Sagem MYX-2 User Manual

Couverture My-X2.fm Page 1 Lundi, 26. mai 2003 11:09 11

You have just purchased a SAGEM mobile phone

, and we congratulate you on your choice.

Your phone can be used inter nationally in t he various dual band networks (GSM 900 MHz and 1800 MHz DCS) depending on the roaming arrangements with your operator.

We remind you that this phone is approved to meet European standards.

We recommend that you read this handbook carefully before using your phone efficiently and in the best conditions.

WARNING

Depending on the confi guration of the net works and the associated su bscriber cards, some func tions may not be available.

Ensure that yo ur SIM car d is a 3 V (Volt) SIM type that i s compatible with your phone. Inserting an incompatible card will be indicated by a message when your phone is switched on. Contact your operator.

SAGEM is a trademark of SAGEM SA. AT is a registered trademark of Hayes Microcomputer Products Inc. Hates is a registered trademark of Hayes Microcomputer Products Inc. T9™ Text Input is a registered trademark of ©Tegic Communications Inc. T9 is protected by one or more of the f ollowi ng US patents : 5, 818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and other patents are being applied for worldwide.

My-X2 English.book Page 1 Lundi, 26. mai 2003 10:45 10

CE Conformance Document

SAGEM SA declare under its sole responsibility that the product Dual Band GSM/DCS Type B2003 conforms to the requirements of the fo llowing EEC directives:

EEC Directive 1999/5/CE Safety EN 60950 EMC EN 301 48 9- 1

Low voltage directive 73/23/CEE Network 3GPP TS 51.010-1 v 5.2.0 selected with GCF-CC v 3.10.0 included

Health EN 50360

EN 301 48 9- 7

Requirements GT01 v 4.7.0 TBR 1 9 Edition 5 TBR 2 0 Edition 3 TBR 3 1 Edition 2 TBR 3 2 Edition 2 EN 301 41 9- 1 EN 301511

EN 50361

My-X2 English.book Page 2 Lundi, 26. mai 2003 10:45 10

Menus

Phonebook

Phonebook menu

Messages

Compose Inbox Drafts Options Memory

WAP

Picture puzzle

Sounds

Ring tones Vibrate Silent mode Beeps

Background

Colours Wallpapers Screensavers Greetin g msg

Settings

Date/T ime My objects Languages Networks Contrast Energy saving Shortcuts Reset s ettings

Calls

Calls for warded View la s t calls Counters Display number Call waiting Auto redial Answer phone number Local in fo

Security

Keypad locking PIN number PIN number 2 Phone code Confidentiality Operator Call bar ring Fixed dia lling

Accessories

Calculator Converter Alarm Timer Car kit Data

Services

My-X2 English.book Page 3 Lundi, 26. mai 2003 10:45 10

Page 2 MENUS Page 7 DESCRIPTION Page 8 PRINCIPLES OF NAVIGATION Page 9 HOME PAGE Page 10 ACTIVATING YOUR PHONE

Page 15 MY PHONE IN 5 MINUTES

Page 19 FIRST SETTING: RING TONE

Page 21 PHONEBOOK

Page 26 MESSAGES

Information on the SIM card Installing the SIM card and installing the battery Changing the cover Charging the battery Do NOT obstruct the antenna with your fingers

Getting started PIN Number Setting time and date Network First call Receiving a call Switching off

Volume and ring tone

Using the phonebook Phonebook menu Phonebook menu Call groups

Composing messages Receiving messages Inbox Drafts Sending options Memory

My-X2 English.book Page 4 Lundi, 26. mai 2003 10:45 10

Contents

Page 32 WAP

The WAP Menus Configuring WAP parameters WAP Logging on Downloading objects WAP Logging off

Page 35 GAMES

Page 36 SOUNDS

Picture puzzle

Volume and ring tone Vibrate Silent mode Beeps

Page 38 BACKGROUND

Colours Wallpapers Screensavers Greeting message

Page 40 SETTINGS

Date / Time My Objects Languages Networks Contrast Energy saving Shortcuts Reset Settings

Page 44 CALLS

Forward calls View last calls Counters Display number Call waiting

My-X2 English.book Page 5 Lundi, 26. mai 2003 10:45 10

Contents

Automatic redial Answer phone number

Page 49 SECURITY

Page 53 ACCESSORIES

Page 57 SERVICES Page 58 TECHNICAL FEATURES Page 60 WARRANTIES Page 63 TROUBLESHOOTING Page 66 INDEX

Local info

Keypad locking PIN number PIN number 2 Phone code Confidentiality Operator c ode Call barring Fixed dialling

Calculator Converter Alarm Timer Car kit Data

My-X2 English.book Page 6 Lundi, 26. mai 2003 10:45 10

Your phone package - Accessories

When you open the box, check th at all the items are present: 1 - Phone

2 - Mains charger 3 - Battery 4 - User manual

Accessories

You can also find (a s an option) or order the f ollow ing accessories: Pedestrian kit (*) Extra battery Extra charger (*) Desktop suppor t (*) Cigar lighter adapter ( *) Colour cover Hands-free kit (*) Strap

For more information: www.planetsagem.com

(*) These accessor ies are id entical to the ones provided fo r the myX-3, myX-5 a nd myX-6 series.

My-X2 English.book Page 7 Lundi, 26. mai 2003 10:45 10

Description

Stop key:

Programmable keys and Shortcut keys

Hold down:

Stop

Press briefly:

In a call context: Rejects a call - h ung up In men u s: Return to home page.

Start key:

Press briefly: Starts phone

In call co ntext: Ca ll - reception of a call - hands-free mode

Left programmable key:

In home page: Access to certain functions ( shortcuts) In men u s: Cancel (or return) as indicated on screen During c all: Reduces volume

Right programmable key:

In home page: Access to certain functions ( shortcuts) In men u s: Accept, choose as shown on screen During c all: Increases volume

Top key:

Previous choice / increa se value / top

Down key:

Down choice / re duce value / down

Left key:

Up input field / mo ve left

Right key:

Down input field / move right

* Key :

Hold down: In home page: Silent mode Press brief ly keypad locking In call reception mode: Short press stops ring tone In ring tone settin g mode: Activates /d eactivates ring ton e

# Key:

Zoom mode (see message and WAP menus)

OK (right programmab le key)

activates or deactivates

V olum e and ring tone

My-X2 English.book Page 8 Lundi, 26. mai 2003 10:45 10

Principles of navigation

These basic principles bring a great deal of intuitiveness to your telephone

All the active areas on a white background (icon selector, programmable keys, menu sele cto r, ch oice list)

by pressing the

Cancel

by pressing the

right programmable key left programmable key

1st level

ounds

2nd level

olume and ring ton

3nd level

The tabs on the side s at the bottom of the screen r efer to the

(and not to the le ft/right key s).

keys

In the menus a t itle ba r indic ate s t he down higher level.

The

down / top

menu to the down within the same menu structure.

The

right programmable ke y

menu. The

left programmable key

The first menu level can be identified by a large animated icon in the centre of the screen.

The second m enu leve l can be iden tified by a large s tatic icon in the centre o f the screen.

The lowest sub-menus are lists.

The

Stop

function is abando ned).

na vigat ion ke ys are us ed to nav igate from one

is used to go from a menu to a sub-

is used to go from a sub-m enu to a m enu .

key (press briefly) is used to return to the hom e page (cu rrent

Programmable

My-X2 English.book Page 9 Lundi, 26. mai 2003 10:45 10

Home page

The home page contains the following

1 - The title bar icons:

Fri 3 May

Battery Calls forwarded Call (establishing th e call) Call (hands free) SMS (reception of an SMS) Silent mode Message in answer phonebox WAP (@) Home zone HPLMN / roaming Keypad locking + WTLS (exclusive functions) Protected WAP logon Protected WAP logon icon with certificate Signal strength level (5 bars).

2 - Date and time 3 - Network provider 4 - Tab centred on down line:

the main "menu" tab shows that the menu can be accessed via the

down / up

The following information may also be displayed: "1 message re ceived"; or "1 call". They can be deleted by pressing

, in digital or analogue mode

keys.

Stop key briefly.

My-X2 English.book Page 10 Lundi, 26. mai 2003 10:45 10

Activating your phone

Information on the SIM card

To use your phon e, yo u have a s ma rt c ard called a SIM card . It cont ains all the informati on needed by t he network as well as other information unique to you and that you can modify:

Secret codes (PIN(s): Personal Identification Numbers), these codes allow you to restrict access to your SIM card.

Phonebook, Messages, How sp e cial services work.

Your phone is compatible with the different SIM cards offered by operators.

It is also compatible with the SIM/WIM cards (cards containing the WIM module in addition (WIM = Wireless Identity Module) that is used for secure WAP communications.

WARNING This card must be handled and sto red wit h care to avoid damaging it by sc raping or bending i t. If y ou

should lose your SIM card, contact your operator or your SMC (Services Marketing Company) immediately. Comment: do not leave your SIM card within the reach of young children.

123

My-X2 English.book Page 11 Lundi, 26. mai 2003 10:45 10

Activating your phone

Installing the SIM card and installing the battery

The SIM card is inserted under the phone's battery. Ensure that the phone is switched off and the charger disconnected.

Turn phone over and remove rear cover by lifting bottom end first.

Take o u t battery if already installed.

Slide card fully u nder re tainin g pla te with gold- plate d cont acts facing phone and bevelled corner pointing as shown on drawing of phon e.

Insert ba tte ry in to p os ition b y firs t p os ition in g to p s ec tio n with connectors.

Replace c over by engagin g top ho ok fir st, t hen push down back of rear cover.

My-X2 English.book Page 12 Lundi, 26. mai 2003 10:45 10

Activating your phone

Changing the cover

Remove rear cover as above.

Turn phone over.

Lift front cover in same way as rear cover. Remove panel

(electronic card).

Position k eypad in new co v er, ensuri n g it is free of dust.

Insert pa nel into fro nt cover.

Do as above t o r eplace rear cover.

My-X2 English.book Page 13 Lundi, 26. mai 2003 10:45 10

Activating your phone

Charging the battery

Your phone is powered by a rechar geable batte ry. A new batter y must be char ged for 4 ho urs at lea st before b eing used for th e firs t tim e. It rea c h es its o pt imu m capacit y a fte r a few cycles of use. When your battery has been discharg ed, the phone displays the state (empty battery icon flashes). In this case recharge your battery for at least 15 minutes before making any more calls so as to avoid being cut off mid-call.

To recharge the battery:

Connect the cha rg er to a mains socket. Plug the end of the cable into the connector at the base of the phone.

The phone starts to charge up, the battery charging light flashes to indicate charging. Charging stops by itself. Disconnect the cable . It is possible that the battery may heat up slightly during charging; this phenomenon is norma l.

WARNING

There is danger of explosion if the battery is replace d in correctly or if it is exposed to fire. Do not short circuit it. The battery does not have any part that you can change. Do not try to ope n the battery cas i n g. Use only the appropriate chargers and batteries shown in the manufacturer's catalogue. Used batteries m ust be disposed of in th e appropriate places. It is adv is a ble to re move the battery if y our pho n e is not used for e x tended periods.

My-X2 English.book Page 14 Lundi, 26. mai 2003 10:45 10

Activating your phone

Do NOT obstruct the antenna with your fingers

The antenn a is integrat ed in your phone, under the back cover a t the top.

Avoid putting your fingers on this area when the phone is switched ON.

If your fingers obstruct the antenna, the phone may have to operate with a higher power level than usual; decreasing its efficiency quickly. It could also affect the quality of your communications.

WARNING

The use of a hands-free kit is recommended when using the phone frequently.

My-X2 English.book Page 15 Lundi, 26. mai 2003 10:45 10

My phone in 5 minutes

Getting started

PIN Number

PIN number?

***

Delete OK

WARNING

If a wrong PIN number is entered three tim e s in succession, your SIM card is blocked. You must the n:

- Enter "**05*".

- Enter the PUK (Personal Unblocking Key) code provided by your operator, and accept.

- Enter your PIN number and accept.

- Enter your PIN number again and accept. After 5 or 10 failed attem pts ( depe nd ing on the type o f SIM card), th e SI M c ard is de finitely locked . You m us t then contact your operat or or your SMC to obtain a new card.

You are now ready to use your phone for the first time.

Switch on the phone by pressing the

This is your SIM's secret code.

If access to the SIM card is protected, the device prompts you to enter the PIN n um be r:

Enter the code

issued. These digits do not appear on the screen for security reasons. Press the

If your phone indicates that the SIM is missing, press the switch off your phone and check that the SIM card is correctly installed.

between 4 and 8 digits given to you when the SIM card was

right programmable key

Start key. A short display appears.

to accep t.

Stop

key to

Time and date

My-X2 English.book Page 16 Lundi, 26. mai 2003 10:45 10

Setting time and date

Date valid?

Friday

03 May 2002

Cancel OK

When you use your phone for the first time, you need to set the date and time. In due course, when the battery is completely discharged, or if it has been

removed, you will be prompted systematically to confirm date and time.

Setting the date:

Set the date by entering it directly in numerical form or by using the

keys to decrease or increase the default values.

Use the

right key

field. Once the date is correct, press the

Setting the time:

(or left key ) to access the

Same procedure as for setting the date.

right programmable key

(or last ) data inp ut

Network

From now on the phone hunts for a network on which it can make calls. If it finds one, it di spla ys the na me of the ne twork on the scr een. You are the n ready to send or receive a call.

If the network icon appears, calls are possible on your operator's netwo rk . If the letter R and a network name are displayed, calls are possible on the network of a different operator. If the l e t te r R i s di sp l ay ed wi t hou t an y ne two r k na me, on ly t he e mer genc y ser vi c es a re ac ces s ibl e (a mb ula nc e, police, fi re brigade ). If the ne twor k i con fl ashe s, t he ph one i s in pe rmane nt s earc h mode. Th ere i s no networ k av ail abl e. Th e si gnal strength indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better reception in order to call in good conditions.

down

My-X2 English.book Page 17 Lundi, 26. mai 2003 10:45 10

First call

Dial the number of your correspondent. Press the

Start key.

During the call, the call in progress icon flashes on screen and tones may indicate the establishment of the call.

Once communication has been established, the call icon stops flashing.

You can adjust the sound level (volume) using the

programmable

At the end of the conversation press the

Internation al ca ll

Press 0 (hold down ) to display "+", then dial the cou ntry code withou t wa iting for the d ial tone, then the nu mb er of the called party.

Emergenc y se rvices

Depending on the operators you can obtain the emergency service with or without SIM card or when the keypad is locked. It is enough to be in an area serve d by a network. To obtain the international emergency service, dial

112

then press the

keys

Start key.

Stop

key to hang up.

left

and

right

My-X2 English.book Page 18 Lundi, 26. mai 2003 10:45 10

Receiving a call

When you receive a call, the number of your correspondent is displayed when it is presented by the network.

Call from

0605030401

Busy

Select

Press the answer, and speak.

To refuse the call, press the

To stop the ring tone or the vibrate, without refusing the call, press the key.

All the numbers corresponding to incoming and outgoing calls are logged in the list of recent calls.

Start

key or the

WARNIN G:

Pressing the Start key a sec ond ti me lau nches han ds-f re e mode, in this mode do not bring the phone up to your ear.

Switching off

Press the Stop key for one second. The end message is displayed. The phone switches off.

right programmable key

Stop key or the

left programmable key

My-X2 English.book Page 19 Lundi, 26. mai 2003 10:45 10

First setting: Ring tone

We want to familiarise you with the interface of your new phone, using a simple setting: choosing a ring tone and adjusting the volume.

Volume and ring tone

Messages

This menu allows you to a llocate a rin g tone to e ach type of event .

In the

home page

The first menu offered is Press the

Enter

this menu by pressing the

, press the

down key four times to access the

down

key to access the main menus.

Phonebook

right programmable key

Sounds

menu.

You can access the menus: Ring tones, Vibrate, Silent mode, beeps.

The first sub-menu offered is

Enter

by pressing the

second level

right programmable key

of the menu that cont ains four sub-

Ring tones

My-X2 English.book Page 20 Lundi, 26. mai 2003 10:45 10

Draft

With the hel p of the function where you want to change the ring tone from the proposed list (Alarm, Calls, Messages and Fax) and accept.

Enter

by pressing the

Using the

down

offered.

Enter

by pressing the

For every new selection, you will hear the corresponding ring. If required, press the

Adjust the volume using the The volume is adjusted over a scale of 1 to 4.

The ring tone is played at the chosen level whenever a change is made. You can select "+"

to a crescendo.

by pressing the

down

up keys select the type of

right programmable key

/ up keys select the ring tone from the list

right programmable key

Silent mode key to cancel the sound.

down

volume

to choose a ring that star ts qui et ly and ri ses

right programmable key

keys.

+ 48 hidden pages
