product does not play sound in Slow mode.

Step Motion Play

hzZyx

• In pause mode, press the PAUSE ( ) button. Each time you press the PAUSE (

new frame appears.

• To return to normal speed playback, press the PLAY (

✎

NOTE

) button.

`The product does not play sound in Step mode.

) button, a

<HDD>

Tools

Title Search 1/3

Time Search : 00:24/01:46

Repeat Mode : Off

Picture Settings

Audio Language : 1.English

Dual I II : Dolby Digital

Detailed Information

= Number < Adjust e Exit

NOTE

✎

`Depending on the disc, the Tools menu may differ.

Moving to a Desired Scene Directly

ThzZyx

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Title Search, Chapter Search, or Time Search.

Press the ◄► or number button to select desired Title, Chapter or Time, then press the ENTER button.

English 57

Basic Functions

Repeating the Title or Chapter

hzZy

To repeat the disc title or chapter. Depending on the disc, the Repeat function may

not be available.

1. During playback, press the TOOLS

button.

Press the ▲▼ buttons to select Repeat Mode.

Press the ◄► buttons to select Chapter or Title, then press the ENTER button.

To return to normal play, press the TOOLS button again.

Press the ▲▼ buttons to select Repeat Mode.

Press the ◄► buttons to select Off, then press the ENTER button.

Repeating the Title or Chapter

Repeat the disc title or all. Depending on the disc, the Repeat function may

not be available.

1. During playback, press the TOOLS

button.

2. Press the ▲▼ buttons to select Repeat Mode, then press the ◄► buttons to select Title or All.

3. To return to normal play, press the TOOLS

button again.

4. Press the ▲▼ buttons to select Repeat Mode.

5. Press the ◄► buttons to select Off, the press the ENTER button.

Repeating a Section

hzZy

1. During playback, press the TOOLS

button.

Press the ▲▼ buttons to select Repeat Mode.

3. Press the ◄► buttons to select Repeat A-B, then press the ENTER button.

4. Press the ENTER button at the point where

you want repeat play to start (A).

5. Press the ENTER button at the point where you want repeat play to stop (B).

6. To return to normal play, press the TOOLS button again.

Press the ▲▼ buttons to select Repeat Mode.

8. Press the ◄► buttons to select Off, and then press the ENTER button.

NOTE

✎

`If you set point (B) before 5 seconds has lapsed, a

prohibition message appears.

`Depending on the disc, the menu items may differ

and this menu may not be available.

Selecting the Picture Settings

ThzZy

This function enables you to adjust video quality when the product is connected to a TV.

1. During playback, press the TOOLS button.

2. Press the ▲▼ buttons to select Picture Settings, and then press the ENTER button.

3. Press the ◄► buttons to select the desired Picture Settings, and then press the ENTER

button.

• Dynamic : Choose this setting to increase

Sharpness.

• Normal : Choose this setting for most

viewing applications.

58 English

• Movie : This is the best setting for watching

movies.

•

User : Lets you adjust the advanced settings.

NOTE

✎

`When you use BD wise function, this menu will not

appear.

Selecting the Subtitle Language

ThZx

You can also operate this function by pressing the AD/SUBTITLE button on the remote control.

06 Basic Functions

Selecting the Audio Language

ThzZx

You can also operate this function by pressing the AUDIO button on the remote control.

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Audio.

Press the ◄► buttons to select the desired audio language.

NOTE

✎

`The ◄► indicator will not appear on the screen

if the BONUSVIEW section does not contain any BONUSVIEW audio settings.

`Information about the main feature/BONUSVIEW

mode will also appear if the Blu-ray Disc has a BONUSVIEW section. Press the ◄► button to switch between main feature and BONUSVIEW audio modes.

`The languages available through the Audio Language

function depend on the languages that are encoded on the disc. This function or certain languages may not be available.

`A Blu-ray Disc can contain up to 32 audio languages

and a DVD up to 8.

`Some Blu-ray Discs may allow you to select either

the PCM or Dolby digital audio soundtrack in English.

`If you press the AUDIO button on the remote control,

Audio bar appears. Press the RETURN button to remove the Audio bar.

1. During playback, press the TOOLS button.

2. Press the ▲▼ buttons to select Subtitle.

3. Press the ◄► buttons to select the desired

subtitle language.

NOTE

✎

`Depending on the Blu-ray Disc / DVD, you may be

able to change the desired subtitle in the Disc Menu. Press the DISC MENU button.

`This function depends on the selection of subtitles

that are encoded on the disc and may not be available on all Blu-ray Discs/DVDs.

`A Blu-ray Disc can contain up to 255 subtitle

languages and a DVD up to 32.

`Information about the main feature/BONUSVIEW

mode will also appear if the Blu-ray Disc has a BONUSVIEW section.

`This function changes both the primary and

secondary subtitles at the same time.

`The total number of primary and secondary subtitles

are displayed respectively.

`If you press the AD/SUBTITLE button on the remote

control, the subtitle bar appears. Press the RETURN button to remove the subtitle bar.

English 59

Basic Functions

Changing the Camera Angle

When a Blu-ray Disc/DVD contains multiple angles of a particular scene, you can use the ANGLE function.

1. During playback, press the TOOLS button.

2. Press the ▲▼ buttons to select Angle.

3. Press the ◄► buttons to select the desired

Angle.

Selecting the Information

This function enables you to check the contents information including the name and size, etc.

1. During playback, press the TOOLS

button.

2. Press the ▲▼ buttons to select the Detailed Information, then press the ENTER button.

Setting BONUSVIEW

The BONUSVIEW feature allows you to view additional content (such as commentaries) in a small screen window while the movie is playing. This function is only available if the disc has the BONUSVIEW feature.

1. During playback, press the TOOLS button.

2. Press the ▲▼ buttons to select BONUSVIEW Video or BONUSVIEW Audio.

3. Press the ◄► buttons to select the desired

BONUSVIEW.

NOTE

✎

`If you switch from BONUSVIEW Video, BONUSVIEW

Audio will change automatically in accordance with BONUSVIEW Video.

`2D contents are playing convert into 3D, bonusview

function is not available. (Depending on discs, black outline may be shown)

Listening to Music

Playing an Audio CD (CD-DA)/MP3

1. Insert an Audio CD (CD-DA) or an MP3 Disc.

• For an Audio CD (CD-DA), the first track plays automatically.

• For an MP3 disc, press the ▲▼ buttons to select Music, then press the ENTER button.

Audio CD (CD-DA)/MP3 Screen Elements

Music

TRACK 001

+ 00:13 / 00:43

Audio CD " Enter < Page / Tools ' Return

Displays the music information.

Displays the playlist.

Displays buttons available.

Shows the current play time/total play time.

Displays the current playback status.

Displays the repeated playback status.

2. Press the ▲▼ buttons to select the track you want to play, and then press the ENTER button.

TRACK 001

00:43

TRACK 002

03:56

TRACK 003

04:41

TRACK 004

04:02

60 English

AMG function

You can use AMG function to display the information of an Audio CD (CD-DA).

1. Insert an Audio CD (CD-DA).

If your disc has a CD information, the below pop-up screen will be displayed.

Music

+ 00:13 / 00:43

Audio CD " Enter < Page / Tools ' Return

CD Information

TRACK 001

Multiple items of CD information found.

Select the appropriate item of CD information.

Thinking of Paradise Shinhwa

TRACK 001

00:43

TRACK 002

03:56

TRACK 003

04:41

TRACK 004

04:02

2. Press the ENTER button.

The CD information will be displayed and the first track will be played automatically.

NOTE

✎

`When the product is disconnected from the network,

it may not retrieve the CD information from the Audio CD (CD-DA) if it's the latest version.

Repeat an Audio CD (CD-DA)/MP3

1. During the Playlist playback, press the TOOLS button.

2. Press the ▲▼ buttons to select Repeat Mode, and then press the ◄► buttons to

select the desired repeat mode.

3. Press the ▲▼ buttons to select Shuffle Mode, and then press the ◄► buttons to select the On or Off.

4. Press the ENTER button.

Off

) One Song The current song is repeated.

(

) All All songs are repeated.

(

) Shuffle

(

Mode

Songs are played in the order in which they were recorded.

The random option plays songs in random order. To operate this function, please set the shuffle mode to On.

Playlist

1. Insert an Audio CD (CD-DA) or an MP3 Disc.

• For an Audio CD (CD-DA), the first track plays automatically.

• For an MP3 disc, press the ▲▼ buttons to select Music, then press the ENTER button.

To move to the Music List, press the STOP ( ) or RETURN button. The Music List screen appears.

3. Press the YELLOW (C) button.

4. Press the ▲▼◄► buttons to move to a

desired track, and then press the ENTER button. A check appears on the track. Repeat this procedure to select additional tracks.

Audio CD | Music

 Close Edit Mode

5. To remove a track from the list, move to the track, and then press the ENTER button again. The check on the track is cancelled.

6. When done, press the TOOLS button.

TRACK 001
